Section 8: Changing Your Settings 101
Display Settings
Section 8
For example, if you set On for 30 seconds and Dim for 15
seconds, after 30 seconds the backlight on the keys would
turn off and 15 seconds later the display light would turn
off.
Press the Left or Right Navigation key to adjust the
settings.
Dialing display
This menu allows you to select the size and color of your
dialing font.
To change the size of the font:
1. Highlight the Font size option and press the Select soft
key or the key.
2. Use the Left or Right navigation key to select between
Large, Medium, or Small.
3. Press the Save soft key or the key to save your
change. Otherwise, press the Cancel soft key.
To change the color of the font:
1. Highlight the Font color option and press the Select soft
key or the key.
2. Use the Left or Right navigation key to select either
Basic (black), Rainbow, or Monochrome.
3. Press the Save soft key or the key to save your
change. Otherwise, press the Cancel soft key.
Show Caller Information
By turning this option on, when you miss a call, caller
information such as name will be displayed on your
display when your missed calls are listed. You can also
t609.book Page 101 Sunday, January 15, 2006 2:03 PM
Section 8
102
select the With Front LCD option to have the information
displayed on the front display screen.
Sound Settings
You can customize various sound settings for your phone.
Incoming call
Get More MegaTones
Using the Get More MegaTones option, you can access
the web site preset by T-Mobile and download new
sounds.
Get More HiFi Ringers
Using the Get More HiFi Ringers option, you can access
the web site preset by T-Mobile and download new HiFi
Ringers.
Note: When downloading MegaTones® or HiFi Ringers TM, charges may
apply.
RingTone
This menu allows you to select a ring melody. Highlight
RingTone and press the key. Use the Up or Down key
and select My sounds, Music, or Default sounds. Then use
the key to select a ringtone.
Volume
This menu allows you to adjust the ring volume to one of
5 levels.
Use the Right or Left navigation key to increase or
decrease the volume.
t609.book Page 102 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 103
Sound Settings
Section 8
Alert type
This menu allows you to specify how you are to be
informed of incoming calls. Use the Right or Left
navigation key to select a ring tone.
The following options are available:
•Melody: the phone rings using the ring melody selected in the
Ringtone menu.
•Vibration: the phone vibrates but does not ring.
•Vibration then melody: the phone vibrates 3 times and then
starts ringing.
Keypad tone
This menu allows you to select the key tone and volume
that the phone sounds when you press a key.
Use the Right or Left navigation key to make your
selections.
To turn off the sound, select Off.
Message tone
This menu allows you to set the message tone for
incoming Text, Picture, and Broadcast messages. You can
set the Tone, Alert type, and Repetition.
Use the Right or Left navigation key to make your
selections.
Power on/off
This menu allows you to select the melody that the phone
sounds when it is switched on and off.
To turn off the sound, select Off.
t609.book Page 103 Sunday, January 15, 2006 2:03 PM
Section 8
104
Folder tone
This menu allows you to select the melody that the phone
sounds when you open or close your phone.
To turn off the sound, select Off.
Silent mode
This menu allows you to select whether or not your phone
will vibrate while in quiet mode. You may choose between
Vibration and Mute.
Extra tones
You can customize additional tones for the phone.
1. To turn a given tone on, press the key. A check mark
displays in front of the option.
2. To turn a given tone off, press the key. The check
mark no longer displays in front of the option.
The following options are available:
•Minute minder: sets whether or not the phone beeps every
minute during an outgoing call to keep you informed of the
length of your call.
•Connection tone: sets whether or not the phone beeps when
your call is connected to the system.
•Alerts on call: sets whether or not you receive tones when a
message arrives while you are on a call.
Network Services Settings
Call forwarding
This network service enables incoming calls to be
rerouted to the number that you specify.
t609.book Page 104 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 105
Network Services Settings
Section 8
Example: You may wish to forward your business calls to a colleague
while you are on holiday.
To set your call forwarding options:
1. Select a call forwarding option by pressing the Up or
Down Navigation key and then press the Select soft key
or the key.
The following options are available:
•Forward always: all calls are forwarded.
•Busy: calls are forwarded when your phone is busy.
•No reply: calls are forwarded when your phone is not
answered.
•Unreachable: calls are forwarded when you are not in an
area covered by your service provider or when your phone is
switched off.
•Cancel all: all call forwarding options are canceled.
2. Select the type of calls, Voice calls or Data calls, by
pressing the Up or Down Navigation key, and then press
the Select soft key or the key.
The current status displays. If the option has already
been set, the number to which the calls are forwarded
displays.
3. To activate call forwarding, select Activate by using the
Left or Right navigation key.
4. To deactivate call forwarding, select Deactivate by using
the Left or Right navigation key.
t609.book Page 105 Sunday, January 15, 2006 2:03 PM
Section 8
106
5. Enter the number to which the calls are to be forwarded
in the Forward to text box and press the Select soft key
or the key.
To enter an international code, press and hold the
key until the + sign displays.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Call barring (SIM Dependent)
Call Barring allows you to restrict specific types of
incoming and outgoing calls for your phone. This is useful
if you allow someone to use your phone for a short period
of time.
Call waiting
This network service informs you when someone is trying
to reach you during another call.
You can specify individual call waiting options for voice
calls and/or data calls.
To set your call waiting options:
1. Select the type of calls, Voice calls or Data calls, to
which the call waiting option is to be applied by pressing
the Up or Down Navigation key and then press the
Select soft key or the key.
The screen informs you whether call waiting is activated
or deactivated.
2. Highlight Activate or Deactivate and press the Select
soft key or the key.
3. Call waiting will then be activated or deactivated.
t609.book Page 106 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 107
Network Services Settings
Section 8
4. Select the Cancel all option to deactivate Call waiting
on all voice and data calls.
Network selection
The Network Selection feature enables you to
automatically or manually select the network used when
roaming outside of your home area.
Note: You can select a network other than your home network only if there
is a valid roaming agreement between the two.
To change Network Selection mode:
1. Highlight the Search now option and press the Select
soft key or the key.
2. Press the Up or Down Navigation key until the network
you want highlights and then press the Select soft key or
the key.
The phone will scan for that network and you will be
connected.
To change you Default setup:
1. Highlight the Default setup option and press the Select
soft key or the key.
2. Highlight either the Automatic or Manual option and
press the Select soft key or the key.
If you select Automatic, you are connected to the first
available network when roaming.
3. If you select Manual, press the Up or Down Navigation
key until the network you want highlights and then press
the Select soft key or the key.
t609.book Page 107 Sunday, January 15, 2006 2:03 PM
Section 8
108
The phone will scan for that network and you will be
connected.
Caller ID
You can prevent your phone number from being
displayed on the phone of the person being called.
Note: Some networks do not allow you to change this setting.
The following options are available:
•Default: the default setting provided by the network is used.
•Hide number: your number does not display on the other
person’s phone.
•Send number: your number is sent each time you make a call.
Bluetooth
About Bluetooth
Bluetooth is a short-range wireless communications
technology capable of exchanging information over a
distance of about 30 feet without requiring a physical
connection.
Unlike infrared, you don't need to line up the devices to
beam information with Bluetooth. If the devices are
within a range of one another, you can exchange
information between them, even if they are located in
different rooms.
The following Bluetooth options are available:
t609.book Page 108 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 109
Bluetooth
Section 8
Turn Bluetooth On/Off
This option allows you to turn Bluetooth On or Off. Make
a selection and press the Select soft key or the key.
My devices
This option allows you to search for new Bluetooth
devices. Highlight the Search new device option and
press the Select soft key or the key. The phone will
search for available devices.
My visibility
This option allows you to turn your visibility to On or Off.
Make a selection and press the Select soft key or the
key.
My phone name
This option shows the name given to your phone for
Bluetooth purposes. You can edit the name if needed.
Security modes
This option allows you to set your security modes to On
or Off. Make a selection and press the Select soft key or
the key.
Features
Actually, the Bluetooth specification is a protocol that
describes how the short-range wireless technology
works, whereas individual profiles describe the services
supported by individual devices. Profiles reduce the
chance that different devices will not work together.
The following Service profiles are available:
t609.book Page 109 Sunday, January 15, 2006 2:03 PM
Section 8
110
•Headset: The remote Bluetooth headset enables outgoing and
incoming calls.
•Handsfree: The remote Bluetooth car kit enables outgoing and
incoming calls.
•Serial port: The remote Bluetooth device acts as a virtual serial
port.
•Dial up networking: The remote Bluetooth device enables
Internet access through a phone modem.
•File transfer: The remote Bluetooth device enables users to
transfer files from their handset to others.
•Object push: The remote Bluetooth device enables the transfer
of personal data (e.g. vCard, vCalendar, etc.) to other devices.
Security Settings
The Security feature enables you to restrict the use of your
phone by others and to restrict the types of calls.
Various codes and passwords are used to protect the
features of your phone.
PIN check
When the PIN Check feature is enabled, you must enter
your PIN each time you switch on the phone.
Consequently, any person who does not have your PIN
cannot use your phone without your approval.
Note: Before enabling or disabling the PIN Check feature, you must enter
your PIN.
The following options are available:
•Disable: the phone connects directly to the network when you
switch it on.
t609.book Page 110 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 111
Security Settings
Section 8
•Enable: you must enter the PIN each time the phone is
switched on.
Change PIN
This feature allows you to change your current PIN,
provided that the PIN check feature is enabled. You must
enter the current PIN before you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone lock
When the Phone lock feature is enabled, the phone is
locked and you must enter the 4- to 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the factory. To
change the phone password, see "Change password" on
page 111.
Once the correct password has been entered, you can use
the phone until you switch it off.
The following options are available:
•Disable: you are not asked to enter the phone password when
you switch on the phone.
•Enable: you are required to enter the phone password when
you switch on the phone.
Change password
The Change password feature allows you to change your
current phone password to a new one. You must enter the
current password before you can specify a new one.
t609.book Page 111 Sunday, January 15, 2006 2:03 PM
Section 8
112
The password is preset to “00000000” at the factory. Once
you have entered a new password, you are asked to
confirm it by entering it again.
Note: If you change your password, be sure to write it down and keep it in
a safe place. If you forget your password, your phone will require service to
have it unlocked.
Privacy
Using the Privacy option, you can lock everything on your
phone with the exception of making a call. The password
must be entered to access Menu mode or t-zones.
To enable Privacy:
1. Highlight the Enable option and press the Select soft key
or the key.
2. Enter your password and press the OK soft key or the
key.
3. “Privacy Activated” will appear on your screen.
To disable Privacy:
1. Highlight the Disable option and press the Select soft
key or the key.
2. Enter your password and press the OK soft key or the
key.
3. “Privacy Deactivated” will appear on your screen.
Note: The password is preset to “00000000” at the factory. To change this
password, see "Change password" on page 111.
t609.book Page 112 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 113
Voice Recognition Settings
Section 8
FDN mode
FDN (Fixed Dial Number) mode, if supported by your
SIM card, allows you to restrict your outgoing calls to a
limited set of phone numbers.
The following options are available:
•Disable: you can call any number.
•Enable: you can only call phone numbers stored in Phonebook.
You must enter your PIN2. You can obtain your PIN2 from your
service provider.
