Users Manual
DRAFT
Internal Use Only
4G LTE SMARTPHONE
User Manual
Please read this manual before operating your
phone and keep it for future reference.
This document is watermarked because certain important information in the document has not yet been verified.
This document has been sent to you as a draft and for informational purposes only.
The document should only be used for internal purposes and may not be distributed outside of Samsung,
except to Samsung's carrier customer for testing purposes. Distributing the
document outside of Samsung, except to Samsung's carrier customer for testing purposes could result in legal exposure
to the company if the preliminary, unverified information in the draft turns out to be inaccurate.
DRAFT
Internal Use Only
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone
System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the
rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain
with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser
General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered
under the open source licenses, please visit:
http://opensource.samsung.com
.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
DRAFT
Internal Use Only
THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS
OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,
OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR
CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.
SAFE™ (Samsung Approved For Enterprise)
SAFE™: "SAFE™" (Samsung for Enterprise) is a mark for a Samsung device which has been tested against Samsung's own
internal criteria for interoperability with certain third party security-related solutions for MDM and VPN. The testing includes field
testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the
Samsung device. During the testing, the device is tested with the security solutions to see if the solutions work with the device as
described by the third party security solution providers. The testing, for example, includes field testing with local network
connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. For more
information about Samsung's SAFE™ program, please refer to
www.samsung.com/us/safe
.
Disclaimer of Warranties: EXCEPT AS OTHERWISE PROVIDED IN THEIR STANDARD END USER LICENSE AND WARRANTY, TO THE
FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD., SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND
THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE "SAMSUNG ENTITIES") EXPRESSLY DISCLAIM ANY AND ALL
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
INTEROPERABILITY OR NON-INFRINGEMENT, WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™
DRAFT
Internal Use Only
DEVICES AND APPLICATIONS TESTED WITH SAFE™ DEVICES. IN NO EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY
DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO
INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES OR APPLICATIONS TESTED WITH SAFE™ DEVICES. In
addition, information technology security protection will be affected by features or functionality associated with, among other
things the e-mail platform, master data management, and virtual private network solutions selected by the software provider,
solution provider or user. Choice of an e-mail, master data management, and virtual private network solution is at the sole
discretion of the software provider, solution provider or user and any associated effect on information technology security
protection is solely the responsibility of the software provider, solution provider or user. For complete statement of limited
warranty, please refer to
www.samsung.com/us/safe
, available on the web and where Samsung smartphone and Galaxy Tab™
devices are sold. [101212]
Samsung Telecommunications America (STA), LLC
Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082
Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
DRAFT
Internal Use Only
©2013 Samsung Telecommunications America, LLC. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
Do you have questions about your Samsung Mobile Device?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications,
Inc., or its affiliates in the United States and/or other countries.
ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.
microSD™ and the microSD logo are Trademarks of the SD Card Association.
Openwave® is a registered Trademark of Openwave, Inc.
Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail, Google Maps, Google Music, Google
Hangouts, Picasa, YouTube and other marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
LTE is a trademark of ETSI
Swype and the Swype logos are trademarks of Swype, Inc. © 2010 Swype, Inc. All rights reserved.
, DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under
license.
Internet Address:
http://www.samsung.com
DRAFT
Internal Use Only
DivX Certified® to play DivX® video up to HD 720p, including premium content.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX
Certified® device that has passed rigorous testing to verify that it plays DivX video. Visit
www.divx.com
for more information and
software tools to convert your files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX
Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu (tap
Apps > Settings > More
tab
> About device > Legal information > License settings > DivX® VOD > Register
). Go to
vod.divx.com
for
more information on how to complete your registration.
Dynamic Noise Suppression from Audience
Your phone is equipped with an advanced voice processing chip that delivers clear mobile calls by suppressing background noise,
intermittent sounds (like a siren or nearby conversation), and echoes, allowing you to hear and be heard nearly anywhere.
How Does It Work?
Based on the intelligence of the human hearing system, the technology:
•
Captures, evaluates and distinguishes all the sound signals surrounding your phone, and the person you're speaking with.
•
Then isolates the primary voice in conversation and filters out the background noise - so the person you're calling hears only your voice,
without disturbing background noise.
•
Dynamically equalizes and adjusts voice volume to optimize your calling experience, so you can hear clearly and don't need to speak louder to
overcome surrounding noise.
The noise suppression technology is built-in and already enabled in your new mobile phone. So it's ready to provide unsurpassed
voice clarity with every call.
DRAFT
Internal Use Only
1
Table of Contents
Section 1: Getting Started .......................... 7
Understanding this User Manual . . . . . . . . . . . . 7
Removing the Battery Cover . . . . . . . . . . . . . . . 9
Installing and Removing the SIM card . . . . . . 10
Installing the microSD Memory Card . . . . . . . 11
Installing the Battery . . . . . . . . . . . . . . . . . . . 12
Replacing the Battery Cover . . . . . . . . . . . . . . 12
Charging the Battery . . . . . . . . . . . . . . . . . . . 13
Extending Your Battery Life . . . . . . . . . . . . . . 15
Switching the Device On or Off . . . . . . . . . . . . 16
Initial Device Configuration . . . . . . . . . . . . . . . 16
Restarting the Device . . . . . . . . . . . . . . . . . . . 17
Locking and Unlocking the Device . . . . . . . . . 17
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Section 2: Understanding Your Device .... 19
Features of Your Device . . . . . . . . . . . . . . . . . 19
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Side Views . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Device Display . . . . . . . . . . . . . . . . . . . . . . . . 24
Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . 30
Customizing the Screens . . . . . . . . . . . . . . . . 35
Screen Navigation . . . . . . . . . . . . . . . . . . . . . 41
Using Motions and Gestures . . . . . . . . . . . . . . 42
Using the Multi Window . . . . . . . . . . . . . . . . . 44
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . 50
Section 3: Call Functions and
Contacts List ..............................................51
Displaying Your Phone Number . . . . . . . . . . . 51
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . 51
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . 52
Making Emergency Calls . . . . . . . . . . . . . . . . 53
Dialing Options . . . . . . . . . . . . . . . . . . . . . . . . 54
Answering a Call . . . . . . . . . . . . . . . . . . . . . . 54
Managing Reject Calls . . . . . . . . . . . . . . . . . . 55
International Calls . . . . . . . . . . . . . . . . . . . . . 56
Pause Dialing . . . . . . . . . . . . . . . . . . . . . . . . . 57
DRAFT
Internal Use Only
2
Wait Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Redialing the Last Number . . . . . . . . . . . . . . .58
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . 58
Wi-Fi Calling . . . . . . . . . . . . . . . . . . . . . . . . . .60
In Call Options . . . . . . . . . . . . . . . . . . . . . . . . . 63
Logs Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Section 4: Entering Text ............................73
Text Input Methods . . . . . . . . . . . . . . . . . . . . .73
Selecting the Text Input Method . . . . . . . . . . .73
Entering Text Using Swype . . . . . . . . . . . . . . .74
Using the Samsung Keyboard . . . . . . . . . . . . . 78
Using the Google Voice Typing . . . . . . . . . . . . . 81
Section 5: Contacts ...................................83
Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Contacts List . . . . . . . . . . . . . . . . . . . . . . . . . .83
Finding a Contact . . . . . . . . . . . . . . . . . . . . . . 87
Contact List Options . . . . . . . . . . . . . . . . . . . . 90
Contact Menu Options . . . . . . . . . . . . . . . . . . . 91
Contact Entry Options . . . . . . . . . . . . . . . . . . . 91
Linking Contact Information . . . . . . . . . . . . . . .92
Sending a Namecard . . . . . . . . . . . . . . . . . . . .94
Copying Contact Information . . . . . . . . . . . . . . 96
Synchronizing Contacts . . . . . . . . . . . . . . . . . .97
Display Options . . . . . . . . . . . . . . . . . . . . . . . .97
Adding more Contacts via Accounts
and Sync . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Additional Contact Options . . . . . . . . . . . . . . .100
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
The Favorites Tab . . . . . . . . . . . . . . . . . . . . .103
Section 6: Messages ...............................104
Types of Messages . . . . . . . . . . . . . . . . . . . .104
Creating and Sending Messages . . . . . . . . . .105
Message Options . . . . . . . . . . . . . . . . . . . . . .106
Viewing Newly Received Messages . . . . . . . .110
Deleting Messages . . . . . . . . . . . . . . . . . . . .112
Message Search . . . . . . . . . . . . . . . . . . . . . .113
Messaging Settings . . . . . . . . . . . . . . . . . . . .113
Assigning Messages as Spam . . . . . . . . . . . .116
Accessing Your Spam Folder . . . . . . . . . . . . .118
Text Templates . . . . . . . . . . . . . . . . . . . . . . .118
Using Email . . . . . . . . . . . . . . . . . . . . . . . . . .118
Microsoft Exchange Email (Outlook) . . . . . . . .124
Using Google Mail . . . . . . . . . . . . . . . . . . . . .130
DRAFT
Internal Use Only
3
Section 7: Multimedia ............................ 132
Assigning the Default Storage Location . . . . 132
Using the Camera . . . . . . . . . . . . . . . . . . . . 133
Camera Options . . . . . . . . . . . . . . . . . . . . . . 134
Quick Settings . . . . . . . . . . . . . . . . . . . . . . . 136
Camera and Camcorder Settings . . . . . . . . . 137
Using the Camcorder . . . . . . . . . . . . . . . . . . 141
Sharing Pictures . . . . . . . . . . . . . . . . . . . . . 144
Editing a Photo . . . . . . . . . . . . . . . . . . . . . . . 150
The Gallery . . . . . . . . . . . . . . . . . . . . . . . . . 152
AllShare Cast Hub . . . . . . . . . . . . . . . . . . . . 153
Section 8: Applications and
Development ............................................ 155
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 155
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Dropbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Flipboard . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
G+ Photos . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Google . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Google Settings . . . . . . . . . . . . . . . . . . . . . . 171
Google + . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Group Play . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
KNOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Lookout Security . . . . . . . . . . . . . . . . . . . . . 182
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Mobile HotSpot . . . . . . . . . . . . . . . . . . . . . . . 184
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Using Playlists . . . . . . . . . . . . . . . . . . . . . . . 188
Transferring Music Files . . . . . . . . . . . . . . . . 189
Removing Music Files . . . . . . . . . . . . . . . . . 189
DRAFT
Internal Use Only
4
My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Optical Reader . . . . . . . . . . . . . . . . . . . . . . . .191
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Play Books . . . . . . . . . . . . . . . . . . . . . . . . . .192
Play Games . . . . . . . . . . . . . . . . . . . . . . . . . .193
Play Magazines . . . . . . . . . . . . . . . . . . . . . . .193
Play Movies & TV . . . . . . . . . . . . . . . . . . . . . .193
Play Music . . . . . . . . . . . . . . . . . . . . . . . . . .194
Play Store . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Downloading a New Google Application . . . . . 197
Launching an Installed Google Application . . . 199
POLARIS Office 5 . . . . . . . . . . . . . . . . . . . . . . 200
S Health . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
S Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
S Translator . . . . . . . . . . . . . . . . . . . . . . . . .204
S Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Samsung Apps . . . . . . . . . . . . . . . . . . . . . . .206
Samsung Hub . . . . . . . . . . . . . . . . . . . . . . . .207
Samsung Link . . . . . . . . . . . . . . . . . . . . . . . .210
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Story Album . . . . . . . . . . . . . . . . . . . . . . . . . 214
T-Mobile My Account . . . . . . . . . . . . . . . . . . 215
T-Mobile Name ID . . . . . . . . . . . . . . . . . . . . .215
T-Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . .216
TripAdvisor . . . . . . . . . . . . . . . . . . . . . . . . . .216
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .217
Visual Voicemail . . . . . . . . . . . . . . . . . . . . . .219
Voice Recorder . . . . . . . . . . . . . . . . . . . . . . .220
Voice Search . . . . . . . . . . . . . . . . . . . . . . . . .221
VPN Client . . . . . . . . . . . . . . . . . . . . . . . . . . .221
WatchON . . . . . . . . . . . . . . . . . . . . . . . . . . . .221
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . .226
Section 9: Connections ...........................228
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . .228
Enable Downloading for Web Applications . . .233
PC Connections . . . . . . . . . . . . . . . . . . . . . . .233
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .234
USB Tethering . . . . . . . . . . . . . . . . . . . . . . . .237
Mobile HotSpot . . . . . . . . . . . . . . . . . . . . . . .238
Section 10: Changing Your Settings ......241
Accessing the Settings Tabs . . . . . . . . . . . . .241
Settings Tabs - Overview . . . . . . . . . . . . . . . .241
Wi-Fi Settings . . . . . . . . . . . . . . . . . . . . . . . .242
Bluetooth settings . . . . . . . . . . . . . . . . . . . . .248
DRAFT
Internal Use Only
5
Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . 249
More Networks . . . . . . . . . . . . . . . . . . . . . . 250
Lock Screen . . . . . . . . . . . . . . . . . . . . . . . . . 259
Display Settings . . . . . . . . . . . . . . . . . . . . . . 265
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . 267
Sound Settings . . . . . . . . . . . . . . . . . . . . . . 267
Home Screen Mode . . . . . . . . . . . . . . . . . . . 270
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . 271
Blocking Mode . . . . . . . . . . . . . . . . . . . . . . . 279
Hands-free Mode . . . . . . . . . . . . . . . . . . . . . 280
Power Saving Mode . . . . . . . . . . . . . . . . . . . 280
Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Accessibility Settings . . . . . . . . . . . . . . . . . . 281
Language and Input Settings . . . . . . . . . . . . 284
Motions and Gestures Settings . . . . . . . . . . . 290
Smart screen . . . . . . . . . . . . . . . . . . . . . . . . 293
Air view . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Voice control . . . . . . . . . . . . . . . . . . . . . . . . 294
Add Account . . . . . . . . . . . . . . . . . . . . . . . . 295
Cloud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Backup and Reset . . . . . . . . . . . . . . . . . . . . 298
Backing up Your Data Before Factory Reset . 298
Location Services . . . . . . . . . . . . . . . . . . . . . 303
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Application Manager . . . . . . . . . . . . . . . . . . 307
Battery Usage . . . . . . . . . . . . . . . . . . . . . . . . 309
SD Card & Device Storage . . . . . . . . . . . . . . 310
Date and Time . . . . . . . . . . . . . . . . . . . . . . . 311
About Device . . . . . . . . . . . . . . . . . . . . . . . . 312
Software Update . . . . . . . . . . . . . . . . . . . . . 313
Section 11: Health and Safety
Information ...............................................314
Exposure to Radio Frequency (RF) Signals . . 314
Specific Absorption Rate (SAR) Certification
Information . . . . . . . . . . . . . . . . . . . . . . . . 319
FCC Part 15 Information to User . . . . . . . . . . 321
Commercial Mobile Alerting System (CMAS) . 321
Smart Practices While Driving . . . . . . . . . . . 321
Battery Use and Safety . . . . . . . . . . . . . . . . . 323
Samsung Mobile Products and Recycling . . . 324
UL Certified Travel Charger . . . . . . . . . . . . . . 326
Display / Touch-Screen . . . . . . . . . . . . . . . . 326
GPS & AGPS . . . . . . . . . . . . . . . . . . . . . . . . . 327
Emergency Calls . . . . . . . . . . . . . . . . . . . . . 328
DRAFT
Internal Use Only
6
Care and Maintenance . . . . . . . . . . . . . . . . .328
Responsible Listening . . . . . . . . . . . . . . . . . .329
Operating Environment . . . . . . . . . . . . . . . . . 332
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices . . . . . . . .334
Restricting Children's Access to Your
Mobile Device . . . . . . . . . . . . . . . . . . . . . . 335
FCC Notice and Cautions . . . . . . . . . . . . . . . . 336
Other Important Safety Information . . . . . . . . 336
Section 12: Warranty Information ..........338
Standard Limited Warranty . . . . . . . . . . . . . . 338
End User License Agreement for Software . . . 343
Index .........................................................351
DRAFT
Internal Use Only
Getting Started 7
Section 1: Getting Started
This section explains how to get started with your phone by
installing and charging the battery, installing the micro SIM
card and optional memory card, and setting up your voice
mail.
Before using your device for the first time, you’ll need to
install and charge the battery and install the micro SIM card.
The micro SIM card is loaded with your subscription details,
such as your PIN, available optional services, and many other
features. If desired, you can also install an SD card to store
media for use with your device.
Understanding this User Manual
The sections of this manual generally follow the features of
your phone. A robust index for features begins on page 351.
Also included is important safety information that you should
know before using your phone. This information is available
near the back of the guide, beginning on page 314.
This manual provides navigation instructions according to
the default display settings. If you select other settings,
navigation may be different.
Unless otherwise specified, all instructions in this manual
assume you are starting from the Home screen and using the
available keys.
Note:
Instructions in this manual are based on default settings,
and may vary from your device, depending on the
software version on your device, and any changes to the
device’s Settings.
Unless stated otherwise, instructions in this User Manual
start with the device unlocked, at the Home screen.
All screen images in this manual are simulated. Actual
displays may vary, depending on the software version of
your device and any changes to the device’s Settings.
DRAFT
Internal Use Only
8
Special Text
Throughout this manual, you’ll find text that is set apart from
the rest. These are intended to point out important
information, share quick methods for activating features, to
define terms, and more. The definitions for these methods
are as follows:
•
Notes
: Presents alternative options for the current feature, menu,
or sub-menu.
•
Tips
: Provides quick or innovative methods, or useful shortcuts.
•
Important
: Points out important information about the current
feature that could affect performance.
•
Warning
: Brings to your attention important information to
prevent loss of data or functionality, or even prevent damage to
your phone.
Text Conventions
This manual provides condensed information about how to
use your phone. To make this possible, the following text
conventions are used to represent often-used steps:
Example:
From the Home screen, press (
Menu
)
➔
Settings
➔
Connections
tab
➔
Bluetooth
.
➔
Arrows are used to represent the sequence of
selecting successive options in longer, or
repetitive, procedures.
DRAFT
Internal Use Only
Getting Started 9
Removing the Battery Cover
The battery, micro SIM card and SD card are installed under
the battery cover.
Important!
Before removing or replacing the battery cover,
make sure the device is switched off. To turn the
device off, hold down the key until the
power-off image displays, then tap
Power off
.
Caution!
Do not bend or twist the back cover excessively
during installation or removal. Doing so may damage
the cover.
To remove the battery cover:
1. Hold the device firmly and locate the cover release
latch (1).
2. Place your fingernail in the opening (2) and firmly
“pop” the cover off the device (similar to a soda can).
DRAFT
Internal Use Only
10
Installing and Removing the SIM card
This device uses a different type of SIM card called a “micro
SIM”. Other larger SIM cards will not function or fit within this
slot.
SIM Card Overview
Important!
Before removing or replacing the micro SIM card,
make sure the device is switched off. To turn the
phone off, hold down the key until the
Device options pop up displays, then tap
Power off
.
The micro SIM card is loaded with your subscription details
such as your telephone number, PIN, available optional
services, and many other features.
Important!
The micro SIM card and its information can be
easily damaged by scratching or bending, so be
careful when handling, inserting, or removing the
card. Keep all SIM cards out of reach of small
children.
Some features on your device (such as Wi-Fi Calling) can be
unlocked by using the new micro SIM card.
To use this new micro SIM card, call or contact T-Mobile
customer service for more information.
This card contains the necessary information for identifying
and authenticating the user to the IMS (IP Multimedia
Subsystem).
To install the SIM card:
1. Carefully slide the micro SIM card into the SIM card
socket until it clicks into place.
2. Make sure that the card’s gold contacts face into the
device and that the upper-left angled corner of the card
is positioned as shown.
Micro SIM card
DRAFT
Internal Use Only
Getting Started 11
To remove the micro SIM card:
1. Remove the battery cover.
2. Carefully place your fingernail into the end of the micro
SIM slot and push the card slightly out.
3. Carefully slide the card out of the micro SIM card
socket.
Note:
If the card is not inserted correctly, the device will not
detect it and no service will be available. If this happens,
turn off the device, remove the card, and reinstall the
card in the correct orientation.
Installing the microSD Memory Card
Your device supports an optional (external) microSD™
memory cards for storage of media such as music, pictures,
video and other files. The SD card is designed for use with
this mobile device and other devices.
1. Remove the battery cover.
2. Locate the microSD card slot on the inside of the
device.
3. Orient the card with the gold strips facing down.
4. Carefully slide the microSD card into the card socket
until it clicks into place.
Important!
Be sure to align the gold contact pins on the card
with the device’s contact pins.
Note:
MicroSD cards should be formatted within the Storage
menu. Using an older or slow microSD card can affect
camera performance, especially for video recording.
DRAFT
Internal Use Only
12
To remove the microSD Memory Card:
1. Remove the battery cover.
2. Firmly press the card into the slot and release it. The
card should pop partially out of the slot.
3. Remove the card from the slot.
4. Replace the battery cover.
Installing the Battery
Before using your device for the first time, install the battery
and charge it fully.
Important!
Before removing or replacing the battery, make
sure the device is switched off. To turn the device
off, hold down the key until the Device
options pop up displays, then tap
Power off
.
To install the battery:
1. Slide the battery into the compartment (1) so that the
tabs on the end align with the slots at the bottom of the
phone, making sure the connectors align.
2. Gently press down to secure the battery (2).
To remove the battery:
Grip the battery at the top end and lift it up and out of
the battery compartment.
Replacing the Battery Cover
Position the battery cover over the battery
compartment and press down until you hear a click.
Caution!
When replacing the battery cover, do not apply
pressure to the screen (“squeeze”) as this can
damage the screen.
DRAFT
Internal Use Only
Getting Started 13
Charging the Battery
Your device is powered by a rechargeable Li-ion battery. A
wall charger, which is used for charging the battery, is
included with your device. Use only approved batteries and
chargers. Ask your local Samsung dealer for further details.
Before using your device for the first time, you must fully
charge the battery.
Note:
Verify that the battery is installed prior to connecting the
wall charger. If both the wall charger is connected and
the battery is not installed, the handset will power cycle
continuously and prevent proper operation. Failure to
unplug the wall charger before you remove the battery,
can cause the device to become damaged.
Important!
It is recommended you fully charge the battery
before using your device for the first time.
1. Connect the USB cable to the charging head.
2. Locate the Charger/Accessory jack.
3. Insert the USB cable into the device’s Charger/
Accessory jack.
4. Plug the charging head into a standard AC power
outlet. The device turns on with the screen locked and
indicates both its charge state and percent of charge.
Warning!
While the device is charging, if the touch screen
does not function due to an unstable power supply
unplug the USB power adapter from the power outlet
or unplug the USB cable from the device.
DRAFT
Internal Use Only
14
Note:
If the charger is incorrectly connected, damage to the
accessory port will occur therefore voiding the phone’s
warranty.
5. When charging is finished, first unplug the charger’s
power plug from the AC wall outlet, then disconnect
the charger’s connector from the phone.
Important!
If your handset has a touch screen display, please
note that a touch screen responds best to a light
touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object
when pressing on the touch screen may damage
the tempered glass surface and void the warranty.
For more information, refer to “Standard Limited
Warranty” on page 338.
DRAFT
Internal Use Only
Getting Started 15
Low Battery Indicator
When the battery level is low and only a few minutes of talk
time remain (~15% charge), a warning tone sounds and the
“Battery low” message repeats at regular intervals on the
display. In this condition, your device conserves its remaining
battery power, by dimming the backlight.
When the battery level becomes too low, the device
automatically turns off.
The on-screen battery charge is represented (by default) as a
colored battery icon. You can also choose to display a
percentage value. Having a percentage value on-screen can
provide a better idea of the remaining charge on the battery.
Press ➔ and then tap
Settings
➔
My device
tab ➔
Display
➔
Show battery percentage
.
For more information, refer to “Display Settings” on page
265.
Extending Your Battery Life
Active applications, light levels, Bluetooth usage, and GPS
functionality all act to drain your battery. The following is a
list of helpful tips that can help conserve your battery power:
•
Reduce your backlight on time.
•
Turn Bluetooth off when not in use.
•
Turn Wi-Fi off when not in use.
•
Deactivate the GPS when not needed. Most applications using
this function will periodically query the GPS satellites for your
current location; each query drains your battery.
•
Do not wait until your battery is completely depleted before
charging your device. Repeating this process of a complete
discharge and recharge can over time reduce the storage
capacity of any battery.
•
Use the Power Saving feature to deactivate some hardware and
interface functions.
•
Check the Battery use screen to review what features or functions
have been consuming your battery resources.
•
Check the Running Services and close any unnecessary
applications.
DRAFT
Internal Use Only
16
•
Use the Task Manager feature to end/shutdown background
applications that are still running. These minimized applications
can, over time, cause your device to “slow down”.
•
Animated wallpapers use processing power, memory, and more
power. Change your Live Wallpaper to a non-animated Wallpaper
gallery or Gallery image.
Switching the Device On or Off
Once the device has been configured, you will not be
prompted with setup screens again.
To turn the device on:
Press and hold (
Power/End
) until the device
switches on.
The device searches for your network and after finding
it, you can make or receive calls.
Note:
The display language is preset to English at the factory.
To change the language, use the Language menu. For
more information, refer to “Language and Input
Settings” on page 284.
To turn the device off:
1. Press and hold (
Power/End
) until the Device
options screen appears.
2. Tap
Power off
().
Initial Device Configuration
1. Select a language from the associated field.
English is the default language.
Note:
If you are visually impaired or have difficulty hearing, tap
Accessibility
to configure the accessibility settings.
2. Tap
Next
and follow the on-screen setup instructions.
Note:
You may be prompted with a notification that your
activation is completed.
Note:
Enabling Google location services can drain battery
power.
For more information, refer to “Creating a Samsung Account”
on page 296.
DRAFT
Internal Use Only
Getting Started 17
Important!
The device name is also used to provide an
identification for your device’s Bluetooth and Wi-Fi
Direct names.
3. Tap
Finish
to complete the setup process.
4. Read the on-screen Collect diagnostics information.
Note:
This software collects only diagnostic data from your
device so that T-Mobile technicians can better
troubleshoot issues with your device.
5. Select either
More info
(to read additional information)
or
Close
to close the message screen.
Important!
Selecting
Close
only closes the current description
screen and does not disable data collection.
To disable data collection, go to
Settings
➔
Accounts
tab ➔
Backup and reset
➔
Collect
diagnostics
and turn off the
Allow diagnostics to be
collected
feature. For more information, refer to
“Collect Diagnostics” on page 302.
Restarting the Device
1. Press and hold (
Power/End
) until the Device
options screen appears.
2. Tap
Restart
().
Locking and Unlocking the Device
By default, the device screen locks when the backlight turns
off.
Place your finger on the screen and swipe the glass in
any of the directions shown unlock the device.
Note:
You can choose to configure lock settings to prevent
unauthorized use of your device. For more information,
refer to “Security” on page 304.
DRAFT
Internal Use Only
18
Voicemail
Setting Up Your Voicemail
Your device automatically transfers all unanswered calls to
voicemail, even if your device is in use or turned off. As soon
as your battery is charged and the micro SIM card inserted,
activate your voicemail account.
Important!
Always use a password to protect against
unauthorized access.
For new users, follow the instructions below to set up
voicemail:
Note:
Voicemail setup may be different depending on your
network.
1. From the Home screen, tap and then touch and
hold the key until the device dials voicemail.
You may be prompted to enter a password.
2. Follow the tutorial to create a password, a greeting,
and a display name.
Accessing Your Voicemail
You can access your Voicemail by either pressing and holding
on the keypad, or by using the device’s Application
icon, then tapping the Voicemail application. To access Voice
Mail using the menu:
1. From the Home screen, tap and then touch and
hold until the device dials voicemail.
Note:
Touching and holding will launch the voicemail
application.
2. When connected, follow the voice prompts from the
voicemail center.
Accessing Your Voicemail From Another Phone
1. Dial your wireless phone number.
2. When you hear your voicemail greeting, press the
asterisk key on the phone you are using.
3. Enter your passcode.
DRAFT
Internal Use Only
Understanding Your Device 19
Section 2: Understanding Your Device
This section outlines key features of your device. It also
describes the device’s keys, screen and the icons that
display when the device is in use.
Features of Your Device
Your device is lightweight, easy-to-use and offers many
significant features. The following list outlines a few of the
features included in your device.
DRAFT
Internal Use Only
Call Functions and Contacts List 51
Section 3: Call Functions and Contacts List
This section describes features and functionality associated
with making or answering calls, and the Contacts list, which
is used to store contact information.
Displaying Your Phone Number
From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
About device
➔
Status
. Your phone number displays in the
My phone number
field.
Note:
The device’s
Settings
menu can also be activated
by pressing and then tapping (
Apps
) ➔
(
Settings
).
Making a Call
You can store phone numbers that are regularly used to the
SIM card or to the device’s memory. These entries are
referred to as the
Contacts list
.
1. From the Home screen, tap (
Phone
).
2. Enter the phone number and then tap .
If you make a mistake while dialing, tap to
clear the last digit. Touch and hold to clear the
entire sequence.
Note:
When you activate the Auto redial option in the
Call settings
➔
Additional settings
menu, the device
automatically redials up to 10 times when the person
does not answer the call or is already on the phone,
provided your call is not sent to voicemail.
Note:
If your screen goes black during your interaction with
the device (launching Keypad, etc.), you might be
accidentally swiping over the front sensors.
DRAFT
Internal Use Only
52
Quick Dialing a Number from the Contacts List
1. From the Home screen, tap (
Contacts
).
2. Locate a contact from the list.
3. In a single motion, touch and drag your finger over the
number by going to the right. This action places a call
to the recipient.
Running a Call in the Background
If you exit the current call screen and return to the Home
screen, you are visually notified that you are still on an active
call by the green phone icon within the Status bar.
This is the best way to stay on your current call and do
something else (multi-task) such as access the Contacts list,
view a recent email, locate a picture, etc..
Ending a Call
Briefly tap key to end the call.
Note:
To redial a recent number, tap at the end of the call
or locate the number from the Logs list, tap the entry
and tap
Call
.
Ending a Call from the Status Bar
1. From an active call, you can launch a separate
application or return to the Home screen. The current
call is kept active in the background.
2. Tap the Status bar to reveal the Notifications tab, and
then drag the tab to the bottom of the screen to open
the Notifications panel.
3. Tap
End
to end the currently active call.
DRAFT
Internal Use Only
Call Functions and Contacts List 53
Making Emergency Calls
If you do not have a SIM card installed the first time you turn
on the phone, the
Insert SIM card to make calls
message
displays and an animated tutorial shows you how to install
the SIM card.
Without a SIM card, you can only make an emergency call
with the phone; normal cell phone service is not available.
Making an Emergency Call Without a SIM card
installed
1. Tap
Emergency call
from the on-screen display to make
an emergency call.
2. Enter 9-1-1 and tap . Complete your call.
During this type of call, you will have access to the
Speaker mode, Keypad, and End Call features.
Note:
Selecting Location consent may drain battery power. For
more information, refer to “Power Saving Mode” on
page 280.
3. Tap to exit this calling mode.
Making an Emergency Call With a SIM card installed
The Emergency calling mode makes redialing an emergency
number a 1-tap process. Before you can resume normal
calling operations, you should first exit this mode.
1. Swipe the Lock screen to unlock the device.
2. From the Home screen, tap .
3. Enter the emergency number (ex: 911) and then tap
.
4. Complete your call. During this type of call, you will
have access to the Speaker mode, Keypad, and End
Call features.
Note:
This mode can drain your battery power more rapidly
than a normal calling mode.
5. At the Emergency Callback screen, follow the
on-screen instructions.
DRAFT
Internal Use Only
54
Dialing Options
When you enter numbers on the Keypad, you will see three
on-screen options.
From the keypad screen, use one of the following options:
•
Voicemail
( ) to access your Voicemail service.
•
Call
( ) to call the entered number.
•
Delete
( ) to delete digits from the current number.
To view additional dialing options:
After entering a number, tap :
•Send message
to send the current caller a text message while
still maintaining the current call active.
• Add to Contacts
to add the current number to either a new or
existing Contacts entry.
• Speed dial setting
to access the Speed dialing setting menu
where you can assign a speed dial location to a current
Contacts entry.
• Add 2-sec pause
to insert a two-second pause to enter a
2-second delay within a number string (the phone continues
dialing after 2 seconds without any additional keys being
pressed.
Tip:
You can create pauses longer than two seconds by
entering multiple 2 second pauses.
• Add wait
to insert a hard pause within the number string (the
phone waits for your input). A wait requires that any
consecutive numbers be manually sent by tapping
Yes
.
• Call settings
to provide you access to the Call settings screen.
Answering a Call
When somebody calls you, the phone rings and displays the
incoming call image. The caller's phone number, picture, or
name if stored in Contacts List, displays.
At the incoming call screen:
•
Touch and slide in any direction to answer the call.
•
Touch and slide in any direction to reject the call.
•
Touch and drag the
Reject call with message
tab upward
and tap a predefined rejection message or tap
Create new
message
to create a new custom outgoing response.
Pressing the Volume down button mutes the ringer.
DRAFT
Internal Use Only
Call Functions and Contacts List 55
If the incoming call is from a number stored in your Contacts,
the entry’s name is displayed. You may also see the caller’s
phone number, if available.
Answering a call with Air Gesture
1. Verify the Air Gestures feature is on and Air call-accept
is active. For more information, refer to “Using Motions
and Gestures” on page 42.
2. At the incoming call screen, wave your hand over the
screen to accept the incoming call.
•
If active, the Air call-accept icon
appears at the top of
the incoming call screen.
Managing Reject Calls
This feature allows you to categorize both known and
unknown callers as rejected contacts. These Contacts are
then added to your Rejection list which can be managed for
individual entries from within the Contacts list or as a whole
from the Call rejection screen.
1. From the Home screen, tap .
2. Press and then tap
Call settings
➔
Call rejection
.
DRAFT
Internal Use Only
56
3. Tap the
Auto reject mode
field to configure your
automatic rejection settings. Rejected calls are routed
automatically to your voicemail. Choose from:
•Off
: disables the auto rejection feature.
• All numbers
: enables the features for all known and unknown
numbers, including those contacts that are not assigned to the
rejection list.
• Auto reject numbers
: automatically rejects all entries assigned
to the Reject list/Blacklist.
Adding numbers to the rejection list
Entries can be added to the list via either the Contacts menu
or via the Auto reject list menu. The Contacts menu option
assigns all numbers for an individual as rejected. The Auto
reject list allows to assign individual numbers.
To assign multiple numbers as rejected via Contacts:
1. From the Home screen, tap (
Contacts
).
