Users Manual

Depending on the software installed or your service provider or country,

some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-xxxxA

English. 02/2006. Rev. 1.0

SGH-E370

User’s Guide

Draft 03

2006. 02. 21

E370XAxxx

Drive safely at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 88.

• The phone could explode if the battery is replaced

with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To quickly

learn the basics for your phone, please refer to “Get

started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention

to the subsequent information regarding safety

or phone features.



Indicates that you can get more information on

the referenced page.

→

Indicates that you need to press the Navigation

keys to scroll to the specified option and then

select it.

[ ]

Indicates a key on the phone. For example,

[]

< >

Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

Special

features of your phone

•MP3 player

Play MP3 music files using your

phone as an MP3 player.

•Web browser

Access the wireless web to get up-

to-the-minute information and a

wide variety of media content.

Special features of your phone

•Bluetooth

Send photos, images, videos, and

other personal data, and connect

to other devices using free,

wireless Bluetooth technology.

• Get personal with photo caller

See who’s calling you when the

phone displays their very own

photo displays.

• Name card

Create name cards with your

number and profile. Whenever

introducing yourself to others, use

this convenient electronic name

card.

• Multimedia message service (MMS)

Send and receive MMS messages with a

combination of text, images, video, and audio.

•E-mail

Send and receive e-mails with images, video, and

audio attachments.

• Java game

Enjoy Java

™

-based embedded

games and download new games.

•Calendar

Keep track of your daily, weekly,

and monthly schedule.

• Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone..................................... 7

Power on or off........................................................ 8

Keys and display ..................................................... 9

Access menu functions ............................................ 11

Customise your phone............................................. 12

Make/Answer calls .................................................. 15

Step outside the phone 15

Begin with your camera, the Music player, the web, and

other special features

Use the camera...................................................... 15

Play music............................................................. 16

Browse the web...................................................... 17

Use Phonebook ...................................................... 18

Send messages...................................................... 19

View messages....................................................... 20

Use Bluetooth ........................................................ 21

Enter text 23

ABC, T9, Number, and Symbol modes

Call functions 25

Advanced calling features

Menu functions 29

All menu options listed

Solve problems 86

Help and personal needs

Health and safety information 88

Index 108

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

1 Call records



p.29

1 Recent contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs



p.29



p.30



p.30



p.30



p.30



p.30



p.31

2 Phonebook



p.31

1 Contact list

2 FDN list

3 Add new contact

4 Group

5 Speed dial

6 My name card

7 Own number

8 Management

9 Service number



p.31



p.32



p.32



p.33



p.34



p.34



p.35



p.35



p.35

3 Applications



p.35

1 Music player

2 Voice recorder

3 Java world

4 World time

5 Alarm

6 Calculator

7 Converter

8 Timer

9 Stopwatch

0 SIM AT



p.35



p.37



p.38



p.39



p.40



p.40



p.41



p.41



p.42



p.42

4 Browser



p.42

1 Home

2 Bookmarks

3 Goto URL

4 Clear cache

5 Profile settings

6 Current profile



p.42



p.43



p.44



p.44



p.44



p.45

5 Messages



p.45

1 Create new message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Broadcast messages

7 Memory status



p.45



p.48



p.53



p.54



p.54



p.60



p.61

6 File manager



p.61

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory status



p.61



p.62



p.63



p.64



p.64



p.65

7 Calendar



p.65

8 Camera



p.69

9 Settings



p.74

1 Time & Date

2 Phone settings

3 Display settings

4 Sound settings

5 Light settings

6 Network services

7 Bluetooth

8 Security

9 Memory status

0 Reset settings



p.74



p.74



p.76



p.77



p.79



p.79



p.81



p.84



p.85



p.85

* Shows only if supported by your

SIM card.

Unpack

Make sure you have each item

You can obtain various accessories from

your local Samsung dealer.

Phone Travel Adapter

Battery User’s Guide

The items supplied with your phone

and the accessories at your Samsung

dealer may vary, depending on your

country or service provider.

Your phone

Buttons, features, and locations

Special

function keys

Headset jack

Earpiece

Display

Microphone

Navigation keys

(Up/Down/Left/

Right)

Correct key

Left soft key

Volume keys

Dial key

Alphanumeric

keys

Camera lens

Right soft key Camera key

Web access/

Confirm key

Power on/off/

Menu exit key

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the phone is already on,

first turn it off by pressing

and holding [ ].

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card are face down.

Install the battery.

Plug the travel adapter

into the phone.

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged, unplug the

adapter from the power outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

Keypad lock

When you close the phone, the keypad lock feature

locks the exposed keys so that nothing will happen if

the keys are accidentally pressed.

To unlock the keypad, press <

Unlock

> and press

Remove the adapter from the phone.

Switch on

Do not turn on the

phone when

mobile phone use

is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Keys

Perform the function indicated on the

bottom line of the display.

In Idle mode, access your favourite

menus directly.



p. 75

In Menu mode, scroll through menu

options.

In Idle mode, launch the web browser.

In Menu mode, select the highlighted

menu option.

Delete characters from the display or an

item in an application.

Make or answer a call.

In Idle mode, retrieve numbers recently

dialled, missed, or received.

Press and hold to switch the phone on

and off.

End a call.

In Menu mode, cancel input and return

the phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, press and hold

[1]

access your voicemail server. Press and

hold [

] to enter an international call

prefix.

Enter special characters.

In Idle mode, press and hold [

]

activate or deactivate Quiet mode. Press

and hold [

]

to insert a pause between

numbers.

Adjust the phone volume.

In Idle mode, with the phone open,

adjust the keypad tone volume. With the

phone closed, press and hold to turn on

the backlight.

In Idle mode, press and hold to turn on

the camera.

In Camera mode, take a photo or start

recording a video.

Get started

Display

Layout

Icons

Received signal strength

Call in progress

Out of your service area; you

cannot send or receive calls

Home Zone, if you have

registered for the appropriate

service

Roaming network

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current functions

assigned to the soft keys.

Menu Contacts

Icons

display various icons.

New text message

New multimedia message

New e-mail

New voicemail

Call diverting feature active



p. 79

Bluetooth active



p. 81

Alarm set



p. 40

Call ringer settings



p. 77

• No indicator: Melody

• : Vibration

• : Vibration then melody

• : Melody then vibration

Quiet mode

Battery power level

* Depending on your country or service provider, the icons shown

on the display may vary.

Get started

Access menu functions

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Select Back

Press the left

soft key to select

the highlighted

option.

Press the right

soft key to return

to the previous

menu level.

Select an

option

1. Press a desired soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods.

•Press <

Back

> to move up

one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want.

Get started

Customise your phone

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ring tone

2. Select a ringtone category.

3. Select a ringtone.

4. Press <

Save

Display

language

Call ringer

melody

You can set wallpaper for the idle

screen on the display.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

2. Select an image category.

3. Select an image.

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Idle mode

wallpaper

Menu mode

skin colour

Get started

You can switch the phone to Quiet

mode to avoid disturbing other

people.

Press and hold

[

]

in Idle mode.

You can set the Navigation keys to

function as shortcuts to access

your favourite menus.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Short cut

2. Select a key.

3. Select a menu to be assigned to

the key.

Quiet mode

shortcuts

Using numbers entered in the

dialling scrren, you can send a text

message, set alarm time, perform

coverter, set scheduler time, or

perform calculation.

To change an Advanced shortcut

key:

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Advanced

shortcut

2. Select

and press [Down].

3. Select a key.

4. Select a menu to be assigned to

the key.

Advanced

Menu shortcuts

Get started

To use an Advanced shortcut

feature:

1. In Idle mode, enter a number.

2. For sending a text message,

enter the destination number.

For an alarm or scheduler item,

enter the time you want as 4-

digit.

For example: Enter “1234.” This

4-digit number will be displayed

as 12:34 in the

Alarm time

line.

For the converter or calculator,

enter the number you want to

convert, or the first number you

want to use.

3. Press one of the Navigation

keys.

4. See the corresponding menu.

Advanced

Menu shortcuts

(continued)

You can protect the phone against

unauthorised use with a phone

password. The phone will require

the password on power-up.

1. In Idle mode, press <

and select

Settings

→

Security

→

Change

password

2. Enter the default password,

00000000

and press <

3. Enter a new 4- to 8-digit

password and press <

4. Enter the new password again

and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and press

Phone lock

Make/Answer calls

Step outside the phone

Begin with your camera, the Music player, the web, and

other special features

Use the camera

1. In Idle mode, enter an area

code and phone number.

2. Press [ ].

3. To end the call, press [ ].

1. When the phone is ringing,

press [ ].

2. To end the call, press [ ].

Press [ / ].

Make a call

Answer a call

Adjust the

volume during

a call

1. Open the phone.

2. In Idle mode, press and hold

[

]

to turn on the camera.

3. Aim the lens at the subject and

make any desired adjustments.

4. Press [ ] or [ ] to take a

photo. The photo is saved

automatically.

Pres

s <

Back

> to

take another

photo.

1. In Idle mode, press <

and select

File manager

→

Images

→

Photos

2. Select the photo you want.

Take a photo

View a photo

Step outside the phone

Play music

1. In Idle mode, press and hold

[ ] to turn on the camera.

2. Press [

] to switch to Record

mode.

3. Press [

] or

[ ] to start

recording.

4. Press [

], < >

, or [ ] to

stop recording. The video is

saved automatically.

5. Press < > to record another

video.

1. In

Idle

mode,

press <

and select

File manager

→

Videos

→

Videos

2. Select the video you want.

Record a video

Play a video

Use these methods:

• Download from the wireless

web



p. 42

• Download from a computer

using Samsung PC Studio



Samsung PC Studio User’s

Guide

• Receive via Bluetooth



p. 84

1. In Idle mode, press <

and select

Applications

→

Music player

2. Press <

Options

> and select

Add to list

→

Add all

Add a

file

3. For

Add a file

, press [ ] to

select the files you want and

press <

Add

Copy MP3 files

to the phone

Create a play

list

Step outside the phone

Browse the web

Using a built-in web browser, you can easily access the

wireless web to get a variety of up-to-date services

and information and to download web content.

4. Press <

Back

> to return to the

Music player screen.

1. From the Music player screen,

press [ ].

2. During playback, use the

following keys:

• : pauses/resumes

playback.

• Left: returns to the previous

file. Moves backward in a

file when held down.

• Right: skips to the next file.

Skips forward in a file when

held down.

• Up: opens the play list.

• / : adjusts the volume.

• Down: stops playback.

Play MP3 file

In Idle mode, press [ ].

• To scroll through browser items,

press the Navigation keys.

• To select an item, press < >.

• To return to the previous page,

press <

Back

> or [

• To return to the homepage,

press and hold [

• To access options, press [

]

select on the top of the

screen.

Launch the

web browser

Navigate the

web

Step outside the phone

Use Phonebook

To the phone’s memory:

1. In Idle mode, enter a phone

number and press <

Save

2. Select

Phone

→

a number type.

3. Specify contact information:

First name, Last name, Mobile,

Home, Office, Fax, Other, Email,

Graphic ID, Alert, Group, and

Notes.

4. Press [ ] to save the entry.

To the SIM card:

1. In Idle mode, enter a phone

number and press <

Save

2. Select

SIM

3. Enter a name.

4. Press [

]

to save the entry.

Add an entry

1. In Idle mode, press

Contacts

2. Enter the first few letters of the

name you want.

3. Select an entry.

4. Scroll to a number, and press

[]

to dial or press [ ] to

edit contact information.

1. In Idle mode, press <

and select

Phonebook

→

name card

2. Specify your contact

information.

3. Press [ ] to save the name

card.

4. To send the name card to other

people, press <

Options

> and

select

Send via

→

a sending

method.

Find an entry

Create and

send a name

card

Step outside the phone

Send messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Text

message

2. Enter the message text.

3. Press <

Options

> and select

Send only

Save and send

4. Enter destination numbers.

5. Press [ ] to send the

message.

Send a text

message (SMS)

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Multimedia

message

2. Select

Subject

3. Enter the message subject and

press [ ].

4. Select

Picture & Video

Sound

and add a media file.

5. Select

Message

6. Enter the message text and

press [ ].

7. Press <

Options

> and select

Send

8. Enter destination numbers or

addresses.

9. Press [ ] to send the

message.

Send a

multimedia

message

(MMS)

Step outside the phone

View messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

2. Select

Subject

3. Enter the e-mail subject and

press [ ].

4. Select

Message

5. Enter the e-mail text and press

[].

6. Select

File attach

7. Add image, video, sound, or

music files.

8. Press <

Options

> and select

Send

9. Enter e-mail addresses.

10.Press [ ] to send the e-mail.

Send an e-mail

When a notification appears:

1. Press <

View

2. Select the message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select a text message.

When a notification appears:

1. Press <

View

2. Select the message from the

Inbox.

View a text

message

View a

multimedia

message

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth technology,

enabling you to connect the phone wirelessly to other

Bluetooth devices and exchange data with them, talk

hands-free, or control the phone remotely.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select a multimedia message.

1. In Idle mode, press <

and select

Messages

→

messages

→

Email box

2. Press <

Select

> when

Check

new mail

is highlighted to

retrieve an e-mail or a header.

3. Select an e-mail or a header.

4. If you selected a header, press

Options

> and select

Retrieve

View an e-mail

In Idle mode, press <

> and

select

Settings

→

Bluetooth

→

Activation

→

1. In Idle mode, press <

and select

Settings

→

Bluetooth

→

My devices

→

Search new device

2. Select a device.

3. Enter a Bluetooth PIN or the

other device’s Bluetooth PIN, if

it has one, and press <

When the owner of the other

device enters the same code,

pairing is complete.

Turn on

Bluetooth

Search for and

pair with a

Bluetooth

device

Step outside the phone

1. Access an application,

Phonebook

File manager

, or

Calendar

2. Select an item.

3. Press <

Options

> and select

Send via

→

Bluetooth

4. Select

Search new device

5. Select a device.

6. If necessary, enter the

Bluetooth PIN and press <

To receive data via Bluetooth, your

phone’s Bluetooth feature must be

active.

