Samsung Electronics Co SGHE820N Single-Band PCS GSM Phone User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM Phone Users Manual
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.: GH68-05273A
English. 11/2004. Rev. 1.0
ELE
C
T
R
O
N
I
C
S
* Some of the contents in this manual may differ from your
phone, depending on the software installed or your
service provider.
GPRS TELEPHONE
SGH-E820P
23
Contents
Important safety precautions ...................... 7
Special features ........................................... 9
Unpacking .................................................. 13
Your phone ................................................ 14
Phone layout...................................................... 14
Display.............................................................. 17
Backlight ........................................................... 20
Service display................................................... 20
Camera............................................................. 20
Built-in antenna ................................................. 21
Getting started........................................... 22
Inserting/Removing the SIM card ......................... 22
Installing/Removing/Charging the battery.............. 23
Switching the phone on or off............................... 27
Selecting functions and options ............................ 28
Locking or unlocking the keypad........................... 30
Call functions ............................................. 31
Making a call...................................................... 31
Ending a call ...................................................... 34
Answering a call ................................................. 35
Rejecting a call................................................... 35
Adjusting the volume .......................................... 35
Accessing options during a call ............................. 36
Using the ear-microphone.................................... 45
Using the Push to talk service .............................. 46
Entering text .............................................. 48
Changing the text input mode .............................. 49
Using the T9 mode ............................................. 50
Using the ABC mode ........................................... 52
Using the symbolic mode..................................... 55
Using the number mode ...................................... 55
Using the menus ........................................ 56
Accessing a menu function................................... 56
Contents
4
List of menu functions ......................................... 57
Phonebook menu ....................................... 63
Find name ......................................................... 63
Add entry .......................................................... 66
Speed list ......................................................... 67
Copy all to phone ............................................... 69
Send all via infrared............................................ 70
Delete all........................................................... 72
Own number...................................................... 73
Group setting..................................................... 74
Memory status ................................................... 75
Service directory ................................................ 75
Push To Talk(PTT) ................................... 76
Login to service / Logout from PTT........................ 78
Callback inbox.................................................... 78
Contact list ........................................................ 79
Group list .......................................................... 80
Add group ......................................................... 81
Settings ............................................................ 84
PTT call records ................................................ 86
Call records ................................................ 90
Missed calls ....................................................... 90
Received calls .................................................... 90
Dialled calls ...................................................... 91
Delete all........................................................... 91
Call time ........................................................... 92
Call costs .......................................................... 92
Network services ....................................... 94
Call diverting ..................................................... 94
Call barring........................................................ 96
Call waiting........................................................ 99
Network selection ............................................. 100
Caller ID ......................................................... 101
Active line ....................................................... 101
Sound settings ......................................... 102
Incoming calls.................................................. 102
Messages ........................................................ 103
Contents
5
Push to talk .................................................... 104
Power on/off .................................................... 105
Connection tone ............................................... 105
Key tone ......................................................... 106
Minute minder.................................................. 106
Quiet mode...................................................... 106
Slider tone....................................................... 107
Alerts on call.................................................... 107
Messages ................................................. 108
Short messages ............................................... 108
Multimedia messages ........................................ 114
Push messages ................................................ 126
Preset messages .............................................. 127
Voice mail ....................................................... 127
Broadcast ........................................................ 128
Settings .......................................................... 130
Memory status ................................................ 133
Fun box .................................................... 134
WWW services ................................................. 134
Media box........................................................ 140
JAVA world ...................................................... 144
SIM-AT MENU (SIM Application Toolkit) ............... 148
Organiser ................................................. 149
New memo ...................................................... 149
Calendar ......................................................... 151
To do list......................................................... 154
Clock .............................................................. 155
Alarm ............................................................. 157
Calculator........................................................ 159
Conversion ...................................................... 160
Timer.............................................................. 161
Stopwatch ....................................................... 162
Camera .................................................... 163
Take photos..................................................... 163
My photos ....................................................... 169
My albums....................................................... 169
Delete all......................................................... 170
Settings ......................................................... 170
Memory status ................................................. 171
Contents
6
Phone settings ......................................... 172
Display............................................................ 172
Greeting message............................................. 174
Security .......................................................... 175
Auto redial....................................................... 178
Voiceclarity ..................................................... 178
Slide down operation ....................................... 179
Active slide ...................................................... 179
Anykey answer................................................. 179
Fax mode ........................................................ 180
Infrared activation ............................................ 180
Reset settings .................................................. 181
Using ALS (Alternate Line Service) .......... 182
Solving problems ..................................... 184
Access codes ............................................ 187
Phone password ............................................... 187
PIN................................................................. 187
PIN2 ............................................................... 188
PUK ................................................................ 188
PUK2 .............................................................. 188
Call barring password........................................ 189
Health and safety information.................. 190
SAR certification information .............................. 190
Precautions when using batteries........................ 194
Road safety ..................................................... 195
Operating environment ..................................... 198
Electronic devices............................................. 198
Potentially explosive atmospheres....................... 200
Emergency calls ............................................... 201
Other important safety information..................... 202
Care and maintenance ...................................... 203
Glossary................................................... 224
Index....................................................... 228
Quick reference card................................ 237
7
Important safety
precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching off in aircraft
Wireless phones can cause interference. Using them
in aircraft is both illegal and dangerous.
Switching off near all medical equipment
Switch off your phone near the medical equipment.
Hospitals or health care facilities may be using
equipment that could be sensitive to external RF
energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Water resistance
Your phone is not water-resistant. Keep it dry.
Important safety precautions
8
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on, especially the phone is in
service.
Emergency call
Key in the emergency number for your present
location, then press the key. Give all the
necessary information as accurately as possible. Do
not cut off the call until given permission to do so.
Keeping small children away from your phone
Keep the phone and all its parts including
accessories out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries.
Qualified service
Only qualified service personnel may install or
repair your phone.
For more detailed safety information, see “Health
and safety information” on page 190.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE
DISPOSE USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
9
Special features
Compact & Stylish slide-up design
Samsung E820 is an
amazing phone with a
refined slide design, which
fits comfortably in your
hand. The semi-automatic
slide allows you to open the
phone quietly, smoothly and
with very little effort.
VGA camera with flash (see page 163)
With the built-in VGA
Camera, the Samsung E820
allows you to shoot the
clearest of images, anytime,
anywhere. Take a close look
at another advanced
technology masterpiece
created by Samsung.
Speaker phone (see page 36)
The integrated speakerphone
incorporates a state-of-the-art
echo cancellation technology
and incorporates both noise
cancellation and voice clarity
functions to let you speak
more freely in the car. They'll
always be able to hear you
loud and clear.
Special features
10
Background noise sensitivity
You can talk in the midst of
a crowd and the phone will
automatically increase the
volume and clarity of the
incoming call to make it
more audible.
Even better than simply
raising the volume on your
phone, the E820 automatically senses the volume
around you to enhance your conversation and keep
you from having to run out of the room.
64 poly ringtones (see page 102)
64 Polyphonic ringtones
will make your calls ring
through with unmistakable
clarity and great sound to
boot. This best in the
market sound will make
the difference between you
and the rest all the more
audible.
Special features
11
Get personal with photo caller ID ( see
page 141,166
)
Now you can see who's calling
you by his or her very own
photo. With the image saved in
your phone, you can view the
image of the person calling you,
before you answer the call. The
Samsung E820’s Photo Caller
ID function provides you with
the convenience of using your picture files in ways
that are impossible with other mobile phones. Step
up to the latest and greatest in convenience with
the E820.
65,536 color TFT LCD
As usual, Samsung leads
the way in mobile display
quality. The display of the
E820 will astounded you
with its vivid colors and
distinctive class. With its
65,536 color TFT screen
the quality of the VGA pictures will come out in true
force. The screen of the display lets the message
come through in vivid life and lets you view your
multimedia messages in bright delight.
Special features
12
MMS (see page 114)
Just shoot it and send it
along with Samsungs
Multimedia solution,
MMS. Multimedia
Messaging Service was
developed from SMS and
makes it possible to send message with a
combination of text, voice, music, and images to
other MMS capable mobile phones. Make
multimedia communication your message to the
world as you discover a new way to tell your story.
JAVA (see page 144)
Make your free time more
relaxing with a bit of mobile
entertainment.
The Samsung E820s Java
TM
‚
based games bring the
challenges to you. Enjoy the
embedded games and download
new Java
TM
‚ based games for more amusement.
The Java
TM
‚ capabilities allow you to download
programs from wide variety of Java
TM
‚ applications -
more than just games.
13
Unpacking
Your package contains the following items:
In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer:
• Advanced handsfree car kit
• Simple handsfree car kit
• PC data link kit
•Headset
Note
: The items supplied with your phone and
available accessories may be different,
depending on your country or service provider.
Phone Travel a da pter
Battery Owner’s manual
14
Your phone
Phone layout
The following illustrations show the main elements
of your phone:
Earpiece
Display
Soft key (right)
WAP Browser
key
Alphanumeric
keys
Soft key (left)
Dial/Menu
confirmation key
Microphone
Cancel/Back/
Correction key
Navigation keys
(Up/Down/Left/
Right)
Volume keys
Ear-microphone
jack
Special
function keys
Power On/Off /
Menu exit key
IrDA port
Camera
PTT key
Flash
(Reverse side)
Mirror
Your phone
15
h
Key(s) Description
(soft keys)
Perform the functions indicated by the
text above them, on the bottom line of
the display.
In Menu Mode, scroll through the
menu options.
In Idle Mode, the Left key enters the
New SMS message writing
screen,
the Right key enters the
Incoming
call’s melody setting
menu and the
Down key enters the
PTT group list
menu. The Up key enters the
Camera
menu, when pressed and held it
switchs the phone to the capture
mode.
In Idle Mode, launches the WAP
(Wireless Application Protocol) browser
directly.
Makes or answers a call.
In Idle Mode, accesses the call log list.
In Menu Mode, selects a menu function
or stores information that you have
entered, such as a name in the phone
or SIM memory.
Deletes characters from the display.
When pressed and held in Idle Mode,
quickly accesses the
New memo
screen.
In Menu Mode, returns to previous
menu.
Your phone
16
Ends a call.
When pressed and held, switches the
phone on or off.
In Menu Mode, cancells your input and
returns to Idle Mode.
When pressed and held in Idle Mode,
quickly accesses your voice mail
server.
Enter numbers, letters and some
special characters.
Used for various purposes in different
functions.
When pressed and held while entering
a phone number, the key enters a
pause.
When pressed and held in Idle Mode,
the key enters or exits the Quiet
Mode.
(on the left side of the phone)
During a call, adjust the earpiece
volume.
In Idle Mode, adjust the key tone
volume.
In the capture mode, flip the picture
vertically by pressing the volume up
key and horizontally by pressing the
volume down key.
Key(s) Description
(continued)
Your phone
17
Display
Display layout
The display has three areas:
(on the right side of the phone)
Press the PTT key once and everyone
can hear you talk - release the key and
hear others talking back to you.
Area Description
First line Displays various icons. See
page 18.
Middle lines Display messages, instructions
and any information that you
enter, such as number to be
dialled.
Last line Shows the functions currently
assigned to the two soft keys.
Key(s) Description
(continued)
Menu Phonebook
Icons
Tex t and
graphic area
Soft keys
Indications
Your phone
18
Icons
Icon Description
Shows the received signal strength. The
more the number of bars, the stronger
the signal.
Appears when a call is in progress.
Appears when you are out of a service
area. When it displays, you cannot make
or receive calls.
Appears when you have new or
unchecked voice messages. When your
SIM card supports ALS (Alternate Line
Service), this icon may appears like ,
, .
Appears when you have new or unread
messages.
Appears when you have new or
unchecked multimedia messages.
Appears when you are retrieving a
multimedia message.
Appears when you are sending a
multimedia message.
Appears when you set the alarms to ring
at a specified time.
Appears when the IrDA port is active. For
details, see page 180.
Appears when you connect the phone to
the computer by the IrDA port.
Your phone
19
Appears when you are connected to the
GPRS network.
Appears when the PTT service is available.
Appears when trying to login to the PTT
service.
Appears when the PTT service is unable to
use temporarily.
Appears when your SIM card supports the
Call diverting status indication and the
Call diverting feature is activated. When
your SIM card supports ALS (Alternate
Line Service), this icon may appears with
the number 1, 2, or both. For example:
, , .
Appears when you are at the home zone.
(
May be shown only if your service provider
supports this feature)
Appears when you are at the office zone.
(
May be shown only if your service provider
supports this feature)
Appears when you set the alert type for
incoming calls to
Vibration
or
Vibration
then melody
. For further details, see
page 103.
Appears when the Quiet Mode is active.
Shows the level of your battery. The more
bars you see, the more power you have
left.
Icon Description
(continued)
Your phone
20
Backlight
The display and the keypad are illuminated by a
backlight. When you press any key, the backlight
illuminates. It turns off if you don’t press any key
within a given period of time, depending on the
Backlight
menu option. For further details, see
page 173.
Service display
The service display works when the LCD turns off
and you are in a service area
.
The service light’s
activity depends on the
Service display
menu
option. See page 173.
Camera
The camera embedded in your phone allows you to
take a picture of people or events while on the
move.
For further details about using the Camera feature,
see page 163.
(Reverse side)
Your phone
21
Built-in antenna
Your phone has a built-in antenna. As with other
mobile radio transmitting equipment, do not touch
the antenna unnecessarily when the phone is
switched on. Contact with the antenna affects call
quality and may cause the phone to operate at a
higher power level than needed.
22
Getting started
Inserting/Removing the SIM card
When you subscribe to a cellular network, you are
provided with a SIM card loaded with your
subscription details, such as your PIN, any optional
services available and so on.
• Keep all miniature SIM cards out of the reach of
small children.
• The SIM card and its data can be easily damaged
by scratches or bending, so be careful when
handling, inserting or removing the card.
• When installing the SIM card, always make sure
that the phone is switched off before you remove
the battery.
Inserting the SIM card
1. If necessary, remove the battery by referring to
page 24.
2. Insert and slide the SIM card under the tab,
ensuring that the notched corner is top left and
the gold contacts of the card face into the
phone.
Getting started
23
Removing the SIM card
To remove the SIM card, slide the card out of the
holder, as shown.
Installing/Removing/Charging the
battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and chargers.
Ask your local Samsung dealer for further details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
standard battery is fully recharged in
approximately 150 minutes.
Installing the battery
1. Insert the teeth on the bottom of the battery
into the corresponding slots on the phone..
Getting started
24
2. Press the battery against the back of the phone
until it clicks into place.
Removing the battery
1. Switch off the phone by pressing and holding the
key.
2. To remove the battery, pull the battery catch
toward the top of the phone and hold it in that
position. Lift the battery away from the phone.
Getting started
25
Charging the battery by using the travel
adapter
Note
: The phone can be used while the battery is
being charged, but this causes the battery to
charge more slowly.
1. Plug the connector of the travel adapter into the
jack at the bottom of the phone.
Check that the arrow on the connector is facing
towards the front of the phone.
2. Plug the adapter into a standard AC wall outlet.
While charging, the battery icon at the top right-
hand corner of the display repeatedly fills to
show that the battery is charging.
Getting started
26
3. When charging is finished, disconnect the
adapter from the power outlet and from the
phone by pressing the grey tabs on both sides of
the connector and pulling the connector out.
Low Battery Indicator
When the battery is weak and only a few minutes of
talk time remain, the battery sensor informs you in
the following ways: an empty battery icon flashes
( ), you hear a warning tone and a message
repeats at regular intervals on the display.
When the battery becomes too weak for the phone
to operate, it switches off automatically.
Getting started
27
Switching the phone on or off
To switch the phone on:
1. Hold down the key until the phone
switches on.
2. If the phone asks for a PIN, enter the PIN and
press the
Ok
soft key. For further details, see
page 187.
The phone searches for your network and the
current date and time appear on the display.
After finding it, you can make or receive a call.
To switch the phone off:
Hold down the key until the power-off
animation displays.
Menu Phonebook
Service Provider
Tue 1 Jun 04
12:53
Getting started
28
Selecting functions and options
Your phone offers a set of functions that allow you
to customise your phone. These functions are
arranged in menus and sub-menus, accessed via
the two soft keys marked and Each menu
and sub-menu allows you to view and alter the
settings of a particular function.
The roles of the soft keys vary according to the
current context; the labels or icons on the bottom
line of the display and just above the soft keys
indicate their current roles.
Example:
Menu Phonebook
Service Provider
Tue 1 Jun 04
12:53
Press the left soft
key to access the
menu functions.
Press the right soft
key to access the
Phonebook feature.
Getting started
29
To view various functions/options available or select
the one is required:
1. Press the appropriate soft key.
In some functions, you may be asked for a
password or PIN. Enter the required code and press
the
Ok
soft key.
2.
To Press the
select the:
• function displayed
• option highlighted
Select
soft key.
view the next function or
highlight the next option
on a list
Down key.
move back to the
previous function or
option on a list
Up key.
move back up one level
in the structure
(or
Back
) soft
key or
C
key.
return to Idle Mode key.
Getting started
30
Locking or unlocking the keypad
You can lock the soft keys, navigation keys, WAP
brower key, volume keys and camera key to avoid
pressing keys by accident.
To lock the keys, slide the folder down.
If you set the
Stop operation
option in the
Slide
down operation
menu (see page 179), the phone
locks the keys automatically when you slide the
folder down.
Otherwise, if you set the
Continue
operation
option in the
Slide down operation
menu (see
page 179), the confirming message appears on the
display when you slide the folder down in the Idle
Mode. In the message, you can lock the keys by
pressing the
Yes
soft key. If you don't press the
Yes
or
NO
soft keys in the confirming message, the
phone locks the keys after a little while.
To unlock the keys, slide the folder up or press the
Unlock
soft key and then press the
OK
soft key
again.
31
Call functions
Making a call
Using the number keypad
When the idle screen is displayed, enter the area
code and phone number, and press the key.
Note:
If you have set the
Auto redial
option to
On
,
the number is redialled automatically up to ten
times if the person you called does not answer
or the line is busy. For further details, see
page 178.
Correcting the number
To clear Press the
the last digit
displayed
C
key.
any other digit in
the number
Navigation keys until the
cursor (|) is immediately to
the right of the digit to be
cleared and press the
C
key.
You can also insert a missing
digit simply by pressing the
appropriate key.
the all digits
displayed
C
key and hold it down for
more than one second.
Call functions
32
Making an international call
1. Press and hold the
0
key for the international
prefix. The + character appears.
2. Enter the country code, area code and phone
number and press the key.
Making a call from phonebook
You can store the names and phone numbers called
regularly in the SIM card and phone’s memory,
which are jointly called the Phonebook. You then do
not need to remember all your numbers; simply
select the required name to recall the associated
number.
For further details about the Phonebook feature,
see page 63.
Using the call logs
The phone stores up to 20 calls dialled, received or
missed chronologically. The last call is saved in the
first position. If the same number occurs more than
once, only the latest occurrence is saved.
To recall any of these numbers:
1. Press the key in Idle Mode to access the Call
log list.
2. Use the Up and Down keys to scroll through the
list until the number you want highlights.
The call logs are listed with the following icons:
• : Dialled calls
• : Received calls
• : Missed calls
Call functions
33
3. To dial the number, press the key.
To view each call record, see “Call records” on
page 90.
Using the PTT call logs
The phone stores up to 20 PTT calls dialled,
received or missed chronologically. The last PTT call
is saved in the first position. If the same PTT call
occurs more than once, only the latest occurrence is
saved.
To make a one-to-one call any of these records:
1. Press the key in Idle Mode to access the Call
log list.
2. Use the Up and Down keys to scroll through the
list until the PTT call record you want highlights.
The PTT call logs are listed with the following
icons:
• : PTT Dialled calls
• : PTT Received calls
• : PTT Missed calls
3. To make a one-to-one call, press the PTT key.
To view each PTT call record, see “PTT call records”
on page 86.