2. Locate an entry and tap it to open the Contact
Overview Screen (page 91).
3. Press and then tap
Add to reject list
. All phone
numbers associated with this entry are then added to
the reject list.
To assign single number as rejected via Auto reject list:
1. From the main
Call settings
page, tap
Call rejection
➔
Auto reject list
.
2. Tap (
Create
) and either enter the phone number
or select a Contact from your Logs or Contacts list.
3. Tap
Save
to complete the assignment.
International Calls
1. From the Home screen, tap and then touch and
hold until the device shows “+” on-screen.
2. Use the on-screen keypad to enter the country code,
area code, and phone number.
3. If you make a mistake, tap once to delete a
single digit.
– or –
Touch and hold to delete all digits.
4. Tap .
DRAFT
Internal Use Only
Call Functions and Contacts List 57
Pause Dialing
You can dial or save phone numbers with pauses for use with
automated systems, such as voicemail or financial phone
numbers.
•
2-Second Pause
automatically sends the next set of numbers
after a two-second pause. This is indicated in the number string
as a comma (
,
).
1. From the Home screen, tap and use the
on-screen keypad to enter the phone number.
2. Press and then tap
Add 2-sec pause
. This feature
adds an automatic two-second pause.
3. Use the keypad to enter the additional numbers that
will be dialed automatically after the second pause.
Tip:
You can create pauses longer than three seconds by
entering multiple 2 second pauses.
4. Tap .
Wait Dialing
Inserting a Wait into your dialing sequence means that the
phone waits until it hears a dial tone before proceeding with
the next sequence of numbers.
•
Wait
sends the next set of numbers only after tapping
Yes
. This is
indicated in the number string as a semicolon (
;
).
Note:
Do not add multiple Waits (;) to a number string as this
will continue to prompt you after each sequence.
1. From the Home screen, tap and use the
on-screen keypad to enter the phone number.
2. Press and then tap
Add wait
. This feature causes
the phone to require your acceptance before sending
the next set of entered digits.
3. Tap .
4. Once prompted to
Send the following tones?
, tap
Yes
to
dial the remaining digits.
DRAFT
Internal Use Only
58
Redialing the Last Number
The device stores the numbers of the calls you’ve dialed,
received, or missed if the caller is identified.
To recall any of these numbers:
1. From the Home screen, tap .
2. Tap the (
Logs
tab) to display the list of recent
calls.
3. Tap the name/number and tap .
Speed Dialing
Once you have stored phone numbers from your Contacts
List, you can set up to 99 speed dial entries (2-100) and then
dial them easily whenever you want, simply by touching the
associated numeric key.
Note:
Speed dial location #1 must be reserved for Voicemail
use.
Setting Up Speed Dial Entries
Important!
Speed dial location #1 is reserved for Voicemail. No
other number can be assigned to this slot.
1. From the Home screen, tap ➔ (
Keypad
tab).
2. Press
and then tap
Speed dial setting
. The
Speed
dial setting
screen displays a virtual list of locations
with the numbers 2 through 100.
3. Tap an unassigned number slot. The
Select contact
screen displays.
4. Tap a contact and select a number to assign it to the
speed dial location. The selected contact number/
image is displayed in the speed dial number box.
DRAFT
Internal Use Only
Call Functions and Contacts List 59
Changing a Speed Dial Entry Order
1. From the Home screen, tap ➔
Keypad
tab.
2. Press
and then tap
Speed dial setting
.
Important!
The number 1 is reserved for Voicemail and
another number cannot be assigned to this slot.
3. Press
and then tap
Change order
.
4. Tap the current entry then tap the new target speed
dial location.
Note:
Tapping 2 existing speed dial locations causes the
entries to switch positions.
5. Tap
Done
. to store the change.
6. Press to return to the previous screen.
Removing a Speed Dial Entry
1. From the Home screen, tap ➔
Keypad
tab.
2. Press
and then tap
Speed dial setting
.
3. Touch and hold a existing on-screen speed dial
location and select
Remove
from the context menu.
– or –
Press
and then tap
Remove
. Tap an entry and
select (
Remove entry
). Select either
Done
(to complete the deletion) or
Cancel
(to exit).
4. Press to return to the previous screen.
Making a Call Using Speed Dial
You can assign a short cut number to a phone number in the
Contacts List for speed dialing.
1. From the Home screen, tap .
2. Touch and hold a previously created speed dial location
(numbers 2-100, or 1 if you are dialing voice mail) until
the number begins to dial.
3. If you are not certain of the speed dial location, tap
➔
➔
Speed dial setting
and tap a speed
dial number to view the assigned phone number.
DRAFT
Internal Use Only
60
Wi-Fi Calling
Wi-Fi Calling is a free feature for T-Mobile customers using
this device with the new SIM card. Wi-Fi Calling is an
excellent solution for coverage issues in and around the
home or wherever cellular coverage is limited. Minutes used
while connected to the Wi-Fi network count against available
rate plan minutes.
The benefits of Wi-Fi Calling include the following:
•
Wi-Fi Calling provides a coverage option to improve upon your
current in-home coverage experience
•
Wi-Fi Calling works anywhere there is a Wi-Fi signal available
Important!
A new micro SIM card must be installed within the
device prior to using this feature. Wi-Fi must first
be active and communicating prior to launching
Wi-Fi Calling.
Note:
This feature is active by default. If you are in an active
Wi-Fi call and go out of range of your Wi-Fi, the call will
be dropped.
Activating Wi-Fi
1. From the Home screen, press and then tap
Settings
➔ (
Connections
tab).
2. Locate the
Wi-Fi
field (and in a single motion touch and
slide to the right to turn it on.
The slider color indicates the activation status.
3. Select a Wi-Fi network from the list of available
networks. Follow the on-screen instructions to
complete connection.
Note:
To avoid international data roaming fees when using
Wi-Fi calling when outside the United States, the Data
Roaming feature on your device must be turned off.
Wi-Fi Connected
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point
(WAP).
Wi-Fi Available
Displays when Wi-Fi is active and there is an
available open wireless network.
DRAFT
Internal Use Only
Call Functions and Contacts List 61
Note:
With certain rate plans, minutes used while connected
to the Wi-Fi network count against available rate plan
Important!
If you are not using a new ISIM card, you will
receive an
Error: ERxx Invalid SIM
message. You
must be using a new ISIM card to use this feature.
Activating Wi-Fi Calling
1. Ensure that the
Wi-Fi connected
icon displays on
the Status Bar.
•
If prompted with an on-screen “Did you know your phone can
make calls over Wi-Fi” popup, tap
Learn
and follow the
remaining on-screen instructions. Tap
Next
➔
Done
.
2. From the main
Settings
page, tap
Connections
tab ➔
More networks
.
3. Locate the
Wi-Fi Calling
field and in a single motion
touch and slide to the right to turn it on.
4. If (
Missing 911 Address
) displays in the Status
Bar, follow these steps to provide 911 an address for
emergency situations:
•
Log into
my.t-mobile.com
.
•
Click on
Profile
and edit the
Edit customer information
.
•
Enter your emergency location information and complete the
online registration.
5. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Wi-Fi Calling
.
6. Tap
Connection Preferences
and select a preference for
use by the Wi-Fi Calling feature:
• Wi-Fi Preferred
: Wi-Fi network is preferred over cellular
network when making calls. Calling requires you to stay in the
Wi-Fi range.
• Cellular Network Preferred
: The cellular network is preferred
over a Wi-Fi network when making calls.
• Never use Cellular Network
: Use only Wi-Fi for calls.
Do not use Cellular Network, even if available.
DRAFT
Internal Use Only
62
7. Tap
OK
to save the setting.
8. From the main
Settings
page, tap
Connections
tab ➔
More networks.
9. Tap
Wi-Fi Calling
slider to toggle off the feature, then
tap it again to reactivate the feature and re-register
your device with the T-Mobile Network.
10. Confirm (
Wi-Fi Calling Ready
) displays in the
Status Bar.
Launching Wi-Fi Calling
Point.
1. Ensure that the
Wi-Fi connected
icon displays on the
status bar.
2. Confirm (
Wi-Fi Calling Ready
) displays in the
Status Bar.
3. Use the phone Dialer, Logs, or Contacts list to make a
call.
4. Go to the dialer and make a call. Make sure
(
Wi-Fi Calling in use
) appears during the call.
While Wi-Fi Calling mode is active, the call button shows a
Wi-Fi indicator .
When Wi-Fi Calling is disabled, the call button goes back to
show normal operation .
When Action Then
Displays on the
screen status
bar.
You are connected to the
T-Mobile network and can
make Wi-Fi calls.
Displays on the
screen status
bar.
The Wi-Fi calling feature is
active and in use within an
active call.
Does not display
on the screen
status bar.
You are charged normal
calling rate minutes.
For more information, refer to
“Activating Wi-Fi Calling” on
page 61.
Displays on the
screen status
bar.
There is an error in the use or
911 registration of the Wi-Fi
Calling feature.
DRAFT
Internal Use Only
Call Functions and Contacts List 63
In Call Options
Your device provides a number of features that are available
for use during a call.
Note:
Noise reduction and Extra volume features are disabled
while using Wi-Fi Calling.
Adjusting the Call Volume
During a call, use the Volume keys on the left side of the
device, to adjust the earpiece volume.
During a call, press the
Up
volume key to increase the
volume level and the
Down
volume key to decrease the
level.
– or –
Adjust the audio by enabling selecting an audio preset.
Tap the on-screen
Personalize call sound
button select
an equalizer setting for the incoming call.
•
Enabled/disabled via the Call settings menu (
Call settings
➔
Personalize call sound
). For more information, refer to
“Configuring General Call Settings”
on page 271.
– or –
Quickly add more volume to the incoming audio by
tapping the on-screen
Extra volume
button
From the Home screen, you can also adjust the ring volume
using these keys.
DRAFT
Internal Use Only
64
Adjusting Noise Reduction
During a call it may be necessary to adjust the noise
reduction feature. Activating this feature can improve the
quality of your conversation by reducing ambient noise.
1. Tap
(
Noise reduction off
) to toggle the status
and activate the feature.
2. Tap
(
Noise reduction on
) to toggle the status
and deactivate the feature.
Personalizing the Call Sound Setting
During a call it may be necessary to adjust the sound of the
incoming call by selecting an audio equalizer setting for the
current call.
1. Tap (
Personalize call sound
).
2. Confirm the option is enabled .
Note:
If prompted to enable the feature via the Call settings
menu, go to
Call settings
➔
Personalize call sound
.
3. Select an available option.
Choose from: Adapt Sound, Soft sound, Clear sound,
and Off.
Placing a Call on Hold
You can place the current call on hold whenever you want. If
your network supports this service, you can also make
another call while a call is in progress.
To place a call on hold:
1. Tap
Hold
to place the current call on hold.
2. Tap
Unhold
to activate the call that is on hold.
To make a new call while a call is in progress:
1. Enter the new phone number that you wish to dial or
look it up in Call history.
2. Once connected, tap
Add call
to dial the second call.
3. Dial the new phone number and tap .
To switch between the two calls:
Tap
Swap
.
The previous In call number turns gray and displays
On hold. The new active call displays a green
background behind the number.
DRAFT
Internal Use Only
Call Functions and Contacts List 65
Turning the Speakerphone on and off
While on a call, you can use your Speakerphone by following
these steps:
1. Tap (
Speaker off
) to toggle the speakerphone on.
2. Tap (
Speaker on
) to toggle the speakerphone off.
Tip:
When the speaker is turned
On
, the color of the speaker is
green. When the speaker is turned
Off
, the color of the
speaker is white.
Muting a Call
1. Tap (
Mute off
) to turn mute on so the other caller
cannot hear you speaking.
2. Tap (
Mute on
) to turn mute off and resume your
conversation.
Switching to Bluetooth Headset
1. Pair the target Bluetooth headset prior to your call.
2. While on a call, switch to the Bluetooth headset instead
of speaker by tapping (
Headset off
).
3. At the prompt, tap
OK
to enable Bluetooth if it is not
already activated.
4. While on a call, switch back to the device speaker by
tapping (
Headset on
).
More In-call Options
During a call you can save the current caller’s information to
the Contacts list, or create a Memo.
Viewing the Contacts List
During a call you can look up a number in the Contacts list.
1. Press and then tap
Contacts
.
2. Browse the Contacts list for the information you need.
3. Press to return to the active call.
DRAFT
Internal Use Only
66
Creating a Message During a Call
During a call you can create a message.
1. Press and then tap
Message
➔ (
Compose
).
2. Address and create the message.
3. Review your message and tap (
Send
).
Creating a Memo During a Call
During a call it may be necessary to record information (a
Note).
1. Press and then tap
Memo
.
2. Use the keyboard to enter the note then tap
Save
.
Multi-Party calls
Making a Multi-Party Call
A multi-party call is a network service that multiple people to
participate in a multi-party or conference call.
For further details about subscribing to this service, contact
T-Mobile customer service.
Setting up a Multi-Party Call
1. From the Home screen, tap .
2. Dial the number for the first participant and tap
.
3. Once connected, tap
Add call
, enter the second phone
number and tap . The first caller is placed on
hold.
4. Wait for the second caller to answer the incoming call
and tap
Merge
. The two calls are now joined into a
multi-party call and display in the order in which they
were called.
DRAFT
Internal Use Only
Call Functions and Contacts List 67
Important!
Multiple callers can be joined to a single
multi-party line. Additional callers participate in a
new Multiparty session and are held in conjunction
with the previous multiparty call. You can swap or
place each multi-party call on hold.
Having a Private Conversation With One Participant
Note:
The Manage conference call option is not available for
multi-party calls created while using the Wi-Fi Calling
feature. You must be on the cellular network to use the
manage feature.
When you have two participants in a multi-party session, it
might be necessary to place one of those participants on
hold so that a private conversation can be held with a single
caller. While you are in a multi-party call:
1. Press and then tap
Manage conference call
.
2. Tap (
Split Caller
) adjacent to the participants you
would like to split from the current multi-line call. The
list displays the callers in the order they were dialed.
Note:
The Manage conference call option is not available for
multi-party calls created while using the Wi-Fi Calling
feature. You must be on the cellular network to use the
manage feature.
3. Tap the participant to which you want to speak
privately.
You can now talk privately to that person while the
other participants can continue to converse with each
other. If there is only one other participant, that person
is placed on hold.
4. To return to the multi-party call, tap the Merge icon. All
of the multi-party call participants can now hear each
other.
DRAFT
Internal Use Only
68
Dropping One Participant
1. Press and then tap
Manage conference call
➔
to the right of the number to drop.
The participant is disconnected and you can continue
the call with the other participant.
2. Tap to end your conversation with the remaining
caller.
Call Waiting
You can answer an incoming call while you have a call in
progress, if this service is supported by the network and you
have previously set the Call waiting option to Activate.
You are notified of an incoming call by a call waiting tone. For
more information, refer to “Configuring Additional Voice Call
Settings” on page 275.
To answer a new call while you have a call in progress:
1. In a single motion, touch and slide it in any
direction to answer the new incoming call.
2. Tap an option from the Accept call after menu:
• Putting xxx on hold
to place the previous caller on hold while
you answer the new incoming call.
• Ending call with xxx
to end the previous call and answer the
new call.
Note:
The new caller appears at the top of the list. The
previous caller is placed on hold and appears at the
bottom of the list.
3. Tap Swap to switch between the two calls. This places
the new caller on hold and activates the previous call.
Important!
The currently active call is displayed with a green
background.
4. Tap
Swap
again to switch back.
DRAFT
Internal Use Only
Call Functions and Contacts List 69
Logs Tab
The Logs tab is a list of the phone numbers (or Contacts
entries) for calls you placed, accepted, or missed. The Logs
tab makes redialing a number fast and easy. It is continually
updated as your device automatically adds new numbers to
the beginning of the list and removes the oldest entries from
the bottom of the list.
The Notification area of the Home screen (upper left) displays
phone notifications, status, or alerts such as:
Accessing the Logs Tab
1. From the Home screen, tap ➔ (
Logs
tab).
2. Tap an entry to view available options.
Note:
The Logs tab only records calls that occur while the
phone is turned on. If a call is received while it is turned
off, it will not be included in your calling history.
Each entry contains the phone number (if it is available) and
Contacts entry name (if the number is in your Contacts).
Displays when a call is in progress.
Displays when a call was missed.
Indicates all outgoing calls made from your device.
Indicates any received calls that were answered.
Indicates a missed call.
Indicates any received calls that were rejected.
Indicates auto rejected calls.
DRAFT
Internal Use Only
70
Accessing Call log from The Notifications Area
1. Locate from the Notifications area of the Status
bar.
2. Tap the Status bar to reveal the Notifications tab, and
then drag the tab to the bottom of the screen to open
the Notifications panel.
3. Tap the Missed call entry to open the Logs screen.
This list provides easy access to redial an entry, or you can
also choose to access two types of history entry lists
depending on how they are touched.
Call logs - Caller Overview
•
Tap a contact entry name or number to reveal the
Call options
screen:
• Create contact
to save the number if it is not already in your
Contacts.
•View contact
to view the Contact details for the current entry.
•Update existing
to update an existing Contacts entry with the
current number.
•Call
allows you to redial the entry by name or number.
• Send message
allows you to create a new text message to the
selected entry.
•Time
provides the time and date of the call and its duration.
•
Press (
Menu
) to reveal additional options:
–
Copy to dialing screen
to pass the current number to your
dialer and then edit the selected number before you place your
next outbound call.
–
Delete
to delete the Contacts entry.
–
Send number
to send the current Contacts entry information to
an external recipient.
–
Add to reject list
to add the current phone number to an
automatic rejection list. Similar to a block list, the selected caller
will be blocked from making an incoming calls to your phone.
•
Touch and hold an entry to display the entry-specific context
menu:
• Copy to dialing screen
to make alterations to the current
phone number prior to redial.
• Add to Contacts
to save the number if it is not already in your
Contacts.
•View contact
to view the information for the currently stored
Contacts entry.
• Send number
to send the current Contacts entry information to
an external recipient.
DRAFT
Internal Use Only
Call Functions and Contacts List 71
• Add to reject list
to add the current phone number to an
automatic rejection list. Similar to a block list, the selected caller
will be blocked from making an incoming calls to your phone.
•Delete
to delete the entry from the Logs list.
Altering Numbers from the Logs List
If you need to make a call from the Logs screen and you
need to alter the number prior to dialing, you can add the
appropriate prefix by prepending the number.
1. From the Home screen, tap ➔
Logs
tab.
2. Touch and hold an entry to access the entry-specific
context menu.
3. Tap
Copy to dialing screen
.
4. Edit the number using the on-screen keypad or delete
digits by pressing to erase the numbers.
5. Tap once the number has been changed.
Erasing the Call logs List
You can delete either an individual call log entry or all current
entries from the Logs list.
To clear a single entry from the list:
1. From the Home screen, tap ➔
Logs
tab.
2. Touch and hold an entry and select
Delete
➔
Delete
.
To clear all entries from the list:
1. From the Home screen, tap ➔
Logs
tab.
2. Press and then tap
Delete.
3. Tap
Select all
.
4. Tap
Delete
➔
Delete
to continue with the erasure.
– or –
Tap
Cancel
to stop the current process.
DRAFT
Internal Use Only
72
Call Duration
1. From the Home screen, tap ➔
Logs
tab.
2. Press and then tap
Call duration
.
3. The following times are displayed for Voice and Data:
•Last call
: shows the length of time for the last call.
• Dialed calls
: shows the total length of time for all calls made.
• Received calls
: shows the total length of time for all calls
received.
• All calls
: shows the total length of time for all calls made and
received.
You may reset these times to zero by pressing
then tapping
Reset
.
Viewing Missed Calls from Lock Screen
When you are unable to answer a call for any reason and
your screen is locked, the number of missed calls are
displayed on the Lock screen immediately after a call is
missed.
1. Press (
Power/End
) to reactivate the screen.
2. Touch and drag the button (with the number of missed
calls on it) anywhere on the screen. The Logs tab is
then displayed.
DRAFT
Internal Use Only
Entering Text 73
Section 4: Entering Text
This section describes how to select the desired text input
method when entering characters into your device. This
section also describes the predictive text entry system that
reduces the amount of key strokes associated with entering
text.
Your device comes equipped with an orientation detector that
can tell if the phone is being held in an upright (Portrait) or
sideways (Landscape) orientation. This is useful when
entering text.
Your device also provides several on-screen keypad text
entry options to make the task of text entry that much easier.
Text Input Methods
There are three text input methods available:
•
Google voice typing
: provides a voice to text interface.
•
Samsung keyboard
(default): an on-screen QWERTY
keyboard that can be used in both portrait and landscape
orientation.
•
Swype
: is enabled so as you can enter text as you swipe
across the on-screen keyboard. Instead of tapping each
key, use your finger to trace over each letter of a word.
The on-screen QWERTY keypad works the same in both
portrait and landscape mode.
Selecting the Text Input Method
The Text Input Method can be assigned from within one of
two locations:
Settings Menu:
From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Language and
input
➔
Default
and select an input method.
Text Input field:
1. From a screen where you can enter text, in a single
motion, touch and drag the Status bar down to the
bottom of the screen to open the Notifications screen.
2. Tap (
Select input method
) and select an available
input method.
DRAFT
Internal Use Only
74
Entering Text Using Swype
Swype™ is the default text input method that allows you to
enter a word by sliding your finger or stylus from letter to
letter, lifting your finger between words. Swype uses error
correcting algorithms and a language model to predict the
next word. Swype also includes a touch predictive text
system.
The on-screen keyboard options are different between the
Android keyboard and Swype on-screen input methods.
Note:
During its initial use, you may be prompted by a series of
Swype Connect set up screens. Follow the initial
on-screen set up instructions.
Enabling and Configuring Swype
If you configure another text input method (Samsung
keyboard) you must re-enable Swype before using the
Swype keyboard.
For more detailed information on configuring Swype settings,
see “Swype Settings” on page 287.
When Swype is enabled there can also be normal keyboard
functionality.
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
.
2. Tap
Default
➔
Swype
.
Swype Text Entry Tips
You can access the SwypeTips application and watch a video
or tutorial on using Swype. You can also use the following
Swype text entry tips.
•
Create a squiggle (like an S shape) to create a double letter (such
as
pp
in apple).
•
Touch and hold a key to view the punctuation menu then make a
selection.
•
Move your finger or stylus over the apostrophe to enter
contractions.
•
Double-touch on the word you want to change to correct a
misspelled word, then touch the delete key to erase one
character. Touch and hold the delete key to erase an entire word.
DRAFT
Internal Use Only
Entering Text 75
Selecting a Text Input Mode in Swype
1. From a screen where you can enter text, tap the text
input field to reveal the on-screen keyboard.
2. With Swype as your text entry method, select one of
the following text mode options:
•ABC
to use Swype with alphanumeric characters from
the on-screen keyboard.
•SYM
(Symbol)
to enter numbers and symbols from the
on-screen keyboard.
case.
Swype Keyboard Overview
• Recipients
: a field where you can enter the recipients of the
current message. You can choose from
Groups
,
Favorites
,
Contacts
, or
Logs
.
• Text Input field
: a field where text, number, or other characters
can be entered.
•CAPS/ALT key
: When in 123ABC mode, this key changes the
capitalization of the subsequent entered characters. When in
SYM mode, this key can show additional symbol characters.
•SWYPE settings
: Touch and hold this button to access the
Swype settings screen.
• Text Input mode
: There are two available modes:
123ABC
and
SYM.
–
123ABC mode contains alphanumeric characters and a few
common punctuation marks. Text mode button indicates
SYM
.
–
SYM mode contains only symbols and numbers. Text mode
button indicates
123ABC
.
DRAFT
Internal Use Only
76
Using 123ABC Mode in SWYPE
In
123ABC
mode, you can enter only letters and a few
common punctuation marks from the on-screen keyboard.
The text mode key shows .
1. From a screen where you can enter text, tap the text
input field to reveal the on-screen keyboard.
2. Tap to configure the keyboard for 123ABC mode
(showing letters and numbers on the on-screen keys).
Once in this mode, the text input type shows .
Note:
After typing an initial uppercase character, the key
changes to and all letters that follow are in lower
case.
3. Swipe your finger continuously over the letters to form
a word.
–
If you make a mistake, tap to erase a single character.
Touch and hold to erase an entire word.
4. Tap (
Send
) to deliver the message.
DRAFT
Internal Use Only
Entering Text 77
By default, the first letter of an entry is capitalized and the
following letters are lower case. After a word is entered and
you lift your finger, the cursor automatically adds a space
after the word.
Note:
If multiple word choices exist for your Swype entry, an
on-screen popup appears to provide additional word
DRAFT
Internal Use Only
78
Using the Samsung Keyboard
This QWERTY keyboard can be used to enter text in either a
Portrait or landscape orientation. The only difference
between the two orientations are the sizes of the keys.
From a screen where you enter text, rotate your phone
counterclockwise to a landscape orientation. The on-screen
QWERTY keyboard displays.
The Samsung Keyboard
This device has a built-in, QWERTY keypad (portrait mode) or
keyboard (landscape mode). Using the QWERTY keypad/
keyboard, you can type letter, numbers, punctuation, and
other characters.
To use the Samsung keyboard you must first configure the
settings to default to the Samsung keyboard.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Language and
input
➔
Default
➔
Samsung keyboard
.
– or –
From a screen where you can enter text, in a single
motion, touch and drag the Status bar down to the
bottom of the screen, then select (
Select input
method
)
➔
Samsung keyboard
.
2. The virtual keyboard is then assigned to the Samsung
keyboard configuration for all subsequent text input.
For more detailed information on configuring Samsung
Keyboard settings, see “Samsung Keyboard Settings” on
page 284.
DRAFT
Internal Use Only
Entering Text 79
Entering Text using Different Input Options
Although the default text input method with the Samsung
keyboard is to use the on-screen keys you have other
options.
Note:
To access settings, touch and hold the
Input Methods
button , then tap (
Settings
) then select it from
DRAFT
Internal Use Only
80
Note:
After typing an initial uppercase character, tap to
Note:
After typing an initial uppercase character, the key
changes to and all letters that follow are in lower
case.
3. Enter your text using the on-screen keyboard.
–
If you make a mistake, tap to erase a single character.
Touch and hold to erase an entire word.
4. Tap (
Send
) to deliver the message.
All lowercase
Displays when the next character is entered in
lowercase.
Initial Uppercase
Displays when the first character of each word is
entered as uppercase but all subsequent
characters are lowercase.
All Uppercase
Displays when all characters will be entered as
uppercase characters.
DRAFT
Internal Use Only
Entering Text 81
Using Symbol/Numeric Mode
Use the Symbol/Numeric Mode to add numbers, symbols,
or emoticons. While in this mode, the text mode key
displays .
1. From a screen where you can enter text, tap the text
input field to reveal the on-screen keyboard. Rotate the
phone counterclockwise to a landscape orientation, if
desired.
2. Tap to configure the keyboard for Symbol
mode. Once in this mode, the text input type shows
.
3. Tap a number, symbol, or emoticon character.
4. Tap to return to ABC mode.
To enter symbols:
1. Tap to configure the keyboard for Symbol
mode.
2. Tap the appropriate symbol key.
– or –
Tap button to cycle through additional pages.
•
The first number on this key indicates which page (1 or 2) of
additional characters is active.
Using the Google Voice Typing
This feature uses Google voice recognition to convert your
spoken words into on-screen text.
You can use your voice to enter text using the Google Voice
typing feature.
1. From the keyboard, touch the top of the screen and
drag it down to display your notification panel.
2. Tap (
Select input method
) ➔
Google voice typing
.
3. At the Listening prompt (
Speak now
), speak
clearly and distinctly into the microphone.
The text is displayed in the message as you are
speaking.
For more detailed information on configuring Google Voice
Typing settings, see “Configure Google Voice Typing” on
page 288.
4. Tap (
Done
) when you are finished.
– or –
Tap (
Resume
) to resume recognition.
Note:
The feature works best when you break your message
down into smaller segments.
DRAFT
Internal Use Only
82
Using Google Voice Typing
1. From a screen where you can enter text, in a single
motion, touch and drag the Status bar down to the
bottom of the screen, then select (
Select input
method
)
➔
Google voice typing
. The virtual keyboard is
then removed and all subsequent input to done via the
microphone as text to speech.
2. Speak into the device’s microphone and watch your
text being entered on-screen.
3. If the text is incorrect, tap
DELETE
.
DRAFT
Internal Use Only
Contacts 83
Section 5: Contacts
This section explains how to use and manage your Contacts
List. You can save phone numbers to your phone’s memory.
Accounts
From the Accounts menu you decide if you want applications
to synchronize, send, and receive data at any given time, or if
you want the applications to synchronize automatically. After
determining how you want the accounts to synchronize,
indicate which account to synchronize with your Contacts
list.
1. Sign in to your Google account.
2. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) and then navigate
to the
My accounts
area.
– or –
From the main
Settings
page, tap
Accounts
tab and
then navigate to the
My accounts
area.
Note:
The Accounts area lists those accounts that have been
added to the device and provides an
Add account
button
to quickly and easily add new ones.
Contacts List
Creating a Contact
The default storage location for saving phone numbers to
your Contacts List is your device’s built-in memory.
If existing Google and Corporate email accounts have been
synchronized to your phone, these will be made available to
your device during the creation of new entries. These new
Contacts entries can be assigned or saved to synced
accounts such as Phone, SIM, Google, or Corporate.
Your device automatically sorts the Contacts entries
alphabetically. You can create either a
Device
,
SIM
,
Samsung
account
,
Google
, or
Microsoft Exchange ActiveSync
contact.
Important!
The Google and Microsoft Exchange ActiveSync
account types are only visible after creating an
email account of those types on your phone.
•
Device
contacts are stored locally on the device.
DRAFT
Internal Use Only
84
Note:
If the device is ever reset to its factory default
parameters, contacts stored on the phone can be lost.
•
SIM
contacts are stored within the micro SIM Card.
Note:
SIM contacts only store the Name and Phone number for
an entry.
•
Samsung account
contacts are shared with your existing
Samsung account.
•
Google
contacts are shared with your existing Google account
and can also be imported to your phone after you have created a
Google Mail account.
•
Microsoft Exchange ActiveSync
(also known as Work or
Outlook) contacts are those contacts that are intended to be
shared with either an Exchange Server or from within Microsoft
®
Outlook
®
.
•
Add new account
lets you create a new account type. Choose
from Samsung account, Google, or Microsoft Exchange
ActiveSync.
Note:
When storing an entry into your micro SIM card, note
that only the Name, and Number are saved. To save
additional information for a particular contact, such as
notes, email, dates, etc., it is important to save that
Contact into your phone’s onboard memory.
1. From the Home screen, tap (
Contacts
).
2. Tap
to create a contact.
Note:
You can also add a new contact by entering a number
from the keypad and pressing and then tap
Add to Contacts
➔
Create contact
. Continue with step 3.
3. Tap a destination type (
Device
,
SIM
,
Samsung account
,
Google
, or
Microsoft Exchange ActiveSync
) (depending
on where you want to save the new contact
information).
DRAFT
Internal Use Only
Contacts 85
4. Tap the
Name
field and enter a name for this contact
using the displayed keypad.
•
Tap to access additional name entries such as: Name
prefix, First name, Middle name, Last name, and Name suffix.
5. Tap the image icon and select a photo for this contact.
Selections are:
,
Pictures by people
,
Take picture
,
or
S Memo
.
Note:
The label entries below can change and are dependant
on the selected destination type (ex: the Other and
Custom might not appear with an Exchange ActiveSync
account destination type).
6. Tap the label button (to the left of the
Phone
field) and
scroll through the list to select a category such as
Mobile
,
Home
,
Work
,
Work Fax
,
Home Fax
,
Pager
,
Other
,
Callback
, or
Custom
.
7. Tap a phone number field and enter a phone number.
•
Tap on the QWERTY keyboard to remove a previously
entered phone number.
•
Tap to enter an additional phone number
•
Tap to remove a previously entered phone number.
8. Enter additional information such as:
Groups
,
Ringtone
,
Message alert
,
Vibration pattern
or tap
Add another field
to input additional category information.
•Add another field
contains the following options: Phonetic
name, Organization, IM, Address, Notes, Nickname, Website,
Internet call, Events, or Relationship.
•
Use your finger to slide the page up or down to see additional
fields and categories.
9. Tap
Save
to complete and store the new entry.
– or –
Tap
Cancel
to delete the current entry.
To save a Number from your Keypad:
1. From the Home screen, tap (
Phone
).
2. Enter a phone number using the on-screen dialpad.
3. Tap
Add to contacts
➔
Create contact
or select the
Contact entry from the on-screen list.
– or –
Press and then tap
Add to contacts
➔
Create
contact
or select the Contact entry from the on-screen
list.
DRAFT
Internal Use Only
86
•
If you're updating an existing contact, tap the entry from the list
and proceed to step 5.
4. Tap a destination type (
Device
,
SIM
,
Samsung account
,
Google
, or
Microsoft Exchange ActiveSync
) (depending
on where you want to save the new contact
information).
5. Tap the
Name
and enter a name for this contact using
the displayed keypad.
•
Tap to access additional name entries such as: Name
prefix, First name, Middle name, Last name, and Name suffix.
6. Tap the image icon and select a photo for this contact.
Selections are:
,
Pictures by people
,
Take picture
,
or
S Memo
.
Note:
The label entries below can change and are dependant
on the selected destination type (ex: the Other and
Custom might not appear with an Exchange ActiveSync
account destination type).
7. Tap the label button (to the left of the
Phone
field) and
scroll through the list to select a category such as
Mobile
,
Home
,
Work
,
Work Fax
,
Home Fax
,
Pager
,
Other
,
Callback
, or
Custom
.
8. Enter additional fields as desired.
9. Tap
Save
to complete and store the new entry.
– or –
Tap
Cancel
to delete the current entry.
Note:
For further details about how to enter characters, see
“Text Input Methods” on page 73.
DRAFT
Internal Use Only
Contacts 87
Finding a Contact
You can store phone numbers and their corresponding
names onto either your SIM card, your phone’s built-in
memory, or an external location (such as Google, Exchange,
or T-Mobile Backup). They are all physically separate but are
used as a single entity, called Contacts.
Depending on the storage size of the particular SIM card, the
maximum number of phone numbers the card can store may
differ.
1. From the Home screen, tap (
Contacts
).
2. Swipe up or down until you see the contact displayed.
– or –
Tap the
Search
field and begin entering the entry’s
name. Matching entries are then displayed. This
process filters through all of your current account
Contact entries to only show you the matching entries.
