safety and usage information Comply with the following precautions to avoid dangerous or illegal situations
and ensure peak performance of your mobile phone.
Safety warnings
Keep your phone away from small children and
pets
Keep your phone and all accessories out of the reach
of small children or animals. Small parts may cause
choking or serious injury if swallowed.
Protect your hearing
Listening to a headset at high volumes can
damage your hearing. Use only the minimum
volume setting necessary to hear your
conversation or music.
Install mobile phones and equipment with
caution
Ensure that any mobile phones or related equipment
installed in your vehicle are securely mounted. Avoid
placing your phone and accessories near or in an air
bag deployment area. Improperly installed wireless
equipment can cause serious injury when air bags inate
rapidly.
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a
mobile phone in a certain area.
Use only Samsung-approved accessories
Using incompatible accessories may damage your phone
or cause injury.
Turn off the phone near medical equipment
Your phone can interfere with medical equipment in
hospitals or health care facilities. Follow all regulations,
posted warnings, and directions from medical personnel.
Turn off the phone or disable the wireless
functions when in an aircraft
Your phone can cause interference with aircraft
equipment. Follow all airline regulations and turn off your
phone or switch to a mode that disables the wireless
functions when directed by airline personnel.
Protect batteries and chargers from damage
Avoid exposing batteries to very cold or very hot
temperatures (below 0° C/32° F or above 45° C/113°
F). Extreme temperatures can reduce the charging
capacity and life of your batteries.
Store the battery pack in a dry place.
Prevent batteries from contacting metal objects, as this
can create a connection between the + and – terminals
of your batteries and lead to temporary or permanent
•
•
•
battery damage.
Never use a damaged charger or battery.
Handle your phone carefully and sensibly
Do not allow your phone to get wet—liquids can cause
serious damage. Do not handle your phone with wet
hands. Water damage to your phone can void your
manufacturer's warranty.
Avoid using or storing your phone in dusty, dirty areas
to prevent damage to moving parts.
Your phone is a complex electronic device—protect
it from impacts and rough handling to avoid serious
damage.
Do not paint your phone, as paint can clog moving
parts and prevent proper operation.
Your phone and memory cards may be damaged
by exposure to magnetic elds. Do not use carrying
cases or accessories with magnetic closures or allow
your phone to come in contact with magnetic elds for
extended periods of time.
Avoid interference with other electronic devices
Your phone emits radio frequency (RF) signals that
may interfere with unshielded or improperly shielded
electronic equipment, such as pacemakers, hearing
aids, medical devices, and other electronic devices in
homes or vehicles. Consult the manufacturers of your
electronic devices to solve any interference problems
you experience.
•
•
•
•
•
•
Important usage information
Use your phone in the normal position
Avoid contact with your phone's internal antenna.
Allow only qualied personnel to service your
phone
Allowing unqualied personnel to service your phone
may result in damage to your phone and will void your
warranty.
Ensure maximum battery and charger life
Avoid charging batteries for more than a week, as
overcharging may shorten battery life.
Over time, unused batteries will discharge and must be
recharged before use.
Disconnect chargers from power sources when not
in use.
Use batteries only for their intended purpose.
Handle SIM cards and memory cards with care
Do not remove a card while the phone is transferring
or accessing information, as this could result in loss of
data and/or damage to the card or phone.
Protect cards from strong shocks, static electricity, and
electrical noise from other devices.
Frequent writing and erasing will shorten the life span
of memory cards.
•
•
•
•
•
•
•
Do not touch gold-coloured contacts or terminals with
your ngers or metal objects. If dirty, wipe the card with
a soft cloth.
Ensure access to emergency services
Emergency calls from your phone may not be possible
in some areas or circumstances. Before travelling in
remote or undeveloped areas, plan an alternate method
of contacting emergency services personnel.
Exposure to Radio Frequency (RF) Signals
Certication Information (SAR)Your wireless phone
is a radio transmitter and receiver. It is designed
and manufactured not to exceed the exposure limits
for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
government. These FCC exposure limits are derived
from the recommendations of two expert organizations,
the National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientic and
engineering experts drawn from industry, government,
and academia after extensive reviews of the scientic
literature related to the biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specic Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
•
Turn off the phone in potentially explosive
environments
Do not use your phone at refuelling points (service
stations) or near fuels or chemicals. Turn off your phone
whenever directed by warning signs or instructions.