Viewing missed calls
If you have a subscription that includes the Caller
Line Identification (CLI) feature and you are unable
to answer a call for any reason, you can find out
who was calling you so that you can call the person
back.
Call functions
34
The number of missed calls displays on the idle
screen immediately after a call was missed.
To view the missed calls immediately:
1. Press the
Missed
soft key.
The list of the missed calls displays.
2. If necessary, scroll to the number you want by
pressing the Up or Down key.
3. To dial the number, press the key.
To use the missed call options, see “Missed calls” on
page 90.
Note
: To clear the missed call notification on the
display, press the key. When you also
have voice mails, short messages or
multimedia messages and multi CBs, the right
soft key indication changes in the following
order:
Missed
,
Connect
,
View
,
CB
and
Phonebook
.
Speed-dialling from Phonebook
Once you have stored numbers in the Phonebook,
you can dial a number simply by pressing one or
two keys. For further details, see page 67.
Ending a call
When you want to finish your call, briefly press the
key. Or, slide the folder down if you set the
Stop operation
option in the
Slide down
operation
menu (see page 179).
Call functions
35
Answering a call
When somebody calls you, the phone rings and
displays the incoming call animation.
If the caller can be identified, the caller’s phone
number, or name if stored in your Phonebook,
displays.
To answer a call, press the key or
Accept
soft
key. Or, slide the folder up when the
Active slide
option is set to on.
Note
: You can answer a call while using the
Phonebook or menu features. The current
operation stops.
Rejecting a call
To reject an incoming call, press the key. Or,
slide the folder down if you set the
Stop operation
option in the
Slide down operation
menu (see
page 179).
Adjusting the volume
During a call, if you wish to adjust the earpiece
volume, use the volume keys on the left side of the
phone.
When you hear a sound, such as ringtone, you can
also adjust the earpiece volume. But it is not fixed.
Note
: When a call comes in, you can mute the call
ringer by pressing and holding one of the
volume keys.
Call functions
36
Accessing options during a call
Your phone provides a number of control functions
that you can use during a call.
Using the loudspeaker
You can speak and listen to the phone from a short
distance without holding the phone to your ear.
Turn on / off the loudspeaker
1. Press the
Options
soft key.
2. Press the Up or Down key to highlight the
Speaker on
(turn on the loudspeaker)/
Normal
(turn off the loudspeaker) option. Press the
Select
soft key.
CAUTIONS
: Do not hold the phone near to your
ear when you use the loudspeaker. Because the
volume may be extremely loud.
Note
: You can turn on/off the loudspeaker by
pressing the
Right
soft key during a call.
Switching the microphone off (Mute)
You can temporarily switch your phone’s
microphone off so that the other person cannot
hear you.
Example: You may wish to say something to
another person in the room but do not
want the calling person to hear you.
1. Press the
Options
soft key.
Call functions
37
2. When
Mute
highlights, press the
Select
soft
key.
The Mute icon ( ) appears on the bottom line
of the display and your correspondent can no
longer hear you.
To switch the microphone back on:
1. Press the
Options
soft key.
2. When
Unmute
highlights, press the
Select
soft
key.
The Mute icon disappears and your
correspondent can hear you.
Searching for a number in Phonebook
You can search for a number in your Phonebook
during a call.
1. Press the
Options
soft key.
2. If necessary, press the Up or Down key to
highlight the
Phonebook
option. Press the
Select
soft key.
3. Select the
Find name
option and press the
Select
soft key.
The Phonebook entries are listed.
4. Enter the first a few letters of the name that you
want to find.
The Phonebook entries are listed starting with
the first entry matching your input.
Note
: You can also scroll through the Phonebook
from the beginning, by pressing
the Up or
Down key
.
Call functions
38
5. To view the highlighted entry, press the
Ok
soft
key.
For further details about the Phonebook feature,
see page 63.
Muting/Sending key tones
You can turn the key tones off or on during a call.
When the
Mute keys
option is selected, your phone
does not transmit the key tones. It allows you to
press keys without hearing annoying key tones
during a call.
To communicate with answering machines or
computerised telephone systems, the
Send keys
option must be selected.
Sending DTMF tones
You can send the DTMF(Dual Tone Multi-Frequency)
tones of the number on the display during a call.
This option is helpful for entering a password or
account number when you call an automated
system, like a banking service.
To send the DTMF tones:
1. When you are connected to the teleservice
system, press the
Options
soft key.
2. Press the Up or Down key to highlight the
Send
DTMF
option. Press the
Select
soft key.
3. Enter the number you want to send and press
the
OK
soft key.
The tones of the displayed number are sent.
Call functions
39
Using the message service
You can read or write a new message during a call.
1. Press the
Options
soft key.
2. Press the Up or Down key to highlight the
Message
option. Press the
Select
soft key.
3. To read a received message, select the
Inbox
option, and then scroll to the message that you
want to read.
To write a new message, select the
Create
option.
4. Press the
Select
soft key.
For further details about the SMS feature, see
page 108.
Using the voiceclarity
The voiceclarity function maintains the background
noise to acceptable level. You can hear the other
party louder and clearer thus it is a desired feature
especially in a noisy environment.
You can manually turn on the voiceclarity feature
while engaged in a call.
Using the voiceclarity function
1. Press the
Options
soft key.
2. Press the Up or Down key to highlight the
Voiceclarity on / Voiceclarity off
option.
Press the
Select
soft key.
Note
: You cannot activate the voiceclarity when you
use the loudspeaker and the handsfree car kit.
Call functions
40
Using the SAT (SIM Application Toolkit)
If you use a SAT card that provides additional
services, the SAT menu displays. For further details,
see your SIM card instructions.
Putting a call on hold
You can place the current call on hold whenever you
want. You can make another call while you have a
call in progress if this service is supported by the
network. Of these two calls, one is active and the
other is on hold and you can switch between the
calls.
Note
: You can not turn on/off the loudspeaker or
voiceclarity features when you hold a call.
To place a call on hold,
1. Press the
Options
soft key.
2. Press the Up or Down key to highlight the
Hold
option.
If you want to reactivate the call, press the
Retrieve
soft key.
To make a call while you have a call in progress:
1. Enter the phone number that you want to dial or
look it up in the Phonebook.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Or alternatively:
1. Press the
Options
soft key.
2. Put the current call on hold by selecting the
Hold
option.
Call functions
41
3. Make the second call in the normal way.
To switch between the two calls, press the
Options
soft key and then select the
Swap
option.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with the other person.
To end the call on hold, press the
Options
soft key
and select the
End held call
option.
When you want to finish, end each call normally by
pressing the key. If you want to finish all calls
at once and you set the
Stop operation
option in
the
Slide down operation
menu (see page 179),
slide the folder down.
Answering a second call
You can answer an incoming call while you have a
call in progress, if this service is supported by the
network and you have activated the
Call waiting
option (see page 99). You will be notified of an
incoming call by a call waiting tone.
To answer a call while you have another call in
progress:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
2. To switch between the two calls, press the
Options
soft key and then select the
Swap
option.
3. To end the call on hold, press the
Options
soft
key and select the
End held call
option.
To end the current call, press the key.
The call on hold is continued.
Call functions
42
Transferring a call
You can transfer the current call to the call on hold
if this service is supported by the network, so that
the callers can talk to each other. You are
disconnected from both of them.
1. During a call, answer or make a call in the
normal way, and press the
Options
soft key.
2. Press the Up or Down key to select the
Transfer
option and press the
Select
soft key.
The two people are connected to each other.
Making a multi-party call
A multi-party call feature is a network service that
allows up to six people to take part simultaneously
in a multi-party or conference call. For more
information, contact your service provider.
Setting up the multi-party call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multi-party
call, press the
Options
soft key and select the
Join
option. Press the
Select
soft key.
4. To add a new person to the multi-party call, call
the person in the normal way. Then press the
Options
soft key and select the
Join
option.
Press the
Select
soft key.
You can add incoming callers by answering the call
and selecting the
Join
option. Repeat as needed.
Call functions
43
Having a second call during a multi-party call
To answer a call when you have the multi-party call:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
2. To switch between the two calls, press the
Options
soft key and then select the
Swap
option.
3. To end the call on hold, press the
Options
soft
key and select the
End held multiparty
option
or
End held call
option.
To end the current call, press the key.
The call on hold is continued.
To make a call when you have the multi-party call:
See “To make a call while you have a call in
progress:” on page 40.
To answer an incoming call when you have the
multi-party call in progress and another call on
hold:
1. Press the
Accept
soft key.
2. Select the
End held
option to end the call on
hold.
Or, select the
End current
option to end the call
in progress.
And then you can answer the new call.
Call functions
44
Having a private conversation with one
participant
1. Press the
Options
soft key and select the
Split
option. Press the
Select
soft key.
2. Press the Up or Down key to highlight a
participant and press the
Select
soft key.
Now you can talk privately with that person. The
other participants can continue to converse with
each other
3. To return to the multi-party call, press the
Options
soft key and select the
Join
option.
4. Press the
Select
soft key.
All of the multi-party call participants can now
hear each other.
Removing one participant
1. Press the
Options
soft key and select the
Remove
option.
2. Press the Up or Down key to highlight a
participant and press the
Select
soft key.
The call ends with that participant, but you can
continue to talk with the other participants.
3. End the multi-party call by pressing the
key.
Call functions
45
Using the ear-microphone
With the ear-microphone, you can make or answer
a call without holding the phone.
When you connect the ear-microphone to the jack
at the right side of the phone, the button on the
ear-microphone works as listed below:
To Press
redial the last call the button twice in Idle Mode.
answer a call and hold the button when you
receive the call.
end a call and hold the button when you
have finished the call.
Call functions
46
Using the Push to talk service
You can make and receive a Push to talk call. For
further details about using the Push to talk feature,
see page 76.
Making a Push to talk call
You can make a one-to-one call or group call using
the Push to talk service.
Note
: You first need to add PTT addresses to your
Phonebook.
To ma ke a one- to-o ne ca l l:
1. Connect to the Push to talk service by selecting
the
Login to service
menu.
For further details about connecting to the Push
to talk service, see page 78.
2. Access the
Contact list
menu and scroll to a
contact using the Up or Down key.
You are connected with the selected person, if
he/she logged into the service.
3. When the contact you want highlights, press the
PTT key.
To ma ke a grou p cal l:
1. Connect to the Push to talk service.
For further details about connecting to the Push
to talk service, see page 78.
2. Access the
Group list
menu (
Menu 5.4
) and
scroll to a group using the Up or Down key.
Call functions
47
3. When the group you want highlights, press the
PTT key.
You are connected with all of the members of
the selected group, if they logged into the
service.
You can also make a call to the default group by
pressing the PTT key while connected to the Push to
talk service.
Receiving a Push to talk call
You can receive a one-to-one call or group call using
the Push to talk service.
When you receive a one-to-one call or group call, a
short tone and vibration notifies you of the call.
For a one-to-one call, the phone displays
information about the sender, if stored in the
Contact list. If you set the
1 to 1 call
menu to
Notify
(see page 85), the phone asks you to
receive the call. Press the
Accept
soft key to
receive the call.
For a group call, the phone displays the group name
and the nickname of the caller. If you press the PTT
key to try to respond to a group while another
member is talking, you hear a tone and “Queueing”
is displayed on your phone. Press and hold the
button, and wait for the other person to finish. Then
you can talk.
Note
: When you receive PTT calls in Quiet mode,
alerts for PTT calls do not sound.
48
Entering text
At many times while you are using your phone, you
need to enter text, such as when storing a name in
the Phonebook, writing a new message, creating
your personal greeting or scheduling events on your
calendar.
You are provided with the following text input
modes:
•
T9 mode
*
This mode allows you to enter words with only
one keystroke per letter. Each key on the keypad
has more than one letter – when you press the
5
key once, J, K or L may be displayed. The T9
mode automatically compares your keystrokes
with an internal linguistic dictionary to determine
the correct word, thus requiring far fewer
keystrokes than the traditional ABC mode.
•
ABC mode
This mode allows you to enter letters by pressing
the key labelled with the required letter once,
twice, three or four times until the letter displays.
•
Number mode
This mode allows you to enter numbers.
•
Symbolic mode
This mode allows you to enter special characters.
*
is a registered trademark of Tegic Communications,
Inc. and is licensed under U.S. Patent 5,818,437/
5,953,541/ 6,011,554.
Entering text
49
Changing the text input mode
When you are in a field that allows characters to be
entered, you will see the text input mode indicator
at the bottom of the display.
Example: Entering a name in the Phonebook
To change to another text input mode:
1. Press the right soft key indicating the current
text input mode.
2. Scroll to the mode you want to use by pressing
the Up or Down key.
You can use the
Add word
option to add new
words into the T9 dictionary. See page 51.
Note
: If you want to exit the menu without
changing the mode, press the soft key or
key.
3. Press the
Select
soft key to confirm the
highlighted text input mode.
Enter name
Ok 16 Eng
Text input mode indicator:
T9 English mode
Entering text
50
Quickly changing the text input mode
Using the T9 mode
To type a word in the T9 mode:
1. Start entering the word by pressing keys
2
to
9
.
Press each key only once for each letter.
Example: To enter “hello” in the T9 mode, press
the
4
,
3
,
5
,
5
, and
6
keys.
The word you are typing appears on the display.
It may change with each key that you press.
2. Enter the whole word before editing or deleting
any keystrokes.
3. If the word is correct, start entering the next
word. Otherwise, press the
0
key repeatedly to
display alternative word choices for the keys
that you have pressed.
Example: Both “of” and “me” have the sequence
of
6
and
3
. The phone displays the
most commonly used choice first.
4. Insert a space between words by pressing the
key.
5. Continue entering the next word.
To switch between the Press and hold the
Number and previous mode key.
Symbol and previous mode key.
ABC and T9 mode right soft key.
Entering text
51
If
Spell
appears above the left soft key while you
are entering text, the word does not exist in the T9
dictionary. To type words not found in the T9 mode,
change the text input mode to the ABC mode, or
proceed as follows:
1. Press the
Spell
soft key, or press the right soft
key and select the
Add word
option.
2. Enter the word you want to add using the ABC
mode (see page 52) and press the
Ok
soft key.
The word is saved in the T9 dictionary and
inserted in the input field.
3. Continue entering other words in the T9 mode.
Smart punctuation
To enter periods, hyphens or apostrophes, press the
1
key. The T9 mode applies rules of grammar to
insert the correct punctuation.
Example: The
1
key is used twice to display two
punctuation marks.
Changing the case
To change the case of the next letter(s) that you
type, press the key. There are three cases:
• Lower Case (no indicator)
• Initial Capital ( )
•Capital Lock ( )
l e t ‘ s e a t .
Entering text
52
Inserting a space
To insert a space between words, press the key.
Entering a number directly
To enter a number, press and hold the number key.
Scrolling
To move the cursor to the left, right, up or down
within the text, press the navigation keys.
Clearing letters and words
To clear the letter to the left of the cursor, press the
C
key. You can clear all of the letters on the display
by pressing and holding the
C
key.
Returning to the previous screen
When the text input field is cleared, press and hold
the
C
key to return to the previous screen.
Using the ABC mode
When typing in the ABC mode, press the key
labelled with the required letter:
- Once for the first letter
- Twice for the second letter
- And so on
Example: To display the letter “C”, quickly press the
2
key three times. To display the letter
“K”, press the
5
key twice. This method is
called Multi-tap typing.
Entering text
53
Note
: The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
press the Right key or wait a few seconds for
the cursor to move to the right automatically,
and then enter the next letter.
Refer to the table for more information about the
characters available.
List of the characters available
(Capital Lock mode in English
)
Key characters in the order displayed
1 . , - ? ! ‘ @ : 1
2 A B C 2
3 D E F 3
4 G H I 4
5 J K L 5
6 M N O 6
7 P Q R S 7
8 T U V 8
9 W X Y Z 9
00
Entering text
54
Changing the case
To change the case of the next letter(s) that you
type, press the key. There are three cases:
• Lower Case (no indicator)
• Initial Capital ( )
• Capital Lock ( )
Inserting a space
To insert a space between words, press the key.
Entering a number directly
To enter a number, press and hold the number key.
Scrolling
To move the cursor to the left, right, up or down
within the text, press the navigation keys.
Clearing letters and words
To clear the letter to the left of the cursor, press the
C
key. You can clear all of the letters on the display
by pressing and holding the
C
key.
Returning to the previous screen
When the text input field is empty, press and hold
the
C
key to return to the previous screen.
Entering text
55
Using the symbolic mode
The Symbolic mode enables you to enter symbols in
your text.
Using the number mode
The Number mode enables you to enter numbers in
your text. Press the keys corresponding to the digits
you want to enter.
To Press the
display more
symbols
Up or Down key.
enter a symbol corresponding number key.
return to the
previous text input
mode with entered
symbol(s)
Ok
soft key.
return to the
previous text input
mode without
entered symbol(s)
soft key.
56
Using the menus
The phone offers a range of functions that allow you
to tailor the phone to your needs. These functions
are arranged in menus and sub-menus.
Accessing a menu function
The menus and sub-menus can be accessed by
pressing the
Menu
or
Phonebook
soft key in Idle
Mode, then scrolling with the navigation keys.
1. In Idle Mode, press the
Menu
soft key to access
the main menu or press the
Phonebook
soft
key to access Phonebook menu.
2. Scroll through the menus using the navigation
keys. And then press the
Select
soft key if you
access the main menu.
3. Find the sub-menu that you wish to use by
scrolling with the Up or Down key.
4. Press the
Select
soft key to access the sub-
menu.
If the menu that you have selected contains
further sub-menus, repeat steps 3 and 4.
5. Scroll to the option you want to choose with the
Up or Down key.
6. Press the
Select
soft key to choose the setting.
Note
: You can return to the previous menu level by
pressing the soft key.
Using the menus
57
You can also access the menus and sub-menus by
quickly entering the corresponding menu number.
Example: Accessing the
Voice mail
menu.
1. Press the
Menu
soft key.
2. Press the
5
for
Messages
.
3. Press the
5
for
Voice mail
.
List of menu functions
Various menus let you check or change your phone
settings. The following list shows the menu
structure.
The numbers assigned to each menu option may
not match the menu number on the phone. It
depends on the services supported by your SIM
card.
Phonebook menu
1. Phonebook
(see page 63)
1. Find name
2. Add entry
3. Speed list
4. Copy all to phone
5. Send all via infrared
6. Delete all
2. Management
(see page 73)
1. Own number
2. Group setting
3. Memory status
3. Services
(see page 75)
1. Service directory
Using the menus
58
Main menu
1. Push to talk
(see page 76)
1. Login to service / Logout from PTT
2. Callback inbox
3. Contact list
4. Group list
5. Add group
1. Create group
2. Get group
6. Settings
1. Active service settings
2. Edit service settings
3. 1 to 1 call
4. Listened group
5. Logon at startup
7. PTT call records
1. Missed calls
2. Received calls
3. Dialled calls
4. Delete all
2. Call records
(see page 90)
1. Missed calls
2. Received calls
3. Dialled calls
4. Delete all
5. Call time
1. Last call time
2. Total sent
3. Total received
4. Reset timers
6. Call costs*
1. Last call cost
2. Total cost
3. Max cost
4. Reset counters
5. Set max cost
6. Price/Unit
Using the menus
59
3. Network services
(see page 94)
1. Call diverting
1. Divert always
2. Busy
3. No reply
4. Unreachable
5. Cancel all
2. Call barring
1. All outgoing
2. International
3. International except to home
4. All incoming
5. Incoming while abroad
6. Cancel all
7. Change barring password
3. Call waiting
4. Network selection
5. Caller ID
6. Active line
*
4. Sound settings
(see page 102)
1. Incoming calls
1. Default melodies
2. My sounds
3. Ring volume
4. Alert type
2. Messages
1. Short messages
2. Multimedia messages
3. Push to talk
1. Voice option
2. Call back
3. Notify
4. Power on/off
5. Connection tone
6. Key tone
7. Minute minder
*
Shown only if it is supported by your SIM card
Using the menus
60
8. Quiet mode
9. Slider tone
10. Alerts on call
5. Messages
(see page 108)
1. Short messages
1. Create
2. Inbox
3. Outbox
4. Delete all
2. Multimedia messages
1. Create
2. Inbox
3. Outbox
4. Draft
5. My folder
6. Delete all
3. Push messages
1. Inbox
2. Setting
3. Delete all
4. Preset messages
5. Voice mail
1. Connect to voice mail
2. Voice server number
6. Broadcast
1. Read
2. Receive
3. Channel
7. Settings
1. Short messages
2. Multimedia messages
8. Memory status
1. Short messages
2. Multimedia messages
Using the menus
61
6. Fun box
(see page 134)
1. WWW Services
*
1. Home
2. Bookmark
3. Go to URL
4. Clear cache
5. Proxy settings
6. Current proxy
2. Media box
1. Photos
2. Images
3. Sounds
4. Delete all
5. Memory status
3. JAVA world
1. Downloads
2. Internet settings
3. Memory status
4. SIM-AT MENU(SIM Application Toolkit)
**
7. Organiser
(see page 149)
1. New memo
2. Calendar
3. To do list
4. Clock
1. Set time
2. Set date
3. Set world time
4. Set format
5. Alarm
6. Calculator
7. Conversion
1. Length
2. Weight
3. Volume
4. Area
5. Temperature
8. Timer
9. Stopwatch
* May not be shown or supported by your network service provider.