– or –
In a single motion, touch and hold the letter tab area
(on the right) until on-screen letters appear, then scroll
through the list. You are then taken to that section of
the Contacts list. Touch the contact entry.
DRAFT
Internal Use Only
88
Editing Contact Information
1. From the Home screen, tap .
2. Tap a contact name from the list and tap (
Edit
).
– or –
Select a contact name and press and then tap
Edit
.
3. Edit the contact information then:
•
Tap
Save
to complete and store the new entry or
•
Tap
Cancel
to delete the current entry.
Adding a Number to an Existing Contact
1. From the Home screen, tap .
2. Tap a contact name
from the list and tap
(
Edit
).
3. Tap a phone number
field and enter a phone
number.
•
Tap on the
QWERTY keyboard to
remove a previously
entered phone number.
•
Tap to enter an
additional phone number
•
Tap to remove a
previously entered phone number.
DRAFT
Internal Use Only
Contacts 89
4. Enter additional information such as:
Groups
,
Ringtone
,
Message alert
,
Vibration pattern
or tap
Add another field
to input additional category information.
•Add another field
contains the following options: Phonetic
name, Organization,IM, Address, Notes, Nickname, Website,
Internet call, Events, or Relationship.
•
Use your finger to slide the page up or down to see additional
fields and categories.
5. Tap
Save
to complete and store the new entry.
– or –
Tap
Cancel
to delete the current entry.
Adding a Pause or Wait to an Existing Contact
1. From the Home screen, tap and use the
on-screen keypad to enter a new phone number.
2. Press and then tap
Add 2-sec pause
. This feature
adds an automatic two-second pause.
– or –
Press and then tap
Add wait
. This feature causes
the phone to require your acceptance before sending
the next set of entered digits.
3. Tap
Add to Contacts
➔
Update existing
.
4. Scroll through the available list of existing entries and
select the desired target.
to the selected entry.
5. Tap the label button (to the left of the new phone
number) and scroll through the list to select a category
type.
6. Tap
Save
to store and update the entry.
Deleting Contacts
be recovered.
1. From the Home screen, tap .
2. Touch and hold a contact name from the list and select
Delete ➔
OK
.
DRAFT
Internal Use Only
90
Contact List Options
1. From the Home screen, tap .
2. Press . The following options display:
•Delete
: allows you to delete 1 or more of your contacts.
•Import/Export
: imports or exports contacts to or from the USB
storage location, and SIM card or SD card.
• Send namecard via
: allows you to send namecards via
methods such as Bluetooth, ChatON, Email, Gmail, Messaging,
or Wi-Fi Direct.
•Merge accounts
: allows you to merge all of your current
Contact entries with either your active Google or Samsung
account. If several of your contacts are from other external
sources, this allows you to “back them up” or copy them to
your Samsung account. Tap
OK
to continue or
Cancel
to exit.
•Accounts
: allows you to add and manage mobile accounts on
Samsung account, ChatON, Google, LDAP, or Microsoft
Exchange ActiveSync. This option also allows you to manually
synchronize all of your current contacts with their respective
accounts. For more information, refer to
“Synchronizing
Contacts”
on page 97.
• Speed dial setting
: allows you to set up speed-dialing.
• Send message/email
: allows you to send a text /picture
message or an email using your Google account.
• Contacts to display
: allows you to choose to display All
contacts, those on your Device, SIM card, Samsung account,
Gmail, or only display contacts that are part of a Customized
list.
• Settings
: allows you to configure where you save new contacts
to, or view your service numbers, or send contact information.
Options include: Only contacts with phones, List by, Display
contacts by, Service numbers, and Contact sharing settings.
•Help
: provides an on-screen Help file that covers most high
level topics for Contacts.
DRAFT
Internal Use Only
Contacts 91
Contact Menu Options
1. From the Home screen, tap .
2. Touch and hold an entry to reveal the context menu.
The following options display:
•Delete
: allows you to delete the currently selected Contacts
entry.
•Share via
: allows you to send the current Contact entry’s
information to an external recipient via either
Bluetooth
,
ChatON
,
Dropbox
,
Email
(Exchange or Internet),
Gmail
,
Messaging
, or
Wi-Fi Direct
.
• Link contact
: allows you to link the current contact to another
current contact. Similar to a “see also” feature. If you can’t
remember a contact’s information, linking entries can help you
find the person you are looking for.
• Add shortcut to home
: adds a shortcut to the current Contacts
entry to an available screen location.
Contact Entry Options
1. From the Home screen,
tap .
2. Tap an entry to reveal the
Contact entry’s Overview
Screen
. This screen
contains Name, contact
numbers, email, and
linked contact
information.
3. Press to reveal the
context menu specific to
this entry.
4. Tap an available option.
DRAFT
Internal Use Only
92
Linking Contact Information
Most people now maintain multiple email accounts, social
networking logins, and other similar account information. For
example, a Facebook account login name might differ from a
corporate email account login because they are maintained
separately and for different groups of people.
This device can synchronize with multiple accounts. When
you synchronize your phone with those accounts, each
account creates a separate contact entry in the Contacts list.
If one of your contacts (Amy Smith) has a regular email
account that you maintain in Gmail, but also has a Facebook
account under her maiden and married name, as well as a
Video! chat account, when you merge those accounts into
your Contacts list you can join all of her entries and view the
information in one record.
Joining contact information makes sending messages easy.
You can select any account email address or information all
from one screen, versus searching multiple, individual
screens to locate the desired account information.
Next time you synchronize your device with your accounts,
any updates contacts make to email account names, email
addresses, etc. automatically update in your contacts list.
1. From the Home screen, tap .
2. Tap a contact name (the name you want to link to
another entry) to reveal the
Contact entry’s Overview
Screen
.
or account information.
3. Press and then tap
Link contact
.
4. Tap the second contact entry (the entry in which to
link). The second contact is now linked with the first
and the account information is merged into one screen.
Note:
The information is still maintained in both entries, but
displays in one record for easier viewing when you link
the contacts.
DRAFT
Internal Use Only
Contacts 93
Important!
It is the first contact image that is displayed for
both, and the first contact’s name that is used.
For example: If Amy (original entry) is joined with
Julie (second entry). Julie seems to disappear and
only Amy remains. Tap the Amy entry (showing the
Amy image) to view both.
5. Tap the main linked contact to view the contact
information you linked. The contacts and information
displays with an icon next to the contact name to
indicate what type of account information is contained
in the entry.
Unlinking a Contact
1. From the Home screen, tap .
2. Tap a contact name (the account name from which you
want to unjoin an entry). This reveals the details for
entry.
or account information.
3. Tap the
Connection
area.
– or –
Press and then tap
Separate contact
.
4. Tap next to the entry you want to unjoin and
select
OK
. The contacts are “unjoined” or separated
and no longer display in the merged record screen.
Both contacts now go back to being separately
displayed.
DRAFT
Internal Use Only
94
Marking a Contact as Default
When you use applications such as the Voice Dialer or other
messaging type applications, the application needs to know
which information is primary (default) in a contact entry list.
For example, when you say “Call John Smith”, if you have
three phone records for John Smith, the Voice dialer is
looking for the “default” number or entry.
The
Mark as default
option marks one entry in a contact
record to use as the default. This comes in handy when you
have multiple entries for the same person.
1. From the Home screen, tap .
2. Tap a Contact entry.
3. Press and then tap
Mark as default
. The Mark as
default screen displays radio buttons next to the
contact name, phone number, or other contact
information.
4. Tap the radio button next to the entry information you
want to be the primary information (such as name,
phone number, or email) and select
Done
.
Note:
If there are multiple phone numbers assigned to an
entry, assigning one as the default will automatically dial
that number when the contact is selected for dialing.
Sending a Namecard
A Namecard contains contact information, and can be sent to
recipients as a Virtual Business Card (V-card) attachment
using Bluetooth, Google Mail, or as a message.
1. From the Home screen, tap .
2. Tap a Contact entry.
3. Press and then tap
Share namecard via
and select
a delivery method:
Bluetooth
,
ChatON
,
Email
(Exchange or
Internet),
Gmail
,
Messaging
, or
Wi-Fi Direct
.
The Namecard attaches to the selected message type
and is delivered when you send the message.
Note:
Email appears as an option only after an Internet or
Exchange email account has been created.
DRAFT
Internal Use Only
Contacts 95
Sending All Current Namecards
Rather than selecting once Contact entry at a time, you can
send all of your current entries at once.
1. From the Home screen, tap .
2. Press and then tap
Share namecard via
.
3. Tap
Select all
to place a check mark alongside all
currently displayed Contact entries.
4. Tap
Done
and select a delivery method:
• Bluetooth
to transmit the contacts to another Bluetooth-
compatible device.
•ChatON
to send the contacts to selected buddies.
•Email
to attach the contact cards to a new outgoing email
(Exchange or Internet).
•Gmail
to attach the contact cards to a new outgoing Internet-
based email.
• Messaging
to attach the contact cards to a new outgoing text
message.
• Wi-Fi Direct
to transmit the entries to another Wi-Fi Direct
enabled device.
Sending a namecard using Bluetooth
You must create a Contact prior to sending a namecard to a
recipient. For more information, refer to “Creating a Contact”
on page 83.
1. From the Home screen, tap .
2. Touch and hold the entry to reveal the on-screen
context menu.
3. Tap
Share via
➔
Bluetooth
.
Important!
You must activate Bluetooth to use this feature.
4. Tap the Bluetooth device in which to send this name
card. Bluetooth forwards the namecard to the recipient.
DRAFT
Internal Use Only
96
Copying Contact Information
Copying Contact Information to the SIM Card
The default storage location for saving phone numbers to
your Contacts list is your phone’s built-in memory. This
procedure allows you to copy numbers saved to the phone’s
memory, onto the SIM card.
1. From the Home screen, tap .
2. From the Contacts List, press and then tap
Import/Export
➔
Export to SIM card
.
3. Tap
Select all
to choose all current phone contact
entries.
– or –
Select a specific entry by touching an entry. A check
mark indicates a selection.
4. Tap
Done
. The name and phone number for the
selected contact is then copied to the SIM.
Copying Contact Information to the microSD
Card
This procedure allows you to copy entry information saved
on the phone’s memory, onto the SD card.
1. From the Home screen, tap .
2. From the Contacts List, press and then tap
Import/Export
➔
Export to SD card
.
3. Tap
OK
to choose all current phone contact entries.
DRAFT
Internal Use Only
Contacts 97
Synchronizing Contacts
Syncing data from your managed accounts allows you to add
and manage a new or existing contact from your online or
remote accounts to your phone. Prior to syncing, you must
first have an active Google or Microsoft Exchange account
with current Contact entries, and be signed into your account
via the phone.
With syncing, any Contacts entries (with phone numbers,
email addresses, pictures, etc.) are updated and synced with
your device.
1. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) and then navigate
to the
My accounts
area.
2. Select the email account containing the contacts you
wish to synchronize.
3. Tap within the adjacent account field to reveal the
account’s synchronization settings screen.
4. To synchronize only Contacts, toggle the active state of
the
Sync Contacts
field. A green check mark indicates
the feature is enabled.
Note:
The process of updating your Contacts tab can take
several minutes. If after 10-20 minutes, your list has not
been updated, repeat step 2-3.
5. Your
Contacts
tab then reflects any updated Contact
information.
Note:
Syncing of contacts requires you are logged into your
Gmail and Corporate accounts via the device.
Display Options
The Display options menu allows you to allows you to choose
which contacts to display. You can also choose to display
only contacts that have phone numbers.
Note:
Once a display filter has been selected, only those
Contact entries are shown until the
All contacts
option is
re-selected.
DRAFT
Internal Use Only
98
1. From the Home screen, tap .
2. Press and then tap
Contacts to display
. Select any
of the following to filter according to the selection:
•All contacts
allows you to display all available Contacts.
• Device
lists those Contacts currently found only on your Phone.
•SIM
lists those Contacts currently found only on your SIM card.
• Samsung account
lists those Contacts currently found and
sync’d within the Samsung account.
•Google
lists those Contacts currently found within the Google
account.
• Microsoft Exchange ActiveSync
lists those Contacts currently
found within the Exchange account.
• Customized list
allows you to enable which account
categories are displayed. For example, on Google contacts, you
can filter which Contact categories are shown (Friends, Family,
etc..)
Adding more Contacts via Accounts
and Sync
When you synchronize applications such as Facebook,
Twitter, MySpace, a corporate email account, or Google,
using the Accounts and sync option synchronizes the data
from the selected account type with your Contacts list.
1. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) and then navigate
to the
My accounts
area.
2. Tap
Add account
.
3. Determine which type of account information you want
to synchronize with your Contact list. Selections are:
Samsung account, ChatON, Dropbox, Email, Google,
LDAP,
Microsoft Exchange ActiveSync,
Sync apps with
Facebook,
or
Twitter
.
4. Tap an account type to add.
5. Follow the prompts. The selected account type
synchronizes with your Contacts list.
6. After synchronizing accounts you may want to link
contact information. For more information, refer to
“Linking Contact Information” on page 92.
DRAFT
Internal Use Only
Contacts 99
To add Facebook content to your Contacts list:
You can now add your Facebook contact information, such as
pictures, email, and phone numbers directly to your Contacts
list. All of their current contact information is then migrated
over to your phone. If a Contacts entry already exists with a
slightly different name, separate entries are created and can
later be linked (joined) together into a single entry.
Important!
This process not only synchronizes your contact
information but also your status, events, and more.
1. From the Home screen, tap (
Play Store
).
2. Search for and select the
Facebook
app.
3. When you are prompted to download the Facebook
application from the Play Store.
•
Tap
INSTALL
➔
ACCEPT
to complete the process.
•
Tap
OPEN
to launch the application.
4. Log into your Facebook account:
•
Enter your account’s access
Email
and
Password
information
and tap
Log in
.
5. If prompted, configure any requested optional
permissions and tap
Log in
.
6. If prompted, select a Contacts Sync option. Choose
from: Sync all, Sync with existing contacts, or Don’t
sync.
7. Tap
Done
to complete the login and sync process.
To resync Social Network Contacts:
1. From the Home screen, press and then tap
Settings
➔
Accounts
tab and then navigate to the
Accounts
area.
2. Tap
Facebook
and toggle the checkmark alongside the
desired fields.
3. Choose the parameters to sync (ex: Sync Calendar,
Sync Contacts, or Sync Gallery) and tap
Sync now
.
Note:
From the main Accounts and sync page you can also tap
Sync all
to resync all accounts.
DRAFT
Internal Use Only
100
Additional Contact Options
Sending an Email to a Contact
Note:
Contacts must contain and email account and address
before you can use the Send email feature.
1. From the Home screen, tap .
2. Press and then tap
Send message/email
➔
Send
email
. Contacts that contain an email address display.
3. Tap the contact(s) to which you want to send an email.
A check mark displays next to the selection.
Note:
The select contact must have an email as part of their
details screen.
4. Tap
Done
.
5. Select an email account type.
6. Compose the email and tap
Send
.
Export/Import
For more information, refer to “Copying Contact Information”
on page 96.
Contact List Settings
From this menu you can determine the default storage
location for Contacts, display your phone’s primary number,
and view service numbers listed in your Contact list.
1. From the Home screen, tap .
2. Press and then tap
Settings
. Configure any of the
following options:
• Only contacts with phones
allows you to display only those
contacts containing phone numbers.
•List by
defines how the current list of Contacts are sorted:
First name
or
Last name
.
• Display contacts by
defines how the current list of Contacts
are listed:
First name first
(ex: Steve Smith) or
Last name first
(Smith, Steve).
• Service numbers
lists the currently available service numbers.
DRAFT
Internal Use Only
Contacts 101
• Contact sharing settings
allows you configure how your
Contacts entries are sent: individually or as a single file
containing all available entries.
Tap
Settings
to select a share setting.
–
Send all namecards
allows you to set your Contact sharing
option to all so that your entire Contacts entries are sent as a
group and not as multiple single files. If all your entries are
selected only a single file is sent.
Note:
Your destination device must support this feature or no
entries will be received by the external device.
–
Send individual namecards
allows you to set your default to
send individual contacts one at a time. Even if you select all your
entries, each is sent individually.
Groups
This feature allows you to add a new or existing contact to a
call group. This group can be one of the already present
groups (Family, Friends, or Work) or a user-created group.
Creating a New Caller Group
1. From the Home screen, tap ➔ (
Groups
tab).
2. Press and then tap
Create
.
3. Tap the
Group name
field and use the on-screen
keypad to enter a new group name. For more
information, refer to “Text Input Methods” on page 73.
4. Tap
Group ringtone
and select a ringtone for the group.
Selections are:
Default ringtone, Ringtones
(select from
available ringtones) or
Add
(to navigate your device and
select an existing audio file).
5. Tap
Message alert
and select a message alert ringtone
to be associated with this group.
6. Tap
Vibration pattern
and select a unique vibration
pattern either from an available list or Create your own.
This pattern is then associated with this group.
7. Tap
Add member
to add Contacts to the new group.
DRAFT
Internal Use Only
102
8. From the available list of contacts, tap the contact(s)
you want to add. A check mark displays next to contact
entry. Then tap
Done
.
– or –
Tap
Select all
to place a check mark alongside all
current entries. Then tap
Done
.
9. Tap
Save
to store the newly created group.
Note:
Some externally maintained group types (such as
Google) can only be managed or updated remotely
online vs via the device. These external types will not
allow editing or deleting members locally via the phone.
Adding an Existing Entry to a Current Caller
Group
1. From the Home screen, tap ➔ .
2. Tap a group entry ➔ (
Add group member
).
3. From the available list of contacts, tap the contact(s)
you want to add. A check mark displays next to contact
entry.
4. Tap
Done
. The selected contacts are added to the
group.
Removing an Entry From a Caller Group
1. From the Home screen, tap ➔ .
2. Tap a group entry.
3. Press and then tap
Remove member
.
4. Tap all of the contacts you want to remove from this
group. A check mark displays next to contact entry.
5. Tap
Done
.The contacts are removed from the group.
Editing a Caller Group
To edit a Group entry, there must be at least one member as
part of the selected group.
1. From the Home screen, tap ➔ .
2. Touch and hold a group entry then select
Edit group
.
3. Make modifications to the
Group name
,
Group ringtone
,
Message alert
,
Vibration pattern
fields, or
Add member
.
4. Tap
Save
.
DRAFT
Internal Use Only
Contacts 103
Deleting a Caller Group
1. From the Home screen, tap ➔ .
2. Press and then tap
Delete groups
.
3. Select either
Select all
or tap the desired group.
4. Tap
Delete
.
5. Select either the
Group only
or
Group and group
members
.
6. Tap
OK
.
Sending a Message to a Group
1. From the Home screen, tap ➔ .
2. Tap an existing group, and press and then tap
Send message
.
– or –
Touch and hold a group entry and select
Send message
.
3. Select the recipients of the new message (indicated by
a green check mark). If an entry contains multiple
phone numbers, each must be selected individually.
4. Tap
Done
.
5. Type your message, and tap (
Send
).
The Favorites Tab
The Favorites tab is a list of the phone numbers that have
been designated as favorite contacts. For more information,
refer to “Logs Tab” on page 69.
1. From the Home screen, tap .
2. Tap (
Favorites
tab).
Adding a contact to your favorites list:
1. From within the Favorites tab, press and select
Add to favorites
.
2. Place a check mark alongside those current Contacts
entries you wish to assign as favorites.
3. Tap
Done
to complete the process.
DRAFT
Internal Use Only
104
Section 6: Messages
This section describes how to send or receive different types
of messages. It also explains the features and functionality
associated with messaging.
Types of Messages
Your phone provides the following message types:
•
Text Messages
•
Multimedia (Picture, Video, and Audio) Messages
•
Email and Gmail Messages
•
Hangouts
•
Messenger
•
ChatON
The Short Message Service (SMS) lets you send and receive
text messages to and from other mobile phones or email
addresses. To use this feature, you may need to subscribe to
your service provider’s message service.
The Multimedia Messaging Service (MMS) lets you send and
receive multimedia messages (such as picture, video, and
audio messages) to and from other mobile phones or email
addresses. To use this feature, you may need to subscribe to
your service provider’s multimedia message service.
Important!
During the creation of a text message, adding an
image, sound file, or video clip automatically
changes it from a text message (SMS) to a
multimedia message (MMS).
Message Icons on the Status Bar
Messaging icons are displayed on the Status Bar at the top of
the display when new messages are received. For more
information, refer to “Status Bar” on page 24.
Note:
The Messaging application can also be accessed by
pressing and then tapping (
Apps
) ➔
DRAFT
Internal Use Only
Messages 105
Creating and Sending Messages
1. From the Home screen, tap
(
Messaging
) ➔
(
Compose
).
2. Tap the
Enter recipient
field to manually enter a
recipient.
– or –
Tap to select from one of the following:
• Groups
: to select a recipient from the Group list.
•Favorites
: to select a recipient from the Favorites list.
•Contacts
: to select a recipient from your Contacts list (valid
entries must have a wireless phone number or email address).
•Logs
: to select a recipient from a list of recently sent
messages.
3. If adding a recipient from either Logs, Contacts, or
Group, tap the contact to place a check mark then tap
Done
. The contact displays in the recipient field.
Note:
Delete any unnecessary members by tapping their
name/number in the recipient area and selecting
Delete
.
4. Add more recipients by tapping either the
Enter
recipient
field or and selecting recipients.
5. Tap the
Enter message
field and use the on-screen
keypad to enter a message. For more information, refer
to “Text Input Methods” on page 73.
6. Review your message and tap (
Send
).
7. If you have more than one recipient, the same text
message is sent to all recipients in the Enter Recipients
field.
Note:
If you exit a message before you send it, it will be
automatically saved as a draft.
DRAFT
Internal Use Only
106
Quick Messaging a Number from the Contacts
List
1. From the Home screen, tap (
Contacts
).
2. Locate an entry from the Contacts list.
3. In a single motion, touch and drag your finger over the
number by going to the left. This action addresses a
new text message to the selected recipient.
Message Options
Options before composing a message
1. From the Home screen, tap
(
Messaging
).
2. Before composing a message, from the main Message
screen press from the main Messaging screen to
display additional messaging options:
•Search
: allows you to search through all of your messages for
a certain word or string of words. Use the on-screen keypad to
enter a word or phrase in which to search, then tap .
For more information, refer to
“Message Search”
on page
113.
• Delete threads
: allows you to delete any message thread.
Select the messages to delete and a green check mark will
appear next to the message. Tap Delete. For more information,
refer to
“Deleting a single message thread”
on page
112.
•Draft messages
: displays the draft messages folder and its
contents.
• Locked messages
: displays the locked messages folder and
its contents.
• Scheduled messages
: displays the scheduled messages
folder and its contents.
• Spam messages
: displays the spam messages folder and its
contents.
• Text templates
: displays your available text message reply
templates. For more information, refer to
“Text Templates”
on page 118.
• Settings
: allows you to access Messaging settings. For more
information, refer to
“Messaging Settings”
on page 113.
DRAFT
Internal Use Only
Messages 107
3. From the Messaging screen list, touch and hold an
on-screen message and select an option:
•Delete
: deletes the entire message and its bubbles.
For more information, refer to
“Deleting a single message
bubble”
on page 112.
•View contact
: allows you to view the current entry information
for the sender.
•Add to contacts
: allows you to add the sender to either a new
or existing Contacts entry.
• Add to spam numbers
: allows you to tag a number as spam
so that these messages can be directly delivered to your spam
folder.
Options while in a current message
1. From the Home screen, tap
(
Messaging
).
2. From within an open message, press to display
additional messaging options:
• Insert smiley
: allows you to add insert smiley icons
images (emoticons).
•Add text
: allows you to add text items from sources
such as: S Memo, Calendar, Location, Contacts, and
Text templates.
•Preview
(only in MMS): allows you to add preview the
MMS message prior to delivery.
•Add to Contacts
: allows you to add the sender to either a new
or existing Contacts entry.
•View contact
: reveals the current Contact’s overview screen.
• Add slide
: converts an SMS message into an MMS
(Multimedia) message and allows you to attach an existing
slideshow.
• Remove slide
: allows you to remove a previously attached
slideshow.
• Add subject
: allows you to enter a subject.
DRAFT
Internal Use Only
108
• Duration (5 sec)
(only in MMS): allows you to change the
duration of the image slideshow.
• Layout (bottom)
(only in MMS): allows you to change the
layout.
• Add recipients
: allows you to enter additional recipients to the
message.
• Delete message
: allows you to erase either select specific
message bubbles or all current messages bubbles.
• Scheduling
: allows you to schedule a time for the current
message to be delivered.
• Add to spam numbers
: allows you to tag a number as spam
so that these messages can be directly delivered to your spam
folder.
•Discard
: closes the current open message.
Note:
You must be logged into your Samsung account prior to
using the S Translator feature.
•Translate
: launches a Translate popup menu. Here you can
both assign the sender’s original language and assign a target
language for the recipient (they will receive your message in the
designated language).
–
Enable the translate feature then configure the available options
as desired. Tap
OK
to store the new settings.
Adding attachments to a message
To add an attachment to your message, tap (
Attach
)
and select one of the following options:
•
: allows you to tap an existing image from your Pictures list
to add it to your message.
•
Take a picture
: allows you to temporarily exit the message, take
a photo with phone’s camera, and then add it to your message by
tapping
Save
.
•
Video
: allows you to choose an existing video from the Videos list,
then add it to your message
.
•
Record video
: allows you to temporarily exit the message,
record a video clip using the phone’s camera, and then add it
to your message by tapping
Save
.
DRAFT
Internal Use Only
Messages 109
•
Audio
: allows you to choose an existing audio file from the
Audio list, then add it to your message by tapping the circle to
the right of the audio so that it turns green, then tapping
Done
.
•
Record audio
: allows you to temporarily exit the message and
record an audio clip using the phone’s microphone. It is then
automatically attached to the message.
•
S Memo
: allows you to add an S Memo that you have created.
•
Calendar
: allows you to add an event from your calendar.
•
Location
: allows you to attach a thumbnail of a map showing
your location.
•
Contacts
: allows you to tap on an existing Address Book entry,
then add it to your message by tapping
Done
.
Adding Additional Text
You can copy text such as names, phone numbers, and
events from your Contacts, Calendar, or a Memo.
1. While composing a message, press ➔
Add text
.
2. At the Add text screen, select one of the following:
•S Memo
: allows you to insert text from an existing S Memo.
•Calendar
: allows you to add the name, date, and time of a
calendar event to your message.
•Location
: allows you to add an address and the link to the
location on Google Maps.
•Contacts
: allows you to add the name and phone number of
any of your contacts to your message.
• Text templates
: allows you to add pre-defined phrases and
sentences. For more information, refer to
“Text Templates”
on page 118.
The information is added to your message.
DRAFT
Internal Use Only
110
Viewing Newly Received Messages
When you receive a message, your phone notifies you by
displaying within the Notification area at the top left of
your Home screen.
To read a message:
1. Open the Notification Bar and select the message. For
more information, refer to “Notification Bar” on page
33.
– or –
From the Home screen, tap
then tap the new
message to view its contents. The selected message
displays on the screen.
2. Tap to play a multimedia message.
•
To pause playback of the multimedia message, tap .
3. In a single motion, touch and drag up or down the page
to scroll through the message (if additional pages were
added).
Message Threads
Sent and received text and
picture messages are
grouped into message
threads. Threaded messages
allow you to see all the
messages exchanged (similar
to a chat program) and
displays a contact on the
screen.
Message threads are listed in
the order in which they were
received, with the latest
message displayed at the
top.
To reply to a text message:
1. From the Home screen,
tap .
2. While the message is
open, tap the
Enter message
field and then type your
reply message.
DRAFT
Internal Use Only
Messages 111
3. Compose your reply.
Your texts are colored Blue and your caller’s replies are
Yellow.
4. Tap (
Send
) to deliver your reply.
– or –
Press and then select one of the available
message options (page 106).
To access message thread options:
From the main Messaging screen, touch and hold the
message to display the following options:
•Delete
: deletes the currently selected message thread.
•View contact
: displays the Contact’s Overview page.
•Add to contact
: begins the process of adding the new number
to your Contacts list.
•Add to spam numbers
: adds the current sender to a spam list.
ny new texts from this sender are automatically blocked.
To access additional Bubble options:
Touch and hold the message bubble within an active
message conversation to display the following options:
• Delete
: deletes the currently selected message bubble from
the thread.
•Copy
: copies the currently selected message bubble from the
thread.
•Forward
: allows you to forward the currently selected message
bubble to an external recipient.
•Lock/Unlock
: locks or unlocks the currently selected message
bubble from being accidentally deleted.
•Copy to SIM
: copies the currently selected message bubble as
a single text message within the SIM card.
• View message details
: displays details for the currently
selected message bubble.
•Translate
: translates the text from the currently selected
bubble into a desired language.
DRAFT
Internal Use Only
112
Deleting Messages
Deleting a single message thread
1. From the Messaging screen, touch and hold a message
from the Messages list, then select
Delete
.
2. At the prompt, tap
OK
to delete or
Cancel
to exit.
Deleting multiple message threads
1. From the Messaging screen, press and then tap
Delete threads
.
2. Tap (
Delete
) then select each message bubble
you want to delete. A check mark displays beside each
selected message.
3. Tap
Delete
.
4. At the prompt, tap
OK
to delete or
Cancel
to end the
process.
Deleting a single message bubble
1. From the Messaging screen, open a message to reveal
the message string.
2. Touch and hold a message bubble, then select
Delete
.
3. At the prompt, tap
OK
to delete or
Cancel
to exit.
Deleting multiple message bubbles
1. From the Messaging screen, open a message to reveal
the message string.
2. Press and then tap
Delete messages
.
3. Place a check mark on the individual bubbles targeted
for deletion or choose
Select all
.
4. Tap
Delete
to erase or
Cancel
to exit.
DRAFT
Internal Use Only
Messages 113
Message Search
You can search through your messages by using the
Message Search feature.
1. From the Messaging screen, press and then tap
Search
.
2. Use the on-screen keypad to enter a word or phrase in
which to search, then tap .
3. All messages that contain the entered search string
display.
Messaging Settings
To configure the settings for text messages, multimedia
messages, Voicemails, and Push messages.
From the Messaging screen, press and then tap
Settings
.
The following Messaging settings are available:
General settings
• Delete old messages
: deletes old messages when the limit is
reached, rather than overwriting them.
• Text message limit
: allows you to set a limit on how many text
messages are allowed in one conversation.
• Multimedia message limit
: allows you to set a limit on how
many multimedia messages are allowed in one conversation.
Text message (SMS) settings
• Delivery reports
: when this option is activated, the network
informs you whether or not your message was delivered.
• Manage SIM card messages
: allows you to manage the
messages stored on the SIM card.
• Message center
: allows you to enter the number of your
message center where your messages reside while the system
is attempting to deliver them.
• Input mode
: allows you to set the input mode for your text
messages. Choose from: GSM Alphabet, Unicode, or
Automatic.
Multimedia message (MMS) settings
• Delivery reports
: when this option is activated, the network
informs you whether or not your message was delivered.
•Read reports
: when this option is activated, your phone
receives a request for a read reply along with your message to
the recipient.
•Auto retrieve
: allows the message system to automatically
retrieve messages.
DRAFT
Internal Use Only
114
• Roaming auto retrieve
: allows the message system to
automatically retrieve while roaming.
•Creation mode
: allows you to select the creation mode: Free,
Restricted, or Warning.
–
Restricted
: you can only create and submit messages with
content belonging to the Core MM Content Domain.
–
Warning
: the phone will warn you via pop up messages that
you are creating a multimedia message which does not fit the
Core MM Content Domain.
–
Free
: you may add any content to the message.
•MMS alert
: alerts you when the messaging modes changes
from an SMS (text) to MMS (multimedia) mode.
Display
• Bubble style
: allows you to choose from several bubble styles
for your messages. Bubbles are the rounded boxes that
surround each message.
• Background style
: allows you to choose from several
background styles for your messages.
• Use the volume key
: allows you to change the text size by
using the up or down volume keys.
Push message settings
• Push messages
: allows you to receive push messages from
the network.
• Service loading
: allows you to set the type of service loading
notification. Choose from: Always, Prompt, or Never.
Notification settings
• Notifications
: allows you to see message notifications on your
status bar.
• Select ringtone
: allows you to set the ringtone for your
message notifications.
•Vibrate
: allows you to configure the vibration mode associated
with message alerts.
• Message alert repetition
: allows you to set the interval for new
message alerts. Choose from: Once, Every 2 minutes, or
Every 10 minutes.
• Preview message
: when enabled, allows you to view a brief
preview of new message text on the Status bar.
DRAFT
Internal Use Only
Messages 115
Emergency message settings
•Emergency alerts
: allows you to configure emergency alert
settings. You can enable/disable those alert categories you
wish to receive. Choose from: Imminent extreme alert,
Imminent severe alert, and AMBER alerts.
Note:
The Presidential alert can not be disabled.
• Emergency notification preview
: allows you to play a sample
emergency alert tone. Tap
Stop
to cancel the playback.
Signature settings
• Add signature
: when enabled, this feature allows you to create
a signature at the end of your outgoing text messages.
• Signature text
: allows you to enter a desired signature for your
message.
Spam message settings
• Spam settings
: when enabled, allows you to configure
available spam settings such as:
–
Add to spam numbers
: allows you to manually enter and
assign a phone number as being sent from a spam source.
–
Add to spam phrases
: allows you to assign a specific text
phrase as belonging to a spam message. Ex: Dear friend.
–
Block unknown senders
: when active, automatically blocks
incoming messages from unknown sources or blocked
numbers.
Emergency Alert Configuration
This device is designed to receive wireless emergency alerts
from the Commercial Mobile Alerting System (CMAS); which
may also be known as the Personal Localized Alerting
Network (PLAN). If your wireless provider has chosen to
participate in CMAS/PLAN, alerts are available while in the
provider's coverage area. If you travel outside your provider's
coverage area, wireless emergency alerts may not be
available. For more information, please contact your wireless
provider.
Emergency Alerts allows customers to receive
geographically-targeted messages. Alert messages are
provided by the US Department of Homeland Security and
will alert customers of imminent threats to their safety within
their area. There is no charge for receiving an Emergency
Alert message.
DRAFT
Internal Use Only
116
There are three types of Emergency Alerts:
•
Alerts issued by the President
•
Alerts involving imminent threats to safety of life
•
AMBER Alerts (missing child alert)
Customers may choose not to receive Extreme Alerts, Severe
Alerts, and AMBER Alerts.
Important!
