Changing Your Settings 114

Tethering & portable hotspot

This option allows you to share your phones’s mobile data

connection via USB or as a portable Wi-Fi hotspot.

Mobile Hotspot

Note:

To enable Mobile Hotspot on your phone, dial 611 or go

att.com/mywireless

to set up the service.

1. From the Home screen, tap ➔

Mobile Hotspot

– or –

From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Tethering and

portable hotspots

➔

Mobile Hotspot

2. Turn Mobile Hotspot on by tapping the slider so that it

changes to the ON position .

The Mobile Hotspot icon is displayed at the top of

your screen.

3. Tap

Configure

at the bottom of the screen.

4. Enter or edit the Network SSID, Hide my device,

Security setting, and Password.

5. Tap

Show password

and

Show advanced options

to see

them displayed.

6. Tap

Save

7. Tap for the following option:

•Timeout settings

: allows you to set the time your device will be

available as a portable Wi-Fi hotspot.

Connecting to Portable Wi-Fi hotspot from other

devices

1. Activate Wi-Fi on the device that wants to connect to

your phone.

2. Find

GALAXY_S4_XXXX

in the Wi-Fi network list and

connect to it. XXXX are four randomly generated digits

that will appear when you set up a Portable Wi-Fi

hotspot on your device.

The connected device can now use internet through

your Portable Wi-Fi hotspot.

Note:

Activating Wi-Fi and connecting to your phone will be

different depending on the type of the other device.

DRAFT

FOR INTERNAL USE ONLY

115

USB tethering

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

Tethering and

portable hotspot

2. Connect your phone to your PC using a USB cable.

3. Tap

USB tethering

to add a check mark and activate the

feature. The USB tethering icon is displayed at the

top of your screen.

Help



From the

Tethering and portable hotspot

menu, tap

Help

for additional information

VPN settings

The VPN settings menu allows you to set up and manage

Virtual Private Networks (VPNs).

Important!

Before you can use a VPN you must establish and

configure one.

Adding a Basic VPN

Before you add a VPN you must determine which VPN

protocol to use: PPTP (Point-to-Point Tunneling Protocol),

L2TP (Layer 2 Tunneling Protocol), L2TP/IPSec PSK (Pre-

shared key based L2TP/IPSec), or L2TP/IPSec CRT

(Certificate based L2TP/IPSec).

1. Before using VPN, you must first set up a screen unlock

PIN or password. For more information, refer to “Lock

Screen Settings” on page 119.

2. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

VPN

3. Tap

Basic VPN

4. Tap

(Add VPN network)

5. Enter a name for the VPN network in the

Name

field.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 116

6. Select a VPN type from the

Type

drop-down menu. The

options are:

•

PPTP (Point-to-Point Tunneling Protocol)

•

L2TP/IPSec PSK (Layer 2 Tunneling Protocol / Internet Protocol

Security Pre-Shared Key)

•

L2TP/IPSec RSA

•

IPSec Xauth PSK

•

IPSec Xauth RSA

•

IPSec Hybrid RSA

7. Enter the Server address and any other required fields

that are dependent upon the

Type

you entered

previously.

8. Tap the

Show advanced options

check box to display

additional VPN options.

9. Tap

Save

to save your VPN settings.

Adding an IPsec VPN

1. Before using VPN, you must first set up a screen unlock

PIN or password. For more information, refer to “Lock

Screen Settings” on page 119.

2. From the Home screen, tap ➔

Settings

➔

Connections

➔

More networks

➔

VPN

3. Tap

Advanced IPsec VPN

4. Tap

Add VPN connection

5. Enter a password, confirm the password, and tap

6. Enter a name for the VPN connection in the

VPN

connection name

field.

7. Select a IPsec type from the drop-down menu.

8. Enter any other required information.

9. Tap the

Show advanced options

check box to display

additional VPN options.

10. Tap

Save

to save your VPN settings.

DRAFT

FOR INTERNAL USE ONLY

117

NFC

NFC (Near Field Communication) allows data exchange when

you touch your device with another compatible device. This

is used for applications such as Android Beam and S Beam.

To activate NFC, follow these steps:

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

NFC

2. Tap the ON/OFF slider, located to the right of the NFC

field, to turn NFC ON .

Android Beam

When Android Beam is activated, you can beam app content

to another NFC-capable device by holding the devices close

together. You can beam browser pages, YouTube videos,

contacts, and more.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

NFC

➔

Android Beam

2. Tap the

OFF / ON

icon to turn Android Beam ON

3. Touch the back of your device with another NFC-

capable device and the content is transferred.

S Beam

When S Beam is activated, you can beam files to another

NFC-capable device by holding the devices close together.

You can beam images and videos from your Gallery, music

files from your Music app, and more.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

S Beam

2. Tap the

OFF / ON

icon to turn S Beam on .

3. Touch the back of your device with another NFC-

capable device and the content is transferred.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 118

Nearby devices

This option allows you to share your media files with nearby

devices using DLNA and connected to the same Wi-Fi.

1. Connect to a Wi-Fi network. For more information, refer

to “Activating Wi-Fi” on page 108.

2. From the Home screen, tap ➔

Settings

➔

Connections

➔

Nearby devices

3. Tap the

File sharing

checkbox to create a check mark

and activate File sharing.

4. Verify (

Nearby devices

) appears at the top of the

screen.

5. At the Nearby devices prompt, tap

6. Tap

Shared contents

, then check the media you would

like to share. Tap

7. Tap

Allowed devices list

, then select the connected

devices you would like to allow.

8. Tap

Not-allowed devices list

, then select the connected

devices you would like to not allow.

9. Tap

Download to

, then select the destination of any

downloaded (shared) content. Choose from Device or

SD card.

10. Tap

Upload from other devices

, then select the actions

you’ll take when you upload content from other

devices. Choose from either Always accept, Always

ask, or Always reject.

Screen Mirroring

The Screen Mirroring feature allows you to share the media

files on your device screen with an HDMI device such as an

HDMI TV.

Note:

This feature requires the optional AllShare Cast dongle

which is available as an accessory. See your AT&T

Customer Service Representative for more information.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Screen Mirroring

2. Connect the AllShare Cast dongle to the HDMI device

using an HDMI A-to-A cable.

3. Tap ➔

Help

for information on using Screen

Mirroring.

DRAFT

FOR INTERNAL USE ONLY

119

Kies via Wi-Fi

Kies via Wi-Fi allows you to sync your PC wirelessly with your

device provided they are both on the same Wi-Fi network.

You can view and share videos, photos, music, ringtones,

and more.

1. From your PC, download the Samsung Kies application

if you don’t already have it. You can find it at

samsung.com

2. From your PC, launch the Samsung Kies application.

3. From your PC, connect to a Wi-Fi network.

4. From the Home screen, tap ➔

Settings

➔

Connections

➔

Kies via Wi-Fi

5. From your device, connect to the same Wi-Fi network

that your PC is connected to if you have not already

done so. For more information, refer to “Connect to a

Wi-Fi Network” on page 166.

Lock Screen Settings

Choose settings for unlocking your screen. For more

information about using the lock and unlock features, see

“Locking and Unlocking the Touch Screen” on page 12.

Screen Lock

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Lock screen

2. Tap

Screen lock

for these options then follow the on-

screen instructions to set up your Screen lock:

•Swipe

: Swipe the screen to unlock it.

• Face unlock

: Look at your phone to unlock it.

• Face and voice

: Look at your phone and speak to unlock.

•Pattern

: A screen unlock pattern is a touch gesture you create

and use to unlock your device. Follow the prompts to create or

change your screen unlock pattern.

•PIN

: Select a PIN to use for unlocking the screen.

• Password

: Create a password for unlocking the screen.

•None

: No pattern, PIN, or password is required. The screen will

never lock.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 120

Lock screen options

Activate or deactivates various Unlock screen functions.

Note:

The Lock screen options will differ depending on what

type of Screen Lock you have selected in step 2.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Lock screen

2. The following options are available depending on the

Screen Lock type that you have selected:

Swipe options

• Multiple widgets

allows you to display multiple widgets on

your lock screen. Appears as an options after a lock mode is

enabled.

• Lock screen widgets

allows you to lock the widgets that are

displayed on your home screens.

•Shortcuts

sets shortcuts to appear at the bottom of the Lock

screen. Touch and slide the slider to the right to turn it on

• Unlock effect

sets the effect you receive when unlocking the

phone. You can select None, Ripple effect, or Light effect.

•Help text

shows help information on the Lock screen.

• Wake up in lock screen

requires that you say a command to

wake-up your phone.

• Set wake-up command

designates your wake-up

commands. Tap Set wake-up command and follow the on-

screen prompts to create a new verbal command.

Face unlock options

• Lock screen widgets

allows you to lock the widgets that are

displayed on your home screens.

• Improve facial recognition

allows you to improve your

device’s face matching capability by capturing your face in

different lighting, with or without glasses, and bearded or

clean-shaven. Follow the on-screen instructions.

• Presence check

requires that you blink when using the Face

unlock feature. This will increase the security of the feature.

• Secured lock time

allows you to set a time-out for lock screen.

My device

DRAFT

FOR INTERNAL USE ONLY

121

Pattern options

• Lock screen widgets

allows you to lock the widgets that are

displayed on your home screens.

• Make pattern visible

allows you to see the pattern as you

draw it.

• Secured lock time

allows you to set a time-out for lock screen.

PIN and Password options

• Lock screen widgets

allows you to lock the widgets that are

displayed on your home screens.

• Secured lock time

allows you to set a time-out for lock screen.

Display Settings

In this menu, you can change various settings for the display.



From the Home screen, tap ➔

Settings

➔

My device

➔

Display

The following options display:

•Wallpaper

: allows you to set the Wallpaper for your Home

screen, Lock screen, or both. For more information, refer to

“Changing the Wallpaper” on page 44.

• Notification panel

: allows you to set the brightness of your

notification panel and also select the quick setting buttons that

you want to display at the top of the notification panel. For more

information, refer to

“Notification Bar” on page 46.

• Screen mode

: allows you to select from several different color

modes.

•Brightness

: configures the LCD Brightness levels. Tap

Automatic brightness to allow the phone to self-adjust or drag

the slider and tap OK.

• Auto-rotate screen

: allows you to switch the display

orientation automatically when you rotate the phone.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 122

• Screen timeout

: adjusts the delay time before the screen

automatically turns off. Selections are: 15 seconds, 30

seconds, 1 minute, 3 minutes, 5 minutes, and 10 minutes.

•Daydream

: allows you to control what your screen does when

your device is docked or sleeping. Tap the OFF / ON icon next

to Daydream to turn it on . Follow the on-screen

instructions.

• Font style

: allows you to set the font style that your phone will

use. You can also tap Get fonts online to choose from a wider

selection.

•Font size

: allows you to select which size of font is displayed.

• Touch key light duration

: allows you to adjust the delay before

the Touch key light automatically turns off.

• Display battery percentage

: allows you to see the battery

charge percentage next to the battery charge icon at the top of

the display.

• Edit after screen capture

: allows you to go edit a screen

immediately after taking a screen capture.

• Auto adjust screen tone

: allows you to save power because

the phone analyzes the displayed screen image and adjusts the

LCD brightness.

Sound Settings

From this menu you can control the sounds on the phone.



From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

The following options display:

Volume

The Volume option allows you to change the volume for all

phone sounds in one easy location.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

➔

Volume

2. Touch and drag the slider to adjust the sound volume

for Media, Ringtone, Notifications, and System.

3. Tap

Vibration intensity

Vibration intensity allows you to select how intense the

vibration is for different options.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

➔

Vibration intensity

2. Touch and drag the slider to adjust the Vibration

intensity for Incoming call, Notification, and Haptic

feedback.

My device

DRAFT

FOR INTERNAL USE ONLY

123

Ringtones

This option allows you to set the ringtone.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

2. Tap

Ringtones

3. Tap a ringtone and tap

– or –

Tap

Add

to select a file from your music files.

Vibrations

This option allows you to set your phone to vibrate and ring.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

2. Tap

Vibrations

3. Select a vibration pattern and tap

– or –

Tap

Create

and follow the on-screen instructions to

create your own vibration.

Default notification sound

This option allows you to set the ringtone that will sound for

notifications and alarms.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

2. Tap

Notifications

3. Tap a ringtone and tap

Vibrate when ringing

This option allows you to enable your phone to vibrate

whenever it rings.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

2. Tap

Vibrate when ringing

to create a check mark and

enable the feature.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 124

System Tone Settings

The System tone settings are used when you use the dialing

pad, make a screen selection, lock your screen, or tap the

screen.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

2. Tap any of the following options to create a check mark

and activate the feature:

• Dialing keypad tone

: makes a sound when you tap a key on

the keyboard.

• Touch sounds

: makes a sound when you touch the screen.

• Screen lock sound

: makes a sound when your screen is

locked or unlocked.

• Haptic feedback

: makes a vibration when you tap soft keys

and on certain UI interactions.

Adapt sound

The Adapt sound feature allows you to customize your call

sounds.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Sound

➔

Adapt sound

2. Read the instructions and tap

Start

3. Follow the on-screen instructions to set up your

personal call sound.

My device

DRAFT

FOR INTERNAL USE ONLY

125

Home screen mode

Home screen mode allows you to set your display to the

conventional layout of

Standard mode

or provide an easier

user experience for the first-time smartphone users using

Easy mode

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Home screen mode

2. Tap the pull-down dropbox and select one of the

following options:

• Standard mode

: provides conventional layout for the apps and

widgets on your home screens.

•Easy mode

: provides easier user experience for first-time

smartphone users on the home screens.

3. Tap

Apply

Open Camera

Open Camera allows you to set the Camera app to launch

when you turn on your phone.

1. From the Home screen, tap ➔

Settings

➔

My device

2. Touch and slide the

Open Camera

slider to the right to

turn it on .

Call Settings

To access the Call settings menu:



From the Home screen, tap ➔

Settings

➔

My device

➔

Call

– or –



From the Home screen, tap ➔ ➔

Call

settings

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 126

Call rejection

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Call rejection

2. Tap the

OFF / ON

icon to turn Auto reject mode on

3. Tap

Auto reject mode

and tap one of the following

options:

•Off

: to turn Auto reject mode off.

• All numbers

: to reject all calls.

• Auto reject numbers

: to reject all calls in your Reject list.

4. Tap

Auto reject list

5. Tap to manually add numbers to the Reject list.

6. Tap

Unknown

, to create a check mark and

automatically reject all calls that are not in your

Contacts list.

Set rejection messages

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Set up call rejection

messages

2. Tap to manually add a reject message.

– or –

Tap one of the pre-written messages to be displayed

when you want the call to be rejected. You can edit the

message if desired.

3. Tap

Save

to save the reject message.

Answering/ending calls

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Answering/ending calls

2. The following options are available:

• The home key answers calls

: Tap this option to be able to

accept incoming calls by pressing the Home key.

• Voice control

: Tap this option to be able to accept incoming

calls by using your voice.

• The power key ends calls

: This option will allow you to end a

call by pressing the power key without turning off the screen.

My device

DRAFT

FOR INTERNAL USE ONLY

127

Turn off screen during calls

This option turns on the proximity sensor during calls so that

your phone will know to turn the screen off to save power.



From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Turn off screen during calls

to create a check mark and enable the feature.

Call alerts

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Call alerts

2. Tap the following options to create a check mark and

activate the features:

• Answer vibration

: enables your phone to vibrate when the

called party answers the phone.

• Call-end vibration

: enables your phone to vibrate when the

call ends.

• Call connect tone

: plays a tone when a call is connected.

• Minute minder

: beeps twice every minute that you are on a

call.

• Call end tone

: plays a tone when a call is ended.

• Alerts on calls

: turns on alarm and message notifications

during a call.

Call Accessories

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Call accessories

2. The following options are available:

• Automatic answering

: configures the device to automatically

answer and incoming call when a headset is detected.

• Automatic answering timer

: configures the time delay before

the device automatically accepts the incoming call.

• Outgoing call conditions

: allows you to make calls even when

the device is locked by using a Bluetooth headset.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 128

Additional settings

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Additional settings

2. Tap one of the following options:

•Caller ID

: allows you to choose how your Caller ID will be

displayed. Select Network default, Hide number, or Show

number.

• Call forwarding

: allows you to forward your calls to another

number.

• Auto area code

: allows you to automatically prepend a specific

area code to all outbound calls.

• Call waiting

: the network service informs you when someone

is trying to reach you during another call. Tap to activate.

• Auto redial

: automatically redials the last number if the call

was either cut off or was unable to connect. Tap to activate.

• Fixed dialing numbers

: allows you to restrict outgoing calls to

a limited set of phone numbers.

Using Fixed Dialing Numbers

Enabling FDN

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Additional settings

➔

Fixed

dialing numbers

2. Tap

Turn on FDN

3. At the prompt, enter your PIN2 code and tap

FDN is enabled.

4. To enable FDN after it has been disabled, tap

Disable

FDN

, enter your PIN2 code and tap

Important!

Not all SIM cards use a PIN2 code. If your SIM card

does not, this menu does not display.

The PIN2 code is provided by your carrier. Entering

an incorrect PIN2 code could cause the phone to

lock. Contact customer service for assistance.

My device

DRAFT

FOR INTERNAL USE ONLY

129

Changing the PIN2 Code

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Additional settings

➔

Fixed

dialing numbers

2. Tap

Change PIN2

3. At the prompt, enter your old PIN2 code.

4. At the prompt, enter a new PIN2 code.

5. Confirm your PIN2 code.

Managing the FDN List

When this feature is enabled, you can make calls only to

phone numbers stored in the FDN list on the SIM card.

Note:

Before you can manage an FDN list a list must be

created.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Additional settings

➔

Fixed

dialing numbers

2. Tap

FDN list

3. A list of all existing FDN numbers will be displayed.

Ringtones and keypad tones

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Ringtones and keypad

tones

2. Tap

Ringtones

, select a ringtone, and tap

3. Tap

Vibrations

, select a vibration type, and tap

4. Tap

Vibrate when ringing

to create a check mark if you

want your phone to vibrate when a call is incoming.

5. Tap

Keypad tones

to create a check mark if you want

tones to play when the keypad is pressed.

Personalize call sound

This option allows you to personalize the sounds you hear

during a call with and without earphones.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Personalize call sound

2. At the Personalize call sound display, tap one of the

following options:

• In-call sound EQ

: allows you to select the sound equalization

you want to use during calls.

• Adapt sound

: allows you to customize your sounds. Follow the

on-screen instructions to set up your personal call sound.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 130

Noise reduction

This option helps to suppress background noise from your

side during a call.



From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Noise reduction

to create a

check mark and enable the feature.

Increase volume in pocket

This option increases the ringtone volume when the device is

in a pocket or a bag. It uses the proximity sensor to detect its

location.



From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Increase volume in pocket

to create a check mark and enable the feature.

Voicemail service

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Voicemail Service

Voicemail service provided by your carrier is the

default.

2. Tap

My carrier

to remove the carrier Voicemail service.

Voicemail settings

You can view or modify your voicemail number from this

menu.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Voicemail settings

2. Tap the

Voice mail number

field, backspace to erase the

digits, and enter a new voicemail number using the

keypad, then tap

3. Tap

Sound

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

Sound

2. Tap a ringtone to hear it played.

3. Select a ringtone and tap

Vibrate

This option allows you to select vibration settings.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

2. Tap

Vibrate

to create a check mark and activate the

Vibrate feature.

My device

DRAFT

FOR INTERNAL USE ONLY

131

TTY Mode

A TTY (also known as a TDD or Text Telephone) is a

telecommunications device that allows people who are deaf,

hard of hearing, or who have speech or language disabilities,

to communicate by telephone.

Your phone is compatible with select TTY devices. Please

check with the manufacturer of your TTY device to ensure

that it is compatible with digital cell phones.

Your phone and TTY device will connect via a special cable

that plugs into your phone’s headset jack. If this cable was

not provided with your TTY device, contact your TTY device

manufacturer to purchase the connector cable.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

➔

TTY mode

2. Tap

TTY Full

TTY HCO

, or

TTY VCO

. A green check mark

will appear. Tap

TTY Off

to turn it off.

Hearing aids

This option allows you to enable your phone’s support for

hearing aids, or disable it to save power.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Call

2. Tap

Hearing aids

to create a check mark and activate

the Hearing aids support feature.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 132

Blocking Mode

When Blocking mode is enabled, notifications for selected

features will be disabled. You will only receive notifications of

incoming calls from people on your allowed list.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Blocking mode

2. In a single motion touch and slide the

Blocking mode

slider to the right to turn it on .

Confirm that the Blocking mode active icon

appears in the Status bar.

3. Place a green check mark adjacent to those features

you would like to enable. Choose from: Block incoming

calls, Turn off notifications, Turn off alarm and timer.

4. Configure a timeframe for these features to be active.

Remove the check mark from the

Always

field to

configure the

From

and

time fields.

5. Tap

Allowed contacts

to assign those contacts that are

exempted from these rules. Choose from None, All

contacts, Favorites, or Custom. Allowed contacts will

then appear in the

Allowed contact list

Driving mode

Driving mode allows you to select whether your phone

announces in plain language incoming calls and messages,

alarm information, and/or schedule alarm information from

your Calendar.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Driving mode

2. Tap the

OFF / ON

icon next to

Driving mode

to turn

Driving mode on .

3. Tap the following options to create a check mark and

enable these text-to-speech readings:

•

Tap

Incoming call

to read out caller information for incoming

calls.

•

Tap

Message

to read out sender information for incoming

messages.

•

Tap

Alarm

to read out alarm information.

•

Tap

Schedule

to read out Calendar event alarm information.

My device

DRAFT

FOR INTERNAL USE ONLY

133

Power saving mode

Power saving mode allows you to manage your phone to

conserve power.

1. From the Home screen, tap ➔

Settings

➔

Power saving mode

2. Tap the

OFF / ON

icon next to

Power saving mode

to turn

Power saving mode on .

3. Tap the following options to create a check mark and

conserve power:

• CPU power saving

: allows you to limit the maximum

performance of the CPU.

• Screen power saving

: allows you to lower the screen power

level.

• Turn off haptic feedback

: allows you to turn off vibration when

you tap or touch the screen.

•Auto enable

: allows you to automatically turn on Power saving

mode when batter power drops below 20%.

4. Tap

Learn about Power saving mode

to learn about

various ways to conserve battery power.

Accessory Settings

This menu allows you to select the Audio output mode when

using a car or desk dock.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Accessory

2. Tap

Audio output

to set your Audio output to Stereo or

Surround.

Accessibility

Accessibility services are special features to make using the

device easier for those with certain physical disabilities. Use

the Accessibility settings to activate these services.

Note:

You can download accessibility applications from Play

Store and manage their use here.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Accessibility

2. The following options are available:

• Auto-rotate screen

: automatically rotate the screen from

landscape to portrait when you rotate your phone.

• Screen timeout

: timeout the accessibility feature after a

defined amount of time.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 134

• Speak passwords

: reads out password information.

• Answering/ending calls

: accept incoming calls by pressing

the home key or end calls using the power key.

•Show shortcut

: allow the accessibility shortcut under the

device options to be used by pressing and holding the power

key.

• Manage accessibility

: save and update your accessibility

settings or share them with another device. You can export your

settings, import a previously saved file, or share your file with

another device.

• TalkBack

: activate the TalkBack feature.

Note:

TalkBack, when installed and enabled, speaks feedback

to help blind and low-vision users.

Important!

TalkBack can collect all of the text you enter,

except passwords, including personal data and

credit card numbers. It may also log your user

interface interactions with the device.

•Font size

: change the size of the fonts used on the device

within menus, options, etc. Choose from: Tiny, Small, Normal,

Large, or Huge.

• Magnification gestures

: use exaggerated gestures such as

triple-tapping, double pinching, and dragging two fingers

across the screen.

• Negative colors

: reverse the display of on-screen colors from

White text on a Black background to Black text on a White

background.

• Color adjustment

: allows you to adjust the display colors if

you are color blind and have difficulty reading the display

because of the colors. Touch and slide the slider to the right to

turn it on . Follow the on-screen instructions.

• Accessibility shortcut

: allows you to quickly enable

accessibility features in 2 quick steps. Touch and slide the

slider to the right to turn it on . Follow the on-screen

instructions.

• Text-to-speech options

: allows you to adjust your text-to-

speech settings. For more information, refer to

“Speech

Settings” on page 140.

DRAFT

FOR INTERNAL USE ONLY

135

• Enhance web accessibility

: allows apps to install scripts

from Google that make their Web content more accessible. Tap

Allow.

• Sound balance

: allows you to use the slider to set the Left

and Right balance when using a stereo device.

• Mono audio

: allows you to enable stereo audio to be

compressed into a single mono audio stream for use with a

single earbud/earphone.

• Turn off all sounds

: allows you to mute every sound made by

the device during taps, selections, notifications, etc.

• Assistant menu

: allows you to improve the device

accessibility for users with reduced dexterity. Touch and slide

the slider to the right to turn it on . Follow the on-

screen instructions.

• Press and hold delay

: allows you to select a time interval for

this action. Choose from: Short, Medium, or Long.

• Interaction control

: allows you to enable or disable motions

and screen timeout. You can also block areas of the screen

from touch interaction. Touch and slide the slider to the right to

turn it on . Follow the on-screen instructions.

Browser Bar

This option displays a menu that lets you configure the

Browser Bar that can give you quick access to Facebook,

Like, Tweet It, A-List, Share, Apps, Popular, News, Sports,

Entertainment, Others, Settings, and Add More from one or

more web browsers you select as Active. For more

information, refer to “Navigating with the Browser” on page

158.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Browser Bar

. The Browser Bar

Settings

screen displays.

2. Tap

About

to display description and Browser Bar

release and copyright information.

3. Tap the

OFF / ON

icon next to

Toolbar

to turn the

Browser Bar on .

4. Tap

Active Browsers

to select which web browsers on

your phone can use the Browser Bar.

5. Tap the

OFF / ON

icon next to

Autoshow

to on to set the

Browser Bar to automatically display whenever you

browse a new web page .