**Shown only if it is supported by your SIM card.
Using the menus
62
8. Camera
(see
page 163
)
1. Take photos
2. My photos
3. My albums
4. Delete all
5. Settings
6. Memory status
9. Phone settings
(see page 172)
1. Display
1. Wallpaper
2. Skin
3. Backlight
4. LCD brightness
5. Service display
2. Greeting message
3. Security
1. PIN check
2. Change PIN
3. Phone lock
4. Change password
5. Privacy
6. SIM lock
7. FDN mode
*
8. Change PIN2*
4. Auto redial
5. Voiceclarity
6. Slide down operation
7. Active slide
8. Anykey answer
9. Fax mode
10. Infrared activation
11. Reset settings
1. Sound settings
2. Phone settings
3. All settings
* Shown only if it is supported by your SIM card.
63
Phonebook menu
Phonebook offers the following features:
•
Phonebook
: allows you to find, create or set up
the speed-dialling feature and manage
Phonebook entries.
•
Management
: allows you to create or remove
your own number, set up caller groups and check
the memory status.
•
Services
: allows you to use the service directory
depending on your SIM card.
Find name
To search for a number in the phonebook, proceed
as follows.
1. Enter a letter(s) of the name that you want to
find.
The Phonebook entries are listed, highlighting
the entry matching your input.
2. If necessary, press the Up or Down key to scroll
to the entry you want.
3. Once you have found the entry, press the
Ok
soft key.
4.
To Press the
dial the displayed
number
key.
Phonebook menu
64
Changing the phone memory entries
Scroll to the category that you want to edit by
pressing the Left or Right key. Following categories
are available and you can edit information of each
category by pressing the
Options
soft key.
change the
Phonebook entries
Options
soft key. For
further details, see
page 64.
Category Then
Mobile
Home
Office
Fax
Other
Select one of the following options. For
details for these options, refer to the
page 65.
Edit number
Change name
Send message
(shown if the category
contains a number)
Copy
(shown if the category contains a
number)
Send via infrared
(shown if the
category contains a number)
Delete entry
E-Mail Enter or edit e-mail address.
Note Enter or edit the memo.
4.
To Press the
Phonebook menu
65
Changing the SIM memory entries
To ch ange th e SI M me mo ry entry’s information,
press the
Options
soft key.
The following options are available:
Edit number
This option allows you to change the number. You
can also add a new number if none has been stored
for the selected category.
Change name
This option allows you to change the name of the
entry.
To clear the old name, press the
C
key. For more
information about how to enter characters, see
page 48.
Send message
This option allows you to send a message to the
number. For more information about how to send a
message, see page 110.
Copy
This option allows you to copy the entry from the
phone’s memory to the SIM card, and vice versa.
Send via infrared
Group Set one of the groups or no group.
Graphic Set one of the images or no image.
Alert Set one of the melodies or not assign.
Category Then
Phonebook menu
66
This option allows you to copy the entry from your
phone to another device that has the IrDA port via
infrared.
Delete entry
This option allows you to delete the entry from
Phonebook. To confirm the deletion, press the
Yes
soft key. Otherwise, press the
No
soft key.
Add entry
You can store phone numbers and the
corresponding names in the memory of your SIM
card. In addition, you can store up to 1000 names
in the phone memory and each name can be
associated with up to five numbers.
1. Enter the number you want to save.
Notes
:
• If you make a mistake while entering a number,
correct it using the
C
key. For further details, see
page 31.
• To insert a dialling pause for special phone
services, such as banking by phone, hold down
the key. “P” is displayed to indicate the pause.
2. When you are sure that the number is correct,
press the
Save
soft key.
3. Select the memory where the number is to be
stored, either
Phone
or
SIM
, and press the
Select
soft key.
Note
: If you change phones, any numbers stored
in your SIM card will automatically be
available with the new phone, whereas any
numbers stored in the phone’s memory
must be stored again.
Phonebook menu
67
4. If you select
SIM
in step 3, go to step 5.
If you select
Phone
in step 3, choose a number
type using the Up or Down key and press the
Select
soft key.
5. Enter the associated name.
For information about how to enter characters,
see page 48.
6. When you are satisfied, press the
Ok
soft key.
7. If you select
Phone
in step 3, go to step 8.
If you select
SIM
in step 3, enter the location
number and press the
Ok
soft key.
8. If you want to change the entry, use the options.
for information about how to do it, see page 64.
If you want to return to Idle Mode, press the
soft key or the key.
Storing a number in Idle mode
As soon as you start to enter a number,
Save
appears above the left soft key to allow you to store
the number in the Phonebook.
Continue the procedure from step 1 on page 66 to
store the number.
Speed list
You can set up to eight speed-dial entries and then
dial them easily whenever you want, simply by
pressing the associated number key.
Phonebook menu
68
Setting up speed-dial entries
1. Press the Up or Down key to scroll to an empty
location and press the
Select
soft key.
2. When the
Edit number
option highlights, press
the
Select
soft key.
3. Enter a phone number and press the
Ok
soft
key. Or,
To retrieve a number from your Phonebook,
press the
Phonebook
soft key. Select an entry
from the list and press the
Ok
soft key. Press
the
Ok
soft key to save it.
4. When you have finished, press the soft key or
the key to exit.
Editing the speed-dial entries
1. Select the speed-dial entry you want to edit
from the list and press the
Select
soft key.
2. Select one of the following menu options by
pressing the Up or Down key and press the
Select
soft key:
•
Edit number
: allows you to change the
number.
•
Change name
: allows you to change the
name of the entry.
•
Delete
: allows you to clear the setting so that
no number is assigned to the key.
3. When you have finished, press the soft key or
the key to exit.
Phonebook menu
69
Using the speed-dial feature
When the idle screen is displayed, press the number
key,
2
to
9
, assigned to the speed-dial entry and
press the key. You can also press and hold the
number key.
Note
: The
1
key
is reserved for your voice mail server
number.
Dialling a number stored in the SIM card
Once you have stored phone numbers in your SIM
card, you can dial them easily whenever required.
To dial a number stored in the SIM card:
1. Enter the number of the SIM card location where
the number you want to dial is stored.
2. Press the key.
The display shows the name and number stored
in that location.
3. Press the
Dial
soft key or the key.
Copy all to phone
You can copy all of the numbers stored in the SIM
card to the phone’s memory.
1. When a confirming message appears, press the
Yes
soft key to copy.
Phonebook menu
70
The numbers in the SIM card are copied to the
phone’s memory, labelled with
Mobile
by
default.
Otherwise, press the
No
soft key.
2. When you have finished, press the soft key or
the key to exit.
Send all via infrared
Via the infrared connection, you can send your
Phonebook entries to another IrDA- compliant
devices and vice versa.
Note
: This feature may not be available depending on
the devices.
Sending your phonebook
1. Align the IrDA ports on both sides each other.
2. Access the
Send all via infrared
menu option
in the
Phonebook
menu and choose one of the
following options and press the
Select
soft key:
•
All
: allows you to send all of the entries, from
the entry you choose to the end of the SIM
card and Phone list.
•
SIM
: allows you to send all of the entries,
from the entry you choose to the end of the
SIM card list.
•
Phone
: allows you to send all of the entries,
from the entry you choose to the end of the
Phone list.
Phonebook menu
71
3. When you select
All
and press the
OK
soft key,
your phone displays all of the Phonebook
entries.
When you select
SIM
or
Phone
and press the
OK
soft key, all of the entries stored in the
corresponding memory location are listed.
4. Scroll to the entry you want to send as
beginning and press the
OK
soft key.
Your phone begins sending the entry(ies).
Receiving phonebook from another device
1. Align the IrDA ports on both sides each other.
2. Access the
Infrared activation
menu
(see
page 180)
and select
On
to activate the port.
3. When your phone receives Phonebook data from
the other device:
If the other person sends you one entry, your
phone displays the name and the phone number
and you can specify whether or not you want to
save it. Continue to step 4.
IrDA port
IrDA port
Phonebook menu
72
If the person sends you the entries by
All
,
SIM
,
Phone
,
you can select a memory location, SIM
card or phone’s memory. Continue to step 5.
4. Press the
Save
soft key to store the entry.
You can also discard the entry by pressing the
Cancel
soft key.
5. Press the
SIM
or
Phone
soft key.
The entries are saved in the appropriate
memory.
Delete all
You can delete Phonebook entries selectively
depending on the memory location, or all entries at
once.
1. Scroll to a desired memory selection and place a
check mark ahead of it by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
memories.
Phonebook menu
73
2. If necessary, repeat step 1 to check another
options.
3. When you have finished checking, press the
Ok
soft key.
4. When a confirming message appears, press the
Yes
soft key to delete all of the entries in the
memory(ies). Then enter the phone password
and press the
Ok
soft key.
The password is preset to “00000000” by
default. To change it, see page 176.
Otherwise, press the
No
soft key.
Own number
To store your own phone number(s) with a name:
1. Scroll to an empty location by pressing the Up or
Down key and press the
Select
soft key.
2. When
Edit number
highlights, press the
Select
soft key.
3. Enter your number and press the
Ok
key.
4. To assign a name, press the Down key to move
to
Change name
and press the
Select
soft key.
5. Enter a name and press the
Ok
soft key.
6. When you have finished, press the soft key or
the key to exit.
To remove one of your numbers:
Phonebook menu
74
1. Select the entry you want to delete from the
Own number list and press the
Select
soft key.
2. Scroll to
Delete
by pressing the Up or Down key
and press the
Select
soft key.
3. When a confirming message appears, press the
Yes
soft key to delete the number.
Otherwise, press the
No
soft key.
4. When you have finished, press the soft key or
the key to exit.
Group setting
You can change the settings of the 11 predefined
caller groups.
1. Select a caller group by pressing the Up or Down
key and press the
Select
soft key.
2. Scroll to a setting option by pressing the Up or
Down key and press the
Select
soft key.
The following options are available:
•
Melody
: allows you to select a melody to
sound when a call comes in from a member in
the group.
Phonebook menu
75
•
Change name
: allows you to change the
name of the group; for further details about
how to enter characters, see page 48.
•
View image
: shows the image to display
when a call comes in from a member in the
group.
3. Change the setting as required and press the
Select
soft key.
4. Repeat steps 2 and 3 to change other options.
When you have finished, press the soft key or
the key to exit.
Memory status
You can check how many names are stored in SIM
card and phone’s memory.
When you have finished, press the soft key or
the key to exit.
Service directory
Note
: This feature may not be available depending on
your SIM card.
The
display shows the list of the numbers in the
Service directory.
If necessary, scroll to a number by pressing the Up
or Down key and press the key to dial the
number.
76
Push To Talk(PTT)
The Push to talk feature over cellular (PTT) is for a
one-way radio service by using GPRS. Push to talk
provides a direct voice communication connection
with the press of the PTT key.
You can use the Push to talk feature to have a
conversation with one person or with a group, as
long as they have a compatible device. For further
details about the Push to talk feature, contact your
service provider.
Talking to group
After logging into PTT service, talk to the default
group by pressing the PTT key except when the PTT
key is used for 1-to-1 call. Group call for any active
group is available in group list menu.
When you press the PTT key, waiting screen is
displayed.
When you hear the access-granted tone and see
nickname and group name, call setup finishes and
now you can start to talk. The PTT key must be
pressed down during whole talk spurt.
After releasing the PTT key, screen changes to
dimming. You can call the correspondent in this
state.
Receiving from group
After logging into PTT service, you can receive from
active group except in silent mode and do not
disturb mode. After receiving, the screen changes
to dimming which means waiting.
If you want not to receive while speech items are
coming, then press the key. It will allow you
Push To Talk(PTT)
77
to end call for one-term. If you want not to disturb
from PTT, use do not disturb mode in sound settings
(see page 104).
When more than one person are trying to talk at
the same time, the person’s information will be
displayed. Release the PTT key and wait for other
person to finish. If you still want to talk to the
group, push the PTT key again.
Making a one-to-one call
After logging into PTT service, a one-to-one call is
possible in these menu, callback inbox, contact list,
and active member query in group list if recipient
address is valid.
• In the Contacts view, choose a contact and press
the PTT key.
• In the call logs, choose a PTT call record and
press the PTT key.
• In the PTT call records menu, choose a record
and press the PTT key.
• Choose a callback from the received callbacks list
and press the PTT key.
• Start a one-to-one call by choosing a nickname
from the list in the active members view and
pushing PTT key.
Respond to the one-to-one call by pushing the PTT
key during the waiting period. The waiting period is
presented on the screen by showing the PTT graphic
and the nickname of the previous speaker.
Receiving a one-to-one call
After logging into PTT service, receive a one-to-one
call except in silent mode and do not disturb mode.
Push To Talk(PTT)
78
After receiving, the screen changes to dimming
which means waiting.
If you want not to receive while speech items are
coming, then press the key. It will allow you
to end call for one-term. If you want not to disturb
from PTT, use do not disturb mode in sound settings
(see page 104).
When more than one person are trying to talk at
the same time, the person’s information will be
displayed. Release the PTT key and wait for other
person to finish. If you still want to talk to the
group, push the PTT key again.
Login to service / Logout from PTT
You can connect to or disconnect from the Push to
talk service by using the these options.
Callback inbox
In this menu, you can view the 20 most recent
callbacks you have received. You can also make a
PTT call using a callback request.
To Press the
scroll to a callback
request
Up or Down key.
view details of a
callback request
Select
soft key.
make a one-to-one
call
PTT key.
Push To Talk(PTT)
79
While viewing a callback request, press the
Options
soft key to access the following options:
Send callback
: allows you to send a callback
request to the selected contact.
Add to phonebook
: allows you to add the sender’s
e-mail address to an existing entry in Phonebook.
Save as
: allows you to save a new entry with the
sender’s e-mail address to the PTT Contact list.
Delete request
: deletes the currently selected
callback request.
Contact list
In this menu, you can view a list of all of the
contacts stored in the PTT group section of
Phonebook.
While viewing a contact, press the
Options
soft key
to access the following options:
Send callback
: allows you to send a callback
request to the selected contact.
Edit address
: allows you to edit the currently
selected e-mail address.
Delete contact
: allows you to delete the currently
selected contact.
To Press the
scroll to a contact Up or Down key.
view details of a
contact
Select
soft key.
make a one-to-one
call
PTT key.
Push To Talk(PTT)
80
Add contact
: allows you to add a new entry to
Contact list.
Group list
In this menu, you can view the PTT groups you
have created using the
Add group
menu or saved
after receiving invitation messages.
To make a group call, scroll to a group and press
the PTT key.
On the Group list screen, press the
Options
soft
key to access the following options:
Status
: allows you to change the current status of
the selected group.
Default: when this option is selected, the currently
selected group is set as the default PTT group.
When you press the PTT key without first choosing a
member or group, the phone automatically dials
this group.
Listened: when this option is selected, the selected
group is set as the listened group.
Inactive: when this option is selected, the selected
group is deactivate. You are unable to make a group
call with the currently selected group.
Send invitation
: allows you to send an invitation
to the members in the PTT group by using the
following options:
Via text message: allows you to send an invitation
to the members in the PTT group Via text message.
For further details, see page 109.
Push To Talk(PTT)
81
Via infrared: allows you to send an invitation to the
members in the PTT group via an IrDA connection.
For further details, see page 180.
Active member
: allows you to view the members
currently connected to the PTT service.
Delete group
: allows you to delete the currently
selected PTT group.
Delete all groups
: allows you to delete all PTT
groups.
Group detail
: allows you to access the following
group options:
Group title: allows you to change the name for the
selected PTT group.
Nickname in group: allows you to change a
nickname for the selected PTT group.
Group graphic: allows you to select an image to be
displayed when you receive a PTT call from the
selected group.
Group address: shows the e-mail address and
maker of the selected PTT group.
Add group
In this menu, you can create new PTT groups and
register to the PTT server so that other people use
the PTT group you have created. You can also add
one of the PTT groups registered to the PTT server
to your Group list.
Note
: Members in a PTT group make subgroups in the
group.
Push To Talk(PTT)
82
Create group
You can create a new PTT group using a domain
name and register to the PTT server.
To create a new PTT group:
1. Select one of the following options and press the
Select
soft key:
•
Open group
: allows you to add an open
group. Other people can view the e-mail
address of the group.
•
Secured group
: allows you to add a secured
group. Other people are not able to view the
e-mail address for the group.
2. Enter a name for the group and press the
OK
soft key.
For further details about how to enter
characters, see page 48.
3. Connect to the PTT server by selecting the
Login to service
menu. For further details
about connecting to the Push to talk service, see
page 78.
The created PTT group is registered to the PTT
server.
4. Select one of the following status choices for the
group and press the
Select
soft key:
•
Default
: when this option is selected, the
currently selected group is set as the default
PTT group. When you press the PTT key
without first choosing a member or group, the
phone automatically dials this group.
•
Listened
: when this option is selected, the
selected group is set as the listened group.
Push To Talk(PTT)
83
•
Inactive
: when this option is selected, the
selected group is deactivated. You are unable
to make a group call with the currently
selected group.
5. When you are finished, press the key.
Get group
You can add one of the PTT groups that are register
to the PTT server to your Group list.
Note
: If you have created a PTT group with an
unregistered e-mail address on your server, the
server will send you a notification that the PTT
group cannot be added.
To add a PTT group:
1. Enter an e-mail address for the PTT group you
want to add and press the
OK
soft key.
For further details about how to enter
characters, see page 48.
2. Connect to the PTT server by selecting the
Login to service
menu. For further details
about connecting to the Push to talk service, see
page 78.
3. Select one of the following status choices for the
group and press the
Select
soft key:
•
Default
: when this option is selected, the
currently selected group is set as the default
PTT group. When you press the PTT key
without first choosing a member or group, the
phone automatically dials this group.
•
Listened
: when this option is selected, the
selected group is set as the listened group.
Push To Talk(PTT)
84
•
Inactive
: when this option is selected, the
selected group is deactivated. You are unable
to make a group call with the currently
selected group.
4. When you are finished, press the key.
Settings
In this menu, you can select the service setting you
want to use and configure various network settings
that are required to send or receive PTT calls.
Active service settings
You can select the service setting you want to use.
Select one of the 5 settings.
Edit service setting
You can configure various network settings that are
required to send or receive a PTT call.
For each setting, the following options are
available:
PTT settingname
: enter the PTT setting name.
PTT username
: enter the username.
Default nickname
: enter a nickname.
PTT password
: enter the PTT password.
Domain
: enter the domain name.