Alerts issued by the President can not be disabled.
To disable Extreme, Severe, and AMBER Alerts:
1. From the Messaging screen, press and then tap
Settings
.
2. Scroll to the bottom and select
Emergency alerts
. All
alerts are enabled by default (check mark showing).
3. Tap on an alert option to disable the alert and remove
the check mark.
Assigning Messages as Spam
You can now assign either a phone number as spam or use a
key term or phrase. Any message assigned as spam is
automatically placed with your Spam messages folder.
To assign a phone number from Messages list as spam:
1. From the Home screen, tap .
2. Touch and hold a message from a phone number.
3. Select
Add to spam numbers
and tap
OK
.
To assign a phone number manually as spam:
1. From the Messaging screen, press and then tap
Settings
.
2. Locate and activate the
Spam settings
option.
• Spam settings
: when enabled, allows you to configure
available spam settings such as:
3. Tap
Add to spam numbers
➔ (
Add
).
•
This function allows you to manually enter and assign a phone
number as being sent from a spam source.
DRAFT
Internal Use Only
Messages 117
4. Tap the
Number
field to manually enter phone number.
– or –
Tap to select from either your existing Logs or
Contacts.
– or –
Tap
Match criteria
and select a parameter that must
match for the spam action to take effect. Choose from:
Same as, Starts with (ex: 800 or 888), Ends with, or
includes.
5. Tap
Save
.
To register text phrases as spam:
Some incoming messages might not be associated with a
phone number but rather an email address. In these cases,
the only way to block those messages, would be assign a
key used term or phrase to activate the Spam block. Ex:
“Dear friend”, “Stock Alert”, or “Act Now”.
1. From the Messaging screen, press and then tap
Settings
.
2. Locate and activate the
Spam settings
option.
3. Tap
Add to spam phrases
➔ (
Add
).
•
This function allows you to assign a specific text phrase as
belonging to a spam message. Ex: Dear friend.
4. Enter a term or word into the field.
5. Tap
Save
.
To register unknown numbers as spam:
Some incoming messages might not be associated with
either a phone number or email address. These incoming
messages contain no information as their info is blocked by
the sender.
1. From the Messaging screen, press and then tap
Settings
.
2. Locate and activate the
Spam settings
option.
3. Tap
Block unknown senders
. A green check mark
indicates the feature is active.
• Block unknown senders
: when active, automatically blocks
incoming messages from unknown sources or blocked
numbers.
If an incoming message is designated in coming from an
unknown sender, it is automatically assigned as spam and is
now located in your Spam folder.
DRAFT
Internal Use Only
118
Accessing Your Spam Folder
Any message assigned as spam is automatically placed with
your Spam messages folder.
From the Messaging screen, press and then tap
Spam messages
.
Text Templates
This screen displays your available text message reply
templates. This is a readily accessible list of both default and
user-defined text snippets that can be used to quickly reply
to incoming messages.
1. From the Home screen, tap .
2. From the Messaging list, press and then tap
Text templates
.
3. Tap a message to immediately insert it into your
current message conversation.
To create your own text template:
1. From the Home screen, tap .
2. From the Messaging list, press and then tap
Text templates
.
3. Tap (
Create text template
).
4. Enter a new text string and tap
Save
.
Using Email
Email (or Internet Email) enables you to review and create
email using several email services. You can also receive text
message alerts when you receive an important email. Your
phone’s Email application lets you access and manage
multiple email accounts simultaneously in one convenient
location.
There are currently three main types of email accounts on
your phone: Gmail, Internet-based email (Gmail, Yahoo, etc..),
and Microsoft Exchange (Corporate email or Outlook®).
To send and receive email messages through an ISP (Internet
Service Provider) account, or if you wish to use your device
to access your corporate email through a VPN (Virtual Private
Network), you will first need to set up an IMAP or POP
account.
DRAFT
Internal Use Only
Messages 119
•
IMAP
(Internet Message Access Protocol) - This protocol is
frequently used in large networks and commercial settings.
IMAP4 is the current standard.
•
POP3
(Post Office Protocol) - This protocol is supported by most
ISPs (Internet service providers) and common among consumer
applications. POP3 is the current standard.
•
Microsoft Exchange ActiveSync
- This protocol is frequently
used with a large corporate email server system and provides
access to email, contact, and calendar synchronization.
Creating an Internet Email Account
1. From the Home screen, tap (
Apps
)
➔
(
Email
).
2. If you already have other email account setup:
•
Open an existing email account, press and then tap
Settings
➔
(
Add account
).
– or –
Enter your
Email address
and
Password
information.
• Email address
: your Internet email address.
• Password
: typically your network access password
(case-sensitive).
DRAFT
Internal Use Only
120
3. Tap
Show password
to display the password as you
enter it in the associated field.
•
Tap
Manual setup
to configure your connection settings
manually (POP3 or IMAP). Follow the on-screen prompts and
enter the information specific to your email provider.
•
Tap
Send email from this account by default
to assign this
email account as your default account for all outgoing emails.
4. Tap
Next
.
5. At the
Account options
screen, select the frequency
which the device should check for new email on the
server and tap
Next
.
Important!
The
Sync Email
feature must be enabled to allow
synching between your device and the remote
server.
•
Tap the
Notify me when email arrives
field to receive new
email notifications.
•
Tap the
Automatically download attachments when
connected to Wi-Fi
field to assist with faster access to large
email attachments when using Wi-Fi.
6. At the
Set up email
screen, name the account and enter
a screen name to identify yourself on this account.
•
The unique account name is used to differentiate this account
from other email accounts accessed by your device.
7. Tap
Done
to store the new account.
Messages for this account display on the Inbox tab. You can
also view Personal information for this account, Receipts (if
you setup the account to return receipts), Travel information,
and more (if available).
Opening an Email
1. From the Home screen, tap ➔ (
Email
).
2. Tap (account name field upper-left) to open
the complete email account list page.
•
Selecting
Combined view
allows you to view all the emails for
your current accounts, managed by the application, to be listed
on a single screen.
3. Select an email account and tap an email message.
DRAFT
Internal Use Only
Messages 121
Refreshing Email messages
1. From the Home screen, tap ➔ (
Email
).
2. Select an email account.
•
If you are already in an email account, tap the account name
field (upper-left) to open the complete email account list page.
•
Select an available email account.
3. Tap (
Refresh
).
Composing Email
1. From the Home screen, tap ➔ (
Email
).
2. Tap (account name field upper-left) to open
the complete email account list page.
3. Tap
Inbox
➔ (
Compose
).
4. Enter the recipient’s email address in the
To
field.
•
If you are sending the email message to several recipients,
separate the email addresses with a comma. You can add as
many message recipients as you want.
5. Tap
Cc/Bcc
to add additional carbon copy and blind
copy recipients.
•
Use the
Cc
field to carbon copy additional recipients.
•
Use the
Bcc
field to blind copy additional recipients.
6. Tap the
Subject
field and enter the email subject.
7. Tap the email text field and compose your email
message.
•
To add an attachment (such as image, video, audio, etc..),
tap
Attach
(from the top of the screen) and make a
category selection.
–
Tap the file you wish to attach.
–
Tap
to delete the attached file.
Note:
If you attach an image to your email, you have the option
to resize it prior to delivery. Choose from: Original,
Large (70%), Medium (30%), or Small (10%). Once
chosen, tap either
Always
or
Just once
.
8. Tap (
Save
) to store a draft of the current email
on your device so that you can come back later and
continue the email.
9. Tap (
Delete
) to discard the current email.
10. Once complete, tap (
Send
).
DRAFT
Internal Use Only
122
Configuring Email Settings
1. From the Home screen, tap ➔ (
Email
).
2. Select an account.
3. Press and then tap
Settings
and alter any of the
following General settings:
•Display
: allows you to configure the way in which your email
list is displayed. Options include: Auto fit content, Message
preview line, and Title line list.
• Composing and sending
: allows you to configure the
functions available during both creating and sending emails.
Options include: Quick responses, Default image size, Delay
email sending.
•Auto advance
: allows you to assign an action after an email is
deleted. Choose from: Next email, Previous email, or Email list.
• Confirm deletions
: requires that you provide confirmation
before deleting a selected email.
• Priority senders
: allows you to assign Contacts as priority
senders, configure a priority sender inbox, assign email
notifications, ringotnes, and vibration patterns for emails from
these senders.
•Spam addresses
: allows you to create a list of spam email
addresses.
• Rules for filtering
: allows you to create and manage filters for
emails. Filter parameters include: Filter name, Subject includes,
or From.
– or –
4. Press and then tap
Settings
➔
<Account
settings>
➔
Account
. Alter any of the following
settings:
• Sync settings
: allows you to adjust the email synchronization
settings, asjust the sync schedule, and adjust the email
retrieval size.
DRAFT
Internal Use Only
Messages 123
•Signature
: lets you both attach a customized signature and
include a handwritten signature to the bottom of all outgoing
emails.
–
In a single motion touch and slide the
Signature
slider to the
right to turn it on.
–
Tap the
Signature
field, change the current text, and tap
Done
to save the new signature.
or
Use your S Pen to enter a handwritten signature within the
empty box field below the current on-screen text.
• Default account
: Assign this account as the default email
account used for outgoing messages.
•Password
: allows you to update your password to match the
one on the email server.
• Email notifications
: Activates the email notification icon to
appear within the Notifications area of the status bar when a
new email (Gmail, etc..) is received.
• Select ringtone
: Plays a selected ringtone when a new email
message is received.
•Vibrate
: Activates a vibration when a new email message is
received.
5. Tap the
More settings
field to access additional options:
• Account name
: displays your uniquely created account display
name.
•Your name
: displays the name used in the From field of your
outgoing email messages.
• Always Cc/Bcc myself
allows you to include your own email
address in either the CC, Bcc, or None fields. Lets you always
receive a copy of outgoing emails.
• Forward with attachments
: Lets you include attachments
when forwarding an email.
• Recent messages
: adjusts the number of on-screen
messages shown in the current category list at any one time.
•Show images
: allows you to view embedded images located
within the body of the currently displayed email.
•Security options
: allows you to enable several security options
such as: Encrypt all, Sign all, Create keys, Private keys, Public
keys, and Set default key. These security policies could restrict
some functions from corporate servers.
• Number of emails to load
: allows you to select the number of
on-screen emails to keep loaded on the screen by default.
DRAFT
Internal Use Only
124
• Auto download attachments
: allows the device to
automatically download email attachments when an active
Wi-Fi connection is detected. This process speeds up the
process of downloading an emails attachments for offline
review by not using a 3G or 4G network connection.
• Auto resend times
: enables the device to resend an outgoing
email a specified number of times if delivery fails.
• Incoming settings
: Lets you specify incoming email settings,
such as User name, Password, IMAP server, Security type,
Port, and IMAP path prefix.
• Outgoing settings
: Lets you specify outgoing email settings,
such as SMTP server, Security type, Port, Require sign-in, User
name, or Password.
Note:
Some the above options may not be displayed when
using some Internet account types.
Microsoft Exchange Email (Outlook)
Your phone also provides access to your company’s Outlook
Exchange server. If your company uses either Microsoft
Exchange Server 2003 or 2007, you can use this email
application to wirelessly synchronize your email, Contacts,
and Calendar information directly with your company’s
Exchange server.
Setting Up a Microsoft Exchange Email account
1. From the Home screen, tap ➔ (
Email
).
2. If you already have other email account setup:
•
Open an existing email account, press and then tap
Settings
➔
(
Add account
).
– or –
Enter your
Email address
and
Password
information.
• Email address
: your Outlook work email address.
• Password
: typically your network access password
(case-sensitive).
3. Tap
Show password
to display the password as you
enter it in the associated field.
4. Tap
Send email from this account by default
, to make
this your default email account for outbound emails.
DRAFT
Internal Use Only
Messages 125
Note:
If selected, the
Manual setup
button changes to read
Microsoft Exchange ActiveSync
. If activated, skip to
step 6.
5. Tap
Next
. Consult your Network or IT Administrator for
further details and support.
6. Tap
Microsoft Exchange ActiveSync
(from the add new
email account screen).
Note:
If prompted with an on-screen notification that the
connection that the “Setup could not finish”, tap
Edit details
to continue with a manual update of
necessary information.
7. When prompted to provide additional detailed
information within the Exchange server settings
screen, enter an updated
Domain
, and confirm your
user name
and
Password
information.
Important!
Remember to manually place the cursor in the
correct spot and enter a Domain name before the
“
[Domain]\[user name]
” entry. Most servers only
provide a username.
8. Update or re-enter your
Exchange server
information
within the appropriate field. This field can often be
populated with incorrect or out of date information
provided by your server.
• Exchange Server
: your exchange server remote email
address. Typically starts with
mail.XXX.com
. Obtain this
information from your company network administrator.
Important!
Do not accept the default entry as this is a guess
based on returned information.
•
If your network requires SSL encryption, tap the
Use secure
connection (SSL)
field to place a check mark in the box and
activate this additional level. Most often, this option should be
enabled.
DRAFT
Internal Use Only
126
Important!
If your Exchange server requires this feature,
leaving this field unchecked can prevent
connection.
9. Consult your IT Administrator if it is necessary to
enable the
Use client certification
option.
10. With the new server information entered, tap
Next
.
11. Read the on-screen
Activation
disclaimer and, when
prompted, tap
OK
. The device then verifies your
incoming server settings.
12. If prompted, read the
Remote security administration
information and tap
OK
to accept the service and
continue.
13. Adjust the various on-screen configuration fields and
tap
Next
. It may take a few seconds for the next screen
to load.
•
Enabling the
Automatically download attachments when
connected to Wi-Fi
option decreases the wait time to access
large email attachments.
14. If prompted, read the
Activate device administrator?
screen and tap
Activate
to complete the email setup
process.
Note:
This process can take a few minutes. If the previous
setup screen re-appears,
ignore it and do not alter any
fields
during this process.
15. Identify your new work email account with a unique
name (Ex: Work), then tap
Done
.
Opening an Exchange Email
1. From the Home screen, tap ➔ (
Email
).
2. Tap the account name field (upper-left) to open the
complete email account list page.
3. Select an exchange email account and tap an email
message.
DRAFT
Internal Use Only
Messages 127
Refreshing Exchange Email
1. From the Home screen, tap ➔ (
Email
).
2. Select an email account.
•
If you are already in an email account, tap the account name
field (upper-left) to open the complete email account list page.
•
Select an available email account.
3. Tap (
Refresh
).
Composing Exchange Email
For more information, refer to “Composing Email” on
page 121.
Deleting an Exchange Email Message
Touch and hold an email (from your inbox list) and then
tap (
Delete
).
Configuring Microsoft Exchange Email Settings
1. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) and then navigate
to the
Accounts
area.
2. Tap the Microsoft Exchange account and
Settings
➔
<Exchange email account>
.
– or –
From the current Email inbox listing, press and
then tap
Settings
.
3. Alter any of the following General settings:
•Display
: allows you to configure the way in which your email
list is displayed. Options include: Auto fit content, Message
preview line, and Title line list.
• Composing and sending
: allows you to configure the
functions available during both creating and sending emails.
Options include: Quick responses, Default image size, Delay
email sending.
•Auto advance
: allows you to assign an action after an email is
deleted. Choose from: Next email, Previous email, or Email list.
• Confirm deletions
: requires that you provide confirmation
before deleting a selected email.
DRAFT
Internal Use Only
128
• Priority senders
: allows you to assign Contacts as priority
senders, configure a priority sender inbox, assign email
notifications, ringotnes, and vibration patterns for emails from
these senders.
•Spam addresses
: allows you to create a list of spam email
addresses.
• Rules for filtering
: allows you to create and manage filters for
emails. Filter parameters include: Filter name, Subject includes,
or From.
– or –
4. From the current Email inbox listing, press and
then tap
Settings
➔
Account settings
➔
<Exchange
email account>
. Alter any of the following settings:
• Sync settings
: allows you to adjust the email synchronization
settings, asjust the sync schedule, and adjust the email
retrieval size.
•Signature
: lets you both attach a customized signature and
include a handwritten signature to the bottom of all outgoing
emails.
–
In a single motion touch and slide the
Signature
slider to the
right to turn it on.
–
Tap the
Signature
field, change the current text, and tap
Done
to save the new signature.
or
Use your S Pen to enter a handwritten signature within the
empty box field below the current on-screen text.
•Default account
: Assign this account as the default email
account used for outgoing messages.
• Password
: allows you to update your password to match the
one on the email server.
• Email notifications
: Activates the email notification icon to
appear within the Notifications area of the status bar when a
new email (Gmail, etc..) is received.
• Select ringtone
: Plays a selected ringtone when a new email
message is received.
•Vibrate
: Activates a vibration when a new email message is
received.
DRAFT
Internal Use Only
Messages 129
5. Tap the
More settings
field to access additional options:
• Account name
: displays your uniquely created account display
name.
• Always Cc/Bcc myself
allows you to include your own email
address in either the CC, Bcc, or None fields. Lets you always
receive a copy of outgoing emails.
•Show images
: allows you to view embedded images located
within the body of the currently displayed email.
• Auto download attachments
: allows the device to
automatically download email attachments when an active
Wi-Fi connection is detected. This process speeds up the
process of downloading an emails attachments for offline
review by not using a 3G or 4G/LTE network connection.
• Auto resend times
enables the phone to resend an outgoing
email a specified number of times if delivery fails.
The default is 3 auto resends.
• Folder sync settings
allows you to configure the sync settings
for various folders such as Inbox, Drafts, Outbox, etc..
• Period to sync Calendar
assigns a period for your phone to
sync calendar events. Choose from:
2 weeks, 1 month
,
3 months
,
6 months
, or
All calendar
.
• Empty server trash
: allows you to delete your email account’s
trash bin remotely.
• In case of sync conflict
allows you to assign the master
source on emails. If there is a conflict with the current email
sync you can assign the server as the main source for all
emails (
Server has priority
) or assign the phone to be the main
source and update the server accordingly (
Device has
priority
).
•Security options
: allows you to enable several security options
such as: Encryption, Encryption algorithm, Sign, Sign
algorithms, Email certificates, and Security policy list. These
security policies could restrict some functions from corporate
servers.
•Sync Contacts
synchronizes the contacts between your device
and the remote exchange server.
•Sync Calendar
synchronizes your exchange calendar entries
between your device and the remote exchange server.
• Sync Task
synchronizes your exchange tasks entries between
your device and the remote exchange server.
• Exchange server settings
provides access to the
Domain\user name, Password, and Exchange server settings.
DRAFT
Internal Use Only
130
6. Press to return to the previous page.
Using Google Mail
Google Mail (Gmail) is Google’s web-based email. When you
first setup the phone, Gmail is configured. Depending on the
synchronization settings, Gmail is automatically synchronized
with your Gmail account.
Signing into Google Mail
1. From the Home screen, tap ➔ (
Gmail
).
Note:
You must sign in to your Gmail account in order to
access features such as Google Mail and Play Store.
2. Tap
New
if you do not have a Google account.
– or –
Tap
Existing
if you have a Google account.
The Inbox loads conversations and email.
Opening Gmail
1. From the Home screen, tap ➔ (
Gmail
).
2. Tap an existing email message.
Refreshing Gmail Mail
From within the Gmail message list, press and
tap
Refresh
at the bottom of the screen to refresh the
screen, send and receive new emails, and synchronize
your email with the Gmail account.
Other Gmail Options
From the main Gmail screen, tap (
Search
) at the
bottom of the screen to search through your Gmail
messages.
Composing a Gmail Message
1. From the Home screen, tap ➔ (
Gmail
).
2. From the Gmail Inbox, tap (
Compose
) at the
bottom of the screen to create a new message.
3. Enter the recipients Email address in the
To
field.
Tip:
Separate multiple recipient email addresses with a
comma.
4. Press and select
Add Cc/Bcc
to add a carbon or
blind copy.
5. Enter the subject of this message in the
Subject
field.
DRAFT
Internal Use Only
Messages 131
6. Tap the
Compose email
field and begin composing your
message.
7. Once complete tap (
Send
).
Viewing a Gmail Message
From the Gmail Inbox, tap a message to view the
following options located on the screen:
•Archive
: archives the selected Email.
• Delete
: deletes the currently selected Email.
• Mark as Unread
: tags the current message as unread
and returns you to the Google Mail Inbox.
Creating an Additional Gmail Account
1. From the Home screen, tap ➔ (
Gmail
).
2. Press and then tap
Settings
➔
ADD ACCOUNT
and
follow the same steps as referenced in the previous
section. For more information, refer to “Signing into
Google Mail” on page 130.
DRAFT
Internal Use Only
Changing Your Settings 241
Section 10: Changing Your Settings
This section explains the device settings for your device. It
includes such settings as: display, security, memory, and any
extra settings associated with your device.
Accessing the Settings Tabs
From the Home screen, tap (
Apps
)
➔
(
Settings
).
– or –
Press ➔ and then tap
Settings
.
The four available tabs are then displayed. The
previous Settings list is now broken down into four
available tabs described below.
Settings Tabs - Overview
The Settings are divided into 4 main groups. When the
Settings screen displays, the following 4 tabs are located at
the top of the screen:
Connections
:
This tab allows you to see all of settings related
to the connection of your device to external
sources. Features include: Wi-Fi, Bluetooth, Data
usage, More networks (Airplane mode, Mobile
networks, Tethering and Mobile HotSpot, VPN, and
Wi-Fi Calling), NFC, S Beam, Nearby devices, and
Screen Mirroring.
My device
:
This tab provides access to device configuration
and customization features. Features include:
Lock screen, Display, LED indicator, Sound,
Home screen mode, Call, Blocking mode,
Hands-free mode, Power saving mode, Accessory,
Accessibility, Language and input, Motions and
gestures, Smart screen, Air view, and Voice control.
DRAFT
Internal Use Only
242
Note:
The settings for your device are described below using
the order in which they appear in the Settings menu.
Functions found under the Connections tab are listed
first, followed by My device, Accounts, and More tabs.
Wi-Fi Settings
This section describes the Wi-Fi settings. For more
information, refer to “Wi-Fi” on page 234.
Activating Wi-Fi
1. From the Home screen, press and then tap
Settings
➔ (
Connections
tab).
2. In a single motion touch and slide the
Wi-Fi
slider to the
right to turn it on . The device scans for
available in-range wireless networks and displays
them under Wi-Fi networks on the same screen.
Wi-Fi settings
Once set up for Wi-Fi connectivity, your device automatically
uses Wi-Fi, when available, for all your mobile services.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
. Configure the
settings as desired.
The available Wi-Fi connection are displayed with a security
type displayed next to them.
Accounts
:
This tab provides both the ability to create and
modify your accounts (ex: Samsung account,
Email, etc.), configure Cloud functionality, and
access Backup and reset features.
More
:
This tab provides access to the remaining set of
device settings not listed under the other tabs.
These include Location services, Security,
Application manager, Battery, Storage, Date and
time, and About device.
DRAFT
Internal Use Only
Changing Your Settings 243
Network Notification
By default, when Wi-Fi is on, you receive notifications in the
Status bar anytime your phone detects an available Wi-Fi
network. You can deactivate this feature if you do not want to
receive notifications.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap
Network notification
. A check mark displayed next
to the feature indicates Network notification is active.
4. Tap
Network notification
again to remove the check
mark and deactivate this feature.
Passpoint
Wi-Fi CERTIFIED Passpoint™ allows users connect to Wi-Fi
hotspot networks by simplifying the process of connecting to
the correct network. In addition, this connection type
provides WPA2™ security protection for safe data
communication. Mobile devices, such as handsets and
tablets, that are certified for Passpoint can still be used in
existing hotspots. Users on passpoint-enabled hotspots, will
also enjoy Wi-Fi roaming.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. In a single motion touch and slide the
Passpoint
slider
to the right to turn it on.
4. Tap the
Passpoint
field and begin the on-screen
process of connecting to a compatible AP.
Sorting your Wi-Fi Entry List
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Sort by
field and select either
Alphabet
or
Signal
strength
.
DRAFT
Internal Use Only
244
Wi-Fi During Sleep
By default, when your device enter a sleep mode, your Wi-Fi
connection stays on all the time. If the feature is Never
enabled during sleep that current data usage is taken over by
your SIM and its network connection.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
➔
Keep Wi-Fi on
during sleep
.
3. Select an available option:
•Always
: maintains your current active Wi-Fi connection even
during sleep.
• Only when plugged in
: maintains the active Wi-Fi connection
only when the device detects it is connected to a power supply.
This reduced the drain on your device’s battery.
• Never (increase data usage)
: shuts off the current Wi-Fi
connection during sleep and diverts any current data usage to
the cellular network connection.
Allow scanning
Allows the Google location service and other apps to scan for
networks, even when Wi-Fi is turned off.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Always allow scanning
field to activate or
deactivate the feature.
Auto Network selection
Allows the device to automatically switch between Wi-Fi
network or cellular network.
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Auto network switch
to activate the feature that
would allow the device to connect to the best available
signal connection.
DRAFT
Internal Use Only
Changing Your Settings 245
Install certificates
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap
Install certificates
and follow the on-screen
instructions.
Finding your WI-Fi Address Information
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Locate the MAC Address and IP Address information at
the bottom of the screen.
•MAC address
: view your device’s MAC address, required
when connecting to some secured networks (not configurable).
•IP address
: view your device’s IP address.
Manually Adding a Wi-Fi Network
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
➔
Add Wi-Fi network
.
2. Enter the Network SSID (the name of your Wireless
Access Point).
3. Tap the
Security
field and select a security option. This
must match the current security setting on your target
WAP (Wireless Access Point).
4. Enter your WAP’s password if the WAP is secure.
5. Tap
Connect
to store the new information and connect
to the target WAP.
Note:
An SSID is a unique key which identifies a wireless LAN.
Its purpose is to stop other wireless equipment from
accessing your LAN — whether accidentally or
intentionally. To communicate, wireless devices must be
configured with the same SSID.
DRAFT
Internal Use Only
246
WPS Push Button
The WPS (Wi-Fi Protected Setup) feature (sometimes
associated with a physical or on-screen button on most
WAPs) allows you to pair your device and WAP without the
need for entering a passcode. This process is similar to Wi-Fi
Direct pairing.
In this case, once the WPS feature is active on your WAP,
your device can then detect it and then immediately pair to it.
Note:
WPS-capable routers appear in the Wi-Fi list of available
devices with the term (
WPS available
) below their name.
To pair your device using WPS:
1. Follow the WPS activation instructions specific to your
Wireless Access Point.
2. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
3. Press then tap
WPS push button
.
4. Once the connection is complete, confirm the external
router now appears in the Wi-Fi list as connected.
WPS PIN Entry
If a WPS Push Button does not work, there is an alternative
WPS connection method where you would use a device
generated PIN number to establish the connection. This
number is then entered into your WAP’s WPS client PIN field
to complete the connection.
To pair your device using WPS PIN:
1. From the main
Settings
page, tap
Connections
tab
➔
Wi-Fi
.
2. Press then tap
WPS PIN entry
.
3. Write down the generate PIN number and enter it into
your Wi-Fi Router’s client PIN field.
4. Once the connection is complete, confirm the external
router now appears in the Wi-Fi list as connected.
DRAFT
Internal Use Only
Changing Your Settings 247
Wi-Fi Direct Setup and Settings
You can configure your device to connect directly with other
Wi-Fi capable devices. This is an easy way to transfer data
between devices. These devices must be enabled for Wi-Fi
direct communication. This connection is direct and not via a
HotSpot or WAP.
Displays when Wi-Fi Direct is active and
communicating.
Note:
Activating this feature will disconnect your current Wi-Fi
network connection.
To activate your connection:
1. From the main
Settings
page, tap
Connections
tab.
2. In a single motion touch and slide the
Wi-Fi
slider to the
right to turn it on. The slider color indicates the
activation status.
3. Tap
Wi-Fi Direct
.
4. Tap
Scan
and select the single device name to begin
the connection process to another Wi-Fi Direct
compatible device.
– or –
Tap
Multi-connect
➔
Scan
and select all the device
names to begin the connection process to these Wi-Fi
Direct compatible devices.
Note:
The target device must also have Wi-Fi Direct service
active and running before it can be detected by your
device.
DRAFT
Internal Use Only
248
5. Tap
Done
. The direct connection is then established.
Confirm appears in the Status bar.
6. When prompted to complete the connection, the
recipient should tap
OK
. Your status field now reads
“Connected” and your connected device is listed within
the Wi-Fi Direct devices listing.
Bluetooth settings
In this menu you can activate Bluetooth, view or assign a
device name, activate your phone so other Bluetooth devices
can discover it, or scan for other, available Bluetooth devices
with which to pair. For more information, refer to “Bluetooth”
on page 228.
Turning Bluetooth On and Off
To turn Bluetooth on:
1. From the Home screen, press and then tap
Settings
➔ (
Connections
tab).
2. In a single motion touch and slide the
Bluetooth
slider
to the right to turn it on.
The slider color indicates the activation status. When
active, displays in the Status area.
To turn Bluetooth off:
1. From the Home screen, press and then tap
Settings
.
2. In a single motion touch and slide the
Bluetooth
slider
to the left to turn it off.
Note:
Bluetooth must be enabled prior to use.
Changing the Device Name
1. From the Home screen, press and then tap
Settings
➔ (
More
tab)
➔
About device
.
2. Tap the
Device name
field and use the on-screen
keyboard to edit the current device name.
3. Tap to erase the current device name and enter
a new name for this device using the keyboard.
4. Tap
OK
to confirm your setting.
DRAFT
Internal Use Only
Changing Your Settings 249
Activating Visibility
1. From the main
Settings
page, tap
Connections
tab
➔
Bluetooth
.
2. Verify your Bluetooth is active.
3. From the top of the Bluetooth settings page, toggle the
state of the visibility check mark. Activating this feature
enabled your device visible allows other devices to pair
and communicate.
Scanning for Devices
This option allows you to scan for active Bluetooth devices so
you can pair with them.
1. From the main
Settings
page, tap
Connections
tab
➔
Bluetooth
.
2. From the bottom of the Bluetooth settings page, tap
Scan
to search for visible external Bluetooth-
compatible devices such as headsets, devices,
printers, and computers.
Important!
Some Bluetooth devices are secured and require a
PIN number to confirm and pair with them.
3. Enter a PIN to pair with the device, if one is required,
and tap
OK
.
Data Usage
Monitor and mange your device’s data usage capabilities.
Features include activation/deactivation or network data
usage, set mobile data usage for a set period of time, and
view application data usage.
From the Home screen, press and then tap
Settings
➔ (
Connections
tab) ➔
Data usage
.
To activate/deactivate Mobile data usage:
1. From the main
Settings
page, tap
Connections
tab ➔
Data usage
.
2. Tap the
Mobile data
field to activate the feature. A
green check mark indicates the feature is active.
3. Tap the
Mobile data
field again to deactivate the
feature.
To set a mobile data limit:
1. From the main
Settings
page, tap
Connections
tab ➔
Data usage
.
2. Place a check mark in the
Set mobile data limit
field.
3. Read the on-screen disclaimer info and tap
OK
.
DRAFT
Internal Use Only
250
4. Touch and drag the far right ends of the Red or Orange
horizontal lines to manually adjust both the Warning
and Maximum data limits.
5. Touch and drag the bottom grey vertical lines to adjust
the time frames.
6. Tap the
Data usage cycle
button and select either the
current cycle or define your own by selecting
Change
cycle
.
7. Press and then select from the available on-
screen options:
• Data roaming
allows you to connect to your service provider’s
partner networks and access data services when you are out of
your service providers area of coverage. For more information,
refer to
“Data Roaming”
on page 251.
• Restrict background data
prevents background data usage.
This can help prevent over usage of your data minutes.
• Auto sync data
allows the device to automatically sync
information and updates with your various services.
• Show Wi-Fi usage
activates an additional Wi-Fi tab that shows
you your Wi-Fi data usage.
• Mobile hotspots
allows you to select available Wi-Fi networks
that can service as mobile hotspots. Place a check mark on
those entries you wish to use.
More Networks
This tab displays additional wireless and network
information.
From the Home screen, press and then tap
Settings
➔ (
Connections
tab) ➔
More
networks
.
Airplane Mode
This mode allows you to use many of your device’s features,
such as Camera, Games, and more, when you are in an
airplane or in any other area where making or receiving calls
or data is prohibited.
Important!
When your device is in Airplane mode, it cannot
send or receive any calls or access online
information or applications.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
.
DRAFT
Internal Use Only
Changing Your Settings 251
2. In a single motion touch and slide the
Airplane mode
slider to the right to turn it on.
3. Tap
OK
. The Airplane mode icon is displayed at
the top of your screen.
Mobile networks
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Mobile networks options.
From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
.
The following options display:
Use mobile data
Allows you to activate mobile data usage on your device.
From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Mobile data
.
Data Roaming
Data roaming allows you to connect to your service
provider’s partner networks and access data services when
you are out of your service providers area of coverage.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
.
2. Tap
Data roaming
to connect to data services while
roaming outside your network.
– or –
Tap
Data roaming
again to remove the green check
mark and deactivate the feature.
Access Point Names
To access a wireless access point:
From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Access Point
Names
. A list of the Access point names display. The
active access point displays a bright green, filled circle
to the right of the name.
DRAFT
Internal Use Only
252
Network mode
You can configure your device to either automatically select
the LTE option (LTE/WCDMA/GSM (auto connect) [by default]),
WCDMA/GSM (auto connect), GSM only, or WCDMA only.
From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network mode
.
• LTE/WCDMA/GSM (auto connect)
is the default network
mode option. This selection allows the device to choose the
fastest connection from among the available connection
speeds, including LTE.
• WCDMA/GSM (auto connect)
allows you to exclude the LTE
network and choose from only 4G, 3G, and 2G networks.
• WCDMA only
restricts your connection to only the 3G network.
•GSM only
restricts your connection to only the 2G network.
Using the LTE Network Option
To confirm you are always using the fastest possible
connection, the device has an automatic detection method
where it finds both the fastest and most stable connection/
communication method from among this selected set
(LTE/4G/3G/2G).
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network mode
.
2. Tap
LTE/WCDMA/GSM (auto connect)
. A selection
indicator displays next to this option to show that it is
active. This is the default mode for this device.
Using the WCDMA/GSM Option
If you wish to not use LTE but still require a fast connection
using the standard 3G/2G network speed, follow these
instructions to connect to these network types.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network mode
.
2. Tap
WCDMA/GSM (auto connect)
. A selection indicator
displays next to this option to show that it is active.
This is the default mode for this device.
DRAFT
Internal Use Only
Changing Your Settings 253
Using the WCDMA - 3G Only Network
This option uses a 3G connection only.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network mode
.
