safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone.Safety warningsKeep your phone away from small children and petsKeep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed.Protect your hearingListening to a headset at high volumes can damage your hearing. Use only the minimum volume setting necessary to hear your conversation or music.Install mobile phones and equipment with cautionEnsure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inate rapidly.Follow all safety warnings and regulationsComply with any regulations that restrict the use of a mobile phone in a certain area.Use only Samsung-approved accessoriesUsing incompatible accessories may damage your phone or cause injury.Turn off the phone near medical equipmentYour phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel.Turn off the phone or disable the wireless functions when in an aircraftYour phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel.Protect batteries and chargers from damageAvoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/113° F). Extreme temperatures can reduce the charging capacity and life of your batteries.Store the battery pack in a dry place.Prevent batteries from contacting metal objects, as this can create a connection between the + and – terminals of your batteries and lead to temporary or permanent •••battery damage.Never use a damaged charger or battery.Handle your phone carefully and sensiblyDo not allow your phone to get wet—liquids can cause serious damage. Do not handle your phone with wet hands. Water damage to your phone can void your manufacturer's warranty.Avoid using or storing your phone in dusty, dirty areas to prevent damage to moving parts.Your phone is a complex electronic device—protect it from impacts and rough handling to avoid serious damage.Do not paint your phone, as paint can clog moving parts and prevent proper operation.Your phone and memory cards may be damaged by exposure to magnetic elds. Do not use carrying cases or accessories with magnetic closures or allow your phone to come in contact with magnetic elds for extended periods of time.Avoid interference with other electronic devicesYour phone emits radio frequency (RF) signals that may interfere with unshielded or improperly shielded electronic equipment, such as pacemakers, hearing aids, medical devices, and other electronic devices in homes or vehicles. Consult the manufacturers of your electronic devices to solve any interference problems you experience.••••••Important usage informationUse your phone in the normal positionAvoid contact with your phone's internal antenna.Allow only qualied personnel to service your phoneAllowing unqualied personnel to service your phone may result in damage to your phone and will void your warranty.Ensure maximum battery and charger lifeAvoid charging batteries for more than a week, as overcharging may shorten battery life.Over time, unused batteries will discharge and must be recharged before use.Disconnect chargers from power sources when not in use.Use batteries only for their intended purpose.Handle SIM cards and memory cards with careDo not remove a card while the phone is transferring or accessing information, as this could result in loss of data and/or damage to the card or phone.Protect cards from strong shocks, static electricity, and electrical noise from other devices.Frequent writing and erasing will shorten the life span of memory cards.•••••••Do not touch gold-coloured contacts or terminals with your ngers or metal objects. If dirty, wipe the card with a soft cloth.Ensure access to emergency servicesEmergency calls from your phone may not be possible in some areas or circumstances. Before travelling in remote or undeveloped areas, plan an alternate method of contacting emergency services personnel.Exposure to Radio Frequency (RF) SignalsCertication Information (SAR)Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the exposure limits for radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. government. These FCC exposure limits are derived from the recommendations of two expert organizations, the National Counsel on Radiation Protection and Measurement (NCRP) and the Institute of Electrical and Electronics Engineers (IEEE). In both cases, the recommendations were developed by scientic and engineering experts drawn from industry, government, and academia after extensive reviews of the scientic literature related to the biological effects of RF energy.The exposure limit set by the FCC for wireless mobile phones employs a unit of measurement known as the Specic Absorption Rate (SAR). The SAR is a measure of the rate of absorption of RF energy by the human body expressed in units of watts per kilogram (W/kg).The FCC requires wireless phones to comply with a •Turn off the phone in potentially explosive environmentsDo not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or re in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry ammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories.Reduce the risk of repetitive motion injuriesWhen sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the buttons lightly, use special features that reduce the number of buttons you have to press(such as templates and predictive text), and take frequent breaks.Safety precautionsDrive safely at all timesAvoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible.Handle and dispose of batteries and chargers with careUse only Samsung-approved batteries and chargers specically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone. Never dispose of batteries or phone in a re. Follow all local regulations when disposing used batteries or phone. Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating.Avoid interference with pacemakersMaintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance.