Users Manual
SGH-A827 Series
PORTABLE Quad-BAND
MOBILE PHONE
User Manual
Please read this manual before operating your
phone, and keep it for future reference.
DRAFTDRAFT
FT
F
A
A
R
DR
D
a827_UCGJ4_JS_111307_d2
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the
SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and
protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions
(patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of
authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will
not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the
software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with
SAMSUNG and its suppliers.
Samsung Telecommunications America (STA), LLC
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein St.
Richardson, TX 75082 Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Internet Address: http://www.samsungusa.com
©2007 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc. and its related entities.
Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsungwireless.com/support
GHXX-XXXXX
Printed in XXXXXX (Korea or China) ????
Licensed by Qualcomm Incorporated under one or more of the following patents: U.S.
Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5, 101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390.
xxxxx Openwave® is a registered Trademark of Openwave, Inc. xxxxxxxx
XXXX Enter your own Copyright INFORMATION -- SEE MARKETING FOR BOX VERBAGE xxxxxx
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES
THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT,
INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS
CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT
PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF
ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
1
Table of Contents
Section 1: Getting Started ..................................................4
SIM Card Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Install Battery and SIM and Charge the Phone . . . . . . . . . . . . . . . .4
Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installing the microSD™ Card . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Turning the Phone On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Section 2: Understanding Your Phone ...............................9
Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Side/Back View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Multitasking Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Selecting Functions and Options . . . . . . . . . . . . . . . . . . . . . . . . .16
Command Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Section 3: Call Functions ..................................................19
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Video Share . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Recent Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Call Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Data Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Data Call Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Options During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Section 4: AT&T Mobile TV with FLO™ for Samsung Viewer
Guide .................................................................................. 31
Welcome to AT&T Mobile TV with FLO™ . . . . . . . . . . . . . . . . . . . 31
To subscribe to AT&T Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using the Mobile TV Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using the Program Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Want more? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Section 5: Cellular Video .................................................. 36
Cellular Video Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Media Clip Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using the Video Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Customizing Cellular Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
My Purchases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Section 6: Entering Text ................................................... 42
Text Input Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Using the T9 Input Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Alphabet Input Method . . . . . . . . . . . . . . . . . . . . . . . . . 45
Using the Symbols Input Method . . . . . . . . . . . . . . . . . . . . . . . . 45
Using the Numeric Input Method . . . . . . . . . . . . . . . . . . . . . . . . . 46
2
Section 7: Messaging ....................................................... 47
Types of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Display Icons for Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Creating and Sending Text Messages . . . . . . . . . . . . . . . . . . . . . .48
Creating and Sending Multimedia Messages . . . . . . . . . . . . . . . .50
Locating a Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Using Message Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Using Instant Messenger (IM) . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Signing into Your Mobile Email . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Signing into Your IM Account . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Using Message Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Deleting Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Messaging Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Section 8: MEdia Net and WAP .........................................61
Accessing the MEdia Net Home . . . . . . . . . . . . . . . . . . . . . . . . . .61
Accessing a MEdia Net Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Navigating with the WAP Browser . . . . . . . . . . . . . . . . . . . . . . . .62
Using Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Downloading Multimedia Files . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Using your History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Clearing Caches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Clearing the Cookies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Changing the WAP Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Section 9: AT&T Mall ........................................................69
Shop Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Shop Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Shop Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Shop Multimedia Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Shop Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Accessing the MEdia Net Home . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Section 10: AT&T Music ................................................... 72
Accessing AT&T Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Using the Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Playing Music while Multitasking . . . . . . . . . . . . . . . . . . . . . . . . . 76
Using Playlists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Using MusicID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Streaming Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Music Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
The Buzz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Music Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Section 11: Using the Applications .................................. 85
Shop Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Using the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Using the Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Record Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Appointment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
3
Section 12: Understanding Your Address Book ............. 101
Using Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Address Book Entry Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Adding a New Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Dialing a Number from the SIM Card using the Location Number 105
Speed Dial List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Finding My Own Phone Number . . . . . . . . . . . . . . . . . . . . . . . . .106
Using FDN Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Group Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Managing Address Book Entries . . . . . . . . . . . . . . . . . . . . . . . . .108
Checking the Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Using the Service Dialing Numbers . . . . . . . . . . . . . . . . . . . . . . .109
Section 13: Changing Your Settings .............................. 110
Quick Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Set Sound Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Set Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Set Time & Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Set Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Set Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Set Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Set Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Reset Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Set Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Phone Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Section 14: Accessibility ................................................ 129
Section 15: Health and Safety Information ................... 130
Health and Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Samsung Mobile Products and Recycling . . . . . . . . . . . . . . . . . . 131
UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Consumer Information on Wireless Phones . . . . . . . . . . . . . . . . 132
Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Responsible Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Using Your Phone Near Other Electronic Devices . . . . . . . . . . . . 141
FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices
142
Potentially Explosive Environments . . . . . . . . . . . . . . . . . . . . . . 144
Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Other Important Safety Information . . . . . . . . . . . . . . . . . . . . . . 145
Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Availability of Various Features/Ring Tones . . . . . . . . . . . . . . . . 147
Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . . . . . . . 147
Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Section 16: Warranty Information ................................. 150
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Index ................................................................................ 155
Getting Started 4
Section 2: Getting Started
This section describes the first steps to operating your phone.
SIM Card Information
When you subscribe for 3G cellular network services, you receive a
plug-in SIM (Subscriber Identity Module) card loaded with your
subscription details, such as your PIN and available optional services.
Install Battery and SIM and Charge the Phone
1. If necessary, power-off the phone by holding down the
key until the power-off image displays.
2. Remove the battery by pressing the battery lock down and
sliding the battery cover away, as shown.
Inserting and Removing the SIM card
Important!:
The plug-in SIM card and its contacts can be easily damaged by scratches or
bending. Use caution when inserting or removing the card, and keep all SIM
cards out of reach of children.
Make sure the gold contacts of the card are face down, then slide the
SIM card into the socket.
Installing the Battery
1. Align the battery tabs with the slots at the bottom of the
phone.
5
2. Press the battery down until it clicks into place.
3. With the battery in position on the phone, place the cover
back on the handset and slide it in until it clicks.
Important!:
Make sure that the battery is properly installed before switching on the
phone.
Charging a Battery
Your phone is powered by a rechargeable Li-ion battery. Use the travel
adaptor to charge the battery, and use only Samsung approved
batteries and chargers.
Note:
You must fully charge the battery before using your phone for the first time. A fully
discharged battery requires up to 4 hours of charge time.
Note:
For connection to an electrical supply not located in the U.S., you must use an
adaptor of the proper configuration for the power outlet. Use of the wrong adaptor
could damage your phone and void your warranty.
1. Plug the connector of the travel adaptor into the jack on the
side of the phone.
Note:
The previous illustration shows both the correct and incorrect method for
connecting the charger. If the incorrect method is attempted, damage to the
accessory port will occur therefore voiding the phone’s warranty.
2. Plug the adaptor into a standard AC wall outlet.
Important!:
The battery charging function may stop if you are on a call or viewing a
streaming-video while charging your battery.
+
Incorrect
Correct
Getting Started 6
3. When the phone is completely charged (the battery icon is
not animated), unplug the adapter from the power outlet.
4. Remove the adapter from the phone by gently pulling the
connector out.
Note:
You must unplug the adaptor before removing the battery from the phone during
charging to avoid damage.
Installing the microSD™ Card
To add additional memory to your phone you can insert a microSD™
card into the side of the phone. Use the following instructions and
illustrations for proper insertion and removal.
1. Open the side slot to insert the card. Place the microSD™
card into the slot.
2. Push the microSD™ card into the slot until it clicks into
place.
Note:
Please note that the side with the metal connectors should be facing down when
inserting the card.
3. To remove the card, a quick press releases the card from
the slot.
7
Note:
The handset supports micro-SD cards of up to 4GB.
Low Battery Indicator
When the battery is weak and only a few minutes of talk time remain,
a warning tone sounds, the “Battery Low” message repeats at regular
intervals on the display, and the empty battery icon blinks. The
backlight turns off to conserve the remaining battery power.
Note:
If your phone is in Silent Mode, the Low Battery Indicator defaults to Vibration (see
“Other Available Profiles” on page 112.). If you change the alert from Vibration to
Mute, you will only see a flashing message indicating a low battery.
If the battery level becomes too low, the phone automatically turns off.
Recharge your battery.
Turning the Phone On or Off
1. Press and hold the key until the phone power-on
screen displays.
Note:
Do not turn on the phone when mobile phone use is prohibited.
2. If the phone asks you to enter a password, enter a
password and press the
Confirm
soft key or the key.
For more information, refer to “Set Phone” on page 115.
The phone searches for your network and after finding it,
the Idle screen displays. Now, you can make or receive
calls.
Note:
The display language is preset to Automatic at the factory. To change the language,
use the
Language
menu. For more information, refer to “Set Phone” on page 115.
3. When you wish to switch off the phone, press and hold the
key until the power-off image displays.
Getting Started 8
Setting Up Your Voice Mail
Note:
If your service provider did not pre-configure your voicemail server number, you will
needto store the voicemail server number before accessing the server. Your service
provider can give you the number.
To access you voice mail from your keypad, use the following steps:
1. Press and hold .
2. Follow the voice mail prompts to the Voice Mail main menu,
then select option 4 to set up your voice mail personal
options:
•
Turn Notification On/Off
•
Change Administrative Options
•
For Greeting or Recorded Name
•
Change Notification Options
Changing the Voice Mail Name and Number
The SIM card gives you default service number of the voice mail
center. However, you may need to change the number. Use the
following procedures to change your voice mail number.
1. Select
Menu
➔
Recent Calls
➔
Voice Mail
➔
Voice Server
Number
➔
Voice Server Name
. Press .
2. Press the
Edit
soft key. Press .
3. Locate the current voicemail number in the Center Address
field and press to delete the current number.
4. Enter your new Voicemail number. Press .
5. Press the key to return to Idle mode.
9
Section 3: Understanding Your Phone
This section outlines some key features of your phone. It also displays
the screen and the icons that are displayed when the phone is in use.
Features of Your Phone
Your phone is lightweight, easy-to-use and offers many significant
features. The following list outlines a few of the features included in
your phone:
•
User friendly, menu-driven access to features and options
•
Bluetooth wireless access
•
Camera and camcorder
•
AT&T Mobile TV
•
Video Sharing
•
Instant Messaging capability
•
E-mail
•
Featured applications provide alarms, calendar, calculator, record audio,
converter, timer, stopwatch, and world time.
•
File viewer
•
Multimedia Message Service (MMS)
•
Multimedia capability (with included Music Player)
•
Photo caller ID
•
Speakerphone capability
•
Web browser
Front View of Your Phone
The following illustrations show the main elements of your phone:
1
2
4
3
5
6
7
8
910
11
12
13
14
15
16
17
18
19
Understanding Your Phone 10
Slots, Controls and Keys
The following list correlates to the open and front view illustrations.
1.
Headset Jack Adapter
: Allows you to plug in the travel
adapter (power), PC connection cable (data transfer), and
optional headset for safe, convenient, hands-free
conversations.
2.
Display Screen
: This screen displays all the information
needed to operate your phone.
3.
Volume key
: This key allows you to turn up or down the
volume of the speaker. The volume key can also be used to
scroll up or down to navigate through the different menu
options. To mute the ringer during an incoming call, press
the volume key up or down. Press and hold these keys to
toggle the display on or off. This key is also used when the
Music Player is active.
4.
Navigation keys
: This key allows you to scroll through phone
menu options and provides a shortcut to phone functions
from standby mode.
5.
Mobile TV key
: Allows you to access the Mobile TV
subscription service.
6.
Left soft key
: Performs the functions indicated by the screen
text on the bottom of the display.
7.
Send key
: Allows you to place or receive a call. In standby
mode, press the key once to access the Recent Call log. If
you press and hold the key down, you will initiate the most
recent call from the Recent Call log.
8.
Voice Mail key
: Press and hold the key to
automatically dial your voicemail.
9.
Special Function keys
:
Asterisk/Shift
key - enters the [*]
character for calling features. In text mode, press to change
the character input type.
Pound/Space
key - enters the
pound [#] character for calling features. In text entry mode,
press to enter a space between characters.
Press and hold the key to activate/deactivate the
Silent profile. Press and hold to enter a pause between
numbers.
10.
Microphone
: Allows the other callers to hear you clearly
when you are speaking to them.
11
11. Alphanumeric keypad: Use these keys to enter numbers,
letters and some special characters. When in Idle mode,
press and hold the key to access your voicemail
server or press and hold to enter an International call
prefix.
12. End/Power on/off/Menu Exit key: Ends a call. Press and
hold the key for a few seconds to power your phone
On or Off. While in the main menu, it returns the phone to
standby mode and cancels you input. When you receive an
incoming call, press to reject call.
13.
Right soft key
: Performs the function indicated by the screen
text on the bottom of the display.
14.
Clear key
: Deletes characters from the display when you are
in text entry mode. Deletes items when in an application.
When in a main menu, press to return to the previous menu.
A quick press of the key displays the Calendar in Month
view.
15.
Multitasking key
: Opens the application switch window
which allows you to select from a group of different
applications without having to exit from the currently active
application. These options include making a voice call, text
messaging, MEdia Net launch, launching the music player,
accessing games and applications, or end multitasking.
16.
Camera
: Activates the camera shutter.
17.
Menu access/Confirm key (WAP browser)
: When navigating
through a menu, pressing the accepts the highlighted
choice in the menu. If you press once in Idle mode, the WAP
browser will launch.
18. Memory Card slot: Used to install an optional microSDTM
card for additional data storage.
19.
Earpiece/Speaker
: Used to listen to audio and music from
your phone.
Understanding Your Phone 12
Side/Back View of Your Phone
Slots, Controls, and Keys
The following list correlates to the back and side view illustrations.
1.
Camera lens
: Allows you to take pictures and shoot video.
2.
Headset jack/Adapter jack
: Allows you to plug in the travel
adapter (power), optional PC connection cable (data
transfer), and optional headset for safe, convenient, hands-
free conversations.
3.
Volume keys/Menu Navigation
: Allows you to adjust the
ringer volume in standby mode or adjust the voice volume
during a call. To mute the ringer during an incoming call,
press the up or down volume key.
The volume keys can also be used to scroll up or down to
navigate through the different menu options.
This key is also used when the Music Player is active.
If you are playing music and the backlight goes out, you will
need to press and hold this key to gain access to the music
player keys when the flip is closed.
4.
Memory Card slot
: Used to install an optional microSD™
card for additional data storage.
5.
Camera Shutter/Multitasking
: The “up” side of this rocker
key is the camera shutter, when the camera or camcorder is
activated. The “down” side of the rocker key activates the
Multitasking menu.
1
2
3
4
5
13
Display Layout
The display has 3 areas:
1.
Icons bar
: displays the various phone icons, representing
such items as messages received, battery strength, signal
strength, and profile set.
2.
Text and Graphic area
: displays the area where text input
occurs, and where graphics display.
3.
Soft Key indicators
: displays the specific usage of the soft
keys. These indicators will change within menus and
functions.
Icons
Menu Options
3
2
1
tv
tv
pm12:13
12:13
Nov 8
Nov 8
Thu
Thu
Shows the received signal strength. The greater the number
of bars, the stronger the signal.
Appears when the phone is accessing services in a GPRS
network. When data is being transferred, this icon animates.
Appears when the phone is accessing services in an EDGE
network. When data is being transferred, this icon animates.
Appears when the phone is accessing services in a 3G (UMTS)
network. When data is being transferred, this icon animates.
Appears when the phone is accessing services in a 3G+
(HSDPA) network. When data is being transferred, this icon
animates.
Appears when the signal network and signal strength are
present for Mobile TV reception.
Appears when a TTY adapter is plugged into the handset,
making it accessible via a keyboard for the hearing or speech
impaired.
tv
tv
Understanding Your Phone 14
Appears when a call is in progress.
Appears when there is no network coverage available. When
you are out of the service area, you cannot make or receive
voice calls.
Appears when an alarm is set on your phone.
Appears when the incoming alert is set to Vibration or when
the Silent profile is set to Vibration.
Appears when your incoming phone calls are being
forwarded to another number.
Appears when a new voice mail has been received.
Appears when a new text message or email has been
received.
Appears when a new multimedia message has been
received.
Appears when a push-messages has been received from the
WAP server.
Appears when a new Over the Air (OTA) software update file
has been received.
Appears after your memory card has been inserted.
Appears when Bluetooth wireless technology is active. It
appears a solid red until the connection is set, then changes
to a solid blue. When transferring data, this icon blinks red and
blue.
Appears when a Bluetooth wireless headset is active and in
use.
Appears when you are using the phone’s Music Player.
Appears when you are connected to a PC via a USB port.
15
Note:
The default phone profile is Normal, the profile is editable and the displayed icons
may vary according to the setting.
Back Light
A back light illuminates the display and the keypad when you press
any key. It turns off when no keys are pressed within a given period of
time, and/or dims the light, depending on the settings in the Backlight
Time menu.
Multitasking Menu
This menu is launched by pressing the Multitasking key on the right
side of your handset. This menu allows you to choose which tasks you
want to perform. The menu icons choices are as follows:
Appears when the phone’s profile is set to Silent. In this case,
the speaker is muted and displays incoming call or message
information on the LCD. This Speaker off icon is replaced on
screen by the Vibration icon when the Silent profile is
changed to Vibration instead of Mute.
Appears when the phone’s profile is set to Driving. In this
case, the speaker is active. In this case, the speaker is active
and will launch the currently selected ringtone or melody
when the associated notification is activated. This icon is
accompanied on screen by the Audio icon.
Appears when the phone’s profile is set to Outdoor. In this
case, the speaker is active, the volume settings are raised to
their highest levels, any currently active ringtones or
melodies are activated, and the phone’s vibrate feature is
activated.
Shows the level of your battery. The more bars you see, the
more power you have remaining.
Call
: allows you to make a voice call while using the handset
for other tasks. If Music Player is active, it is muted during the
call.
Messaging
: allow you to sent a text or multimedia message
while using the handset for other tasks.
MEdia Net
: allows you to launch the MEdia Net browser while
using the handset for other tasks.
Music Player
: allows you to launch the Music Player while
using the handset for other tasks. If an incoming call is
received, or you want to make a voice call, the Music Player
is muted until the call ends.
Understanding Your Phone 16
Selecting Functions and Options
Your phone offers a set of functions that can be customized for your
ease and specific needs. These functions are arranged in menus and
sub-menus, accessed using the two soft keys. Each menu and sub-
menu allows you to view and alter the settings of a particular function.
If you select the
Options
right soft key in Idle mode, the
following displays under the title of My Menu:
•
Bluetooth
: allows you to use the Bluetooth functionality of the handset.
•
Alarms
: allows you to set or alter alarm settings, including a Wake-up
Alarm.
•
Calendar
: allows you to access the Calendar application, where you can set
alarms, tasks, events, and reminders.
•
My Stuff
: allows you to quickly access your My Stuff folder which contains
items such as: Music, Video, Graphics, and Application files.
•
Empty
: (locations 5-12) allows you to program addditional frequently used
features. Select an empty slot and press the key. Use the
Menu
and
Navigation keys to select a feature, then press the
Assign
soft key or the
key.
In some functions, you may be asked for a password or PIN. Enter the
code and press the
Select
soft key or the key.
When you access a list of options, your phone highlights the currently
active option. If, however, there are only two options, such as
On/Off
or
Enable/Disable
, your phone highlights the option that is not currently
active, so that you can select it directly.
Selecting Options
To view the various functions and options available and to select the
one you want:
•
Press the appropriate soft key.
•
To select the function displayed or the option highlighted, press the
Select
soft key or the key.
•
To view the next function or highlight the next option on a list, press the
Down
Navigation key or the key on the left side of the phone.
•
To move back to the previous function or option on a list, press the
Up
Navigation key or the key on the left side of the phone.
•
To move back up one level in the menu structure, press the
Back
soft key.
•
To exit the menu structure without changing the settings, press the
key.
Games and Apps
: allows you to launch games or other
applications while using the handset for other tasks.
End All?
: allows you to end or cancel multitasking, and
returns the handset to single task usage.
17
Command Keys
Functions for the soft keys are defined by what appears above each in
the display. There are two soft keys, the left soft key and the
right soft key .
Soft Keys
The roles of the soft keys vary depending on the function you are
currently using; the labels on the bottom line of the display just above
each key indicate their current role.
Left Soft Key
Some functions of the left soft key are as follows.
•
IAt the Idle screen, the left soft key function is to launch the main
Menu
.
•
When in a menu mode, the left soft key function is
Select
. It may also
be the
OK
or
Confirm
function.
Right Soft Key
Some functions of the right soft key are as follows.
•
At the Idle screen, the right soft key function is to launch the
My
Menu
screen. See ‘Selecting Functions and Options” on page 18.
•
When in a menu mode, the right soft key function is
Back
or
Cancel
.
Clear Key
The CLR key is used to erase or clear numbers, text, or symbols
from the display. You can also use to return to a previous menu
or to return to standby mode from any menu.
•
At the Idle screen, a quick press displays the calendar in Month view.
•
If you enter an incorrect character, briefly press to backspace (and
delete) the character.
•
To erase the entire sentence, press and hold .
•
To back up one menu level, briefly press .
End Key
The
End
key is used to turn on/off your phone, disconnect calls,
and return to the standby mode.
•
Press and hold the to turn on/off your phone.
•
Briefly press once to disconnect a call.
•
Press to return to standby mode from any menu.
/HIW6RIW.H\
&RUUHVSRQGLQJ
/HIW6RIW.H\
6HOHFWLRQ
&RUUHVSRQGLQJ
5LJKW6RIW.H\
6HOHFWLRQ
5LJKW6RIW.H\
Understanding Your Phone 18
Send Key
The
Send
key is used to answer calls, dial calls, and to recall
the last number(s) dialed, received, or missed.
•
Press once to answer calls.
•
Enter a number and briefly press to make a call.
•
Briefly press in standby mode to display a list of recent calls to and
from your phone.
•
Press twice in standby mode to call the most recent number.
•
Press to pick up a waiting call.
Navigation Key
Use the directional keys on the Navigation key to browse menus, sub
menus, and lists. Press the
Up
or
Down
Navigation keys when jumping
to highlighted links on the web.
Each key also acts as a shortcut to launch applications from the Idle
screen.
OK Key
The key is used as an
OK
key during many menu selection
functions. It can also be used to complete many of the functions
instead of the soft keys. It also may function as the shutter key for the
camera.
Address Book
Choose Your
Community
Create New Message
My Stuff
19
Section 4: Call Functions
This section describes how to make or answer a call. It also includes
the features and functionality associated with making or answering a
call.
Making a Call
At the Idle screen, enter the area code and phone number, and press
the key.
Note:
When you activate the
Auto Redial
option in the Voice Call menu, the phone
automatically redials up to 10 times when the person does not answer the call or is
already on the phone.
Making an International Call
Press and hold the key. The + character displays.
Enter the country code, area code, and phone number, then press the
key.
Correcting an Entered Number
Use the following steps to correct a mis-typed entry when dialing.
1. After entering a number
•
To clear the last digit displayed, press the key.
•
To clear another digit in the number, press the
Left
or
Right
Navigation
key until the cursor is immediately to the right of the digit to be cleared.
Press the key.
•
To enter a missing digit press the
Left
or
Right
Navigation key until the
cursor is in position and enter the digit.
•
To clear the whole display, press and hold the key.
•
Press the key to return to the Idle screen.
Ending a Call
When you want to finish your call, briefly press the key.
Redialing the Last Number
All incoming, outgoing and missed calls are listed in the Recent Calls
Menu. If the number or caller is listed in your Address Book, the name
associated displays.
To access the
Recent Calls
menu:
1. In Idle mode, select
Menu
➔
Recent Calls
.
2. Use the
Up
and
Down
Navigation keys to scroll through the
Recent Calls options. Choose from
All Calls
,
Missed Calls
,
Calls Made
,
Calls Received
,
Voice Mail
,
Speed Dial List
,
Delete
All
,
Call Time
,
Data Volume
, or
Data Call Time
.
Call Functions 20
3. Highlight the number to select, and press the key; or
in Idle mode, press the key to display a list of the
most recent numbers used in the order you dialed or
received them.
4. Use the
Up
and
Down
Navigation keys to scroll through the
numbers until the number you want highlights.
5. To dial the number, highlight the number and press the
key.
Making a Call from the Address Book
You can store phone numbers that you use regularly on the SIM card
or in the phone’s memory. These entries are collectively called the
Address Book
.
Once you have stored a number in the
Address Book
, you can dial it by
pressing a few keys using the
Speed Dial
feature.
For further details about the
Address Book
feature, see “Finding an
Address Book Entry” on page 101.
Answering a Call
When a call is received, the phone rings and displays the caller’s
phone number, or name if stored in the Address Book.
1. In Idle mode, press the key. You may set other
options to answer an incoming call using the following:
•
If the
Any key
option in the
Menu
‘
Settings
‘
Set Calls
‘
General
‘
Call Answer
menu is activated, you can press any key to answer a call
except for the key .
Note:
To reject an incoming call, press and hold the
Volume
key on the left side of the
phone. A quick press of the
Volume
key silences the ringer on an incoming call.
2. End the call by pressing the key.
Note:
You can answer a call while using the Address Book or other menu features. After
ending the call, the phone returns to the function screen you were using.
Video Share
The Video Share feature allows you to place a call and share live or
recorded video while on the call. You can initiate or receive video by
using the following steps. To enable or disable Video Share, see
“Video Share Settings” on page 125.
Initiating and Receiving a Video Share Session
To initiate and receive a Video Share session, use the following steps:
1. Dial the number and press the key.
21
2. Once the call is answered, if you're both capable of Video
Share, the
Video Share
icon displays
on both screens and the soft key changes to
Video
Share
. Press the soft key to invite the other party to
see video shot from your phone.
