Users Manual

9. User manual

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-XXXXXA

English. 04/2005. Rev 1.0

* Depending on the software installed or your service provider, some of the descriptions in this

manual may not match from your phone.

* Depending on your country, your phone and accessories may appear different from the

illustrations in this manual.

SGH-E350

User’s Guide

Draft

2005. 04. 26

E350XAED3

Use road safety at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 87.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To quickly

learn the basics for your phone, please refer to “Get

started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful

attention to the subsequent information

regarding safety or phone features.



Indicates that you can get more information

on the referenced page.

→

Indicates that you need to press the

Navigation keys to scroll to the specified

option and then select it.

[ ] Indicates a key on the phone. For example,

[]

< > Indicates a soft key, whose function is

displayed on the phone screen. For example,

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

Special

features of your phone

•MP3 player

Play MP3 music files on your

phone.

•IrDA

Send and receive Phonebook and

File manager data via an infrared

port.

Special features of your phone

• Get personal with photo caller

See who’s calling you when the

phone displays their very own

photo displays.

• Name card

Create name cards with your

number and profile. Whenever

introducing yourself to others, use

this convenient electronic name

card.

•WAP browser

Access the wireless web and access

various services and current

information.

• Multimedia message service (MMS)

Send and receive MMS messages with a

combination of text, images, video, and audio.

•E-mail

Send and receive e-mails with images, video, and

audio attachments.

•Java

Enjoy Java

™

-based embedded

games and download new games.

•Calendar

Keep track of your daily, weekly,

and monthly schedule.

• Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ................................... 7

Power on or off...................................................... 8

Keys and display.................................................... 9

Access menu functions.......................................... 11

Customise your phone .......................................... 12

Make/Answer calls................................................ 14

Step outside the phone 14

Begin with your camera, music, and other special features

Use camera......................................................... 14

Play MP3s ........................................................... 15

Play games.......................................................... 16

Browse the web ................................................... 16

Use Phonebook .................................................... 17

Send messages.................................................... 18

View messages .................................................... 19

Enter text 21

ABC, T9, Number, and Symbol mode

Call functions 24

Advanced calling features

Menu functions 29

All menu options listed

Solve problems 84

Help and personal needs

Health and safety information 87

Index 113

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

1 Call records



p.29

1 Current contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs



p.29



p.29



p.29



p.30



p.30



p.30



p.30

2 Phonebook



p.31

1 Contact list

2 FDN list

3 Add new contact

4 Group

5 Speed dial

6 My name card

7 Own number

8 Management

9 Service number



p.31



p.32



p.32



p.33



p.33



p.34



p.34



p.34



p.35

3 Applications



p.35

1 MP3 Player

2 Voice recorder

3 Java world

4 World time

5 Alarm

6 Calculator

7 Converter

8 Timer

9 Stopwatch

0 SIM-AT



p.36



p.37



p.39



p.40



p.41



p.42



p.42



p.42



p.43



p.43

4 Browser



p.43

1 Home

2 Bookmarks

3 Go to URL

4 Clear cache

5 Profile settings

6 Current profile



p.43



p.44



p.45



p.45



p.45



p.46

5 Messages



p.47

1 Create new message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Broadcast messages

7 Memory status



p.47



p.49



p.55



p.56



p.56



p.61



p.61

6 File manager



p.62

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory status



p.62



p.62



p.63



p.64



p.64



p.65

7 Calendar



p.65

8 Camera



p.69

9 Settings



p.75

1 Time & Date

2 Phone settings

3 Display settings

4 Sound settings

5 Network services

6 Connectivity

7 Security

8 Memory status

9 Reset settings



p.75



p.75



p.77



p.78



p.79



p.81



p.82



p.84



p.84

*Shows only if supported by your

SIM card.

Unpack

Make sure you have each item

You can obtain various accessories from

your local Samsung dealer.

Phone Travel Adapter

The items supplied with your phone

and the accessories at your Samsung

dealer may vary, depending on your

country or service provider.

Battery User’s Manual

Your phone

Buttons, features, and locations

Special

function keys

Headset

jack

Earpiece

Display

Power on/off/

Menu exit key

Microphone

Navigation keys

(Up/Down/Left/

Right)

WAP access/

Confirm key

Correct key

Mirror

Soft key (left)

Volume keys

Dial key

Alphanumeric

keys

Camera

IrDA port

Soft key (right)

Camera

key

Flash

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the

phone is already

on, first turn it off by

holding

[]

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card face down into the

phone.

Install the battery.

Plug the travel adapter

into the phone.

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged, unplug the

Adapter from the power outlet.

3 4

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

Keypad lock

When you close the phone, the keypad lock feature

locks the exposed keys so that nothing will happen if

the keys are accidentally pressed.

To unlock the keypad, press the left soft key and press

Remove the adapter from the phone.

Switch on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Perform the function indicated on the

bottom line of the display.

In Idle mode, access menu options

directly.



p. 76

In Menu mode, scroll through the menu

options.

In Idle mode, launch the Wireless

Application Protocol (WAP) browser.

In Menu mode, select the highlighted

menu option.

Delete characters from the display.

Send or answer a call.

In Idle mode, retrieve the recent

numbers dialled, missed, or received.

End a call.

Hold down to switch the phone on and

off.

In Menu mode, cancel input and return

the phone to Idle mode.

Enter numbers, letters, and some

special characters.

In Idle mode, hold

[1]

down to access

your voicemail server. Hold [

] down to

make an international call.

Enter special characters.

In Idle mode, hold [

]

down to activate

or deactivate Quiet mode. Hold [

]

down to enter a pause.

(on the left)

Adjust the phone volume.

In Idle mode, with the phone open,

adjust the keypad tone volume. With

the phone closed, press to turn on the

backlight.

Get started

Display

(on the right)

In Idle mode, hold down to turn on the

camera.

In Camera mode, take a photo or start

recording a video.

Layout

Icons

Received signal strength

Call in progress

Out of your service area; you

cannot send or receive calls

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current functions

assigned to the two soft.

Menu Contacts

Icons

display various icons.

Alarm set

New message

New multimedia message

New e-mail message

New voicemail

Call diverting feature is active

IrDA port is active

Connected to hands-free or

headset

Roaming network

Home Zone, if you have

registered for the appropriate

service

Quiet mode is active

Call ringer set to vibrate



p. 78

Battery power level

Get started

Access menu functions

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Press the left soft

key to access

Menu mode.

Press the right soft

key to access

Contact list

in the

Phonebook

menu.

Menu Contacts

Select an

option

1. Press the appropriate soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods.

•Press <

Back

> or [

] to

move up one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want.

Get started

Customise your phone

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ring tone

2. Select a ringer category.

3. Select a ringer melody.

4. Press <

Save

Display

language

Call ringer

melody

You can set a wallpaper for the idle

screen.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

2. Select an image category.

3. Scroll to an image by pressing

[Left] or [Right].

4. Press <

Save

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Idle mode

wallpaper

Menu mode

skin colour

Get started

You can switch to Quiet mode to

avoid disturbing other people with

your phone sound.

Press and hold

[

]

in Idle mode.

You can use Navigation keys as

shortcut keys to access specific

menus directly from Idle mode.

To change a shortcut menu:

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Short cut

2. Select a key.

3. Press <

Options

> and select

Change

4. Select a menu to be assigned to

the key.

Quiet mode

shortcuts

You can protect the phone against

unauthorised use with a phone

password. The phone will require

the password on powerup.

1. In Idle mode, press <

and select

Settings

→

Security

→

Change

password

2. Enter the default password,

“00000000” and press <

3. Enter a new 4- to 8-digit

password and press <

4. Enter the new password again

and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and press

Phone lock

Make/Answer calls

Step outside the phone

Begin with your camera, music, and other special features

Use camera

1. In Idle mode, enter an area code

and phone number.

2. Press

[]

3. To end the call, press

[]

1. When the phone is ringing, press

[]

2. To end the call, press

[]

Press [ / ].

Make a call

Answer a call

Adjust the

volume during

a call

1. Open the phone.

2. In Idle mode, press and hold

[

]

to turn on the camera.

3. Aim the camera lens at the

subject and adjust the image.

4. Press

[]

to take a photo. The

photo is saved automatically.

Pres

s [ ] to

take another photo.

1. In Idle mode, press <

> and

select

File manager

→

Images

→

Photos

2. Select the photo you want.

Take a photo

View a photo

Step outside the phone

Play MP3s

1. In Idle mode, press and hold

[

] to turn on the camera.

2. Press [

] to switch to Record

mode.

3. Press

[]

to start recording.

4. Press

[]

to stop recording. The

video is saved automatically.

1. In

Idle

mode,

press <

and select

File manager

→

Videos

→

Videos

2. Select the video you want.

Use these methods:

• Download from the wireless

web



p. 43

• Download from a computer

using EasyStudio II



EasyStudio II User’s Guide

Record a video

Play a video

Copy MP3 files

to the phone

•Receive via IrDA



p. 81

• Receive by MMS

1. In Idle mode, press <

and select

Applications

→

MP3 Player

2. Press <

Options

> and select

Add to list

→

Add all

Add a

file

3. For

Add a file

, select a file and

press <

Add

>. Repeat from step

1. From the MP3 player screen,

press [ ].

2. During playback, use the

following keys:

• [ ]: pauses/resumes

playback.

• [Left]: goes back to the

previous file.

Create a play

list

Play MP3 file

Step outside the phone

Play games

Browse the web

Using a built-in WAP (Wireless Application Protocol)

browser, you can get easy access to the wireless web

to get a variety of up-to-date services and information

and to enjoy downloads of web content.

• [Right]: skips to the next

file.

• [Up]: opens the play list.

• [Down]: stops playback.

• [ / ]: adjusts the volume.

1. In Idle mode, press <

and select

Applications

→

Java world

→

Downloads

→

Forgotten Warrior

Freekick

Arch Angel

2. Press any key once or twice to

launch the game.

1. Press <

Play

> and select

START

GAME

2. Press <

Skip

Play MP3 file

(continued)

Select a game

Play Forgotten

Warrior

1. Select

Game

→

the game mode

you want

→

a team

→

a player.

1. Select

NEW GAME

→

a game

mode

2. Press <

SKIP

>, <

Play

>, and

then <

> until the game

starts, or <

Skip

> to start the

game immediately.

In Idle mode, press [ ].

Play Freekick

Play Arch Angel

Launch the

browser

Step outside the phone

Use Phonebook

• To scroll through browser items,

press the Navigation keys.

• To select an item, press < >.

• To return to the previous page,

press <

Back

> or [

• To access browser options,

press <

> and select

To the phone’s memory

1. In Idle mode, enter a phone

number and press <

Options

and select

Save

2. Select

Phone

→

a number type.

Navigate with

the WAP

browser

Add an entry

3. Specify the contact information:

Last name, First name, Mobile,

Home, Office, Fax, Other, Email,

Caller ID, Ringtone, Group, and

Notes.

4. Press [ ] to save the entry.

To the SIM card

1. In Idle mode, enter a phone

number and press <

Options

and select

Save

2. Select

SIM

3. Enter a name.

4. Press [ ] to save the entry.

1. In Idle mode, press

Contacts

2. Select an entry.

3. Select a number and press

[]

to dial, or press

Options

> to access options.

Find an entry

Step outside the phone

Send messages

1. In Idle mode, press <

and select

Phonebook

→

name card

2. Specify your contact

information.

3. Press <

Save

> to save the

name card.

4. To send the name card to other

people, press <

Options

> and

select

Send via

→

the sending

method you want.

Create and

send a name

card

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Text

message

2. Enter the message text.

3. Press [ ].

4. Enter destination numbers.

5. Press [ ] to send the message.

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Multimedia

message

2. Select

Subject

3. Enter the message subject and

press [ ].

4. Select

Picture & Video

Sound

and add a media file.

5. Select

Message

Send a text

message (SMS)

Send a

multimedia

message

(MMS)

Step outside the phone

View messages

6. Enter the message text and

press [ ].

7. Press <

Options

> and select

Send

8. Enter destination numbers.

9. Press [ ] to send the message

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

2. Select

Subject

3. Enter the e-mail subject and

press [ ].

4. Select

Message

5. Enter the e-mail text and press

[].

6. Select

File attach

7. Add image, video, music, or

sound files.

Send an e-mail

8. Press <

Options

> and select

Send

9. Enter e-mail addresses.

10.Press [ ] to send the e-mail.

When a notification appears:

1. Press <

View

2. Select a message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select a text message.

View a text

message

Step outside the phone

When a notification appears:

1. Press <

View

2. Press <

Options

> and select

Retrieve

3. Select a message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select a multimedia message.

View a

multimedia

message

1. In Idle mode, press <

and select

Messages

→

messages

→

Email box

2. Select an account.

3. Press <

Select

> when

Check

new mail

is highlighted to

retrieve an e-mail or a header.

4. Select an e-mail or a header.

5. If you selected a header, press

Options

> and select

Retrieve

View an e-mail

Enter text

ABC, T9, Number, and Symbol mode

You can enter text for some features such as

messaging, Phonebook, or Calendar, using ABC mode,

T9 mode, Number mode, and Symbol mode.

Changing the text input mode

The text input mode indicator appears when the cursor

is in a text field.

Press the right soft key to change the text input mode.

Example:

Writing a text message

Using ABC mode

Press the appropriate key until the character you want

appears on the screen.

Text input mode

indicator

ABC mode

T9 mode

Number mode

Symbol mode

Enter text

Tips for using ABC mode

• To enter the same letter twice or to enter a

different letter on the same key, wait for the cursor

to move to the right automatically or press [Right].

Then, enter the next letter.

• Press [ ] to insert a space.

• Press [ ] to shift case. Lower Case (No indicator),

Initial capital ( ), and Capital lock ( ) are

available.

• Press [Left] or [Right] to move the cursor.

•Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Using T9 mode

T9 is a predictive text input mode that allows you to

key in any character using single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word. Press

each key once for each letter.

For example, press [

], [

], and [

] to

enter HELLO in T9 mode.

T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, go to step 4.

Otherwise, press [

] to display alternative word

choices for the keys that you have pressed.

For example, OF and ME use [

] and [

4. Press [ ] to insert a space and enter the next

word.

Tips for using T9 mode

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to shift case in T9 mode. Lower Case (No

indicator), Initial capital ( ), and Capital lock ( )

are available.

• Press [ ] to insert a space.

• Press [Left] or [Right] to move the cursor.

• Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for your key

presses. When there are no more alternative

words,

Spell

appears on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC mode and

press <

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbol(s) [

insert the symbol(s) <

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

Making an international call

1. In Idle mode, press and hold [

]. The

character

appears.