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the current
PIN2 before you can specify a new one. Once you have
entered a new PIN2, you are asked to confirm it by
entering it again.
Note: Not all SIM cards have a PIN2. If your SIM card does not, this menu
does not display.
Voice Recognition Settings
You can adjust the settings and preferences for
VoiceSignal by opening the Voice recognition settings
menu.
To access the VoiceSignal Settings menu, while in the
VoiceSignal application, follow these steps:
1. Press the Settings soft key.
2. Use the navigation keys to select the setting you want to
change.
t609.book Page 113 Sunday, January 15, 2006 2:03 PM
Section 8
114
Or, to access the VoiceSignal Settings menu, from Idle
mode, follow these steps:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Settings icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight Voice recognition settings and press the
Select soft key or the key.
The following options are available:
•Choice Lists: if VoiceSignal is not absolutely confident that it
has correctly identified a name or number, it can display a
choice list of up to three possibilities, and prompt you to
confirm the correct one. You can control when choice lists
appear by changing the Choice Lists setting to the following:
•Automatic: VoiceSignal displays a choice list when it is not
confident it has identified the correct choice from among
multiple alternatives.
•Always On: when there are multiple alternatives, VoiceSignal
always displays a choice list.
•Always Off: VoiceSignal never displays a choice list. Instead,
the application picks the best from among the possible
choices.
•Sensitivity: in VoiceSignal, sensitivity controls the balance
between rejecting too much, which means the phone
frequently does not recognize names, numbers, or commands,
and rejecting too little, which means it frequently recognizes
something even if nothing was said. When VoiceSignal rejects
an utterance, it displays a message such as “Please repeat…”
or “No match found.” If you frequently experience these
messages, you might be able to get better recognition by
adjusting the Sensitivity setting toward Reject Less. If you
t609.book Page 114 Sunday, January 15, 2006 2:03 PM
Section 8: Changing Your Settings 115
Reset Settings
Section 8
frequently experience false activations (VoiceSignal detects a
wrong match), you might be able to get better performance by
adjusting the Sensitivity setting toward Reject More.
•Digit Dialing: use the Digit Dialing menu to adapt digit dialing
to your voice.
•Adapt Digits: lets you adapt digits, which can improve
voice recognition of phone numbers. Adaptation takes about
60 seconds.
•Reset Digits: erases any digit adaptation you have done and
resets digit recognition to the factory default. If you have not
adapted digits, this option is grayed out.
•Sound: you can customize the VoiceSignal user interface by
turning playback on or off for prompts, names, and numbers.
You can also change the speed and volume of name playback.
•Prompts: turns playback on or off for prompts such as
“Please say a command.”
•Digits: turns playback on or off for digits, for example, when
confirming a phone number.
•Names: turns playback on or off for names.
•Name settings: adjusts the speed and volume of name
playback.
•About: displays information about VoiceSignal including version
number, build number, and device number.
Reset Settings
From this menu you can reset your phone and sound
settings to the default settings.
The following options are available:
•All: Phone, Display, and Sound settings will be returned to
default values.
t609.book Page 115 Sunday, January 15, 2006 2:03 PM
Section 8
116
•Phone settings: only phone settings will be returned to
default values.
•Display settings: only display settings will be returned to
default values.
•Sound settings: only sound settings will be returned to
default values.
To reset your settings:
1. Highlight one of the options and press the key to
place a check mark next to the option.
2. Press the Reset soft key.
3. You will be prompted with Reset settings?. Press the
Yes soft key.
4. Enter the 4- to 8-digit password and press the OK soft
key or the key. You will receive a Reset confirmation
message.
The password is preset to “00000000.” To change this
password, see "Change password" on page 111.
t609.book Page 116 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 117
Section 9
Section 9: Fun & Apps
Topics Covered
• File Manager
• Games
• Audio Player
•Camera
• Voice Recognition
•Organizer
•PIM Sync
This section outlines the various applications that are
available on your phone.
t609.book Page 117 Sunday, January 15, 2006 2:03 PM
118
Section 9
File Manager
File Manager allows you to manage your sounds, images,
icons, music, and videos in one convenient location.
Sounds
In this menu, you can view the list of sounds downloaded
from the web server or received in multimedia messages.
You can set a downloaded sound as the current ring tone.
Note: When downloading MegaTones® or HiFi Ringers TM, charges may
apply.
The following options are available:
Get More MegaTones
Using the Get More MegaTones option on the sounds
list, you can access the web site preset by T-Mobile and
download new sounds.
Get More HiFi Ringers
Using the Get More HiFi Ringers option on the sounds
list, you can access the web site preset by T-Mobile and
download new HiFi Ringers.
My sounds
Highlight an item in the My sounds menu and press the
Options soft key. The following options are available:
•Download new: takes you to t-zones where you can download
new sounds.
•Play: plays the sound.
•Send via: allows you to send the sound via Picture message or
Bluetooth.
t609.book Page 118 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 119
File Manager
Section 9
•Set as: allows you to set the sound as your Ringtone, a Caller
ringtone, or an Alarm tone.
•Move to memory card: allows you to move the sound to your
TransFlash memor y card.
•Copy to memory card: allows you to copy the sound to your
TransFlash memory card.
•Delete: allows you to delete the sound or delete all sounds.
•Rename: allows you to change the name of the sound.
•Share for Bluetooth: allows the sound to be shared or
released for the use of another Bluetooth device.
•Protection: allows you to lock the sound to protect it from
deletion.
•Properties: displays the sound name, date, format, length,
size, and protection.
Voice list
The Voice list contains your recorded audio messages.
Highlight an item in the Voice list menu and press the
Options soft key. The following options are available:
•Play: plays the audio message.
•Send via: allows you to send the audio message via Picture
message or Bluetooth.
•Move to memory card: allows you to move the audio message
to your TransFlash memory card.
•Copy to memory card: allows you to copy the audio message
to your TransFlash memory card.
•Delete: allows you to delete the audio message or delete all
audio messages.
•Rename: allows you to change the name of the audio message.
t609.book Page 119 Sunday, January 15, 2006 2:03 PM
120
Section 9
•Share for Bluetooth: allows the audio message to be shared or
released for the use of another Bluetooth device.
•Protection: allows you to lock the audio message to protect it
from deletion.
•Properties: displays the audio message name, date, format,
length, size, and protection.
Memory card
Select this option to see the sounds that you have saved to
your memory card.
Note: The Memory card option will only appear if a TransFlash memory
card has been inserted in your phone.
Images
In this menu, you can view the list of images downloaded
from the web server or received in messages. You can set
a downloaded image as the current background image.
The following options are available:
Get More Wallpapers
Using the Get More Wallpapers option, you can access
the web site preset by T-Mobile and download new
images.
My Album
This menu provides the ability for you to view the photos
you have stored on the t-zone browser. Use the following
procedures to access My Album.
Note: When viewing photos on My Album, charges may apply.
t609.book Page 120 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 121
File Manager
Section 9
1. In your t-zone browser, select the My Albums Menu link
and press the Select soft key or the key.
2. Photos sent to this folder are stored in the Inbox Album.
Press the Select soft key to view the photos.
3. Press the key to exit t-zones and return to the Idle
screen.
My Journal
This menu provides the ability for you to store your
photos using the t-zone browser.
Note: When storing photos on My Journal, charges may apply.
My downloads
This menu allows you to access your downloaded
images.
Scroll to the image you want to view. By pressing the
Options soft key you can access the following options:
•Download new: takes you to t-zones where you can download
new images.
•View: displays the image.
•Send via: allows you to send the image via Picture message or
Bluetooth.
•Set as: allows you to set the image as Wallpaper or as a Caller
ID.
•Move to memory card: allows you to move the item to the
TransFlash memory card.
•Copy to memory card: allows you to copy the item to the
TransFlash memory card.
t609.book Page 121 Sunday, January 15, 2006 2:03 PM
122
Section 9
•Delete: allows you to delete the image.
•Rename: allows you to change the name of the item.
•Display mode: allows you to see your images displayed in a
Line view or in Thumbnail view.
•Slide show: allows you to see all of your photos in a slide show
presentation.
•Share for Bluetooth: allows the image to be shared or released
for the use of another Bluetooth device.
•Protection: allows you to lock the image to protect it from
deletion.
•Properties: displays the image name, date, format, resolution,
size, quality, and protection.
My photos
In this menu you can review the photos you’ve taken.
Highlight a photo and press the Options soft key to
choose from the following options:
•View: displays the photo.
•Send to My Album: sends the photo to My Album.
•Send via: allows you to send the image via Picture message or
Bluetooth.
•Default destination: allows you to remove or replace the
default destination.
•Set as: allows you to set the photo as Wallpaper or as a Caller
ID.
•Move to memory card: allows you to move the photo to the
TransFlash memory card.
•Copy to memory card: allows you to copy the photo to the
TransFlash memory card.
•Delete: allows you to delete the photo.
t609.book Page 122 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 123
File Manager
Section 9
•Rename: allows you to change the name of the photo.
•Display mode: allows you to see your images displayed in a
Line view or in Thumbnail view.
•Slide Show: allows you to see all of your photos in a slide show
presentation.
•Share for Bluetooth: allows the photo to be shared or released
for the use of another Bluetooth device.
•Protection: allows you to lock the image to protect it from
deletion.
•Properties: displays the image name, date, format, resolution,
size, and protection.
Memory card
Select this option to see the images that you have saved to
your memory card.
Note: The Memory card option will only appear if a TransFlash memory
card has been inserted in your phone.
Videos
In this menu, you can view a list of videos downloaded
from the web server or received in multimedia messages.
The following options are available:
Downloaded videos
This menu allows you to access your downloaded video
clips.
Scroll to the video you want to view. By pressing the
Options soft key you can access the following options:
•Play: plays the video.
t609.book Page 123 Sunday, January 15, 2006 2:03 PM
124
Section 9
•Send via: allows you to send the video via Picture message or
Bluetooth.
•Move to memory card: allows you to move the video to the
TransFlash memory card.
•Copy to memory card: allows you to copy the video to the
TransFlash memory card.
•Delete: allows you to delete the video.
•Rename: allows you to change the name of the video.
•Display mode: allows you to see your videos displayed in a
Line view or in Thumbnail view.
•Share for Bluetooth: allows the video to be shared or released
for the use of another Bluetooth device.
•Protection: allows you to lock the video to protect it from
deletion.
•Properties: displays the video name, date, format, resolution,
size, length, quality, and protection.
My videos
In this menu you can review the photos you’ve taken.
Highlight a video and press the Options soft key to
choose from the following options:
•Play: plays the video.
•Send via: allows you to send the video via Picture message or
Bluetooth.
•Move to memory card: allows you to move the video to the
TransFlash memory card.
•Copy to memory card: allows you to copy the video to the
TransFlash memory card.
•Delete: allows you to delete the video.
•Rename: allows you to change the name of the video.
t609.book Page 124 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 125
File Manager
Section 9
•Display mode: allows you to see your videos displayed in a
Line view or in Thumbnail view.
•Share for Bluetooth: allows the video to be shared or released
for the use of another Bluetooth device.
•Protection: allows you to lock the video to protect it from
deletion.
•Properties: displays the video name, date, format, resolution,
size, length, quality, and protection.