Important!:
When establishing a Video connection, the first phone that actually presses
Video Share becomes the sending phone.
"
Establishing a Video Connection
" displays. A message is
sent to the recipient "
###-###-#### Wants to Share Video
With You.
"
3. The recipient receives a Video Share pop-up to
Accept
or
Decline
the Video Share call. To continue, press the
soft key to
Accept
or the soft key to
Decline
.
4. A
“Recording Started”
pop-up displays that shows the
memory available for the video.
5. During a Video Share session, the following functions
display as icons on the screen. Use the
Right
and
Left
Navigation key to select.
When the function is selected, the following options display
above the right soft option key:
6. To stop the video sharing, press the
Options
soft key and
select the “Video Share End” option.
A pop-up message displays “A
re You Sure You Want to Stop
Video Sharing?
”
Stop
: press this key to stop the video share feature.
Brightness
: press this key to adjust the brightness for
the video.
Landscape
: Select this option to rotate the picture from
Portrait to Landscape mode. Press any key to revert to
Portrait. Receiver only.
Mute
: Press this key to turn the audio off.
Spkr Off/On
: press this key to turn off/on the speaker.
Call Functions 22
7. Press the
Yes
soft key to stop. The phone then displays
“
Video Sharing has been Stopped. Save the Recorded Video?
”
Press the
Yes
soft key to save the video. Recorded videos
are stored in the
My Stuff
➔
Video
folder.
Video Share (In-Call)
You can begin a Video Share call during an existing call by pressing
the
Options
soft key and selecting
Video Share
➔
Live
.
Play a Video Share Recording
During a call (while not in a Live Video Share session) you can share a
recorded video for the recipient. Press the
Options
key and select
Video Share
➔
Recorded
and then select from the available files in your
My Stuff
➔
Video folder
. To make the connection, the recipient should
press
Accept
and the video begins to play on both phones.
Recent Contacts
The phone stores the numbers of the calls you’ve dialed, received, or
missed in the Recent Calls menu. If the number or caller is listed in
your Address Book, the associated name displays.
Recent contact also include text and multimedia messages and email
messages, as well as alerts for voice mail messages.
Viewing Missed Contacts
The number of contacts you have missed displays on the Idle screen if
the phone is on. The missed contact tab also displays when you first
turn the phone on and you had calls or messages when the phone
was off.
To view the call details, use the following steps:
1. If the phone is off,turn it on.
If you had missed contacts during the time the phone was
off, the View Tab displays, containing the missed calls,
voicemail, or messages.
2. If you have more than one missed contact, use the
Left
or
Right
Navigation key to select the type of missed contact,
then press the
View
soft key. The most recently missed
contact displays.
Note:
If there is a voicemail sent by the same number, associated icons display and can
be selected.
3. To scroll through the list of missed contacts, press the
Up
or
Down
Navigation key.
23
4. To move to another contact type (i.e. voice mail, text,
multimedia, or email messages), press the
Left
or
Right
Navigation key.
Viewing the Details of a Missed Voice Call
To view the details of a selected missed voice call, use the following
steps:
1. Press the
View
soft key. The most recently missed call
displays. To scroll through the list of missed calls, press the
Up
or
Down
Navigation key.
2. Selecte a missed call and press the
Options
soft key.
3. Use the Navigation keys to highlight
Details
and press the
key.
Calling Back a Missed Call
To call back a missed call number, use the following steps:
1. Press the
View
soft key. The most recently missed call
displays.
2. To scroll through the list of missed calls, press the
Up
or
Down
Navigation key.
3. Highlight the number and press the
Options
soft key and
select
Call Back
, or press .
Saving a Missed Call to your Address Book
To save the missed call entry to your address book, use the following
steps:
1. Press the
View
soft key. The most recently missed call
displays.
2. With the missed call selected and press the
Options
soft
key.
3. Use the navigation keys to highlight
Save to Address
book
and press the key.
4. Select the location of your Address Book:
• Phone
: This option allows you to save the missed number to your
Address Book stored on the phone.
•SIM
: This option allows you to save the missed number to your Address
Book stored on the SIM card.
For further details about the Address Book feature, see “Adding a New
Contact” on page 102.
Sending a Message to a Missed Call
To send a text message or attachment to a missed call entry, use the
following steps:
1. Immediately after missing a call, press the
View
soft key.
Call Functions 24
2. Press
Options
➔
Send Message
. Press the
Select
soft key, or
the key.
3. At the “Create New Message” screen, type in your message
using the alphanumeric keys.
4. Press the
Options
➔
Add Item
to insert items such as an
Image, Sound, or Video.
5. When you are done with your message, press the
Options
➔
Send
option. You may also press the
Send To
soft key or
the key.
Note:
When you "Add item" in the options, the setting automatically changes to
"Multimedia Message".
Deleting a Missed Call
To delete a missed call entry, use the following steps:
1. Immediately after missing a call, press the
View
soft key.
2. Press
Options
➔
Delete
. Press the
Select
soft key, or the
key.
Delete has two options: Selected or All.
Selected
will delete
only the entry that is actively selected;
All
will delete all
entries in the Recent Calls Log.
3. At the “Delete?” prompt, press either the
Yes
soft key or the
key to confirm deletion, or the
No
soft key to cancel.
4. You can press the key at any time to exit the Missed
Call feature.
Call Time
Call time refers to the amount of time used in calls, both calls sent and
calls received.
1. From the Idle Screen, press the
Menu
➔
Recent Calls
and
press
Select
or the key.
2. Press
Call Time
➔
Select
soft key or the key.
The following options are available.
• Last Call Time
: shows the length of time for the last call.
•Total Sent
: shows the total length of time for the calls made.
• Total Received
: shows the total length of time for the calls received.
3. To reset the value of these counters, select the desired
option and press the
Reset
soft key.
4. Enter the password and press the
Confirm
soft key to reset
the selected option.
5. Press the
Back
soft key or the key to end.
25
Data Volume
Data Volume refers to the amount of data (volume) to and from the
phone.
1. In Idle mode, press
Menu
➔
Recent Calls
➔
Data Volume
and
press the
Select
soft key or the key.
2. Use the
Up
and
Down
Navigation keys to view the following
information:
•Last Sent Data
: shows the size of the last data packet (measured in KB
- kilobytes) sent by the phone since the last time this counter was reset.
• Last Received Data
: shows the size of the last data packet (measured
in KB - kilobytes) received by the phone since the last time this counter
was reset.
•Total Sent Data
: shows the size of the total data packet (measured in
KB - kilobytes) which have been sent by the phone since the last time
this counter was reset.
• Total Received Data
: shows the size of the total data packet
(measured in KB - kilobytes) which have been received by the phone
since the last time this counter was reset.
3. To reset the value of these counters, select the desired
option and press the
Reset
soft key.
4. Enter the password and press the
Confirm
soft key to reset
the selected option.
5. Press the
Back
soft key or the key to end.
Data Call Time
1. In Idle mode, press the
Menu
➔
Recent Calls
➔
Data Call
Time
and press the
Select
soft key or the key. The
following options are available:
• Last Data Call:
shows the time used for the last data call sent or
received since the last time this counter was reset.
• Total Data Call:
shows the total time used to send or receive data since
the last time this counter was reset.
2. To reset the value of these counters, select the desired
option and press the
Reset
soft key.
3. Enter the password and press the
Confirm
soft key to reset
the selected option.
4. Press the
Back
soft key or the key to end.
Silent Mode
Silent mode is convenient when you wish to stop the phone from
making noise, in a theater for example. For more information, refer to
“Other Available Profiles” on page 112.
In Idle mode, press and hold the key until the phone vibrates,
and the “
Silent Profile on
” message displays on screen. Both the Silent
mode or Vibrate icons display on screen.
Call Functions 26
In Silent mode, your phone’s speakers are muted. The phone vibrates
and lights up the display, or just lights the display, depending on the
settings of the Silent Phone Settings feature.
To exit and reactivate the previous sound settings, press and hold the
key again until “Normal Profile on” displays. The Silent mode
and Vibrate icons no longer displayed.
Options During a Call
Your phone provides a number of control functions that you can use
during a call.
Adjusting the Call Volume
During a call, if you want to adjust the earpiece volume, use the
Volume keys on the left side of the phone.
Press the key to increase the volume level and the key to
decrease the level.
In Idle mode, you can also adjust the ringer volume using these same
keys.
Putting a Call on Hold
You can place the current call on hold whenever you want. You can
also make another call while you have a call in progress if your
network supports this service.
To put a call on hold:
1. While on a call, press the
Options
soft key.
2. Highlight
Hold
and press the
Select
soft key. The call is on
hold.
3. You can reactivate the call whenever you want, by pressing
the
Resume
soft key.
To make a call while you have a call in progress:
1. Place the current call on hold using the previous
procedures.
2. Enter the new phone number that you wish to dial or look it
up in the Address Book.
3. Press the key to dial the second call. Once
connected, both calls display on the screen.
27
When you have an active call and a call on hold, you may switch
between the two calls, changing the one on hold to active and placing
the other on hold.
To switch between the two calls:
1. Press the
Options
soft key.
2. Highlight
Swap
and press the
Select
soft key. The current
call (#2) is placed on hold and the previous call on hold (#1)
is reactivated so that you can continue conversing with that
person.
3. Press the key to end the currently selected call.
To end a call:
1. Press the
Options
soft key.
2. Highlight
End
and press the
Select
soft key.
3. Highlight the call you wish to end (Active Call, Held Call, or
All Calls) and press the
Select
soft key.
4. Press the key to end the remaining call.
Using the Speakerphone Key
1. During a call, press the speakerphone key .
2. Use the volume keys (located on the left side of your phone)
to adjust the volume.
In Call Options
During a call, the two soft keys become call
Options
(left soft key) and
Mute
(right soft key). To access the following call options, press the
Options
soft key.
•
Mute
: Mutes the onboard microphone. You may mute the microphone using
this option or use the Mute soft key. To turn the microphone back on, use
the Unmute soft key or the Unmute option accessed through the Options
key.
•
Video Share
: Initiates a video sharing session. Video can be Live or
Recorded.
•
Hold
: Places the current call on hold.
•
New Call
: Places the current call on hold and then allows you to enter and
dial another number.
•
Address Book
: Allows you to access your Address Book information.
•
Send Message
: Allows you to create and send a new Text message or
Multimedia Message.
•
Calendar
: Allows you to temporarily access your calendar while still
maintaining the current call.
•
Notes
: Allows you to associate a note with the current phone number.
Call Functions 28
•
Whisper Mode On/Off:
Increases the microphone sensitivity level so that
you do not have to speak loudly to be heard by the other party. Used in quiet
environments such as theaters, meetings, etc.
•
Mute Keypad Tone
: Silences/mutes the key tones when on the call. To turn
this feature off (unmute the keypad), return to this option and select Send
Keypad Tone.
•
Send DTMF
: Sends DTMF (Dual Tone Multi-Frequency) tones to the contacts
you have selected. These DTMF tones are sent as a group. The DTMF tones
are the tones used in phones for tone dialling, sounding when you press the
number keys. This option is helpful for entering a password or an account
number when you call an automated system, like a banking service.
•
Save to Address Book
: Allows you to add the current phone number to your
Contacts list on either your Phone or SIM card.
•
End Call
: Allows you to end the current call.
If you are in a call, you can place the current call on hold by selecting
the
New Call
option above. Once the additional call has been
answered, the following options are available.
•
Swap
: Places the current call on hold and then activates the previous call.
•
Join
: Joins all of the calls you have established with your phone (both active
and on hold) into a multi-party call.
When you want to finish, end each call normally by pressing the
key.
Muting or Sending Keypad Tones
These options allow you to turn the keypad tones off or on. If the
Mute
Keypad Tone
option is selected, it allows you to press keys without
hearing keypad tones during a call.
Note:
To communicate with answering machines or computerized telephone systems, the
Send Keypad Tone
option must be selected.
Switching off the Microphone (Mute)
You can temporarily switch your phone’s microphone off, so that the
other person cannot hear you.
Example:
You wish to say something to person in the room, but do not want the person on
the phone to hear you.
During a call, to switch the microphone off temporarily:
1. Press the
Mute
soft key. Unmute displays.
2. Press the
Unmute
soft key to deactivate the Mute function.
Searching for a Number in the Address Book
You can search for a number in the Address Book during a call.
1. Press the
Options
soft key.
29
2. Press the
Down
Navigation key to highlight the
Address
Book
option.
3. Press the
Select
soft key or the key.
4. Highlight the Address Book entry by using the
Up
or
Down
Navigation key.
- or -
5. Enter the first few letters of the contact into the Search field,
which then highlights the closest match in the Address
Book list.
6. To view the highlighted entry, press the
View
soft key.
7. Press the
Select
soft key to automatically place the active
call on hold and dial the searched contact.
For further details about the Address Book feature, see “Finding an
Address Book Entry” on page 101.
Call Waiting
The Call Waiting feature allows you to answer an incoming call while
you have a call in progress, if this service is supported by the network,
and you have set the
Settings
➔
Set Calls
➔
Voice Call
➔
Call Waiting
menu option to
Activated
. You are notified of an incoming call by a call
waiting tone.
To answer a call while you have a call in progress:
1. Press the key to answer the incoming call. The first
call is automatically put on hold.
2. To switch between the two calls, press the
Options
soft key
and highlight
Swap
.
To end a call on hold:
1. Press the
Options
soft key.
2. Select
End
➔
Held Call
or press the key.
To end the current call, press the key.
Note: Join
: Joins all of the calls you have established with your phone (both active and on
hold).
Swap
: Places the current call on hold and then activates the previous call.
3-Way Calling (Multi-Party Calling)
The 3-Way or Multi-Party feature allows you to answer a series of
incoming calls and place them on hold. If this service is supported by
the network, all calls can be joined together. You are notified of an
incoming call by a call waiting tone.
Call Functions 30
To answer a call while you have a call in progress:
1. Press the key to answer the first incoming call.
2. Press the key to answer the consecutive incoming
calls. The previous call is then automatically put on hold.
3. To bring together the calls, press the
Options
soft key and
highlight
Join
.
4. To end the current call, press the key.
31
Section 5: AT&T Mobile TV with FLO™ for Samsung Viewer Guide
This section describes how to subscribe to AT&T Mobile TV with
FLO™, use the Mobile TV Player, use the Program Guide, use the
Subscription Manager, and set up Parental Controls.
Welcome to AT&T Mobile TV with FLO™
Congratulations! You are one step closer to experiencing the next
telecommunications revolution: AT&T Mobile TV with FLO.
The AT&T Mobile TV with FLO service allows you to watch an exciting
lineup of live entertainment, news, sports and kids' programming
from some of the most popular networks, including CBS, Comedy
Central, ESPN, FOX, MTV, NBC and Nickelodeon.
In addition to offering compelling programming and the highest quality
video and audio, the Mobile TV service is easy to use. After you
subscribe to your service, you can start watching your favorite
programs in the palm of your hand. The Program Guide is simple to
use and navigate, allowing you to see what is on. The Samsung
handset allows you to change from one channel to the next quickly
and easily without progress bars and download delays.
What's more, watching television will not compromise the quality of
the voice service you've come to expect. AT&T Mobile TV with FLO
service was designed to give you a mobile TV experience unlike any
other.
Using your new Samsung phone to enjoy the AT&T Mobile TV with FLO
service is simple.
1. Turn on your Samsung phone.
2. Press the key on your Samsung phone.
Note:
The first time you start AT&T Mobile TV may take a few minutes.
The Welcome to AT&T Mobile TV with FLO screen displays.
AT&T Mobile TV with FLO™ for Samsung Viewer Guide 32
Important!:
Programming and available networks are subject to change. Mobile TV with
FLO services may require separate subscription fees. Contact AT&T for
details.
To subscribe to AT&T Mobile TV
1. Choose
Subscribe Now
and press the key.
The
Review Basic Package
screen displays.
If you choose
Subscribe Later
, you will have the opportunity
anytime you launch AT&T Mobile TV and get the
Subscribe
Now
option.
2. Read the basic package information and press the
Continue
soft key.
If premium content is available, the
Select Premium Package
screen displays.
3. Scroll to the premium package(s) you want to add to your
basic package and press the key.
You can choose more than one premium package at a time.
4. Press the
Continue
key when you are finished.
5. Press the
More Info
key if you need more information about
a premium package.
Note:
If you do not wish to select a premium package, press
Continue
after selecting the
base package.
The
Terms of Service
screen displays.
6. Read the Terms of Service and if you agree, press the
Agree
soft key. Press the
Disagree
soft key if you do not agree.
You are prompted to exit the subscription process.
7. Press the
Submit
key to complete the subscription.
You are now subscribed to the package(s) you selected.
8. Press the
Close
key to return to the Player. You can start
viewing content immediately.
Important!:
The costs of the package(s) are automatically added to your monthly bill.
9. Edit or cancel your subscription package(s) through the
Subscription
screen, accessed in the
Program Guide Options
menu.
Using the Mobile TV Player
Mobile TV Player displays scheduled programming content according
to the Mobile TV with FLO service package to which you subscribe.
33
Important!:
You must be subscribed to AT&T Mobile TV with Flo service in order to use the
Mobile TV player.
To launch Mobile TV Player:
1. At the Idle screen, select
Menu
➔
Videos
➔
Mobile TV
.
Note:
To quickly launch Mobile TV Player, press the key.
The Mobile TV Player launch screen displays, showing the
progress of the application. Once the initialization is
complete, the first channel in the list displays.
2. Press the key to exit Mobile TV Player.
To change channels in Mobile TV Player:
ᮣ
Press the
Up
and
Down
Navigation keys.
When you select a current program in the Program Guide to which you
are subscribed, the Mobile TV Player displays the program.
The Mobile TV Player shows the channel logo or call letters, title of the
program, duration of the program, and, if available, rating information.
You can perform the following options from the Player:
•
Guide key
: displays the Program Guide
•
Up arrow
: cycles up through channels
•
Down arrow
: cycles down through channels
Using the Program Guide
Using the program guide is simple. You can view program times and
program descriptions by pressing the
Up
and
Down
Navigation keys.
To view information about programs playing at a later time, press the
Right
and
Left
Navigation keys.
1. To view a current program in the Program Guide, highlight
the program and press the key.
The Program Guide includes all scheduled programming
currently available with their respective channels, program
titles descriptions, and show times.
If you select a channel that is not currently included in your
subscription package, you can add that programming
package immediately by following the prompts on your
phone.
2. Press the
Options
soft key to display the menu and perform
tasks from the Program Guide.
3. Scroll to the desired option and press the key.
AT&T Mobile TV with FLO™ for Samsung Viewer Guide 34
View description
ᮣ
From the
Options
menu, select
View description
to view a
description of a program you highlighted in the Program Guide.
Subscription manager
ᮣ
From the
Options
menu, select
Subscription manager
to manage
your subscription. While in the subscription screen, press the
Options
key to display the subscription menu.
Parental controls
ᮣ
From the
Options
menu, select
Parental controls
if you wish to limit
access to certain rated programs.
To set Parental Controls:
1. Turn
Parental Controls
on.
2. Set up a PIN for the service.
3. Select the rating levels for the service.
After you perform these tasks, the service assesses a
program's rating before it allows program viewing.
Programs with restricted ratings require the PIN you set up
to view the program.
Note:
You must turn parental controls on before the ratings criteria can take effect.
When a program is selected that exceeds the rating you set
ᮣ
Enter the PIN you selected at the prompt.
Note:
If you do not enter the correct PIN, the program cannot be viewed or listened to.
To allow viewing only of this program:
ᮣ
Enter your PIN at the prompt. The program is now available for
viewing.
Note:
After you set up the PIN, you must enter the PIN to remove or add programming
packages to your subscription.
Important!:
Keep the PIN in a safe place. Do not share your PIN with unauthorized third
parties. If you forget your PIN, call AT&T customer service for assistance.
Check for updates
ᮣ
From the
Options
menu, select the
Check for updates
option to see if
there is an updated version of AT&T Mobile TV with FLO service
available for your phone.
Refresh subscription
ᮣ
From the
Options
menu, select the
Refresh subscription
option if you
believe your subscription is out of sync.
35
Tip:
You can sync your subscription if you have more than one AT&T Mobile TV-enabled
phone, and you want to swap the SIM card.
When you refresh your subscription, AT&T Mobile TV with FLO service
checks your records to verify that you are receiving the correct
package.
About
ᮣ
From the
Options
menu, select the
About
option to display the
current version of AT&T Mobile TV with FLO operating on your
phone.
Want more?
For more information about AT&T Mobile TV with FLO and for current
programming, go to
www.att.com/mobiletv
.
Cellular Video 36
Section 6: Cellular Video
Your phone is equipped with a WAP (Wireless Application Protocol)
browser which allows you to access the Internet and upload media
files directly to your phone. These media files display using the built-in
Media Player.
Cellular Video (CV) is a media service which allows you to not only
navigate to your favorite web sites but stream media content
(Weather, News/Sports highlights, etc..) directly to your phone.
1. At the Idle screen, select
Menu
➔
Cellular Video
.
2. Press
Select
or the key. You are then taken to your
default Cellular Video homepage.
This homepage provides you with several sections of
accessible content:
•My Favorites
: allows you to choose from some recently uploaded video
clips from media providers.
• Video Categories
: provides some general content categories from
which to begin searching for media.
• Customize Cellular Video
: allows you to access the Cellular Video
Settings menu where you can configure most of the settings associated
with Cellular Video.
•Parental Control
: provides you with settings which can be configured
to restrict certain media content from being displayed on the phone.
• MEdia Net
: exits from the Cellular Video application and launches the
MEdia Net homepage.
•Help
: provides basic on-line assistance which answers most of the
common issues users come across while using this feature.
3. Highlight the desired media clip or select from one of the
available categories and press the Select soft key or the
key.
Cellular Video Options
1. At the Idle screen, select
Menu
➔
Cellular Video
.
2. Press
Select
or the key.
3. From the main Cellular Video homepage, press the
Options
soft key to use one of the following options:
•Go to
: returns you to the main Cellular Video homepage.
•Go
: lets you navigate Forward (next sequenced web page) or Backward
(to the previously visited web page) through pages in your browsing
history.
•Reload
: reloads the current page with updated information.
• Desktop View
: changes the display mode of the browser.
•Page Size
: change the page size of the displayed web page (Large,
Normal, or Small).
37
• Go to Homepage
: takes you back at any time to the homepage of the
Wireless Web service provider.
• Add to Favorites
: bookmarks the current page and marks it as a
favorite site.
•View Favorites
: accesses and displays the bookmarks assigned as
favorite web pages.
• Send URL via
: send the URL of the current page via either a message
or to another party via a Bluetooth device.
•Enter URL
: allows you to manually enter the URL address of a WAP site.
After entering an address, press the OK soft key to go there directly.
•Copy URL to Message
: send the URL of the current page to another
party as a message.
•Save
: saves either the image of the current web page or the current
page itself.
•Saved Pages
: access the list of web pages you have saved.
•History
: displays the list of web pages you have recently accessed.
• Advanced
: allows you to change the following settings for the browser.
–
Clear Caches
: deletes the information stored in the cache. The cache
stores the most recently accessed pages.
–
Empty Cookies
: delete cookies. Cookies are pieces of personal
information sent to a web server while navigating the web.
–
Preferences
: changes the settings for the web browser to suit your
preference.
–
Certificates
: accesses certificate information from your phone.
–
Page Details
: displays the properties for the currently active web page.
–
Browser Settings
: selects a connection profile to be used when
connecting to the Internet.
–
About Browser
: displays the access version and copyright information
about the browser.
Media Clip Options
With the media currently active on the phone (either playing or
paused), press the
Options
soft key to open a list of the following
streaming media options.
Tip:
Within the clips listed in the My Favorites section of your main CV homepage,
highlight the description and then press the key to begin the stream.
Pause/Resume
This feature allows you to toggle the state of the current video
between being
Paused
or
Resuming
playback.
Stop
The feature stops the current media, exits the media player and
returns you to the main Cellular Video homepage.
Jump to track time
This feature pauses the current media content and displays a “Jump
to track time” pop-up which allows you to enter an Hour, Minute, and
Second value which corresponds to the media’s timeline.
Cellular Video 38
If, as an example, the content is three minutes long, entering a value
of: 00:01:30, would cause the Media Player to begin replaying the
content from its half-way point.
1. Use your keypad to enter a value for the Hour, Minute, and
Seconds.
2. Press the
Jump
soft key to cause the Media Player to
resume playback at that value on the clip’s timeline
- or -
3. Press the
Cancel
soft key to go back to your media clip and
resume playback from its previous location.
Properties
Displays a Media Player window which gives file specific information
such as title, and Duration.
Settings
This feature pauses the content and navigates you to the
Player
Settings
menu where you can configure the Media Player’s Volume
setting.
1. Use the
Up
or
Down
Navigation key to increase/decrease the
current volume setting for the player while in Portrait mode.
Use your
Left
or
Right
Navigation key to increase/decrease
the current volume setting for the player while in Landscape
mode.
2. Press the
Save
soft key to save your changes
- or -
3. Press the
Back
soft key to resume your media playback
without saving your changes.
Cellular Video Settings
This feature allows you to configure the current server profile being
used by the key to access the on-board WAP. For more
information, refer to “Changing the WAP Profiles” on page 67.
Landscape
This features rotates the streaming media clip to display in a
landscape orientation.
The default orientation is a portrait orientation.
This functionality is also enabled from the main
Landscape
soft key.
39
Using the Video Categories
This grouping of media categories provides access to an additional
listing of streaming media. Where the previous Favorites list of media
stream can be user edited and updated, this list of categories is
defined by Cellular Video’s homepage and can not be changed.
Viewing a Video Clip
1. At the Idle screen, select
Menu
➔
Cellular Video
.