2. Enter the country code, area code, and phone

number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

2. Scroll to the number you want and press [ ].

Making a call from Phonebook

Once you have stored a number in Phonebook, you

can dial the number by selecting it from

Phonebook.



p. 31

You can also use the speed dial feature to assign your

most frequently called numbers to specific number

keys.



p. 33

Dialling a number from the SIM card

1. In Idle mode, enter the location number for the

phone number you want and press [ ].

2. Find the number your want.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

• Press

[

]

to clear the last digit or press and hold

[

]

to clear the whole display. You can move the

cursor to edit an incorrect digit.

• Press and hold

[ ] to enter a pause between

numbers.

Call functions

Answering a call

When you receive an incoming call, the phone rings

and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

in the

Extra

settings

menu is active, you can press any key, except for

Reject

> or [ ].



p. 76

•Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to mute the ringer.

Viewing missed calls

If you have missed calls, the screen displays how

many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

Using the headset

Use the headset to make or answer calls without

holding the phone.

Connect the headset to the jack on the right side of

the phone.

The buttons on the headset work as listed below:

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to

decrease the volume level.

To Press

redial the last call and hold the button twice.

answer a call the button.

end a call the button.

Call functions

Placing a call on hold/Retrieving

Press <

Hold

> or <

Retrieve

> to place a call on hold

or retrieve the call.

Making a second call

You can make another call if your network supports it.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the calls.

4. Press <

Options

> and select

End

held

call

to end

the call on hold.

5. To end the current call, press [ ].

Answering a second call

You can answer an incoming call while already on the

phone, if your network supports it and you have

activated the call waiting feature.



p. 80

1. Press [ ] to answer the call. The first call is

automatically put on hold.

2. Press <

Swap

> to switch between the calls.

3. Press <

Options

> and select

End

held

call

to end

the call on hold.

4. To end the current call, press [ ].

Transferring a call

You can transfer the currently active call to a caller on

hold, if your network supports it. With this option, the

two callers can talk to each other, but you are

disconnected from the call.

Press <

Options

> and select

Transfer

Using the menu options

You can access Menu mode and use menu functions.

Press <

Options

> and select

Switching off the microphone

(Mute mode)

You can temporarily switch off your phone’s

microphone so that the person on the phone cannot

hear you.

Press <

Options

> and select

Mute

Unmute

During a call, some munu functions are not

available.

Call functions

Using the voice clarity feature

This feature removes extraneous noise and increases

call quality so that the person with whom you are

speaking can hear you clearly even if you are in a

noisy place.

Press <

Options

> and select

Voice clarity on

Voice clarity off

Muting or sending key tones

You can turn the key tones off or on.

Press <

Options

> and select

Mute keys

Send

keys

Sending a sequence of DTMF tones

Dual tone multi-frequency (DTMF) tones are the tones

used in phones for tone dialling.

You can send DTMF tones as a group after entering the

entire number you need to send or retrieving a

number from Phonebook. This feature is helpful for

entering a password or an account number when you

call an automated system, like a banking service.

1. When connected with a teleservice system, press

Options

> and select

Send DTMF

2. Enter the number you need to send and press

Using Phonebook

You can access the

Phonebook

menu to locate or

store entries.



p. 31

Press <

Options

> and select

Phonebook

Using the message service

You can access the

Messages

menu to read an

incoming message and send a new message.

Press <

Options

> and select

Message

To communicate with answering machines or

computerised telephone systems,

Send keys

must

be selected.

Using SIM services

The

SIM service

menu is available if you use a SIM

card in your phone. A SIM card provides services such

as news, weather, sports, entertainment, and location

services.

For details, see your SIM card instructions or contact

your service provider.

Making a multi-party call

Use this feature to allow as many as six people to join

a multi-party call, or conference call.

Your service provider must support multi-party calls

for you to use this feature.

Setting up a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is

automatically put on hold.

3. Press <

Options

> and select

Join

. The first

participant is added to the multi-party call.

4. If desired, call another person or answer an

incoming call.

5. Press <

Options

> and select

Join

6. Repeat steps 4 and 5 as desired.

Having a private conversation with one

participant

1. Press <

Options

> and select

Private

2. Select a name or number from the participant list.

You can talk privately with that person, while the

other participants converse with each other.

3. To return to the multi-party call, press <

Options

and select

Join

Dropping one participant

1. Press <

Options

> and select

Remove

2. Select a name or number from the participant list.

The participant is dropped from the call, but the

call continues with the other parties.

3. Close the phone or press [ ] to end the multi-

party call.

Menu functions

Call records

(Menu 1)

Menu functions

All menu options listed

Call records

(Menu 1)

Use this menu to view the calls you have dialled,

received, or missed, the length of your calls, and the

cost of your calls.

To access this menu, press <

> in Idle mode and

select

Call records

Current contacts

(Menu 1.1)

This menu displays the most recent calls dialled,

received, or missed.

Accessing a call record

1. Press [Left] or [Right] to select a call type.

2. Press [Up] or [Down] to scroll through the call list.

3. Press [ ] to view the details of a call, or [ ] to

dial a number.

Using call record options

While viewing the call list, press <

Options

> to access

the following options:

•

Details

: display the details of the selected call.

•

Call

: dial the number.

•

Save as contacts

: save the number in

Phonebook.

•

Send message

: send an SMS or MMS message.

•

Delete

: delete the selected call record or all call

records.

Missed calls

(Menu 1.2)

This menu displays the most recent calls that you did

not answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you have

dialled.

Menu functions

Received calls

(Menu 1.4)

This menu displays the most recent calls you have

received.

Delete all

(Menu 1.5)

Use this menu to delete all of the records in each call

type.

1. Press [ ] to check the call type(s) to be cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls made and

received. The actual time invoiced by your service

provider will vary.

•

Last

call

time

: check the length of your last call.

•

Total

sent

: check the total length of all the calls

you have dialled.

•

Total

received

: check the total length of all the

calls you have received.

•

Reset timers

: reset the call timers. You need to

enter the phone password.

Call costs

(Menu 1.7)

This network feature displays the cost of calls. This

menu is available only if your SIM card supports this

feature. Note that this is not intended to be used for

billing purposes.

•

Last

call

cost

: check the cost of your last call.

•

Total

cost

: check the total cost of all of your calls.

If the total cost exceeds the maximum cost set in

Set

max

cost

, you must reset the counter before

you can make another call.

•

Max

cost

: check the maximum cost limit set in

Set

max

cost

•

Reset

counters

: reset the cost counters.

•

Set

max

cost

: set the maximum cost authorised

for your calls.

•

Price/Unit

: set the price per unit that is applied

when the cost of your calls is calculated.

The password is preset to

00000000

. You can

change this password.



p. 83

Menu functions

Phonebook

(Menu 2)

Phonebook

(Menu 2)

You can store phone numbers on your SIM card and in

your phone’s memory. The SIM card and phone’s

memory are physically separate, but they are used as

a single entity called Phonebook.

To access this menu, press <

> in Idle mode and

select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for numbers in Phonebook.

Finding an entry

1. Enter the first few letters of the name that you

want to find.

2. Select the name you want from the list.

3. Press [ ] to dial the number, or <

Options

> to

access Phonebook options.

Using Phonebook options

While viewing the contact list or contact details, press

Options

> to access the following options:

•

View

: display details about the contact.

•

Edit

: edit the contact information.

•

Send message

: send an SMS or MMS message.

•

Copy

: copy the contact to the phone’s memory or

the SIM card.

•

Add new contact

: add a new contact to the

phone’s memory or the SIM card.

•

Send via

: send the contact via SMS, MMS, e-mail,

or infrared port.

•

Delete

: delete the selected contact or all contacts.

•

Language select

: select a language to be used in

the text input mode.

Press <

Contacts

> in Idle mode to quickly access

this menu.

Menu functions

FDN list

(Menu 2.2)

Use this menu to create a list of contacts to be used in

FDN (Fixed Dialling Number) mode, in which the

phone allows outgoing calls only to the specified

phone numbers, if your SIM card supports this

feature. You can activate FDN mode in the FDN mode

menu.



p. 83

Adding a contact

1. Press <

Options

> and select

Add

2. Enter your PIN2 and press <

3. Enter a name and phone number, or press

Options

> and select Contact list to retrieve a

contact from Phonebook.

4. If necessary, change the location number.

5. Press <

Save

> to save the contact.

Using contact options

Scroll to a contact and press <

Options

> to access

options.



p. 31

Add new contact

(Menu 2.3)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the

contact.

•

Last name

First name

: assign a name.

•

Mobile

Home

Office

Fax

Other

: add a

number in any category.

•

: assign an e-mail address.

•

Caller ID

: assign an image as a caller ID

image to alert you to a call from the number.

•

Ringtone

: assign a ringer melody to alert you

to a call from the contact.

•

Group

: assign the contact to a caller group.

•

Notes

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter a name and press [Down].

Menu functions

Phonebook

(Menu 2)

3. Enter a phone number.

4. Press [Down] and change the location number, if

necessary.

5. Press <

Save

> to save the contact.

Group

(Menu 2.4)

Use this menu to organise your contacts in caller

groups.

Adding members to a caller group

1. Select a group.

2. Press <

Add

>. The list of contacts stored in your

phone’s memory is displayed.

3. Scroll to a contact and press <

Select

4. To add more contacts, press <

Options

> and

select

Add

→

a contact.

5. Repeat step 4 as desired.

Managing caller groups

While viewing the group list, press <

Options

> to

access the following options:

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: change the properties of the selected group.

•

Send message

: send SMS, MMS, or e-mail

messages to the group members.

•

Delete

: delete the selected group. Group

members, however, are not deleted from

Phonebook.

Speed dial

(Menu 2.5)

Use this menu to assign a speed dial number (2 to 9)

for eight of your most frequently called numbers.

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved

for your voicemail server.

2. Select a contact you want from the contact list.

3. Select a number from the contact, if it has more

than one number.

4. Press <

Select

Menu functions

Managing speed dial entries

From the Speed dial screen, press <

Options

> to

access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: view the number assigned to the key.

•

Change

: assign a different number to the

assigned key.

•

Remove

: clear the speed dial settings for the

selected key.

Dialling speed dial entries

Press and hold the appropriate key in Idle mode.

My name card

(Menu 2.6)

Use this menu to create a name card and send it to

other people.

Saving your name card

The procedure for creating your name card is the

same as the one for saving a phone number in the

phone’s memory.



p. 32

Using name card options

After saving your name card, press <

Options

> to

access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS, MMS, e-

mail, or infrared port.

•

Remove

: delete the name card.

Own number

(Menu 2.7)

Use this feature to check your phone numbers, or to

assign a name to each of the numbers. Changes made

here do not affect the actual subscriber numbers on

your SIM card.

Management

(Menu 2.8)

Use this menu to manage Phonebook.

•

Default saving

: select a default memory location

to save contacts.

If you select

Ask on saving

, the phone will ask

you to select a memory location when saving a

number.

Menu functions

Applications

(Menu 3)

•

Copy all to phone

: copy all of the contacts stored

on the SIM card to the phone’s memory.

•

Sort by contacts

: change the sort order of

Phonebook.

•

Delete all

: delete all of the contacts from your

phone’s memory, your SIM card, your FDN list, or

all at once.

1.Press [ ] to check the location(s) to be cleared.

2.Press <

Delete

3.Press <

Yes

> again to confirm the deletion.

4.Enter the phone password and press <

•

Memory status

: display the number of contacts

you have stored in Phonebook.

Service number

(Menu 2.9)

This menu is available if your SIM card supports

Service Dialling Numbers (SDN). Use this menu to

view the list of SDNs assigned by your service

provider, including emergency numbers, directory

enquiries, and voicemail numbers.

1. Scroll to the number you want.

2. Press <

Dial

> or [ ].

Applications

(Menu 3)

Use this menu to play Java games, to play music files,

to record a voice memo, to set time zones and alarms,

or to use the phone as a calculator, timer, or

stopwatch.

To access this menu, press <

> in Idle mode and

select

Applications

The password is preset to

00000000

. You

can change this password.



p. 83

Menu functions

MP3 Player

(Menu 3.1)

Use this menu to enjoy music. First, you need to save

MP3 files in your phone’s memory.

Downloading or receiving music files

Use these methods to save MP3 files to your phone’s

memory:

• Download from the wireless web



p. 43

• Download from a computer using the EasyStudio II

program



EasyStudio II User’s Guide

• Via an active infrared port



p. 81

The downloaded or received files are stored in the

Music

folder.



p. 63

Creating a play list

Add MP3 files to the play list.

1. From the MP3 player screen, press <

Options

and select

Add to list

2. Select either of the following options:

•

Add all

: add all of the files in the phone’s

memory to the play list.

•

Add a file

: add specific files to the play list.

3. If you selected

Add a file

, scroll to a file and press

Add

>. Repeat from step 2.

4. Press <

Back

> to go back to the MP3 player

screen.

Playing music files

From the MP3 player screen, press [ ].

During playback, use the following keys:

Keys Function

Pauses or resumes playback.

Left Goes back to the previous file.

Right Skips to the next file.

Up Opens the play list.

3 Changes the repeat mode.

6 Switches to shuffle mode.

/ Adjusts the volume level.

Down Stops playback.

Menu functions

Applications

(Menu 3)

Using MP3 file options

From the MP3 player screen, press <

Options

> to

access the following options:

•

Pause

Play

: pause or resume playback.

•

Send via

: send the currently selected file via e-

mail or infrared port.

•

Open play list

: display the play list.

•

Set as

: set the file as your alarm sound, ringtone,

or a caller alert melody for a Phonebook entry.

•

Delete

: delete the selected file.

•

Settings

: change the default settings for playing

music files.

Repeat mode

: select a repeat mode.

Shuffle

: set the MP3 player to play music in

random order.

Visualization

: select a visualization type

Skin

: select a skin type.

Volume

: select a volume level.

•

Properties

: access the properties of the file.

Accessing the play list

From the MP3 player screen, press [Up] to access the

play list.

Press <

Options

> to access the following options:

•

Play

: play the currently selected file.

•

Add to list

: add files to the play list.

•

Move list

: move the selected file to the position

you want within the play list.

•

Remove

: remove the selected file from the play

list.

•

Remove all

: remove all files from the play list.

Voice recorder

(Menu 3.2)

Use this menu to record voice memos. A voice memo

can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume the recording.

Menu functions

3. When you finish, press <

Stop

>. The voice memo

is saved automatically.

After recording a voice memo, press <

Options

> to

access the following options:

•

Play

: play back your voice memo.

•

Send via

: send the voice memo via MMS, e-mail,

or infrared port.

•

Set as

: set the file as your alarm sound, ringtone,

or a caller alert melody for a Phonebook entry.

•

Delete

: delete the voice memo.

•

Rename

: change the name of the voice memo.

•

Move to favorite

: move the voice memo to the

favourite sounds folder.

•

Protection

: protect the voice memo from being

deleted.

•

Properties

: access the properties of the voice

memo.

