4G LTE SMARTPHONE

User Manual

Please read this manual before operating your

phone, and keep it for future reference.

This document is watermarked because certain important information in the document has not yet been verified. This document has been sent to you

as a draft and for informational purposes only. The document should only be used for internal purposes and may not be distributed outside of Samsung,

except to Samsung's carrier customer for testing purposes. Distributing the document outside of Samsung, except to Samsung's carrier customer for

testing purposes could result in legal exposure to the company if the preliminary, unverified information in the draft turns out to be inaccurate.

DRAFT

FOR INTERNAL USE ONLY

SM-C105A_UM_English_UCUAMH8_CB_082713_F1

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers

relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone

System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual

Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,

computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the

rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare

derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No

title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain

with SAMSUNG and its suppliers.

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser

General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered

under the open source licenses, please visit:

http://opensource.samsung.com

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE

PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND

WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR

ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE

PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR

COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING

DRAFT

FOR INTERNAL USE ONLY

THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED

WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR

ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF

THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS

OR BENEFITS.

Modification of Software

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,

OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR

CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.

IF YOUR CARRIER PROHIBITS THIS, IF YOU ATTEMPT TO DOWNLOAD SOFTWARE ONTO THE DEVICE WITHOUT AUTHORIZATION,

YOU WILL BE NOTIFIED ON THE SCREEN THAT THE PHONE WILL NO LONGER OPERATE AND BE INSTRUCTED TO POWER DOWN

THE DEVICE. YOU MUST THEN CONTACT YOUR CARRIER TO RESTORE THE DEVICE TO THE CARRIER AUTHORIZED SETTINGS.

SAFE™ (Samsung Approved For Enterprise)

SAFE™: "SAFE™" (Samsung for Enterprise) is a mark for a Samsung device which has been tested against Samsung's own

internal criteria for interoperability with certain third party security-related solutions for MDM and VPN. The testing includes field

testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the

Samsung device. During the testing, the device is tested with the security solutions to see if the solutions work with the device as

described by the third party security solution providers. The testing, for example, includes field testing with local network

connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. For more

information about Samsung's SAFE™ program, please refer to

www.samsung.com/us/safe

Disclaimer of Warranties: EXCEPT AS OTHERWISE PROVIDED IN THEIR STANDARD END USER LICENSE AND WARRANTY, TO THE

FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD., SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND

DRAFT

FOR INTERNAL USE ONLY

THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE "SAMSUNG ENTITIES") EXPRESSLY DISCLAIM ANY AND ALL

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,

INTEROPERABILITY OR NON-INFRINGEMENT, WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™

DEVICES AND APPLICATIONS TESTED WITH SAFE™ DEVICES. IN NO EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY

DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO

INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES OR APPLICATIONS TESTED WITH SAFE™ DEVICES. In

addition, information technology security protection will be affected by features or functionality associated with, among other

things the e-mail platform, master data management, and virtual private network solutions selected by the software provider,

solution provider or user. Choice of an e-mail, master data management, and virtual private network solution is at the sole

discretion of the software provider, solution provider or user and any associated effect on information technology security

protection is solely the responsibility of the software provider, solution provider or user. For complete statement of limited

warranty, please refer to

www.samsung.com/us/safe

, available on the web and where Samsung smartphone and Galaxy Tab™

devices are sold. [101212]

Samsung Telecommunications America (STA), LLC

Headquarters:

1301 E. Lookout Drive

Richardson, TX 75082

DRAFT

FOR INTERNAL USE ONLY

Do you have questions about your Samsung Mobile Phone? For 24 hour information and assistance, we offer a new FAQ/ARS

System (Automated Response System) at:

http://www.samsung.com/us/support.

Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications,

Inc., or its affiliates in the United States and/or other countries.

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are

registered trademarks and are wholly owned by the Bluetooth SIG.

microSD™ and the microSD logo are Trademarks of the SD Card Association.

Openwave® is a registered Trademark of Openwave, Inc.

LTE is a trademark of ETSI.

and are trademarks of SRS Labs, Inc. CS Headphone and WOW HD technologies are incorporated under license

from SRS Labs, Inc.

Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail, Google Maps, Google Music, Google Talk,

Picasa, YouTube and other marks are trademarks of Google Inc.

Customer Care Center:

1000 Klein Rd.

Plano, TX 75074

Toll Free Tel: 1.888.987.HELP (4357)

Internet Address:

http://www.samsung.com

DRAFT

FOR INTERNAL USE ONLY

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

Devices purchased for use on AT&T's system are designed for use exclusively on AT&T's system. You agree that you won't make

any modifications to the Equipment or programming to enable the Equipment to operate on any other system. A voice plan is

required on all voice-capable devices, unless specifically noted otherwise in the terms governing your agreement. Some devices

or plans may require you to subscribe to a data plan.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, AT&T wants you to be

aware that some applications that you enable may involve the location of your phone being shared. For applications available

through AT&T, AT&T offers privacy controls that let you decide how an application may use the location of your phone and other

phones on your account. However, AT&T's privacy tools do not apply to applications available outside of AT&T. Please review the

terms and conditions and the associated privacy policy for each location-based service to learn how location information will be

used and protected.

Your phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from AT&T or

elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These

controls may not be available for certain devices which bypass AT&T controls.

AT&T may collect certain types of information from your device when you use AT&T services to provide customer support and to

improve its services. For more information on AT&T's Privacy Policy, visit

http://www.att.com/privacy

Your phone features earSmart™, an intelligent voice processor that delivers a clear voice experience, allowing you to

hear and be

heard

™ in nearly any environment. earSmart technology uses the science of human hearing to distinguish sounds, identify your

voice and suppress surrounding noise, for clear conversations just about anywhere.

DRAFT

FOR INTERNAL USE ONLY

How Does It Work?

•

The earSmart voice processor in your phone captures your voice and all the sounds around you.

•

Working like the human ear, it processes and distinguishes these sounds, isolates your voice conversation, and removes background noise -

from both ends of a call.

•

It also automatically equalizes and adjusts voice volume so you can hear and talk naturally, even in the noisiest places.

•

With earSmart technology, you can talk where you want, and have clear conversations for mobile calls, video chats, even speakerphone calls,

without worrying about surrounding noise.

DRAFT

FOR INTERNAL USE ONLY

Table of Contents

Section 1: Getting Started ............................. 6

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . 6

Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . 9

Switching the Phone On or Off . . . . . . . . . . . . . . 11

Locking and Unlocking the Touch Screen . . . . . . 12

Configuring your Phone . . . . . . . . . . . . . . . . . . . 12

Creating a Samsung Account . . . . . . . . . . . . . . . 14

Creating a New Google Account . . . . . . . . . . . . . 14

Retrieving your Google Account Password . . . . . 15

Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . 15

Section 2: Understanding Your Phone ........ 16

Features of Your Phone . . . . . . . . . . . . . . . . . . . 16

Front View of Your Phone . . . . . . . . . . . . . . . . . . 17

Side Views of Your Phone . . . . . . . . . . . . . . . . . . 19

Rear View of Your Phone . . . . . . . . . . . . . . . . . . 21

Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . 34

Using Motions and Gestures . . . . . . . . . . . . . . . . 36

Customizing Your Home Screen . . . . . . . . . . . . . 39

Notification Bar . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Section 3: Call Functions .............................50

Displaying Your Phone Number . . . . . . . . . . . . . . 50

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Making Emergency Calls . . . . . . . . . . . . . . . . . . . 51

Making a Call Using Speed Dial . . . . . . . . . . . . . . 52

Making a Call from the Address Book . . . . . . . . . 52

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . 53

Dialing Options . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Call Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Options During a Call . . . . . . . . . . . . . . . . . . . . . . 57

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Section 4: Entering Text ..............................62

Text Input Methods . . . . . . . . . . . . . . . . . . . . . . . 62

Entering Text Using the Samsung Keyboard . . . . . 62

Changing the Text Input Mode - Keypad . . . . . . . 63

Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . 63

Using Symbol/Numeric Mode . . . . . . . . . . . . . . . 64

Predictive Text . . . . . . . . . . . . . . . . . . . . . . . . . . 64

DRAFT

FOR INTERNAL USE ONLY

Samsung Keyboard Settings . . . . . . . . . . . . . . . . 65

Using the Google Voice Typing Feature . . . . . . . . 65

Section 5: Contacts and Your Address

Book ...........................................................66

AT&T Address Book Activation . . . . . . . . . . . . . . 66

Adding a New Contact . . . . . . . . . . . . . . . . . . . . . 67

Editing an Existing Contact . . . . . . . . . . . . . . . . . 69

Using Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Joining Contacts . . . . . . . . . . . . . . . . . . . . . . . . . 71

Synchronizing Accounts . . . . . . . . . . . . . . . . . . . 73

Address Book Options . . . . . . . . . . . . . . . . . . . . . 73

Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Address Book Favorites . . . . . . . . . . . . . . . . . . . . 77

Managing Address Book Contacts . . . . . . . . . . . . 77

Section 6: Camera ........................................80

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Section 7: Messaging ...................................92

Types of Messages . . . . . . . . . . . . . . . . . . . . . . . 92

Creating and Sending Messages . . . . . . . . . . . . . 92

Message Options . . . . . . . . . . . . . . . . . . . . . . . . 93

Viewing New Received Messages . . . . . . . . . . . . 95

Deleting Messages . . . . . . . . . . . . . . . . . . . . . . . .97

Message Search . . . . . . . . . . . . . . . . . . . . . . . . .97

Messaging Settings . . . . . . . . . . . . . . . . . . . . . . .97

Using Email . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

Using Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Google + . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Messages App . . . . . . . . . . . . . . . . . . . . . . . . . .105

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Section 8: Changing Your Settings ........... 107

Accessing Settings . . . . . . . . . . . . . . . . . . . . . . .107

Settings Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . .107

Wi-Fi Settings . . . . . . . . . . . . . . . . . . . . . . . . . .108

Bluetooth settings . . . . . . . . . . . . . . . . . . . . . . .109

Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . .110

More networks . . . . . . . . . . . . . . . . . . . . . . . . . .111

NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117

S Beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117

Nearby devices . . . . . . . . . . . . . . . . . . . . . . . . .118

Screen Mirroring . . . . . . . . . . . . . . . . . . . . . . . .118

Kies via Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Lock Screen Settings . . . . . . . . . . . . . . . . . . . . .119

DRAFT

FOR INTERNAL USE ONLY

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . 121

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . 122

Home screen mode . . . . . . . . . . . . . . . . . . . . . 125

Open Camera . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Blocking Mode . . . . . . . . . . . . . . . . . . . . . . . . . 132

Driving mode . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Power saving mode . . . . . . . . . . . . . . . . . . . . . 133

Accessory Settings . . . . . . . . . . . . . . . . . . . . . . 133

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Browser Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Language and input . . . . . . . . . . . . . . . . . . . . . 136

Motions and Gestures . . . . . . . . . . . . . . . . . . . . 141

Smart screen . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Voice control . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Add Account . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Back up and reset . . . . . . . . . . . . . . . . . . . . . . 145

Location services . . . . . . . . . . . . . . . . . . . . . . . 147

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Application Manager . . . . . . . . . . . . . . . . . . . . . 152

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Date and time . . . . . . . . . . . . . . . . . . . . . . . . . . 155

About Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Section 9: Connections ..............................158

Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

PC Connections . . . . . . . . . . . . . . . . . . . . . . . . . 175

Section 10: Applications ............................ 177

Amazon Kindle . . . . . . . . . . . . . . . . . . . . . . . . . 177

AT&T Code Scanner . . . . . . . . . . . . . . . . . . . . . 178

AT&T DriveMode . . . . . . . . . . . . . . . . . . . . . . . . 179

AT&T FamilyMap . . . . . . . . . . . . . . . . . . . . . . . . 179

AT&T Locker . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

AT&T Navigator . . . . . . . . . . . . . . . . . . . . . . . . . 180

AT&T Ready2Go . . . . . . . . . . . . . . . . . . . . . . . . 181

AT&T Smart Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . 181

Battery Manager . . . . . . . . . . . . . . . . . . . . . . . . 181

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

DRAFT

FOR INTERNAL USE ONLY

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Data Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Device Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Flipboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Google . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Google Settings . . . . . . . . . . . . . . . . . . . . . . . . . 190

Google + . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Group Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Local . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Lookout Security . . . . . . . . . . . . . . . . . . . . . . . . 192

Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Mobile Hotspot . . . . . . . . . . . . . . . . . . . . . . . . . 194

Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195

My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198

myAT&T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199

Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200

Paper Artist . . . . . . . . . . . . . . . . . . . . . . . . . . . .202

Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202

Photo Suggest . . . . . . . . . . . . . . . . . . . . . . . . . .202

Play Books . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202

Play Magazines . . . . . . . . . . . . . . . . . . . . . . . . .203

Play Movies & TV . . . . . . . . . . . . . . . . . . . . . . . .203

Play Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204

Play Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204

POLARIS Office 5 . . . . . . . . . . . . . . . . . . . . . . . .205

S Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205

S Translator . . . . . . . . . . . . . . . . . . . . . . . . . . . .207

S Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208

Samsung Apps . . . . . . . . . . . . . . . . . . . . . . . . . .208

Samsung Hub . . . . . . . . . . . . . . . . . . . . . . . . . .209

Samsung Link . . . . . . . . . . . . . . . . . . . . . . . . . .212

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

Story Album . . . . . . . . . . . . . . . . . . . . . . . . . . . .215

TripAdvisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215

DRAFT

FOR INTERNAL USE ONLY

Video Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . . . 217

Voice Search . . . . . . . . . . . . . . . . . . . . . . . . . . 218

WatchON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

YPmobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

Section 11: Health and Safety Information 227

Exposure to Radio Frequency (RF) Signals . . . . 227

Specific Absorption Rate (SAR) Certification

Information . . . . . . . . . . . . . . . . . . . . . . . . . . 232

FCC Part 15 Information to User . . . . . . . . . . . . 234

Commercial Mobile Alerting System (CMAS) . . . 234

Smart Practices While Driving . . . . . . . . . . . . . 234

Battery Use and Safety . . . . . . . . . . . . . . . . . . . 236

Samsung Mobile Products and Recycling . . . . . 238

UL Certified Travel Charger . . . . . . . . . . . . . . . . 239

Display / Touch-Screen . . . . . . . . . . . . . . . . . . 239

GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . 240

Care and Maintenance . . . . . . . . . . . . . . . . . . . 241

Responsible Listening . . . . . . . . . . . . . . . . . . . . 242

Operating Environment . . . . . . . . . . . . . . . . . . . 244

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices . . . . . . . . . . 246

Restricting Children's Access to

Your Mobile Device . . . . . . . . . . . . . . . . . . . . 248

FCC Notice and Cautions . . . . . . . . . . . . . . . . . . 248

Other Important Safety Information . . . . . . . . . . 249

Section 12: Warranty Information .............251

Standard Limited Warranty . . . . . . . . . . . . . . . . 251

End User License Agreement for Software . . . . . 256

Section 13: Samsung Product

Registration .............................................264

Index ............................................................ 265

DRAFT

FOR INTERNAL USE ONLY

Getting Started 6

Section 1: Getting Started

This section explains how to start using your phone by first

configuring your hardware, activating your service, and then

setting up your voice mail.

Setting Up Your Phone

Prior to use, it is necessary to install both the battery and SIM

card into their corresponding internal compartments.

Opening the Battery Compartment

䡲

From the right-hand side of the camera, open the

battery compartment by prying the cover loose on the

right (1) and swinging it to the left (2).

Caution!

Do not bend or twist the battery compartment cover

excessively. Doing so may damage the cover.

Installing the SIM Card

When you subscribe to a cellular network, you are provided

with a plug-in SIM card loaded with your subscription details,

such as your PIN, available optional services, and many

others features.

Important!

The plug-in SIM card information and its contacts

can be easily damaged by scratching or bending,

so be careful when handling, inserting, or

removing the card. Keep all SIM cards out of reach

of small children.

䡲

Carefully slide the SIM card into the SIM card socket

(as shown) until the card locks into place (3).

DRAFT

FOR INTERNAL USE ONLY

•

Make sure that the card’s gold contacts face into the phone

and that the upper-left angled corner of the card is positioned

as shown.

Note:

If the card is not inserted correctly, the phone will not

detect the SIM card. Re-orient the card back into the slot

if the SIM is not detected.

Installing the Battery

1. Slide the battery cover release to the right (1)

OPEN

position. The battery cover flips upward (2).

2. Insert the battery into the opening, making sure the

connectors align (3).

Incorrect

Correct

DRAFT

FOR INTERNAL USE ONLY

Getting Started 8

3. Rotate the battery cover downward and slide the

battery cover release to the left (1)

position

Closing the Battery Compartment

䡲

Swing the battery compartment cover to the right (1)

and press the right-hand side (2) until you have a

secure seal.

Note:

Make sure the battery is properly installed before

switching on the phone.

Removing and Installing the Memory Card

You can use a microSD (SD) or microSDHC card to

expand available memory space if you desire. This secure

digital card enables you to exchange images, music, and

data between SD-compatible devices. This type of memory

card is designed for use with this mobile phone and other

devices.

Note:

Your phone has been tested to support up to a 64GB

memory card.

Installing the Memory Card

1. On the left-hand side of your phone, pull the microSD

memory card cover out and rotate it to expose the card

slot.

2. Push the microSD card into the slot until it clicks (as

shown).

•

Make sure the microSD’s gold contact pins face downward and

the card is securely inserted.

DRAFT

FOR INTERNAL USE ONLY

For more information on Memory Cards, see “Memory Card”

on page 48.

Removing the Memory Card

1. Open the memory card slot cover.

2. Push on the memory card until it clicks and is released.

3. Grasp the memory card and remove it from the phone.

Charging a Battery

Your device is powered by a rechargeable Li-ion battery. The

Travel Charger that is used to charge the battery, is included

with your device. Use only Samsung-approved batteries and

chargers.

Note:

You must fully charge the battery before using your

phone for the first time. A discharged battery recharges

fully in approximately 4 hours.

Note:

Long backlight settings, searching for service, vibrate

mode, web browser use, and other variables may

reduce the battery’s talk and standby times.

