- Contents
- Important Safety Precautions
- Unpacking
- . Standard / Extended Battery
- . Car Charger
- . Car Cradle
- . Stylish Handsfree Car Kit
- . PC Data Link Kit
- . Keep SIM cards out of the reach of small children.
- . The SIM card and its Phonebook can easily be damaged by scratches or bending, so be careful when handling, inserting, or removing the card.
- . When installing the SIM card, always make sure that the phone is switched off before you remove the battery.
- 2. Insert and slide the SIM card under the two tabs, ensuring that the notched corner is at the top left and the gold Phonebook of the card face down into the phone.
- 2. Press the battery against the back of the phone until it clicks into place.
- 2. To remove the battery, press and hold the catch above the battery. Lift the battery away from the phone.
- 2. Plug the charger into a standard AC wall outlet.
- 3. When charging is finished, unplug the charger from the power outlet and from the phone by pressing the grey buttons on both sides of the connector and pulling the connector out.
- 2. Insert the teeth on the bottom of the battery into the slot on the battery charger and press the battery until it clicks into place.
- 3. Plug the travel charger into a standard AC wall outlet.
- 4. Ensure that the charger has been disconnected either from the charger or the wall outlet before removing the battery. To remove the battery, push and hold the catch on the charger and lift the battery away.
- 2. Press and hold the key until the phone switches on.
- 3. If the phone asks for a PIN, enter the PIN code and press the Confirm soft key. For further details, see page 122.
- 4. To switch the phone off, press and hold the key until the power-off animation displays.
- 2.
- 2. Enter the country code, area code, and phone number and press the key.
- 2. Press the Left or Right scroll key to scroll to the desired type of call: all, dialled calls, missed calls, or received calls.
- 3. Use the Up and Down scroll keys to scroll through the list until the desired number highlights.
- 4. To dial the number, press the key.
- 2. To dial the number, press the key.
- 2. If there is more than one number, select the number you want to phone back and press the key.
- 2. Press and hold the key to insert a pause.
- 3. Enter the number that needs to follow the pause, such as your account number.
- 4. Repeat steps 2 and 3 to add more pauses and numbers, if necessary.
- 5. Press the key to dial.
- 6. When prompted, press the key to send the DTMF (Dual Tone Multi-frequency) tones of the number that follows the pause.
- 7. Repeat Step 6, as you are prompted.
- 2. End the call by closing the handset or pressing the key.
- 2. Select New call and press the OK key.
- 3. Enter the phone number you want to dial and press the key, Call soft key, or OK key to make the second call.
- 2. Make the second call in the normal way.
- 2. In the select box, select Accept to answer the incoming call. The first call is automatically put on hold.
- 3. To switch between the two calls, press the SWAP soft key.
- 2. Make a second call, referring to page 24.
- 3. To join the first participant to the conference call, press the Options soft key and select Join using the Up and Down scroll keys.
- 4. Press the OK key.
- 5. To add a new person to the conference call, repeat steps 2 to 4, as needed.
- 2. Press the Up or Down scroll key to scroll to the participant you want to split off and press the OK key.
- 3. To return to the conference call, press the Options soft key and select Join. Press the OK key.
- 2. Press the Up or Down scroll key to scroll to the participant you want to remove and press the OK key.
- 2. Press the Up or Down scroll key to select Phonebook and press the OK key.
- 3. Enter the first few letters of the name you want to find.
- 2. Press the Up or Down scroll key to select Send text msg. and press the OK key.
- 3. Scroll to the person to whom you want to send the message and press the OK key.
- 4. When you have finished selecting recipients, press the Options soft key and select the Write option. Then press the OK key.
- 5. Write your message and press the Options soft key and select the Send option. Then press the OK key.
- 6. Enter any other phone number to which you want to send the message.
- 7. When you have finished entering the numbers, press the Options soft key and select the Send option. Then press the OK key.
- 2. Press the Up or Down scroll key to select Memo and press the OK key.
- 3. Enter the memo. Use the Down scroll key to move to the date field and then enter the date.
- 4. When you have finished entering the memo, press the Options soft key and select the Save option or press the OK key.
- 2. Press the Options soft key.
- 3. Press the Up or Down scroll key to select Save to memo and press the OK key.
- 2. Press the Up or Down scroll key to select Mute and press the OK key.
- 2. Press the Up or Down scroll key to select Unmute and press the OK key.
- 2. Press the Up or Down scroll key to select Send DTMF and press the OK key.
- 3. Enter the number you want to send and press the Send soft key.
- 2. Press the V-Call soft key.
- 3. Use the Show me soft key to see the image of yourself as the other person sees you.
- 4. Use the Options soft key to mute the sound and/or disengage the Camera. You can choose the functions you want to discontinue: Voice, Camera(Video), Voice-Video all, or Keytone.
- 2. Enter the whole word before editing or deleting any keystrokes.
- 3. If the word is correct, start entering the next word. Otherwise, press the 0 key to display alternative word choices for the keys that you pressed.
- 4. Put a space between words by pressing the key.
- 5. Continue entering any other words in T9 mode.
- 2. Enter the word you want to add using ABC mode (see page 34) and press the Add soft key.
- 3. Continue entering other words in T9 mode.
- 2. Scroll using the scroll keys to reach the required application menu. Press the OK key to enter the menu.
- 3. If the menu contains sub-menus, you can access them by scrolling using the Up and Down scroll keys and pressing the Select soft key.
- 4.
- 2. Scroll through the menus by pressing the scroll keys until you reach the Settings menu. To access the Settings menu, press the OK key.
- 3. To access the Phone menu, press the Select soft key or OK key.
- 4. Scroll through the sub-menus by pressing the Up or Down scroll key, then use either the Select soft key or the OK key to choose your language.
- 5. Press the OK key when Screen Text is highlighted.
- 6. Scroll through the list of languages by pressing the Up or Down scroll key until the appropriate one is highlighted. Press the Select soft key or the OK key.
- 7. Press the Save soft key to save the setting in the Language screen. Otherwise press the Back soft key.
- 8. Press the key to exit the menu.
- 2. Press for Settings.
- 3. Press for Phone.
- 4. Press for Language.
- 1. Applications (see page 42)
- 2. Call log (see page 53)
- 3. Phonebook (see page 56)
- 4. Internet (see page 63)
- 5. Messages (see page 67)
- 6. My Items (see page 83)
- 7. Organiser (see page 87)
- 8. Profiles (see page 92)
- 9. Settings (see page 94)
- Applications
- 1. Press the Left or Right scroll key to select an application folder, Basic, Alarm, or Games & more.
- 2. Press the Up or Down scroll key to select an application.
- 3. Press the OK key to start the application.
- SIM Applications
- Camera/Video recorder
- 1. To turn on your camera, press the Left soft key in idle mode.
- 2. Point the camera at the subject, rotating the camera if necessary.
- 3. Press the OK key. Or, press the Options soft key and press the OK key when Take picture is highlighted to take a picture.
- 4. The photo is saved automatically and then
- . As multimedia msg.: allows you to send the picture as a multimedia message. For further details about sending multimedia messages, see page 68.
- . As email: allows you to send the picture as an e-mail.
- . Via file sender: allows you to send a message with the picture attached.
- . Automatic: when you take a picture, the flash will light.
- . Manual: to switch the camera flash on or off, you have to press the Up key in the Navigation key in capture mode. The flash goes on. When you have taken a picture the flash goes out.
- 1. To turn on your camera, press the Left soft key.
- 2. When you are in camera mode, press the Options soft key and then select Record video.
- 3. Press the Options soft key. Select Record by pressing the Up or Down scroll key and press the OK key.
- 4. Your phone starts recording. Maximum recording time is 30 seconds.
- 5. While recording video:
- 6. When the recording time expires, the phone automatically saves the video in the Videos folder in My Items; see page 85.
- . As multimedia msg.: allows you to send the video as part of a multimedia message. For further details about sending multimedia messages, see page 68.
- . As email: allows you to send the video as part of an e-mail.
- . Via file messenger: allows you to send a message with the video attached.
- Media Player
- . you view a media file in the My Items menu.
- . you want to play a sound file or a video in the browser.
- 1. On the Media Player screen, press the Options soft key.
- 2. Scroll to Open play list and press the OK key.
- 3. Press the Up or Down scroll key to select the file you want to play and press the OK key or the Select soft key.
- 4.
- 1. On the Media Player screen, press the Options soft key.
- 2. Press the Up or Down scroll key to scroll to Player settings and press the OK key.
- 3. Press the Up or Down scroll key to scroll through the options. You can select the desired setting using the Left and Right scroll keys.
- . Repeat: allows you to set Media Player to repeat either all files or only a single file. Selecting None means that the file is played just once.
- . Play order: allows you to set the order to Random or Normal.
- . Volume: allows you to adjust the volume level. This option is available only when you have already opened a file.
- . Hide controller: hides the Media Player control bar when you place a check mark next to this option by pressing the OK key. If you want the control bar to show again, remove the check mark by pressing the OK key.
- Voice Memo
- World Clock
- Calculator
- Converter
- 1. Select the units to be converted by pressing the Left or Right scroll key.
- 2. When you enter the value to be converted, you can see the corresponding value of each unit.
- 1. Select the base currency by pressing the Left or Right scroll key.
- 2. Scroll to another currency by pressing the Up or Down scroll key and edit the rates.
- 3. Press the Options soft key and select the Save option to save the rate.
- Alarm
- 1. Select the type of alarm from among Once alarm, Daily alarm, or Wake up alarm.
- 2. Set On by pressing the Left or Right scroll key.
- 3. Move to the time field by pressing the Down scroll key and enter the time for the alarm to sound.
- 4. (Only for the Wake up alarm) Move to the repeat field by pressing the Down scroll key and select the repetition type from among None, Every day, Except weekend, or Except Sunday.
- 5. Move to the alert tone field by pressing the Down scroll key. After pressing the OK key, you can select an alarm melody
- 6. Press the Save soft key to save it.
- 1. Select the type of alarm from among Once alarm, Daily alarm, or Wake up alarm.
- 2. Set Off by pressing the Left or Right scroll key.
- . Press the OK soft key or key.
- . When the Wake up alarm tone sounds, press the Snooze soft key to stop the alarm for five minutes, after which it will resume. You can do this a maximum of five times.
- Games & More
- Call Log
- . missed, dialled, and received calls, or all calls
- . cost of your calls
- . length of time of calls you have made or received
- . You can access the all calls list by pressing the key in idle mode.
- . When you are not calling, but using a headset with the phone is closed, you can see the call log on the sub LCD by pressing the headset button. You can also scroll through the log by pressing the volume keys on the left side of the phone.
- Missed, Dialled, Received, or All Calls (Menu 2-1~4)
- Data Calls (Menu 2-5)
- Call Costs (Menu 2-6)
- 1. The Call Costs screen shows you the total cost, last call costs, and cost limit.
- 2. While viewing the call costs, press the Options soft key to use the following options:
- . Reset call costs: allows you to reset the cost counter; first, you must enter your PIN2 code (see page 112) and then press the Confirm soft key.
- . Edit cost limit: allows you to enter the maximum cost that you authorise for your calls; first, you must enter your PIN2 code (see page 112) and then press the Confirm soft key.
- . Setup currency: allows you to set the currency of the call cost; first, you must enter your PIN2 code (see page 112) and then press the Confirm soft key.
- Call Times (Menu 2-7)
- 1. Press the Up or Down scroll key to scroll through the call timer for each call type.
- . Total dialled: total time of the voice calls you have dialled.
- . Total received: total time of the voice calls you have received.
- . Total dialled: total time of the video calls you have dialled.
- . Total received: total time of the video calls you have received.
- . Reset: resets the call timer.
- . Reset all: resets all of the call timers.
- Phonebook
- Search Contact (Menu 3-1)
- New (Menu 3-2)
- 1. Press the Up or Down scroll key to scroll through the input boxes and enter the corresponding information you want to save:
- . First Name/Last Name: enter the first and the last name of the contact. For further details about entering characters, see page 32.
- . Mobile()/Home()/Work()/ Fax()/Etc.(): enter the number you want to add in the appropriate input box.
- . Email: enter the person’s e-mail address.
- . Group: press the OK key to add the person to a group.
- . Homepage: enter the URL address of the person’s home page.
- . Memo: enter information you need to remember about the person.
- . Name: enter the name of the contact. For further details about entering characters, see page 32.
- . Phone number/Additional phone number: enter the phone number you want to add.
- . Email: enter the person’s e-mail address.
- . Group: press the OK key to add the person to a group.
- 2. Press the Down scroll key to move to the location number input box and modify a number, if you want.
- 3. Press the Options soft key and select Save option.
- 1. Enter the name of the contact.
- 2. Press the Down scroll key to move to the Phone number input box and enter a number.
- 3. Press the Down scroll key to move to the location number input box and modify a number, if you want.
- 4. Press the Save soft key.
- 1. In idle mode, enter the number to be stored.
- 2. Press the Options soft key and press the OK key when Save contact to highlights.
- 3. Press the Up or Down scroll key to scroll through the input boxes and enter the corresponding information you want to save. T...
- . Picture: allows you to select an image to be displayed when a call or message comes in from the contact. Press the OK key. You can select from icon, animation, and photo, and then choose a file from My Items.
- . Ring tone: allows you to set a sound to be played when a call comes in from the contact. Press the OK key and select an audio file from My Items.
- . Msg. alert tone: allows you to select a sound to be played when a message comes in from the contact. Press the OK key and select a sound file from My Items.
- Viewing Contact Information
- Groups (Menu 3-3)
- 1. When the Group list displays, if necessary press the Up or Down scroll key to scroll through the Group list to the Group you want.
- 2. Press the Options soft key from the Group list to access the following options:
- . View members: views the Phonebook list saved for this group.
- . Add group: you can enter a group name for a new group. You can see the new group name in the Group list.