2. Tap
WCDMA only
. A check mark displays next to this
option to indicate that it is active. Connecting to 3G
networks slows the data transfer speed and time.
Using the 2G - GSM Only Network
If you are not using applications that require a faster network
speed (any application that accesses the network or uses a
browser), using the 2G only (WCDMA) network saves battery
life.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network mode
.
2. Tap
GSM only
. A check mark displays next to this option
to indicate that it is active. Connecting to 2G networks
slows the data transfer speed and time.
Network Operators
Using this feature you can view the current network
connection. You can also scan and select a network operator
manually, or set the network selection to Automatic.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
.
2. Tap
Network operators
. The current network connection
displays at the bottom of the list.
Important!
You must deactivate data service prior to searching
for an available network.
3. Tap
Search now
to manually search for a network.
4. Tap
Select automatically
to automatically select a
network connection.
Note:
Connecting to 2G networks slows the data transfer
speed and time.
DRAFT
Internal Use Only
254
Default Setup Options
Your phone default is set to Automatic (to automatically
search for an available network. You can set this option to
Manual to select a network each time you connect.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Mobile networks
➔
Network
operators
.
2. Tap
Default setup
.
3. Tap
Automatic
to allow the device to automatically
select a network.
– or –
Tap
Manual
to locate and connect to a network
manually.
Tethering and Mobile HotSpot
This option allows you to share your phone’s mobile data
connection via a direct USB connection between your phone
and computer. A wireless version of this same functionality
would be the Mobile AP feature.
Note:
You can not mount your device’s microSD card to your
computer while using the USB tethering feature.
If additional software or USB drivers are required,
navigate to: http://www.samsung.com/us/support/
downloads.
From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Tethering and Mobile HotSpot
.
For more information, refer to “USB Tethering” on page 237.
For more information, refer to “Mobile HotSpot” on page
238.
DRAFT
Internal Use Only
Changing Your Settings 255
VPN settings
The VPN settings menu allows you to set up and manage
Virtual Private Networks (VPNs).
Note:
Before using VPN, you must first set up a screen unlock
PIN or password. For more information, refer to
“Security” on page 304.
Adding a VPN
Before you add a VPN you must determine which VPN
protocol to use: PPTP, L2TP/IPSec PSK, L2TP/IPSec RSA,
IPSec Xauth PSK, IPSec Xauth RSA, IPSec Hybrid RSA.
Important!
Before you can use a VPN you must establish and
configure one.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
VPN
.
2. If prompted, read the screen lock information and
follow the on-screen steps to setup an unlock PIN or
password.
3. Tap (
Add VPN network
).
4. In the form that appears, fill in the information provided
by your network administrator.
5. Tap
Save
.
Note:
Similar setup process can be used for all available VPN
types.
Connecting to a VPN
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
VPN
.
2. Tap the VPN entry you want to connect to.
3. Enter any requested credentials into the pop-up that
opens.
4. Tap
Connect
.
Edit a VPN
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
VPN
.
2. Touch and hold the VPN that you want to edit.
3. In the pop-up that opens, select
Edit network
.
4. Make the desired VPN setting changes.
5. Tap
Save
.
DRAFT
Internal Use Only
256
Delete a VPN
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
VPN
.
2. Touch and hold the VPN that you want to delete.
3. Tap
Delete network
within the pop-up that opens up.
Wi-Fi Calling
You can configure your device to make and receive calls over
an active Wi-Fi connection. Wi-Fi Calling is an excellent
solution for coverage issues in and around the home or
wherever cellular coverage is limited. Minutes used while
connected to the Wi-Fi network count against available rate
plan minutes.
For more information, refer to “Wi-Fi Calling” on page 60.
1. Ensure that the
Wi-Fi connected
icon displays on
the status bar.
2. From the main
Settings
page, tap
Connections
tab ➔
More networks
.
3. In a single motion touch and slide the
Wi-Fi Calling
slider to the right to turn it on.
Wi-Fi Calling Settings
Important!
A compatible SIM card must be installed within the
device prior to using this feature. Wi-Fi must first
be active and communicating prior to launching
Wi-Fi Calling.
1. From the main
Settings
page, tap
Connections
tab ➔
More networks
➔
Wi-Fi Calling
.
2. Tap
Connection Preferences
and select a preference for
use of the Wi-Fi Calling feature:
• Wi-Fi Preferred
: Wi-Fi network is preferred over cellular
network when making calls. Calling requires you to stay in the
Wi-Fi range.
• Cellular Network Preferred
: The cellular network is preferred
over a Wi-Fi network when making calls.
• Never use Cellular Network
: Use only Wi-Fi for calls. Do not
use Cellular Network, even if available.
3. Tap
Help
from the main Wi-Fi Calling Settings page to
navigate through either an on-screen tutorial or review
the top 10 Wi-Fi Calling questions.
DRAFT
Internal Use Only
Changing Your Settings 257
Near Field Communication
This feature is used to read and exchange tags. When used
in conjunction with Android Beam, your device can be used
to beam application content when NFC-capable devices are
touched.
1. From the main
Settings
page, tap
Connections
tab.
2. Tap the
NFC
field and verify the feature is active
(indicated by ).
Android Beam
When Android Beam is activated, you can beam app content
to another NFC-capable device by holding the devices close
together. You can beam browser pages, YouTube videos,
contacts, and more.
1. From the main
Settings
page, tap
Connections
tab
➔
NFC
➔
Android Beam
.
2. Tap the
OFF / ON
icon to turn Android Beam on.
3. Touch the back of your device with another
NFC-capable device and the content is transferred.
S Beam
This feature (when activated via NFC) allows you to beam
large files directly to another compatible device that is in
direct contact. These files can be larger, such as Videos, HD
pictures, and other large files.You can beam images and
videos from your gallery, music files from your music player,
and more.
1. From the main
Settings
page, tap
Connections
tab.
2. Verify the NFC feature is active.
3. Tap
S Beam
and make sure the feature is turned on.
4. If not already active, in a single motion touch and slide
the
S Beam
slider to the right to turn it on.
5. Complete the transfer process between the two
NFC-enabled devices by placing them back to back.
This feature can come in very handy to quickly share
pictures between users with compatible S Beam devices. For
more information, refer to “Using S Beam to Share Pictures”
on page 146.
DRAFT
Internal Use Only
258
Nearby devices
This option allows you to share your media files with nearby
devices using DLNA and connected to the same Wi-Fi.
1. Connect to a Wi-Fi network. For more information, refer
to “Connecting to a Wi-Fi Network” on page 235.
2. From the main
Settings
page, tap
Connections
tab
➔
Nearby devices
.
3. Tap the
File sharing
field to turn File sharing on. A green
check mark indicates the feature is active. Once active,
(
Nearby devices
) appears at the top of the screen.
4. At the Nearby devices prompt, tap
OK
.
5. Tap
Shared contents
, then check the media you would
like to share. Tap
OK
.
6. Tap
Allowed devices list
, then select the connected
devices you would like to allow.
7. Tap
Not-allowed devices list
, then select the connected
devices you would like to not allow.
8. Tap
Download to
, then select the destination of any
downloaded (shared) content. Choose from USB
storage (Device) or SD card.
9. Tap
Upload from other devices
, then select the actions
you’ll take when you upload content from other
devices. Choose from either Always accept, Always
ask, or Always reject.
Screen Mirroring
With feature enabled, you can wirelessly mirror what is
currently displayed on your device’s screen with an external
TV via devices such as the AllShare Cast Hub®.
Note:
Screen mirroring can only be done with a compatible
wireless TV or one enabled with the AllShare Cast Hub.
For more information, refer to “AllShare Cast Hub” on page
153.
1. From the main
Settings
page, tap
Connections
tab
➔
Screen Mirroring
.
2. In a single motion touch and slide the
Screen Mirroring
slider to the right to turn it on. The slider color indicates
the activation status.
DRAFT
Internal Use Only
Changing Your Settings 259
Note:
This feature allows a connection between your device
and the optional AllShare Cast Hub, via a shared Wi-Fi
Direct connection. The AllShare Cast Hub then allows
the communicating TV to mirror what is being shown on
the device's display.
For more information, refer to “AllShare Cast Hub” on page
153.
Lock Screen
This menu contains features that allows you to configure the
device’s security parameters.
Screen Unlock Pattern Overview
To secure data and limit phone access, set the phone to
require a screen unlock pattern each time you turn on the
device, or every time the phone wakes up from sleep mode
(when the screen automatically turns off).
From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Lock screen
➔
Screen lock
.
The Screen lock menu allows to choose from a variety of
locking features such as:
•Swipe
: Swipe the screen to unlock it.
• Face unlock
: Look at your phone to unlock it.
• Face and voice
: Look at your phone and speak to unlock.
•Pattern
: A screen unlock pattern is a touch gesture you create
and use to unlock your device. Follow the prompts to create or
change your screen unlock pattern.
•PIN
: Select a PIN to use for unlocking the screen.
•Password
: Create a password for unlocking the screen.
•None
: No pattern, PIN, or password is required. The screen will
never lock.
Swipe options
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Configure one of the following options.
• Multiple widgets
allows you to display multiple widgets on
your lock screen. Appears as an options after a lock mode is
enabled.
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
DRAFT
Internal Use Only
260
•Shortcuts
sets shortcuts to appear at the bottom of the Lock
screen. Touch and slide the slider to the right to turn it on.
• Unlock effect
sets the effect you receive when unlocking the
phone. You can select None, Ripple effect, or Light effect.
•Help text
shows help information on the Lock screen.
• Wake up in lock screen
requires that you say a command to
wake-up your phone.
• Set wake-up command
designates your wake-up
commands. Tap
Set wake-up command
and follow the
on-screen prompts to create a new verbal command.
Using Swipe
This feature is the least secure locking method and only
requires that a user swipe the screen to unlock the device.
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
➔
Swipe
.
Using Face Unlock
This feature used facial recognition to unlock your phone.
This feature is less secure than PIN, Pattern, and Password
locks and can be bypassed by someone else who looks
similar to you.
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
➔
Face unlock
.
3. Read the on-screen notification and tap
Next
.
4. From the About Face Unlock screen, tap
Set it up
➔
Continue
.
5. Follow the on-screen instructions.
6. If your face is not recognized, choose an unlocking
method: Pattern or PIN.
DRAFT
Internal Use Only
Changing Your Settings 261
Face unlock options
Once Face unlock is enabled, additional options are
available:
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
• Improve facial recognition
allows you to improve your
device’s face matching capability by capturing your face in
different lighting, with or without glasses, and bearded or
clean-shaven. Follow the on-screen instructions.
• Presence check
requires that you blink when using the Face
unlock feature. This will increase the security of the feature.
• Lock automatically
locks the screen 5 seconds after the
screen turns off.
• Lock instantly with power key
once enabled, instantly locks
the screen after pressing the power key.
Using Face and Voice Unlock
This feature used facial recognition to unlock your phone.
This feature is less secure than PIN, Pattern, and Password
locks and can be bypassed by someone else who looks
similar to you.
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
➔
Face and voice
.
3. Read the on-screen notification and tap
Next
.
4. From the About Face Unlock screen, tap
Set it up
➔
Continue
.
5. Follow the on-screen instructions.
6. Once prompted to speak and unlock command, tap
and repeat the phrase four times.
7. Once complete, tap
Done
.
DRAFT
Internal Use Only
262
Setting an Unlock Pattern
Creating a screen unlock pattern increases security on the
phone. When you enable the User visible pattern field, you
will draw an unlock pattern on the screen whenever you
want to unlock the phone’s buttons or touch screen. When
you activate the User tactile feedback field, you feel vibration
as feedback while drawing the pattern.
The feature is now paired with a backup PIN code that acts
as a backup to the pattern lock. If you forget your pattern,
you can regain access to the device by entering a PIN code.
Note:
Make sure the Require Pattern field is activated.
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
➔
Pattern
.
3. Read the instructions then tap
Next
.
4. Draw your pattern by touching your first on-screen
point. Then,
without removing your finger from the
screen, drag your finger over adjacent points until the
gray trace line overlaps each point
and they are
highlighted with a green circle.
5. When you have connected at least four dots in a
vertical, horizontal or diagonal direction, lift your finger
from the screen and tap
Continue
.
6. Confirm the new pattern by redrawing it and then
tapping
Confirm
. The Unlock pattern is set.
7. Enter the backup PIN code and tap
Continue
.
8. Reenter the PIN to reconfirm the previous entry and
tap
OK
.
Changing the Screen Lock Pattern
This feature allows you to change the previously stored
unlock pattern and update it if necessary. This process is
similar to changing your password from time to time.
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
.
3. Retrace your current pattern on the screen.
4. Tap
Pattern
and repeat steps 3 - 7 from the previous
section.
DRAFT
Internal Use Only
Changing Your Settings 263
Deleting the Screen Lock Pattern
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
.
3. Retrace your current pattern on the screen.
4. Tap
None
.
Pattern options
Once an unlock pattern is enabled, additional options are
available:
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
• Make pattern visible
allows you to see the pattern as you
draw it.
• Lock automatically
allows you to set a time-out for lock
screen.
• Lock instantly with power key
allows you to lock the screen
by pressing .
What If I Forget my Pattern?
If you forget your device's lock pattern, you can unlock your
device or reset it using your Google™ Account credentials.
When you enter the wrong unlock pattern too many times,
you should see an option at the bottom of the screen that
says
Forgot pattern?
Follow these steps to use either your PIN
or email address.
Important!
You can only enter an incorrect lock pattern 5 times
before the device is locked.
Important!
If you are unsuccessful in retrieving your lock
pattern or unlocking your device, please contact
T-Mobile for assistance.
To unlock your device with a PIN code:
1. Tap
Backup PIN
(located at the bottom of the screen).
2. Tap
Done
.
3. If you have forgotten your current pattern, tap
Pattern
from the Screen unlock settings menu and follow the
procedures outlined in "Setting an Unlock Pattern" on
page 262 to create a new pattern.
DRAFT
Internal Use Only
264
To unlock your device using your Google account:
1. Tap
Forgot pattern?
(located at the bottom of the
screen).
2. Tap the
Username (email)
and
Password
fields, use the
on-screen keyboard to enter your Google Account
credentials, and tap
Sign in
to complete the login
process.
3. If you have forgotten your Google Account credentials,
visit the Google website to recover them. If you still
cannot get your Google Account credentials, contact
your wireless carrier for additional options.
PIN Lock and Unlock
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
➔
PIN
.
3. Enter a PIN number using the numeric keypad and
touch
Continue
to confirm the password.
4. Confirm the PIN by re-entering it and tap
OK
to confirm.
Your phone now requires you to enter this PIN number
in order to unlock the phone.
Password Lock and Unlock
1. From the main
Settings
page, tap
My device
tab ➔
Lock screen
.
2. Tap
Screen lock
.
3. Tap
Password
.
4. Enter a password using the keypad and tap
Continue
to
confirm the password.
5. Confirm the password by re-entering it and tap
OK
to
confirm.
DRAFT
Internal Use Only
Changing Your Settings 265
Display Settings
In this menu, you can change various settings for the display
such as the font, orientation, pop-up notifications, puzzle
lock feature, animation, brightness, and screen timeout, and
power saving mode.
Adjusting the Screen Display
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Display
.
2. Configure the following screen display settings:
• Wallpaper
: allows you to set the Wallpaper for your Home
screen, Lock screen, or both.
• Notification panel
: allows you to set the brightness of your
notification panel and also select the quick setting buttons that
you want to display at the top of the notification panel
(page 33).
•Multi window
: tap this option to enable/disable the automatic
Multi window feature.
• Screen mode
: allows you to select from several different color
modes.
• Reading mode
: allows you to activate an optimized reading
mode for selected applications. This menu allows you to assign
available applications (such as Calculator, Camera, Contacts,
etc...) for enhancement using the Reader mode.
•Brightness
: adjusts the on-screen brightness level. For more
information, refer to
“Adjusting Screen Brightness”
on
page 266.
• Auto rotate screen
: when enabled, the phone automatically
switches from portrait to landscape orientation and vice versa.
When this setting is disabled, the phone displays in portrait
mode only.
• Screen timeout
: adjusts the delay time before the screen
automatically turns off. Selections are: 15 seconds,
30 seconds, 1 minute, 2 minutes, 5 minutes, and
10 minutes.
•Daydream
: allows you to control what your screen does when
your device is docked or sleeping. Tap the adjacent OFF / ON
icon to turn it on. Follow the on-screen instructions.
DRAFT
Internal Use Only
266
• Font style
: sets the fonts used on the LCD display. Selections
are:
Default font
,
Choco cooky
,
Cool jazz
,
Rosemary
,
Samsung Sans
or
Get fonts online
. Tap
Get fonts online
to
download additional fonts.
•Font size
: allows you to select which size of font is displayed.
• Touch key light duration
: allows you to adjust the delay before
the Touch key light automatically turns off.
• Show battery percentage
: to activate/deactivate the display of
battery charge percentage atop the battery icon at the top of
the screen.
• Edit after screen capture
: allows you to go edit a screen
immediately after taking a screen capture.
• Auto adjust screen tone
: adjusts the phone’s LCD brightness
level to automatically adjust and conserve battery power.
• Increase touch sensitivity
: allows you to adjust the touch
sensitivity of your phone automatically depending on the type of
material on the display.
Adjusting Screen Brightness
This feature configures the LCD Brightness levels.
1. From the main
Settings
page, tap
My device
tab ➔
Display
➔
Brightness
.
2. Tap
Automatic brightness
to allow the phone to
self-adjust and tap
OK
.
– or –
Touch and slide the on-screen slider to adjust the level
and tap
OK
.
Assigning a Wallpaper
The Wallpaper settings option allows you to set the Wallpaper
for your Home screen, Lock screen, or both.
1. From the main
Settings
page, tap
My device
tab ➔
Display
➔
Wallpaper
.
2. Select an available option to change its current
wallpaper.
For more information, refer to “Managing Wallpapers” on
page 39.
DRAFT
Internal Use Only
Changing Your Settings 267
LED Indicator
This option allows you to turn on your LED lights for charging,
missed events, and incoming notifications. The light will turn
on by default unless you turn them off.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
LED indicator
.
2. Tap the following LED indicator options to turn them on
or off:
•Charging
: LED lights up when the device is connected to the
charger.
• Low battery
: LED lights up when the battery level is low.
• Notifications
: LED lights up when you have missed calls,
messages, or application events.
• Voice recording
: LED lights up when you are recording voice.
The LED only lights up when the screen is off.
Sound Settings
From this menu you can control the sounds on the phone as
well as configure the display settings.
From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Sound
.
The following options display:
Silent mode via Device Options Screen
Silent mode is convenient when you wish to stop the phone
from making noise, in a theater for example. In Silent Mode
the speaker is muted and the phone only vibrates to notify
you of incoming calls, or other functions that normally have a
defined tone or sound as an alert.
1. From the Home screen, press and hold
(
Power/End
) until the
Device options
screen displays.
2. Tap either
Mute
,
Vibrate
, or
Sound
from the Device
options screen to activate or deactivate these features
(the current mode displays).
DRAFT
Internal Use Only
268
Adjusting the Volume Settings
The Volume menu now provides access to various volume
settings within one on-screen popup menu.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
➔
Volume
.
2. Touch and drag the on-screen slider to assign the
volume settings for any of the following volume levels.
• Music, video, games, and other media
,
Ringtone
,
Notifications
or
System
.
3. Tap
OK
to assign the volume levels.
Vibration intensity
Vibration intensity allows you to select how intense the
vibration is for different options.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
➔
Vibration intensity
.
2. Touch and drag the slider to adjust the Vibration
intensity for
Incoming call
,
Notification
, and
Haptic
feedback
.
3. Tap
OK
to assign the vibration levels.
Setup the Ringtones
This option allows you to set the ringtone.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap
Ringtones
.
3. Tap a ringtone from the available list. The ringtone
briefly plays when selected.
4. Tap
Add
to locate a compatible media file that can be
used as a ringtone.
5. Tap
OK
to assign a ringer.
Setup the Vibration
This option allows you to set your device to vibrate and ring.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap
Vibrations
.
3. Select a vibration pattern and tap
OK
.
– or –
Tap
Create
to then use an on-screen touch circle to
create your own custom vibration pattern. Tap
Save
to
store the new vibration pattern.
DRAFT
Internal Use Only
Changing Your Settings 269
Notifications
This option allows you to set the ringtone that will sound for
notifications and alarms.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap
Default notification sound
.
3. Select a ringtone and tap
OK
.
Setting up Vibration When Ringing
This option allows you to enable your phone to vibrate when
a call is incoming.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap the
Vibrate when ringing
field to activate the
feature.
Audible System Tone Settings
These options are used when you use the dialing pad, make
a screen selection, lock your screen, or tap the screen. Each
time you press a key or make a selection the selected tone
sounds.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap
Dialing keypad tone
to activate a tone when you
use on-screen keys. A check mark displayed next to
these features indicates active status.
3. Tap
Touch sounds
to activate a tone when you touch the
screen. A check mark displayed next to this feature
indicates active status.
4. Tap
Screen lock sound
to activate a tone when you use
the Lock screen. A check mark displayed next to this
feature indicates active status.
5. Tap
Haptic feedback
to activate the a vibration when
you press soft keys on certain screens. A check mark
displayed next to the feature indicates this feature is
active.
DRAFT
Internal Use Only
270
Samsung Keyboard
These options are used when you use the on-screen keypad.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
.
2. Tap
Key-tap sound
to activate a tone when you use
on-screen keys. A check mark displayed next to this
features indicates active status.
3. Tap
Key-tap vibration
to activate the a vibration when
you press on-screen keys. A check mark displayed
next to the feature indicates this feature is active.
Audio Output
This sound feature configures the audio output.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
➔
Audio output
.
2. Choose from either Stereo or Surround.
Adapt Sound
The Adapt sound feature allows you to customize your call
sounds.
1. From the main
Settings
page, tap
My device
tab ➔
Sound
➔
Adapt Sound
.
2. Read the instructions and tap
Start
.
3. Follow the on-screen instructions to set up your
personal call sound.
Home Screen Mode
This application allows you to set your display to the
conventional layout of
Standard mode
or provide an easier
user experience for the first-time smartphone users using
Easy mode
.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab)
➔ (
Home
screen mode
).
2. Tap the pull-down Dropbox and select one of the
following options:
• Standard mode
: provides conventional layout for the apps and
widgets on your home screens.
•Easy mode
: provides easier user experience for first-time
smartphone users on the home screens.
3. Tap
Apply
and give your device a few seconds to
update the device with the new look and feel.
DRAFT
Internal Use Only
Changing Your Settings 271
Call Settings
1. From the Home screen, tap .
2. Press and then tap
Call settings
.
– or –
From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Call
.
To access the Call settings menu:
1. From the Home screen, tap (
Phone
).
2. Press and then tap
Call settings.
Configuring General Call Settings
Configure the general call settings using this option.
1. From the Home screen, tap (
Phone
). Press
and then tap
Call settings.
2. Tap one of the following options:
• Call rejection
: allows you to manage your rejection mode and
rejection list.
–
Auto reject mode
: sets the phone to automatically reject
incoming calls or messages.
–
Auto reject list
: provides access to current rejection entries
and numbers.
• Set up call rejection messages
: allows you to manage both
existing rejection messages and create new ones.
• Answering/ending calls
: allows you to manage the settings
for answering and ending calls.
–
The home key answers calls
allows you to press to
answer the phone.
–
Voice control
allows you to answer incoming voice calls using
voice.
–
The power key ends calls
allows you to press the power key
to end the current call.
• Turn off screen during calls
: allows you to force the screen to
turn off during an active call.
• Call alerts
: allows you to assign call alert tones and activate
call alerts and vibration.
–
Call vibrations
: vibrates the phone when the called party
answers. Choose from: Answer vibration or Call-end vibration.
–
Call status tones
: assigns sounds settings during the call.
Choose from: Call connect tone, Minute minder, and Call end
tone.
–
Alerts on calls
: selects whether alarm and message
notification is turned off during a call.
DRAFT
Internal Use Only
272
• Call accessories
: allows you to assign headset settings during
incoming calls.
–
Automatic answering
configures the device to automatically
answer and incoming call when a headset is detected.
–
Automatic answering timer
configures the time delay before
the device automatically accepts the incoming call.
–
Outgoing call conditions
configures the connected Bluetooth
device to make outbound calls within one of two settings: Even
when device locked or Only when device unlocked.
• Wi-Fi Calling
: Allows you to both activate/deactivate the Wi-Fi
Calling feature and configure its settings. For more information,
refer to
“Wi-Fi Calling”
on page 60.
Note:
If the Wi-Fi Calling feature is active and connected, the
Call forwarding feature is greyed-out and inaccessible.
• Additional settings
: allows you to configure additional call
settings. For more information, refer to
“Configuring
Additional Voice Call Settings”
on page 275.
• Ringtones and keypad tones
: allows you to manage your
device’s ringtones and vibratory features. Choose from:
Ringtones, Vibrations, Vibrate when ringing, and Dialing keypad
tone
(used when the keypad is pressed).
• Personalize call sound
: allows you to enable the personalize
call sound function within an active call. You can adjust the
audio by enabling selecting an audio preset. For more
information, refer to
“Adjusting the Call Volume”
on page
63.
•Noise reduction
: allows you to enable suppression of
background audio.
• Increase volume in pocket
: enables the ringtone volume to be
increased when the device is in a pocket or bag.
• Voicemail service
: allows you to assign the service.
• Voicemail settings
: displays the settings for the voicemail.
•Sound
: assigns your device’s ringtone.
•Vibrate
: configures the vibrate settings.
• TTY mode
: allows you to configure the TTY settings.
For more information, refer to
“TTY Mode”
on page 279.
DRAFT
Internal Use Only
Changing Your Settings 273
Call rejection
1. From the main
Call settings
page, tap
Call rejection
➔
Auto reject mode
and tap one of the following options:
• All numbers
: to reject all calls.
• Auto reject numbers
: to reject all calls in your Reject list.
2. Tap
Auto reject list
.
3. Tap to manually add numbers to the Reject list.
4. Tap
Unknown
to create a check mark and automatically
reject all calls that are not in your Contacts list.
Set reject messages
1. From the main
Call settings
page, tap
Set up call
rejection messages
.
2. Tap to manually add a reject message.
– or –
Tap one of the pre-written messages to be displayed
when you want the call to be rejected. You can edit the
message if desired.
3. Tap
Save
to save the reject message.
Answering/ending calls
1. From the main
Call settings
page, tap
Answering/
ending calls
.
2. Select any of the following options:
• The home key answers calls
allows you to press to
answer the phone.
• Voice control
allows you to answer incoming voice calls using
voice.
• The power key ends calls
allows you to press the power key
to end the current call.
Turn off screen during calls
This option turns on the proximity sensor during calls so that
your phone will know to turn the screen off to save power.
From the main
Call settings
page, tap
Turn off screen
during calls
to create a check mark and enable the
feature.
DRAFT
Internal Use Only
274
Call alerts
1. From the main
Call settings
page, tap
Call alerts
.
2. Tap
Call vibrations
to enable your phone to vibrate
when the called party answers the phone.
–
Choose from: Answer vibration or Call-end vibration.
3. Tap
Call status tones
to set the sound settings during a
call then tap
OK
.
–
Choose from: Call connect tone, Minute minder, and Call end
tone.
4. Tap
Alerts on calls
to turn off alarm and message
notifications during a call.
Accessory settings for call
1. From the main
Call settings
page, tap
Call accessories
.
2. The following options are available:
• Automatic answering
: configures the device to automatically
answer and incoming call when a headset is detected.
• Automatic answering timer
: configures the time delay before
the device automatically accepts the incoming call.
• Outgoing call conditions
: allows you to make calls even when
the device is locked.
Wi-Fi Calling
Wi-Fi Calling is a free feature for T-Mobile customers using
this device with the new SIM card. Wi-Fi Calling is an
excellent solution for coverage issues in and around the
home or wherever cellular coverage is limited. Minutes used
while connected to the Wi-Fi network count against available
rate plan minutes.
For more information, refer to “Wi-Fi Calling” on page
60.
DRAFT
Internal Use Only
Changing Your Settings 275
Configuring Additional Voice Call Settings
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap one of the following options:
•Caller ID
: chooses whether your number is displayed when
someone answers your outgoing call. Choose from: Network
default, Hide number, or Show number.
• Call forwarding
: configures the forwarding settings. For more
information, refer to
“Configuring Call Forwarding”
on
page 275.
• Auto area code
: allows you to automatically prepend a specific
area code to all outbound calls.
•Call barring
: blocks specific types of calls (All outgoing calls,
International calls, etc..).
• Call waiting
: notifies you of an incoming call while you are on
another call.
• Auto redial
: automatically redial the dialed number if it is
unable to connect or the call is cut off.
• Fixed dialing Numbers
: manages fixed dialing numbers. See
description below.
Configuring Call Forwarding
1. From the main
Call settings
page, tap
Additional
settings
➔
Call forwarding
.
Important!
Call Forwarding is disabled when the Wi-Fi Calling
feature is enabled.
2. Tap an available option:
• Always forward
: incoming calls are re-routed to a secondary
number that you specify.
• Forward when busy
: forwards all your calls to voicemail when
your phone is busy.
• Forward when unanswered
: automatically forwards to your
voicemail number when the phone is not answered, and
otherwise allows you to enter a voicemail number.
• Forward when unreachable
: automatically forwards to your
voicemail number when the phone is not in service, or is turned
off.
DRAFT
Internal Use Only
276
Using Auto Area Code
This feature prepends an area code to all outbound calls.
When enabled, the designated prefix is always added before
your dialed numbers.
Ex: If you were using 999 as your area code, 555-5555
would be dialed as 999 - 555-5555.
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Auto area code
, enter a new prefix, and then tap
OK
.
Call Barring
Configures the device to barr (prevent) selected outbound
calls.
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Call barring
and select from the available settings.
Choose from: All outgoing calls, International calls, Intl’
calls except home, All incoming calls, or Incoming
when roaming.
Call Waiting
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Call waiting
to enable/disable the on-screen
notification of new incoming call during an active call.
Auto Redial
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Auto redial
to automatically enable/disable the
feature whereby the device redials the dialed number if
it is unable to connect or the call is cut off.
Fixed Dialing Numbers
Fixed Dial Number (FDN), allows you to restrict outgoing calls
to a limited set of phone numbers.
Enabling FDN
1. From the main
Call settings
page, tap
Additional
settings
➔
Fixed dialing numbers
.
2. Tap
Turn on FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.
DRAFT
Internal Use Only
Changing Your Settings 277
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
an incorrect PIN2 code could cause the phone to
lock. Contact customer service for assistance.
Changing the PIN2 Code
1. From the main
Call settings
page, tap
Additional
settings
➔
Fixed dialing numbers
.
2. Tap
Change PIN2
.
3. At the prompt, enter your old PIN2 code.
4. At the prompt, enter a new PIN2 code.
5. Confirm your PIN2 code.
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
the PIN2 incorrectly three times will cause the
device to lock. Contact customer service for
assistance.
Managing the FDN List
When this feature is enabled, you can make calls only to
phone numbers stored in the FDN list on the SIM card.
1. From the main
Call settings
page, tap
Additional
settings
➔
Fixed dialing numbers
.
2. Tap
Turn on FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.
FDN is enabled.
4. Tap
FDN list
then press and then tap
Add contact
or edit the contacts that were stored.
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
the PIN2 incorrectly three times will cause the
device to lock. Contact customer service for
assistance.
DRAFT
Internal Use Only
278
Ringtones and keypad tones
1. From the main
Call settings
page, tap
Ringtones and
keypad tones
.
2. Tap
Ringtones
, select a ringtone, and tap
OK
.
•
Tap
Add
to locate an audio file to create as a ringtone.
3. Tap
Vibrations
, select a vibration type, and tap
OK
.
•
Tap
Create
to begin creating your own custom vibration.
4. Tap
Vibrate when ringing
to create a check mark if you
want your phone to vibrate when a call is incoming.
5. Tap
Dial keypad tones
to create a check mark if you
want tones to play when the keypad is pressed.
Personalize call sound
This option allows you to personalize the sounds you hear
during a call with and without earphones.
From the main
Call settings
page, tap
Personalize call
sound
and activate the feature by selecting an available
option.
For more information, refer to “Personalizing the Call Sound
Setting” on page 64.
Noise reduction
This option allows you to suppress background noise during
a call.
From the main
Call settings
page, tap
Noise reduction
to create a check mark and enable the feature.
Increase volume in pocket
This option increases the ringtone volume when the device is
in a pocket or a bag. It uses the proximity sensor to detect its
location.
From the main
Call settings
page, tap
Increase volume
in pocket
to create a check mark and enable the
feature.
Voicemail
You can view your voicemail number from this menu.
1. From the main
Call settings
page, tap
Voicemail service
.
2. If an additional voicemail service is in use (other than
carrier), tap
Voice settings
to now view your selected
voicemail number and information.
DRAFT
Internal Use Only
Changing Your Settings 279
Sound - Voicemail Ringtone
This option allows you to assign your default voicemail
notification tone.
1. From the main
Call settings
page, tap
Sound
.
2. Select a voicemail notification tone and tap
OK
.
Vibrate
This option allows you to activate a vibration for an incoming
voicemail.
From the main
Call settings
page, tap
Vibrate
field to
toggle the feature on or off.
TTY Mode
A TTY (also known as a TDD or Text Telephone) is a
telecommunications device that allows people who are deaf,
hard of hearing, or who have speech or language disabilities,
to communicate by telephone.
Your device is compatible with select TTY devices. Please
check with the manufacturer of your TTY device to ensure
that it is compatible with digital cell phones.
Your phone and TTY device will connect via a special cable
that plugs into your phone’s headset jack. If this cable was
not provided with your TTY device, contact your TTY device
manufacturer to purchase the connector cable.
1. From the main
Call settings
page, tap
TTY mode
.
2. Tap
TTY Full
,
TTY HCO
,
or
TTY VCO
to activate the
feature, or
TTY Off
to deactivate the feature. Off is the
default setting.
Blocking Mode
When Blocking mode is enabled, notifications for selected
features will be disabled. You will only receive notifications of
incoming calls from people on your allowed list.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab).
2. In a single motion touch and slide the
Blocking mode
slider to the right to turn it on.
Confirm the Blocking mode active icon appears in
the Status bar.
DRAFT
Internal Use Only
280
3. Place a green check mark adjacent to those features
you would like to enable. Choose from: Block incoming
calls, Turn off notifications, Turn off alarm and timer,
Turn off LED indicator.