Although you can use the phone while the battery is

charging, doing so will require additional charging time.

Correct Incorrect

DRAFT

FOR INTERNAL USE ONLY

Getting Started 10

Using the Travel Charger

Important!

Verify that the handset battery is installed prior to

connection. If the battery is not properly installed

and the wall charger is connected, the handset

may power off and on continuously, preventing

proper operation.

1. Plug the flat end of the Travel Charger into the Power/

Accessory Interface connector and the other end into a

standard AC wall outlet.

2. When charging is finished, remove the flat end from

the interface connector jack on the phone.

Warning!

If your handset has a touch screen display, please

note that a touch screen responds best to a light

touch from the pad of your finger. Using excessive

force or a metallic object when pressing on the touch

screen may damage the tempered glass surface and

void the warranty. For more information, refer to

“Standard Limited Warranty” on page 251.

Note:

Failure to unplug the wall charger before you remove the

battery, can cause damage to the phone.

Correct

Incorrect

DRAFT

FOR INTERNAL USE ONLY

Low Battery Indicator

When the battery is weak and only a few minutes of talk time

remain, the battery icon ( ) blinks and the device sounds a

warning tone at regular intervals. In this condition, your

phone conserves its remaining battery power, not by turning

off the backlight, but by entering the dimming mode. For a

quick check of your battery level, glance at the battery

charge indicator located in the upper-right corner of your

device’s display. Solid color ( ) indicates a full charge.

When the battery level becomes too low, the phone

automatically turns off.

You can also choose to display a percentage value to the left

of the battery icon. Having a percentage value on-screen can

provide a better idea of the remaining charge on the battery.

䡲

From the Home screen, tap ➔

Settings

➔

My device

➔

Display

➔

Show battery

percentage

For more information, refer to “Display Settings” on

page 121.

Switching the Phone On or Off

1. Press and hold until the phone switches

on.

2. Swipe your finger across the screen to unlock the

phone.

Note:

The display language is preset to English at the factory.

To change the language, use the Language menu. For

more information, refer to “Language and input” on

page 136.

My device

DRAFT

FOR INTERNAL USE ONLY

Getting Started 12

3. To switch off the phone, press and hold ,

until the

Device options

screen displays.

4. Tap

Power off

to switch off the phone.

5. At the

Power off

prompt, tap

Locking and Unlocking the Touch

Screen

1. Press to lock the touch screen.

2. Press again to display the lock screen

then swipe your finger across the screen to unlock.

Note:

Swipe is the default screen locking method. To change

your screen lock, see “Lock Screen Settings” on

page 119.

Configuring your Phone

When you first turn on your phone, you will need to set up a

few things.

1. The

Welcome to AT&T Ready2Go!

screen displays. The

default language for your phone is English. If you would

like to select another language, tap

English

and scroll

up or down to select one of the listed languages.

2. Tap the

Accessibility

box at the bottom of the screen to

modify any of the Accessibility function if you desire.

For more information, refer to “Accessory Settings” on

page 133.

3. Tap

4. At the

Got Google?

display, tap

Yes

if you already have a

Google account and sign in to your account, or tap

you do not have a Google account.

5. If you answered

in step 4, tap

Get an account

and

follow the on-screen instructions to create a new

Google account or sign in to an existing account.

If you want to wait until later to create a Google

account, tap

Not now

DRAFT

FOR INTERNAL USE ONLY

Note:

In order to utilize your device to the fullest extent, you

will need to create a Google™ Account when you first

use your device. With a Google Account, you will have

access to more Google applications and applications will

always be in sync between your phone and computer.

6. At the

Google & location

screen, a blue check mark

displays next to the text that explains that you allow

Google’s location service to collect anonymous location

data from your phone. If you disagree, tap the check

mark to remove it.

7. A blue check mark also displays next to the text that

explains that you allows your location to be used for

Google search results and other Google services. If you

disagree, tap the check mark to remove it. Tap the

icon .

8. At the

This phone belongs to...

display, enter your

First

and

Last

names in the provided fields so that your

phone can personalize some applications. Tap .

9. At the

Set up email

display, tap an Email account to set

up your email. For more information, refer to “Using

Email” on page 100.

10. Tap

11. At the

Samsung account

display, tap

Create new

account

if you don’t have one yet or tap

if you

have already set up your Samsung account. For more

information, refer to “Creating a Samsung Account”

on page 14.

– or –

Tap

Skip

if you want to wait until later.

12. At the

Thank you

screen, enter a device name (optional)

and tap

13. At the

Learn about key features

display, tap each

function to learn more about them.

14. Tap

Finish

to complete your setup.

15. At the

AT&T Locker Setup

display, tap

Locker

or tap

Skip

if you want to sign up later. For more

information, refer to “AT&T Locker” on page 180.

The main Home screen displays.

DRAFT

FOR INTERNAL USE ONLY

Getting Started 14

Creating a Samsung Account

An active Samsung account is required to begin accessing

applications such as ChatON and Samsung Hub. If you did

not create a Samsung account when you first set up your

phone, follow these steps:

1. From the home screen, tap ➔

Settings

➔

Accounts

➔

Add account

2. Tap

Samsung account

3. Tap

Create new account

4. Enter the required information and tap

5. Tap

Terms and conditions

to read them and tap .

6. Tap all of the other headings to read them and tap .

7. Tap the

I accept all the terms

above

checkbox.

8. Tap

Agree

9. At the Welcome screen, tap

10. Follow the on-screen instructions to verify your email

address and activate your account.

Creating a New Google Account

In order to utilize your device to the fullest extent, you will

need to create a Google™ Account when you first use your

device. With a Google Account, Google applications will

always be in sync between your phone and computer.

If you did not create a new account during the setup

procedure when you first turned your phone on, follow these

steps:

1. From the Home screen, tap ➔

Gmail

The

Add a Google Account

screen displays.

2. Tap

New

to create a new Google account.

– or –

If you already have a Google account, tap

Existing

3. Follow the on-screen instructions to add a Google

Account.

Note:

Once you have created a Google account, you only need

to sign in.

DRAFT

FOR INTERNAL USE ONLY

Retrieving your Google Account

Password

A Google account password is required for Google

applications. If you misplace or forget your Google Account

password, follow these instructions to retrieve it:

1. From your computer, use an Internet browser and

navigate to

http://google.com/accounts.

2. Click on the

Can’t access your account?

link.

3. Tap the

I don’t know my password

radio button.

4. Enter your Email address and click

Continue

5. Follow the password recovery procedure.

Setting Up Your Voice Mail

1. From the Home screen, tap , then tap .

2. Follow the tutorial to create a password, record a

greeting, and record your name.

Note:

These steps may be different depending on your

network.

Accessing Your Voice Mail

1. From the Home screen, tap , then tap .

You may be prompted to enter a password.

2. When connected, follow the voice prompts from the

voice mail center.

Accessing Your Voice Mail From Another Phone

1. Dial your wireless phone number.

2. When you hear your voicemail greeting, press the

asterisk key on the phone you are using.

3. Enter your password.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 16

Section 2: Understanding Your Phone

This section outlines some key features of your phone and

describes the screen and the icons that appear when the phone

is in use. It also shows how to navigate through the phone and

provides information on using a memory card.

Features of Your Phone

The Samsung GALAXY S4 zoom is the optimum is

lightweight, easy-to-use device for consumers who want to

share their moments visually as well as verbally. In addition

to sending text messages, emails, instant messages, or text

social networking posts, consumers want to share images of

their daily moments in unique ways.

The following list outlines a few of the features included in

your phone.

•

LTE network (5-6 bands) with 1.9 gigahertz quad-core processor

•

16 Megapixel 10X optical zoom camera and camcorder with

1.9 Megapixel Front Facing camera

•

Brilliant 4.3” Full qHD Super AMOLED display

•

Android v 4.2.2, Jelly Bean Platform

•

Touch screen provides quick response to in-phone menus and

options including applications and up to seven home screens.

•

Smart Switch™ compliant. For more information, see

www.samsungsmartswitch.com

•

Ready access to the Internet

•

Built-in Bluetooth and advanced Wi-Fi

technology

•

Mobile Hotspot and USB Tethering capability

•

AT&T GPS Navigator functionality provides real-time navigation

•

Delivers data faster using 4G LTE and High Speed Packet Access

Plus (HSPA+).

•

Up to 64GB expandable memory slot

•

8 GB memory and 1.5 GB RAM

•

Corporate and Personal Email

•

Sync and update social network applications

•

Over 650,000 Apps available to download via Google Play

Store™ and Samsung Hub

•

Full Integration of Google Mobile™ Services (Gmail, YouTube,

Google Maps, Google Voice Search)

•

Multiple Messaging Options: Text/Picture/Video Messaging, and

Instant Messaging with Google Hangouts™

•

Samsung Link to share your media content across DLNA certified

devices

DRAFT

FOR INTERNAL USE ONLY

Front View of Your Phone

Light (RGB) and Proximity Sensors

: Light sensor lets you

use the ambient light level to adjust the screen

brightness/contrast. Proximity sensor darkens the

screen when held close to your face during a call.

External speaker

: allows you to hear the caller.

3. Application icons: you can place shortcuts to your

favorite applications on the Home screen.

4. Primary shortcuts: allows quick access to important

features such as Phone, Contacts, Messaging, Internet,

and Apps. For more information, refer to “Primary

Shortcuts” on page 22.

5. Menu key: allows you to access sub-menus with

additional options for different features and

applications such as Home screen, Phone, Contacts,

Messaging, and Web.

6. Home key: allows you to return to the main Home

screen from any Home screen or menu. Press and hold

to display Recent apps, Task Manager, and Google

Search. Quickly press twice to activate the S Voice

application.

7. Back key: allows you step backwards when navigating

a menu or web page.

Home screen indicator

: shows which Home screen is

presently displayed.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 18

9. Weather widget: displays Time, Day, Date,

Temperature and weather conditions for your area.

10. Indicator icons: shows the information needed to

operate your phone, such as the received signal

strength, phone battery level, time, unread Emails,

missed calls, etc.

11.

Front facing camera

: allows you to take pictures of

yourself when you toggle to the front facing camera.

For more information, refer to “Taking Photos” on

page 80.

DRAFT

FOR INTERNAL USE ONLY

Side Views of Your Phone

Infrared Blaster

: Used to emit infrared signals used for

controlling external devices.

2. Power/Lock key: ( ) lets you power your

phone on and off. Also allows you to lock or unlock the

touch screen. For more information on locking your

phone, see “Locking and Unlocking the Phone” on

page 37.

Volume keys

: allow you to adjust the ringer volume

while in standby mode or adjust the voice volume

during a call. When receiving an incoming call, briefly

press down either volume key ( ) to mute

the ring tone. Adjusts text size when reading a

message.

Shutter button

: From a Home page, press and hold to

launch the Camera. From the Camera view finder

screen, press to take pictures.

5. Power/Accessory Interface connector: allows you to

connect a Travel Charger or other optional accessories

such as a USB/data cable or a hands-free headset for

convenient, hands-free conversations.

Microphone

: allows other callers to hear you when you

are speaking to them. It is also used for the

Speakerphone.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 20

microSD (memory card) slot

: Install and remove an

optional microSD memory card for additional image/

photo/video storage and for music storage.

3.5mm Headset jack

: allows you to plug in an optional

headset or headphones.

Tripod mount

: allows you to attach your camera to a

tripod (not included).

10.

Microphone

: used for noise cancellation and stereo

recording.

DRAFT

FOR INTERNAL USE ONLY

Rear View of Your Phone

Microphone

: allows other callers to hear you when you

are speaking to them. It is also used for the

Speakerphone.

Shutter button

: From a Home page, press and hold to

launch the Camera. From the Camera view finder

screen, press to take pictures.

3. Flash: allows you to take pictures in low-light

conditions.

4. AF Assist light: used for focusing the camera when

taking pictures in low-light conditions.

Camera Mode ring

: allows you to quickly and simply

change the camera mode to suit the subject and

lighting conditions. For more information, refer to

“Camera Modes” on page 81.

6. Lens cover: protects the camera lens. It is

automatically opened when the lens is extended to

take pictures and record videos.

External speaker

: allows you to hear when the

Speakerphone is turned on.

8. Power/Accessory Interface connector: allows you to

connect a Travel Charger or other optional accessories

such as a USB/data cable.

Lanyard port

: allows you to attach a lanyard or

handstrap to the camera.

10.

microSD (memory card) slot

: Install and remove an

optional microSD memory card for additional image/

photo/video storage and for music storage.

247

810

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 22

Display Layout

Your display screen provides a wealth of information about

the phone’s status and options, as well as providing access

to application icons. For more information, refer to “Front

View of Your Phone” on page 17.

Primary Shortcuts

There are four non-movable Application Shortcuts that

appear at the bottom of all Home screens. The default

shortcuts are:

•

Phone

for dialing a number.

•

Contacts

for managing your contacts in your Address Book.

•

Messaging

for creating and viewing Messages.

•

Internet

for surfing the Internet.

•

Apps

for accessing the applications on your phone.

You can change the Phone, Messaging, S Note, and Internet

application shortcuts to any icon that is displayed in the Apps

menu.

For more information, refer to “Adding and Removing

Primary Shortcuts” on page 41.

Indicator Icons

This list identifies the symbols you’ll see on your phone’s

display and Indicator area:

Displays your current signal strength. The greater

the number of bars, the stronger the signal.

Indicates that the Airplane Mode is active. You

cannot send or receive any calls or access online

information.

Displays when there is no SIM card in the phone.

Displays when there is no network available.

Displays when your phone is in Blocking mode.

Displays when there is a system error or alert.

Displays to indicate a security warning. You are

prompted to set a screen lock password.

Displays when a call is in progress.

DRAFT

FOR INTERNAL USE ONLY

Displays when a call is on hold.

Displays when the speakerphone is on.

Displays when a call has been missed.

Displays when a call has been muted.

Displays when Call forwarding is set to Always

forward. For more information, refer to “Call

forwarding” on page 61.

Displays your battery charge level. Icon shown is

fully charged.

Displays when your battery is charging. Also

displays battery charge level.

Device Power Low – Shows your current battery

only has between 15 and 28 percent power

remaining.

Device Power Very Low – Shows your current

battery only has between 5 and 15 percent power

remaining.

Device Power Critical – Shows your current battery

only has less than 5 percent power remaining and

will immediately shutdown.

Displays when your connection to an EDGE network

is active.

Displays when your phone is communicating with

the EDGE network.

Displays when your connection to a UTMS, HSDPA,

HSPA, or HSPA+ network is active.

Displays when your phone is communicating with

the UTMS, HSDPA, HSPA, or HSPA+ network.

Displays when your connection to a 4G LTE network

is active.

Displays when your phone is communicating with

the 4G LTE network.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 24

Displays when your phone is downloading or has

downloaded a file. It will blink green when it is

installing.

Displays when the an outbound file transfer is in

progress.

Displays when a Play Store download has

completed.

Displays when updates are available for download.

Displays when the phone is connected to a

computer via a supported USB cable connection.

Displays when the phone is tethered via a

supported USB cable connection.

Displays when a new text or multimedia message

is received.

Displays when a new voice mail is received.

Displays when Email is received.

Displays when the time and date for a Calendar Event

has arrived. For more information, refer to

“Calendar” on page 182.

Displays when you set an alarm to ring at a specified

time. For more information, refer to “Alarm” o n p a g e

184.

Displays when the Sound profile is set to Mute.

Displays when the Sound profile is set to Vibrate.

Displays when Bluetooth is activated.

Displays when a Bluetooth device has been paired

with the phone.

Displays when Wi-Fi is connected, active, and

communicating with a Wireless Access Point

(WAP).

Displays when there is a Wi-Fi access point

available but you are not connected to it. May also

display if there is a communication issue with the

target Wireless Access Point (WAP).

DRAFT

FOR INTERNAL USE ONLY

For more details on configuring your phone’s settings, see

“Changing Your Settings” on page 107.

Displays when Wi-Fi Direct is active and your phone

is connected to another device.

Displays when your phone as been configured as a

portable Wi-Fi hotspot.

Displays when GPS is active and acquiring a signal.

Displays when data synchronization and

application sync is active and synchronization is in

progress for Gmail, Calendar, and Contacts.

Displays when your phone is connecting to the

Device Management server when you first turn on

your phone.

Displays when Near Field Communication (NFC)

has been activated.

Displays when your device is connected being used

to control streaming media and is connected to a

Digital Living Network Alliance (DLNA) certified

device using the Samsung Link application.

Displays when a file is being uploaded or sync’d

between your device and an external Web storage

location.

Displays when the uploaded or transferred file was

successfully delivered.

Displays when TTY device has been inserted.

Displays when a screen capture has been taken.

Displays when the keypad is active.

Displays when an emergency call is taking place.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 26

Application Icons

The Apps menu provides quick access to the items you use

most frequently.

The following table contains a description of each

application. If the application is already described in another

section of this user manual, then a cross reference to that

particular section is provided.

For information on navigating through the Apps icons, see

“Navigating Through the Application Menus” on page 38.

1. From the Home screen, tap , then tap one of the

application icons.

2. Follow the on-screen instructions.

3. To return to the main Home screen, tap .

The following applications are available:

Amazon Kindle

: allows you to download books,

magazines, and newspapers to read on your phone.

For more information, refer to “Amazon Kindle” on

page 177.

AT&T Code Scanner

: AT&T Code Scanner allows you to

scan 2D (QR and datamatrix codes) and 1D (UPC and

EAN) barcodes found in magazines, stores, and online.

For more information, refer to “AT&T Code Scanner” on

page 178.

AT&T DriveMode

: With the AT&T DriveMode

application, you can set your phone to auto reply when

you are driving and don’t want to answer the phone.

You can set auto reply to Messages, Emails, and Phone

Calls. You can also allow up to five of your contacts to

contact you while you are in Drive mode. For more

information, refer to “AT&T DriveMode” on page 179.

AT&T FamilyMap

: provides peace of mind by being able

to conveniently locate a family member from your

wireless phone or PC and know that your family's

location information is secure and private. For more

information, refer to “AT&T FamilyMap” on page 179.