6. Tap

Manage Extensions

to rearrange and select which

shortcuts appear on the Browser Bar.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 136

7. Tap

to display the Browser Bar vendor’s

8. Tap

Analytics

to enable or disable collection of Browser

Bar analytical data.

9. Tap

Clear Cookies

to erase Browser Bar cookies,

tokens, history, and cached information.

Language and input

This menu allows you to configure the language in which to

display the menus. You can also set on-screen keyboard

options.

Language

You can change the language used by your device by

following these steps:

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

➔

Language

2. Tap a language from the list.

My device

DRAFT

FOR INTERNAL USE ONLY

137

Keyboards and Input Methods

You can change the keyboard used by your device by

following these steps:

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Ignore

Default

. The Samsung keyboard is the only one

defined to your phone.

3. Tap the icon next to the input method (Google

voice typing or Samsung keyboard) that you would like

to configure the settings for.

4. Based on your selection of input method, the

appropriate settings will appear and are explained

below.

Google voice typing settings

From this menu you can set Samsung keyboard options.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Tap the icon next to

Google voice typing

3. The following options are available:

• Choose input languages

: tap on a language that you want to

input. Select

Automatic

to use the local language or select a

language from the list.

• Block offensive words

tap to create a check mark and

enable the blocking of recognized offensive words from the

results of your voice-input Google typing.

• Download offline speech recognition

: Enables voice input

while offline.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 138

Samsung Keyboard settings

From this menu you can set Samsung keyboard options.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Tap the icon next to

Samsung keyboard

• Portrait keyboard types

allows you to choose

Alphabets

and

Numbers and symbols

keyboard configurations (Qwerty

[default] or 3x4 Keyboard).

• Input languages

sets the input language. Tap a language from

the available list. The keyboard is updated to the selected

language.

• Predictive text

enables predictive text entry mode. This must

be enabled to gain access to the advanced settings. Touch and

hold to access the advanced settings. Touch and slide the slider

to the right to turn it on . (For more information, refer

“Predictive Text Settings” on page 139.

)

• SwiftKey Flow

allows you to type words by swiping between

on-screen keys.

• Cursor control

allows you to move the cursor by sliding your

finger across the keyboard.

• Key-tap vibration

enables vibration feedback when you tap an

on-screen key.

•Key-tap sound

enables auditory feedback when you tap an

on-screen key.

• Advanced

displays the following advanced options:

–

Auto capitalization

automatically capitalizes the first letter of

the first word in each sentence (standard English style).

–

Auto spacing

automatically inserts spaces between words.

–

Auto-punctuate

automatically inserts a full stop in a sentence

by tapping the space bar twice when using the on-screen

QWERTY keyboard.

–

Character preview

provides an automatic preview of the

current character selection within the text string. This is helpful

when multiple characters are available within one key.

•Tutorial

launches a brief on-screen tutorial covering the main

concepts related to the Samsung keyboard.

• Reset settings

resets the keyboard settings back to their

original configuration.

My device

DRAFT

FOR INTERNAL USE ONLY

139

Predictive Text Settings

From this menu you can set Predictive Text settings.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Tap the icon next to

Samsung keyboard

Tap the ON/OFF slider, located to the right of the

Predictive text field, to turn it ON .

4. Tap

Predictive text

5. The following options are available:

• Personalized data

: allows you to use personal language that

you have added to make your prediction results better.

• Learn from Facebook

: allows you to login to your Facebook

account so your phone can learn your Facebook style.

• Learn from Gmail

: allows you to login to your Gmail account so

your phone can learn your Gmail style.

• Learn from Twitter

: allows you to login to your Twitter account

so your phone can learn your Twitter style.

• Learn from Messaging

: allows your device to learn from your

Messages.

• Learn from Contacts

: allows your device to learn from your

Contacts.

•Clear remote data

: deletes anonymous data that is stored on

the personalization server.

• Clear personal data

: removes all personalized data that you

have entered.

• Privacy policy

: tap the privacy policy link to read the privacy

policy. Follow the on-screen instructions.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 140

Speech Settings

This menu allows you to set the speech settings for Voice

input.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Tap

Voice search

to configure the following:

• Language

: Choose a language for your voice input.

• Speech output

: Sets whether you will use speech output

always or only when using hands-free.

• Block offensive words

: Enable or disable blocking of

recognized offensive words from the results of your voice-input

Google searches.

• Hotword detection

: Enable to being able to launch voice

search by saying the word “Google”.

• Download offline speech recognition

: Enables voice input

while offline.

• Personalized recognition

: enables the improvement of

speech recognition accuracy.

• Google Account dashboard

: allows you to manage your

collected data.

• Bluetooth headset

: allows you to record audio through a

Bluetooth headset if available.

3. Tap

Text-to-speech options

and select

Samsung text-to-

speech engine

Google Text-to-speech Engine

4. Tap next to the preferred TTS engine configure the

following settings:

• Language

: allows you to set the language for spoken text.

• Settings for Samsung text-to-speech engine

allows you to

view Open Source Licenses.

• Settings for Google Text-to-speech Engine

: allows you to

view Open Source Licenses.

• Install voice data

: allows you to install voice data for speech

synthesis.

5. Scroll down to the

General

section to access the

following options:

• Speech rate

: Set the speed at which the text is spoken.

• Listen to an example

: Play a sample of speech synthesis

(available if voice data is installed).

My device

DRAFT

FOR INTERNAL USE ONLY

141

Pointer speed

This option sets your Pointer speed.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Language and input

2. Tap

Pointer speed

then drag the slider to the right to go

faster or to the left to go slower.

3. Tap

to save your setting.

Motions and Gestures

The Motions and Gestures settings allow you to set up

various Motion activation services. For more information on

using gestures, see “Using Motions and Gestures” on

page 36.



From the Home screen, tap ➔

Settings

➔

My device

➔

Motions and gestures

Motion

Motion allows you to control your device by performing

natural movements.

1. From the Motions and gestures screen, tap

Motion

2. Tap the ON/OFF icon at the top of your screen

to activate Motion.

3. The following options are available:

•Direct call

: Once enabled, the device will dial the currently

displayed on-screen Contact entry as soon as you place the

device to your ear. Tap the ON/OFF icon to turn it on.

•Smart alert

: Once enabled, pickup the device to be alerted and

notified of you have missed any calls or messages. Tap the ON/

OFF icon to turn it on.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 142

• Zoom

: Once enabled, you must be on a screen where content

can be zoomed. In a single motion, touch and hold two points

on the display then tilt the tilt the device back and forth to zoom

in or out. Tap the ON/OFF icon to turn it on.

• Move an icon

: Once enabled, move Home page shortcuts

from one panel to another by pressing and holding the shortcut

and moving the device left or right. Tap the ON/OFF icon

to turn it on.

• Browse an image

Once enabled, touch and hold a desired

on-screen image to pan around it. Move the device left or right

to pan vertically or up and down to pan horizontally. Tap the ON/

OFF icon to turn it on.

• Mute/pause

: Once enabled, mute incoming calls and any

playing sounds by turning the device display down on a

surface. Tap the ON/OFF icon to turn it on.

4. Tap ➔

Help

for additional information.

Gyroscope calibration

Gyroscope calibration allows you to calibrate motion

correctly using the device’s built-in gyroscope.

1. From the Motions and gestures screen, tap

Gyroscope

calibration

2. Place your device on a flat surface.

3. Tap

Calibrate

4. When finished,

Calibrated

will appear on your screen.

Tap to return to the previous screen.

DRAFT

FOR INTERNAL USE ONLY

143

Smart screen

The Smart screen options allow you to customize your

screen settings to make the screen more responsive and

easier to use.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Smart screen

2. Tap any of the following options to create a check mark

and activate the features:

•Smart stay

: disables the screen timeout if your phone detects

that your face is watching the screen.

• Smart rotation

: disables the auto screen rotation by checking

the orientation of your face and the device.

Voice control

The Voice control settings allow you to set up voice

commands to control your device.

1. From the Home screen, tap ➔

Settings

➔

My device

➔

Voice control

2. Tap the ON/OFF icon at the top of your screen

to activate Voice control.

3. The following options are available. Tap an option to

create a check mark and activate the feature.

• Incoming calls

: allows you to answer or reject calls using the

commands

Answer

and

Reject

•Alarm

: allows you to stop or snooze an alarm by using the

commands

Stop

and

Snooze

•Camera

: allows you to take pictures using the voice

commands

Smile

Cheese

Capture

, or

Shoot

•Music

: allows you to control your Music app using the voice

commands

Pause

Play

Volume Up

, and

Volume Down

Note:

If you set the alert type for calls or alarms to vibration,

voice control will not be available.

My device

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 144

Add Account

This menu allows you to set up, manage, and synchronize

accounts, including your Google and email accounts.

Adding an Account

1. From a Home screen, tap ➔ Settings ➔

Accounts

➔

Add account

2. Tap one of the account types.

3. Use the keyboard and follow the prompts to enter your

credentials and set up the account.

A green circle will appear next to the account type once

you have created an account. Your new account will

also be displayed in the

My accounts

section of the

main

Accounts

menu.

Removing an Account

Important!

Removing an account also deletes all of its

messages, contacts, and other data from the

device.

1. From a Home screen, tap ➔ Settings ➔

Accounts

2. Tap the account type, which is located in the

accounts

section.

3. Tap the account name.

4. At the bottom of the screen, tap

Remove account

, then

tap

Remove

account

at the prompt to remove the

account and delete all its messages, contacts, and

other data.

DRAFT

FOR INTERNAL USE ONLY

145

Synchronizing Accounts

Select the items you want to synchronize on your account

such as Books, Calendar, Contacts, and more.

1. From a Home screen, tap ➔ Settings ➔

Accounts

2. Tap the account type to be synchronized in the

accounts

section.

3. Tap the account name to access the account Sync

settings.

4. Tap

Sync now

to synchronize your account or only tap

the Sync items that you want to synchronize.

5. Tap

Cancel sync

to stop the synchronization.

6. Tap

Settings

Account settings

to access your account

settings.

7. Tap

Storage usage

(Samsung accounts) to see your

storage usage for different applications.

Back up and reset

The Back up and reset settings allow you to back up your

data, back up accounts, automatically restore your phone,

and reset your phone settings to the factory settings.

Back Up My Data

By setting this option, the Google server will back up all of

your settings and data.

1. From a Home screen, tap ➔ Settings ➔

Accounts

➔

Back up and reset

2. Tap

Back up my data

to enable or disable back up of

application data, WI-Fi passwords, and other settings

to the Google server.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 146

Backup Account

If you have enabled the

Back up my data

option, then the

Backup account

option is available.

1. From a Home screen, tap ➔ Settings ➔

Accounts

➔

Back up and reset

2. Tap

Backup account

3. Tap your Google Gmail account to set your Google

Gmail account to be backed up to the Google server.

– or –

Tap

Add account

to set another account to be backed

up to the Google server.

Automatic Restore

By setting this option, when you reinstall an application, all of

your backed up settings and data will be restored.

1. From a Home screen, tap ➔ Settings ➔

Accounts

➔

Back up and reset

2. Tap

Automatic restore

to enable or disable automatic

restoration of settings from the Google server.

Factory Data Reset

From this menu you can reset your phone and sound settings

to the factory default settings.

1. From a Home screen, tap ➔ Settings ➔

Accounts

➔

Back up and reset

2. Tap

Factory data reset

The Factory data reset screen displays reset

information.

3. Tap

Reset device

, then follow the prompts to perform

the reset.

Warning!

Performing a Factory data reset will erase all data

from your phone and internal SD card, including your

Google account, system and application data and

settings, and downloaded applications. It will not

erase current system software, bundled

applications, and external SD card files such as

music and photos.

DRAFT

FOR INTERNAL USE ONLY

147

Location services

The Location services settings allow you to set up how the

phone will determine your location and the sensor settings

for your phone.

1. From the Home screen, tap ➔

Settings

➔

Location services

2. Tap any of the following options to create a check mark

and activate the service:

• Access to my location

: allows apps that have asked your

permission to use your location information.

• Use GPS satellites

: allows applications to use GPS to pinpoint

your location.

• Use wireless networks

: allows applications to use data from

mobile networks and Wi-Fi to help determine your location.

• My places

: allows you to add location information for your

Home, Office, and Car.

Security

The Security settings allow you to determine the security

level for your phone.

Encryption

To require a numeric PIN or password to decrypt your phone

each time you power it on or encrypt the data on your SD

card each time it is connected:

1. From the Home screen, tap ➔

Settings

➔

Security

2. You must first set up a screen lock type if you haven’t

already done so. For more information, refer to “Screen

Lock” on page 119.

3. Tap

Encrypt device

. For more information, read the

displayed help screen.

4. Tap

Encrypt external SD card

to enable the encryption

on SD card data that requires a password be entered

each time the microSD card is connected.

Tip:

Make sure your battery is charged more than 80 percent.

Encryption may take an hour or more.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 148

Set up/change password

Use this option to set up your password when one is first

required or change your current password.

1. From the Home screen, tap ➔

Settings

➔

Security

➔

Set up/change password

2. Enter a new password and tap

Confirm

3. Enter the new password again and tap

Confirm

Set up SIM card lock

Prevent another user from using your SIM card to make

unauthorized calls or from accessing information stored on

your SIM card by protecting the information using a PIN code.

When enabled, your phone will ask for a PIN number each

time you use the phone. Using this option you can also

change your SIM PIN number.

1. From the Home screen, tap ➔

Settings

➔

Security

➔

Set up SIM card lock

2. Tap

Lock SIM card

, enter your SIM PIN code, then tap

3. Tap

Change SIM PIN

4. Enter your old SIM PIN code and tap

5. Enter your new SIM PIN code and tap

6. Re-type your new SIM PIN code and tap

Note:

You must activate Lock SIM card before you can

change your SIM PIN code.

DRAFT

FOR INTERNAL USE ONLY

149

Forgotten SIM PIN password

If you enter the wrong SIM PIN more than 3 times, you will

need to contact your AT&T Customer Service Representative

to get the PUK code for your device.

1. Each time you enter a wrong SIM PIN number the

phone will display how many attempts you have

remaining.

2. After the third incorrect attempt, the

Type PUK and new

PIN code

screen displays and your SIM card is locked.

3. Enter the new PUK code that you received from your

AT&T Customer Service Representative in the

PUK code

field.

4. Enter a new PIN code in the

New PIN code

field and tap

5. Enter the new PIN code again in the

Confirm PIN code

field and tap

Note:

While your SIM PIN is locked, you will still be able to

make Emergency calls if necessary.

Make passwords visible

When enabled, password characters display briefly as you

touch them while entering passwords.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Make passwords visible

to create a check mark

and enable or disable the display of password

characters.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 150

Device Administrators

The Device Administration feature allows you to select one or

more administration applications that control your device for

security purposes (for example, if your phone is lost of

stolen). These applications enforce remote or local device

security policies.

Some of the features a device administration application

might control are:

•

Setting the number of failed password attempts before the

device is restored to factory settings.

•

Automatically locking the device.

•

Restoring factory settings on the device.

Note:

If a device uses multiple enabled administration

applications, the strictest policy is enforced.

1. From the Home screen, tap ➔

Settings

➔

Security

➔

Device administrators

2. Select a device administrator and follow the prompts. If

no device administrators are listed, you can download

them from the Play Store.

Unknown sources

This feature allows you to download and install non-Market

applications.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Unknown sources

A check mark is displayed to indicate it is active.

Warning!

Enabling this option causes your phone and personal

data to be more vulnerable to attack by applications

from unknown sources.

Verify apps

This feature allows you to either block or warn you before

installing apps that may cause harm to your phone.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Verify apps

A check mark is displayed to indicate it is active.

DRAFT

FOR INTERNAL USE ONLY

151

Trusted Credentials

If a certificate authority (CA) certificate gets compromised or

for some other reason you do not trust it, you can disable or

remove it.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Trusted credentials

The trusted credentials screen has two tabs:

• System

: Displays CA certificates that are permanently installed

in the ROM of your device.

•User

: Displays any CA certificates that you installed, for

example, in the process of installing a client certificate.

3. Tap a CA certificate to examine its details.

A scrolling screen displays the details.

4. Scroll to the bottom of the details screen and tap

Turn

off

to disable a System certificate, or

Remove

remove a User certificate.

5. Tap

to return to the certificate list.

When enabled, a check mark appears in the check box.

Install from device storage

Install encrypted certificates from an installed memory card.

Note:

You must have installed a memory card containing

encrypted certificates to use this feature.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Install from device storage

, then choose a

certificate and follow the prompts to install.

Caution!

When you disable a system CA certificate,

the

Turn off

button changes to

Turn on

, so

you can enable the certificate again, if

necessary. When you remove a user-

installed CA certificate, it is permanently

deleted and must be re-installed, if needed.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 152

Clear credentials

Clear stored credentials.

Note:

This setting only appears if you have installed encrypted

certificates.

1. From the Home screen, tap ➔

Settings

➔

Security

2. Tap

Clear credentials

to remove all certificates.

Application Manager

You can download and install applications from Play Store or

create applications using the Android SDK and install them

on your device. Use Application manager settings to manage

applications.

Warning!

Because this device can be configured with system

software not provided by or supported by Google or

any other company, end-users operate these devices

at their own risk.

Memory Usage

See how memory is being used by Downloaded or Running

applications.

1. From the Home screen, tap ➔

Settings

➔

Application manager

2. Tap

DOWNLOADED

SD CARD

RUNNING

, or

ALL

display memory usage for that category of

applications.

The graph at the bottom of the DOWNLOADED tab

shows used and free device memory. The graph at the

bottom of the SD CARD tab shows used and free USB

(memory card) storage. The graph at the bottom of the

RUNNING tab shows used and free RAM.

DRAFT

FOR INTERNAL USE ONLY

153

Downloaded

Displays apps you have downloaded onto your device.

1. From the Home screen, tap ➔

Settings

➔

Application manager

2. Tap the

DOWNLOADED

tab to view a list of all the

downloaded applications on your device.

3. To switch the order of the lists displayed in the

Downloaded tabs, tap ➔

Sort by size

Sort by

name

4. To reset your application preferences, tap ➔

Reset

app preferences

5. Tap an application to view and update information

about the application, including memory usage, default

settings, and permissions.

SD Card Services

View and control services running on a microSD card

installed in your device.

1. From the Home screen, tap ➔

Settings

➔

Application manager

2. Tap the

SD CARD

tab. All the applications that are

currently stored on the microSD card display.

3. Tap one of the applications to view application

information.

The following options display:

• Force stop

: Stops the application from running on the device.

This is usually done prior to uninstalling or moving the

application.

• Uninstall

: Removes the application from the microSD card.

• Move to device storage

: Move the application from the

microSD card to device storage.

•Clear data

: Erases application data from the microSD card.

• Clear cache

: Erases data stored in cache memory.

• Clear defaults

: When active, resets application settings to their

default values.

Note:

This will reset the preferences for disabled

apps, disabled app notifications, default

applications for actions, and background data

restrictions for apps. You will not lose any app

data.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 154

Running Services

View and control services running on your device.

1. From the Home screen, tap ➔

Settings

➔

Application manager

2. Tap the

RUNNING

tab. All the applications that are

currently running on the device display.

3. Tap

Show cached processes

to display all the cached

processes that are running. Tap

Show services in use

switch back.

4. Tap one of the applications to view application

information.

The following options display:

•Stop

: Stops the application from running on the device. This is

usually done prior to uninstalling the application.

•Report

: Report failure and other application information.

Note:

Options vary by application.

Battery

See how much battery power is used for device activities.

1. From the Home screen, tap ➔

Settings

➔

➔ Battery.

The battery level displays in percentage. The amount

of time the battery was used also displays. Battery

usage displays in percentages per application.

2. Tap

Screen

Android System

Android OS

Cell standby

Media server

Device idle

, or any other listed application

to view how it is affecting battery use.

Note:

Other applications may be running that affect battery

use.

Warning!

Not all services can be stopped. Stopping

services may have undesirable

consequences on the application or

Android System.

DRAFT

FOR INTERNAL USE ONLY

155

Storage

From this menu you can view the memory allocation for the

memory card and USB as well as mount or unmount the SD

card.

For more information about mounting or unmounting the SD

card, see “Memory Card” on page 48.

To view the memory allocation for your external SD card:



From the Home screen, tap ➔

Settings

➔

Storage

. The available memory

displays under the

Total space

and

Available

space

headings for both Device memory and SD card.

SD card



Tap

Unmount SD card

to unmount your SD card so that

you can safely remove it, then tap

– or –



Tap

Format SD card

to format your SD card. This will

delete all data on your SD card including music, videos,

and photos.

Note:

The

Format SD card

option is only available when your

SD card is mounted.

Date and time

This menu allows you to change the current time and date

displayed.

1. From the Home screen, tap ➔

Settings

➔

Date and time

2. Tap

Automatic date and time

to allow the network to set

the date and time.

3. Tap

Automatic time zone

to allow the network to set the

time zone.

4. Tap

Set date

and tap the up and down arrows to set the

Month

Day

, and

Year

then tap

Set

5. Tap

Set time

and tap the up and down arrows to set the

Hour

Minute

, and

, then tap

Set

6. Tap

Select time zone

, then tap a time zone.

7. Optional: Tap

Use 24-hour format

. If this is not selected

the phone automatically uses a 12-hour format.

8. Tap

Select date format

and tap the date format type.

Important!

Deactivate

Automatic date and time

manually set the rest of the options.

DRAFT

FOR INTERNAL USE ONLY

Changing Your Settings 156

About Device

This menu contains legal information, system tutorial

information, and other phone information such as the model

number, firmware version, baseband version, kernal version,

and software build number.

To access phone information:

1. From the Home screen, tap ➔

Settings

➔

About device

2. The following information displays:

• Software update

: allows you to update your phone software, if

available. For more information, refer to

“Software Update”

on page 157.

• Status

: displays the Battery status, Battery level (percentage),

Network, Signal strength, Mobile network type, Service state,

Roaming, Mobile network state, My phone number (the phone

number for this device), IMEI number, IMEISV number, IP

address, Wi-Fi MAC address, Bluetooth address, Serial

number, Up time, and Device status.

• Legal information

: This option displays information about

Open source licenses as well as Google legal information. This

information clearly provides copyright and distribution legal

information and facts as well as Google Terms of Service,

pertinent information as a reference. Read the information and

terms, then tap

to return to the Settings menu.

•Label

: displays device certification logos.

•Device name

: displays the phone’s model name.

• Model number

: displays the phone’s model number.

• Android version

: displays the android version loaded on this

handset.

• Baseband version

: displays the baseband version loaded on

this handset.

•Kernel version

: displays the kernel version loaded on this

handset.

• Build number

: displays the software, build number.

DRAFT

FOR INTERNAL USE ONLY

157

Note:

Baseband, kernal and build numbers are usually used

for updates to the handset or support. For additional

information please contact your AT&T service

representative.

Software Update

The AT&T Software Update feature enables you to use your

phone to connect to the network and upload any new phone

software directly to your phone. The phone automatically

updates with the latest available software when you access

this option.

1. From the Home screen, tap ➔

Settings

➔

About device

➔

Software update

2. Tap

Check for updates

3. At the

AT&T Software update

prompt, tap

continue.

4. The phone automatically updates the software (if

available), otherwise, when the

Current software is up

to date

prompt is displayed, tap

5. When updating software, once the update file is

downloaded, you can delay the update on the start

screen by postponing it for a certain period of time. If

you want to resume the update before the selected

time, tap

Continue update

DRAFT

FOR INTERNAL USE ONLY

Connections 158

Section 9: Connections

This section describes the various connections your phone

can make including accessing the Internet with your

Browser, Wi-Fi, Bluetooth, and Connecting your PC.

Browser

The Browser is your access to the mobile web. This section

explains how to navigate the Browser and introduces you to

the basic features.

Accessing the Browser

To access the Browser:



From the Home screen, tap

Browser

The AT&T/YAHOO! mobile homepage displays.

Navigating with the Browser

1. To select an item, tap an entry.

2. To scroll through a website, sweep the screen with

your finger in an up or down motion.

3. Sweep the screen left to right to move laterally across

a web page.

4. To access the Browser bar at the bottom of the screen,

tap and drag upward. Tap anywhere on the

screen to hide it. The Browser bar gives you quick

access to Facebook, Like, Tweet It, A-List, Share, Apps,

Popular, News, Sports, Entertainment, Others, Settings,

and Add More. For more information, refer to “Browser

Bar” on page 135.

5. To return to a previous page, tap .

6. To move forward to a web page, tap .

DRAFT

FOR INTERNAL USE ONLY

159

Zooming in and out of the Browser

There are several ways to Zoom in and out on your browser

while in desktop view. After tapping on a link or article, use

one of these methods:

•

Tilting

: Tap and hold the screen at two points then tilt the device

back and forth to reduce or enlarge the screen. You must first

enable motion in the Settings section. For more information, refer

“Motions and Gestures”

on page 141.

•

Double tap

: Quickly tap the screen twice on the web page to

zoom in or out.

•

Pinching

: Sweep in opposite directions at the same time to zoom

in or out (use a pinching-in or pinching-out motion).

Browser Options

1. From the home page, tap to access the following

options:

•Homepage

: displays the home web page.

•New window

: displays a new window so you can browse

multiple URLs. For more information, refer to

“Adding and

Deleting Windows”

on page 160.

•Add bookmark

: allows you to add a URL to your bookmark list

• Add shortcut

: allows you to add a shortcut to your Home

screen.

•Save page

: allows you to store the current page in memory so

that it can be read later even if you loose your Internet

connection. It is saved in your Saved pages folder.

•Share via

: allows you to share the page using Bluetooth,

ChatON, Email, Flipboard, Gmail, Google, Google+, Hangouts,

Messaging, S Memo, or Wi-Fi Direct.

• Find on page

: allows you to search in the current page.

• Incognito mode

: pages viewed in incognito mode won’t

appear within your browser history or search history, and no

traces (such as cookies) are left on your device. For more

information, refer to

“Going Incognito”

on page 161.