If necessary, press <

Yes

> to

confirm that you are willing to

receive.

Send data

Receive data

Enter text

ABC, T9, Number, and Symbol modes

You can enter text for some features such as

messaging, Phonebook, or Calendar, using ABC mode,

T9 mode, Number mode, and Symbol mode.

Changing the text input mode

• Press and hold [ ] to switch between T9 and ABC

modes.

• Press [ ] to change case or switch to Number

mode.

• Press and hold [ ] to switch to Symbol mode.

Using ABC mode

Press the appropriate key until the character you want

appears on the screen.

(Creating an SMS message with GSM alphabet encoding)

Upper case Lower case

Characters in order displayed

Key

Enter text

Other ABC mode operations

• To enter the same letter twice or to enter a

different letter on the same key, wait for the cursor

to move to the right automatically or press [Right].

Then, enter the next letter.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

•Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Using T9 mode

T9 is a predictive text input mode that allows you to

key in any character using single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word. Press

each key once for each letter.

For example, press [

], [

], and [

] to

enter hello in T9 mode.

T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, go to step 4.

Otherwise, press [

] to display alternative word

choices for the keys that you have pressed.

For example, of and me use [

] and [

4. Press [ ] to insert a space and enter the next

word.

Other T9 mode operations

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

• Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for your key

presses. When there are no more alternative

words,

Spell

appears on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC mode and

press <

Add

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

Making an international call

1. In Idle mode, press and hold [

]. The

character

appears.

2. Enter the country code, area code, and phone

number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

2. Scroll to the number you want and press [ ].

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbol(s) [

insert the symbol(s) <

Press [

] to clear the last digit or press and hold

[

] to clear the whole display. You can move the

cursor to edit an incorrect digit.

Call functions

Making a call from Phonebook

Once you have stored a number in Phonebook, you

can dial the number by selecting it from

Phonebook.



p. 31

You can also use the speed dial feature to assign your

most frequently called numbers to specific number

keys.



p. 34

You can quickly dial a number from the SIM card using

its location number assigned when stored.

1. In Idle mode, enter the location number for the

phone number you want and press [ ].

2. Find the number you want.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

Answering a call

When you receive an incoming call, the phone rings

and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

is active, you can press

any key, except for <

Reject

> and [ ].



p. 76

• Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to reject a call or mute the

ringer, depending on the

Volume key

setting.



p. 76

Viewing missed calls

If you have missed calls, the screen displays how

many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls without

holding the phone.

Connect the headset to the jack on the right side of

the phone. The button on the headset works as

follows:

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to

decrease the volume level.

Using the speakerphone feature

Use the phone as a speakerphone to talk and listen

with the phone a short distance away.

1. During a call, plug the speaker into the phone.

Speaker mode is automatically activated.

2. Press [ ] to return to normal phone mode.

Placing a call on hold/Retrieving

Press <

Hold

> or <

Retrieve

> to place a call on hold

or retrieve the call.

Making a second call

You can make another call if your network supports it.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the calls.

4. Press <

Options

> and select

End

held

call

to end

the call on hold.

5. To end the current call, press [ ].

To Press

redial the last call the button and then press

and hold it again.

answer a call and hold the button.

end a call and hold the button.

Call functions

Answering a second call

You can answer an incoming call while already on the

phone, if your network supports it and you have

activated the call waiting feature.



p. 80

1. Press [ ] to answer the call. The first call is

automatically put on hold.

2. Press <

Swap

> to switch between the calls.

3. To end the current call, press [ ].

Using In-call options

Press <

Options

> to access the following options

during a call:

•

Voice clarity on

Voice clarity off

: remove

extraneous noise and increase call quality so that

the person with whom you are speaking can hear

you clearly even if you are in a noisy place.

•

Mute

Unmute

: switch off the phone's microphone

so that the other person on the phone cannot hear

you, or switch it back on.

•

Mute keys

Send keys

: switch the key tones on

or off.

•

Phonebook

: access the contact list.

•

Send DTMF

: send the DTMF (Dual tone multi-

frequency) tones as a group. The DTMF tones are

the tones used in phones for tone dialling,

sounding when you press the number keys. This

option is helpful for entering a password or an

account number when you call an automated

system, like a banking service.

•

Message

: send a new message or access received

messages.

•

Join

: set up a multi-party call by adding a caller

on hold to a currently active call. You can include

up to 5 people on a multi-party call.

•

Transfer

: transfer the currently active call to a

caller on hold. The two callers can talk to each

other, but you are disconnected from the call.

To communicate with answering machines or

computerised telephone systems,

Send keys

must be selected.

•

End held call

: disconnect the call currently on

hold.

•

Split

: have a private conversation with one

multiparty call participant. The other participants

can converse with each other. After the private

conversation, select Join to return both all private

participants to the multi-party call.

•

Remove

: disconnect one multi-party call

participant.

•

Switch to headset

Switch to phone

: switch the

call to a Bluetooth stereo headset or hands-free

car kit or back to the phone.

•

SIM service

: access special services, such as

news, weather forecasts, entertainment, and

location services, provided by your SIM card. This

option is available when you use a SIM card

supporting SIM Application Toolkit menus, and may

be differently displayed depending on your service

provider.

Menu functions

All menu options listed

Call records

(Menu 1)

Use this menu to view the calls you have dialled,

received, or missed, and the length of the calls. You

can also check the cost of your calls, if your SIM card

supports this function.

To access this menu, press <

> in Idle mode and

select

Call records

Recent contacts

(Menu 1.1)

This menu displays the most recent calls dialled,

received, or missed.

Accessing a call record

1. Press [Left] or [Right] to move to another call

type.

2. Press [Up] or [Down] to scroll through the call list.

3. Press [ ] to view the details of a call, or press

[ ] to dial a number.

Menu functions

Using call record options

While viewing call details, press <

Options

> to access

the following options:

•

Save as contacts

: save the number in

Phonebook.

•

Send message

: send an SMS or MMS message to

the selected number.

•

Delete

: delete the selected call record or all

records.

Missed calls

(Menu 1.2)

This menu displays the most recent calls you did not

answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you have

dialled.

Received calls

(Menu 1.4.)

This menu displays the most recent calls you have

received.

Delete all

(Menu 1.5)

Use this menu to delete all of the records in each call

type.

1. Press [ ] to select the call types to be cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls made and

received. The actual time invoiced by your service

provider will vary.

•

Last

call

time

: check the length of your last call.

•

Total

sent

: check the total length of all the calls

you have dialled.

•

Total

received

: check the total length of all the

calls you have received.

•

Reset timers

: reset the call timers. You need to

enter the phone password.

The password is preset to

00000000

. You can

change this password.



p. 84

Menu functions

Phonebook

(Menu 2)

Call costs

(Menu 1.7)

This network feature displays the cost of calls. This

menu is available only if supported by your SIM card.

Note that this is not intended to be used for billing

purposes.

•

Last

call

cost

: check the cost of your last call.

•

Total

cost

: check the total cost of all of your calls.

If the total cost exceeds the maximum cost set in

Set

max

cost

, you must reset the counter before

you can make another call.

•

Max

cost

: check the maximum cost limit set in

Set

max

cost

•

Reset

counters

: reset the cost counters.

•

Set

max

cost

: set the maximum cost authorised

for your calls.

•

Price/Unit

: set the price per unit that is applied

when the cost of your calls is calculated.

Phonebook

(Menu 2)

You can store phone numbers on your SIM card and in

your phone’s memory. The SIM card and phone’s

memory are physically separate, but they are used as

a single entity called Phonebook.

To access this menu, press <

> in Idle mode and

select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for numbers in Phonebook.

Finding an entry

1. Enter the first few letters of the name that you

want to find.

2. Select the name from the list.

3. Scroll to a number, and press [ ] to dial or press

[ ] to edit contact information.

Press <

Contacts

> in Idle mode to quickly access

this menu.

Menu functions

Using Phonebook options

While viewing contact details, press <

Options

> to

access the following options:

•

Edit

: edit contact information.

•

Send message

: send an SMS or MMS message to

the selected number, or an e-mail to the selected

address.

•

Copy

: copy the contact to the phone’s memory,

the SIM card, or FDN list.

•

Send via

: send the contact via SMS, MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected contact.

•

Print via Bluetooth

: print the contact information

via a Bluetooth-compatible printer.

FDN list

(Menu 2.2)

Use this menu to create a list of contacts to be used in

FDN (Fixed Dialling Number) mode, in which the

phone allows outgoing calls only to the specified

phone numbers, if your SIM card supports this

feature. You can activate FDN mode in the

FDN mode

menu.



p. 85

Adding a contact

1. Press <

Options

> and select

Add

2. Enter your PIN2 and press <

3. Enter information.

•

Name

: assign a name.

•

Phone number

: add a phone number.

•

Location

: assign a location number.

4. Press <

Save

> to save the contact.

Using contact options

Scroll to a contact and press <

Options

> to access

options.



“Using Phonebook options”

Add new contact

(Menu 2.3)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the

contact.

•

First name

Last name

: assign a name.

Menu functions

Phonebook

(Menu 2)

•

Mobile

Home

Office

Fax

Other

: add a

number in any type.

•

: assign an e-mail address.

•

Graphic ID

: assign an image to alert you to a

call from the person.

•

Alert

: assign a ringtone to alert you to a call

from the person.

•

Group

: assign the contact to a caller group.

•

Notes

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Phone number

: add a number.

•

Location

: assign a location number.

3. Press <

Save

> to save the contact.

Group

(Menu 2.4)

Use this menu to organise your contacts in caller

groups.

Adding members to a caller group

1. Select a group.

2. Press <

Add

3. Select a contact to be added.

Managing caller groups

While viewing the group list, press <

Options

> to

access the following options:

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: change the properties of the selected group.

•

Send message

: send an SMS, MMS, or e-mail

message to the group members you want.

•

Delete

: delete the selected group. Group

members, however, will not be deleted from

Phonebook.

To assign a caller ID image, ringtone, or group,

the contact must be saved to the phone’s

memory.

Menu functions

Speed dial

(Menu 2.5)

Use this menu to assign a speed dial number (2 to 9)

for 8 of your most frequently called numbers.

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved

for your voicemail server.

2. Select a contact from the contact list.

3. Select a number, if the contact has more than one

number.

Managing speed dial entries

From the Speed dial screen, press <

Options

> to

access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: check the name and number assigned to a

key.

•

Change

: assign a different number to a key.

•

Remove

: clear the speed dial setting for a key.

Dialling speed dial entries

In Idle mode, press and hold the appropriate key.

My name card

(Menu 2.6)

Use this menu to create a name card and send it to

other people.

Saving your name card

The procedure for creating your name card is the

same as the one for saving a phone number in the

phone’s memory.



p. 32

Using name card options

After saving your name card, press <

Options

> to

access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS, MMS,

e-mail, or Bluetooth.

•

Exchange namecard

: exchange name cards with

another person via Bluetooth.

•

Remove

: delete the name card.

•

Print via Bluetooth

: print your contact

information via a Bluetooth-compatible printer.

Menu functions

Applications

(Menu 3)

Own number

(Menu 2.7)

Use this feature to check your phone numbers, or to

assign a name to each of the numbers. Changes made

here do not affect the actual subscriber numbers on

your SIM card.

Management

(Menu 2.8)

Use this menu to manage Phonebook entries.

•

Default saving

: select a default memory location

to save contacts. If you select

Ask on saving

, the

phone will ask you to select a memory location

each time you save a number.

•

Copy all to

: copy all of the contacts stored on

your SIM card to your phone’s memory, or vice

versa.

•

Sort by contacts

: change the sort order of

Phonebook entries.

•

Delete all

: delete all of the contacts from your

phone’s memory, SIM card, or FDN list.

•

Memory status

: check the number of contacts

you have stored in your phone’s memory and on

the SIM card.

Service number

(Menu 2.9)

Use this menu to view the list of Service Dialling

Numbers (SDN) assigned by your service provider,

including emergency numbers and numbers for

directory enquiries. This menu is available if your SIM

card supports SDN.

1. Scroll to the number you want.

2. Press <

Dial

> or [ ].

Applications

(Menu 3)

Use this menu to play Java games or play music files.

You can also use convenient features, such as a voice

recorder, alarm clock, calculator, converter, and

stopwatch.

To access this menu, press <

> in Idle mode and

select

Applications

Music player

(Menu 3.1)

Use this menu to enjoy music. First, you need to save

music files into your phone’s memory.

Menu functions

Downloading or receiving music files

Use these methods to save music files to your phone’s

memory:

• Download from the wireless web



p. 42

• Download from a computer using the Samsung PC

Studio program



Samsung PC Studio User’s

Guide

• Receive via an active Bluetooth connection



p. 84

The downloaded or received files are stored in the

Music

folder.



p. 63

Creating a play list

1. From the Music player screen, press <

Options

and select

Add to list

2. Select either of the following options:

•

Add all

: add all of the files in the phone’s

memory to the play list.

•

Add a file

: add specific files to the play list.

3. If you selected

Add a file

, press [ ] to select

the files you want and press <

Add

4. Press <

Back

> to go back to the Music player

screen.

Playing music files

From the Music player screen, press [ ].

During playback, use the following keys:

Keys Function

Pauses or resumes playback.

Left Returns to the previous file. Moves

backward in a file when held down.

Right Skips to the next file. Moves forward in a

file when held down.

Up Opens the play list.

Down Stops playback.

/ Adjusts the volume level.

Changes the playback animation.

Changes the repeat mode.

Turns Shuffle mode on or off.

Menu functions

Applications

(Menu 3)

Using Music player options

During playback, press <

Options

> to access the

following options:

•

Pause

Play

: pause or begin playback.

•

Open play list

: access the play list.

•

Remove

: remove the selected file from the play

list.

•

Settings

: change the default settings for playing

music files.