- . Rename group: allows you to change the group name.
- . Delete group: deletes the selected group.
- . Delete all groups: deletes all of the groups.
- . Details: allows you to view detailed information about the selected member.
- . Edit group: allows you to change members in the group. Mark and unmark names you want to add or delete using the OK key and press the Save soft key.
- Speed Dial (Menu 3-4)
- 1. When the Speed Dial list displays, highlight the Speed dial number you want to edit by pressing the scroll key.
- 2. Press the Options soft key to access the following options:
- . Assign: allows you to add a speed dial number at an empty slot.
- . Details: allows you to view detailed information about the selected speed dial entry, for example, the image and phone number of the contact.
- . Change: allows you to change one entry into another.
- . Remove: allows you to clear the selected speed dial number.
- My Name Card (Menu 3-5)
- Copy All to Phone (Menu 3-6)
- Memory Status (Menu 3-7)
- Internet
- Launching the Browser
- Closing the Browser
- Using the Browser
- Entering Text in the Browser
- Using the Browser Menus
- Using Bookmarks
- 1. Go to the page that you want to bookmark and press the Options soft key.
- 2. Scroll to Add bookmark and press the OK key.
- 3. Enter the title for the bookmark and press the Save soft key.
- 1. Press the Links soft key on the startup screen of the Internet menu.
- 2. Scroll to a bookmark item and press the OK key.
- Setting up the Browser
- Messages
- Write (Menu 5-1)
- 1. On the Write screen, press the Select soft key when Short msg. highlights.
- 2. Write your message.
- 3. If you want to use the message options while entering your message, press the Options soft key. Select one of the following options:
- . Use text template: allows you to use one of the preset message templates stored in the Text templates menu; for further details, see page 77.
- . Input language: selects the language to be used.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu; for further details, see page 76.
- . Add Phonebook: allows you to add a contact to the message.
- . Send: allows you to send the message.
- . Contacts: allows you to search Phonebook for a number. See page 92.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu; for further details, see page 76.
- . Send settings: allows you to change the settings for the message transmission.
- 6. To send the message to more than one person, press the Down scroll key to move to another To input box.
- 7. When you have finished setting the destination(s), press the Options soft key and select the Send option to send the message.
- 1. On the Write screen, select Multimedia msg.
- 2. Enter the subject in the Subject text field.
- 3. To attach an image, video, or audio file, press the scroll key to move to the Picture or Video or Audio field and press the O...
- 4. Enter your message into the Text field.
- 5. If you want to use the message options while entering your message, press the Options soft key. Select one of the following options:
- . Preview: shows your message as it will be displayed on the recipient’s phone. Scroll through the message by pressing the Up or Down scroll key.
- . Input language: selects the language to be used.
- . Use text template: allows you to use one of the preset message text templates stored in the Text templates menu; for further details, see page 77.
- . Delete picture/video/sound/text: deletes the selected image, video, sound, or text.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu; for further details, see page 76.
- . Add page: adds a new page.
- . Delete page: deletes a selected page. This option is only available if more than one page has been created.
- . Edit page: allows you to use the following options:
- 6. When you have finished creating the message, press the Options soft key and select Send.
- 7. Enter a destination number in the To input box.
- 8. To send the message to more than one person, press the Down scroll key to move to another To input box.
- 9. When you have finished setting the destination(s), press the Options soft key and select the Send option to send the message.
- 1. On the Write screen, select File messenger and press the OK key.
- 2. Enter the subject of your message.
- 3. Press the Down scroll key and enter your message contents.
- 4. Press the Down scroll key to attach a media file and press the OK key. The My Items screen displays.
- 5. Select a media file by pressing the scroll keys and press the OK key to select it. A check mark appears next to the selected file.
- 6. Repeat step 5 to add more files.
- 7. When you have finished selecting the files, press the Options soft key and press the OK key when Attach highlights. You can cancel your selection by choosing Deselect all.
- 8. If you want to use the message options while entering your message, press the Options soft key. Select one of the following options:
- . Use text template: allows you to use one of the preset message templates stored in the Text templates menu.
- . Delete all attached file(s): removes all attached files.
- . Attachment(s): shows a list of attached file(s).
- . Input language: selects the language to be used.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu.
- . Send: allows you to send the message.
- . Contacts: allows you to search Phonebook for a number. See page 92.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu; for further details, see page 76.
- . Settings: allows you to change the settings for message transmission.
- 11. To send the message to more than one person, press the Down scroll key to move to another To input box.
- 12. When you have finished setting the destination(s), press the Options soft key and select the Send option to send the message.
- 1. On the Write screen, press the Select soft key when Email highlights.
- 2. Enter the subject of your message.
- 3. Press the Down scroll key and enter your message contents.
- 4. Press the Down scroll key to attach a media file, if desired, and press the OK key. The My Items screen displays.
- 5. Select a media file by pressing the scroll keys and press the OK key to select it. A check mark appears next to the selected file.
- 6. Repeat step 5 to add more files.
- 7. When you have finished selecting the files, press the Options soft key and press the OK key when Attach highlights. You can cancel your selection by choosing Deselect all.
- 8. If you want to use the message options while entering your message, press the Options soft key. Select one of the following options:
- . Use text template: allows you to use one of the preset message templates stored in the Text templates menu; for further details, see page 77.
- . Delete all attached file(s): removes all attached files.
- . Attachment(s): shows a list of attached file(s).
- . Input language: selects the language to be used.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu.
- . Send: allows you to send the message.
- . Contacts: allows you to search Phonebook for an e-mail address. See page 92.
- . Save to Drafts: saves the message as a draft. You can access it later in the Drafts menu; for further details, see page 76.
- . Send settings: allows you to change the settings for message transmission.
- Inbox (Menu 5-2)
- Email Box (Menu 5-3)
- Outbox (Menu 5-4)
- Drafts (Menu 5-5)
- Templates (Menu 5-6)
- 1. On the Messages screen, scroll to the Templates menu and press the Select soft key. Press the Select soft key when MMS templates highlights.
- 2. Select an MMS message template.
- 3. Press the Options soft key to use the following options:
- . View: views the selected MMS template.
- . Send: send the selected MMS template as a multimedia message.
- . Edit: allows you to edit the selected MMS template the same way you edit an MMS message. After you edit it, you can send it the same way you send an MMS message.
- . Delete: deletes the selected MMS template.
- Delete All (Menu 5-7)
- 1. Scroll to a message type and place a check mark next to it by pressing the OK key.
- 2. If necessary, repeat step 1 to select another type.
- 3. When you have finished making selections, press the Delete soft key.
- 4. When a confirming message appears, press the Yes soft key to delete all of the messages in the type(s).
- Settings (Menu 5-8)
- Send settings
- Receive settings
- . Auto: you receive multimedia messages automatically.
- . Manual: you receive a notification message first. Then, if you choose, you can download the multimedia message.
- . Restricted (only for Roaming network): If you select this method of notification, there may be a possible additional charge, depending on whether you download the message or not.
- Network settings
- Send settings
- Receive settings
- Network settings
- Account Settings
- Memory Status (Menu 5-9)
- Write (Menu 5-1)
- My Items
- Exploring Multimedia Files
- . As multimedia msg.: allows you to send a multimedia message using the multimedia file. For further details about sending multimedia messages, see page 68.
- . As email: allows you to send an e-mail using the multimedia file.
- . Via file messenger: allows you to send a message with a multimedia file attached.
- Viewing an Image
- Creating a New Image
- Playing a Video File
- Creating a Video
- Playing a Music File
- 1. Press the Up or Down scroll key to select Music. The music list displays.
- 2. Press the Up or Down scroll key to select a music file and press the OK key.
- 3. The music plays.
- 1. Press the Up or Down scroll key to select Sounds.
- 2. Press the Left or Right scroll key to scroll through the sub folders: Ringtones, Recordings, and Downloads.
- 3. Press the Up or Down scroll key to select a file and press the OK key.
- 4. The music plays.
- Creating a Sound
- Exploring Multimedia Files
- Organiser
- Calendar (Menu 7-1)
- . Press the Up or Down scroll key to move to the previous or next week.
- . Press the Left or Right scroll key to move to the previous or next day.
- . Press the volume keys to move to the previous or next month. You can also press the Left, Right, or Up scroll key when the title bar showing the month and year highlights.
- . Press the OK key to access the selected day.
- Today’s Events (Menu 7-2)
- Schedule (Menu 7-3)
- 1. Scroll through the entry fields by pressing the Up or Down scroll key. Enter information or select the settings you want.
- . Title: enter a title for the event. See page 32 for more information about entering characters.
- . Details: enter the event details.
- . Start: enter the start time of the event. You can move the cursor using the Left and Right scroll keys.
- . End: enter the end time of the event the same way as you would enter a start time.
- . Start date: enter the start date. You can move the cursor using the Left and Right scroll keys.
- . End date: enter the end date the same way as you would enter a start date.
- . Location: enter information about the event location.
- . Alarm: press the OK key to set an alarm to remind you of the event. Then set when the alarm is to alert you: enter the number ...
- . Repeat: if you are entering a recurring event, press the OK key and select the repeat option using the Left and Right scroll keys. Then enter the date that you wish the event to cease recurring.
- Anniversary (Menu 7-4)
- 1. Scroll through the entry fields by pressing the Up or Down scroll key. Enter information or select the settings you want.
- . Occasion: enter the information about the occasion. See page 32 for more information about entering characters.
- . Date: enter the date. You can move the cursor using the Left and Right scroll keys.
- . Alarm: press the OK key to set an alarm to remind you of the event. To set an alarm ahead of the day required, enter the desir...
- . Repeat every year: press the OK key to mark or unmark this option.
- Task List (Menu 7-5)
- 1. Scroll through the entry fields by pressing the Up or Down scroll key. Enter information or select the settings you want.
- . Task: enter the information about the occasion. See page 32 for more information about entering characters.
- . Start date: enter the start date. You can move the cursor using the Left and Right scroll keys.
- . Due date: enter the due date.
- . Priority: enter the priority, choosing 1, 2 or 3. 1 is the highest priority.
- Memo (Menu 7-6)
- Missed Event Alarm (Menu 7-7)
- Calendar (Menu 7-1)
- Profiles
- Changing the Profiles
- Customising the Profiles
- 1. To modify a profile, scroll to the profile on the Profiles list by pressing the Up or Down scroll key, and then press the OK key. A list of profile settings opens. The available setting options vary depending on the selected profile.
- 2. Scroll to the setting you want to change by pressing the Up or Down scroll key, and then change the setting using the Left or Right scroll keys, or the OK key.
- 3. When you finish setting the options, press the Save soft key.
- Settings
- Phone (Menu 9-1)
- 1. Press the OK key in the Screen Text field.
- 2. Press the Up or Down scroll key to select a language for the display text, e.g., menu names and warning or confirmation messages, and press the Select soft key.
- 3. Press the Down scroll key to move to the Input T9 field and press the OK key.
- 4. Press the Up or Down scroll key to select a language for the T9 input mode and press the Select soft key.
- 5. Press the Save soft key.
- 1. Press the Left or Right scroll key to check the current function assigned, and select the scroll key whose function you want to change.
- 2. Press the Options soft key to use the following options:
- Display (Menu 9-2)
- 1. When Greeting message highlights in the Display menu, press the Select soft key.
- 2. Press the C key to clear the message.
- 3. Enter a new message.
- 4. When you have finished entering the message, press the Save soft key.
- 1. Select Wallpaper in the Display menu using the Up or Down scroll key, and press the Select soft key. You can also press the Wallpaper soft key from the Settings startup screen.
- 2. Press the Up or Down scroll key to scroll to the image you want to use.
- 3. Press the Select soft key.
- Call (Menu 9-3)
- 1. From Voice call, Data call, and Video call, select the type of call to be diverted by pressing the Up or Down scroll key, and then press the OK key.
- 2. Select when the calls should be diverted by pressing the Up or Down scroll key, and then press the OK key.
- 3. Press the Left or Right scroll key to select one of the following options:
- 4. Press the Down scroll key and enter or change the number to which you want your calls diverted. Or, press the Phonebook soft key to select a stored number.
- 5. Press the Up scroll key and press the Req. soft key.
- 1. From Voice call, Data call, and Video call, select the type of call to be barred by pressing the Up or Down scroll key, and then press the OK key.
- 2. Select which calls should be barred by pressing the Up or Down scroll key, and then press the OK key.
- 3. Press the Left or Right scroll key to select one of the following options.
- 4. Press the Down scroll key and enter the call barring password supplied by your service provider.
- 5. Press the Req. soft key.
- Changing the Barring Password
- 1. From the barring menu screen, press the Options soft key and select the Change password option.
- 2. Enter the current password in the Old input box.
- 3. Press the Down scroll key and enter a new password.
- 4. Press the Down scroll key and enter the new password again to confirm it.
- 5. Press the Confirm soft key.
- 1. From Voice call and Data call, select the type of call by pressing the Up or Down scroll key, and then press the OK key.
- 2. Press the Left or Right scroll key to select one of the following options.
- 3. Press the Req. soft key.
- Activating a Closed User Group
- 1. Press the OK key to put a check mark on the Use user group field.
- 2. Press the Down scroll key to move to the Outside access field. Use the OK key to enable or disable calls to numbers other than those in the Closed User Group.
- 3. Press the Down scroll key to move to the Group index field and select the CUG index you want to activate.
- 4. Press the Save soft key.
- Managing the Index List
- 1. On the Closed User Group screen, press the Down scroll key to move to the Group index field.
- 2. Press the OK key to see the Group index list.
- 3. Press the Up or Down scroll key to select an index and press the Options soft key.
- Video call (Menu 9-4)
- Network (Menu 9-5)
- Connections (Menu 9-6)
- Security (Menu 9-7)
- 1. Enter the current password and press the Confirm soft key.