4. Configure a timeframe for these features to be active.
Remove the check mark from the
Always
field to
configure the
From
and
To
time fields.
5. Tap
Allowed contacts
to assign those contacts that are
exempted from these rules. Choose from None, All
contacts, Favorites, or Custom. Allowed contacts will
then appear in the
Allowed contact list
.
Hands-free Mode
When enabled, alarm and information will be read aloud.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Hands-free
mode
.
2. In a single motion touch and slide the
Hands-Free mode
slider to the right to turn it on.
Confirm the Hands-Free mode active icon
appears in the Status bar.
3. Enable any of the following options:
• Incoming call
: read out callers’ information when receiving
incoming calls.
•ChatON
: read out ChatON callers’ information when receiving
incoming calls.
• Air call-accept
: wave your hand over the screen to accept
incoming calls.
• Message
: read out senders’ information when receiving
incoming calls.
•Alarm
: read out alarm information when alarms sound.
• Schedule
: read out scheduled alarm information when alarms
sound.
Power Saving Mode
This feature allows you both automatically set the phone to
use a power saving mode and configure additional power
saving options manually, all in an effort to conserve battery
power.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Power saving
mode
.
DRAFT
Internal Use Only
Changing Your Settings 281
2. In a single motion touch and slide the slider to the right
to turn it on.
3. Tap the following options to create a check mark and
conserve power:
• CPU power saving
: allows you to limit the maximum
performance of the CPU.
• Screen power saving
: allows you to lower the screen power
level.
• Turn off haptic feedback
: allows you to turn off vibration when
you tap or touch the screen.
4. Tap
Learn about Power saving
to learn about various
ways to conserve battery power.
Accessory
This menu allows you to select the Audio output mode when
using a car or desk dock.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Accessory
.
2. Tap
Dock sound
to play sounds when inserting or
removing the phone from the dock.
3. Tap
Audio output mode
to use the external dock
speakers when the phone is docked.
4. Tap
Desk home screen display
if you wish to show the
desk home screen when the device is docked.
5. Tap
Automatic unlock
if you are using a phone cover
and you want your phone to unlock when you open the
cover.
6. Tap
Audio output
to set your Audio output to Stereo or
Surround.
Accessibility Settings
This service lets you enable and disable downloaded
accessibility applications that aid in navigating your Android
device, such as TalkBack (uses synthesized speech to
describe the results of actions), KickBack (provides haptic
feedback for actions), and SoundBack (plays sounds for
various actions). Also lets you enable use of the power key to
end calls.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Accessibility
.
Note:
Initially, it might be necessary to download accessibility
applications from the Play Store.
My device
My device
DRAFT
Internal Use Only
282
2. Select the
Auto rotate screen
field to activate this
feature which automatically rotates an available
screen.
3. Tap
Screen timeout
to timeout the accessibility feature
after a defined amount of time.
4. Tap
Lock automatically
to lock the screen automatically
after a selected amount of time.
Note:
The Lock automatically function is only available if your
device is already using the screen lock feature.
5. Select the
Speak passwords
field to activate this
feature which reads out password information.
6. Select
Answering/ending calls
field to select the
methods you can use to answer and end a call.
7. Select
Easy touch mode
field to be able to tap to
stop/snooze alarms, calendar events, and timer alerts,
and accept/reject incoming calls.
8. Tap
Show shortcut
allows you to press and hold
(
Power/End
) to use the accessibility shortcut
under the Device options screen.
9. Tap
Manage accessibility
to save and update your
accessibility settings or share them with another
device. You can export your settings, import a
previously saved file, or share your file with another
device.
10. Tap
TalkBack
to activate the feature.
Note:
TalkBack, when installed and enabled, speaks feedback
to help blind and low-vision users.
Important!
TalkBack can collect all of the text you enter,
except passwords, including personal data and
credit card numbers. It may also log your user
interface interactions with the device.
11. Tap the
Font size
field to change the size of the fonts
used on the device within menus, options, etc..
Choose from: Tiny, Small, Normal, Large, or Huge.
12. Enable
Magnification gestures
to use exaggerated
gestures such as triple-tapping, double pinching, and
dragging two fingers across the screen.
DRAFT
Internal Use Only
Changing Your Settings 283
13. Tap the
Negative colors
field to reverse the display of
on-screen colors from White text on a Black
background to Black text on a White background.
14. Select
Color adjustment
to allow you to adjust the
display colors if you are color blind and have difficulty
reading the display because of the colors. Touch and
slide the slider to the right to turn it on. Follow the
on-screen instructions.
15. Tap
Notification reminder
to allow you to play a beep
when you have unread notifications. Touch and slide
the slider to the right to turn it on. Follow the on-screen
instructions.
16. Tap
Accessibility shortcut
to allow you to quickly enable
accessibility features in 2 quick steps. Touch and slide
the slider to the right to turn it on. Follow the on-screen
instructions.
17. Tap the
Text-to-speech options
field to configure the
text to speech configuration parameters.
18. Use the
Sound balance
field to allow you to use the
slider to set the Left and Right balance when using a
stereo device.
19. Tap the
Mono audio
field to enable stereo audio to be
compressed into a single mono audio stream for use
with a single earbud/earphone.
20. Tap the
Turn off all sounds
field to mute every sound
made by the device during taps, selections,
notifications, etc..
21. Tap the
Hearing aids
field to improve the sound quality
of your device for use with hearing aids.
22. Tap
Flash notification
to allows you to set your camera
light to blink whenever you receive a notification.
23. Enable the
Assistant menu
to allow you to improve the
device accessibility for users with reduced dexterity.
Touch and slide the slider to the right to turn it on.
Follow the on-screen instructions.
24. Tap the
Press and hold delay
field to select a time
interval for this action. Choose from: Short (0.5),
Medium (1.0 second), Long (1.5 seconds), or Custom.
DRAFT
Internal Use Only
284
25. Enable
Interaction control
to allows you to enable or
disable motions and screen timeout. You can also block
areas of the screen from touch interaction. Touch and
slide the slider to the right to turn it on. Follow the
on-screen instructions.
Language and Input Settings
This setting allows you to configure the language in which to
display the menus. You can also set on-screen keyboard
options.
From the Home screen, press and then tap
Settings
➔ (
My device
tab) ➔
Language and
input
.
Language Settings
To set the language that the menus display on the phone:
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔
Language
.
2. Select a language and region from the list.
Choose Input Method
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔
Default
.
2. Select an input method.
– or –
Tap
Set up input methods
to alter/modify the available
input methods.
Samsung Keyboard Settings
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔ (adjacent to the
Samsung
keyboard
field).
– or –
From within an active text entry screen, touch and hold
(
Input Methods
), drag across the icons, and
select (
Settings
) to reveal the
Samsung keyboard
settings
screen.
2. Set any of the following options:
• Input languages
sets the input language. Tap a language from
the available list. The keyboard is updated to the selected
language.
DRAFT
Internal Use Only
Changing Your Settings 285
• Predictive text
enables predictive text entry mode. This must
be enabled to gain access to the advanced settings. Touch and
hold to access the advanced settings.
• Auto replacement
automatically completes or replaces the
current word with the most probable word match after tapping
the space bar or entering a punctuation mark.
•Auto capitalization
automatically capitalizes the first letter of
the first word in each sentence (standard English style).
•Auto spacing
automatically inserts space between words.
• Auto punctuate
automatically inserts a full stop in a sentence
by tapping the space bar twice when using the on-screen
QWERTY keyboard.
• Keyboard swipe
: allows you to combine the Samsung
keyboard with an additional input method choose from:
–
None
leaves text input as only via the on-screen keyboard.
–
SwiftKey Flow
like using Swipe, allows you to enter text by
sliding your fingers across the on-screen keyboard. This feature
is optimized for use with the on-screen QWERTY keyboard.
–
Cursor control
when enabled, allows you to control your
on-screen cursor by moving your finger across the keyboard.
• Key-tap feedback
provides feedback functions to be enabled
such as:
–
Sound
enables auditory feedback when you tap an
on-screen key.
–
Vibration
enables vibration feedback when you tap an
on-screen key.
–
Character preview
provides an automatic preview of the
current character selection within the text string. This is helpful
when multiple characters are available within one key.
• More settings
provides access to additional settings.
–
Help
launches a brief on-screen help tutorial covering the main
concepts related to the Samsung keyboard.
–
Reset settings
resets the keyboard settings back to their
original configuration.
DRAFT
Internal Use Only
286
Predictive Text - Advanced Settings
The predictive text system provides next-letter prediction and
regional error correction, which compensates for users
pressing the wrong keys on QWERTY keyboards.
Note:
Only available when ABC mode is selected. Predictive
text advanced settings are available only if the Predictive
function is enabled.
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔ (adjacent to the
Samsung
keyboard
field).
– or –
From within an active text entry screen, touch and hold
(
Input Methods
) ➔ to reveal the
Samsung
keyboard settings
screen.
2. In a single motion touch and slide the
Predictive text
slider to the right to turn it on.
3. Tap the
Predictive text
field and configure any of the
following advanced options:
• Live word update
allows the device to automatically update its
word database with popular new words every day.
• Personalized data
activate this feature to use the personal
language data that you have entered and selected to make
your text entry prediction results better. By enabling this feature
you can choose from the following personalization features:
• Learn from Facebook
allows you to log into your current
Facebook account and add used text to your personal
dictionary.
• Learn from Gmail
: allows you to sign in to your existing Gmail
account from where your style and existing contact information
is added to your personal dictionary. Helps recognize familiar
names.
• Learn from Twitter
allows you to sign into your existing Twitter
account and add used text to your personal dictionary.
• Learn from Messages
allows your device to learn your
messaging style by using your Messaging information.
• Learn from Contacts
updates predictive style by learning your
Contacts style.
•Clear remote data
allows you to delete your anonymous data
stored on the personalization server.
• Clear personal data
removes all personalized data entered by
the user.
DRAFT
Internal Use Only
Changing Your Settings 287
•Privacy
displays on-screen privacy information.
4. Press to return to the previous screen.
Swype Settings
To configure Swype settings:
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔ (adjacent to the
Swype
field).
2. Tap
Settings
on the left side of the screen to alter these
settings:
• Vibrate on keypress
: activates a vibration sensation as you
enter text using the keypad.
• Sound on keypress
: turns on sounds generated by the Swype
application.
• Pop-up on keypress
: displays the character above the key
when typing.
• Show complete trace
: once enabled, sets wether or not to
display the complete Swype path.
•Auto-capitalization
: automatically capitalizes the first letter of
a sentence.
•Auto-spacing
: automatically inserts a space between words.
When you finish a word, just lift your finger or stylus and start
the next word.
• Next word prediction
: once enabled, predicts the next word in
your text string based on your current text entries.
• Show Voice key
: once enabled, displays the Voice icon on
your Swype keyboard so you can use the Voice input option.
3. Tap
My Words
on the left side of the screen to access
the following options:
• Backup & Sync
: allows you to backup your Swype dictionary
and sync your Swype dictionary across multiple devices.
• Living Language
: when enabled, this feature automatically
updates your Swype dictionary with popular new words.
• Social integration
: allows you to learn information from your
Facebook, Twitter, and Gmail accounts to help you while using
Swype.
• Edit my dictionary
: allows you to edit your personal Swype
dictionary.
• Clear language data
: deletes all of your personal language
data, including your words.
DRAFT
Internal Use Only
288
• Contribute usage data
: when enabled, allows the Nuance
®
application to collect usage data for better word predictions.
•Cellular data
: when enabled, activates cellular data usage by
the Swype application so it can receive program updates,
language downloads, and other related features via your
existing data connection.
4. Tap
Languages
on the left side of the screen to activate
and select the current text input language. Default
language is English. Touch
Download languages
, to
download additional languages.
5. Tap
Gestures
on the left side of the screen to view
helpful information on using gestures while using
Swype.
6. Tap
Help
on the left side of the screen to see the
following options:
•How to Swype
: provides tips on how to learn to use Swype.
• Show helpful tips
: once enabled, displays helpful tips and
hints as you are using Swype.
•Version
: displays the software version information.
7. Tap
Updates
on the left side of the screen to download
any new Swype updates. If an update is available, it
will display under the updates heading. If no updates
are displayed, then check back later to see any
available updates.
Configure Google Voice Typing
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
.
– or –
From a screen where you can enter text, in a single
motion, touch and drag the Status bar down to the
bottom of the screen, then select (
Select input
method
)
➔
Set up input methods
.
2. Tap (adjacent to the
Google voice typing
field).
3. Select a language by tapping
Choose input languages
area.
4. Remove the check mark from the
Automatic
field. This
allows you to select additional languages.
5. Select the desired languages.
DRAFT
Internal Use Only
Changing Your Settings 289
6. Activate
Block offensive words
to block recognition of
known offensive words or language. (A blue check
mark indicates the feature is active).
7. Tap
Download offline speech recognition
to enable speech
recognition via locally stored files so that even if you
are not connected to a network you can still use the
service.
Configuring Voice Input Recognition
This feature allows the device to correctly recognize verbal
input.
1. From the main
Settings
page, tap
My device
tab ➔
Language and input.
2. Tap
Voice search
to configure the following:
• Language
: choose a language for your voice input.
• Speech output
: Sets whether you will use speech output
always or only when using hands-free.
• Block offensive words
: enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
• Hotword detection
: enable to being able to launch voice
search by saying the word “Google”.
• Download offline speech recognition
: enables voice input
while offline.
• Bluetooth headset
: records audio through a connected
Bluetooth headset.
3. Press to return to the previous screen.
Configuring Text-to-speech
This feature allows the device to provide a verbal readout of
on-screen data such as messages and incoming caller
information. This action is called TTS (Text To Speech).
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔
Text-to-speech options
.
2. Select a current Preferred TTS engine from the list of
available options. Select
Samsung text-to-speech
engine
or
Google Text-to-speech Engine
. The default is
Google Text-to-speech.
DRAFT
Internal Use Only
290
3. Tap next to the preferred TTS engine configure
the following settings:
• Language
: allows you to set the language for spoken text.
• Settings for Google Text-to-speech Engine
: allows you to
view Open Source Licenses.
• Settings for Samsung text-to-speech engine
: allows you to
configure the General settings for the Samsung TTS.
• Install voice data
: allows you to install voice data for speech
synthesis.
4. Configure the General options to alter the settings
associated with this feature:
• Speech rate
: adjusts the rate at which on-screen text is
spoken by the device.
• Listen to an example
: plays a short example of what the text-
to-speech feature sounds like on your device when activated.
Configuring the Mouse-TrackPad
This feature allows you to configure the pointer speed for a
connected mouse or trackpad.
1. From the main
Settings
page, tap
My device
tab ➔
Language and input
➔
Pointer speed
.
2. Adjust the slider and tap
OK
.
Motions and Gestures Settings
This feature allows you to assign specific functions to certain
phone actions that are detected by both the accelerometer
and gyroscope.
Caution!
Excessive shaking or impact to the device may cause
unintended results. To learn how to properly control
motions, tap (
Apps
) ➔
Settings
➔
My device
tab
➔
Motions and gestures
. When tapped, each entry
comes with an on-screen tutorial.
• Air gesture
: Allows you to control your device by performing
motions above the sensor (without touching the device).
•Motion
: Allows you to control your device using natural
movements (on the screen).
DRAFT
Internal Use Only
Changing Your Settings 291
• Palm motion
: Allows you to control your device by touching the
screen with your entire hand.
To activate Air gesture:
1. From the Home screen, press and then tap
Settings
➔
My device
tab ➔
Motions and gestures
.
2. In a single motion touch and slide the
Air gesture
slider
to the right to turn it on.
3. Read the on-screen notification and tap
OK
.
Note:
At least one feature must be activated before Air gesture
can be activated.
4. Tap
Learn about sensor and icon
field to review
on-screen information about the Air gestures sensor
and related icon.
5. In a single motion, slide a feature’s activation slider to
the on position.
The following is a description some of the most commonly
used gestures:
•
Quick glance
: Once enabled, you can move your hand over the
air gesture sensor (located above the on-screen clock at the
upper-right) to temporarily activate preview window that can be
used to display selected user-enabled information such as:
Time & Date, Notification icons, Missed calls, etc..
•
Air jump
: Once enabled, you can move your hand over the air
gesture sensor (up or down) and easily jump to either the top or
bottom of a lengthy display page (ex: Internet or Email).
•
Air browse
: Once enabled, you can move your hand over the air
gesture sensor (left or right) and easily move to either the
previous or next item in a series (ex: music tracks, pictures, or
pages).
•
Air move
: Once enabled, you can move use one finger to hold
down on an app shortcut or event entry and then swipe across the
air gestures sensor to then move it to a new a different page.
•
Air call-accept
: Once enabled, you can simply wave your hand
over the air gesture sensor to accept any incoming call.
DRAFT
Internal Use Only
292
To activate Motion:
1. From the main
Settings
page, tap
My device
tab ➔
Motions and gestures
.
2. In a single motion touch and slide the
Motion
slider to
the right to turn it on.
3. Read the on-screen notification and tap
OK
.
Note:
At least one feature must be activated before Motion can
be activated.
4. In a single motion, slide a feature’s activation slider to
the on position.
The following is a description some of the most commonly
used gestures:
•
Direct call
: Once enabled, the device will dial the currently
displayed on-screen Contact entry as soon as you place the
device to your ear.
•
Smart alert
: Once enabled, pickup the device to be alerted and
notified of you have missed any calls or messages.
•
Zoom
: Once enabled, you must be on a screen where content can
be zoomed. In a single motion, touch and hold two points on the
display then tilt the device back and forth to zoom in or out.
•
Browse an image
: Once enabled, touch and hold a desired
on-screen image to pan around it. Move the device left or right to
pan vertically or up and down to pan horizontally around the large
on-screen image.
•
Mute/pause
: Once enabled, mute incoming calls and any playing
sounds by turning the device display down on a surface. This is
the opposite of the Pickup to be Notified Gesture.
To activate Palm Motion:
1. From the main
Settings
page, tap
My device
tab ➔
Motions and gestures
.
2. In a single motion touch and slide the
Palm motion
slider to the right to turn it on.
3. Read the on-screen notification and tap
OK
.
Note:
At least one feature must be activated before Palm
motion can be activated.
4. In a single motion, slide a feature’s activation slider to
the on position.
The following is a description some of the most commonly
used gestures:
DRAFT
Internal Use Only
Changing Your Settings 293
•
Capture screen
: Once enabled, you can capture any
on-screen information swiping across the screen. In a single
motion, press the side of your hand on the screen and swipe form
left to right. The image is then copied to the clipboard.
•
Mute/pause
: Once enabled, you can pause any
on-screen video or mute any current sound by simply covering
the screen with your hand. Once you remove your hand from the
screen, the device goes back to normal by either continuing to
play the current video or unmuting the current sound.
Smart screen
The Smart screen options allow you to customize your
screen settings to make the screen more responsive and
easier to use.
1. From the Home screen, press and then tap
Settings
➔ (
My device
tab)
➔
Smart screen
.
2. Tap any of the following options to create a checkmark
and activate the features:
•Smart stay
: disables the screen timeout if your phone detects
that your face is watching the screen.
• Smart rotation
: disables the auto screen rotation by checking
the orientation of your face and the device.
• Smart pause
: pauses videos when your device detects that
your head has moved away from the screen.
• Smart scroll
: once your eyes have been detected, the screen
will scroll according to your device’s tilt angle. Tap the adjacent
field to the right of the Smart scroll field to activate the feature.
With Smart scroll, the screen will scroll depending on the
phone’s tilt angle once your eyes have been detected.
Air view
With the Air view feature, you can hover your finger over the
screen and Air view features will be displayed. For example,
you can hover your finger over a scheduled item in your
calendar to see more details.
1. From the main
Settings
page, tap
My device
tab
➔
Air view
.
2. Tap the ON/OFF icon at the top of your screen to
activate Air view ( ).
DRAFT
Internal Use Only
294
3. The following options are available. Tap an option to
create a checkmark and activate the feature.
• Information preview
: allows you to see information previews,
extended text, and enlarged images when you hover your
finger over the screen.
Note:
It is recommended that the Information preview function
be enabled if using Air view.
• Progress preview
: allows you to preview a scene or show
elapsed time when you hover your finger over the progress bar
while watching a video.
• Speed dial preview
: allows you to see the contacts and their
speed dial numbers when you hover your finger over them in
your contacts list.
• Webpage magnifier
: allows you to see magnified links on
webpages when you hover your finger over them.
• Sound and haptic feedback
: allows you to play sound and
feel vibration when you hover your finger over Air view items.
Voice control
The Voice control settings allow you to set up voice
commands to control your device.
1. From the main
Settings
page, tap
My device
tab
➔
Voice control
.
2. Verify the feature is active by tapping at the
top of your screen to activate Voice control.
3. The following options are available. Tap an option to
create a checkmark and activate the feature.
• Incoming calls
: allows you to answer or reject calls using the
commands
Answer
and
Reject
.
•ChatON
: allows you to answer or reject calls using the
commands
Answer
and
Reject
.
•Alarm
: allows you to stop or snooze an alarm by using the
commands
Stop
and
Snooze
.
•Camera
: allows you to take pictures using the voice
commands
Smile
,
Cheese
,
Capture
, or
Shoot
.
•Music
: allows you to control your Music player using the voice
commands
Next
,
Previous
,
Pause
,
Play
,
Volume Up
, and
Volume Down
.
DRAFT
Internal Use Only
Changing Your Settings 295
Note:
If you set the alert type for calls or alarms to vibration,
voice control will not be available.
Add Account
This menu allows you to set up, manage, and synchronize
accounts, including your Google and email accounts.
Adding an Account
1. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab).
2. Navigate to the
My accounts
area and then tap
Add
account
and select one of the account types.
3. Use the keyboard and follow the prompts to enter your
credentials and set up the account.
4. A green circle will appear next to the account type once
you have created an account. Your email account will
also be displayed in the
Accounts
section of the main
Settings menu.
Removing an Account
Important!
Removing an account also deletes all of its
messages, contacts, and other data from the
device.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area and then tap the
account name.
3. From the Accounts area of the screen, tap the account
entry.
4. Tap
Remove account
, then tap
Remove
account
at the
prompt to remove the account and delete all its
messages, contacts, and other data.
DRAFT
Internal Use Only
296
Synchronizing a Accounts
By default, all managed accounts are synchronized. You can
also manually sync all current accounts.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area and then tap the
account name.
3. Tap the account name entry.
4. Tap
Sync now
to synchronize your account or tap
Sync
all
to synchronize all your accounts. Tap
Cancel sync
to
stop the synchronization.
5. Tap
Settings
to access your account settings.
Creating a Samsung Account
Just as important as setting up and activating a Google
account to help provide access to Play Store, etc.. An active
Samsung account is required to begin accessing applications
such as Samsung Hub.
Note:
The Samsung account application will manage your
access to the previously mentioned applications, and
there is no longer a need to remember different
passwords for each application.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area
and then tap
Add account
➔
Samsung account
.
3. If you have previously created a Samsung account, tap
Sign in
.
– or –
If this is your first time, tap
Create new account
.
4. Follow the on-screen instructions.
Note:
You may be prompted to confirm your credentials via
email.
5. If prompted, follow the on-screen instructions to verify
your account via the provided email address.
Note:
Without confirming your email address and following the
documented procedures, related applications will not
function properly since it is Samsung account that is
managing their username and password access.
DRAFT
Internal Use Only
Changing Your Settings 297
Cloud
This feature allows you to use your external cloud storage
solution to both synchronize your device to your Samsung
account and then backup that local content to the cloud.
Your device comes with a built-in Cloud storage solution
known as Dropbox.
Important!
This feature requires an active Wi-Fi connection
prior to use.
1. Log into your Samsung account and verify it is active.
For more information, refer to “Creating a Samsung
Account” on page 296.
2. Log into your external cloud storage solution. In our
case we are using a Dropbox account. For more
information, refer to “Dropbox” on page 167.
3. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) ➔
Cloud
.
4. Confirm your Samsung account appears at the top of
the screen.
5. Tap
Storage usage
to display an overview of your total
used space.
6. Tap
Sync settings
, select which device parameters will
be synched, and tap
Sync now
. Choose from: Sync
Calendar, Sync Contacts, Sync Internet, and Sync
Memos.
7. Tap
Backup
or
Restore
to launch the feature.
•Backup
: manually loads up the currently selected categories
and backs up the data to your cloud storage location. Tap
Backup
to begin the manual backup process.
•Restore
: allows you to retrieve your previously backed up data
from your Samsung account and then download it to your
device.
8. Tap
Link Dropbox account
➔
Allow
to now link your
active Dropbox account.
DRAFT
Internal Use Only
298
Backup and Reset
Location settings, backup configurations, or reset the phone
to erase all personal data.
From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) ➔
Backup and
reset
.
Mobile Backup and Restore
The device can be configured to back up your current
settings, application data and settings.
1. From the main
Settings
page, tap
Accounts
tab ➔
Backup and reset
.
2. Tap
Back up my data
to create a backup of your current
phone settings and applications.
3. Tap
Backup account
to assign the account being
backed up.
4. Tap
Automatic restore
to assist in the re-installation of
a previously installed application (including
preferences and data).
5. Tap
Factory data reset
to reset your device and sound
settings to the factory default settings.
6. Tap
Collect diagnostics
to collects diagnostic data for
troubleshooting use. For more information, refer to
“Collect Diagnostics” on page 302.
Backing up Your Data Before Factory
Reset
Backing Up Your Contacts using an SD card
Before initiating a factory reset, it is recommended that you
backup your personal data prior to use.
Important!
If you choose to back up contacts to your SIM card,
all information other than name and number is lost.
Therefore, it is recommended that you back up
contacts to your SD card.
DRAFT
Internal Use Only
Changing Your Settings 299
To export a Contact list to your microSD card:
1. From the Home screen, tap (
Contacts
).
2. Press and then tap
Import/Export
.
3. Tap
Export to SD card
➔
OK
. The contacts will be stored
in a .vcf file on your SD card.
For more information, refer to “Export/Import” on page
100.
To copy contacts from an SD card back to your device:
1. From the Home screen, tap (
Contacts
).
2. Press and then tap
Import/Export
➔
Import from
USB storage
.
3. At the Save contact to prompt, tap
Device
. The contacts
on the SD card are copied to your phone.
Backing Up Media to your PC
You can back up your pictures, videos, documents, and other
media to your PC. You can connect your device to a PC as a
removable disk and copy files back and forth between your
phone and PC. If you insert an SD card in the device, you can
also access the files directory from the SD card by using your
device as a memory card reader.
1. Connect the USB cable to your device, then connect the
cable to your PC USB port. After a few seconds, a
pop-up window displays on the PC when it is
connected with your device.
2. On the PC pop-up, click
Open device
to view files.
3. Verify your device appears as a removable disk on your
PC. Once connected, you can access the Phone folder
(internal phone memory) and the Card folder (SD card).
4. Select the location where the files are that you would
like to copy to your PC (Device or Card).
5. Select the folders where the information is kept. This
would include folders such as DCIM (camera pictures
and videos), Pictures, Music, Playlists, Download, etc.
DRAFT
Internal Use Only
300
6. Select the files that you want to copy and copy them
(Control C - copy) to a folder on your PC (Control V -
paste).
7. Disconnect the USB cable from your phone and the PC.
8. To copy files on your PC back to your phone, simply
reverse the procedure.
Verify your images and videos are on your microSD card:
1. From the Home screen, tap (
Apps
)
➔
(
Gallery
).
2. Verify the Gallery contains all of your pictures and
videos.
3. Remove both the back cover and remove the internal
microSD card prior to initiating the process.
Backing Up Media to your SD card
You can back up your pictures, videos, documents, and other
media to your SD card.
1. From the Home screen, tap (
Apps
)
➔
(
My Files
).
2. Select the folder where the files are that you would like
to copy to the SD card. This would include folders such
as DCIM (camera pictures and videos), Pictures, Music,
Playlists, Download, etc. For example, tap (
Apps
)
➔ (
My Files
) ➔
Images
➔
Camera
.
3. Tap the files that you want to copy to create a
checkmark in the box next to the filename.
4. Tap the options icon in the top right corner of the
display.
5. Select
Copy
➔
SD memory card
.
6. Go to the folder on your SD card where you would like
to copy to files to. For example, Pictures.
7. Tap
Paste here
in the top right corner of the display.
8. The files are copied to the folder.
DRAFT
Internal Use Only
Changing Your Settings 301
Backing Up Internet Bookmarks to your
Samsung Account
You can back up your Internet bookmarks by using your
Samsung account. Only bookmarks you have added (non-
default) can be backed up.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area and then tap
Add
account
and select
Samsung account
.
3. Sign in to your Samsung account or tap
Create new
account
if you don't have one yet.
Follow the on-screen instructions.
4. From the Home screen, tap (
Apps
)
➔
(
Internet
).
5. From the webpage, tap (
Bookmarks
).
6. Press and then tap
Move to folder
.
7. Place a checkmark on those Bookmarks you want to
back up, then tap
Done
.
8. Select a location or folder. The Bookmarks that you
moved are now listed under the Samsung account
heading in your Bookmark list.
9. When you get a new phone, update your software, or
reset your device, sign in to your Samsung account and
the backed up bookmarks will be displayed on your
Bookmarks page under the Samsung account heading.
Backing Up Settings to Google
You can use your Google account to back up apps, Wi-Fi
passwords, and other data.
1. From the Home screen, tap (
Apps
)
➔
(
Gmail
).
2. Tap
Existing
if you have a Google account.
The Inbox loads conversations and email.
– or –
Tap
New
if you do not have a Google account.
3. Confirm that immediately after signing in to your
Google account, the Google services screen is
displayed.
4. From within the Google services screen, tap the
checkbox within the
Backup
area.
5. From the Home screen, press and then tap
Settings
➔ (
Accounts
tab) ➔
Backup and
reset
.
DRAFT
Internal Use Only
302
6. Tap
Back up my data
to create a checkmark. This will
back up your app data, Wi-Fi passwords, and other
settings.
7. Your Google account should be listed under the
Backup
account
option. If not, Tap
Backup account
➔
Add
account
and sign into your Google account.
8. Tap the checkbox next to
Automatic restore
to create a
checkmark. This will restore the settings that were
backed up when you re-install an application.
Factory Data Reset
From this menu you can reset your device and sound settings
to the factory default settings.
1. From the main
Settings
page, tap
Accounts
tab ➔
Backup and reset
➔
Factory data reset.
2. Read the on-screen reset information.
3. Tap
Reset
device.
4. If necessary, enter your password and tap
Delete all
.
The device resets to the factory default settings
automatically and when finished displays the Home
screen.
Collect Diagnostics
This feature only collects diagnostic data for troubleshooting
use.
1. From the main
Settings
page, tap
Accounts
tab ➔
Backup and reset
➔
Collect diagnostics.
2. Read the on-screen System Manager Application
information.
Note:
This software collects only diagnostic data from your
device so that T-Mobile technicians can better
troubleshoot issues with your device.
3. Choose to enable or disable the feature by placing a
check mark in the
Allow diagnostics to be collected
field.
4. Select either
More info
(to read additional information)
or
Close
to close the message screen.
DRAFT
Internal Use Only
Changing Your Settings 303
Important!
Selecting
Close
only closes the current description
screen and does not disable data collection.
To disable data collection, go to
Settings
➔
Accounts
tab
➔
Back up and reset
➔
Collect
diagnostics
and turn off the
Allow diagnostics to be
collected
feature.
Location Services
The Location services allows you to configure the device’s
location services.
Important!
The more location determining functions are
enabled, the more accurate the determination will
be of your position.
1. From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Location services
.
2. Tap any of the following options to create a checkmark
and activate the service:
• Access to my location
: allows apps that have asked your
permission to use your location information. Tap the ON/OFF
slider to turn it on.
• Use GPS satellites
: allows applications to use GPS to pinpoint
your location.
• Use wireless networks
: allows applications to use data from
mobile networks and Wi-Fi to help determine your location.
•My places
: allows you to add location information for your
Home, Office, and Car.
Enabling the GPS Satellites
1. From the main
Settings
page, tap
More
tab ➔
Location
services
.
2. Tap
Use GPS satellites
to enable the GPS satellite.
Using Wireless Networks
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Use wireless networks option.
1. From the main
Settings
page, tap
More
tab ➔
Location
services
.
2. Tap
Use wireless networks
to allow apps to use data
from sources such as Wi-Fi and mobile networks to
provide a better approximation of your current location.
DRAFT
Internal Use Only
304
Enabling My Places
1. From the main
Settings
page, tap
More
tab ➔
Location
services
.
2. Tap
My places
to enable the storage of your favorite
locations.
Security
The Security settings allow you to determine the security
level for your device.
Encrypt Device
When enabled, this feature requires a numeric PIN or
password to decrypt your device each time you power it on
or encrypt the data on your SD card each time it is
connected:
1. From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Security
.
2. Tap
Encrypt device
. For more information, read the
displayed help screen.
3. Tap
Encrypt external SD card
to enable the encryption
on SD card data that requires a password be entered
each time the microSD card is connected.
Tip:
Make sure your battery is charged more than 80 percent.
Encryption may take an hour or more.
Setting up SIM Card Lock
Prevent another user from using your SIM card to make
unauthorized calls or from accessing information stored on
your SIM card by protecting the information using a PIN code.
When enabled, your phone will ask for a PIN number each
time you use the phone. Using this option you can also
change your SIM PIN number.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Set up SIM card lock
.
3. Tap
Lock SIM card
, enter your SIM PIN code, then tap
OK
.
Note:
You must activate Lock SIM card before you can change
your SIM PIN code.
To change an existing SIM Card PIN:
1. Tap
Change SIM PIN
.
2. Enter the old SIM PIN code and tap
OK
.
3. Enter the new SIM PIN code and tap
OK
.
DRAFT
Internal Use Only
Changing Your Settings 305
4. Re-type the new SIM PIN code and tap
OK
.
Password Settings
When you create a phone password you can also configure
the phone to display the password as you type it instead of
using an asterisk (*).
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Make passwords visible
to activate this feature.
Device Administration
Activating this feature allows Google to administrate your
phone in a way similar to IT security settings on a corporate
PC. This would be beneficial in the case that your phone was
lost or stolen. The phone could be “deactivated” or
“restricted” (through administration) from a remote location.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Device administrators
to begin configuring this
setting.
3. Select an administrator device and follow the prompts.
Unknown Sources
Before you can download a web application you must enable
the Unknown sources feature (enables downloading).
Developers can use this option to install non-Play Store
applications.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Unknown sources
to active this feature.