IP address
: enter the IP address.
Push To Talk(PTT)
85
Connection settings
: allows you to access the
following options:
APN settings: allows you to access the following
APN settings:
- Access point name: enter the access point name
for the address of the PTT server.
- Access point username: enter the access point
user name for the address of the PTT server.
- Access point password: enter the password
required to connect to the PTT server.
1 to 1 call
In this menu, you can change the settings for
receiving one-to-one calls.
The following options are available:
Notify
: display the notification that allows you to
accept or reject all incoming one-to-one calls.
On
: receive all incoming one -to-one calls.
Off
: reject all incoming one-to-one calls.
Listened group
In this menu, you can set whether or not the phone
receives listened group calls.
The following options are available:
Off
: the phone rejects all listened group calls.
On
: the phone receives all listened group calls.
Push To Talk(PTT)
86
Logon at startup
In this menu, you can set whether or not the phone
is automatically connected to the PTT service when
you turn on the phone.
The following options are available:
Off
: the phone is not connected to the PTT service
when you turn on the phone.
On
: the phone is automatically connected to the
PTT service when you turn on the phone.
Ask first
: you are asked to connect to the PTT
service when you turn on the phone.
PTT call records
In this menu, you can view the records of one to
one PTT calls you have missed, received, or dialled.
You can also delete PTT call records.
Missed calls
In this menu, you can view the 20 most recent PTT
calls you have received, but did not answer.
While viewing a PTT call record, press the
Options
soft key to access the following options:
To Press the
select a PTT call
record
Up or Down key.
view details of a PTT
call record
Select
soft key.
make a one-to-one
call
PTT key.
Push To Talk(PTT)
87
Send callback
: allows you to send a callback
request to the selected contact.
Add to phonebook
: allows you to add the sender’s
e-mail address to an existing entry in Phonebook.
Save as
: allows you to save a new entry with the
sender’s e-mail address to the PTT Contact list.
Delete
: allows you to delete the PTT call record.
Delete all
: allows you to delete all PTT call records.
Received calls
In this menu, you can view the 20 most recent PTT
calls you have received.
While viewing a PTT call record, press the
Options
soft key to access the following options:
Send callback
: allows you to send a callback
request to the selected contact.
Add to phonebook
: allows you to add the sender’s
e-mail address to an existing entry in Phonebook.
Save as
: allows you to save a new entry with the
sender’s e-mail address to the PTT Contact list.
Delete
: allows you to delete the PTT call record.
Delete all
: allows you to delete all PTT call records.
To Press the
select a PTT call
record
Up or Down key.
view details of a PTT
call record
Select
soft key.
make a one-to-one
call
PTT key.
Push To Talk(PTT)
88
Dialled calls
In this menu, you can view the 20 most recent PTT
calls you have dialled.
While viewing a PTT call record, press the
Options
soft key to access the following options:
Send callback
: allows you to send a callback
request to the selected contact.
Add to phonebook
: allows you to add the sender’s
e-mail address to an existing entry in Phonebook.
Save as
: allows you to save a new entry with the
sender’s e-mail address to the PTT Contact list.
Delete
: allows you to delete the PTT call record.
Delete all
: allows you to delete all PTT call records.
To Press the
select a PTT call
record
Up or Down key.
view details of a PTT
call record
Select
soft key.
make a one-to-one
call
push to talk toggle
button.
Push To Talk(PTT)
89
Delete all
In this menu, you can delete all of the PTT call
records in each PTT call record separately. You can
also delete all of your PTT call records at one time.
2. Press the
Delete
soft key to delete the marked
PTT call records.
3. When a confirmation message displays, press
the
Yes
soft key.
1.
To Press the
select a PTT call
record
Up or Down key. To
delete all of your PTT call
records, select
All
.
place a check
mark
Mark
soft key.
remove a check
mark
Unmark
soft key.
90
Call records
Via this menu, you can view the:
• calls you missed, received or dialled.
• cost of your calls.
• length of your calls.
Note
: You can access the numbers in the three types
of call records by pressing the
key in Idle
Mode.
Missed calls
This option lets you view the last 20 unanswered
calls if the caller line identification is available.
The number, or name if available, displays together
with the date and time when the call was missed.
By pressing the
Options
soft key, you can also:
• delete the current call record from the list.
• delete all of the calls.
• paste the number into Phonebook.
Received calls
This option lets you view the last 20 received calls if
the caller line identification is available.
The number, or name if available, displays together
with the date and time when the call was received.
Call records
91
By pressing the
Options
soft key, you can also:
• delete the current call record from the list.
• delete all of the calls.
• paste the number into Phonebook.
Dialled calls
This option lets you view the last 20 dialled
numbers.
The number, or name if available, displays together
with the date and time when the call was made.
By pressing the
Options
soft key, you can also:
• delete the current call record from the list.
• delete all the calls.
• paste the number into Phonebook.
Delete all
You can delete all of the numbers stored in each call
record.
When a confirming messages appears, press the
Yes
soft key to confirm.
Otherwise, press the
No
soft key.
Call records
92
Call time
This option lets you view the timers for calls made
and received.
Notes:
•
If your SIM card supports the ALS (Alternate Line
Service) feature, you must first select the
appropriate line.
• The actual time invoiced for calls by your service
provider may vary, depending on network features,
rounding-off for billing purposes and others.
The following timers are available:
Last call time
: the length of the last call.
Total sent
: the total length of all calls made since
the timer was last reset.
Total received
: the total length of all calls received
since the timer was last reset.
Reset timers
: the option used to reset the call
timers. You need to enter the phone password and
then press the
Ok
soft key.
Call costs
This feature lets you view the cost of calls.
Notes
:
• This feature is not intended to be used for billing
purposes.
• AOC (Advice Of Charge) information may display in
Idle Mode, depending on your SIM card or service
provider.
Call records
93
The following options are available:
Last call cost
: cost of the last call made.
Total cost
: total cost of all calls made since the
cost counter was last reset. If the total cost exceeds
the maximum cost set via the
Set max cost
option, you can no longer make any calls until you
reset the counter.
Max cost
: maximum cost set via the
Set max cost
option.
Reset counters
: option used to reset the cost
counter; you must first enter your PIN2 (see
page 188) and then press the
Ok
soft key.
Set max cost
: option used to enter the maximum
cost that you authorise for your calls; you must first
enter your PIN2 (see page 188) and then press the
Ok
soft key.
Price/Unit
: option used to set the cost of one unit;
this price per unit is applied when calculating the
cost of your calls; you must first enter your PIN2
(see page 188) and then press the
Ok
soft key.
94
Network services
These menu functions are network services.
Please contact your service provider to check their
availability and subscribe to them, if you wish.
Call diverting
Note
: The call divert options may be different
depending on your SIM card and those not
supported by your network operator may not
be shown.
This network service enables incoming calls to be
rerouted to the number that you specify.
Example: You may wish to divert your business calls
to a colleague while you are on holiday.
Call diverting can be set up in the following ways:
Divert always
: all calls are diverted.
Busy
: calls are diverted if your phone is engaged
on another call.
No reply
: calls are diverted if you do not answer
the phone.
Unreachable
: calls are diverted if you are not in an
area covered by your service provider.
Cancel all
: all call diverting options are
deactivated.
You can specify individual call diverting options for
each of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
Network services
95
• Data calls only (not available when line 2 is in
use)
Example: You can:
• systematically divert fax calls to your
office fax machine.
• divert voice calls to your colleague if
you are already using the phone.
Setting call diverting options
1. Select the type of call diverting by pressing the
Up or Down key and then press the
Select
soft
key.
2. Select the type of calls to be diverted by
pressing the Up or Down key and then press the
Select
soft key.
3. Press the
Activate
soft key to confirm your
settings.
4. Enter the number to which the calls are to be
diverted.
To enter an international code, hold down the
0
key until the + sign displays.
You can also select a number in Phonebook or
the voice mail server number, by pressing the
Options
soft key, followed by
Phonebook
or
Voice server
.
5. When you are satisfied, press the
Ok
soft key.
The phone sends your settings to the network
and displays the network’s acknowledgement.
Network services
96
Deactivating specific call diverting
options
1. Select the call diverting option to be
deactivated.
2. Select the type of calls to which this option
applies.
3. Press the
Remove
soft key.
The phone sends your settings to the network
and displays the network’s acknowledgement.
You can also deactivate all call diverting options by
selecting the
Cancel all
option.
Call barring
The call barring network service allows you to
restrict your calls.
Call barring can be set up in the following ways:
All outgoing
: calls cannot be made.
International
: international calls cannot be made.
International except to home
: when abroad,
calls can be made only to numbers within the
current country and to your home country, that is
the country where your home network provider is
located.
All incoming
: calls cannot be received.
Incoming while abroad
: calls cannot be received
when you are using your phone outside your home
service area.
Network services
97
Cancel all
: all call barring options are deactivated;
calls can be made and received normally.
Change barring password
: allows you to change
barring password.
You can specify individual call barring options for
each of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
• Data calls only (not available when line 2 is in
use)
Setting call barring options
1. Select the type of call barring by pressing the Up
or Down key and then press the
Select
soft key.
2. Select the type of calls to be barred by pressing
the Up or Down key and then press the
Select
soft key.
3. Press the
Activate
soft key to confirm your
settings.
4. Enter your call barring password supplied by
your service provider and press the
Ok
soft key.
The phone sends your settings to the network
and displays the network’s acknowledgement.
Network services
98
Deactivating specific call barring options
1. Select the call barring option to be deactivated.
2. Select the type of calls to which this option
applies.
3. Press the
Deactivate
soft key.
4. Enter your call barring password supplied by
your service provider.
The phone sends your settings to the network
and displays the network’s acknowledgement.
You can also deactivate all call barring options by
selecting the
Cancel all
option.
Changing the barring password
You can set and change the call barring password
obtained from your service provider.
1. Select
Change barring password
from the
Call barring screen, and press the
Select
soft
key.
2. Enter the current password and press the
Ok
soft key.
3. Enter a new password and press the
Ok
soft
key.
4. Enter the new password again to confirm it and
press the
Ok
soft key.
Network services
99
Call waiting
This network service informs you when someone is
trying to reach you during another call.
You can specify individual call waiting options for
each of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
• Data calls only (not available when line 2 is in
use)
Activating the call waiting feature
1. Select the type of calls to which the call waiting
option is to be applied by pressing the Up or
Down key and then press the
Select
soft key.
2. Press the
Activate
soft key to confirm your
settings.
The phone sends your settings to the network
and displays the network’s acknowledgement.
Deactivating specific call waiting options
1. Select the type of call to which the option
applies.
2. Press the
Deactivate
soft key.
The phone sends your settings to the network
and displays the network’s acknowledgement.
You can also deactivate all call waiting options by
selecting the
Cancel all
option.
Network services
100
Network selection
The Network selection feature enables you to
automatically or manually select the network used
when roaming outside your home area.
Note
: You can select a network other than your home
network only if it has a valid roaming
agreement with your home network.
To indicate to automatically or manually select the
network when roaming:
1. Press the Up or Down key until the appropriate
option highlights and press the
Select
soft key.
If you select
Automatic
, you are connected to
the first available network when roaming.
If you select
Manual
, the phone scans for the
available networks. Go to step 2.
2. Press the Up or Down key until the preferred
network highlights and press the
Select
soft
key.
You are connected to that network when
roaming.
Network services
101
Caller ID
You can prevent your phone number from being
displayed on the phone of the person being called.
Note
: Some networks do not allow the user to change
this setting.
The following options are available:
Default
: the default setting provided by the
network is used.
Hide number
: your number does not display on
the other person’s phone.
Send number
: your number is sent each time you
make a call.
Active line
Some SIM cards may be used with two subscriber
numbers. This functions is available only if your SIM
card supports it.
This menu option allows you to select the line to be
used to make calls. However, calls can be answered
on both lines, regardless of the selected line.
102
Sound settings
You can use the Sound settings feature to
customise various settings, such as the:
• ringtone, volume and type for incoming calls or
messages.
• sounds made when your call is connected or
when you press a key.
• quiet mode which your phone switches to when
you hold down the key in the Idle Mode.
Incoming calls
This option allows you to set up the ringer for
incoming calls.
Notes
:
• You can quickly enter the
Incoming Calls
menu by pressing the Right key in Idle mode.
• If your SIM card supports the ALS (Alternate
Line Service) feature, you must select the line
you wish to change first.
The following options are available:
Each time you select a melody from the list, it plays
the melody.
Default melodies
: allows you to select one of the
predefined melodies.
My sounds
: allows you to select one of the sounds
received from other sources, such as the WAP sites,
the EasyStudio PC software or multimedia
messages.
Sound settings
103
Ring volume
: allows you to adjust the ring
volume. Use the Up and Down keys or the volume
keys on the left side of the phone. The more bars
you see, the louder the volume.
Alert type
: lets you specify how you are informed
of any incoming calls.
Melody: the phone rings using the melody selected
via the
Default melodies
and
My sounds
option.
See above.
Vibration: the phone vibrates but does not ring.
Vibration then melody: the phone first vibrates and
then starts ringing.
Messages
This option allows you to set up the ringer for each
incoming short message and multimedia message
received.
Short messages / Multimedia messages
The following options are available:
Tone
: lets you choose from many different tones.
Each time you select a tone from the list, the tone is
played.
Alert type
: lets you specify how you are informed
of any incoming messages.
Silent: only the text notification appears; the phone
neither rings nor vibrates.
Ton e : the phone rings using the tone selected via
the
Tone
option. See above.
Sound settings
104
Vibration: the phone vibrates but does not ring.
Vibration then tone: the phone first vibrates and
then starts ringing.
Repetition
: allows you to specify how often the
phone informs you of a new message. You can
choose either
Once
or
Periodic
.
Push to talk
You can select an alert type and melody for
incoming PTT calls.
Voice option
This option allows you to select how the phone
informs you when you receive a PTT call during a
call. The following options are available:
Do not disturb
: the phone does not alert you when
you receive a PTT call.
Headset
: the phone alerts you with an alert sound
through a headset.
Loud speaker
: the phone alerts you with an alert
sound through a speaker.
Callback
This option allows you to select whether or not the
phone alerts you when you receive a callback
request. The following options are available:
Tone
: allows you to use one of several tones.
Alert type
: allows you to specify how you are to be
informed of incoming PTT calls.
Sound settings
105
Repetition
: allows you to specify how often the
phone informs you of a new PTT call. You can
choose either
Once
or
Periodic
.
Notify
This option allows you to select whether or not the
phone alerts you when you receive a one to one PTT
call. The following options are available:
Default Melody
: allows you to use one of several
melodies.
My Sound
: allows you to use one of the melodies
you have downloaded from the Wireless Web.
Ring Volume
: allows you to adjust the volume.
Alert type
: allows you to specify how you are to be
informed of incoming PTT calls.
Power on/off
This option allows you to select the melody that the
phone sounds when you switch it on or off.
You can choose either
Classical
or
Future
. To turn
the sound off, select
Off
.
Connection tone
This menu option allows you to specify whether or
not the phone beeps when the phone connects to
the network.
The following options are available:
Off
: the phone does not beep.
On
: the phone beeps when your call is accepted.
Sound settings
106
Key tone
This menu option allows you to select the tone that
the keypad sounds when you press a dial key.
To turn the sound off, select
Off
.
To adjust the key tone volume, press the volume
keys on the left side of the phone in Idle Mode.
Minute minder
This menu option allows you to specify whether or
not the phone beeps every minute during a call to
keep you informed of the length of your call.
The following options are available:
Off
: the phone does not beep.
On
: the phone beeps every minute.
Quiet mode
When you hold the key down in Idle Mode, the
phone switches to the Quiet Mode. You can specify
whether the phone vibrates or mutes when in the
Quiet Mode.
Note
: the phone does not alert you when you send or
receive a PTT call in the Quiet Mode.
The following options are available:
Vibration
: the phone vibrates rather than rings in
the Quiet Mode.
Mute
: the phone mutes sounds in the Quiet Mode.
Sound settings
107
Slider tone
This menu allows you to select the slider tone that
the phone sounds when you slide the folder up or
down.
To turn the sound off, select
Off
.
Alerts on call
This menu allows you to set the phone to all alerts
while calling.
To turn the alerts off, select
Off
.
108
Messages
This menu allows you to create, send, read and
save messages with the Short Message Service
(SMS: text message), Enhanced Message Service
(EMS: message including simple image, animation
or melody) and Multimedia Message Service
(MMS: message supporting the presentation of
various media types, such as full colour images and
polyphonic ring tones). Voice mails are also
available.
Note
: This feature is only available if your service
provider’s network supports it. Contact your
service provider for more information.
Short messages
Short message service (SMS) allows you to send
and receive short text messages to and from other
GSM mobile phones. In addition, your phone
supports the Enhanced Messaging Service (EMS),
which enables you to make short messages
consisting of simple pictures, melodies, animations
and styled text all of which adds a new dimension to
simple text messages.
To send text messages by phone, you must obtain
the number of the SMS centre from your service
provider.
Receiving a new message
When you receive a new message, the New
message icon ( ) and a text notification showing
the number of the message appear on the display.
You also hear an alert, depending on the message
sound setting; for further details, see page 103.
Messages
109
To read the new message(s) immediately, press the
View
soft key. The list of the messages appears.
Note:
To clear the new message notification on the
display, press the key. When you also
have missed calls, voice mails, short messages
or multimedia messages, and multi CBs, the
right soft key indication changes in the
following order:
Missed
,
Connect
,
View
,
CB
and
Phonebook
.
Managing memory
Inbox and Outbox share a given amount of memory
in your phone or SIM card. When the message
memory is full, the New message icon ( ) blinks
and an error message displays. (It disappears when
you press the
key
, but it reappears if you
don’t delete old messages.) In this case, you cannot
receive any new messages. You must delete one or
more old messages to get free memory for new
messages using the
Delete
option within the Inbox
or Outbox or the
Delete all
option; for further
details, see page 114.
Create
Using this menu, you can write messages,
containing text, images and melodies.
1. Create a message.
On the first line of the display, you see the
number of remaining characters you can enter,
the number of current message and the
maximum messages you can create, and the
font style you set in
Text
option.
Note
: For further information about how to enter
characters, see page 48.
Messages
110
2. While entering your message, press the
Options
soft key to use the following options.
•
Send
: allows you to send the message. Refer
to the next step.
•
Text
: allows you to format the text. Following
text attributes can all be combined as
required.
Text size: Small/Medium/Large
Text mode: Normal/Underscore/Strikethrough
Bold: Off/On
Italic: Off/On
Alignment: Left/Center/Right
•
Add media
: allows you to add pictures,
animations and/or melodies to the message.
Select a category;
Add picture
,
Add
animation
or
Add melody
. You can then
choose a factory-set object or an object that
you have received from another source and
stored in the Media box. See page 140.
•
Add phonebook
: allows you to add phone
number(s) from the phonebook to the
message.
•
Preset messages
: allows you to add a preset
message to your text. Select one of nine
messages stored in the
Preset messages
menu option. See page 127.
•
Save message
: allows you to save the
message so that it can be sent later. You can
read the message in the Outbox.
3. When you have finished entering your message,
choose
Send
from the options.
Messages
111
4. Enter a destination number on the Address
screen.
You can search for a number in Phonebook by
pressing the
Phonebook
soft key.
Note
: To clear or clear all your input, press or press
and hold the
C
key. When you have no input,
press and hold the
C
key to move to the
previous screen.
To send the message to multiple destinations up
to 5, press the
Add
soft key and repeat step 4.
5. When you have finished entering the numbers,
press the
Ok
soft key.
6. If the Enter centre screen displays, enter the
service number and press the
Ok
soft key.
You
can store the SMS service centre number. For
details, see page 130.
Note
: When the phone fails to send the message;
Press the
Retry
soft key to try again the
transmission. Or, press the
No
soft key and the
Save
soft key to save the message or exit the
menu by pressing the
No
soft key.