- 2. Enter a new password and press the Confirm soft key.
- 3. Enter the new password again to confirm it and press the Confirm soft key.
- 1. Scroll to an item and place a check mark next to it by pressing the OK key.
- 2. If necessary, repeat step 1 to check another item.
- 3. When you have finished making your selections, press the Save soft key.
- 4. When a confirming message appears, enter your phone password and press the Confirm soft key to lock the content(s) selected.
- 1. Enter the current PIN code and press the Confirm soft key.
- 2. Enter a new PIN code and press the Confirm soft key.
- 3. Enter the new code again to confirm it and press the Confirm soft key.
- 1. Enter the current PIN2 code and press the Confirm soft key.
- 2. Enter a new PIN2 code and press the Confirm soft key.
- 3. Enter the new code again to confirm it and press the Confirm soft key.
- Date & Time (Menu 9-8)
- Own Number (Menu 9-9)
- Memory Status (Menu 9-0)
- Reset Settings (Menu 9-*)
- Phone (Menu 9-1)
- Solving Problems
- Access Codes
- Health and Safety Information
- Glossary
- 3G (3rd Generation)
- The collective name used to describe mobile systems able to support a wide range of Mobile Internet services, operating with greater bandwidth than lower generation phones.
- Bearer
- Various mechanisms the network uses to transmit voice and data.
- Call Barring
- Call Diverting
- Call Holding
- Call Waiting
- CLI (Caller Line Identification) Services
- GPRS (General Packet Radio Service)
- New non-voice value-added service that allows information to be sent and received across a mobile telephone network. GPRS guaran...
- GSM (Global System for Mobile Communication)
- Java
- MMS (Multimedia Message Service)
- Multiparty Calling
- Packet-Switched
- PIN (Personal Identification Number)
- PUK (PIN Unblocking Key)
- Roaming
- SIM (Subscriber Identification Module)
- SMS (Short Message Service)
- UMTS (Universal Mobile Telecommunications System)
- Index
*
Some of the contents of this manual may differ from your phone, depending upon the software
installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-06010A
English. 11/2004. Rev. 1.1
Z107Eng_Vodafone.book Page 0 Friday, October 22, 2004 5:04 PM
Samsung SGH-Z107
User’s guide
Z107Eng_Vodafone.book Page 1 Friday, October 22, 2004 5:04 PM
2
Welcome
Congratulations on choosing the Samsung
SGH-Z107.
Your new Samsung SGH-Z107 uses 3G (3rd
Generation) technology, also known as UMTS.
This technology allows fast data connections
similar to broadband speeds, enabling video
capture using its built-in camcorder, and sending
and receiving video, including video calls.
The SGH-Z107 features today’s most advanced
technology including a built-in rotating digital
camera and high-quality TFT colour screen that
reproduces 260,000 different colour shades (four
times more than other colour screens). It also
features 64 polyphonic ringtones.
Copyright © 2004 By Samsung. All rights reserved.
This User’s Guide is published by Samsung.
Some of the contents in this User’s Guide may differ
from your phone, depending on your service provider or
on the software installed.
Improvements and changes to this User’s Guide due to
typographical errors, inaccuracies of current
information, or improvement of software or hardware,
may be made by Samsung without notice.
Z107Eng_Vodafone.book Page 2 Friday, October 22, 2004 5:04 PM
3
Contents
Important Safety Precautions . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . 8
Phone Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
External Light . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Getting Started. . . . . . . . . . . . . . . . . . . . . . 13
Inserting/Removing the SIM Card . . . . . . . . . . . . . 13
Installing/Removing/Charging the Battery . . . . . . . 14
Switching the Phone On or Off . . . . . . . . . . . . . . . 17
Selecting Functions and Options . . . . . . . . . . . . . . 17
Switching Applications . . . . . . . . . . . . . . . . . . . . . 20
Call Functions. . . . . . . . . . . . . . . . . . . . . . . 21
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . 23
Rejecting a Call. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . 24
Accessing Options During a Call . . . . . . . . . . . . . . 24
Using Video Call Features. . . . . . . . . . . . . . . . . . . 29
Using the Headset. . . . . . . . . . . . . . . . . . . . . . . . 31
Entering Text . . . . . . . . . . . . . . . . . . . . . . . 32
Changing the Text Input Mode . . . . . . . . . . . . . . . 32
Using T9 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using Number Mode . . . . . . . . . . . . . . . . . . . . . . 36
Using Symbol Mode. . . . . . . . . . . . . . . . . . . . . . . 36
Using Menu Functions . . . . . . . . . . . . . . . . 37
Accessing a Menu Function by Scrolling . . . . . . . . . 37
Shortcuts to Menu Functions. . . . . . . . . . . . . . . . . 39
List of Menu Functions . . . . . . . . . . . . . . . . . . . . . 40
Applications . . . . . . . . . . . . . . . . . . . . . . . . 42
SIM Applications . . . . . . . . . . . . . . . . . . . . . . . . . 42
Camera/Video recorder . . . . . . . . . . . . . . . . . . . . 42
Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Voice Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Calculator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Games & More. . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Missed, Dialled, Received, or All Calls
(Menu 2-1~4)
. 53
Data Calls
(Menu 2-5)
. . . . . . . . . . . . . . . . . . . . . . 54
Call Costs
(Menu 2-6)
. . . . . . . . . . . . . . . . . . . . . . 54
Call Times
(Menu 2-7)
. . . . . . . . . . . . . . . . . . . . . . 55
Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . 56
Search Contact
(Menu 3-1)
. . . . . . . . . . . . . . . . . . 56
New
(Menu 3-2)
. . . . . . . . . . . . . . . . . . . . . . . . . . 57
Viewing Contact Information. . . . . . . . . . . . . . . . . 59
Groups
(Menu 3-3)
. . . . . . . . . . . . . . . . . . . . . . . . 60
Speed Dial
(Menu 3-4)
. . . . . . . . . . . . . . . . . . . . . 61
My Name Card
(Menu 3-5)
. . . . . . . . . . . . . . . . . . 62
Copy All to Phone
(Menu 3-6)
. . . . . . . . . . . . . . . . 62
Memory Status
(Menu 3-7)
. . . . . . . . . . . . . . . . . . 62
Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Launching the Browser. . . . . . . . . . . . . . . . . . . . . 63
Closing the Browser. . . . . . . . . . . . . . . . . . . . . . . 63
Z107Eng_Vodafone.book Page 3 Friday, October 22, 2004 5:04 PM
Contents
4
Using the Browser. . . . . . . . . . . . . . . . . . . . . . . . 63
Entering Text in the Browser . . . . . . . . . . . . . . . . 64
Using the Browser Menus. . . . . . . . . . . . . . . . . . . 64
Using Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . 64
Setting up the Browser . . . . . . . . . . . . . . . . . . . . 66
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Write
(Menu 5-1)
. . . . . . . . . . . . . . . . . . . . . . . . . 67
Inbox
(Menu 5-2)
. . . . . . . . . . . . . . . . . . . . . . . . . 74
Email Box
(Menu 5-3)
. . . . . . . . . . . . . . . . . . . . . . 75
Outbox
(Menu 5-4)
. . . . . . . . . . . . . . . . . . . . . . . 76
Drafts
(Menu 5-5)
. . . . . . . . . . . . . . . . . . . . . . . . 76
Templates
(Menu 5-6)
. . . . . . . . . . . . . . . . . . . . . 77
Delete All
(Menu 5-7)
. . . . . . . . . . . . . . . . . . . . . . 78
Settings
(Menu 5-8)
. . . . . . . . . . . . . . . . . . . . . . 78
Memory Status
(Menu 5-9)
. . . . . . . . . . . . . . . . . . 82
My Items . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Exploring Multimedia Files . . . . . . . . . . . . . . . . . . 83
Organiser . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Calendar
(Menu 7-1)
. . . . . . . . . . . . . . . . . . . . . . 87
Today’s Events
(Menu 7-2)
. . . . . . . . . . . . . . . . . . 88
Schedule
(Menu 7-3)
. . . . . . . . . . . . . . . . . . . . . . 88
Anniversary
(Menu 7-4)
. . . . . . . . . . . . . . . . . . . . 89
Task List
(Menu 7-5)
. . . . . . . . . . . . . . . . . . . . . . 90
Memo
(Menu 7-6)
. . . . . . . . . . . . . . . . . . . . . . . . 90
Missed Event Alarm
(Menu 7-7)
. . . . . . . . . . . . . . . 91
Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Changing the Profiles. . . . . . . . . . . . . . . . . . . . . . 92
Customising the Profiles. . . . . . . . . . . . . . . . . . . . 92
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Phone
(Menu 9-1)
. . . . . . . . . . . . . . . . . . . . . . . . 94
Display
(Menu 9-2)
. . . . . . . . . . . . . . . . . . . . . . . 96
Call
(Menu 9-3)
. . . . . . . . . . . . . . . . . . . . . . . . . . 97
Video call
(Menu 9-4)
. . . . . . . . . . . . . . . . . . . . . 101
Network
(Menu 9-5)
. . . . . . . . . . . . . . . . . . . . . . 102
Connections
(Menu 9-6)
. . . . . . . . . . . . . . . . . . . . 103
Security
(Menu 9-7)
. . . . . . . . . . . . . . . . . . . . . . 104
Date & Time
(Menu 9-8)
. . . . . . . . . . . . . . . . . . . 107
Own Number
(Menu 9-9)
. . . . . . . . . . . . . . . . . . . 108
Memory Status
(Menu 9-0)
. . . . . . . . . . . . . . . . . 108
Reset Settings
(Menu 9-*)
. . . . . . . . . . . . . . . . . . 108
Solving Problems . . . . . . . . . . . . . . . . . . . 109
Access Codes . . . . . . . . . . . . . . . . . . . . . . 111
Phone Password. . . . . . . . . . . . . . . . . . . . . . . . . 111
PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
PIN2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
PUK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
PUK2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Call Barring Password . . . . . . . . . . . . . . . . . . . . . 112
Health and Safety Information. . . . . . . . . 113
SAR Certification Information. . . . . . . . . . . . . . . . 113
Precautions When Using Batteries . . . . . . . . . . . . 114
Road Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Operating Environment. . . . . . . . . . . . . . . . . . . . 115
Electronic Devices . . . . . . . . . . . . . . . . . . . . . . . 115
Potentially Explosive Environments. . . . . . . . . . . . 117
Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . 117
Other Important Safety Information . . . . . . . . . . . 118
Care and Maintenance . . . . . . . . . . . . . . . . . . . . 119
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Z107Eng_Vodafone.book Page 4 Friday, October 22, 2004 5:04 PM
5
Important Safety Precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road Safety at All Times
Do not use a hand-held phone while driving;
park the vehicle first.
Switching Off When Refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switching Off in an Aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.
Special Regulations
Meet any special regulations in force in the area
you are in and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger (in a hospital for
example).
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna
when the phone is switched on.
Z107Eng_Vodafone.book Page 5 Friday, October 22, 2004 5:04 PM
Important Safety Precautions
6
Emergency Call
Ensure the phone is switched on and in service.
Cancel all running applications before making an
emergency call. Key in the emergency number
for your present location, then press the key.
Give all the necessary information as accurately
as possible. Do not end the call until given
permission to do so.
Water Resistance
Your phone is not water-resistant. Keep it dry.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries.
Qualified Service
Only qualified service personnel may install or
repair your phone.
For more detailed safety information, see “Health
and Safety Information” on page 113.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
Z107Eng_Vodafone.book Page 6 Friday, October 22, 2004 5:04 PM
7
Unpacking
Your package contains the following items: In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer.
• Standard / Extended Battery
• Car Charger
• Car Cradle
• Stylish Handsfree Car Kit
•PC Data Link Kit
Notes
:
• Use only the supplied or an approved headset for
the Z107 model. The device comes with two
batteries in the package. The larger battery has a
higher capacity.
• The items supplied with your phone and available
accessories may differ, depending on your
country or service provider.
Phone Travel Charger
Batteries Owner’s Manual
Data Link Cable PC Link CD
Battery Holder
Z107Eng_Vodafone.book Page 7 Friday, October 22, 2004 5:04 PM
8
Your Phone
Phone Layout
The following illustrations show the main
elements of your phone:
Closed
Open
Reject key
Antenna
External
display
Infrared port
External light
Earpiece
Headset
jack
Application switch
key
Folder
Navigation/
Scroll keys
Volume/Menu
browse keys
Correction/Back
key
Menu/OK key
Camera module
Send key
Special function
keys
Main display
Soft key (right)
Power On/Off /
End key
Alphanumeric
keys
Soft key (left)
Z107Eng_Vodafone.book Page 8 Friday, October 22, 2004 5:04 PM
Your Phone
9
Key Description
(soft keys)
Perform the functions indicated by
the text above them, on the
bottom line of the display.
In menu mode: scrolls through the
menu options.
In idle mode: the Up key enters the
Search Contact menu and the
Down key enters the Calendar
menu. The Left key and the Right
key allow you to access specified
menu options as shortcuts.
In menu mode: selects the
highlighted menu or option.
In idle mode: enters the main
menu.
Makes or answers a call.
In idle mode: accesses call records.
Lets you open the Call, Messages,
or Internet applications without
quitting the current application.
Deletes entered numbers or text.
In menu mode, returns to the
previous menu.
Ends a call.
Switches the phone on and off
when held down.
In menu mode: exits the current
screen and takes you back to idle
mode.
Enters numbers, letters, and some
special characters.
Used for various purposes in
different functions.
The key inserts a pause when
held down while entering a number.
In idle mode: the key enters or
exits silent mode when held down.
Key Description
(continued)
Z107Eng_Vodafone.book Page 9 Friday, October 22, 2004 5:04 PM
Your Phone
10
Display
Display Layout
The display has three areas.