• Saved pages

: contains web pages you have saved using the

Save page option.

•History

: displays your browsing history.

•Desktop view

: allows you to assign the browser to display the

current page in the desktop view (to closely mimic the display

as it would appear on a desktop computer).

•Brightness

: allows you to set the screen brightness.

DRAFT

FOR INTERNAL USE ONLY

Connections 160

•Print

: allows you to print the screen or web page on a

Samsung printer using Wi-Fi or Wi-Fi Direct.

•Settings

: allows you to modify your web settings. For more

information, refer to

“Browser Settings”

on page 164.

Enter a URL

You can access a website quickly by entering the URL.

Websites are optimized for viewing on your phone.

To enter a URL and go to a particular website, follow these

steps:

1. Tap the URL field at the top of your screen.

2. Enter the URL using the on-screen keypad.

The website displays.

Search the Internet

To perform an internet search using keywords, follow these

steps:

1. Tap the Search bar at the top of the browser.

2. Enter the keyword(s) to search using the on-screen

keypad and tap .

3. Tap a link to view the website.

Adding and Deleting Windows

You can have up to eight Internet windows open at one time.

To add a new window, follow these steps:

1. From your browser, tap ➔

New window

A new browser window is opened.

2. Tap (

Windows

) to see thumbnails of all open

windows.

3. Tap a window listing to open up that Internet window.

4. Tap at the top right corner of the web page

thumbnail to delete the window.

DRAFT

FOR INTERNAL USE ONLY

161

Going Incognito

The incognito feature allows you to view Internet sites

outside of normal browsing. Pages viewed in this incognito

window won’t appear within your browser history or search

history, and no traces (such as cookies) are left on your

device.

Note:

Any downloaded files will be preserved and will stay on your

device after you exit the incognito mode.

To add a new incognito window:

1. From your browser, tap ➔

Incognito mode

2. At the information prompt, tap

3. A new browser window displays.

To exit from the incognito window:

1. From your browser window, tap (

Windows

2. Scroll across the available windows and locate the

incognito window. The incognito icon appears in

the upper-left of the new browser window while you

are in this mode.

3. Tap next to the incognito listing to delete this

window.

Using Bookmarks

While navigating a website, you can bookmark a site to

quickly and easily access it at a future time. The URLs

(website addresses) of the bookmarked sites are displayed in

the Bookmarks page. From the Bookmarks page you can

also view your Most visited websites and view your History.

1. From the Home webpage, tap (

Bookmarks

The Bookmarks page is displayed.

2. Tap to display the following options:

• List/Thumbnail view

: Select

Thumbnail view

(default) to view

a thumbnail of the webpage with the name listed, or select

List

view

to view a list of the bookmarks with Name and URL listed.

• Create folder

: Creates a new folder in which to store new

bookmarks.

•Delete

: Erases selected bookmarks.

• Change order

: Rearranges the current bookmarks.

• Move to folder

: Selected bookmarks are moved to a selected

folder.

DRAFT

FOR INTERNAL USE ONLY

Connections 162

3. Tap a bookmark to view the webpage, or touch and

hold a bookmark for the following options:

• Open in new window

: Opens the webpage in a new window.

• Edit bookmark

: Allows you to edit the name or URL of the

bookmark. For more information, refer to

“Editing

Bookmarks”

on page 162.

•Add shortcut

: Adds a shortcut to the bookmarked webpage to

your phone’s Home screen.

• Share link

: Allows you to share a URL address using many

different options.

• Delete bookmark

: Allows you to delete a bookmark. For more

information, refer to

“Deleting Bookmarks”

on page 162.

• Set as homepage

: Sets the bookmark to your new homepage.

Adding Bookmarks

1. From any webpage, tap ➔ .

2. Use the on-screen keypad to enter the Name, Address,

and Location.

3. Tap

Save

Saved to bookmarks

will appear at the bottom of the

page.

Editing Bookmarks

1. From the Bookmarks page, tap and hold the bookmark

you want to edit.

2. Tap

Edit bookmark

3. Use the on-screen keypad to edit the Name, Address,

and Location.

4. Tap

Save

Deleting Bookmarks

1. From the Bookmarks page, tap and hold the bookmark

you want to delete.

2. Tap

Delete bookmark

3. At the

Delete

confirmation window, tap

DRAFT

FOR INTERNAL USE ONLY

163

Emptying the Cookies

A cookie is a small file which is placed on your phone by a

website during navigation. In addition to containing some

site-specific information, it can also contain some personal

information (such as a username and password) which can

pose a security risk if not properly managed. You can clear

these cookies from your phone at any time.

1. From the Home webpage, tap ➔

Settings

➔

Privacy

➔

Delete personal data

2. Tap

Cookies and site data

to create a check mark.

3. Tap

Done

Using your History

The History list provides you with a list of the most recently

visited websites. These entries can be used to return to

previously unmarked web pages.

1. From the Home webpage, tap ➔

History

A list of your most recently visited websites is

displayed with Name and URL address.

2. Tap on a category such as

Today

Last 7 days

Most

visited

3. Tap any entry to display the webpage.

4. Tap ➔

Clear history

to delete the History list.

Saving Pages

You can save a page for future viewing without making it a

bookmark.

1. From the Home webpage, tap ➔

Save page

Page saved in Saved pages

is displayed.

2. The web page is saved.

DRAFT

FOR INTERNAL USE ONLY

Connections 164

Saved Pages

The Saved pages list provides you with a list of the websites

that you have saved.

1. From the Home webpage, tap ➔

Saved pages

A list of your saved webpages is displayed with their

Name. The webpages that have been visited the most

will appear at the top.

2. Tap any entry to display the webpage.

Browser Settings

To make adjustments in your browser settings, follow these

steps:

1. From the Home webpage, tap ➔ ➔

Settings

2. The following options are available:

Basics:

• Set homepage

: Sets the current home page for the Web

browser.

• Auto fill forms

: allows you to enter text to be used in your web

profile. Tap Add profile, then enter text for the Web form auto

fill.

Privacy:

• Search and Web address suggestions

: displays predictions

of related queries and popular websites in the address bar as

you type.

• Preload available links before opening

: allows you improve

performance when loading pages.

• Remember form data

: Allows the device to store data from

any previously filled out forms. Remove the check mark to

disable this function.

• Remember passwords

: Stores usernames and passwords for

visited sites. Remove the check mark to disable this function.

• Delete personal data

: allows you to delete all personal data

such as Browsing history, Cache, Cookies and site data,

Passwords, Auto-fill data, and Location access.

DRAFT

FOR INTERNAL USE ONLY

165

Accessibility:

•Text scaling

: allows you to preview the text size, scale the text

size using a slider bar, set the zoom amount on double tap, and

minimize the font size using a slider bar.

• Force zoom

: allows you to override the website’s request to

control zoom.

• Text encoding

: adjusts the current text encoding.

• Fullscreen

: allows you to use Fullscreen mode to hide the

status bar.

• Text booster

: allows you to view PC websites easily by

boosting the text size.

Content settings:

• Accept cookies

: Allows sites, that require cookies, to save and

read cookies from your device.

• Turn on location

: Allows websites to request access to your

location.

• Turn on JavaScript

: Enables Javascript for the current Web

page. Without this feature, some pages may not display

properly. Remove the check mark to disable this function.

• Block pop-ups

: Prevents popup advertisement or windows

from appearing on-screen. Remove the check mark to disable

this function.

•Default storage

: Allows you to set your default storage to

Device or Memory Card.

• Website settings

: View advanced settings for individual

websites.

• Turn on notifications

: Allows website notifications. Select

Always on, On demand, or Off.

• Clear notifications

: Deletes website notification access

information.

• Reset settings

: Restores all settings to default.

Note:

The layout may change as a result.

DRAFT

FOR INTERNAL USE ONLY

Connections 166

Bandwidth management:

• Preload webpages

: Allows the browser to preload pages in

the background. You can set to Always, Only on Wi-Fi, and

Never.

•Load images

: Allows web page images to be loaded along

with the other text components of a loaded website.

• Open pages in overview

: Displays an overview of newly

opened web pages.

Wi-Fi

About Wi-Fi

Wi-Fi (short for "wireless fidelity"and sometimes referred to

as wifi) is a term used for certain types of Wireless Local

Area Networks (WLAN). These device types use an 802.11

wireless specification to transmit and receive wireless data.

Wi-Fi communication requires access to an existing and

accessible Wireless Access Point (WAP). These WAPs can

either be Open (unsecured) as within most Hot Spots, or

Secured (requiring knowledge of the Router name and

password).

Turning Wi-Fi On

By default, your device’s Wi-Fi feature is turned off. Turning

Wi-Fi on makes your device able to discover and connect to

compatible in-range WAPs.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi ON .

Connect to a Wi-Fi Network

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

The network names and security settings (Open

network or Secured with WEP) of detected Wi-Fi

networks are displayed in the Wi-Fi networks section.

2. Tap the network you want to connect to.

3. Enter a wireless password if necessary.

Note:

When you select an open network, you will be

automatically connected to the network.

DRAFT

FOR INTERNAL USE ONLY

167

Manually add your new network connection

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap

Add Wi-Fi network

3. Enter the

Network SSID

. This is the name of your

Wireless Access Point.

4. Tap the

Security

field and select a security option. This

must match the current security setting on your target

WAP.

5. If secured, you will also need to enter your WAP’s

password.

6. Tap

Show advanced options

, if you need to add

advanced options such as Proxy settings, IP settings,

or Key management.

7. Tap

Connect

to store the new information and connect

to your target WAP.

Note:

The next time your device connects to a previously

accessed or secured wireless network, you are not

prompted to enter the WAP key again, unless you reset

your device back to its factory default settings.

Turning Wi-Fi Off

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi OFF .

Note:

Use of wireless data connections such as Wi-Fi and

Bluetooth can cause an added drain to your battery and

reduce your use times.

Manually Scan for a Wi-Fi Network

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap

Scan

All available Wi-Fi networks are displayed.

DRAFT

FOR INTERNAL USE ONLY

Connections 168

Wi-Fi Status Indicators

The following icons show your Wi-Fi connection status at a

glance:

Displays when Wi-Fi is connected, active, and

communicating with a Wireless Access Point

(WAP).

Displays when there is a Wi-Fi access point

available but you are not connected to it. May also

display if there is a communication issue with the

target Wireless Access Point (WAP).

Displays when connected to another device using

Wi-Fi Direct. For more information, refer to “Wi-Fi

Direct” on page 169.

Wi-Fi Advanced Settings

The Advanced Wi-Fi menu allows you to set up many of your

device’s advanced Wi-Fi services.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap ➔

Advanced

The following options are available:

• Network notification

: alerts you when a new WAP is available.

• Keep Wi-Fi on during sleep

: allows you to specify when to

disconnect from Wi-Fi.

• Check for Internet service

: Checks if Wi-Fi internet service is

available when connected to an AP (Access Point).

•Auto connect

: allows you to be automatically connected to an

AT&T Wi-Fi Hotspot as soon as your phone detects it.

•MAC address

: view your device’s MAC address, required

when connecting to some secured networks (not configurable).

•IP address

: view your device’s IP address.

DRAFT

FOR INTERNAL USE ONLY

169

Wi-Fi Direct

Wi-Fi Direct allows device-to-device connections so you can

transfer large amounts of data over a Wi-Fi connection.

Note:

See your service plan for applicable charges for Wi-Fi

Direct.

1. From the Home screen, tap ➔

Settings

➔

Connections

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi ON .

3. At the bottom of the Wi-Fi screen, tap the

Wi-Fi Direct

button.

4. Repeat

steps 1 - 3

on the other device you want to

connect with. The steps on a different model of phone,

may be different.

5. On your phone, tap

Scan

The device scans for other Wi-Fi Direct devices.

6. Once the device you want to connect to is displayed,

tap on it.

7. The other device has 2 minutes to tap

for the

connection to be made.

8. Once connected, the other device will show as

Connected

in your list of Wi-Fi Direct devices and the

icon will display at the top of your screen.

9. For additional information about Wi-Fi Direct,

tap ➔

Help

DRAFT

FOR INTERNAL USE ONLY

Connections 170

Sharing Information with Connected Device

To share Videos, Photos, or other information with the

connected device, follow these steps:

1. View the information that you want to share. For

example, if you want to share a photo, find the photo in

your camera viewer or

My Files

folder, then tap the

Share,

Share via,

Send via

option.

2. Tap the

Wi-Fi Direct

option.

3. Tap the connected device name. For example,

Android_49ba.

4. Tap

Done

5. The file is transferred and the other device will receive

a screen notification that a Wi-Fi file has been

received. The file can be found in

My Files

➔

All files

➔

Device storage

in the

ShareViaWifi

folder.

Note:

Depending on the other device model, the prompts and

shared folder information may differ.

AT&T Smart Wi-Fi

With AT&T Smart Wi-Fi, you can maximize your battery

performance, maximize your data, simplify access to AT&T

Hot Spots and Wi-Fi networks, automate your Wi-Fi

connections, and track your data use.

1. From the Home screen, tap ➔

AT&T Smart

Wi-Fi

2. The first time you access AT&T Smart Wi-Fi, you will

need to install it. Tap

at the prompt.

3. Sign on to your Google account if you have not already

done so.

4. The Play Store displays the

AT&T Smart Wi-Fi

application. Tap

Update

5. Tap

Accept & download

6. Follow the on-screen instructions to use AT&T Wi-Fi.

For more information on how to use this application, go

www.att.com/smartwifi

DRAFT

FOR INTERNAL USE ONLY

171

NFC

NFC (Near Field Communication) allows data exchange when

you touch your device with another compatible device. This

is used for applications such as S Beam. To activate NFC on

your device, see “NFC” on page 117.

S Beam

When S Beam is activated, you can beam files to another

NFC-capable device by holding the devices close together.

You can beam images and videos from your Gallery, music

files from your Music app, and more. For more information,

refer to “S Beam” on page 117.

Bluetooth

About Bluetooth

Bluetooth is a short-range communications technology that

allows you to connect wirelessly to a number of Bluetooth

devices, such as headsets and hands-free car kits, and

Bluetooth-enabled handhelds, computers, printers, and

wireless devices. The Bluetooth communication range is

usually up to approximately 30 feet.

Turning Bluetooth On and Off

To turn Bluetooth on:

1. From the Home screen, tap ➔

Settings

➔

Connections

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth ON .

When active, appears within the Status area.

DRAFT

FOR INTERNAL USE ONLY

Connections 172

To turn Bluetooth off:

1. From the Home screen, tap ➔

Settings

➔

Connections

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth OFF .

Bluetooth Status Indicators

The following icons show your Bluetooth connection status

at a glance:

Displays when Bluetooth is active.

Displays when Bluetooth is connected (paired) and

communicating.

Bluetooth Settings

The Bluetooth settings menu allows you to set up many of

the characteristics of your device’s Bluetooth service,

including:

•

Entering or changing the name your device uses for Bluetooth

communication and description

•

Setting your device’s visibility (or “discoverability”) for other

Bluetooth devices

To access the Bluetooth Settings menu:

1. From the Home screen, tap ➔

Settings

➔

Connections

2. Verify your Bluetooth is ON .

3. Tap

Bluetooth

To change your Bluetooth name:

1. From the Home screen, tap ➔

Settings

➔

About device

➔

Device name

2. Use the keyboard to modify your device name and tap

DRAFT

FOR INTERNAL USE ONLY

173

To make your device visible:

1. From the Bluetooth settings page, tap ➔

Visibility

time-out

•

Making your device visible allows it to be detected by other

devices for pairing and communication.

2. Select a time that you would like your device visibility

to time-out.

To show received files:



From the Bluetooth settings page, tap ➔

Received

files

A list of all files received from Bluetooth is displayed.

To scan for Bluetooth devices:

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap

Scan

to search

for visible external Bluetooth-compatible devices such

as headsets, devices, printers, and computers.

Pairing Bluetooth Devices

The Bluetooth pairing process allows you to establish trusted

connections between your device and another Bluetooth

device. When you pair devices, they share a passkey,

allowing for fast, secure connections while bypassing the

discovery and authentication process.

To pair your device with another Bluetooth device:

1. Verify your Bluetooth is active.

2. Tap

Scan

. Your device will display a list of discovered

in-range Bluetooth devices.

3. Tap a device from the list to initiate pairing.

4. Enter the passkey or PIN code, if needed, and tap

5. The external device will then have to also accept the

connection and enter your device’s PIN code.

Once successfully paired to an external device,

appears within the Status area.

Note:

Due to different specifications and features of other

Bluetooth-compatible devices, display and operations

may be different, and functions such as transfer or

exchange may not be possible with all Bluetooth

compatible devices.

DRAFT

FOR INTERNAL USE ONLY

Connections 174

Note:

Pairing between two Bluetooth devices is a one-time

process. Once a pairing has been created, the devices

will continue to recognize their partnership and

exchange information without having to re-enter a

passcode again.

Disconnecting a paired device

Disconnecting a paired device breaks the connection

between the device and your phone, but retains the

knowledge of the pairing. At a later point when you wish to

reconnect the device, there is no need to setup the

connection information again.

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap the previously

paired device (from the bottom of the page).

3. Tap

to confirm disconnection.

Note:

Disconnections are manually done but often occur

automatically if the paired device goes out of range of

your phone or it is powered off.

Deleting a paired device (unpair)

Deleting a device from your list removes its “connection

record” and upon reconnection would require that you re-

enter all the previous pairing information.

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap next to the

previously paired device. This opens the connected

device’s menu options.

3. Tap

Unpair

to delete the paired device.

4. Tap

Rename

to change the name of the paired device.

5. Tap

Call audio

to enable or disable call audio from the

paired device.

6. Tap

Media audio

to enable or disable media audio from

the paired device.

DRAFT

FOR INTERNAL USE ONLY

175

Sending Contacts via Bluetooth

Depending on your paired devices’ settings and capabilities,

you may be able to send pictures, Contact information, or

other items using a Bluetooth connection.

Note:

Prior to using this feature, Bluetooth must first be

enabled, and the recipient’s device must be visible.

1. Verify your Bluetooth is active.

2. From the Home screen, tap

Contacts

3. Tap ➔

Import/Export

➔

Share namecard via

4. Tap each contact that you would like to send via

Bluetooth. A green check mark will appear next to each

entry you select.

5. Tap

Done

6. Tap

Bluetooth

7. Select the paired device to send the contacts to.

Note:

The external Bluetooth device must be visible and

communicating for the pairing to be successful.

8. A Bluetooth share notification will appear in your

notifications list.

PC Connections

You can connect your device to a PC using your PC data

cable using various USB connection modes.

Storage

: allows you to use the onboard storage capacity of

the phone to store and upload files. This option allows your

computer to detect the phone as a removable storage drive.

Kies

: allows you to manage music, movies and photos. You

can also backup precious contacts and calendars, download

apps and podcasts and automatically upgrade device

firmware. Kies conveniently syncs your life across all your

devices.

Note:

To sync your device to your PC, it is highly

recommended that you install Samsung Kies which is

available at

http://www.samsung.com/kies

(for Windows/

Mac).

Note:

If you are a Windows XP user, ensure that you have

Windows XP Service Pack 3 or higher installed on your

computer. Also, ensure that you have Samsung Kies 2.0

or Windows Media Player 10 or higher installed on your

computer.

DRAFT

FOR INTERNAL USE ONLY

Connections 176

Connecting as a Storage Device

You can connect your device to a PC as a removable disk and

access the file directory. If you insert a memory card in the

device, you can also access the files directory from the

memory card by using the device as a memory card reader.

Note:

The file directory of the memory card displays as a

removable disk, separate from the internal memory.

1. Connect the USB cable to the device and connect the

cable to the computer. After a few seconds, a pop-up

window displays on the PC when connected.

2. On the PC pop-up, click

Open device to view files

3. Copy files from the PC to the memory card.

DRAFT

FOR INTERNAL USE ONLY

177

Section 10: Applications

This section contains a description of each application that is

available in the Apps Menu, its function, and how to navigate

through that particular application. If the application is

already described in another section of this user manual,

then a cross reference to that particular section is provided.

Note:

This manual only addresses applications that have been

loaded on your device as of the date of purchase.

Information concerning third party applications that you

may choose to download from the Google Play Store or

otherwise should be obtained from the application

provider directly and not from Samsung.

Tip:

To open applications quickly, add the icons of frequently-

used applications to one of the Home screens. For details,

see “Customizing Your Home Screen” on page 39.

Amazon Kindle

This application allows you to download books, magazines,

and newspapers to read on your phone.

1. From the Home screen, tap ➔

Amazon Kindle

2. At the Kindle display, tap

Get Kindle for Android

Note:

The first time you use Amazon Kindle, you will need to

download the updated application from the Play Store.

When the Play Store page displays, tap

Update

. For more

information, refer to “Play Store” on page 204.

3. Sign on to your Google account. For more information,

refer to “Creating a New Google Account” on page 14.

4. Follow the on-screen instructions to download the

application from the Play Store.

DRAFT

FOR INTERNAL USE ONLY

Applications 178

AT&T Code Scanner

AT&T Code Scanner allows you to scan two-dimensional (QR

and datamatrix codes) and one-dimensional (UPC and EAN)

barcodes found in magazines, stores, and online.

1. From the Home screen, tap ➔

AT&T Code Scanner

Note:

The first time you use the AT&T Code Scanner, you will

need to download the updated application from the Play

Store. When the Play Store page displays, tap

Update

For more information, refer to “Play Store” on page

204.

2. Sign on to your Google account if you are not already

signed on. For more information, refer to “Creating a

New Google Account” on page 12.

3. Read the Terms and Conditions and tap

continue.

4. At the My Profile screen, tap

to enter profile

information or tap

Not now

to bypass.

5. Position your phone approximately 6-8 inches from the

barcode. Ensure that the barcode is completely within

the window as shown below. Keep your phone steady

for best results.

6. The scanner will automatically scan the barcode. It

may take several seconds.

7. After the scan, tap

Yes

to open the web page to view

the information on the barcode that was scanned.

DRAFT

FOR INTERNAL USE ONLY

179

AT&T DriveMode

With the AT&T DriveMode application, you can set your

phone to auto reply when you are driving and don’t want to

answer the phone. You can set auto reply to Messages,

Emails, and Phone Calls. You can also allow up to five of your

contacts to contact you while you are in Drive mode.

1. From the Home screen, tap ➔

AT&T DriveMode

The

AT&T DriveMode

screen is displayed.

2. Read the Terms and Conditions and Privacy Policy and

tap

to continue.

3. Read the additional information and tap

Continue

4. Follow the on-screen instructions to set up your AT&T

DriveMode options.

AT&T FamilyMap

AT&T FamilyMap provides peace of mind by being able to

conveniently locate a family member from your wireless

phone or PC and know that your family's location information

is secure and private.

Note:

FamilyMap requires a paid subscription. To sign up for

service, visit

http://www.att.com/familymap

for more

information or contact your AT&T Customer Service

Representative.

1. From the Home screen, tap ➔

AT&T FamilyMap

Note:

The first time you use AT&T Family Map, you will need to

download the application from the Play Store. For more

information, refer to “Play Store” on page 204.

2. At the AT&T FamilyMap Sign In webpage, tap

Get

Started

to create an account.

– or –

Tap

if you already have an account.

3. Follow the on-screen instructions.

DRAFT

FOR INTERNAL USE ONLY

Applications 180

AT&T Locker

AT&T Locker allows you to store, share, and sync all of your

photos, videos, and documents in one safe, convenient

place; the AT&T cloud.

1. Sign on to your Google account if you are not already

signed on. For more information, refer to “Creating a

New Google Account” on page 14.

2. From the Home screen, tap ➔

AT&T Locker

3. At the AT&T Locker home screen, tap

to create

an account or tap

if you already have an

account.

4. Follow the on-screen instructions to use AT&T Locker.

AT&T Navigator

AT&T Navigator provides you with access to real-time GPS-

driven applications. These programs not only allow you to

achieve turn-by-turn navigation, but also access local

searches.

Important!

You must have a data plan to use this feature.

Note:

These services require the purchase of a subscription.

To launch the AT&T Navigator application, follow these steps:

1. From the Home screen, tap ➔

AT&T Navigator

2. Read the

and tap

acknowledge the terms of use.

The first time that you use AT&T Navigator, the

necessary files will be downloaded. The AT&T

Navigator main screen displays.

3. Tap an AT&T Navigator plan that you choose to

purchase.

4. Follow the on-screen instructions.

DRAFT

FOR INTERNAL USE ONLY

181

AT&T Ready2Go

AT&T Ready2Go allows you to quickly and easily setup your

phone by using the web browser on your PC. You can set-up

email accounts, import contacts, set wallpaper, configure Wi-

Fi and many more features. For more information, refer to

“Configuring your Phone” on page 12.

AT&T Smar t Wi-Fi

With AT&T Smart Wi-Fi, you can maximize your battery

performance, maximize your data, simplify access to AT&T

Hot Spots and Wi-Fi networks, automate your Wi-Fi

connections, and track your data use. For more information,

refer to “AT&T Smart Wi-Fi” on page 170.

Battery Manager

This app is a shortcut to your Battery settings so you can

manage how much battery power is used for device

activities.



From the Home screen, tap ➔

Battery Manager

For more information, refer to “Battery” on page 154.

Calculator

With this feature, you can use the phone as a calculator. The

calculator provides the basic arithmetic functions; addition,

subtraction, multiplication, and division. The Calculator also

keeps a history of recent calculations.

1. From the Home screen, tap ➔

Calculator

2. Enter the first number using the on-screen numeric

keys.

3. Enter the operation for your calculation by tapping the

corresponding on-screen arithmetic function key.

4. Enter the second number.

5. To view the result, tap equals (

6. To view calculator history, tap located at the

top of the calculator buttons. A history of your past

calculations is displayed. Tap again to display

the calculator keypad.

7. To clear the calculator history, tap ➔

Clear history

8. To change the text size, tap ➔

Text size

. Tap

Small, Medium, or Large.