AT&T Locker

: AT&T Locker allows you to store, share,

and sync all of your photos, videos, and documents in

one safe, convenient place; the AT&T cloud. For more

information, refer to “AT&T Locker” on page 180.

DRAFT

FOR INTERNAL USE ONLY

AT&T Navigator

: AT&T Navigator provides you with

access to real-time GPS-driven applications. These

programs not only allow you to achieve turn-by-turn

navigation, but also access local searches based on a

variety of category parameters. For more information,

refer to “AT&T Navigator” on page 180.

AT&T Ready2Go

: AT&T Ready2Go allows you to quickly

and easily setup your phone by using the web browser

on your PC. You can set-up email accounts, import

contacts, set wallpaper, configure Wi-Fi and many

more features. For more information, refer to

“Configuring your Phone” on page 12.

AT&T Smart Wi-Fi

: With AT&T Smart Wi-Fi, you can

maximize your battery performance, maximize your

data, simplify access to AT&T Hot Spots and Wi-Fi

networks, automate your Wi-Fi connections, and track

your data use. For more information, refer to “AT&T

Smart Wi-Fi” on page 170.

Battery Manager

: This app is a shortcut to your

Battery settings so you can manage how much

battery power is used for device activities. For

more information, refer to “Battery” on page 154.

Browser

: Open the web browser to start surfing the

web. The browser is fully optimized and comes with

advanced functionality to enhance the Internet

browsing feature on your phone. For more information,

refer to “Browser” on page 158.

Calculator

: Using this feature you can use the phone as

a calculator. The calculator provides the basic

arithmetic functions; addition, subtraction,

multiplication, and division. You can also use this as a

scientific calculator. For more information, refer to

“Calculator” on page 181.

Calendar

: With the Calendar application, you can

consult the calendar by day, week, month, year, create

events, and set an alarm to act as a reminder, if

necessary. For more information, refer to “Calendar”

on page 182.

Camera

: Use your 13.0 megapixel camera feature to

produce photos and videos. For more information, refer

to “Camera” on page 80.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 28

ChatON

: With the ChatON application, you can interact

with friends and family with text, images, hand-written

notes and video shared instantly. You can also chat in

groups. For more information, refer to “ChatON” on

page 183.

Chrome

: The Google Chrome app allows you to use the

Google Chrome web browser on your phone. For more

information, refer to “Chrome” on page 184.

Clock

: The Clock application allows you to access

alarms, view the World Clock, set a stopwatch, use a

timer, and setup a Desk Clock. For more information,

refer to “Clock” on page 184.

Contacts

: You can manage your daily contacts by

storing their name and number in your Address Book.

You can also synchronize your phone Address Book

with AT&T Address Book, the network backup service.

For more information, refer to “Contacts and Your

Address Book” on page 66.

Data Manager

: This app is a shortcut to your Data usage

settings so you can manage your data. For more

information, refer to “Data Usage” on page 110.

Device Help

: The Help application allows you to get

more information on your phone features,

applications, settings, accessories, and access to

online help. For more information, refer to “Device

Help” on page 188.

Downloads

: The Downloads application allows you to

manage all of your downloads from the Play Store and

the Browser. For more information, refer to

“Downloads” on page 188.

: Email enables you to review and create email

using various email services. You can also receive text

message alerts when you receive an important email.

For more information, refer to “Using Email” on page

100.

Flipboard

: This application creates a personalized

digital magazine out of everything being shared with

you. Access news stories, personal feeds and other

related material. For more information, refer to

“Flipboard” on page 189.

DRAFT

FOR INTERNAL USE ONLY

Gallery

: The Gallery is where you view photos and play

back videos. For photos, you can also perform basic

editing tasks, view a slideshow, set photos as

wallpaper or contact image, and share as a picture

message. For more information, refer to “Gallery” on

page 89.

Games

: allows you to access social and premium

games. Join Game Hub to enjoy free games with your

friends. For more information, refer to “Games” on

page 189.

Gmail

: Gmail is a web-based email service. Gmail is

configured when you first set up your phone.

Depending on your synchronization settings, Gmail

can automatically synchronize with your Gmail

account on the web. For more information, refer to

“Using Gmail” on page 102.

Google

: The Google Search application is the same on-

screen Internet search engine that is on the Google

Search Bar on your main Home screen. For more

information, see “Google Search Bar” on page 34.

Google Settings

Google+

: makes messaging and sharing with your

friends a lot easier. You can set up Circles of friends,

visit the Stream to get updates from your Circles, use

Messenger for fast messaging with everyone in your

Circles, or use Instant Upload to automatically upload

videos and photos to your own private album on

Google+. For more information, refer to “Google +” o n

page 104.

Group Play

: Group Play allows you to share pictures,

music, and documents in real-time with your friends.

For more information, refer to “Group Play” on page

190.

Hangouts

: Google Hangouts is a free Windows and

web-based application for instant messaging offered

by Google. Conversation logs are automatically saved

to a Chats area in your Gmail account. This allows you

to search a chat log and store them in your Gmail

accounts. For more information, refer to “Hangouts”

on page 104.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 30

Local

: Local is an application that uses Google Maps

and your location to help you find Restaurants, Cafes,

Bars, Attractions, and more. You can also add your own

locations. For more information, refer to “Local” on

page 192.

Lookout Security

: Lookout Mobile Security provides

key security options that are unique to the mobile

market. For more information, refer to “Lookout

Security” on page 192.

Maps

: Depending on your location, you can view basic,

custom, and satellite maps and local business

information, including locations, contact information,

and driving directions. You can also post public

messages about a location and track your friends. For

more information, refer to “Maps” on page 193.

Messages

: AT&T Messages brings your texts, calls, and

voicemail messages together into a single

conversation thread and is accessible by phone or

computer. For more information, refer to “Messages

App” on page 105.

Messaging

: You can send and receive different types of

messages. For more information, refer to “Messaging”

on page 92.

Messenger

: Messenger allows you to bring groups of

friends together into a simple group conversation.

When you get a new conversation in Messenger,

Google+ sends an update to your phone. For more

information, refer to “Messenger” on page 104.

Mobile Hotspot

: This application allows you to share

your phones’s mobile data connection as a portable

Wi-Fi hotspot. For more information, refer to “Tethering

& portable hotspot” on page 114.

Mobile TV

: Mobile TV is a subscription service that

allows you to watch your favorite TV shows using your

handset. For more information, refer to “Mobile TV” o n

page 194.

Music

: The Music app allows you to play music files that

you have stored on your phone and memory card. You

can also create playlists. For more information, refer to

“Music” on page 195.

DRAFT

FOR INTERNAL USE ONLY

My Files

: My Files allows you to manage your sounds,

images, videos, bluetooth files, Android files, and other

memory card data in one convenient location. For more

information, refer to “My Files” on page 198.

myAT&T

: myAT&T allows you to manage your own AT&T

account. You can review and pay your bill, check

minutes and data usage, upgrade to a new device, or

change your rate plan. For more information, refer to

“myAT&T” on page 199.

Navigation

: Navigation is an internet-connected GPS

navigation system with voice guidance. You can type or

speak your destination. For more information, refer to

“Navigation” on page 200.

Paper Artist

: allows you to draw new images or import

images from your Gallary and change them. For more

information, refer to “Paper Artist” on page 202.

Phone

: Allows you to access the dialer keypad, call

logs, and favorites. For more information, refer to “Call

Functions” on page 50.

Photo Suggest

: allows you to view photos of places of

interest near your location. For more information, refer

to “Photo Suggest” on page 202.

Play Books

: With Google Play Books, you can find

more than 3 million free e-books and hundreds of

thousands more to buy in the eBookstore. For more

information, refer to “Play Books” on page 202.

Play Magazines

: With Google Play Magazines, you can

subscribe to your favorite magazines and have them

available to read on your phone at any time or any

place. For more information, refer to “Play Magazines”

on page 203.

Play Movies & TV

: With Google Play Movies & TV, you can

rent thousands of different movies and television

shows. You can watch instantly, or download your

movie or show for offline viewing at a later time. For

more information, refer to “Play Movies & TV” o n p a ge

203.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 32

Play Music

With the Music application, while online, you can

play music that you have added to your music file as well as

any music you copied from your PC. While offline, you can

listen to music you have copied from your PC.

For more

information, refer to “Play Music” on page 204.

Play Store

: The Play Store provides access to

downloadable applications and games to install on

your phone. For more information, refer to “Play Store”

on page 204.

POLARIS Office 5

: POLARIS® Office 5 is a Microsoft

Office compatible office suite. This application

provides a central place for managing your documents

online or offline. For more information, refer to

“POLARIS Office 5” on page 205.

S Memo

: Use this application to create memos using

existing templates or your own design. You can use

handwriting or the keyboard to enter text. For more

information, refer to “S Memo” on page 205.

S Translator

: With the S Translator you can easily

translate words and phrases into many different

languages. For more information, refer to “S

Translator” on page 207.

S Voice

: With the S Voice application you can use your

voice to perform operations that you would normally

have to do by hand such as dialing a phone number,

texting a message, playing music, etc. For more

information, refer to “S Voice” on page 208.

Samsung Apps

: With Samsung Apps, you can

download hundred of applications from a variety of

categories. For more information, refer to “Samsung

Apps” on page 208.

Samsung Hub

: Samsung Hub is Samsung’s integrated

store for media content that offers a comprehensive

and consistent media service experience. You can

browse and purchase all media content within a single

store front. For more information, refer to “Samsung

Hub” on page 209.

Samsung Link

: With the Samsung Link app, you can

share and play content across smart devices anytime

and anywhere. For more information, refer to

“Samsung Link” on page 212.

DRAFT

FOR INTERNAL USE ONLY

Settings

: This icon navigates to the sound and phone

settings for your phone. It includes such settings as:

display, security, memory, and any extra settings

associated with your phone. For more information,

refer to “Changing Your Settings” on page 107.

Story Album

: With Story Album, you can create a digital

Album of your story in media. Special moments will be

on a timeline, and if you wish, you can have your album

published as a hard copy. For more information, refer

to “Story Album” on page 215.

TripAdvisor

: With the TripAdvisor, you can plan and

have your perfect trip. With over 75 million reviews and

opinions by travelers, it is easy to find the best hotels,

restaurants, and fun things to do. For more information,

refer to “TripAdvisor” on page 215.

Video

: The Video application plays video files stored on

your phone or microSD card. For more information,

refer to “Video” on page 215.

Video Editor

: allows you to cut, merge, and enhance

your videos with title frames and transitions. For more

information, refer to “Video Editor” on page 216.

Voice Recorder

: The Voice Recorder allows you to

record an audio file up to one minute long and then

immediately send it as a message. For more

information, refer to “Voice Recorder” on page 217.

Voice Search

: The Google Voice Search application

allows you to search the web using only your voice. For

more information, refer to “Voice Search” on page

218.

WatchON

: With the WatchON application, you can use

your phone as a remote control for your TV. For more

information, refer to “WatchON” on page 219.

YouTube

: YouTube is a video sharing website on which

users can upload and share videos, and view them in

MPEG-4 format. For more information, refer to

“YouTube” on page 223.

YPmobile

: The YPmobile (Yellowpages) application

provides quick and ready access to businesses, map

locations, and storage of your favorite searches. For

more information, refer to “YPmobile” on page 225.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 34

Tip:

To open applications quickly, add the icons of frequently-

used applications to the Home screen or to the folders you

created. For details, see “Customizing Your Home Screen”

on page 39.

Google Search Bar

The Google Search Bar (found on Home screen 2) provides

you an on-screen Internet search engine powered by

Google™.

1. From the main Home screen, tap the Google Search

bar .

2. Use the on-screen keypad to enter the item you want

to search for, then tap .

3. Tap to use Google Voice Search. Follow the

on-screen instructions.

Menu Navigation

You can tailor the phone’s range of functions to fit your needs

using both menus and widgets. Menus, sub-menus, and

features can be accessed by scrolling through the available

on-screen menus. Your phone originally has three home

screens but you can expand up to seven home screens.

Command Keys

Menu Key

Tap

to display a context-sensitive menu of options

for the current screen or feature.

Home Key

Press

Home

to display the main Home screen. Press

and hold to display recently used apps and access the Task

manager.

Back Key

Tap

Back

to return to the previous screen, option or step.

DRAFT

FOR INTERNAL USE ONLY

Terms used in this user manual

Tap

Lightly touch items to select or launch them. For example:

•

Tap the on screen keyboard to enter characters or text.

•

Tap a menu item to select it.

•

Tap an application’s icon to launch the application.

Touch and Hold

Activate on-screen items by a touch and hold gesture. For

example:

•

Touch and hold a widget on the home screen to move it.

•

Touch and hold on a field to display a pop-up menu of options.

Swipe and Palm Swipe

To swipe, lightly drag your finger vertically or horizontally

across the screen. Use swipe when:

•

Unlocking the screen

•

Scrolling through the Home screen or a menu

To palm swipe, swipe the side of your hand horizontally

across the screen. Use palm swipe when:

•

Capturing the screen

Panning

To pan, touch and hold a selected icon, then move the device

to the left or right to reposition it to another page. You must

first activate Motion on your device. Use panning to:

•

Move icons on your Home screens or Application Menus to

another page.

Tilt

To activate the tilt feature, press and hold two points on the

screen then tilt the device back and forth to reduce or

enlarge the screen. Use tilt to:

•

Reduce or enlarge the screen in the Gallery or Browser.

Turn over

Turn your phone over so that the screen faces downward. For

example:

•

Mute incoming calls and playing sounds by turning your phone

over.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 36

Using Motions and Gestures

By activating the various motion and gesture features, you

can access a variety of time saving functions.

Caution!

Excessive shaking or impact to the device may cause

unintended results. To learn how to properly control

motions, tap

Apps

➔

Settings

➔

My device

➔

Motions and gestures

. When

tapped, each entry comes with an on-screen tutorial.

•Motion

: Allows you to control your device using natural

movements (on the screen).

• Gyroscope calibration

: Allows you to properly calibrate your

device’s touch screen.

To activate Motion:

1. From the Home screen, tap

➔

Settings

➔

My device

➔

Motions and gestures

2. Tap the ON/OFF slider located to the right of

Motion

turn it on .

3. Read the on-screen notification and tap

Note:

At least one feature must be activated before Motion can

be activated.

4. Tap the ON/OFF slider located to the right of each

feature to turn it on .

For more information, refer to “Motions and Gestures” on

page 141.

My device

DRAFT

FOR INTERNAL USE ONLY

Locking and Unlocking the Phone

To unlock your phone:

1. Press the lock button located on the upper

right side of your phone.

2. The lock screen will display with

Swipe screen to

unlock

displayed at the bottom of the screen.

3. Swipe the touch screen in any direction.

4. The Home screen will be displayed.

Note:

There are several additional ways you can lock your

screen. For more information, refer to “Lock Screen

Settings” on page 119.

Home Screen Overview

The main home screen is the starting point for many

applications and functions, and it allows you to add items

like application icons, shortcuts, folders, or Google widgets

to give you instant access to information and applications.

This is the default page and accessible from any menu by

pressing .

Navigating Through the Home Screens

Your phone originally has three home screens but you can

expand up to seven home screens. If you like, you can place

different applications on each of the home screens.

䡲

From the main Home screen, sweep the screen with

your finger in either direction. The main Home Screen

is located in the middle with a Home screen on each

side.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 38

Navigating Through the Application Menus

Your phone initially has four Application Menus available.

Follow these steps to navigate through the Application

Menus:

1. At the Home screen, tap . The first Application

Menu will be displayed.

2. Sweep the screen left or right to access the other three

menus.

3. Tap one of the application icons.

Note:

As you add applications, the number of Application

menus that you have available will increase.

Navigating Using Sub-Menus

Sub-menus are available when you are at any Home screen

or have selected a feature or application such as Phone,

Contacts, Messaging, or Internet.

To access a sub-menu:

1. Tap .

A sub-menu will appear at the bottom of the phone

screen.

Sub-Menu items

DRAFT

FOR INTERNAL USE ONLY

2. Tap an option.

Accessing Recently-Used Apps

1. Press and hold from any screen to open the

recently-used applications window.

2. Tap an icon to open the selected application.

– or –

Tap to go to the Task manager.

– or –

Tap to go to Google Search.

– or –

Tap to delete the record of all recently used

applications.

Customizing Your Home Screen

You can customize your Home screen by doing the following:

•

Creating Shortcuts

•

Adding and Removing Primary Shortcuts

•

Adding and Removing Widgets

•

Moving Icons in the Apps Menu

•

Creating Application Folders

•

Adding a New Page to the Application Menu

•

Changing the Wallpaper

•

Adding and Deleting Home Screens

•

Moving Home Screens

Creating Shortcuts

Shortcuts are different than the current Home screen

Widgets that only launch an application. Shortcuts activate a

feature, action, or launch an application.

Note:

To move a shortcut from one screen to another, it must

first be deleted from its current screen. Navigate to the

new screen, then add the shortcut.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 40

Adding a shortcut from the Apps Menu

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Tap to display your current applications.

4. Scroll through the list and locate your desired

application.

5. Touch and hold the application icon. This creates an

immediate shortcut of the selected icon and closes the

Apps

tab.

6. While still holding the on-screen icon, position it on the

current page. Once complete, release the screen to

lock the new shortcut into its new position on the

current screen.

Adding a shortcut via the Add to Home screen

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Touch and hold on an empty area of the Home screen.

4. Under

Add to home screen

, tap

Apps and widgets

Folder

, or

Page

5. Press and hold a shortcut from the available list and

position it on the current screen.

Deleting a shortcut

1. Press to activate the main Home screen.

2. Touch and hold the desired shortcut. This unlocks it

from its location on the current screen.

3. Drag the icon over the

Remove

icon and release it.

As you place the shortcut into the Trash, both items

turn red.

Note:

This action does not delete the shortcut, it just removes

it from the current screen.

DRAFT

FOR INTERNAL USE ONLY

Adding and Removing Primary Shortcuts

You can change any of your primary shortcuts with the

exception of the

Apps

shortcut.

1. Press to activate the main Home screen.

2. Touch and hold the primary shortcut you want to

replace, then drag it to an empty space on any Home

screen.