(on the left side of the phone)
During a call: adjusts the earpiece
volume.
In idle mode with the handset
open: adjusts the key volume.
In idle mode with the handset
closed: turns on the external
display’s backlight when held down.
The volume keys on the left side of
the phone also turn the picture
upside down / mirror image while
in camera mode or during a video
telephone call.
(on the right side of the phone)
Rejects incoming calls when the
handset is closed.
Key Description
(continued)
Area Description
First line Displays various icons (see
page 11).
Middle Displays messages,
instructions, and any
information that you enter:
the number you are dialling,
for example.
Last line Shows the current functions
assigned to the two soft keys.
Icons
Text and
graphic area
Soft key
indicators
Z107Eng_Vodafone.book Page 10 Friday, October 22, 2004 5:04 PM
Your Phone
11
Icons
Icon Description
Shows the received signal strength.
The greater the number of bars, the
better the signal.
Informs you which calling mode you
are in.
• : A call is in progress.
• : A call is impossible.
• : A video call is in progress.
• : A video call has been
disconnected.
Informs you whether you are in a 2.5G
or 3G (UMTS) network.
• : You are in a 3G (UMTS) network.
• : You are retrieving and sending
data in a 3G (UMTS) network.
This icon is animated.
• : You are calling in a 3G (UMTS)
network.
• : You are in a 2.5G network.
• : You are retrieving and sending
data in a 2.5G network. This
icon is animated.
• : You are calling in a 2.5G
network.
Appears when your phone is connected
to a PC running the internet wizard or
is synchronised with a PC.
• : You are connected to a PC.
• : This icon is animated while
browsing on the PC.
• : This icon is animated while
synchronising with a PC.
Appears when you have set an alarm.
Appears when you are out of your
home area and have logged onto a
different network (i.e., when travelling
in other countries).
Informs you of the type of message
received.
• : E-mail message
• : Multimedia message
• : Configuration message
• : Text message
• : Voice mail
Icon Description
(continued)
Z107Eng_Vodafone.book Page 11 Friday, October 22, 2004 5:04 PM
Your Phone
12
External Display
Your phone has an external display on the folder
cover. It indicates when you have an incoming
call or message, and alerts you at the specified
time when you have set an alarm.
When you hold down one of the volume keys, the
external display backlight illuminates.
External Light
The external light is at the front of the phone.
The light flashes when you are in a service area
and when you switch your phone on. It also
functions as a flash when you take photos.
Appears when the Infrared port is
actived. For detail, see page 96.
Appears when you connect the phone
to a computer by the Infrared port.
Tells you your phone’s sound profile.
• : Car profile
• : Silent profile
• : Meeting profile
• : Outdoor profile
When your phone’s sound profile is set
to Normal, no profile icons will display.
Appears when you access a secured
web page or when you are connected
to the network using a security
protocol while loading Java MIDlets.
Shows the level of your battery. The
more bars you see, the more power
you have left.
Icon Description
(continued)
External light
Z107Eng_Vodafone.book Page 12 Friday, October 22, 2004 5:04 PM
13
Getting Started
Inserting/Removing the SIM Card
Your SIM Card is already loaded with your
subscription details, such as your PIN.
• Keep SIM cards out of the reach of small chil-
dren.
• The SIM card and its Phonebook can easily be
damaged by scratches or bending, so be care-
ful when handling, inserting, or removing the
card.
• When installing the SIM card, always make
sure that the phone is switched off before you
remove the battery.
Inserting the SIM Card
1. If necessary, remove the battery by referring
to page 15.
2. Insert and slide the SIM card under the two
tabs, ensuring that the notched corner is at
the top left and the gold Phonebook of the
card face down into the phone.
Z107Eng_Vodafone.book Page 13 Friday, October 22, 2004 5:04 PM
Getting Started
14
Removing the SIM Card
To remove the SIM card, slide the card out of the
holder, as shown.
Installing/Removing/Charging the
Battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and
chargers. Ask your local Samsung dealer for
further details.
Note
: You must fully charge the battery before
using your phone for the first time. A
discharged standard battery is fully
recharged in approximately 120 minutes.
Installing the Battery
1. Insert the teeth on the bottom of the battery
into the corresponding slots on the phone.
2. Press the battery against the back of the
phone until it clicks into place.
Make sure that the battery is properly
installed before switching the phone on.
Z107Eng_Vodafone.book Page 14 Friday, October 22, 2004 5:04 PM
Getting Started
15
Removing the Battery
1. If the phone is on, switch it off first by
pressing and holding the key until the
power-off animation is displayed.
2. To remove the battery, press and hold the
catch above the battery. Lift the battery away
from the phone.
Charging with the Travel Charger
Note
: The phone can be used while the battery is
being charged, but this causes the battery to
charge more slowly.
1. Plug the travel charger connector into the
bottom of the phone. Check that the arrow on
the connector is facing up, as is the phone.
2. Plug the charger into a standard AC wall
outlet.
Z107Eng_Vodafone.book Page 15 Friday, October 22, 2004 5:04 PM
Getting Started
16
3. When charging is finished, unplug the charger
from the power outlet and from the phone by
pressing the grey buttons on both sides of the
connector and pulling the connector out.
Charging the Battery Using the Battery
Charger
1. Plug the travel charger connector into the
bottom of the battery charger.
2. Insert the teeth on the bottom of the battery
into the slot on the battery charger and press
the battery until it clicks into place.
3. Plug the travel charger into a standard AC
wall outlet.
4. Ensure that the charger has been
disconnected either from the charger or the
wall outlet before removing the battery. To
remove the battery, push and hold the catch
on the charger and lift the battery away.
Low Battery Indicator
When the battery is weak and only a few minutes
of talk time remain, the battery sensor informs
you in the following ways:
• An empty battery icon flashes ( ).
• You hear a warning tone.
• A message is briefly shown on the display.
After 5 minutes, the message is again briefly
shown. The message will appear one last time
just before the phone automatically switches
off.
When the battery becomes too weak for the
phone to operate, it switches off automatically.
Z107Eng_Vodafone.book Page 16 Friday, October 22, 2004 5:04 PM
Getting Started
17
Switching the Phone On or Off
1. Open the phone.
2. Press and hold the key until the phone
switches on.
3. If the phone asks for a PIN, enter the PIN
code and press the
Confirm
soft key. For
further details, see page 122.
The phone begins searching for your network.
When it finds the network, you will see the
network operator’s name. You can make or
receive a call only when connected to a
network.
Note
: To change the language, use the
Language
menu (Menu 9-1-4); for
further details, see page 94.
4. To switch the phone off, press and hold the
key until the power-off animation displays.
Selecting Functions and Options
You can select different functions and option
menus using the two soft keys ( and ).
The roles of the soft keys vary according to the
phone feature you're using. To see what action
will occur or which menu will be accessed by
pressing them, look at the bottom line of the
display (just above each soft key).
Z107Eng_Vodafone.book Page 17 Friday, October 22, 2004 5:04 PM
Getting Started
18
Example
:
To view the various functions and options
available and to select the one you want:
1. Press the appropriate soft key.
In some functions, you may be asked for a PIN or
password. Enter the code and press the
Confirm
soft key or the
OK
key.
Press the left soft
key to access the
Camera mode.
Press the right
soft key to access
the Internet.
2.
To Press the
select the:
• function displayed
• option highlighted
Select
/
Save
soft key
or the
OK
key.
If the function/option
is numbered, you can
press the
corresponding
number key.
scroll up or down
through the menus
or options
Up or Down scroll key.
scroll left or right
through the menus
or options
Left or Right scroll
key.
move back up one
level in the structure
Back
soft key or the
C
key.
return to idle mode
Back
soft key or the
key.
Z107Eng_Vodafone.book Page 18 Friday, October 22, 2004 5:04 PM
Getting Started
19
Using an Option list
When you press the
Options
soft key in a
function, a list of available
options displays.
If the display cannot show
all of the available options,
an Up or Down arrow at the
top and/or bottom of the list
indicates that you can scroll
to further list items currently off-screen.
When an option has sub-
options, an arrow is shown on
the right.
Press
the
Select
soft key or
the Right scroll key and the
sub-option list appears. You can use it in the
same way as a normal option list.
To exit the sub-option list, press the Left scroll
key or the
Back
soft key.
To Press the
scroll through the list Up or Down scroll key.
select the option
highlighted
OK
key,
Select
soft
key, or the
corresponding number
key.
exit the menu and
return to the previous
screen
Back
soft key.
Z107Eng_Vodafone.book Page 19 Friday, October 22, 2004 5:04 PM
Getting Started
20
Switching Applications
When you press the
Application switch key
( ), you can quickly
switch to the Call,
Messages, or Internet,
applications – without
losing your place in
whatever other application
or menu you're using at the
time.
The coloured icon means an application is
running, and grey means it's not running. Scroll
through
Call
,
Messages
, and
Internet
using
the Left and Right scroll keys and press the
Select
soft key to launch the application. Choose
End all?
to end all of the applications.
For example, you can be making an entry in the
Organiser, then use the Application switch key to
open
Call
to make a phone call. When you've
finished, you can then press the
Back
soft key to
return to your Organiser entry.
Z107Eng_Vodafone.book Page 20 Friday, October 22, 2004 5:04 PM
21
Call Functions
Making a Call
Using the Number Keypad
When the idle screen displays, enter the area
code and phone number, and press the key.
Correcting the Number
Making an International Call
1. Press and hold down the
0
key for the
international prefix. The + character appears.
2. Enter the country code, area code, and phone
number and press the key.
Using Call Records
Your phone stores records of dialled, received,
and missed calls, chronologically. The last call is
saved in the first position.
To recall any of these numbers:
1. In idle mode, press the key.
2. Press the Left or Right scroll key to scroll to
the desired type of call: all, dialled calls,
missed calls, or received calls.
3. Use the Up and Down scroll keys to scroll
through the list until the desired number
highlights.
4. To dial the number, press the key.
You can also use the
Call log
menu (Menu 2).
See page 53.
To clear the Press
last digit displayed the
C
key.
whole display and hold the
C
key for
more than one second.
Z107Eng_Vodafone.book Page 21 Friday, October 22, 2004 5:04 PM
Call Functions
22
Making a Call Using Phonebook
You can store contact information, such as
names and phone numbers that you use
regularly, in the SIM card and the phone’s
memory. This information is stored in one list,
called Phonebook. For more information about
adding information to Phonebook, see page 59.
1. Find the number you want to dial.
For further details about searching for a
number, see page 56.
2. To dial the number, press the key.
Viewing Missed Calls
The number of missed calls displays on the idle
screen immediately after a call has been missed.
If you have a subscription that includes Caller
Line Identification (CLI) and you are unable to
answer a call for any reason, you can find out
who was calling you and then call the person
back.
To view the missed call immediately:
1. Open the folder. The pop-up window shows
that you have missed calls.
2. If there is more than one number, select the
number you want to phone back and press
the key.
To use the missed call options, see page 53.
Making a Call Using a Pause
When you call automated systems, like banking
services, you are often required to enter a
password or account number. Instead of
manually entering the numbers each time, you
can enter them before dialling, separated by a
pause.
1. In idle mode, enter the phone number of the
business, such as a bank’s teleservice
number.
2. Press and hold the key to insert a pause.
A “P” appears, meaning that a pause will
occur at that point in the dialling sequence.
Z107Eng_Vodafone.book Page 22 Friday, October 22, 2004 5:04 PM
Call Functions
23
3. Enter the number that needs to follow the
pause, such as your account number.
4. Repeat steps 2 and 3 to add more pauses and
numbers, if necessary.
5. Press the key to dial.
6. When prompted, press the key to send the
DTMF (Dual Tone Multi-frequency) tones of
the number that follows the pause.
The number is sent to the system.
7. Repeat Step 6, as you are prompted.
Ending a Call
When you want to finish your call, briefly press
the key, or close the handset, or press the
End call
option in the call options.
Answering a Call
When someone calls you, the phone rings and an
incoming call box displays.
If the caller can be identified, the caller’s phone
number, or name if stored in Phonebook,
displays. If the incoming call is a restricted call
(the caller has opted to not send his/her phone
number for identification), the display shows
Withheld
; if it is unknown, the display shows
Anonymous
.
1. To answer a call, open the handset. If it is
already open, press the key, the
OK
key,
or the
Accept
soft key.
2. End the call by closing the handset or
pressing the key.
Note
: You can answer a call while using menu
functions. The current operation is cancelled.
Rejecting a Call
To reject an incoming call, press and hold the
key on the right side of the phone.
Z107Eng_Vodafone.book Page 23 Friday, October 22, 2004 5:04 PM
Call Functions
24
When the phone is open, you can also press the
Reject
soft key or the key.
Adjusting the Volume
If you wish to adjust the earpiece volume during
a call, use the keys on the left side of the phone.
Press the key to increase the volume level and
the key to decrease the level.
Using these keys, you can also adjust the key
tone volume in idle mode with the handset open.
Note
: When a call comes in, you can mute the call
ringer by pressing and holding the or
key.
Accessing Options During a Call
Your phone provides a number of control
functions that you can use during a call.
Putting a Call on Hold
You can place the current call on hold whenever
you want. You can make another call while you
have a call in progress if your network supports
this service. Of these two calls, one is active and
the other is on hold and you can switch back and
forth between them.
To place a call on hold, simply press the
Hold
soft key. You can reactivate the call whenever
you want, by pressing the
Unhold
soft key.
Making a Second Call
To make a call while you have a call in progress:
1. Press the
Options
soft key.
2. Select
New call
and press the
OK
key.
3. Enter the phone number you want to dial and
press the key,
Call
soft key, or
OK
key to
make the second call.
Z107Eng_Vodafone.book Page 24 Friday, October 22, 2004 5:04 PM
Call Functions
25
The first call is automatically put on hold.