Memory card
Select this option to see the videos that you have saved to
your memory card.
Note: The Memory card option will only appear if a TransFlash memory
card has been inserted in your phone.
Music
My music
This options allows you to access your MP3 files in your
Music list.
Memory card
Select this option to see the music files that you have saved
to your memory card.
Note: The Memory card option will only appear if a TransFlash memory
card has been inserted in your phone.
Other files
This option allows you to view other types of files that you
have stored on your phone. This includes Excel
spreadsheets, text files, wmf files, PowerPoint
t609.book Page 125 Sunday, January 15, 2006 2:03 PM
126
Section 9
presentations, PDFs, MHTML, JPEGs, GIFs, BMPs, and
Word documents. You can send these files by picture
message or Bluetooth. You can also move or copy the files
to your memory card.
Memory card
You can check the contents of your TransFlash memory
card and see what has been saved there. Press the Up or
Down navigation keys to scroll between Sounds, Images,
Videos, Music, and Other files.
After selecting a folder, press the Options soft key for the
following options:
•Open: allows you to open the folder so you can access its
contents.
•Create folder: allows you to create a new folder.
•Properties: lists the folder name, date, format, size, and
protection.
•Memory card info: lists the Memory card capacity, used space,
and free space.
Note: The Memory card option will only appear if a TransFlash memory
card has been inserted in your phone.
For more information on downloading files from your PC
to your Memory card, contact your service provider.
Memory status
You can check the amount of memory being used and
memory remaining for sounds, music, images, videos,
and other files. You can select Phone or Memory card.
Press the Left or Right navigation keys to scroll between
size and count.
t609.book Page 126 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 127
Games
Section 9
Games
You can download MIDlets (Java applications that run on
mobile phones) from various sources using t-zones and
store them in your phone.
When you access the Games menu, the list of default
games appears. Once you have downloaded games, they
are added to the list.
Note: Java services may not be available, depending on your service
provider.
Get more games
You can download more games from the web site preset
by your service provider using the Get more games
option.
My games
1. Scroll to the MIDlet you want on the Games list and press
the key.
2. The startup screen of the MIDlet will be displayed along
with game options. Use the Navigation keys to scroll
between options. Press the key to make a selection.
Note: MIDlet game options will differ depending on the MIDlet you select.
Audio Player
The Audio Player can be used to play files you have
loaded from your PC to your TransFlash memory card.
t609.book Page 127 Sunday, January 15, 2006 2:03 PM
128
Section 9
Note: The following characters cannot be used in the filename:
/ \ * ? “ < > : | 9
The file name is limited to 47 total characters).
1. In the Fun & Apps menu, select Audio player and press
the Select soft key or the key.
2. Before you select an MP3, press the Options soft key to
select from the following options:
•Add music from: allows you to add music from your Phone
or memory card.
•Settings: allows you to set these settings; repeat mode,
shuffle, visualization, backlight, and volume.
After you select an MP3, press the Options soft key to
select from the following options:
•Play: allows you to listen to the MP3 from your phone.
•Open playlist: allows you to view your Music list and select
other songs.
•Add music from: allows you to add music from your Phone
or memory card.
•Remove from playlist: removes the selected MP3 from
your current playlist.
•Settings: allows you to set these settings; repeat mode,
shuffle, visualization, backlight, and volume.
•Properties: allows you to view MP3 name, date, format,
bitrate, length, size, and protection.
3. Highlight the Add music from option and press the
Select soft key or the key.
t609.book Page 128 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 129
Camera
Section 9
4. Depending on where your MP3s are stored, highlight the
Phone or memory card option and press the Select soft
key or the key.
5. Press the Up or Down navigation keys to highlight the
song or songs you want to listen to. Press the key to
checkmark the songs.
6. Press the Add soft key. The marked songs will be added
to your Music list.
7. Press the Options soft key and highlight the Play option.
Press the Select soft key or the key to play your
music.
8. While listening to an MP3, press the Options soft key for
the following options:
•Pause: allows you to pause the song you are listening to.
Press the to resume the song.
•Open playlist: allows you to open My playlist or Current
playlist.
•Add music from: allows you to add music from your Phone
or memory card.
•Remove from play list: removes the MP3 from your
current playlist.
•Settings: allows you to set these settings; repeat, shuffle,
equalize, 3D sound, visualization, MP3 skin, and volume.
•Properties: allows you to view MP3 name, date, format,
bitrate, length, size, and protection.
Camera
For information on using your camera and camcorder,
see "Section 10: Camera and Camcorder" on page 145.
t609.book Page 129 Sunday, January 15, 2006 2:03 PM
130
Section 9
Voice Recognition
VoiceSignal is advanced speech recognition software
that can be used to activate a wide-variety of functions
on your phone. VoiceSignal software automatically
voice activates all contacts for voice dialing and
searching, no pre-recording or training needed. Speak
phone numbers naturally to dial, and use voice
commands to launch applications and navigate phone
menus.
VoiceSignal Options
The following is a list of functions that you can
perform using VoiceSignal speech recognition on your
phone.
•Call <Name or #>: dial by saying either a Name or a number in
your Contacts list
•Send Text<Name>: send a text message to a number or to
someone in your Contacts List.
• Lookup <Name>: open the contact record for any name in
your Contacts list.
•Go To <App>: open any application installed on your device.
•Check <Item>: provides details of your network coverage,
signal strength, and battery level.
Call Digit Dialing
Digit Dial allows you to dial any phone number by
simply speaking the digits into the phone. No training
is necessary, and Digit Dial is programmed to
understand natural speech.
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
t609.book Page 130 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 131
Voice Recognition
Section 9
2. After a brief pause, a list of optional commands appears
in the display and the audio prompt “Say a command”
plays through the earpiece.
3. To use Digit Dialing, say “Call” and the area code and
number that you want to dial at a distance of 3-12 inches
from the phone in a natural voice.
4. The number that you said is repeated through the
earpiece and your phone dials the number.
5. If VoiceSignal is not sure of the number that you said, a
list of possible matches appears in the display.
6. You’re asked to confirm the correct number as
VoiceSignal displays the results. Say “Yes” or “No” to
confirm or reject the number when prompted.
Call Name Dialing
To use Name Dial, you’ll need to have entries stored in
your Phonebook. See ‘Section 6: Understanding Your
Phonebook” on page 53 for information on creating
Phonebook entries.
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
2. After a brief pause, a list of optional commands appears
in the display and the audio prompt “Say a command”
plays through the earpiece.
3. To use Name Dialing, say “Call” and the name of the
contact that you want to dial.
4. The name that you said is repeated through the earpiece
and your phone dials the number.
t609.book Page 131 Sunday, January 15, 2006 2:03 PM
132
Section 9
5. If VoiceSignal is not sure of the name that you said, a list
of possible matches appears in the display.
6. You’re asked to confirm the correct number as
VoiceSignal displays the results. Say “Yes” or “No” to
confirm or reject the number when prompted.
7. The location is repeated through the earpiece and your
phone dials the number.
Send Text Message
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
2. A list of commands appears in the display and the audio
prompt “Say a command” plays through the earpiece.
3. Say “Send Text” at a distance of 3-12 inches from the
microphone. “Say the Name or Number” plays through
the earpiece.
4. After you say a name or number, you might be prompted,
“Did you say?” To confirm a name or number, wait for
the beep and then say “Yes.”
5. You can also choose the correct name or number from
the choice list using the phone’s arrow keys.
6. The Text Message client is launched. Enter your text
message.
Name Lookup
To perform a name lookup, you’ll need to have some
entries in your Contacts list.
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
t609.book Page 132 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 133
Voice Recognition
Section 9
2. A list of commands appears in the display and the audio
prompt “Say a command” plays through the earpiece.
3. Say “Lookup” at a distance of 3-12 inches from the
microphone. “Say the name” plays through the earpiece.
4. Say the name exactly as it is displayed in your Contacts
list, first name followed by last name.
5. The contact name appears in the display with other
information that you’ve entered for that contact.
Opening Applications
You can open an application or access a menu on your
phone using VoiceSignal.
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
2. A list of commands appears in the display and the audio
prompt “Say a command” plays through the earpiece.
3. Say “Go To” at a distance of 3-12 inches from the
microphone. A list of options displays and a prompt of
“Please choose” plays through the earpiece. If the option
you desire is not listed, say “Next Menu” to scroll to the
next page.
4. The menu option spoken opens.
Checking Phone Status
Use the Check command to see and hear status
information from your phone, including its phone
number, status, current signal strength, network
coverage, and battery level.
To check phone status:
t609.book Page 133 Sunday, January 15, 2006 2:03 PM
134
Section 9
1. In Idle mode, select the VoiceSignal shortcut (Right
navigation key).
2. A list of commands appears in the display and the audio
prompt “Say a command” plays through the earpiece.
3. Say “Check” at a distance of 3-12 inches from the
microphone. A list of options displays and a prompt of
“Please choose” plays through the earpiece.
4. The phone status menu option spoken is displayed.
Organizer
The Organizer allows you to set alarms, schedule
appointments, view the calendar, create To-Do lists,
perform simple math calculations, check world time,
perform unit conversions, set a timer, and use a
stopwatch.
Alarm
This feature allows you to:
•set up to 3 alarms to ring at specified times.
•set the phone to switch on automatically and ring the alarm
even if the phone is switched off.
The following options are available:
•Wake-up call: the alarm rings to wake you up in the morning.
•Alarm1: set the day, time, and tone for this alarm.
•Alarm2: set the day, time, and tone for this alarm.
•Auto power: alarm rings at the specified time even if the phone
is turned off. If the option is set to Off and the phone is
switched off at the specified time, the alarm does not ring.
To set an alarm:
t609.book Page 134 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 135
Organizer
Section 9
1. Highlight the alarm you would like to set and press the
Select soft key or the key.
2. Highlight the Alarm option and press the Right
navigation key to set Alarm to On.
3. Press the Down key to highlight the Alarm time option.
Enter the time you want the Alarm to sound.
4. Press the Down key to highlight the AM/PM option.
Press the Left or Right navigation key to set to AM or
PM.
5. Press the Down key to highlight the Repeat option.
Press the Left or Right navigation key to set to Once or
Everyday.
6. Press the Down key to highlight the Alarm tone option.
Press the key to bring up a list of alarm tone
locations.
7. Press the Up or Down Navigation key to highlight an
alarm tone location. Choose between My sounds, Music,
or Default sounds. Press the Select soft key or the
key.
8. Press the Up or Down Navigation key to select an alarm
tone. Press the Select soft key or the key.
9. Press the Save soft key.
10. Press the key to return to Idle mode.
Note: Your phone is preset to a 12-hour format. To change the time format,
see "Time & Date Settings" on page 96.
11. To stop the alarm when it rings, press any key.
t609.book Page 135 Sunday, January 15, 2006 2:03 PM
136
Section 9
Calendar
With the Calendar feature, you can:
•consult the calendar by month, week, or day.
•set schedules and note anniversaries
•make a To do list.
•write memos to keep track of your schedule.
•set an alarm to act as a reminder, if necessary.
•check your memory status.
When you select the Calendar menu, the following
options are available:
Month view
When you select this option, the calendar displays the
selected month with today’s date highlighted.