3. Scroll through the App menu to find the shortcut you

want to add as the new primary short cut.

4. Touch and hold the new shortcut, then drag it to the

empty space in the row of primary shortcuts.

The new primary shortcut will now appear on all Home

screens.

Adding and Removing Widgets

Widgets are self-contained applications that reside in either

your Widgets tab or on the main or extended Home screens.

Unlike a shortcut, the Widget appears as an on-screen

application.

Adding a Widget

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Touch and hold on an empty area of the screen.

4. Tap

Apps and widgets

5. Tap the

Widgets

tab at the top of the screen.

6. Press and hold an available Widget to position it on the

current screen, then release the Widget.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 42

Removing a Widget

1. Touch and hold a Widget until you can move it around

on the screen.

2. Drag the Widget up to the

Remove

icon and

release it.

As you place the Widget into the Trash, both items turn

red.

Note:

This action does not actually delete the Widget from

your phone, it just removes it from the current Home

screen.

Moving Icons in the Apps Menu

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Tap

➔

View type

5. Tap

Customizable grid

. A green circle will appear next

to the option.

6. Tap

➔

Edit

7. Scroll through the list and locate the icon you wish to

move.

8. Touch and drag the icon to the position that you want.

To move to a different page, drag the icon to the edge

of the page until the page scrolls to the desired page.

9. Tap

Save

10. Press to return to the Home screen.

DRAFT

FOR INTERNAL USE ONLY

Creating Application Folders

You can create application folders to hold similar applications

if you wish.

To create a folder follow these steps:

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Tap

➔

Edit

5. Touch and hold the first application that you would like

to move to a folder.

6. Drag the icon down to the

Create folder

icon.

7. Enter a folder name and tap

A folder is displayed in the original place of the

application icon with the application icon displayed on

top of it. You can now drag other Apps into the folder.

8. To view information on an App, drag the App icon up to

the App info icon to view information on the

application.

9. Tap

Save

Adding a New Page to the Application Menu

You can add a new page to your application menu by

following these steps:

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Tap

➔

Edit

5. Touch and hold the first application that you would like

to move to a new page.

6. Drag the icon down to the

Create page

icon.

7. Tap

Save

The app will appear on a new page.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 44

Changing the Wallpaper

You can change the Wallpaper (background) of your home

screens by following these steps:

1. From any Home screen, touch and hold on an empty

area of the screen.

The

Home screen

window is displayed.

2. Tap

Set wallpaper

3. Select the location where you would like to change the

wallpaper. Tap

Home screen

Lock screen

, or

Home and

lock screens

4. Tap one of the following options:

•Gallery

: select a wallpaper from photographs you have taken

with your camera.

• Live wallpapers

: select an animated wallpaper. This option is

not available for the Lock screen option.

• Travel wallpapers

: This option displays a series of

recommended travel destinations. This option is not available

for the Home screen option.

• Wallpapers

: select from many still-life wallpapers.

5. Select a wallpaper and tap

Set wallpaper

Done

, or

Cancel

Adding and Deleting Home Screens

You can add and delete Home screens. You can have up to

seven Home screens.

To add a new Home screen:

1. Press to activate the main Home screen.

2. Tap

➔

Edit page

3. Tap the Home screen that contains .

A new screen is added.

4. If desired, touch and hold the new screen and drag it to

a different location.

5. Press to return to the main Home screen.

You can now add items to your new Home screen.

DRAFT

FOR INTERNAL USE ONLY

To delete a Home screen:

1. Press to activate the main Home screen.

2. Tap

➔

Edit page

3. Touch and hold the Home screen you want to delete.

4. Drag it to the trash can located at the top of the screen.

The trash can background will turn red.

5. If there are items on the Home screen, the

Remove

home screen page

prompt is displayed.

6. Tap

to delete the page and its contents, otherwise

tap

Cancel

7. Press to return to the main Home screen.

Moving Home Screens

You can arrange your Home screens in any order that you

want.

To move a Home screen, follow these steps:

1. Press to activate the main Home screen.

2. Tap

➔

Edit page

3. Touch and hold the Home screen you want to move.

4. Drag it to the location that you would like to place it.

In this example, the top right screen is moved to the

bottom left position.

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 46

When you move a Home screen, the other Home

screens are re-ordered automatically.

5. Press to return to the main Home screen.

Notification Bar

The Notification Bar includes a pull-down list to show

information about processes that are running, recent

notifications, and alerts. To display the Status indicator:

䡲

On the Home screen, touch and hold the Notification

Bar until the pull-down displays, then drag down

vertically.

DRAFT

FOR INTERNAL USE ONLY

Clearing Notifications

To clear all notifications from the Notification panel:

1. From the Home screen, touch and hold the Notification

Bar until the pull-down displays, then drag down

vertically.

2. Tap the

Clear

button.

The notifications are cleared and the panel closes.

Accessing Additional Panel Functions

In addition to notifications, the Notification panel also

provides quick and ready access to separate device

functions. These can be quickly activated or deactivated by

toggling them on or off. You can choose the functions that

will be displayed.

1. From the notification panel, tap to display

additional options.

Clear Button

DRAFT

FOR INTERNAL USE ONLY

Understanding Your Phone 48

The following functions (default) can either be

activated (green) or deactivated (gray): Wi-Fi, GPS,

Sound, Screen rotation, Bluetooth, Blocking mode,

Power saving, Screen Mirroring, S Beam, NFC, Driving

mode, Smart stay, Sync, and Airplane mode.

2. Tap then locate the Notifications panel area

located at the bottom of the Notifications panel screen.

3. In a single motion, touch and hold a desired function

then drag it to the top row.

4. Tap

Brightness adjustment

to create a check mark if

you want to be able to adjust the screen brightness via

the Notification panel.

5. Tap and then tap to display only your primary

functions.

Memory Card

Your device lets you use a microSD (SD) or microSDHC

card to expand available memory space. This secure digital

card enables you to exchange images, music, and data

between SD-compatible devices. This section addresses the

features and options of your device’s SD functionality. The

device has a USB SD card mode.

Mounting the SD Card

To store additional photos, music, videos, and other

applications, you must mount (install) the SD card prior to

use. Mounting the SD card establishes a USB connection

with your computer.

1. Insert the SD card into the external, SD card slot. For

more information, refer to “Removing and Installing the

Memory Card” on page 8.

2. Your SD card is scanned to see the available

information on it.

DRAFT

FOR INTERNAL USE ONLY

Unmounting the SD card

Unmounting the SD card prevents corruption and damage to

the SD card while removing it from the slot.

1. From the Home screen, tap ➔

Settings

➔

Storage

2. Scroll to the bottom of the display and tap

Unmount SD

card

3. Tap

For more information, refer to “Removing and Installing

the Memory Card” on page 8.

SD card Available Memory Status

To view the memory allocation for your external SD card:

1. From the Home screen, tap ➔

Settings

➔

Storage

2. The available memory for Device and SD card displays

under the

Total space

and

Available space

headings.

Erasing Files from the SD card

You can erase files from the SD card using the phone.

1. Ensure the SD card is mounted. For more information,

refer to “Mounting the SD Card” on page 48.

1. From the Home screen, tap ➔

Settings

➔

Storage

2. Tap

Format SD card

3. At the

Format SD card

confirmation prompt, tap

Format

SD card

Warning!

Performing the next step erases all data stored on

the SD card.

4. Tap

Delete all

to format or tap to cancel.

DRAFT

FOR INTERNAL USE ONLY

Call Functions 50

Section 3: Call Functions

This section describes how to make or answer a call. It also

includes the features and functionality associated with

making or answering a call.

For more information, refer to “Call Settings” on page 125.

Displaying Your Phone Number

䡲

Tap ➔

Settings

➔

About device

➔

Status

. Your phone number is displayed in the

phone number

field.

Making a Call

1. From the Home screen, tap and use the on-screen

keypad to enter the number you wish to dial.

2. Tap to make the call.

Note:

When you activate the

Auto redial

option in the Voice Call

menu, the phone will automatically redial up to 10 times

when the person does not answer the call or is already

on the phone. For more information, refer to “Call

Settings” on page 61.

Making an International Call

1. From the Home screen, tap , then touch and hold

. The + character appears.

2. Use the on-screen keypad to enter the country code,

area code, and phone number.

•

If you make a mistake, tap

until the desired numbers

have been deleted.

3. Tap to make the call.

Manual Pause Dialing

To manually call a number with pause(s) without storing it in

your Contacts list:

1. From the Home screen, tap and use the on-screen

keypad to enter the phone number.

2. Tap to display the dialer sub-menu.

3. Tap

Add 3-sec pause

to add a three second pause, and

use the keypad to enter the additional numbers.

Tip:

You can create pauses longer than three seconds by

entering multiple three second pauses.

DRAFT

FOR INTERNAL USE ONLY

4. Select

Add wait

to add a wait. A wait will pause the

calling sequence until you enter a number or press a

key.

5. Tap to make the call.

For more information, refer to “Adding Pauses to Contact

Numbers” on page 68.

Correcting an Entered Number

Use the following steps to correct a mis-typed entry when

dialing.

䡲

After entering a number using the keypad:

•

If you make a mistake, tap

to erase a single character.

•

Press and hold

to erase the entire string of numbers.

Ending a Call

䡲

Tap the key.

Dialing a Recent Number

All incoming, outgoing and missed calls are recorded in the

Call log. If the number or caller is listed in your Address

Book, the associated name is also displayed.

1. From the Home screen, tap .

2. Tap the Logs tab.

A list of recent calls is displayed.

3. Tap the desired Contact to enter the

Details

page, then

tap to make a call.

Making Emergency Calls

If you do not have a SIM card installed the first time you turn

on the phone, the

Insert SIM card to make calls

message

displays and an animated tutorial shows you how to install

the SIM card.

Without a SIM card, you can only make an emergency call

with the phone; normal cell phone service is not available.

Making an Emergency Call without a SIM card

1. Tap

Emergency call

from the on-screen display to make

an emergency call.

2. Enter 9-1-1 and tap . Complete your call. During

this type of call, you will have access to the Speaker

mode, Keypad, and End Call features.

3. Tap to exit this calling mode.

DRAFT

FOR INTERNAL USE ONLY

Call Functions 52

Making an Emergency Call with a SIM card

The Emergency calling mode makes redialing an emergency

number a 1-tap process. Before you can resume normal

calling operations, you should first exit this mode.

1. From the Home screen, tap .

2. Enter the emergency number (example: 911) and then

tap .

3. Complete your call. During this type of call, you will

have access to the Speaker mode, Keypad, and End

Call features.

Note:

This mode can drain your battery power more rapidly

than normal calling mode.

Making a Call Using Speed Dial

You can assign a short cut number to a phone number in your

Contacts List for speed dialing.

1. From the Home screen, tap

Contacts

to display

your Contacts List.

2. Tap to display the Contacts List sub-menu.

3. Tap

Speed dial setting

4. The

Speed dial setting

screen displays showing the

numbers 1 through 100. The number 1 is reserved for

Voicemail.

5. Tap an unused number and the

Select contact

screen

displays.

6. Tap a contact to assign to the number. The selected

contact number will display in the speed dial number

box.

7. To remove a speed dial number or change the order,

tap to display the Speed dial setting sub-menu.

8. Tap

Change order

Remove

9. To make a call using Speed Dial, tap ➔

Keypad

and from the Dialer, touch and hold the speed dial

number. If the speed dial number is more than 1 digit

long, enter the first digits, then hold the last digit.

Making a Call from the Address Book

You can store phone numbers that you use regularly on the

SIM card or in the phone’s memory. These entries are

collectively called the Address Book.

For further details about the Address Book feature, see

“Finding an Address Book Entry” on page 69.

DRAFT

FOR INTERNAL USE ONLY

Answering a Call

When a call is received the phone rings and displays the

caller’s phone number, or name if stored in the Address

Book.

1. At the incoming call screen:

•

Touch and drag

in any direction to answer the call.

•

Touch and drag

in any direction to reject the call and

send it to your voicemail.

•

Touch and drag the

Reject call with message

tab upward and

tap a predefined text message to send to the caller.

–

I’m driving

–

I’m at the cinema

–

I’m in class

–

I’m in a meeting

–

Sorry, I’m busy. Call back later.

– or –

–

Tap

Create new message

to compose a new message.

2. Tap to end the call.

Note:

You can answer a call while using the Address Book or

other menu feature. After ending the call, the phone

returns to the previously active function screen.

DRAFT

FOR INTERNAL USE ONLY

Call Functions 54

Dialing Options

From the Home screen and Application menus, you have the

option to access the Dialer and initiate a call by tapping

➔

Keypad

. From the Dialer and the Contacts screen, the

following tabs are located at the top of your screen:

•

Keypad

: dials the current number entered using the on-screen

keypad.

•

Logs

: displays a list of all dialed, received, and missed calls.

•

Favorites

: displays your contacts that you have marked as

Favorites.

•

Contacts

: takes you to your Address Book where you can select a

contact to call.

After you begin to enter numbers, the

Add to Contacts

option

appears so you can save the Contact if needed.

Call Log

The phone stores the numbers of the calls you’ve dialed,

received, or missed in the Call log. The Call log displays the

details of the call.

1. From the Home screen, tap .

2. Tap the Logs tab.

A list of recent calls is displayed. If the number or caller

is listed in your Address Book, the associated name is

displayed.

All calls made, received, and missed are listed. Types of calls

are identified by the following icons:

Calling Back a Missed Call

To call back a missed call number:

1. From the Home screen, tap ➔ Logs .

A list of recent calls is displayed. If the number or caller

is listed in your Address Book, the associated name is

displayed.

•

Incoming Calls

•

Outgoing Calls

•

Missed Calls

•

Rejected Calls

•

Auto Rejected Calls

DRAFT

FOR INTERNAL USE ONLY

2. Swipe the desired missed call to the right to call.

– or –

Swipe the desired missed call to the left to message.

Saving a Recent Call to your Address Book

1. From the Home screen, tap ➔ Logs .

A list of recent calls is displayed.

2. Tap the call you want to save to your Address Book.

3. The call detail page is displayed. Tap

Create contact

add the call to your Address Book.

The Create contact screen is displayed.

– or –

If you want to replace the number for an existing

contact, tap

Update existing

4. Enter information into the various fields using the

keypad.

5. Tap

Save

to save when you are finished.

For further details about the Address Book feature, see

“Adding a New Contact” on page 67.

Sending a Message to a Recent Call

1. From the Home screen, tap ➔ Logs .

A list of recent calls is displayed.

2. Swipe the entry you want to message to the left.

Add as new

Call the number Send a message

contact

Update an existing

contact

DRAFT

FOR INTERNAL USE ONLY

Call Functions 56

3. At the Message screen, tap the empty text field and

use the on-screen keypad to type in a message.

4. When you are done with your message, tap to

send.

For more information, refer to “Creating and Sending

Messages” on page 92.

Deleting a Call from the Call Log

1. From the Home screen, tap ➔ Logs .

A list of recent calls is displayed.

2. Touch and hold the call you want to delete from the Call

log.

3. Tap Delete.

4. At the

Delete log

prompt, tap

Delete

The call is deleted from the Call log.

Adding a Call to the Reject List

1. From the Home screen, tap ➔ Logs .

A list of recent calls is displayed.

2. Touch and hold the call you want to add to the Reject

List.

3. Tap Add to reject list.

4. At the Add to reject list prompt, tap

Future calls from this number will be rejected and sent

to your voicemail.

Call Duration

1. From the Home screen, tap ➔ Logs .

2. Tap ➔

Call duration

3. The following times are displayed for Voice and Data:

•Last call

: shows the length of time for the last call.

• Dialed calls

: shows the total length of time for all calls made.

• Received calls

: shows the total length of time for all calls

received.

• All calls

: shows the total length of time for all calls made and

received.

4. You may reset these times to zero by tapping

➔

Reset

DRAFT

FOR INTERNAL USE ONLY

Options During a Call

Your phone provides a number of control functions that you

can use during a call.

Adjusting the Call Volume

During a call, to adjust the volume, use the

Volume

keys on

the left side of the phone.

䡲

Press the

volume key to increase the volume level

and press the

Down

volume key to decrease the

volume level.

– or –

Quickly add more volume to the incoming audio by

tapping the on-screen

Extra volume

button .

From the Home screen, you can also adjust the ringer volume

using these same keys.

In-Call Options

During an active call there are several functions available by

tapping a corresponding on-screen button.

•

Hold

place the current active call on hold.

•

Add call

: displays the dialer so you can call another person.

•

Keypad

: displays the on-screen keypad, where you can

enter number using DTMF (Dual Tone Multi-Frequency).

•

End call

: terminates the call.

•

Speaker

: routes the phone’s audio through either the speaker or

through the earpiece.

–

Tap

Speaker

to route the audio through the speaker. (You can

adjust the speaker volume using the volume keys.) A green line

will appear under the Speaker button.

–

Tap

Speaker

again

to use the phone’s earpiece (see

“Using

the Speakerphone During an Active Call”

on page 60). The

green line will disappear when Speaker is not activated.

•

Mute/Unmute

turn the onboard microphone either on or off.

–

Tap

Mute

during a call to mute the microphone. A green line

will appear under the Mute button.

–

Tap

Mute

again to unmute the microphone. The green line will

disappear when Mute is not activated.

•

Headset

connects to a Bluetooth headset.

–

Tap

Headset

during a call to activate a Bluetooth headset. A

green line will appear under the Headset button.

–

Tap

Headset

again to de-activate the Bluetooth headset. The

green line will disappear when the Headset is not activated.

•

Tap

for more options:

–

Contacts

: allows you to go to your Contact list.

–

Memo

: allows you to write a memo.

–

Message

: allows you to write a message during a call.

DRAFT

FOR INTERNAL USE ONLY

Call Functions 58

Personalizing the Call Sound Setting

During a call it may be necessary to adjust the sound of the

incoming call by selecting an audio equalizer setting for the

current call.

1. From the call screen, tap .

2. Confirm the option is enabled .

3. Select an available option. Choose from: Adapt Sound,

Soft sound, Clear sound, and Off.