••••safety limit of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure limit incorporates a substantial margin of safety to give additional protection to the public and to account for any variations in measurements.SAR tests are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certied power level in all tested frequency bands. Although the SAR is determined at the highest certied power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.Before a new model phone is available for sale to the public, it must be tested and certied to the FCC that it does not exceed the exposure limit established by the FCC. Tests for each model phone are performed in positions and locations (e.g. at the ear and worn on the body) as required by the FCC. The highest SAR values for this model phone as reported to the FCC are: GSM850 Head:0.113 W/Kg, Body-worn: 0.838 W/Kg; GSM1900 Head: 0.152 W/Kg, Body-worn: 0.917 W/Kg.For body worn operation, this model phone has been tested and meets the FCC RF exposure guidelines whenused with a Samsung accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Non-compliance with the above restrictions may result in violation of FCC RF exposure guidelines.SAR information on this and other model phones can be viewed on-line at www.fcc.gov/oet/fccid. This site uses the phone FCC ID number, A3LSWDS3600. Sometimes it may be necessary to remove the battery pack to nd the number. Once you have the FCC ID number for a particular phone, follow the instructions on the website and it should provide values for typical or maximum SAR for a particular phone. Additional product specic SAR information can also be obtained at www.fcc.gov/cgb/sar.FCC Notice and CautionsFCC NoticeThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radiocommunications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:-Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.CautionsThe phone may cause TV or radio interference if used in close proximity to receiving equipment. The FCC can require you to stop using the phone if such interference cannot be eliminated.Vehicles using liqueed petroleum gas (such as propane or butane) must comply with the National Fire Protection Standard (NFPA-58). For a copy of this standard, contact the National Fire Protection Association, One Battery march Park, Quincy, MA 02269, Attn: Publication Sales Division.Changes or modications made in the radio phone, not expressly approved by Samsung, will void the user°Øs authority to operate the equipment.Only use approved batteries, antennas and chargers. The use of any unauthorized accessories may be dangerous and void the phone warranty if said accessories cause damage or a defect to the phone.Although your phone is quite sturdy, it is a complex piece of equipment and can be broken. Avoid dropping, hitting, bending or sitting on it.Samsung S3600Printed in KoreaCode No.:GH68-XXXXXEnglish (EU). 08/2008. Rev. 1.0Mobile Phoneuser manualSome of the contents in this manual may differ from your phone depending on the software of the phone or your service provider.Bluetooth ID : B0XXXXXwww.samsungmobile.comDeclaration of Conformity (R&TTE)We, Samsung Electronicsdeclare under our sole responsibility that the productGSM Mobile Phone : S3600to which this declaration relates, is in conformity with the following standards and/or other normative documents.SAFETY EN 60950- 1 : 2001+A11:2004EMC EN 301 489- 01 V1.5.1 (11-2004) EN 301 489- 07 V1.2.1 (08-2002)SAR EN 50360 : 2001 EN 62209- 1 : 2006RADIO EN 301 511 V9.0.2 (03- 2003)We hereby declare that [all essential radio test suites have been carried out and that] the above named product is in conformity to all the essential requirements of Directive 1999/5/EC.The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the following Notied Body(ies):BABT, Balfour House, Churcheld Road, Walton-on-Thames, Surrey, KT12 2TD, UK* Identication mark: 0168The technical documentation kept at : Samsung Electronics QA Lab.which will be made available upon request.(Representative in the EU)Samsung Electronics Euro QA Lab.Blackbushe Business Park, Saxony Way,Yateley, Hampshire, GU46 6GG, UK* 2008.06.27 Yong-Sang Park / S. Manager(place and date of issue) (name and signature of authorised person)* It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre, see the warranty card or contact the retailer where you purchased your phone.Position only
Phone layoutInstructional iconsNote: notes, usage tips, or additional informationFollowed by: the order of options or menus you must select to perform a step; for example: Press <Menu>  Messages (represents Menu, followed by Messages)[ ] Square brackets: phone keys; for example: [ ] (represents the Power/Menu exit key)< >Angled brackets: softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey)Turn your phone on or off1. To turn your phone on, press and hold [ ].2. To turn your phone off, press and hold [ ].Make a call1. In Idle mode, enter an area code and a phone number.2. Press [ ] to dial the number.3. To end the call, press [ ].Answer a call1. When a call comes in, press [ ].2. To end the call, press [ ].Adjust the volume To adjust the volume of the ringtone 1. In Idle mode, press <Menu>  Settings  Phone proles.2. Scroll to the phone prole you are using.3. Press <Options>  Edit.4. Select Call alert volume.5. Scroll left or right to adjust the volume level.6. Press <Save> twice. To adjust the volume of voice during a call While a call is in progress, press [ / ] to adjust the earpiece volume.Change your ringtone1. In Idle mode, press <Menu>  Settings  Phone proles.2. Scroll to the phone prole you are using.3. Press <Option>  Edit.4. Select Voice call ringtone.5. Select a ringtone category  a ringtone.6. Press <Save>.Call a recently dialled number1. In Idle mode, press [ ].2. Scroll left or right to select a call type.3. Scroll up or down to select a number or name.4. Press [OK] to view details of the call or [ ] to dial the number.Enter text To change the text input mode Press and hold [ ] to switch to an input mode. Depending on your region, you may be able to access an input mode for your specic language.Press [ ] to change case or switch to Number mode.Press and hold [ ] to switch to Symbol mode. T9 mode 1. Press the appropriate alphanumeric keys to enter an entire word.2. When the word displays correctly, press [ ] to insert a space. If the correct word does not display, select an alternate word from the list that appears.