At the bottom of the calendar, the following icons are
displayed along with the number of entries for each:
Schedule items
Anniversary events
Miscellaneous items
The number of entries next to each icon reflects the
number of entries for the selected day on the calendar.
The following options are available when you press the
Options soft key:
•View mode: allows you to select between Day view or Week
view of the selected day.
t609.book Page 136 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 137
Organizer
Section 9
•Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
•Go to: allows you to see the Month view with today’s date
highlighted or a specified date.
•Delete: allows you to delete all events for a selected date, or
delete all events for preceding dates. You can also delete all
events.
Week view
When you select this option, the calendar displays the
selected week with today’s date and time highlighted.
The following options are available when you press the
Options soft key:
•View mode: allows you to select between Day view or Month
view of the selected day.
•Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
•Go to: allows you to see the Week view with today’s date
highlighted or a specified date.
•Delete: allows you to delete all events for a selected date, or
delete all events for preceding dates. You can also delete all
events.
Day view
When you select this option, you are taken to the Day view
of the selected day with any events listed. The following
options are available when you press the Options soft
key:
•Create: allows you to create a Schedule, Anniversary,
Miscellaneous, or To do event.
•View mode: allows you to select between Month view or Week
view of the selected day.
t609.book Page 137 Sunday, January 15, 2006 2:03 PM
138
Section 9
Schedule
This option allows you to write memos to a schedule.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the Schedule option and press the Select soft
key or the key.
3. Enter the subject in the Subject text box then press the
Down soft key.
4. Continue to enter other information including Details,
Start date, Start time, AM/PM, End date, End time, AM/
PM, Location, Alarm, and Alarm tone. Check the Repeat
box using the key if you want to repeat the alarm.
5. When you are finished, press the Save soft key.
Your information is saved to the Schedule.
Anniversary
This option allows you to record Anniversaries in your
calendar. You can also set an alarm to remind you of
important anniversaries.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the Anniversary option and press the Select
soft key or the key.
3. Enter the occasion in the Occasion text box then press
the Down soft key.
t609.book Page 138 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 139
Organizer
Section 9
4. Continue to enter other information including Date,
Alarm, Alarm time, AM/PM, Alarm tone, and whether or
not to Repeat every year.
5. When you are finished, press the Save soft key.
Your Anniversary information is saved to the Calendar.
Miscellaneous
This option allows you to record miscellaneous dates or
events in your calendar.
1. From Month, Week, or Day View, press the Options soft
key. Highlight the Create option and press the Select
soft key or the key.
2. Highlight the Miscellaneous option and press the
Select soft key or the key.
3. Enter the subject in the Subject text box then press the
Down soft key.
4. Continue to enter other information including Details,
Start date, Start time, AM/PM, End date, End time, and
AM/PM.
5. When you are finished, press the Save soft key.
Your Miscellaneous information is saved to the Calendar.
Missed Alarm Events
You can check on all of the events that you have set an
alarm on.
1. Highlight the Missed alarm events option and press the
Select soft key or the key.
t609.book Page 139 Sunday, January 15, 2006 2:03 PM
140
Section 9
2. To view an event information, highlight an event and
press the key. If no alarm events have been missed,
0 Missed is displayed.
The missed alarm event information is displayed.
3. To acknowledge and remove the event, press the
Confirm soft key or the key.
The event will be removed from the Missed alarm events
menu.
Memory Status
This option displays the number of Calendar, Schedule,
Anniversary, and Miscellaneous events and the amount
of memory that they use.
Task
You can use the Task function to in the same way you
would use a to-do list. When the task has been completed,
you can check it off as done.
To enter tasks into your Organizer, follow these steps:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight Organizer and press the Select soft key or the
key.
4. Highlight Task and press the Select soft key or the
key.
t609.book Page 140 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 141
Organizer
Section 9
5. The first time you enter the task menu, it will be empty.
Press the Options soft key and highlight the Create
option. Press the Select soft key or the key.
6. In the Task text box, enter your task. It can be up to 100
characters long.
7. Press the Down Navigation key and highlight the Start
Date option. If you want to have a start date, press the
key to check the box then use the Down key to
highlight the Start date text box. Enter the start date.
8. Scroll down and repeat step 7 for the End date.
9. Scroll down and highlight the Select priority option. Use
the Left or Right Navigation keys to select High,
Normal, or Low.
10. Press the Save soft key.
To see your Task list, you can go to the Tas k option in the
Organizer or you can see each task under Day view of the
calendar for the day it was started.
To mark a task as Done:
1. Select the task in the task list.
2. Press the Options soft key and highlight the Done
option. Press the Select soft key or the key.
3. The task will have a check mark after it in the Task list.
Calculator
With this feature, you can use the phone as a calculator.
The calculator provides the basic arithmetic functions;
addition, subtraction, multiplication, and division.
1. Enter the first number using the numeric keys.
t609.book Page 141 Sunday, January 15, 2006 2:03 PM
142
Section 9
2. Enter the operation for your calculation by pressing the
following navigation keys:
•Left: subtraction (-)
•Right: addition (+)
•Up: multiplication (x)
•Down: division (y)
3. The Left soft key can be used to create a decimal point
and left and right brackets.
4. Enter the next number.
5. To view the result, press the key.
Repeat steps 1 to 5 as many times as required.
World time
This feature allows you to find out what time it is another
part of world, using the Left and Right Navigation keys.
There are two time lines available. You can set the first
setting to your home city and then use the second setting
to check other city times.
Press the Options soft key for the following options:
•Save: this allows you to save your world time settings.
•Set daylight saving time: use the key to place a
checkmark next to the cities that you want to set daylight
savings time. Each city listed represents a time zone.
Unit conversion
The Unit conversion menu provides the following
conversion categories:
•Currency
t609.book Page 142 Sunday, January 15, 2006 2:03 PM
Section 9: Fun & Apps 143
Organizer
Section 9
•Length
•Weight
•Volume
•Area
•Temperature
To convert any of the above categories, do the following:
1. Scroll to the conversion feature you wish to use and
press the Select soft key or the key.
2. Enter the quantity you want converted in the text box.
Note: To include a decimal point, press the key.
3. Use the Up,Down,Left, and Right navigation keys to
select the From and To units of money or measure for
the quantity you want converted.
4. Press the OK soft key or the key.
Timer
You can use this menu to set a timer. To enable the Timer,
use the following options:
1. Press the Set soft key to enter the length of time.
2. Enter the time and press the OK soft key.
3. Press the key to start the timer. Press the key
again to stop the timer.
Stopwatch
This feature allows you to use a stopwatch. Press the
key to start the stopwatch. Press the Reset soft key to erase
t609.book Page 143 Sunday, January 15, 2006 2:03 PM
144
Section 9
all stopwatch times recorded. Press the key for the lap
time. You can have up to 4 lap times.
PIM Sync ???
?? Need more information.
Intro goes here.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the PIM sync option. Press the Select soft key
or the key.
4. Press the Options soft key for the following options:
•Start sync: ??
•View result: ??
•New sync profile: ??
•Edit sync profile: ??
•Delete: ??
t609.book Page 144 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 145
Section 10
Section 10: Camera and Camcorder
Topics Covered
• Using the Camera and Camcorder
• Take and Send
• Record Video
• My Photos
• My Videos
• My Album
• My Journal
This section explains how to use the camera and
camcorder on your phone. You can take photos and video
clips using the built-in camera and camcorder.
t609.book Page 145 Sunday, January 15, 2006 2:03 PM
146
Section 10
Using the Camera and Camcorder
Using the camera/camcorder module in your phone,
you can take photos or video clips of people or events
while on the move. Additionally, you can send photos
and video clips to other people in a Picture Messaging
message or set a wallpaper or caller ID image.
Note:
Do not take photos or videos of people without their permission.
Do not take photos or videos in places where cameras are not allowed.
Do not take photos or videos in places where you may interfere with
another person’s privacy.
Take and Send
Your camera produces photos in JPEG format.
Note: When you take a photo in direct sunlight or in bright conditions,
shadows may appear on the photo.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Using the Navigation keys, scroll to the Camera option.
Press the Select soft key or the key to enter the
menu.
4. Highlight Take and Send and press the Select soft key
or the key.
t609.book Page 146 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 147
Take and Send
Section 10
5. Adjust the image by aiming the camera at the subject.
Press the Left soft key to access the camera options. For
details, see "Using Camera Options" on page 147. You
can use the keypad to quickly change the camera
options.
6. Press the key to take the photo. Send To: My
Album? is displayed. Press the Yes soft key if you want
to send the photo to your T-Mobile My Album service.
The phone’s default destination is set to My Album. The
photo is automatically saved in My photos in the phone.
Note: To change the default destination for your pictures, press the
Options soft key when Send To: My Album? appears on the display.
Highlight the Default destination option. You can then remove your default
destination or change it to a phone number, email address, Phonebook, My
Album, My Journal, or a Recent log.
7. To use the photo options, press the Options soft key.
8. To return to Capture mode, select Take another.
9. To return to Idle mode, press the key.
Using Camera Options
In Capture mode, you can use various options for the
camera by pressing the Left soft key.
The following options are available:
Record video: switches from camera to camcorder.
Shooting mode: allows you to take a photo in various
modes. Once you change the mode, the corresponding
indicator appears at the top right of the display. The
following modes are available:
t609.book Page 147 Sunday, January 15, 2006 2:03 PM
148
Section 10
•Single shot: allows you to take a photo in the normal mode.
•Multi shot: allows you to take a series of action stills. Select the
capture speed, High Speed or Normal Speed, and the number
of photos the camera will take. When you press the key, the
camera takes photos successively.
•Mosaic shot: allows you to take several photos to combine in a
mosaic.
Effects: allows you to change the color tone or apply
special effects to the photo.
Frames: allows you to select a decorative frame. Select a
frame from the list using the Navigation keys and press
the key to save your setting.
Timer: allows you to set a time delay before the camera
takes the photo. Select the length of delay you want. When
you press key, the camera takes the photo after the
specified time has elapsed.
Go to My photos: takes you to your My photos folder.
Settings: allows you to change the image settings.
•Size: allows you to set the image size to either
SXGA(1280X1024), Mega(1152X864), SVGA(800X600),
VGA(640x480), QVGA(320x240), Mobile(240X320), or
Frame(240X180). The selected image size displays on the
capture screen.
•View finder: allows you to set the view finder to Full screen,
Full screen & indicator, Full screen & Guideline, or Standard
ratio.
•Shutter sound: allows you to select a tone for the shutter
sound. Choose between 4 tones.
•Zoom sound: allows you to turn zoom sound On or Off.
t609.book Page 148 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 149
Take and Send
Section 10
•Brightness sound: allows you to turn brightness sound On or
Off.
•Default name: allows you to change the default name assigned
to your photo.
Camera short cuts: shows you how to change options
using your keypad in capture mode. The following short
cuts are available:
Up and Down navigation keys zoom in and out.
Left and Right navigation keys adjust the image brightness.
Up volume key flips the image vertically.