Inbox
Your phone receives incoming messages and saves
them in the Inbox. SMS is usually saved in the SIM
card, but if the SIM memory is full, the incoming
messages will be saved in the phone’s memory.
When the
Inbox
menu is selected, the list of
messages received displays with the:
• sender’s phone number, or name if stored in
Phonebook.
Messages
112
• message status; for a read message, for a
message to read or for an incomplete
message.
To view a message, scroll to it and press the
Select
soft key. The screen shows the:
• date and time when the message was received.
• memory where the message was stored; for
the SIM card or for the phone’s memory.
• message contents.
You can scroll to the next or previous message by
pressing the Left or Right key.
To scroll through the message contents, press the
Up or Down key. When you focus on an object that
includes a melody, the melody is played.
You can choose the following options by pressing
the
Options
soft key:
Delete
: allows you to delete the message.
Message reply
:
allows you to reply by sending a
message.
Call back
: allows you to call the sender back.
Cut address
:
extracts phone numbers, email
addresses or URL addresses in the text, so that you
can call the number or send a message to the
number or save it in your Phonebook.
Send
: allows you to send the message to another
person.
Edit
:
allows you to edit the message.
Extract media
:
you can save media (except the
predefined EMS animations and sounds) from the
message into Media box. You can use these items
when writing a message; for further details, see
page 110.
Messages
113
Transfer
:
allows you to transfer the message from
the SIM card to the phone’s memory or vice versa.
Outbox
Outbox stores any messages that you have already
sent or just saved without sending.
When the
Outbox
menu option is selected, the list
of messages you have sent or saved displays with
the:
• recipient’s phone number, or name if stored in
Phonebook.
• message status; for a sent message or for
a message to send.
To view a message, scroll to it and press the
Select
soft key. The screen shows the:
• message status; for a sent message or for
a message to send.
• memory where the message was stored; for
the SIM card or for the phone’s memory.
• message contents.
You can scroll to the next or previous message by
pressing the Left or Right key.
To scroll through the message, press the Up or
Down key.
You can choose the following options by pressing
the
Options
soft key:
Delete
:
allows you to delete the message.
Cut address
: extracts phone numbers, email
addresses or URL addresses in the text, so that you
can call the number or send a message to the
number or save it in your Phonebook.
Messages
114
Send
:
allows you to send the message to another
person.
Edit
:
allows you to edit the message.
Transfer
:
allows you to transfer the message from
the SIM card to the phone’s memory or vice versa.
Delete all
You can delete all messages stored in the SIM card
and phone’s memory in this menu.
1. Scroll to a message box and place a check mark
ahead of it by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
message boxes.
2. If necessary, repeat step 1 to check another
box.
3. When you have finished checking, press the
Ok
soft key.
4. When a confirming message appears, press the
Yes
soft key to delete all of the messages in the
box(es).
Otherwise, press the
No
soft key.
Multimedia messages
Multimedia Message Service (MMS) is a messaging
service very similar to Short Message Service
(SMS). It provides asynchronous delivery of
personal multimedia messages from between phone
and phone, phone and e-mail, phone and web(by
URL).
Messages
115
In addition to the familiar text content of text
messages, multimedia messages can contain
images, graphics, voice and sounds. An MMS
message is a multimedia presentation in a single
entry. It is not a text file with attachments.
Using the MMS feature, your phone can receive
multimedia messages. You can also send picture
messages. This function is available only if it is
supported by your service provider. Only phones
that offer picture message features can receive and
display picture messages.
Retrieving a new message
When you are retrieving a message, the Retrieving
icon ( ) appears on the display. When you finish
retrieving a new message, the New message icon
( ) and a text notification showing the number of
the message appear on the display. You also hear
an alert, depending on the message sound setting;
for further details, see page 103.
To read the new message in Idle Mode, press the
View
soft key. And then you see the list in the
Inbox. If you select a message, you can read it.
Notes
:
• while retrieving a new message, you cannot access
WAP sites, and cannot also enter the
Downloads
menu (see page 144).
• To clear the new message notification on the display,
press the key. When you also have missed
calls, voice mails, short messages or multimedia
messages, and multi CBs, the right soft key
indication changes in the following order:
Missed
,
Connect
,
View
,
CB
and
Phonebook
.
Messages
116
If
Msg. reception
was set to
Manual
(for details,
see page 131), when the New message icon ( )
appears on the display, you have to retrieve
messages in the Inbox. You select a message with
the icon ( ) in the Inbox. Then you can select
retrieve or delete message by pressing the
Opt.
soft key.
Managing memory
When the memory is full, the New message icon
( ) blinks and an error message displays. (It
disappears when you press the
key
, but it
reappears if you don’t delete old messages.) In this
case, you cannot receive any new messages. You
must delete one or more old messages to get free
memory for new messages using the
Delete
option
within the Inbox, Outbox, Draft or My folder, or the
Delete all
option; for further details, see page 125.
Notes
:
• You can only receive up to 150 messages.
• Multimedia message boxes, Camera, and Media box
share a given amount of memory in your phone. You
can also use the
Delete
or
Delete all
option to
delete some sounds or images in Camera or Media
box.
Create
This menu option allows you to create a new
multimedia message and then send it to multiple
destinations.
Messages
117
1. Select one of the following items using the Up or
Down key and press the
Add
soft key.
Item How to add
Subject 1. Enter a subject of your message.
For details about entering
characters, see page 48.
2. Press the
Ok
soft key.
Note
: To return to previous screen while
entering a subject, press and hold
the
C
key.
Picture To add a new picture;
1. Select the
Create new
option.
2. Take a photo using the camera
feature. For details about the
camera feature, see page 163.
(continued)
3. Select one of pictures you want to
add. The picture is displayed.
4. Press the
Add
soft key.
To add a picture in the Media box;
1. Select one of the picture categories.
The picture list of the category is
displayed.
2. Select one of pictures you want to
add. The picture is displayed.
3. Press the
Add
soft key.
Messages
118
Sound To add a new sound;
1. Select the
Record new
option.
2. Press the
Record
soft key to start
recording.
3. Press the
Stop
soft key to stop
recording.
4. Press the
Play
soft key to replay the
sound. Or, press the
Add
soft key to
add it. Enter the sound’s name and
press the
Ok
soft key. The sound is
added to the message and saved in
Media box automatically.
Sound
(continued)
To add a sound in the Media box;
1. Select one of the sound categories.
The sound list of the category is
displayed.
2. Select one of the sounds you want
to add.
3. Press the
Select
soft key to add it.
Item How to add
Messages
119
3. Press the
Opt.
soft key to use the following
options.
•
Preview
: shows your message as it will
display on the recipient’s phone. To go back to
the message screen, press the
Edit
soft key.
To send the message, press the
Send
soft key
and go to step 4.
•
Send
: allows you to send the message to
another person. Refer to the next steps.
•
Add page
: allows you to add up to 10 pages.
You can move to each page using the Left or
Right key on the message screen.
•
Page timing
: allows you to set how long one
page of the received messages displays. After
a specified time, the display automatically
scrolls to the next page.
Message
1. Enter a new message. Or you can
enter a preset message.
To enter a preset message;
• Press the
Opt.
soft key and select
the
Preset messages
.
• Select one of the preset
messages.
2. Press the
Opt.
soft key and select
the
Done
option to add the
message.
Note
: To return to previous screen while
entering a subject, press and hold
the
C
key.
Item How to add
Messages
120
•
Text effect
: allows you to set the colour, size
and style of the message text.
•
Clear subject
/
/
sound
/
message
:
allows you to delete the subject, image, sound
or message by selected work.
•
Delete page
: allows you to delete the current
page.
•
Save message
: saves the message in
Draft
(see page 124) or
My folder
(see page 125).
Note
: To go back to the edit screen, press the
soft key or the
C
key.
4. When you finish creating the message, select
Send
from the options.
5. Select an entry on the Send screen.
If it is an empty entry, enter a destination as
below.
Number
: to enter a destination number.
Email
: to enter e-mail address.
Phonebook
: to enter a destination from
phonebook.
After entering a destination, press the
Ok
soft
key.
If it is not an empty entry, do the following
things.
Edit address
: to edit the selected address.
Delete address
: to delete the selected address.
Note
: To clear or clear all your input, press or press
and hold the
C
key. When you have no input,
press and hold the
C
key to move to the
previous screen.
Messages
121
6. To send the message to multiple destinations up
to 20, repeat step 4.
7. When you have finished entering the
destinations, press the
Send
soft key.
If you want to cancel a sending message or resend
a message that you failed to send, go to the
Outbox
. Then select the message and the option
in point. For further details, see page 123.
Inbox
Your phone receives incoming messages and saves
them in the Inbox.
When the
Inbox
menu is selected, the list of
messages received displays with the:
• message’s subject or No subject if the message
had no subject.
• sender’s phone number, or name if stored in the
Phonebook.
• message status; for a retrieving message,
for a read message, for a message to
read, for a read notification message and
for a notification message to read.
Note
: The icon of message status can have
various forms like ,
,
as the
priority that sender fixed (see page 131).
To view a message, scroll to it and press the
Select
soft key. But you cannot view the retrieving
message.
To scroll through the message contents, press the
Up or Down key. When the message has more than
one page, you can press the Left or Right key to
move through the pages or the pages are moved
through as predefined page timer, which the sender
sets, has elapsed.
Messages
122
Notes
:
• Some types of sound or picture may not be able to
play or display.
• When the message has an attachment like video
clips, the Attachment icon ( ) appears on the title
line. You may not play the attachment. And you may
also not extract it from the message.
You can choose the following options by pressing
the
Opt.
soft key:
Delete
: deletes the message
Replay
: replays the message.
Reply
: replies to the sender by sending a message.
Forward
: forwards the message to another person.
Call back
: allows you to call the sender back.
Cut media
: extracts the picture or sound, so that
you can set them as a wallpaper or ringtone or you
can send them as a multimedia message.
Cut address
: extracts phone numbers, email
addresses or URL addresses in the text, so that you
can call the number or send a message to the
number or save it in your Phonebook.
Properties
: shows you detailed information about
the message.
Move to My folder
: moves the message to the My
folder for later use.
Messages
123
Outbox
Outbox stores messages that you sent, you failed to
send and you cancelled sending.
When the
Outbox
menu option is selected, the list
of messages you have sent or saved displays with
the:
• message’s subject or No subject if the message
had no subject.
• recipient’s phone number, or name if stored in the
Phonebook.
• message status; for a sending message,
for a sent message, for a message that you
failed to send or you cancelled sending, for a
delivery report. When a receiver retrieves a
message you sent and the
Delivery report
option (see page 131) is set to on, is
changed into .
To view a message, scroll to it and press the
Select
soft key. But you cannot view the sending message.
To cancel a sending message, scroll through and
select the message by pressing the Up or Down key,
and then press the
Select
soft key. Then the
confirming message appears. In the message, you
can cancel sending it by pressing the
Yes
soft key.
To resend the message that you failed to send,
scroll through and select the message by pressing
the Up or Down key, and then press the
Select
soft
key. Then press the
Opt.
soft key, and then select
the
Send
option.
To scroll through the message, press the Up or
Down key. When the message has more than one
page, you can press the Left or Right key to move
through the pages or the pages are moved through
as paging timing that sender fixed automatically.
Messages
124
You can choose the following options by pressing
the
Opt.
soft key:
Delete
: deletes the message.
Replay
: replays the message.
Send
: send the message.
Properties
: shows you detailed information about
the message.
Move to My folder
: moves the message to the
My
folder for later use
.
Draft
This message box stores messages that you save,
interrupted messages by an incoming call, or
messages while you create a new message.
Note
: Saves messages that are failed to send in the
Outbox.
To view a message, scroll to it and press the
Select
soft key.
You can choose the following options by pressing
the
Opt.
soft key:
Send
: replies to the sender by sending a message.
Replay
: replays the message.
Delete
: deletes the message.
Properties
: shows you detailed information about
the message.
Messages
125
My folder
You can move the messages stored in the Inbox or
Outbox to the My folder by using the
Move to My
folder
option. While making a new message, you
can also save to My folder by using the
Save
message
option.
To view a message, scroll to it and press the
Select
soft key.
You can choose the following options by pressing
the
Opt.
soft key:
Delete
: deletes the message.
Replay
: replays the message.
Send
: send the message.
Cut media
: extracts the picture or sound, so that
you can set them as a wallpaper or ringtone or you
can send them as a multimedia message.
Cut address
: extracts phone numbers, email
addresses or URL addresses in the text, so that you
can call the number or send a message to the
number or save it in your Phonebook.
Properties
: shows you detailed information about
the message.
Delete all
This menu option allows you to delete all of the
messages in each message box. You can also delete
all of your messages at one time.
1. Scroll to a message box and place a check mark
ahead of it by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
message boxes.
Messages
126
2. If necessary, repeat step 1 to check another
box.
3. When you have finished checking, press the
Ok
soft key.
4. When a confirming message appears, press the
Yes
soft key to delete all of the messages in the
box(es).
Otherwise, press the
No
soft key.
Push messages
This menu allows you to set to be received and read
push messages.
The following options are available:
Inbox
: Your phone receives push messages and
saves them in the Inbox. And you can read push
messages in the Inbox.
Setting
: This option allows you to set the push
message receiving options.
Always: always push message comes in.
Never: the push message never comes in.
Optional: Only the push messages whose setting
matches to the number in this option come in. The
preset number is SMS service centre. You can also
edit the number.
Delete all
: deletes all of the push messages.
Messages
127
Preset messages
Using this menu, you can preset up to nine
messages that you use most frequently. When you
access this menu, the preset message list displays.
1. Scroll to a message or an empty entry by
pressing the Up or Down key.
2. Press the
Select
soft key and enter a new
message or change the old message.
For further details about entering characters,
see page 48.
3. Press the
Ok
soft key to save the message.
Voice mail
When you receive a voice mail, your phone displays
the icon and you hear an alert.
Connect to voice mail
• In Idle Mode, when you receive a new voice mail,
press the
Connect
soft key to access your voice
mail server and follow the instructions provided.
• In Idle Mode, hold the
1
key down to access your
voice mail server and follow the instructions
provided.
• Call your voice mail server number by accessing
the
Connect to voice mail
menu and follow the
instructions provided.
Messages
128
Voice server number
Before using the voice mail service, you must store
the voice mail server number obtained from your
service provider.
When you select an entry, following options are
available.
Edit number
: enter a voice mail server number or
press the
Phonebook
soft key to enter a number
from the Phonebook. And then press the
Ok
soft
key.
Change name
: enter a server name and press the
Ok
soft key to save it.
Delete
: when the confirming message appears,
press the
Yes
soft key. To cancel, press the
No
soft
key.
Broadcast
This network service allows you to receive text
messages on various topics, such as the weather or
traffic. Messages are displayed immediately as they
are received, provided that:
• the phone is in Idle Mode.
•the
Receive
option is set to
On
.
• the message channel is currently active on the
channel list.
When you get broadcast messages, you can see the
messages in Idle Mode. If it is short you can see the
display, otherwise, press the
CB
soft key to read the
message.
Messages
129
In the
Broadcast
menu option, the following
options are available:
Read
: lets you read the received broadcast
messages.
Archive: shows the list of the messages you saved
from the temporary list.
Temp ora ry: shows the latest messages. These
messages will be gone when the phone is switched
off.
If the message is long, press the UP or Down key.
When you read a message, press the
Options
soft
key to access following options:
Cut number: shows the list of numbers included in
the message.
Save: (Temporary only) saves this message to
Archive list.
Delete: delete this message.
Delete all: delete all message on the list.
Receive
: allows you to turn the reception of
broadcast messages on or off.
Channel
: the check mark inside
All
check box
indicates that the channel is enabled.
To enable or disable this channel press the
Select
soft key, then select
Enable
or
Disable
.
The
Add channel
option allows you to add a new
channel to the channel list. Enter the appropriate
channel code obtained from your service provider
and a title for the channel.
Messages
130
Settings
Short messages
Using this menu, you can set up default SMS
information. The following options are available:
Service centre
: allows you to store or change the
number of your SMS centre required when sending
messages. You must obtain this number from your
service provider.
Validity period
: allows you to set the length of
time your messages are stored at the message
centre while attempts are made to deliver them.
Message type
: allows you to set the message type
to
Text
,
Fax
,
Voice
,
ERMES
,
X400
, or
E-Mail
.
The network can convert the messages into the
selected format.
Reply path
: allows the recipient of your SMS
message to send you a reply via your message
centre, if the service is provided by the network.
Delivery report
: allows you to set on or off. When
this function is set to on, the network informs you
whether or not your message has been delivered.
Character support
: allows you to select the
character set when editing and sending messages.
GSM-alphabet: you can only send the message
using GSM characters.
Uni-code: you can send the message using Unicode
characters, including GSM alphabets. And the
maximum number of characters which can be
entered in a message is reduced to half in length.
Automatic: if you select
Automatic
, the phone
selects the character set according as you use
Unicode characters or not.
Messages
131
Multimedia messages
Using this menu, you can set up default settings for
sending or receiving MMS message. The following
options are available:
Send settings
:
The following options are available:
Priority: allows you to set the priority of message.
Validity period: allows you to set the length of time
your messages are stored at the message centre
while attempts are made to deliver them.
Delivery after: you can set the delay time before
the phone sends your messages.
Address hiding: when this option sets to
On
, your
phone number does not display on the recipients
phone.
Delivery report: when this option sets to
On
, the
network informs you whether or not your message
has been delivered.
Read reply: when this option sets to
On
, your
recipient’s phone sends a reply to let you know
when your message was read by her/him.
Receive settings
: the following options are
available:
Msg. reception: allows you to set how you receive a
message. You can select one of
Manual
,
Automatic
and
Reject
.
Anonymous reject: when this option sets to
On
,
your phone rejects messages without a caller ID.
Adverts reject: when this option sets to
On
, you
can reject advertisements by service provider.
Messages
132
Report allowed: when this option sets to
Off
, your
phone does not send a reply to the recipient’s
phone even if the sender asks for the read reply.
MMS profiles
: in this menu, you can configure
MMS profile settings that are required when you
send or receive multimedia messages.
Current profile: allows you to select one profile to
use currently.
Profile setting: allows you to set up to five profiles.
• Profile name: enter the name of the profile.
• Server URL: enter the address of profile server.
• GSM setting: allows you to change the proxy
settings for the GSM network.
- Gateway: enter the IP address and IP port.
- Data call type: select a network connection
type between ISDN and Analogue.
- Dial number: enter the server phone
number.
- Login ID: enter the server login ID.
- Password: enter the server password.
• GPRS setting: allows you to change the proxy
settings for the GPRS network.
- Gateway: enter the IP address and IP port.
- APN: enter the access point name used for
the address of the GPRS network gateway.
- Login ID: enter the user ID required to
cconnect to GPRS network.
- Password: enter the password required to
connect to the GPRS network.
Messages
133
• Bearer: select the bearer to be used for each type
of network accesses.
- GPRS only: it only work in GPRS network.
- GSM only: it only works in GSM network.
Memory status
You can check the memory status for messages.
Short messages
You can check how many messages are stored in
SIM card and phone’s memory.
When you have finished, press the soft key or
the key to exit.
Multimedia messages
Multimedia message boxes, Camera and Media box
share a given amount of memory in your phone.
The display shows the status of free and used
memory.
You can see the used memory status of multimedia
message boxes, Camera and Media box by pressing
the Left or Right key.
134
Fun box
The
Fun box
menu contains several fun options:
• WWW services
•Media box
•JAVA world
•SIM-AT menu
WWW services
Your phone comes equipped with a WAP (Wireless
Application Protocol) Browser, making it possible for
you to access the Wireless Web.
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service
indicator icon ( or ) appears on the display to
inform you that you are connected to the Wireless
Web and will be billed accordingly. Rates vary
according to your service option.
The WAP Browser ends the network connection
after a certain period of inactivity and automatically
reconnects as necessary. For this reason, you may
find that you are billed for several network
connections within a single session. This is normal
and is designed to minimise your bill.