Repeat mode

: select a repeat mode.

Shuffle

: set the Music player to play music in

random order.

Visualization

: change the playback animation.

Volume

: select a volume level.

•

Details

: access the file properties.

Accessing the play list

From the Music player screen, press [Up] to access the

play list.

Press <

Options

> to access the following options:

•

Play

: play the currently selected file.

•

Add to list

: add files to the play list.

•

Change order

: move the selected file to the

position you want within the play list.

•

Remove

: remove the selected file or all files from

the play list.

Voice recorder

(Menu 3.2)

Use this menu to record voice memos. A voice memo

can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume the recording.

3. Press <

Save

> or [Down] to end the recording.

The voice memo is saved automatically.

4. Press [ ] to review the voice memo, or press

[Up] to record a new memo.

Playing a voice memo

1. From the Voice recorder screen, press <

Options

and select

Go to voice list

2. Select a voice memo.

Menu functions

During playback, use the following keys:

Changing voice recorder settings

You can change the default settings for the voice

recorder. From the Voice recorder screen, press

Options

> and select

Settings

to access the

following options:

•

Recording time

: select a maximum recording

time.

•

Volume

: select a volume level.

•

Default name

: change the default prefix of voice

memos.

Java world

(Menu 3.3)

Use this menu to access and play Java games and to

change the network settings for accessing Java

services.

Accessing a game

Select a game from the game list and follow the

onscreen instructions. The procedure may differ from

game to game.

Using Java application options

From the application list, press <

Options

> to access

the following options:

•

Start

: launch the selected application.

•

Delete

: delete the selected application.

•

Details

: access the application properties.

•

Permission

: set permission settings for services

charging you additional costs, such as network

access and SMS.

•

Protection

: lock the application to protect it from

being deleted, or unlock the application.

Keys Function

Pauses or resumes playback.

Left Moves backward in a memo.

Right Moves forward in a memo.

Up Switches to Record mode for a new voice

memo.

Down Stops playback.

/ Adjusts the volume.

Menu functions

Applications

(Menu 3)

•

Upgrade

: upgrade the application to the latest

version, except for embedded games.

•

Send information via SMS

: send the URL

containing the application via SMS, except for

embedded games.

•

Memory status

: access memory information for

applications.

•

Network settings

: set up a connection profile to

be used for applications requiring network access.

The following options are available:

APN

: enter the access point name.

: enter the user ID.

Password

: enter the password.

Proxy

: select whether or not you use a proxy

server to access network services. Depending on

this setting, options in

Proxy settings

vary.

Proxy settings

: provide you with the following

options:

When the proxy is set to

Enable

IP address

: enter the HTTP proxy address.

Port

: enter the port number.

When the proxy is set to

Disable

DNS1

: enter the primary DNS address.

DNS2

: enter the secondary DNS address.

World time

(Menu 3.4)

Use this menu to find out what time it is in another

part of the world.

Viewing world time

1. From the world map, press [Left] or [Right] to

scroll to the city you want. As the time line moves,

the time and date of the given zone display.

2. Press [ ] to save the time zone.

Applying daylight savings time

1. From the world map, press <

Options

> and select

Set daylight saving time

2. Press [ ] to select the time zones you want.

3. Press <

Save

Menu functions

Alarm

(Menu 3.5)

Use this menu to set alarms to sound at specific times.

Setting an alarm

1. Select the type of alarm.

2. Set each alarm option:

•

Alarm

: activate the alarm.

•

Alarm time

: enter the time for the alarm to

ring.

•

AM/PM

: set

in 12-hour format.

•

Alarm day

: select the days on which you want

the alarm to sound. If you select

Once alarm

the alarm sounds at the specified time and

then is deactivated.

•

Alarm tone

: select an alarm tone.

3. Press <

Save

Stopping an alarm

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press <

> or [ ].

Press any key, except <

> and [ ], to stop the

alarm and cause it to sound again after 5 minutes.

You can do this a maximum of five times.

Setting the alarm to sound even if the phone

is off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the alarm to ring,

the phone is switched on and sounds the alarm.

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

Off

on the Alarm line.

3. Press <

Save

Calculator

(Menu 3.6)

Use this menu to perform basic arithmetic functions,

such as addition, subtraction, multiplication, and

division.

1. Enter the first number.

•Press <

.()

> to insert a decimal point or

bracket.

•

Press

[ ] or [ ] t

o move the cursor.

2. Press one of the Navigation keys to access the

math function you want.

3. Enter the second number.

Menu functions

Applications

(Menu 3)

4. Press [ ] to view the result.

5. If necessary, repeat from step 2 to continue the

calculation.

Converter

(Menu 3.7)

Use this menu for common conversions, such as

currency and temperature.

Performing a conversion

1. Select a converter.

2. Press [Left] or [Right] to select the original unit

and press [Down].

3. Enter the value to be converted and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

zero (+) or below zero (-)

4. Press [Left] or [Right] to select the unit to which

you want to convert.

The equivalent value for the amount you entered

displays.

Using converter options

Press <

Options

> to access the following options:

•

Clear

: clear the current values.

•

Reverse

: reverse the conversion.

•

Currency rates

: display the currency rate list.

Timer

(Menu 3.8)

Use this menu to set a period of time for the phone to

count down. The phone will sound an alarm when the

specified period of time has expired.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to count down

and press <

3. Press [ ] to start counting down.

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer

before it rings.

Menu functions

Stopwatch

(Menu 3.9)

Use this menu to measure elapsed time. The

maximum time is 10 hours.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can repeat

this step for a total of 4 intervals.

SIM AT

(Menu 3.0)

This menu is available if you use a SIM AT card that

supports SIM Application Toolkit menus and provides

additional services, such as news, weather, sports,

entertainment, and location services. Available

services may vary, depending on your service

provider’s plans. For details, see your SIM card

instructions or contact your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP) browser on

your phone allows you to access the wireless web.

From the wireless web, you can access up-to-date

information and a wide variety of media content, such

as games, wallpapers, ringtones, and music files.

To access this menu, press <

> in Idle mode and

select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the network

and load the homepage of the wireless web service

provider. You can also press [ ] in Idle mode.

Navigating the web browser

To Press

scroll through browser items [Up] or [Down].

select a browser item <> or [ ].

return to the previous page <

Back

> or [

return to the homepage and hold [

Menu functions

Browser

(Menu 4)

Using browser menu options

From any web page, press [

]

or select on the top

of the screen to access the following options:

•

Back

: go back to the previous page.

•

Home

: return to the homepage.

•

Exit

: exit the web browser.

•

Reload

: reload the current page with updated

information.

•

Show URL

: display the URL address of the current

web page.

•

About...

: access version information for the web

browser.

Accessing other phone menus

From any web page, press [ ] to access the following

options:

•

Goto URL

: enter a URL address manually.

•

Bookmarks

: access the bookmark list.

•

Messages

: send SMS messages or view the

messages stored on the phone.

•

File manager

: access the

File manager

menu.

Exiting the browser

Press [ ] to end the network connection and exit the

browser.

Bookmarks

(Menu 4.2)

Use this menu to save URL addresses in order to

quickly access web pages.

Adding a bookmark

1. Select an empty location.

2. Enter a name for the bookmark and press [Down].

3. Enter a URL address and press [ ].

Accessing a bookmarked page

Selecting a bookmark item launches the web browser

and accesses the associated web page.

Using bookmark options

After saving an item, press <

Options

> to access the

following options:

•

: access the bookmarked web page.

•

Edit

: edit the address and name of the bookmark.

Menu functions

•

Delete

: delete the selected bookmark or all

bookmarks.

Goto URL

(Menu 4.3)

Use this menu to manually enter a URL address and

access the associated web page.

Clear cache

(Menu 4.4)

Use this menu to clear information stored in the cache.

A cache is a temporary memory that stores recently

accessed web pages.

Profile settings

(Menu 4.5)

Use this menu to select a connection profile to be used

for accessing the wireless web. Contact your service

provider for details about your settings options.

For each profile, the following options are available:

•

Profile

name

: enter a profile name.

•

Home

URL

: enter the URL address of the page to

be used as your homepage.

•

Bearer

: select the network bearer type.

•

Proxy

: activate or deactivate the proxy server.

•

GPRS settings

: customise the following GPRS

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the HTTP proxy server address.

Proxy port

: enter the port number.

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID.

Password

: enter the password.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID

Password

: enter the password

•

GSM settings

: customise the following GSM

network settings:

Menu functions

Messages

(Menu 5)

When the proxy is set to

Enable

Proxy IP

: enter the HTTP proxy server address.

Proxy port

: enter the port number.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

Current profile

(Menu 4.6)

Use this menu to activate one of the proxy servers you

have set up.

Messages

(Menu 5)

Use the

Messages

menu to send and receive text

messages, multimedia messages, and e-mails. You

can also use push message and cell broadcast

message features.

To access this menu, press <

> in Idle mode and

select

Messages

Create new message

(Menu 5.1)

Use this menu to create and send messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to send or

receive text messages that may include pictures,

animated images, and melodies.

1. Enter your message.

The maximum number of characters allowed in a

message varies by service provider. If your

message exceeds the maximum number of

characters, the phone will split the message.

Menu functions

2. Press <

Options

> to access one of the following

options:

•

Send only

: send the message.

•

Save and send

: save the copy of the message

and send it.

•

Insert

: add a template, Phonebook entry, or

bookmark into text.

•

Add picture

Add

animation

Add melody

attach a simple image, animated image, or

melody.

•

Attach

: add a name card or calendar data as

data format attachments.

•

Save to

: save the message in the

Draft

folder

box.

•

Language select

: change the language used

in T9 input mode.

•

Text style

: change the text attributes.

3. When you have finished, press <

Options

> and

select

Send only

Save and send

4. Enter a destination number.

To send the message to more than one recipient,

fill in additional destination fields.

5. Press [ ] to send the message.

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers messages

containing a combination of text, image, video, and

audio, from phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Picture & Video

Sound

line and add

an image, a video, or a sound file.

4. Select the

Message

line.

5. Enter the message text and press [ ].

6. Press <

Options

> to access the following options:

•

Edit

: edit the subject or text of your message.

•

Change image

Change

video

Change

sound

: replace an added item.

• The maximum size allowed for a message can

differ, depending on your service provider.

• Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

Menu functions

Messages

(Menu 5)

•

Add image

Add video

: add an image or video

file.

•

Preview

: view the message as it will be shown

on the recipient’s phone.

•

Send

: send the message.

•

Save to

: save the message.

•

Add page

: add pages. Move to each page by

pressing [Left] or [Right].

•

Delete page

: delete an added page.

•

Edit page

: change the duration of page display

or move the page forward among the other

pages.

•

Attach

: attach name cards or calendar data as

data format attachments, or a document file

stored in the

Other files

folder.

•

Remove subject

Remove media

Remove

sound

Remove message

: remove an added

item.

7. When you have finished, press <

Options

> and

select

Send

8. Enter a phone number or e-mail address.

To send the message to more than one recipient,

fill in additional destination fields.

9. Press [ ] to send the message.

(Menu 5.1.3)

You can create and send e-mails that include text,

audio, and images. To use this feature, you need to

subscribe to an e-mail service and set up your e-mail

account and profile.



p. 58, p. 60

1. Select the

Subject

line.

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text and press [ ].

5. Select the

File attach

line to access the following

options:

•

Add image

Add videos

Add sounds

Add

music

: add media files stored in the phone’s

memory.

Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

E370-2.fm Page 47 Tuesday, February 21, 2006 11:29 AM

Menu functions

•

Other files

: add document files stored in the

Other files

folder.

•

Send

: send the message.

•

Save to

: save the message in the

Draft

folder

box.

•

Attach

: attach name cards or calendar data as

data format attachments.

6. When you have finished, press <

Options

> to

access the following options:

•

Add image

Add videos

Add sounds

Add

music

: add media files stored in the phone’s

memory.

•

Other files

: add document files stored in the

Other files

folder.

•

Edit

: edit the subject or text.

•

View

: play an added item.

•

Send

: send the message.

•

Save to

: save the message in the

Draft

folder

box.

•

Attach

: attach name cards or calendar data as

data format attachments.

•

Remove subject

Remove message

: clear

the subject or text.

•

Remove

: delete the selected attachment or all

attachments.

•

Remove all attachments

: delete all

attachments.

7. When you have finished, press <

Options

> and

select

Send

8. Enter an e-mail address.

To send the e-mail to more than one recipient, fill

in additional destination fields.

9. Press [ ] to send the e-mail.

My messages

(Menu 5.2)

Use this menu to access messages you have received,

sent, or which have failed in sending.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you have

received, except for e-mails.

Menu functions

Messages

(Menu 5)

Viewing a message

The following icons may appear on the message list;

depending on the message type or status, icons may

vary:

• SMS / Delivery report

• MMS

• MMS notification ( : Being retrieved, :

Failed to retrieve)

• Push message from web servers

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

: reply to the sender via SMS or MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Add to block list

: add the sender’s number to the

Block list to reject the messages from the sender.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

into your phone’s memory.

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer.

•

Protection

: protect the message from being

deleted.

MMS messages/MMS notifications

•

Retrieve

: retrieve the MMS message from the

MMS server.

•

Reply via SMS

: reply to the sender via SMS.

•

Reply via MMS to

: reply to the sender via MMS.

• Depending on the DRM (Digital Rights

Management)

system, messages having web

content may not be

able to be forwarded.

• A

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Add to block list

: add the sender’s number to the

Block list to reject the messages from the sender.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

into your phone’s memory.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Push messages

•

Go to URL

: connect to the URL specified in the

message.

•

Delete

: delete the message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

Configuration message

•

Install

: apply the configuration specified in the

message to your phone.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

Delivery report messages

•

Delete

: delete the message.

Draft

(Menu 5.2.2)

This folder stores messages you have saved to send at

a later time.

From the message list, press <

Options

> to access

the following options:

•

View

: open the message.

•

Edit

: edit the message.

•

Send

: send the message.