2. Press the
Select
soft key or the key.
3. Use the
Up
or
Down
Navigation key to highlight the video
clip from within the Favorites section and press the
Select
soft key or the key.
4. After the stream is buffered into memory, you can choose to
either
Pause
or play the content. Pressing the key
toggles the
Play
and
Pause
functionality.
Customizing Cellular Video
Updating the Favorites List
The list of media providers which display in the Favorites section of
the Cellular Video homepage can be edited and changed by the user.
1. At the Idle screen, select
Menu
➔
Cellular Video
.
2. Press the
Select
soft key or the key.
3. Use the
Up
or
Down
Navigation key to highlight the
Edit
button from the upper-right of the homepage (adjacent to
the My Favorites title) and press the
Select
soft key or the
key.
4. From
Customize Cellular Video
➔
Options
➔
Edit My
Favorites
, press the
Select
soft key or the key.
5. Navigate to the
Add to Favorites
section of the page and
highlight one the additional streaming media channels
which are not currently in your Favorites list (ex: Cartoon
Network).
6. Press the
Options
soft key. Highlight
Add to Favorites
and
press the
Select
soft key or the key.
Adding a Video Alert
When new media is available for upload to your phone (such as
breaking news), you can set your phone to notify you of the new
available content.
1. At the Idle screen, select
Menu
➔
Cellular Video
.
2. Press the
Select
soft key or the key.
Cellular Video 40
3. Use the
Up
or
Down
Navigation key to highlight the
Customize Cellular Video
button from the bottom of the
homepage and press the
Select
soft key or the key.
4. From
Customize Cellular Video
➔
Options
➔
My Video Alerts
,
press the
Select
soft key or the key.
5. Navigate to the
Add to My Alerts
section of the page and
highlight one the available services (ex: Breaking News).
6. Press the
Options
➔
Add to Favorites
and press the
Select
soft key or the key.
My Purchases
The Cellular Video homepage can be used to shop for streaming
multimedia content. The My Purchases section can help keep track of
your purchase history and view any new resale products.
1. At the Idle screen, press the
Menu
➔
Cellular Video
and
press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight the
Customize Cellular Video
button from the bottom of the
homepage and press the
Select
soft key or the key.
3. From
Customize Cellular Video
➔
Options
➔
My Purchases
,
press the
Select
soft key or the key.
4. Highlight
Purchase History
and press the
Select
soft key or
the key. This provides you with an on-screen listing of
your “to date” purchase history for media content.
5. Highlight
My Account
and press the
Select
soft key or the
key. This provides you with an on-screen description of
your account details.
Parental Controls
Your phone can be configured to block both purchased and streamed
media content. Before filtering, you must first establish a PIN and
password, and a contact e-mail address. Once those have been
established, you have two available filter options: Content Filters and
Purchase Blocker.
•
Content Filtering
: let you restrict access to inappropriate content both on
and outside of MEdia Net.
•
Purchase Blocking
: lets you restrict the ability to buy ringtones, downloads,
games, etc.., from this phone.
Setting up Parental Control
1. At the Idle screen, press the
Menu
➔
Cellular Video
and
press the
Select
soft key or the key.
41
2. Use the
Up
or
Down
Navigation key to highlight the
Customize Cellular Video
button from the bottom of the
homepage, and press the
Select
soft key or the key.
3. From
Customize Cellular Video
➔
Options
➔
Parental
Controls
, press the
Select
soft key or the key.
4. Highlight the
OK
button and press the key to access the
MEdia Net parental setup fields.
5. From the Parental Control Setup screen, use your keypad to
enter information into the following fields:
PIN Code
,
Re-
enter PIN code
, and
contact email address
.
6. Use the Navigation keys to highlight the
Save
button and
press the key. Allow a few minutes for your information
to be received and accepted by MEdia Net. You can then use
this information to activate the parental filters.
Configuring the Filters
1. At the Idle screen, press the
Menu
➔
Cellular Video
, and
press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight the
Customize Cellular Video
button from the bottom of the
homepage and press the
Select
soft key or the key.
3. Highlight the
OK
button and press the key.
4. When prompted, enter the PIN and e-mail address which
was registered with MEdia Net in the previous section.
5. Highlight
Content Filters
and press the
Select
soft key or the
key.
6. Highlight the
On
button and press the
Select
soft key or the
key to toggle the
On/Off
state.
7. Highlight
Purchase Blocker
and press the
Select
soft key or
the key.
8. Highlight the
On
button and press the
Select
soft key or the
key to toggle the
On/Off
state.
9. Press the
Back
soft key or the key. This activates the
filters.
Entering Text 42
Section 7: Entering Text
This section outlines how to select the desired text input mode when
entering characters into your phone. This section also describes how
to use the T9 predictive text entry system to reduce the amount of key
strokes associated with entering text.
Text Input Modes
The Text Input option switches the key entry functions from an T9
Alphabet, ABC (Alphabet), Numeric Mode, and Symbols Mode.
T9 Input Method (T9 abc, T9 Abc, and T9 ABC)
This input method allows you to enter words with only one keystroke
per letter. Each key on the keypad has more than one letter; for
example, pressing the key can enter J, K, or L. However, the T9
method automatically compares the series of keystrokes you make
with an internal linguistic dictionary to determine the most likely word,
thus requiring far fewer keystrokes than the traditional Alphabet
mode. The T9 abc method makes all characters lowercase. The T9
Abc method makes the initial character an uppercase while the
remaining characters are left as lowercase. The T9 ABC method
makes all characters uppercase.
ᮣ
To select the T9 Input method, select
Menu
➔
Messaging
➔
Create
New Message
➔
Options
➔
Input Method
.
ABC (Alphabet) Input Method (Abc, abc, and ABC)
This input method allows you to enter letters by pressing the key
labeled with the letter you want. Press the key once, twice, three, or
four times until the correct letter displays. The Abc mode makes only
the initial character of the word uppercase. The abc method makes all
characters of the word lowercase. The ABC method makes all
characters of the word uppercase.
ᮣ
To select the Alphabetic method, select
Menu
➔
Messaging
➔
Create New Message
➔
Options
➔
Input Method
.
Numeric
This mode allows you to enter numbers.
ᮣ
To select the Numeric Input method, select
Menu
➔
Messaging
➔
Create New Message
and press the key until the numeric input
() displays on the top line of the message input screen.
En
1
43
Symbols
This mode allows you to enter symbols, such as punctuation marks.
ᮣ
To select the Symbolic input method, select
Menu
➔
Messaging
➔
Create New Message
, and press and hold the key until the
symbol grid displays on the message input screen.
Changing the Text Input Mode
When you are in a field that allows characters to be entered (such as
in a text message), the input mode indicator displays on the screen.
1. To change the input mode from within a text or multimedia
message, press the
Options
soft key.
2. Highlight
Input Method
and press the key. The default
mode is Abc.
3. Choose from the following options:
4. To access Symbol mode, press and hold the key. Press
the number key corresponding to the symbol you want to
enter. Use the
Up
and
Down
Navigation keys to scroll
through the available symbols. Press the
Cancel
soft key to
exit.
5. To access the Numeric mode, press the key.
Using the T9 Input Method
T9 Predictive Text input method is based on a built-in dictionary.
abc
all lowercase
Abc
initial capitalization
ABC
all uppercase
T9
Predictive Text: input method is based on a built-
in dictionary.
T9 abc
Predictive Text: completed words are all
lowercase.
T9 Abc
Predictive Text: completed words are all initial
capitalization.
T9 ABC
Predictive Text: completed words are all
uppercase.
Entering Text 44
Enter a Word in T9 Mode
1. In T9 method, begin entering a word by pressing the
through keys. Press each key only once for each
letter. The built-in dictionary lists words that match the
keystrokes you have entered.
Example: To enter “Hello”, press
, , , ,
The word that you are typing displays on the screen. It may
change with each key that you press.
2. Enter the whole word before editing or deleting the
keystrokes.
3. When the word displays correctly, go to step 4.
If the word doesn’t display correctly, press the key to
display alternative word choices for the keys that you have
pressed.
Example:
Both “Of” and “Me” have the and keys. The phone displays the
most commonly used choice first.
4. Insert a space by pressing the key and start entering
the next word.
Add a New Word into the T9 Dictionary
1. After pressing the keys corresponding to the word you want
to add, press the key to display the alternative
words.
2. When the last alternative word displays,
Spell
displays.
Press the
Spell
soft key.
3. Enter the word you want to add using the ABC mode.
4. Press the
Add
soft key or the key.
The word is added to the T9 dictionary and becomes the
first word for the associated keypress series.
Note:
This feature may not be available for some languages.
•
To enter periods, hyphens, colons, or parenthesis, press and hold the
key.
•
T9 mode applies grammar rules to ensure that correct punctuation is used.
•
To shift case in T9 mode, use the key. There are 4 cases: Initial
capital, Capital lock, Lower case, and Numeric.
•
You can move the cursor by using the
Left
and
Right
Navigation keys. To
delete letters, press the key. Press and hold the key to clear the
display.
45
Using the Alphabet Input Method
To use the ABC Alphabet input method use the through
keys to enter your text.
1. Press the key labeled with the letter you want:
•
Once for the first letter
•
Twice for the second letter
•
And so on
2. Select the other letters in the same way.
Note:
The cursor moves to the right when you press a different key. When entering the
same letter twice or a different letter on the same key, just wait for a few seconds
for the cursor to move to the right automatically, and then select the next letter.
Keys
Using the Symbols Input Method
The Symbol input method enables you to insert symbols and
punctuation marks into text.
1. To enter symbol mode press and hold the key.
2. Use the Navigation keys to select an on-screen symbol
group.
3. To select a symbol from that group, press the corresponding
number key.
4. To clear the symbol(s), press the key. When the input
field is empty, this key returns the display to the previous
mode.
. , ’ - ? ! @ : / 1
A
B C Ä Å Æ Ç 2 a b c ä à å æ ç 2
D E F
É
∆ Φ 3 d e f è é Φ 3
G H I Γ 4 g h i ì Γ 4
J K L Λ 5 j k l Λ 5
M N O Ñ Ö Ø Ω 6 m n o ñ ö ò ø Ω 6
P Q R S П Σ Ψ 7 p q r s β Σ Ψ 7
T U V
Ü
θ 8 t u v ü ù 8
W X Y Z Ξ 9 w x y z Ξ 9
+ = < > € £ $ % & ¥ ¤ 0
Entering Text 46
5. To return to your message, press the
OK
soft key or the
key.
Using the Numeric Input Method
The Numeric mode enables you to enter numbers into a text message.
To enter Numeric input mode, press the key until
123
displays in
the input method. Press the keys corresponding to the digits you want
to enter.
47
Section 8: Messaging
This section describes how to send or receive different types of
messages. It also includes the features and functionality
associated with messaging.
Types of Messages
Your phone provides the following message types:
•
IM Messages
•
Text Messages
•
Multimedia Messages
Display Icons for Messages
When new messages are received on your handset, icons appear
in two locations on the phone display: one the View Tab that
appears at the bottom of your screen, and in the icon line at the
top of the display (see “Display Layout” on page 13).
Message Icons on the Icon Line
On the icon line at the top of the display, a new voicemail is
indicated by the icon. A new text message or email
message is indicated by the icon. A new multimedia
message is indicated by the icon.
View Tab
The View Tab is an area that only appears on the display when a
missed call, new message, or voicemail is sent to the phone.
There are three tabs for View: Missed Calls ( ), Voicemail
( ), and Messages ( ). You can search through calls
and messages you have not viewed by using the
Right
and
Left
navigation keys to get to the message type, then select the
View
soft key. When you select a tab, you are viewing either the
Missed Call folder or the Messaging Inbox, or calling the
Voicemail number.
View Exit
tv
tv
pm
12:13
12:13
Nov 8
Nov 8
Thu
Thu
2 Missed Calls
3:25PM Nov 9
Messaging 48
Note:
If you select the Voicemail icon, pressing or the
Dial
soft key will dial
the Voicemail center so that you can listen to your voicemails.
Creating and Sending Text Messages
The Short Message Service (SMS) allows you to send and receive
short text messages to and from other mobile phones. To use this
feature, you must subscribe to your service provider’s message
service.
The Message icon ( ) displays in the Messaging Inbox when
you have received new text messages. When the memory is full,
an error message displays and you cannot receive any new
messages. Use the
Delete
option in each message box to delete
obsolete messages.
If you receive an email from a phone from outside your
subscriber service, it is possible that your icon may look slightly
different. Some providers have text messages with pictures such
as emoticons that do not constitute a multimedia message. The
icon will then appear as .
Creating a New Text Message
1. At the Idle screen, press
Menu
➔
Messaging
➔
Create
New Message
, and press the
Select
soft key or the
key.
2. Enter either a phone number or contact name (from
your Address Book) by pressing the key to access
both a list of recent calls and your Address Book
Contacts and Groups.
• Recent Log
: allows you to choose from a brief list of recently
dialed phone numbers. Press the key to add a selected
number to your message’s recipients list field. This entry can later
be appended prior to sending the message.
•Contacts
: allows you to insert additional recipients from your
Address Book by using your
Up
and
Down
Navigation keys to
select those entries you wish to add.
–
Press the key to place a checkmark next to those entries.
–
Once you have selected the desired entries, press the
Done
soft
key to return to the message.
• Groups
: allows you to insert additional Group members from your
Address Book by using your
Up
and
Down
Navigation keys to
select those entries you wish to add.
3. Use the
Down
Navigation key to access the text field
and begin creating your text message.
49
4. Press the
Options
soft key when you have finished
writing your message. Choose from the following
options:
•Send
: allows you to send the message.
•Text
: allows you to highlight the text inserted, then set the Text
Selection on or off, Cut previously entered text, Copy text, or
Remove text before sending.
• Add Item
: allows you to add an image, sound or video clip to your
message.
Note:
If you add an image, sound clip, or video clip to your message, the message
is sent as a Multimedia Message.
• Create Item
: allows you to temporarily exit from the current text
message and create either a new photo, video clip, or audio clip
for your current text message.
–
Take Photo
: allows you to temporarily exit the message, take a
photo with phone’s camera, and then add it to your message.
–
Record Audio
: allows you to temporarily exit the message,
record an audio clip using the phone’s microphone, and then add
it to your message.
–
Record Video:
allows you to temporarily exit the message,
record a video clip using the phone’s camera, and then add it to
your message.
•Insert
: allows you to insert a predefined Text template, Text
emoticon, Business card, or favorite web address into the
message.
–
Text Template
: allows you to insert one of the preset message
templates to the text, such as Out of Office, I’m in a meeting...,
etc.
–
Text Emoticon
: allows you to add an a emotion (created by
phone characters) to your message. An example would be:
which creates a :-) “happy face”.
–
Address Book
: allows you to add contact information for an
entry from your Address Book directly to your message.
–
Favorites
: allows you to add a web address from your Favorites
list of Internet sites to the message.
• Add Recipients
: allows you to update the recipient list by
appending it with information form either your Recent Log,
Contacts, or Groups entries.
• Change to Multimedia Message
: allows you to convert the
current message to/from either a text or multimedia message
prior to being sent.
Note:
A multimedia message should only be sent to a phone which can support the
receipt and display of this message type.
• Input Language
: allows you to temporarily change the input
language used to create your message.
• Input Method
: allows you to change the method used to input
data into your message, such as text, numbers, and symbols. For
more information, refer to "Entering Text" on page 40.
•Add Attachment
: allows you to add either a file, card, or other
information such as a calendar entry, task, or note.
Messaging 50
–
File
: allows you to insert an audio, graphic, or video clip to your
message as an attached file.
–
Business Card
: allows you to insert the contact information for
an entry from Address Book directly to your message as an
attached file.
–
Appointment
: allows you to insert an Appointment entry from
your calendar directly to your message as an attached file.
–
Anniversary
: allows you to insert an Anniversary entry from your
calendar directly to your message as an attached file.
–
Private
: allows you to insert a Private entry from your calendar
directly to your message as an attached file.
–
Holiday
: allows you to insert a Holiday entry from your calendar
directly to your message as an attached file.
–
Important
: allows you to insert an entry from your calendar
tagged as Important directly to your message as an attached file.
–
Tasks
: allows you to insert an entry from your calendar tagged as
a Task directly to your message as an attached file.
–
Notes
: allows you to insert a presaved Note (text) directly to your
message as an attached file.
–
Favorites
: allows you to add a web address from your Favorites
list of Internet sites as an attachment to the message.
• Sending Options:
allows you to save a copy or adjust your Text
Message Center Settings.
• Save to Drafts
: allows you to save the message to the Drafts
folder.
• Save as Template
: allows you to save the message as a text
template.
•Back
: allows you to return to the active message.
5. Press the
Send To
soft key and confirm the recipient(s).
You can add additional recipients from your Address
Book by selecting one of the
Empty
fields and pressing
the key.
•
Add the additional recipients from your Address Book by then
using your
Up
and
Down
Navigation keys to select those entries
you wish to add.
•
Press the key to place a checkmark next to those entries.
•
Once you have selected the desired entries, press the
Done
softkey to return to the previous list of Recipients.
6. Send the message to the selected recipients by
pressing the
Send to
soft key. You may also use the
Options
soft key to select
Save to Draft
or
Save as
Template
.
Creating and Sending Multimedia Messages
The Multimedia Messaging Service allows you to send and
receive multimedia messages to and from other mobile phones.
To use this feature, you must subscribe to your service provider’s
multimedia message service.
The Multimedia Message icon ( ) displays when you have
received new multimedia messages. When the memory is full, an
error message displays and you cannot receive any new
51
messages. Use the
Delete
option in each message box to delete
obsolete messages.
1. At the Idle screen, select
Menu
➔
Messaging
➔
Create
New Message
, and press the
Select
soft key or the
key.
2. Enter either a phone number or contact a contact
name (from your Address Book) by pressing the
key to access both a list of recent calls and your
Address Book Contacts and Groups.
• Recent Log
: allows you to choose from a brief list of recently
dialed phone numbers. Press the key to add a selected
number to your message’s recipients list field. This entry can later
be appended prior to sending the message.
•Contacts
: allows you to insert additional recipients from your
Address Book by using your
Up
and
Down
Navigation keys to
select those entries you wish to add.
–
Press the key to place a checkmark next to those entries.
–
Once you have selected the desired entries, press the
Done
soft
key to return to the message.
• Groups
: allows you to insert additional Group members from your
Address Book by using your
Up
and
Down
Navigation keys to
select those entries you wish to add.
3. Use the
Down
Navigation key to access the text field
and begin creating your message.
4. Select
Options
➔
Change to Multimedia Message
and
press the
Select
soft key or the key.
Note:
A multimedia message should only be sent to a phone which can support the
receipt and display of this message type.
5. Add an Image, Sound, or Video clip directly into your
message by pressing the
Options
soft key and
selecting from one of the following options:
•Send
: allows you to send the message.
•Preview
: allows you to preview your message prior to being sent.
•Text
: allows you to enter, cut, copy, and remove text from your
message prior to being sent.
•Add Item
:: allows you to add an image, sound or video clip to
your message.
• Create Item
: allows you to temporarily exit from the current text
message and create either a new photo, video clip, or audio clip
for your current text message.
–
Take Photo
: allows you to temporarily exit the message, take a
photo with phone’s camera, and then add it to your message.
–
Record Audio
: allows you to temporarily exit the message,
record an audio clip using the phone’s microphone, and then add
it to your message.
–
Record Video
: allows you to temporarily exit the message,
record a video clip using the phone’s camera, and then add it to
your message.
Messaging 52
•Insert
: allows you to insert a predefined Text template, Text
emoticon, Business card, or favorite web address into the
message.
–
Text Template
: allows you to insert one of the preset message
templates to the text, such as Out of Office, I’m in a meeting...,
etc.
–
Text Emoticon
: allows you to add an a emotion (created by
phone characters) to your message. An example would be:
which creates a :-) “happy face”.
–
Address Book
: allows you to add the information for an entry
from your Address Book directly into your message.
–
Favorites
: allows you to add a web address from your Favorites
list of Internet sites to the message.
• Add Recipients
: allows you to update the recipient list by
appending it with information form either your Recent Call Log,
Contacts, or Group entries.
• Change to Text Message
: allows you to convert the multimedia
message back to a text-based message which can contain
multimedia files as attachment and not as part of the main body of
the message.
• Add Page
: allows you to add a text page to your multimedia
message.
• Input Language
: allows you to change the language used for the
message text.
• Input Method
: allows you to change the method used to input
data into your message, such as text, numbers, and symbols.For
more information, refer to
“Text Input Modes”
on page 42.
•Edit Style
: allows you to edit the style of your outgoing message
with option such as: Select page, Background Color, Page
Duration (for embedded media), Font Color, and Font Style.
• Add Subject
: allows you to add a subject header to your
multimedia message.
•Add Attachment
: allows you to add either a file, card, or other
information such as a calendar entry, task, or note.
–
File
: allows you to insert an audio, graphic, or video clip to your
message as an attached file.
–
Business Card
: allows you to insert the contact information for
an entry from Address Book directly to your message as an
attached file.
–
Appointment
: allows you to insert an Appointment entry from
your calendar directly to your message as an attached file.
–
Anniversary
: allows you to insert an Anniversary entry from your
calendar directly to your message as an attached file.
–
Private
: allows you to insert a Private entry from your calendar
directly to your message as an attached file.
–
Holiday
: allows you to insert a Holiday entry from your calendar
directly to your message as an attached file.
–
Important
: allows you to insert an entry from your calendar
tagged as Important directly to your message as an attached file.
–
Tasks
: allows you to insert a Task directly to your message as an
attached file.
–
Notes
: allows you to insert a presaved Note (text) directly to your
message as an attached file.
–
Favorites
: allows you to add a web address from your Favorites
list of Internet sites as an attachment to the message.
53
• Sending Options:
allows you to configure the options associated
with sending the message.
• Save to Drafts
: saves the current message to the Drafts folder.
• Save as Template
: allows you to save the current text message
or multimedia message to the current list of preset message
templates, such as Out of Office, I’m in a meeting..., etc.
•Back
: allows you to return to the active message.
6. Press the
Send To
soft key and confirm the recipient(s).
You can add additional recipients from your Address
Book by selecting one of the Empty fields and pressing
the key.
–
Add the additional recipients from your Address Book by then
using your
Up
and
Down
Navigation keys to select those entries
you wish to add.
–
Press the key to place a checkmark next to those entries.
–
Once you have selected the desired entries, press the
Done
softkey to return to the previous list of Recipients.
7. Send the message to the selected recipients by
pressing the
Send
soft key. You may also use the
Options
soft key to select
Save to Draft
or
Save as
Template
.
Locating a Message
1. In Idle mode, press the
Menu
➔
Messaging
➔
Inbox
and press the
Select
soft key. The message list opens.
Retrieving a Text Message
When a new Text message comes in, the display (in Idle mode)
shows a new Message notification icon ( ) along with the
available sender’s information.
1. Press the
View
soft key to launch the Inbox list of
message.
2. Use the
Up
or
Down
Navigation keys to select the
message.
3. Press the key to open the message.
4. Press the key to return to Idle mode when you
are finished.
Retrieving a Multimedia Message
When a new Multimedia message comes in, the View Tabshows
the Multimedia Message icon ( ) and a text notification
along with the sender’s number.
1. Use the
Up
or
Down
Navigation keys to select a
message from the list.
Messaging 54
2. Select
Options
➔
Properties
, and press the
Select
soft
key or the key to view brief information about the
message, such as the sender’s number, the message
size, and the subject.
If you want to view the message later from the
Inbox
,
press the
Back
soft key.
3. To view the message, select
Options
➔
View
, then
press the
Select
soft key or the key.
4. To review the multimedia message, press the
key.
•
To pause the audio/video clip, press the key.
•
To stop the audio/video clip press the
Stop
soft key.
5. To scroll through the message (if additional text page
have been added), press the
Up
or
Down
Navigation
key.
6. Press the key to return to Idle mode when you
are finished.
Note:
Messages can also be accessed by navigating to your Inbox (
Menu >
Messaging
).
Using Message Options
While viewing the content of a message, press the
Options
soft
key to access the following message options:
Options for SMS Messages
•
Reply
: allows you to reply to the message via Text message.
•
Forward
: allows you to forward the message.
•
Call Back
: allows you to dial the originating message number.
•
Delete
: deletes the message.
•
Move to Phone/Move to SIM
: If a message is stored in the SIM card,
it is saved to the phone’s memory. If a message is stored in the
phone’s memory it is then saved to the SIM card.
•
Save to Address Book
: allows you to save the recipient or sender’s
information from the message to your Address Book on either the
Phone or SIM.
Note:
When storing an Address Book entry into the SIM card, note that only the
Name, Address, Group, and Slot location are initially displayed. To save
additional information for a particular contact, such as other phone numbers,
or e-mail, it is important to add new information fields to that Contact. It is
also important to note that if you move the SIM card to another phone that
does not support additional fields on the SIM card, that information is not
available.
•
Save as Template
: allows you to save the message as a text template.
•
Print via Bluetooth
: allows you to print the content of the text
message wirelessly to a target Bluetooth-compatible printer.
55
Options for Multimedia Messages
•
View/Play
: allows you to view or play the multimedia message.
•
Reply
: allows you to reply to the message.
•
Reply to All
: allows you to reply to the all recipients of the message.
•
Forward
: allows you to forward the message to another person.
•
Call Back
: allows you to dial the originating message number.
•
Delete
: allows you to delete the selected or all messages.
•
Move to My Folder
: moves the message to the phone’s My Folder
location.
•
Save as Template
: saves to the message as a template for this
message type. This template can be used to save time during the
creation of the next similar message.
•
Save Items
: saves the multimedia content to the My Stuff folder.
•
Save to Address Book
: allows you to save the recipient or sender’s
information from the message to your Address Book on either the
Phone or SIM.