9. Turn your phone sideways to the landscape position to

display the scientific calculator.

DRAFT

FOR INTERNAL USE ONLY

Applications 182

Calendar

With the Calendar feature, you can consult the calendar by

day, week, or month, create events, and set an alarm to act

as a reminder, if necessary.

To access the Calendar:

1. From the Home screen, tap ➔

Calendar

2. The following tabs are available on the right side of the

display:

•Year

: displays the Year view.

•Month

: displays the Month view.

• Week

: displays the Week view.

•Day

: displays the Day view.

•List

: displays the List view.

•Task

: allows you to search for tasks.

3. Tap (

Create event

) to create a new Calendar

event.

4. Tap

Today

to display the current date indicated by a

blue box.

5. Tap

Calendars

to select the calendar options that you

want displayed.

6. Tap and select one of the following options:

•Go to

: displays a specific date.

• Delete

: allows you to delete All events, All events before today,

or an individual event.

•Search

: allows you to search within your current events.

•Sync

: allows you to synchronize your calendar with one or all of

your accounts. This option only appears when an account has

been opened.

•Settings

: displays a list of configurable settings.

Calendar Settings

1. From any Calendar view, tap ➔

Settings

2. Tap

View styles

and select an option.

•

Tap

Month view styles

and select an option.

•

Tap

Week view

and select a type.

3. Tap

First day of week

and select either

Local default,

Saturday, Sunday

Monday

4. Tap

Hide declined events

to activate this option. A check

mark indicates selection.

5. Tap

Lock time zone

(to lock event time based on your

current user-selected time zone). Select a time zone

from within the

Select time zone

field.

DRAFT

FOR INTERNAL USE ONLY

183

6. Tap

Show week number

to display the week numbers

along the side of the week entries.

7. Tap

Calendars

and select the type of general

synchronization settings you want. A check mark

indicates selection.

8. Tap

Set alerts & notifications

to adjust the event

notification method. Choose from:

Alert

Status bar

notification

, and

Off

9. Tap

Select ringtone

to assign a ringtone to a calendar

event notification.

10. Tap

Vibration

to set the Event notification tone to

vibrate.

11. Tap

Quick responses

to select quick responses to

emailing guests.

Camera

Use your 13.0 megapixel camera feature to produce photos in a

JPEG format. Your phone also functions as a Camcorder to take

videos. For more information, refer to “Camera” on page 80.

ChatON

With the ChatON application, you can interact with friends

and family with text, images, hand-written notes and video

shared instantly. You can chat in groups, while a Web client

will allow the easy sharing of content and conversations

between your phone and PC. For more information, refer to

“ChatON” on page 106.

DRAFT

FOR INTERNAL USE ONLY

Applications 184

Chrome

The Google Chrome app allows you to use the Google

Chrome web browser on your phone.

1. From the Home screen, tap ➔

Chrome

2. Read the Google Chrome Terms of Service and tap

Accept and Continue

3. If you have an existing Chrome account, tap

bring your open tabs, bookmarks, and omnibox data

from your computer to your phone, otherwise tap

thanks

4. Follow the on-screen instructions to use Google

Chrome.

Clock

The Clock application allows you to access alarms, view the

World Clock, set a stopwatch, and use a timer.

Alarm

This feature allows you to set an alarm to ring at a specific

time.

1. From the Home screen, tap ➔

Clock

➔

Alarm

➔

Create alarm

. The following options

display:

•Time

: tap

(

) or (

Down

)

to set the new time for the

alarm to sound. Tap AM or PM.

•Alarm repeat

: use this option to set the repeating status for the

alarm by tapping on the days that you want the alarm to sound.

Tap the Repeat weekly checkbox to have the alarm repeat

weekly.

• Alarm type

: sets the way in which the alarm sounds when

activated (Melody, Vibration, Vibration and melody, and

Briefing).

•More

: displays the following additional options:

DRAFT

FOR INTERNAL USE ONLY

185

–

Alarm tone

: sets the sound file which is played when the

alarm is activated. Select an option or tap Add for additional

options.

–

Alarm volume

: drag the slider to adjust the alarm’s volume.

–

Location alarm

: when activated, the alarm only sounds

when you are at a specific location. Touch and slide the

slider to the right to turn it on then follow the on-

screen instructions to enter a location.

–

Snooze

: use this option to set a Duration (3, 5, 10, 15, or 30

Minutes) and Snooze repeat (1, 2, 3, 5, or 10 Times). Tap

the ON/OFF slider to activate.

–

Smart alarm

: tracks body movements and calculates the

best time for sounding the alarm. Place the phone

somewhere on your bed then the phone's movement sensor

(also known as accelerometer) is sensitive enough to work

from any part of the bed. Set the Interval and the Tone. Tap

the ON/OFF slider to activate.

–

Name

: allows you to use a specific name for the alarm. The

name will appear on the display when the alarm activates.

2. Tap

Save

to store the alarm details.

Turning Off an Alarm



To stop an alarm when it sounds, touch and sweep the

icon to the right.

Setting the Snooze Feature



To activate the Snooze feature after an alarm sounds,

touch and sweep the icon to the left. Snooze must

first be set in the alarm settings. For more information,

refer to “Alarm” on page 184.

Deleting Alarms

To delete an alarm, follow these steps:

1. From the Home screen, tap ➔

Clock

➔

Alarm

➔

Delete

2. Tap the alarm or alarms you wish to delete. A green

check mark will appear next to each selection. Tap

Select all

to delete all alarms.

3. Tap

Delete

DRAFT

FOR INTERNAL USE ONLY

Applications 186

World Clock

World Clock allows you to view the time of day or night in

other parts of the world. World Clock displays time in

hundreds of different cities, within all 24 time zones around

the world.

1. From the Home screen, tap ➔

Clock

➔

World Clock

. The clock for your time zone is displayed.

2. Tap

Add city

to add another city to the World Clock.

3. Scroll through the list of cities to find the city you want

to add, or tap the Search bar and use the keypad to

enter a city to search for.

4. Tap the city you want to add. The clock for that city will

display.

5. To set Daylight Savings time, press and hold a city,

then tap

DST settings

6. Select

Automatic

Off

, or

1 hour

7. If Daylight Savings Time is selected, a sun symbol on

the World Clock listing will appear.

Deleting a World Clock Entry

1. From the Home screen, tap ➔

Clock

➔

World Clock

➔

Delete

2. Press and hold the city clocks you wish to delete.

3. Tap

Delete

Stopwatch

You can use this option to measure intervals of time.

1. From the Home screen, tap ➔

Clock

➔

Stopwatch

2. Tap

Start

to start the stopwatch and tap

Lap

to mark a

unit of time per lap.

3. Tap

Stop

to stop the stopwatch.

4. Tap

Restart

to continue or tap

Reset

to erase all times

recorded.

DRAFT

FOR INTERNAL USE ONLY

187

Timer

You can use this option to set a countdown timer. Use a timer

to count down to an event based on a preset time length

(hours, minutes, and seconds).

1. From the Home screen, tap ➔

Clock

➔

Timer

2. The

Minutes

field is highlighted and set to 1 minute.

Use the keypad to set the number of minutes you want.

3. Tap the

Hours

field to set hours if desired. As you tap

different fields, they will become highlighted.

4. Tap the

Seconds

field to set seconds.

5. Tap

Start

to begin the timer and tap

Stop

to pause the

timer.

6. After stopping, tap

Restart

to continue or tap

Reset

set the timer back to the original setting.

Desk clock

You can use the Desk clock when you have a desk dock and

you want your phone to display the time, day, date, location,

and weather conditions when it is docked.

1. From the Home screen, tap ➔

Clock

➔

Desk clock

The default Desk clock is displayed.

2. Tap to display the Desk clock in full-screen mode.

3. To make changes, tap

➔

Settings

4. The following options are displayed while in full-screen

mode:

• Hide status bar

: when this is checked, the status bar is hidden

from view.

•Wallpaper

: tap to select Desk clock wallpaper from Default,

Gallery, or Same as home screen.

•Calendar

: when this is checked, the calendar is displayed. Tap

to uncheck.

• Weather

: when this is activated, the location, temperature, and

weather condition is displayed. Touch and slide the slider to the

right to turn it on .

•Dock

: allows you to set your Dock settings such as Dock

sound, Audio output mode, Desk home screen display,

Automatic unlock, and Audio output.

DRAFT

FOR INTERNAL USE ONLY

Applications 188

Contacts

You can manage your daily contacts by storing their name

and number in your Address Book. Address Book entries can

be sorted by name, entry, or group.

You can also synchronize your phone Address Book with

AT&T Address Book, the network backup service.

For more information, refer to “Contacts and Your Address

Book” on page 66.

Data Manager

This app is a shortcut to your Data usage settings so you can

manage your data.



From the Home screen, tap ➔

Data Manager

For more information, refer to “Data Usage” on page

110.

Device Help

DeviceHelp provides online information to help with your

device questions.

1. From the Home screen, tap ➔

Device Help

The

AT&T Device Help

screen is displayed.

2. Follow the on-screen instructions for accessing helpful

information.

Downloads

Provides quick access to tabs containing a list of your current

downloaded files (Internet and Other).

1. From the Home screen, tap ➔

Downloads

All of your downloads are listed.

2. Tap an available file and select it for use.

3. Choose an available action such as Share, Delete, Sort

by size, or Clear list.

Email enables you to review and create email using various

email services. You can also receive message alerts when

you receive an important email. For more information, refer

to “Using Email” on page 100.

DRAFT

FOR INTERNAL USE ONLY

189

Flipboard

This application creates a personalized digital magazine out

of everything being shared with you. Access news stories,

personal feeds and other related material. Flip through your

Facebook newsfeed, tweets from your Twitter account,

photos from friends and much more.

1. From the Home screen, tap ➔

Flipboard

2. Swipe up on the Flipboard screen, then tap

Flipboard

Account

at the top of the display.

3. Tap

Create

to set up a new Flipboard account.

– or –

Tap

to log into your previously created profile.

4. Follow the on-screen instructions to use Flipboard.

Gallery

The Gallery is where you view photos and play back videos.

For photos, you can also perform basic editing tasks, view a

slideshow, set photos as wallpaper or contact image, and

share as a picture message. For more information, refer to

“Gallery” on page 89.

Games

Access social and premium games. Join Game Hub to enjoy

free games with your friends.

1. From a Home screen, touch ➔

Games

2. Tap a game and follow the on-screen instructions.

Gmail

Gmail is a web-based email service. Gmail is configured

when you first set up your phone. Depending on your

synchronization settings, Gmail can automatically

synchronize with your Gmail account on the web. For more

information, refer to “Using Gmail” on page 102.

Google

The Google Search application is the same on-screen

Internet search engine that is on the Google Search Bar on

your main Home screen. For more information, refer to

“Google Search Bar” on page 34.

DRAFT

FOR INTERNAL USE ONLY

Applications 190

Google Settings

As Google has become more intertwined with other

applications, this menu provides a quick and ready access

point to configure preferences for Google+, Maps & Latitude,

Locations, etc. You can also use the Search function to

initiate a Google Search from this menu.

1. From the Home screen, tap

➔

Google Settings

and select an on-screen option.

2. Tap one of the following options:

Google+

Apps with

Google+ Sign-in

Maps & Latitude

Location

, and

Ads

3. Follow the on-screen prompts to modify your Google

Settings.

Google +

Google+ makes messaging and sharing with your friends a

lot easier. You can set up Circles of friends, visit the Stream

to get updates from your Circles, use Messenger for fast

messaging with everyone in your Circles, or use Instant

Upload to automatically upload videos and photos to your

own private album on Google+. For more information, refer

to “Google +” on page 104.

Group Play

Group Play allows you to share pictures, music, and

documents in real-time with your friends. You can create a

group from your device or join other groups. You can also

play games with your friends.

1. From the Home screen, tap ➔

Group Play

2. The first time you access Group Play, read the

Disclaimer and tap

The Group Play main screen is displayed.

Creating a group

If you have media you want to share, create a group.

1. From the Group Play main screen, if you want to set a

group password, tap the

Set group password

checkbox.

2. Tap

Create group

3. If you selected the

Set group password

checkbox in

step 1, enter a group password at the

Set group

password

prompt, and tap

Mobile AP is enabled.

4. Tap one of the media items listed under the

Share and

play content

heading.

DRAFT

FOR INTERNAL USE ONLY

191

5. Tap the items you want to share to create a check

mark, then tap

Done

6. Have your friends sign onto Group Play from their

devices and they can view your media using you as a

Mobile AP.

7. Tap ➔

Info

for information on the device that is

hosting the Mobile AP.

8. Tap ➔

Help

for additional information.

Joining a group

If you want to see media from your friend’s phone, join a

group.

1. From the Group Play main screen, tap

Join group

2. Your phone scans for available groups for you to join.

3. Tap a group to join.

You will now be able to see your group’s shared media.

4. Tap ➔

Info

for information on the device that is

hosting the Mobile AP.

Hangouts

Hangouts is a free Windows and web-based application for

instant messaging offered by Google. Conversation logs are

automatically saved to a Chats area in your Gmail account.

This allows you to search a chat log and store them in your

Gmail accounts. For more information, refer to “Hangouts”

on page 104.

Internet

Open the web browser to start surfing the web. The browser

is fully optimized and comes with advanced functionality to

enhance the Internet browsing feature on your phone. For

more information, refer to “Browser” on page 158.

DRAFT

FOR INTERNAL USE ONLY

Applications 192

Local

Local is an application that uses Google Maps and your

location to help you find Restaurants, Cafes, Bars,

Attractions, and other businesses. You can also add your own

locations.

1. From the Home screen, tap ➔

Local

2. Tap on one of the business categories to search for a

particular business.

All of the business categories that are close to you will

be displayed.

3. Tap on a business that you want to see the details for.

4. The business details such as address, phone, website,

and location are displayed. You can also see reviews

from around the web and from Google users.

Lookout Security

Lookout Security™ provides mobile device-specific security

features that are coupled with a minimal performance hit.

Lookout Mobile Security provides key security options that

are unique to the mobile market. Along with the antivirus and

anti-malware tech, there's a lost and stolen phone locator

service, an application privacy adviser, and a backup service.

1. From the Home screen, tap ➔

Lookout Security

2. Follow the prompts to set up Lookout Security

functions.

DRAFT

FOR INTERNAL USE ONLY

193

Maps

Depending on your location, you can view basic, custom, and

satellite maps and local business information, including

locations, contact information, and driving directions. You

can also post public messages about a location and track

your friends.

Important!

Before using Google Maps you must have at least

an active data (3G) connection. The Maps

application does not cover every country or city.

Enabling a Location Source

Before you use Google Maps and find your location or search

for places of interest, you must enable a location source. To

enable the location source you must enable the wireless

network, or enable the GPS satellites.

1. From the Home screen, tap ➔

Settings

➔

Location services

2. Tap the

Use GPS satellites

field. A green check mark

will display next to the field.

Note:

Selecting

Use GPS satellites

allows you to locate places

of interest at the street-level. However, this also requires

a clear view of the sky and uses more battery power.

To receive better GPS signals, avoid using your device in the

following conditions:

•

inside a building or between buildings

•

in a tunnel or underground passage

•

in poor weather

•

around high-voltage or electromagnetic fields

•

in a vehicle with tinted windows

Using Maps

1. From the Home screen, tap ➔

Maps

A map will display with your location in the very center.

2. Follow the on-screen instructions to use the Maps

application.

DRAFT

FOR INTERNAL USE ONLY

Applications 194

Messages

The AT&T Messages app brings your texts, calls, and

voicemail messages together into a single conversation

thread and is accessible by phone or computer. For more

information, refer to “Messages App” on page 105.

Messaging

You can send and receive different types of messages. For

more information, refer to “Messaging” on page 92.

Messenger

Messenger allows you to bring groups of friends together into

a simple group conversation. When you get a new

conversation in Messenger, Google+ sends an update to your

phone. For more information, refer to “Messenger” on page

104.

Mobile Hotspot

This application allows you to share your phones’s mobile

data connection via USB or as a portable Wi-Fi hotspot. For

more information, refer to “Tethering & portable hotspot” on

page 114.

Mobile TV

Mobile TV is a subscription service that allows you to watch

your favorite TV shows using your handset.

Note:

This feature requires a paid subscription. See your AT&T

Customer Service Representative for more information.

1. From the Home screen, tap ➔

Mobile TV

Note:

The first time you use Mobile TV, you will need to

download the application from the Play Store. For more

information, refer to “Play Store” on page 204.

2. The Play Store displays the

Mobile TV

application. Tap

Update

3. Tap

Accept & download

4. Tap

Open

5. Read the

Terms and Conditions

and tap

Accept & Start

Trial

to continue or

Exit

to exit.

6. The Mobile TV main page displays. Follow the on-

screen instructions to watch TV.

DRAFT

FOR INTERNAL USE ONLY

195

Note:

Mobile TV will use a large amount of data and you are

responsible for all data charges. It is strongly

recommended that you upgrade to a large data plan in

addition to this purchase.

Music

Music is an application that can play music files. Music

supports files with extensions AAC, AAC+, eAAC+, MP3,

WMA, 3GP, MP4, and M4A. Launching Music allows you to

navigate through your music library, play songs, and create

playlists (music files bigger than 300 KB are displayed).

Playing Music

1. From the Home screen, tap ➔

Music

2. Tap a library category at the top of the screen (Songs,

Playlists, Albums, Artists, Music square, or Folders) to

view the available music files.

3. Scroll through the list of songs and tap an entry to

begin playback.

4. The following Music controls are available:

Pause the song.

Start the song after pausing.

Press and hold to rewind the song. Tap to go to

previous song.

Press and hold to fast-forward the song. Tap to

go to next song.

Volume control.

Volume control showing volume muted.

Plays the entire song list once.

Replays the current list when the list ends.

Repeats the currently playing song.

Shuffles the current list of songs randomly.

Songs play in order and are not shuffled.

Lists the current playlist songs.

Displays the current song in the player window.

Assign the current song as a Favorite.

Streams the current music file to another device

via Samsung Link.

DRAFT

FOR INTERNAL USE ONLY

Applications 196

Music Options

To access additional options, follow these steps:

1. While in Music, tap .

2. The follow options are available before you play music:

Note:

The following options may or may not appear depending

on whether or not music is actually playing. Also,

options will be different if the song you are listening to is

in a playlist.

•Add to playlist:

allows you to add the current music file to a

selected playlist.

• Via Bluetooth

: scans for devices and pairs with a Bluetooth

headset.

•Delete

: deletes the music file.

•Search

: allows you to search your device for a certain song.

•Settings

: allows you to change your Music settings. For more

information, refer to

“Music Settings”

on page 196.

•End

: allows you to end the Music app.

Music Settings

The Music Settings menu allows you to set preferences for

the Music app such as whether you want the music to play in

the background, sound effects, and how the music menu

displays.

1. From the Home screen, tap ➔

Music

2. Tap ➔

Settings

3. Select one of the following settings:

•SoundAlive

: set a type of equalization such as Normal, Pop,

Rock, Jazz, Dance, Classic, etc.

• Adapt sound

: allows you to set Adapt sound on when your are

listening with earphones to alert of incoming calls and

notifications.

• Play speed

: set the play speed anywhere between 0.5X and

2.0X using the slider.

• Music menu

: this menu allows you to select which categories

you want to display. Choices are: Albums, Artists, Genres,

Music square, Folders, Composers, Years, Most played,

Recently played, or Recently added. Tap each item that you

want to display in the Music menu.

DRAFT

FOR INTERNAL USE ONLY

197

• Music auto off

: when activated, music will automatically turn

off after a set interval.

•Lyrics

: when activated, displays lyrics when available.

• Smart volume

: automatically adjusts each track’s volume to an

equal level.

• Voice control

: allows you to use voice commands to control

the Music app.

Using Playlists

Playlists are used to assign songs to a list of preferred media

which can then be grouped into a list for later playback.

These Playlists can be created via either the handset’s Music

options menu or from within a 3rd party music application

(such as Windows Media Player) and then downloaded to the

handset.

Creating a Playlist

1. From the Home screen, tap ➔

Music

2. Tap the

Playlists

tab.

3. Tap ➔

Create playlist

4. Type a name for this playlist in the field and tap

Adding Music to a Playlist

To add files to the playlist:

1. From the Home screen, tap ➔

Music

2. Tap the

Playlists

tab.

3. Tap the playlist name in which to add music.

4. Tap (

Add music)

5. Tap a music file, or tap

Select all

to add all the music

tracks to this playlist then tap

Done

DRAFT

FOR INTERNAL USE ONLY

Applications 198

Removing Music from a Playlist

To remove music files from a playlist:

1. From the Home screen, tap ➔

Music

2. Tap the

Playlists

tab.

3. Tap the playlist name in which to delete music.

4. Tap ➔

Remove

5. Tap the checkbox to the left of each track you want to

remove from this playlist, or tap

Select all

to remove all

the music tracks from this playlist, then tap

Remove

Editing a Playlist

Besides adding and removing music files in a playlist, you

can also rename the playlist.

To edit a playlist:

1. From the Home screen, tap ➔

Music

2. Tap

Playlists

3. Tap ➔

Edit title

4. Tap a playlist name to edit.

5. Enter a new name for the playlist then tap

For information on downloading music for your phone, see

“Play Music” on page 204.

My Files

My Files allows you to manage your sounds, images, videos,

bluetooth files, Android files, and other memory card data in

one convenient location.

1. From the Home screen, tap ➔

My Files

➔

All

files

2. Tap

Device storage

to see the contents of your internal

SD card.

3. The following folders may display:

•Alarms

: this folder contains any alarm files you may have.

•Android

: the Android folder stores files that are used in Android

applications.

•Application

: this folder contains app info for S Memo.

• Bluetooth

: this folder stores files sent via a Bluetooth device.

•DCIM

: this is the default location for pictures and videos taken

by the device. Tap

DCIM

➔

Camera

to view the picture or

video files. For more information, refer to

“Viewing Pictures”

on page 89. Also, see

“Viewing Videos”

on page 90.

• Download

: this folder contains downloads you have made.

•Movies

: this folder contains your Video and Movie files.

•Music

: this folder contains your Music files.

DRAFT

FOR INTERNAL USE ONLY

199

• Notifications

: this folder contains all of the notifications you

have received.

•Pictures

: this folder contains your photos.

•Podcasts

: this folder contains all of your podcasts.

•Ringtones

: this folder contains any ringtones you have

purchased.

•S Memo

: this folder contains all the S Memos you have written.

Note:

Different folders may appear depending on how your

phone is configured.

4. If you have an external SD card inserted, tap

memory card

to see the contents of your external SD

card (memory card).

myAT&T

The myAT&T application allows you to manage your own

AT&T account. You can review and pay your bill, check

minutes and data usage, upgrade to a new device, or change

your rate plan.

Note:

The first time you use myAT&T, you will need to

download the updated application from the Play Store.

When the Play Store page displays, tap

Update

. For more

information, refer to “Play Store” on page 204.

Initial Setup

1. From the Home screen, tap ➔

myAT&T

2. Sign into your Google Account. If you haven’t set up an

account, see “Creating a New Google Account” on

page 14.

3. After signing into your Google Account, the Play Store

displays the

myAT&T

application. Tap the application.

4. Tap

Update

5. Follow the on-screen instructions.

DRAFT

FOR INTERNAL USE ONLY

Applications 200

Using myAT&T

1. From the Home screen, tap ➔

myAT&T

The

myAT&T

page is displayed.

2. Read the Terms and Conditions and tap

continue.

3. Enter your

User ID

and

Password

using the on-screen

keypad, then tap

4. Follow the on-screen instructions.

Navigation

Navigation is an internet-connected GPS navigation system

with voice guidance. You can type or speak your destination.

Note:

For voice-guided navigation, you need to install text-to-

speech support from the Play Store.

To receive better GPS signals, avoid using your device in the

following conditions:

•

inside a building or between buildings

•

in a tunnel or underground passage

•

in poor weather

•

around high-voltage or electromagnetic fields

•

in a vehicle with tinted windows

Launching Navigation

1. From the Home screen, tap ➔

Navigation

2. Read the Navigation information page and tap

to continue or

Don’t accept

to exit.

3. Select one of the following options:

• Speak destination

: allows you to speak your destination.

DRAFT

FOR INTERNAL USE ONLY

201

•Type destination

: allows you to use the keypad to enter your

destination.

•Go home

: takes you to your home address. The first time you

are prompted to enter it.

•Map

: takes you to the map location of your present location

using GPS.

• Recent Destinations

: allows you to access information on

previous destinations you have used. This option only appears

after you have entered one or more destinations.

4. Follow the on-screen instructions.

Obtaining Driving Directions

Your phone’s built-in GPS hardware allows you to get real-

time driving directions to selected locations or

establishments based on your current location.

Using a Physical Address

1. From the Home screen, tap ➔

Navigation

2. Tap either

Speak Destination

Type Destination

3. If typing in the address, enter the address, City, and

State using the keypad. As you type, possible

addresses will be displayed. Tap on one when you see

the address you want.

The route will be displayed.

4. If speaking the address, the Voice guidance screen is

displayed. For voice-guided navigation you need to

install text-to-speech support from the Play Store. Tap

Install

to install the application or tap

Skip

to exit.

Note:

You will need to be signed on to your Google account

before downloading applications from the Play Store. For

more information, refer to “Creating a New Google

Account” on page 14.

DRAFT

FOR INTERNAL USE ONLY

Applications 202

5. As you drive the route display will be updated and you

will receive voice-guided navigation directions.

6. Tap for additional options.

Paper Artist

The Paper Artist application allows you to draw new images

or import images from your Gallary and change them.

Note:

This application is not preloaded on your phone.

1. From the Home screen, tap ➔

Paper Artist

. A

pop-up displays, prompting you to download the app.

2. To download Paper Artist, tap

Phone

The Phone application allows you to access the dialer

keypad, call logs, and favorites. For more information, refer

to “Call Functions” on page 50.