Note
: You can first enter a phone number and then
press the
Options
soft key. Then select the
New call
option.
Or alternatively:
1. Put the current call on hold by pressing the
Hold
soft key.
2. Make the second call in the normal way.
To switch between the two calls, simply press the
SWAP
soft key. The current call is placed on hold
and the call on hold is reactivated so that you can
continue conversing with the other person.
To end the current call, press the key. The
call on hold is still on hold. To reactivate this call
press the
Unhold
soft key.
To end both calls at one time, close the folder, or
press the
Options
soft key and select
End calls
.
Answering a Waiting Call
You can answer an incoming call while you have
a call in progress, if this service is supported by
the network and you have activated the
Waiting
menu option; see page 100. Your phone alerts
you to an incoming call by sounding a call waiting
tone.
To answer a call while you have a call in
progress:
1. Press the
Accept
soft key.
2. In the select box, select
Accept
to answer
the incoming call. The first call is
automatically put on hold.
If you want to end the first call, select
End
active call
or
End held call
. Then you can
answer the incoming call.
3. To switch between the two calls, press the
SWAP
soft key.
To end the current call, press the key. The
call on hold is automatically reactivated.
To end both calls at one time, close the folder, or
press the
Options
soft key and select
End calls
.
Z107Eng_Vodafone.book Page 25 Friday, October 22, 2004 5:04 PM
Call Functions
26
Making a Conference Call
The Conference Call feature is a network service
that allows up to five people to take part
simultaneously in a call. You can make a
conference call by making or receiving another
call while you are on an active call.
Setting up the Conference Call
1. Call the first participant in the normal way.
2. Make a second call, referring to page 24.
OR
Answer a waiting call, referring to page 25.
3. To join the first participant to the conference
call, press the
Options
soft key and select
Join
using the Up and Down scroll keys.
4. Press the
OK
key.
5. To add a new person to the conference call,
repeat steps 2 to 4, as needed.
Holding a Private Conversation With One
Participant
To speak privately with one person during a
conference call:
1. Press the
Options
soft key and select
Split
.
Press the
OK
key.
2. Press the Up or Down scroll key to scroll to
the participant you want to split off and press
the
OK
key.
Now you can talk privately to that person. The
other participants can continue to converse
with each other.
You can switch between the conference call
and the split call by pressing the
SWAP
soft
key.
3. To return to the conference call, press the
Options
soft key and select
Join
. Press the
OK
key.
All the conference call participants can now
hear each other.
Z107Eng_Vodafone.book Page 26 Friday, October 22, 2004 5:04 PM
Call Functions
27
Removing One Participant
1. Press the
Options
soft key and select the
Drop
option. Press the
OK
key.
2. Press the Up or Down scroll key to scroll to
the participant you want to remove and press
the
OK
key.
The call ends with that participant, but you
can continue to talk to the other participants.
You can end the conference call by closing the
phone or pressing the key.
Searching Phonebook
You can search for a number in Phonebook
during a call.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Phonebook
and press the
OK
key.
3. Enter the first few letters of the name you
want to find.
For further details about entering text, see
page 32.
For further details about the Phonebook feature,
see page 56.
Sending a Text Message
You can send a text message during a normal call
or conference call. You can send the message to
other people as well as to your current call
participants.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Send text msg.
and press the
OK
key.
The list of all call participants appears.
3. Scroll to the person to whom you want to
send the message and press the
OK
key.
A check mark appears in front of the selected
person. Repeat this step as needed.
4. When you have finished selecting recipients,
press the
Options
soft key and select the
Write
option. Then press the
OK
key.
5. Write your message and press the
Options
soft key and select the
Send
option. Then
press the
OK
key.
For further details about entering text, see
page 32.
Z107Eng_Vodafone.book Page 27 Friday, October 22, 2004 5:04 PM
Call Functions
28
6. Enter any other phone number to which you
want to send the message.
If you want to add more numbers, press the
Down scroll key and enter a number. Repeat
as needed.
7. When you have finished entering the
numbers, press the
Options
soft key and
select the
Send
option. Then press the
OK
key.
For more information on the SMS feature, refer
to page 67.
Making a memo
You can make a memo during a normal call or
conference call.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Memo
and press the
OK
key.
3. Enter the memo. Use the Down scroll key to
move to the date field and then enter the
date.
4. When you have finished entering the memo,
press the
Options
soft key and select the
Save
option or press the
OK
key.
Or,
1. Enter the number(s).
2. Press the
Options
soft key.
3. Press the Up or Down scroll key to select
Save to memo
and press the
OK
key.
For further details about entering text, see
page 32.
Switching the Microphone Off (Mute)
You can temporarily switch your phone’s
microphone off, so that the person you are
talking to cannot hear you.
Example: You wish to say something to another
person in the room, but do not want
the calling party to hear you.
To switch the microphone off temporarily:
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Mute
and press the
OK
key.
Z107Eng_Vodafone.book Page 28 Friday, October 22, 2004 5:04 PM
Call Functions
29
The Mute icon ( ) appears on the display and
your party can no longer hear you.
To switch the microphone back on:
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Unmute
and press the
OK
key.
The Mute icon disappears.
Mute/Unmute Key Tones
You can turn the key tones off or on. If you select
Mute key tone
, your phone does not transmit
any key tones, which allows you to press keys
without hearing annoying key tones during a call.
Sending DTMF Tones
You can send a number to the person with whom
you are talking during a call. The number sent
will appear on the display of the other person’s
phone.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Send
DTMF
and press the
OK
key.
3. Enter the number you want to send and press
the
Send
soft key.
Using Video Call Features
When in a 3G (UMTS) service area, your phone
can make or receive video calls, allowing you to
see another person on the screen during a
conversation. The other person’s phone must
support the video call feature.
Note:
If the other person does not turn their
camera on, you will not be able to see him or
her. You can communicate only by voice.
Making a Video Call
1. In idle mode, enter a phone number to dial.
You can also use phone numbers in call
records.
Or,
Turn on the camera by pressing the Left soft
key.
Z107Eng_Vodafone.book Page 29 Friday, October 22, 2004 5:04 PM
Call Functions
30
2. Press the
V-Call
soft key.
When your call is connected, the other person
appears on the screen.
3. Use the
Show me
soft key to see the image of
yourself as the other person sees you.
4. Use the
Options
soft key to mute the sound
and/or disengage the Camera. You can
choose the functions you want to discontinue:
Voice, Camera(Video), Voice-Video all, or
Keytone.
Note
: The Video call service is a special feature of
the 3G (UMTS) network. You can make and
receive a video call when the 3G icon (
)
is displayed.
Receiving a Video Call
You can receive a video call the same as
receiving a normal call, except that you can see
the person on the screen.
See page 23 for details about answering a call.
Changing View Options
You can change the screen mode for video calls
to PIP (Picture-in-Picture). In the PIP mode, the
display has both a main and a sub-frame, so that
you can see yourself on the screen, as well as the
other person.
To change the screen mode, press the
View
soft
key until you see the desired status. The
following modes are available:
• See the other person only
•See yourself only
• See the other person in the main frame and
yourself in the sub-frame
• See yourself in the main frame and the other
person in the sub-frame
Turning Your Voice or Video On or Off
You can mute your voice or turn the video off
during a video call.
During a video call, press the
Options
soft key to
display the option list.
The following options are available:
Mute voice
: mutes your voice. The other person
can see you, but cannot hear you.
Z107Eng_Vodafone.book Page 30 Friday, October 22, 2004 5:04 PM
Call Functions
31
Turn off camera
: turns the camera off. The
other person can hear you, but cannot see you.
Turn off all
: mutes your voice and turns the
camera off. The other person cannot hear or see
you.
Mute keytone
: mutes your key tones.
Flip image
: turns the image on the display
upside down during video calls.
Quality control
: allows you to adjust the image
quality:
Normal
,
Good quality
, or
Good
motion
.
Good quality
emphasises the picture
quality and
Good motion
emphasises the frame
count.
Show (Hide) brightness
: displays or hides the
brightness control bar.
Effects
: allows you to change the colour tone of
the picture.
Sepia
,
Mono
,
Night
, and
Normal
are available.
Show (Hide) information
: shows or hides the
information bar on the screen which contains
information such as caller ID, call time, and mute
status. This option is preset at the factory to hide
so that
Show information
displays unless you
change it.
End call
: ends the video call.
Using the Headset
With the headset, you can make or answer a call
without holding the phone.
When you connect the headset to the jack on the
left side of the phone, the button on the headset
works as listed below:
To Press
redial the last call the button twice in idle
mode.
answer a call and hold the button.
end a call and hold the button.
Z107Eng_Vodafone.book Page 31 Friday, October 22, 2004 5:04 PM
32
Entering Text
You may need to enter text, when storing a name
in Phonebook, creating your personal greeting, or
scheduling events on your calendar.
Your phone has the following text input modes:
•
T9 mode
*
This mode allows you to enter words with only
one keystroke per letter. Each key on the
keypad has more than one letter. For example,
when you press the
5
key repeatedly, J, K, or L
may be displayed. The T9 mode automatically
compares your keystrokes with an internal
linguistic dictionary to determine the correct
word, thus requiring far fewer keystrokes than
the traditional ABC mode.
•
ABC mode
This mode allows you to enter letters by
pressing the key labelled with the letter you
want once, twice, three, or four times until the
letter is displayed.
•
Number mode
This mode allows you to enter numbers.
•
Symbol mode
This mode allows you to enter special
characters, like punctuation marks.
Changing the Text Input Mode
When you are in a field that allows characters to
be entered, the text input mode indicator appears
at the bottom of the display.
Example: When you write a memo, the following
screen displays:
* T9 is a registered trademark of Tegic Communications, Inc.
and is licensed under U.S. Patent 5,818,437/ 5,953,541/
6,011,554.
Text input mode
indicator
Z107Eng_Vodafone.book Page 32 Friday, October 22, 2004 5:04 PM
Entering Text
33
Shortcuts to the Text Input Modes
Using T9 Mode
To enter a word in T9 mode:
1. Start entering the word by pressing the keys
2
to
9
. Press each key only once for each
letter.
Example: To enter “hello” in the T9 mode,
press
4
,
3
,
5
,
5
and
6
.
The word you are entering appears on the
display. It may change with each key that you
press.
2. Enter the whole word before editing or
deleting any keystrokes.
3. If the word is correct, start entering the next
word. Otherwise, press the
0
key to display
alternative word choices for the keys that you
pressed.
Example: Both “of” and “me” have the
sequence of
6
and
3
. The phone
displays the most commonly used
choice first.
To select Press the Right soft key until
T9 mode displays. See page 33.
The letter after T9 indicates
which language you are using.
ABC mode displays. See page 34.
Number mode displays. See page 36.
Symbol mode displays. See page 36.
To switch between the Press and hold the
Number and previous
mode key.
Symbol and previous
mode key.
Z107Eng_Vodafone.book Page 33 Friday, October 22, 2004 5:04 PM
Entering Text
34
4. Put a space between words by pressing the
key.
5. Continue entering any other words in T9
mode.
If
Spell
appears above the left soft key while you
are entering text, the word does not exist in the
T9 dictionary. To type words not found in the T9
mode, change the text input mode to ABC mode,
or proceed as follows:
1. Press the
Spell
soft key.
2. Enter the word you want to add using ABC
mode (see page 34) and press the
Add
soft
key.
The word is saved in the T9 dictionary and
inserted in the input field.
3. Continue entering other words in T9 mode.
Smart Punctuation
To enter periods, hyphens, or apostrophes, press
the
1
key. T9 mode applies rules of grammar and
inserts the correct punctuation.
Changing Case
To change the case of the next letters that you
type, press the key. There are three cases:
•Initial Capital ( )
• Capital Lock ( )
•Lower Case ( )
Scrolling
To move the cursor to the left or right within the
text, press the Left or Right scroll key.
Clearing Letters and Words
To delete letters, press the
C
key when the
cursor is immediately to the right of the letter
you want to delete. Press and hold down the
C
key to clear the display.
Note
: If there are no letters entered and you press
the
C
key, you will return to the previous
screen.
Using ABC Mode
When entering letters in ABC mode, press the
key labelled with the letter you want:
Z107Eng_Vodafone.book Page 34 Friday, October 22, 2004 5:04 PM
Entering Text
35
- Once for the first letter
- Twice for the second letter
- And so on
Example: To display the letter “c”, quickly press
the
2
key three times. To display the
letter “k”, press the
5
key twice. For
this reason, this method is called
Multi-tap typing.
The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait a few seconds for the cursor to
automatically move to the right, or press the
Right scroll key and then enter the next letter.
Refer to the table below for more information
about available characters.
Note
: When you write a text message and you
select the
GSM alphabet
option in
Character support
(see page 79), the
following GSM alphabet characters are
available:
Changing Case
To change the case of the next letters that you
type, press the key. There are three cases:
•Initial Capital ( )
• Capital Lock ( )
•Lower Case ( )
Inserting a Space
To insert a space between words, press the
key.
Z107Eng_Vodafone.book Page 35 Friday, October 22, 2004 5:04 PM
Entering Text
36
Scrolling
To move the cursor to the left or right within the
text, press the Left or Right scroll key.
Clearing Letters and Words
To delete letters, press the
C
key when the
cursor is immediately to the right of the letter
you want to delete. Press and hold the
C
key
down to clear the display.
Note
: If there are no letters entered and you press
the
C
key, you will return to the previous
screen.
Using Number Mode
You can enter numbers in Number mode. Press
the keys corresponding to the required digits.
Using Symbol Mode
You can insert symbols into a text message. The
text message you’ve entered is shown in the
symbol entering field. Move the cursor to where
you want to enter a symbol using the Left or
Right scroll key.
To Press the
display more
symbols Up or Down scroll key.
select a symbol corresponding number
key. The selected symbol
displays in the input box.
clear a symbol from
the input box
C
key.
incorporate the
selected symbol(s)
into your message
as shown
OK
key or Right soft key.