Fun box
135
Home
When you select this menu option, the phone
connects to the network and loads the homepage of
the Wireless Web service provider.
Once connected, the homepage displays. The
content depends on the service provider.
Note
: To quickly launch the WAP browser from Idle
Mode, press the key.
To scroll through the screen, use the Up and Down
keys.
To exit the browser, press the key at any
time. The phone returns to Idle Mode.
Navigating the wap browser
Entering text in the wap browser
When you are prompted to enter text, the current
text input mode appears above the right soft key.
To Press the
scroll through and
select browser
items
Up or Down key until the item
you want highlights, and then
press the soft key.
select a numbered
item
corresponding numeric key.
return to the
previous page
(or
Back
) soft key or
C
key.
return to the
startup homepage
key and select the
Home
browser option. For details,
see page 136.
Fun box
136
For further information on how to enter text, see
page 48.
Using the WAP browser menus
There are various menu options available when
surfing the Wireless Web.
To access the WAP Browser menu:
1. Press the key or scroll to the logo on the top
left of all WAP pages and then press the soft
key.
A list of options appears.
2. Highlight the required option using the Up or
Down key.
3. Press the soft key to select the option.
4. If necessary, select the secondary option by
pressing the Up or Down key and then press the
soft key.
Note:
The WAP Browser menus may vary,
depending on your version of the browser.
The following WAP Browser menus are available:
Back
: returns to the previous page.
Home
: takes you back at any time to the
homepage of the Wireless Web service provider.
Exit
: exits the WAP browser.
Reload
: reloads the current page.
Show URL
: shows the URL address of the WAP
page you are currently accessing.
About
: shows browser information.
Fun box
137
Using the WAP browser options
Several options are available when you are surfing
the Wireless Web. To access these options, press
the key once connected to the Wireless Web.
Goto URL
: allows you to manually enter the URL
address of the site that you wish to access.
Bookmark
: allows you to use the
Bookmark
menu option. For details, see page 137.
Messages
: allows you to read or write an SMS
message. For details, see page 108.
Media box
: allows you to use your Media box. For
details, see page 140.
Answering a call during a WAP connection
You can receive an incoming call while you are
navigating the WAP browser.
Answer the call by pressing the key or the
Accept
soft key, as you normally would. After
ending the call, you can continue navigating on the
WAP page you were previously accessing.
Bookmark
This menu option allows you to store the URL
addresses of up to 15 of your favourite Web sites.
To store a URL address:
1. Select an empty location and press the
Select
soft key.
2. Enter the address and press the
Ok
soft key to
save it.
Fun box
138
3. Enter the name of the bookmark and press the
Ok
soft key.
For further information about how to enter text,
see page 48.
Once you have stored an address, the following
options are available when you select it.
Go
: allows you to access the site directly.
Edit
: allows you to change the name and URL
address of the bookmark.
Delete
: allows you to delete the bookmark.
Go to URL
This menu option allows you to manually enter the
URL address of the Web site that you wish to
access.
Enter the URL address and press the
Ok
soft key.
For further information about how to enter text, see
page 48.
Clear cache
This menu option allows you to clear the
information stored in the cache, the phone’s
temporary memory used to store the most recently
accessed WAP pages.
Fun box
139
Proxy settings
This menu option allows you to set up five proxy
servers.
Note:
You do not need to change the browser settings
in most cases. Change the settings only when
your network provider asks you to.
For each proxy, the following options are available:
Proxy name
: enter the name of the HTTP proxy
server.
GSM setting
: you can change the proxy settings
for the GSM network.
Gateway: enter the IP Address and IP Port
Data call type: select a network connection type;
ISDN
or
Analogue
.
Dial number: enter the PPP server phone number.
Login ID: enter the PPP server login ID.
Password: enter the PPP server password.
GPRS setting
: you can change the proxy settings
for the GPRS network.
Gateway: enter the IP Address and IP Port.
APN: enter the access point name used for the
address of the GPRS network gateway.
Login ID: enter the user ID required to connect to
the GPRS network.
Password: enter the password required to connect
to the GPRS network.
Fun box
140
Home URL
: you can change the address of your
startup homepage.
When the default homepage displays, you can
delete it using the
C
key and enter your own choice.
To enter any special characters, / for example, use
the Symbolic mode; see page 55.
Bearer
: you can select the bearer to be used for
each type of network accesses.
GPRS first: your phone will search for the GPRS
network first. If this service is not available, you can
set the GSM service temporarily.
GPRS only: the phone only works in GPRS
networks.
GSM only: the phone only works in GSM networks.
Current proxy
This menu option allows you to activate one of the
proxies you set up to use the WAP connection.
Media box
This menu option stores various media items from
other sources, such as the WAP sites, the
EasyStudio PC software or multimedia messages.
Photos
This option allows you to view the taken pictures.
My photos
: allow you to view the photos in my
photos.
Fun box
141
My album1 / My album 2
: allow you to view the
photos in the selected album.
When you view a photo, press the
Options
soft key
to do the followings.
Send
: allows you to send it via a message.
Rename
: allows you to rename it.
Delete
: allows you to delete it.
Move to album
: allows you to move it to one of
the albums.
Set as
: allows you to set it as a wallpaper or a
caller ID.
Wallpaper: allows you to set it as a wallpaper.
Caller ID: allows you to set it as a caller ID.
Protection
: allows you to protect it from deletion
or not.
Properties
: allows you to view the detail
information of the photo.
Images
This option allows you to view the images received
from other sources, such as the WAP sites, the
EasyStudio PC software or multimedia messages.
When you view an image, press the
Options
soft
key to send, rename, delete, set as a wallpaper or
view the properties.
For further details about these options, see the
options of the
Photos
menu (see page 140).
Fun box
142
Sounds
This option allows you to listen to the recorded
voices and the melodies received from other
sources, such as the WAP sites, the EasyStudio PC
software or multimedia messages.
Voices
: allow you to listen to the recorded voices.
My sounds
: allow you to listen to various melodies.
When you select a sound, press the
Options
soft
key to send, rename, delete, set as a ringtone (only
in My sounds) or view the properties.
For further details about these options, see the
options of the
Photos
menu (see page 140).
Delete all
This option deletes all of the photos, images and
sounds in the Media box.
Photos
1. Scroll to a box and place a check mark ahead it
by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
items. If you want to delete the protected
photos and the caller ID photos, select the
With
protected photos
option and the
With caller
ID photos
option.
2. If necessary, repeat step 1 to check another
box.
3. When you have finished checking, press the
Ok
soft key.
Fun box
143
4. When a confirming message appears, press the
Yes
soft key to delete all of the photos in the
box(es).
Otherwise, press the
No
soft key.
Images
When a confirming message appears, press the
Yes
soft key to delete all of the images.
Otherwise, press the
No
soft key.
Sounds
1. Scroll to a sound box and place a check mark
ahead it by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
boxes.
2. If necessary, repeat step 1 to check another
box.
3. When you have finished checking, press the
Ok
soft key.
4. When a confirming message appears, press the
Yes
soft key to delete all of the sounds in the
box(es).
Otherwise, press the
No
soft key
Memory status
Media box, Camera and multimedia message boxes
share a given amount of memory in your phone.
The display shows the status of free and used
memory.
You can see the used memory status of Media box,
Camera and multimedia message boxes by pressing
the Left or Right key.
Fun box
144
JAVA world
You can download MIDlets (Java applications
running on mobile phones) from various sources
using the WAP Browser and store them in your
phone.
Downloads
A list of Java games is displayed. In basic, two pre-
loaded MIDlets (Java games) are provided. If the
list of Java games is empty, a pop up message is
displayed to invite to download a new game. To add
MIDlets to the list, you can download MIDlets from
the Web sites.
SnowBallFight
The goal of this game is to challenge and defeat the
snowball fight champions of four different teams.
Accessing a game
After loading the game, press any key twice to go to
the first menu screen. At the first menu screen,
press key to play a game, or press key to
access the main menu of this game.
To Press the
find a game Up or Down key.
run a game
Launch
soft key.
view detail
information
Info
soft key.
delete the game
Delete
soft key in the
information display.
Fun box
145
Play
: allows you to start a new game or a saved
game. Saved game allows you to continue the
beginning of last stage you played.
Instructions
: shows you the explanation of control
keys, offense items and defense items.
Configuration
: allows you to turn the sound,
vibration on or off and select the game speed from
1 to 5.
Quit
: quits the game and returns to the downloads
menu screen.
Playing a game
Move the character along the street using the
navigation key. If you have enough gold coins which
you can earn while fighting to buy items, you can
buy defense items at the drug store and offense
items at the item shop. Move the character to the
team of current stage and press key to select it.
When the snowball fight game starts, hit the rival
kids with snowballs and avoid theirs. While fighting
you can use items you have. If you raise enough
mana, you can also use special attack. You should
win all fights in four stages in order to challenge the
champions of the snowball fight.
Key Commands
4/6 or Left/Right: move left or right
2,5 or Up, :control the distance at the first press
and throw the snowball at the next press.
8 or Down: use the special attack depending on
your mana
3: enters item mode to use your item, select the
item you want to use by pressing 2, 5, Up or key.
Fun box
146
Special attacks
Level 1: Aurora, all enemies are hit by a snowball.
Level 2: Ice dragon, all enemies are hit by a
snowball and frozen for 8 seconds.
Level 3: Icicle storm, double powered snowball
attack to all enemies and decreasing enemies’
attack accuracy for 10 seconds.
BubbleSmile
BubbleSmile is an arcade puzzle game.
Accessing a game
After loading the game, you will see the following
options, press key to select one of them:
Start game
: allows you to start a new game with
timed mode or skilled mode.
• Timed mode: you have to achieve the best score
before gauge disappear at the time bar. When
you get the same coloured bubble together,
gauge at the time bar increases.
• Skilled mode: you have to make more then 4
bubbles disappear at once for the gauge at the
skill bar increase. If 3 or none of bubbles
disappear, then the gauge decreases.
Continue
: allows you to continue the last game
you played. The menu is only available when a
game has already been played.
High score
: shows you the high score table.
How to play
: shows you the instruction of this
game.
Option
: allows you to set the sound on or off
Fun box
147
Playing a game
Your score goes up when you remove the bubbles.
Only when more than 3 same coloured bubbles line
up horizontally or diagonally, they disappear. To line
up the bubbles, move the band rounding three
bubbles to suitable place and rotate it. When the
game is over, your score is ranked on the high score
board if it is within third.
Key Commands
2, 4, 6, 8, or navigation key: move the band up,
down, left or right
1: rotate the bubbles in the band counterclockwise
3: rotate the bubbles in the band clockwise
Internet settings
This menu option allows you to set the information
to connect the Java server. This information is
provided by the network operator automatically, but
you can change it manually.
APN: enter the access point name used for the
address of the GPRS network gateway.
Login ID: enter the user ID required to connect to
the GPRS network.
Password: enter the password required to connect
to the GPRS network.
DNS settings: enter the DNS address. The DNS
(Domain Name Server) address to connect the Java
server is automatically set when making data call
set up.
Fun box
148
Memory status
You can check the free space for Java download.
The display also shows the total memory and used
memory.
SIM-AT MENU (SIM Application
Toolkit)
If you use a SAT card that provides additional
services, the SAT menu displays. For further details,
see your SIM card instructions.
Shown only if it is supported by your SIM card.
149
Organiser
The Organiser feature enables you to:
• view the calendar and/or write a memo or to do
list.
• set the current date and time, and find out what
time it is in various cities around the world.
• set the alarm so that the phone rings at a specific
time.
• use your phone as a calculator, unit convertor,
timer or stopwatch.
New memo
This menu option allows you to create a new memo.
Note
: You can also access this menu by holding down
the
C
key in Idle Mode.
1. Write your memo of up to 100 characters and
press the
Ok
soft key.
For further information about how to enter text,
see page 48.
2. Select the category of the memo to be saved
and press the
Select
soft key.
The following categories are available:
•
Scheduler
: general schedule events, such as
appointments or meetings.
•
To do list
: tasks you need to do. They are
saved on the to do list.
•
Call
: calls you need to make.
Organiser
150
•
Anniversary
: anniversaries to be
remembered, such as wedding anniversaries,
birthdays or other special days.
Note
: You can save up to 25 items to each
category, so you can save 100 memos
totally.
3. Scroll to a date on the calendar by pressing the
navigation keys. Press the
Select
soft key.
4. If applicable depending on the category you
selected, enter the event time and press the
Ok
soft key.
5. If you have selected the 12-hour time format
(see page 156), select
AM
or
PM
by pressing
the Up or Down key and then press the
Select
soft key.
6. To set an alarm for the memo, press the
Yes
soft key.
Otherwise, press the
No
soft key. The memo is
saved immediately. Go to step 10.
7. Enter the time for the alarm to sound and press
the
Ok
soft key.
8. If you have selected the 12-hour time format
(see page 156), select
AM
or
PM
by pressing
the Up or Down key and then press the
Select
soft key.
9. Select an alarm melody and press the
Select
soft key.
The memo is saved and then displays on the
screen.
Organiser
151
10. You can choose the following option by pressing
the
Options
soft key:
•
Add
: allows you to add a new memo on the
day.
•
Delete
: allows you to delete the memo.
•
Edit
: allows you to edit the memo.
•
Move
: allows you to move the memo to a
different date.
•
Copy
: allows you to copy the memo to a
different date.
11. When you have finished, press the soft key
or the key to exit.
Calendar
The calendar helps you to keep track of schedule,
calls that you need to make, tasks that you need to
do and anniversaries. You can set the alarm to ring
when the set date for a schedule is reached.
Consulting the calendar
To Press the
move to another
day
Left or Right key.
move to another
week
Up or Down key.
move to the
previous or next
month
Up or Down key and hold it
down
move to the
previous or next
year
Left or Right key and hold it
down.
Organiser
152
The following options are available when you press
the
Options
soft key on the Calendar display:
Add memo
: allows you to add a new memo on the
day.
Go to date
: allows you to enter a particular date
and then schedule an event on that date.
View all
: shows all of the events that you have
scheduled.
Delete day
: deletes the scheduled event on the
selected day.
Delete all
: deletes all of the events that you have
scheduled.
Creating a new memo
1. Scroll to a date on the calendar, referring to
page 151, and press the
Select
soft key.
2. Write your memo and press the
Ok
soft key.
For further information about how to enter
characters, see page 48.
3. Select the category of the memo to be saved
and press the
Select
soft key.
The following categories are available:
•
Scheduler
: general schedule events, such as
appointments or meetings.
•
To do list
: tasks you need to do.
•
Call
: calls you need to make.
•
Anniversary
: anniversaries to be
remembered, such as wedding anniversaries,
birthdays or other special days.
Organiser
153
4. Follow the procedure from step 4 on page 150
onwards to save the memo.
Viewing your calendar memos
A date that has a memo associated with it is
highlighted in a red box. If you select a date when
events have already been scheduled, the number of
memos of each type is shown at the bottom of the
calendar.
• : General schedule events
•: To do list
•: Calls
• : Anniversaries
Press the
Select
soft key to view the memos.
If you have created more than one memo on the
same day, you can scroll to the event you want to
view by pressing the Left or Right key.
The following options are available when you press
the
Options
soft key:
Add
: allows you to add a new memo. For further
information about how to add a memo, see
page 149.
Delete
: allows you to delete the memo.
Edit
: allows you to edit the memo.
Move
: allows you to move the memo to a different
date.
Copy
: allows you to copy the memo to a different
date.
Organiser
154
To do list
This menu allows you to view a list of tasks.
To create a new memo of the To do list type:
1. Write the memo about your task and press the
Ok
soft key.
For more information about how to enter
characters, see page 48.
2. Scroll to a date on the calendar, referring to
page 151, and press the
Select
soft key.
3. Follow step 4 on page 150 onwards to save the
memo.
Once you have defined tasks, they are listed with a
status mark ( for Done or for Undo) within
the
To do list
menu.
To scroll to a specific task, press the Up or Down
key and press the
Select
soft key. The task displays
with the deadline, alarm setting, job details and
status mark.
You can scroll to the previous or next task by
pressing the Left or Right key.
The following options are available when you press
the
Options
soft key:
Add
: allows you to add a new task. For details
about adding To do list-type memos, see page 149.
Mark
: allows you to change the status mark.
Edit
: allows you to edit the contents of the task.
Move
: allows you to move the task to a different
date.
Organiser
155
Copy
: allows you to copy the task to a different
date.
Delete
: allows you to delete the task.
Delete all
: allows you to delete all of tasks from
the list.
Clock
This option allows you to change the current time
and date displayed. You can also check the current
time for Greenwich Mean Time (GMT) and 22 major
cities around the world.
The following options are available:
Set time
: allows you to enter the current time. You
can choose the time format in the
Set format
menu option; see page 156.
Note
: Before setting the time, you must specify your
time zone in the
Set world time
menu option.
Set date
: allows you to enter the day, month and
year. You can change the date format in the
Set
format
menu option; see page 156.
Set world time
: allows you to check the current
time in GMT and 22 major cities around the world.
Scroll through the cities using the Left or Right key.
The screen shows the:
•city name.
• current date and time.
• time difference between the selected city and
your city if you have set the local time (see
below) or GMT (by default).
Organiser
156
To select your time zone:
1. Select the city corresponding to your time zone
by pressing the Left or Right key one or more
times.
The local date and time display.
2. Press the
Set
soft key.
4. When you have finished, press the soft key or
the key to exit.
Set format
: allows you to change the time and
date formats.
Time format: 24 hours
12 hours
Date format: DD/MM/YYYY (day/month/year)
YYYY/MM/DD (year/month/day)
3.
To Select
update the current
date/time with this
new setting
Set local
.
indicate that the
time zone is
currently using the
daylight saving
time
Set DST.
The icon is
shown next to the time
difference.
indicate that the
time zone is no
longer using the
daylight saving
time
Remove DST
(only
available when the
icon is shown next to the
time difference).
Organiser
157
Alarm
This option allows you to set an alarm to ring at a
specific time. You can set up to three alarms or set
the phone to ring an alarm when it is switched off.
To set an alarm:
1. Select either
Morning call
,
Alarm1
or
Alarm2
by pressing the Up or Down key.
The icon means that no alarm is currently
set. The icon means that an alarm has
already been set.
2. Press the
Select
soft key.
3. Press the
Options
soft key.
4. Scroll to an option by pressing the Up or Down
key and press the
Select
soft key. Change the
setting, as needed.
•
Alarm day
: place or remove a check mark on
the day(s) of the week by pressing the
Select
soft key. If you want to set a daily alarm,
select
Everyday
. If you want to set a
temporary alarm, select
Once
alarm
. When
you press the
Ok
soft key after selecting, your
phone asks you to enter the alarm time.
•
Alarm time
: enter the time for the alarm to
sound.
•
Alarm tone
: select an alarm melody.
•
Remove alarm
: deactivates the alarm.
Note
: The alert type of Alarm1 and 2 is affected by
the alert type of incomming call. Moring call’s
alert type is always melody.
5. Repeat step 4 to change each setting.
Organiser
158
6. When you have finished, press the soft key or
the key to exit.
Once an alarm has been set, you can see the Alarm
icon ( ) on the top line of the display. To stop the
alarm when it rings, press any key.
Note
: When the Quiet Mode is activated, the alarm
tone doesn’t sound. But When you set an
Morning call, it sounds the alarm tone even if
the Quiet Mode is activated.
To set the alarm to ring even if your phone is
switched off:
1. Scroll to
Auto power
on the Alarm list and
press the
Select
soft key.
2. If necessary, press the Up or Down key to select
On
.
To turn the Auto Power feature off, select
Off
.
3. Press the
Select
soft key to save the setting.
4. When you have finished, press the soft key or
the key to exit.
Once you have activated the auto power alarm, a
check mark appears ahead of
Auto power
. If the
phone is switched off at the specified alarm time, it
automatically switches on and rings the alarm. It
then automatically switches off again.