•

Delete

: delete the selected message or all

messages.

•

Move to my folder

: move the message to the

folder

box.

Menu functions

Messages

(Menu 5)

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Sort by

: change the sort order of the message list.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Outbox

(Menu 5.2.3)

This folder stores messages that the phone is

attempting to send or has failed to send.

While viewing a message, press <

Options

> to access

the following options:

•

Send again

: send the message again.

•

Open file

: open the attached file.

•

Save file

: save the attached file in the phone’s

memory.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Sentbox

(Menu 5.2.4)

This folder stores messages that you have sent.

While viewing a message, press <

Options

> to access

the following options:

•

Open file

: open the attached file.

•

Save file

: save the attached file in the phone’s

memory.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

Menu functions

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Email box

(Menu 5.2.5)

This folder stores e-mails that you have received.

1. Select an e-mail account.

2. Press <

Select

> when

Check new mail

displays,

or press <

Options

> and select

Check new mail

The phone checks for new e-mails and downloads

received e-mails.

The following icons may appear on the list to show

the e-mail status:

• : Retrieved from the server

• : Being retrieved

•: Failed to retrieve

3. Select an e-mail or a header.

4. If the e-mail has more than one page, press [/]

to scroll through pages one by one.

Press and hold [/] to move to the first or last

page.

5. Select an attached file to view or play it.

6. Press [ ] or [ ] to move to the previous or next

e-mail.

Using e-mail options

While viewing the e-mail or header, press <

Options

to access the following options:

•

View

: open the selected item.

•

Retrieve

: retrieve one or all of the e-mails from

the e-mail server.

•

Open file

: open the attached file.

•

Save file

: save the attached file in the phone’s

memory.

•

Reply to

: send a reply to the sender or to all of

the other recipients.

•

Forward

: forward the e-mail to other people.

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

Messages

(Menu 5)

•

Delete

: delete the selected e-mail.

•

Move to my folder

: move the e-mail to the

folder

box.

•

Add to block list

: add the sender’s e-mail

address to the filter list to reject e-mails from that

address.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut attachment

: save media content from the

message to your phone’s memory.

•

Print via Bluetooth

: print the e-mail via a

Bluetooth-compatible printer.

•

Details

: access the e-mail properties.

My folder

(Menu 5.2.6)

Use this menu to save the message you have saved

using the

Move to my folder

option while reading a

message.

Templates

(Menu 5.3)

Use this menu to make and use templates of

frequently used messages.

Text template

(Menu 5.3.1)

You can create SMS templates with the sentences you

use frequently so that you can retrieve and insert

them when composing an SMS message.

Creating a template

1. Select an empty location.

2. Enter a message and press [ ].

Using template options

From the template list, press <

Options

> to access

the following options:

•

Edit

: edit the selected template.

•

Send message

: create and send a new message

using the template.

•

Delete

: delete the selected template.

Menu functions

MMS template

(Menu 5.3.2)

You can access embedded MMS templates or ones you

have saved so that you can use them in composing an

MMS message.

From the template list, press <

Options

> to access

the following options:

•

View

: open the selected template.

•

Send message

: create and send a new message

using the template.

•

Edit

: edit the template.

•

Add new

: add a new template.

•

Delete

: delete the selected template or all

templates, except for the embedded ones.

Delete all

(Menu 5.4)

Use this menu to delete all of the messages in each

message folder at once. You can also select messages

in message type you want to delete.

1. Press [ ] to select the message folders or

message types to be cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Settings

(Menu 5.5)

Use this menu to set up various options for using the

messaging services.

Text message

(Menu 5.5.1)

You can configure SMS settings.

•

Send settings

: set up the options for sending

SMS messages:

Reply path

: allow recipients to reply to you

through your SMS server.

Delivery report

: set the network to inform you

when your messages have been delivered.

Character support

: select a character encoding

type. If you select

Auto

, the phone switches the

encoding type from GSM-alphabet to Unicode if

you enter a Unicode character. Use of Unicode

encoding will reduce the maximum number of

characters in a message to about half. If this menu

is not shown, your phone provides automatic

character encoding by default.

Menu functions

Messages

(Menu 5)

Validity period

: set the length of time your

messages are stored in the SMS server.

Message type

: set the default message type. The

network can convert the messages into the

selected format.

Service centre

: store or change the number of

your SMS server.

•

Block number

: store the phone numbers from

which you want to reject messages.

Multimedia message

(Menu 5.5.2)

You can configure MMS settings.

•

Send settings

: set up the options for sending

MMS messages:

Delivery report

: set the network to inform you

when your messages have been delivered.

Address hiding

: set your address to be hidden

from the recipient’s phone.

Read reply

: send a read-reply request along with

your messages.

Priority

: set the priority level of messages.

Expiry date

: set the length of time messages are

stored in the MMS server.

Delivery after

: set a time delay before messages

are sent.

•

Receive settings

: set up the options for receiving

MMS messages:

Anonymous reject

: reject messages from

unknown senders.

Advert allowed

: accept advertisements.

Report allowed

: set the network to inform the

sender when a message has been delivered to you.

Home reception

: determine if your phone

retrieves new messages automatically when you

are in your home service area.

Roaming reception

: determine if your phone

retrieves new messages automatically when you

are roaming in another network.

Reception within home network or abroad has the

following options:

Automatic

: the phone automatically retrieves

messages from the server.

Menu functions

Reject

: the phone rejects all messages.

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

•

MMS profiles

: set up a connection profile and

select a profile to be used for MMS.

Current profile

: select a profile.

Profile settings

: set up the following options for

each profile.

Profile name

: assign a name to the MMS profile.

Server URL

: enter the URL address of your MMS

server.

Proxy

: connect to the GPRS network using the

proxy server.

GPRS settings

: customise the settings required

for connecting to the GPRS network.

When the proxy is set to

Enable

IP address

: enter the IP address.

Port

: enter the port number.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

Version

: select an available OMA version and

maximum size limit for sending or receiving

messages.

•

Block number

: specify phone numbers from

which messages will not be accepted. Numbers

specified here are also included in the SMS

blocking list.

Depending on your service provider, it may not

be possible to support the maximum limit

300KB. In this case, try again after changing

the setting to 100KB.

Menu functions

Messages

(Menu 5)

•

Message class

: set up the options creating MMS

messages:

Message class

: select the type of message

content you will add or how the message size.

Text

: you can add only text of up to 30 KB.

Image basic

: you can add any type of item,

except for video, of up to 30 KB.

Image rich

: you can add any type of item,

except for video, of up to 100 KB.

Video basic

: you can add any type of item of up

to 100 KB.

Video rich

: you can add any type of items of up

to 300 KB.

Creation mode

: select an MMS creation mode.

Free

: you can create a message with any type of

contents and of any size.

Restricted

: you can create a message with the

type of content and size specified in Message

class.

Warning

: you can create a message with any

type of content and of any size, but the phone

will inform you when the content and size have

exceeded the maximum.

(Menu 5.5.3)

You can configure e-mail settings.

•

Send settings

: set up the options for sending e-

mails:

Send copy to self

: send a copy of your e-mails to

your e-mail account.

Delivery confirm

: set the network to inform you

when your e-mails have been delivered.

Read confirm

: send a read-reply request along

with e-mails.

Priority

: select the priority level of e-mails.

Include signature

: attach your name, phone

number, a simple memo, or a tag line to your

e-mails.

You cannot change e-mail profile and account

settings while an e-mail is being sent or retrieved.

Menu functions

Edit name

: enter the name in your signature.

Edit telephone number

: enter the phone number

in your signature.

Edit note

: enter the tag line in your signature.

•

Receive settings

: set up the options for receiving

e-mails.

Check interval

: determine how often the phone

checks the server for incoming e-mails. If you

select

Not used

, use the

Check new mail

option

to receive new e-mails manually.

Read reply

: determine whether or not the phone

sends a read-reply for incoming e-mails. If you

select

Announce

, the phone asks you to send a

read-reply.

Retrieve option

: set whether the phone

downloads e-mail headers only or the complete

e-mail.

Delete option

: determine whether e-mails are

deleted immediately or the next time you connect

to the server.

Reject if over

: determine the maximum size for

incoming e-mails. Your phone will reject e-mails

that exceed the specified size.

Leave a copy of messages on the server

: leave

copies of e-mails on the e-mail server after

retrieving.

•

Email account

: set up an e-mail account and

select an account to be used.

Current account

: select an account.

Account settings

: configure e-mail accounts

using different e-mail servers. Press <

Options

and select

Create

In use

: activate the current e-mail account.

Account name

: enter a name for the currently

selected account.

To access the following options, press [ ], or

press <

Options

> and select

User name

: enter a user name.

Email address

: enter your e-mail address.

Menu functions

Messages

(Menu 5)

Reply address

: enter the e-mail address to

which you want recipients to send reply

messages.

To access the following options, press [ ], or

press <

Options

> and select

Secure connection (SMTP)

: use a secure

connections for e-mail service.

SMTP server

: enter the IP address or host name

of the outgoing e-mail server.

SMTP port

: enter the SMTP port number.

SMTP user ID

: enter the SMTP user ID.

SMTP password

: enter the SMTP password.

Retrieve server type

: select the protocol for

the incoming e-mail server. The remaining

options depend on the protocol type setting.

When the protocol type is

POP3

- Secure connection (POP3)

: use a secured

connection for the POP3 protocol.

POP3 server

enter the IP address or host name

of the server that receives your e-mail.

POP3 port

: enter the POP3 port number.

Same ID and password

: select to use the same

SMTP user ID and password with incoming

server.

POP3 user ID

: enter the POP3 user ID.

POP3 password

: enter the POP3 password.

APOP login

: connect to the server by using the

APOP login scheme.

When the protocol type is

IMAP4

- Secure connection (IMAP4)

: use a secured

connection for the IMAP4 protocol.

IMAP4 server

: enter the IP address or host

name of the server that receives your e-mail.

IMAP4 port

: enter the IMAP4 port number.

Same ID and password

: select to use the same

SMTP user ID and password with incoming

server.

IMAP4 user ID

: enter the IMAP4 user ID.

IMAP4 password

: enter the IMAP4 password.

Include attachments

: select this option to

receive attachments with e-mails.

Menu functions

Email retrieval limit

: set the number of

headers you will retrieve from the server.

•

Email profile

: configure the network settings

required to send or receive e-mails.

Current profile

: select a profile.

Profile settings

: configure up to five e-mail

profiles.

Profile name

: enter a profile name.

APN

: enter the access point name.

: enter user ID.

Password

: enter the password.

DNS1

: enter the primary DNS address.

DNS2

: enter the secondary DNS address.

•

Block list

: set up an e-mail Block list.

Address list

: specify e-mail addresses to reject

e-mails from those addresses.

Subject list

: specify subjects to reject e-mails

which contain those subjects.

Push message

(Menu 5.5.4)

You can change the settings for receiving push

messages from the wireless web server.

•

Receive

: set how your phone receives push

messages.

•

Service centre

: enter the address of the server

from which you want to receive push messages,

when the

Receive

option is set to

SMS-C

specific

Broadcast messages

(Menu 5.6)

You can change the settings for receiving CB

messages.

•

Read

: open received messages.

The

Temporary

box saves network messages until

the phone is switched off.

The

Archive

box.

Menu functions

File manager

(Menu 6)

•

Receive

: select to receive CB messages, or not.

•

Channel

: indicate the channels from which you

wish to receive CB messages. Please contact your

service provider for further details.

•

Language

: select the preferred languages in

which CB messages display.

Memory status

(Menu 5.7)

Use this menu to view the maximum memory and

available memory for each message type. You can also

view the amount of memory currently in use in each

folder.

File manager

(Menu 6)

The

File manager

menu allows you to access images,

videos, music files, and sound files stored in the

phone’s memory.

To access this menu, press <

> in Idle mode and

select

File manager

Images

(Menu 6.1)

This menu displays photos you have taken and images

you have downloaded, received in messages, or

imported from your computer.

Viewing an image

1. Select an image folder.

2. Select an image.

Viewing a slide show

You can view your photos as a slide show, a sequential

presentation of each photo in the current folder.

1. Select

Photos

2. Press <

Options

> and select

Slide show

3. Select an interval option. The slide show begins.

4. Press <

Cancel

> to stop the slide show.

According to the DRM (Digital Rights Management)

system, web content may not be able to be

forwarded. The content is indicated by .

Menu functions

Using image options

While viewing an image, press <

Options

> to access

the following options:

•

List

: return to the image list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the image as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Edit

: add emoticons, frames, or effects to the

image.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

(

favourite images

): move the file to

another folder.

•

Slide show

: view all images as a slide show.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Print via Bluetooth

: print the image via a

Bluetooth-compatible printer.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Videos

(Menu 6.2)

This menu displays video clips you have recorded,

downloaded, received in messages, or imported from

your computer.

Playing a video clip

1. Select a video folder.

2. Select a video clip.

During playback, use the following keys.

Video clips recorded on other devices, such as

camcorders, may not play correctly.

Keys Function

Pauses or resumes playback.

Left Moves backward in the file.

Right Skips forward in a file.

/ Adjusts the volume.

Down Stops playback.

Menu functions

File manager

(Menu 6)

Using video options

While viewing the file list, press <

Options

> to access

the options.

•

Play

: play the video clip.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the selected file or all files.

•

Rename

: change the file name.

•

Move to

(

favourite videos

): move the file to

another folder.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Music

(Menu 6.3)

This menu displays music files you have downloaded,

received in messages, or imported from your

computer.

Playing a music file

Scroll to a file and press [ ].



p. 36

Using music options

While viewing the file list, press <

Options

> to access

the following options:

•

Play

: play the music file.

•

Send via

: send the file via e-mail or Bluetooth.

•

Add play list

: add the selected file to the current

play list.

•

Set as

: set the music file as your call ringtone, a

ringtone for a Phonebook entry, or an alarm tone.

•

Delete

: delete the selected file or all files.

•

Settings

: change the default settings for playing

music files.