Z107Eng_Vodafone.book Page 36 Friday, October 22, 2004 5:04 PM
37
Using Menu Functions
Your phone offers a range of functions that allow
you to tailor the phone to your needs. These
functions are arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling using the scroll keys or by using the
shortcuts.
Accessing a Menu Function by
Scrolling
1. In idle mode, press the
OK
key to access the
menu.
2. Scroll using the scroll keys to reach the
required application menu. Press the
OK
key
to enter the menu.
3. If the menu contains sub-menus, you can
access them by scrolling using the Up and
Down scroll keys and pressing the
Select
soft
key.
If the menu that you have selected contains
further options, repeat the same procedure.
4.
To Press the
scroll through
the menus Up or Down scroll
key.
confirm the
chosen setting
Select
or
Save
soft
key or the
OK
key.
return to the
previous menu level
Back
soft key.
exit the menu without
changing
the settings
key or the
Back
soft key, if
available.
Z107Eng_Vodafone.book Page 37 Friday, October 22, 2004 5:04 PM
Using Menu Functions
38
Example: Changing the Language
Display
1. When the idle screen is displayed, press the
OK
key to access the menu.
The startup screen of the
Messages
menu is
highlighted by default.
2. Scroll through the menus by pressing the
scroll keys until you reach the
Settings
menu. To access the
Settings
menu, press
the
OK
key.
3. To access the
Phone
menu, press the
Select
soft key or
OK
key.
4. Scroll through the sub-menus by pressing the
Up or Down scroll key, then use either the
Select
soft key or the
OK
key to choose your
language.
Z107Eng_Vodafone.book Page 38 Friday, October 22, 2004 5:04 PM
Using Menu Functions
39
5. Press the
OK
key when Screen Text is
highlighted.
6. Scroll through the list of languages by
pressing the Up or Down scroll key until the
appropriate one is highlighted. Press the
Select
soft key or the
OK
key.
7. Press the
Save
soft key to save the setting in
the Language screen. Otherwise press the
Back
soft key.
8. Press the key to exit the menu.
Shortcuts to Menu Functions
Some menus, sub-menus, and options can be
quickly accessed by using their shortcut
numbers. Simply press the
OK
key and enter the
number.
Note
: The numbers assigned to each menu option
are indicated on the list on the following
pages. They may not match the menu
numbers on the phone, depending on the
services supported by your SIM card.
Example: Accessing the
Language
menu option.
1. Press the
OK
key.
2. Press for
Settings
.
3. Press for
Phone
.
4. Press for
Language
.
Z107Eng_Vodafone.book Page 39 Friday, October 22, 2004 5:04 PM
Using Menu Functions
40
List of Menu Functions
The following list shows the menu structure and
indicates the:
• number assigned to each option
• page on which you can find a description of
each feature
1. Applications
(see page 42)
2. Call log
(see page 53)
2.1 Missed calls
2.2 Dialled calls
2.3 Received calls
2.4 All calls
2.5 Data calls
2.6 Call costs
2.7 Call times
3. Phonebook
(see page 56)
3.1 Search contact
3.2 New
3.3 Groups
3.4 Speed dial
3.5 My name card
3.6 Copy all to phone
3.7 Memory status
4. Internet
(see page 63)
5. Messages
(see page 67)
5.1 Write
5.1.1 Short msg.
5.1.2 Multimedia msg.
5.1.3 File messenger
5.1.4 Email
5.2 Inbox
5.3 Email box
5.4 Outbox
5.5 Drafts
5.6 Templates
5.7 Delete all
5.8 Settings
5.8.1 Short msg.
5.8.2 Multimedia msg.
5.8.3 Email
5.8.4 Voice mail
5.9
Memory status
6. My Items
(see page 83)
Z107Eng_Vodafone.book Page 40 Friday, October 22, 2004 5:04 PM
Using Menu Functions
41
7. Organiser
(see page 87)
7.1 Calendar
7.2 Today’s events
7.3 Schedule
7.4 Anniversary
7.5 Task list
7.6 Memo
7.7 Missed event alarm
8. Profiles
(see page 92)
9. Settings
(see page 94)
9.1 Phone
9.1.1 LCD brightness
9.1.2 Backlight
9.1.3 Ext. light
9.1.4 Language
9.1.5 Shortcuts
9.1.6 Active folder
9.1.7 Anykey answer
9.1.8 Infrared
9.2 Display
9.2.1 Greeting message
9.2.2 Wallpaper
9.2.3 Cover LCD
9.2.4 Main menu style
9.3 Call
9.3.1 Caller ID
9.3.2 Diverting
9.3.3 Barring
9.3.4 Waiting
9.3.5 Auto redial
9.3.6 Closed user group
9.4 Video call
9.5 Network
9.5.1 Network selection
9.5.2 Network mode
9.6 Connections
9.7 Security
9.7.1 Phone lock
9.7.2 SIM lock
9.7.3 PIN lock
9.7.4 Fixed dialling mode
9.7.5 Change phone password
9.7.6 Privacy lock
9.7.7 Change PIN code
9.7.8 Change PIN2 code
9.8 Date & time
9.9 Own number
9.0 Memory status
9.
Reset settings
Z107Eng_Vodafone.book Page 41 Friday, October 22, 2004 5:04 PM
42
Applications
Using the
Applications
menu, you can use
popular applications, alarms, and Java programs
such as games.
Using Applications
1. Press the Left or Right scroll key to select an
application folder,
Basic
,
Alarm
, or
Games
& more
.
2. Press the Up or Down scroll key to select an
application.
3. Press the
OK
key to start the application.
Note
: For
World Clock
,
Calculator
, and
Converter
in the
Basic
folder, and the
Alarm
application, please refer to the
corresponding application pages. See
page 50 and page 51 respectively.
SIM Applications
In this menu, you can use several applications
provided by the default settings on your SIM
card.
Camera/Video recorder
Using the camera module built into your phone,
you can take pictures or record videos of people
or events. Additionally, you can send the images
to other people in a multimedia message.
When the camera turns on, you can dial a
number to make a video call; for further details
about using the video call feature, see page 29.
Z107Eng_Vodafone.book Page 42 Friday, October 22, 2004 5:04 PM
Applications
43
Taking a Picture
1. To turn on your camera, press the Left soft
key in idle mode.
You can see the picture to be taken on the
display.
2. Point the camera at the subject, rotating the
camera if necessary.
To flip the picture, press the Up or Down
volume key on the left side of the phone. Up
flips the picture upside down, while Down flips
the picture left to right, as a mirror image.
3. Press the
OK
key. Or, press the
Options
soft
key and press the
OK
key when
Take
is highlighted to take a picture.
4. The photo is saved automatically and then
When you press the
Options
soft key in Step 4,
the following options are available:
Viewfinder
: switches the screen to capture view
mode to allow you to take another picture.
Send
:
•
As multimedia msg.
: allows you to send the
picture as a multimedia message. For further
details about sending multimedia messages,
see page 68.
•
As email
: allows you to send the picture as an
e-mail.
To Press the
use the options
Options
soft key.
For details about
available options, see
below.
delete the image file
Delete
soft key.
return to capture
mode
OK
key.
turn the camera off
and return to idle
mode
key.
The photo is saved
automatically.
Z107Eng_Vodafone.book Page 43 Friday, October 22, 2004 5:04 PM
Applications
44
•
Via file sender
: allows you to send a message
with the picture attached.
Set as wallpaper
: allows you to set the picture
as wallpaper.
Set as caller ID
: allows you to use the image as
a caller ID indicator to be displayed when a call
comes in from a contact.
My photos
: allows you to move to the
Photos
folder in
My Items
. You can see the picture in
the
Photos
folder; see page 84.
Rename
: allows you to change the image file’s
name. For more information about entering
characters, see page 32.
Camera Mode Options
Press the
Options
soft key in camera mode:
Take picture
: takes a picture.
Record video
: turns to video recording mode.
My photos
: allows you to move to the
Photos
folder in
My Items
.
Multi shot
: takes a rapid series of pictures (from
3 -10).
Flip image
: select
Up-down
for flipping
vertically,
Left-right
for flipping horizontally.
Scroll to the item you want to flip and place a
check mark ahead of it by pressing the
OK
key.
Timer
: sets the phone to take a picture after a
predefined delay. Once you have set the time,
the timer icon appears at the bottom of the
screen. When you press the
OK
key, the phone
takes a picture after the predefined time has
elapsed.
Effects
: allows you to change the colour tone of
the picture.
Sepia
,
Mono
,
Night
, and
Normal
are available.
Brightness
: adjusts the brightness of the
picture.
Camera settings
:
Default name: allows you to define a default
name of your choice.
Capture quality: allows you to adjust the quality
between
Low
,
Normal
,
Fine
, or
Super fine
.
You can also select
Memory Save
. The
Memory
Save
option gives you a lower quality image, but
takes up less memory space.
Z107Eng_Vodafone.book Page 44 Friday, October 22, 2004 5:04 PM
Applications
45
Flash mode : allows you to set the camera flash
to be either always on or to be turned on
manually.
•
Automatic
: when you take a picture, the flash
will light.
•
Manual
: to switch the camera flash on or off,
you have to press the Up key in the Navigation
key in capture mode. The flash goes on. When
you have taken a picture the flash goes out.
Recording a Video
You can use your phone just like a camcorder to
record what is currently displayed on the camera
screen and save it as a video file.
1. To turn on your camera, press the Left soft
key.
2. When you are in camera mode, press the
Options
soft key and then select
Record
video
.
You can see the picture to be recorded on the
display.
3. Press the
Options
soft key. Select
Record
by
pressing the Up or Down scroll key and press
the
OK
key.
4. Your phone starts recording. Maximum
recording time is 30 seconds.
5. While recording video:
To Press the
pause recording
Pause
soft key.
resume paused
recording
Record
soft key.
stop recording
Stop
soft key. The
video is automatically
saved in the
Videos
folder.
use the options
Options
soft key. For
details about
available options, see
below.
delete the video file
Delete
soft key.
return to recording
mode
OK
key.
turn the camera off
and return to idle
mode
key.
Z107Eng_Vodafone.book Page 45 Friday, October 22, 2004 5:04 PM
Applications
46
6. When the recording time expires, the phone
automatically saves the video in the
Videos
folder in
My Items
; see page 85.
When you press the
Options
soft key in steps 4
and 5, the following options are available:
Viewfinder
: switches the screen to view finder
mode to allow you to take another video.
Play file
: allows to open a file from the
Videos
folder in
My Items
.
Send
•
As multimedia msg.
: allows you to send the
video as part of a multimedia message. For
further details about sending multimedia
messages, see page 68.
•
As email
: allows you to send the video as part
of an e-mail.
•
Via file messenger
: allows you to send a
message with the video attached.
My photos
: moves you to the
Videos
sub folder
in
My Items
.
Rename
: allows you to change the image file’s
name.
Video Mode Options
Press the
Options
soft key in the video mode:
Record
: records a video.
Take picture
: changes to camera mode.
My videos
: You can open stored video files.
Flip image
: select
Up-down
for flipping
vertically,
Left-right
for flipping horizontally.
Scroll to the item you want to flip and place a
check mark next to it by pressing the
OK
key.
Brightness
: adjusts the brightness of the video.
Video settings
: allows you to define a default
name of your choice and to adjust the quality
from
Very low
,
Normal
,
High
, or
Very high
. It
also allows you to set recording time. If you
select the
For message
option in the
Recording
time
box, you can send video files of large
capacity and the quality is fixed at
Normal
.
Z107Eng_Vodafone.book Page 46 Friday, October 22, 2004 5:04 PM
Applications
47
Media Player
Media Player
plays audio and video files you
download or stream to the phone. You can listen
to music or watch a movie with Media Player.
Media Player
is used when:
• you view a media file in the
My Items
menu.
• you want to play a sound file or a video in the
browser.
Playing a File using Media Player
1. On the Media Player screen, press the
Options
soft key.
2. Scroll to
Open play list
and press the
OK
key.
The screen displays files available in Media
Player.
3. Press the Up or Down scroll key to select the
file you want to play and press the
OK
key or
the
Select
soft key.
The selected audio or video file plays on
Media Player.
When the control bar is shown, you can scroll to
the different control buttons by pressing the Left
or Right scroll key and press the
OK
key to select
the button.
: plays or resumes (if paused).
4.
To Press the
pause
OK
key.
resume playing
OK
key again.
stop playing
Stop
soft key.
adjust the volume
level volume keys.
exit Media Player
Back
soft key.
Z107Eng_Vodafone.book Page 47 Friday, October 22, 2004 5:04 PM
Applications
48
: stops playing.
: pauses playing.
: rewinds when you press and hold the
OK
key. Plays when you release the
OK
key.
: fast forwards when you press and hold the
OK
key. Plays when you release the
OK
key.
When you press the
Options
soft key while a file
is playing, the following options are available:
Play
: resumes playing.
Stop
: stops playing.
Pause
: pauses playing.
Open play list
: allows you to open another file
or make a list of files you want to play.
Open file
: You can open stored video files.
Hide/Show controller
: hides or displays the
Media Player control bar.
Player settings
: allows you to change Media
Player settings. For further details, see below,
“Setting up Media Player”.
VOD settings
: sets the network access point for
the VOD (Video On Demand) service.
Setting up Media Player
You can set several options for playing audio or
video files on Media Player.
1. On the Media Player screen, press the
Options
soft key.
2. Press the Up or Down scroll key to scroll to
Player settings
and press the
OK
key.
3. Press the Up or Down scroll key to scroll
through the options. You can select the
desired setting using the Left and Right scroll
keys.
•
Repeat
: allows you to set Media Player to
repeat either all files or only a single file.
Selecting
None
means that the file is
played just once.