Playing a voice memo

1. From the Voice recorder screen, press <

Options

and select

Go to voice list

2. Select a voice memo. The memo plays.

On the player screen, you can use the following keys:

Using voice recorder options

From the Voice record screen, press <

Options

> to

access the following options:

•

Record

: record a new voice memo.

•

Settings

: change the default settings for

recording a voice memo.

Recording time

: select a maximum recording

time.

Volume

: select a volume level.

Default name

: change the default prefix of the

voice memo.

Equalizer value

: select an equalizer image.

Keys Function

Pauses or resumes playback.

Up Goes back to the Voice record screen.

Down Stops playback.

/ Adjusts the volume.

Menu functions

Applications

(Menu 3)

•

Go to voice list

: go to the voice memo list.

Java world

(Menu 3.3)

Use this menu to access and play Java games and to

change the network settings for accessing Java

services.

Using Java game options

From the Java world screen, select

Downloads

and

press <

Options

> to access the following options:

•

Launch

: launch the selected game.

•

Application settings

: set a game to be continued

when a call comes in or an alarm sounds during

the game. You can also set the phone to exchange

game information with the network while playing

an online game or when you need to connect to

the Internet.

•

Delete

: delete the game.

•

Properties

: view the game properties.

Playing Forgotten Warrior

1. From the

Java world

menu, select

Downloads

→

Forgotten Warrior

2. Press any key.

3. Press <

PLAY

4. Select

START GAME

CONTINUE

5. Press <

Skip

> to start a game.

Playing Freekick

1. From the

Java world

menu, select

Downloads

→

Freekick

2. Press any key.

3. Select

Game

→

the game mode you want

→

team

→

a player.

During a game, press <

OPTIONS

> to access game

options.

During a game, press

[]

to access game menus.

Menu functions

Playing Arch Angel

1. From the

Java world

menu, select

Downloads

→

Arch Angel

2. Press any key.

3. Select

NEW GAME

LOAD GAME

→

a game

mode.

4. Press <

> continuously or <

SKIP

>, and then

Play

5. Press <

> until the game starts, or <

Skip

> to

start the game immediately.

Changing Java settings

You can change the settings for accessing Java

services.

1. From the

Java world

menu, select

Settings

2. Change the following settings:

•

APN

: enter the access point name.

•

: enter the user ID.

•

Password

: enter the password.

•

Proxy

: select whether or not you use a proxy

server to access network services. Depending

on this setting, options in

Proxy settings

vary.

•

Proxy settings

: provide you with the following

options:

When the proxy is set to

Enable

IP address

: enter the HTTP proxy address.

Port

: enter the port number.

When the proxy is set to

Disable

DNS1

: Enter the primary DNS address.

DNS2

: Enter the secondary DNS address.

Checking memory status

You can view the amount of total and used memory for

Java games.

From the

Java world

menu, select

Memory status

World time

(Menu 3.4)

Use this menu to set your local time zone and find out

what time it is in another part of the world.

During a game, press <

OPTIONS

> to access game

options.

Menu functions

Applications

(Menu 3)

Setting your local time zone

1. From the world map, press [Left] or [Right] to

select the city that corresponds to your home time

zone. As the time line moves, the time and date of

the given zone display.

2. Press <

Options

> and select

Save

to save the

time zone.

Viewing and setting a foreign time zone

1. From the world map, press [Down].

2. Press [Left] or [Right] to select the foreign time

zone you want to view.

3. Press <

Options

> and select

Save

to save the

time zone.

Applying Daylight Savings Time

1. From the world map, press <

Options

> and select

Set daylight saving time

2. Press [ ] to check the time zone(s) you want.

3. Press <

Save

Alarm

(Menu 3.5)

Use this menu to set alarms to sound at specific times.

Setting an alarm

1. Select the type of alarm.

2. Select

on the

Alarm

line and press [Down].

3. Enter the time for the alarm to sound and press

[Down].

4. If necessary, select

in 12-hour time

format and press [Down].

5. Select the day(s) on which you want to the alarm

to ring.

6. Select the

Alarm tone

line.

7. Select an alarm melody.

8. Press <

Save

> and then <

Yes

Stopping an alarm

When the alarm sounds, choose either of the following

options to stop the alarm.

• Press <

You can change the time format.



p. 75

Menu functions

•Press <

Snooze

> or any key to stop the wake-up

alarm for 5 minutes. You can do this a maximum of

five times.

Setting the alarm to ring even if the phone is

off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the alarm to ring,

the phone is switched on and sounds the alarm.

Calculator

(Menu 3.6)

Use this menu to perform basic arithmetic functions,

such as addition, subtraction, multiplication, and

division.

1. Enter the first number.

• Press the left soft key to insert a decimal point

or bracket.

•

Press

[] or [] t

o move the cursor.

2. Press one of the Navigation keys to access the

math function you want.

3. Enter the second number.

4. Press [ ] to view the result.

Converter

(Menu 3.7)

Use this menu for common conversions, such as

currency and temperature.

1. Select a converter.

2. Press [Left] or [Right] to select the original unit

and press [Down].

3. Enter the value to be converted and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

zero (+) or below zero (-)

4. Press [Left] or [Right] to select the unit you want

to convert to.

The equivalent value for the amount you entered

displays.

Timer

(Menu 3.8)

Use this menu to set a period of time for the phone to

count down. The phone will sound an alarm when the

specified period of time has expired.

Menu functions

Browser

(Menu 4)

Starting the timer

1. Press <

Set

2. Enter the length of time you want to count down

and press <

3. Press [ ] to start counting down.

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer

before it rings.

Stopwatch

(Menu 3.9)

Use this menu to measure elapsed time. The precision

of the stopwatch is one one-hundredth of a second.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can repeat this

step for a total of 4 intervals.

3. To reset the stopwatch, press <

Reset

SIM AT

(Menu 3.10)

This menu is available if you use a SIM AT card that

provides additional services, such as news, weather,

sports, entertainment, and location services. Available

services may vary, depending on your service

provider’s plans. For details, see your SIM card

instructions or contact your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP) browser on

your phone allows you to access the wireless web.

Using the WAP browser, you can access up-to-date

information and a wide variety of media content, such

as wallpapers, ringtones, and music files.

To access this menu, press <

> in Idle mode and

select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the network

and load the homepage of the wireless web service

provider. You can also press [ ] in Idle mode.

Menu functions

Navigating with the WAP browser

Using WAP page options

From any WAP page, press <

> and select

to access the following options:

•

Back

: go back to the previous page.

•

Home

: go back to the homepage.

•

Exit

: exit the WAP browser.

•

Reload

: reload the current page.

•

Show URL

: display the URL address of the current

web page.

•

About...

: access version information for your WAP

browser.

Using menu options

While viewing the menu options, press [ ] to access

the following menu options:

•

Go to URL

: enter the URL address of a website

and access the website.

•

Bookmarks

: save URL addresses to quickly

access websites.

•

Messages

: send SMS messages or view the

messages stored in the phone.

•

File manager

: access images, videos, music files,

and sound files stored in the phone’s memory.

Exiting the WAP browser

Press [ ] to exit the browser.

Bookmarks

(Menu 4.2)

Use this menu to save URL addresses in order to

quickly access websites.

Adding a bookmark

1. Select an empty location.

2. Enter a name for the bookmark and press [Down].

To Press

scroll through browser items the Navigation

keys.

select a browser item < >.

Menu functions

Browser

(Menu 4)

3. Enter a URL address and press <

Options

> and

select

Save

Accessing a bookmarked page

Scroll to a bookmark item and press [ ].

Using bookmark options

After saving an item, press <

Options

> to access the

following options:

•

: access the bookmarked website.

•

Edit

: edit the address and name of the bookmark.

•

Delete

: delete the selected bookmark.

Go to URL

(Menu 4.3)

Use this menu to manually enter the URL address of a

website and access the website.

Clear cache

(Menu 4.4)

Use this menu to clear the cache, a temporary

memory that stores recently accessed web pages.

Profile settings

(Menu 4.5)

Use this menu to set up servers for the WAP browser.

Contact your service provider for details about your

settings options.

For each server, the following options are available:

•

Profile

name

: assign a name to the server profile.

•

Home

URL

: set the address of your homepage.

•

Bearer

: select a bearer for each type of network

address accessed.

•

Proxy

: select whether or not the phone uses a

proxy server to launch the WAP browser. Your

service provider can tell you if your network

requires a proxy server, and they can give you the

appropriate settings.

•

GPRS settings

: customise the following GPRS

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the WAP gateway address.

Proxy port

: enter the port number.

Menu functions

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID.

Password

: enter the password.

When the proxy is set to

Disable

DNS 1

: enter the primary address.

DNS 2

: enter the secondary address

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID

Password

: enter the password

•

GSM settings

: customise the following GSM

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the WAP gateway address.

Proxy port

: enter the port number.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

When the proxy is set to

Disable

DNS 1

: enter the primary address.

DNS 2

: enter the secondary address.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

Current profile

(Menu 4.6)

Use this menu to activate one of the proxy servers you

have set up.

Menu functions

Messages

(Menu 5)

Messages

(Menu 5)

Use the

Messages

menu to send and receive text

messages, multimedia messages, and e-mails. You

can also use WAP push message, and cell broadcast

message features.

To access this menu, press <

> in Idle mode and

select

Messages

Create new message

(Menu 5.1)

Use this menu to create and send SMS, MMS, or

e-mail messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to send or

receive text messages that may include pictures,

animated images, and melodies.

1. Enter your message.

2. Press <

Options

> to access one of the following

options:

•

Insert

: retrieve a text template, contact, or

bookmark item.

•

Add picture

animation

melody

: add a

picture, animated image, or melody to the

message.

•

Attach

: add a name card or calendar memo.

•

Save to

: save the message in

Draft

folder

•

Language select

: select a language to be

used in the text input mode.

•

Text style

: change the text attributes.

3. When you have finished, press <

Options

> and

select

Save and send

Send only

4. Enter a destination number.

To send the message to more than one recipient,

press [Down] and fill in additional destination

fields.

5. Press [ ] to send the message.

The maximum number of characters allowed in a

text message varies by service provider. If your

message exceeds the maximum number of

characters, the phone will split the message.

Menu functions

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers messages

containing a combination of text, image, video, and

audio, from phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Picture & Video

Sound

line and add

an image, a video, or a sound file.

4. Select the

Message

line.

5. Enter the message text and press [ ].

6. Press <

Options

> to access the following options:

•

Edit

: edit the subject or text of your message.

•

Preview

: check the message you created.

•

Save to

: save the message to

Draft

folder

, or

MMS Template

•

Add page

: add pages. Move to each page by

pressing [Left] or [Right] on the message

screen.

•

Delete page

: delete the current page.

•

Edit page

: set the page duration or move the

current page to the next or previous page.

•

Attach

: add a name card or a calendar memo.

•

Remove subject


sound

message

clear the subject, image, sound, or text.

7. When you have finished, press <

Options

> and

select

Send

8. Enter a phone number or e-mail address.

To send the message to more than one recipient,

press [Down] and fill in additional destination

fields.

9. Press [ ].

(Menu 5.1.3)

You can send e-mails that include text, audio, and

images. To use this feature, you need to subscribe to

an e-mail service and set up your e-mail account and

profile.



p. 59

1. Select the

Subject

line.

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

The maximum size allowed for an MMS message

can differ depending on the country. If you

cannot attach another file, add another page.

Menu functions

Messages

(Menu 5)

4. Enter the e-mail text and press [ ].

5. Select the

File attach

line.

6. Add media files.

Depending on the file type or DRM

(Digital Rights Management) system, some files may

not be able to be forwarded

7. When you have finished, press <

Options

> to

access the following options:

•

Edit

: edit the subject or text.

•

View

: play an added item.

•

Attach

: add a calendar memo or a name card.

•

Save to

: save the message in the

Drafts

My folder

box.

•

Remove subject

message

: clear the subject

or text.

•

Remove

: delete the selected attachment.

•

Remove all attachments

: delete all

attachments.

8. When you have finished, press <

Options

> and

select

Send

9. Enter an e-mail address.

To send the e-mail to more than one recipient,

press [Down] and fill in additional destination

fields.

10.Press [ ] to send the e-mail.

My messages

(Menu 5.2)

Use this menu to store all of the messages you have

received, sent, or tried to send.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you have

received, except for e-mails.

Viewing a message at the time of its receipt

When a message has been received, the phone alerts

you by:

• Displaying a message icon with text notification

• Sounding a tone or vibrating, depending on the

message alert setting

To read a message immediately, press <

View

> and

select a message from the Inbox.

Options may vary depending on the selected

field.

Menu functions

For an MMS notification, press <

Options

> and select

Retrieve

. The message is downloaded from the MMS

server to the phone’s memory.

Viewing a message in Inbox

The following icons may appear on the message list;

depending on the message type or status, icons may

vary:

• SMS

• MMS

• MMS notification; indicates that MMS has

been retrieving from the server and

indicates that MMS has been failed to

retrieve.

• WAP push/configuration

• CB messages

• Delivery report

While viewing the message list, press <

Options

> to

access the following options:

•

View

: open the message.

•

Retrieve

: retrieve the MMS message from the

server.

•

Delete

: delete the message.

•

Move to my folder

: move the message to the

folders

folder.

•

Sort by

: change the sort order of the messages.

•

Protection

: protect the message from being

deleted.

• According to the DRM (Digital Rights

Management) system, messages having web

content may not be able to be forwarded.

They are indicated by .

• A

icon next to a message means that a

message is of high priority. A grey-coloured

message icon is of low priority.

Options may vary depending on your country or

service provider.

Menu functions

Messages

(Menu 5)

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

: reply to the sender via SMS or MMS

message.

•

Forward

: forward the message.

•

Delete

: delete the message.

•

Move to phone/SIM

: move the message

between the SIM card and the phone’s memory.

•

Add to block list

: add the number to the Block

list.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

into your phone’s memory.

•

Protection

: protect the message from being

deleted.

MMS messages

•

Reply via SMS

: send a reply message via SMS.

•

Reply via MMS to

: send a reply message via

MMS.

•

Forward

: forward the message to another person.

•

Delete

: delete the message or all messages.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

into your phone’s memory.

•

Properties

: access the message properties.

Configuration messages

•

Install

: apply the configuration specified in the

message to your phone.

•

Delete

: delete the message.

•

Properties

: access the message properties.

WAP push messages

•

Go to URL

: connect to the URL specified in the

message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

Menu functions

CB messages

•

Save

: saves the message to the phone’s memory.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

Delivery report messages

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

Draft

(Menu 5.2.2)

This folder stores messages you have saved to send at

a later time.

While viewing the message list, press <

Options

> to

access the following options:

•

View

: display the message.

•

Edit

: edit the message.

•

Send

: send the message.