Your phone could cause explosions or re in and around
fuel or chemical storage and transfer areas or blasting
areas. Do not store or carry ammable liquids, gases,
or explosive materials in the same compartment as the
phone, its parts, or accessories.
Reduce the risk of repetitive motion injuries
When sending text messages or playing games on
your phone, hold the phone with a relaxed grip, press
the buttons lightly, use special features that reduce the
number of buttons you have to press
(such as templates and predictive text), and take
frequent breaks.
Safety precautions
Drive safely at all times
Avoid using your phone while driving and obey all
regulations that restrict the use of mobile phones while
driving. Use hands-free accessories to increase your
safety when possible.
Handle and dispose of batteries and chargers
with care
Use only Samsung-approved batteries and chargers
specically designed for your phone.
Incompatible batteries and chargers can cause serious
injuries or damage to your phone.
Never dispose of batteries or phone in a re. Follow
all local regulations when disposing used batteries or
phone.
Never place batteries or phones on or in heating
devices, such as microwave ovens, stoves, or
radiators. Batteries may explode when overheated.
Never crush or puncture the battery. Avoid exposing
the battery to high external pressure, which can lead to
an internal short circuit and overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between mobile
phones and pacemakers to avoid potential interference,
as recommended by manufacturers and the independent
research group, Wireless Technology Research.
If you have any reason to suspect that your phone is
interfering with a pacemaker or other medical device, turn
off the phone immediately and contact the manufacturer
of the pacemaker or medical device for guidance.
•
•
•
•
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.SAR
tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at
its highest certied power level in all tested frequency
bands. Although the SAR is determined at the highest
certied power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate
at multiple power levels so as to use only the power
required to reach the network. In general, the closer you
are to a wireless base station antenna, the lower the
power output.
Before a new model phone is available for sale to the
public, it must be tested and certied to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed
in positions and locations (e.g. at the ear and worn on
the body) as required by the FCC. The highest SAR
values for this model phone as reported to the FCC
are: GSM850 Head:0.113 W/Kg, Body-worn: 0.838
W/Kg; GSM1900 Head: 0.152 W/Kg, Body-worn: 0.917
W/Kg.For body worn operation, this model phone has
been tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated
for this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body. Non-compliance with
the above restrictions may result in violation of FCC
RF exposure guidelines.SAR information on this and
other model phones can be viewed on-line at www.fcc.
gov/oet/fccid. This site uses the phone FCC ID number,
A3LSWDS3600. Sometimes it may be necessary to
remove the battery pack to nd the number. Once you
have the FCC ID number for a particular phone, follow
the instructions on the website and it should provide
values for typical or maximum SAR for a particular
phone. Additional product specic SAR information can
also be obtained at www.fcc.gov/cgb/sar.
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.. This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radiocommunications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:-Reorient or
relocate the receiving antenna. -Increase the separation
between the equipment and receiver. -Connect the
equipment into an outlet on a circuit different from that to
which the receiver is connected. -Consult the dealer or
an experienced radio/TV technician for help.
Cautions
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.Vehicles using liqueed petroleum
gas (such as propane or butane) must comply with the
National Fire Protection Standard (NFPA-58). For a copy
of this standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA 02269,
Attn: Publication Sales Division.
Changes or modications made in the radio phone, not
expressly approved by Samsung, will void the user°Øs
authority to operate the equipment.Only use approved
batteries, antennas and chargers. The use of any
unauthorized accessories may be dangerous and void
the phone warranty if said accessories cause damage
or a defect to the phone.Although your phone is quite
sturdy, it is a complex piece of equipment and can be
broken. Avoid dropping, hitting, bending or sitting on it.
Samsung S3600
Printed in Korea
Code No.:GH68-XXXXX
English (EU). 08/2008. Rev. 1.0
Mobile Phone
user manual
Some of the contents in this manual may differ
from your phone depending on the software of
the phone or your service provider.
Bluetooth ID : B0XXXXX
www.samsungmobile.com
Declaration of Conformity (R&TTE)
We,
Samsung Electronics
declare under our sole responsibility that the product
GSM Mobile Phone : S3600
to which this declaration relates, is in conformity with the following standards and/or
other normative documents.