Activating Noise Reduction

During a call it may be necessary to activate the noise

reduction feature. Activating this feature can improve the

quality of your conversation by reducing ambient noise.

Noise reduction in on by default.

1. Tap to turn

Noise reduction off

2. Tap to turn

Noise reduction on

Placing a Call on Hold

You can place the current call on hold at any point during a

conversation. You can also make another call while you have

a call in progress if your network supports this service.

1. While on a call, tap

Hold

. This action places

the current caller on hold.

2. You can later reactivate this call by tapping Unhold

To make a new call while you have a call in progress

1. Tap

Hold

2. Tap

Add call

to display the dialer.

3. Enter the new number and tap .

Once connected, the active call will appear in a large

box at the top of your screen and the call on hold will

appear in a smaller box in the middle of your screen.

Switching Between Calls

When you have an active call and a call on hold, you may

switch between the two calls, changing the one on hold to

active and placing the other on hold.

1. Tap Swap.

The current call (caller #2) is placed on hold and the

previous call on hold (caller #1) is then reactivated so

that you can continue conversing with that person. The

active call will appear in a green box.

2. Tap to end the currently active call.

Hold

Unhold

Hold

DRAFT

FOR INTERNAL USE ONLY

To end a specific call

1. Tap

Swap

until the call you want to end appears in a

green box.

2. Tap to end the specific call.

3. Tap to end the remaining call.

To answer a call while you have a call in progress

You can answer another call while you have a call in progress

if you have activated your Call waiting feature. Otherwise, the

other call will go to your Voicemail box. For more information,

refer to “Additional settings” on page 128.

1. Tap and slide to the right to answer another call.

2. Tap

Putting "Name/Number" on hold

to put the first call

on hold.

– or –

Tap

Ending call with "Name/Number"

to end the first

call.

3. To switch between the two calls, tap Swap.

•Swap

: Places the current call on hold and then activates the

previous call. The active call will appear in a green box. Tap

Swap

again to switch back.

To end a call on hold

1. Tap to disconnect the active call.

2. The call on hold will now become the active call. Tap

to end the call.

3-Way Calling (Multi-Party Calling)

The 3-Way or Multi-Party feature allows you to answer a

series of incoming calls and place them on hold. If this

service is supported by the network, all calls can be joined

together. You are notified of an incoming call by a call waiting

tone.

Note:

The Merge option combines all of the calls you have

established with your phone (both active and on hold).

Swap places the current call on hold and then activates

the previous call.

This feature joins all of the calls you have established with

your phone (both active and on hold) into a multi-party call.

1. Tap and slide to the right to answer the call.

2. Tap and slide to the right to answer the next call.

DRAFT

FOR INTERNAL USE ONLY

Call Functions 60

3. Tap

Putting "Name/Number" on hold

to put the first call

on hold.

4. Join the first two callers into a single multi-party call by

tapping Merge .

5. To temporarily leave the conference call, tap

Hold

To rejoin the conference call tap

Unhold

6. Tap to end the call.

Using the Speakerphone During an Active Call

While in an active call, it is possible to enable the

speakerphone feature.

1. Tap

Speaker

The

Speaker

button now appears as and the

speakerphone is activated.

2. Use the

Volume

keys (located on the left side of your

phone) to adjust the volume.

3. To deactivate the speakerphone, tap

Speaker

Important!

For more information, refer to “Responsible

Listening” on page 242.

Switching off the Microphone (Mute)

You can temporarily switch your phone’s microphone off, so

that the other person cannot hear you.

Example:

You wish to say something to person in the room,

but do not want the person on the phone to hear

you.

To mute your phone during a call

1. Tap Mute .

The

Mute

button now appears as and Mute is

activated.

2. Tap Mute to deactivate the Mute function and

reactivate the microphone.

Bluetooth headset

1. Tap Headset .

2. The phone will scan for your Bluetooth headset. When

found, connect to the headset.

The

Headset

button now appears as and the

Bluetooth headset is activated.

3. Tap Headset to deactivate the Bluetooth headset

and reactivate the phone speaker.

Merge

Hold

Unhold

Speaker

Mute

Headset

DRAFT

FOR INTERNAL USE ONLY

Searching for a Number in Address Book

1. During the active call, tap

➔

Contacts

2. Tap the Address Book entry.

For further details about the Address Book feature, see

“Finding an Address Book Entry” on page 69.

Call waiting

The Call Waiting feature allows you to answer an incoming

call while you have a call in progress, if this service is

supported by the network, and you must first activate the

Call Waiting feature:

䡲

From the Home screen, tap ➔

➔

Call settings

➔

Additional settings

➔

Call waiting

You are notified of an incoming call by a call waiting

tone.

Call forwarding

1. From the Home screen, tap ➔ ➔

Call settings

➔

Additional settings

➔

Call forwarding

2. Tap one of the following options:

• Always forward

: allows you to forward all voice calls.

• Forward when busy

allows you to forward voice calls to a

designated number instead of your voice mail number if you

are on another phone call.

• Forward when unanswered

: allows you to forward voice calls

to a designated number instead of your voicemail number

when there is no answer on your phone. You can also select

the amount of time that the phone delays before forwarding.

• Forward when unreachable

: allows you to forward voice calls

to a designated number instead of your voicemail number

when you are not in an area covered by your service provider or

when your phone is switched off.

Call Settings

To access the Call settings menu:

䡲

From the Home screen, tap ➔ ➔

Call

settings

– or –

䡲

From the Home screen, tap ➔

Settings

➔

My device

➔

Call

For detailed information on all of the call settings, see “Call

Settings” on page 125.

My device

DRAFT

FOR INTERNAL USE ONLY

Entering Text 62

Section 4: Entering Text

This section describes how to select the desired text input

method when entering characters into your phone. This

section also describes the predictive text entry system that

reduces the amount of key strokes associated with entering

text.

Your phone comes equipped with an orientation detector that

can tell if the phone is being held in an upright (Portrait) or

sideways (Landscape) orientation. This is useful when

entering text.

Text Input Methods

There are two text input methods available:

•

Google Voice typing

: allows you to enter text by speaking.

•

Samsung keyboard (default)

: Samsung’s on-screen

QWERTY keypad that can be used in both portrait and

landscape orientation.

To change the input method, see “Keyboards and Input

Methods” on page 137.

Entering Text Using the Samsung

Keyboard

From a screen where you can enter text, rotate your phone

counterclockwise to a Landscape orientation. The on-screen

QWERTY keypad will display.

New

Paragraph

Text Input Mode

Shift

Key

Delete

Key

Space Bar

Voice Typing

and More Options

DRAFT

FOR INTERNAL USE ONLY

Changing the Text Input Mode - Keypad

There are two main keypad layout keys that will change the

on-screen keys within the QWERTY keypad.

The available Text Input modes are:

Sym

and

Abc

Note:

When in

Abc

mode, the

Sym

button will appear. When in

Sym

mode, the

Abc

ABC

abc

button will appear.

Using ABC Mode

1. If desired, rotate your phone counterclockwise to a

Landscape orientation.

2. When you tap the

Enter message

field, the following

screen displays:

3. Tap the desired alphabetic characters.

4. The screen initially opens in ABC mode. After typing the

first letter, the shift key ( ) will change to

and following letters will be lowercase.

5. Tap to input another upper-case letter or tap

twice to switch to ABC mode. The shift key will

change to in ABC mode. All following letters will

be uppercase until you tap the shift key again.

Symbol/Numeric Mode

: activates the number,

symbol, and emoticon keys.

ABC Mode

: activates the default alphabet keys.

Can also be set to

Abc

abc

by using the shift

() key.

DRAFT

FOR INTERNAL USE ONLY

Entering Text 64

Using Symbol/Numeric Mode

Use Symbol/Numeric Mode to add numbers, symbols, or

emoticons.

1. Rotate your phone counterclockwise to a Landscape

orientation.

2. Tap at the bottom of the screen. The following

screen displays:

3. Tap the desired number, symbol, or emoticon

characters.

4. Tap the button to access additional symbols.

5. Tap to return to Abc mode.

Predictive Text

By using the Predictive Text option, you can have next-letter

prediction and regional error correction, which compensates

for pressing the wrong keys on the QWERTY keyboard.

Predictive text is turned on by default.

1. Press and hold on the keyboard, then tap

2. Tap the ON/OFF slider, located to the right of the

Predictive text

field, to .

3. In the text portion of the message screen, begin typing

a word. A list of word options is displayed. Tap one of

the words to replace the word that has already been

typed or scroll the line of words to the left for more

word choices.

DRAFT

FOR INTERNAL USE ONLY

4. Continue typing your message. Tap to send the

message or tap for more options. For more

information, refer to “Creating and Sending Messages”

on page 92.

Note:

You can also use Predictive Text mode in the portrait

orientation.

Samsung Keyboard Settings

For information on how you can configure your Samsung

keyboard settings, see “Samsung Keyboard settings” on

page 138.

Using the Google Voice Typing Feature

You can use your voice to enter text using the Google Voice

typing feature.

1. Tap on the keyboard.

2. At the

Speak now

prompt, speak clearly and distinctly

into the microphone.

3. If the red microphone turns gray, then the feature has

timed out and you should tap the microphone icon to

start again.

The text is displayed in the message as you are

speaking.

4. After you have quit speaking for several seconds, tap

to return to the keyboard.

Note:

The feature works best when you break your message

down into smaller segments.

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 66

Section 5: Contacts and Your Address Book

This section allows you to manage your daily contacts by

storing their name and number in your Address Book.

Address Book entries can be sorted by name, entry, or group.

AT&T Address Book Activation

When you access the AT&T Address Book, the network

backup service, contacts are automatically synchronized

between your phone and online address book. The changes

you make are automatically saved and if you ever upgrade,

damage, or lose your phone, you can easily restore your

contacts onto your new phone.

To activate the AT&T Address Book:

1. From the Home screen, tap

Contacts

Your Address Book is displayed.

2. If you have not synchronized your phone with your

online AT&T Address Book recently, the

AT&T Address

Book

screen is displayed. Tap

Start Sync

if you want to

synchronize your Address Book.

3. Follow the on-screen instructions.

Your AT&T Address Book is Ready to Use. You can now make

a call or send a message through your Address Book.

You can also manage your Address Book on the web

http://www.att.com/addressbook

Synchronizing your AT&T Address Book

If you ever upgrade, damage, or lose your phone, you can

easily restore your contacts onto your new phone by

following these steps:

1. From the Home screen, tap

Contacts

2. Tap ➔

Settings

➔

AT&T Address Book

3. At the AT&T Address Book screen, tap

Yes

synchronize your phone with your online Address Book.

4. If there are existing contacts on your phone, you will be

prompted if you would like to remove them first. Tap

Yes

Note:

You must first copy any contacts that exist on your SIM

card to your phone. For more information, refer to

“Copying Contacts to the Phone” on page 78.

Your phone is synchronized.

DRAFT

FOR INTERNAL USE ONLY

5. At the

Your AT&T Address Book is Ready for Use

prompt,

tap

Your Contact list is displayed.

Adding a New Contact

Use the following procedure to add a new contact to your

Address Book.

Saving a Number from the Home screen

1. From the Home screen, tap

Contacts

➔ .

2. At the

Save contact to

prompt, tap on

Device

SIM

, or an

Account name.

3. Tap the image icon and assign a picture to the new

entry by choosing one of three options:

•Image

: retrieve a previously stored image from your Gallery or

from your My files folder and assign it to this entry. Tap an

image to assign the image to the contact, then tap

Done

• Pictures by people

: retrieve a previously shared image from

your Gallery.

• Take picture

: use the camera to take a new picture and assign

it to this entry, then tap

Done

•S Memo

: use an image from one of your S Memos.

•Remove

: although not an option with a new entry, deletes any

previously assigned image on an existing contact.

4. Tap the

Name

field and use the on-screen keypad to

enter the full name. For more information, refer to

“Entering Text” on page 62.

– or –

Tap next to the

Name

field to display additional

name fields.

5. Tap the

Phone number

field.

The numerical keypad is displayed.

The

Mobile

button initially displays next to the

Phone number

field. If you want to add a phone number

that is not a mobile number, tap the

Mobile

button and

select from Mobile, Home, Work, Work fax, Home Fax,

Pager, Other, Custom (add your own label), or Callback.

6. Enter the phone number.

Tap to add another Phone number field or tap

to delete a field.

Mobile

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 68

7. Tap any of the following fields that you want to add to

your new contact:

• Groups

: assign the contact to Not assigned, ICE - emergency

contacts, Co-workers, Family, or Friends.

•Ringtone

: adds a field used to assign a message tone that will

sound when messages are received from this contact.

• Message alert

: allows you to set the ringtone for your

message alerts.

• Vibration pattern

: allows you to set the specific type of

vibration.

•Add another field

tap this button to add another field such as

Phonetic name, Organization, Email, IM, Address, Notes,

Nickname, Website, Internet call, Events, or Relationship.

8. Tap

Save

to save the new contact.

Adding Pauses to Contact Numbers

When you call automated systems, you are often required to

enter a password or account number. Instead of manually

entering the numbers each time, you can store the numbers

in your Contacts along with special characters called pauses

and waits. A pause will stop the calling sequence for two

seconds and a wait will pause the calling sequence until you

enter a number or press a key.

To add a pause or a wait to an existing Contact:

1. From the Home screen, tap

Contacts

, and then tap

the name or number to open the Contact.

2. Tap to edit.

3. Tap the phone number field.

4. Tap the screen at the position where the pause or wait

needs to be added.

5. Tap .

6. Tap

Pause

to add a two-second pause or tap

Wait

add a wait, and use the keypad to enter the additional

numbers. A pause will be displayed as a comma (,) and

a wait will be displayed as a semi-colon (;).

7. Tap

Save

to save your changes, or tap

Cancel

discard.

DRAFT

FOR INTERNAL USE ONLY

Editing an Existing Contact

When editing an existing contact, you can tap a field and

change or delete the information, or you can add additional

fields to the contact’s list of information.

1. From the Home screen, tap

Contacts

2. Press and hold the Contact that you want to edit.

3. Tap

Edit

4. Tap any of the fields to add, change, or delete

information.

5. Tap

Save

to save the edited information.

Using Contacts

Dialing or Messaging from Address Book

Once you have stored phone numbers in the Address Book,

you can dial them easily and quickly by either using their SIM

card location number or by using the Search field to locate

the entry.

From the Address book, you can also send messages.

Finding an Address Book Entry

You can store phone numbers and their corresponding

names onto your SIM card and phone’s onboard memory.

The two locations are physically separate but are used as a

single entity, called the Address Book.

Depending on your particular SIM card, the maximum

number of phone numbers the SIM card can store and how

they are stored may differ.

1. From the Home screen, tap

Contacts

2. Within the Contacts list (sorted alphabetically), tap a

letter on the right side of the display to quickly jump to

the contacts beginning with that letter.

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 70

3. Tap the contact you wish to call or message.

4. Tap the phone icon to make a phone call or tap the

message icon to send a message.

For more information, refer to “Creating and Sending

Messages” on page 92.

Tip:

From the Contact list, sweep right over a listing to make a

call. Sweep left over a listing to send a message.

DRAFT

FOR INTERNAL USE ONLY

Joining Contacts

Joining Contact Information

Many people now maintain multiple email accounts, social

networking logins, and other similar account information. For

example, a Facebook account login name might differ from a

corporate email account login because they are maintained

separately and for different groups of people.

This device can synchronize with multiple accounts such as

Facebook, Twitter, MySpace, Corporate email, and Google.

When you synchronize your phone with these accounts, each

account creates a separate contact entry in the Contacts list.

If one of your contacts (Amy Smith, for example) has a

regular email account that you maintain in Gmail, but also

has a Facebook account under her maiden and married

name, as well as a Yahoo! chat account, when you merge

these accounts into your Contacts list you can join all of her

entries and view the information in one record.

The next time you synchronize your phone with your

accounts, any updates that contacts make to email account

names, email addresses, etc. automatically update in your

contacts list.

For more information about synchronizing accounts, see

“Synchronizing Accounts” on page 73.

1. From the Home screen, tap

Contacts

2. Tap a contact name (the name you want to join to

another entry).

Note

: typically this is the same contact

with a different name or account information.

3. Tap ➔

Join contact

The contact list is displayed.

Note:

Only contacts stored on your phone can be joined.

4. Tap the second contact entry (the entry in which to

join). The second contact is now joined with the first

and the account information is merged into one screen.

Note:

The information is still maintained in both entries, but

displays in one record for easier viewing when you join

the contacts.

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 72

5. Tap area under the

Connection

bar to view the contact

information you joined. The contacts and information

displays with an icon next to the contact name to

indicate what type of account information is contained

in the entry.

Unjoining a Contact

1. From the Home screen, tap

Contacts

2. Tap a contact name (the account name from which you

want to unlink an entry).

Note

: typically this is the same

contact with a different name or account information.

3. Tap the area under the

Connection

bar.

4. Tap the minus sign next to entry in which you

want to unjoin.

5. At the

Separate contact

prompt, tap

The contact is now separated and no longer displays in

the merged record screen.

Marking a Contact as Default

When you use messaging type applications, the application

needs to know which information is primary (default) in a

contact entry list. For example, you may have three different

contact records for John Smith, so the application will be

looking for the “default” number or entry.

1. From the Home screen, tap

Contacts

2. Tap a Contact name.

3. Tap ➔

Mark as default

. The Mark as default

screen displays radio buttons next to the contact

names or phone numbers of all the linked contacts.

The radio button next to the default contact will be

green.

4. To change the default contact, tap the radio button next

to another entry that you want to be the default. The

radio button will turn green, then tap

Done

DRAFT

FOR INTERNAL USE ONLY

Synchronizing Accounts

From the Accounts menu you decide if you want applications

to synchronize, send, and receive data at any given time, or if

you want the applications to synchronize automatically. After

determining how you want the accounts to synchronize,

indicate which account to synchronize with your Contacts

list.

1. From the Home screen, tap

Contacts

2. Tap

➔

Accounts

If you have previously added any accounts, the

Sync

settings

prompt is displayed with your current accounts

listed.

3. Tap an account that you would like to synchronize.

4. At the

Sync settings

screen, tap the options that you

would like to synchronize for that account.