•

Delete

: delete the message or all messages.

•

Move to my folder

: move the message to the

folder

box.

•

Move to phone/SIM

: move the message

between the SIM card and the phone’s memory.

•

Sort by

: change the sort order of the message list.

•

Protection

: protect the message from being

deleted.

Outbox

(Menu 5.2.3)

This folder stores messages that the phone is

attempting to send or has failed to send.

While viewing a message, press <

Options

> to access

the following options:

•

Send again

: send the message again.

•

Forward

: forward the message to other people.

•

Delete

: delete the selected message.

•

Move to phone/SIM

: move the message

between the SIM card and the phone’s memory.

•

Protection

: protect the message from being

deleted.

From the message list, press <

Options

> to access

the following options:

•

View

: open the message.

Menu functions

Messages

(Menu 5)

•

Send again

: send the message again.

•

Delete

: delete the message or all messages.

•

Move to my folder

: move the message to

folder

box.

•

Move to phone/SIM

: move the message

between the SIM card and the phone’s memory.

•

Sort by

: change the sort order of the message list.

•

Protection

: protect the message from being

deleted.

Sentbox

(Menu 5.2.4)

This folder stores messages that you have sent.

While viewing a message, press <

Options

> to access

the following options:

•

Forward

: forward the message to other people.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Move to phone/SIM

: move the message

between the SIM card and the phone’s memory.

•

Protection

: protect the message from being

deleted.

•

Properties

: access information about the

message.

From the message list, press <

Options

> to access

the following options:

•

View

: open the message.

•

Forward

: forward the message to other people.

•

Delete

: delete the selected message.

•

Move to my folder

: move the message to the

folder

box.

•

Sort by

: change the sort order of the message list.

•

Properties

: access properties of the message.

•

Protection

: protect the message from being

deleted.

•

Move to Phone/SIM

: move the message

between the SIM card and the phone’s memory.

Menu functions

Email box

(Menu 5.2.5)

This folder stores e-mails that you have received.

1. Select an e-mail account.

2. Press <

Select

> when

Check new mail

highlighted to get new e-mails from the server.

The phone checks for new e-mails and retrieves

received e-mails.

The following icons may appear on the message

list; depending on the e-mail status, icons may

vary:

• has been read

• has not been read

• has been retrieved from the server

• has not been retrieved; indicates that

an e-mail has been retrieving from the

server and indicates that an e-mail has

been failed to retrieve.

3. Scroll to an e-mail or header and press [ ].

4. If the e-mail has more than one page, press [ / ]

to scroll through pages one by one.

Press [Left] or [Right] to move to the first or last

page.

5. Select an attached file to view or play it.

While viewing the e-mail content or message list,

press <

Options

> to access the following options:

•

View

: open the selected item.

•

Retrieve

: retrieve one or all of the e-mails from

the e-mail server.

•

Reply to

: send a reply to the sender or to all of

the other recipients.

•

Forward

: forward the e-mail.

•

Delete

: delete the currently selected item.

•

Move to my folder

: move the e-mail to the

folder

folder.

•

Add to block list

: add the sender’s e-mail

address to the filter list to reject e-mails from that

address.

icon next to a message means that a

message is of high priority. A grey-

coloured message icon is of low priority.

Options may vary depending on the status of the

e-mail.

Menu functions

Messages

(Menu 5)

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut attachment

: save media content from the

message to your phone’s memory.

•

Check new Email

: check the Email box for new

e-mails.

•

Properties

: access the properties of the e-mail.

My folder

(Menu 5.2.6)

Use this menu to save the message you have saved in

this folder while reading a message.

While viewing a message list, press <

Options

> to

access the following options:

•

View

: view the message.

•

Edit

: edit the message.

•

Send

: send the message.

•

Delete

: delete the selected message or all of the

messages.

•

Sort by

: change the sort order or the message

list.

•

Properties

: access properties of the message.

Templates

(Menu 5.3)

Use this menu to create, edit, and send text templates

and MMS templates.

Text template

(Menu 5.3.1)

Use this menu to preset a maximum of frequently

used messages.

From the Text templates screen, press <

Options

> to

access the following options:

•

Edit

: change the selected template.

•

Send message

send the template as an SMS,

MMS, or e-mail message.

•

Delete

: delete the template.

MMS template

(Menu 5.3.2)

When you access this menu, you can view the list of

templates you have saved.

From the MMS template list, press <

Options

> to

access the following options:

•

View

: open the template message.

•

Send message

send the template as an MMS

message.

Menu functions

•

Edit

: change the selected template.

•

Add new

: add a new template.

•

Delete

: delete the template or all templates.

Delete all

(Menu 5.4)

Use this menu to delete messages in each message

folder one by one, or all at once.

1. Press [ ] to check the message boxes to be

cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Settings

(Menu 5.5)

Use this menu to set up various options for using the

messaging service.

Text message

(Menu 5.5.1)

You can configure default SMS settings.

•

Send settings

: set up the following options for

sending a text message:

Reply path

: allow the recipient to reply to you

through your message centre.

Delivery report

: set the network to inform you

when your message has been delivered.

Character support

: select a character encoding

type. If you select

Auto

, the phone switches the

encoding type from GSM-alphabet to Unicode if

you enter an Unicode character. Use of Unicode

encoding will reduce the maximum number of

characters in a message to about half.

If this menu is not shown, your phone provides the

Auto

character encoding by default.

Validity period

: set the length of time your

messages are stored in the SMS centre.

Message type

: set the default message type. The

network can convert the messages into the

selected format.

Service centre

: store or change the number of

your message centre.

•

Block address

: set up a message filter by

entering phone numbers so that the phone rejects

messages from those numbers.

Menu functions

Messages

(Menu 5)

Multimedia message

(Menu 5.5.2)

You can configure default MMS settings.

•

Send settings

: set up the following options for

sending a multimedia message:

Delivery report

: set the network to inform you

when your message has been delivered.

Address hiding

: set your address to be hidden

from the recipient’s phone.

Read reply

: determine whether or not the phone

sends a read-reply request.

Priority

: set the priority level of your messages.

Expiry Date

: set the length of time your

messages are stored in the MMS centre.

Delivery after

: set a time delay before messages

are sent.

Send size

: select maximum size of attached items

allowed for an MMS message.

•

Receive settings

: set up the following options for

receiving a multimedia message:

Anonymous reject

: reject messages from

unknown senders.

Advert allowed

: accept advertisements.

Report allowed

: send a delivery report from the

network to the sender.

Home reception

: determine if your phone

retrieves new messages automatically when you

are in your home service area.

Roaming reception

: determine if your phone

retrieves new messages automatically when you

are roaming in another network.

Home reception and Roaming reception have the

following options:

•

Automatic

: the phone automatically retrieves

messages from the server.

•

Reject

: the phone rejects all messages.

•

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

•

MMS profiles

: select a connection profile to be

used for MMS.

Current profile

: select a profile.

Menu functions

Profile settings

: customise the following

options for each profile.

Profile name

: assign a name to the MMS

profile.

Server URL

: enter the address of your MMS

server.

Proxy

: connect to the GPRS network using the

proxy server.

GPRS settings

: customise the settings

required for connecting to the GPRS network.

IP address

: (when the proxy is set to Enable)

enter the IP address.

Port

: (when the proxy is set to Enable) enter

the port number.

DNS1

: (when the proxy is set to Disable) enter

the primary address.

DNS2

: (when the proxy is set to Disable) enter

the secondary address.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

Version

: select the maximum file size of MMS

attachments.

•

Block number

: set up a message filter by

entering phone numbers so that the phone rejects

messages from those numbers.

(Menu 5.5.3)

You can configure default network settings that are

required to send or receive e-mails.

•

Send settings

: set up the following options for

sending an e-mail:

Send copy to self

: send a copy of your e-mail to

your own e-mail address.

Delivery confirm

: set the network to inform you

when your e-mail has been delivered.

Read confirm

: send a request for a reply along

with your e-mail.

Priority

: select the priority level of your e-mail.

You cannot change e-mail profile settings while an

e-mail is being sent or retrieved.

Menu functions

Messages

(Menu 5)

Include signature

: attach your name, phone

number, a simple memo, or a tag line to your

e-mail.

Edit name

: edit the name in your signature.

Edit telephone number

: edit the phone number

in your signature.

Edit note

: edit the tag line in your signature.

•

Receive settings

: set up the following options for

receiving e-mails.

Check interval

: determine how often the phone

checks the server for incoming e-mails.

If you set this option to

Not used

, you can use the

Check new mail

feature to check your e-mail

manually.

Read reply

: determine whether or not the phone

sends a read-reply request.

When this option is set to

Announce

, the phone

reminds you to send a read-reply request with

your e-mail address.

Retrieve option

: determine whether or not the

phone retrieves headers only or the entire e-mail.

Delete option

: determine whether e-mails are

deleted immediately or the next time you connect

to the server.

Reject if over

: determine the maximum size for

incoming e-mails. Your phone will reject

e-mails that exceed the specified size.

Leave a copy of messages on the server

: leave

copies of e-mails after retrieving.

•

Email account

: set up an e-mail account and

select an account to be used.

Current account

: select an account.

Account settings

: configure up to five e-mail

accounts using different e-mail servers. The

following options are available for each account:

•

In use

: activate the current e-mail account.

•

Account name

: enter a name for the currently

selected account.

•

User name

: enter a user name.

•

Email address

: enter your e-mail address.

Menu functions

•

Reply address

: enter an e-mail address to be

used when you send a reply message.

•

User ID

: enter your e-mail ID.

•

Password

: enter your e-mail password.

•

SMTP server

: enter the IP address or domain

name of the outgoing e-mail server.

•

SMTP port

: enter the SMTP port number.

•

Protocol type

: select the protocol for the

incoming e-mail server. The remaining options

depend on the protocol type setting.

The following options are available when the

protocol type is

POP3

•

POP3 server

enter the IP address or domain

name of the server that receives your e-mail.

•

POP3 port

: enter the POP3 port number.

•

APOP login

: connect to the server by using

the APOP login scheme when this option is

selected.

These options are available when the protocol type

IMAP4

•

IMAP4 server

: enter the IP address or domain

name of the server that receives your e-mail.

•

IMAP4 port

: enter the IMAP4 port number.

•

Include attachments

: select this option to

receive attachments with e-mails.

•

Max. Emails retrieved

: set the number of

headers you will retrieve from the server.

•

Email profile

: configure the network settings

required to send or receive e-mails.

Current profile

: select a profile.

Profile settings

: configure up to five e-mail

profiles.

Profile name

: enter a profile name.

APN

: enter the access point name.

: enter user ID.

Password

: enter the password.

DNS1

: enter the primary DNS address.

DNS2

: enter the secondary DNS address.

•

Block list

: set up a message filter.

Address list

: specify e-mail addresses to reject

e-mails from those addresses.

Subject list

: specify subjects to reject e-mails

which contain those subjects.

Menu functions

Messages

(Menu 5)

Push message

(Menu 5.5.4)

You can change the settings for receiving WAP push

messages from the wireless web server. The following

options are available:

•

Receive

: set how your phone receives push

messages.

•

Service centre

: enter the address of the server

from which you want to receive push messages,

when the

Receive

option is set to

SMS-C

specific

Broadcast messages

(Menu 5.6)

The Cell Broadcast service delivers short messages on

various such as the weather or traffic.

Use this menu to change the settings for the service

and access broadcast messages.

•

Read

: open received messages.

The

Temporary

box saves network messages until

the phone is switched off.

The

Archive

box.

•

Receive

: enable or disable the reception of

broadcast messages.

•

Channel

: specify the channels from which you

receive broadcast messages.

When you select

Respective channels

, you can

set up a list of active CB channels.

•

Language

: select the language in which broadcast

messages display.

Please contact your service provider for details.

Memory status

(Menu 5.7)

Use this menu to view the maximum memory and

available memory for each message type. You can also

view the memory currently in use in each folder.

Menu functions

File manager

(Menu 6)

The

File manager

menu allows you to access images,

videos, music files, and sound files stored in the

phone’s memory.

To access this menu, press <

> in Idle mode and

select

File manager

Images

(Menu 6.1)

This menu displays photos you have taken and images

downloaded or received in messages.

Viewing an image

1. Select an image folder.

2. Scroll to an image and press [ ].

Using image options

While viewing an image or the image list, press

Options

> to access the options.

•

View

: display the image.

•

List

: show the image list.

•

Send via

: send the image via MMS, e-mail, or

infrared port.

•

Set as

: set the image as your wallpaper or caller

ID image for a Phonebook entry.

•

Edit

: add emoticon, frame, or effect to the image.

•

Delete

: delete the image or all images.

•

Rename

: change the name of the image.

•

Move to favourite images

: move the image to

the

Favourite images

folder.

•

Slide show

: set all images to display as a slide

show. You can select a time interval between

images.

•

Protection

: protect the image from being deleted.

•

Properties

: access the properties of the image.

Videos

(Menu 6.2)

This menu displays video clips you have recorded,

downloaded, or received in messages.

Playing a video clip

1. Select a video folder.

According to the DRM (Digital Rights Management)

system, web content may not be able to be

forwarded. The content is indicated by .

Menu functions

File manager

(Menu 6)

2. Scroll to a clip and press [ ].



p. 38

During playback, use the following keys.

Using video options

While viewing the video list, press <

Options

> to

access the options.

•

Play

: play the video clip.

•

Send via

: send the video clip via MMS, e-mail, or

infrared port.

•

Delete

: delete the video clip or all video clips.

•

Rename

: change the name of the video clip.

•

Move to favourite videos

: move the video clip to

the

Favourite videos

folder.

•

Protection

: protect the video clip from being

deleted.

•

Properties

: access the properties of the video

clip.

Music

(Menu 6.3)

This menu displays MP3 files you have downloaded,

received in messages, or imported from your

computer.

Playing a music file

Scroll to a file and press [ ].



p. 36

Using music options

While viewing the music list, press <

Options

> to

access the following options:

•

Play

: play the music file.

•

Send via

: send the file via e-mail or infrared port.

•

Add play list

: add a file to the play list.

Keys Function

Pauses or resumes playback.

Up Turns the repeat feature on or off.

Left Goes back to the previous video clip.

Right Skips to the next video clip.

/ Adjusts the volume.

Down Stops playback.

Menu functions

•

Set as

: set the file as your ringtone, alarm tone or

as a caller alert melody for a Phonebook entry.

•

Delete

: delete the selected file or all files.

•

Settings

: change the default settings for playing

music files.

Repeat mode

: select a repeat mode.

Shuffle

: select a playing order.

Visualization

: select a visualization type.

Skin

: select a skin type.

Volume

: select a volume level.

•

Rename

: change the file name.

•

Protection

: protect the file from being deleted.

•

Properties

: access the properties of the file.