Verify Apps
Allows you to block or warn yourself before installing apps
that can cause harm.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Verify apps
to active this feature.
Note:
Enabling this feature can prevent installation of some
applications from the Play Store.
DRAFT
Internal Use Only
306
Change Security Level
Allows you to change the current security level so taht
threats that meet the selected criteria are blocked.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Change security level
and select an available
option:
•High
: blocks all unauthenticated actions
•Normal
: blocks explicit threats.
Security Update Service
These options allow you to configure the way in which the
device checks for changes in available security policies and
the method used for the update.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Auto update security
to automatically check for
changes to the securty policy and then download any
updates automatically in order to improce security and
service.
3. Tap
Via Wi-Fi only
to only update the security policy
automatically once the device is connected to an active
Wi-Fi network.
Credential Storage
This option allows certain applications to access secure
certificates and other credentials. Certificates and
credentials can be installed to the SD card and password
protected.
1. From the main
Settings
page, tap
More
tab ➔
Security
.
2. Tap
Storage type
to designate the backup stoage
location for certificates.
3. Tap
Trusted credentials
to display only trusted CA
certificates. A check mark displayed next to the feature
indicates secure credentials.
4. Tap
Install from device storage
to install encrypted
certificates from the USB Storage location.
5. Tap
Clear credentials
to clear the device (SD card or
phone memory) of all certificate contents and reset the
credentials password.
DRAFT
Internal Use Only
Changing Your Settings 307
Application Manager
This device can be used for Android development. You can
write applications in the SDK and install them on this device,
then run the applications using the hardware, system, and
network. This feature allows you to configure the device for
development.
Warning!
Because the device can be configured with system
software not provided by or supported by Google or
any other company, end-users operate these devices
at their own risk.
This menu allows you to manage installed applications. You
can view and control currently running services, or use the
device for application development.
You can also view the amount of memory or resources used
as well as the remaining memory and resources for each of
the applications on your phone and clear the data, cache, or
defaults.
From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Application manager
➔
ALL
.
Clearing Application Cache and Data
Important!
You must have downloaded applications installed
to use this feature.
1. From the main
Settings
page, tap
More
tab ➔
Application manager
.
2. Tap an application in which to clear the cache or data.
3. Tap
Force stop
,
Turn off, Clear data
,
Clear cache
, or
Clear
defaults
.
Uninstalling Third-party Applications
Important!
You must have downloaded applications installed
to use this feature.
1. From the main
Settings
page, tap
More
tab ➔
Application manager
.
2. Tap the
DOWNLOADED
tab and select your desired
application.
3. Tap
Uninstall
(from within the top area of the
Application info page).
4. At the prompt, tap
OK
to uninstall the application.
DRAFT
Internal Use Only
308
5. Select a reason for uninstalling the application, then
tap
OK
.
Memory Usage
See how memory is being used by Downloaded or Running
applications.
1. From the main
Settings
page, tap
More
tab ➔
Applications manager
.
2. Tap
DOWNLOADED
,
SD CARD
,
RUNNING
, or
ALL
to
display memory usage for that category of
applications.
The graph at the bottom of the Downloaded tab shows
used and free device memory. The graph at the bottom
of the Running tab shows used and free RAM.
Downloaded
Displays apps you have downloaded onto your device.
1. From the main
Settings
page, tap
More
tab ➔
Applications manager
.
2. Tap the
DOWNLOADED
tab to view a list of all the
downloaded applications on your device.
3. To switch the order of the lists displayed in the
Downloaded tabs, press and select
Sort by size
or
Sort by name
.
4. Tap an application to view and update information
about the application, including memory usage, default
settings, and permissions.
Running Services
The Running services option allows you to view and control
currently running services such as Backup, Google Talk, SNS
(messaging), Swype, and more.
1. From the main
Settings
page, tap
More
tab ➔
Application manager
.
2. Tap the
RUNNING
tab to view all currently active and
running applications. This tab also shows the total RAM
being used by these currently active applications.
3. Tap a process and select
Stop
to end the process and
stop it from running. When you stop the process the
service or application will no longer run until you start
the process or application again.
4. Tap
Show cached processes
to view additional cached
applications.
DRAFT
Internal Use Only
Changing Your Settings 309
Important!
Stopping a process might have undesirable
consequences on the application.
Storage Used
This option allows you to view a list (on the current tab) of
current applications as sorted by size.
1. From the main
Settings
page, tap
More
tab ➔
Application manager
.
2. Tap the
ALL
tab to display all available applications.
3. Press and then tap
Sort by size
to change the
current list to show items based on the amount of
storage they occupy.
Reset App Preferences
This feature provides you with the ability to reset all
preferences for the following features: Disabled apps,
Disabled app notifications, Default applications for actions,
and Background data restrictions.
1. From the main
Settings
page, tap
More
tab ➔
Applications manager
.
2. Tap the
ALL
tab to display all available applications.
3. Press and then tap
Reset app preferences
➔
Reset apps
.
Important!
As an example, if you assigned your browser to
always launch YouTube links and want that
changed, you must reset the default actions.
Battery Usage
This option allows you to view a list of those components
using battery power. The amount of time the battery was
used also displays. Battery usage displays in percentages
per application.
1. From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Battery
. The battery
level displays in percentage.
2. From the upper-right tap (
Refresh
) to update the
list.
– or –
Tap an entry to view more detailed information.
Note:
Other applications may be running that affect battery
use.
DRAFT
Internal Use Only
310
SD Card & Device Storage
From this menu you can view the memory allocation for the
memory card as well as mount or unmount the SD card.
To view the memory allocation for your external SD card:
From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Storage
.
The available memory displays under the Total space
and SD card headings.
Important! DO NOT
remove a microSD card while the device is
accessing or transferring files. Doing so will result
in loss or damage of data. Make sure your battery
is fully charged before using the microSD card.
Your data may become damaged or lost if the
battery runs out while you are using the microSD
card.
Mounting the SD Card
To store photos, music, videos, and other applications. You
must mount (install) the SD card prior to use. Mounting the
SD card establishes a USB connection with your computer.
1. From the main
Settings
page, tap
More
tab ➔
Storage
.
2. Tap
Mount
SD card
.
Unmounting the SD card
Unmounting the SD card prevents corruption and damage to
the SD card while removing it from the slot.
1. From the main
Settings
page, tap
More
tab ➔
Storage
.
2. Tap
Unmount
SD card
➔
OK
.
3. After the “
SD card will be unmounted
” message
displays and the
Mount SD card
now appears in the
menu list, remove the SD card.
DRAFT
Internal Use Only
Changing Your Settings 311
Erasing Files from the SD card
To erase files from the SD card using the device:
1. Ensure the SD card is mounted.
2. From the main
Settings
page, tap
More
tab ➔
Storage
➔
Mount SD card
.
3. Tap
Format SD card
➔
Format SD card
➔
Delete all
to
format the SD card. The SD card formats and erases all
the data stored on it.
Date and Time
This menu allows you to change the current time and date
displayed.
1. From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
Date and time
.
2. Tap
Automatic date and time
to allow the network set
the date and time.
Important!
Deactivate
Automatic date and time
to manually set
the rest of the options.
3. Tap
Set date
and use the plus or minus icons to set the
Month
,
Day
, and
Year
then tap
Set
.
4. Tap
Set time
and use the plus or minus icons, set
Hour
,
and
Minute
. Tap
PM
or
AM
, then tap
Set
.
5. Tap
Automatic time zone
to allow the network set the
time zone information automatically.
6. Tap
Select time zone
, then tap a time zone.
7. Tap
Use 24-hour format
. If this is not selected the device
automatically uses a 12-hour format.
8. Tap
Select date format
and select the date format type.
DRAFT
Internal Use Only
312
About Device
This menu contains legal information, system tutorial
information, and other phone information such as the model
number, firmware version, baseband version, kernel version,
and software build number.
To access phone information:
From the Home screen, press and then tap
Settings
➔ (
More
tab) ➔
About device
. The
following information displays:
• Software update
: allows you to connect to the network and
upload any new phone software directly to your device. The
device automatically updates with the latest available software
when you access this option.
• Status
: displays the battery status, the level of the battery
(percentage), the Network connection, Signal strength, Mobile
network type, Service state, Roaming status, Mobile network
state, My phone number, IMEI number, IMEISV, IP address,
Wi-Fi MAC address, Bluetooth address, Serial number, Up
time, and Device status.
• Legal information
: This option displays information about
Open source licences, Google legal information, as well as
License settings. This information clearly provides copyright
and distribution legal information and facts as well as Google
Terms of Service, Terms of Service for Android-powered
Phones, and much more pertinent information as a reference.
Read the information and terms, then press to return to
the Settings menu.
Tip:
To find your device’s DivX® registration code and
information about registering your device to play DivX
protected video, tap
License settings
➔
DivX® VOD
.
• Device name
: allows you to both display and edit the device’s
name.
• Model number
: displays the device’s model number.
• Android version
: displays the firmware version loaded on this
device.
• Baseband version
: displays the baseband version loaded on
this device.
•Kernel version
: displays the kernel version loaded on this
device.
DRAFT
Internal Use Only
Changing Your Settings 313
• Build number
: displays the software, build number.
Note:
Firmware, baseband, kernel and build numbers are
usually used for updates to the handset or support. For
additional information please contact your T-Mobile
service representative.
•SELinux status
: displays the status of SELinux. SELinux is a
set of security policies/modules which is applied to the device
to improve the overall security.
• Secure boot status
: displays the type used for the boot status.
Software Update
The Software Update feature enables you to use your device
to connect to the network and upload any new software
directly to your device. The device automatically updates
with the latest available software when you access this
option.
The following icons show your Bluetooth connection status
at a glance:
Displays when the Software updated feature is
active.
Displays when the Software update feature is in
progress.
To update your device:
1. From the Home screen, press and then tap
Settings
➔ (
More
tab)
➔
About device
➔
Software update
.
2. Read the Software update information screen.
3. Select an available option:
Note:
You configure the device’s software update parameters.
•Cancel
: Tap this option to cancel the operation.
• Wi-Fi settings
: Enable this option to only download available
updates via an active Wi-Fi connection. If disabled, the device
will begin available downloads via its’ T-Mobile connection.
•OK
: Tap this option to connect to the remote server, detect if
there is an available update, the begin the download over your
existing data connection.
–
Software updates can include bug fixes, enhancements to
services, to the device or currently installed software.
DRAFT
Internal Use Only
314
Section 11: Health and Safety Information
This device is capable of operating in Wi-Fi
™
mode in the
2.4 and 5 GHz bands. The FCC requires that devices
operating within 5.15-5.25 GHz may only be used indoors,
not outside, in order to avoid interference with Mobile
Satellite Services (MSS). Therefore, this device is restricted
from being used outdoors when operating in frequencies
between 5.15-5.25 GHz.
This section outlines the safety precautions associated with
using your phone. The terms “mobile device” or “cell phone”
are used in this section to refer to your phone.
Read this
information before using your mobile device
.
Exposure to Radio Frequency (RF)
Signals
The U.S. Food and Drug Administration (FDA) has published
information for consumers relating to Radio Frequency (RF)
exposure from wireless phones. The FDA publication
includes the following information:
Do cell phones pose a health hazard?
Many people are concerned that cell phone radiation will
cause cancer or other serious health hazards. The weight of
scientific evidence has not linked cell phones with any health
problems.
Cell phones emit low levels of Radio Frequency (RF) energy.
Over the past 15 years, scientists have conducted hundreds
of studies looking at the biological effects of the radio
frequency energy emitted by cell phones. While some
researchers have reported biological changes associated
with RF energy, these studies have failed to be replicated.
The majority of studies published have failed to show an
association between exposure to radio frequency from a cell
phone and health problems.
The low levels of RF cell phones emit while in use are in the
microwave frequency range. They also emit RF at
substantially reduced time intervals when in the stand-by
mode. Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does not
produce heating effects causes no known adverse health
effects.
DRAFT
Internal Use Only
Health and Safety Information 315
The biological effects of radio frequency energy should not
be confused with the effects from other types of
electromagnetic energy.
Very high levels of electromagnetic energy, such as is found
in X-rays and gamma rays, can ionize biological tissues.
Ionization is a process where electrons are stripped away
from their normal locations in atoms and molecules. It can
permanently damage biological tissues including DNA, the
genetic material.
The energy levels associated with radio frequency energy,
including both radio waves and microwaves, are not great
enough to cause ionization of atoms and molecules.
Therefore, RF energy is a type of non-ionizing radiation.
Other types of non-ionizing radiation include visible light,
infrared radiation (heat), and other forms of electromagnetic
radiation with relatively low frequencies.
While RF energy does not ionize particles, large amounts can
increase body temperatures and cause tissue damage. Two
areas of the body, the eyes and the testes, are particularly
vulnerable to RF heating because there is relatively little
blood flow in them to carry away excess heat.
Research Results to Date: Is there a connection
between RF and certain health problems?
The results of most studies conducted to date say no. In
addition, attempts to replicate and confirm the few studies
that have shown a connection have failed.
The scientific community at large therefore believes that the
weight of scientific evidence does not show an association
between exposure to Radio Frequency (RF) from cell phones
and adverse health outcomes. Still the scientific community
has supported additional research to address gaps in
knowledge. Some of these studies are described below.
Interphone Study
Interphone is a large international study designed to
determine whether cell phones increase the risk of head and
neck cancer. A report published in the International Journal
of Epidemiology (June, 2010) compared cell phone usage for
more than 5,000 people with brain tumors (glioma and
meningioma) and a similar number of healthy controls.
Results of this study did NOT show that cell phones caused
brain cancer. In this study, most people had no increased risk
of brain cancer from using cell phones. For people with the
heaviest use of cell phones (an average of more than ½ hour
per day, every day, for over 10 years) the study suggested a
DRAFT
Internal Use Only
316
slight increase in brain cancer. However, the authors
determined that biases and errors prevented any conclusions
being drawn from this data. Additional information about
Interphone can be found at
http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.
Interphone is the largest cell phone study to date, but it did
not answer all questions about cell phone safety. Additional
research is being conducted around the world, and the FDA
continues to monitor developments in this field.
International Cohort Study on Mobile Phone Users
(COSMOS)
The COSMOS study aims to conduct long-term health
monitoring of a large group of people to determine if there
are any health issues linked to long-term exposure to radio
frequency energy from cell phone use. The COSMOS study
will follow approximately 300,000 adult cell phone users in
Europe for 20 to 30 years. Additional information about the
COSMOS study can be found at
http://www.ukcosmos.org/index.html
.
Risk of Brain Cancer from Exposure to Radio
Frequency Fields in Childhood and Adolescence
(MOBI-KIDS)
MOBI-KIDS is an international study investigating the
relationship between exposure to radio frequency energy
from communication technologies including cell phones and
brain cancer in young people. This is an international
multi-center study involving 14 European and non-European
countries. Additional information about MOBI-KIDS can be
found at
http://www.creal.cat/programes-recerca/en_projectes-creal/
view.php?ID=39.
Surveillance, Epidemiology, and End Results (SEER)
Program of the National Cancer Institute
The National Cancer Institute (NCI) actively follows cancer
statistics in the United States to detect any change in rates of
new cases for brain cancer. If cell phones play a role in risk
for brain cancer, rates should go up, because heavy cell
phone use has been common for quite some time in the U.S.
Between 1987 and 2005, the overall age-adjusted incidence
of brain cancer did not increase. Additional information about
SEER can be found at
http://seer.cancer.gov/
.
DRAFT
Internal Use Only
Health and Safety Information 317
Cell Phone Industry Actions
Although the existing scientific data do not justify FDA
regulatory actions, the FDA has urged the cell phone industry
to take a number of steps, including the following:
•
Support-needed research on possible biological effects of RF
for the type of signal emitted by cell phones;
•
Design cell phones in a way that minimizes any RF exposure to
the user; and
•
Cooperate in providing users of cell phones with the current
information on cell phone use and human health concerns.
The FDA also is working with voluntary standard-setting
bodies such as the Institute of Electrical and Electronics
Engineers (IEEE), the International Commission on
Non-Ionizing Radiation Protection (ICNIRP), and others to
assure that safety standards continue to adequately protect
the public.
Reducing Exposure: Hands-Free Kits and Other
Accessories
Steps to Reduce Exposure to Radio Frequency Energy
If there is a risk from being exposed to radio frequency
energy (RF) from cell phones - and at this point we do not
know that there is - it is probably very small. But, if you are
concerned about avoiding even potential risks, you can take
a few simple steps to minimize your RF exposure.
•
Reduce the amount of time spent using your cell phone;
•
Use speaker mode or a headset to place more distance between
your head and the cell phone.
Hands-Free Kits
Hands-free kits may include audio or Bluetooth® headsets
and various types of body-worn accessories such as
belt-clips and holsters. Combinations of these can be used to
reduce RF energy absorption from cell phones.
Headsets can substantially reduce exposure because the
phone is held away from the head in the user's hand or in
approved body-worn accessories. Cell phones marketed in
the U.S. are required to meet RF exposure compliance
requirements when used against the head and against the
body.
DRAFT
Internal Use Only
318
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits can be used for
convenience and comfort. They are also required by law in
many states if you want to use your phone while driving.
Cell Phone Accessories that Claim to Shield the Head
from RF Radiation
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
accessories which claim to shield the head from those
emissions reduce risks. Some products that claim to shield
the user from RF absorption use special phone cases, while
others involve nothing more than a metallic accessory
attached to the phone.
Studies have shown that these products generally do not
work as advertised. Unlike “hands-free” kits, these so-called
“shields” may interfere with proper operation of the phone.
The phone may be forced to boost its power to compensate,
leading to an increase in RF absorption.
Children and Cell Phones
The scientific evidence does not show a danger to any users
of cell phones from RF exposure, including children and
teenagers. The steps adults can take to reduce RF exposure
apply to children and teenagers as well.
•
Reduce the amount of time spent on the cell phone;
•
Use speaker mode or a headset to place more distance between
the head and the cell phone.
Some groups sponsored by other national governments have
advised that children be discouraged from using cell phones
at all. For example, The Stewart Report from the United
Kingdom made such a recommendation in December 2000.
In this report, a group of independent experts noted that no
evidence exists that using a cell phone causes brain tumors
or other ill effects. Their recommendation to limit cell phone
use by children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations (updated 10/1/2010):
•
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/.
DRAFT
Internal Use Only
Health and Safety Information 319
•
Environmental Protection Agency (EPA):
http://www.epa.gov/radtown/wireless-tech.html.
•
Occupational Safety and Health Administration (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/
.
(Note: This web address is case sensitive.)
•
National Institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/.
•
World Health Organization (WHO):
http://www.who.int/peh-emf/en/.
•
International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de.
•
Health Protection Agency:
http://www.hpa.org.uk/Topics/Radiation/.
•
US Food and Drug Administration:
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm.
Specific Absorption Rate (SAR)
Certification Information
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the exposure
limits for Radio Frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government.
These FCC RF exposure limits are derived from the
recommendations of two expert organizations: the National
Council on Radiation Protection and Measurement (NCRP)
and the Institute of Electrical and Electronics Engineers
(IEEE). In both cases, the recommendations were developed
by scientific and engineering experts drawn from industry,
government, and academia after extensive reviews of the
scientific literature related to the biological effects of RF
energy.
The RF exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of the
rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a safety limit of 1.6
watts per kilogram (1.6 W/kg).
DRAFT
Internal Use Only
320
The FCC SAR limit incorporates a substantial margin of safety
to give additional protection to the public and to account for
any variations in measurements.
SAR tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum reported value.
This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the phone.
Before a new model phone is available for sale to the public,
it must be tested and certified to the FCC that it does not
exceed the SAR limit established by the FCC. Tests for each
model phone are performed in positions and locations (e.g. at
the ear and worn on the body) as required by the FCC. For
body-worn operation, this phone has been tested and meets
FCC RF exposure guidelines when used with an accessory
that contains no metal and that positions the mobile device a
minimum of 1.0cm from the body.
Use of other accessories may not ensure compliance with
FCC RF exposure guidelines. The FCC has granted an
Equipment Authorization for this mobile device with all
reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. This mobile phone has a FCC ID
number: A3LSMG900T [Model Number: SM-G900T] and the
specific SAR levels for this mobile phone can be found at the
following FCC website:
http://www.fcc.gov/oet/ea/
.
The SAR information for this device can also be found on
Samsung’s website:
http://www.samsung.com/sar
.
SAR information on this and other model phones can be
accessed online on the FCC's website through
http://
transition.fcc.gov/oet/rfsafety/sar.html
. To find information that
pertains to a particular model phone, this site uses the phone
FCC ID number which is usually printed somewhere on the
case of the phone. Sometimes it may be necessary to
remove the battery pack to find the number. Once you have
the FCC ID number for a particular phone, follow the
instructions on the website and it should provide values for
typical or maximum SAR for a particular phone. Additional
SAR information can also be obtained at
http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-
cellular-telephones
.
DRAFT
Internal Use Only
Health and Safety Information 321
FCC Part 15 Information to User
Pursuant to part 15.21 of the FCC Rules, you are cautioned
that changes or modifications not expressly approved by
Samsung could void your authority to operate the device.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Commercial Mobile Alerting System
(CMAS)
This device is designed to receive wireless emergency alerts
from the Commercial Mobile Alerting System ("CMAS";
which may also be known as the Personal Localized Alerting
Network ("PLAN")). If your wireless provider has chosen to
participate in CMAS/PLAN, alerts are available while in the
provider's coverage area. If you travel outside your provider's
coverage area, wireless emergency alerts may not be
available. For more information, please contact your wireless
provider.
Smart Practices While Driving
On the Road - Off the Phone
The primary responsibility of every driver is the safe
operation of his or her vehicle.
DRAFT
Internal Use Only
322
Responsible drivers understand that no secondary task
should be performed while driving whether it be eating,
drinking, talking to passengers, or talking on a mobile phone
- unless the driver has assessed the driving conditions and is
confident that the secondary task will not interfere with their
primary responsibility.
Do not engage in any activity while
driving a moving vehicle which may cause you to take your
eyes off the road or become so absorbed in the activity that
your ability to concentrate on the act of driving becomes
impaired
. Samsung is committed to promoting responsible
driving and giving drivers the tools they need to understand
and address distractions.
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or
restricted in certain areas. For example, only hands-free use
may be permitted in certain areas.
Before answering calls, consider your circumstances. Let the
call go to voicemail when driving conditions require.
Remember, driving comes first, not the call!
If you consider a call necessary and appropriate, follow these
tips:
•
Use a hands-free device;
•
Secure your phone within easy reach;
•
Place calls when you are not moving;
•
Plan calls when your car will be stationary;
•
Do not engage in stressful or emotional conversations;
•
Let the person with whom you are speaking know that you are
driving and will suspend the call if necessary;
•
Do not take notes or look up phone numbers while driving;
Notice regarding legal restrictions on mounting this device in
an automobile:
Laws in some states may prohibit mounting this device on or
near the windshield of an automobile. In other states, the law
may permit mounting this device only in specific locations in
the automobile. Be sure to consult the state and local laws or
ordinances where you drive before mounting this device in
an automobile. Failure to comply with these restrictions could
result in fines, penalties, or other damages.
Never mount this device in a manner that will obstruct the
driver's clear view of the street and traffic.
DRAFT
Internal Use Only
Health and Safety Information 323
Never use wireless data services such as text messaging, Web
browsing, or e-mail while operating a vehicle.
Never watch videos, such as a movie or clip, or play video
games while operating a vehicle.
For more information, go to
http://www.ctia.org
.
Battery Use and Safety
Important! Handle and store batteries properly to avoid injury or
damage
. Most battery issues arise from improper
handling of batteries and, particularly, from the
continued use of damaged batteries.
•
Do not disassemble, crush, puncture, shred, or otherwise
attempt to change the form of your battery
. Do not put a high
degree of pressure on the battery. This can cause leakage or an
internal short-circuit, resulting in overheating.
•
Do not let the phone or battery come in contact with liquids.
Liquids can get into the phone's circuits, leading to corrosion.
Even when the phone appears to be dry and appears to operate
normally, the circuitry could slowly corrode and pose a safety
hazard. If the phone and/or battery get wet, have them checked
by your service provider or contact Samsung, even if they appear
to be working properly.
•
Do not place your battery in or near a heat source
. Excessive
heating can damage the phone or the battery and could cause the
phone or the battery to explode. Do not dry a wet or damp battery
with an appliance or heat source such as a microwave oven, hair
dryer, iron, or radiator. Avoid leaving your phone in your car in
high temperatures.
•
Do not dispose of the phone or the battery in a fire
. The phone
or the battery may explode when overheated.
•
Do not handle a damaged or leaking battery
. Do not let leaking
battery fluid come in contact with your eyes, skin or clothing. For
safe disposal options, contact your nearest Samsung-authorized
service center.
DRAFT
Internal Use Only
324
•
Avoid dropping the cell phone
. Dropping the phone or the
battery, especially on a hard surface, can potentially cause
damage to the phone and battery. If you suspect damage to the
phone or battery, take it to a service center for inspection.
•
Never use any charger or battery that is damaged in any way
.
•
Do not allow the battery to touch metal objects
. Accidental
short-circuiting can occur when a metallic object (coin, key,
jewelry, clip, or pen) causes a direct connection between the +
and - terminals of the battery (metal strips on the battery), for
example when you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the battery or the
object causing the short-circuiting.
Important!
Use only Samsung-approved batteries, and
recharge your battery only with
Samsung-approved chargers which are
specifically designed for your phone.
WARNING!
Use of a non-Samsung-approved battery or charger may
present a risk of fire, explosion, leakage, or other hazard
.
Samsung's warranty does not cover damage to the phone
caused by nonSamsung-approved batteries and/or chargers.
•
Do not use incompatible cell phone batteries and chargers
.
Some websites and second-hand dealers not associated with
reputable manufacturers and carriers, might be selling
incompatible or even counterfeit batteries and chargers.
Consumers should purchase manufacturer or
carrier-recommended products and accessories. If unsure about
whether a replacement battery or charger is compatible, contact
the manufacturer of the battery or charger.
•
Misuse or use of incompatible phones, batteries, and
charging devices could result in damage to the equipment
and a possible risk of fire, explosion, or leakage, leading to
serious injuries, damages to your phone, or other serious
hazard
.
Samsung Mobile Products and
Recycling
Samsung cares for the environment and encourages its
customers to recycle Samsung mobile devices and genuine
Samsung accessories.
Proper disposal of your mobile device and its battery is not
only important for safety, it benefits the environment.
Batteries must be recycled or disposed of properly.
DRAFT
Internal Use Only
Health and Safety Information 325
Recycling programs for your mobile device, batteries, and
accessories may not be available in your area.
We've made it easy for you to recycle your old Samsung
mobile device by working with respected take-back
companies in every state in the country.
Drop It Off
You can drop off your Samsung-branded mobile device
and batteries for recycling at one of our numerous
Samsung Recycling Direct (SM) locations. A list of these
locations may be found at:
http://pages.samsung.com/us/recyclingdirect/
usactivities_environment_samsungrecyclingdirect_locations.
jsp
.
Samsung-branded devices and batteries will be accepted
at these locations for no fee.
Consumers may also recycle their used mobile device or
batteries at many retail or carrier-provided locations
where mobile devices and batteries are sold. Additional
information regarding specific locations may be found at:
http://www.epa.gov/epawaste/partnerships/plugin/cellphone/
index.htm
or at
http://www.call2recycle.org/
.
Mail It In
The Samsung Mobile Take-Back Program will provide
Samsung customers with a free recycling mailing label.
Just go to
http://fun.samsungmobileusa.com/recycling/index.jsp
and
follow the instructions to print out a free pre-paid postage
label and then send your old mobile device or battery to
the address listed, via U.S. Mail, for recycling.
Dispose of unwanted electronics through an approved
recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect
Or call, (877) 278-0799.
Follow local regulations regarding disposal of mobile
devices and batteries
Dispose of your mobile device and batteries in accordance
with local regulations. In some areas, the disposal of these
items in household or business trash may be prohibited. Help
us protect the environment - recycle!
Warning!
Never dispose of batteries in a fire because they may
explode.
DRAFT
Internal Use Only
326
UL Certified Travel Charger
The Travel Charger for this phone has met applicable UL
safety requirements. Please adhere to the following safety
instructions per UL guidelines:
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY
LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW THESE
INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR
OF THE PROPER CONFIGURATION FOR THE
POWER OUTLET.
THIS POWER UNIT IS INTENDED TO BE
CORRECTLY ORIENTED IN A VERTICAL OR
HORIZONTAL OR FLOOR MOUNT POSITION.
Display / Touch-Screen
Please note the following information when using your
mobile device:
WARNING REGARDING DISPLAY
The display on your mobile device is made of glass or
acrylic and could break if your mobile device is
dropped or if it receives significant impact. Do not use
if screen is broken or cracked as this could cause
injury to you.
WARRANTY DISCLAIMER: PROPER USE OF A
TOUCH-SCREEN MOBILE DEVICE
If your mobile device has a touch-screen display,
please note that a touch-screen responds best to a
light touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object when
pressing on the touch-screen may damage the
tempered glass surface and void the warranty. For
more information, please refer to the “Standard
Limited Warranty”.
DRAFT
Internal Use Only
Health and Safety Information 327
GPS & AGPS
Certain Samsung mobile devices can use a Global Positioning
System (GPS) signal for location-based applications. A GPS
uses satellites controlled by the U.S. Government that are
subject to changes implemented in accordance with the
Department of Defense policy and the 2008 Federal Radio
navigation Plan (FRP). Changes may affect the performance
of location-based technology on your mobile device.
Certain Samsung mobile devices can also use an Assisted
Global Positioning System (AGPS), which obtains information
from the cellular network to improve GPS performance. AGPS
uses your wireless service provider's network and therefore
airtime, data charges, and/or additional charges may apply in
accordance with your service plan. Contact your wireless
service provider for details.
Your Location
Location-based information includes information that can be
used to determine the approximate location of a mobile
device. Mobile devices which are connected to a wireless
network transmit location-based information. Additionally, if
you use applications that require location-based information
(e.g. driving directions), such applications transmit
location-based information. The location-based information
may be shared with third-parties, including your wireless
service provider, applications providers, Samsung, and other
third-parties providing services.
Use of AGPS in Emergency Calls
When you make an emergency call, the cellular network may
activate AGPS technology in your mobile device to tell the
emergency responders your approximate location.
AGPS has limitations and
might not work in your area
.
Therefore:
•
Always tell the emergency responder your location to the best of
your ability; and
•
Remain on the mobile device for as long as the emergency
responder instructs you.
Navigation
Maps, directions, and other navigation-data, including data
relating to your current location, may contain inaccurate or
incomplete data, and circumstances can and do change over
time. In some areas, complete information may not be
available. T
herefore, you should always visually confirm that
the navigational instructions are consistent with what you see
before following them. All users should pay attention to road
conditions, closures, traffic, and all other factors that may
impact safe driving or walking. Always obey posted road signs
.
DRAFT
Internal Use Only
328
Emergency Calls
This mobile device, like any wireless mobile device, operates
using radio signals, wireless and landline networks, as well
as user-programmed functions, which cannot guarantee
connection in all conditions, areas, or circumstances.
Therefore, you should never rely solely on any wireless
mobile device for essential communications (medical
emergencies, for example). Before traveling in remote or
underdeveloped areas, plan an alternate method of
contacting emergency services personnel. Remember, to
make or receive any calls, the mobile device must be
switched on and in a service area with adequate signal
strength.
Emergency calls may not be possible on all wireless mobile
device networks or when certain network services and/or
mobile device features are in use. Check with local service
providers.
To make an emergency call:
1. If the mobile device is not on, switch it on.
2. From the Home screen, tap .
3. Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
4. Tap .
If certain features are in use (call blocking, for example), you
may first need to deactivate those features before you can
make an emergency call. Consult your User Manual and your
local cellular service provider. When making an emergency
call, remember to give all the necessary information as
accurately as possible. Remember that your mobile device
may be the only means of communication at the scene of an
accident; do not cut off the call until given permission to do
so.
Care and Maintenance
Your mobile device is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
DRAFT
Internal Use Only
Health and Safety Information 329
Keep your Samsung Mobile Device away from:
Liquids of any kind
Keep the mobile device dry. Precipitation, humidity, and
liquids contain minerals that will corrode electronic
circuits. If the mobile device does get wet, do not
accelerate drying with the use of an oven, microwave, or
dryer, because this may damage the mobile device and
could cause a fire or explosion.
Do not use the mobile device with a wet hand. Doing so
may cause an electric shock to you or damage to the
mobile device.
Extreme heat or cold
Avoid temperatures below 0°C / 32°F or above 45°C /
113°F.
Microwaves
Do not try to dry your mobile device in a microwave oven.
Doing so may cause a fire or explosion.
Dust and dirt
Do not expose your mobile device to dust, dirt, or sand.
Cleaning solutions
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the mobile device. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water
solution. If the mobile device has a retractable camera
lens, do not use soap and water to clean the lens. Use a
blower or brush or lens cleaning paper dampened in a
lens cleaning solution.
Shock or vibration
Do not drop, knock, or shake the mobile device. Rough
handling can break internal circuit boards.
Paint
Do not paint the mobile device. Paint can clog the
device’s moving parts or ventilation openings and prevent
proper operation.
Responsible Listening
Caution! Avoid potential hearing loss
.
Damage to hearing occurs when a person is exposed to loud
sounds over time. The risk of hearing loss increases as
sound is played louder and for longer durations. Prolonged
exposure to loud sounds (including music) is the most
common cause of preventable hearing loss. Some scientific
research suggests that using portable audio devices, such as
DRAFT
Internal Use Only
330
portable music players and cell phones, at high volume
settings for long durations may lead to permanent
noise-induced hearing loss.
This includes the use of headphones (including headsets,
earbuds, and Bluetooth® or other wireless devices).
Exposure to very loud sound has also been associated in
some studies with tinnitus (a ringing in the ear),
hypersensitivity to sound, and distorted hearing. Individual
susceptibility to noise-induced hearing loss and potential
hearing problem varies. Additionally, the amount of sound
produced by a portable audio device varies depending on the
nature of the sound, the device settings, and the headphones
that are used. As a result, there is no single volume setting
that is appropriate for everyone or for every combination of
sound, settings, and equipment.
You should follow some common sense recommendations
when using any portable audio device:
•
Always turn the volume down before plugging the earphones into
an audio source.
•
Set the volume in a quiet environment and select the lowest
volume at which you can hear adequately.
•
Be aware that you can adapt to higher volume settings over time,
not realizing that the higher volume may be harmful to your
hearing.