SAFETY EN 60950- 1 : 2001+A11:2004
EMC EN 301 489- 01 V1.5.1 (11-2004)
EN 301 489- 07 V1.2.1 (08-2002)
SAR EN 50360 : 2001
EN 62209- 1 : 2006
RADIO EN 301 511 V9.0.2 (03- 2003)
We hereby declare that [all essential radio test suites have been carried out and
that] the above named product is in conformity to all the essential requirements of
Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in
Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the
following Notied Body(ies):
BABT, Balfour House, Churcheld Road,
Walton-on-Thames, Surrey, KT12 2TD, UK*
Identication mark: 0168
The technical documentation kept at :
Samsung Electronics QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK*
2008.06.27 Yong-Sang Park / S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone
number of Samsung Service Centre, see the warranty card or contact the retailer
where you purchased your phone.
Position only
Phone layout
Instructional icons
Note: notes, usage tips, or additional information
Followed by: the order of options or menus you
must select to perform a step; for example: Press
<Menu> Messages (represents Menu, followed
by Messages)
[ ] Square brackets: phone keys; for example: [ ]
(represents the Power/Menu exit key)
< >
Angled brackets: softkeys that control different
functions at each screen; for example: <OK>
(represents the OK softkey)
Turn your phone on or off
1. To turn your phone on, press and hold [ ].
2. To turn your phone off, press and hold [ ].
Make a call
1. In Idle mode, enter an area code and a phone
number.
2. Press [ ] to dial the number.
3. To end the call, press [ ].
Answer a call
1. When a call comes in, press [ ].
2. To end the call, press [ ].
Adjust the volume
To adjust the volume of the ringtone
1. In Idle mode, press <Menu> Settings Phone
proles.
2. Scroll to the phone prole you are using.
3. Press <Options> Edit.
4. Select Call alert volume.
5. Scroll left or right to adjust the volume level.
6. Press <Save> twice.
To adjust the volume of voice during a call
While a call is in progress, press [ / ] to adjust the
earpiece volume.
Change your ringtone
1. In Idle mode, press <Menu> Settings Phone
proles.
2. Scroll to the phone prole you are using.
3. Press <Option> Edit.
4. Select Voice call ringtone.
5. Select a ringtone category a ringtone.
6. Press <Save>.
Call a recently dialled number
1. In Idle mode, press [ ].
2. Scroll left or right to select a call type.
3. Scroll up or down to select a number or name.
4. Press [OK] to view details of the call or [ ] to dial
the number.
Enter text
To change the text input mode
Press and hold [ ] to switch to an input mode.
Depending on your region, you may be able to
access an input mode for your specic language.
Press [ ] to change case or switch to Number mode.
Press and hold [ ] to switch to Symbol mode.
T9 mode
1. Press the appropriate alphanumeric keys to enter an
entire word.
2. When the word displays correctly, press [ ] to insert
a space. If the correct word does not display, select
an alternate word from the list that appears.
•
•
•
ABC mode
Press the appropriate alphanumeric key until the
character you want appears on the display.
Number mode
Press the appropriate alphanumeric key to enter a
number.
Symbol mode
Press the appropriate alphanumeric key to select a
symbol.
To move the cursor, press the navigation key.
To delete characters one by one, press [C]. To delete
all of the characters, press and hold [C].
To insert a space between characters, press [ ].
To enter punctuation marks, press [1].
•
•
•
•
Install the SIM card and battery
1. Remove the battery cover and insert the SIM card.
2. Insert the battery and replace the battery cover.
Charge the battery
1. Plug the supplied travel adapter.
2. When charging is nished, unplug the travel adapter.
Do not remove the battery from the phone before
unplugging the travel adapter rst. Otherwise, the
phone may be damaged.
Battery coverBattery cover SIM cardSIM card
BatteryBattery
To AC power outletTo AC power outlet
Add a new contact
1. In Idle mode, enter a phone number and press
<Options>.
2. Select Save a memory location (phone or SIM)
New.
3. Select a number type (if necessary).
4. Enter contact information.
5. Press [OK] or press <Options> Save to add the
contact to memory.