•
Print via Bluetooth
: allows you print the contents of the message on a
Bluetooth compatible printer.
•
Lock
: locks the message.
•
Properties
: displays some of the file properties for the message such
as: sender, date/time, file size, priority, etc..
Using Instant Messenger (IM)
The Instant Messenger function allows you to send and receive
instant messages using AIM, Windows Live, and Yahoo
communities. You must first create a default community account
before accessing it on your phone.
Default Community Settings
To access your default community session settings, use the
following steps:
1. At the Idle screen, press the
Menu
➔
Messaging
➔
IM
,
and press the
Select
soft key or the key.
2. Select
Settings
and press the
Select
soft key or the
key.
3. Select
Choose Your Community
and press the
Select
soft key or the key. This is the service that loads
when you press the IM soft key.
4. Use the Navigation keys to highlight your option, and
press the
Select
soft key or the key to save your
selection.
Messaging 56
Signing into Your Mobile Email
Take your email with you! With Mobile Email you can check your
Yahoo!® Mail, AOL®, AIM , Windows Live Mail, AT&T Yahoo!®,
BellSouth, and other providers quickly and easily.
1. At the Idle screen, press the
Menu
➔
Messaging
➔
Mobile Email
, and press the
Select
soft key or the
key.
2. Use the Navigation keys to select an e-mail carrier of
your choice and press the
Select
soft key or the
key.
3. Use the Navigation keys to select which domain your
personal account uses (e.g., "@hotmail.com") and
press the
Select
soft key or the key.
4. Type in your personal Email address (e.g.,
"silverfox2"), then enter your account's Password and
press the
Sign In/On
soft key. You are connected to
your account's Inbox and contacts, where you can
send and receive emails.
Signing into Your IM Account
Although each account type differs, the initial sign in procedure is
common to all supported types. Before beginning the sign in
procedure, you must complete the previous procedures for
selecting your default IM Community.
1. At the Idle screen, select
Menu
➔
Messaging
➔
IM
➔
Sign In/On
, and press the
Select
soft key or the
key.
2. Use the Navigation keys to select each log in field and
then use the keypad to enter the appropriate
information.
3. Select
Options
➔
Sign In/On
, and press the
Select
soft
key or the key.
Using Message Templates
Your phone has message templates (both SMS and MMS) which
allows you to retrieve them when creating a message. You can
change the templates as your preferences or send a message
immediately.
57
1. At the Idle screen, select
Menu
➔
Messaging
➔
Templates
, and press the
Select
soft key or the
key.
2. Highlight a template type (Text or Multimedia) and
press the
Select
soft key or the key.
3. Use the
Up
or
Down
Navigation keys to select a current
template message and press the
Options
soft key to
access the following options:
•Edit
: allows you to change the currently selected template.
• Insert to Message
: allows you to insert the selected template
into a new text message.
• Add New
: allows you to add a new the template.
•Delete
: deletes the currently selected template.
4. Press the key to return to Idle mode when you
are finished.
Deleting Messages
You can delete the messages in each message folder(s)
individually or all at one time. You can also delete all of your
messages at one time.
1. At the Idle screen, select
Menu
➔
Messaging
➔
Delete
All
, and press the
Select
soft key or the key.
2. Using the
Up
or
Down
Navigation keys to select the
message folder(s) you want to empty.
3. Press the key to mark the folder you want to
delete.
•All
: allows you select all of the list items and mark each one for
content deletion.
• Inbox
: allows you select the your Inbox folder and mark its files for
deletion.
•Sent
: allows you select the your Sent folder and mark its files for
deletion.
•Outbox
: allows you select the your Outbox folder and mark its
files for deletion.
• Drafts
: allows you select the your Drafts folder and mark its files
for deletion.
• My Folder
: allows you select the your My Folder and mark its files
for deletion.
To view the contents in each folder, use the
Right
key
to display the folder’s contents or use the
Left
key to
close the folder’s contents.
4. To delete all of the messages in all folders, select
All
.
5. Press the
Delete
soft key. At the “Delete?” pop-up,
press the
Yes
soft key or the key to delete.
Messaging 58
6. Press the key to return to Idle mode when you
are finished.
Messaging Settings
You can set up various options for using messaging services.
1. At the Idle screen, select
Menu
➔
Messaging
➔
Messaging Settings
, and press the
Select
soft key or
the key.
2. Select the type of messages that you want to change
settings.
•Text Message
• Multimedia Message
• Voice Mail
• Push Message
3. Press the
Select
soft key or the key.
Text Message
The following options are available:
•
Sending Options
: allows you to set the following options:
–
Keep a Copy
: allows you to keep a copy of your sent messages.
•
Text Message Center Settings
: allows you to set the default method
of text message transmission used by the Text Message Center. The
options are:
–
SMS Settings
: allows you to configure the text delivery parameters
used when sending this type of message.
–
Email Settings
: allows you to configure the Email parameters used
when sending this type of message.
–
Empty
: allows you to configure a new Text Message Center profile for
use when sending this type of message.
Multimedia Message
The following options are available:
•
Sending Options
:
–
Priority
: you can select the priority level of your messages.
–
Expiration
: select the length of time you wish the message you sent to
remain on the MMS server.
–
Delivery
: you can set a time delay before the phone sends your
messages.
–
Size
: you can set the maximum allowed size for a multimedia
message.
–
Request Delivery Report
: when this option is enabled, the network
informs you whether or not your message was delivered.
–
Request Read Report
: when this option is enabled, your phone sends
a request for a reply along with your message to the recipient.
59
–
Keep a Copy
: you specify whether you want to keep a copy of the sent
messages on your phone.
–
Add My Business Card
: you send your content information along with
your sent messages.
•
Receiving Options
: you can specify the category of messages you
want to receive. Allows you to set the following:
–
Download Type
: allows you to set the message receipt options.
Choose from Auto Download, Manual, or Reject.
–
Send Delivery Report
: when this option is enabled, the phone allow
the network report to the sender whether or not the message was
received.
–
Send Read Report
: when this option is enabled, your phone sends a
notification back to the recipient indicating that your message was
received.
–
Reject Anonymous
: allows you to automatically reject messages with
a category of anonymous.
–
Reject Advertisement
: allows you to automatically reject messages
with a category of advertisement.
•
Multimedia Message Profiles
: you can select a connection profile
which is then used for sending and receiving Multimedia messages.
–
MMS Profiles
: allows you to select an option for sending a multimedia
message. Choose from the following options:
•
MEdia Net
•
AT&T MMS
•
AT&T IMS
–
Profile Settings
(accessed by pressing the
Options
soft key)
•
Set Name
•
Access Name
•
Auth Type
•
User ID
•
Password
•
Protocol
•
Home URL
•
Proxy address
•
Linger Time (Sec.)
•
Advanced Settings (Static IP, Static DNS, and Traffic Class)
–
Auto Resize Image
: you can specify that the received image by be
resized up/down:
•
No Resize
•
100 KB
•
300 KB
•
600 KB
–
Creation Mode
: you can specify that the users creating new media
content be given the following options:
•
Warning
•
Free
•
Restricted
–
Default Style
: you can specify the default visual parameters used by
this type of message:
•
Font Color
•
Font Style
Messaging 60
•
Background Color
•
Page Duration
Voice Mail
The following options are available:
•
Voicemail
: you can specify the default phone number used for access
of phone’s remote voicemail. If you select the
Edit
soft key, the
following fields display:
–
Name
: allows you to create a new descriptive name for this access
number.
–
Center Address
: allows you edit the existing number and create a new
number for use when accessing the remote voicemail.
Important!:
Changing the Voicemail Center Address can affect your ability to access
your voicemail. Check with your provider’s Customer Service before
changing.
Push Message
Push Messages are service provider-sent messages, that include
software upgrades or general information messages.
The following options are available:
•
Receiving Option
: you can specify whether to turn push message
reception On or Off.
•
Service Loading
: you can specify whether to load this service:
–
Always
–
Prompt
–
Never
Memory Status
You can check the amount of the memory being used and the
memory remaining for Multimedia, Text, Push, and Configuration
Messages. The display shows the total space including the used
and free space. You can also view how much space is currently
occupied by each message box.
1. At the Idle screen, select
Menu
➔
Messaging
➔
Memory Status
, and press the
Select
soft key or the
key.
2. Use your
Up
,
Down
,
Left
or
Right
Navigation keys to
select a particular folder for review.
3. Press the
Select
soft key or the key. The contents
of that folder are then listed.
4. Press the key to return to Idle mode when you
are finished.
61
Section 9: MEdia Net and WAP
Your phone is equipped with a WAP (Wireless Application Protocol)
browser which allows you to access the Internet. This section explains
how to access the WAP services of your service provider and navigate
the WAP browser.
Accessing the MEdia Net Home
1. In Idle mode, press the key to launch the WAP browser.
You can also select
Menu
➔
MEdia Net
➔
MEdia Net Home
,
and press the
Select
soft key or the key.
Your phone is connected to the network and loads the
MEdia Net homepage. The content of the start-up
homepage contains the following selections:
•Search field
: allows you enter a text string into the field and then
search the MEdia Net database for matches. Once you have entered a
word, press the
Right
Navigation key to select the
Search
button and
press the key to begin your search.
• My Links
: provides you with quick access to your those sites which you
have setup in this category. Highlight one of these entries and press the
key to launch that web page.
•Categories
: provides you with a list of MEdia Net web pages containing
links to a variety of special interest sites. Highlight a selection from this
list and press the key. These categories can be edited from within
Customize MEdia Net.
Note:
Prior to using these services, you must complete the MEdia Net registration process
located at: att.com/wireless. Prior to using some of these services, you must agree
to the terms of the service agreement and setup the service on your handset.
• My Account
: provides you with access to a listing of your most recent
purchases and available product (services). From the My Account
screen, highlight
My Purchases
and press the key to begin.
• Customize MEdia Net
: provides you with a list of MEdia Net setup and
service options which allow you to configure different aspects of the
MEdia Net experience. Highlight a selection from this list and press the
key.
–
Edit My Links
: provides you with a list of available Internet links which
you can choose to add to your My Links section of the main Media Net
homepage. To add a link, navigate to the Add to My Links section,
highlight an entry, and press the key. To remove a link, navigate to
the Move/Delete Links section, highlight an entry, and press the
key. From the Edit My Links page, highlight
Remove
, and press the
key.
–
Edit Categories
: allows you to edit those category entries which
appear on the MEdia Net homepage. Although the first four entries
(WHAT’S HOT, Tones, Games, Pics, and Cellular Video) can not be
removed, the remaining entries can be toggled on or off. Highlight a
category entry and press the key to toggle it on (appear on the
page) or off (remove it from the homepage).
MEdia Net and WAP 62
–
Parental Control
: provides you with settings which can be configured
to restrict certain media content from being downloaded on the phone.
For more information, refer to "Parental Controls" on page 38.
–
Username & Password
: allows you to setup a username and
password prior to gaining access to the MEdia Net homepage and
related services.
Note:
Prior to using this service you must agree to the terms of the service agreement
and setup the service on your handset.
–
MEdia Net Mail
: allows you to access and edit the entries found within
the MEdia Net messaging center. Although most of the entries can not
be removed, the remaining entries can be toggled on or off by
navigation to the top of the page, highlight
Edit
, and press the
key. From the Mail & Messaging page, highlight an entry and press the
key to toggle it on (appears on the Mail & Messaging page) or off
(remove it from the Mail & Messaging page).
–
MEdia Net Tour
: allows you to take a quick guided tour through the
main features of the MEdia Net pages (homepage, navigation, teams,
etc.).
–
Privacy Policy
: provides the web address for Cellular’s Privacy Policy.
•Help
: provides you with list of some of the most frequently asked
questions regarding MEdia Net functionality. Highlight a question and
press the key to launch an on screen description
2. To scroll through the screen, use the
Up
and
Down
Navigation keys.
3. To exit the browser at any time, simply press the key.
Accessing a MEdia Net Site
There are several ways to access a WAP site:
•
Selecting a link on the browser
•
Using a bookmark item in the Favorites folder; use the Bookmarks option on
the browser menu list or Favorites menu.
•
Entering a URL address manually; use the Go to URL option on the browser
menu list.
Navigating with the WAP Browser
1. To scroll through browser items, press the
Up
or
Down
Navigation keys.
2. To select a browser item, highlight a MEdia Net entry and
press the key or press the
Options
soft key and choose
Select
.
3. To return to the previous page, press the key, or press
the
Options
soft key and choose
Back
.
4. To access the browser menu list, press the
Menu
soft key.
5. To return to the start-up homepage, select
Menu
➔
Home
option and press the
Select
soft key or the key.
63
Entering Text in the WAP Browser
When you are prompted to enter text, the currently active text input
mode is indicated on the screen. To change the text input mode, press
the key one or more times.
The following modes are available:
•
Upper-Case Alphabet Mode (A)
: allows you to enter upper-case
characters.
•
Lower-Case Alphabet Mode (a)
: allows you to enter lower-case
characters.
Note:
You can enter symbols in upper or lower case alphabet mode by pressing the 1 key.
•
T9 Mode (T9)
: allows you to enter characters by pressing one key per letter.
In this mode, you can use only the 0 key to display alternative words. To
change case, press and hold the * key.
•
Number Mode (1)
: allows you to enter numbers.
Selecting and Using Menu Options
Various options are available when you are using the WAP Browser to
navigate the Wireless Web.
To access a option, press the
Options
soft key. A menu list displays.
Note:
The menus may vary, depending on your version of the WAP Browser.
The following options are available:
•
Go to
: lets you navigate Forward (next sequenced web page) or Backward
(to the previously visited web page) through pages in your browsing history.
•
Reload
: reloads the current page with updated information.
•
Smart-Fit View/Desktop View:
changes the display mode of the browser.
•
Page Size
: change the page size of the displayed web page (Large, Normal,
or Small).
•
Go to Homepage
: takes you back at any time to the homepage of the
Wireless Web service provider.
•
Add to Favorites
: bookmarks the current page and marks it as a favorite
site.
•
View Favorites
: accesses and displays the bookmarks assigned as favorite
web pages.
•
Send URL via
: send the URL of the current page via either a message or to
another party via a Bluetooth device.
•
Enter URL
: allows you to manually enter the URL address of a WAP site.
After entering an address, press the OK soft key to go there directly.
•
Copy URL to Message
: send the URL of the current page to another party as
a message.
•
Save
: saves either the image of the current web page or the current page
itself.
•
Saved Pages
: access the list of web pages you have saved.
•
History
: displays the list of web pages you have recently accessed.
•
Advanced
: allows you to change the following settings for the browser.
MEdia Net and WAP 64
–
Clear Cache
: deletes the information stored in the cache. The cache stores
the most recently accessed pages.
–
Empty Cookies
: delete cookies. Cookies are pieces of personal information
sent to a web server while navigating the web.
–
Cookie Options
: sets whether or not cookies are stored on your phone. If you
select Prompt, the phone prompts you to save the cookies on every page that
requires cookies.
–
Preferences
: changes the settings for the web browser to suit your
preference.
–
Certificates
: accesses certificate information from your phone.
–
Page Details
: displays the properties for the currently active web page.
–
Browser Settings
: selects a connection profile to be used when connecting
to the Internet.
–
About Browser
: displays the access version and copyright information about
the browser.
Using Favorites
While navigating through either the Internet or the MEdia Net pages,
you can bookmark a site to quickly and easily access it at a future
time. The URL addresses of the bookmarked sites are stored in the
Favorites folder, wherein you can either use the 6-preset URL
addresses or store your own favorite URL addresses.
Accessing a WAP Site Using Favorites
1. At the Idle screen, press the
Menu
soft key.
2. Highlight MEdia Net and press the
Select
soft key or the
key.
3. Select
Favorites
and press the
Select
soft key.
4. Select a bookmark item on the Favorite list. The preset
URLs consist of:
• Cellular Video
•Chat
•News
•Sports
• Weather
• MEdia Net (homepage)
5. Press the
Options
soft key to select
Go to
or press the
key.
Storing a URL Address as a Favorite
1. At the Idle screen, press the
Menu
soft key.
2. Select MEdia Net and press the
Select
soft key or the
key.
3. Select
Enter URL
and press the
Select
soft key.
65
4. Enter the URL address and press the key to launch the
web page.
Tip:
Use can use the key to cycle through that available symbols and choose the .
(period) and the @ (at) needed for most website addresses.
5. Press the
Options
soft key, and use the
Down
Navigation
key, highlight
Add to Favorites
and press the key.
6. Press the
Go to
soft key to launch the website.
7. Press the key to return to Idle mode when you are
finished.
Editing Favorites
1. From the
Favorites
list, select the bookmark you want to
change.
2. Press the
Options
soft key, highlight
Edit Favorites
and press
the key.
3. Change the address and the name, as you would when
storing a new one.
4. Press the
Save
soft key.
5. Press the key to return to Idle mode when you are
finished.
Deleting Favorites
1. From the Favorites list, select the bookmark you want to
delete.
2. Press
Options
soft key, highlight
Delete
and press the
key.
3. Highlight
Selected
and press the
Select
soft key or the
key.
4. Press the
Yes
soft key or the key to confirm the
deletion.
5. Press the key to return to Idle mode when you are
finished.
Downloading Multimedia Files
You can buy a variety of multimedia files, such as ringtones, graphics,
applications, Multimedia contents, and so on from the WAP browser
and download them to your phone’s memory. Your phone has
embedded links to the WAP sits providing you with download services,
preset by your service provider.
1. At the Idle screen, press the
Menu
➔
AT&T Mall
➔
Shop
Tones
,
Shop Games
,
Shop Graphics
,
Shop Multimedia
, or
Shop Applications
, depending on the type of items you want
MEdia Net and WAP 66
to buy.
2. To access homepage of the online shopping mall, select
MEdia Net Home
.
3. Find the item you want to download and follow the on-
screen instructions to purchase it.
Note:
This content is delivered to you in Multimedia messages. You can retrieve the
messages from the server and then save the items in your phone’s memory. you
cannot forward these messages to other people or add the saved items to a
Multimedia message.
Using your History
The History list provides you with a list of the most recently visited
web sites. These entries can be used to return to previously unmarked
web pages.
1. At the Idle screen, press the
Menu
➔
MEdia Net
➔
History
and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight an entry
from the list.
3. Press the
Options
soft key, highlight
Go to
and press the
Select
soft key or the key.
4. Press the key to exit from the browser when you are
finished.
Clearing Caches
A cache is the phone’s temporary memory in which the most recently
accessed web pages are stored. You can clear the caches at anytime.
1. At the Idle screen, press the
Menu
➔
MEdia Net
➔
Advanced
and press the
Select
soft key or the key.
2. Select
Clear Caches
and press the
Select
soft key or the
key.
3. Press the
Yes
soft key or the key to confirm the
deletion.
4. Press the key to return to Idle mode when you are
finished.
Clearing the Cookies
A cookie is a small file which is placed on your phone by a web site
during navigation. In addition to containing some site-specific
information, it can also contain some personal information (such as a
username and password) which can pose a security risk if not
properly managed. You can clear this cookies from your phone at any
time.
67
1. At the Idle screen, press the
Menu
➔
MEdia Net
➔
Advanced
➔
Empty Cookies
and press the
Select
soft key or the
key.
2. Press the
Yes
soft key or the key to confirm the
deletion.
3. Press the key to return to Idle mode when you are
finished.
Changing the WAP Profiles
Your phone is wirelessly connecting to the Internet via a built in WAP
browser. Connection can be made via either one of four available WAP
browsers: MEdia Net, AT&T MMS (MultiMedia Server), or AT&T IMS.
Use this menu to create and customize the profiles containing the
settings for connecting your phone to the network. You need these
settings to use the web browser or send MMS messages or e-mails.
Although the active connection can be changed by the user, it is
recommended that this choice be made with the assistance of either
the retailer or customer service representative.
1. At the Idle screen, press the
Menu
➔
MEdia Net
➔
Browser
Settings
, and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight one of these
options:
• MEdia Net
• AT&T MMS
• AT&T IMS
3. Press the
Options
soft key.
Note:
The WAPs are pre-configured and cannot be altered on this screen. The MMS
connection option can be edited, renamed, or deleted on this screen. Your phone is
set up by default for connecting to the network. If you change the settings without
first checking with your service provider, the web browser, MMS, and e-mail
features may not work properly.
4. To create a new connection, press the
Options
soft key,
select
New
, and press the
Select
soft key or the key.
- or -
5. To edit the existing MMS, highlight this entry, press the
Options
soft key, select
Edit
, and press the
Select
soft key or
the key.
6. Select the parameter you want to edit:
• Set Name
: enter a profile name.
• Access Name
: edit the access point name.
• Auth Type
: select the type of authentication used for this WAP
connection: None, Normal, or Secure.
MEdia Net and WAP 68
•User ID
: enter the User ID required to connect to the network.
• Password
: enter the user password required to connect to the network.
•Protocol
: set the connection protocol used by the WAP browser: WAP
or HTTP.
•Home URL
: enter the URL address of the page to be used as your
homepage.
• Proxy address
: (HTTP only) set the proxy server address and port.
• Linger Time (Sec.)
: sets a time period (in seconds) after which the
network is disconnected if there is no new data traffic.
• Advanced Settings
: allows you to configure some of the IP-specific
information: Static IP, Static DNS, Server information, and Traffic Class.
–
Static IP
: specify if you want to manually enter an IP address. If you
want the IP address to be automatically assigned by the server, remove
the check mark.
–
Local Phone IP
: enter the IP address obtained from the network
operator, if you checked the Static IP option.
–
Static DNS
: specify if you want to manually enter the Domain Name
Server (DNS) address. If you want the address to be automatically
assigned by the server, remove the check mark.
–
Server 1/Server 2:
enter the Domain Name Server (DNS) addresses.
–
Traffic Class:
select the traffic class.
Note:
The WAP settings may vary depending on the service provider.
69
Section 10: AT&T Mall
The AT&T Mall topics covered in this section are shopping for Tones,
Games, Graphics, Multimedia, and Accessing the MEdia Home site.
Shop Tones
The
Shop Tones
menu option allows you to shop for audio tones using
the built-in browser. You can download and save audio to either your
Audio
or Music
folder
.
To access this menu option, use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
Shop Tones
and press the
Select
soft key or the key to launch the
built-in browser and select a file to download.
Follow the on-screen options. The downloaded files can be
stored into either the
Audio
or
Music
folders found within the
My Stuff (Phone) location.
2. Select an audio file and press the key.
3. When you are ready to purchase the audio file, press the
Buy Now
button to complete the transaction.
Shop Games
The
Shop Games
menu option allows you to shop for games using the
built-in browser. You can download new games to your
Games
folder.
To access this menu option, use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
Shop Games
and press the
Select
soft key or the key to launch the
built-in browser and select a game to download.
Follow the on-screen options. The downloaded files can be
stored in the
Games
folder found within the My Stuff (Phone)
location.
2. Select a game entry and press the key.
3. When you are ready to purchase the game, press the
Buy
Now
button to complete the transaction.
AT&T Mall 70
Shop Graphics
The
Shop Graphics
menu option allows you to shop for graphic images
using the built-in browser. You can download new images to your
Graphics
folder. To access this menu option, use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
Shop
Graphics
and press the
Select
soft key or the key to
launch the built-in browser and select an image to
download.
Follow the on-screen options. The downloaded files can be
stored in the
Graphics
folder found within the My Stuff
(Phone) location. These images can be used as wallpapers
or included into multimedia messages.
2. Select an image entry and press the key.
3. When you are ready to purchase the image, press the
Buy
Now
button to complete the transaction.
Shop Multimedia Content
The
Shop Multimedia
menu option allows you to shop for multimedia
files using the built-in browser. You can download new videos to your
Videos
folder. To access this menu option, use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
Shop
Multimedia
and press the
Select
soft key or the key to
launch the built-in browser and select a video file to
download.
Follow the on-screen options. The downloaded files can be
stored in the
Video
folder found within the My Stuff (Phone)
location. These files can be included into multimedia
messages or sent as attachment files to text messages.
2. Select an video file entry and press the key.
3. When you are ready to purchase the file, press the
Buy Now
button to complete the transaction.
71
Shop Applications
The
Shop Applications
menu option allows you to shop for application
files using the built-in browser. You can download the new
applications to your
Applications
folder. To access this menu option,
use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
Shop
Applications
and press the
Select
soft key or the key
to launch the built-in browser and select an application to
download.
Follow the on-screen options. The downloaded applications
can be stored in the
Applications
folder found within the My
Stuff (Phone) location. These files can be included into
multimedia messages or sent as attachment files to text
messages.
2. Select an application file entry and press the key.
3. When you are ready to purchase the application, press the
Buy Now
button to complete the transaction.
Accessing the MEdia Net Home
The
MEdia Net Home
menu option allows you to quickly access your
MEdia Net homepage. This page gives you quick access to
information such as local weather, sports scores, horoscope
information and quick links to the previously mentioned shopping
sites. To access this menu option, use the following steps:
1. At the Idle screen, select
Menu
➔
AT&T Mall
➔
MEdia Net
Home
and press the
Select
soft key or the key to
launch the built-in browser and launch this AT&T
homepage.
AT&T Music 72
Section 11: AT&T Music
AT&T Music is a music service which provides you access to
Streaming Music, Music Videos, Music store, Music communities,
Music applications, and a unique MusicID application.
Accessing AT&T Music
ᮣ
At the Idle screen, select
Menu
➔
AT&T Music
and press the
Select
soft key or the key.
Note:
Audio files less than 300 KB are treated as ringtones, whereas audio files which are
greater than 300 KB are stored in the Music Folder.
A user can not set an MP3 file as a ringtone if it is larger than 300 KB.