Repeat mode

: select a repeat mode.

Shuffle

: set the MP3 player to play music at

random.

Visualization

: select a playback animation.

Volume

: select a volume level.

Menu functions

•

Rename

: change the file name.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Sounds

(Menu 6.4)

This menu displays voice memos you have recorded,

and sound clips you have downloaded, received in

messages, or imported from your computer.

Playing a sound clip

1. Select a sound folder.

2. Select a sound clip. For a voice memo, see

Voice

recorder



p. 36

Using sound options

While viewing the file list, press <

Options

> to access

the following options:

•

Play

: play the sound clip.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the sound file as your call ringtone, a

ringtone for a Phonebook entry, or an alarm tone.

•

Delete

: delete the selected file or all files.

•

Rename

: change the file name.

•

Move to

(

favourite sounds

): move the file to

another folder.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Other files

(Menu 6.5)

Files that you receive but which are not supported by

your phone are stored in this folder. These

unsupported file formats include *.doc, *.hwp, *.ppt,

*.txt.

While viewing the file list, press <

Options

> to access

the following options:

•

Send via

: send the file via e-mail or Bluetooth.

•

Delete

: delete the selected file or all files.

Menu functions

Calendar

(Menu 7)

•

Rename

: change the name of the file.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Memory status

(Menu 6.6)

Use this menu to view memory information for media

items in the phone’s memory.

Calendar

(Menu 7)

The

Calendar

menu enables you to keep track of your

schedule.

To access this menu, press <

> in Idle mode and

select

Calendar

Consulting the calendar

When you enter the

Calendar

menu, the calendar in

Month view appears with today’s date indicated by a

blue box.

Selecting a day

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [ / ] to move by month.

Using calendar options

Press <

Options

> to access the following options:

•

View mode

: change the view mode of the

calendar.



p. 68

•

Create

: add a new item.



next section

•

Go to

: select today’s date or enter the specific

date you want to access.

•

Sort by

: sort items by the type of items.

•

Delete

: delete the items stored on the calendar by

using various deleting options.

•

Missed alarm events

: view events whose alarms

you have missed.

•

Memory status

: access memory information for

the event items stored on the calendar.

Menu functions

Creating an item

You can store scheduled events, anniversaries,

memos, and To-do items on the calendar. More than

one event per day can be stored.

Entering a new schedule item or

miscellaneous item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Schedule

Miscellaneous

3. Enter information or change the settings:

•

Subject

: enter the title of the item.

•

Details

: enter item details.

•

Start date

and

Start time

: enter the starting

date and time for the item.

•

AM/PM

: select

in the 12-hour time

format.

•

End date

and

End time

: enter the ending date

and time for the item.

•

AM/PM

: select

in the 12-hour time

format.

•

Location

: (for

Schedule

) enter information

about the item location.

•

Alarm

: set an alarm for the item.

•

before

: set how long before the item the alarm

is to alert you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: (for

Schedule

) select to set the item

to recur and select a unit of time to repeat.

•

until

: (for

Schedule

) if the item will recur, set

an ending date.

4. Press <

Save

> to save the item.

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary.

Menu functions

Calendar

(Menu 7)

•

before

: set how long before the event the

alarm is to alert you.

•

Alarm time

: enter the time for the alarm to

sound.

•

AM/PM

: select

in the 12-hour time

format.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: select to set the phone to

remind you of the anniversary every year.

4. Press <

Save

> to save the anniversary.

Entering a To-do item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

To do

3. Enter information or change the settings:

•

To do

: enter information about the item.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Priority

: select a priority level.

4. Press <

Save

> to save the item.

Viewing an item

Once you have scheduled items, the following icons

and the number of items for a specific day appear at

the bottom of the calendar.

Accessing an item

1. Select a date on the calendar to display the items

for the day.

2. Select an item to view its details.

3. Press [Left] or [Right] to access the other items

scheduled for the selected day.

Using options

While viewing an item, press <

Options

> to access

the following options:

•

Edit

: edit the item.

•

Create

: add a new item.

•

Send via

: send the item via SMS, MMS, e-mail, or

Bluetooth.

• Schedule item • Anniversary

• To-do item • Miscellaneous item

Menu functions

•

View mode

: change the view mode of the

calendar.

•

Done

Undone

: mark the To-do item as done, or

not.

•

Delete

: delete the item.

•

Print via Bluetooth

: print item details via a

Bluetooth-compatible printer.

•

Missed alarm events

: view items whose alarms

you have missed.

•

Memory status

: access memory information for

the items stored on the calendar.

Viewing an event in different mode

You can change the calendar display to Day view or

Week view. Press <

Options

> and select

View mode

→

a view mode.

Day view

You can view items for the selected date. Select an

item to view its details.

The following icons may display to indicate the item

status:

• Alarm set

• Recurring event

• Completed to-do

• To-do priority (Red: high, Blue: normal, and

Grey: low)

Week view

You can view items for the selected week. A cell on the

timetable indicates the presence of a scheduled item.

Select a cell in the day you want.

Viewing a missed alarm item

When you are unable to acknowledge an alarm for a

schedule item of anniversary, the phone stores the

missed alarm item until you confirm it.

1. Press <

Options

> and select

Missed alarm

events

2. Select an item.

3. Press <

Confirm

> to confirm and delete the item.

Menu functions

Camera

(Menu 8)

Camera

(Menu 8)

You can use the camera module embedded in your

phone to take photos and record videos.

To access this menu, press <

> in Idle mode and

select

Camera

, or press and hold [

Taking a photo

You can take photos in various modes. The camera

produces JPEG photos.

1. Access the

Camera

menu to turn on the camera

and switch the display to Capture mode. You can

also press and hold [

]

in Idle mode.

2. Make any desired adjustments.

• Press the left soft key to access camera

options.



next section

• Use the keypad to change camera settings or

switch to other modes.



p. 70

3. Press [

] or

[ ] to take a photo. The photo is

saved in the

Photos

folder.

Using camera options in Capture mode

In Capture mode, press the left soft key to access the

following options:

•

Record video

: switch to Record mode.

•

Shooting mode

: take a photo in the following

modes:

Single shot

: take a photo in normal mode.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras are

not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

To Press

use photo options <

Options



p. 70

delete the photo [

] and then <

Yes

return to Capture mode <

Back

> or [ ].

Menu functions

Multi shot

: take a series of action stills. Select the

number of photos the camera will take and the rate

at which the photos are taken.

•

Effects

: change the colour tone or apply a special

effect.

•

Frames

: apply a decorative frame.

•

Flash

: determine the use of the flash.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to photos

: go to the

Photos

folder.

•

Settings

: change the default settings for taking a

photo.

Size

: select an image size.

Quality

: select an image quality.

View finder

: select a preview screen.

Shutter sound

: select the sound that you hear

when you press the shutter release.

Zoom sound

: turn on or off the sound that you

hear when zooming in or out.

Brightness sound

: turn on or off the sound that

you hear when adjusting the image brightness.

Default name

: change the default prefix of file

names.

•

Camera short cuts

: view the functions of the

keys you can use in Capture mode.

Using the keypad in Capture mode

You can use the keypad to customise your camera

settings in Capture mode.

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Record mode.



p. 71

Changes the image size.

Changes the image quality.

Menu functions

Camera

(Menu 8)

Using photo options

After saving a photo, press <

Options

> to access the

following options:

•

Take another

: return to Capture mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the photo as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Multi shot delete all

: delete all of the multi-shot

photo.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to photos

: access the

Photos

folder.



p. 61

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Print via Bluetooth

: print the image via a

Bluetooth-compatible printer.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Recording a video

You can record a video of what is displayed on the

camera screen and save it.

1. In Capture mode, press [

2. Make any desired adjustments.

• Press < > to access camera options.



next section

• Use the keypad to change camera settings or

switch to other modes.



p. 73

Changes the camera mode.

Changes the colour tone or applies a

special effect.

Selects a decorative frame.

Sets the timer.

Determines the flash use.

Goes to the

Photos

folder.

Changes the preview screen.

Key Function

Menu functions

3. Press [

] or

[ ] to start recording.

4. Press <

> or

[ ] to stop recording. The video is

saved in the

Videos

folder.

Using camera options in Record mode

In Record mode, press < > to access the following

options:

•

Take a photo

: switch to Capture mode.

•

Effects

: change the colour tone or apply a special

effect.

•

Flash

: determine the use of the flash.

•

Timer

: set a time delay before the camera starts

recording.

•

Go to videos

: go to the

Videos

folder.

•

Settings

: change the following settings for

recording a video:

Recording mode

: select a video recording mode.

Limit of MMS

: record a video suitable for MMS

messages.

Limit of Email

: record a video suitable for

e-mails.

Normal

: record a video within the limit of the

currently available memory.

Size

: select a file size.

Quality

: select an image quality.

Audio rec.

: record audio with a video clip.

Zoom sound

: turn the sound effect for zooming

on or off.

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

Default name

: change the default prefix of file

names.

To Press

play back the video clip [ ].

use video options < >.



p. 73

delete the video clip [

] and then <

Yes

access the

Videos

folder [Up].



p. 62

return to Record mode < >.

Menu functions

Camera

(Menu 8)

•

Camcorder short cuts

: view the functions of the

keys you can use in Record mode.

Using the keypad in Record mode

You can use the keypad to customise your camera

settings in Record mode:

Using video options

After saving a video clip, press < > to access the

following options:

•

Record another

: return to Record mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to videos

: access the

Videos

folder.



p. 62

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Keys Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture mode.



p. 69

Changes the frame size.

Changes the image quality.

Changes the video recording mode.

Changes the colour tone or applies a

special effect.

Mutes or unmutes the audio.

Sets the timer.

Determines the flash use.

Goes to the

Videos

folder.

Keys Function

Menu functions

Settings

(Menu 9)

The

Settings

menu provides you with various setting

options to customise the phone to your preferences

and needs. You can also reset the settings to their

default status.

To access this menu, press <

> in Idle mode and

select

Settings

Time & Date

(Menu 9.1)

Use this menu to change the time and date displayed

on your phone. Before setting the time and date,

specify your time zone in

Home zone



p. 39

•

Time

: enter the current time.

•

Home zone

: set your local time zone and find out

what time it is in another part of the world.

•

AM/PM

: select

in 12-hour time format.

•

Time format

: select a time format.

•

Set date

: enter the current date.

•

Date format

: select a date format.

•

Week start day

: set which day of the week the

calendar starts with.

Phone settings

(Menu 9.2)

Many different features of your phone’s system can be

customised to suit your preferences.

Language

(Menu 9.2.1)

Use this menu to select one of several languages for

the display text.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed

briefly when the phone is switched on.

Slide settings

(Menu 9.2.3)

Use this menu to set how the phone reacts when you

open it for an incoming call, and when you close it

while using a function.

•

: set whether or not to answer a call by opening

the phone.

To apply daylight savings time to time zones,

select

Set daylight saving time

Menu functions

Settings

(Menu 9)

•

Down

: set whether or not the phone maintains

the menu you are using when you close the phone.

Short cut

(Menu 9.2.4)

You can use the Navigation keys as shortcuts to access

specific menus directly from Idle mode. Use this menu

to assign a shortcut to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut key.

2. Select the menu to be assigned to the key.

Using shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

Advanced shortcut

(Menu 9.2.5)

Use this menu to activate the Advanced shortcut

feature. You can quickly access the text message,

alarm, calendar, and converter applications from the

dialling screen.

Activating the Advanced shortcut feature

1. From the Advanced screen, select

2. Press <

Save

Changing an Advanced shortcut key

1. Select the key to be changed as a shortcut key.

2. Select the menu that will be assigned to the key.

Using Advanced shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

When you set

Down

Continue operation

the keypad lock works just in Idle mode.

Menu functions

Volume key

(Menu 9.2.6)

Use this menu to change the volume key settings.

•

Volume key function

: set whether the phone

mutes the call ringer or rejects a call if you press

and hold [ / ] when a call comes in. You can also

set whether the phone displays a message when

incoming calls are rejected.

•

Text message

: enter a message that will be

displayed when a call is rejected.

Extra settings

(Menu 9.2.7)

You can turn the automatic redialling or answering

feature on or off and activate the voice clarity feature.

•

Auto redial

: set the phone to make up to ten

attempts to redial a phone number after an

unsuccessful call.

•

Anykey

answer

: answer an incoming call by

pressing any key, except <

Reject

> and [ ].

When this option is not selected, you must press

> or [ ] to answer a call.

•

Voice clarity

: increase the microphone’s

sensitivity to allow the other person on the phone

to hear your voice clearly, even though you may be

whispering.

Display settings

(Menu 9.3)

Use this menu to change settings for the display and

light.

Wallpaper

(Menu 9.3.1)

You can change the background image that is

displayed in Idle mode.

Text display

(Menu 9.3.2)

You can change the display settings for the text

displayed on the idle screen.

•

Text position

: select a text position. If you don’t

want to display text in Idle mode, select

Off

•

Text style

: select a font style.

•

Text colour

: select a font colour.

Menu functions

Settings

(Menu 9)

Dialling display

(Menu 9.3.3)

Use this menu to select a font colour and size for the

numbers entered and the background colour of the

display while dialling.

Calendar

(Menu 9.3.4)

Use this menu to display the current calendar on the

idle screen.

Skin

(Menu 9.3.5)

Use this menu to select a skin colour for Menu mode.

LCD brightness

(Menu 9.3.6)

You can adjust the brightness of the display for

varying lighting conditions.

Show caller information

(Menu 9.3.7)

Use this menu to have a caller’s phone number, or

name if saved in Phonebook, shown on the main

display after you have missed a call.

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to select a volume and alert type for

incoming calls.

•

Alert type

: specify how you are to be informed of

incoming calls.

Melody

: the phone rings using the selected

ringtone.

Vibration

: the phone vibrates but not rings.

Vibration then melody

: the phone vibrates three

times and then starts ringing.

Melody then vibration

: the phone rings and then

vibrates.