Down volume key creates a mirror image.
changes from camera to camcorder or camcorder to camera.
changes the picture resolution.
changes the camera shot mode.
changes the color tone or applies a special effect to the
photo.
selects a decorative frame.
sets a time delay.
takes you to My Photos menu.
changes capture mode to full screen.
t609.book Page 149 Sunday, January 15, 2006 2:03 PM
150
Section 10
Record Video
Your camcorder produces videos in 3GP format.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Using the Navigation keys, scroll to the Camera option.
Press the Select soft key or the key to enter the
menu.
4. Highlight Record video and press the Select soft key or
the key.
5. Adjust the image by aiming the camcorder at the subject.
Press the Left soft key to access the camcorder options.
For details, see "Using Camcorder Options" on page 151.
You can use the keypad to quickly change the camcorder
options.
6. To start recording your video clip, press the key.
7. To stop the recording, press the Right soft key. The video
clip is automatically saved in the My videos folder.
8. To delete the video clip, press the Left soft key, highlight
Delete, and press the Select soft key or the key.
To return to Idle mode, press the key.
To access camcorder options, press the Left soft key.
t609.book Page 150 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 151
Record Video
Section 10
Using Camcorder Options
In Capture mode, you can use various options for the
camcorder by pressing the Left soft key.
The following options are available:
Take picture: allows you to take a photo in camera mode.
Effects: allows you to change the color tone or apply
special effects to the video clip.
Timer: allows you to set a time delay before the camcorder
takes the video clip. Select the length of delay you want.
When you press the key, the camcorder records the
video after the specified time has elapsed.
Go to My videos: takes you to your My videos folder
where you can view your videos.
Settings: allows you to change the recording settings.
•Recording mode: allows you to set to Normal or Limit for
message to keep the video shorter.
•Size: allows you to set the image size to either QCIF(176x144),
or Sub-QCIF(128x96). The selected image size displays on the
capture screen.
•View finder: allows you to set the view finder to Full screen
view or Standard Ratio.
•Audio Record: allows you to be able to record sounds with
your video. Set to On or Off.
•Default name: allows you to change the default name assigned
to your video.
Camcorder short cuts: shows you how to change options
using your keypad in capture mode. The following short
cuts are available:
t609.book Page 151 Sunday, January 15, 2006 2:03 PM
152
Section 10
Up and Down navigation keys zoom in and out.
Left and Right navigation keys adjust the video brightness.
Up volume key flips the image vertically.
Down volume key creates a mirror image.
changes from camera to camcorder or camcorder to camera.
changes the video resolution.
changes the shooting mode.
changes the color tone or applies a special effect to the video.
changes scene program from Normal to Night scene.
sets a time delay.
takes you to My videos menu.
changes capture mode to full screen.
My Photos
1. In Idle mode press the Menu soft key to access the Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Camera option and press the Select soft
key or the key.
t609.book Page 152 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 153
My Photos
Section 10
4. Select My photos and press the Select soft key or the
key.
When you access this menu, your phone displays the
photos in Thumbnail mode, which shows them as small
images. Use the Navigation keys to scroll through the
photos.
5. To view the photos on the full screen, press the key.
To go back to Thumbnail mode, press the Back soft key
or the key.
6. You can use the Left and Right navigation keys to scroll
through your photos.
My photos Options
In the My photos menu, press the Options soft key to use
the following options:
•View: allows you view the photo on your display.
•Send to My Album: allows you to send the photo to My Album.
•Send via: allows you to send the photo via Picture message or
Bluetooth.
•Default destination: allows you to remove or edit the default
destination.
•Set as: allows you to set the photo as your wallpaper or as a
Caller ID.
•Move to memory card: allows you to move the selected photo
or all photos to your TransFlash memory card.
•Copy to memory card: allows you to copy the selected photo
or all photos to your TransFlash memory card.
•Delete: allows you to delete the photo or delete all photos.
•Rename: allows you to change the name of the photo.
t609.book Page 153 Sunday, January 15, 2006 2:03 PM
154
Section 10
•Display mode: allows you to see your photos displayed in a
Line view or in Thumbnail view.
•Slide show: allows you to see all of your photos in a slide show
presentation.
•Share for Bluetooth: allows the photo to be shared or released
for the use of another Bluetooth device.
•Protection: allows you to protect the photo from being deleted.
•Properties: shows the properties of the photo, such as the file
name, file date, file format, image resolution, file size, and
protection status.
Deleting a Photo
You can delete photos one by one or all at one time.
1. From the My photos menu, select the photo you want to
delete and press the Options soft key. Highlight the
Delete option and press the Select soft key or the
key.
2. Highlight the Selected option and press the Select soft
key or the key. Or, highlight All to delete all photos.
3. Press the Yes soft key to confirm the deletion.
4. When you have finished, press the key.
My Videos
1. In Idle mode press the Menu soft key to access the Menu
mode.
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight the Camera option and press the Select soft
key or the key.
t609.book Page 154 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 155
My Videos
Section 10
4. Select My videos and press the Select soft key or the
key.
When you access this menu, your phone displays the
video clips in Thumbnail mode, which shows them as
small images. Use the Navigation keys to scroll through
the video clips.
5. To view the video clips on the full screen, press the
key.
My videos Options
In the My videos menu, press the Options soft key to use
the following options:
•Play: allows you to play the video clip on your display.
•Send via: allows you to send the video as part of a Picture
message or Bluetooth.
•Move to memory card: allows you to move the video to your
TransFlash memory card.
•Copy to memory card: allows you to copy the video (or all
videos) to your TransFlash memory card.
•Delete: allows you to delete the selected video clip or delete all
video clips.
•Rename: allows you to change the name of the video clip.
•Display mode: allows you to see your videos displayed in a
Line view or in Thumbnail view.
•Share for Bluetooth: allows the video (or all videos) to be
shared or released for the use of another Bluetooth device.
•Protection: allows you to protect the video clip from being
deleted.
t609.book Page 155 Sunday, January 15, 2006 2:03 PM
156
Section 10
•Properties: shows the properties of the video clip, such as the
name, date, format, resolution, size, video length, quality, and
protection status.
Deleting a Video Clip
You can delete video clips one by one or all at one time.
1. From the My videos menu, use the Up or Down
Navigation key to highlight the video you want to delete
and press the Options soft key.
2. Highlight the Delete Option, then press the Select soft
key or the key.
3. Highlight Selected if you only want to delete the video
clip that you selected. Highlight All if you want to delete
all video clips.
4. Press the Select soft key or the key.
5. Press the Yes soft key to confirm the deletion.
6. When you have finished, press the key to return Idle
mode.
My Album
This menu provides the ability for you to view the photos
you have stored on the t-zone website. Use the following
procedures to access My Album.
Note: When viewing photos on My Album, charges may apply.
1. In Idle mode press the Menu soft key to access the Menu
mode.
t609.book Page 156 Sunday, January 15, 2006 2:03 PM
Section 10: Camera and Camcorder 157
My Journal
Section 10
2. Using the Navigation keys, scroll to the Fun & Apps icon.
Press the Select soft key or the key to enter the
menu.
3. Highlight Camera and press the Select soft key or the
key.
4. Select My Album and press the Select soft key or the
key. The browser is launched and the T-Mobile Web
page displays.
5. Select the My Albums Menu link and press the key.
6. Photos sent to this folder are stored in the Inbox Album.
Highlight the Inbox Album link and press the key.
Highlight a photo and press the key to view the
photos.
7. Press the key to exit t-zones and return to the Idle
screen.
My Journal
This menu provides the ability for you to store your
photos using the t-zone website.
Note: When storing photos on My Journal, charges may apply.
t609.book Page 157 Sunday, January 15, 2006 2:03 PM
158
Section 10
t609.book Page 158 Sunday, January 15, 2006 2:03 PM
Section 11: t-zones 159
Section 11
Section 11: t-zones
Topics Covered
•t-zones
This section outlines the t-zones service on your phone.
For more information, contact T-Mobile.
t609.book Page 159 Sunday, January 15, 2006 2:03 PM
160
Section 11
t-zones
Your phone is equipped with a WAP (Wireless
Application Protocol) browser to allow you to access and
navigate the Wireless Web using your phone.
To access t-zones, follow these steps:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Using the Navigation keys, scroll to the t-zones icon.
Press the Select soft key or the key to enter the
menu.
The following options are available:
Home
Selecting this menu connects the phone to the network
and loads the t-zones homepage.
Note: You can enter t-zones without going through the t-zones menu by
simply pressing the t-zones soft key while in Idle mode.
The content of the t-zones startup homepage depends on
your Wireless Web service provider. To scroll through the
screen, use the Up and Down keys.
To go to the startup homepage from any other screen in the
t-zones, use the Home option. For more information on
the t-zones menus, see "Selecting and Using Menu
Options" on page 162.
Exiting the t-zones
To exit the browser at any time, simply press the key.
t609.book Page 160 Sunday, January 15, 2006 2:03 PM
Section 11: t-zones 161
t-zones
Section 11
Navigating the t-zones
1. To scroll through browser items, press the Up or Down
Navigation key.
2. To select browser items, press the key. Or, press the
Options soft key. Highlight the Select option and press
the OK soft key.
3. To return to the previous page, press the key. Or,
press the Options soft key. Highlight the Back option and
press the OK soft key.
4. To return to the startup homepage, press the Menu soft
key. Highlight the Home option and press the Select soft
key.
Entering Text in t-zones
When you are prompted to enter text, the currently active
text input mode is indicated on the screen. The following
modes are available:
•Upper-case character mode (A): allows you to enter upper-
case English characters.
•Lower-case character mode (a): allows you to enter lower-
case English characters.
Note: You can enter symbols in upper-case or lower-case character mode
by pressing the key.
•Number mode (1): allows you to enter numbers.
To change the text input mode, use the following
procedures:
1. Press the Right soft key one or more times.
2. To enter a space, press the key.
t609.book Page 161 Sunday, January 15, 2006 2:03 PM
162
Section 11
3. To edit text, set the cursor to the right of the character(s)
to be corrected.
4. Press the key as required.
5. Enter the correct character(s).
Selecting and Using Menu Options
Various menus are available when you are using t-zones
to navigate the Wireless Web.
To access the browser options menu:
1. Press the Menu soft key.
Note: The menus may vary, depending on your version of t-zones.
The following options are available:
•Favorites: shows the bookmarks list. You can bookmark the
current web page or access previously bookmarked pages.
•Reload: reloads the current page.
•Home: takes you back at any time to the home page of the
Wireless Web service provider.
•Go to URL: allows you to manually enter the URL address of a
Web page. After entering an address, press the key to go
there directly.
•Show URL: displays the URL address of the Web page to which
you are currently connected. It also enables you to set the
current site as the startup home page.
•Clear cache: allows you to clear the information stored in the
phone’s temporary memory which stores the most recently
accessed Web pages.
•Inbox: takes you to your message Inbox.
•Show images: allows you to view Internet images.
t609.book Page 162 Sunday, January 15, 2006 2:03 PM
Section 11: t-zones 163
t-zones
Section 11
•Certificates: allows you to view Internet certificates.
•Text Message: allows you to create a text message.
Favorites
This menu stores up to 15 URL addresses.
To store a URL address:
1. Select an empty location and press the Select soft key or
the key.
2. Enter a name for the favorite item in the Name text box
and press the Down key.
3. Enter the address in the URL text box and press the Save
soft key.