Photo Suggest

Photo Suggest allows you to view photos of places of interest

near your location.



From the Home screen, tap ➔

Photo Suggest

. A map appears with stacks of

available images of places of interest.

Play Books

With Google Play Books, you can find more than 3 million

free e-books and hundreds of thousands more to buy in the

eBookstore.

1. From the Home screen, tap ➔

Play Books

2. Log on to your Google account. For more information,

refer to “Creating a New Google Account” on page 14.

3. Follow the on-screen instructions for using the Play

Books application.

DRAFT

FOR INTERNAL USE ONLY

203

Play Magazines

With Google Play Magazines, you can subscribe to your

favorite magazines and have them available to read on your

phone at any time or any place.

1. From the Home screen, tap ➔

Play Magazines

2. Log on to your Google account if you have not already

done so. For more information, refer to “Creating a

New Google Account” on page 14.

3. At the Welcome! display, tap the shop icon to

browse the full catalog.

4. Read the Google Play Terms of Service and tap

5. Sweep the screen to the left or right to view

Categories, Featured, Top Selling, and New Arrivals.

6. Tap a magazine to see more information and

subscribe.

7. Follow the on-screen instructions to subscribe to a

magazine.

Play Movies & TV

With Google Play Movies & TV, you can rent thousands of

different movies and television shows. You can watch

instantly, or download your movie or show for offline viewing

at a later time.

1. From the Home screen, tap

➔

Play Movies & TV

2. Log on to your Google account if you have not already

done so.

3. Following the on-screen instructions for renting and

viewing movies and TV shows.

4. Tap the

MOVIES

tab to view movies you can rent.

5. Tap the

TV SHOWS

tab to view shows you can rent.

6. Tap the

PERSONAL VIDEOS

tab to view movies you have

on your phone or memory card.

7. Tap for additional options.

DRAFT

FOR INTERNAL USE ONLY

Applications 204

Play Music

With Google Play Music, you can play music that you have

added to your music file as well as any music you copied

from your PC. While offline, you can listen to music you have

copied from your PC.

1. From the Home screen, tap ➔

Play Music

All music on your device and external SD card is

displayed including Music folders that may contain

multiple songs.

2. Tap a song to start playback.

3. From the main Play Music screen, you can tap any of

the following tabs for a more detailed listing of songs:

Playlists, Recent, Artists, Albums, Songs, and Genres.

4. Tap for the following options:

•Shuffle all

: allows you to play all of your music in a shuffled

order.

•Settings

: allows you to view Open source licenses and the

music version for the Play Music application.

•Help

: allows you to view a help file on the Google Support

website.

Play Store

Play Store provides access to downloadable applications and

games to install on your phone. Play Store also allows you to

provide feedback and comments about an application, or flag

an application that might be incompatible with your phone.

Before using the Play Store you must have a Google Account.

For more information, refer to “Using Gmail” on page 102.

1. From the main Home screen, tap

Play Store

2. Sign in to your Google account.

3. The first time you sign in, the Play Store Terms of

Service will be displayed. Tap

to continue or

Decline

to exit.

4. Tap

Apps

Games

, or

AT&T

to download or purchase

games or applications. You can also download updates

to existing applications.

5. Follow on the on-screen instructions.

DRAFT

FOR INTERNAL USE ONLY

205

POLARIS Office 5

POLARIS® Office Mobile for Android is a Microsoft Office

compatible office suite. This application provides a central

place for managing your documents online or offline. The

application can also open Adobe PDF (Portable Document

Format) files.

1. From the Home screen, tap ➔

POLORIS Office 5

2. Enter your Email information (if desired) and touch

to complete the process.

– or –

Touch

Skip

to ignore this registration.

The main POLARIS Office 5 screen displays.

3. Follow the on-screen instructions to use POLARIS

Office 5.

S Memo

The S Memo application allows you to create memos using

the keypad, your finger, or both. You can add images, voice

recordings, and text all in one place.

Creating a New Memo

1. From the Home screen, tap ➔

S Memo

2. Tap an existing Memo to open it then tap the screen to

enter edit mode.

– or –

Tap to start a new memo in text mode with the

keypad displayed or tap to start a new memo in

drawing mode using your finger or a compatible

on-screen writing tool. You can change back and forth

in a memo to add text with the keypad and the pen.

DRAFT

FOR INTERNAL USE ONLY

Applications 206

The icons that you see displayed on the screen are described

in the following table: 3. Tap to access the following options:

Note:

Depending on whether you have saved the memo, are in

keypad mode, or in handwriting mode, the options will

appear differently. The following is a list of the options

you may see.

Changes the view mode.

Allows you to add free-format drawing.

Displays the keypad to you can add text.

Toolbar

Show/Hide

Add Page

Writing area

Secondary

Keyboard

Toolbar

Eraser tool allows you to erase marks and drawings.

Undo the last action.

Redo the last action that was undone.

Make a voice recording to add to the memo. This option

is not available in free-format drawing mode.

Hide the secondary toolbar.

Show the secondary toolbar.

Provides access to a quick selection bar. Choose from:

Take picture, Images, Clipboard, Maps, and Clip art.

These elements can be used within the memo.

Add an additional page to the memo.

DRAFT

FOR INTERNAL USE ONLY

207

•Share via

: allows you to share your memo as either an Image

file (.jpg), a PDF file (.pdf), Plain text, or S Memo file (.snb) via

Group Play, Wi-Fi Direct, Bluetooth, ChatON, Flipboard, Picasa,

Google+, Messaging, AT&T Locker, Gmail, or Email.

•Delete

: allows you to delete the S Memo.

•Export

: allows you to save the memo to your Gallery as either a

JPG or as a PDF.

•Save as

: allows you to save the memo with a different name.

•Add tag

: allows you to set tags to add in searches.

•Add to Favorites

: allows you to tag the current memo as a

favorite.

• Change background

: allows you to set the background for

your memo. Tap the background that you want, then tap .

• Create event

: allows you to link the memo to your Calendar

events.

•Set as

: allows you to set a memo as a contact icon, Home

screen wallpaper, or Lock screen wallpaper.

•Print

: allows you to print the screen or web page on a

Samsung printer using Wi-Fi.

When you are finished creating your memo, tap

Save

on the

top menu bar.

S Translator

With the S Translator you can easily translate words and

phrases into many different languages.

1. Sign in with your Samsung Account if you have not

already done so. For more information, refer to

“Creating a Samsung Account” on page 14.

2. From the Home screen, tap ➔

S Translator

3. At the S Translator screen, tap the top language bar

and enter your language.

4. Tap the language bar at the bottom of the screen to

select the language that you would like to translate to.

5. Enter text into the upper box and tap .

It will be translated into the language of the upper box.

– or –

Enter text into the lower box and tap .

It will be translated into the language of the lower box.

6. Tap either of the

Speak

buttons at the bottom of the

screen to translate using either language by using your

voice. The translation will appear automatically in the

appropriate box.

DRAFT

FOR INTERNAL USE ONLY

Applications 208

7. Tap for additional options.

S Voice

With the S Voice application you can use your voice to

perform operations that you would normally have to do by

hand such as dialing a phone number, texting a message,

playing music, etc.

1. From the Home screen, tap ➔

S Voice

2. Read the Samsung Disclaimer then tap

Confirm

continue.

3. Read the Vlingo Terms of Service then tap

Agree

continue.

4. Read the information on the

About S Voice

screen, then

tap

5. Read the information on the

Say what you want

screen,

then tap

6. Read the information on the

Wake up S Voice

screen,

then tap

7. Read the information on the

Edit what you said

screen,

then tap

8. Read the information on the

Help

screen, then tap

Finish

9. At the S Voice screen, tap or say “Hi Galaxy”

to wake up S voice.

10. Speak into the phone and follow the on-screen

instructions.

11. Tap for additional options.

Samsung Apps

With Samsung Apps, you can download hundred of

applications from a variety of categories.

1. Sign on to your Samsung account if you have not

already done so.

2. From the Home screen, tap ➔

Samsung Apps

3. Tap an application that you would like, then tap

Get

4. Tap

Accept and download

The application is downloaded to your device. You can

find the app icon in your app menu.

5. Tap ➔

Help and notices

for additional information.

DRAFT

FOR INTERNAL USE ONLY

209

Samsung Hub

Samsung Hub is Samsung’s integrated store for media

content that offers a comprehensive and consistent media

service experience.

Samsung Hub makes it easy to find, sample, and purchase

movies, TV shows, books, games, and music, in one user-

friendly location. With hundreds of titles available,

entertaining your family on-the-go has never been easier.

You can rent or purchase your favorite content and watch

from any location. Samsung Hub is your gateway to mobile

entertainment.

You must have an active Samsung Account to purchase and

rent content via Samsung Hub.

Note:

Samsung Hub usage is based on service availability.

Important!

You must be using an active Wi-Fi/4G/LTE

connection to preview and download a media file.

The internal memory acts as a storage location for

your downloaded rental or purchase.

Important!

The Samsung account manages the access

information (username/password) to several

applications, such as Samsung Link, Chat On, and

Samsung Hub.

Creating a New Samsung Hub Account

Before you can rent or buy media, you must first create an

account. Enter the required information.

1. Confirm you have already logged in to your Samsung

account.

2. From the Home screen, tap ➔

Samsung Hub

3. When prompted to connect via mobile networks, select

either

Cancel

Connect

4. If notified your Samsung account is not yet active or

verified, tap

. You must be signed in to your

Samsung account to use the application’s various

features.

Tip:

In some cases it might be necessary to sign in to your

Samsung account via the application. Tap and then

select

DRAFT

FOR INTERNAL USE ONLY

Applications 210

Note:

Your Samsung Hub account is managed by the Samsung

account application. This application manages your user

profile information.

5. Tap ➔

Help

for additional information.

Using Samsung Hub

The main Samsung Hub screen provides an overview of all

the available categories on one page such as: Music, Video,

Books, and Games. The overview page also displays recently

added media that you can rent or purchase.

1. From the Home screen, tap ➔

Samsung Hub

•

The Overview screen (landing page) displays an main access

for all available categories and recently available content for

purchase or rental.

2. Scroll across the screen to select from the following

available pages:

•MUSIC

: displays featured Music content available for purchase/

stream from the Music store & Radio. This page also allows you

to search for new content, or navigate directly to the Music

store page by clicking on the Music link at the top of the page.

•VIDEO

: displays featured film and TV content available for

purchase/rent from the video store. This page also allows you

to search for new content, or navigate directly to the Movie &

TV store page by clicking the Video link at the top of the page.

• BOOKS

: displays featured Book content available for purchase

from the Book store. This page also allows you to search for

new content, or navigate directly to the Book store page by

clicking the Books link at the top of the page.

• GAMES

: displays featured Game content available from the

Game store. This page also allows you to search for new

content, or navigate directly to the Game store page by clicking

the Games link a the top of the page.

3. To purchase or view featured content in more detail,

tap on any content (Thumbnail or text) to navigate to

the product detail page.

4. Depending on the content, you can either purchase,

rent, or stream the content directly from the product

detail page.

5. Choose a payment method, then follow the on-screen

instructions.

DRAFT

FOR INTERNAL USE ONLY

211

Samsung Hub Notices

•

Any media item (Media Content) may be rented or purchased after

you create an account in Samsung Hub.

•

Media Content that is purchased and downloaded may be viewed

concurrently on up to five (5) devices with Samsung Hub (or “the

service”) that are also registered to the same account.

•

You may remove a device from your account no more than once

every 90 days.

•

You may remove Media Content from a device as many times as

you’d like. You will have the ability to re-download the Media

Content later subject to content re-download availability and

content provider permissions.

•

You may need network coverage to access Media Content you

have acquired through the Service.

•

You can use 3G, 4G, or Wi-Fi connectivity to download Media

Content.

•

Unlike purchased Media Content, rented Media Content will be

viewable on only 1 device in your account at a time.

•

Media Content is downloaded and saved to your authorized

device's SD card. No SD Card included out of box.

•

Your Media Content may pause/stop or not download in networks

where there is a weak signal.

•

You may begin watching downloaded Media Content as soon as a)

license acquisition has occurred and b) sufficient amount of the

Media Content has been buffered.

•

You must finish watching Media Content within the time limit set

out for each piece of content (which may be as short as 24

consecutive hours).

–

Stopping, pausing or restarting rented Media Content does not

extend the available viewing time.

–

In no event will rented Media Content be available for a period

of more than thirty (30) days (or shorter on a title-by-title basis)

after the Media Content has been rented (e.g., if you begin

viewing rented Media Content on the 29th day after the rental

transaction, but do not finish viewing the entire title, that rented

Media Content may not be available for the entire twenty-four

(24) consecutive hour period if such period would extend the

viewable time beyond the thirty (30) day rental window).

•

Unless otherwise restricted by the Content Providers, you can

download Media Content to your TV using HDMI connections;

otherwise, you cannot play Media Content downloaded from your

mobile device output.

DRAFT

FOR INTERNAL USE ONLY

Applications 212

Samsung Link

With the Samsung Link app, you can share and play content

across smart devices anytime and anywhere.

This application wirelessly synchronizes your Samsung

device with your TV, streams content, and even keeps tabs

on who calls or sends text messages with real-time,

on-screen monitoring. Samsung Link makes staying

connected easy.

Samsung Link allows users to share their in-device media

content with other external devices using DLNA certified™

(Digital Living Network Alliance) Devices. These external

devices must also be DLNA-compliant. Wi-Fi capability can

be provided to TVs via a digital multimedia streamer.

Important!

You must first connect both of your communicating

devices to the same Wi-Fi and be using an

active/registered Samsung account prior to using

this application. For more information, refer to “Wi-

Fi Settings” on page 108. For more information,

refer to “Creating a Samsung Account” on page

14.

1. From the Home screen, tap ➔

Samsung Link

2. Tap

to sign into your Samsung Account if you

have not already done so.

3. If prompted, read the on-screen message about

network charges and tap

to continue and return to

the main Samsung Link screen.

4. Tap

Start

and follow the on-screen prompts.

5. Scroll across the application screen to view either

MY RECENT CONTENT

DEVICES & STORAGE

6. The DEVICES & STORAGE screen contains two separate

streaming media options:

•Registered storage

: allows you to receive and playback media

stored externally (server, laptop, etc.) directly on your device by

allowing you to add a Web storage service for streaming

content.

• Registered devices

: allows you to stream/share selected

multimedia content from your device to DLNA compliant device

connected to the same Wireless Access Point.

DRAFT

FOR INTERNAL USE ONLY

213

Configuring Samsung Link Settings

Samsung Link must first be configured prior to its initial use.

You must setup parameters such as connected Wi-Fi, Items

to share, source server address, and external device

acceptance rights.

1. From the Home screen, tap ➔

Samsung Link

➔

DEVICES & STORAGE tab

2. Tap

➔

Settings

and configure the following

settings as desired:

•Registered storage

: allows you to add a Web storage location.

Without a storage service/location added, you will not be able

to use Samsung Link.

• My device

: displays your device name as it is used with

Samsung Link. Tap to change the device name.

•Save to

: allows you to save your media to your internal phone

memory or to an SD card.

• Auto upload

: allows you to enable automatic upload of images

from your device to those storage locations specified within the

Web storage list.

Touch and slide the slider to the right to turn it on

•Video optimization

: allows you to setup the video quality for

streamed video content.

Touch and slide the slider to the right to

turn it on .

• Password lock

: allows you to restrict access to Samsung Link

by requiring a user enter the currently active and associated

Samsung account password.

Touch and slide the slider to the

right to turn it on .

• My account

: displays Samsung account information.

•Customer support

: allows you to contact the Samsung Link

team via a new email from an available email account.

• About this service

: displays application information

DRAFT

FOR INTERNAL USE ONLY

Applications 214

Sharing Media via Samsung Link to a Target

Device

Important!

Make sure all communicating devices are

connected to the same Wi-Fi.

1. Launch AllShare Play/Samsung Link on the target

device (such as an Internet TV, Samsung Tablet, etc.).

2. From the Home screen, tap ➔

Samsung Link

Note:

You must be signed in to your Samsung Account before

you can use this feature.

3. Tap your device name from the

Registered devices

area.

4. Tap an available category tab (Pictures, Music, Movies,

Files, or Info) and select a file.

•

A file with in the upper-left indicates it is stored remotely

on a Web storage location. Selecting this media causes your

device to access the file currently stored on your services’

servers.

5. Tap an available on-screen file, image, or video to

place a green check mark alongside it.

6. Tap (

Stream to connected devices

) and select an

available target device to begin streaming.

7. On a target device (ex: Internet TV) select the

on-screen

Allow

button to continue.

Note:

At this stage your device is requesting access to share

media with the external source.

8. Confirm (

Samsung Link Controller enabled

)

appears in the Notification area at the top of the device

to indicate you are using your device as the media

source.

Settings

This widget navigates to the sound and phone settings for

your phone. It includes such settings as: display, security,

memory, and any extra settings associated with your phone.

For more information, refer to “Changing Your Settings” on

page 107.

DRAFT

FOR INTERNAL USE ONLY

215

Story Album

With Story Album, you can create a digital Album of your

story in media. Special moments will be on a timeline, and if

you wish, you can have your album published as a hard copy.

1. From the Home screen, tap ➔

Story Album

2. Read the introductory information and tap

3. Tap

Start

to begin your Story Album.

4. Follow the on-screen instructions.

5. Tap ➔

Help

for additional information.

TripAdvisor

With the TripAdvisor, you can plan and have your perfect trip.

With over 75 million reviews and opinions by travelers, it is

easy to find the best hotels, restaurants, and fun things to do.

1. From the Home screen, tap ➔

TripAdvisor

2. Sign in with your Samsung Account if you have not

already done so.

3. Follow the on-screen instructions to use TripAdvisor.

4. Tap for additional options.

Video

The Video application plays video files stored on your phone

or microSD card.

1. Tap ➔

Video

All videos that you have on your phone and memory

card will be displayed.

2. Tap the video that you want to play.

The video will begin to play.

3. The following video controls are available:

Pause the video.

Start the video after being paused.

Press and hold to rewind the video. Tap to

go to previous video.

Press and hold to fast-forward the video.

Tap to go to next video.

Volume control.

DRAFT

FOR INTERNAL USE ONLY

Applications 216

Note:

The screen view icons are a three-way toggle. The icon

that is displayed, is the mode that will appear after the

icon is tapped.

For more information on downloading videos for your phone,

see “Samsung Hub” on page 209 and see “PC Connections”

on page 175.

Video Editor

The Video Editor allows you to cut, merge, and enhance your

videos with title frames and transitions.

Note:

This application is not preloaded on your phone.

1. From the Home screen, tap ➔

Video Editor

A pop-up displays, prompting you to download the app.

2. To download Video Editor, tap

Download

PIP (Picture In Picture) view. T

he video will

be played in a small window so you can use

your phone for other purposes while watching

the video. Double-tap screen to return to

previous size.

Original size view. T

he video will be played in

its original size.

Full-screen in ratio view. T

he video is

enlarged as much as possible without

becoming distorted.

Full-screen view. T

he entire screen is used,

which may cause some minor distortion.

Streams the video to another device via

Samsung Link.

DRAFT

FOR INTERNAL USE ONLY

217

Voice Recorder

The Voice Recorder allows you to record an audio file up to

one minute long and then immediately share it using Wi-Fi

Direct, Messaging, Gmail, or via Bluetooth. Recording time

will vary based on the available memory within the phone.

1. From the Home screen, tap ➔

Voice Recorder

2. To start recording, tap

Record

and speak into the

microphone.

3. During the recording process you can either tap

Stop

to stop and save the recording or

Pause

temporarily halt the recording. After pausing, tap

Record

to resume recording. Once the audio

recording has stopped, the message is automatically

saved. Tap

Cancel

to cancel the recording

without saving.

4. Tap

List

to display a list of all your voice

recordings. Tap a voice recording to play it.

5. Tap

to display the following options:

•Share via

: allows you to share your recording using Bluetooth,

Email, Gmail, Messaging, or Wi-Fi Direct.

•Delete

: allows you to delete 1 or more voice recordings. Tap

the recordings to delete and tap

Delete

• Settings

: the following settings are available:

–

Storage

: allows you to choose where your recordings will be

saved. Select between Phone or memory card.

–

Recording quality

: allows you to set the recording quality to

High or Normal.

–

Limit for MMS

: allows you to select On or Off. If you Limit for

MMS by selecting On, you will be assured that the recording can

be sent in a message.

–

Contextual filename

: (requires GPS tagging) allows you to

adjust the filename based on contextual information such as

your current GPS location.

–

Default name

: allows you to choose the name prefix for your

recordings. For example, if your Default name is Voice, your

recordings would be named Voice 001, Voice 002, Voice 003,

etc.

–

Noise reduction

: allows you to activate/deactivate background

noise suppression.

DRAFT

FOR INTERNAL USE ONLY

Applications 218

–

Recording volume

: allows you to assign the ambient noise

quality of your current location so the device can better detect

audio. Choose from High or Low.

–

Channel

: allows you to assign recording mode to either Mono

or Stereo.

–

Skip interval

: allows you to assign a skip length.

•End

: allows you to close the application.

Voice Search

The Google Voice Search application allows you to search the

web using only your voice.

1. From the Home screen, tap ➔

Voice Search

2. When the Google Voice Search screen displays, speak

the word or words that you would like to search for on

the internet.

3. If the timer expires and the mic icon changes from red

to gray, tap the mic icon and speak the word or words

that you would like to search for on the internet.

Results are displayed on your phone.

4. The following options are available at the bottom of

your screen:

•

Web

: After selecting a different option, tap Web to return to the

original search results.

•

Images

: Displays images for your search.

•

Places

: Displays places and businesses in your local area

pertaining to your search.

•

: After tapping MORE, sweep your screen to the left to

see additional options such as News, Shopping, Videos, Blogs,

Discussions, and Books.

• Phone

: Displays a phone number if applicable.

DRAFT

FOR INTERNAL USE ONLY

219

WatchON

With the WatchON application, you can use your phone as a

remote control for your TV.

Important!

Before initiating use, verify you have an active

Internet connection available (either mobile

network or Wi-Fi connection).

Note:

Before beginning your initial WatchON application setup,

confirm your TV is turned off.

Initial Configuration

1. Sign into your Samsung account.

2. From the Home screen, tap ➔

WatchON

Note:

If you are not connected to an active Wi-Fi, you may be

prompted to continue the set up process via a mobile

network. Click

Connect

to proceed.

3. Select your desired country for your TV Guide’s source

listing and tap

4. Enter your current zip code and tap

Done

. This zip code

must correspond to the location of your desired TV and

set top box.

5. From the

Find your TV service

screen, select a service

provider from the available channel listing.

6. From the

Choose your TV Brand

screen, tap your TV’s

manufacturer name.

•

If you have a brand of TV not listed or you are using a projector,

select from one of the following two options. Choose from

either

Other TV Brands

I Have a Projector

7. Aim your device at the TV and tap (

Power

) to

confirm the set up process completed successfully and

the correct TV IR codes were selected.

Note:

The process of the initial TV activation can take up to 10

seconds. Please do not press the button again.

8. If the TV turned on, tap

Yes

– or –

If the TV did not turn on after tapping (

Power

) and

waiting 10 seconds, tap

Retry

DRAFT

FOR INTERNAL USE ONLY

Applications 220

9. From the

Choose Your TV Tuner

screen, select the entry

that corresponds to your current channel control

method:

• Cable/Satellite/STB/PVR/DVR

: selected when changing

channels is done via a receiver box. Channels are not changed

via the TV remote but rather through the receiver/box.

• My xxx TV

: selected when a signal is fed directly into the TV

and no box is used. Channels are changed directly on the TV by

using the TV remote and not a box’s remote.

Note:

Try matching your current channel selection method.

10. Select the Satellite Box Brand from the available list.

For example, DirectTV®.

•

If your brand does not appear in the list, tap

Other Satellite

Box Brands

and follow the on-screen instructions.

Important!

You must configure your set top box for IR

communication with your device. If you do not

select

More Info..

below and follow the on-screen

instructions you may not be able to properly use

the application.

11. When prompted to Enable IR, tap

More Info..

to learn

how to configure your set top box to receive and

respond to IR controls.

12. Only after completing the IR setup process and

programming your box, tap .

Note:

This IR programming of your set top box is a one-time

process and once successful should not need to be

repeated.

13. If prompted to personalize your experience, follow the

on-screen instructions.

DRAFT

FOR INTERNAL USE ONLY

221

Using WatchON

To change channels:

1. Sign into your Samsung account.

2. From the Home screen, tap ➔

WatchON

3. From the top of the main screen, tap (

Remote

Control

). This launches an on-screen set of remote

control tabs. Choose from one of the following:

•Easy remote

: provides the most common used control

features. Scroll down to view additional functions.

• [Set top box]

: displays customized control specific to your

configured set top box. Ex: satellite dish remote control

functions.

•TV

: provides access to control functions specific to your TV.

4. From the top of the main screen tap (

Select Room

)

to choose from different receivers/boxes in different

rooms. (Example: Living Room box, Bedroom box, etc.).

5. Tap to return to the main menu.

Locating your favorite programming:

1. Sign into your Samsung account.

2. From the Home screen, tap ➔

WatchON

3. From the main screen Tap (

Combined View

) to

reveal available media categories.

4. Select an available category.

– or –

Tap

Guide

to display on your TV an on-screen listing of

available set top box shows.

For additional information on the WatchON application,

tap and then select

Help

DRAFT

FOR INTERNAL USE ONLY

Applications 222

WatchOn Settings

1. From the Home screen, tap ➔

WatchON

2. Tap and then select an available on-screen option:

• Change Room

: allows you to select a previously configured

room.

•Settings

: provides access to the Samsung WatchOn settings

menu.

•Help

: displays on-screen help information.

•About

: displays on-screen information about the application.

Personalize WatchON

You can personalize your application to do things such as

show content only from your selected media categories, or

add an additional room’s set top box.

To configure your Just for you settings:

The Just for you option displays available content matching

your activated media categories. These categories can be

configured during your initial set up or at any later time.