To turn off an alarm:
• Press the
Confirm
soft key.
• When the mornig call’s alarm tone sounds, press
any key or the
Snooze
soft key to stop the alarm
for five minutes, after which it will resume. You
can do this a maximum of five times.
Organiser
159
The snooze alarm tone sounds while the phone is
switched off and the
Auto power
is set to on, and
the Quiet Mode is activated. If you reset the moring
call’s alarm time or deactivate the morning call’s
alarm, the snooze alarm is cancelled.
Calculator
You can use the phone as a calculator. The
calculator performs basic arithmetic functions, such
as addition, subtraction, multiplication, division and
remainder computation.
To perform a calculation:
1. Enter the first number using the number keys.
Note
: To erase any mistakes or clear the display,
press the
C
key.
2. Press the key to enter a decimal point (
.
) or
the key to enter the appropriate arithmetic
symbol:
+
(add),
-
(subtract),
(multiply),
/
(divide),
%
(remainder),
(
or
)
.
3. Enter the second figure.
4. Repeat steps 2 and 3, if necessary.
5. Press the
Equal
soft key to view the result.
The result appears in the
Answer
box.
Note
: The result is rounded to six decimal places.
6. When you have finished, press the soft key or
the key to exit.
Organiser
160
Conversion
This menu option allows you to convert from one
type of unit to another.
To c onv ert a va lue:
1. Scroll to the type of conversion to be performed
from
Length
,
Weight
,
Volume
,
Area
and
Temperature
, and press the
Select
soft key.
2. Enter the value to be converted and press the
Down key to move to the
From
field.
You can enter a decimal point (.) using the
key. And you can enter a minus (-) using the
key in
Temperature
.
3. Select the original unit by pressing the Left or
Right key and press the Down key to move to
the
To
field.
Refer to the table on the following page for the
units available.
4. Select the required unit by pressing the Left or
Right key.
5. Press the
Ok
soft key or the key to view the
result.
The result appears in the
Answer
box.
6. When you have finished, press the soft key or
the key to exit.
Organiser
161
Units available
Timer
Using the Timer feature, you can set the phone to
sound an alarm after a certain time.
1. Press the
Set
soft key.
2. Enter the length of time you want to count down
in hours and minutes and press the
Ok
soft key.
3. Press the
Start
soft key to start counting down.
Even if you exit the Timer screen, the timer will
continue running. After the specified time has
expired, the phone informs you by playing a melody
and displaying a text notification.
Type Units
Length mm cm m
km in ft
yard mile
Weight g kg ton
grain oz pound
Volume cm
3
m
3
l
in
3
ft
3
yd
3
gal
Area cm
2
m
2
a
in
2
ft
2
yd
2
acre
Temperature °C °F
Organiser
162
To stop the timer melody when it rings, press any
key.
To stop the timer before the end, press the
Stop
soft key on the Timer screen.
Notes
:
• The timer uses power from the battery consequently,
the phone’s operating time is reduced.
• When the Quiet Mode is activated, there is no sound.
Stopwatch
The stopwatch can be used to measure times for
various sports.
Example: Running or swimming races
Up to four stopwatches can be used.
The precision of the stopwatch is one hundredth of
a second. The maximum measurement time is 10
hours.
1. To start the stopwatches, press the
Ok
soft key.
2. When you wish to stop the first stopwatch, press
the
Ok
soft key. Repeat this step for the other
stopwatches.
3. Press the
Reset
soft key to reset the watches.
4. Press the
C
or key to exit.
163
Camera
Using the camera module embedded in your phone,
you can take pictures for people or events while on
the move. Additionally, you can send photos to
other people in a picture message or as an e-mail
attachment. The camera produces JPEG pictures.
CAUTIONS
:
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras
are not
allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
Take photos
This menu allows you to take a picture to send the
photo as a picture message to other destinations.
You can use the picture as a background and store
it separately in My album folder.
Taking a picture
1. Slide the folder up.
2. To access the Take photos menu directly, press
the Up key in Idle Mode. And then press the
Select
soft key when
Take photos
highlights.
To take pictures immediately in Idle Mode, press
and hold the Up key.
The image to be captured appears on the
display.
Camera
164
The icons on the top line of the display indicate
the size, quality, flash type and current mode
(shown if you select the multi-shot mode or
night mode).
3. Adjust the image by aiming the camera to the
subject.
To Press the
adjust the brightness of
the picture
Left or Right key.
zoom in or out the
Up or Down key.
flip the picture up and
down
volume up key
reverse the picture like a
mirror image
volume down key
turn the viewfinder’s
frame on or off
1
key
change the picture size
2
key
change the picture
quality
3
key
select the mode
4
key
select the effect
5
key
go to the
Settings
menu
6
key
select the frame
7
key
select the delay time
8
key
go to the
My photos
menu
9
key
Camera
165
For more information about these functions, see
“Using the camera options” on page 166.
4. Press the soft key to take a picture.
The picture is automatically saved in the
My
photos
(see page 169).
When you press the
Options
soft key after taking a
picture, the following options are available. Scroll
the option you want by pressing the Up and Down
keys and press the
Select
soft key:
Send
: allows you to send a multimedia message
using the taken picture. For further details about
sending multimedia messages, see page 114.
Rename
: allows you to rename the taken picture.
switch the camera flash
on or off (if you set the
Manual
option in the
Flash light
menu. See
page 168, 171)
0
key
5.
To Press the
use the options
Options
soft key.
For details about the
options, see below.
delete the picture file
Delete
soft key.
return to the capture
mode to take another
picture.
C
key.
turn the camera off
and return to Idle Mode
key.
To Press the
Camera
166
Go to my photos
: allows you to see the taken
pictures in the
My photos
(see page 169).
Set as
: allows you to set it as a wallpaper or a
caller ID.
Wallpaper: allows you to set it as a wallpaper.
Caller ID: allows you to set it as a caller ID.
Protection
: allows you to protect the taken picture
from deletion or not.
Properties
: this option shows you information
about the picture, such as name, size, date,
resolution, protection type and format.
Using the camera options
When you press the soft key in the capture
mode, the following options are available for the
current shot:
Mode
: You can take a picture in various modes.
Once you change the mode, its indicator appears at
the top left on the display.
Normal shot: you can take a picture in the normal
mode.
Multi-shot: you can take action stills. Select speed
and the number of pictures you want to take. When
you press the soft key, the phone automatically
takes and saves the pictures successively as many
times as you set. The Mobile (128*120) size will be
set by default.
Note
: The zoom control bar and the brigthness control
bar do not display when you use the multi-shot
mode.
Camera
167
Night mode: this option allows you to take a picture
of the best quality when it is dark.
Capture only: you can take pictures without review.
Frame
: this option allows you to use a frame on
the picture. Press the navigation key to find the
frame format you want to use. You can preview the
image with the frame format by using the
Preview
soft key. The Mobile (128*120) size will be set by
default.
Note
: The zoom control bar and the brigthness control
bar do not display when you use the frame.
Effects
: this option allows you to apply special
effects to the picture. Press the Up or Down key to
find the tone you want to use.
Gray
,
Negative
,
Sepia
,
Emboss
and
Sketch
are available. To
deactivate the effect setting, select
Off
.
Rotation
: this option allows you to flip the image
vertically or reverse it as a mirror image.
Timer
: you can select the delay time. When you
press the capture key, the phone takes the picture
after the specified time. When you exit the camera
mode or select
Off
in the
Timer
menu, the timer is
off.
Settings
: this option allows you to change the
settings for taking a picture. And this option is
synchronized with the
Settings
menu. See
page 170.
Photo size: sets the image size to one of
VGA(640*480)
,
QVGA(320*240)
,
QQVGA(160*120)
and
Mobile(128*120)
. The
selected image size displays on the capture screen.
Camera
168
Photo quality: allows you to select the image quality
from
Super fine
,
Fine
,
Normal
, and
Economy
.
The option you select appears on the top of the
display.
Shutter sound: allows you to select a sound when
you press the shutter, the soft key.
Note
: This sound setting is not applied to the multi-
shot sound.
Flash light: allows you to set the camera flash to
use automatically or not.
• Manual: to switch the camera flash on or off, you
have to press the
0
key in the capture mode.
• Automatic: when you press the shutter, the
soft key, the phone lights a flashlight. After a
while the camera takes a picture and the
flashlight go out.
Default name: allows you to change the default
prefix name of the picture.
Help
: this option shows you the functions of the
navigation keys and the volume keys in the capture
mode.
Camera
169
My photos
In this menu, you can review the pictures you have
taken.
My albums
My Album allows you to store the pictures as your
photo album. Select one of albums. It shows the
pictures saved in the album. For details about
viewing your pictures and using them, see
page 169.
To Press the
scroll through the
pictures
navigation keys.
show the selected picture
as an enlargement
View
soft key.
go back to the multiple
view mode
Multi
soft key.
use the options
Options
soft key.
For details, see
page 165.
turn the camera off
and return to Idle Mode
key.
Camera
170
Delete all
You can delete all the photos saved in each
category.
1. Scroll to a photo box and place a check mark
ahead it by pressing the
Select
soft key.
Selecting
All
places check marks on all of the
photo boxes. If you want to delete the protected
photos and the caller ID photos, select the
With
protected photos
option and the
With caller
ID photos
option.
2. If necessary, repeat step 1 to check another
box.
3. When you have finished checking, press the
Ok
soft key.
4. When a confirming message appears, press the
Yes
soft key to delete all of the photos in the
box(es).
Otherwise, press the
No
soft key.
Settings
This menu option allows you to change the default
settings of the options for using the camera feature.
The following options are available:
Photo size
: sets the image size to one of
VGA(640*480)
,
QVGA(320*240)
,
QQVGA(160*120)
and
Mobile(128*120)
. The
selected image size displays on the capture screen.
Camera
171
Photo quality
: allows you to select the image
quality from
Super fine
,
Fine
,
Normal
, and
Economy
. The option you select appears on the top
of the display.
Shutter sound
: allows you to select a sound when
you press the shutter, the soft key.
Note
: This sound setting is not applied to the Multi-
shot sound.
Flash light
: allows you to set the camera flash to
use automatically or not.
Manual: to switch the camera flash on or off, you
have to press the
0
key in the capture mode.
Automatic: when you press the shutter, the soft
key, the phone lights a flashlight. After a while the
camera takes a picture and the flashlight go out.
Default name
: allows you to change the default
prefix name of the picture.
Memory status
Camera, Media box and multimedia message boxes
share a given amount of memory in your phone.
The display shows the status of free and used
memory.
You can see the used memory status of Camera,
Media box and multimedia message boxes by
pressing the Left or Right key.
172
Phone settings
Many different features of your phone can be
customised to suit your preferences via the
Phone settings
menu.
Display
You can change the background image and the
colour of the components on the display according
to your preference and needs.
Wallpaper
This option allows you to change the background
image to be displayed in Idle Mode.
The following options are available:
Animations
: allows you to select one of the
animations.
Photos
: allows you to select one of the photos
taken by the camera.
Images
: allows you to select one of the images in
the
Images
in the
Media box
menu that are
downloaded from the WAP sites, the EasyStudio PC
software or multimedia messages.
Text position
: allows you to select the position of
the text displayed on the idle screen, such as the
operator’s name, current date and time, and text
notifications of missed calls or new messages.
Choose either
Top
or
Bottom
. If you set this option
to
Off
, your phone displays only the wallpaper
image.
Phone settings
173
Text style
: allows you to set the style of the text
displayed on the idle screen.
Note:
When you set the wallpaper image to
Calendar
, the Text position and Text style
options don’t work.
Skin
You can change the colour setting of the display
components, such as soft key indications area or
the menu names and icons.
Backlight
You can specify how long the phone uses the
backlight.
Select how long the backlight remains on after the
last key is pressed.
LCD brightness
This option allows you to adjust the brightness of
the display screens to make them lighter or darker.
1. Adjust the contrast by using the Up and Down
keys or the volume keys on the left side of the
phone.
2. When you are satisfied, press the
Ok
soft key to
save the selection.
Service display
You can turn off the service display or change the
time interval of the service display.
Phone settings
174
Greeting message
This menu option allows you to set a greeting
message to be displayed briefly when the phone is
switched on.
When you access this menu, the current message
displays.
For further information on how to enter text, see
page 48.
To Press the
clear the existing
message
C
key and hold it down.
enter a new
message
appropriate alphanumeric
keys.
save your input
Ok
soft key.
cancel your input
and return to Idle
Mode
key.
Phone settings
175
Security
The security settings enable you to restrict the use
of your phone to the people and types of calls of
your choice.
Various codes and passwords are used to protect
the features of your phone. For more information,
see page 187 -189.
PIN check
When the PIN Check feature is enabled, you must
enter your PIN each time you switch the phone on.
Consequently, any person who does not have your
PIN cannot use your phone without your approval.
Note
: Before disabling the PIN Check feature, you
must enter your PIN.
The following options are available:
Disable
: the phone connects directly to the
network when you switch it on.
Enable
: you must enter the PIN each time the
phone is switched on.
To change your PIN, see the
Change PIN
menu
option below.
Change PIN
This feature allows you to change your current PIN
to a new one, provided that the PIN Check feature
is enabled. You must enter the current PIN before
you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone settings
176
Phone lock
When the Phone lock feature is enabled, the phone
is locked and you must enter the 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the
factory. To change the phone password, see the
Change password
menu option below.
Once the correct password has been entered, you
can use the phone until you switch it off.
The following options are available:
Disable
: you are not asked to enter the phone
password when you switch the phone on.
Enable
: you are required to enter the phone
password when you switch the phone on.
Change password
The Change password feature allows you to change
your current phone password to a new one. You
must enter the current password before you can
specify a new one.
The password is preset to “00000000” at the
factory. Once you have entered a new password,
you are asked to confirm it by entering it again.
Privacy
This feature allows you to lock or unlock the usage
of the contents, such as multimedia messages,
photos, images and sounds.
To enable or disable the Privacy feature, you must
enter your phone password.
Phone settings
177
SIM lock
To enable the SIM lock feature, you must enter a
new four- to eight-digit SIM lock code, and confirm
it by entering it again.
The following options are available:
Disable
: you can use any other SIM cards with
your phone.
Enable
: you must enter the SIM lock code to use
another SIM card with your phone.
To unlock the SIM, enter the SIM lock code.
FDN mode
The FDN (Fixed Dial Number) mode, if supported by
your SIM card, allows you to restrict your outgoing
calls to a limited set of phone numbers.
The following options are available:
Disable
: you can phone any number.
Enable
: you can only call phone numbers stored in
Phonebook. You must enter your PIN2.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
To change your PIN2, see the
Change PIN2
menu
option below.
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the
current PIN2 before you can specify a new one.
Phone settings
178
Once you have entered a new PIN2, you are asked
to confirm it by entering it again.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
Auto redial
With the Auto Redial function, the phone makes up
to ten attempts to redial a phone number after an
unsuccessful call.
Note
: The interval between two call attempts varies.
The following options are available:
Off
: the number is not redialled.
On
: the number is redialled automatically.
Voiceclarity
The voiceclarity feature makes received sound loud
and clear during a call. It is useful when you are in
a noisy place.
The following options are available:
Off
: allows you turn off the this function.
On
: allows you turn on the this function.
Phone settings
179
Slide down operation
You can select the phone’s action when you slide
the folder down.
Stop operation
: when you slide the folder down,
the phone stops the current operation and locks the
keypad automatically.
Continue operation
: when you slide the folder
down, the phone performs the current operation
continuously. But the confirming message to lock
the keypad appears on the display in the Idle Mode.
Active slide
You can answer incoming calls by sliding the folder
up or not.
Off
: you have to press a key to answer a call,
depending on the setting of the
Anykey answer
option. See below.
On
: you can simply slide the folder up to answer a
call.
Anykey answer
You can answer incoming calls by pressing anykey
or not.
Off
: you can only press or the
Accept
soft key
to answer incoming calls.
On
: you can press any key, except and the
Reject
soft key to answer incoming calls.
Phone settings
180
Fax mode
You can use your phone as a modem for faxing
when it is connected to computing devices. You
need to purchase a data kit from your local
Samsung dealer.
In this menu, you can enable the fax mode on your
phone.
The following options are available:
Off
: you can send or receive data calls.
On
: you can send or receive fax calls.
In any case you can send or receive voice calls.
After connecting the phone to your computing
device using the data cable and set this menu to
On
. Your phone works as a fax modem.
For further details about setting and faxing through
the phone on your computer, see the computers
user’s manual.
Infrared activation
In this menu, you can activate or deactivate the
infrared port.
The following options are available:
Off
: deactivates infrared feature on the phone.
On
: activates the infrared feature on the phone.
The IrDA icon ( ) appears on the top line of the
display.
Phone settings
181
If there is no communication between your phone
and the IrDA-compliant device within 1 minute of
activating the feature, it is automatically
deactivated.
Reset settings
This menu option allows you to reset your phone to
its default configuration. You can reset the sound
settings, phone settings or all of the settings
together.
1. Select one of the settings to reset by pressing
the
Select
soft key.
2. When a confirming message appears, press the
Yes
soft key to reset settings. Then enter the
phone password and press the
Ok
soft key.
The password is preset to “00000000” by
default. To change it, see page 176.
Otherwise, press the
No
soft key.
182
Using ALS (Alternate
Line Service)
The ALS feature enables two lines to be associated
with one SIM card. Consequently, you can make
and receive calls on either line. If you subscribe to
this network service, a few additional menu options
enable you to set up this feature.
Note:
Please contact your service provider to check
the availability of this feature and how to
subscribe to ALS.
Selecting a line
You can select a line for each call via the
Active
line
menu option. For further details, refer to
page 101.
Editing the line name
You can edit the name of each line via the
Own
number
menu option.
When you edit the name of a line, this name
replaces “Line 1” or “Line 2”, as applicable. For
further details, refer to page 73.
Setting the ring type
To distinguish between incoming calls on the two
lines, you can select a different ring tone for each
line via the
Incoming calls
menu option. For
further details, see page 102.
Using ALS (Alternate Line Service)
183
Setting call diverting options
You can set up call diverting via the
Call diverting
menu option. This service reroutes incoming calls
on the line of your choice to a specified number. For
further details, see page 94.
Viewing call information
You can view call times and last call cost
information for each line. For further details, see
page 92.
184
Solving problems
Before contacting the after-sales service, perform
the following simple checks. They may save you the
time and expense of an unnecessary service call.
When you switch your phone on, the
following messages may appear
No SIM card
Check that the SIM card is correctly installed.
Phone locked Enter password
The Phone lock feature is enabled. You must enter
the phone’s password before you can use the
phone.
Enter PIN
• You are using your phone for the first time. You
must enter the Personal Identification Number
supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, you must enter the PIN. To
disable this feature, use the
PIN check
menu
option. See page 175.
Enter PUK
The PIN was entered wrongly three times in
succession and the phone is now blocked. Enter the
PUK supplied by your network operator.
Solving problems
185
“No service” displays
• The network connection was lost. You may be in a
weak reception area (in a tunnel or surrounded
by buildings). Move and try again.
• You are trying to access an option for which you
have not taken out a subscription with your
service provider. Contact the service provider for
further details.
You have entered a number but it was
not dialled
• Have you pressed the key?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring option.
Your correspondent cannot reach you
• Is your phone switched on (the key pressed
for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring option.
Your correspondent cannot hear you
speaking
• Have you switched off the microphone (
Mute
appears)?
• Are you holding the phone close enough to your
mouth? The microphone is located at the bottom
of the phone.
Solving problems
186
The phone starts beeping and “Battery
Low” flashes on the display
The battery is insufficiently charged. Replace the
battery and recharge it.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ); the number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialled when you recall a
Phonebook entry
• Check that the number has been stored correctly,
by using the Phonebook Search feature.
• Re-store them, if necessary.
If the above guidelines do not help you to solve
the problem, take a note of:
• the model and serial numbers of your phone
•your warranty details
• a clear description of the problem
Then contact your local dealer or Samsung
after-sales service.