5. Tap

Sync now

to synchronize the account.

The account is synchronized.

6. Tap to return to the Contacts list.

Note:

You can also synchronize your accounts using the

Settings menu. For more information, refer to

“Synchronizing Accounts” on page 145.

Address Book Options

You can access Address Book options while at the main

Address Book page or while in the details page for a specific

entry.

Options in Address Book

1. From the Home screen, tap

Contacts

➔ .

2. The following options are displayed:

• Delete:

allows you to delete 1 or more of your contacts.

• SIM Management

: allows you to copy contacts from your

phone to your SIM card or from your SIM card to your phone.

You can also delete contacts from your SIM.

•Import/Export

: allows you to move contacts to or from your

memory card or USB storage. You can also send a namecard

via Bluetooth, ChatON, Email, Gmail, Messaging, or Wi-Fi

Direct.

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 74

• Accounts

: allows you to add and manage your Samsung,

ChatON, Google, LDAP (Lightweight Directory Access Protocol),

and Microsoft Exchange ActiveSync accounts. Tap Add account

and then follow the on-screen instructions.

• Speed dial setting

: allows you to set up speed-dialing. For

more information, refer to

“Making a Call Using Speed

Dial”

on page 52.

• Send message/email

: allows you to send a text or message.

• Contacts to display

: You can choose to display all of your

contacts or only display contacts on your Phone, SIM, or

contacts stored to other accounts. You can also tap Customized

list to change other options on how your contacts are displayed.

•Settings

: allows you to choose set the following options:

–

Only contacts with phones

: allows you to only display

contacts that have phone numbers.

–

List by

: allows you to sort by First name or Last name.

–

Display contacts by

: allows you to sort by First name or Last

name first.

–

Service numbers

: allows you to

display or edit your service

numbers.

–

Contact sharing settings

: allows you to send all or individual

contacts via Bluetooth in the form of namecards.

–

AT&T Address Book

: allows you to access the AT&T Address

Book so you can sync your contacts.

•Help

: provides additional information on using your contacts.

Options at Selected Contact Screen

1. From the Home screen, tap

Contacts

2. Tap a contact and at the contact’s display screen, tap

3. The following options are displayed:

•History

: allows you to view the phone and message history for

the contact.

•Edit

: allows you to edit the contact’s information.

• Delete

: allows you to delete the contact from your Address

Book.

•Join contact

: allows you to join contacts with other contacts

(only displays when contact is saved to SIM).

• Separate contact

: allows you to separate contacts that have

been joined. This option only appears if the contact has been

joined.

DRAFT

FOR INTERNAL USE ONLY

• Mark as default

: when you have multiple contacts linked

together, you can mark one of them as default (only displays

when contact is saved to the phone). For more information,

refer to

“Marking a Contact as Default”

on page 72.

• Assign speed dial

: allows you to assign this contact to your

speed dial list. For more information, refer to

“Making a Call

Using Speed Dial”

on page 52.

• Share namecard via

: allows you to send the contact’s

information via Bluetooth, ChatON, Email, Gmail, Messaging, or

Wi-Fi Direct.

• Add to/Remove from reject list

: allows you to add or remove

the contact from your reject list. If they call while being on the

reject list, the call will be sent directly to voice mail.

• Print contact info

: allows you to print the contact’s namecard

to a Samsung printer using Wi-Fi.

• Add shortcut to home

: allows you to place a shortcut for this

contact on your Home screen.

Groups

Adding a Contact to a Group

1. From the Home screen, tap

Contacts

2. Press and hold a contact that you would like to add to a

group.

3. Tap

Add to group

4. Tap a group entry.

5. Tap

Save

The contact is added to the group.

Removing a Contact From a Group

1. From the Home screen, tap

Contacts

➔

Groups

2. Tap a group entry.

3. Tap ➔

Remove member

4. Tap all of the contacts you want to remove from this

group. A green check mark will appear next to their

name.

5. Tap

Done

The contacts are now removed from the group.

Groups

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 76

Creating a New Group

1. From the Home screen, tap

Contacts

➔

Groups

➔ ➔

Create

2. Tap the

Group name

field and use the on-screen

keypad to enter a new group name. For more

information, refer to “Entering Text” on page 62.

3. Tap

Group ringtone

to choose a ringtone for assignment

to this new group. Tap a ringtone to hear how it

sounds, then tap

– or –

Tap

Add

to select a ringtone from your music files.

4. Tap

Message alert

to choose an alert tone for

assignment to this new group, then tap

5. Tap

Vibration pattern

to choose a vibration audio file for

assignment to this new group, then tap

– or –

Tap

Create

and follow the on-screen instructions to

create your own vibration pattern.

6. Tap

Add member

to add contacts to the new group.

7. Tap each contact you want to add to create a check

mark. You can also tap

Select all

8. Tap

Done

9. Tap

Save

to save the new Group category.

Editing a Caller Group

To edit a Group entry, there must be at least one member as

part of the selected group.

1. From the Home screen, tap

Contacts

➔

Groups

2. Tap a group entry.

3. Tap ➔

Edit

4. Make modifications to the

Group name

Group ringtone

Vibration pattern

fields.

5. Tap

Add member

to add more contacts to this group.

6. Tap

Done

7. Tap

Save

to save the edited Group category.

Groups

DRAFT

FOR INTERNAL USE ONLY

Address Book Favorites

Once you have stored phone numbers in the Address Book,

you can add them to your Favorites list.

To view your Favorites list:

䡲

From the Home screen, tap

Contacts

➔

Favorites

Adding Favorites to your Address Book

1. From the Home screen, tap

Contacts

2. Within the Contacts list, touch and hold a contact that

you want to add to your favorites list.

3. Tap

Add to favorites

on the displayed list.

4. A gold star will appear next to the contact in the

Address Book.

Removing Favorites from your Address Book

1. From the Home screen, tap

Contacts

2. Within the Contacts list, touch and hold a contact that

you want to remove from your favorites list. Contacts in

your Favorites list will have a gold star.

3. Tap

Remove from favorites

on the displayed list.

4. The gold star will no longer appear next to the contact

in the Address Book.

Managing Address Book Contacts

You can copy, delete, and view the memory status for the

Phone and SIM contacts on your phone.

Copying Contacts to the SIM Card

Note:

When storing an Address Book entry into the SIM card,

only the name, phone number, and email address are

available as fields. Also, if you move the SIM card to

another phone that does not support additional fields on

the SIM card, this additional information may not be

available.

1. From the Home screen, tap

Contacts

➔ ➔

SIM Management

2. Tap

Copy Contacts to SIM

The phone then displays a list of your current phone

contacts.

3. Tap the contacts to place a check mark adjacent to

those entries you wish to have copied to the SIM card.

Favo rites

DRAFT

FOR INTERNAL USE ONLY

Contacts and Your Address Book 78

•

Repeat this step for all individual entries you wish copied to the

SIM or tap

Select all

to place a check mark alongside all

entries.

4. Tap

Done

to copy.

5. At the

Copy to SIM

display, tap

The selected numbers are copied to the SIM card.

Copying Contacts to the Phone

1. From the Home screen, tap

Contacts

➔ ➔

SIM Management

2. Tap

Copy Contacts from SIM

3. At the

Create contact under account

prompt, tap on

Device

or an account name that you would like to copy

the contact to.

The phone then displays a list of your current contacts

stored on your SIM card.

4. Tap the contacts to place a check mark adjacent to

those entries you wish to have copied to your phone.

•

Repeat this step for all individual entries you wish copied to

your phone or tap

Select all

to place a check mark alongside

all entries.

5. Tap

Done

to copy.

The selected numbers are copied.

Deleting Contacts from the SIM card

1. From the Home screen, tap

Contacts

➔ ➔

SIM Management

2. Tap

Delete Contacts from SIM

The phone then displays a list of your current SIM

contacts.

3. Tap the contacts to place a check mark adjacent to

those entries you wish to have deleted from the SIM

card.

•

Repeat this step for all individual entries you wish copied to the

SIM or tap

Select all

to place a check mark alongside all

entries.

4. Tap

Delete

5. At the

Delete Contacts from SIM

prompt, tap

The selected numbers are deleted from the SIM card.

DRAFT

FOR INTERNAL USE ONLY

Deleting Address Book Entries from the Phone

You can delete Phone or SIM entries from your phone’s

memory.

1. From the Home screen, tap

Contacts

2. Within the Contacts list, touch and hold a contact that

you want to delete.

3. Tap

Delete

on the displayed list.

4. At the

Delete

prompt, tap

to delete the contact or

Cancel

to exit.

Using the Service Dialing Numbers

You can view the list of Service Dialing Numbers (SDN)

assigned by your service provider. These numbers may

include emergency numbers, customer service numbers, and

directory inquiries.

1. From the Home screen, tap

Contacts

➔ ➔

Settings

2. Tap

Service numbers

3. Scroll through the available numbers (if available).

4. Tap a number and the call is made.

Note:

This menu is available only when your SIM card

supports Service Dialing Numbers.

DRAFT

FOR INTERNAL USE ONLY

Camera 80

Section 6: Camera

This section explains how to use the Camera features of your

phone to take photos and record videos, and how to use the

Gallery app to access the photos and videos you store on

your phone.

Camera

You can take photographs and shoot video by using the built-

in camera functionality. The 13 megapixel camera in your

phone produces photos in JPEG format.

Important!

Do not take photos of people without their

permission.

Do not take photos in places where cameras are

not allowed.

Do not take photos in places where you may

interfere with another person’s privacy.

Using the Camera

Taking Photos

Taking pictures with your device’s built-in camera is as

simple as choosing a subject, pointing the camera, then

pressing the camera key.

Note:

When taking a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

1. From the main Home screen, tap ➔

Camera

to activate the camera mode.

2. Using the phone’s main display screen as a viewfinder,

adjust the image by aiming the camera at the subject.

3. Before you take a picture, tap the Zoom

Out

and

keys

to zoom in or out. You can magnify the picture up to

x10 (1000 percent).

Focus Field

Camera


Viewer

Mode

Effects

Battery

Charge

Change

Mode

Quick Settings

Front

(Gallery)

Video

Record

Take


Facing

Camera

Options

Zoom

Out

DRAFT

FOR INTERNAL USE ONLY

4. If desired, before taking the photo, you can tap

on-screen icons to access various camera options and

settings.

5. You can also tap the screen to move the focus to the

area you touch.

6. Press the Camera key ( ) until the shutter sounds.

(The picture is automatically stored within your

designated storage location. If no microSD card is

installed, all pictures are stored on the Phone.)

7. While viewing a picture, after you have taken it, pinch

the screen outwards to zoom in or pinch the screen

inwards to zoom out.

You can magnify the picture up to x4.

8. Tap to return to the viewfinder.

Camera Modes

There are many different camera modes that you can use to

help optimize your photos depending on the conditions and

your experience.

1. From the camera viewfinder, tap the Mode button to

change the mode to one of the following:

•Auto

: Automatically adjusts your camera to optimize color and

brightness. This is the default setting.

•Smart

: Adjusts your camera to suit the subject and/or type of

photo you want to take:

–

Smart mode suggest

: Use this to take photos using a smart

mode you select from a list that the camera automatically

suggests. Half-press the Shutter button, select a smart mode

from the suggested list, then press the Shutter button to take the

photo.

–

Beauty face

: Use this to take photos with lightened faces for

gentler images.

–

Best photo

: Use this to take multiple photos in a short time,

and then choose the best photos among them. Press the

Shutter button to take multiple photos. When Gallery opens, tap

and hold thumbnails of photos to save, and then tap Done.

–

Continuous shot

: Use this to take photos continuously, 4

photos per second.

DRAFT

FOR INTERNAL USE ONLY

Camera 82

–

Best face

: Use this to take multiple group shots at the same

time and combine them to create the best possible image. Press

the Shutter button to take multiple photos. When Gallery opens,

tap the yellow frame on each face, and choose the best

individual face for the subject. After choosing a pose for each

individual, tap Done to merge the images into a single photo,

and tap Save.

–

Kids shot

: Use this to play a sound to attract a child’s attention

so you can take a photo.

–

Landscape

: Use this to take photos that emphasize the

landscape and sky by making green and blue more intense.

–

Dawn

: Use this to take photos that emphasize the dawn sky by

making blue more intense.

–

Snow

: Use this to take photos that emphasize the brightness of

snow by making the white more intense.

–

Macro

: Use this to take photos of close objects or text.

–

Food

: Use this to take photos that emphasize the vivd colors of

food.

–

Party/Indoor

: Use this to take photos of indoor activities, such

as parties, without blurring the images.

–

Action freeze

: Use this to take fast action photos.

–

Rich tone

: Use this to take and merge photos with various

exposures to produce soft images with rich color.

–

Panorama

: Use this to take wide panoramic photos. Press the

Shutter button to take a photo, and then move the camera in

any direction. When the blue frame aligns with the preview

screen, the camera automatically takes another shot in the

panoramic sequence. To stop shooting, press the Shutter button

again.

–

Waterfall

: Use this to take photos of waterfals and flowing

water using long exposures. Recommend you mount your

camera on a tripod.

–

Animated photo

: Use this to create a picture in which a few

selected static objects move by animating objects detected by

the device.

–

Drama

: Use this to take a series of photos of a moving object

and then merge them together into one image.

–

Eraser

: Saves the best of 5 taken pictures and removes any

passers by.

–

Sound & shot

: Use this mode to enrich pictures by adding

background sounds for a few seconds. The background sound

is recorded for up to 9 seconds after taking the photo.

DRAFT

FOR INTERNAL USE ONLY

–

Silhouette

: Use this to take photos of silhouettes using

backlighting.

–

Sunset

: Use this to take photos that emphasize the sunset by

making the colors more intense.

–

Night:

Use this to take photos in low-light conditions, without

using the flash. Press the Shutter button to take multiple photos.

Photos are automatically merged into a single photo.

–

Fireworks

: Use this to take photos of fireworks at night with

long exposures. Recommend you mount your camera on a

tripod.

–

Light trace

: Use this to take photos of light trails at night with

long exposures. Recommend you mount your camera on a

tripod.

•Expert

: Allows you to manually adjust some or all shooting

options, including the shutter speed, aperture value, exposure

value, and ISO sensitivity.

–

C (Color Wizard) mode

: Use this to take photos in which you

manually adjust the color balance by changing the EV

(brightness), color saturation, contrast, and sharpness.

–

P (Program) mode

: Use this to take photos using an optimal

exposure value resulting from automatic adjustments to shutter

speed and aperture value.

–

M (Manual) mode

: Use this to take photos in controlled

environments, such as a studio, or at night. In this mode, you

have full manual control of the exposure of your photos,

including shutter speed as well as aperture value.

•My mode

: Use this to register your favorite shooting modes, up

to 5 of them, then select them conveniently.

DRAFT

FOR INTERNAL USE ONLY

Camera 84

Quick Settings

Tap at the top of the display to quickly change Camera

settings. Not all of the following options are available in both

still camera and video camera modes. The available options

vary by mode.

Camera and Camcorder Settings

This section describes the different settings that you can

configure on your camera. Not all of the following options are

available in both still camera and video camera modes. The

available options vary by mode.

1. From the viewfinder, tap (

Quick Settings

) ➔

(

Camera Settings

2. The follow settings are located under the Camera,

Camcorder, Share, and General tabs. The settings that

are displayed will depend on what camera mode you

are in.

• Camera:

–

Flash

: Use this for low light shots. You can set the flash to Off,

Auto, or Fill in.

–

Timer

: Use this for delayed-time shots. You can set the timer

to Off, 2 sec, 5 sec, or 10 sec.

–

Face detection

: allows you to adjust the camera focus based

on face detection technology.

–

Photo size

: Select a resolution for photos. Use higher resolution

for higher quality. Higher resolution photos take up more

memory.

Configure Camera settings.

Activate or deactivate the flash.

Use this to activate or deactivate delay timer.

Use this to activate or deactivate GPS Tag.

Activate or deactivate the voice control to take

photos.

Activate or deactivate the sharing options.

Hide Quick settings.

DRAFT

FOR INTERNAL USE ONLY

• Camcorder:

–

Movie size

: Select a resolution for videos. Use higher resolution

for higher quality. Higher resolution videos take up more

memory.

–

Multi motion

: Use this for slow motion videos. You can set

Multi motion to 1/8, 1/4, 1/2, or 1 (normal speed motion).

–

Sound

: Use this to decrease zoom noise when recording

videos. You can set Sound to Quiet zoom turned on/off or Mute.

–

Windcut

: Use this to remove some background noise and wind

noise.

•Share:

–

Share shot

: Use this to send a photo/video directly to another

device using Wi-Fi Direct.

–

Buddy photo share

: Uses face recognition from pictures in

your contact entries to send your friends or family pictures of

themselves.

–

ChatON photo share

: Send a photo directly to another device

via ChatON.

–

Remote viewfinder

: Set a device to control the camera

remotely.

• Settings:

–

Camera function volume

: Adjust the auto focus sound.

–

Beep

: Activate or deactivate beep sounds.

–

Description

: Display mode descriptions.

–

Guidelines

: Display a guide to help you compose a scene.

–

Auto screen off

: Set the length of time the device waits before

turning off the display’s backlight.

–

Review

: Briefly display photos or videos taken.

–

Signature

–

Date/time Imprint

: Use this to imprint the date and/or the time

on the photos when taking them.

–

Auto adjust display

: Set the camera to automatically adjust

the brightness of the display.

–

GPS tag

: attach a GPS location tag to the photo. To improve

GPS signals, avoid shooting in locations where the signal

may be obstructed, such as between buildings or in low-

lying areas, or in poor weather conditions. Your location may

appear on your photos when you upload them to the

Internet. To avoid this, deactivate the GPS tag setting.

Note:

When you select a value other than 1,

sound is not recorded.

DRAFT

FOR INTERNAL USE ONLY

Camera 86

–

Voice control

: activates/deactivates voice control feature

that allows you to verbally take a photo.

–

Contextual filename

: allows you to have your location

added as part of the filename. You must first activate GPS

tag described above.

–

AF lamp

: Use this to activate the AF-assist light in low-light

conditions.