•

Ring tone

: select a ringtone for the call ringer.

•

Volume

: select a ringer volume.

Menu functions

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone

sounds when you press a key.

Message tone

(Menu 9.4.3)

Use this menu to change the sound settings for

incoming SMS messages, MMS messages, e-mails

individually.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are to be informed

when a message comes in.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone

sounds when it is switched on or off.

Slide tone

(Menu 9.4.5)

Use this menu to select the tone that the phone

sounds when you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to set how the phone acts to alert you

to a specific event while in Quiet mode.

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones for the

phone.

•

Minute

minder

: set the phone to beep every

minute during an outgoing call to keep you

informed of the length of your call.

•

Connection

tone

: set the phone to beep when an

outgoing call connects to the system.

•

Alerts on call

: set the phone to beep when you

receive a new message or when the time for an

alarm comes during a call.

•

Indicative

tones

: set the phone to beep when a

pop-up windown displays.

You can adjust the keypad tone volume using

[/]

in Idle mode.

Menu functions

Settings

(Menu 9)

Light settings

(Menu 9.5)

Use this menu to change the settings for backlight.

Backlight

(Menu 9.5.1)

You can select the length of time the backlight or

display stays on.

•

: select the length of time the backlight stays

on.

•

Dim

: select the length of time the display stays on

in Dim mode after the backlight turns off. After a

specified time, the display turns off.

Keypad light

(Menu 9.5.2)

You can select the keypad backlight setting.

•

Use at any time

: flash the backlight when you

press any key.

•

Use at night time

: flash the backlight only

between 05:00 PM and 12:00 AM.

•

Use at custom time

: flash the backlight during

the period time you have specified.

Network services

(Menu 9.6)

Use this menu to access network services. Please

contact your service provider to check their availability

and subscribe to them, if you wish.

Call diverting

(Menu 9.6.1)

This network service reroutes incoming calls to a

phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on another

call.

•

: divert calls when you do not answer

the phone.

•

Unreachable

: divert calls when you are not in

an area covered by your service provider or

when your phone is switched off.

•

Cancel

all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. Select

Activate

. To deactivate call diverting, select

Deactivate

Menu functions

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be diverted.

6. If you selected

No reply

, move to the

Sec

line and

select the length of time the network delays before

diverting a call.

7. Press <

Select

Call barring

(Menu 9.6.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All

outgoing

: prohibit outgoing calls.

•

International

: prohibit international calls.

•

International

except

home

: only allow calls

to numbers within the current country when

you are abroad, and to your home country.

•

All

incoming

: prohibit incoming calls.

•

Incoming

while

abroad

: prohibit incoming

calls when you use your phone outside of your

home service area.

•

Cancel

all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call

barring password obtained from your service

provider.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call barring, select

Deactivate

4. Enter the call barring password supplied by your

service provider and press <

Select

Call waiting

(Menu 9.6.3)

This network service informs you when someone is

trying to reach you while you are on another call.

1. Select the type of calls to which call waiting option

will apply.

2. Select

Activate

and press <

Select

To deactivate call waiting, select

Deactivate

Network selection

(Menu 9.6.4)

This network service allows you to manually select the

network to be used while roaming outside of your

home area, or to let the network be chosen

automatically.

Menu functions

Settings

(Menu 9)

You can select a network other than your home

network only if there is a valid roaming agreement

between the two.

Caller ID

(Menu 9.6.5)

This network service allows you to prevent your phone

number from being displayed on the phone of the

person being called. If you select

Default

, the phone

will use the default setting provided by the network.

Voice mail server

(Menu 9.6.6)

Use this menu to store the number of the voicemail

server and access your voicemails.

•

Connect to voice mail

: connect to the voicemail

server to listen to your messages.

•

Voice server number

: enter the voicemail server

name and number.

Band selection

(Menu 9.6.7)

For the phone to make and receive phone calls, it

must register with an available network. Your phone

can handle any of the following types of networks:

GSM 1900, Combined GSM 900/1800, and Tri band

(GSM 900/1800/1900).

The country where you purchased your phone

determines the default band that it uses. When you

travel abroad, you may need to change to an

appropriate band.

Bluetooth

(Menu 9.7)

Using the Bluetooth feature, you can connect the

phone wirelessly to other Bluetooth devices and

exchange data with them, talk hands-free, or control

the phone remotely.

Bluetooth technology allows free wireless connections

between all Bluetooth-compliant devices within a

range of 10 meters. Since the devices communicate

using radio waves, they do not need to be in line of

sight to each other.

Some networks may not allow you to change this

setting.

You must enter the voice server number before you

can access your voicemails. Your service provider

can give the voice server number.

Menu functions

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following options:

•

Activation

: activate or deactivate the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices.

•

My phone’s visibility

: allow other Bluetooth

devices to search for your phone.

•

My phone’s name

: assign a Bluetooth device

name to your phone, which is then displayed on

other devices.

•

Secure mode

: determine if the phone asks for

your confirmation when other devices access your

data.

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth

device

1. From the Bluetooth setting options, select

devices

2. Select

Search new device

After searching, a list of devices to which you can

connect displays. The following icons indicate the

type of device:

The colour of the icon indicates the status of the

the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently connected to

your phone

3. Select a device.

• If there are obstacles between the devices, the

operating distance may be reduced.

• It is recommended that you don’t use the

Bluetooth feature while using multimedia

features,

such as voice recorder, camera, and MP3 player,

or vice versa, for better performance.

• Some devices may not be compatible with your

phone.

• Headset • Printer

• Computer • PDA

• Mobile phone • Unknown device

E370-2.fm Page 82 Tuesday, February 21, 2006 11:14 AM

Menu functions

Settings

(Menu 9)

4. Enter a Bluetooth PIN and press <

>. This code

is used just once and you don’t need to memorise

it.

When the owner of the other device enters the

same code, pairing is complete.

Using device options

From the device list, press <

Options

> to access the

following options:

•

Connect

: connect to a headset or hands-free car

kit.

•

Disconnect

: end the connection with the

connected device.

•

Browse files

: search for data from the device and

import data directly to your phone.

•

Service list

: access the Bluetooth service list of

the device.

•

Rename

: rename the paired device.

•

Authorize device/Unauthorize device

determine whether or not the phone asks you to

permit connection when other devices try to

connect to your phone.

•

Delete

: remove the selected device or all devices

from the list.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want

to send is stored.

3. Select the item you want

4. Press <

Options

> and select

Send

via

→

Bluetooth

5. Select

Search new device

The phone searches for devices within range and

displays a list of available devices.

6. Select a device.

7. If necessary, enter the Bluetooth PIN needed for

pairing and press <

Some devices, especially headsets or hands-free car

kits, may have a fixed Bluetooth PIN, such as

0000

If the other device has a code, you must enter it.

Menu functions

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth

feature must be active.

1. If an unauthorised Bluetooth device sends data to

your phone, press <

Yes

> to allow the device to

access your phone.

2. Press <

Yes

> to receive data.

Security

(Menu 9.8)

Use this menu to protect the phone against

unauthorised use by managing the several access

codes of your phone and SIM card.

PIN check

(Menu 9.8.1)

The 4- to 8-digit PIN (Personal Identification Number)

protects your SIM card against unauthorised use.

When this feature is enabled, the phone requires your

PIN each time it is switched on.

Change PIN

(Menu 9.8.2)

Use this menu to change your PIN. The PIN check

feature must be enabled to use this feature.

Phone lock

(Menu 9.8.3)

Use this menu to lock the phone from unauthorised

use. When this feature is enabled, you must enter a 4-

to 8-digit phone password each time the phone is

switched on.

The password is preset to

00000000

. To change the

password, use the

Change password

menu.

Change password

(Menu 9.8.4)

Use this menu to change your phone password.

If you enter an incorrect PIN/PIN2 three times in

succession, the SIM card is blocked. To unblock it,

you need to enter your PUK/PUK2 (Personal

Unblocking Key). The codes are supplied by your

network operator.

Privacy

(Menu 9.8.5)

Use this menu to lock access to messages, media files,

or all menu functions on the phone, except for call

functions. When a privacy option is enabled, you must

enter the phone password to access the locked items

or functions.

SIM lock

(Menu 9.8.6)

This menu allows your phone to work only with the

current SIM card by assigning a SIM lock code. You

must enter the SIM lock code to use a different SIM

card.

FDN mode

(Menu 9.8.7)

If supported by your SIM card, Fixed Dialling Number

(FDN) mode restricts your outgoing calls to a limited

set of phone numbers. When this feature is enabled,

you can make calls only to phone numbers stored on

the SIM card.

Change PIN2

(Menu 9.8.8)

If supported by your SIM card, use this menu to

change your current PIN2.

Memory status

(Menu 9.9)

Use this menu to check the amount of memory for

messages, media items, calendar items, contacts, and

Java applications. You can also check the shared

memory for MMS, Email, and File manager.

Reset settings

(Menu 9.0)

Use this menu to reset the phone settings, display

settings, and sound settings individually.

1. Press [ ] to select the setting categories to be

reset

2. Press <

Reset

3. Press <

Yes

> to confirm the reset.

4. Enter the phone password and press <

The password is preset to

00000000

. You can

change this password



p. 84

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service

call, perform the simple checks in this section before

contacting a service professional.

When you switch on your phone, the

following messages may appear:

“Insert SIM card”

• Be sure that the SIM card is correctly installed.

“Phone lock”

• The automatic locking function has been enabled.

You must enter the phone’s password before you

can use the phone.

“Enter PIN”

• You are using your phone for the first time. You

must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the

phone is switched on, the PIN has to be entered.

To disable this feature, use the

PIN check

menu.

“Enter PUK”

• The PIN has been entered incorrectly three times

in succession, and the SIM card is now blocked.

Enter the PUK supplied by your service provider.

“No Service,” “Network Failure,” or “Not

Done” displays

• The network connection has been lost. You may be

in a weak signal area. Move and try again.

• You are trying to access an option for which you

have no subscription with your service provider.

Contact the service provider for further details.

You have entered a number but it was not

dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right cellular

network.

• Be sure that you have not set an outgoing call

barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ]

pressed for more than one second.)

Solve problems

• Be sure that you are accessing the correct cellular

network.

• Be sure that you have not set an incoming call

barring option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone close

enough to your mouth. The microphone is located

at the bottom of the phone.

The phone starts beeping and “Battery low”

flashes on the display

• Your battery is insufficiently charged. Recharge the

battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display

( ). The number of bars indicates the signal

strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialled when you re-call a

Phonebook entry

• Use the Contact list feature to ensure the number

has been stored correctly.

• Re-store the number, if necessary.

The battery doesn’t charge properly or the

phone sometimes turns itself off

• Wipe the charging contacts both on the phone and

on the battery with a clean soft cloth.

If the above guidelines do not help you to

solve the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales

service.

Health and safety information

Exposure to Radio Frequency (RF) Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter and receiver.

It is designed and manufactured not to exceed the

exposure limits for radio frequency (RF) energy set by

the Federal Communications Commission (FCC) of the

U.S. government. These FCC exposure limits are

derived from the recommendations of two expert

organizations, the National Counsel on Radiation

Protection and Measurement (NCRP) and the Institute

of Electrical and Electronics Engineers (IEEE). In both

cases, the recommendations were developed by

scientific and engineering experts drawn from

industry, government, and academia after extensive

reviews of the scientific literature related to the

biological effects of RF energy.

The exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure

of the rate of absorption of RF energy by the human

body expressed in units of watts per kilogram (W/kg).

The FCC requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6 W/kg). The

FCC exposure limit incorporates a substantial margin

of safety to give additional protection to the public and

to account for any variations in measurements.

SAR tests are conducted using standard operating

positions accepted by the FCC with the phone

transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can be

well below the maximum value. This is because the

phone is designed to operate at multiple power levels

so as to use only the power required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output.

NorthAmerica_Cingular_T-mobile.fm Page 88 Wednesday, February 22, 2006 9:32 PM

Health and safety information

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that

it does not exceed the exposure limit established by

the FCC. Tests for each model phone are performed in

positions and locations (e.g. at the ear and worn on

the body) as required by the FCC.

The highest SAR values for this model phone as

reported to the FCC are Head: 0.300 W/Kg, Body-

worn: 0.914 W/Kg.

For body worn operation, this model phone has been

tested and meets the FCC RF exposure guidelines

whenused with a Samsung accessory designated for

this product or when used with an accessory that

contains no metal and that positions the handset a

minimum of 1.5 cm from the body.

Non-compliance with the above restrictions may result

in violation of FCC RF exposure guidelines.

SAR information on this and other model phones can

be viewed on-line at www.fcc.gov/oet/fccid. This site

uses the phone FCC ID number, A3LSGHE370.

Sometimes it may be necessary to remove the battery

pack to find the number. Once you have the FCC ID

number for a particular phone, follow the instructions

on the website and it should provide values for typical

or maximum SAR for a particular phone. Additional

product specific SAR information can also be obtained

at www.fcc.gov/cgb/sar.

NorthAmerica_Cingular_T-mobile.fm Page 89 Wednesday, February 22, 2006 9:32 PM

Health and safety information

Consumer Information on Wireless Phones

The U.S. Food and Drug Administration (FDA) has

published a series of Questions and Answers for

consumers relating to radio frequency (RF) exposure

from wireless phones. The FDA publication includes

the following information:

What kinds of phones are the subject of this

update?

The term wireless phone refers here to hand-held

wireless phones with built-in antennas, often called

“cell,” “mobile,” or “PCS” phones. These types of

wireless phones can expose the user to measurable

radio frequency energy (RF) because of the short

distance between the phone and the user's head.

These RF exposures are limited by Federal

Communications Commission safety guidelines that

were developed with the advice of FDA and other

federal health and safety agencies. When the phone is

located at greater distances from the user, the

exposure to RF is drastically lower because a person's

RF exposure decreases rapidly with increasing

distance from the source. The so-called “cordless

phones,” which have a base unit connected to the

telephone wiring in a house, typically operate at far

lower power levels, and thus produce RF exposures

well within the FCC's compliance limits.