Adding Music to your Handset
Music files (such as ringtones) can be added to your handset by using
one or more of the following methods:
•
Download music and ringtones over the AT&T network directly to your
device by using the Shop Music feature.
•
Add music from your existing digital media collection through Windows
Media Player®.
•
Add music from music store partners through the applicable music client.
Note:
If the Bluetooth feature is currently active on your handset, USB communication is
not available. To transfer files to your handset, turn off the Bluetooth functionality
(
Settings
➔
Set Connectivity
➔
Bluetooth
).
Shopping for Music
AT&T Music can be used to shop for ringtones, Answer Tones™ and
songs from some of your favorite music stores.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Shop Music
and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight your music
store of choice (or select Ringtones), and press the
Select
soft key or the key.
3. From the
Categories
listing, highlight the desired entry and
press the key. Press the
Back
soft key to return to the
previous page.
4. To exit the browser at any time, simply press the key.
73
Transferring Music from the Digital Music Stores
In order to download music from the computer to your handset, a
microSD™ card and USB data cable are required. These items are
sold separately; go to
att.com/mobile-music
.
1. Insert the microSD™ card into the handset. For more
information see "Installing the microSD™ Card" on page 3
2. Using your computer, open your preferred Windows Media
Digital Rights Management (WMDRM) PC music
management client (i.e.,
www.napster.com
).
3. Download the selected song to your library.
4. Use the USB adapter cable to connect the handset to the
target PC. When an active connection is established, a USB
icon ( ) displays on the phone.
5. Once the USB connection is established, the handset
displays "
Connected
" and the computer screen then
displays your device. If the detection occurs, skip to step
11.
Note:
If the target computer does not detect the newly connected handset or provide an
MTP Player dialog window on the PC screen, please follow steps 6 - 10.
6. At the Idle screen, select
Menu
➔
Settings
➔
Set
Connectivity
and press the
Select
soft key or the key.
7. Select
Select USB Mode
➔
Media Player
and press the
Save
soft key or the key.
8. Highlight the song you wish to download to the handset.
9. Using your right mouse button, click on the highlighted song
and select
Transfer Track(s) to Portable Device
from the
drop-down menu. This step begins the download process.
When downloading music from WMDRM clients, there are specific
icons that indicate that the music is protected by the WMDRM client.
These icons display in the Music Player window.
Indicates that the music was downloaded for playing
only (cannot be forwarded).
Indicates that the music was downloaded with digital
protections against unauthorized use.
Indicates that the music was stored on the SIM card.
Indicates that the music was downloaded from a
WMDRM client.
AT&T Music 74
Transferring Music using a Media Application
A USB cable, microSD™ card, and a current version of a media
application (such as Windows Media Player) are required for this
procedure.
1. Open the media player on your computer (if you are using
Windows Media Player, use version 10.0 or higher).
2. Use the USB adapter cable (sold separately) to connect the
handset to the target PC. When an active connection is
established, a USB icon ( ) displays on the screen.
3. Once the USB connection is established, the handset
displays "
Connected
" and the computer screen then
displays your device.
Note:
If the target computer does not detect the newly connected handset or provide an
MTP Player dialog window on the PC screen, please follow steps 6 - 10 from the
previous see "Transferring Music from the Digital Music Stores" on page 88
Note:
The following steps reflect the procedure used with Windows Media Player. If you
are using some other form of media player, please refer to the application’s Help
files for specific directions.
4. From within the Windows Media Player application, click on
the
Sync
tab. Previously downloaded songs are then listed
on the left side of the application.
5. Choose the destination location for the media files. The
SGH-A827 - Phone
and
SGH-A827 Card
entries both display in
a drop-down list on the right side of the screen. This
selection determines whether the audio files are
synchronized with the Phone or with the inserted memory
card.
Note:
If there are no items present in the playlist, click the
Edit Playlist
button and begin
adding the music files from among the various media categories.
6. Click on the checkmark boxes (to the left of the song entry)
to select the song(s) you want to synchronize to your
handset.
7. Click the
Start Sync
button at the upper right corner of the
application to download the selected songs to your handset.
A “
synchronization in progress
” message displays on the
screen. Do not unplug the handset during this process.
Once complete, a Music folder displays below the device
entry on the right of the
Sync
tab.
75
8. It is now safe to unplug the USB connector from the
handset.
Using the Music Player
The Music Player is an application that can play music files. The
music player supports files with extensions AAC, AAC+, eAAC+, MP3,
WMA, 3GP, MPEG, MP4, and M4A. Launching the Music Player allows
you to navigate within your Music folders and select playback
material.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to highlight a folder from
the list:
• Now playing
: displays the songs that were recently played.
• All Music
: provides a list of all uploaded music files which have been
purchased or downloaded from your computer. This can include
ringtones, answer tones, and music.
•Artists
: provides a list of the artists that you have music stored.
• Albums
: provides a list of albums that you have stored.
• Playlists
: provides a list of your music playlists. These playlists provide
access to streaming music streams. See ‘Using Playlists” on page 92.
•Genres
: provides a list of your music by music genre (e.g. rock, jazz, or
classical) if that information was available when the music was loaded to
the handset.
• Shop Music
: allows you to shop online music and download to the
handset.
3. Select a playlist, album, genre, artist, or individual song.
4. Press the
Options
soft key. Highlight
Open
and press the
Select
soft key or the key to begin playing the song.
Playing Music Transferred to the Handset
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key.
2. Highlight
All Music
and press the key to open the folder.
3. Use the
Up
or
Down
Navigation key to select the song you
want to listen to and press the key, or just press the
key to begin playing all the music stored on the
handset and/or the microSD™ card.
Playing Music through a Stereo Bluetooth Device
Your device supports the Stereo Bluetooth profile (A2DP) that when
synched to a stereo Bluetooth headset plays music in stereo.
1. Pair your handset to a stereo Bluetooth device. For specific
pairing procedures, For more information, refer to “Set
Connectivity” on page 120.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
AT&T Music 76
Player
and press the
Select
soft key or the key.The
following options display:
•
Now playing
•
All Music
•
Artists
•
Albums
•
Playlists
•
Genres
•
Shop Music
2. Make your selection and press the key to open the
folder.
3. Use the
Up
or
Down
Navigation key to select a song and
press the key to play the song within the Music Player.
4. During playback, press the
Options
soft key. Highlight
Play
via
➔
Bluetooth stereo headset
and press the key. The
headset searches for compatible stereo bluetooth devices.
5. From the list of compatible devices, select the previously
paired bluetooth headset and press the key to begin
listening to your song through the headset.
Playing Music while Multitasking
The Multitasking option allows you to play the Music Player in the
background while performing other tasks on your phone. The music
pauses when an incoming call is accepted, and the music resumes
when the call ends. Music continues to play when you receive a Text
Message, Multimedia Message, or an Instant Message.
The other options of multitasking are:
•
Call
: make or receive a call (music player is paused)
•
Messaging
: send or receive a text or multimedia message. Music continues
to play unless an audio clip is received as a part of a multimedia message.
•
MEdia Net
: browse the web (music continues to play).
•
Music Player
: turns on Music Player, or allows you to use full-screen
controls of the music player.
•
Games and Apps
: lets you play games or access applications while
listening to music.
Important!:
Playing music and pausing the music player requires the same amount of
battery power.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key. The
following options display:
•
Now playing
•
All Music
•
Artists
•
Albums
•
Playlists
77
•
Genres
•
Shop Music
2. Make your selection and press the key to open the
folder.
3. Use the
Up
and
Down
Navigation keys to find the music you
want to play.
4. Once the music starts to play, the music icon displays on
the top of the screen ( ). Press the
Options
soft key and
highlight the
Hide Player
option, and press the key.
5. Press the key to return to the Idle screen. The
Music
Player
displays as center key options.
To go to the previous song press the
Rewind
(
Left
Navigation
key). To temporarily stop the music press
Pause
( ). To
advance to the next song, press
Fast Forward
(
Right
Navigation key).
After the Music Player is enabled, you can listen to music in the
background while performing other phone functions.
Important!:
When you are finished using the Music Player function, you must press the
key to stop the function to prevent the battery from losing its charge.
The player continues to use the battery while Pausing.
Using Playlists
Playlists are used to assign songs to a list of preferred media which
can then be grouped into a list for later playback. These Playlists can
be created via either the handset’s Music Player options menu or from
within a 3rd-party music application (such as Windows Media Player)
and then downloaded to the handset.
Note:
The Music Player does not necessarily support all features of a particular file format
nor all the variations of those formats. The Music Player includes support for
Windows Media Digital rights Management (WMDRM) which allows you to play
some purchased or subscription content. Copyright protections may prevent some
images, music (including ringtones) and other content from being copied, modified,
transferred or forwarded.
Creating a Playlist
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key.
2. Select
Playlists
and press the
Options
soft key.
3. Highlight
Create Playlist
and press the
Select
soft key or the
key.
The list of available music folders display. Select by album
name, artist, genre, or all music. The list of music available
for that option displays.
AT&T Music 78
4. Go through the list of music, using the key to select
one or multiple songs to add to the playlist.
5. Press the
Done
soft key when you have finished selecting
the songs for the playlist. The Music Player will prompt you
for a name for the playlist.
6. Enter the name of the playlist, and press the
Save
soft key.
Adding songs to a Playlist
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key.
2. Highlight
Playlists
and press
Options
➔
Open
and press the
key.
3. Highlight a previously created playlist and press the
key.
4. Press the
Options
➔
Add Tracks
and press the key.
The list of available music folders display. Select by album
name, artist, genre, or all music. The list of music available
for that option displays.
5. Go through the list of music, using the key to select
one or multiple songs to add to the playlist.
You can choose to add All available songs. All selects all of
the available listed songs and marks them for addition to
the playlist.
6. Press the
Done
soft key and confirm the name of the playlist
to which you want to add the song.
7. Press the
Save
soft key and wait for the song to be added to
the current playlist.
Remove songs from a Playlist
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music
Player
and press the
Select
soft key or the key.
2. Select
Playlists
➔
Options
➔
Open
and press the key.
Highlight the existing playlist and press the
Options
soft key.
3. Highlight
Delete Tracks
and press the key.
The number of songs currently in that playlist display below
the playlist name.
4. Use the
Up
or
Down
Navigation key to highlight an audio file
(or multiple files) and press the key to select.
5. Press the
Done
soft key.
79
6. Confirm the playlist name that you are editing, and press
the
Save
soft key.
Importing a Playlist from a 3rd Party Application
Note:
While this procedure specifies Windows Media Player, other 3rd-party music
applications can be used to download songs and playlists to your handset. Refer to
the Help files of your specific music application for details.
1. Open Windows Media Player on your computer (version
10.0 or higher).
2. Use the USB adapter cable to connect the handset to the
target PC. When an active connection is established, a USB
icon ( ) displays on the screen.
3. Once the USB connection is established, the handset
displays "
Connected
" and the computer screen then
displays the A827 device.
Note:
If the target computer does not detect the newly connected handset or provide an
MTP Player dialog window on the PC screen, please follow steps 6 - 10 from the
previous see "Transferring Music from the Digital Music Stores" on page 88.
4. From within the Windows Media Player application, click on
the
Library
tab.
5. From the left side of the
Library
tab, click on
All Music
. The
right side of the page is then populated with all of the songs
which the player has previously found.
6. Right click on the song entry and select,
Add to.. >
Additional Playlists
.
7. From the
Add to Playlist
dialog, click the
New
button and
type in a unique playlist name.
8. Click
OK
when you are done entering the new playlist name.
The new Windows Media playlist is then displayed within
the
My Playlist
section of the Library tab (left side).
9. Drag and drop the newly created playlist from the
My
Playlist
section to the
A287-Phone
or the
A827-Card
entry
listed just above it.
The
A827-Phone
and
A827-Card
entries both display on the
left side of the screen.
Note:
If there are no items present in the playlist, click the
Edit Playlist
button and begin
adding the music files from among the various media categories.
10. It is now safe to unplug the USB connector from the
handset.
AT&T Music 80
Using MusicID
MusicID is an application which uses the onboard microphone to
analyze a song sample and then compare it to a remote database of
songs. Once the application completes the analysis of the song
sample, it then provides you with the name of the song, artist and
album art as well as opportunities to buy related content.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
MusicID
and press the
Select
soft key or the key. You are then
presented with a list of ID options:
• ID song!
: begins the analysis of the song being sampled through the
handset’s microphone.
• manage IDs
: provides a list of recently identified song and allows you to
obtain information about the song, delete the song, or send the Music ID
as a link to another phone number.
•help me out
: provides you with on screen descriptions of several key
MusicID features.
•exit
: allows you to exit the application and return to the main AT&T
Music menu.
2. To exit the application at any time, simply press the
key.
Using ID song!
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
MusicID
and press the
Select
soft key or the key.
2. Highlight
ID song!
and press the key.
3. Place the handset’s microphone up to the source of the
song, which can be from either a radio, stereo, or headset.
The handset then begins to analyze the audio signal. If a
song match is found, the screen displays the Artist Name,
Track Title, and Album cover art.
4. To purchase the song (with ringtone and wallpaper if
available), highlight
get:
, and press the key.
5. To share the song ID with another user, highlight
Share ID
press the key. Enter the recipient’s phone number and
press the
ShareID!
soft key. Within a short time the recipient
receives a message containing a Music ID link to the song.
6. If the song can not be found, the handset displays a “Sorry,
No Match Try Again!” message. Press the
newID!
soft key
and try analyzing the song again.
7. To exit the application at any time, simply press the
key.
81
Using Manage IDs
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
MusicID
and press the
Select
soft key or the key.
2. Highlight
Manage IDs
and press the key. The screen
displays a list of the most recent successful song IDs which
were made.
3. Highlight a song and press the
Options
soft key.
4. Highlight one of the following options and press the
key.
•ID Info
: displays the Artist Name, Track Title, and Album cover art of the
identified song.
• Delete ID
: deletes the selected song from the list of identified songs.
•New ID!
: begins the song analysis process again. Hold the microphone
to the song source and wait for analysis.
5. To exit the application at any time, simply press the
key.
Getting Help with Music ID
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
MusicID
and press the
Select
soft key or the key.
2. Highlight
help me out
and press the key to select a
topic. The screen displays a list of helpful topics related to
the musicID application. These topics cover:
• IDing a Song
: provides information about the analysis process.
• Recommendations and More!
: describes the process following the
successful identification of a song. You can choose to purchase the song
and wallpaper (if available) or send the musicID as a link to another
phone number.
• Subscription
: provides details about the general usability and monthly
term information.
• About Music ID
: provides information about the Music ID software
version.
Exiting from the Music ID Application
There are two ways to exit from the musicID application:
1. Highlight
exit
and press the key to select the option
2. Exit the application at any time by simply pressing the
key.
Streaming Music
This service allows you to stream over 30 channels of commercial
free music through your handset.
AT&T Music 82
Note:
Since this product uses a large amount of data in its stream process, you should
note that you are responsible for all data charges incurred. It is recommended that
you subscribe to a MEdia Max data bundle so that you are not charged for data
overages.
Note:
XM Radio Mobile does not work with Bluetooth. Periodically, the application
prompts the customer to confirm they are still listening to the stream.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Streaming
Music
and press the
Select
soft key or the key.
2. Use the
Down
Navigation key to scroll through the following
list of available Menu options:
•Back
: if you are already streaming a music station, this option allows
you to return to the main guide.
• Guide
: launches the main XM Radio Mobile page which lists the
currently available radio stations. Once the subscription is purchased,
this list increases from those available only during the trial period, to
more than 30 music stations.
•Help
: provides some on screen information about some of the main XM
Radio Mobile features and functions.
• About
: provides information about the XM Radio Mobile software
version.
•Exit
: allows you to exit from the Streaming Music application and return
to the main AT&T Music menu.
Streaming a Music Channel
1. Press the
OK
soft key to accept the terms of the trial period.
You have only a few days to use the service before the trial
period expires. If at any time you wish to purchase a
subscription to the XM Radio Mobile service, press the
Buy
soft key and follow the on screen prompts.
2. Use the
Up
or
Down
Navigation key to highlight a radio
station category from the guide list and press the key.
3. Use the
Up
or
Down
Navigation key to highlight a specific
radio channel and press the key to begin the stream to
your phone.
Music Video
The Music Video homepage is a component of the Cellular Video
service. This page provides you with links to some of the most popular
multimedia content.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music Video
and press the
Select
soft key or the key.
You are then taken to your CV Music homepage. This
homepage provides you with several sections of accessible
content.
83
2. Highlight the desired media clip or select from one of the
available categories and press the key.
Music Video Options
The options for the Music Video page are identical to those options
provided for within the Cellular Video homepage. For more
information, refer to “Cellular Video Options” on page 36.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
Music Video
and press the
Select
soft key or the key.
2. From the main Music Video homepage, press the
Options
soft key.
Viewing a Video Clip
1. Use the
Up
or
Down
Navigation key to highlight the video
clip and press the
Select
soft key or the key.
2. After the stream buffers into memory, you can choose to
either Pause or play the content. Pressing the key
toggles the
Play
and
Pause
functionality.
The Buzz
This service allows you to navigate through Top 20 chart songs (in a
variety of categories). Other features of this service include streaming
entertainment news about your favorite music artists, access to an
artists main page (containing discographies, ringtones, concert
dates,etc..), concert information, games, and setup options for your
own personal billboard notifications.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
The Buzz
and press the
Select
soft key or the key.
2. Press the
Trial
soft key to accept the terms of the trial
period. You have only a few days to use the service before
the trial period expires. If at any time you wish to purchase
a subscription to this service, press the Buy soft key and
follow the on screen prompts.
3. Enter an area code, phone number (without dashes), and
Zip code into the appropriate fields on the Customize
screen. Use the
Up
or
Down
Navigation key to switch
between fields.
4. Press the
Confirm
soft key to accept and save your
information.
5. Once the phone number is successfully registered, press
the
OK
soft key to continue onto the main Billboard mobile
menu where you are given a list of categories from which to
select.
AT&T Music 84
6. To exit the application at any time, simply press the
key.
Community
This Community is a place where you can find a listing of various fan
sites that provide sound clips, wallpapers, bios, discographies, and
other information about an artist.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
AT&T Music
➔
Community
and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to select a fan site and
press the key. These pages can contain a variety of
sites for music or artist information.
3. To exit the application at any time, simply press the
key.
Music Apps
The Music Apps option accesses the internet to provide Music tools
for your handset. Services provided on this site are, Music ID, XM
Radio Mobile, Billboard Mobile Channel, MobiTV: Live TV, and MobiTV
en Espanol.
1. At the Idle screen, select
Menu
➔
AT&T Music
➔
AT&T Music
➔
Music Apps
and press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to select a fan site and
press the key to make your selection.
85
Section 12: Using the Applications
The on-board applications (such as camera, camcorder, calendar, and
alarms) can be supplemented with additional applications which can
be purchased via the AT&T Mall.
ᮣ
At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
and press
the
Select
soft key or the key.
Shop Applications
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
and press the
Select
soft key or the key.
2. Using the navigation keys, select
Shop Applications
. For
more information, refer to “Shop Applications” on page 85.
Using the Camera
Taking Photos
Note:
When taking a photo in direct sunlight or in bright conditions, shadows may appear
on the photo.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
and press the
Select
soft key or the key. Or you can
press and hold the
Camera
key on the right of the handset.
2. Using the navigation keys, select
Camera
and press the
key.
3. Before taking the photo, press the
Menu
soft key to access
camera options accessed from icons above the viewfinder
display.
4. Adjust the image by aiming the camera at the subject.
5. Press the key to take the photo.
6. Once the photo is taken, press the key to attach the
photo to a message.
Note:
Your camera produces photos in JPEG format. The number that displays in the
lower-left of the screen indicates the current number of pictures that were saved to
the selected media and an approximate number of total pictures which can be
taken at the current image size.
The maximum size of a photo taken with the camera on any setting is within the
limits that can be sent in a Multimedia Message.
7. Press the
Back
soft key to return to the picture viewer.
You can use the keypad to quickly change the camera options using
the camera shortcut keys.
Using the Applications 86
Camera Settings Options
If you press the
Menu
soft key before shooting a photo, the following
options are displayed below the icons listed across the top of the
viewfinder window.
•
Shooting Mode
: allows you to take a photo in various modes. Once you
change the mode, the corresponding indicator displays at the top right of the
screen. The modes are:
–
Camera
–
Camcorder
–
Video Share
•
Image type
: allows you to select an image type from the following:
–
Single shot
: allows you to take a single photo and view it before returning to
the shooting mode. Press the
Select
soft key to set the camera to either: Take
& Review or Take & Return.
–
Multi-shot
: allows you to take a succession of consecutive photos. Press the
Select soft key to set the number of shots.
–
Mosaic style
: allows you to take up to four photos and then have them
grouped together into a single final photo. Press the Select soft key to set the
number of these mosaic photos
.
–
Frame shot
: allows you to choose a custom frame border for your. Choose
from one of the 20 available frames.
–
Panorama
: allows you to choose a panoramic shot.
•
Image Size
: allows you to select an image size from the following options:
–
1280x960 (1.3M size)
–
640x240
–
320x240
•
Timer
: allows you to set a time delay before the camera takes the photo.
–
Off
–
3 seconds
–
5 seconds
–
10 seconds
•
Lighting
: allows you to set a lighting condition from the following options:
–
Auto
–
Daylight
–
Incandescent
–
Fluorescent
–
Cloudy
•
View Effects
: allows you turn on or off the ability view what the different
effects will have on the photo.
•
Effects
: allows you to choose a custom color tone for your photo. Choose
from the following Effects Mode.
–
No Effects
: automatically adjust the picture for the best quality available.
–
Black & White
: removes all color and display the picture as black and white.
–
Sepia
: adds a sepia tint to the picture. This is the common orange tint that
was popular in early photography.
–
Negative
: changes the image to a negative image display.
87
–
Help
: allows you to see the shortcuts for various options, and to see a brief
description.
–
Settings
: allows you to change the default settings of the camera options.
Camera Options
Camera options available after the photo has been taken and you are
still at the viewfinder screen are:
•
Take photo
: allows you to take another photo.
•
Send
: allows you to send the photo via a message, a Bluetooth device, or to
HP’s Snapfish\xaa application.
•
Set as
: allows you to set the photo as Wallpaper for your display, or as a
Caller ID.
•
Rotate
: allows you to rotate the photo to landscape.
Accessing the Graphics Folder
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Graphics
and
press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to select a photo.
3. To open the photo, press the key.
Photo Options after Photo is Taken
If you navigate to the Graphics folder, the options before you select a
specific photo are:
•
Take Photo
: allows you to take a photo.
•
Create Folder
: allows you to create a new subfolder in the Graphics folder.
Once you have selected a graphic, but not loaded it, the options are:
•
View
: allows you to view the photo.
•
Send
: allows you to attach the graphic to a message, send it to a Bluetooth
device, or to send to the Sony ImageStation® photo service.
•
Set as
: allows you to set the currently selected graphic to be displayed on
the Main Display or assigned to a Caller ID.
•
Move
: allows you to move either a Selected or Multiple graphics to one of
the My Stuff (Phone) folders.
•
Copy
: allows you to make a copy of the Selected or Multiple graphics and
then send it to one of the My Stuff (Phone) folders.
•
Delete
: allows you to delete either Selected, Multiple, or All graphics.
•
Rename
: allows you to rename the graphic.
•
Take Photo
: allows you to take a photo.
•
Create Folder
: allows you to create a new subfolder in the Graphics folder.
•
Sort by
: allows you to sort the list of graphics by either: Date, Type, Name,
or Size.
•
Bluetooth Visibility
: allows you to select either Selected or Multiple
graphics visibility to Bluetooth devices.
Using the Applications 88
•
Print via
: allows you to make a selected graphic printable by either USB or
Bluetooth printer.
•
Lock
: allows you to lock the photo.
•
Properties
: allows you to view the properties of a photo.
Once you have selected and loaded the graphic, the options change
to:
•
Zoom
: allows you to zoom in or out on the existing photo.
•
Send
: allows you to attach the graphic to a message, send it to a Bluetooth
device, or to send to HP’s Snapfish photo service.
•
Set as
: allows you to set the currently selected graphic to be displayed on
the Main Display or assigned to a Caller ID.
•
Delete
: allows you to delete either Selected, Multiple, or All graphics.
•
Rename
: allows you to rename the graphic.
•
Edit
: allows you to edit the loaded photo, using the following options:
–
Save as
: allows you to name the photo.
–
Effects
: allows you to use effects for the entire photo: including Black and
White, Sepia, Negative, Milky, Lighting, Crayon Pastel, Oil Paint, Blur,
Despeckle, and Sharpen.
–
Partial effects
: allows you to used effects that affect only specific areas of a
photo, such as Partial Blue and Redeye Repair.
–
Adjust
: allows you to adjust the Brightness, Contrast, and Color of the photo.
–
Transform
: allows you to Resize, Rotate, or Flip the photo image.
–
Crop
: allows you to crop or remove unwanted areas framing your photo.
–
Insert
: allows you to insert Frames, Cliparts, Emoticons, and Text.
–
Send
: allows you to attach the graphic to a message, send it to a Bluetooth
device, or to send to the Sony ImageStation® photo service.
–
Set as
: allows you to set the currently selected graphic to be displayed on
the Main Display or assigned to a Caller ID.
–
Print via
: allows you to make a selected graphic printable by either USB or
Bluetooth printer.
•
Bluetooth Visibility
: allows you to select either Selected or Multiple
graphics visibility to Bluetooth devices.
•
Slide Show
: allows you to create a slide show of all photos in the folder.
•
Print via
: allows you to make a selected graphic printable by either USB or
Bluetooth printer.
•
Lock
: allows you to lock the photo.
•
Properties
: allows you to view the properties of a photo.