Sounds

(Menu 6.4)

This menu displays sound files you have recorded,

downloaded, or received in messages.

Playing a sound clip

1. Select a sound folder.

2. Scroll to a clip and press [ ].



p. 36

Using sound options

While viewing the sound list, press <

Options

> to

access the following options:

•

Play

: play the sound file.

•

Send via

: send the file via MMS, e-mail, or

infrared port.

•

Set as

: set the file as your ringtone, alarm tone or

as a caller alert melody for a Phonebook entry.

•

Delete

: delete the selected file or all files.

•

Rename

: change the file name.

•

Move to favourite sounds

: move the sound clip

to the

Favourite sounds

folder.

•

Protection

: protect the file from being deleted.

•

Properties

: access the properties of the file.

Other files

(Menu 6.5)

Files that you receive but which are not supported by

your phone are stored in this folder. These

unsupported file formats include *.doc, *.hwp, *.ppt,

*.txt.

Menu functions

Calendar

(Menu 7)

While viewing the file list, press <

Options

> to access

the following options:

•

Send via

: send the file via e-mail or infrared port.

•

Delete

: delete the file or all files.

•

Rename

: change the file name.

•

Protection

: protect the file from being deleted.

•

Properties

: access the properties of the file.

Memory status

(Menu 6.6)

You can check the total amount of memory for media

items and the amount of memory currently in use in

each media box.

Calendar

(Menu 7)

The Calendar feature enables you to keep track of

your schedule and to-do list, to view missed alarm

events, and to make a memo.

To access this menu, press <

> in Idle mode and

select

Calendar

Consulting the calendar

When you enter the

Calendar

menu, the calendar in

Month view appears with today’s date indicated by a

blue box.

The number of events for the specific day appears at

the bottom of the calendar. The following icons

indicate the type of event:

Press <

Options

> to access the following options:

•

View mode

: change the view mode of the

calendar.

•

Create

: add a new event.

•

Go to

: go to the current date or a specific date.

•

Sort by

: sort items by the type of event.

•

Delete

: delete items stored on the calendar by

using various deleting options.

• Scheduled event • Anniversary

• To-do item • Memo

You can only delete scheduled event with a

repeating alarm on Day view.

Menu functions

•

Missed alarm events

: view events whose alarms

you have missed.

•

Memory status

: view the memory status for

items stored in the phone’s memory.

Creating an event

You can schedule up to 400 events on the calendar,

and schedule more than one event per day.

Entering a new scheduled event

1. Scroll to a date on the calendar.

2. Press <

Options

> and select

Create

→

Schedule

Miscellaneous

3. Enter information or change the settings in the

following entry fields:

•

Subject

: enter the title of the event.

•

Details

: enter event details.

•

Start date

and

Start time

: enter the starting

date and time for the event.

•

AM/PM

: select

•

End date

and

End time

: enter the ending date

and time for the event.

•

AM/PM

: select

•

Location

: (for

Schedule

) enter information

about the event location.

•

Alarm

: set an alarm for the event.

•

before

: set how long before the event the

alarm is to alert you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: (for

Schedule

) select to set the event

to recur and a repeat unit.

•

until

: (for

Schedule

) if the event will recur,

set the ending date.

4. Press <

Save

> to save the event.

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings in the

following entry fields:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

Menu functions

Calendar

(Menu 7)

•

Alarm

: select to set an alarm for the

anniversary.

•

before

: set how long before the event the

alarm is to alert you.

•

Alarm time

: enter the time for the alarm to

sound.

•

AM/PM

: select

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: select to set the phone to

remind you of the anniversary every year.

4. Press <

Save

> to save the event.

Entering a to-do item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

To do

3. Enter information or change the settings in the

following entry fields:

•

To do

: enter information about the item.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Priority

: select a priority level.

4. Press <

Save

> to save the event.

Viewing an event

Square brackets on a calendar date indicate the

following type of events scheduled for that day:

1. Select a date on the calendar to display the events

for the day.

2. Select an event to view its details.

While viewing an event or the event list, press

Options

> to access the following options:

•

View

: display the event details.

•

Edit

: edit the event.

•

Create

: add a new event.

•

Send via

: send the event via SMS, MMS, e-mail,

or infrared port.

•

View mode

: change the view mode of the

calendar.

•

Sort by

: sort items by the type of events.

•

Delete

: delete items stored on the calendar by

using various deleting options.

• Blue: scheduled event • Orange: anniversary

• Red: to-do item • Green: memo

Menu functions

•

Missed alarm events

: view events whose alarms

you have missed.

•

Memory status

: view the memory status for

items stored in the phone’s memory.

Viewing an event in different mode

By default, the calendar appears in Month view mode.

Press <

Options

> and select view mode to change the

mode.

Day view

You can view events for the selected date.

Select an event to view its details.

The following icons will be displayed according to the

event’s type and status:

• Alarm set

• Recurring event

• Completed to-do

• To-do priority; : high, : normal, and

: low

Week view

You can view events (only for items stored for

Schedule) for the selected week.

A cell on the timetable indicates the presence of event

information.

Select the cell that contains the event you want.

Viewing a missed alarm event

When you are unable to acknowledge an alarm, the

phone displays a missed alarm notification.

• Press <

View

> to view the corresponding event.

• Press <

Exit

Accessing missed event alarm

1. press <

Options

> and select

Missed alarm

events

2. Select an event.

3. Press <

Confirm

> to confirm and delete the event.

Menu functions

Camera

(Menu 8)

Using missed alarm options

From the event list, press <

Options

> to access the

following options:

•

View

: access the event.

•

Delete

: delete the event.

•

Delete all

: delete all events.

Camera

(Menu 8)

You can use the camera module embedded in your

phone to take photos and record videos.

To access this menu, press <

> in Idle mode and

select

Camera

, or press and hold [

Take a photo

You can take photos in various modes using the

phone. The camera produces JPEG photos.

1. Access the

Camera

menu to turn on the camera.

The image to be captured appears on the display.

2. Adjust the image by aiming the camera lens at the

subject.

• Press the left soft key to access the camera

options. See the next section.

• Use the keypad to change the camera settings

or switch to other modes.



p. 70

3. Press [

]

to take a photo. The photo is saved in

the

Photos

folder.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras are

not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

To Press

use photo options <

Options



p. 71

delete the photo <

Delete

> and then

Yes

Menu functions

Using camera options in Capture mode

In Capture mode, press the left soft key to access the

following options:

•

Shooting mode

: take a photo in the following

modes:

Single shot

: take a photo in normal mode.

Multi shot

: take a series of action stills. Select the

number of photos the camera will take.

•

Effects

: change the colour tone or apply a special

effect to a photo.

•

Frames

: apply a decorative frame to a photo.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to photos

: go to the

Photos

folder.

•

Settings

: change the default settings for taking a

photo.

Size

: select an image size.

Quality

: select an image quality.

View finder

: change the view mode.

Shutter sound

: select the sound that you hear

when you press the shutter release, [

]

Zoom sound

: turn on or off the sound that you

hear when zooming in.

Brightness sound

: turn on or off the sound that

you hear when adjusting the image brightness.

Default name

: change the default prefix of the

photo name.

•

Camera short cuts

: view the functions of the

keys you can use.

Using the keypad in Capture mode

You can use the keypad to customise your camera

settings in Capture mode.

return to Capture mode [ ].

To Press

Key Function

Flips the image vertically.

Shows the mirror image.

Menu functions

Camera

(Menu 8)

Using photo options

After saving a photo, press <

Options

> to access the

following options:

•

Take another

: return to Capture mode.

•

Send via

: send the photo via MMS, e-mail, or

infrared port.

•

Set as

: set the photo as your wallpaper for the idle

screen or as a caller ID image for a Phonebook

entry.

•

Delete

: delete the photo.

•

Rename

: change the name of the photo.

•

Go to photos

: go to the

Photos

folder.

•

Protection

: protect the photo from being deleted.

•

Properties

: view the properties of the photo.

Viewing a photo

1. In Capture mode, press the left soft key and select

Go to photos

2. Scroll to a photo and press [ ].

Left/Right Adjusts the brightness of the image.

Up/Down Zooms in or out.

Switches to Record mode.



p. 72

Changes the image size.

Changes the image quality.

Changes the camera mode.

Changes the colour tone or applies a

special effect to the photo.

Selects a decorative frame.

Sets the timer.

Goes to the

Photos

folder.

Determine the flash use.

Changes the preview screen.

Key Function

Menu functions

While viewing a photo or the photo list, press

Options

> to access the following options:

•

View

: view the photo on the full screen.

•

List

: return the screen to the photo list.

•

Send via

: send the photo via MMS, e-mail, or

infrared port.

•

Set as

: set the photo as your wallpaper for the

Idle screen or as a caller ID image for a Phonebook

entry.

•

Edit

: add emoticon, frame, or effect to the image.

•

Delete

: delete the photo or all photos.

•

Rename

: change the name of the photo.

•

Move to favourite images

: move the photo to

the

My photos

folder.

•

Slide show

: set all photos to display as a slide

show. You can select a time interval between

photos.

•

Protection

: protect the photo from being deleted.

•

Properties

: view the properties of the photo.

Recording video

You can record a video of what is displayed on the

camera screen and save it as a .3gp file.

1. In Capture mode, press [

2. Aim the camera lens at the subject to adjust the

image.

• Press the left soft key to access the camera

options. See the next section.

• Use the keypad to change the camera settings

or switch to other modes.



p. 73

3. Press [

]

to start recording.

4. Press [

]

or the right soft key to stop recording.

The video is automatically saved in the

Videos

folder.

To Press

play back the video clip [ ].

use the video options the left softkey.



p. 74

delete the video clip [

] and then <

Yes

return to Record mode the right softkey.

Menu functions

Camera

(Menu 8)

Using camera options in Record mode

In Record mode, press the left soft key to access the

following options:

•

Effects

: change the colour tone or apply a special

effect to a video.

•

Flash

: determine the flash use.

•

Timer

: set a time delay before the camera starts

recording.

•

Go to videos

: go to the

Videos

folder.

•

Settings

: change the following settings for

recording a video:

Recording mode

: select a video recording mode.

Select

Limit of

MMS

to record a video suitable for

an MMS or e-mail message. The video clip is saved

in 3GP format.

Select

Normal

to record a video within the limit of

the currently available memory.

Size

: select a file size.

Quality

: select an image quality.

Audio rec.

: record audio with a video clip.

Default name

: change the default prefix of the

file name.

•

Camcorder short cuts

: view the functions of the

keys you can use.

Using the keypad in Record mode

You can use the keypad to customise your camera

settings in Record mode:

Keys Function

Flips the image vertically.

Shows the mirror image.

Left/

Right Adjusts the brightness of the image.

Up/

Down Zooms in or out.

Switches to Capture mode.



p. 69

Changes the frame size.

Changes the image quality.

Changes the video recording mode.

Menu functions

Using video options

After saving a video clip, press the left soft key to

access the following options:

•

Record another

: return to Record mode.

•

Send via

: send the video clip via MMS, e-mail, or

infrared port.

•

Go to video album

: go to the

Video clips

video clips

folder.

•

Rename

: change the name of the video clip.

•

Protection

: protect the video clip from being

deleted.

•

Properties

: access the properties of the video

clip.

Playing a video clip

1. In Record mode, press the left soft key and select

Go to videos.

2. Scroll to a video clip and press [ ].

During playback, use the following keys:

Changes the colour tone or applies a

special effect to the video clip.

Mutes or unmutes the audio.

Sets the timer.

Goes to the

Video clips

My video clips

folder.

Keys Function

Pauses/resumes playback.

Up Opens the vidoe clip list.

Left Goes back to the previous file.

Right Skips to the next file.

/ Adjusts the volume.

Down Stops playback.

Menu functions

Settings

(Menu 9)

While viewing video list, press <

Options

> to access

the following options:

•

Play

: play the selected video clip.

•

Send via

: send the video clip via MMS, e-mail, or

infrared port.

•

Delete

: delete the video clip or all video clips.

•

Rename

: change the name of the video clip.

•

Move to favourite videos

: move the video clip to

the

Favourite videos

folder.

•

Protection

: protect the video clip from being

deleted.

•

Properties

: view the properties of the video clip.

Settings

(Menu 9)

Use this menu to customise your phone settings. You

can also reset the settings to their default values.

To access this menu, press <

> in Idle mode and

select

Settings

Time & Date

(Menu 9.1)

Use this menu to change the time and date displayed

on your phone. Before setting the time and date,

specify your time zone in the

World time

menu.



p. 40

•

Set time

: enter the current time.

•

AM/PM

: select

in 12-hour time format.

•

Time format

: select a time format.

•

Set date

: enter the current date.

•

Date format

: select a date format.

Phone settings

(Menu 9.2)

Many different features of your phone’s system can be

customised to suit your preferences.

Language

(Menu 9.2.1)

Use this menu to select one of several languages for

the display text.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed

briefly when the phone is switched on.

Menu functions

Slide settings

(Menu 9.2.3)

Use this menu to set how the phone reacts when you

open it for an incoming call, and when you close it

while using a function.

•

: set whether or not to answer a call by opening

the phone.

•

Down

: set whether or not the phone maintains

the menu you are using when you close the phone.

Short cut

(Menu 9.2.4)

You can use the Navigation keys as shortcut keys to

access specific menus directly from Idle mode. Use

this menu to assign a shortcut to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut key.

2. Press <

Options

> and select

Change

3. Select the menu to be assigned to the key.

Using shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

Side key

(Menu 9.2.5)

Use this menu to set how the phone reacts when you

press [ / ] when a call comes in.

•

Mute

: the keys mutes the call ringer.

•

Reject

: the key rejects the call.

Extra settings

(Menu 9.2.6)

You can turn the automatic redialling or answering

feature on or off.

•

Auto redial

: set the phone to make up to ten

attempts to redial a phone number after an

unsuccessful call.

•

Anykey

answer

: answer an incoming call by

pressing any key, except [ ] or <

Reject

When this option is not selected, you must press

[] or <

> to answer a call.

When you set

Down

Continue operation

, the

keypad lock works just in Idle mode.

Menu functions

Settings

(Menu 9)

•

Voice clarity

: increase the microphone’s

sensitivity to allow the other person on the phone

to hear your voice clearly, even through you may

be whispering.

Display settings

(Menu 9.3)

Use this menu to change settings for the display and

light.

Wallpaper

(Menu 9.3.1)

You can change the background image that is

displayed in Idle mode.

Text display

(Menu 9.3.2)

You can change the display settings for the text

displayed on the idle screen.

•

Text position

: select a text position on the

display. If you don’t want to display text in Idle

mode, select

Off

•

Text style

: select a text style.

•

Text colour

: select the text colour.

Calendar

(Menu 9.3.3)

You can display the calendar in Month view on the idle

screen.