Do wireless phones pose a health hazard?

The available scientific evidence does not show that

any health problems are associated with using

wireless phones. There is no proof, however, that

wireless phones are absolutely safe. Wireless phones

emit low levels of radio frequency energy (RF) in the

microwave range while being used. They also emit

very low levels of RF when in the stand-by mode.

Whereas high levels of RF can produce health effects

(by heating tissue), exposure to low level RF that does

not produce heating effects causes no known adverse

health effects. Many studies of low level RF exposures

have not found any biological effects. Some studies

have suggested that some biological effects may

occur, but such findings have not been confirmed by

additional research. In some cases, other researchers

have had difficulty in reproducing those studies, or in

determining the reasons for inconsistent results.

NorthAmerica_Cingular_T-mobile.fm Page 90 Wednesday, February 22, 2006 9:32 PM

Health and safety information

What is FDA's role concerning the safety of

wireless phones?

Under the law, FDA does not review the safety of

radiation-emitting consumer products such as wireless

phones before they can be sold, as it does with new

drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown

to emit radio frequency energy (RF) at a level that is

hazardous to the user. In such a case, FDA could

require the manufacturers of wireless phones to notify

users of the health hazard and to repair, replace or

recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA

regulatory actions, FDA has urged the wireless phone

industry to take a number of steps, including the

following:

• “Support needed research into possible biological

effects of RF of the type emitted by wireless

phones;

• “Design wireless phones in a way that minimizes

any RF exposure to the user that is not necessary

for device function; and

• “Cooperate in providing users of wireless phones

with the best possible information on possible

effects of wireless phone use on human health.

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at

the federal level. The following agencies belong to this

working group:

• “National Institute for Occupational Safety and

Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health Administration

• “National Telecommunications and Information

Administration

The National Institutes of Health participates in some

interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless

phones with the Federal Communications Commission

(FCC). All phones that are sold in the United States

must comply with FCC safety guidelines that limit RF

NorthAmerica_Cingular_T-mobile.fm Page 91 Wednesday, February 22, 2006 9:32 PM

Health and safety information

exposure. FCC relies on FDA and other health agencies

for safety questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from

these base stations are typically thousands of times

lower than those they can get from wireless phones.

Base stations are thus not the primary subject of the

safety questions discussed in this document.

What are the results of the research done

already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in

their research methods. Animal experiments

investigating the effects of radio frequency energy

(RF) exposures characteristic of wireless phones have

yielded conflicting results that often cannot be

repeated in other laboratories. A few animal studies,

however, have suggested that low levels of RF could

accelerate the development of cancer in laboratory

animals. However, many of the studies that showed

increased tumor development used animals that had

been genetically engineered or treated with cancer-

causing chemicals so as to be pre-disposed to develop

cancer in absence of RF exposure. Other studies

exposed the animals to RF for up to 22 hours per day.

These conditions are not similar to the conditions

under which people use wireless phones, so we don't

know with certainty what the results of such studies

mean for human health.

Three large epidemiology studies have been published

since December 2000. Between them, the studies

investigated any possible association between the use

of wireless phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors of the brain

or salivary gland, leukemia, or other cancers. None of

the studies demonstrated the existence of any harmful

health effects from wireless phones RF exposures.

However, none of the studies can answer questions

about long-term exposures, since the average period

of phone use in these studies was around three years.

NorthAmerica_Cingular_T-mobile.fm Page 92 Wednesday, February 22, 2006 9:32 PM

Health and safety information

What research is needed to decide whether RF

exposure from wireless phones poses a health

risk?

A combination of laboratory studies and

epidemiological studies of people actually using

wireless phones would provide some of the data that

are needed. Lifetime animal exposure studies could be

completed in a few years. However, very large

numbers of animals would be needed to provide

reliable proof of a cancer promoting effect if one

exists. Epidemiological studies can provide data that is

directly applicable to human populations, but ten or

more years' follow-up may be needed to provide

answers about some health effects, such as cancer.

This is because the interval between the time of

exposure to a cancer-causing agent and the time

tumors develop - if they do - may be many, many

years. The interpretation of epidemiological studies is

hampered by difficulties in measuring actual RF

exposure during day-to-day use of wireless phones.

Many factors affect this measurement, such as the

angle at which the phone is held, or which model of

phone is used.

What is FDA doing to find out more about the

possible health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology

Program and with groups of investigators around the

world to ensure that high priority animal studies are

conducted to address important questions about the

effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health

Organization international Electromagnetic Fields

(EMF) Project since its inception in 1996. An influential

result of this work has been the development of a

detailed agenda of research needs that has driven the

establishment of new research programs around the

world. The Project has also helped develop a series of

public information documents on EMF issues.

FDA and Cellular Telecommunications & Internet

Association (CTIA) have a formal Cooperative

Research and Development Agreement (CRADA) to do

research on wireless phone safety. FDA provides the

scientific oversight, obtaining input from experts in

government, industry, and academic organizations.

CTIA-funded research is conducted through contracts

NorthAmerica_Cingular_T-mobile.fm Page 93 Wednesday, February 22, 2006 9:32 PM

Health and safety information

to independent investigators. The initial research will

include both laboratory studies and studies of wireless

phone users. The CRADA will also include a broad

assessment of additional research needs in the

context of the latest research developments around

the world.

What steps can I take to reduce my exposure

to radio frequency energy from my wireless

phone?

If there is a risk from these products - and at this

point we do not know that there is - it is probably very

small. But if you are concerned about avoiding even

potential risks, you can take a few simple steps to

minimize your exposure to radio frequency energy

(RF). Since time is a key factor in how much exposure

a person receives, reducing the amount of time spent

using a wireless phone will reduce RF exposure.

• “If you must conduct extended conversations by

wireless phone every day, you could place more

distance between your body and the source of the

RF, since the exposure level drops off dramatically

with distance. For example, you could use a

headset and carry the wireless phone away from

your body or use a wireless phone connected to a

remote antenna.

Again, the scientific data do not demonstrate that

wireless phones are harmful. But if you are concerned

about the RF exposure from these products, you can

use measures like those described above to reduce

your RF exposure from wireless phone use.

What about children using wireless phones?

The scientific evidence does not show a danger to

users of wireless phones, including children and

teenagers. If you want to take steps to lower exposure

to radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing the time of

wireless phone use and increasing the distance

between the user and the RF source will reduce RF

exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at all. For

NorthAmerica_Cingular_T-mobile.fm Page 94 Wednesday, February 22, 2006 9:32 PM

Health and safety information

example, the government in the United Kingdom

distributed leaflets containing such a recommendation

in December 2000. They noted that no evidence exists

that using a wireless phone causes brain tumors or

other ill effects. Their recommendation to limit

wireless phone use by children was strictly

precautionary; it was not based on scientific evidence

that any health hazard exists.

Do hands-free kits for wireless phones reduce

risks from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free

kits can be used with wireless phones for convenience

and comfort. These systems reduce the absorption of

RF energy in the head because the phone, which is the

source of the RF emissions, will not be placed against

the head. On the other hand, if the phone is mounted

against the waist or other part of the body during use,

then that part of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are required to

meet safety requirements regardless of whether they

are used against the head or against the body. Either

configuration should result in compliance with the

safety limit.

Do wireless phone accessories that claim to

shield the head from RF radiation work?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that accessories that claim to shield the head

from those emissions reduce risks. Some products

that claim to shield the user from RF absorption use

special phone cases, while others involve nothing

more than a metallic accessory attached to the phone.

Studies have shown that these products generally do

not work as advertised. Unlike “hand-free” kits, these

so-called “shields” may interfere with proper operation

of the phone. The phone may be forced to boost its

power to compensate, leading to an increase in RF

absorption. In February 2002, the Federal trade

Commission (FTC) charged two companies that sold

devices that claimed to protect wireless phone users

from radiation with making false and unsubstantiated

NorthAmerica_Cingular_T-mobile.fm Page 95 Wednesday, February 22, 2006 9:32 PM

Health and safety information

claims. According to FTC, these defendants lacked a

reasonable basis to substantiate their claim.

What about wireless phone interference with

medical equipment?

Radio frequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason,

FDA helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted

cardiac pacemakers and defibrillators from wireless

telephones. This test method is now part of a standard

sponsored by the Association for the Advancement of

Medical instrumentation (AAMI). The final draft, a joint

effort by FDA, medical device manufacturers, and

many other groups, was completed in late 2000. This

standard will allow manufacturers to ensure that

cardiac pacemakers and defibrillators are safe from

wireless phone EMI. FDA has tested wireless phones

and helped develop a voluntary standard sponsored by

the Institute of Electrical and Electronic Engineers

(IEEE). This standard specifies test methods and

performance requirements for hearing aids and

wireless phones so that no interference occurs when a

person uses a compatible phone and a compatible

hearing aid at the same time. This standard was

approved by the IEEE in 2000.

FDA continues to monitor the use of wireless phones

for possible interactions with other medical devices.

Should harmful interference be found to occur, FDA

will conduct testing to assess the interference and

work to resolve the problem.

Additional information on the safety of RF exposures

from various sources can be obtained from the

following organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

• Occupational Safety and Health Administration's

(OSHA):

http://www.osha.gov/SLTC/

radiofrequencyradiation/index.html

NorthAmerica_Cingular_T-mobile.fm Page 96 Wednesday, February 22, 2006 9:32 PM

Health and safety information

• National institute for Occupational Safety and

Health (NIOSH):

http://www.cdc.gov/niosh/emfpg.html

• World health Organization (WHO):

http://www.who.int/peh-emf/

• International Commission on Non-Ionizing

Radiation Protection:

http://www.icnirp.de

• National Radiation Protection Board (UK):

http://www.nrpb.org.uk

• Updated 4/3/2002: US food and Drug

Administration

http://www.fda.gov/cellphones

Road Safety

Your wireless phone gives you the powerful ability to

communicate by voice, almost anywhere, anytime.

But an important responsibility accompanies the

benefits of wireless phones, one that every user must

uphold.

When driving a car, driving is your first responsibility.

When using your wireless phone behind the wheel of a

car, practice good common sense and remember the

following tips:

1. Get to know your wireless phone and its features,

such as speed dial and redial. If available, these

features help you to place your call without taking

your attention off the road.

2. When available, use a hands-free device. If

possible, add an additional layer of convenience

and safety to your wireless phone with one of the

many hands free accessories available today.

NorthAmerica_Cingular_T-mobile.fm Page 97 Wednesday, February 22, 2006 9:32 PM

Health and safety information

3. Position your wireless phone within easy reach. Be

able to access your wireless phone without

removing your eyes from the road. If you get an

incoming call at an inconvenient time, let your

voice mail answer it for you.

4. Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy

traffic or hazardous weather conditions. Rain,

sleet, snow, ice and even heavy traffic can be

hazardous.

5. Do not take notes or look up phone numbers while

driving. Jotting down a “to do” list or flipping

through your address book takes attention away

from your primary responsibility, driving safely.

6. Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before

pulling into traffic. Try to plan calls when your car

will be stationary. If you need to make a call while

moving, dial only a few numbers, check the road

and your mirrors, then continue.

7. Do not engage in stressful or emotional

conversations that may be distracting. Make

people you are talking with aware you are driving

and suspend conversations that have the potential

to divert your attention from the road.

8. Use your wireless phone to call for help. Dial 9-1-1

or other local emergency number in the case of

fire, traffic accident or medical emergencies.

Remember, it is a free call on your wireless phone!

9. Use your wireless phone to help others in

emergencies. If you see an auto accident, crime in

progress or other serious emergency where lives

are in danger, call 9-1-1 or other local emergency

number, as you would want others to do for you.

10. Call roadside assistance or a special non-

emergency wireless assistance number when

necessary. If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal, a

minor traffic accident where no one appears

injured, or a vehicle you know to be stolen, call

roadside assistance or other special non-

emergency number.

NorthAmerica_Cingular_T-mobile.fm Page 98 Wednesday, February 22, 2006 9:32 PM

Health and safety information

“The wireless industry reminds you to use your

phone safely when driving.”

For more information, please call 1-888-901-SAFE, or

visit our web-site www.wow-com.com

Provided by the Cellular Telecommunications &

Internet Association

Operating Environment

Remember to follow any special regulations in force in

any area and always switch your phone off whenever it

is forbidden to use it, or when it may cause

interference or danger. When connecting the phone or

any accessory to another device, read its user's guide

for detailed safety instructions. Do not connect

incompatible products.

As with other mobile radio transmitting equipment,

users are advised that for the satisfactory operation of

the equipment and for the safety of personnel, it is

recommended that the equipment should only be used

in the normal operating position (held to your ear with

the antenna pointing over your shoulder).

Using Your Phone Near Other Electronic

Devices

Most modern electronic equipment is shielded from

radio frequency (RF) signals. However, certain

electronic equipment may not be shielded against the

RF signals from your wireless phone. Consult the

manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a

minimum distance of 15 cm (6 inches) be maintained

between a wireless phone and a pacemaker to avoid

potential interference with the pacemaker.

These recommendations are consistent with the

independent research and recommendations of

Wireless Technology Research.

Persons with pacemakers:

• should always keep the phone more than 15 cm

(6 inches) from their pacemaker when the phone is

switched on.

• should not carry the phone in a breast pocket.

NorthAmerica_Cingular_T-mobile.fm Page 99 Wednesday, February 22, 2006 9:32 PM

100

Health and safety information

• should use the ear opposite the pacemaker to

minimize potential interference.

If you have any reason to suspect that interference is

taking place, switch your phone off immediately.

Hearing Aids

Some digital wireless phones may interfere with some

hearing aids. In the event of such interference, you

may wish to consult your hearing aid manufacturer to

discuss alternatives.