Camera Shortcuts
Shortcut keys allow you to change options using your keypad,
Navigation keys, and Volume key in capture mode. The following
options are available.
takes photo.
adjust the image brightness (Left/Right).
zooms in or out (Up/Down). Not allowed if the picture
size is set to its maximum value.
89
Using the Camcorder
Shooting Video
When shooting video in direct sunlight or in bright conditions, it is
recommended that you provide your subject with sufficient light by
having the light source behind you.
1. In Idle mode, select
Menu
➔
My Stuff
➔
Applications
➔
Camera
and press the
Select
soft key or the key.
2. Press the key to switch to the camcorder.
3. Before shooting the video, you can adjust the camcorder
settings using the follow options accessed by pressing the
Menu
soft key.
4. Adjust the image by aiming the camera at the subject.
5. Press the key to begin shooting video.
6. Press the
Stop
soft key to stop the recording and save the
video file to your My Stuff folder.
Camcorder Settings Options
•
Recording Mode
: allows you to set the maximum allowable recording time.
The default for Recording Mode is Multimedia Message. Changing from this
default may prevent you from sending the video using MMS.
–
Multimedia Message
: allows you to select from 10 Seconds, 30 Seconds, For
Full Memory, or Video Share.
–
Normal
: allows you to film up to the full amount of available memory.
•
Size
: allows you to set the video size. Choose 320x240 or 176x144.
switches the handset between camera and camcorder
mode
changes the image size.
changes the image quality.
changes the camera shooting mode.
changes the effects of the photo.
within the camera mode, this loads frame option #20
on screen.
sets a time delay (Off, 3, 5, or 10 seconds).
switches to the Photo Album.
adds a quadrant overlay to help you position your shot.
Using the Applications 90
•
Timer
: allows you to set a time delay before the camcorder begins to shoot
video.
–
Off
–
3 seconds
–
5 seconds
–
10 seconds
•
White Balance
: allows you to set the white balance for the camcorder.
Choose Auto, Daylight, Cloudy, Incandescent, or Fluorescent.
•
Effects
: allows you to choose a custom color tone for your video. Choose
from the following Effects Mode.
–
No Effects
: automatically adjust the picture for the best quality available.
–
Black & White
: removes all color and display the picture as black and white.
–
Sepia
: adds a sepia tint to the picture. This is the common orange tint that
was popular in early photography.
–
Negative
: changes the image to a negative image display.
•
Audio Recording
: turn audio recording with your video On or Off.
•
Help
: allows you to see the shortcuts for various options, and to see a brief
description.
•
Settings
: allows you to change the default settings of the camera options.
Camcorder Options
Before leaving the camcorder viewfinder after recording the video, the
following options are available by pressing the
Options
soft key:
•
Record Video
: allows you to take another video.
•
Send via
: allows you to attach the multimedia file to a message or send it to
a Bluetooth device.
Accessing the Video Folder
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Video
and
press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to select a video file.
3. To play the video, press the
Select
soft key or the key.
The file is played in the Media Player application.
4. Press the
Back
soft key to return to the camcorder viewer.
5. You can use the keypad to quickly change the camera
options using the camera shortcut keys.
Video Options
Once you have navigated into your Video folder, but have not
highlighted a video, the following options display:
•
Record Video
: allows you to take another video.
•
Create Folder
: allows you to create another folder within the Video folder.
Once you have highlighted a video, but have not loaded it, the
following options are available:
•
Play
: allows you to play the video clip.
91
•
Send via
: allows you to attach the multimedia file to a message or send it to
a Bluetooth device.
•
Move
: allows you to move either a Selected or Multiple videos to one of the
My Stuff (Phone) folders.
•
Copy
: allows you to make a copy of the Selected or Multiple videos and then
send it to one of the My Stuff (Phone) folders.
•
Delete
: allows you to delete Selected, Multiple, or All videos.
•
Rename
: allows you to rename a video.
•
Record Video
: allows you to go back to the Camcorder viewfinder and
record another video.
•
Create Folder
: allows you to create another folder within the Video folder.
•
Sort by
: allows you to sort the list of files by either: Date, Type, Name, or
Size.
•
Bluetooth Visibility
: allows you to make either a Selected or Multiple videos
visible to Bluetooth devices.
•
Lock
: allows you to lock the video file to prevent deletion.
•
Properties
: allows you to view the properties of a video file.
Once you have loaded the selected video clip, the following options
are available:
•
Play/Resume
: allows you to play/resume playing the video clip.
•
Stop
: allows you to stop playing the video clip.
•
Jump to Track Time
: allows you to jump to a specific time in the video.
•
Send via
: allows you to attach the multimedia file to a message or send it to
a Bluetooth device.
•
Full screen
: allows you to view the video using the full display screen.
•
Properties
: allows you to view the properties of a video file.
Once the video has completed playing, the following options are
available:
•
Play
: allows you to play the video.
•
Send via
: allows you to attach the multimedia file to a message or send it to
a Bluetooth device.
•
Properties
: allows you to view the properties of the video clip.
Camcorder Shortcuts
Shortcut keys allow you to change options using your keypad,
Navigation keys, and Volume key in capture mode. The following
options are available.
shoots video.
adjust the image brightness (Left/Right).
zooms in or out (Up/Down).
switches the handset between camera and camcorder
mode.
changes the video size.
Using the Applications 92
Music Player
This feature allows you to access both local and streaming music,
video, or playlists and then play then through a built in Music Player.
For more information, see “Using the Music Player” on page 75.
Record Audio
Record Audio allows you to record voice memos. It also allows you to
send your audio clip to other people as an attachment of an MMS
message. Recording time is limited to free memory space available.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Audio
➔
Record Audio
and press the
Select
soft key or the key.
2. To start recording, press the key. Record a memo by
speaking into the microphone. Options available before an
audio recording is made are:
• Record
: allows you to start recording an audio clip. If you are planning
to send the Audio Clip via MMS, set the Record Audio Setting >
Recording Time to Limit for MMS.
• My Voice Clips
: allows you to go to the My Stuff folder for previously
recorded voice clips.
• Record Audio Settings
: allows you to set up a recording preset:
Default Name and Recording Time (1 min, 2 min, 3 min, 4 min, 5 min,
or 60 min, Limit for MMS).
3. Press the
Stop
soft key to stop the recording or pause the
recording by pressing the key. If the recording time
expires, the message is automatically saved.
4. Press the
Options
soft key to display the following options:
•Play
: allows you to play the memo.
• Record
: allows you to save the current memo and begin another
session.
• My Voice Clips
: allows you to save the audio clip to your My Stuff
folder.
• Record Audio Settings
: allows you to set up a recording preset:
Default Name and Recording Time (1 min, 2 min, 3 min, 4 min, 5 min,
or 60 min, Limit for MMS).
• Send via
: allows you to send your memo to other people by using MMS
or to a Bluetooth device.
changes the video quality.
changes the recording mode.
changes the effects used on the video.
within the camcorder mode, this toggles the
microphone On/Off (mute).
sets a time delay (Off, 3, 5, or 10 seconds).
opens the Video folder where the videos are stored.
93
•Set as
: allows you to set the audio file as a voice call ringtone, a
ringtone for a specific caller, or an alarm tone.
• Delete
: allows you to delete the memo.
•Rename
: allows you to change the memo’s name.
• Bluetooth Visibility
: allows you to make the audio file visible to a
Bluetooth device.
•Lock
: allows you to lock the Audio file.
• Properties
: displays the Name, Size, Format, Duration, Forwarding,
Created Date/Time, and storage Location of the voice memo.
5. To save these changes, press the
Save
soft key.
6. To exit, press the
Back
soft key or the key.
Audio
This folder shows a list of audio clips. Audio clips include default tones
that come with the handset, audio clips you have downloaded, and
audio clips you have recorded. When a voice memo is recorded and
saved, it is stored in the Audio folder. To access this folder, use the
following steps:
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Audio
and
press the
Select
soft key or the key.
2. Use the
Up
or
Down
Navigation key to select a recorded
memo.
3. A list of voice memos displays. To play a recording, press
the
Options
soft key and select
Play
, or the key.
4. To exit, press the
Back
soft key or the key.
Alarms
This feature allows you to:
•
set the alarm to ring at a specific time.
•
set the phone to switch on automatically and ring the alarm even if the
phone is switched off.
To set the alarm:
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Alarms
and press the
Select
soft key or the key. The
following options display:
• Wake-up Alarm
: the alarm rings to wake you up at the specified time.
• Alarm 1
: primary alarm setting.
• Alarm 2
: secondary alarm setting.
• Alarm 3
: third alarm setting.
• Alarm 4
: fourth alarm setting.
• Auto Power-up
: the alarm rings even when the phone is turned off.
Using the Applications 94
2. Select an alarm type and press the
Options
soft key or the
key. Set the following options:
• Alarm Activation
: Use this to activate/deactivate this feature (On/Off).
The only way to edit the remaining fields is to select On.
•Alarm Time
: use the alphanumeric keypad enter a time for the alarm to
sound.
Note:
Your phone is preset to a 12-hour format. To change the time format, see "Set Time
& Date" on page 110.
• Alarm Type
: press the key to select a new type of alert notification
(Melody, Increasing Melody, Vibration, Vibration then Melody, Vibration &
Melody, or Vibration & Increasing Melody)
• Alert Tone
: press the key to select a tone from one of the My Stuff
folders.
• Alarm Volume
: press the Left and Right Navigation key to adjust the
volume level (1-7).
•Alarm Day
: press the key to access the Recurrence menu. Use the Up
or Down Navigation key to highlight a occurrence of the day(s) you wish
your alarm to sound. Press the key to select the day entry. Press the OK
soft key to save your settings.
• Snooze
: use this option to set the snooze feature for the alarm (Off,
1 Min., 3 Min., 5 Min., 7 Min., or 10 Min).
• Repeat
: use set the number of times this alarm type can be repeated (1
Time, 2 Times, 3 Times, 5 Times, or 10 Times). Snooze must be active
for this feature to be enabled.
3. Press the key to save these changes.
Note:
To turn off the alarm when it rings, open the phone and press any key, or press the
OK
soft key if the phone is already open.
Setting the Auto Power-up Alarm
You can set up the phone to ring an alarm, even if the phone is
switched off.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Alarm
➔
Auto Power-up
and press the
Select
soft key or
the key.
2. Using the
Up
or
Down
Navigation key, highlight
On
and press
the
Save
soft key or the key to activate the Autopower
feature.
If the menu option is set to
Off
, and the phone is switched
off at the specified time, the alarm does not ring.
3. Press the key to return to Idle mode when you are
finished.
95
Calendar
The calendar feature allows you to view the Month, Week, and Day
layout views. You can also create an Appointment, Anniversary,
Holiday, Important, or Private entries. It also shows any Missed Alarm
Events that have occurred.
To access the Calender menu, use the following steps:
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Calendar
and press the
Select
soft key or the key.
2. Press the
Options
soft key. Highlight
Create
.
3. Press the
Select
soft key or the key. The following
options are available:
• Appointment
• Anniversary
• Holiday
•Important
•Private
4. Other options for the Calendar include:
• Settings
: this option allows you to configure the Calendar’s Starting Day
and Default View Mode.
•Missed Alarm Event
: this option displays any missed events.
•Memory Status
: this option displays a list of the different Calendar
event categories along with the memory allocation for each.
Appointment
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Calendar
and press the
Select
soft key or the key.
2. Press the
Options
soft key. Highlight
Create
, select
Appointment
, and press the
Select
soft key or the key to
use the following options:
• Title
: enter a title for this appointment (up to 15 characters).
• Details
: enter a description for this appointment (up to 100 characters).
• Start Date
: enter a date for this appointment to begin.
•Start Time
: enter a time for this appointment to begin. Use the
Right
Navigation key to select AM or PM for the start time of the scheduled
event.
• End Date
: enter a date for this appointment to end.
• End Time
: enter a time for this appointment to end. Use the
Right
Navigation key to select AM or PM for the start time of the scheduled
event.
•Location
: enter a location description for this appointment (up to 15
characters).
•Alarm
: allows you to set an alarm for this event. Press the key to select
this option. Once selected, all remaining alarm settings are enabled.
• Before:
allows you to the amount of time (minutes, hours, days) before
your appointment, you wish the alarm to sound.
• Alarm Tone
: allows you to choose an alarm tone. Once highlighted,
press the
Options
soft key,
Select
option to select this audio file.
• Repeat
: allows you to set an the number of repetitions allowed for this
appointment (Daily, Weekly, or Monthly). Use the
Right
or
Left
Using the Applications 96
Navigation keys to select. Once selected, all remaining alarm settings
are enabled.
•Every
: allows you to set an the number of times the entry is repeat in
the selected time frame.
• Except Weekends
: allows you to exempt non-work days (weekends)
from the appointment schedule.
•Until
: allows you to set as duration for this appointment by assigning an
expiration date).
3. Press the key to save this new appointment entry when
you are finished.
Anniversary
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Calendar
and press the
Select
soft key or the key.
2. Press the
Options
soft key. Highlight
Create
, select
Anniversary
, and press the
Select
soft key or the key to
use the following options:
•Title
: enter a title for this occasion.
• Details
: enter details for the occasion.
•Date
: enter a date for this anniversary to begin.
•Alarm
: allows you to set an alarm for this event. Press the key to
select this option. Once selected, all remaining alarm settings are
enabled.
–
Before
: allows you to the amount of time (day, week) before your
appointment, you wish the alarm to sound.
–
Alarm Time
: allows you to enter a time for the alarm to begin notifying
you of the occasion. Use the
Right
Navigation key to select AM or PM.
–
Alarm Tone
: allows you to choose an alarm tone. Once highlighted,
press the key to select this audio file.
• Repeat Every Year
: allows you to set whether this entry is repeated on
a yearly basis. Press the key to select this option. Once selected,
all remaining alarm settings are enabled.
3. Press the key to save this new anniversary entry when
you are finished.
Note:
The remaining Calendar entry types (Holiday, Important, or Private entries) contain
similar fields and use similar creation procedures.
Other Event Options
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Calendar
and press the
Select
soft key or the key.
2. Select a day containing a Calendar entry and press the
key. If the selected day has one or multiple Calendar
entries, those are then displayed in a list.
Viewing an Event
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Calendar
and press the
Select
soft key or the key. The
calendar displays with today date highlighted.
97
2. Select the date of the event (s) you want to view and press
the key, or use the Navigation keys to move to the date
with an assigned event.
Note:
The icon categories displayed at the bottom display any events scheduled for the
day you selected.
3. Press the
Up
or
Down
Navigation key to scroll to the
previous or next event. Highlight an entry and press the
Options
soft key to use one of the following Calendar entry
options:
•View
: this option allows you view the details for a selected event.
•Create
: this option allows you to add an additional event to the selected
day(s).
• Send via
: allows you to send this event via a text message or Bluetooth
device.
•View Mode
: allows you select the view mode for the calendar: either
Week View or Month View.
• Event List
: allows you to view all events of a specific type.
• Delete
: allows you to delete the event.
•Save to My Stuff
: allows you to save the event to your My Stuff folder.
• Print via Bluetooth
: allows you to print the event information using a
Bluetooth printer.
• Settings
: this option allows you to configure the Calendar’s Starting Day
and Default View Mode.
•Missed Alarm Event
: this option displays any missed events.
•
M
emory Status:
this option displays a list of the different Calendar
event categories along with the memory allocation for each.
4. Press the key to return to Idle mode when you are
finished.
Tasks
This menu option allows you to create a “to do” entry of tasks which
are created in a similar fashion to previously described Calendar
entries.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tasks
and press the
Select
soft key or the key.
2. Press the
Options
soft key. Highlight
Create
, and press the
Select
soft key or the key to use the following options:
• Title
: enter a title for this task (up to 15 characters).
• Details
: enter a detailed description for this task (up to 100 characters).
• Start Date
: enter a date for this task to begin.
•Due Date
: enter a date for this task to end.
•Priority
: allows you assign the task a priority (1, 2, or 3).
•Alarm
: allows you to set an alarm for this event. Press the
Right
Navigation key to select this option. Once selected, all remaining alarm
settings are enabled.
–
Alarm Date
: allows you to the specify the date you wish the alarm to
sound.
Using the Applications 98
–
Alarm Time:
enter a time for this alarm to sound. Use the
Right
Navigation key to select AM or PM for the start time of the alarm and
press the
Select
soft key.
–
Alarm Tone
: allows you to choose an alarm tone. Once highlighted,
pess the key to select this audio file.
3. Press the key to save this new appointment entry when
you are finished.
Tools
Tools are feature options that allow you to use your handset for a
variety of non-phone related activities. To access any of the tools,
perform the following:
ᮣ
At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
and press the
Select
soft key or the key.
Notes
This option allows you to create notes to add to your events.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Notes
and press the
Select
soft key or the key.
2. A blank New Notes screen displays. Press the
Options
soft
key. Highlight
Create
, and press the
Select
soft key or the
key.
3. Enter your text and press the
Options
soft key and then the
Save
soft key.
Calculator
With this feature, you can use the phone as a calculator. The
calculator provides the basic arithmetic functions; addition,
subtraction, multiplication, and division.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Calculator
and press the
Select
soft key or the
key.
2. Enter the first number using the numeric keys.
3. To include a decimal point or a bracket, press the left soft
key until the symbol you want displays.
4. Enter the operation for your calculation by pressing the
Navigation keys, according to the illustration on the display.
5. Enter the second number.
6. To view the result, press the key.
Tip Calculator
With this feature, you can use the phone to calculate the amount of
money left as a tip based on parameters such as: total bill amount, tip
percentage, and number of members in your party.
99
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Tip Calculator
and press the
Select
soft key or the
key.
2. Enter the values into the appropriate fields by using the
numeric keys:
• Bill
•Tip(%)
• # paying
3. To include a decimal point by pressing the key.
4. The remaining fields indicate:
• Tip($):
the amount of the tip based on the figures entered.
•You pay:
your share of the total check amount. This value is based on
the figure entered within the # paying field.
Converter
The conversion menu provides the following conversion categories:
•
Currency
•
Length
•
Weight
•
Volume
•
Area
•
Temperature
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Converter
and press the Select soft key or the
key.
2. Highlight the specific converter function, and press the
Select
soft key or the key.
World Time
World Time allows you to view the time of day or night in another parts
of the world. World displays time in the 30 different major cities
representing the 24 time zones around the world.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
World Time
and press the
Select
soft key or the
key.
2. Use the
Left
or
Right
Navigation keys to browse cities and
times.
3. Press the key or the Set DST soft key to indicate that
the selected time zone has Daylight Savings Time (DST).
The displayed time shifts to reflect the time zone and usage
of DST.
4. Default time zone for the handset is set under the
Settings
➔
Set Time & Date
.
Using the Applications 100
Timer
You can use this menu to set a countdown timer. To enable the Timer,
use the following options:
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Timer
and press the
Select
soft key or the key.
2. Press the
Set
soft key to enter the length of time.
3. Enter the time and press the
OK
soft key.
4. Press the key to start the timer. Press the key to
stop the timer.
Stopwatch
You can use this menu to measure intervals of time for 50 separate
times.
1. At the Idle screen, select
Menu
➔
My Stuff
➔
Applications
➔
Tools
➔
Stopwatch
and press the
Select
soft key or the
key.
2. Press the key to start the stopwatch.
3. Press the to stop the stopwatch. Press the
Reset
soft
key to erase all times recorded.
101
Section 13: Understanding Your Address Book
This section allows you to manage your daily contacts by storing their
name and number in your Address Book, either on your phone or on
the SIM card. Address Book entries can be sorted by name, entry, or
group.
Note:
When storing an Address Book entry into the SIM card, note that only the Name,
Phone Number, Group, and Slot location are initially displayed. To save additional
information for a particular contact, such as other phone numbers, or e-mail, it is
important to add new fields to that Contact information. It is also important to note
that if you move the SIM card to another phone that does not support additional
fields on the SIM card, this additional information may not be available.
Using Contacts
Dialing a Number from Address Book
Once you have stored phone numbers in the Address Book, you can
dial them easily and quickly by either using their SIM card location
number or by using the Search field to locate the entry.
Note:
The default Address Book entries are: Check Bill Balance - *225#, Directory
Assistance - 411,
MusicID - #43, Pay My Bill - *729, View My Minutes - *646#, Voice Connect - *08,
*Now - *669.
Finding an Address Book Entry
You can store phone numbers and their corresponding names onto the
SIM card and phone’s onboard memory. They are physically separate
but are used as a single entity, called the Address Book.
Depending on your particular SIM card, the maximum number of
phone numbers the SIM card can store may differ.
1. At the Idle screen, select
Menu
➔
Address Book
, and press
the
Select
soft key or the key.
2. Enter the first few letters of the name.
The Address Book entries are then listed, starting with the
first entry matching your input.
3. To select a different entry, press the
Up
or
Down
Navigation
key until the entry you want is highlighted.
4. Once you have found the entry, press the key to dial
the number, or press the
Options
soft key to access the
Address Book entry options.
Understanding Your Address Book 102
Address Book Entry Options
While accessing any Address Book entry, press the Options soft key to
use the options for the entry.
The following options are available:
•
View
: provides you with details about that contact entry. Press the Back soft
key to return to the Address Book listing.
•
Add New Contact
: allows you to add a new entry to either your Phone or
SIM card.
•
Call
: allows you to call a currently selected entry.
•
Video Share
: innitiates a Video Share Call with this contact, with either live
video or a pre-recorded video clip.
•
Send Message
: allows you to send a text message or a multimedia
message to the selected entry.
•
Edit
: allows you to edit the properties of an entry such as: Name, Category,
Group, or location. Press the key to save your changes.
•
Duplicate
: allows you to duplicate a selected entry. Press the key to
save your duplicate entry.
•
Delete
: allows you to delete either a selected address book entry or multiple
entries from a target location such as the Phone and/or SIM card.
•
Save to My Stuff
: allows you to copy the contact information from its
current location to your My Stuff folder.
•
Send Business Card via
: allows you to send a message to the selected
entry which contains a Business Card. Business Card information can be
your own Business Card, or other Business Cards stored in your Address
Book. This can be sent as either a message or via Bluetooth wireless device.
•
Assign Speed Dial
: allows you to set the speed dial key for this entry.
•
Add to Reject List
: allows you to add the contact to your reject list.
Incoming calls from those on your Reject List go directly to voice mail
•
Copy to Phone/SIM
: allows you to copy selected or multiple contact
information from the SIM to the phone or from your phone to the SIM.
•
Move to Phone/SIM:
allows you to move selected or multiple contact
information from the SIM to the phone or from your phone to the SIM.
•
FDN Contacts
: Fixed Dialling Number mode restricts your outgoing calls to a
limited set of phone numbers. When this feature is enabled, you can make
calls only to phone numbers stored on the SIM FDN list.
•
Copy to FDN Contacts
: allows you to copy the list of restricted phone
numbers from your phone to the FDN section of the SIM card.
•
Print via Bluetooth
: allows you send the selected contact entry information
to a Bluetooth-compatible printer.
•
Management
: allows you to create My Business Card, set Speed Dial, Save
New Contacts to (default), View Contacts from, Own Number, Service
Number, and shows the memory status (the amount of memory allocation
for the following categories: Phone, SIM, Additional No.1 (SIM card),
Additional No.2, Email, and FDN).
Adding a New Contact
Use the following procedures to store a new contact to your Phone or
SIM Card.
103
Storing a Number in the Phone’s Memory
1. At the Idle screen, enter the phone number of a contact not
in your Address Book.
2. Select
Options
➔
Save to Address Book
, and press the
Select
soft key or the key.
3. Choose the target location for the entry (Phone or SIM),
press the
Select
soft key or the key.
4. Press the
Select
soft key or the key to assign this
number as a New entry.
5. From the
Select Type
screen, select from the following
category types:
• Mobile - Private
: assigns the number entered as a Private Mobile
entry.
•Mobile - Business
: assigns the number entered as a Business Mobile
entry.
• Landline - Private
: assigns the number entered as a Private Landline
entry.
• Landline - Business
: assigns the number entered as a Business
Landline entry.
•Fax
: assigns the number entered as a Fax entry.
•Etc.
: allows you to classify the entry as a miscellaneous type.
6. Enter alphanumeric characters into each of the available
fields:
• First Name
: allows you enter a first name for this entry.
•Last Name
: allows you enter a Last name for this entry.
• Display Name
: allows you enter a display name for this entry which
then displays when you receive a call from this contact.
• Phone Number
: allows you keep or alter the currently entered phone
number.
• Number Type
: allows you to enter an additional landline-private
number to this entry.
•Contact E-mail
: allows you to enter a contact E-mail address for this
entry.
•Group
: allows you to assign this contact to group. Press the Options soft
key to display available groups. Use the Up or Down Navigation keys to
select a group. Press the
Select
soft key or the key to save your
selection.
• Caller ID
: allows you to set a graphic to the Caller ID for this contact.
Press the
Options
soft key or the key to access the My Stuff
menu.
• Ringtone
: allows you to choose a ringtone for this contact information.
Press the
Options
soft key or the key to access the My Stuff
menu.
• Instant Messaging
: allows you to assign an Instant Message profile to
this entry. Press the key to access the IM menu.
•Note
: allows you enter notes associated with this contact.
7. Press the
Options
soft key or the key to save the
information for this entry.
Understanding Your Address Book 104
Storing a Number in the SIM Card
Note:
When storing an Address Book entry into the SIM card, note that only the Name,
Phone Number, Group, and Slot location are initially displayed. To save additional
information for a particular contact, such as other phone numbers, or e-mail, it is
important to add new fields to that Contact information.
Important!:
It is important to note that if you move the SIM card to another phone that
does not support additional fields on the SIM card, additional information
beyond the Name, Phone Number, Group, and Slot Number is not available.
1. At the Idle screen, either enter the phone number of a
contact not in your Address Book, or go to your Address
Book by selecting the
Menu
soft key and highlight
Address
Book
.