1. Sign into your Samsung account.

2. From the Home screen, tap ➔

WatchON

3. From the main screen Tap (

Combined View

) ➔

Just for you

4. From the

On TV

tab, tap and then select

Settings

5. Access parameters such as

Basic info

Genres

and

Sports

to then configure and enable those parameters

you would like to show in the Just for you tab.

DRAFT

FOR INTERNAL USE ONLY

223

To add a new room:

Your device can be used to control boxes/receivers from

several rooms. You could go from controlling your set top box

in your living room and then move into your bedroom to do

the same.

1. Sign into your Samsung account.

2. From the Home screen, tap ➔

WatchON

3. From the

On TV

tab, tap

➔

Settings

➔

Add room

4. Name the new room and tap

5. Enter your current zip code and tap

Done

. This zip code

must correspond to the location of your desired TV and

set top box.

6. Follow steps 4-10 starting on page 219 to complete

the process.

YouTube

YouTube™ is a video sharing website on which users can

upload and share videos. The site is used to display a wide

variety of user-generated video content, including movie

clips, TV clips, and music videos, as well as video content

such as video blogging, informational shorts and other

original videos.

Note:

YouTube is a data-intensive feature. It is recommended

that you upgrade to a large data plan to avoid additional

data charges.

1. From the Home screen, tap ➔

YouTube

2. At the You Tube introduction screen, tap

3. Tap the search field to search for specific videos,

scroll down to browse through the main page

thumbnails, or scroll to the bottom to explore additional

options.

4. To view a video, tap an available preview thumbnail or

tap the title link.

To watch a high quality video:



Tap

➔

Settings

➔

General

➔

High quality on

mobile

DRAFT

FOR INTERNAL USE ONLY

Applications 224

To configure YouTube Settings:



Tap

➔

Settings

and configure the following

parameters:

•General

–

High quality on mobile

, when enabled, allows you to start all

videos in high quality mode while you are connected to a mobile

network.

–

Caption font size

allows you to set the font size used by on-

screen captions. Choose from: Small, Medium, Large, or Huge.

–

Uploads

specifies network preferences for uploads.

–

Content localization

allows you to prioritize channels and

videos from a specific country or region.

–

Improve YouTube

allows you to anonymously send YouTube

information to help improve the application.

• Channel Feed Content

–

Sets the content that you want to appear within your channel

feed. All activity is the default option.

•Search

–

Clear search history

allows you to clear previous YouTube

searches from showing up in the YouTube search box.

–

Never remember history

allows you to force YouTube to never

store search history information.

–

SafeSearch filtering

allows you to configure block settings for

videos containing restricted content. This option blocks these

videos from appearing within your search results. Choose from:

Don’t filter, Moderate, or Strict blocking.

• Preloading

–

Preload subscriptions

allows you to preload (or go get videos

while on Wi-Fi and charging) your subscription videos.

–

Preload watch later

allows you to enable the preload function

on selected videos so you can watch them later. Read the data

usage information and tap

to accept the terms.

Note:

Preloading YouTube videos will use some of your

device’s storage space and may result in additional

charges if your Wi-Fi plan is not unlimited.

DRAFT

FOR INTERNAL USE ONLY

225

• About

–

Help

: provides answers to most YouTube questions.

–

Feedback

: allows you to provide user feedback to YouTube.

–

Google Mobile Terms of Service

: displays the Google Mobile

–

YouTube Terms of Service

: displays the YouTube terms of

Service.

–

Google Mobile Privacy Policy

: displays the Google Mobile

–

YouTube Privacy Policy

: displays the YouTube Privacy Policy.

–

Open source licenses

: displays the Open source licenses

–

App version

: displays the software version for the current

YouTube application.

Note:

It is not necessary to sign in to the YouTube site to view

content. However, if you wish to sign in to access

additional options, access the page via the Web browser

and tap

at the top right corner, enter your

YouTube or Google username and password, and tap

YPmobile

The Yellowpages Mobile application provides quick and ready

access to businesses, map locations, and storage of your

favorite searches. This application allows you to tap into local

businesses, locations, and events, connecting you to your

search in real-time.

Note:

The first time you use YP, you will need to download the

updated application from the Play Store. When the Play

Store page displays, tap

Update

Install

then follow the

on-screen instructions. For more information, refer to

“Play Store” on page 204.

1. From the Home screen, tap ➔

YPmobile

2. Sign on to your Google account if you have not already

done so. For more information, refer to “Creating a

New Google Account” on page 14.

3. Read the End-User License Agreement (EULA) and tap

to continue.

4. Your location is found using GPS. Tap

to allow

YPmobile to use your current location.

5. Tap the

Find a business nearby!

field.

DRAFT

FOR INTERNAL USE ONLY

Applications 226

6. Enter information in the

What:

and

Near:

fields and tap

7. Results will be displayed.

8. Tap

(Map)

to see the locations marked with pins

on the map.

9. Pinch the map screen inwards to zoom out or pinch it

outwards to zoom in.

10. Tap a pin to read information about the location.

11. Tap

to display additional options.

DRAFT

FOR INTERNAL USE ONLY

227

Section 11: Health and Safety Information

This device is capable of operating in Wi-Fi

™

mode in the

2.4 and 5 GHz bands. The FCC requires that devices

operating within 5.15-5.25 GHz may only be used indoors,

not outside, in order to avoid interference with Mobile

Satellite Services (MSS). Therefore, this device is restricted

from being used outdoors when operating in frequencies

between 5.15-5.25 GHz.

This section outlines the safety precautions associated with

using your phone. The terms “mobile device” or “cell phone”

are used in this section to refer to your phone.

Read this

information before using your mobile device

Exposure to Radio Frequency (RF)

Signals

The U.S. Food and Drug Administration (FDA) has published

information for consumers relating to Radio Frequency (RF)

exposure from wireless phones. The FDA publication

includes the following information:

Do cell phones pose a health hazard?

Many people are concerned that cell phone radiation will

cause cancer or other serious health hazards. The weight of

scientific evidence has not linked cell phones with any health

problems.

Cell phones emit low levels of Radio Frequency (RF) energy.

Over the past 15 years, scientists have conducted hundreds

of studies looking at the biological effects of the radio

frequency energy emitted by cell phones. While some

researchers have reported biological changes associated

with RF energy, these studies have failed to be replicated.

The majority of studies published have failed to show an

association between exposure to radio frequency from a cell

phone and health problems.

The low levels of RF cell phones emit while in use are in the

microwave frequency range. They also emit RF at

substantially reduced time intervals when in the stand-by

mode. Whereas high levels of RF can produce health effects

(by heating tissue), exposure to low level RF that does not

produce heating effects causes no known adverse health

effects.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 228

The biological effects of radio frequency energy should not

be confused with the effects from other types of

electromagnetic energy.

Very high levels of electromagnetic energy, such as is found

in X-rays and gamma rays, can ionize biological tissues.

Ionization is a process where electrons are stripped away

from their normal locations in atoms and molecules. It can

permanently damage biological tissues including DNA, the

genetic material.

The energy levels associated with radio frequency energy,

including both radio waves and microwaves, are not great

enough to cause ionization of atoms and molecules.

Therefore, RF energy is a type of non-ionizing radiation.

Other types of non-ionizing radiation include visible light,

infrared radiation (heat), and other forms of electromagnetic

radiation with relatively low frequencies.

While RF energy does not ionize particles, large amounts can

increase body temperatures and cause tissue damage. Two

areas of the body, the eyes and the testes, are particularly

vulnerable to RF heating because there is relatively little

blood flow in them to carry away excess heat.

Research Results to Date: Is there a connection

between RF and certain health problems?

The results of most studies conducted to date say no. In

addition, attempts to replicate and confirm the few studies

that have shown a connection have failed.

The scientific community at large therefore believes that the

weight of scientific evidence does not show an association

between exposure to Radio Frequency (RF) from cell phones

and adverse health outcomes. Still the scientific community

has supported additional research to address gaps in

knowledge. Some of these studies are described below.

Interphone Study

Interphone is a large international study designed to

determine whether cell phones increase the risk of head and

neck cancer. A report published in the International Journal

of Epidemiology (June, 2010) compared cell phone usage for

more than 5,000 people with brain tumors (glioma and

meningioma) and a similar number of healthy controls.

Results of this study did NOT show that cell phones caused

brain cancer. In this study, most people had no increased risk

of brain cancer from using cell phones. For people with the

heaviest use of cell phones (an average of more than ½ hour

per day, every day, for over 10 years) the study suggested a

DRAFT

FOR INTERNAL USE ONLY

229

slight increase in brain cancer. However, the authors

determined that biases and errors prevented any conclusions

being drawn from this data. Additional information about

Interphone can be found at

http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.

Interphone is the largest cell phone study to date, but it did

not answer all questions about cell phone safety. Additional

research is being conducted around the world, and the FDA

continues to monitor developments in this field.

International Cohort Study on Mobile Phone Users

(COSMOS)

The COSMOS study aims to conduct long-term health

monitoring of a large group of people to determine if there

are any health issues linked to long-term exposure to radio

frequency energy from cell phone use. The COSMOS study

will follow approximately 300,000 adult cell phone users in

Europe for 20 to 30 years. Additional information about the

COSMOS study can be found at

http://www.ukcosmos.org/index.html

Risk of Brain Cancer from Exposure to Radio

Frequency Fields in Childhood and Adolescence

(MOBI-KIDS)

MOBI-KIDS is an international study investigating the

relationship between exposure to radio frequency energy

from communication technologies including cell phones and

brain cancer in young people. This is an international

multi-center study involving 14 European and non-European

countries. Additional information about MOBI-KIDS can be

found at

http://www.creal.cat/programes-recerca/en_projectes-creal/

view.php?ID=39.

Surveillance, Epidemiology, and End Results (SEER)

Program of the National Cancer Institute

The National Cancer Institute (NCI) actively follows cancer

statistics in the United States to detect any change in rates of

new cases for brain cancer. If cell phones play a role in risk

for brain cancer, rates should go up, because heavy cell

phone use has been common for quite some time in the U.S.

Between 1987 and 2005, the overall age-adjusted incidence

of brain cancer did not increase. Additional information about

SEER can be found at

http://seer.cancer.gov/

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 230

Cell Phone Industry Actions

Although the existing scientific data do not justify FDA

regulatory actions, the FDA has urged the cell phone industry

to take a number of steps, including the following:

•

Support-needed research on possible biological effects of RF

for the type of signal emitted by cell phones;

•

Design cell phones in a way that minimizes any RF exposure to

the user; and

•

Cooperate in providing users of cell phones with the current

information on cell phone use and human health concerns.

The FDA also is working with voluntary standard-setting

bodies such as the Institute of Electrical and Electronics

Engineers (IEEE), the International Commission on

Non-Ionizing Radiation Protection (ICNIRP), and others to

assure that safety standards continue to adequately protect

the public.

Reducing Exposure: Hands-Free Kits and Other

Accessories

Steps to Reduce Exposure to Radio Frequency Energy

If there is a risk from being exposed to radio frequency

energy (RF) from cell phones - and at this point we do not

know that there is - it is probably very small. But, if you are

concerned about avoiding even potential risks, you can take

a few simple steps to minimize your RF exposure.

•

Reduce the amount of time spent using your cell phone;

•

Use speaker mode or a headset to place more distance between

your head and the cell phone.

Hands-Free Kits

Hands-free kits may include audio or Bluetooth® headsets

and various types of body-worn accessories such as

belt-clips and holsters. Combinations of these can be used to

reduce RF energy absorption from cell phones.

Headsets can substantially reduce exposure because the

phone is held away from the head in the user's hand or in

approved body-worn accessories. Cell phones marketed in

the U.S. are required to meet RF exposure compliance

requirements when used against the head and against the

body.

DRAFT

FOR INTERNAL USE ONLY

231

Because there are no known risks from exposure to RF

emissions from cell phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits can be used for

convenience and comfort. They are also required by law in

many states if you want to use your phone while driving.

Cell Phone Accessories that Claim to Shield the Head

from RF Radiation

Because there are no known risks from exposure to RF

emissions from cell phones, there is no reason to believe that

accessories which claim to shield the head from those

emissions reduce risks. Some products that claim to shield

the user from RF absorption use special phone cases, while

others involve nothing more than a metallic accessory

attached to the phone.

Studies have shown that these products generally do not

work as advertised. Unlike “hands-free” kits, these so-called

“shields” may interfere with proper operation of the phone.

The phone may be forced to boost its power to compensate,

leading to an increase in RF absorption.

Children and Cell Phones

The scientific evidence does not show a danger to any users

of cell phones from RF exposure, including children and

teenagers. The steps adults can take to reduce RF exposure

apply to children and teenagers as well.

•

Reduce the amount of time spent on the cell phone;

•

Use speaker mode or a headset to place more distance between

the head and the cell phone.

Some groups sponsored by other national governments have

advised that children be discouraged from using cell phones

at all. For example, The Stewart Report from the United

Kingdom made such a recommendation in December 2000.

In this report, a group of independent experts noted that no

evidence exists that using a cell phone causes brain tumors

or other ill effects. Their recommendation to limit cell phone

use by children was strictly precautionary; it was not based

on scientific evidence that any health hazard exists.

Additional information on the safety of RF exposures from

various sources can be obtained from the following

organizations (updated 10/1/2010):

•

FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 232

•

Environmental Protection Agency (EPA):

http://www.epa.gov/radtown/wireless-tech.html.

•

Occupational Safety and Health Administration (OSHA):

http://www.osha.gov/SLTC/radiofrequencyradiation/

(Note: This web address is case sensitive.)

•

National Institute for Occupational Safety and Health (NIOSH):

http://www.cdc.gov/niosh/.

•

World Health Organization (WHO):

http://www.who.int/peh-emf/en/.

•

International Commission on Non-Ionizing Radiation Protection:

http://www.icnirp.de.

•

Health Protection Agency:

http://www.hpa.org.uk/Topics/Radiation/.

•

US Food and Drug Administration:

http://www.fda.gov/Radiation-EmittingProducts/

RadiationEmittingProductsandProcedures/

HomeBusinessandEntertainment/CellPhones/default.htm.

Specific Absorption Rate (SAR)

Certification Information

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed the exposure

limits for Radio Frequency (RF) energy set by the Federal

Communications Commission (FCC) of the U.S. Government.

These FCC RF exposure limits are derived from the

recommendations of two expert organizations: the National

Council on Radiation Protection and Measurement (NCRP)

and the Institute of Electrical and Electronics Engineers

(IEEE). In both cases, the recommendations were developed

by scientific and engineering experts drawn from industry,

government, and academia after extensive reviews of the

scientific literature related to the biological effects of RF

energy.

The RF exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure of the

rate of absorption of RF energy by the human body

expressed in units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a safety limit of 1.6

watts per kilogram (1.6 W/kg).

DRAFT

FOR INTERNAL USE ONLY

233

The FCC SAR limit incorporates a substantial margin of safety

to give additional protection to the public and to account for

any variations in measurements.

SAR tests are conducted using standard operating positions

accepted by the FCC with the phone transmitting at its

highest certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while

operating can be well below the maximum reported value.

This is because the phone is designed to operate at multiple

power levels so as to use only the power required to reach

the network. In general, the closer you are to a wireless base

station antenna, the lower the power output of the phone.

Before a new model phone is available for sale to the public,

it must be tested and certified to the FCC that it does not

exceed the SAR limit established by the FCC. Tests for each

model phone are performed in positions and locations (e.g. at

the ear and worn on the body) as required by the FCC. For

body-worn operation, this phone has been tested and meets

FCC RF exposure guidelines when used with an accessory

that contains no metal and that positions the mobile device a

minimum of 1.0 cm from the body.

Use of other accessories may not ensure compliance with

FCC RF exposure guidelines. The FCC has granted an

Equipment Authorization for this mobile device with all

reported SAR levels evaluated as in compliance with the FCC

RF exposure guidelines. This [mobile phone/tablet/device]

has a FCC ID number: A3LSMC105A [Model Number: SM-

C105A] and the specific SAR levels for this [mobile phone/

tablet/device] can be found at the following FCC website:

http://www.fcc.gov/oet/ea/

The SAR information for this device can also be found on

Samsung’s website:

http://www.samsung.com/sar

SAR information on this and other model phones can be

accessed online on the FCC's website through

http://

transition.fcc.gov/oet/rfsafety/sar.html

. To find information that

pertains to a particular model phone, this site uses the phone

FCC ID number which is usually printed somewhere on the

case of the phone. Sometimes it may be necessary to

remove the battery pack to find the number. Once you have

the FCC ID number for a particular phone, follow the

instructions on the website and it should provide values for

typical or maximum SAR for a particular phone. Additional

SAR information can also be obtained at

http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-

cellular-telephones

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 234

FCC Part 15 Information to User

Pursuant to part 15.21 of the FCC Rules, you are cautioned

that changes or modifications not expressly approved by

Samsung could void your authority to operate the device.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Commercial Mobile Alerting System

(CMAS)

This device is designed to receive wireless emergency alerts

from the Commercial Mobile Alerting System ("CMAS";

which may also be known as the Personal Localized Alerting

Network ("PLAN")). If your wireless provider has chosen to

participate in CMAS/PLAN, alerts are available while in the

provider's coverage area. If you travel outside your provider's

coverage area, wireless emergency alerts may not be

available. For more information, please contact your wireless

provider.

Smart Practices While Driving

On the Road - Off the Phone

The primary responsibility of every driver is the safe

operation of his or her vehicle.

DRAFT

FOR INTERNAL USE ONLY

235

Responsible drivers understand that no secondary task

should be performed while driving whether it be eating,

drinking, talking to passengers, or talking on a mobile phone

- unless the driver has assessed the driving conditions and is

confident that the secondary task will not interfere with their

primary responsibility.

Do not engage in any activity while

driving a moving vehicle which may cause you to take your

eyes off the road or become so absorbed in the activity that

your ability to concentrate on the act of driving becomes

impaired

. Samsung is committed to promoting responsible

driving and giving drivers the tools they need to understand

and address distractions.

Check the laws and regulations on the use of mobile devices

and their accessories in the areas where you drive. Always

obey them. The use of these devices may be prohibited or

restricted in certain areas. For example, only hands-free use

may be permitted in certain areas.

Before answering calls, consider your circumstances. Let the

call go to voicemail when driving conditions require.

Remember, driving comes first, not the call!

If you consider a call necessary and appropriate, follow these

tips:

•

Use a hands-free device;

•

Secure your phone within easy reach;

•

Place calls when you are not moving;

•

Plan calls when your car will be stationary;

•

Do not engage in stressful or emotional conversations;

•

Let the person with whom you are speaking know that you are

driving and will suspend the call if necessary;

•

Do not take notes or look up phone numbers while driving;

Notice regarding legal restrictions on mounting this device in

an automobile:

Laws in some states may prohibit mounting this device on or

near the windshield of an automobile. In other states, the law

may permit mounting this device only in specific locations in

the automobile. Be sure to consult the state and local laws or

ordinances where you drive before mounting this device in

an automobile. Failure to comply with these restrictions could

result in fines, penalties, or other damages.

Never mount this device in a manner that will obstruct the

driver's clear view of the street and traffic.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 236

Never use wireless data services such as text messaging, Web

browsing, or e-mail while operating a vehicle.

Never watch videos, such as a movie or clip, or play video

games while operating a vehicle.

For more information, go to

http://www.ctia.org

Battery Use and Safety

Important! Handle and store batteries properly to avoid injury or

damage

. Most battery issues arise from improper

handling of batteries and, particularly, from the

continued use of damaged batteries.

•

Do not disassemble, crush, puncture, shred, or otherwise

attempt to change the form of your battery

. Do not put a high

degree of pressure on the battery. This can cause leakage or an

internal short-circuit, resulting in overheating.

•

Do not let the phone or battery come in contact with liquids.

Liquids can get into the phone's circuits, leading to corrosion.

Even when the phone appears to be dry and appears to operate

normally, the circuitry could slowly corrode and pose a safety

hazard. If the phone and/or battery get wet, have them checked

by your service provider or contact Samsung, even if they appear

to be working properly.

•

Do not place your battery in or near a heat source

. Excessive

heating can damage the phone or the battery and could cause the

phone or the battery to explode. Do not dry a wet or damp battery

with an appliance or heat source such as a microwave oven, hair

dryer, iron, or radiator. Avoid leaving your phone in your car in

high temperatures.

•

Do not dispose of the phone or the battery in a fire

. The phone

or the battery may explode when overheated.

•

Do not handle a damaged or leaking battery

. Do not let leaking

battery fluid come in contact with your eyes, skin or clothing. For

safe disposal options, contact your nearest Samsung-authorized

service center.

DRAFT

FOR INTERNAL USE ONLY

237

•

Avoid dropping the cell phone

. Dropping the phone or the

battery, especially on a hard surface, can potentially cause

damage to the phone and battery. If you suspect damage to the

phone or battery, take it to a service center for inspection.

•

Never use any charger or battery that is damaged in any way

•

Do not allow the battery to touch metal objects

. Accidental

short-circuiting can occur when a metallic object (coin, key,

jewelry, clip, or pen) causes a direct connection between the +

and - terminals of the battery (metal strips on the battery), for

example when you carry a spare battery in a pocket or bag.

Short-circuiting the terminals may damage the battery or the

object causing the short-circuiting.

Important!

Use only Samsung-approved batteries, and

recharge your battery only with

Samsung-approved chargers which are

specifically designed for your phone.

WARNING!

Use of a non-Samsung-approved battery or charger may

present a risk of fire, explosion, leakage, or other hazard

Samsung's warranty does not cover damage to the phone

caused by non-Samsung-approved batteries and/or

chargers.

•

Do not use incompatible cell phone batteries and chargers

Some websites and second-hand dealers not associated with

reputable manufacturers and carriers, might be selling

incompatible or even counterfeit batteries and chargers.

Consumers should purchase manufacturer or

carrier-recommended products and accessories. If unsure about

whether a replacement battery or charger is compatible, contact

the manufacturer of the battery or charger.

•

Misuse or use of incompatible phones, batteries, and

charging devices could result in damage to the equipment

and a possible risk of fire, explosion, or leakage, leading to

serious injuries, damages to your phone, or other serious

hazard

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 238

Samsung Mobile Products and

Recycling

Samsung cares for the environment and encourages its

customers to recycle Samsung mobile devices and genuine

Samsung accessories.

Proper disposal of your mobile device and its battery is not

only important for safety, it benefits the environment.

Batteries must be recycled or disposed of properly.

Recycling programs for your mobile device, batteries, and

accessories may not be available in your area.

We've made it easy for you to recycle your old Samsung

mobile device by working with respected take-back

companies in every state in the country.

Drop It Off

You can drop off your Samsung-branded mobile device

and batteries for recycling at one of our numerous

Samsung Recycling Direct (SM) locations. A list of these

locations may be found at:

http://pages.samsung.com/us/recyclingdirect/

usactivities_environment_samsungrecyclingdirect_locations.jsp

Samsung-branded devices and batteries will be accepted

at these locations for no fee.

Consumers may also recycle their used mobile device or

batteries at many retail or carrier-provided locations

where mobile devices and batteries are sold. Additional

information regarding specific locations may be found at:

http://www.epa.gov/epawaste/partnerships/plugin/cellphone/

index.htm

or at

http://www.call2recycle.org/

Mail It In

The Samsung Mobile Take-Back Program will provide

Samsung customers with a free recycling mailing label.

Just go to

http://fun.samsungmobileusa.com/recycling/index.jsp

Dispose of unwanted electronics through an approved

recycler.

To find the nearest recycling location, go to our website:

www.samsung.com/recyclingdirect

Or call, (877) 278-0799.

DRAFT

FOR INTERNAL USE ONLY

239

Follow local regulations regarding disposal of mobile

devices and batteries

Dispose of your mobile device and batteries in accordance

with local regulations. In some areas, the disposal of these

items in household or business trash may be prohibited. Help

us protect the environment - recycle!

Warning!

Never dispose of batteries in a fire because they may

explode.

UL Certified Travel Charger

The Travel Charger for this phone has met applicable UL

safety requirements. Please adhere to the following safety

instructions per UL guidelines:

FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY

LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE

PROPERTY DAMAGE.

IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE

INSTRUCTIONS.

DANGER - TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS.

FOR CONNECTION TO A SUPPLY NOT IN NORTH

AMERICA, USE AN ATTACHMENT PLUG ADAPTOR

OF THE PROPER CONFIGURATION FOR THE

POWER OUTLET.

THIS POWER UNIT IS INTENDED TO BE

CORRECTLY ORIENTED IN A VERTICAL OR

HORIZONTAL OR FLOOR MOUNT POSITION.

Display / Touch-Screen

Please note the following information when using your

mobile device:

WARNING REGARDING DISPLAY

The display on your mobile device is made of glass or

acrylic and could break if your mobile device is

dropped or if it receives significant impact. Do not use

if screen is broken or cracked as this could cause

injury to you.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 240

WARRANTY DISCLAIMER: PROPER USE OF A

TOUCH-SCREEN MOBILE DEVICE

If your mobile device has a touch-screen display,

please note that a touch-screen responds best to a

light touch from the pad of your finger or a non-metallic

stylus. Using excessive force or a metallic object when

pressing on the touch-screen may damage the

tempered glass surface and void the warranty. For

more information, please refer to the “Standard

Limited Warranty”.

GPS

Certain Samsung mobile devices can use a Global Positioning

System (GPS) signal for location-based applications. A GPS

uses satellites controlled by the U.S. Government that are

subject to changes implemented in accordance with the

Department of Defense policy and the 2008 Federal Radio

navigation Plan (FRP). Changes may affect the performance

of location-based technology on your mobile device.

Even with GPS, when you make an emergency call:

•

Always tell the emergency responder your location to the best of

your ability; and

•

Remain on the mobile device for as long as the emergency

responder instructs you.

Navigation

Maps, directions, and other navigation-data, including data

relating to your current location, may contain inaccurate or

incomplete data, and circumstances can and do change over

time. In some areas, complete information may not be

available.