•
Play order
: allows you to set the order to
Random
or
Normal
.
•
Volume
: allows you to adjust the volume
level. This option is available only when you
have already opened a file.
Z107Eng_Vodafone.book Page 48 Friday, October 22, 2004 5:04 PM
Applications
49
•
Hide controller
: hides the Media Player
control bar when you place a check mark
next to this option by pressing the
OK
key.
If you want the control bar to show again,
remove the check mark by pressing the
OK
key.
Voice Memo
You can record sound files or listen to recorded
sound files.
Press the Up or Down scroll key to control the
volume.
Press the Left or Right scroll key to move through
the buttons and press the
OK
key to select one.
: starts or resumes recording.
: pauses recording.
: stops recording and saves the file.
: plays the file.
: rewinds the file.
: fast forwards through the file.
Press the
Options
soft key to use the following
options.
Record
: starts recording.
Open files
: opens a sound file.
Send
: allows you to send the sound file as a
multimedia message or e-mail. For further
details about sending a message, see page 68.
Record settings
: allows you to set the
recording file name and maximum recording
time.
Z107Eng_Vodafone.book Page 49 Friday, October 22, 2004 5:04 PM
Applications
50
World Clock
You can check the time difference between your
city and a selected city.
1. Select the city corresponding to your time
zone by pressing the Left or Right scroll key.
The screen shows the current time and date
of several cities in the same time zone.
2. Press the Down key and select another city
and its corresponding time zone by pressing
the Left or Right scroll key.
Press the
Options
soft key to use the following
options.
Save
: allows you to save the setting.
Summer time
: allows you to use daylight
savings time.
Calculator
You can use the phone as a 14-digit calculator.
The calculator performs basic mathematical
functions: addition, subtraction, multiplication,
and division.
1. Enter the first figure using the number keys.
To enter a decimal point, press the key.
You can make a number negative by pressing
the Left scroll key after entering the number.
2. Press the appropriate scroll key to select your
calculation.
3. Enter the second figure.
4. Press the
OK
key to get the result.
Press the
Options
soft key to use the following
options:
Recent calculation
: shows the last calculation
result.
Recent calculation will not appear if a calculation
has never been performed on your phone.
Save to memory
: saves the current digit or
result to memory.
Recall memory
: recalls the saved digit.
Clear memory
: clears the memory.
Z107Eng_Vodafone.book Page 50 Friday, October 22, 2004 5:04 PM
Applications
51
Recall memory and Clear memory appear only
when values have been stored in the memory.
Converter
You can convert one type of unit to another.
Scroll to the type of conversion to be performed
from
Currency
,
Length
,
Weight
,
Volume
,
Area
, and
Temperature
, and press the
OK
key.
1. Select the units to be converted by pressing
the Left or Right scroll key.
2. When you enter the value to be converted,
you can see the corresponding value of each
unit.
Note
: You can enter a decimal point (
.
) by
pressing the key. You can also enter
(-) by pressing the key, but only for
Temperature
.
On the conversion screen, press the
Options
soft
key to use the following options:
Clear
: clears the current values.
Reverse
: reverses the conversion.
Currency rates
: sets the currency rates.
To change currency rates:
1. Select the base currency by pressing the Left
or Right scroll key.
2. Scroll to another currency by pressing the Up
or Down scroll key and edit the rates.
3. Press the
Options
soft key and select the
Save
option to save the rate.
To clear the rates for all currencies, select the
Clear all
option.
To return to the previous screen without
changing the rate, press the
Back
soft key.
Alarm
You can set alarms to ring at specific times.
To set an alarm:
1. Select the type of alarm from among
Once
alarm
,
Daily alarm
, or
Wake up alarm
.
2. Set
On
by pressing the Left or Right scroll
key.
Z107Eng_Vodafone.book Page 51 Friday, October 22, 2004 5:04 PM
Applications
52
3. Move to the time field by pressing the Down
scroll key and enter the time for the alarm to
sound.
4. (Only for the Wake up alarm) Move to the
repeat field by pressing the Down scroll key
and select the repetition type from among
None
,
Every day
,
Except weekend
, or
Except Sunday
.
5. Move to the alert tone field by pressing the
Down scroll key. After pressing the
OK
key,
you can select an alarm melody
6. Press the
Save
soft key to save it.
Note
: When the Call alter type is not set to Melody
or Vib&melody, the alarm tone will not sound
except for the Wake up alarm.
To deactivate an alarm:
1. Select the type of alarm from among
Once
alarm
,
Daily alarm
, or
Wake up alarm
.
2. Set
Off
by pressing the Left or Right scroll
key.
Press the
Save
soft key to save the change.
To turn off the Wake up alarm:
• Press the
OK
soft key or key.
• When the Wake up alarm tone sounds, press
the
Snooze
soft key to stop the alarm for five
minutes, after which it will resume. You can do
this a maximum of five times.
Games & More
In this menu, you can play the games which
came pre-installed on your phone. You can also
download new games that are compatible with
your phone.
Z107Eng_Vodafone.book Page 52 Friday, October 22, 2004 5:04 PM
53
Call Log
In this menu, you can view:
• missed, dialled, and received calls, or all calls
•cost of your calls
• length of time of calls you have made or
received
Notes:
• You can access the all calls list by pressing the
key in idle mode.
• When you are not calling, but using a headset
with the phone is closed, you can see the call
log on the sub LCD by pressing the headset
button. You can also scroll through the log by
pressing the volume keys on the left side of
the phone.
Missed, Dialled, Received, or All
Calls
(Menu 2-1~4)
1. From the Call log screen, press the Left or
Right scroll key to scroll to the type of calls
you want to view.
Each time you press the key, a list of the
various call records appears. Your phone
records up to the last 20 calls in each log.
If the number is saved in Phonebook, the
corresponding name displays.
2. Press the Up or Down scroll key to select the
call you want to view.
When you press the
Options
soft key in the call
log list, the following options are available:
Details
: shows detailed information about the
call.
Save to contact
: allows you to save the number
in Phonebook.
V-Call
: allows you to make a video call to the
number.
3.
To Press the
dial the number key.
return to idle mode key.
Z107Eng_Vodafone.book Page 53 Friday, October 22, 2004 5:04 PM
Call Log
54
Send message
: allows you to send to the
number either a text message, a multimedia
message, or a message with media attached.
Delete
: deletes the call.
Delete all
: deletes all of the call records stored
in the current call log.
Data Calls
(Menu 2-5)
You can see the total size of sent and received
data calls. Data calls include:
• sending and receiving multimedia messages
• sending and receiving e-mail
• browsing WAP pages
• downloading MIDlets (Java applications that
run on mobile phones)
• using your phone as a modem.
Press the
Options
soft key to use the following
options:
Reset
: clears the selected data call log.
Reset all
: clears all of the data call logs.
Call Costs
(Menu 2-6)
This feature lets you view the cost of calls.
Notes
:
• This feature may not be shown depending on your
SIM card.
• This feature is not intended to be used for billing
purposes.
• AOC (Advice Of Charge) information may display
on call, depending on your SIM card or service
provider.
1. The Call Costs screen shows you the total
cost, last call costs, and cost limit.
2. While viewing the call costs, press the
Options
soft key to use the following
options:
•
Reset call costs
: allows you to reset the
cost counter; first, you must enter your
PIN2 code (see page 112) and then press
the
Confirm
soft key.
•
Edit cost limit
: allows you to enter the
maximum cost that you authorise for your
calls; first, you must enter your PIN2 code
(see page 112) and then press the
Confirm
soft key.
Z107Eng_Vodafone.book Page 54 Friday, October 22, 2004 5:04 PM
Call Log
55
•
Setup currency
: allows you to set the
currency of the call cost; first, you must
enter your PIN2 code (see page 112) and
then press the
Confirm
soft key.
Call Times
(Menu 2-7)
1. Press the Up or Down scroll key to scroll
through the call timer for each call type.
•
Total dialled
: total time of the voice
calls you have dialled.
•
Total received
: total time of the voice
calls you have received.
•
Total dialled
: total time of the video
calls you have dialled.
•
Total received
: total time of the video
calls you have received.
2. While viewing the call time, press the
Options
soft key to use the following options:
•
Reset
: resets the call timer.
•
Reset all
: resets all of the call timers.
Note
: The actual time invoiced by your service
provider may vary, depending on network
features, rounding-off for billing purposes,
and other factors.
Z107Eng_Vodafone.book Page 55 Friday, October 22, 2004 5:04 PM
56
Phonebook
You can create a phonebook by saving phone
numbers and names. Your phone gives you an
easy way to make calls simply by using numbers
and names you have stored in your phonebook.
Search Contact
(Menu 3-1)
When you access this menu, the Search contact
screen displays.
Enter the first few letters of the name you want
to search for. The contact entries are listed
alphabetically, starting with those that most
closely match your input.
1. If necessary, press the Up or Down scroll key
to find the contact you want.
When you press the
Options
soft key from the
Phonebook list, the following options are
available:
Details
: shows detailed information about the
contact. For more information, see page 59.
Add new contact
: adds a new contact to the
phone or SIM. For more information about
adding a contact, see page 57.
Edit
: allows you to edit the name or number of
the contact.
Delete
: deletes the selected contact.
Video call
: makes a video call to the person. For
further details, see page 29.
Search groups
: searches groups, see page 60.
Service number
: select a number from the
service number list and press the
Call
soft key to
call. This option may not display depending on
your SIM card.
Delete all
: displays the memory locations,
Phone & SIM, Phone, and SIM, from which
contacts can be deleted. All contacts in the
selected memory location(s) will be deleted.
2.
To Press the
dial the number key.
view details of the
contact.
OK
key.
Z107Eng_Vodafone.book Page 56 Friday, October 22, 2004 5:04 PM
Phonebook
57
Select the
Yes
soft key to delete the contents of
the selected memory; otherwise select the
No
soft key.
New
(Menu 3-2)
You can add to your phonebook by saving phone
numbers and the corresponding names in the
memories of your SIM card and phone. You can
save up to 1000 names in the phone’s memory.
Each name can have up to five numbers, and
other personal information.
When you add a new contact, you have to select
the memory location by pressing the Up and
Down scroll key in the input box.
Adding a Contact to the Phone’s
Memory
When you access this menu, you will see the
startup screen of the Add contact menu. You can
also access this screen by pressing the
Add
soft
key in main menu mode.
1. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save:
•
First Name
/
Last Name
: enter the first
and the last name of the contact. For
further details about entering characters,
see page 32.
•
Mobile
()/
Home
()/
Work
()/
Fax
()/
Etc.
( ): enter the number you
want to add in the appropriate input box.
•
Email
: enter the person’s e-mail address.
•
Group
: press the
OK
key to add the person
to a group.
•
Homepage
: enter the URL address of the
person’s home page.
•
Memo
: enter information you need to
remember about the person.
2. When you have entered the information you
want, press the
Options
soft key and select
the
Save
option.
Z107Eng_Vodafone.book Page 57 Friday, October 22, 2004 5:04 PM
Phonebook
58
Adding a Contact to the USIM Card
1. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save:
•
Name
: enter the name of the contact. For
further details about entering characters,
see page 32.
•
Phone number
/
Additional phone
number
: enter the phone number you want
to add.
•
Email
: enter the person’s e-mail address.
•
Group
: press the
OK
key to add the person
to a group.
2. Press the Down scroll key to move to the
location number input box and modify a
number, if you want.
3. Press the
Options
soft key and select
Save
option.
Adding a Contact to the SIM Card
1. Enter the name of the contact.
2. Press the Down scroll key to move to the
Phone number
input box and enter a
number.
3. Press the Down scroll key to move to the
location number input box and modify a
number, if you want.
4. Press the
Save
soft key.
Adding a Contact from Idle Mode
1. In idle mode, enter the number to be stored.
2. Press the
Options
soft key and press the
OK
key when
Save contact to
highlights.
3. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save.
The input boxes available depend on the
memory type you select in the memory
setting. Refer to the previous pages for
subsequent steps.
Z107Eng_Vodafone.book Page 58 Friday, October 22, 2004 5:04 PM
Phonebook
59
Other Options for Phone memory type
when Adding Phonebook List
When you press the
Options
soft key from the
Phonebook list, the following options are
available:
Save
: saves a contact.
Special options
: you can set a distinctive image
and sound for a contact. Press the Up or Down
scroll key to move to each field.
•
: allows you to select an image to be
displayed when a call or message comes in
from the contact. Press the
OK
key. You can
select from icon, animation, and photo, and
then choose a file from
My Items
.
•
Ring tone
: allows you to set a sound to be
played when a call comes in from the contact.
Press the
OK
key and select an audio file from
My Items
.
•
Msg. alert tone
: allows you to select a sound
to be played when a message comes in from
the contact. Press the
OK
key and select a
sound file from
My Items
.
After changing the options, press the
Options
soft key and select
Save
. If you want to decline
the changes and return to the default settings,
select
Reset
.
Add item
: allows you to add another contact
number. Select one of the types, then add the
number.
Delete item
: deletes the selected contact item
which you’ve added using the
Add item
option.
Change type
: changes the contact type of the
selected contact item. Select one of the types.
Mark/Unmark video call
: activates or
deactivates a video call to the selected contact
number item.
Viewing Contact Information
You can access the details
of a contact in the phone’s
memory and SIM by
pressing the
OK
key on the
Contact list.
Z107Eng_Vodafone.book Page 59 Friday, October 22, 2004 5:04 PM
Phonebook
60
When you press the
Options
soft key, the
following options are available:
Edit
: allows you to edit the selected number and
name.
Send message
: allows you to send a message
to the contact. You can write a text message,
create a multimedia message, or write a
message to which you attach a media file using
file sender. For more information about sending a
message, see page 68.
Special options
: you can set a distinctive image
and sound for the contact. Press the Up or Down
scroll key to move to each field.