2. Press the
Select
soft key or the key.
3. Select the Address Book entry you wish to add and press
the
Options
soft key, or scroll to
Address Book Options
➔
Add
New Contact
by pressing the
Up
or
Down
Navigation key and
press the
Select
soft key or the key.
4. When offered the choice between Save to Phone or Save to
SIM, select SIM and press the
Select
soft key or the
key.
5. Enter the following information for the New Contact.
•Name
: allows you to enter a name for the number entered.
• Phone Number
: assigns the number entered to the entry.
•Group
: allows you to assign the contact to a group, such as Office,
Family, Friends, or a group you have created.
•Location
: allows you to assign a location on the SIM for the contact
being entered.
6. Press the key to save your new entry and return to a
screen which then lists the details of your new entry onto
the SIM.
7. To view available options for this entry, press the
Options
soft key:
•Edit
: allows you to edit the properties of an entry such as: Name,
Number, or Location. Press the key to save your changes.
•Call
: allows you to call a currently selected entry.
• Video Share
: innitiates a Video Share Call with this contact.
• Send Message
: allows you to send a text message or a multimedia
message to the selected entry.
• Duplicate
: allows you to duplicate a selected entry. Press the key to
save your duplicate entry.
• Delete
: allows you to delete the currently selected address book entry
from a target location.
•Save to My Stuff
: allows you to copy the contact information from its
current location to your My Stuff folder.
• Mark Default Num ber
: allows you to mark a default number to be
used for this contact.
105
• Send Business Card via
: allows you to send a message to the
selected entry which contains the information from their Address Book
entry which you have on file. This can be sent as either a message or via
Bluetooth.
• Add to Reject List
: allows you to add this contact to your Reject List.
• Copy to Phone/SIM
: allows you to copy the contact information from
the SIM to the phone or from your phone to the SIM.
• Move to Phone/SIM
: allows you to move the contact information from
the SIM to the phone or from your phone to the SIM.
• Copy to FDN Contacts
: allows you to copy the restricted phone
number list to the FDN section of the SIM card.
• Print via Bluetooth
: allows you send the selected contact entry
information to a Bluetooth compatible printer.
8. To return to the Idle screen, press the key.
Dialing a Number from the SIM Card using the
Location Number
1. In Idle mode, enter the location number for the phone
number you want to dial and press the key.
2. The contact entry information displays.
3. Press the
Up
or
Down
Navigation key to find other numbers
on the list.
4. Press the
Call
soft key, the key, or the key when
you have selected the number you want to call.
Speed Dial List
Once you have stored phone numbers from your Address Book list,
you can set up to 8-speed dial entries on the
Speed Dial List
and then
dial them easily whenever you want, simply by pressing and holding
the associated numeric key.
Note:
Memory location 1 is reserved for your Voice mail server number.
In Idle mode, to speed dial the numbers assigned to keys to
, press and hold the appropriate key.
Setting Up Speed Dial Entries
All Speed Dial List entries must already be in your Address Book.
1. From the Idle Screen, select
Menu
➔
Recent Calls
and press
the
Select
soft key.
2. Set up a recent call as a contact in your Address Book (see
“Adding a New Contact” on page 102.).
3. Once the contact is saved to the Address Book, the new
entry highlights, and you may press the
Options
key and
select the
Assign Speed Dial
option. Press the
Select
soft
key.
Understanding Your Address Book 106
4. Select the key in which you wish to assign the speed-
dialing number (from the 2 to 9 keys), and press the
Select
soft key or the key.
You may also assign Speed Dial numbers by going directly to the
Address Book and following steps 3 and 4.
Changing a Number Assigned to a Key
1. From the Idle Screen, select
Menu
➔
Recent Calls
➔
Speed
Dial List
, and press the
Select
soft key or the key.
2. Select the Speed Dial entry key you wish to change that
already has a contact assigned to it, and press the
Options
soft key.
3. Select
Remove
, and press the
Select
soft key or the
key.
4. Select the Speed Dial number, and press the
Options
soft
key, and select
Add
.. Choose where the new contact is
located (Address Book or FDN Contacts), and press the
Select
soft key or the key.
The Address Book or FDN Contacts list displays.
5. Select the contact to assign to the Speed Dial number, and
press the
Select
soft key or the key.
The Speed Dial List displays with the new contact assigned
to the number.
6. Press the key to return to Idle mode when you are
finished.
Deleting Speed Dial Entries
1. From the Idle Screen, select
Menu
➔
Recent Calls
➔
Speed
Dial List
, and press the
Select
soft key or the key.
2. Select the Speed Dial entry key you wish to remove that has
a contact assigned to it, and press the
Options
soft key.
3. Select
Remove
, and press the
Select
soft key or the
key.
4. Press the key to return to Idle mode when you are
finished.
Finding My Own Phone Number
This function is a memory aid, which you can use to check your own
phone number if you need to do so.
You can assign a name to each of your own phone numbers registered
on the SIM card. You can also edit the names and numbers. Any
changes made here do not in any way affect the actual subscriber
numbers on the SIM card.
107
1. At the Idle screen, select
Menu
➔
Settings
➔
Set Phone
➔
Own Number
, and press the
Select
soft key or the key.
Important!:
While this field is editable, changing this number could affect your ability to
use the handset.
Using FDN Mode
FDN (Fixed Dialing Number) mode, if supported by the SIM card,
restricts your outgoing calls to a limited set of phone numbers. When
this feature is enabled, you can make calls only to phone numbers
stored in the FDN list on the SIM card.
1. At the Idle screen, select
Menu
➔
Address Book
➔
Options
➔
FDN Contacts
, then press the
Select
soft key or the key.
2. The FDN List screen displays. If there are no FDN numbers
assigned, press the
Options
soft key and select
Create FDN
Contact
.
3. You must enter your PIN2 password. This number is
provided to you by your Service Provider.
4. Enter the FDN number and select from the following
options:
•Off
: you can call any number.
•On
: you can only call the phone numbers stored in the
SIM FDN
list.
Copy to FDN Contacts
1. Highlight an entry in the Address Book, press the
Options
soft key, and select the
Copy to FDN Contacts
option.
2. You must enter your PIN2 password. This number is
provided to you by your Service Provider.
3. Enter the FDN number and press the
Select
soft key or the
key.
Group Settings
Editing a Caller Group
1. At the Idle screen, select
Menu
➔
Address Book
➔
Contact
List
➔
Groups
and press the
Select
soft key or the key.
2. Scroll through the list of groups by pressing the
Up
or
Down
Navigation key.
3. Highlight the target group entry and press the
Options
soft
key.
4. Highlight
Group Settings
, press the
Select
soft key or the
key.
The following options are then available:
•Picture
: allows you to view the assigned group image.
Understanding Your Address Book 108
• Ringtone
: allows you to set the ringtone associated with this group.
Selecting Ringtones takes you to your
My Stuff
folder, where you can
choose recorded audio files, default ringtones, or downloaded ringtones
from the
Audio
folder.
5. Once you’ve made your changes, press the
Options
soft key,
select
Save
and press the
Select
soft key or the key.
6. Press the key to return to Idle mode when you are
finished.
Managing Address Book Entries
You can copy, delete, and view the memory status for the Phone and
SIM entries on your phone.
Copying an Entry to the Phone
You can copy a SIM entry to the Phone by using the Duplicate option.
When you copy entries to the phone, duplicate entries are created.
1. At the Idle screen, select
Menu
➔
Address Book
, press the
Select
soft key or the key.
2. Select an entry which currently resides on the phone.
•
If the entry’s associated Group graphic has a SIM location icon on it, then
the entry already exists on the SIM card. This is the type you can
duplicate.
•
If the entry’s associated Group image does not have a SIM location icon,
then this entry currently already exists on the phone.
3. Press the
Options
soft key, highlight
Copy to Phone
, and
press the
Select
soft key or the key.
4. Press the key to return to Idle mode when you are
finished.
Note:
Options are available for phone entries that are not available when stored to the
SIM card. For details see "Storing a Number in the Phone’s Memory" on page 106
Deleting All of the Address Book Entries
You can delete All, Phone, SIM, and SIM (FDN) entries from your
phone’s memory.
1. At the Idle screen, press the
Menu
➔
Address Book
➔
Options
➔
Multiple
, press the
Select
soft key or the key.
2. Choose the location of the Address Book entries you wish to
delete (
Phone
,
SIM,
or
Phone & SIM
), press the
Select
soft
key or the key.
3. Highlight
All
and press the key.
You can remove the check mark by pressing the key
again. Selecting
All
places a checkmark adjacent to every
entry in the list.
109
4. Press the
Delete
soft key to delete the entries from the
selected memory location.
5. At the
Delete?
confirm screen, press the
Yes
soft key to
continue, or the
No
soft key to cancel.
6. Enter the password and press the
Confirm
soft key or the
key.
7. Press the key to return to Idle mode when you are
finished.
Checking the Memory Status
You can check how many names and numbers are stored in the
Address book, in both SIM card and the phone memory. You can also
see the capacity of both memories.
1. At the Idle screen, select
Menu
➔
Address Book
➔
Options
➔
Memory Status
by pressing the
Up
or
Down
Navigation
key and press the Select soft key or the key.
2. Press the key to return to Idle mode when you are
finished viewing your phone’s Memory Status.
Using the Service Dialing Numbers
You can view the list of Service Dialing Numbers (SDN) assigned by
your service provider. These numbers include emergency numbers,
customer service numbers and directory inquiries.
1. At the Idle screen, press the
Menu
➔
Address Book
➔
Options
➔
Service Number
, and press the
Select
soft key or
the key.
2. Scroll through the numbers by using the
Up
or
Down
Navigation key.
3. To dial the number displayed, press the key.
Note:
This menu is available only when the SIM card supports Service Dialing Numbers.
Changing Your Settings 110
Section 14: Changing Your Settings
This section explains the sound and phone settings for your
phone. It includes display settings, security settings, and extra
settings associated with your phone.
Quick Tips
Quick Tips is a web-based information service that offers
Frequently Asked Questions and Tips for specific devices. When
you select this option, your handset is identified and FAQs for this
handset display.
Set Sound Profile
You can customize various profiles for your phone by changing
the sound settings.
1. Select
Menu
➔
Settings
➔
Set Sound Profile,
and press
Select
or the key.
2. Use the
Down
Navigation key to scroll through the list
of available options.
Normal Profile
In the Set Profiles option, the soft keys can be used for different
purposes.
•
Left Soft Key:
Save
•
Center Key ( ):
Edit
•
Right Soft Key:
Back
Use the
Left
and
Right
Navigation keys to move between the
various tabs.
This menu allows you to alter the audio settings for the following
categories:
Call:
•
Call Alert Type
: allows you to select the way in which the selected
ringtone is played when a call comes in on the phone.
–
Melody
: the phone sounds the selected melody.
–
Increasing Melody
: the phone sounds the selected melody, which
increases in volume until the call is answered, rejected, or goes to
voice mail.
–
Vibration then Melody
: the phone vibrates initially, but then plays the
melody.
–
Vibration & Melody
: the phone vibrates and also plays the melody.
111
–
Vibration & Increasing Melody
: the phone vibrates and also plays the
melody, which increases in volume until the call is answered, rejected,
or goes to voice mail.
•
Call Ringtone
: allows you to select a ringtone from your My Stuff
(Phone) folder which contains not only the default phone ringtones, but
also any new ringtones which have been downloaded from the
Internet.
•
Ringtone Volume
: allows you to select the volume that the ringtone is
played. The range is from 1-7.
Message:
•
Message Alert Type
: allows you to select the way in which you are
alerted to an incoming message alert.
–
Melody
: the phone sounds the selected melody.
–
Vibration
: the phone vibrates only.
–
Vibration & Melody
: the phone sounds the selected melody and
vibrates at the same time.
–
Mute
: the phone does not reflect an incoming message except through
an incoming message alert on the display.
•
Message Alert Tone
: allows you to select the alert tone that the phone
plays.
•
Message Alert Repetitions
: allows you to select how often the
Message Alert Tone sounds: either Once or Periodic.
•
Message Tone Volume
: allows you to select the volume that the
ringtone is played. The range is from 1-7.
Phone:
•
Keypad Tone
: allows you to choose the tone for pressing the keypad
keys. Options are: Beep, Xylophone, and Mute.
•
Power On Type
: allows you to select the way in which you are alerted
when the phone is powered on. Options are:
–
Melody
: the phone sounds the selected melody.
–
Vibration
: the phone vibrates only.
–
Vibration & Melody
: the phone sounds the selected melody and
vibrates at the same time.
–
Mute
: the phone does not reflect an incoming message except through
an incoming message alert on the display.
•
Power Off Type
: allows you to select the way in which you are alerted
when the phone is powered off. Options are:
–
Melody
: the phone sounds the selected melody.
–
Vibration
: the phone vibrates only.
–
Vibration & Melody
: the phone sounds the selected melody and
vibrates at the same time.
–
Mute
: the phone does not reflect an incoming message except through
an incoming message alert on the display.
•
Phone Sound Volume
: allows you to select the volume that the phone
sounds are played. The range is from 1-7.
Changing Your Settings 112
Other Available Profiles
The phone can be set to additional audio profiles which are
available via the Profiles menu. Although each profiles has
similarities, they have each been preset to use different audio
parameters for incoming phone call alerts, message alerts, and
phone usage. For more information, refer to “Icons” on page 13.
Note:
If your phone is in Silent Mode, the Low Battery Indicator defaults to
Vibration. If you change the Silent Mode alert from Vibrate to Mute, you see
only a flshing icon indicating a low battery.
Note:
The Silent profile can also be activated by pressing and holding the key
or by reducing the volume to 0. An on screen message notifies you that the
new Silent profile is now active. To deactivate this profile, press and hold the
key again.
Note:
To make changes to a profile, highlight the desired Profile and press the Edit
key . Make your changes, then press the
Options
soft key and highlight
the
Save
option.The phone displays a verification of profile change.
The
Silent
profile causes the speaker to be muted and
the phone only vibrates or displays information on its
LCD. This icon is accompanied on screen by the
Vibration or Mute icon.
The
Driving
profile keeps the speaker active and
launches the currently selected ringtone or melody
when the associated notification is activated.
The
Outdoor
profile keeps the speaker active, the
volume settings are raised to their highest levels, any
currently active ringtones or melodies are activated,
and the phone’s vibrate feature is activated. This icon
is accompanied on screen by the Vibration/Audio
icon.
113
Set Display
In this menu, you can change various settings for the display or
backlight.
1. Press the
Menu > Settings > Select
soft key.
2. Select
Set Display > Select
soft key or the key.
The options following are available. Use the
Down
Navigation key
to scroll to and set options.
Display Settings
•
Wallpaper
: allows you to select from either the preloaded wallpapers
found in the My Stuff (Phone) folder or photographs which have been
either taken with the camera or downloaded from the Internet. The
None option leaves the wallpaper blank. Press the Up or Down
Navigation keys to make your selection. Press the Set soft key or the
key to make your selection.
•
Greeting Message
: allows you to enter the text which displays on the
screen when the phone powers on.
•
Menu Style
: allows you to select whether the phone’s menus are
presented in Grid Menu style or List Menu style. Press the
Up
or
Down
Navigation keys to make your selection. Press the
Save
soft key or the
key to make your selection.
•
Pop Up List Menu
: allows you to select whether to activate pop up
menus. Press the
Up
or
Down
Navigation keys to make your selection.
Choose from On or Off. Press the
Save
soft key or the key to
make your selection.
•
Idle Screen Setting
: allows you to set the format for the clock used on
the Idle screen.
•
Dialing Display
: allows you to select the properties of those items
which are part of the display such as Font and Color:
–
Font Type
: allows you to select what font is used. Press the Left or
Right Navigation keys to make your selection. Choose from Normal 1,
Normal 2, Quill Pen, or Sticky Note. Press the
Save
soft key or the
key to make your selection.
–
Font Size
: allows you to select a size for the selected font. Press the
Left or Right Navigation keys to make your selection. Choose from
Large, Medium, or Small. Press the
Save
soft key or the key to
make your selection.
–
Font Color
: allows you to select a color for the selected font. Press the
Left or Right Navigation keys to make your selection. Choose from
Monochrome, Rainbow, Gradation, or Basic. Press the
Save
soft key or
the key to make your selection.
–
Background Color
: allows you to select a color for the background
screen. Press the Left or Right Navigation keys to make your selection.
Choose from the available colors. Press the
Save
soft key or the
key to make your selection.
Changing Your Settings 114
Light Settings
Note:
Light settings can affect the length of time before battery recharge is
necessary.
•
Brightness
: allows you to adjust the display brightness for the LCD to
see it better in different lighting conditions. Press the
Left
or
Right
Navigation keys to adjust the brightness. Press the Save soft key or the
key to make your selection.
•
Backlight Time
: allows you to select the amount of time for the
backlight to remain on and the length of time for the actual dimming to
occur. Press the Up or Down Navigation keys to make your selection.
For On choose from either 10 Seconds, 30 Seconds, 1 Minute, 3
Minutes, or 10 Minutes. For Dim choose from either Off, 5 Seconds, 30
Seconds, 1 Minute, or 3 Minutes. Press the
Save
soft key or the
key to make your selection.
•
Keypad Light
: allows you to determine when to use the keypad light.
Press the
Up
or
Down
Navigation keys to make your selection. Choose
from either Use at Any Time, or Use at Custom Time. Press the
Options
soft key to select
Edit
, make your selection and then press
the
Select
soft key and select
Save
or the key to make your
selection.
Set Time & Date
This menu allows you to change the current time and date
displayed. You can also find out what time it is in another part of
the world.
1. Press
Menu > Settings
and press the
Select
soft key or
the key.
2. Select
Set Time & Date
and press the
Select
soft key or
the key. The following options are available. Use
the
Down
Navigation key to scroll to and set options:
• Time Zone Updating
: allows you to select whether the time zone
information is updated: Automatic (which greys-out some of the
other options), Manual Only, or Prompt first.
•Home Zone
: allows you to enter the assign your current time
zone based upon Greenwich Mean Time. Upon selection, major
cities in each zone display. Use the Left or Right Navigation key to
select a new zone. Press the OK soft key or the key to save the
new selection.
Tip:
You can also choose to activate Daylight Savings Time within the Home Zone
menu option.
•Time
: allows you to enter the current time using your keypad.
Press the Right Navigation key to select AM or PM. Press the Save
soft key or the key to save the new selection.
115
•Date
: allows you to enter the current date using your keypad.
Press the Left or Right Navigation key to navigate between the
month, day, or year fields. Press the Save soft key or the key to
save the new selection.
•Time Format
: allows you to change the time format to 12 hours
(12H) or 24 hours (24H). Use the Left or Right Navigation key to
select between the two options. Press the Save soft key to save
the new selection. Available for change when the Time Zone
Updating is set to Automatic.
• Date Format
: allows you to change the date format. Press the
key to activate the option. Use the Up or Down Navigation key to
select between the different options. Press the OK soft key to
change the format. Press the Save soft key to save the new
selection. Available for change when Time Zone Updating is set to
Automatic.
Note:
Automatic updates of time and date do not change the time you have set for
alarm settings or calendar memos.
Set Phone
To customize the settings of your phone use the following steps:
1. Press the
Menu
➔
Settings
➔
Set Phone
and press the
Select
soft key or the key.
The following options are available. Use the
Down
Navigation key to scroll to and set options.
The options available for Set Phone are as follows:
•
Language
: allows you to select a display language. You can set the
Screen Text language or the Input T9 Mode.
–
Screen Text
: allows you to select the phone text. Use the
Up
or
Down
Navigation key to highlight your selection. Press the
OK
soft key or the
key to make your selection. Press the
Save
soft key to save your
new selection. Options include:
•Automatic
: the language is automatically selected according to
the language of the SIM card used.
• English
: the selected phone language is changed to English.
•Français
: the selected phone language is changed to French.
•Español
: the selected phone language is changed to Spanish.
–
Input T9
: sets the language used when entering text into the phone.
Use the Up or Down Navigation key to highlight your selection. Press
the OK softkey or the key to make your selection. Press the Save soft
key to save your new selection. Options include:
–
English
: the selected phone language is changed to English.
–
Français
: the selected phone language is changed to French.
–
Español
: the selected phone language is changed to Spanish.
•
Shortcuts
: allows you to change the applications assigned to your
Navigation keys.
–
Press a particular Navigation key and press the
Options
softkey.
–
Highlight Change and press the . Use the
Up
or
Down
Navigation key to
select a new application to assign to the previously pressed key.
Changing Your Settings 116
–
Press the
Save
soft key or the key to save the new application to
the assigned Navigation key.
•
Own Number
: displays the number assigned to the SIM card in your
phone. You can change the phone number, but entering another
number prevents you from making or receiving calls on the handset.
You may also add other names and numbers into your phone for easy
referral.
•
Security
: The Security feature enables you to restrict the use of your
phone by the others and to restrict the types of calls. Various codes
and passwords are used to protect the features of your phone. The
following options are available. Use the
Up
or
Down
Navigation key to
scroll to and set options.
–
Lock Phone
: when the Phone lock feature is enabled, the phone is
locked and you must enter the 4- to 8-digit phone password each time
the phone is switched on. To change the phone password, see “Change
Phone Password” on page 112. Once the correct password is entered,
you can use the phone until you switch it off. The following options are
available:
•
Off: you are not asked to enter the phone password when you
switch on the phone.
•
On: you are required to enter the phone password when you
switch on the phone.
–
Lock SIM Card
: when the Lock SIM Card feature is enabled, your
phone only works with the current SIM. You must enter the lock code to
unlock the SIM so you can use a different SIM card. Once you have
entered the lock code, you are asked to confirm your password.
Reenter your password and press the OK soft key.
–
Check PIN Code
: when the Check PIN Code feature is enabled, you
must enter your PIN each time you switch on the phone. Consequently,
any person who does not have your PIN cannot use your phone without
your approval. The following options are available:
•Off
: the phone connects directly to the network when you switch it
on.
•On
: you must enter the PIN each time the phone is switched on.
Note:
Before disabling the Check PIN Code feature, you must enter your PIN.
–
Lock Applications
: using this option you can lock various applications.
Once you have locked the contents, you must enter the phone’s
password to access the associated menus. The applications options
are:
•
All
•
IM
•
Messaging
•
Recent Calls
•
My Stuff
•
Calendar
•
Tasks
•
Notes
•
Address Book
117
–
Set FDN Mode
: FDN (Fixed Dial Number) mode, if supported by your
SIM card, allows you to restrict the outgoing calls to a limited set of
phone numbers. The following options are available:
•Off
: you can call any number.
•On
: you can only call phone numbers stored in phone book. You
must enter your PIN2. The following options are available:
–
Full length entries or wild cards can be entered in to the FDN list.
–
A full length number with a specific contact name can be entered
into the FDN list.
–
Wildcard entries allow a range of numbers to be dialed with a
single entry: ex. 555 – All dialed numbers that begin with 555
are allowed. Numbers that do not match the conditions in the
FDN list are restricted. Note: Entering an asterisk (*) is not
required for wild card entries.
Note:
Not all SIM cards have a PIN2. If your SIM card does not, this menu does not
display.
–
Change Phone Password
: the Change Phone Password option allows
you to change your current phone password to a new one. You must
enter the current password before you can specify a new one. Once
you have entered a new password, you are asked to confirm it by
entering it again.
–
Change PIN Code
: this option allows you to change your current PIN,
provided that the PIN Check feature is enabled. You must enter the
current PIN before you can specify a new one. Once you have entered a
new PIN, you are asked to confirm it by entering it again.
–
Change PIN2 Code
: the Change PIN2 option allows you to change your
current PIN2 to a new one. You must enter the current PIN2 before you
can specify a new one. Once you have entered a new PIN2, you are
asked to confirm it by entering it again.
Note:
Not all SIM cards have a PIN2. If your SIM card does not, this menu does not
display.
–
APN Control
: allows you to turn control of Access Point Names (APN)
On or Off. APNs are a method by which you can access advanced
communication using your handset. This advanced communication
includes instant messaging, text messaging, multimedia messaging,
email, and internet access. Turning On APN Control requires the PIN2
code.
•
Airplane Mode
: The Airplane profile allows you to use many of your
phone’s features, such as Games, Music, Notepad, Voice Memos, etc.,
but you cannot send or receive any calls or access online information.
This icon is accompanied on screen by the Mute icon.
–
Keypad Tone
: allows you to set the keypad tone to Beep, Xylophone, or
Mute (no tone is played).
–
Power On Type
: allows you to set the power on ringtone type to
Melody, Vibration, Vibration & Melody, or Mute.
–
Power Off Type
: allows you to select power off ringtone type to Melody,
Vibration, Vibration & Melody, or Mute.
Changing Your Settings 118
–
Phone Sound Volume
: shows the volume of the phone sounds. In
Airplane profile, the sound is preset to 0, but you can change the
volume.
Set Calls
This menu allows you to change the actions taken by the phone
when dialing and receiving calls. These settings extend to not
only voice calls but also Data calls as well.
1. Press the
Menu > Settings
. Press the
Select
soft key or
the key.
2. Select
Set Calls
and press the
Select
soft key or the
key.
The following options are available. Use the
Down
Navigation key
to scroll to and set options.
General
This allows you to configure some common high level
parameters used by the phone for most types of calls.
•
Show My Number
: allows you to select how your ID is handled when
an outgoing call is initiated. Use the
Up
or
Down
Navigation key to
highlight your selection. Press the key to make your selection. Press
the
Save
soft key to save your new selection. Options include:
–
By Network
: you are identified to the other party using the default
network information.
–
Send
: your phone number and name are sent to the other party.
–
Hide
: your identifying information is hidden from the other party.