–

Start mode

: Select the default camera mode that launches

when the device is turned on.

–

Storage

: Select the memory location for storage.

–

Reset

: Reset the camera settings.

Viewing your Pictures

After you take a photo, you can access various options from

the Image Viewer. The Image Viewer uses your Gallery. For

more information, refer to “Gallery” on page 89.

Editing a Photo

You can edit your photos using the built-in Photo editor

application on your device. The photo editor application

provides basic editing functions for pictures that you take on

your phone. Along with basic image tuning like brightness,

contrast, and color it also provides a wide variety of effects

used for editing the picture.

1. From the Home screen, tap ➔

Gallery

2. Select a folder location and tap a file to open it.

3. With the image displayed, tap ➔

Edit

to launch the

Photo editor.

Note:

To select the picture area, touch and hold the current

picture.

4. Select an image area by touching and holding the

image and then selecting an available option:

• Selection mode

: provides several on-screen selection options

such as: Select area, Inverse selection, Selection size, and

Selection mode (Magnetic, Lasso, Brush, Round, and Square).

• Select all

: select the entire area of the current image.

Note:

To use this feature, you must activate the

GPS tag setting.

DRAFT

FOR INTERNAL USE ONLY

•Clipboard

: copies the currently selected area to your device’s

clipboard.

5. Use the following editor controls to edit your picture:

6. Tap to access the following options:

• Save as

: allows you to rename your current image and save it

to your gallery.

•Select image

: allows you to select a new image for editing.

• Take picture

: allows you to activate the camera and take a

new image for editing.

•Share via

: allows you to share your saved photo via AT&T

Locker, Bluetooth, ChatON, Email, Flipboard, Gmail, Google+,

Group Play, Hangouts, Messaging, Picasa, S Memo, or Wi-Fi

Direct.

•Set as

: assigns the currently saved image as either a: Contact

photo, Home and lock screens, Home screen, or Lock screen.

: move to previous photo project.

: move to next photo project.

Rotate

: allows you to rotate a photo in all 4

directions. You can also mirror image a photo.

Crop

: allows you to crop (cut-out) an area of a

photo.

Color

: allows you to Auto adjust color, Brightness,

Contrast, Saturation, Adjust RGB, Temperature,

Exposure, and Hue of a photo.

Effects

: allows you to add various effects to your

photo.

Portrait

: allows you to apply various face

correction effects such as: Red-eye fix, Airbrush

face, Face brightness, Out-of-focus, Beauty face,

Funny face, or Spot healing.

Sticker

: allows you to place various pre-created

on-screen stickers atop your current image.

Drawing

: allows you to add draw directly on your

current picture by using either a brush/pen or

eraser.

Frame

: places a pre-created border style atop

your current image.

DRAFT

FOR INTERNAL USE ONLY

Camera 88

Using the Camcorder

In addition to taking photos, the camera also doubles as a

camcorder that also allows you to record, view, and send

videos.

Note:

The camera may not be able to properly record videos to

a memory card with a slow transfer speed.

Shooting Video

Tip:

When shooting video in direct sunlight or in bright

conditions, it is recommended that you provide your

subject with sufficient light by having the light source

behind you.

1. From the main Home screen, tap

Camera

activate the camera mode.

2. Using the camera’s main display screen as a

viewfinder, adjust the image by aiming the camcorder

at the subject.

3. Before you take a video, use the Volume control

buttons to zoom in or out. You can magnify the video up

to x4 (400 percent).

4. Tap the Video key ( ) to begin shooting video. The

red light will blink while recording.

5. You can tap the screen to move the focus to the area

you touch.

6. target area.

7. To capture an image from the video while recording,

tap .

8. Tap the Pause key ( ) to stop the recording and

save the video file to your Camera folder.

9. Tap the Stop key ( ) to stop the recording and save

the video file to your Camera folder.

10. Once the file has been saved, tap the image viewer,

then tap to play your video.

11. Tap to return to the viewer.

Viewing your Videos

After you take a video, you can access various options from

the Image Viewer. The Image Viewer uses your Gallery and

the Video player. For more information, refer to “Gallery” on

page 89. Also, see“Video” on page 215.

DRAFT

FOR INTERNAL USE ONLY

Gallery

The Gallery is where you view photos and play back videos.

For photos, you can also perform basic editing tasks, view a

slideshow, set photos as wallpaper or contact image, and

share as a picture message.

1. Tap ➔

Gallery

All of the Albums that hold your pictures and videos will

be displayed with folder name and number of files.

2. Tap an Album and thumbnails of the contents will be

displayed.

Note:

If your device displays that the memory is full when you

access Gallery, delete some of the files by using

My Files

or other file management applications and try again. For

more information, refer to “My Files” on page 198.

Viewing Pictures

1. From the main gallery, tap ➔

Slideshow

to see a

slideshow of all of your pictures.

2. Tap a thumbnail to view a single picture.

Note:

If no control icons are displayed on the screen in

addition to the picture, tap anywhere on the screen to

display them.

3. The following options are available at the top of the

screen:

•AllShare

: allows you to share the picture via an optional

AllShare dongle.

•Share via

: allows you to share the picture via Bluetooth,

ChatON, Email, Flipboard, Gmail, Group Play, Messaging,

Picasa, S Memo, Send single image, or Wi-Fi Direct.

• Delete

: allows you to delete the picture.

•Camera

: activates the camera.

4. Tap for additional options.

DRAFT

FOR INTERNAL USE ONLY

Camera 90

Viewing Videos

Note:

If no control icons are displayed on the screen in

addition to the picture, tap anywhere on the screen to

display them.

1. Tap a video to select it.

2. Tap to play the video.

3. Tap for additional options.

For video player controls, see “Video” on page 215.

Using S Beam to Share Pictures

This feature (when activated via NFC) allows you to beam

large files directly to another compatible device that is in

direct contact. These files can be larger, such as Videos, HD

pictures, and other large files.You can beam images and

videos from your gallery, music files from your Music, and

more.

1. From the Home screen, tap ➔

Settings

2. If not already active, in a single motion touch and slide

the

NFC

slider to the right to turn it on .

3. Tap

S Beam

and make sure the feature is turned on.

4. If not already active, in a single motion touch and slide

the

S Beam

slider to the right to turn it on .

5. On the source device (containing the desired image or

video), tap ➔

Gallery

6. Locate and tap the selected image to open it in the

preview window.

Important!

Neither device must be in Lock mode or displaying

the Lock screen. They must both be active and

unlocked. It is recommended that the target device

be on the Home screen.

DRAFT

FOR INTERNAL USE ONLY

7. Place the two active NFC-enabled devices back to back

to begin (1).

Note:

If the

Touch to beam

screen does not appear on the

source device:

- Pull them apart

- Verify the image is visible in the preview window on

the source device (providing the file)

- Place them together again

8. From the

Touch to beam

screen, tap the reduced image

preview to begin the transfer (2).

9. When prompted, separate the two devices. After a few

seconds (depending on file size) the recipient with then

see the transferred file displayed on their screen.

To share multiple pictures via S Beam:

1. On the source device (containing the desired image or

video), tap ➔

Gallery

2. Locate the selected folder.

3. Touch and hold the first image and place a check mark

on it and all desired images.

4. Place the two active NFC-enabled devices back to back

to begin.

5. From the

Touch to beam

screen, tap the reduced image

preview to begin the transfer.

6. When prompted, separate the two devices.

7. The picture(s) is transferred to the other device.

Touch to beam

Place devices back to back

Tap the source image

DRAFT

FOR INTERNAL USE ONLY

Messaging 92

Section 7: Messaging

This section describes how to send and receive different

types of messages. It also includes the features and

functionality associated with messaging.

Types of Messages

Your phone provides the following message types:

•

Text Messages

•

Multimedia (Picture, Video, and Audio) Messages

•

Email and Gmail Messages

•

Google Talk

•

ChatON

The Short Message Service (SMS) lets you send and receive

text messages to and from other mobile phones or email

addresses. To use this feature, you may need to subscribe to

your service provider’s message service.

The Multimedia Messaging Service (MMS) lets you send and

receive multimedia messages (such as picture, video, and

audio messages) to and from other mobile phones or email

addresses. To use this feature, you may need to subscribe to

your service provider’s multimedia message service.

Important!

When creating a message, adding an image, a

sound file, or a video clip to a text message

changes the message from a text message to a

multimedia message.

Messaging icons are displayed at the top of the screen and

indicate when messages are received and their type. For

more information, refer to “Indicator Icons” on page 22.

Creating and Sending Messages

1. From the main Home screen, tap

Messaging

➔

Compose

Note:

The main Home screen initially contains the

Messaging

icon. If you delete it, or if you want to access

Messaging from another Home screen, you must tap

Apps

➔

Messaging

DRAFT

FOR INTERNAL USE ONLY

2. Tap on the

Enter recipient

field to manually enter a

recipient or tap to select a recipient from your

Contacts. You can also select the recipient based on

Groups, Favorites, or Logs.

3. If adding a recipient from your Contacts, tap the

contact to place a check mark then tap

Done

The contact will be placed in the recipient field.

Note:

For the Group option, if the number of recipients is less

than 10, all members in the group will be added. You will

need to delete any unnecessary members in the list by

selecting the trash can icon and deleting unwanted

entries.

Note:

Enter additional recipients by separating each entry with

a semicolon (;) then using the previous procedure.

4. Tap the

Enter message

field and use the on-screen

keypad to enter a message. For more information, refer

to “Entering Text” on page 62.

5. Add more recipients by tapping the recipient field.

6. Review your message and tap

Send

Note:

If you exit a message before you send it, it will be

automatically saved as a draft.

Message Options

Options before composing a message

1. From the main Home screen, tap

Messaging

2. Before composing a message, tap to reveal

additional messaging options:

•Search

: allows you to search through all of your messages for

a certain word or string of words. Enter a search string in the

Messaging Search window and tap .

• Delete threads

: allows you to delete any message thread.

Select the messages to delete and a green check mark will

appear next to the message. Tap

Delete

•Draft messages

: displays the draft messages folder and its

contents.

• Locked messages

: displays the locked messages folder and

its contents.

• Scheduled messages

: displays the scheduled messages

folder and its contents.

DRAFT

FOR INTERNAL USE ONLY

Messaging 94

• Spam messages

: displays the spam messages folder and its

contents.

•Settings

: allows you to access Messaging settings. For more

information, refer to

“Messaging Settings”

on page 97.

Options while composing a message

1. While composing a message, tap to reveal

additional messaging options.

•Insert smiley

: allows you to add emoticons, such as a happy

face to your message.

•Add text

: allows you to copy text from your contacts, calendar,

or from a memo to add to your message. This is a convenient

feature for adding names, phone numbers, events, etc. to your

message.

For more information, refer to “Adding

Additional Text”

on page 95.

• Add to Contacts

: allows you to add the recipient to your

Contacts list. This option only appears if the recipient is not

already in your Contacts list.

•View contact

: allows you to see information on the recipient.

This option only appears if the recipient is in your Contacts list.

• Add slide

: allows you to add a new page to a message.

• Add recipients

: allows you to add additional recipients.

• Delete message

: allows you to delete the message.

• Scheduled message

: allows you to assign the current

message for scheduled delivery at a designated time.

• Add to spam numbers

: allows you to tag a number as spam

so that these messages can be directly delivered to your spam

folder.

• Remove from spam numbers

allows you to unregister a

number from the spam number list. This option only appears if

the number was previously registered as spam.

•Discard

: allows you to delete the current message.

•Translate

: launches a Translate popup menu. Here you can

both assign the sender’s original language and assign a target

language for the recipient (they will receive your message in the

designated language). Other options include, Check Incoming

messages only, and Include original text in outgoing message.

Tap to create a check mark.

Adding attachments to a message

To add an attachment to your message, tap and select

one of the following options:

•

Images

: allows you to tap an existing image from your Pictures

list to add it to your message.

DRAFT

FOR INTERNAL USE ONLY

•

Take a picture

: allows you to temporarily exit the message, take

a photo with phone’s camera, and then add it to your message by

tapping

Save

•

Video

: allows you to choose an existing video from the Videos list,

then add it to your message

•

Record video

: allows you to temporarily exit the message,

record a video clip using the phone’s camera, and then add it

to your message by tapping

Save

•

Audio

: allows you to choose an existing audio file from the

Audio list, then add it to your message by tapping the circle to

the right of the audio so that it turns green, then tapping

Done

•

Record audio

: allows you to temporarily exit the message and

record an audio clip using the phone’s microphone. It is then

automatically attached to the message.

•

S Memo

: allows you to add an S Memo that you have created.

•

Calendar

: allows you to add an event from your calendar. Select

the desired event and tap

Done

•

Location

: allows you to attach a thumbnail of a map showing

your location.

•

Contacts

: allows you to tap on an existing Address Book entry,

then add it to your message by tapping

Done

Adding Additional Text

You can copy text such as names, phone numbers, and

events from your Contacts, Calendar or a Memo.

1. While composing a message, tap ➔

Add text

2. At the Add text screen, select one of the following:

•S Note

: allows you to insert text from an existing S Note.

•Calendar

: allows you to add the name, date, and time of a

calendar event to your message.

•Location

: allows you to add an address and the link to the

location on Google Maps.

•Contacts

: allows you to add the name and phone number of

any of your contacts to your message.

• Text templates

: allows you to add pre-defined phrases and

sentences.

The information is added to your message.

Viewing New Received Messages

1. When you receive a new message, the new message

icon will appear at the top of your screen.

2. Open the Notification Bar and select the message. For

more information, refer to “Notification Bar” on page

46.

DRAFT

FOR INTERNAL USE ONLY

Messaging 96

– or –

From the main Home screen, tap

Messaging

then

tap the new message to view it.

The selected message appears in the display.

3. To play a multimedia message, tap .

•

To pause playback of the multimedia message, tap

4. To scroll through the message (if additional text pages

have been added), touch the screen and in a single

motion, scroll up or down the page.

Message Threads

Sent and received text and picture messages are grouped

into message threads. Threaded messages allow you to see

all the messages exchanged (similar to a chat program) and

displays a contact on the screen. Message threads are listed

in the order in which they were received, with the latest

message displayed at the top.

To access message thread options:

䡲

From the main Messaging screen, touch and hold the

message to display the following options:

•View contact

: displays the Contact’s Overview page.

•Add to contact

: begins the process of adding the new number

to your Contacts list.

• Delete thread

: deletes the currently selected message thread.

•Add to spam numbers

: adds the current sender to a spam list.

ny new texts from this sender are automatically blocked.

To access additional Bubble options:

䡲

Touch and hold the message bubble within an active

message conversation to display the following options:

• Delete message

: deletes any currently selected message

bubble from the thread.

• Copy message text

: copies the currently selected message

bubble from the thread.

•Lock/Unlock message

: locks or unlocks the currently selected

message bubble from being accidentally deleted.

•Forward

: allows you to forward the currently selected message

bubble to an external recipient.

•Copy to SIM

: copies the currently selected message bubble as

a single text message within the SIM card.

• View message details

: displays details for the currently

selected message bubble.

DRAFT

FOR INTERNAL USE ONLY

•Translate

: translates the text from the currently selected

bubble into a desired language.

Deleting Messages

Deleting a single message thread

1. From the main Home screen, tap

Messaging

2. Touch and hold a message, then tap

Delete thread

3. At the

Delete

prompt, tap

to delete or

Cancel

cancel.

Deleting multiple message threads

1. From the main Home screen, tap

Messaging

2. Tap ➔

Delete threads

3. Tap each message you want to delete. A check mark

will appear beside each message you select.

4. Tap

Delete

5. At the

Delete

prompt, tap

to delete or

Cancel

cancel.

Message Search

You can search through your messages by using the

Message Search feature.

1. From the main Home screen, tap

Messaging

2. Tap ➔

3. Use the on-screen keypad to enter a word or phrase to

search for, then tap .

4. All messages that contain the search string you

entered are displayed.

Messaging Settings

To configure the settings for text messages, multimedia

messages, Voice mails, and Push messages.

1. From the main Home screen, tap

Messaging

➔

Settings

2. The following Messaging settings are available:

General settings:

• Delete old messages

: deletes old messages when the limit is

reached, rather than having them overwritten.

• Text message limit

: allows you to set a limit on how many text

messages can be in one conversation.

• Multimedia message limit

: allows you to set a limit on how

many multimedia messages can be in one conversation.

• Text templates

: allows you to edit or add new text templates to

use in your messaging.

DRAFT

FOR INTERNAL USE ONLY

Messaging 98

Text message (SMS) settings:

• Manage SIM card messages

: allows you to manage the

messages that you have stored on your SIM card.

• Message center

: allows you to enter the number of your

Message center where your messages reside while the system

is attempting to deliver them.

• Input mode

: allows you to set the input mode for your text

messages. Choose between GSM Alphabet, Unicode, or

Automatic.

Multimedia message (MMS) settings:

• Group messaging

: allows you to send a single message to

multiple recipients.

•Auto-retrieve

: allows the message system to retrieve

messages automatically.

•Creation mode

: allows you to select the creation mode, Free,

Restricted, or Warning.

–

Restricted

: you can only create and submit messages with

content belonging to the Core MM Content Domain.

–

Warning

: the phone will warn you via pop up messages that

you are creating a multimedia message which does not fit the

Core MM Content Domain.

–

Free

: you may add any content to the message.

• MMS alert

: allows you to receive an alert when MMS mode

becomes active.

Display:

• Bubble style

: allows you to choose from several bubble styles

for your messages. Bubbles are the rounded boxes that

surround each message.

• Background style

: allows you to choose from several

background styles for your messages.

•Use the volume key

: allows you to change the text size by

using the up or down volume keys.

Push message settings:

• Push messages

: allows you to receive push messages from

the network.

Cell Broadcast (CB) settings:

•CB activation

: allows you to receive Cell Broadcast (CB)

messages.

• Channel configuration

: allows you to set up the channel that

you will receive CB messages on.

DRAFT

FOR INTERNAL USE ONLY

Notifications settings:

• Notifications

: allows you to see message notifications on your

status bar.

• Select ringtone

: allows you to set the ringtone for your

message notifications.