Note: For further details about how to enter characters, see "Section 5:
Entering Text" on page 45.
After saving favorite items, you can access the following
options by selecting the item, then pressing the Options
soft key:
•Go to URL: takes you to the site.
•Edit: allows you to edit the address.
•Delete: allows you to delete the selected address or you can
delete all addresses.
Or, you can select the favorite item and press the key.
Your browser will take you to the site.
Go to URL
This menu allows you to manually enter the URL address
of a web site that you wish to access.
t609.book Page 163 Sunday, January 15, 2006 2:03 PM
164
Section 11
For further details about entering characters, see "Section
5: Entering Text" on page 45.
Clear Cache
You can clear the information stored in the cache, which is
the phone’s temporary memory which stores the most
recently accessed Web pages.
At the Clear cache? prompt, press the Yes soft key to
confirm the deletion. Otherwise, press the No soft key.
t609.book Page 164 Sunday, January 15, 2006 2:03 PM
Section 12
Section 12: Health and Safety Information 165
Section 12: Health and Safety
Information
Topics Covered
• Health and Safety Information
This section outlines the safety precautions associated
with using your phone. These safety precautions should
be followed to safely use your phone.
t609.book Page 165 Sunday, January 15, 2006 2:03 PM
Section 12
166
Health and Safety Information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
government. These FCC exposure limits are derived from
the recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry, government,
and academia after extensive reviews of the scientific
literature related to the biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of
the rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a safety limit of
1.6 watts per kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of safety to give
additional protection to the public and to account for any
variations in measurements.
t609.book Page 166 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 167
Health and Safety Information
O
P
JU
D
F
4
5#4VGUVUCTGEQPFWEVGFWUKPIUVCPFCTFQRGTCVKPI
RQUKVKQPUCEEGRVGFD[VJG(%%YKVJVJGRJQPG
VTCPUOKVVKPICVKVUJKIJGUVEGTVKHKGFRQYGTNGXGNKPCNN
VGUVGFHTGSWGPE[DCPFU#NVJQWIJVJG5#4KUFGVGTOKPGF
CVVJGJKIJGUVEGTVKHKGFRQYGTNGXGNVJGCEVWCN5#4NGXGN
QHVJGRJQPGYJKNGQRGTCVKPIECPDGYGNNDGNQYVJG
OCZKOWOXCNWG6JKUKUDGECWUGVJGRJQPGKUFGUKIPGFVQ
QRGTCVGCVOWNVKRNGRQYGTNGXGNUUQCUVQWUGQPN[VJG
RQYGTTGSWKTGFVQTGCEJVJGPGVYQTM+PIGPGTCNVJG
ENQUGT[QWCTGVQCYKTGNGUUDCUGUVCVKQPCPVGPPCVJGNQYGT
VJGRQYGTQWVRWV
$GHQTGCPGYOQFGNRJQPGKUCXCKNCDNGHQTUCNGVQVJG
RWDNKEKVOWUVDGVGUVGFCPFEGTVKHKGFVQVJG(%%VJCVKV
FQGUPQVGZEGGFVJGGZRQUWTGNKOKVGUVCDNKUJGFD[VJG
(%%6GUVUHQTGCEJOQFGNRJQPGCTGRGTHQTOGFKP
RQUKVKQPUCPFNQECVKQPUGICVVJGGCTCPFYQTPQPVJGDQF[
CUTGSWKTGFD[VJG(%%(QTDQF[YQTPQRGTCVKQPVJKUOQFGN
RJQPGJCUDGGPVGUVGFCPFOGGVU(%%4(GZRQUWTG
IWKFGNKPGUYJGPWUGFYKVJC5COUWPICEEGUUQT[FGUKIPCVGFHQT
VJKURTQFWEVQTYJGPWUGFYKVJCPCEEGUUQT[VJCVEQPVCKPUPQ
OGVCNCPFVJCVRQUKVKQPUVJGJCPFUGVCOKPKOWOQHEO
HTQOVJGDQF[7UGQHQVJGTCEEGUUQTKGUOC[PQVGPUWTG
EQORNKCPEGYKVJ(%%4(GZRQUWTGIWKFGNKPGU
6JG(%%JCUITCPVGFCP'SWKROGPV#WVJQTK\CVKQPHQT
VJKUOQDKNGRJQPGYKVJCNNTGRQTVGF5#4NGXGNUGXCNWCVGF
CUKPEQORNKCPEGYKVJVJG(%%4(GZRQUWTGIWKFGNKPGU
6JGOCZKOWO5#4XCNWGUHQTVJKUOQFGNRJQPGCU
T
)5/
Ŗ*GCF9-I
Ŗ$QF[YQTP9-I
GRQTVGFVQVJG(%%CTG
t609.book Page 167 Sunday, January 15, 2006 2:03 PM
OPJUDF4
5#4KPHQTOCVKQPQPVJKUCPFQVJGTOQFGNRJQPGUECPDG
2%5
Ŗ*GCF9-I
Ŗ$QF[YQTP9-I
XKGYGFQPNKPGCVYYYHEEIQXQGVHEEKF6QHKPF
KPHQTOCVKQPVJCVRGTVCKPUVQCRCTVKEWNCTOQFGNRJQPG
VJKUUKVGWUGUVJGRJQPG(%%+&PWODGTYJKEJKUWUWCNN[
RTKPVGFUQOGYJGTGQPVJGECUGQHVJGRJQPG5QOGVKOGU
KVOC[DGPGEGUUCT[VQTGOQXGVJGDCVVGT[RCEMVQHKPFVJG
PWODGT1PEG[QWJCXGVJG(%%+&PWODGTHQTC
RCTVKEWNCTRJQPGHQNNQYVJGKPUVTWEVKQPUQPVJGYGDUKVG
CPFKVUJQWNFRTQXKFGXCNWGUHQTV[RKECNQTOCZKOWO5#4
HQTCRCTVKEWNCTRJQPG#FFKVKQPCNRTQFWEVURGEKHKE5#4
KPHQTOCVKQPECPCNUQDGQDVCKPGFCVYYYHEEIQXEIDUCT
$POTVNFS*OGPSNBUJPOPO8JSFMFTT1IPOFT
6JG75(QQFCPF&TWI#FOKPKUVTCVKQP(&#JCU
RWDNKUJGFCUGTKGUQH3WGUVKQPUCPF#PUYGTUHQT
EQPUWOGTUTGNCVKPIVQTCFKQHTGSWGPE[4(GZRQUWTG
HTQOYKTGNGUURJQPGU6JG(&#RWDNKECVKQPKPENWFGUVJG
HQNNQYKPIKPHQTOCVKQP
8IBULJOETPGQIPOFTBSFUIFTVCKFDUPGUIJTVQEBUF
6JGVGTOYKTGNGUURJQPGTGHGTUJGTGVQJCPFJGNFYKTGNGUU
RJQPGUYKVJDWKNVKPCPVGPPCUQHVGPECNNGFEGNN
OQDKNGQT2%5RJQPGU6JGUGV[RGUQHYKTGNGUURJQPGU
ECPGZRQUGVJGWUGTVQOGCUWTCDNGTCFKQHTGSWGPE[GPGTI[
4(DGECWUGQHVJGUJQTVFKUVCPEGDGVYGGPVJGRJQPGCPF
VJGWUGTUJGCF6JGUG4(GZRQUWTGUCTGNKOKVGFD[(GFGTCN
%QOOWPKECVKQPU%QOOKUUKQPUCHGV[IWKFGNKPGUVJCV
YGTGFGXGNQRGFYKVJVJGCFXKEGQH(&#CPFQVJGTHGFGTCN
JGCNVJCPFUCHGV[CIGPEKGU9JGPVJGRJQPGKUNQECVGFCV
t609.book Page 168 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 169
Consumer Information on Wireless Phones
Section 12
greater distances from the user, the exposure to RF is
drastically lower because a person's RF exposure
decreases rapidly with increasing distance from the
source. The so-called "cordless phones," which have a
base unit connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC's compliance
limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range
while being used. They also emit very low levels of RF
when in the stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to low
level RF that does not produce heating effects causes no
known adverse health effects. Many studies of low level
RF exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers have
had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new drugs
t609.book Page 169 Sunday, January 15, 2006 2:03 PM
Section 12
170
or medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard no
longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
•Support needed research into possible biological effects of RF
of the type emitted by wireless phones;
•Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device function;
and
•Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
•National Institute for Occupational Safety and Health
•Environmental Protection Agency
•Federal Communications Commission
•Occupational Safety and Health Administration
•National Telecommunications and Information Administration
t609.book Page 170 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 171
Consumer Information on Wireless Phones
Section 12
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations are
thus not the primary subject of the safety questions
discussed in this document.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy (RF)
exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer-causing chemicals so as
to be pre-disposed to develop cancer in absence of RF
exposure. Other studies exposed the animals to RF for up
t609.book Page 171 Sunday, January 15, 2006 2:03 PM
Section 12
172
to 22 hours per day. These conditions are not similar to the
conditions under which people use wireless phones, so
we don't know with certainty what the results of such
studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phones RF exposures. However,
none of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be
needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide
data that is directly applicable to human populations, but
ten or more years' follow-up may be needed to provide
answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a
cancer-causing agent and the time tumors develop - if
they do - may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
t609.book Page 172 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 173
Consumer Information on Wireless Phones
Section 12
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of new
research programs around the world. The Project has also
helped develop a series of public information documents
on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
t609.book Page 173 Sunday, January 15, 2006 2:03 PM
Section 12
174
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products - and at this point we
do not know that there is - it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
•If you must conduct extended conversations by wireless phone
every day, you could place more distance between your body
and the source of the RF, since the exposure level drops off
dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body or
use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing
the distance between the user and the RF source will
reduce RF exposure.
t609.book Page 174 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 175
Consumer Information on Wireless Phones
Section 12
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in
the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence that
any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
t609.book Page 175 Sunday, January 15, 2006 2:03 PM
Section 12
176
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike "hand-free" kits, these so-called "shields" may
interfere with proper operation of the phone. The phone
may be forced to boost its power to compensate, leading
to an increase in RF absorption. In February 2002, the
Federal trade Commission (FTC) charged two companies
that sold devices that claimed to protect wireless phone
users from radiation with making false and
unsubstantiated claims. According to FTC, these
defendants lacked a reasonable basis to substantiate their
claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI. FDA
has tested wireless phones and helped develop a
t609.book Page 176 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 177
Consumer Information on Wireless Phones
Section 12
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for
hearing aids and wireless phones so that no interference
occurs when a person uses a compatible phone and a
compatible hearing aid at the same time. This standard
was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the following
organizations:
•FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
•Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
•Occupational Safety and Health Administration's (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/
index.html
•National institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/topics/emf
•World health Organization (WHO):
http://www.who.int/peh-emf/
•International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de
•National Radiation Protection Board (UK):
http://www.nrpb.org.uk
t609.book Page 177 Sunday, January 15, 2006 2:03 PM
Section 12
178
•Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features, such
as speed dial and redial. If available, these features help
you to place your call without taking your attention off
the road.