Send and view messages
To send a text message
1. In Idle mode, press <Menu> Messages Create
new message Message.
2. Enter a destination number and scroll down.
3. Enter the message text.
4. Press <Options> Send to send the message.
To view text messages
1. In Idle mode, press <Menu> Messages My
messages Inbox.
2. Select a text message.
Activate the mobile tracker
This feature helps track your phone when it is stolen
or when someone tries to use your phone using other
SIM card, the phone will automatically send the preset
tracking message to family or friends. This feature may
be unavailable due to certain features supported by your
service provider.
1. In Idle mode, press <Menu> Settings Security
Mobile tracker
2. Enter your password and press <OK>.
3. Scroll left or right to On.
4. Scroll down and press [OK] to open the recipient list.
5. Press [OK] to open your contact list.
6. Scroll to a contact and press [OK].
7. Select a number (if necessary).
8. When you are nished selecting contacts, press
<Select> Select to return to the recipient list.
9. Press <Options> Save to save the recipients.
10. Scroll down and enter the sender's name.
11. Press [OK] <Accept>.
Activate and send an SOS message
In an emergency, you can send SOS messages to your
family or friends for help.
To activate the SOS message
1. In Idle mode, press <Menu> Messages SOS
messages Sending options.
2. Scroll left or right to On.
3. Scroll down and press [OK] to open the recipient list.
4. Press [OK] to open your contact list.
5. Scroll to a contact and press [OK].
6. Select a number (if necessary).
7. When you are nished selecting contacts, press
<Select> Select to return to the recipient list.
8. Press <Options> Save to save the recipients.
9. Scroll down and set the number of times to repeat
the SOS message.
10. Press <Save> <Yes>.
To send an SOS message
1. With the phone closed, press [ / ] four times to
send an SOS message to preset numbers.
The phone switches to SOS mode and sends the
preset SOS message.
2. To exit SOS mode, press [ ].
Use the camera
Capture photos
1. In Idle mode, press the navigation key down.
2. Aim the lens at the subject and make any
adjustments.
3. Press [OK] to take a photo.
4. Press <Back> to take another photo (step 2).
View photos
In Idle mode, press <Menu> My les Images
My photos a photo le.
Listen to music
1. In Idle mode, press <Menu> Music.
2. Select a music category a music le.
3. Control playback using the following keys:
Keys Function
OK Pause or resume playback
/Adjust the volume up or down
Navigation
Left: Restart playback;
Skip backward (press within 3 seconds);
Scan backward in a le (press and hold)
Right: Skip forward;
Scan for ward in a le (press and hold)
Up: Open the playlist
Down: Stop playback
•
•
•
•
1
4-way navigation key
In ldle mode, access user-dened
menus; In Menu mode, scroll
through menu options
2
Web access/Conrm key
In ldle mode, access the web
browser;
In Menu mode, select the highlighted
menu option or conrm an input
3
My Menu key
In Idle mode, access My Menu mode
4
Dial key
Make or answer a call; In Idle mode,
retrieve recently dialled, missed, or
received numbers
5
Volume key
Adjust the phone's volume;
Send an SOS message
Activate and send an SOS message
6
Voice mail service key
In Idle mode, access voice mails
(press and hold)
7
Alphanumeric keys
8
Softkeys
Perform actions indicated at the
bottom of the display
9
Delete key
Delete characters
10
Organiser key
In Idle mide, access organiser
applications
11
Power/Menu exit key
Turn the phone on and off (press and
hold); End a call;
In Menu mode, cancel input and
return to Idle mode
12
Silent prole key
In Idle mode, activate or deactivate
Silent prole (press and hold)
Your phone displays the following status indicators on the top of
the screen:
Icon Description
Signal strength
GPRS network connected
EDGE network connected
Call in progress
Call diverting active
SOS message feature
activated
Alarm activated
Browsing the web
Connecting to secured
web page
In Home Zone service area
In Ofce Zone service area
Icon Description
Bluetooth activated
New text message (SMS)
New multimedia message
(MMS)
New email message
New voice mail message
Music playback in progress
FM radio on
Memory card inserted
Normal prole activated
Silent prole activated
Battery power level
1
2
4
5
7
8
11
12
3
9
10
6