•Vibrate

: allows you to configure the vibration mode associated

with message alerts.

• Message alert repetition

: allows you to set the interval for new

message alerts. Choose from: Once, Every 2 minutes, or Every

10 minutes.

• Preview message

: when enabled, allows you to view a

preview of new message text on the Status bar.

Emergency message settings:

• Emergency alerts

: allows you to receive wireless emergency

alerts from the Commercial Mobile Alerting System (CMAS).

For more information, refer to

“Emergency Alerts”

on page

100.

• Emergency notification review

: allows you to play the

emergency alert tone so you will know what to expect when an

alert is received.

• Alert reminder

: allows you to set reminders after you receive

an alert. You can select Once, Every 2 minutes, Every 15

minutes, or Off (default).

Signature settings:

• Add signature

: when enabled, this feature allows you to create

a signature at the end of your outgoing text messages.

• Signature text

: allows you to enter a desired signature for your

message.

Spam message settings:

• Spam settings

: when enabled, allows you to configure

available spam settings such as:

• Add to spam numbers

: allows you to manually enter and

assign a phone number as being sent from a spam source.

• Add to spam phrases

: allows you to assign a specific text

phrase as belonging to a spam message. Ex: Dear friend.

• Block unknown senders

: when active, automatically blocks

incoming messages from unknown sources or blocked numbers.

DRAFT

FOR INTERNAL USE ONLY

Messaging 100

Emergency Alerts

This device is designed to receive wireless emergency alerts

from the Commercial Mobile Alerting System (CMAS) which

may also be known as the Personal Localized Alerting

Network (PLAN). If your wireless provider has chosen to

participate in CMAS/PLAN, alerts are available while in the

provider's coverage area. If you travel outside your provider's

coverage area, wireless emergency alerts may not be

available. For more information, please contact your wireless

provider.

Emergency Alerts allows customers to receive

geographically-targeted messages. Alert messages are

provided by the US Department of Homeland Security and

will alert customers of imminent threats to their safety within

their area. There is no charge for receiving an Emergency

Alert message.

There are three types of Emergency Alerts:

•

Alerts issued by the President

•

Alerts involving imminent threats to safety of life (Extreme and

Severe)

•

AMBER Alerts (missing child alert)

Customers may choose not to receive Imminent Threats

(Extreme and Severe) and AMBER Alerts. Alerts issued by the

President can not be disabled. To disable Imminent Threats

and AMBER Alerts, follow the instructions below:

1. From the main Home screen, tap

Messaging

2. Tap ➔

Settings

3. Scroll to the bottom and tap

Emergency alerts

4. All alerts are enabled by default (check mark showing).

Tap on an alert option to disable the alert and remove

the check mark.

Using Email

Email enables you to review and create email using various

email services. You can also receive text message alerts

when you receive an important email.

Creating an Email Account

1. From the Home screen, tap

Your accounts screen displays with an Email setup

screen displayed.

2. Enter you email address in the

address

field.

3. Enter your password in the

Password

field.

DRAFT

FOR INTERNAL USE ONLY

101

4. If you want to see your password as it is being typed,

tap

Show password

to create a check mark.

5. Tap

6. At the

Account options

screen, tap any of the options

you would like.

7. Tap

8. Enter a name for this email account (optional).

9. Tap

Done

Creating a Corporate Email Account

Use the following procedure to configure your phone to

synchronize with a corporate email account.

1. From the Home screen, tap

Your accounts screen displays with an Email setup

screen displayed.

2. Enter you email address in the

address

field.

3. Enter your password in the

Password

field.

4. If you want to see your password as it is being typed,

tap

Show password

to create a check mark.

5. If you want all of your emails sent from this email

account by default, tap the checkbox to create a check

mark. This checkbox only appears if you have

previously set up an email account.

6. Tap

Manual setup

7. Tap the

Microsoft Exchange ActiveSync

field.

8. Enter all the Exchange server information, Domain,

User name and Password, then tap

9. At the

Activation

prompt, tap

The

Account options

screen is displayed.

10. Enter the desired information in the different fields,

then tap

11. Enter an Account name for this account (Optional) and

tap

Done

Wait for the Inbox to synchronize before use.

12. Tap ➔

Settings

to change the account settings.

Creating Additional Email Accounts

To create additional email accounts after setting up your first

account, follow these steps:

1. From the Home screen, tap

DRAFT

FOR INTERNAL USE ONLY

Messaging 102

Your Email screen displays showing your emails from

the active account.

2. Tap ➔

Settings

3. Tap

Add account

to add another email account.

4. Enter the information required to set up another

account. For more information, refer to “Creating an

Email Account” on page 100.

Switching Between Email Accounts

1. From the Home screen, tap

Your Email screen displays showing your emails from

the active account.

2. Tap the Inbox button at the top of your screen.

Your Email accounts screen is displayed.

3. Tap the Email account

Inbox

you would like to switch

to. You can also select

Combined inbox

which will

display email messages from all accounts.

4. The new Email account is displayed.

Using Gmail

Gmail is Google’s web-based email. When you first setup the

phone, Gmail is configured. Depending on the

synchronization settings, Gmail is automatically synchronized

with your Gmail account.

Signing into Your Gmail

Note:

You must sign in to your Gmail account in order to

access Gmail.

1. Sign on to your Google account if you are not already

signed on. For more information, refer to “Creating a

New Google Account” on page 14.

2. From the Home screen, tap ➔

Gmail

3. Follow the on-screen instructions.

The Inbox loads conversations and email.

Creating a Gmail Message

1. From the Gmail Inbox, tap at the bottom of the

screen to create a new message.

2. Enter the recipients Email address in the

field.

Separate multiple recipient email addresses with a

comma.

DRAFT

FOR INTERNAL USE ONLY

103

3. Tap and select

Add Cc/Bcc

to add a carbon or blind

copy.

4. Enter the subject of this message in the

Subject

field.

5. Tap the

Compose email

field and begin composing your

message.

6. Tap to send.

Viewing a Gmail Message

1. From the Gmail Inbox, tap a message to view it.

2. The following options are available at the bottom of the

screen after a message has been selected:

•Archive

: archives the selected message.

• Delete

: deletes the message.

•Labels

: allows you to attach labels to a message. This is

similar to putting it in a folder.

•Mark Unread

: after reading a message, marks as unread.

•Newer

: swipe your screen to the right to see newer messages.

•Older

: swipe your screen to the left to see older messages.

3. Tap to select one of the following additional

options:

• Mark important/not important

: allows you to set the

importance of a message.

•Mute

: allows you to mute the sound in a message if applicable.

•Report spam

: allows you to report a message as spam. Tap

the UNDO option if you change your mind.

• Report phishing

: allows you to report a message that you feel

is trying to improperly get information from you.

• Settings

: displays Email settings that you can modify.

• Send feedback

: allows you to send feedback or report a

problem.

•Help

: displays the Google.com webpage so you can search the

web for help.

Other Gmail Options

1. Tap at the bottom of the screen to refresh the

screen, send and receive new emails, and synchronize

your email with the Gmail account.

2. Tap at the bottom of the screen to set up and

manage Labels for your Gmail messages.

3. Tap at the bottom of the screen to search through

your Gmail messages.

DRAFT

FOR INTERNAL USE ONLY

Messaging 104

Hangouts

Hangouts is a free Windows and web-based application for

instant messaging offered by Google. Conversation logs are

automatically saved to a Chats area in your Gmail account.

This allows you to search a chat log and store them in your

Gmail accounts.

1. Log on to your Google account if you have not already

done so. For more information, refer to “Creating a

New Google Account” on page 14.

2. From the Home screen, tap ➔

Hangouts

3. Begin using Google Talk.

4. Tap ➔

Help

for more information on using Google

Talk.

Note:

The Network confirms your login and processes. This

could take up to 5 minutes to complete.

Google +

Google+ makes messaging and sharing with your friends a

lot easier. You can set up Circles of friends, visit the Stream

to get updates from your Circles, use Messenger for fast

messaging with everyone in your Circles, or use Instant

Upload to automatically upload videos and photos to your

own private album on Google+.

1. Sign on to your Google account. For more information,

refer to “Creating a New Google Account” on page 14.

2. From the Home screen, tap ➔

Google+

3. Select the account you want to use to sign in to

Google+.

– or –

Tap

Add account

to create another account.

4. Follow the on-screen instructions to use Google+.

5. Visit

www.google.com/mobile/+/

for more information.

Messenger

Messenger allows you to bring groups of friends together into

a simple group conversation. When you get a new

conversation in Messenger, Google+ sends an update to your

phone.

1. Sign on to your Google account. For more information,

refer to “Creating a New Google Account” on page 14.

2. From the Home screen, tap ➔

Messenger

– or –

DRAFT

FOR INTERNAL USE ONLY

105

From the Google+ application, select

Messenger

3. Select the account you want to use to sign in to

Google+ and tap

– or –

Tap

Add account

to create another account.

4. Follow the on-screen instructions to add or follow

people.

5. Tap

at the bottom of the screen.

6. At the

Messenger

screen, tap to start a new

message.

7. In the upper text field, enter a name, email address, or

circle.

8. In the bottom message field, enter a message then tap

9. From the

Messenger

screen, tap

Learn more

for more

detailed information.

Messages App

AT&T Messages brings your texts, calls, and voicemail

messages together into a single conversation thread and is

accessible by phone or computer.

1. From the Home screen, tap ➔

Messages

2. Sign on to your Google account if you are not already

signed on. For more information, refer to “Creating a

New Google Account” on page 14.

Note:

The first time you use the Messages app, you will need

to download the updated application from the Play

Store. When the Play Store page displays, tap

Update

For more information, refer to “Play Store” on page

204.

3. At the Welcome screen, read the information and tap

Continue

or tap

Learn More

to receive more

information.

4. The first time you use Messages, you will need to set

up a few things. Tap

Record Greeting

to record a

personal greeting, or tap

Skip

if you want to do it later.

DRAFT

FOR INTERNAL USE ONLY

Messaging 106

5. Follow the on-screen instructions to use the Messages

app.

ChatON

Provides a global mobile communication service where you

can chat with more than 2 buddies via a group chat. Share

things such as pictures, videos, animation messages

(Scribbles), audio, Contacts, Calendar entries, and Location

information.

For more information, visit:

https://web.samsungchaton.com

1. From the Home screen, tap ➔

ChatON

2. At the ChatON display, tap

to sign in to your

Samsung account if you have not already done so. For

more information, refer to “Creating a Samsung

Account” on page 14.

– or –

Tap

Skip

if you have already signed in to your Samsung

account.

3. Enter your real name and tap

4. Follow the on-screen instructions to add a buddy and

begin your chat session.

DRAFT

FOR INTERNAL USE ONLY

107

Section 8: Changing Your Settings

This section explains the settings used for customizing your

device.

Accessing Settings

1. From any Home screen, tap ➔

Settings

– or –

From any Home screen, tap ➔

Settings

Settings Tabs

The Settings are divided into 4 main groups. When the

Settings screen displays, the following 4 tabs are located at

the top of the screen:

Connections

This tab allows you to see all of settings related to

the connection of your device to external sources.

Features include: Wi-Fi, Bluetooth, Data usage,

More networks (Airplane mode, Mobile networks,

Tethering and portable hotspot, and VPN), NFC,

S Beam, Nearby devices, Screen Mirroring, and

Kies via Wi-Fi.

My device

This tab provides access to device configuration

and customization features. Features include:

Lock screen, Display, Sound, Home screen mode,

Call, Blocking mode, Driving mode, Power saving

mode, Accessory, Accessibility, Browser bar,

Language and input, Motions and gestures, Smart

screen, and Voice control.

Accounts

This tab provides both the ability to create and

modify your accounts (example; Samsung account,

Email, Google account, etc.) and access Backup and

reset features.

This tab provides access to the remaining set of

device settings not listed under the other three tabs.

These include Location services, Security,

Application manager, Battery, Storage, Date and

time, and About device.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 108

Note:

The settings for your device are described below in the

order that they appear within the Settings menu. Options

under the Connections tab are listed first, followed by

My device, Accounts, and More settings.

Wi-Fi Settings

This section describes the Wi-Fi settings. For information on

how to use Wi-Fi, see “Wi-Fi” on page 166.

Activating Wi-Fi

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi ON .

3. Tap

Scan

to scan for available Wi-Fi networks. For more

information, refer to “Connect to a Wi-Fi Network” on

page 166.

Activating Wi-Fi Direct

Wi-Fi Direct allows device-to-device connections so you can

transfer large amounts of data over a Wi-Fi connection.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

Direct field, to turn Wi-Fi Direct ON .

3. At the bottom of the Wi-Fi screen, tap the

Wi-Fi Direct

button.

For more information, refer to “Wi-Fi Direct” on page

169.

DRAFT

FOR INTERNAL USE ONLY

109

Advanced Wi-Fi Settings

The advanced Wi-Fi settings allow you to set up and manage

wireless access points.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap ➔

Advanced

The following options are available:

• Network notification

: alerts you when a new WAP is available.

• Passpoint

: allows you to connect to passpoint-enabled Wi-Fi

Access Points automatically. Touch and slide the slider to the

right to turn it on .

• Keep Wi-Fi on during sleep

: allows you to specify when to

disconnect from Wi-Fi.

• Check for Internet service

: Checks if Wi-Fi internet service is

available when connected to an AP (Access Point).

• Auto connect

: allows you to be automatically connected to an

AT&T Wi-Fi Hotspot as soon as your phone detects it.

•MAC address

: view your device’s MAC address, required

when connecting to some secured networks (not configurable).

•IP address

: view your device’s IP address.

Bluetooth settings

In this menu you can activate Bluetooth, view or assign a

device name, activate your phone so other Bluetooth devices

can discover it, or scan for other, available Bluetooth devices

with which to pair.

Activating Bluetooth

1. From the Home screen, tap ➔

Settings

➔

Connections

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth ON .

The Bluetooth icon is displayed on the status bar.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 110

Additional Bluetooth Settings

When Bluetooth is on, additional settings are available.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Bluetooth

2. Tap

Scan

to scan for nearby discoverable devices. After

searching, tap a device to pair with it. For more

information, refer to “Pairing Bluetooth Devices” on

page 173.

3. Tap and select a Bluetooth setting to configure:

• Visibility timeout

: Use this setting to control when to

automatically turn off the Discoverable option: 2 minutes, 5

minutes, 1 hour, or Never time out.

• Received files

: Shows the list of files received by using

Bluetooth.

• Help

: Provides additional information on Bluetooth and

Bluetooth settings.

4. Tap the checkbox next to

SAMSUNG-SGH-I337

if you do

not want your phone visible to other Bluetooth devices.

Data Usage

From this screen you can view your Mobile data usage and

turn your Mobile data capability On or Off.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Data usage

2. Tap

Mobile data

to create a check mark and turn Mobile

data usage on.

3. Tap

Set mobile data limit

to create a check mark and

allow a data limit to be set.

4. Touch and drag the red limit bar to the GB limit that you

desire.

5. Tap the

Data usage cycle

drop-down menu and select a

date.

The data usage displays as a visual (chart) and also

displays a list of each application with a breakdown of

how much data was used per application.

Note:

Data is measured by your device. Your service provider

may account for data usage differently.

DRAFT

FOR INTERNAL USE ONLY

111

6. Tap to display additional options. Tap to activate.

• Data roaming

: enables data roaming on your device.

• Restrict background data

: restricts some apps and services

from working unless you are connected to a Wi-Fi network.

• Auto-sync data

: allows your accounts to automatically sync

•Show Wi-Fi usage

: displays a Wi-Fi tab that shows Wi-Fi

usage.

• Mobile hotspots

: displays available mobile hotspots.

More networks

This option displays additional Connectivity information.

䡲

From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

Options display for Airplane mode, Mobile networks,

Tethering and portable hotspots, and VPN.

Airplane mode

Airplane mode allows you to use many of your phone’s

features, such as Camera, Games, and more, when you are

in an airplane or in any other area where making or receiving

calls or data is prohibited.

Important!

When your phone is in Airplane Mode, it cannot

send or receive any calls or access online

information or applications.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

2. Tap the Airplane mode checkbox to create a check

mark and activate the feature.

3. At the

Enable airplane mode

prompt, tap

The Airplane mode icon is displayed at the top of

your screen.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 112

Mobile networks

Before you use applications such as Google Maps and find

your location or search for places of interest, you must

enable the Mobile networks options.

Mobile data

To enable data access over the mobile network, this option

must be selected. It is set on by default.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Mobile

networks

2. Tap

Mobile data

to create a check mark and activate

the feature.

Data Roaming

Data roaming allows you to connect to your service

provider’s partner networks and access data services when

you are out of your service providers area of coverage.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Mobile

networks

2. Tap

Data roaming

to create a check mark and activate

the feature.

Access Point Names

To use Wi-Fi you need access to a wireless access point

(hotspot).

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Mobile

networks

2. Tap

Access Point Names

A list of the Access Point names display. The active

access point displays a green, filled circle to the right

of the name.

DRAFT

FOR INTERNAL USE ONLY

113

Network Operators

Using this feature you can view the current network

connection. You can also scan and select a network operator

manually, or set the network selection to Automatic.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Mobile

networks

2. Tap

Network operators

The current network connection displays at the bottom

of the list.

Important!

You must deactivate data service prior to searching

for an available network.

Note:

Connecting to 2G networks slows the data transfer

speed and time.

Default setup options

Your phone default is set to Automatic (to automatically

search for an available network. You can set this option to

Manual to select a network each time you connect.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Mobile

networks

2. Tap

Network operators

3. Tap

Default setup

4. Tap

Manual

to locate and connect to a network

manually, or tap

Automatic

to allow the device to

automatically select a network.

DRAFT

FOR INTERNAL USE ONLY

Samsung Electronics Co SMC105A Multi-band GSM/EDGE/UMTS/LTE Handset with WLAN, Bluetooth and RFID User Manual C105A ZOOM

Samsung Electronics Co Ltd Multi-band GSM/EDGE/UMTS/LTE Handset with WLAN, Bluetooth and RFID C105A ZOOM

Contents

Users Manual 1

Navigation menu

Namespaces

Views

Navigation