•
When using headphones, turn the volume down if you cannot
hear the people speaking near you or if the person sitting next to
you can hear what you are listening to.
•
Do not turn the volume up to block out noisy surroundings. If you
choose to listen to your portable device in a noisy environment,
use noise-cancelling headphones to block out background
environmental noise. By blocking background environment noise,
noise cancelling headphones should allow you to hear the music
at lower volumes than when using earbuds.
•
Limit the amount of time you listen. As the volume increases, less
time is required before you hearing could be affected.
•
Avoid using headphones after exposure to extremely loud noises,
such as rock concerts, that might cause temporary hearing loss.
Temporary hearing loss might cause unsafe volumes to sound
normal.
DRAFT
Internal Use Only
Health and Safety Information 331
•
Do not listen at any volume that causes you discomfort. If you
experience ringing in your ears, hear muffled speech, or
experience any temporary hearing difficulty after listening to your
portable audio device, discontinue use and consult your doctor.
You can obtain additional information on this subject from the
following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: (800) 222-2336
Email: info@audiology.org
Internet:
http://www.audiology.org/Pages/
default.aspx
National Institute on Deafness and Other
Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD 20892-2320
Email: nidcdinfo@nih.gov
Internet:
http://www.nidcd.nih.gov/
National Institute for Occupational Safety
and Health (NIOSH)
395 E Street, S.W., Suite 9200
Patriots Plaza Building
Washington, DC 20201
Voice: 1-800-35-NIOSH
(1-800-356-4674)
1-800-CDC-INFO (1-800-232-4636)
Outside the U.S. 513-533-8328
DRAFT
Internal Use Only
332
Operating Environment
Remember to follow any special regulations in force in any
area, and always switch your mobile device off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the mobile device or any accessory
to another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
Using Your Mobile Device Near Other Electronic
Devices
Most modern electronic equipment is shielded from Radio
Frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals from
your wireless mobile device. Consult the manufacturer to
discuss alternatives.
Implantable Medical Devices
A minimum separation of six (6) inches should be maintained
between a handheld wireless mobile device and an
implantable medical device, such as a pacemaker or
implantable cardioverter defibrillator, to avoid potential
interference with the device.
Persons who have such devices:
•
Should ALWAYS keep the mobile device more than six (6) inches
from their implantable medical device when the mobile device is
turned ON;
•
Should not carry the mobile device in a breast pocket;
•
Should use the ear opposite the implantable medical device to
minimize the potential for interference;
•
Should turn the mobile device OFF immediately if there is any
reason to suspect that interference is taking place;
•
Should read and follow the directions from the manufacturer of
your implantable medical device. If you have any questions about
using your wireless mobile device with an implantable medical
device, consult your health care provider.
For more information see:
http://www.fcc.gov/oet/rfsafety/rf-
faqs.html#
.
Email: cdcinfo@cdc.gov
Internet:
http://www.cdc.gov/niosh/topics/noise/
default.html
1-888-232-6348 TTY
DRAFT
Internal Use Only
Health and Safety Information 333
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information. Switch your
mobile device off in health care facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your vehicle
before using your mobile device in a motor vehicle. You
should also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your mobile device off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your mobile device off when in any area with a
potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an explosion
or fire resulting in bodily injury or even death. Users are
advised to switch the mobile device off while at a refueling
point (service station).
Users are reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants, or where blasting
operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. They
include below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains chemicals
or particles, such as grain, dust, or metal powders, and any
other area where you would normally be advised to turn off
your vehicle engine. Vehicles using liquefied petroleum gas
(such as propane or butane) must comply with the National
Fire Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection Association.
When your Device is Wet
Do not turn on your device if it is wet. If your device is
already on, turn it off and remove the battery immediately (if
the device will not turn off or you cannot remove the battery,
leave it as-is). Then, dry the device with a towel and take it
to a service center.
DRAFT
Internal Use Only
334
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices
The U.S. Federal Communications Commission (FCC) has
established requirements for digital wireless mobile devices
to be compatible with hearing aids and other assistive
hearing devices.
When individuals employing some assistive hearing devices
(hearing aids and cochlear implants) use wireless mobile
devices, they may detect a buzzing, humming, or whining
noise. Some hearing devices are more immune than others
to this interference noise, and mobile devices also vary in the
amount of interference they generate.
The wireless telephone industry has developed a rating
system for wireless mobile devices to assist hearing device
users find mobile devices that may be compatible with their
hearing devices. Not all mobile devices have been rated.
Mobile devices that are rated have the rating on their box or
a label located on the box.
The ratings are not guarantees. Results will vary depending
on the user's hearing device and hearing loss. If your hearing
device happens to be vulnerable to interference, you may not
be able to use a rated mobile device successfully. Trying out
the mobile device with your hearing device is the best way to
evaluate it for your personal needs.
M-Ratings
: Wireless mobile devices rated M3 or M4 meet
FCC requirements and are likely to generate less interference
to hearing devices than mobile devices that are not labeled.
M4 is the better/higher of the two ratings. M-ratings refer to
enabling acoustic coupling with hearing aids that do not
operate in telecoil mode.
T-Ratings
: Mobile devices rated T3 or T4 meet FCC
requirements and are likely to generate less interference to
hearing devices than mobile devices that are not labeled. T4
is the better/higher of the two ratings. T-ratings refer to
enabling inductive coupling with hearing aids operating in
telecoil mode.
Hearing devices may also be rated. Your hearing aid
manufacturer or hearing health professional may help you
find this rating. Higher ratings mean that the hearing device
is relatively immune to interference noise.
Under the current industry standard, American National
Standards Institute (ANSI) C63.19, the hearing aid and
wireless mobile device rating values are added together to
indicate how usable they are together. For example, if a
DRAFT
Internal Use Only
Health and Safety Information 335
hearing aid meets the M2 level rating and the wireless
mobile device meets the M3 level rating, the sum of the two
values equals M5.
Under the standard, this should provide the hearing aid user
with normal use while using the hearing aid with the
particular wireless mobile device. A sum of 6 or more would
indicate excellent performance.
However, these are not guarantees that all users will be
satisfied. T ratings work similarly.
The HAC rating and measurement procedure are described in
the American National Standards Institute (ANSI) C63.19
standard.
HAC for Newer Technologies
This phone has been tested and rated for use with hearing
aids for some of the wireless technologies that it uses.
However, there may be some newer wireless technologies
used in this phone that have not been tested yet for use with
hearing aids.
It is important to try the different features of this phone
thoroughly and in different locations, using your hearing aid
or cochlear implant, to determine if you hear any interfering
noise. Consult your service provider or the manufacturer of
this phone for information on hearing aid compatibility. If you
have questions about return or exchange policies, consult
your service provider or phone retailer.
Restricting Children's Access to Your
Mobile Device
Your mobile device is not a toy. Do not allow children to play
with it because they could hurt themselves and others,
damage the mobile device, or make calls that increase your
mobile device bill.
Keep the mobile device and all its parts and accessories out
of the reach of small children.
M3 + M2 = 5
T3 + T2 = 5
DRAFT
Internal Use Only
336
FCC Notice and Cautions
FCC Notice
The mobile device may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC can
require you to stop using the mobile device if such
interference cannot be eliminated.
Cautions
Any changes or modifications to your mobile device not
expressly approved by Samsung could void your warranty for
this equipment and void your authority to operate this
equipment. Only use approved batteries, antennas, and
chargers. The use of any unauthorized accessories may be
dangerous and void the mobile device warranty if said
accessories cause damage or a defect to the mobile device.
Although your mobile device is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid dropping,
hitting, bending, or sitting on it.
Other Important Safety Information
•
Only qualified personnel should service the mobile device or
install the mobile device in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty applicable to
the device.
•
Ensure that any mobile devices or related equipment installed in
your vehicle are securely mounted.
•
Check regularly that all wireless mobile device equipment in your
vehicle is mounted and operating properly.
•
When using a headset in dry environments, static electricity can
build up in the headset and cause a small quick static electrical
shock. To minimize the risk of electrostatic discharge from the
headset avoid using the headset in extremely dry environments or
touch a grounded unpainted metal object to discharge static
electricity before inserting the headset.
•
Do not store or carry flammable liquids, gases, or explosive
materials in the same compartment as the mobile device, its
parts, or accessories.
•
For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including installed
or portable wireless equipment near or in the area over the air
bag or in the air bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious injury could
result.
DRAFT
Internal Use Only
Health and Safety Information 337
•
Switch your mobile device off before boarding an aircraft. The use
of wireless mobile devices in aircraft is illegal and may be
dangerous to the aircraft's operation. Check with appropriate
authorities before using any function of a mobile device while on
an aircraft.
•
Failure to observe these instructions may lead to the suspension
or denial of cell phone services to the offender, or legal action, or
both.
•
While using your device, leave some lights on in the room and do
not hold the screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing
lights while watching videos or playing games for extended
periods. If you feel any discomfort, stop using the device
immediately.
•
Reduce risk of repetitive motion injuries. When you repetitively
perform actions, such as pressing keys, drawing characters on a
touch screen with your fingers, or playing games, you may
experience occasional discomfort in your hands, neck, shoulders,
or other parts of your body. When using your device for extended
periods, hold the device with a relaxed grip, press the keys lightly,
and take frequent breaks. If you continue to have discomfort
during or after such use, stop use and see a physician.
•
If your device has a camera flash or light, do not use the flash or
light close to the eyes of people or pets. [122011]
DRAFT
Internal Use Only
338
Section 12: Warranty Information
Standard Limited Warranty
What is covered and for how long?
SAMSUNG TELECOMMUNICATIONS AMERICA, LLC
(“SAMSUNG”) warrants that SAMSUNG’s handsets and
accessories (“Products”) are free from defects in material
and workmanship under normal use and service for the
period commencing upon the date of purchase by the first
consumer purchaser and continuing for the following
specified period of time after that date:
*If applicable.
What is not covered?
This Limited Warranty is conditioned upon proper use of the
Product.
This Limited Warranty does not cover: (a) defects or damage
resulting from accident, misuse, abnormal use, abnormal
conditions, improper storage, exposure to liquid, moisture,
dampness, sand or dirt, neglect, or unusual physical,
electrical or electromechanical stress; (b) scratches, dents
and cosmetic damage, unless caused by SAMSUNG;
(c) defects or damage resulting from excessive force or use
of a metallic object when pressing on a touch screen;
(d) equipment that has the serial number or the
enhancement data code removed, defaced, damaged,
altered or made illegible; (e) ordinary wear and tear;
(f) defects or damage resulting from the use of Product in
conjunction or connection with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (g) defects or damage resulting from improper
testing, operation, maintenance, installation, service, or
adjustment not furnished or approved by SAMSUNG;
(h) defects or damage resulting from external causes such as
collision with an object, fire, flooding, dirt, windstorm,
lightning, earthquake, exposure to weather conditions, theft,
blown fuse, or improper use of any electrical source;
(i) defects or damage resulting from cellular signal reception
Device 1 Year
Battery(ies)* 1 Year
Case/Pouch/Holster* 90 Days
Other Device
Accessories*
1 Year
DRAFT
Internal Use Only
Warranty Information 339
or transmission, or viruses or other software problems
introduced into the Product; or (j) Product used or purchased
outside the United States. This Limited Warranty covers
batteries only if battery capacity falls below 80% of rated
capacity or the battery leaks, and this Limited Warranty does
not cover any battery if (i) the battery has been charged by a
battery charger not specified or approved by SAMSUNG for
charging the battery; (ii) any of the seals on the battery are
broken or show evidence of tampering; or (iii) the battery has
been used in equipment other than the SAMSUNG phone for
which it is specified.
What are SAMSUNG’s obligations?
During the applicable warranty period, provided the Product
is returned in accordance with the terms of this Limited
Warranty, SAMSUNG will repair or replace the Product, at
SAMSUNG’s sole option, without charge. SAMSUNG may, at
SAMSUNG’s sole option, use rebuilt, reconditioned, or new
parts or components when repairing any Product, or may
replace the Product with a rebuilt, reconditioned or new
Product.
Repaired/replaced cases, pouches and holsters will be
warranted for a period of ninety (90) days. All other repaired/
replaced Products will be warranted for a period equal to the
remainder of the original Limited Warranty on the original
Product or for ninety (90) days, whichever is longer. All
replaced Products, parts, components, boards and
equipment shall become the property of SAMSUNG. Except to
any extent expressly allowed by applicable law, transfer or
assignment of this Limited Warranty is prohibited.
What must you do to obtain warranty service?
To obtain service under this Limited Warranty, you must
return the Product to an authorized phone service facility in
an adequate container for shipping, accompanied by the
sales receipt or comparable proof of sale showing the
original date of purchase, the serial number of the Product
and the seller’s name and address.
To obtain assistance on where to deliver the Product, please
call SAMSUNG Customer Care at 1-888-987-4357. If
SAMSUNG determines that any Product is not covered by this
Limited Warranty, you must pay all parts, shipping, and labor
charges for the repair or return of such Product.
You should keep a separate backup copy of any contents of
the Product before delivering the Product to SAMSUNG for
warranty service, as some or all of the contents may be
deleted or reformatted during the course of warranty service.
DRAFT
Internal Use Only
340
What are the limits on SAMSUNG’s liability?
THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF
SAMSUNG’S RESPONSIBILITIES, AND THE EXCLUSIVE
REMEDY REGARDING THE PRODUCTS.
ALL IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT
SHALL SAMSUNG BE LIABLE FOR DAMAGES IN EXCESS OF
THE PURCHASE PRICE OF THE PRODUCT OR FOR, WITHOUT
LIMITATION, COMMERCIAL LOSS OF ANY SORT; LOSS OF
USE, TIME, DATA, REPUTATION, OPPORTUNITY, GOODWILL,
PROFITS OR SAVINGS; INCONVENIENCE; INCIDENTAL,
SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES; OR
DAMAGES ARISING FROM THE USE OR INABILITY TO USE THE
PRODUCT. SOME STATES AND JURISDICTIONS DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, OR THE DISCLAIMER OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS
AND DISCLAIMERS MAY NOT APPLY TO YOU.
SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,
EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO
THE QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE
OR SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR
EQUIPMENT USED IN CONJUNCTION WITH THE PRODUCT, OR
THE ABILITY TO INTEGRATE ANY SUCH SOFTWARE OR
EQUIPMENT WITH THE PRODUCT, WHETHER SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT IS INCLUDED WITH
THE PRODUCT DISTRIBUTED BY SAMSUNG OR OTHERWISE.
RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY
SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS
SOLELY WITH THE USER AND THE DIRECT VENDOR, OWNER
OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT.
Nothing in the Product instructions or information shall be
construed to create an express warranty of any kind with
respect to the Products. No agent, employee, dealer,
representative or reseller is authorized to modify or extend
this Limited Warranty or to make binding representations or
claims, whether in advertising, presentations or otherwise,
on behalf of SAMSUNG regarding the Products or this Limited
Warranty.
This Limited Warranty gives you specific legal rights, and you
may also have other rights that vary from state to state.
DRAFT
Internal Use Only
Warranty Information 341
What is the procedure for resolving disputes?
ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM
THIS LIMITED WARRANTY OR THE SALE, CONDITION OR
PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED
EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION,
AND NOT BY A COURT OR JURY.
Any such dispute shall not be combined or consolidated with
a dispute involving any other person’s or entity’s Product or
claim, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the Limited Warranty and all
disputes that are subject to this arbitration provision. The
arbitrator shall decide all issues of interpretation and
application of this arbitration provision and the Limited
Warranty.
For any arbitration in which your total damage claims,
exclusive of attorney fees and expert witness fees, are
$5,000.00 or less (“Small Claim”), the arbitrator may, if you
prevail, award your reasonable attorney fees, expert witness
fees and costs as part of any award, but may not grant
SAMSUNG its attorney fees, expert witness fees or costs
unless it is determined that the claim was brought in bad
faith. In a Small Claim case, you shall be required to pay no
more than half of the total administrative, facility and
arbitrator fees, or $50.00 of such fees, whichever is less, and
SAMSUNG shall pay the remainder of such fees.
Administrative, facility and arbitrator fees for arbitrations in
which your total damage claims, exclusive of attorney fees
and expert witness fees, exceed $5,000.00 (“Large Claim”)
shall be determined according to AAA rules. In a Large Claim
case, the arbitrator may grant to the prevailing party, or
apportion among the parties, reasonable attorney fees,
expert witness fees and costs. Judgment may be entered on
the arbitrator’s award in any court of competent jurisdiction.
This arbitration provision also applies to claims against
SAMSUNG’s employees, representatives and affiliates if any
such claim arises from the Product’s sale, condition or
performance.
DRAFT
Internal Use Only
342
You may opt out of this dispute resolution procedure by
providing notice to SAMSUNG no later than 30 calendar days
from the date of the first consumer purchaser’s purchase of the
Product. To opt out, you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: “Arbitration
Opt Out.” You must include in the opt out e-mail (a) your name
and address; (b) the date on which the Product was purchased;
(c) the Product model name or model number; and (d) the IMEI
or MEID or Serial Number, as applicable, if you have it (the IMEI
or MEID or Serial Number can be found (i) on the Product box;
(ii) on the Product information screen, which can be found
under “Settings;” (iii) on a label on the back of the Product
beneath the battery, if the battery is removable; and (iv) on the
outside of the Product if the battery is not removable).
Alternatively, you may opt out by calling 1-888-987-4357 no
later than 30 calendar days from the date of the first consumer
purchaser’s purchase of the Product and providing the same
information. These are the only two forms of notice that will be
effective to opt out of this dispute resolution procedure. Opting
out of this dispute resolution procedure will not affect the
coverage of the Limited Warranty in any way, and you will
continue to enjoy the benefits of the Limited Warranty.
Severability
If any portion of this Limited Warranty is held to be illegal or
unenforceable, such partial illegality or unenforceability shall
not affect the enforceability of the remainder of the Limited
Warranty.
Precautions for Transfer and Disposal
If data stored on this device is deleted or reformatted using
the standard methods, the data only appears to be removed
on a superficial level, and it may be possible for someone to
retrieve and reuse the data by means of special software.
To avoid unintended information leaks and other problems of
this sort, it is recommended that the device be returned to
Samsung’s Customer Care Center for an Extended File
System (EFS) Clear which will eliminate all user memory and
return all settings to default settings. Please contact the
Samsung Customer Care Center
for details.
Important!
Please provide warranty information (proof of
purchase) to Samsung’s Customer Care Center in
order to provide this service at no charge. If the
warranty has expired on the device, charges may
apply.
DRAFT
Internal Use Only
Warranty Information 343
Samsung Telecommunications America, LLC
1301 E. Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
No reproduction in whole or in part allowed without prior
written approval. Specifications and availability subject to
change without notice. [111611]
End User License Agreement for
Software
IMPORTANT. READ CAREFULLY: This End User License
Agreement ("EULA") is a legal agreement between you
(either an individual or a single entity) and Samsung
Electronics Co., Ltd. ("Samsung") for software, owned by
Samsung and its affiliated companies and its third party
suppliers and licensors, that accompanies this EULA, which
includes computer software and may include associated
media, printed materials, "online" or electronic
documentation in connection with your use of this device
("Software").
This device requires the use of preloaded software in its
normal operation. BY USING THE DEVICE OR ITS PRELOADED
SOFTWARE, YOU ACCEPT THE TERMS OF THIS EULA. IF YOU
DO NOT ACCEPT THESE TERMS, DO NOT USE THE DEVICE OR
THE SOFTWARE.
1.
GRANT OF LICENSE
. Samsung grants you the following
rights provided that you comply with all terms and conditions
of this EULA: You may install, use, access, display and run
one copy of the Software on the local hard disk(s) or other
permanent storage media of one computer and use the
Software on a single computer or a mobile device at a time,
and you may not make the Software available over a network
where it could be used by multiple computers at the same
time. You may make one copy of the Software in machine
readable form for backup purposes only; provided that the
backup copy must include all copyright or other proprietary
notices contained on the original.
Certain items of the Software may be subject to open source
licenses. The open source license provisions may override
some of the terms of this EULA. We make the applicable
open source licenses available to you on the Legal Notices
section of the Settings menu of your device.
DRAFT
Internal Use Only
344
2.
RESERVATION OF RIGHTS AND OWNERSHIP
. Samsung
reserves all rights not expressly granted to you in this EULA.
The Software is protected by copyright and other intellectual
property laws and treaties. Samsung or its suppliers own the
title, copyright and other intellectual property rights in the
Software. The Software is licensed, not sold.
3.
LIMITATIONS ON END USER RIGHTS
. You may not reverse
engineer, decompile, disassemble, or otherwise attempt to
discover the source code or algorithms of, the Software
(except and only to the extent that such activity is expressly
permitted by applicable law not withstanding this limitation),
or modify, or disable any features of, the Software, or create
derivative works based on the Software. You may not rent,
lease, lend, sublicense or provide commercial hosting
services with the Software.
4.
CONSENT TO USE OF DATA
. You agree that Samsung and its
affiliates may collect and use technical information gathered
as part of the product support services related to the
Software provided to you, if any, such as IMEI (your device’s
unique identification number), device number, model name,
customer code, access recording, your device’s current SW
version, MCC (Mobile Country Code), MNC (Mobile Network
Code). Samsung and its affiliates may use this information
solely to improve their products or to provide customized
services or technologies to you and will not disclose this
information in a form that personally identifies you. At all
times your information will be treated in accordance with
Samsung’s Privacy Policy, which can be viewed at:
http://account.samsung.com/membership/pp
.
5.
SOFTWARE UPDATES
. Samsung may provide to you or
make available to you updates, upgrades, supplements and
add-on components (if any) of the Software, including bug
fixes, service upgrades (parts or whole), products or devices,
and updates and enhancements to any software previously
installed (including entirely new versions), (collectively
“Update”) after the date you obtain your initial copy of the
Software to improve the Software and ultimately enhance
your user experience with your device. This EULA applies to
all and any component of the Update that Samsung may
provide to you or make available to you after the date you
obtain your initial copy of the Software, unless we provide
other terms along with such Update. To use Software
provided through Update, you must first be licensed for the
Software identified by Samsung as eligible for the Update.
After the Update, you may no longer use the Software that
formed the basis for your Update eligibility. The updated
Software version may add new functions and, in some
limited cases, may delete existing functions.
DRAFT
Internal Use Only
Warranty Information 345
While the Update will be generally available, in some limited
circumstances, the Software updates will only be offered by
your network carrier, and such Software updates will be
governed by your contractual relationship with your network
carrier.
With the “Automatic Update” function enabled (as in the
default setting in the System Update menu in the Setting),
your device downloads some Updates automatically from
time to time. Your device will, however, ask for your consent
before installing any Update If you choose to disable the
“Automatic Update” function, then you can check the
availability of new Updates by clicking on the “Check
Update” menu in the Setting. We recommend that you check
availability of any new Updates periodically for optimal use of
your device. If you want to avoid any use of network data for
the Update downloads, then you should choose the “Wi-Fi
Only” option in the Setting. (Regardless of the option you
choose, the “Automatic Update” function downloads Updates
only through Wi-Fi connection.)
6. Some features of the Software may require your device to
have access to the internet and may be subject to
restrictions imposed by your network or internet provider.
Unless your device is connected to the internet through Wi-Fi
connection, the Software will access through your mobile
network, which may result in additional charges depending
on your payment plan. In addition, your enjoyment of some
features of the Software may be affected by the suitability
and performance of your device hardware or data access.
7.
SOFTWARE TRANSFER
. You may not transfer this EULA or
the rights to the Software granted herein to any third party
unless it is in connection with the sale of the mobile device
which the Software accompanied. In such event, the transfer
must include all of the Software (including all component
parts, the media and printed materials, any upgrades, this
EULA) and you may not retain any copies of the Software.
The transfer may not be an indirect transfer, such as a
consignment. Prior to the transfer, the end user receiving the
Software must agree to all the EULA terms.
8.
EXPORT RESTRICTIONS
. You acknowledge that the
Software is subject to export restrictions of various countries.
You agree to comply with all applicable international and
national laws that apply to the Software, including all the
applicable export restriction laws and regulations.
9.
TERMINATION
. This EULA is effective until terminated. Your
rights under this License will terminate automatically without
notice from Samsung if you fail to comply with any of the
DRAFT
Internal Use Only
346
terms and conditions of this EULA. Upon termination of this
EULA, you must cease all use of the Software and destroy all
copies, full or partial, of the Software.
10.
DISCLAIMER OF WARRANTY
. UNLESS SEPARATELY STATED
IN A WRITTEN EXPRESS LIMITED WARRANTY
ACCOMPANYING YOUR DEVICE, ALL SOFTWARE PROVIDED
BY SAMSUNG WITH THIS MOBILE DEVICE (WHETHER
INCLUDED WITH THE DEVICE, DOWNLOADED, OR
OTHERWISE OBTAINED) IS PROVIDED "AS IS" AND ON AN
"AS AVAILABLE" BASIS, WITHOUT WARRANTIES OF ANY KIND
FROM SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE
FULLEST EXTENT POSSIBLE PURSUANT TO APPLICABLE
LAW, SAMSUNG DISCLAIMS ALL WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY
QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A
PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,
ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT, NON
INFRINGEMENT OF THIRD PARTY RIGHTS OR OTHER
VIOLATION OF RIGHTS. SOME JURISDICTIONS DO NOT
ALLOW EXCLUSIONS OR LIMITATIONS OF IMPLIED
WARRANTIES, SO THE ABOVE EXCLUSIONS OR LIMITATIONS
MAY NOT APPLY TO YOU. NO ADVICE OR INFORMATION,
WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM
SAMSUNG OR ITS AFFILIATES SHALL BE DEEMED TO ALTER
THIS DISCLAIMER BY SAMSUNG OF WARRANTY REGARDING
THE SOFTWARE, OR TO CREATE ANY WARRANTY OF ANY
SORT FROM SAMSUNG.
11.
THIRD-PARTY APPLICATIONS
. Certain third party
applications may be included with, or downloaded to this
mobile device. Samsung makes no representations
whatsoever about any of these applications. Since Samsung
has no control over such applications, you acknowledge and
agree that Samsung is not responsible for the availability of
such applications and is not responsible or liable for any
content, advertising, products, services, or other materials
on or available from such applications. You expressly
acknowledge and agree that use of third party applications is
at your sole risk and that the entire risk of unsatisfactory
quality, performance, accuracy and effort is with you. It is up
to you to take precautions to ensure that whatever you select
to use is free of such items as viruses, worms, Trojan horses,
and other items of a destructive nature. References on this
mobile device to any names, marks, products, or services of
any third-parties are provided solely as a convenience to you,
and do not constitute or imply an endorsement, sponsorship,
or recommendation of, or affiliation with the third party or its
products and services. You agree that Samsung shall not be
DRAFT
Internal Use Only
Warranty Information 347
responsible or liable, directly or indirectly, for any damage or
loss, including but not limited to any damage to the mobile
device or loss of data, caused or alleged to be caused by, or
in connection with, use of or reliance on any such third party
content, products, or services available on or through any
such application. You acknowledge and agree that the use of
any third-party application is governed by such third party
application provider's Terms of Use, License Agreement,
Privacy Policy, or other such agreement and that any
information or personal data you provide, whether knowingly
or unknowingly, to such third-party application provider, will
be subject to such third party application provider's privacy
policy, if such a policy exists. SAMSUNG DISCLAIMS ANY
RESPONSIBILITY FOR ANY DISCLOSURE OF INFORMATION OR
ANY OTHER PRACTICES OF ANY THIRD PARTY APPLICATION
PROVIDER. SAMSUNG EXPRESSLY DISCLAIMS ANY
WARRANTY REGARDING WHETHER YOUR PERSONAL
INFORMATION IS CAPTURED BY ANY THIRD PARTY
APPLICATION PROVIDER OR THE USE TO WHICH SUCH
PERSONAL INFORMATION MAY BE PUT BY SUCH THIRD
PARTY APPLICATION PROVIDER.
12.
SAMSUNG APPLICATIONS
. Certain Samsung applications
and services may be included with, or downloaded to, this
mobile device. Many of them require Samsung Services
membership registration (“Samsung Account”), and your
rights and obligations will be set forth in separate Samsung
Account terms and conditions and privacy policies. There are
non-Samsung Account applications and services that require
your consent to their separate terms and conditions and
privacy policies. You expressly acknowledge and agree that
your use of such applications and services will be subject to
the applicable terms and conditions and privacy policies.
13.
LIMITATION OF LIABILITY
. SAMSUNG WILL NOT BE LIABLE
FOR ANY DAMAGES OF ANY KIND ARISING OUT OF OR
RELATING TO THE USE OR THE INABILITY TO USE THE
SOFTWARE OR ANY THIRD PARTY APPLICATION, ITS
CONTENT OR FUNCTIONALITY, INCLUDING BUT NOT LIMITED
TO DAMAGES CAUSED BY OR RELATED TO ERRORS,
OMISSIONS, INTERRUPTIONS, DEFECTS, DELAY IN
OPERATION OR TRANSMISSION, COMPUTER VIRUS, FAILURE
TO CONNECT, NETWORK CHARGES, IN-APP PURCHASES,
AND ALL OTHER DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES EVEN IF
SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSIONS OR
LIMITATIONS MAY NOT APPLY TO YOU. NOTWITHSTANDING
DRAFT
Internal Use Only
348
THE FOREGOING, SAMSUNG ELECTRONIC CO.'S TOTAL
LIABILITY TO YOU FOR ALL LOSSES, DAMAGES, CAUSES OF
ACTION, INCLUDING BUT NOT LIMITED TO THOSE BASED ON
CONTRACT, TORT, OR OTHERWISE, ARISING OUT OF YOUR
USE OF THE SOFTWARE OR THIRD PARTY APPLICATIONS ON
THIS MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS
EULA, SHALL NOT EXCEED THE AMOUNT PURCHASER PAID
SPECIFICALLY FOR THIS MOBILE DEVICE OR ANY SUCH
THIRD PARTY APPLICATION THAT WAS INCLUDED WITH THIS
MOBILE DEVICE. THE FOREGOING LIMITATIONS,
EXCLUSIONS, AND DISCLAIMERS (INCLUDING SECTIONS 10,
11, 12 AND 13) SHALL APPLY TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY
FAILS ITS ESSENTIAL PURPOSE.
14.
U.S. GOVERNMENT END USERS RESTRICTED RIGHTS
. The
Software is licensed only with "restricted rights" and as
"commercial items" consisting of "commercial software"
and "commercial software documentation" with only those
rights as are granted to all other end users pursuant to the
terms and conditions herein. All Products are provided only
with "restricted rights" with only those rights as are granted
to all other end users pursuant to the terms and conditions
herein. All Software and Products are provided subject to
Federal Acquisition Regulation (FAR) 52.227.19.
15.
APPLICABLE LAW
. This EULA is governed by the laws of
the jurisdiction where you are a resident or, if a resident of
the United States, by the laws of the state of Texas, without
regard to its conflict of law provisions. This EULA shall not be
governed by the UN Convention on Contracts for the
International Sale of Goods, the application of which is
expressly excluded.
16.
DISPUTE RESOLUTION
.
(a) Non-United States residents. If a dispute, controversy or
difference arising in any way from this EULA or your use of
the Software is not amicably settled, it shall be subject to the
non-exclusive jurisdiction of the courts of the jurisdiction
where you are a resident. Notwithstanding the foregoing,
Samsung may apply for injunctive remedies (or an equivalent
type of urgent legal relief) in any jurisdiction.
(b) United States residents. ALL DISPUTES WITH SAMSUNG
ARISING IN ANY WAY FROM THIS EULA OR YOUR USE OF THE
SOFTWARE SHALL BE RESOLVED EXCLUSIVELY THROUGH
FINAL AND BINDING ARBITRATION, AND NOT BY A COURT OR
JURY. Any such dispute shall not be combined or
consolidated with any other person’s or entity’s claim or
dispute, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
DRAFT
Internal Use Only
Warranty Information 349
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the EULA and all disputes
that are subject to this arbitration provision. The arbitrator
shall decide all issues of interpretation and application of this
arbitration provision and the EULA. For any arbitration in
which your total damage claims, exclusive of attorney fees
and expert witness fees, are $5,000.00 or less ("Small
Claim"), the arbitrator may, if you prevail, award your
reasonable attorney fees, expert witness fees and costs as
part of any award, but may not grant Samsung its attorney
fees, expert witness fees or costs unless it is determined that
the claim was brought in bad faith. In a Small Claim case,
you shall be required to pay no more than half of the total
administrative, facility and arbitrator fees, or $50.00 of such
fees, whichever is less, and Samsung shall pay the
remainder of such fees. Administrative, facility and arbitrator
fees for arbitrations in which your total damage claims,
exclusive of attorney fees and expert witness fees, exceed
$5,000.00 ("Large Claim") shall be determined according to
AAA rules. In a Large Claim case, the arbitrator may grant to
the prevailing party, or apportion among the parties,
reasonable attorney fees, expert witness fees and costs.
Judgment may be entered on the arbitrator's award in any
court of competent jurisdiction. This arbitration provision also
applies to claims against Samsung’s employees,
representatives and affiliates if any such claim arises from
the licensing or use of the Software. You may opt out of this
dispute resolution procedure by providing notice to Samsung
no later than 30 calendar days from the date of the first
consumer purchaser’s purchase of this device. To opt out,
you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: "Arbitration
Opt Out." You must include in the opt out e-mail (a) your
name and address; (b) the date on which the device was
purchased; (c) the device model name or model number; and
(d) the IMEI or MEID or Serial Number, as applicable, if you
have it (the IMEI or MEID or Serial Number can be found (i) on
the device box; (ii) on the device information screen, which
can be found under "Settings;" (iii) on a label on the back of
the device beneath the battery, if the battery is removable;
and (iv) on the outside of the device if the battery is not
DRAFT
Internal Use Only
350
removable). Alternatively, you may opt out by calling
1-888-987-4357 no later than 30 calendar days from the
date of the first consumer purchaser's purchase of the
device and providing the same information. These are the
only two forms of notice that will be effective to opt out of
this dispute resolution procedure. Opting out of this dispute
resolution procedure will not affect your use of the device or
its preloaded Software, and you will continue to enjoy the
benefits of this license.
17.
ENTIRE AGREEMENT; SEVERABILITY
. This EULA is the
entire agreement between you and Samsung relating to the
Software and supersedes all prior or contemporaneous oral
or written communications, proposals and representations
with respect to the Software or any other subject matter
covered by this EULA. If any provision of this EULA is held to
be void, invalid, unenforceable or illegal, the other provisions
shall continue in full force and effect. [050113]