2. When available, use a hands-free device. If possible, add
an additional layer of convenience and safety to your
wireless phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy reach. Be able
to access your wireless phone without removing your
eyes from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow, ice and
even heavy traffic can be hazardous.
t609.book Page 178 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 179
Road Safety
Section 12
5. Do not take notes or look up phone numbers while
driving. Jotting down a "to do" list or flipping through
your address book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be stationary.
If you need to make a call while moving, dial only a few
numbers, check the road and your mirrors, then
continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Make people you are talking
with aware you are driving and suspend conversations
that have the potential to divert your attention from the
road.
8. Use your wireless phone to call for help. Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is a free
call on your wireless phone!
9. Use your wireless phone to help others in emergencies. If
you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 9-1-1
or other local emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you see
a broken-down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic accident where no
t609.book Page 179 Sunday, January 15, 2006 2:03 PM
Section 12
180
one appears injured, or a vehicle you know to be stolen,
call roadside assistance or other special non-emergency
number.
"The wireless industry reminds you to use your phone safely
when driving."
For more information, please call 1-888-901-SAFE, or visit
our web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association.
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the phone or any accessory to
another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and
for the safety of personnel, it is recommended that the
equipment should only be used in the normal operating
position (held to your ear with the antenna pointing over
your shoulder if you are using an external antenna).
Using Your Phone Near Other Electronic Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
t609.book Page 180 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 181
Using Your Phone Near Other Electronic Devices
Section 12
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of Wireless
Technology Research.
Persons with pacemakers:
•should always keep the phone more than 15 cm (6 inches) from
their pacemaker when the phone is switched on.
•should not carry the phone in a breast pocket.
•should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aid Compatibility with Mobile Phones
When some mobile phones are used near some hearing
devices (hearing aids and cochlear implants), users may
detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of
interference they generate.
The wireless telephone industry has developed ratings
for some of their mobile phones, to assist hearing device
users in finding phones that may be compatible with their
t609.book Page 181 Sunday, January 15, 2006 2:03 PM
Section 12
182
hearing devices. Not all phones have been rated. Phones
that are rated have the rating on their box or a label on the
box.
The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hearing loss.
If your hearing device happens to be vulnerable to
interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing
device is the best way to evaluate it for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC
requirements and are likely to generate less interference
to hearing devices than phones that are not labeled. M4 is
the better/higher of the two ratings.
T-Ratings: P ho nes ra te d T 3 or T4 m ee t FC C req ui re men ts
and are likely to be more usable with a hearing device’s
telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. T4 is the better/higher of the two ratings. (Note
that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to
this type of interference. Your hearing device
manufacturer or hearing health professional may help
you find results for your hearing device. The more
immune your hearing aid is, the less likely you are to
experience interference noise from mobile phones.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
t609.book Page 182 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 183
Potentially Explosive Environments
Section 12
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has been
added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles
t609.book Page 183 Sunday, January 15, 2006 2:03 PM
Section 12
184
using liquefied petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to turn
off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone must be
switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network
services and/or phone features are in use. Check with
local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
t609.book Page 184 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 185
FCC Notice and Cautions
Section 12
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut off
the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase your
phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane
or butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One
Batterymarch Park, Quincy, MA 02269, Attn: Publication
Sales Division.
Cautions
Any changes or modifications to your phone not
expressly approved in this document could void your
warranty for this equipment, and void your authority to
operate this equipment. Only use approved batteries,
antennas and chargers. The use of any unauthorized
t609.book Page 185 Sunday, January 15, 2006 2:03 PM
Section 12
186
accessories may be dangerous and void the phone
warranty if said accessories cause damage or a defect to
the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other Important Safety Information
•Only qualified personnel should service the phone or install the
phone in a vehicle. Faulty installation or service may be
dangerous and may invalidate any warranty applicable to the
device.
•Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
•Do not store or carry flammable liquids, gases or explosive
materials in the same compartment as the phone, its parts or
accessories.
•For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including both
installed or portable wireless equipment in the area over the air
bag or in the air bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious injury
could result.
•Switch your phone off before boarding an aircraft. The use of
wireless phone in aircraft is illegal and may be dangerous to
the aircraft's operation.
•Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender, or
legal action, or both.
t609.book Page 186 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 187
Product Performance
Section 12
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on
the signal strength in your area. Your phone informs you
of the current signal strength by displaying a number of
bars next to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a window may give
you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15 minutes of
searching, a Power Save feature is automatically
activated. If your phone is active, it periodically rechecks
service availability or you can check it yourself by
pressing any key.
Anytime the Power Save feature is activated, a message
displays on the screen. When a signal is found, your
phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and receiver.
When it's turned on, it receives and transmits radio
frequency (RF) signals. When you use your phone, the
system handling your call controls the power level. This
power can range from 0.006 watts to 0.2 watts in digital
mode.
t609.book Page 187 Sunday, January 15, 2006 2:03 PM
Section 12
188
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
•If your phone is equipped with an external antenna, hold the
phone with the antenna raised, fully-extended and over your
shoulder.
•Do not hold, bend or twist the phone's antenna, if applicable.
•Do not use the phone if the antenna is damaged.
•If your phone is equipped with an internal antenna, obstructing
the internal antenna could inhibit call performance.
•Speak directly into the phone's receiver.
•Avoid exposing your phone and accessories to rain or liquid
spills. If your phone does get wet, immediately turn the power
off and remove the battery. If it is inoperable, call Customer
Care for service.
Availability of Various Features/Ring Tones
Many services and features are network dependent and
may require additional subscription and/or usage
charges. Not all features are available for purchase or use
in all areas. Downloadable Ring Tones may be available at
an additional cost. Other conditions and restrictions may
apply. See your service provider for additional
information.
t609.book Page 188 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 189
Battery Standby and Talk Time
Section 12
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data, and
other application usage patterns.
Battery Precautions
•Avoid dropping the cell phone. Dropping it, especially on a hard
surface, can potentially cause damage to the phone and
battery. If you suspect damage to the phone or battery, take it
to a service center for inspection.
•Never use any charger or battery that is damaged in any way.
•Use the battery only for its intended purpose.
•If you use the phone near the network's base station, it uses
less power; talk and standby time are greatly affected by the
signal strength on the cellular network and the parameters set
by the network operator.
•Follow battery usage, storage and charging guidelines found in
the user’s guide.
•Battery charging time depends on the remaining battery charge
and the type of battery and charger used. The battery can be
charged and discharged hundreds of times, but it will gradually
wear out. When the operation time (talk time and standby time)
is noticeably shorter than normal, it is time to buy a new
battery.
•If left unused, a fully charged battery will discharge itself over
time.
•Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a charger
is not in use, disconnect it from the power source. Do not leave
the battery connected to a charger for more than a week, since
overcharging may shorten its life.
t609.book Page 189 Sunday, January 15, 2006 2:03 PM
Section 12
190
•Do not use incompatible cell phone batteries and chargers.
Some Web sites and second-hand dealers, not associated with
reputable manufacturers and carriers, might be selling
incompatible or even counterfeit batteries and chargers.
Consumers should purchase manufacturer or carrier
recommended products and accessories. If unsure about
whether a replacement battery or charger is compatible,
contact the manufacturer of the battery or charger.
•Extreme temperatures will affect the charging capacity of your
battery: it may require cooling or warming first.
•Do not leave the battery in hot or cold places, such as in a car in
summer or winter conditions, as you will reduce the capacity
and lifetime of the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold battery may
temporarily not work, even when the battery is fully charged.
Li-ion batteries are particularly affected by temperatures below
0 °C (32 °F).
•Do not place the phone in areas that may get very hot, such as
on or near a cooking surface, cooking appliance, iron, or
radiator.
•Do not get your phone or battery wet. Even though they will dry
and appear to operate normally, the circuitry could slowly
corrode and pose a safety hazard.
•Do not short-circuit the battery. Accidental short-circuiting can
occur when a metallic object (coin, clip or pen) causes a direct
connection between the + and - terminals of the battery (metal
strips on the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the terminals may
damage the battery or the object causing the short-circuiting.
•Do not permit a battery out of the phone to come in contact with
metal objects, such as coins, keys or jewelry.
•Do not crush, puncture or put a high degree of pressure on the
battery as this can cause an internal short-circuit, resulting in
overheating.
•Dispose of used batteries in accordance with local regulations.
In some areas, the disposal of batteries in household or
business trash may be prohibited. For safe disposal options for
t609.book Page 190 Sunday, January 15, 2006 2:03 PM
Section 12: Health and Safety Information 191
Care and Maintenance
Section 12
Li-Ion batteries, contact your nearest Samsung authorized
service center. Always recycle. Do not dispose of batteries in a
fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years.
•Keep the phone and all its parts and accessories out of the
reach of small children.
•Keep the phone dry. Precipitation, humidity and liquids contain
minerals that will corrode electronic circuits.
•Do not use the phone with a wet hand. Doing so may cause an
electric shock to you or damage to the phone.
•Do not use or store the phone in dusty, dirty areas, as its moving
parts may be damaged.
•Do not store the phone in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
warp or melt certain plastics.
•Do not store the phone in cold areas. When the phone warms
up to its normal operating temperature, moisture can form
inside the phone, which may damage the phone's electronic
circuit boards.
•Do not drop, knock or shake the phone. Rough handling can
break internal circuit boards.
•Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water solution.
•Do not paint the phone. Paint can clog the device's moving
parts and prevent proper operation.
t609.book Page 191 Sunday, January 15, 2006 2:03 PM
Section 12
192
•Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may explode
when overheated.
•If your phone is equipped with an external antenna, use only the
supplied or an approved replacement antenna. Unauthorized
antennas or modified accessories may damage the phone and
violate regulations governing radio devices.
•If the phone, battery, charger or any accessory is not working
properly, take it to your nearest qualified service facility. The
personnel there will assist you, and if necessary, arrange for
service.
t609.book Page 192 Sunday, January 15, 2006 2:03 PM
Section 13: Warranty Information 193
Section 13
Section 13: Warranty Information
Topics Covered
• Standard Limited Warranty
t609.book Page 193 Sunday, January 15, 2006 2:03 PM
194
Section 13
Standard Limited Warranty
What is Covered and For How Long? SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P.
("SAMSUNG") warrants to the original purchaser
("Purchaser") that SAMSUNG's Phones and accessories
("Products") are free from defects in material and
workmanship under normal use and service for the
period commencing upon the date of purchase and
continuing for the following specified period of time after
that date:
Phone 1 Year
Batteries 1 Year
Leather Case/ Pouch 90 Days
Holster 90 Days
Other Phone Accessories 1 Year
What is Not Covered? This Limited Warranty is conditioned
upon proper use of Product by Purchaser. This Limited
Warranty does not cover: (a) defects or damage resulting
from accident, misuse, abuse, neglect, unusual physical,
electrical or electromechanical stress, or modification of
any part of Product, including antenna, or cosmetic
damage; (b) equipment that has the serial number
removed or made illegible; (c) any plastic surfaces or other
externally exposed parts that are scratched or damaged
due to normal use; (d) malfunctions resulting from the use
of Product in conjunction with accessories, products, or
t609.book Page 194 Sunday, January 15, 2006 2:03 PM
Section 13: Warranty Information 195
Standard Limited Warranty
Section 13
ancillary/peripheral equipment not furnished or
approved by SAMSUNG; (e) defects or damage from
improper testing, operation, maintenance, installation, or
adjustment; (f) installation, maintenance, and service of
Product, or (g) Product used or purchased outside the
United States or Canada. This Limited Warranty covers
batteries only if battery capacity falls below 80% of rated
capacity or the battery leaks, and this Limited Warranty
does not cover any battery if (i) the battery has been
charged by a battery charger not specified or approved by
SAMSUNG for charging the battery, (ii) any of the seals
on the battery are broken or show evidence of tampering,
or (iii) the battery has been used in equipment other than
the SAMSUNG phone for which it is specified.