Skin

(Menu 9.3.4)

You can select a skin colour for Menu mode.

LCD brightness

(Menu 9.3.5)

You can adjust the brightness of the display for

varying lighting conditions.

Backlight

(Menu 9.3.6)

You can select the length of time the backlight and the

display stays on.

•

: select the length of time the backlight is on at

times of inactivity.

•

Dim

: select the length of time the display is in

Dimming mode after the backlight turns off.

Dialing font colour

(Menu 9.3.7)

Use this menu to select a font colour for the numbers

entered while dialling.

Menu functions

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to select a volume and alert type for

incoming calls.

•

Ring tone

: select a ringtone for the call ringer.

•

Volume

: select a ringer volume.

•

Alert type

: specify how you are to be informed of

incoming calls.

Melody

: the phone rings using the selected

ringtone.

Vibration

: the phone vibrates but not rings.

Vibration then melody

: the phone vibrates three

times and then starts ringing.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone sounds

when you press a key.

Message tone

(Menu 9.4.3)

Use this menu to set up the ringer for incoming

messages or e-mails.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are to be informed of

any incoming messages.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone

sounds when it is switched on or off.

Slide tone

(Menu 9.4.5)

Use this menu to select the tone that the phone sounds

when you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to set how the phone acts to alert you to

a specific event in Quiet mode, instead of making

sounds.

•

Vibration

: set the phone to vibrate.

•

Mute

: mute all sound settings.

You can adjust the keypad tone volume using

[/]

in Idle mode.

Menu functions

Settings

(Menu 9)

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones for the

phone.

•

Minute

minder

: set the phone to beep every

minute during an outgoing call to keep you

informed of the length of your call.

•

Connection

tone

: set the phone to beep when it

is connected to the system.

•

Alerts on call

: set the phone to beep when you

receive a new message or when the time for an

alarm comes during a call.

•

Indicative

tones

: set the phone to beep when a

pop-up window displays.

Network services

(Menu 9.5)

Use this menu to access network services. Please

contact your service provider to check their availability

and subscribe to them, if you wish.

Call diverting

(Menu 9.5.1)

This network service reroutes incoming calls to a

phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on another

call.

•

: divert calls when you do not answer

the phone.

•

Unreachable

: divert calls when you are not in

an area covered by your service provider or

when your phone is switched off.

•

Cancel

all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. To activate call diverting, select

Activate

Otherwise, select

Inactivate

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be diverted

and press <

Select

6. If you selected

No reply

, move to the

Seconds

line and select the length of time the network

delays before diverting a call.

Menu functions

Call barring

(Menu 9.5.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All

outgoing

: prohibit all outgoing calls.

•

International

: prohibit international calls.

•

International

except

home

: only allow

calls to numbers within the current country

when you are abroad, and to your home

country.

•

All

incoming

: prohibit incoming calls.

•

Incoming

while

abroad

: prohibit incoming

calls when you use your phone outside of your

home country.

•

Cancel

all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call

barring password obtained from your service

provider.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call barring, select

Inactivate

4. Enter the call barring password supplied by your

service provider and press <

Select

Call waiting

(Menu 9.5.3)

This network service informs you when someone is

trying to reach you while you are on another call.

1. Select the type of calls to which call waiting option

will apply.

2. Select

Activate

and press <

Select

To deactivate call waiting, select

Inactivate

Network selection

(Menu 9.5.4)

This network service allows you to either automatically

or manually select the network to be used while

roaming outside of your home area.

You can select a network other than your home

network only if there is a valid roaming agreement

between the two.

•

Automatic

: connect to the first available network

when roaming.

•

Manual

: select the network you want.

Menu functions

Settings

(Menu 9)

Caller ID

(Menu 9.5.5)

This network service allows you to prevent your phone

number from being displayed on the phone of the

person being called. However, some networks do not

allow the user to change this setting.

•

Default

: use the default setting provided by the

network.

•

Hide

number

: ensure your number does not

display on the other person’s phone.

•

Send

number

: send your number each time you

make a call.

Voice mail server

(Menu 9.5.6)

Use this menu to store the number of the voicemail

server and access your voicemails.

•

Connect to voice mail

: connect to the voicemail

server to allow you to listen to your messages. You

can also connect to the voicemail server by

pressing and holding [

] in Idle mode.

•

Voice server number

: enter the voicemail server

number.

Band selection

(Menu 9.5.7)

For the phone to make and receive phone calls, it

must register with an available network. Your phone

can handle any of the following types of networks:

GSM 1900 and Combined GSM 900/1800.

The country where you purchased your phone

determines the default band that it uses. When you

travel abroad, you may need to change to an

appropriate band.

When you select a new band, your phone

automatically searches for all available networks. Your

phone registers with a preferred network within the

band.

Connectivity

(Menu 9.6)

Use this menu to activate the infrared port.

You must enter the voice server number before you

can access your voicemails. Your service provider

can give the voice server number.

You cannot use the infrared feature while using

multimedia features such as voice recorder,

camera, and MP3 player, or vice versa.

Menu functions

Infrared

(Menu 9.6.1)

Use this feature to send and receive data through the

infrared port. To use an infrared connection, you must

do the following:

• Configure and activate an IrDA-compliant infrared

port on the other device.

• Activate the infrared feature on your phone (the

IrDA icon displays on the top line).

• Align the IrDA port on the

phone with the IrDA port on

the other device.

If there is no communication

between your phone and the

other IrDA-compliant device

within 60 seconds of activating

the feature, it is automatically

deactivated.

Security

(Menu 9.7)

Use this menu to protect the phone against

unauthorised use by managing the several access

codes of your phone and SIM card.

PIN check

(Menu 9.7.1)

The 4- to 8-digit PIN (Personal Identification Number)

protects your SIM card against unauthorised use.

When this feature is enabled, the phone requires your

PIN each time it is switched on.

Change PIN

(Menu 9.7.2)

Use this menu to change your PIN. The PIN check

feature must be enabled to use this feature.

If you enter an incorrect PIN/PIN2 three times in

succession, the SIM card is blocked. To unblock it,

you need to enter your PUK/PUK2 (Personal

Unblocking Key). The codes are supplied by your

network operator.

Menu functions

Settings

(Menu 9)

Phone lock

(Menu 9.7.3)

This feature locks the phone from unauthorised use.

When this feature is enabled, you must enter a 4- to

8-digit phone password each time the phone is

switched on.

The password is preset to

00000000

. To change the

password, use the

Change password

menu.

Change password

(Menu 9.7.4)

Use this menu to change your phone password. The

password is preset to

00000000

Privacy

(Menu 9.7.5)

Use this menu to lock your media contacts, including

MMS messages, e-mails, images, videos, music files,

and sounds.

1. Press [ ] to check the item(s) to lock.

2. Press <

Save

3. Enter the phone password and press <

To access a locked item, you need to enter the phone

password.

SIM lock

(Menu 9.7.6)

The SIM lock feature allows your phone to work only

with the current SIM by assigning a SIM lock code. You

must enter the SIM lock code to use a different SIM

card.

FDN mode

(Menu 9.7.7)

If supported by your SIM card, Fixed Dialling Number

(FDN) mode restricts your outgoing calls to a limited

set of phone numbers. When this feature is enabled,

you can make calls only to phone numbers stored on

the SIM card. To use this feature, you must enter your

PIN2.

Change PIN2

(Menu 9.7.8)

If supported by your SIM card, the change PIN2

feature changes your current PIN2.

Memory status

(Menu 9.8)

Use this menu to check the amount of memory being

used for storing data in

Shared memory

Messages

File manager

Calendar

Phonebook

, and

JAVA

word

. You can also check the shared memory for

MMS, Email, and File manager.

Reset settings

(Menu 9.9)

Use this menu to reset the phone settings, display

settings, and sound settings individually. You can also

reset all the settings in your phone at the same time.

1. Press [ ] to check the setting category(ies) to be

reset.

2. Press <

Reset

> to reset the marked items.

3. Press <

Yes

> to confirm the reset.

4. Enter the phone password and press <

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service

call, perform the simple checks in this section before

contacting a service professional.

When you switch on your phone, the following

messages may appear:

“Insert SIM card”

• Be sure that the SIM card is correctly installed.

“Phone lock”

• The automatic locking function has been enabled.

You must enter the phone’s password before you

can use the phone.

“Enter PIN”

• You are using your phone for the first time. You

must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the

phone is switched on, the PIN has to be entered.

To disable this feature, use the

PIN check

menu.

The password is preset to

00000000

. You can

change this password



p. 83

Solve problems

“Enter PUK”

• The PIN code has been entered incorrectly three

times in succession, and the phone is now blocked.

Enter the PUK supplied by your service provider.

“No Service,” “Network Failure,” or “Not

Done” displays

• The network connection has been lost. You may be

in a weak signal area. Move and try again.

• You are trying to access an option for which you

have no subscription with your service provider.

Contact the service provider for further details.

You have entered a number but it was not

dialled

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular

network.

• Be sure that you have not set an outgoing call

barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ]

pressed for more than one second.)

• Be sure that you are accessing the correct cellular

network.

• Be sure that you have not set an incoming call

barring option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone close

enough to your mouth. The microphone is located

at the bottom of the phone.

The phone starts beeping and “Low battery”

flashes on the display

• Your battery is insufficiently charged. Recharge the

battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display

( ). The number of bars indicates the signal

strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialled when you re-call a

Phonebook entry

• Use the Contact list feature to ensure the number

has been stored correctly.

• Re-store the number, if necessary.

The battery doesn’t charge properly or the

phone sometimes turns itself off

• Wipe the charge contacts both on the phone and

on the battery with a clean soft cloth.

If the above guidelines do not help you to

solve the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales

service.

Health and safety information

Exposure to Radio Frequency

(RF) Signals

Your wireless phone is a radio transmitter and

receiver. It is designed and manufactured not to

exceed the emission limits for exposure to radio

frequency (RF) energy set by the Federal

Communications Commission (FCC) of the U.S.

Government. These limits are part of

comprehensive guidelines and establish

permitted levels of RF energy for the general

population. The guidelines are based on the

safety standards that were developed by

independent scientific organizations through

periodic and through evaluation of scientific

studies.

The standards include a substantial safety margin

designed to assure the safety of all persons,

regardless of age and health.

The exposure standard for wireless phones

employs a unit of measurement known as

Specific Absorption Rate (SAR). The SAR limit set

by the FCC is 1.6W/kg

*In the U.S. and Canada, the SAR limit for mobile phones

used by the public is 1.6 watts/kg (W/kg)

averaged over one gram of tissue. The standard

incorporates a substantial margin of safety to give

additional protection for the public and to account for any

variations in measurements.

Health and safety information

SAR tests are conducted using standard operating

positions specified by the FCC with the phone

transmitting at its highest certified power level in

all tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can

be well below the maximum value. This is because

the phone is designed to operate at multiple power

levels so as to use only the power required to reach

the network. In general, the closer you are to a

wireless base station antenna, the lower the power

output of the phone. Before a new model phone is

available for sale to the public, it must be tested

and certified to the FCC that it does not exceed the

limit established by the government-adopted

requirement for safe exposure. The tests are

performed in positions and locations (e.g., at the

ear and worn on the body) as required by the FCC

for each model. While there may be differences

between the SAR levels of various phones and at

various positions, they all meet the government

requirement.

The FCC has granted an Equipment Authorization

for this model phone with all reported SAR levels

evaluated as in compliance with the FCC RF

exposure guidelines. SAR information on this

model phone is on file with the FCC and can be

found under the Display Grant section of http://

www.fcc.gov/oet/fccid after searching on FCC ID

printed in the label on the phone.

FCC certification information for this model phone

is attached separation paper.

For Body Operation

For body worn operation, this model phone has

been tested and meets the FCC RF exposure

guidelines when used with a Samsung-supplied or

approved accessory designated for this product or

when used with and accessory that contains no

Health and safety information

metal and that positions the handset a minimum

from the body.

The minimum distance for this model phone is

written in the FCC certification information from

the body. None compliance with the above

conditions may violate FCC RF exposure guidelines.

For more Information concerning exposure to radio

frequency signals, see the following websites:

Federal Communications Commission (FCC)

http://www.fcc.gov/rfsafety

Cellular Telecommunications Industry Association

(CTIA):

http://www.wow-com.com

U.S.Food and Drug Administration (FDA)

http://www.fda.gov/cdrh/consumer

World Health Organization (WHO)

http://www.who.int/peh-emf/en

Precautions When Using Batteries

• Never use any charger or battery that is

damaged in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base

station, it uses less power; talk and standby time

are greatly affected by the signal strength on the

cellular network and the parameters set by the

network operator.

• Battery charging time depends on the remaining

battery charge and the type of battery and

charger used. The battery can be charged and

discharged hundreds of times, but it will

gradually wear out. When the operation time

(talk time and standby time) is noticeably

shorter than normal, it is time to buy a new

battery.

• If left unused, a fully charged battery will

discharge itself over time.

Health and safety information

• Use only Samsung-approved batteries and

recharge your battery only with Samsung-

approved chargers. When a charger is not in use,

disconnect it from the power source. Do not

leave the battery connected to a charger for

more than a week, since overcharging may

shorten its life.

• Extreme temperatures will affect the charging

capacity of your battery: it may require cooling

or warming first.

• Do not leave the battery in hot or cold places,

such as in a car in summer or winter conditions,

as you will reduce the capacity and lifetime of

the battery. Always try to keep the battery at

room temperature. A phone with a hot or cold

battery may temporarily not work, even when

the battery is fully charged. Li-ion batteries are

particularly affected by temperatures below 0

°ýC (32 °ýF).

• Do not short-circuit the battery. Accidental

shortcircuiting can occur when a metallic object

(coin, clip or pen) causes a direct connection

between the + and . terminals of the battery

(metal strips on the battery), for example when

you carry a spare battery in a pocket or bag.

Short-circuiting the terminals may damage the

battery or the object causing the short-circuiting.

• Dispose of used batteries in accordance with

local regulations. Always recycle. Do not dispose

of batteries in a fire.

Road Safety

Your wireless phone gives you the powerful ability

to communicate by voice, almost anywhere,

anytime. But an important responsibility

accompanies the benefits of wireless phones, one

that every user must uphold.

Health and safety information

When driving a car, driving is your first

responsibility. When using your wireless phone

behind the wheel of a car, practice good common

sense and remember the following tips.

1. Get to know your wireless phone and its

features, such as speed dial and redial. If

available, these features help you to place your

call without taking your attention off the road.

2. When available, use a hands-free device. If

possible, add an extra layer of convenience and

safety to your wireless phone with one of the

many hands-free accessories available today.

3. Position your wireless phone within easy reach.

Be able to access your wireless phone without

removing your eyes from the road. If you get

an incoming call at an inconvenient time, let

your voice mail answer it for you.