187
Access codes
There are several access codes that are used by
your phone and its SIM card. These codes help you
protect the phone against unauthorised use.
Some access codes can be changed using the
Security
menu option. See page 175 for further
details.
Phone password
The Phone lock feature (see page 176) uses the
phone password to protect your phone against
unauthorised use.
The phone password is supplied with the phone and
is preset to “00000000” at the factory. To change
the password, use the
Change password
menu
option. See page 176.
PIN
The PIN (Personal Identification Number) protects
your SIM card against unauthorised use. It is
usually supplied with the SIM card. When the PIN
Check feature is enabled (see page 175), you must
enter the PIN each time you switch on the phone.
If you key in an incorrect PIN three times in
succession, key in the PUK and press the
Ok
soft
key to unlock the phone. Key in a new PIN and
press the
Ok
soft key. Key in the new PIN again and
press the
Ok
soft key.
Access codes
188
PIN2
The PIN2, supplied with some SIM cards, is required
to access some functions, such as charging unit
counters. These functions are only available if
supported by your SIM card.
If you key in an incorrect PIN2 three times in
succession, key in the PUK2 and press the
Ok
soft
key to unlock the phone. Key in a new PIN2 and
press the
Ok
soft key. Key in the new PIN2 again
and press the
Ok
soft key.
PUK
The PUK (PIN Unblocking Key) is required to change
a blocked PIN. The PUK may be supplied with the
SIM card. If not, contact your local service provider.
If you key in an incorrect PUK ten times in
succession, the SIM card cannot be used anymore.
Contact your service provider for a new card.
You cannot change the PUK. If you lose the code,
contact your service provider.
PUK2
The PUK2, supplied with some SIM cards, is
required to change a blocked PIN2.
If you key in an incorrect PUK2 ten times in
succession, you cannot use the functions requiring
the PIN2. Contact your service provider for a new
card.
Access codes
189
You cannot change the PUK2. If you lose the code,
contact your service provider.
Call barring password
The 4-digit call barring password is required when
you use the Call Barring function. You obtain the
password from your service provider when you
subscribe to this function.
You can change this password using the
Change
barring
password
menu option. For further
details, see page 98.
190
Health and Safety
Information
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that were
developed by independent scientific organizations
through periodic and through evaluation of scientific
studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health.
The exposure standard for wireless phones employs a
unit of measurement known as Specific Absorption
Rate (SAR). The SAR limit set by the FCC is 1.6W/kg *.
*In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements.
safety-end-NorthA 1/27/03 2:05 PM Page 125
192
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
193
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output of
the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the limit established by the
government-adopted requirement for safe exposure.
The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by
the FCC for each model. While there may be
differences between the SAR levels of various phones
and at various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone is
attached separation paper.
For Body Operation
To maintain compliance with FCC RF exposure require-
ments, use only belt-clips, holsters or similar accessories
that maintain a 1.5 cm. separation distance between the
user's body and the back of the phone, including the
antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components
in its assembly. The use of accessories that do not
satisfy these requirements may not comply with FCC
RF exposure requirements, and should be avoided.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
safety-end-NorthA 1/27/03 2:05 PM Page 126
195
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of
a car, practice good common sense and remember
the following tips.
194
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Precautions When Using Batteries
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time to
buy a new battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to
a charger for more than a week, since overcharging
may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
safety-end-NorthA 1/27/03 2:05 PM Page 128
197
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
196
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that you
are driving and suspend conversations that have
the potential to divert your attention from the
road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is
a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives
are in danger, call the emergency number, as you
would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal,
a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or any other special non-
emergency wireless number.
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping
through your phonebook takes your attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
safety-end-NorthA 1/27/03 2:05 PM Page 130
199
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
198
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Wireless Technology Research.
Persons with pacemakers:
• Should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such interference,
you may wish to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information. Switch off your phone in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the
independent research and recommendations of
safety-end-NorthA 1/27/03 2:05 PM Page 132
201
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
200
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by
location.
3. Press the <SEND> key.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before
you can make an emergency call. Consult this
document and your local cellular service provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
safety-end-NorthA 1/27/03 2:05 PM Page 134
203
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
202
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with a wet hand while it is
charging. Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit
boards.
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or in
the air bag deployment area. If wireless equipment
is improperly installed and the air bag inflates,
serious injury could result.
• Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
safety-end-NorthA 1/27/03 2:05 PM Page 136
205
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
204
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint it. Paint can clog the device’s moving
parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as
a microwave oven, a stove or a radiator. The phone
may explode when overheated.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified
service facility. The personnel there will assist you,
and if necessary, arrange for service.
Acknowledging Special Precautions and the FCC
and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment. FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following measures:
safety-end-NorthA 1/27/03 2:05 PM Page 138
207
AAppppeennddiixx
Appendix A: CERTIFICATION INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency(RF)
energy set by the Federal Communications Commission
of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on safety standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate(SAR). The SAR limit set by the FCC is
1.6 W/kg. SAR Tests are conducted using standard
operating positions accepted by the FCC with the
phone transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
206
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
safety-end-NorthA 1/27/03 2:05 PM Page 140
209
Appendix B: Guide to Safe and Responsible Wireless
Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE
ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE
WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE,
ANYTIME-WITH THE BOSS, WITH A CLIENT, WITH THE
KIDS, WITH EMERGENCY PERSONNEL OR EVEN WITH
THE POLICE. EACH YEAR, AMERICANS MAKE BILLIONS
OF CALLS FROM THEIR WIRELESS PHONES, AND THE
NUMBERS ARE RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable
tool, but good judgment must be exercised at all times
while driving a motor vehicle-whether on the phone or
not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within
the speed limit. It means using seatbelts and requiring
other passengers to do the same.
208
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government-
adopted requirement for safe exposure. The tests are
performed in positions and locations(e.g., at the ear and
worn on the body) as required by the FCC for each
model.
The highest SAR values for this model phone as reported
to the FCC are Head: 0.202W/Kg, Body-worn: 0.433W/Kg,
PTT:0.074W/Kg
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as
in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHE820N.
In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6
watts/kilogram(W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety
to give additional protection for the public and to
account for any variations in measurements.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 142
211
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are speaking
with know you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay
attention to the road.
5. Do not take notes or look up phone numbers while
driving. If you are reading an address book or business
card, or writing a “to do” list while driving a car, you are
not watching where you are going. It’s common sense.
Don’t get caught in a dangerous situation because you
are reading or writing and not paying attention to the
road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan your calls before you begin your trip or
attempt to coincide your calls with times you may be
stopped at a stop sign, red light or otherwise stationary.
But if you need to dial while driving, follow this simple
tip-dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are distracting
and even dangerous when you are behind the wheel of a
car. Make people you are talking with aware you are
driving and if necessary, suspend conversations which
have the potential to divert your attention from the road.
210
But with wireless phone use, driving safely means a
little more. This brochure is a call to wireless phone
users everywhere to make safety their first priority when
behind the wheel of a car. Wireless telecommunications
is keeping us in touch, simplifying our lives, protecting us
in emergencies and providing opportunities to help
others in need. When it comes to the use of wireless
phones, safety is your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember.
1. Get to know your wireless phone and its features such
as speed dial and redial. Carefully read your instruction
manual and learn to take advantage of valuable features
most phones offer, including automatic redial and
memory. Also, work to memorize the phone keypad so
you can use the speed dial function without taking your
attention off the road.
2. When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach
and where you can grab it without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, if possible, let your voice mail answer
it for you.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 144
212
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to
protect yourself and your family in dangerous situations-
with your phone at your side, help is only three numbers
away. Dial 9-1-1 or other local emergency number in the
case of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a perfect
opportunity to be a “Good Samaritan” in your community.
If you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 9-1-1
or other local emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special wireless non-
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a
vehicle you know to be stolen, call roadside assistance
or other special non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
213
their responsibilities as safe drivers and good citizens.
As we approach a new century, more and more of us will
take advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a
responsibility to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-
com.com/consumer/issues/driving/articles.cfm?ID=85
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 146
215
low level RF that does not produce heating effects
causes no known adverse health effects. Many studies
of low level RF exposures have not found any biological
effects. Some studies have suggested that some
biological effects may occur, but such findings have not
been confirmed by additional research. In some cases,
other researchers have had difficulty in reproducing
those studies, or in determining the reasons for
inconsistent results.
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to
emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require
the manufacturers of wireless phones to notify users of
the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
Support needed research into possible biological effects
of RF of the type emitted by wireless phones;
Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
Cooperate in providing users of wireless phones with the
214
Appendix C: Consumer Update on Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called cell,
mobile, or PCS phones. These types of wireless phones
can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the
phone and the user s head. These RF exposures are
limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA
and other federal health and safety agencies. When the
phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF
exposure decreases rapidly with increasing distance
from the source. The so-called “cordless phones,” which
have a base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and
thus produce RF exposures well within the FCC’s
compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radiofrequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 148
217
4. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radiofrequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result
of this work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
5. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
216
best possible information on possible effects of wireless
phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Federal Communications Commission
Occupational Safety and Health Administration
National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF exposure.
FCC relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 150
219
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in
the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
7. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they are
used against the head or against the body. Either
configuration should result in compliance with the safety
limit.
8. Do wireless phone accessories that claim to shield the
head from RF radiation work?
218
If there is a risk from these products—and at this point
we do not know that there is—it is probably very small.
But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your
exposure to radiofrequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless
phone will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected
to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can use
measures like those described above to reduce your RF
exposure from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to users
of wireless phones, including children and teenagers. If
you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described
above would apply to children and teenagers using
wireless phones. Reducing the time of wireless phone
use and increasing the distance between the user and
the RF source will reduce RF exposure.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 152
221
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for
hearing aids and wireless phones so that that no
interference occurs when a person uses a compatible
phone and a compatible hearing aid at the same time.
This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve
the problem.
10. What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF)
exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer-causing chemicals so
as to be pre-disposed to develop cancer in the absence
of RF exposure. Other studies exposed the animals to RF
for up to 22 hours per day. These conditions are not
similar to the conditions under which people use
wireless phones, so we don t know with certainty what
220
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special
phone cases, while others involve nothing more than a
metallic accessory attached to the phone. Studies have
shown that these products generally do not work as
advertised. Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation of the
phone. The phone may be forced to boost its power to
compensate, leading to an increase in RF absorption. In
February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed to
protect wireless phone users from radiation with making
false and unsubstantiated claims. According to FTC,
these defendants lacked a reasonable basis to
substantiate their claim.
9. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 154
223222
the results of such studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period of
phone use in these studies was around three years.
11. What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few
years. However, very large numbers of animals would be
needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide
data that is directly applicable to human populations, but
10 or more years follow-up may be needed to provide
answers about some health effects, such as cancer. This
is because the interval between the time of exposure to
a cancer-causing agent and the time tumors develop - if
they do - may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
12. Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-
slc.gov/SLTC/radiofrequencyradiation/index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 156
224
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet and take full
advantage of the features of your mobile phone,
here are a few definitions.
ALS (Alternate Line Service)
Capability of associating two lines with one SIM
card. With this service, you can make and receive
calls on either line, as required.
Call barring
Ability to restrict outgoing and incoming calls.
Call diverting
Ability to reroute calls to another number.
Call holding
Ability to put one call on standby while answering or
making another call; you can then switch between
the two calls, as required.
Call waiting
Ability to inform users that they have an incoming
call when engaged on another call.
CLI (Caller Line Identification) services
Services allowing subscribers to view or block the
telephone numbers of callers.
Glossary
225
EMS (Enhanced Message Service)
Network service sending and receiving messages
that include images, sounds and animations to and
from another user without having to speak to the
correspondent.
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a mobile
telephone network. GPRS guaranties continuous
connection to the Internet for mobile phone and
computer users. It is based on the Global System
for Mobile Communication (GSM) circuit-switched
cellular phone connections and the Short Message
Service (SMS).
GSM (Global System for Mobile
communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
IrDA (Infrared Data Association)
A standard defined by the IrDA consortium. It
specifies a way to wirelessly transfer data via
infrared radiation. The IrDA specifications include
standards for both the physical devices and the
protocols they use to communicate with each other.
MMS (Multimedia Message Service)
A message service for the mobile environment,
standardized by the WAP Forum and the 3rd
Generation Partnership Program (3GPP). For phone
Glossary
226
users, MMS is similar to Short Message Service
(SMS)-it provides automatic, immediate delivery of
user-created content from phone to phone. The
message addressing used is primarily phone
numbers, thus the traffic goes from phone to
phone. MMS also provides support for e-mail
addressing, so that messages can also be sent by
e-mail. In addition to the text content of SMS, MMS
messages can contain still images, voice or audio
clips, and later also video clips and presentation
information.
Multiparty calling
Ability to establish a conference call involving up to
five additional parties.
PIN (Personal Identification Number)
Security code that protects the phone/SIM against
unauthorised use. The PIN is supplied by the
service provider with the SIM card. It may be a four
to eight-digit number and can be changed, as
required.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your home
area (when travelling for example).
Glossary
227
SDN (Service Dialling Numbers)
Telephone numbers supplied by your network
provider and giving access to special services, such
as voice mail, directory inquiries, customer support
and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small slot
on the back of the phone and is protected by the
battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to
speak to the correspondent. The message created
or received can be displayed, received, edited or
sent.
Soft keys
Two keys marked and on the phone, the
purpose of which:
• varies according to the function that you are
currently using
• is indicated on the bottom line of the display just
above the corresponding key
Voice mail
Computerised answering service that automatically
answers your calls when you are not available,
plays a greeting (optionally in your own voice) and
records a message.
228
Index
A
ABC mode •
48
,
52
Access codes •
187
Accessories •
13
Active line
select •
101
service, use •
182
Alarm, set •
157
Alert type •
103
ALS •
182
Autopower alarm •
158
B
background image, set •
172
Backlight •
20
Barring
calls •
96
Battery
charging •
25
installing •
23
low battery indicator •
26
precautions •
191
removing •
24
Broadcast •
128
Browser, WAP •
134
C
Calculator •
159
Calendar •
151
Caller
groups •
74
ID •
101
Calls
alert type •
103
answering •
35
a second call •
41
barring •
96
costs •
92
dialled •
91
diverting •
94
emergency •
196
ending •
34
holding •
40
international •
32
log •
32
making •
31
missed •
33
,
90
multi-party •
42
received •
90
records •
90
redialling •
32
automatically •
178
rejecting •
35
ring tone •
102
searching for a number
in phonebook •
63
times •
92
waiting •
41
,
99
Card, SIM
dialling numbers •
69
inserting •
22
locking •
177
removing •
23
Care •
198
Characters
entering •
48
Clock •
155
Conference calls •
42
Connection tone •
105
Conversion, unit •
160
Cost of calls •
92
D
Date, set •
155
Dialled calls •
91
Dialling •
31
SIM card numbers •
69
Display
brightness •
173
icons •
18
DTMF tones, send •
38
E
Ear-microphone •
45
Earpiece volume •
35
Emergency calls •
196
Index
229
F
FDN mode •
177
Fixed Dial Number mode •
177
Fun box •
134
Functions, select •
28
G
Greeting message •
174
Group settings •
74
I
Icons •
18
Inbox •
111
Input mode
changing •
49
International calls •
32
Internet •
134
K
Key tones
type, select •
106
volume •
35
Keys
location •
14
L
LCD
brightness •
173
icons •
18
settings •
172
Length of calls •
92
,
106
Letters
entering •
48
Locking
phone •
176
SIM card •
177
Low battery indicator •
26
M
Maintenance •
198
Media box •
140
Memory status, phonebook •
75
Memos
making •
149
,
152
viewing •
153
Menu
list •
57
scrolling •
56
Messages
MMS •
114
SMS •
108
Messages •
108
alert types •
103
broadcast •
128
deleting •
114
,
125
greeting •
174
inbox •
111
outbox •
113
preset •
127
reading •
111
ring tone •
103
voice mail •
127
writing •
109
Microphone, mute •
36
Minute minder •
106
Missed calls •
33
,
90
Multi-party calls
making •
42
private conversation •
44
removing a participant •
44
N
Names
entering •
48
searching/dialling •
63
storing •
66
Network selection •
100
Network services •
94
Numbers
correcting •
31
FDN •
177
mode •
48
,
55
speed-dial •
67
storing •
66
Index
232
O
Options, select •
28
Organiser •
149
Outbox •
113
,
123
P
Password
barring •
98
,
189
phone •
176
,
187
Personal Identification
Number •
187
Phone
layout •
14
settings •
172
switching on/off •
27
Phonebook •
63
copying numbers •
65
,
66
deleting numbers •
66
editing numbers •
65
erasing numbers •
66
memory status •
75
sending SMS •
65
storing numbers/names
•
66
PIN •
187
changing •
175
checking •
175
PIN2 •
188
changing •
177
Power on/off tone •
105
Preset messages •
127
Problem, solve •
184
PUK •
188
PUK2 •
188
Push to talk
76
Q
Quiet mode •
106
R
Received calls •
90
Redialling
automatically •
178
Reset settings •
181
Ringer
incoming calls •
102
messages •
103
Road safety •
193
S
Safety
batteries •
191
electronic devices •
194
explosive atmospheres •
196
information •
190
,
197
medical devices •
195
operating environment •
193
precautions •
7
road •
193
Second call, answer•
41
Security settings •
175
Service directory, dial •
75
Settings
alarm •
157
date •
155
display •
172
network •
94
phone •
172
reset •
181
security •
175
sound •
102
time •
155
SIM card
dialling numbers •
69
inserting •
22
locking •
177
removing •
23
SMS •
108
Soft keys, use •
28
,
29
Sound settings •
102
Speed-dialling •
68
Stopwatch •
162
Switching on/off
microphone •
36
phone •
27
Symbolic mode •
48
,
55
Index
233
T
T9 mode •
48
,
50
Text
entering •
48
input modes •
48
Time
setting •
155
world •
155
Timer •
161
To do list •
154
Tone
connection •
105
keypad •
106
message •
103
power on/off •
105
Travel adapter •
25
V
Voiceclarity •
39
Volume
call ringer •
103
earpiece •
35
keys •
35
W
Waiting call •
41
,
99
WAP Browser •
134
World time •
155
WWW Services •
134
Index
234
237
Access
the menu
functions
➀
Press the
Menu
soft key
in Idle Mode.
➁
Scroll with the
navigatioin keys through
the main menus until
you reach the required
menu. And then press
the
Select
soft key.
➂
Scroll with the Up or
Down key through the
list of options until the
required option is
selected.
➃
Press the
Select
soft key
to confirm.
Each of the two soft keys ( and )
performs the function indicated by the
text above them, on the bottom line on
the display.
Switch on/
off
Press and hold the
key.
Make a call
➀
Enter the number.
➁
Press the key.
End a call Press the key.
Answer a
call
Press the key.
Adjust the
volume
Press the volume keys
on the left side of the
phone.
SGH-E820P GPRS telephone
Quick reference card
238
Redial the
last
number
Press the key twice.
Speed-
dial
In Idle Mode, hold down the
appropriate key (
2
to
9
).
Or, press the key and the
key.
Dial a
number
in your
SIM card
Enter the SIM location,
press the key, and press
the key.
Listen to
your
voice
mail
Press and hold the
1
key.
Store
numbers in
Phonebook
➀
Enter the number.
➁
Press the
Save
soft
key.
➂
Select the memory
type and press the
Select
soft key.
➃
If you select
Phone
,
select the number type
and press the
Select
soft key.
➄
Enter the name and
press the
Ok
soft key.
➅
If you select
SIM
, enter
the location number and
press the
Ok
soft key.
Search for
a number in
Phonebook
➀
Press the
Phonebook
soft key in Idle Mode.
➁
Select
Find name
.
➂
Enter a name.
➃
Press the
Ok
soft key.
➄
Press the Left or Right
ke y, if nece ssary.
➅
Press the key to dial.