Other Medical Devices

If you use any other personal medical devices, consult

the manufacturer of your device to determine if it is

adequately shielded from external RF energy. Your

physician may be able to assist you in obtaining this

information. Switch your phone off in health care

facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities

may be using equipment that could be sensitive to

external RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles. Check with the manufacturer or its

representative regarding your vehicle. You should also

consult the manufacturer of any equipment that has

been added to your vehicle.

Posted Facilities

Switch your phone off in any facility where posted

notices require you to do so.

Potentially Explosive Environments

Switch your phone off when in any area with a

potentially explosive atmosphere and obey all signs

and instructions. Sparks in such areas could cause an

explosion or fire resulting in bodily injury or even

death.

Users are advised to switch the phone off while at a

refueling point (service station). Users are reminded of

the need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution

NorthAmerica_Cingular_T-mobile.fm Page 100 Wednesday, February 22, 2006 9:32 PM

101

areas), chemical plants or where blasting operations

are in progress.

Areas with a potentially explosive atmosphere are

often but not always clearly marked. They include

below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas (such

as propane or butane), areas where the air contains

chemicals or particles, such as grain, dust or metal

powders, and any other area where you would

normally be advised to turn off your vehicle engine.

Emergency Calls

This phone, like any wireless phone, operates using

radio signals, wireless and landline networks as well as

user programmed functions, which cannot guarantee

connection in all conditions. Therefore, you should

never rely solely on any wireless phone for essential

communications (medical emergencies, for example).

Remember, to make or receive any calls the phone

must be switched on and in a service area with

adequate signal strength. Emergency calls may not be

possible on all wireless phone networks or when

certain network services and/or phone features are in

use. Check with local service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present

location (for example, 911 or other official

emergency number). Emergency numbers vary by

location.

3. Press .

If certain features are in use (call barring, for

example), you may first need to deactivate those

features before you can make an emergency call.

Consult this document and your local cellular service

provider.

When making an emergency call, remember to give all

the necessary information as accurately as possible.

Remember that your phone may be the only means of

communication at the scene of an accident; do not cut

off the call until given permission to do so.

NorthAmerica_Cingular_T-mobile.fm Page 101 Wednesday, February 22, 2006 9:32 PM

102

Health and safety information

Restricting Children's access to your Phone

Your phone is not a toy. Children should not be allowed

to play with it because they could hurt themselves and

others, damage the phone or make calls that increase

your phone bill.

FCC Notice and Cautions

FCC Notice

The phone may cause TV or radio interference if used

in close proximity to receiving equipment. The FCC

can require you to stop using the phone if such

interference cannot be eliminated.

Vehicles using liquefied petroleum gas (such as

propane or butane) must comply with the National Fire

Protection Standard (NFPA-58). For a copy of this

standard, contact the National Fire Protection

Association, One Battery march Park, Quincy, MA

02269, Attn: Publication Sales Division.

Cautions

Changes or modifications made in the radio phone, not

expressly approved by Samsung, will void the user’s

authority to operate the equipment.

Only use approved batteries, antennas and chargers.

The use of any unauthorized accessories may be

dangerous and void the phone warranty if said

accessories cause damage or a defect to the phone.

Although your phone is quite sturdy, it is a complex

piece of equipment and can be broken. Avoid

dropping, hitting, bending or sitting on it.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

NorthAmerica_Cingular_T-mobile.fm Page 102 Wednesday, February 22, 2006 9:32 PM

103

Other Important Safety Information

• Only qualified personnel should service the phone

or install the phone in a vehicle. Faulty installation

or service may be dangerous and may invalidate

any warranty applicable to the device.

• Check regularly that all wireless phone equipment

in your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases or

explosive materials in the same compartment as

the phone, its parts or accessories.

• For vehicles equipped with an air bag, remember

that an air bag inflates with great force. Do not

place objects, including both installed or portable

wireless equipment in the area over the air bag or

in the air bag deployment area. If wireless

equipment is improperly installed and the air bag

inflates, serious injury could result.

• Switch your phone off before boarding an aircraft.

The use of wireless phone in aircraft is illegal and

may be dangerous to the aircraft's operation.

• Failure to observe these instructions may lead to

the suspension or denial of telephone services to

the offender, or legal action, or both.

Product Performance

Getting the Most Out of Your Signal Reception

The quality of each call you make or receive depends

on the signal strength in your area. Your phone

informs you of the current signal strength by

displaying a number of bars next to the signal strength

icon. The more bars displayed, the stronger the signal.

If you're inside a building, being near a window may

give you better reception.

Understanding the Power Save Feature

If your phone is unable to find a signal after 15

minutes of searching, a Power Save feature is

automatically activated. If your phone is active, it

periodically rechecks service availability or you can

check it yourself by pressing any key.

Anytime the Power Save feature is activated, a

message displays on the screen. When a signal is

found, your phone returns to standby mode.

NorthAmerica_Cingular_T-mobile.fm Page 103 Wednesday, February 22, 2006 9:32 PM

104

Health and safety information

Understanding How Your Phone Operates

Your phone is basically a radio transmitter and

receiver. When it's turned on, it receives and transmits

radio frequency (RF) signals. When you use your

phone, the system handling your call controls the

power level. This power can range from 0.006 watts to

0.2 watts in digital mode.

Maintaining Your Phone's Peak Performance

For the best care of your phone, only authorized

personnel should service your phone and accessories.

Faulty service may void the warranty.

There are several simple guidelines to operating your

phone properly and maintaining safe, satisfactory

service.

• Hold the phone with the antenna raised, fully-

extended and over your shoulder.

• Try not to hold, bend or twist the phone's antenna.

• Don't use the phone if the antenna is damaged.

• Speak directly into the phone's receiver.

• Avoid exposing your phone and accessories to rain

or liquid spills. If your phone does get wet,

immediately turn the power off and remove the

battery. If it is inoperable, call Customer Care for

service.

Availability of Various Features/Ring

Tones

Many services and features are network dependent

and may require additional subscription and/or usage

charges. Not all features are available for purchase or

use in all areas. Downloadable Ring Tones may be

available at an additional cost. Other conditions and

restrictions may apply. See your service provider for

additional information.

Battery Standby and Talk Time

Standby and talk times will vary depending on phone

usage patterns and conditions. Battery power

consumption depends on factors such as network

configuration, signal strength, operating temperature,

features selected, frequency of calls, and voice, data,

and other application usage patterns.

NorthAmerica_Cingular_T-mobile.fm Page 104 Wednesday, February 22, 2006 9:32 PM

Health and safety information

105

Battery Precautions

• Never use any charger or battery that is damaged

in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network's base

station, it uses less power; talk and standby time

are greatly affected by the signal strength on the

cellular network and the parameters set by the

network operator.

• Battery charging time depends on the remaining

battery charge and the type of battery and charger

used. The battery can be charged and discharged

hundreds of times, but it will gradually wear out.

When the operation time (talk time and standby

time) is noticeably shorter than normal, it is time

to buy a new battery.

• If left unused, a fully charged battery will

discharge itself over time.

• Use only Samsung-approved batteries and

recharge your battery only with Samsung-

approved chargers. When a charger is not in use,

disconnect it from the power source. Do not leave

the battery connected to a charger for more than a

week, since overcharging may shorten its life.

• Extreme temperatures will affect the charging

capacity of your battery: it may require cooling or

warming first.

• Do not leave the battery in hot or cold places, such

as in a car in summer or winter conditions, as you

will reduce the capacity and lifetime of the battery.

Always try to keep the battery at room

temperature. A phone with a hot or cold battery

may temporarily not work, even when the battery

is fully charged. Li-ion batteries are particularly

affected by temperatures below 0 °C (32 °F).

• Do not short-circuit the battery. Accidental short-

circuiting can occur when a metallic object (coin,

clip or pen) causes a direct connection between the

+ and - terminals of the battery (metal strips on

the battery), for example when you carry a spare

battery in a pocket or bag. Short-circuiting the

terminals may damage the battery or the object

causing the short-circuiting.

NorthAmerica_Cingular_T-mobile.fm Page 105 Wednesday, February 22, 2006 9:32 PM

106

Health and safety information

• Dispose of used batteries in accordance with local

regulations. In some areas, the disposal of

batteries in household or business trash may be

prohibited. For safe disposal options for Li-Ion

batteries, contact your nearest Samsung

authorized service center. Always recycle. Do not

dispose of batteries in a fire.

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for

many years.

• Keep the phone and all its parts and accessories

out of the reach of small children.

• Keep the phone dry. Precipitation, humidity and

liquids contain minerals that will corrode electronic

circuits.

• Do not use the phone with a wet hand. Doing so

may cause an electric shock to you or damage to

the phone.

• Do not use or store the phone in dusty, dirty areas,

as its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt

certain plastics.

• Do not store the phone in cold areas. When the

phone warms up to its normal operating

temperature, moisture can form inside the phone,

which may damage the phone's electronic circuit

boards.

• Do not drop, knock or shake the phone. Rough

handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents or

strong detergents to clean the phone. Wipe it with

a soft cloth slightly dampened in a mild soap-and-

water solution.

NorthAmerica_Cingular_T-mobile.fm Page 106 Wednesday, February 22, 2006 9:32 PM

Health and safety information

107

• Do not paint the phone. Paint can clog the device's

moving parts and prevent proper operation.

• Do not put the phone in or on heating devices,

such as a microwave oven, a stove or a radiator.

The phone may explode when overheated.

• When the phone or battery gets wet, the label

indicating water damage inside the phone changes

color. In this case, phone repairs are no longer

guaranteed by the manufacturer's warranty, even

if the warranty for your phone has not expired.

• If your phone has a flash or light, do not use it too

close to the eyes of people or animals. This may

cause damage to their eyes.

• Use only the supplied or an approved replacement

antenna. Unauthorized antennas or modified

accessories may damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger or any accessory is

not working properly, take it to your nearest

qualified service facility. The personnel there will

assist you, and if necessary, arrange for service.

NorthAmerica_Cingular_T-mobile.fm Page 107 Wednesday, February 22, 2006 9:32 PM

Index

ABC mode, text input • 23

Alarm • 40

Answering

call • 26

second call • 28

Anykey answer • 76

Auto redial • 76

Background image • 76

Backlight time, set • 77

Band selection • 81

Barring, calls • 80

Battery

charging • 7

low indicator • 8

precautions • 89

Bluetooth

receiving, data • 84

sending, data • 83

settings • 82

Broadcast messages • 60

Browser, web • 42

Calculator • 40

Calendar • 65

Call costs • 31

Call records

dialled • 30

missed • 30

received • 30

Caller group • 33

Caller ID • 81

Calls answering • 26

barring • 80

diverting • 79

holding • 27

making • 25

redialling • 25

rejecting • 26

transferring • 28

waiting • 80

Camera

photos • 69

videos • 71

CB (Cell Broadcast) messages •

Characters, enter • 23

Connection tone • 78

Converter • 41

Creating messages

e-mail • 47

MMS • 46

SMS • 45

Date, set • 74

Deleting

calendar item • 68

call records • 30

e-mail • 51, 53

MMS • 50, 51

Phonebook • 32, 35

SMS • 49, 51

Dialled calls • 30

Display

backlight, set • 79

brightness • 77

icons • 10

language • 74

layout • 10

settings • 76

Diverting, calls • 79

DTMF tones, send • 28

E-mails

creating/sending • 47

deleting • 53

setting • 57

viewing • 52

Emergency calls • 92

FDN (Fixed Dial Number) mode

• 85

File manager • 61

Games • 38

Greeting message • 74

Health and safety • 88

Holding, call • 27

Icons, description • 10

Images, downloaded • 61

108

Inbox, messages

e-mail • 52

SMS/MMS • 48

International calls • 25

Internet • 42

Keypad tones

sending/muting • 28

setting • 78

volume • 78

Language, select • 74

Last number, redial • 25

Locking

media contents • 85

menu functions • 85

phone • 84

SIM card • 85

Low battery indicator • 8

Memory status

downloaded items • 65

phone • 85

Phonebook • 35

Message tone • 78

Messages

e-mail • 47, 52

greeting • 74

MMS • 46, 49

SMS • 45, 49

Minute minder • 78

Missed alarm items • 68

Missed calls

call record • 30

caller ID, set • 77

MMS messages

creating/sending • 46

setting • 55

viewing • 48

Multiparty-call • 28

Music player • 35

Music, downloaded • 63

Name card • 34

Names

entering • 23

searching • 31

Network band, select • 81

Network selection • 80

Network services • 79

Outbox, messages • 51

Password

call barring • 80

phone • 84

Phonecare and maintenance •

display • 10

icons • 10

locking • 84

password • 84

resetting • 85

switching on/off • 8

unpacking • 6

Phonebook

adding • 32

copying • 32

deleting • 35

editing • 32

finding • 31

managing • 35

options • 32

speed-dialling • 34

Photos

taking • 69

viewing • 61

PIN, change • 84

PIN2, change • 85

Power on/off tone • 78

Privacy • 85

Problems, solve • 86

Received calls • 30

Received message

e-mail • 52

SMS/MMS • 48

Recording

videos • 71

voice memos • 37

Redialling

automatically • 76

manually • 25

Resetting phone • 85

Ringer

incoming calls • 77

messages • 78

Road safety • 90

109

Index

Roaming • 80

Safety

information • 88

precautions • 1

SDN (Service Dialling

Numbers) • 35

Security, calls • 84

Sent messages • 51

SIM card

inserting • 7

locking • 85

Slide tone • 78

SMS messages

creating/sending • 45

deleting • 49

setting • 54

viewing • 48

Sound settings • 77

Sounds, downloaded • 64

Speakerphone feature • 27

Speed-dial • 34

Stopwatch • 42

Switching on/off

microphone • 28

phone • 8

Text input mode, change • 23

Text, enter • 23

Time, set • 74

Timer • 41

Videos

recording • 71

Voice clarity • 28, 76

Voice memos

playing • 37

recording • 37

Waiting call • 80

Wallpaper • 76

Web browser

access • 42

cache, clear • 44

World time • 39

110

Index

Samsung Electronics Co SGHE370 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual

Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