What are SAMSUNG's Obligations? During the applicable
warranty period, SAMSUNG will repair or replace, at
SAMSUNG's sole option, without charge to Purchaser,
any defective component part of Product. To obtain
service under this Limited Warranty, Purchaser must
return Product to an authorized phone service facility in
an adequate container for shipping, accompanied by
Purchaser's sales receipt or comparable substitute proof
of sale showing the date of purchase, the serial number of
Product and the sellers' name and address. To obtain
assistance on where to deliver the Product, call Samsung
Customer Care at 1-888-987-4357. Upon receipt,
SAMSUNG will promptly repair or replace the defective
Product. SAMSUNG may, at SAMSUNG's sole option,
use rebuilt, reconditioned, or new parts or components
when repairing any Product or replace Product with a
rebuilt, reconditioned or new Product. Repaired/
replaced leather cases, pouches and holsters will be
t609.book Page 195 Sunday, January 15, 2006 2:03 PM
196
Section 13
warranted for a period of ninety (90) days. All other
repaired/replaced Product will be warranted for a period
equal to the remainder of the original Limited Warranty
on the original Product or for 90 days, whichever is longer.
All replaced parts, components, boards and equipment
shall become the property of SAMSUNG. If SAMSUNG
determines that any Product is not covered by this
Limited Warranty, Purchaser must pay all parts,
shipping, and labor charges for the repair or return of such
Product.
WHAT ARE THE LIMITS ON SAMSUNG'S WARRANTY/LIABILITY?
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED HEREIN, PURCHASER TAKES THE
PRODUCT "AS IS," AND SAMSUNG MAKES NO
WARRANTY OR REPRESENTATION AND THERE
ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT,
INCLUDING BUT NOT LIMITED TO:
•THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR
ANY PARTICULAR PURPOSE OR USE;
•WARRANTIES OF TITLE OR NON-INFRINGEMENT;
•DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF THE
PRODUCT;
•THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS
CONTAINED THEREIN; OR
•COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF
ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
THERETO.
NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN
t609.book Page 196 Sunday, January 15, 2006 2:03 PM
Section 13: Warranty Information 197
Standard Limited Warranty
Section 13
EXPRESS WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT. ALL IMPLIED
WARRANTIES AND CONDITIONS THAT MAY ARISE
BY OPERATION OF LAW, INCLUDING IF
APPLICABLE THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY LIMITED TO
THE SAME DURATION OF TIME AS THE EXPRESS
WRITTEN WARRANTY STATED HEREIN. SOME
STATES/PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU. IN ADDITION, SAMSUNG
SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY
KIND RESULTING FROM THE PURCHASE, USE, OR
MISUSE OF, OR INABILITY TO USE THE PRODUCT
OR ARISING DIRECTLY OR INDIRECTLY FROM THE
USE OR LOSS OF USE OF THE PRODUCT OR FROM
THE BREACH OF THE EXPRESS WARRANTY,
INCLUDING INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS, OR FOR
DAMAGES ARISING FROM ANY TORT (INCLUDING
NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT
COMMITTED BY SAMSUNG, ITS AGENTS OR
EMPLOYEES, OR FOR ANY BREACH OF CONTRACT
OR FOR ANY CLAIM BROUGHT AGAINST
PURCHASER BY ANY OTHER PARTY. SOME STATES/
PROVINCES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU. THIS
t609.book Page 197 Sunday, January 15, 2006 2:03 PM
198
Section 13
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH
VARY FROM STATE TO STATE/PROVINCE TO
PROVINCE. THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT AND STATES
PURCHASER'S EXCLUSIVE REMEDY. IF ANY
PORTION OF THIS LIMITED WARRANTY IS HELD
ILLEGAL OR UNENFORCEABLE BY REASON OF ANY
LAW, SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILITY SHALL NOT AFFECT THE
ENFORCEABILITY FOR THE REMAINDER OF THIS
LIMITED WARRANTY WHICH PURCHASER
ACKNOWLEDGES IS AND WILL ALWAYS BE
CONSTRUED TO BE LIMITED BY ITS TERMS OR AS
LIMITED AS THE LAW PERMITS. THE PARTIES
UNDERSTAND THAT THE PURCHASER MAY USE
THIRD-PARTY SOFTWARE OR EQUIPMENT IN
CONJUNCTION WITH THE PRODUCT. SAMSUNG
MAKES NO WARRANTIES OR REPRESENTATIONS
AND THERE ARE NO CONDITIONS, EXPRESS OR
IMPLIED, STATUTORY OR OTHERWISE, AS TO THE
QUALITY, CAPABILITIES, OPERATIONS,
PERFORMANCE OR SUITABILITY OF ANY
THIRDPARTY SOFTWARE OR EQUIPMENT,
WHETHER SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT IS INCLUDED WITH THE PRODUCT
DISTRIBUTED BY SAMSUNG OR OTHERWISE,
INCLUDING THE ABILITY TO INTEGRATE ANY
SUCH SOFTWARE OR EQUIPMENT WITH THE
PRODUCT. THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE AND SUITABILITY
t609.book Page 198 Sunday, January 15, 2006 2:03 PM
Section 13: Warranty Information 199
Standard Limited Warranty
Section 13
OF ANY SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT LIE SOLELY WITH THE PURCHASER
AND THE DIRECT VENDOR, OWNER OR SUPPLIER
OF SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT, AS THE CASE MAY BE.
This Limited Warranty allocates risk of Product failure
between Purchaser and SAMSUNG, and SAMSUNG's
Product pricing reflects this allocation of risk and the
limitations of liability contained in this Limited
Warranty. The agents, employees, distributors, and
dealers of SAMSUNG are not authorized to make
modifications to this Limited Warranty, or make
additional warranties binding on SAMSUNG.
Accordingly, additional statements such as dealer
advertising or presentation, whether oral or written, do
not constitute warranties by SAMSUNG and should not
be relied upon.
Samsung Telecommunications America, L.P.
1301 East Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2006 Samsung Telecommunications America. All rights
reserved.
No reproduction in whole or in part allowed without
prior written approval. Specifications and availability
subject to change without notice.
Printed in Korea.
t609.book Page 199 Sunday, January 15, 2006 2:03 PM
200
Section 13
t609.book Page 200 Sunday, January 15, 2006 2:03 PM
201
Index
A
ABC mode 46,47
Accessing a Menu Function
38
Alarm 134
Alert type 103
Audio player 127
B
Backlight
description 18
settings 100
Battery
charging 9
installing 8
low indicator 10
Bluetooth
About 108
Features 109
Searching for new devices
109
Security modes 109
Settings 108
Turning Bluetooth On and Off
109
Visibility 109
Broadcast Messages 92
C
Calendar 136
Call Barring 106
Call Functions 21
Adjusting the Call Volume 24
Answering a Call 24
Call Records 25
Correcting the Number 22
Ending a Call 22
Making a Call 22
Making a Call from Phone-
book 23
Redialing Last Number 22
Silent mode 29
Call Records
All calls 26
Call time 28
Delete all 28
Incoming calls 27
Missed calls 26
Outgoing calls 27
Call Waiting 34,106
Caller group 61
Caller ID 108
Camcorder 145
recording video 150
Camera 145
taking photos 146
Change password 111
Charging battery 9
D
Dialing display 101
Display
backlight 18
icons 17
DTMF 33
E
Email 87
Entering Text 45
Changing the Text Entry
t609.book Page 201 Sunday, January 15, 2006 2:03 PM
202
Mode 46
Using ABC Mode 47
Using Number Mode 51
Using Symbol Mode 51
Using T9 Mode 49
F
File Manager 118
Fun & Apps 117
Functions and Options 29
G
Games 127
Get More Help 19
Getting Started 5
Activating Your Phone 6
Voicemail 11
H
Health and Safety Informa-
tion 165
HiFi Ringers 102,118
I
Icons, description 17
Instant Messaging 92
International Call 22
K
Keypad Tone 103
L
Low battery indicator 10
M
Making a Call
Phonebook 23
MegaTones 102,118
Memory card 126
Menu Navigation 37
Menu Outline 39
Message settings 90
Message Tone 103
Messages 69
Messaging
Types of Messages 70
Missed Call
Viewing 26
Multi-Party Call 35
Dropping One Participant 36
Private Conversation 35
Setting up 35
Mute 32
My Album 120,156
My Journal 121,157
My Name Card 64
My photos
accessing pictures 152
My videos 154
N
Network Selection 107
Network Services
Call Barring 106
Call Forwarding 104
Call Waiting 106
Caller ID 108
Network Selection 107
Network Services Settings
104
Number mode 46
t609.book Page 202 Sunday, January 15, 2006 2:03 PM
203
O
On/off switch, phone 10
Options
During a Call 31
Putting a Call on Hold 31
Organizer 134
Alarm 134
Calculator 141
Calendar 136
Stopwatch 143
Task 140
Timer 143
Unit conversion 142
World time 142
Own Number 65
P
Phone
icons 17
switching on/off 10
Phone lock 111
Phone Settings 97
Phonebook
Searching for a Number 33
Phonebook Management 66
Picture Messages 75
PIM Sync 144
PIN
change 111
check 110
Privacy 112
Push message
viewing in Inbox 83
R
Reset settings 115
Ring Volume 102
S
Security settings 110
Sentbox 85
Settings 95
Bluetooth 108
Display 99
Network Services 104
Phone 97
Reset 115
Security 110
Sound Settings 102
Time & Date 96
Voice recognition 113
Shortcuts 38
Silent mode 104
SIM card
installing 6
Soft Keys 29
Speakerphone 32
Speed Dial
Setting Up Entries 60
Standard Limited Warranty
194
Stopwatch 143
Storing a number
Phone’s Memory 54
SIM Card 55
Switching on/off
phone 10
Symbol mode 46
t609.book Page 203 Sunday, January 15, 2006 2:03 PM
204
T
T9 mode 46
Templates 88
Text input mode
changing 46
Text Messages 72
Timer 143
TransFlash memory card 126
Travel adapter 9
t-zones 160
Entering Text 161
Exiting 160
Navigating 161
U
Understanding Your Phone 13
Features of Your Phone 14
View of Your Phone 14
Understanding Your Phone-
book 53
Finding a Phonebook Entry
57
Finding My Phone Number
65
Management 66
V
Voice Mail 11,89
changing number 12
Voice Messages 70
Voice notes 70
Voice Recognition 130
VoiceSignal
checking phone status 133
digit dial 130
features 130
menu 130
name dial 131
name lookup 132
open applications 133
send text message 132
settings 113
W
Warranty Information 193
t609.book Page 204 Sunday, January 15, 2006 2:03 PM