••• ABC mode Press the appropriate alphanumeric key until the character you want appears on the display. Number mode Press the appropriate alphanumeric key to enter a number. Symbol mode Press the appropriate alphanumeric key to select a symbol.To move the cursor, press the navigation key.To delete characters one by one, press [C]. To delete all of the characters, press and hold [C].To insert a space between characters, press [ ].To enter punctuation marks, press [1].••••Install the SIM card and battery1. Remove the battery cover and insert the SIM card.2. Insert the battery and replace the battery cover.Charge the battery1. Plug the supplied travel adapter.2. When charging is nished, unplug the travel adapter. Do not remove the battery from the phone before unplugging the travel adapter rst. Otherwise, the phone may be damaged.Battery coverBattery cover SIM cardSIM cardBatteryBatteryTo AC power outletTo AC power outletAdd a new contact1. In Idle mode, enter a phone number and press <Options>.2. Select Save  a memory location (phone or SIM)  New.3. Select a number type (if necessary).4. Enter contact information.5. Press [OK] or press <Options>  Save to add the contact to memory.Send and view messages To send a text message 1. In Idle mode, press <Menu>  Messages  Create new message  Message.2. Enter a destination number and scroll down.3. Enter the message text.4. Press <Options>  Send to send the message. To view text messages 1. In Idle mode, press <Menu>  Messages  My messages  Inbox.2. Select a text message.Activate the mobile trackerThis feature helps track your phone when it is stolen or when someone tries to use your phone using other SIM card, the phone will automatically send the preset tracking message to family or friends. This feature may be unavailable due to certain features supported by your service provider.1. In Idle mode, press <Menu>  Settings  Security  Mobile tracker2. Enter your password and press <OK>.3. Scroll left or right to On.4. Scroll down and press [OK] to open the recipient list.5. Press [OK] to open your contact list.6. Scroll to a contact and press [OK].7. Select a number (if necessary).8. When you are nished selecting contacts, press <Select>  Select to return to the recipient list.9. Press <Options>  Save to save the recipients.10. Scroll down and enter the sender's name.11. Press [OK]  <Accept>.Activate and send an SOS messageIn an emergency, you can send SOS messages to your family or friends for help. To activate the SOS message 1. In Idle mode, press <Menu>  Messages  SOS messages  Sending options.2. Scroll left or right to On.3. Scroll down and press [OK] to open the recipient list.4. Press [OK] to open your contact list.5. Scroll to a contact and press [OK].6. Select a number (if necessary).7. When you are nished selecting contacts, press <Select>  Select to return to the recipient list.8. Press <Options>  Save to save the recipients.9. Scroll down and set the number of times to repeat the SOS message.10. Press <Save>  <Yes>. To send an SOS message 1. With the phone closed, press [ / ] four times to send an SOS message to preset numbers.The phone switches to SOS mode and sends the preset SOS message. 2. To exit SOS mode, press [ ].Use the camera Capture photos 1. In Idle mode, press the navigation key down.2. Aim the lens at the subject and make any adjustments.3. Press [OK] to take a photo. 4. Press <Back> to take another photo (step 2). View photos In Idle mode, press <Menu>  My les  Images  My photos  a photo le.Listen to music1. In Idle mode, press <Menu>  Music.2. Select a music category  a music le. 3. Control playback using the following keys:Keys FunctionOK Pause or resume playback/Adjust the volume up or downNavigationLeft: Restart playback; Skip backward (press within 3 seconds); Scan backward in a le (press and hold)Right: Skip forward; Scan for ward in a le (press and hold)Up: Open the playlistDown: Stop playback••••14-way navigation keyIn ldle mode, access user-dened menus; In Menu mode, scroll through menu options2Web access/Conrm keyIn ldle mode, access the web browser;In Menu mode, select the highlighted menu option or conrm an input 3My Menu keyIn Idle mode, access My Menu mode4Dial keyMake or answer a call; In Idle mode, retrieve recently dialled, missed, or received numbers5Volume keyAdjust the phone's volume;Send an SOS message Activate and send an SOS message6Voice mail service keyIn Idle mode, access voice mails (press and hold)7Alphanumeric keys8SoftkeysPerform actions indicated at the bottom of the display9Delete keyDelete characters10Organiser keyIn Idle mide, access organiser applications11Power/Menu exit keyTurn the phone on and off (press and hold); End a call; In Menu mode, cancel input and return to Idle mode12Silent prole keyIn Idle mode, activate or deactivate Silent prole (press and hold)Your phone displays the following status indicators on the top of the screen:Icon DescriptionSignal strengthGPRS network connectedEDGE network connectedCall in progressCall diverting activeSOS message feature activatedAlarm activatedBrowsing the webConnecting to secured web pageIn Home Zone service areaIn Ofce Zone service areaIcon DescriptionBluetooth activatedNew text message (SMS)New multimedia message (MMS)New email messageNew voice mail messageMusic playback in progressFM radio onMemory card insertedNormal prole activatedSilent prole activatedBattery power level124578111239106