4. Let the person you are speaking with know you

are driving; if necessary, suspend the call in

heavy traffic or hazardous weather conditions.

Rain, sleet, snow, ice and even heavy traffic can

be hazardous.

5. Do not take notes or look up phone numbers

while driving. Jotting down a To Do list or

flipping through your phonebook takes your

attention away from your primary

responsibility, driving safely.

6. Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before

pulling into traffic. Try to plan calls when your

car will be stationary. If you need to make a call

while moving, dial only a few numbers, check

the road and your mirrors, then continue.

7. Do not engage in stressful or emotional

conversations that may be distracting. Make the

people with whom you are talking aware that

Health and safety information

you are driving and suspend conversations that

have the potential to divert your attention from

the road.

8. Use your wireless phone to call for help. Dial

the emergency number in the case of fire,

traffic accident or medical emergencies.

Remember, it is a free call on your wireless

phone!

9. Use your wireless phone to help others in

emergencies. If you see a car accident, crime in

progress or other serious emergency where

lives are in danger, call the emergency number,

as you would want others to do for you.

10.Call roadside assistance or a special

nonemergency wireless assistance number

when necessary. If you see a broken-down

vehicle posing no serious hazard, a broken

traffic signal, a minor traffic accident where no

one appears injured, or a vehicle you know to

be stolen, call roadside assistance or any other

special nonemergency wireless number.

Operating Environment

Remember to follow any special regulations in

force in any area and always switch off your phone

whenever it is forbidden to use it, or when it may

cause interference or danger.

When connecting the phone or any accessory to

another device, read its user’s guide for detailed

safety instructions. Do not connect incompatible

products.

As with other mobile radio transmitting equipment,

users are advised that for the satisfactory

operation of the equipment and for the safety of

personnel, it is recommended that the equipment

should only be used in the normal operating

Health and safety information

Settings

position (held to your ear with the antenna

pointing over your shoulder).

Electronic Devices

Most modern electronic equipment is shielded from

radio frequency (RF) signals. However, certain

electronic equipment may not be shielded against

the RF signals from your wireless phone. Consult

the manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a

minimum distance of 15 cm (6 inches) be

maintained between a wireless phone and a

pacemaker to avoid potential interference with the

pacemaker. These recommendations are consistent

with the independent research and

recommendations of Wireless Technology

Research.

Persons with pacemakers:

• Should always keep the phone more than 15 cm

(6 inches) from their pacemaker when the phone

is switched on

• Should not carry the phone in a breast pocket

• Should use the ear opposite the pacemaker to

minimize potential interference

If you have any reason to suspect that interference

is taking place, switch off your phone immediately.

Hearing Aids

Some digital wireless phones may interfere with

some hearing aids. In the event of such

interference, you may wish to consult your hearing

aid manufacturer to discuss alternatives. Other

Medical Devices If you use any other personal

medical devices, consult the manufacturer of your

device to determine if it is adequately shielded

Health and safety information

from external RF energy. Your physician may be

able to assist you in obtaining this information.

Switch off your phone in health care facilities when

any regulations posted in these areas instruct you

to do so. Hospitals or health care facilities may be

using equipment that could be sensitive to external

RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles. Check with the manufacturer or its

representative regarding your vehicle. You should

also consult the manufacturer of any equipment

that has been added to your vehicle.

Posted Facilities

Switch off your phone in any facility where posted

notices require you to do so.

Potentially Explosive Atmospheres

Switch off your phone when in any area with a

potentially explosive atmosphere and obey all

signs and instructions. Sparks in such areas could

cause an explosion or fire resulting in bodily injury

or even death. Users are advised to switch off the

phone while at a refueling point (service station).

Users are reminded of the need to observe

restrictions on the use of radio equipment in fuel

depots (fuel storage and distribution areas),

chemical plants or where blasting operations are in

progress.

Areas with a potentially explosive atmosphere are

often but not always clearly marked. They include

below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas

(such as propane or butane), areas where the air

contains chemicals or particles, such as grain, dust

Health and safety information

Settings

or metal powders, and any other area where you

would normally be advised to turn off your vehicle

engine.

Emergency calls

This phone, like any wireless phone, operates using

radio signals, wireless and landline networks, as

well as user-programmed functions, which cannot

guarantee connection in all conditions. Therefore,

you should never rely solely on any wireless phone

for essential communications (medical

emergencies, for example).

Remember, to make or receive any calls the phone

must be switched on and in a service area with

adequate signal strength. Emergency calls may not

be possible on all wireless phone networks or when

certain network services and/or phone features are

in use. Check with local service providers.

To make an emergency call, proceed as follows.

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present

location (for example, 112 or any other official

emergency number). Emergency numbers vary

by location.

3. Press the key.

If certain features are in use (call barring, for

example), you may first need to deactivate those

features before you can make an emergency call.

Consult this document and your local cellular

service provider.

When making an emergency call, remember to

give all the necessary information as accurately as

possible. Remember that your phone may be the

only means of communication at the scene of an

Health and safety information

accident; do not end the call until given permission

to do so.

Other important safety information

• Only qualified personnel should service the

phone or install the phone in a vehicle. Faulty

installation or service may be dangerous and

may invalidate any warranty applicable to the

device.

• Check regularly that all wireless phone

equipment in your vehicle is mounted and

operating properly.

• Do not store or carry flammable liquids, gases,

or explosive materials in the same compartment

as the phone, its parts, or accessories.

• For vehicles equipped with an air bag, remember

that an air bag inflates with great force. Do not

place objects, including both installed or portable

wireless equipment in the area over the air bag

or in the air bag deployment area. If wireless

equipment is improperly installed and the air bag

inflates, serious injury could result.

• Switch off your phone before boarding an

aircraft. The use of wireless phones in aircraft

may be dangerous to the operation of the

aircraft, and is illegal.

• Failure to observe these instructions may lead to

the suspension or denial of telephone services to

the offender, or legal action, or both.

Care and maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for

many years.

Health and safety information

Settings

• Keep the phone and all its parts and accessories

out of the reach of small children.

• Keep the phone dry. Precipitation, humidity, and

liquids contain minerals that will corrode

electronic circuits.

• Do not use the phone with a wet hand. Doing so

may cause an electric shock to you or damage to

the phone.

• Do not use or store the phone in dusty, dirty

areas, as its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt

certain plastics.

• Do not store the phone in cold areas. When the

phone warms up to its normal operating

temperature, moisture can form inside the

phone, which may damage the phone’s

electronic circuit boards.

• Do not drop, knock, or shake the phone. Rough

handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents,

or strong detergents to clean the phone. Wipe it

with a soft cloth slightly dampened in a mild

soap-and-water solution.

• Do not paint the phone. Paint can clog the

device’s moving parts and prevent proper

operation.

• Do not put the phone in or on heating devices,

such as a microwave oven, a stove, or a radiator.

The phone may explode when overheated.

• Use only the supplied or an approved

replacement antenna. Unauthorised antennas or

Health and safety information

modified accessories may damage the phone

and violate regulations governing radio devices.

• If the phone, battery, charger, or any accessory

is not working properly, take it to your nearest

qualified service facility. The personnel there will

assist you, and if necessary, arrange for service.

Acknowledging Special Precautions and

the FCC and Industry Canada Notice

Cautions

Modifications not expressly approved by the party

responsible for compliance could void the user's

authority to operate the equipment.

FCC Compliance Information

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful

interference, and

2. This device must accept any interference

received.

Including interference that may cause undesired

operation.

Information to User

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following

measures:

Health and safety information

Settings

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/ TV

technician for help.

Appendix A: CERTIFICATION

INFORMATION (SAR)

THIS MODEL PHONE MEETS THE GOVERNMENT’S

REQUIREMENTS FOR EXPOSURE TO RADIO

WAVES.

Your wireless phone is a radio transmitter and

receiver. It is designed and manufactured not to

exceed the emission limits for exposure to radio

frequency(RF) energy set by the Federal

Communications Commission of the U.S.

Government. These limits are part of

comprehensive guidelines and establish permitted

levels of RF energy for the general population. The

guidelines are based on safety standards that were

developed by independent scientific organizations

through periodic and thorough evaluation of

scientific studies. The standards include a

substantial safety margin designed to assure the

safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones

employs a unit of measurement known as the

Specific Absorption Rate(SAR). The SAR limit set

by the FCC is 1.6 W/kg. SAR Tests are conducted

using standard operating positions accepted by the

FCC with the phone transmitting at its highest

certified power level in all tested frequency bands.

Although the SAR is determined at the highest

certified power level, the actual SAR level of the

phone while operating can be well below the

100

Health and safety information

maximum value. This is because the phone is

designed to operate at multiple power levels so as

to use only the power required to reach the

network. In general, the closer you are to a

wireless base station antenna, the lower the power

output.

Before a new model phone is available for sale to

the public, it must be tested and certified to the

FCC that it does not exceed the limit established by

the governmentadopted requirement for safe

exposure. The tests are performed in positions and

locations(e.g., at the ear and worn on the body) as

required by the FCC for each model.

The highest SAR values for this model phone as

reported to the FCC are Head: 1.09 W/Kg, Body-

worn: 0.448 W/Kg. Body-worn operations are

restricted to Samsungsupplied, approved or none

Samsung designated accessories that have no

metal and must provide at least 1.5cm separation

between the device, including its antenna whether

extended or retracted, and the user’s body. None

compliance to the above restrictions may violate

FCC RF exposure guidelines

The FCC has granted an Equipment Authorization

for this model phone with all reported SAR levels

evaluated as in compliance with the FCC RF

exposure guidelines. SAR information on this

model phone is on file with the FCC and can be

found under the Display Grant section of http://

www.fcc.gov/oet/fccid after searching on FCC ID

A3LSGHE350.

Appendix B: Guide to Safe and Responsible

Wireless Phone Use

Cellular Telecommunications & Internet Association

“Safety is the most important call you will ever make.”

A Guide to Safe and Responsible Wireless

Phone Use

Health and safety information

Settings

101

TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY

TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF

CONVENIENCE, SAFETY AND VALUE DELIVERED BY

THE WIRELESS TELEPHONE. QUITE SIMPLY, THE

WIRELESS PHONE GIVES PEOPLE THE POWERFUL

ABILITY TO COMMUNICATE BY VOICE-ALMOST

ANYWHERE, ANYTIME-WITH THE BOSS, WITH A

CLIENT, WITH THE KIDS, WITH EMERGENCY

PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR,

AMERICANS MAKE BILLIONS OF CALLS FROM THEIR

WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY

GROWING.

But an important responsibility accompanies those

benefits, one that every wireless phone user must

uphold. When driving a car, driving is your first

responsibility. A wireless phone can be an invaluable

tool, but good judgment must be exercised at all times

while driving a motor vehicle whether on the phone or

not.

The basic lessons are ones we all learned as

teenagers. Driving requires alertness, caution and

courtesy. It requires a heavy dose of basic common

sense-keep your head up, keep your eyes on the road,

check your mirrors frequently and watch out for other

drivers. It requires obeying all traffic signs and signals

and staying within the speed limit. It means using seat

belts and requiring other passengers to do the same.

But with wireless phone use, driving safely means a

little more. This brochure is a call to wireless phone

users everywhere to make safety their first priority

when behind the wheel of a car. Wireless

telecommunications is keeping us in touch, simplifying

our lives, protecting us in emergencies and providing

opportunities to help others in need. When it comes to

the use of wireless phones, safety is your most

important call.

Wireless Phone “Safety Tips”

Below are safety tips to follow while driving and using

a wireless phone which should be easy to remember:

1. Get to know your wireless phone and its

features such as speed dial and redial. Carefully

read your instruction manual and learn to take

102

Health and safety information

advantage of valuable features most phones

offer, including automatic redial and memory.

Also, work to memorize the phone keypad so

you can use the speed dial function without

taking your attention off the road.

2. When available, use a hands free device. A

number of hands free wireless phone

accessories are readily available today. Whether

you choose an installed mounted device for

your wireless phone or a speaker phone

accessory, take advantage of these devices if

available to you.

3. Position your wireless phone within easy reach.

Make sure you place your wireless phone within

easy reach and where you can grab it without

removing your eyes from the road. If you get

an incoming call at an inconvenient time, if

possible, let your voice mail answer it for you.

4. Suspend conversations during hazardous

driving conditions or situations. Let the person

you are speaking with know you are driving; if

necessary, suspend the call in heavy traffic or

hazardous weather conditions. Rain, sleet,

snow and ice can be hazardous, but so is heavy

traffic. As a driver, your first responsibility is to

pay attention to the road.

5. Do not take notes or look up phone numbers

while driving. If you are reading an address

book or business card, or writing a “to do” list

while driving a car, you are not watching where

you are going. It’s common sense. Don’t get

caught in a dangerous situation because you

are reading or writing and not paying attention

to the road or nearby vehicles.

6. Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before

pulling into traffic. Try to plan your calls before

Health and safety information

Settings

103

you begin your trip or attempt to coincide your

calls with times you may be stopped at a stop

sign, red light or otherwise stationary. But if

you need to dial while driving, follow this simple

tip-dial only a few numbers, check the road and

your mirrors, then continue.

7. Do not engage in stressful or emotional

conversations that may be distracting. Stressful

or emotional conversations and driving do not

mix-they are distracting and even dangerous

when you are behind the wheel of a car. Make

people you are talking with aware you are

driving and if necessary, suspend conversations

which have the potential to divert your

attention from the road.

8. Use your wireless phone to call for help. Your

wireless phone is one of the greatest tools you

can own to protect yourself and your family in

dangerous situations-with your phone at your

side, help is only three numbers away. Dial 9-1-

1 or other local emergency number in the case

of fire, traffic accident, road hazard or medical

emergency. Remember, it is a free call on your

wireless phone!

9. Use your wireless phone to help others in

emergencies. Your wireless phone provides you

a perfect opportunity to be a “Good Samaritan”

in your community. If you see an auto accident,

crime in progress or other serious emergency

where lives are in danger, call 9-1-1 or other

local emergency number, as you would want

others to do for you.

10.Call roadside assistance or a special wireless

non emergency assistance number when

necessary. Certain situations you encounter

while driving may require attention, but are not

urgent enough to merit a call for emergency

services. But you still can use your wireless

104

Health and safety information

phone to lend a hand. If you see a broken-down

vehicle posing no serious hazard, a broken

traffic signal, a minor traffic accident where no

one appears injured or a vehicle you know to be

stolen, call roadside assistance or other special

non-emergency wireless number.

Careless, distracted individuals and people driving

irresponsibly represent a hazard to everyone on the

road. Since 1984, the Cellular Telecommunications

Industry Association and the wireless industry have

conducted educational outreach to inform wireless

phone users of their responsibilities as safe drivers

and good citizens. As we approach a new century,

more and more of us will take advantage of the

benefits of wireless telephones. And, as we take to the

roads, we all have a responsibility to drive safely.