Therefore, you should always visually confirm that

the navigational instructions are consistent with what you see

before following them. All users should pay attention to road

conditions, closures, traffic, and all other factors that may

impact safe driving or walking. Always obey posted road signs.

Emergency Calls

This mobile device, like any wireless mobile device, operates

using radio signals, wireless and landline networks, as well

as user-programmed functions, which cannot guarantee

connection in all conditions, areas, or circumstances.

Therefore, you should never rely solely on any wireless

mobile device for essential communications (medical

emergencies, for example). Before traveling in remote or

underdeveloped areas, plan an alternate method of

contacting emergency services personnel. Remember, to

DRAFT

FOR INTERNAL USE ONLY

241

make or receive any calls, the mobile device must be

switched on and in a service area with adequate signal

strength.

Emergency calls may not be possible on all wireless mobile

device networks or when certain network services and/or

mobile device features are in use. Check with local service

providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. From the Home screen, tap . The dialer is

displayed.

3. Key in the emergency number for your present location

(for example, 911 or other official emergency number).

Emergency numbers vary by location.

4. Tap the key.

If certain features are in use (call blocking, for example), you

may first need to deactivate those features before you can

make an emergency call. Consult your User Manual and your

local cellular service provider. When making an emergency

call, remember to give all the necessary information as

accurately as possible. Remember that your mobile device

may be the only means of communication at the scene of an

accident; do not cut off the call until given permission to do

so.

Care and Maintenance

Your mobile device is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for many

years:

Keep your Samsung Mobile Device away from:

Liquids of any kind

Keep the mobile device dry. Precipitation, humidity, and

liquids contain minerals that will corrode electronic

circuits. If the mobile device does get wet, do not

accelerate drying with the use of an oven, microwave, or

dryer, because this may damage the mobile device and

could cause a fire or explosion.

Do not use the mobile device with a wet hand. Doing so

may cause an electric shock to you or damage to the

mobile device.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 242

Extreme heat or cold

Avoid temperatures below 0°C / 32°F or above 45°C /

113°F.

Microwaves

Do not try to dry your mobile device in a microwave oven.

Doing so may cause a fire or explosion.

Dust and dirt

Do not expose your mobile device to dust, dirt, or sand.

Cleaning solutions

Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the mobile device. Wipe it with a soft

cloth slightly dampened in a mild soap-and-water

solution.

Shock or vibration

Do not drop, knock, or shake the mobile device. Rough

handling can break internal circuit boards.

Paint

Do not paint the mobile device. Paint can clog the

device’s moving parts or ventilation openings and prevent

proper operation.

Responsible Listening

Caution! Avoid potential hearing loss

Damage to hearing occurs when a person is exposed to loud

sounds over time. The risk of hearing loss increases as

sound is played louder and for longer durations. Prolonged

exposure to loud sounds (including music) is the most

common cause of preventable hearing loss. Some scientific

research suggests that using portable audio devices, such as

portable music players and cell phones, at high volume

settings for long durations may lead to permanent

noise-induced hearing loss.

This includes the use of headphones (including headsets,

earbuds, and Bluetooth® or other wireless devices).

Exposure to very loud sound has also been associated in

some studies with tinnitus (a ringing in the ear),

hypersensitivity to sound, and distorted hearing. Individual

susceptibility to noise-induced hearing loss and potential

hearing problem varies. Additionally, the amount of sound

produced by a portable audio device varies depending on the

nature of the sound, the device settings, and the headphones

DRAFT

FOR INTERNAL USE ONLY

243

that are used. As a result, there is no single volume setting

that is appropriate for everyone or for every combination of

sound, settings, and equipment.

You should follow some common sense recommendations

when using any portable audio device:

•

Always turn the volume down before plugging the earphones into

an audio source.

•

Set the volume in a quiet environment and select the lowest

volume at which you can hear adequately.

•

Be aware that you can adapt to higher volume settings over time,

not realizing that the higher volume may be harmful to your

hearing.

•

When using headphones, turn the volume down if you cannot

hear the people speaking near you or if the person sitting next to

you can hear what you are listening to.

•

Do not turn the volume up to block out noisy surroundings. If you

choose to listen to your portable device in a noisy environment,

use noise-cancelling headphones to block out background

environmental noise. By blocking background environment noise,

noise cancelling headphones should allow you to hear the music

at lower volumes than when using earbuds.

•

Limit the amount of time you listen. As the volume increases, less

time is required before you hearing could be affected.

•

Avoid using headphones after exposure to extremely loud noises,

such as rock concerts, that might cause temporary hearing loss.

Temporary hearing loss might cause unsafe volumes to sound

normal.

•

Do not listen at any volume that causes you discomfort. If you

experience ringing in your ears, hear muffled speech, or

experience any temporary hearing difficulty after listening to your

portable audio device, discontinue use and consult your doctor.

You can obtain additional information on this subject from the

following sources:

American Academy of Audiology

11730 Plaza American Drive, Suite 300

Reston, VA 20190

Voice: (800) 222-2336

Email: info@audiology.org

Internet:

http://www.audiology.org/Pages/

default.aspx

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 244

Operating Environment

Remember to follow any special regulations in force in any

area, and always switch your mobile device off whenever it is

forbidden to use it, or when it may cause interference or

danger. When connecting the mobile device or any accessory

to another device, read its user's guide for detailed safety

instructions. Do not connect incompatible products.

Using Your Mobile Device Near Other Electronic

Devices

Most modern electronic equipment is shielded from Radio

Frequency (RF) signals. However, certain electronic

equipment may not be shielded against the RF signals from

your wireless mobile device. Consult the manufacturer to

discuss alternatives.

National Institute on Deafness and Other

Communication Disorders

National Institutes of Health

31 Center Drive, MSC 2320

Bethesda, MD 20892-2320

Email: nidcdinfo@nih.gov

Internet:

http://www.nidcd.nih.gov/

National Institute for Occupational Safety

and Health (NIOSH)

395 E Street, S.W., Suite 9200

Patriots Plaza Building

Washington, DC 20201

Voice: 1-800-35-NIOSH

(1-800-356-4674)

1-800-CDC-INFO (1-800-232-4636)

Outside the U.S. 513-533-8328

Email: cdcinfo@cdc.gov

Internet:

http://www.cdc.gov/niosh/topics/noise/

default.html

1-888-232-6348 TTY

DRAFT

FOR INTERNAL USE ONLY

245

Implantable Medical Devices

A minimum separation of six (6) inches should be maintained

between a handheld wireless mobile device and an

implantable medical device, such as a pacemaker or

implantable cardioverter defibrillator, to avoid potential

interference with the device.

Persons who have such devices:

•

Should ALWAYS keep the mobile device more than six (6) inches

from their implantable medical device when the mobile device is

turned ON;

•

Should not carry the mobile device in a breast pocket;

•

Should use the ear opposite the implantable medical device to

minimize the potential for interference;

•

Should turn the mobile device OFF immediately if there is any

reason to suspect that interference is taking place;

•

Should read and follow the directions from the manufacturer of

your implantable medical device. If you have any questions about

using your wireless mobile device with an implantable medical

device, consult your health care provider.

For more information see:

http://www.fcc.gov/oet/rfsafety/rf-

faqs.html#

Other Medical Devices

If you use any other personal medical devices, consult the

manufacturer of your device to determine if it is adequately

shielded from external RF energy. Your physician may be able

to assist you in obtaining this information. Switch your

mobile device off in health care facilities when any

regulations posted in these areas instruct you to do so.

Hospitals or health care facilities may be using equipment

that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles. Check with

the manufacturer or its representative regarding your vehicle

before using your mobile device in a motor vehicle. You

should also consult the manufacturer of any equipment that

has been added to your vehicle.

Posted Facilities

Switch your mobile device off in any facility where posted

notices require you to do so.

Potentially Explosive Environments

Switch your mobile device off when in any area with a

potentially explosive atmosphere and obey all signs and

instructions. Sparks in such areas could cause an explosion

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 246

or fire resulting in bodily injury or even death. Users are

advised to switch the mobile device off while at a refueling

point (service station).

Users are reminded of the need to observe restrictions on the

use of radio equipment in fuel depots (fuel storage and

distribution areas), chemical plants, or where blasting

operations are in progress. Areas with a potentially explosive

atmosphere are often, but not always, clearly marked. They

include below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas (such as

propane or butane), areas where the air contains chemicals

or particles, such as grain, dust, or metal powders, and any

other area where you would normally be advised to turn off

your vehicle engine.

When your Device is Wet

Do not turn on your device if it is wet. If your device is

already on, turn it off and remove the battery immediately (if

the device will not turn off or you cannot remove the battery,

leave it as-is). Then, dry the device with a towel and take it

to a service center.

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices

The U.S. Federal Communications Commission (FCC) has

established requirements for digital wireless mobile devices

to be compatible with hearing aids and other assistive

hearing devices.

When individuals employing some assistive hearing devices

(hearing aids and cochlear implants) use wireless mobile

devices, they may detect a buzzing, humming, or whining

noise. Some hearing devices are more immune than others

to this interference noise, and mobile devices also vary in the

amount of interference they generate.

The wireless telephone industry has developed a rating

system for wireless mobile devices to assist hearing device

users find mobile devices that may be compatible with their

hearing devices. Not all mobile devices have been rated.

Mobile devices that are rated have the rating on their box or

a label located on the box.

The ratings are not guarantees. Results will vary depending

on the user's hearing device and hearing loss. If your hearing

device happens to be vulnerable to interference, you may not

DRAFT

FOR INTERNAL USE ONLY

247

be able to use a rated mobile device successfully. Trying out

the mobile device with your hearing device is the best way to

evaluate it for your personal needs.

M-Ratings

: Wireless mobile devices rated M3 or M4 meet

FCC requirements and are likely to generate less interference

to hearing devices than mobile devices that are not labeled.

M4 is the better/higher of the two ratings. M-ratings refer to

enabling acoustic coupling with hearing aids that do not

operate in telecoil mode.

T-Ratings

: Mobile devices rated T3 or T4 meet FCC

requirements and are likely to generate less interference to

hearing devices than mobile devices that are not labeled. T4

is the better/higher of the two ratings. T-ratings refer to

enabling inductive coupling with hearing aids operating in

telecoil mode.

Hearing devices may also be rated. Your hearing aid

manufacturer or hearing health professional may help you

find this rating. Higher ratings mean that the hearing device

is relatively immune to interference noise.

Under the current industry standard, American National

Standards Institute (ANSI) C63.19, the hearing aid and

wireless mobile device rating values are added together to

indicate how usable they are together. For example, if a

hearing aid meets the M2 level rating and the wireless

mobile device meets the M3 level rating, the sum of the two

values equals M5.

Under the standard, this should provide the hearing aid user

with normal use while using the hearing aid with the

particular wireless mobile device. A sum of 6 or more would

indicate excellent performance.

However, these are not guarantees that all users will be

satisfied. T ratings work similarly.

M3 + M2 = 5

T3 + T2 = 5

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 248

The HAC rating and measurement procedure are described in

the American National Standards Institute (ANSI) C63.19

standard.

HAC for Newer Technologies

This phone has been tested and rated for use with hearing

aids for some of the wireless technologies that it uses.

However, there may be some newer wireless technologies

used in this phone that have not been tested yet for use with

hearing aids.

It is important to try the different features of this phone

thoroughly and in different locations, using your hearing aid

or cochlear implant, to determine if you hear any interfering

noise. Consult your service provider or the manufacturer of

this phone for information on hearing aid compatibility. If you

have questions about return or exchange policies, consult

your service provider or phone retailer.

Restricting Children's Access to Your

Mobile Device

Your mobile device is not a toy. Do not allow children to play

with it because they could hurt themselves and others,

damage the mobile device, or make calls that increase your

mobile device bill.

Keep the mobile device and all its parts and accessories out

of the reach of small children.

FCC Notice and Cautions

FCC Notice

The mobile device may cause TV or radio interference if used

in close proximity to receiving equipment. The FCC can

require you to stop using the mobile device if such

interference cannot be eliminated. Vehicles using liquefied

petroleum gas (such as propane or butane) must comply with

the National Fire Protection Standard (NFPA-58). For a copy

of this standard, contact the National Fire Protection

Association.

Cautions

Any changes or modifications to your mobile device not

expressly approved in this document could void your

warranty for this equipment and void your authority to

operate this equipment. Only use approved batteries,

antennas, and chargers. The use of any unauthorized

accessories may be dangerous and void the mobile device

warranty if said accessories cause damage or a defect to the

mobile device.

DRAFT

FOR INTERNAL USE ONLY

249

Although your mobile device is quite sturdy, it is a complex

piece of equipment and can be broken. Avoid dropping,

hitting, bending, or sitting on it.

Other Important Safety Information

•

Only qualified personnel should service the mobile device or

install the mobile device in a vehicle. Faulty installation or service

may be dangerous and may invalidate any warranty applicable to

the device.

•

Ensure that any mobile devices or related equipment installed in

your vehicle are securely mounted.

•

Check regularly that all wireless mobile device equipment in your

vehicle is mounted and operating properly.

•

When using a headset in dry environments, static electricity can

build up in the headset and cause a small quick static electrical

shock. To minimize the risk of electrostatic discharge from the

headset avoid using the headset in extremely dry environments or

touch a grounded unpainted metal object to discharge static

electricity before inserting the headset.

•

Do not store or carry flammable liquids, gases, or explosive

materials in the same compartment as the mobile device, its

parts, or accessories.

•

For vehicles equipped with an air bag, remember that an air bag

inflates with great force. Do not place objects, including installed

or portable wireless equipment near or in the area over the air

bag or in the air bag deployment area. If wireless equipment is

improperly installed and the air bag inflates, serious injury could

result.

•

Switch your mobile device off before boarding an aircraft. The use

of wireless mobile devices in aircraft is illegal and may be

dangerous to the aircraft's operation. Check with appropriate

authorities before using any function of a mobile device while on

an aircraft.

•

Failure to observe these instructions may lead to the suspension

or denial of cell phone services to the offender, or legal action, or

both.

•

While using your device, leave some lights on in the room and do

not hold the screen too close to your eyes.

•

Seizures or blackouts can occur when you are exposed to flashing

lights while watching videos or playing games for extended

periods. If you feel any discomfort, stop using the device

immediately.

DRAFT

FOR INTERNAL USE ONLY

Health and Safety Information 250

•

Reduce risk of repetitive motion injuries. When you repetitively

perform actions, such as pressing keys, drawing characters on a

touch screen with your fingers, or playing games, you may

experience occasional discomfort in your hands, neck, shoulders,

or other parts of your body. When using your device for extended

periods, hold the device with a relaxed grip, press the keys lightly,

and take frequent breaks. If you continue to have discomfort

during or after such use, stop use and see a physician.

•

If your device has a camera flash or light, do not use the flash or

light close to the eyes of people or pets. [122011]

DRAFT

FOR INTERNAL USE ONLY

251

Section 12: Warranty Information

Standard Limited Warranty

What is covered and for how long?

SAMSUNG TELECOMMUNICATIONS AMERICA, LLC

(“SAMSUNG”) warrants that SAMSUNG’s handsets and

accessories (“Products”) are free from defects in material

and workmanship under normal use and service for the

period commencing upon the date of purchase by the first

consumer purchaser and continuing for the following

specified period of time after that date:

What is not covered?

This Limited Warranty is conditioned upon proper use of the

Product.

This Limited Warranty does not cover: (a) defects or damage

resulting from accident, misuse, abnormal use, abnormal

conditions, improper storage, exposure to liquid, moisture,

dampness, sand or dirt, neglect, or unusual physical,

electrical or electromechanical stress; (b) scratches, dents

and cosmetic damage, unless caused by SAMSUNG;

of a metallic object when pressing on a touch screen;

(d) equipment that has the serial number or the

enhancement data code removed, defaced, damaged,

altered or made illegible; (e) ordinary wear and tear;

(f) defects or damage resulting from the use of Product in

conjunction or connection with accessories, products, or

ancillary/peripheral equipment not furnished or approved by

SAMSUNG; (g) defects or damage resulting from improper

testing, operation, maintenance, installation, service, or

adjustment not furnished or approved by SAMSUNG;

(h) defects or damage resulting from external causes such as

collision with an object, fire, flooding, dirt, windstorm,

lightning, earthquake, exposure to weather conditions, theft,

blown fuse, or improper use of any electrical source;

(i) defects or damage resulting from cellular signal reception

Phone 1 Year

Batteries 1 Year

Case/Pouch/Holster 90 Days

Other Phone Accessories 1 Year

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 252

or transmission, or viruses or other software problems

introduced into the Product; or (j) Product used or purchased

outside the United States. This Limited Warranty covers

batteries only if battery capacity falls below 80% of rated

capacity or the battery leaks, and this Limited Warranty does

not cover any battery if (i) the battery has been charged by a

battery charger not specified or approved by SAMSUNG for

charging the battery; (ii) any of the seals on the battery are

broken or show evidence of tampering; or (iii) the battery has

been used in equipment other than the SAMSUNG phone for

which it is specified.

What are SAMSUNG’s obligations?

During the applicable warranty period, provided the Product

is returned in accordance with the terms of this Limited

Warranty, SAMSUNG will repair or replace the Product, at

SAMSUNG’s sole option, without charge. SAMSUNG may, at

SAMSUNG’s sole option, use rebuilt, reconditioned, or new

parts or components when repairing any Product, or may

replace the Product with a rebuilt, reconditioned or new

Product.

Repaired/replaced cases, pouches and holsters will be

warranted for a period of ninety (90) days. All other repaired/

replaced Products will be warranted for a period equal to the

remainder of the original Limited Warranty on the original

Product or for ninety (90) days, whichever is longer. All

replaced Products, parts, components, boards and

equipment shall become the property of SAMSUNG. Except to

any extent expressly allowed by applicable law, transfer or

assignment of this Limited Warranty is prohibited.

What must you do to obtain warranty service?

To obtain service under this Limited Warranty, you must

return the Product to an authorized phone service facility in

an adequate container for shipping, accompanied by the

sales receipt or comparable proof of sale showing the

original date of purchase, the serial number of the Product

and the seller’s name and address.

To obtain assistance on where to deliver the Product, please

call SAMSUNG Customer Care at 1-888-987-4357. If

SAMSUNG determines that any Product is not covered by this

Limited Warranty, you must pay all parts, shipping, and labor

charges for the repair or return of such Product.

You should keep a separate backup copy of any contents of

the Product before delivering the Product to SAMSUNG for

warranty service, as some or all of the contents may be

deleted or reformatted during the course of warranty service.

DRAFT

FOR INTERNAL USE ONLY

253

What are the limits on SAMSUNG’s liability?

THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF

SAMSUNG’S RESPONSIBILITIES, AND THE EXCLUSIVE

REMEDY REGARDING THE PRODUCTS.

ALL IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO

THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT

SHALL SAMSUNG BE LIABLE FOR DAMAGES IN EXCESS OF

THE PURCHASE PRICE OF THE PRODUCT OR FOR, WITHOUT

LIMITATION, COMMERCIAL LOSS OF ANY SORT; LOSS OF

USE, TIME, DATA, REPUTATION, OPPORTUNITY, GOODWILL,

PROFITS OR SAVINGS; INCONVENIENCE; INCIDENTAL,

SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES; OR

DAMAGES ARISING FROM THE USE OR INABILITY TO USE THE

PRODUCT. SOME STATES AND JURISDICTIONS DO NOT

ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY

LASTS, OR THE DISCLAIMER OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS

AND DISCLAIMERS MAY NOT APPLY TO YOU.

SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,

EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO

THE QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE

OR SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR

EQUIPMENT USED IN CONJUNCTION WITH THE PRODUCT, OR

THE ABILITY TO INTEGRATE ANY SUCH SOFTWARE OR

EQUIPMENT WITH THE PRODUCT, WHETHER SUCH

THIRD-PARTY SOFTWARE OR EQUIPMENT IS INCLUDED WITH

THE PRODUCT DISTRIBUTED BY SAMSUNG OR OTHERWISE.

RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,

OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY

SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS

SOLELY WITH THE USER AND THE DIRECT VENDOR, OWNER

OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR

EQUIPMENT.

Nothing in the Product instructions or information shall be

construed to create an express warranty of any kind with

respect to the Products. No agent, employee, dealer,

representative or reseller is authorized to modify or extend

this Limited Warranty or to make binding representations or

claims, whether in advertising, presentations or otherwise,

on behalf of SAMSUNG regarding the Products or this Limited

Warranty.

This Limited Warranty gives you specific legal rights, and you

may also have other rights that vary from state to state.

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 254

What is the procedure for resolving disputes?

ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM

THIS LIMITED WARRANTY OR THE SALE, CONDITION OR

PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED

EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION,

AND NOT BY A COURT OR JURY.

Any such dispute shall not be combined or consolidated with

a dispute involving any other person’s or entity’s Product or

claim, and specifically, without limitation of the foregoing,

shall not under any circumstances proceed as part of a class

action. The arbitration shall be conducted before a single

arbitrator, whose award may not exceed, in form or amount,

the relief allowed by the applicable law. The arbitration shall

be conducted according to the American Arbitration

Association (AAA) Commercial Arbitration Rules applicable to

consumer disputes. This arbitration provision is entered

pursuant to the Federal Arbitration Act. The laws of the State

of Texas, without reference to its choice of laws principles,

shall govern the interpretation of the Limited Warranty and all

disputes that are subject to this arbitration provision. The

arbitrator shall decide all issues of interpretation and

application of this arbitration provision and the Limited

Warranty.

For any arbitration in which your total damage claims,

exclusive of attorney fees and expert witness fees, are

$5,000.00 or less (“Small Claim”), the arbitrator may, if you

prevail, award your reasonable attorney fees, expert witness

fees and costs as part of any award, but may not grant

SAMSUNG its attorney fees, expert witness fees or costs

unless it is determined that the claim was brought in bad

faith. In a Small Claim case, you shall be required to pay no

more than half of the total administrative, facility and

arbitrator fees, or $50.00 of such fees, whichever is less, and

SAMSUNG shall pay the remainder of such fees.

Administrative, facility and arbitrator fees for arbitrations in

which your total damage claims, exclusive of attorney fees

and expert witness fees, exceed $5,000.00 (“Large Claim”)

shall be determined according to AAA rules. In a Large Claim

case, the arbitrator may grant to the prevailing party, or

apportion among the parties, reasonable attorney fees,

expert witness fees and costs. Judgment may be entered on

the arbitrator’s award in any court of competent jurisdiction.

This arbitration provision also applies to claims against

SAMSUNG’s employees, representatives and affiliates if any

such claim arises from the Product’s sale, condition or

performance.

DRAFT

FOR INTERNAL USE ONLY

255

You may opt out of this dispute resolution procedure by

providing notice to SAMSUNG no later than 30 calendar days

from the date of the first consumer purchaser’s purchase of the

Product. To opt out, you must send notice by e-mail to

optout@sta.samsung.com, with the subject line: “Arbitration

Opt Out.” You must include in the opt out e-mail (a) your name

and address; (b) the date on which the Product was purchased;

or MEID or Serial Number, as applicable, if you have it (the IMEI

or MEID or Serial Number can be found (i) on the Product box;

(ii) on the Product information screen, which can be found

under “Settings;” (iii) on a label on the back of the Product

beneath the battery, if the battery is removable; and (iv) on the

outside of the Product if the battery is not removable).

Alternatively, you may opt out by calling 1-888-987-4357 no

later than 30 calendar days from the date of the first consumer

purchaser’s purchase of the Product and providing the same

information. These are the only two forms of notice that will be

effective to opt out of this dispute resolution procedure. Opting

out of this dispute resolution procedure will not affect the

coverage of the Limited Warranty in any way, and you will

continue to enjoy the benefits of the Limited Warranty.

Severability

If any portion of this Limited Warranty is held to be illegal or

unenforceable, such partial illegality or unenforceability shall

not affect the enforceability of the remainder of the Limited

Warranty.

Precautions for Transfer and Disposal

If data stored on this device is deleted or reformatted using

the standard methods, the data only appears to be removed

on a superficial level, and it may be possible for someone to

retrieve and reuse the data by means of special software.

To avoid unintended information leaks and other problems of

this sort, it is recommended that the device be returned to

Samsung’s Customer Care Center for an Extended File

System (EFS) Clear which will eliminate all user memory and

return all settings to default settings. Please contact the

Samsung Customer Care Center

for details.

Important!

Please provide warranty information (proof of

purchase) to Samsung’s Customer Care Center in

order to provide this service at no charge. If the

warranty has expired on the device, charges may

apply.

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 256

Samsung Telecommunications America, LLC

1301 E. Lookout Drive

Richardson, Texas 75082

Phone: 1-800-SAMSUNG

Phone: 1-888-987-HELP (4357)

No reproduction in whole or in part allowed without prior

written approval. Specifications and availability subject to

change without notice. [111611]

End User License Agreement for

Software

IMPORTANT. READ CAREFULLY: This End User License

Agreement ("EULA") is a legal agreement between you

(either an individual or a single entity) and Samsung

Electronics Co., Ltd. ("Samsung") for software, owned by

Samsung and its affiliated companies and its third party

suppliers and licensors, that accompanies this EULA, which

includes computer software and may include associated

media, printed materials, "online" or electronic

documentation in connection with your use of this device

("Software").

This device requires the use of preloaded software in its

normal operation. BY USING THE DEVICE OR ITS PRELOADED

SOFTWARE, YOU ACCEPT THE TERMS OF THIS EULA. IF YOU

DO NOT ACCEPT THESE TERMS, DO NOT USE THE DEVICE OR

THE SOFTWARE.

GRANT OF LICENSE

. Samsung grants you the following

rights provided that you comply with all terms and conditions

of this EULA: You may install, use, access, display and run

one copy of the Software on the local hard disk(s) or other

permanent storage media of one computer and use the

Software on a single computer or a mobile device at a time,

and you may not make the Software available over a network

where it could be used by multiple computers at the same

time. You may make one copy of the Software in machine

readable form for backup purposes only; provided that the

backup copy must include all copyright or other proprietary

notices contained on the original.