•
Auto Reject
: allows you to enable a phone feature which allows you to
automatically reject calls from a list of contacts. Use the
Left
or
Right
Navigation key to toggle the activation of this feature. Select
Auto
Reject
to On. Use the Navigation keys to select the Reject List, and
press the key to see the list of rejected numbers. Press the
key to select an entry from the list. You may add a number manually or
by selecting from contacts. Press the
Options
soft key, and then
Create
. Select the Search soft key for numbers from Recent Calls list
or from the Address Book. Press the
Select
soft key or the key to
make your selection. Press the
Save
soft key or the key to save
your new selection.
•
Call Answer
: allows you to select how your phone answers incoming
calls. Use the
Up
or
Down
Navigation key to highlight your selection.
Press the key to make your selection. Press the
Save
soft key to
save your new selection. Options include:
–
Send Key
: allows you to answer an incoming call by pressing either the
Accept
soft key or the key.
–
Any key
: allows you to answer an incoming call by pressing any key on
your phone.
•
Auto Reply
: allows you to activate or deactivate the Auto Reply option.
If activated, allows you to enter a text message that is sent in response
119
to a call or text message. You may select the Input Language and Input
Method for entering this response.
•
Call Status Tones
: allows you to activate an alert tone for one of three
available status categories. Use the
Up
or
Down
Navigation key to
highlight your selection. Press the key to make your selection.
Press the
Save
soft key to save your new selection. Options include:
–
Call Connect Tone
: allows you to activate an alert tone when the
connection is made.
–
Minute Minder
: allows you to activate an alert tone which sounds
every minute the call is active.
–
Call End Tone
: allows you to activate an alert tone when the line is
disconnected.
•
Alerts On Call
: allows you to activate an alert tone for new messages
being received during an active call. Use the
Up
or
Down
Navigation
key to toggle between On and Off. Press the key to make your
selection. Press the
Save
soft key to save your new selection.
Voice Call
This option allows you to configure those phone parameters
associated to voice calls.
•
Call Forwarding
: enables incoming calls to be rerouted to a number
that you specify. Use the
Up
or
Down
Navigation key to highlight your
selection. Press the key to make your selection. Press the
Select
soft
key to save your new selection. Options include:
–
Always
: allows you to forward Voice Calls. Press the Select soft key
and either enter the phone number or press the
Options
soft key to
select a number from your Address Book. Once you have selected a
number, press the
Options
soft key and select to either Activate/
Deactivate this feature.
–
Busy
: allows you to forward Voice Calls to a designated number instead
of your voice mail number if you are on another phone call. Press the
Select
soft key and either enter the phone number or press the
Options
soft key to select a number from your Address Book. Once you
have selected a number, press the
Options
soft key and select to either
Activate/Deactivate this feature.
–
No Reply
: allows you to forward Voice Calls to a designated number
instead of your voicemail number when there is no answer on your
phone. Press the
Select
soft key and either enter the phone number or
press the
Options
soft key to select a number from your Address Book.
Once you have selected a number, press the
Options
soft key and
select to either Activate/Deactivate this feature.
Changing Your Settings 120
–
Unreachable
: allows you to forward Voice Calls to a designated
number instead of your voicemail number when you are not in an area
covered by your service provider or when your phone is switched off.
Press the
Select
soft key and either enter the phone number or press
the
Options
soft key to select a number from your Address Book. Once
you have selected a number, press the
Options
soft key and select to
either Activate/Deactivate this feature.
–
Cancel All
: allows you to cancel all Call Forwarding features. Press the
Select
soft key to activate this feature.
•
Call Waiting
: informs you when someone is trying to reach you during
another call. Press the key to make your selection. Press the
Select
soft key to save your new selection. Options include:
–
Activate
: allows you to activate this feature for all Voice Calls. Press
the
Options
soft key to select this option.
–
Deactivate
: allows you to deactivate this feature for all Voice Calls.
Press the
Options
soft key to select this option.
–
Check Status
: allows you to check the status of this feature for all
Voice Calls. Press the
Options
soft key to select this option.
•
Auto Redial
: allows to you automatically redial the last number if the
call was either cut off or you were unable to connect. Press the
key to make your selection. Press the
Save
soft key or the key to
save your new selection. Options include:
–
On
: causes the phone to automatically redial the last number if the call
was disconnected or the call was cut off.
–
Off
: keeps the phone from automatically redialing the last number if the
call was disconnected or the call was cut off.
Set Connectivity
The Set Connectivity option allows you to manage the settings
associated with the connection types available to your phone,
including, Bluetooth, Network, USB, and IMS settings.
1. Press the
Menu
soft key. Select Settings and press the
Select
soft key or the key.
2. Select
Set Connectivity
and press the
Select
soft key or
the key.
3. Use the
Down
Navigation key to scroll to and set these
options.
Bluetooth
Bluetooth is a short-range wireless communications technology
capable of exchanging information over a distance of about 30
feet without requiring a physical connection. Unlike infrared, you
don't need to line up the devices to beam information with
Bluetooth. If the devices are within connectivity range of one
another, you can exchange information between them, even if
they are located in different rooms.
121
The Bluetooth wireless technology settings menu provides the
ability to view and change the device name, show the visibility,
and set the security for the device.
•
Activation
: allows you to use the Bluetooth features available when
Bluetooth is activated. When Bluetooth features are deactivated, you
cannot send or receive information via any Bluetooth device.
Deactivate to save battery life or in situations where wireless
technology use is prohibited.
•
My Devices
: provides a list of Bluetooth wireless technology devices
discovered by your handset.
•
My Phone’s Visibility
: allows your phone to wirelessly transmit its
phone name and status when activated. Visibility is essential if you are
attempting to connect with Bluetooth devices. However, allowing your
phone to promote its visibility can pose a security risk and incite
unauthorized connection. Bluetooth Visibility should be paired with a
Bluetooth security option such as Secure Mode to minimize this risk.
Highlight the option (On/Off) and press the Select soft key or the
key.
•
My Phone’s Name
: allows your phone to identify itself using the
name entered into this text field, when your phone’s Bluetooth visibility
is turned On. This name can be altered by selecting the pre-existing
text and selecting a new text string in its place. This feature should be
paired with a Bluetooth security option.
•
Secure Mode
: allows your phone to wirelessly transmit its phone name
and status in a secure manner when the Bluetooth Visibility is turned
On. When Secure Mode is also set to On, connection to your handset
from another device requires a password in order to pair the two
devices.
•
Remote SIM Mode
: allows you to turn On or Off Remote SIM Mode.
Remote SIM mode, when set to On, allows the Bluetooth phone car kit
to access the contact information stored on the SIM card.
•
Bluetooth Services
: the Bluetooth specification is a protocol that
describes how the short-range wireless technology works, whereas
individual profiles describe the services supported by individual
devices. Profiles increase the chance that different devices will work
together. Your phone supports the following profile services:
–
Headset
: enables outgoing and incoming calls with a Bluetooth
headset.
–
Handsfree
: the remote Bluetooth car kit enables outgoing and incoming
calls.
–
Bluetooth Stereo Headset
: enables outgoing and incoming calls via a
Bluetooth headset, plus allows you to listen to your music files.
–
Serial Port
: data communication can be established via a Serial Port
connection.
–
Dial Up
: The phone is configured as a dial up modem for access to the
Internet.
Changing Your Settings 122
–
Basic Printing
: The phone is configured to use Bluetooth technology to
enable basic printing from the phone. This is useful to print received
text message or contact information.
–
File Transfer
: The phone is configured to transfer data wirelessly to a
target device.
–
Object Push
: The phone is configured to wirelessly exchange personal
data (such as Namecards, Phonebook Contacts, etc.) with applicable
Bluetooth devices.
1. From the Bluetooth menu items, select
My Devices
➔
Search For New Device
and press the
Select
soft key or
the key.
2. Connecting to a Bluetooth device from the Device list,
highlight the device and press the
Select
soft key or the
key.
3. Enter the PIN for the device.
If connecting to a Bluetooth wireless device, consult
your Bluetooth device user manual for your assigned
PIN. If connecting to another handset, enter the same
user-defined PIN on both handsets.
Note:
The first time you try to pair with a handset, you and the owner of the other
handset must enter the same PIN. Once the handsets are paired, you do not
need to use the PIN again.
4. Press the
OK
soft key or the key.
5. If you are unable to pair with the device a popup
displays on the screen. Press the
Yes
soft key to retry.
6. Press the key to erase the previous name.
7. Use the phone’s keypads to enter a new name. The
default input entry method is Abc, where the initial
character is Uppercase and each consecutive
character in that same word is left as lowercase text.
8. Press the
Save
soft key or the key to save the new
name.
Configuring your Phone’s Connections
Your phone is wirelessly connecting to the Internet via a built in
WAP browser. Connection can be made via any of the available
WAP browsers: MEdia Net, AT&T MMS (MultiMedia Server), and
AT&T IMS. You need these settings to use the web browser or
send MMS messages or e-mails.
123
Use this menu to create and customize the profiles containing the
settings for connecting your phone to the network. Although the
active connection can be changed by the user, it is recommended
that this choice be made with the assistance of either the retailer
or customer service representative.
1. At the Idle screen, select
Menu
➔
Settings
➔
Set
Connectivity
➔
Connections
and press the
Select
soft
key or the key. Use the
Up
or
Down
Navigation key
to highlight one of these options:
•
MEdia Net
•
AT&T MMS
•
AT&T IMS
2. Press the
Options
soft key.
Note:
The MEdia Net is pre-configured and cannot be altered on this screen. The
AT&T MMS connection option can be edited, renamed, or deleted on this
screen. Your phone is set up by default for connecting to the network. If you
change the settings without first checking with your service provider, the
web browser, MMS, and e-mail features may not work properly.
3. To create a new connection, press the
Options
soft key,
select
New
, and press the
Select
soft key or the
key.
4. To edit the existing AT&T MMS, highlight this entry,
press the
Options
soft key, select
Edit
, and press the
Select
soft key or the key.
5. Select the parameter you want to edit:
• Set Name
: enter a profile name.
• Access Name
: edit the access point name.
• Auth Type
: select the type of authentication used for this WAP
connection: None, Normal, or Secure.
•User ID
: enter the User ID required to connect to the network.
•Password
: enter the user password required to connect to the
network.
•Protocol
: set the connection protocol used by the WAP browser:
WAP, HTTP, or Other.
• Home URL:
enter the URL address of the page to be used as your
homepage.
• Proxy address:
set the proxy server address and port.
• Linger Time (Sec.)
: sets a time period (in seconds) after which
the network is disconnected if there is no new data traffic.
• Advanced Settings
: allows you to configure some of the IP-
specific information: Static IP, Static DNS, Server information, and
Traffic Class.
–
Static IP
: specify if you want to manually enter an IP address. If
you want the IP address to be automatically assigned by the
server, remove the check mark.
–
Local Phone IP
: allows you to configure the local phone IP
address.
Changing Your Settings 124
–
Static DNS
: specify if you want to manually enter the Domain
Name Server (DNS) address. If you want the address to be
automatically assigned by the server, remove the check mark.
–
Server 1/Server 2
: enter the Domain Name Server (DNS)
addresses.
–
Traffic Class
: select the traffic class.
Note:
The WAP settings may vary depending on the service provider.
Configuring your Phone’s USB Mode
Your phone can connect to a PC via the USB cable (sold
separately). The phone can be configured to launch a default
application when an active USB connection is detected.
Note:
The Bluetooth feature must first be disabled before initiating a USB
connection with the phone. Prior to connecting the USB cable to the phone,
install the latest version of the PC Studio application. This application installs
the necessary USB drivers onto your machine.
1. Use the USB adapter cable to connect the handset to
the target PC. When an active connection is
established, a USB icon ( ) displays on the
screen.
2. At the Idle screen, select
Menu
➔
Settings
➔
Set
Connectivity
➔
Select USB Mode
and press the
Select
soft key or the key.
3. Use the
Up
or
Down
Navigation key to highlight one of
these options:
•Media Player
: sets the Media Player to launch as the default
application when a USB connection is detected. This is the default
application when the phone is initialized, but can be reset to one of
the other options.
• PC Studio
: can be set to launch PC Studio as the default
application when a USB connection is detected. For a free
download of PC Studio, go to www.samsung.com.
• Ask on Connection
: requires the phone to present a “Select
USB Mode” pop-up which requires you to assign a default USB
application.
• Mass Storage
: sets the USB connection to a mass storage
device such as a zip drive. Mass storage is available only when a
micro-SD card is inserted.
4. With the application highlighted, press the
Save
soft
key or the key.
125
IMS Settings
IMS is the method used to connect to the server in order to
receive multimedia messages. It has a default setting of On so
that you can receive messages with attached audio, graphics, or
video files. When a multimedia message is sent, your phone
retrieves it and displays the message in its entirety. If you reset
the IMS setting to Off, you receive an alert that you have a
multimedia message, but the phone does not retrieve the
message. You must have the setting to On to retrieve the
message.
Note:
Having the IMS setting on Off may save minutes and memory.
Set Applications
The Set Application feature allows you to configure the functional
parameters for most of the onboard applications. These
applications are described in more detail within other sections of
this manual.
1. At the Idle screen, select
Menu
➔
Settings
➔
Set
Applications
, and press the
Select
soft key or the
key.
2. Select the type of application which you want to
change.
•
Messaging Settings (page 58)
•
Browser Settings (page 67)
•
Camera Settings (page 87)
•
Camcorder Settings (page 90)
•
Player Settings (page 93)
•
Cellular Video Settings (page 38)
•
Record Audio Settings (page 92)
•
Calendar Settings (page 95)
•
Address Book Settings (page 102)
•
Video Share Settings (page 125)
3. Press the
Select
soft key or the key.
Video Share Settings
To enable the Alerts, Auto Record, and Service options for Video
Share, use the following steps.
1. From the Idle screen, select
Menu
➔
Settings
➔
Application Settings
➔
Video Share Settings
and press
the key. To access the following options, press the
Select
soft key.
•Alerts
: allows you to turn On or Off the Video Share Alerts which
displays a message and a tone.
Changing Your Settings 126
• Auto Record
: allows you to turn On or Off the Auto Record which
records the Video Share call.
• Service
: allows you to turn On or Off the Video Share service.
(This option default is On.)
• Recording Location
: allows you to set whether video recorded is
stored on the phone or on the SIM card.
2. Press the
Save
soft key or the key to save the
option.
Reset Settings
You can easily reset your phone to its default settings. To reset
your phone:
1. At the Idle screen, select
Menu
➔
Settings
➔
Reset
Settings
and press the
Select
soft key or the key.
2. The following options are available. Use the
Up
or
Down
Navigation key to scroll to and set options.
Choose from the following:
•
All
•
Profiles
•
Display Settings
•
Phone Settings
•
Alarms
3. Press the key to make your selection and press
the
OK
soft key.
4. Enter your phone password, if prompted. At the “Reset
Settings?” prompt, press the
Yes
soft key to reset, or
the
No
soft key to cancel. Once your phone was reset
to the default settings for those selected options, the
phone restarts itself in order to incorporate the new
settings.
Set Memory
You can easily check the amount of memory being used for
storing data, such as messages, media, calendar data, or
contacts entries. You can also delete any selected information
from your phone:
1. At the Idle screen, select
Menu
➔
Settings
➔
Set
Memory
and press the
Select
soft key or the key.
2. The following options are available. Use the
Up
or
Down
Navigation key to scroll to and set options.
Choose from the following:
•
Clear Memory
•
Memory Status
127
Clearing Memory
To completely remove any personal information stored on your
device, see “Precautions for Transfer and Disposal” on page
153.
1. At the Idle screen, select
Menu
➔
Settings
➔
Clear
Memory
and press the
Select
soft key or the key.
2. Highlight
All
and press the key to select all
available categories.
You can remove the check mark by pressing the
key again. Selecting
All
places a checkmark
adjacent to every entry in the list.
- or -
3. Highlight a specific category and press the key to
select it. Press the
OK
soft key.
4. Enter your password (if applicable) and press the
Confirm
soft key. Depending on your phone’s security
settings, you may be asked to enter your password a
second time.
5. At the
Clear?
confirm screen, press the
Yes
soft key to
continue, or the
No
soft key to cancel.
6. Press the key to return to Idle mode when you
are finished.
Checking the Memory Status
1. At the Idle screen, select
Menu
➔
Settings
➔
Memory
Status
and press the
Select
soft key or the key.
2. Highlight the storage category and the
Select
soft key
or the key. you can choose from one of the
following categories:
•
Shared Memory
•
Messaging
•
My Stuff
•
Calendar
•
Tasks
•
Notes
•
Address Book
3. To view the contents of a category’s memory, use the
Up
or
Down
navigation key to select the entry and
press the
Select
soft key.
Changing Your Settings 128
4. To delete all the entries in this category, highlight
All
and press the key to select the categories.
5. Press the
Delete
soft key.
6. At the
Delete?
confirm screen, press the
Yes
soft key to
continue, or the
No
soft key to cancel.
7. Enter your password (if applicable) and press the
Confirm
soft key. Depending on your phone’s security
settings, you may be asked to enter your password a
second time.
8. Press the key to return to Idle mode when you
are finished.
Software Update
The Software Update feature enables you to use your phone to
connect to the network and upload any new phone software
directly to your phone.
1. At the Idle screen, select
Menu
➔
Settings
➔
Software
Update
and press the
Select
soft key or the key.
2. Press the key to continue the update process and
follow the on screen instructions.
Phone Information
This option allows you to see the phone number of the phone, the
manufacturer, and the model number. This information may be
necessary if talking to Customer Service in the event of a
problem.
129
Section 15: Accessibility
TTY (also known as a TDD or Text Telephone) is a telecommunications
device that allows people who are deaf or hard of hearing, or who
have speech or language disabilities, to communicate via a telephone.
This phone comes TTY-ready and only requires the insertion of the
TTY device to enable this feature.
Use the following steps to access the TTY settings:
ᮣ
Inserting a TTY connector into the Headset/Adapter jack (on the
right side of the phone) enables this function.
For additional technical support, you may access the following
website or call 1-888-987-4357.
http://www.samsungtelecom.com/contact_us/accessibility.asp
23
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
o
%HIRUH D QHZ PRGHO SKRQH LV DYDLODEOH IRU VDOH WR WKH
SXEOLFLWPXVWEH WHVWHGD
QG FHUWLILHG WR WKH )&& WKDW
LW GRHVQRW H[FHHG WKH H[SRVXUH OLPLW HVWDEOLVKHGE\
WKH )&& 7HVWV IRU HDFK PRGHO SKRQH DUH SHUIRUPHG LQ
SRVLWLRQV DQG ORFDWLRQV HJ DW WKHHDU DQGZRU
QRQ
WKH ERG\ DV UHTXLUHGE\WKH)&&
7KH KLJKHVW 6$5 YDOXHVI
RU WKLV PRGHO SKRQH DV
UHSRUWHG WR WKH )&& DUH
)RU ERG\ ZRUQ RSHUDWLRQWKLVPRGHO SKRQH KDV EHHQ
WHVWHGDQGPHHWVWKH)&&5)H
[SRVXUH JXLGHOLQHV
ZKHQ XVHGZLW
KD6D
PVXQJ DFFHVVRU\GHVLJQDWHG IRU
WKLV SURGXFW RU ZKHQX
VHG ZLWK DQ DFFHVVRU\ WKDW
FRQWDLQV QR PHWDO DQG WKDW SRVLWLRQV WKH KDQGVHW D
PLQLPXPRI FPIURPWKHERG\
1RQFRPSOLDQFH ZLWK WKH DERYH UHVWULFWLRQV PD\ UHVXOW
LQ YLRODWLRQ RI )&& 5) H[SRVXUH JXLGHOLQHV
6$5 LQIRUPDWLRQ RQ WKLV DQG RWKHU PRGHO SKRQHV FDQ
EH YLHZHG RQOLQH DW ZZZIFFJRYRHWIFFLG 7KLV VLWH
XVHV WKH SKRQH)&& ,' QXPEHU$/6*+ $
6RPHWLPHV LW PD\ EH QHFHVVDU\ WR UHPRYH WKH EDWWHU\
SDFN WR ILQG WKH QXPEHU 2QFH \RX KDYH WKH )&& ,'
QXPEHU IRU D SDUWLFXODU SKRQH IROORZ WKH LQVWUXFWLRQV
RQ WKH ZHEVLWHDQ
G LW VKRXOG SURYLGH YDOXHV IRU W\SLFDO
RU PD[LPXP 6$5 IRU D SDUWLFXODU SKRQH $GGLWLRQDO
SURGXFW VSHFLILF 6$5 LQIRUPDWLRQ FDQ DOVR EH REWDLQHG
DWZZZIFF
JRYFJEVDU
VQR&,U
HPXQ 3VVHOHUL:QRQRLWDPURIKVHQR
8HK76)D
GRRQ JXU'GPG$LWV
LQ UD '
)QRLW$VDK
LOEXSV D
GHKLUHVVHHX
4IRV
VQR
LWQ$GQDVZVUHUR
I
UHPXVQR
FVUH WDOLJQWRUD IRLGU )5\FQHXTH
UX
VRS
[
HH
IU LZPRHUH
OV
VHQRKSVHK7)'$SXEOF
LWDRLQQLOFXGVH
HK
WIROOZRL I
QLJQLWDPUR
QR
25
Health and safety information
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
Health and safety information
26
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
27
Health and safety information
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Health and safety information
28
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
What research is needed to decide whether
RF exposure from wireless phones poses a
health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists.
Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
29
Health and safety information
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Health and safety information
30
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
31
Health and safety information
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
Health and safety information
32
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
33
Health and safety information
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
Health and safety information
34
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use
your phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
35
Health and safety information
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Health and safety information
36
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
37
Health and safety information
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.This
equipment generates, uses and can radiate radio
frequency energy and,if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
o
&RQQHFWWK
HHTXLSPHQWLQWR DQ RXWOHW RQ D FLUFXLW
GLIIHUHQW IURP WKDW WRZKLFK WKH UHFHLYHU LV
FRQQHFWHG
&RQ
VXOW WKHGHDOHUR
UDQ H[SHULHQFHG UDGLR79
WHFKQLFLDQ IRUKH
OS
7KHSK
RQH PD\ FDXVH 79 RU UDGLR LQWHUIHUHQFH LI XVHG
LQ FORVH SUR[LPLW\ WR UHFHLYLQJHTXLSPHQW 7KH)&&
FDQUHTXLUH \RX WR VWRS XVLQJ WKH SKRQH LI VXFK
LQWHUIHUHQFH FDQQRW EH HOLPLQDWHG
9HKLFOHVXVLQJOLTXHILHGSHWUROHXPJ
DV
VXFK DV
SURSDQH RU EXWDQHPX
VW FRPSO\ ZLWK WKH 1DWLRQDO )LUH
3URWHFWLRQ 6WDQGDUG 1)3$)RUDFRS\RIW
KLV
VWDQGDUG FRQWDFW WKH1DWLRQDO )LUH 3URWHFWLRQ
$VVRFLDWLRQ 2QH %DWWHU\ PDUFK 3DUN 4XLQF\ 0$
$WWQ 3XEOLFDWLRQ6DOHV 'LYLVLRQ
2QO\ XVH DSSURYHG EDWWHULHV DQWHQQDVD
QGFKDUJHUV
7KH XVH RIDQ\XQDXWKRUL]HG DFFHVVRULHV PD\ EH
GDQJHURXV DQG YRLG WKH SKRQH ZDUUDQW\LI VDLG
DFFHVVRULHVFDXV
HGDPDJH RU D GHIHFW WR WKH SKRQH
$OWKRXJK \RXU SKRQHLV TXLWH VWXUG\ LW LV D FRPSOH[
SLHFH RI HTXLSPHQW DQG FDQ EH EURNHQ $YRLG
GURSSLQJ KLWWLQJ EHQGLQJ RUVLWWLQJ RQ LW
2WKHU ,PSRUWDQW 6DIHW\ ,QIRUPDWLRQ
2QO\ TXDOLILHG SHUVRQQHO VKRXOG VHUYLFH WKH SKRQH
RU LQVWDOO WKH SKRQH LQ D YHKLFOH )DXOW\ LQVWDOODWLRQ
RU VHUYLFH PD\ EH GDQJHURXV DQG PD\ LQYDOLGDWH
DQ\ ZDUUDQW\ DSSOLFDEOH WR WKH GHYLFH
&KHFN UHJXODUO\ WKDW DOO ZLUHOHVV SKRQH HTXLSPHQW
LQ \RXU YHKLFOH LV PRXQWHG DQG RSHUDWLQJ SURSHUO\
'R QRW VWRUH RU FDUU\ IODPPDEOH OLTXLGV JDVHV RU
H[SORVLYH PDWHULDOV LQ WKH VDPH FRPSDUWPHQW DV
WKH SKRQH LWV SDUWV RU DFFHVVRULHV
)RU YHKLFOHV HTXLSSHG ZLWK DQ DLU EDJ UHPHPEHU
WKDW DQ DLU EDJLQIODWHV ZLWK JUHDW IRUFH 'RQRW
SODFH REMHFWV LQFOXGLQJ ERWK LQVWDOOHG RU SRUWDEOH
ZLUHOHVV HTXLSPHQW LQ WKH DUHD RYHUWKHDLUEDJRU
VQRLW
X
D&
WRQ
H
QRKSRLGDUHKWQLHGDPVQRL
WDF
L
I
LGRPUR
V
H
J
QDK&
V¶
U
H
V
XHKW
GLRY
OOL
Z
J
QXVPD6\
E
GH
YR
USSD
\OVVHUS[H
WQHPS
L
XTH
HK
WHWD
U
HSR
R
W\WLURKWXD
39
Health and safety information
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and safety information
40
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
41
Health and safety information
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Caution: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Health and safety information
42
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
43
Health and safety information
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