“The wireless industry reminds you to use your phone

safely when driving.”

Cellular Telecommunications & Internet Association

For more information, please call 1-888-901-SAFE.

For updates: http://www.wow-com.com/consumer/

issues/driving/articles.cfm?ID =85

Appendix C: Consumer Update on Wireless

Phones

U.S. Food and Drug Administration

1. What kinds of phones are the subject of this

update?

The term wireless phone refers here to hand-held

wireless phones with built-in antennas, often called

cell, mobile, or PCS phones. These types of wireless

phones can expose the user to measurable radio

frequency energy (RF) because of the short distance

between the phone and the user s head. These RF

exposures are limited by Federal Communications

Commission safety guidelines that were developed

with the advice of FDA and other federal health and

safety agencies. When the phone is located at greater

distances from the user, the exposure to RF is

drastically lower because a person’s RF exposure

decreases rapidly with increasing distance from the

Health and safety information

Settings

105

source. The so-called “cordless phones,” which have a

base unit connected to the telephone wiring in a

house, typically operate at far lower power levels, and

thus produce RF exposures well within the FCC’s

compliance limits.

2. Do wireless phones pose a health hazard?

The available scientific evidence does not show that

any health problems are associated with using

wireless phones. There is no proof, however, that

wireless phones are absolutely safe. Wireless phones

emit low levels of radio frequency energy (RF) in the

microwave range while being used. They also emit

very low levels of RF when in the stand-by mode.

Whereas high levels of RF can produce health effects

(by heating tissue), exposure to low level RF that does

not produce heating effects causes no known adverse

health effects. Many studies of low level RF exposures

have not found any biological effects. Some studies

have suggested that some biological effects may

occur, but such findings have not been confirmed by

additional research. In some cases, other researchers

have had difficulty in reproducing those studies, or in

determining the reasons for inconsistent results.

3. What is FDA’s role concerning the safety of wireless

phones?

Under the law, FDA does not review the safety of

radiation emitting consumer products such as wireless

phones before they can be sold, as it does with new

drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown

to emit radio frequency energy (RF) at a level that is

hazardous to the user. In such a case, FDA could

require the manufacturers of wireless phones to notify

users of the health hazard and to repair, replace or

recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA

regulatory actions, FDA has urged the wireless phone

industry to take a number of steps, including the

following:

• Support needed research into possible biological

effects of RF of the type emitted by wireless

phones;

106

Health and safety information

• Design wireless phones in a way that minimizes

any RF exposure to the user that is not

necessary for device function; and

• Cooperate in providing users of wireless phones

with the best possible information on possible

effects of wireless phone use on human health

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at

the federal level. The following agencies belong to this

working group:

• National Institute for Occupational Safety and

Health

• Environmental Protection Agency Federal

Communications Commission

• Occupational Safety and Health Administration

• National Telecommunications and Information

Administration

• The National Institutes of Health participates in

some interagency working group activities, as

well.

FDA shares regulatory responsibilities for wireless

phones with the Federal Communications Commission

(FCC). All phones that are sold in the United States

must comply with FCC safety guidelines that limit RF

exposure. FCC relies on FDA and other health agencies

for safety questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from

these base stations are typically thousands of times

lower than those they can get from wireless phones.

Base stations are thus not the primary subject of the

safety questions discussed in this document.

4. What is FDA doing to find out more about the

possible health effects of wireless phone RF?

Health and safety information

Settings

107

FDA is working with the U.S. National Toxicology

Program and with groups of investigators around the

world to ensure that high priority animal studies are

conducted to address important questions about the

effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health

Organization International Electromagnetic Fields

(EMF) Project since its inception in 1996. An influential

result of this work has been the development of a

detailed agenda of research needs that has driven the

establishment of new research programs around the

world. The Project has also helped develop a series of

public information documents on EMF issues.

FDA and the Cellular Telecommunications & Internet

Association (CTIA) have a formal Cooperative

Research and Development Agreement (CRADA) to do

research on wireless phone safety. FDA provides the

scientific oversight, obtaining input from experts in

government, industry, and academic organizations.

CTIA-funded research is conducted through contracts

to independent investigators. The initial research will

include both laboratory studies and studies of wireless

phone users. The CRADA will also include a broad

assessment of additional research needs in the

context of the latest research developments around

the world.

5. What steps can I take to reduce my exposure to

radio frequency energy from my wireless phone?

If there is a risk from these products—and at this point

we do not know that there is—it is probably very

small. But if you are concerned about avoiding even

potential risks, you can take a few simple steps to

minimize your exposure to radio frequency energy

(RF). Since time is a key factor in how much exposure

a person receives, reducing the amount of time spent

using a wireless phone will reduce RF exposure.

If you must conduct extended conversations by

wireless phone every day, you could place more

distance between your body and the source of the RF,

since the exposure level drops off dramatically with

distance. For example, you could use a headset and

carry the wireless phone away from your body or use a

wireless phone connected to a remote antenna

108

Health and safety information

Again, the scientific data do not demonstrate that

wireless phones are harmful. But if you are concerned

about the RF exposure from these products, you can

use measures like those described above to reduce

your RF exposure from wireless phone use.

6. What about children using wireless phones?

The scientific evidence does not show a danger to

users of wireless phones, including children and

teenagers. If you want to take steps to lower exposure

to radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing the time of

wireless phone use and increasing the distance

between the user and the RF source will reduce RF

exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at all. For

example, the government in the United Kingdom

distributed leaflets containing such a recommendation

in December 2000. They noted that no evidence exists

that using a wireless phone causes brain tumors or

other ill effects. Their recommendation to limit

wireless phone use by children was strictly

precautionary; it was not based on scientific evidence

that any health hazard exists.

7. Do hands-free kits for wireless phones reduce risks

from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free

kits can be used with wireless phones for convenience

and comfort. These systems reduce the absorption of

RF energy in the head because the phone, which is the

source of the RF emissions, will not be placed against

the head. On the other hand, if the phone is mounted

against the waist or other part of the body during use,

then that part of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are required to

meet safety requirements regardless of whether they

are used against the head or against the body. Either

configuration should result in compliance with the

safety limit.

Health and safety information

Settings

109

8. Do wireless phone accessories that claim to shield

the head from RF radiation work?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that accessories that claim to shield the head

from those emissions reduce risks. Some products

that claim to shield the user from RF absorption use

special phone cases, while others involve nothing

more than a metallic accessory attached to the phone.

Studies have shown that these products generally do

not work as advertised. Unlike “hand-free” kits, these

so-called “shields” may interfere with proper operation

of the phone. The phone may be forced to boost its

power to compensate, leading to an increase in RF

absorption. In February 2002, the Federal trade

Commission (FTC) charged two companies that sold

devices that claimed to protect wireless phone users

from radiation with making false and unsubstantiated

claims. According to FTC, these defendants lacked a

reasonable basis to substantiate their claim.

9. What about wireless phone interference with

medical equipment?

Radio frequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason,

FDA helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted

cardiac pacemakers and defibrillators from wireless

telephones. This test method is now part of a standard

sponsored by the Association for the Advancement of

Medical instrumentation (AAMI). The final draft, a joint

effort by FDA, medical device manufacturers, and

many other groups, was completed in late 2000. This

standard will allow manufacturers to ensure that

cardiac pacemakers and defibrillators are safe from

wireless phone EMI.

FDA has tested hearing aids for interference from

handheld wireless phones and helped develop a

voluntary standard sponsored by the Institute of

Electrical and Electronic Engineers (IEEE). This

standard specifies test methods and performance

requirements for hearing aids and wireless phones so

that no interference occurs when a person uses a

110

Health and safety information

compatible phone and a compatible hearing aid at the

same time. This standard was approved by the IEEE in

2000.

FDA continues to monitor the use of wireless phones

for possible interactions with other medical devices.

Should harmful interference be found to occur, FDA

will conduct testing to assess the interference and

work to resolve the problem.

10.What are the results of the research done already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in

their research methods. Animal experiments

investigating the effects of radio frequency energy

(RF) exposures characteristic of wireless phones have

yielded conflicting results that often cannot be

repeated in other laboratories. A few animal studies,

however, have suggested that low levels of RF could

accelerate the development of cancer in laboratory

animals. However, many of the studies that showed

increased tumor development used animals that had

been genetically engineered or treated with cancer

causing chemicals so as to be pre-disposed to develop

cancer in the absence of RF exposure. Other studies

exposed the animals to RF for up to 22 hours per day.

These conditions are not similar to the conditions

under which people use wireless phones, so we don t

know with certainty what the results of such studies

mean for human health.

Three large epidemiology studies have been published

since December 2000. Between them, the studies

investigated any possible association between the use

of wireless phones and primary brain cancer, gioma,

meningioma, or acoustic neuroma, tumors of the brain

or salivary gland, leukemia, or other cancers. None of

the studies demonstrated the existence of any harmful

health effects from wireless phone RF exposures.

However, none of the studies can answer questions

about long-term exposures, since the average period

of phone use in these studies was around three years.

11.What research is needed to decide whether RF

exposure from wireless phones poses a health

risk?

Health and safety information

Settings

111

A combination of laboratory studies and

epidemiological studies of people actually using

wireless phones would provide some of the data that

are needed. Lifetime animal exposure studies could be

completed in a few years. However, very large

numbers of animals would be needed to provide

reliable proof of a cancer promoting effect if one

exists. Epidemiological studies can provide data that is

directly applicable to human populations, but 10 or

more years follow-up may be needed to provide

answers about some health effects, such as cancer.

This is because the interval between the time of

exposure to a cancer-causing agent and the time

tumors develop - if they do - may be many, many

years. The interpretation of epidemiological studies is

hampered by difficulties in measuring actual RF

exposure during day-to-day use of wireless phones.

Many factors affect this measurement, such as the

angle at which the phone is held, or which model of

phone is used.

12.Which other federal agencies have responsibilities

related to potential RF health effects?

Additional information on the safety of RF exposures

from various sources can be obtained from the

following organizations.

FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

Occupational Safety and Health Administration’s

(OSHA):

http://www.osha-slc.gov/SLTC/

radiofrequencyradiation/index.html

National Institute for Occupational Safety and Health

(NIOSH):

http://www.cdc.gov/niosh/emfpg.html

World health Organization (WHO):

http://www.who.int/peh-emf/

International Commission on Non-Ionizing Radiation

Protection:

http://www.icnirp.de

112

Health and safety information

National Radiation Protection Board (UK):

http://www.nrpb.org.uk

*Updated 4/3/2002: US Food and Drug Administration

http://www.fda.gov/cellphones

113

Index

Alarm • 41

Answering

call • 25

second call • 26

Anykey answer • 76

Auto redial • 76

Backlight time, set • 77

Band selection • 81

Barring, calls • 80

Battery

charging • 7

low indicator • 8

precautions • 88

Broadcast messages • 61

Browser, WAP • 43

Calculator • 42

Calendar • 65

Call costs • 30

Call records

dialled • 29

missed • 29

received • 30

Call time • 30

Caller group, managing • 33

Caller ID • 81

Calls answering • 25

barring • 80

diverting • 79

emergency • 95

holding • 26

redialling • 24

rejecting • 25

waiting • 80

Camera

photos • 69

videos • 72

Care • 96

CB (Cell Broadcast) messages •

Characters, enter • 21

Conference call • 28

Connection tone • 79

Converter • 42

Creating calendar

anniversaries • 66

events • 66

miscellaneous • 66

tasks • 67

Creating messages

e-mail • 48

MMS • 48

SMS • 47

Deleting

call records • 30

e-mails • 54

missed alarms • 69

MMS messages 51

phonebook • 35

photos • 72

SMS messages • 50

video clips • 75

Dialled calls • 29

Display

icons • 10

language • 75

settings • 77

Diverting, calls • 79

DTMF tones, send • 27

E-mails

creating/sending • 48

deleting • 54

setting • 58

viewing • 54

Emergency calls • 95

FDN (Fixed Dial Number) mode

• 83

File manager • 62

Games • 39

Greeting message • 75

Holding, call • 26

Icons, description • 10

Images, downloaded • 62

Inbox, messages

e-mail • 54

MMS • 51

SMS • 49

Infrared, connect • 82

Input mode, change • 21

International calls • 24

Internet • 43

Key tone volume • 78

Keypad tones

sending • 27

setting • 78

114

Index

Language, select • 75

Last number, redial • 24

Locking

media contents • 83

phone • 83

SIM card • 83

Low battery indicator • 8

Maintenance • 96

Memory status

downloaded items • 65

phone • 84

phonebook • 35

Message tone • 78

Messages

e-mail • 48

greeting • 75

MMS • 48

SMS • 47

web • 51

Minute minder • 79

Missed alarm events • 68

Missed calls • 29

MMS messages

creating/sending • 48

deleting • 51

setting • 57

viewing • 49

MP3 player

options • 37

playing • 36

Multi-party calls • 28

Music, downloaded • 63

Muting

key tones • 27

microphone • 26

Name card • 34

Names

entering • 21

searching • 31

Network band, select • 81

Network selection • 80

Network services • 79

Outbox, messages • 52

Password

barring • 80

phone • 83

Phonedisplay • 10

icons • 10

locking • 83

password • 83

resetting • 84

switching on/off • 8

unpacking • 6

Phonebook

copying • 31

deleting • 35

editing • 31

managing • 34

options • 31

speed-dialling • 33

Photos

deleting • 72

taking • 69

viewing • 71

PIN, change • 82

PIN2, change • 83

Power on/off tone • 78

Precaution • 1

Privacy • 83

Problems, solve • 84

Received calls • 30

Received message

cell broadcast • 61

e-mail • 54

MMS • 51

SMS • 51

web • 51

Recording

videos • 72

voice memos • 37

Redialling

automatically • 76

manually • 24

Resetting phone • 84

Ringer

incoming calls • 78

messages • 78

Roaming • 80

Safety

information • 96

precautions • 1

Security, calls • 82

Sent messages • 53

SIM card

inserting • 7

locking • 83

SMS messages

creating/sending • 47

deleting • 50

viewing • 49

Sound settings • 78

Sounds, downloaded • 64

Speed-dial • 33

115

Index

Stopwatch • 43

Switching on/off

microphone • 26

phone • 8

Templates

MMS • 55

text • 55

Text, enter • 21

Timer • 42

Videos

deleting • 75

playing • 74

recording • 72

Voice memos

playing • 38

recording • 37

Waiting call • 80

WAP browser • 43

World time • 40

116

Index

Samsung Electronics Co SGHE350 Single-Band PCS GSM Phone User Manual C s and Settings Admi

Samsung Electronics Co Ltd Single-Band PCS GSM Phone C s and Settings Admi

Users Manual

Navigation menu

Namespaces

Views

Navigation