Certain items of the Software may be subject to open source

licenses. The open source license provisions may override

some of the terms of this EULA. We make the applicable

open source licenses available to you on the Legal Notices

section of the Settings menu of your device.

DRAFT

FOR INTERNAL USE ONLY

257

RESERVATION OF RIGHTS AND OWNERSHIP

. Samsung

reserves all rights not expressly granted to you in this EULA.

The Software is protected by copyright and other intellectual

property laws and treaties. Samsung or its suppliers own the

title, copyright and other intellectual property rights in the

Software. The Software is licensed, not sold.

LIMITATIONS ON END USER RIGHTS

. You may not reverse

engineer, decompile, disassemble, or otherwise attempt to

discover the source code or algorithms of, the Software

(except and only to the extent that such activity is expressly

permitted by applicable law not withstanding this limitation),

or modify, or disable any features of, the Software, or create

derivative works based on the Software. You may not rent,

lease, lend, sublicense or provide commercial hosting

services with the Software.

CONSENT TO USE OF DATA

. You agree that Samsung and its

affiliates may collect and use technical information gathered

as part of the product support services related to the

Software provided to you, if any, such as IMEI (your device’s

unique identification number), device number, model name,

customer code, access recording, your device’s current SW

version, MCC (Mobile Country Code), MNC (Mobile Network

Code). Samsung and its affiliates may use this information

solely to improve their products or to provide customized

services or technologies to you and will not disclose this

information in a form that personally identifies you. At all

times your information will be treated in accordance with

Samsung’s Privacy Policy, which can be viewed at:

http://account.samsung.com/membership/pp

SOFTWARE UPDATES

. Samsung may provide to you or

make available to you updates, upgrades, supplements and

add-on components (if any) of the Software, including bug

fixes, service upgrades (parts or whole), products or devices,

and updates and enhancements to any software previously

installed (including entirely new versions), (collectively

“Update”) after the date you obtain your initial copy of the

Software to improve the Software and ultimately enhance

your user experience with your device. This EULA applies to

all and any component of the Update that Samsung may

provide to you or make available to you after the date you

obtain your initial copy of the Software, unless we provide

other terms along with such Update. To use Software

provided through Update, you must first be licensed for the

Software identified by Samsung as eligible for the Update.

After the Update, you may no longer use the Software that

formed the basis for your Update eligibility. The updated

Software version may add new functions and, in some

limited cases, may delete existing functions.

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 258

While the Update will be generally available, in some limited

circumstances, the Software updates will only be offered by

your network carrier, and such Software updates will be

governed by your contractual relationship with your network

carrier.

With the “Automatic Update” function enabled (as in the

default setting in the System Update menu in the Setting),

your device downloads some Updates automatically from

time to time. Your device will, however, ask for your consent

before installing any Update If you choose to disable the

“Automatic Update” function, then you can check the

availability of new Updates by clicking on the “Check

Update” menu in the Setting. We recommend that you check

availability of any new Updates periodically for optimal use of

your device. If you want to avoid any use of network data for

the Update downloads, then you should choose the “Wi-Fi

Only” option in the Setting. (Regardless of the option you

choose, the “Automatic Update” function downloads Updates

only through Wi-Fi connection.)

6. Some features of the Software may require your device to

have access to the internet and may be subject to

restrictions imposed by your network or internet provider.

Unless your device is connected to the internet through Wi-Fi

connection, the Software will access through your mobile

network, which may result in additional charges depending

on your payment plan. In addition, your enjoyment of some

features of the Software may be affected by the suitability

and performance of your device hardware or data access.

SOFTWARE TRANSFER

. You may not transfer this EULA or

the rights to the Software granted herein to any third party

unless it is in connection with the sale of the mobile device

which the Software accompanied. In such event, the transfer

must include all of the Software (including all component

parts, the media and printed materials, any upgrades, this

EULA) and you may not retain any copies of the Software.

The transfer may not be an indirect transfer, such as a

consignment. Prior to the transfer, the end user receiving the

Software must agree to all the EULA terms.

EXPORT RESTRICTIONS

. You acknowledge that the

Software is subject to export restrictions of various countries.

You agree to comply with all applicable international and

national laws that apply to the Software, including all the

applicable export restriction laws and regulations.

TERMINATION

. This EULA is effective until terminated. Your

rights under this License will terminate automatically without

notice from Samsung if you fail to comply with any of the

DRAFT

FOR INTERNAL USE ONLY

259

terms and conditions of this EULA. Upon termination of this

EULA, you must cease all use of the Software and destroy all

copies, full or partial, of the Software.

10.

DISCLAIMER OF WARRANTY

. UNLESS SEPARATELY STATED

IN A WRITTEN EXPRESS LIMITED WARRANTY

ACCOMPANYING YOUR DEVICE, ALL SOFTWARE PROVIDED

BY SAMSUNG WITH THIS MOBILE DEVICE (WHETHER

INCLUDED WITH THE DEVICE, DOWNLOADED, OR

OTHERWISE OBTAINED) IS PROVIDED "AS IS" AND ON AN

"AS AVAILABLE" BASIS, WITHOUT WARRANTIES OF ANY KIND

FROM SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE

FULLEST EXTENT POSSIBLE PURSUANT TO APPLICABLE

LAW, SAMSUNG DISCLAIMS ALL WARRANTIES EXPRESS,

IMPLIED, OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,

IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY

QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A

PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,

ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT, NON

INFRINGEMENT OF THIRD PARTY RIGHTS OR OTHER

VIOLATION OF RIGHTS. SOME JURISDICTIONS DO NOT

ALLOW EXCLUSIONS OR LIMITATIONS OF IMPLIED

WARRANTIES, SO THE ABOVE EXCLUSIONS OR LIMITATIONS

MAY NOT APPLY TO YOU. NO ADVICE OR INFORMATION,

WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM

SAMSUNG OR ITS AFFILIATES SHALL BE DEEMED TO ALTER

THIS DISCLAIMER BY SAMSUNG OF WARRANTY REGARDING

THE SOFTWARE, OR TO CREATE ANY WARRANTY OF ANY

SORT FROM SAMSUNG.

11.

THIRD-PARTY APPLICATIONS

. Certain third party

applications may be included with, or downloaded to this

mobile device. Samsung makes no representations

whatsoever about any of these applications. Since Samsung

has no control over such applications, you acknowledge and

agree that Samsung is not responsible for the availability of

such applications and is not responsible or liable for any

content, advertising, products, services, or other materials

on or available from such applications. You expressly

acknowledge and agree that use of third party applications is

at your sole risk and that the entire risk of unsatisfactory

quality, performance, accuracy and effort is with you. It is up

to you to take precautions to ensure that whatever you select

to use is free of such items as viruses, worms, Trojan horses,

and other items of a destructive nature. References on this

mobile device to any names, marks, products, or services of

any third-parties are provided solely as a convenience to you,

and do not constitute or imply an endorsement, sponsorship,

or recommendation of, or affiliation with the third party or its

products and services. You agree that Samsung shall not be

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 260

responsible or liable, directly or indirectly, for any damage or

loss, including but not limited to any damage to the mobile

device or loss of data, caused or alleged to be caused by, or

in connection with, use of or reliance on any such third party

content, products, or services available on or through any

such application. You acknowledge and agree that the use of

any third-party application is governed by such third party

application provider's Terms of Use, License Agreement,

information or personal data you provide, whether knowingly

or unknowingly, to such third-party application provider, will

be subject to such third party application provider's privacy

policy, if such a policy exists. SAMSUNG DISCLAIMS ANY

RESPONSIBILITY FOR ANY DISCLOSURE OF INFORMATION OR

ANY OTHER PRACTICES OF ANY THIRD PARTY APPLICATION

PROVIDER. SAMSUNG EXPRESSLY DISCLAIMS ANY

WARRANTY REGARDING WHETHER YOUR PERSONAL

INFORMATION IS CAPTURED BY ANY THIRD PARTY

APPLICATION PROVIDER OR THE USE TO WHICH SUCH

PERSONAL INFORMATION MAY BE PUT BY SUCH THIRD

PARTY APPLICATION PROVIDER.

12.

SAMSUNG APPLICATIONS

. Certain Samsung applications

and services may be included with, or downloaded to, this

mobile device. Many of them require Samsung Services

membership registration (“Samsung Account”), and your

rights and obligations will be set forth in separate Samsung

Account terms and conditions and privacy policies. There are

non-Samsung Account applications and services that require

your consent to their separate terms and conditions and

privacy policies. You expressly acknowledge and agree that

your use of such applications and services will be subject to

the applicable terms and conditions and privacy policies.

13.

LIMITATION OF LIABILITY

. SAMSUNG WILL NOT BE LIABLE

FOR ANY DAMAGES OF ANY KIND ARISING OUT OF OR

RELATING TO THE USE OR THE INABILITY TO USE THE

SOFTWARE OR ANY THIRD PARTY APPLICATION, ITS

CONTENT OR FUNCTIONALITY, INCLUDING BUT NOT LIMITED

TO DAMAGES CAUSED BY OR RELATED TO ERRORS,

OMISSIONS, INTERRUPTIONS, DEFECTS, DELAY IN

OPERATION OR TRANSMISSION, COMPUTER VIRUS, FAILURE

TO CONNECT, NETWORK CHARGES, IN-APP PURCHASES,

AND ALL OTHER DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

EXEMPLARY, OR CONSEQUENTIAL DAMAGES EVEN IF

SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH

DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE

EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSIONS OR

LIMITATIONS MAY NOT APPLY TO YOU. NOTWITHSTANDING

DRAFT

FOR INTERNAL USE ONLY

261

THE FOREGOING, SAMSUNG ELECTRONIC CO.'S TOTAL

LIABILITY TO YOU FOR ALL LOSSES, DAMAGES, CAUSES OF

ACTION, INCLUDING BUT NOT LIMITED TO THOSE BASED ON

CONTRACT, TORT, OR OTHERWISE, ARISING OUT OF YOUR

USE OF THE SOFTWARE OR THIRD PARTY APPLICATIONS ON

THIS MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS

EULA, SHALL NOT EXCEED THE AMOUNT PURCHASER PAID

SPECIFICALLY FOR THIS MOBILE DEVICE OR ANY SUCH

THIRD PARTY APPLICATION THAT WAS INCLUDED WITH THIS

MOBILE DEVICE. THE FOREGOING LIMITATIONS,

EXCLUSIONS, AND DISCLAIMERS (INCLUDING SECTIONS 10,

11, 12 AND 13) SHALL APPLY TO THE MAXIMUM EXTENT

PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY

FAILS ITS ESSENTIAL PURPOSE.

14.

U.S. GOVERNMENT END USERS RESTRICTED RIGHTS

. The

Software is licensed only with "restricted rights" and as

"commercial items" consisting of "commercial software"

and "commercial software documentation" with only those

rights as are granted to all other end users pursuant to the

terms and conditions herein. All Products are provided only

with "restricted rights" with only those rights as are granted

to all other end users pursuant to the terms and conditions

herein. All Software and Products are provided subject to

Federal Acquisition Regulation (FAR) 52.227.19.

15.

APPLICABLE LAW

. This EULA is governed by the laws of

the jurisdiction where you are a resident or, if a resident of

the United States, by the laws of the state of Texas, without

regard to its conflict of law provisions. This EULA shall not be

governed by the UN Convention on Contracts for the

International Sale of Goods, the application of which is

expressly excluded.

16.

DISPUTE RESOLUTION

(a) Non-United States residents. If a dispute, controversy or

difference arising in any way from this EULA or your use of

the Software is not amicably settled, it shall be subject to the

non-exclusive jurisdiction of the courts of the jurisdiction

where you are a resident. Notwithstanding the foregoing,

Samsung may apply for injunctive remedies (or an equivalent

type of urgent legal relief) in any jurisdiction.

(b) United States residents. ALL DISPUTES WITH SAMSUNG

ARISING IN ANY WAY FROM THIS EULA OR YOUR USE OF THE

SOFTWARE SHALL BE RESOLVED EXCLUSIVELY THROUGH

FINAL AND BINDING ARBITRATION, AND NOT BY A COURT OR

JURY. Any such dispute shall not be combined or

consolidated with any other person’s or entity’s claim or

dispute, and specifically, without limitation of the foregoing,

shall not under any circumstances proceed as part of a class

DRAFT

FOR INTERNAL USE ONLY

Warranty Information 262

action. The arbitration shall be conducted before a single

arbitrator, whose award may not exceed, in form or amount,

the relief allowed by the applicable law. The arbitration shall

be conducted according to the American Arbitration

Association (AAA) Commercial Arbitration Rules applicable to

consumer disputes. This arbitration provision is entered

pursuant to the Federal Arbitration Act. The laws of the State

of Texas, without reference to its choice of laws principles,

shall govern the interpretation of the EULA and all disputes

that are subject to this arbitration provision. The arbitrator

shall decide all issues of interpretation and application of this

arbitration provision and the EULA. For any arbitration in

which your total damage claims, exclusive of attorney fees

and expert witness fees, are $5,000.00 or less ("Small

Claim"), the arbitrator may, if you prevail, award your

reasonable attorney fees, expert witness fees and costs as

part of any award, but may not grant Samsung its attorney

fees, expert witness fees or costs unless it is determined that

the claim was brought in bad faith. In a Small Claim case,

you shall be required to pay no more than half of the total

administrative, facility and arbitrator fees, or $50.00 of such

fees, whichever is less, and Samsung shall pay the

remainder of such fees. Administrative, facility and arbitrator

fees for arbitrations in which your total damage claims,

exclusive of attorney fees and expert witness fees, exceed

$5,000.00 ("Large Claim") shall be determined according to

AAA rules. In a Large Claim case, the arbitrator may grant to

the prevailing party, or apportion among the parties,

reasonable attorney fees, expert witness fees and costs.

Judgment may be entered on the arbitrator's award in any

court of competent jurisdiction. This arbitration provision also

applies to claims against Samsung’s employees,

representatives and affiliates if any such claim arises from

the licensing or use of the Software. You may opt out of this

dispute resolution procedure by providing notice to Samsung

no later than 30 calendar days from the date of the first

consumer purchaser’s purchase of this device. To opt out,

you must send notice by e-mail to

optout@sta.samsung.com, with the subject line: "Arbitration

Opt Out." You must include in the opt out e-mail (a) your

name and address; (b) the date on which the device was

purchased; (c) the device model name or model number; and

(d) the IMEI or MEID or Serial Number, as applicable, if you

have it (the IMEI or MEID or Serial Number can be found (i) on

the device box; (ii) on the device information screen, which

can be found under "Settings;" (iii) on a label on the back of

the device beneath the battery, if the battery is removable;

and (iv) on the outside of the device if the battery is not

DRAFT

FOR INTERNAL USE ONLY

263

removable). Alternatively, you may opt out by calling

1-888-987-4357 no later than 30 calendar days from the

date of the first consumer purchaser's purchase of the

device and providing the same information. These are the

only two forms of notice that will be effective to opt out of

this dispute resolution procedure. Opting out of this dispute

resolution procedure will not affect your use of the device or

its preloaded Software, and you will continue to enjoy the

benefits of this license.

17.

ENTIRE AGREEMENT; SEVERABILITY

. This EULA is the

entire agreement between you and Samsung relating to the

Software and supersedes all prior or contemporaneous oral

or written communications, proposals and representations

with respect to the Software or any other subject matter

covered by this EULA. If any provision of this EULA is held to

be void, invalid, unenforceable or illegal, the other provisions

shall continue in full force and effect. [050113]

DRAFT

FOR INTERNAL USE ONLY

Samsung Product Registration 264

Section 13: Samsung Product Registration

www.samsung.com/register

Get More

• Latest info on promotions, events and special oers on related products

• Review Samsung products and share your opinion

• Great deals on downloads

Customize your Samsung device experience

• Activate product warranty

• Access to a personalized My Samsung Mobile account

• No monthly fees

Scan this code to go

directly to the registration page.

DRAFT

FOR INTERNAL USE ONLY

265

Index

Abc mode 63

About Device 156

Accounts 144

Add accounts 144

Adding a New Contact

Idle Screen 67

Address Book 66

Adding a New Contact 67

Adding Pauses to Contact

Numbers 68

Copying a contact to the Phone 78

Copying Contacts to Phone 78

Copying Contacts to SIM Card 77

Deleting Address Book Entries 79

Deleting Contacts from

SIM card 78

Dialing a Number 69

Favorites 77

Finding an Address Book Entry 69

Group Settings 75

Managing Address Book

Contacts 77

Service Dialing Numbers 79

Using Contacts List 69

Address Book Options 73

Adobe PDF 205

Air Gesture

Quick Glance 36

Airplane mode 111, 122

Alarm 184

Android Beam 117

Applications

Using the Camcorder 88

Using the Camera 80

World Clock 186

Applications settings

managing 153

running services 154

AT&T DriveMode 179

AT&T FamilyMap 179

AT&T Locker 180

AT&T Navigator 180

AT&T Smart Wi-Fi 170

Back key 34

Backing up your data 145

Battery

charging 9

Display Percentage 11

Installing 7

Low Battery Indicator 11

Battery Use & Safety 236

Bigger Font

Setting 134

Blocking Mode 132

On 132

Bluetooth

Outgoing Headset Condition 127

Sending contacts 175

Books

Play Books 202

Browsert 158

Bubble

Options 96

DRAFT

FOR INTERNAL USE ONLY

266

Calculator 181

Calendar 182

Calibration 142

Call Functions 50

3-Way Calling (Multi-Party

Calling) 59

Address Book 52

Adjusting the Call Volume 57

Answering a Call 53

Call Back Missed Call 54

Call Duration 56

Call forwarding 61

Call Log 54

Call waiting 61

Correcting the Number 51

Dialing a Recent Number 51

Ending a Call 51

International Call 50

Making a Call 50

Manual Pause Dialing 50

Options During a Call 57

Putting a Call on Hold 58

Saving a recent call number to

Address Book 55

Searching for a Number in

Address Book 61

Using the Speakerphone 60

Call rejection 126

Call Sound

Adding More Volume 57

Personalize 58

Camcorder 88

Settings 84

Shooting Video 88

Camcorder Options

Camcorder Options after a Video is

Taken 88

Camera 80

Modes 81

Quick Settings 84

Settings 84

Taking Pictures 80

Care and Maintenance 241

Changing Your Settings 107

Charging battery 9

ChatON 106

Children and Cell Phones 231

Clock 184

Commercial Mobile Alerting System

(CMAS) 100, 234

Contacts 66

Emptying 163

Creating a Playlist 197

Dialing Options 54

Display

icons 22

Using Negative Colors 134

Display / Touch-Screen 239

Do cell phones pose a health

hazard? 227

Downloads 188

Draft Messages 93

DriveMode 179

Editing a Picture 86

Email 100

Creating a Corporate Email

Account 101

DRAFT

FOR INTERNAL USE ONLY

267

Creating Additional Email

Accounts 101

Switching Between Email

Accounts 102

Emergency alert settings 99

Emergency Alerts (CMAS) 100

Emergency Calls 240

Making 51

With SIM 52

Without SIM 51

Entering Text 62

Changing the Text Entry Mode 63

Using 123Sym Mode 64

Using Abc Mode 63

Using Swype 65

Using Symbol/Numeric Mode 64

Exposure to Radio Frequency (RF)

Signals 227

Extra Volume 57

Family Map 179

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless

Devices 246

FCC Notice and Cautions 248

Featured Apps 189

Flipboard 189

Font Size

Changing 134

Gallery 89

viewing pictures 89

viewing videos 90

Gestures 141

Overview 36

Getting Started 6

Setting Up Your Phone 6

Voice mail 15

Gmail 102

Google

Ads 190

Google Chrome 184

Google Maps 193

Google Play Music 204

Google Voice Typing 65

Google voice typing settings 137

GPS 240

Group

Adding a contact 75

Editing 76

Removing a contact 75

Group Settings

Editing a Caller Group 76

Health and Safety Information 227

Home key 34

Home screen mode 125

Hotspots 111, 112, 114

Icons

Application 26

Indicator 22

Icons, description 22

In-Call Options 57

Incognito 161

Create Window 161

Exit Window 161

International Call 50

Joining Contacts 71

DRAFT

FOR INTERNAL USE ONLY

268

Keyboard Input Methods 137

Keyboard settings 138

Keypad

Changing Text Input 63

Kies via Wi-Fi 114

Landscape 62

Language and input 136

Language and keyboard settings

select locale 136

Local 192

Location services 147

Location services settings 119

Lock Screen

Say Wake-Up Command 120

Shortcuts 120

Maps 193

Memory Card 48

Memory Card Installation 8

key 34

Menu Navigation 34

Message

Thread Options 96

Message Options 93

Message Search 97

Messaging

Adding a Signature 99

Block Unknown Senders 99

Creating and Sending Text

Messages 92

Deleting a message 97

Draft 93

Gmail 102

Locked 93

Options 93

Scheduled Messages 93

Settings 97

Signing into Email 100

Signing into Gmail 102

Spam 94

Translate Text 94

Types of Messages 92

microSD card 8, 48

Installing 8

Removing 9

microSDHC card 8, 48

Mobile Hotspot 114

Mobile TV 194

Mobile Web

Entering Text in the Mobile Web

Browser 160

Navigating with the Mobile

Web 159

Using Bookmarks 161

Mono

Audio Setup 135

Motion 141

Activate 36

Overview 36

Motions 141

Movies 203

Multimedia 80

Music 195

Music Options 196

DRAFT

FOR INTERNAL USE ONLY

269

Music Player 195

adding music 197

creating a playlist 197

playlists 197

removing music 198

settings 196

Mute 57, 60

My Files 198

myAT&T 199

Navigation 200

command keys 34

context-sensitive menus 35

terms used 35

touch gestures 35

Navigator 180

Nearby devices 118

Negative Colors 134

NFC

On 90

Noise Reduction 58

Operating Environment 244

Other Important Safety

Information 249

PC Connections 175

Personal Localized Alerting Network

(PLAN) 100, 234

Phone

Front View 17

icons 22

Rear View 21

Side View 19

Switching On/Off 11


Editing 86


Color Correction 87

Face Corrections 87

Frame 87

Pictures 89

Gallery 89

Sharing 90

Places 202

Play Books 202

Play Movies & TV 203

Play Music 204

Play Store 204

Pointer speed 141

POLARIS Office 5 205

POLARIS® Office 5 205

Polaris® Office 5 32

Power Saving Mode 133

Powering

Off 11

On 11

Privacy settings

factory data reset 146

QWERTY keypad 62

Red Eye

Correction 87

Reducing Exposure

Hands-Free Kits and Other

Accessories 230

Reject list 56

remote control WatchON 219

DRAFT

FOR INTERNAL USE ONLY

270

Reset

factory data 146

Responsible Listening 242

Restricting Children's Access to Your

Mobile Device 248

S Beam 117

On 90

Sharing Multiple Pictures 91

Sharing Pictures 90

S Memo 205

Creating a New Memo 205

S Translator 207

S Voice 208

Set Wake-Up Command 120

SafeSearch

Filtering 224

Samsung Hub

Creating a New Account 209

Using 210

Samsung Link

Sharing Media 214

Samsung Link Settings 213

Samsung Mobile Products and

Recycling 238

scientific calculator 181

SD Card 48

Security 145, 147

Security settings

device administration 150

trusted credentials 151

Service Dialing Numbers 79

Settings 84, 107

Shortcuts 22

SIM card

installation 6

Installing 6

Smart Practices While Driving 234

Smart screen 143

Smart Switch 16

Smart Wi-Fi 170

Snooze 185

Software Update 157

Spam

Add Number 94, 96

Block Unknown Senders 99

Settings 99

Spam Messages

Assigning 94

Speakerphone Key 60

Specific Absorption Rate (SAR)

Certification Information 232

Standard Limited Warranty 251

Stopwatch 186

Swap 58

SWYPE

entering text using 65

Symbol/Numeric mode 64

Synchronization settings

auto-sync 119

Synchronizing Accounts 145

Tethering 114

Text Input

Abc mode 63

Methods 62

numeric mode 64

symbol mode 64

Timer 187

Automatic Answering 127

DRAFT

FOR INTERNAL USE ONLY

271

Touch Screen 12

Lock/Unlock 12

Transferring Large Files 90

Translate 94

TranslateMessage Bubble 97

Translator 207

Travel Charger 9

Using 10

TTY Mode 131

UL Certified Travel Charger 239

Understanding Your Phone 16

Features of Your Phone 16

Front View 17

Rear View 21

Side Views 19

Unmute 57

USB settings

mass storage device 176

USB Tethering 115

Using Favorites

Adding Favorites 162

Deleting a Favorite 162

Editing Favorites 162

Video 215

Video player 215

Voice control 143

Voice Mail

Accessing 15

From Another Phone 15

Setup 15

Voice Recorder 217

Volume 122

Warranty Information 251

WatchON 219

Adding a New Room 223

Changing Channels 221

Configure Just For You 222

Initial Configuration 219

Locating Programs 221

Personalize 222

Settings 222

Using 221

Web 158

Widgets

Calculator 27

Camera 27

Email 28

Gmail 29, 189

Settings 33, 214

Voice Recorder 217

Wi-Fi 166

using Kies via Wi-Fi 119

Wi-Fi Direct 108, 169

Wi-Fi Settings 108

World Clock

Deleting an Entry 186

World clock 186

YouTube 223

High Quality 223

SafeSearch Filtering 224

Settings 224

YPmobile (Yellowpages mobile) 225

DRAFT

FOR INTERNAL USE ONLY

Samsung Electronics Co SMC105A Multi-band GSM/EDGE/UMTS/LTE Handset with WLAN, Bluetooth and RFID User Manual C105A ZOOM

Samsung Electronics Co Ltd Multi-band GSM/EDGE/UMTS/LTE Handset with WLAN, Bluetooth and RFID C105A ZOOM

Contents

Users Manual 2

Navigation menu

Namespaces

Views

Navigation