Video call
: allows you to make a video call to
the person. For further details, see page 29.
Copy to SIM/phone
: copies the contact to the
SIM or to the phone.
Send name card
: allows you to send a name
card as a text message or as an e-mail, via file
sender or infrared.
Paste
: allows you to paste the selected number
into the normal dialling mode.
Delete
: deletes the selected contact.
Groups
(Menu 3-3)
You can manage groups. The Phonebook stored
in the phone’s memory or supplied by the USIM
card can be assigned to contact groups.
Editing Groups from the Group List
1. When the Group list displays, if necessary
press the Up or Down scroll key to scroll
through the Group list to the Group you want.
To Press the
enter
OK
key
scroll through the
items Up or Down scroll key.
dial the selected
number key.
save changes after
editing information
OK
key after editing each
item.
return to the
Phonebook list
Back
soft key or
C
key.
Z107Eng_Vodafone.book Page 60 Friday, October 22, 2004 5:04 PM
Phonebook
61
2. Press the
Options
soft key from the Group
list to access the following options:
•
View members
: views the Phonebook list
saved for this group.
•
Add group
: you can enter a group name
for a new group. You can see the new group
name in the Group list.
•
Rename group
: allows you to change the
group name.
•
Delete group
: deletes the selected group.
•
Delete all groups
: deletes all of the
groups.
Editing Group Items
1. When you select a group, you can see the list
of names enrolled in the group.
2. If necessary press the Up or Down scroll key
to scroll through the name list.
3. Press the
Options
soft key to access the
following options:
•
Details
: allows you to view detailed
information about the selected member.
•
Edit group
: allows you to change members
in the group. Mark and unmark names you
want to add or delete using the
OK
key and
press the
Save
soft key.
Speed Dial
(Menu 3-4)
You can set up to eight speed dial numbers and
then dial them simply by pressing the associated
number key.
Editing Speed Dial from the Speed Dial
List
1. When the Speed Dial list displays, highlight
the Speed dial number you want to edit by
pressing the scroll key.
2. Press the
Options
soft key to access the
following options:
•
Assign
: allows you to add a speed dial
number at an empty slot.
•
Details
: allows you to view detailed
information about the selected speed dial
entry, for example, the image and phone
number of the contact.
Z107Eng_Vodafone.book Page 61 Friday, October 22, 2004 5:04 PM
Phonebook
62
•
Change
: allows you to change one entry
into another.
•
Remove
: allows you to clear the selected
speed dial number.
My Name Card
(Menu 3-5)
You can store personal information, such as your
first and last name, wireless phone number,
home number, office number, fax number, e-
mail, URL, memos, etc.
Press the
Options
soft key to access the
following options:
Save
: saves your information.
Add item
: allows you to add another contact
number. Select one of the types then add the
number.
Delete item
: deletes the contact item which
you’ve added using the
Add item
option.
Change type
: changes the selected contact
item’s type. Select one of the types.
Copy All to Phone
(Menu 3-6)
You can copy all of the Phonebook stored in the
SIM card to the phone memory. When a
confirming message appears, press the
Yes
soft
key to copy. Otherwise, press the
No
soft key.
Memory Status
(Menu 3-7)
You can check how many contact items are
stored in the phone or SIM memory.
You can see the number of existing and
remaining available entries in the SIM card or
phone memory.
Z107Eng_Vodafone.book Page 62 Friday, October 22, 2004 5:04 PM
63
Internet
Using the built-in WAP (Wireless Application
Protocol) browser you can now access the
Wireless Web at faster speeds than with non-3G
phones.
You can download and play the latest music,
streaming videos, polyphonic ringtones, and
mobile games. You can send and receive Instant
Message, and get the latest news and sports
results.
Each time you start the Internet, the or
icon animates to inform you that you are
connected to the Wireless Web. You will be billed
accordingly. Rates vary according to your service
option.
Launching the Browser
1. Access the
Internet
menu.
2. A connection is established with your service
provider and the internet homepage displays.
3. To scroll through the screen, use the scroll
keys.
Closing the Browser
To exit the browser, simply press the key at
any time.
Using the Browser
To Press the
scroll through
browser items scroll keys.
scroll up or down
pages volume keys
select the item
highlighted
OK
key.
select a numbered
item corresponding numeric
key.
Z107Eng_Vodafone.book Page 63 Friday, October 22, 2004 5:04 PM
Internet
64
Entering Text in the Browser
When prompted, you can enter letters, numbers,
or symbols the same way as you would when
using the phone in other ways. See page 32 for
more information about entering characters.
Using the Browser Menus
In the browser, press the
Options
soft key to
use the following options:
Reload page
: reloads the current page with
updated information.
Go to URL
: allows you to manually enter the
URL address of the web page you want to access.
View bookmarks
: shows you the bookmark list.
Save image
: saves the image of the current
page.
Settings
: allows you to change the settings for
connecting to the Wireless Web. For further
details, see page 66.
Empty cache
: clears information stored in the
cache, which is the phone’s temporary memory
used to store the most recently accessed web
pages. After you have accessed confidential
information requiring passwords like your bank
account, you need to empty the cache. When a
warning message appears, press the
Yes
soft
key to clear the information.
Disconnect
: disconnects from the network.
History
: shows URLs previously visited.
Using Bookmarks
Bookmarks save you time by reducing the
number of steps it takes to access a web page.
You can bookmark many individual pages for
easy access at a later time.
return to the
previous page
Back
soft key, or press
the
Options
soft key
and select
History
.
return to the startup
homepage
Options
soft key and
select
Go to
homepage
.
To Press the
Z107Eng_Vodafone.book Page 64 Friday, October 22, 2004 5:04 PM
Internet
65
Bookmarking a Web page
1. Go to the page that you want to bookmark
and press the
Options
soft key.
2. Scroll to
Add bookmark
and press the
OK
key.
3. Enter the title for the bookmark and press the
Save
soft key.
Accessing a Bookmarked Web Page
1. Press the
Links
soft key on the startup
screen of the Internet menu.
Or,
Press the
Options
soft key on any web page.
Scroll to
View bookmarks
and press the
OK
key.
2. Scroll to a bookmark item and press the
OK
key.
Using Bookmark Options
On the bookmark list, press the
Options
soft key
to use the following options:
Go to
: allows you to access the corresponding
web page.
Go to homepage
: sends you back to the home
page.
Go to URL
: allows you to manually enter the
URL address of the web page you want to access.
Edit bookmark
: allows you to change the title
and/or URL address of the selected bookmark
item.
Add bookmark
: allows you to add a new
bookmark.
Send URL
: allows you to send the URL as a text
message, via file messenger or as email.
Delete
: deletes the selected bookmark.
Delete all
: deletes all of the bookmarks.
Settings
: allows you to change the settings for
connecting to the Wireless Web. For further
details, see below.
Empty cache
: clears information stored in the
cache, which is the phone’s temporary memory
used to store the most recently accessed web
pages. After you have accessed confidential
information requiring passwords like your bank
Z107Eng_Vodafone.book Page 65 Friday, October 22, 2004 5:04 PM
Internet
66
account, you need to empty the cache. When a
warning message appears, press the
Yes
soft
key to clear the information.
Setting up the Browser
Note
: You do not need to change the settings
unless your network operator requests it.
If you change them without the operator’s
instructions, you may not be able to use
the browser.
Contact your service provider for details and
parameters for each option.
To change the WAP settings:
1. Press the
Options
soft key on any web page.
2. Scroll to
Settings
and press the
OK
key.
3. The access points displays.
Note
: Some access points are not able to be
changed by the service provider.
4. Scroll to the access point that you want to use
and press the
OK
key to change the current
access point.
To edit or make access points, select the setting
set you want at step 4 and then press the
Options
soft key to use the following options:
Select
: saves your changes.
Edit
/
New
: edits the selected Set or makes a
new Set. For more information, see “Connections
(Menu 9-6)” on page 103.
Delete
: deletes the selected Set when it is not in
use.
Rename
: changes the name of the Set.
Z107Eng_Vodafone.book Page 66 Friday, October 22, 2004 5:04 PM
67
Messages
This menu allows you to create, send, read, and
save messages with the Short Message Service
(SMS), Multimedia Message Service (MMS), and
E-mail service.
SMS is a service which allows you to send or
receive text messages.
MMS is a messaging service very similar to SMS.
MMS enables you to send far longer text
messages than SMS - and to attach images,
graphics, voice, audio, and video clips-in any
combination, as a single multimedia message.
You can send MMS messages to phones with
MMS capability, and to any e-mail address.
Write
(Menu 5-1)
In this menu, you can write and send a text
message, a multimedia message, or an e-mail.
Note:
You can also press the
Write
soft key from
the startup screen of
the Messages menu to
write a new message.
Writing and Sending Text Messages
1. On the
Write
screen, press the
Select
soft
key when
Short msg.
highlights.
2. Write your message.
For more information about entering
characters, see page 32.
3. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
Z107Eng_Vodafone.book Page 67 Friday, October 22, 2004 5:04 PM
Messages
68
•
Use text template
: allows you to use one
of the preset message templates stored in
the
Text templates
menu; for further
details, see page 77.
•
Input language
: selects the language to
be used.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Add Phonebook
: allows you to add a
contact to the message.
4. When you finish writing the message, press
the
Options
soft key and select the
Send
option.
5. Enter a destination number in the
To
input
box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Phonebook
for a number. See page 92.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Send settings
: allows you to change the
settings for the message transmission.
6. To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to edit mode, press
the
C
key in an empty
To
input box.
7. When you have finished setting the
destination(s), press the
Options
soft key
and select the
Send
option to send the
message.
Writing and Sending Multimedia
Messages
When you send an MMS message with an image,
a video, an audio file, or text content, the entire
MMS message is shown on the recipient’s screen.
1. On the
Write
screen, select
Multimedia
msg
.
2. Enter the subject in the
Subject
text field.
To use a preset message template stored in
the
Text templates
menu, press the
Options
soft key and select the
Use text
template
option.
Z107Eng_Vodafone.book Page 68 Friday, October 22, 2004 5:04 PM
Messages
69
3. To attach an image, video, or audio file, press
the scroll key to move to the
Picture or
Video
or
Audio
field and press the
OK
key.
Select a file from the list and press the
Select
soft key or the
OK
key. You can also attach a
picture you have taken with the phone
camera.
If you want to exchange an attached image,
video, or audio file for another, you must first
delete the currently attached file. Press
Options
and select
Delete picture/video/
sound
. Press
OK
. Then attach the new file as
detailed above.
If you want to send the attached image or file
without an accompanying text message, after
you have attached the image or file, press
OK
. Proceed directly to step 7 below.
Notes
:
•
When you add a video file to a message, you
can not add an audio file or write a text
message. In this case you can add an audio
file or write a text message by adding another
page to your message. If
you want to send
lengthy video files of large capacity, the
Recording time
has to be set accordingly
in the
For message
option. See page 46.
• The maximum size allowed for a multimedia
message can differ depending upon the
country.
4. Enter your message into the
Text
field.
5. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
Preview
: shows your message as it will be
displayed on the recipient’s phone. Scroll
through the message by pressing the Up or
Down scroll key.
Press the
Stop
soft key and press the
Options
soft key to use the following
options:
Play: plays the preview.
Send: allows you to send the message.
Page duration: allows you to set how long
each page of a received message displays.
After the specified time, the display
automatically scrolls to the next page.
Colour & Font edit: allows you to set the
Font colour
,
Font style
,
and
Background
colour
by pressing the Up or Down scroll
key.
Z107Eng_Vodafone.book Page 69 Friday, October 22, 2004 5:04 PM
Messages
70
•
Input language
: selects the language to
be used.
•
Use text template
: allows you to use one
of the preset message text templates stored
in the
Text templates
menu; for further
details, see page 77.
•
Delete picture/video/sound/text
:
deletes the selected image, video, sound, or
text.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Add page
: adds a new page.
•
Delete page
: deletes a selected page. This
option is only available if more than one
page has been created.
•
Edit page
: allows you to use the following
options:
Page duration: allows you to set how long
each page of a received message displays.
After the specified time, the display
automatically scrolls to the next page.
Move pg fwd: moves from the current page
to the previous page.
Move pg bkwd: moves from the current
page to the next page.
•
Save as template
: saves the message as a
template. You can access it later in the
MMS
templates
menu, see page 77.
6. When you have finished creating the
message, press the
Options
soft key and
select
Send
.
7. Enter a destination number in the
To
input
box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Phonebook
for a number. See page 92.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Settings
: allows you to change the settings
for message transmission.
8. To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
Z107Eng_Vodafone.book Page 70 Friday, October 22, 2004 5:04 PM
Messages
71
When you want to return to edit mode, press
the
C
key in an empty
To
input box.
9. When you have finished setting the
destination(s), press the
Options
soft key
and select the
Send
option to send the
message.
Writing and Sending Messages with
Other Media Files Attached
When you send a message with media file(s)
attached, the recipient receives the message
with an attached file list.
1. On the
Write
screen, select
File messenger
and press the
OK
key.
2. Enter the subject of your message.
For more information about entering
characters, see page 32.
3. Press the Down scroll key and enter your
message contents.
4. Press the Down scroll key to attach a media
file and press the
OK
key. The My Items
screen displays.
5. Select a media file by pressing the scroll keys
and press the
OK
key to select it. A check
mark appears next to the selected file.
6. Repeat step 5 to add more files.
Note
: The maximum size allowed for attached
files can differ depending upon the
country.
7. When you have finished selecting the files,
press the
Options
soft key and press the
OK
key when
Attach
highlights. You can cancel
your selection by choosing
Deselect all
.
8. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
Use text template
: allows you to use one
of the preset message templates stored in
the
Text templates
menu.
•
Delete all attached file(s)
: removes all
attached files.
•
Attachment(s)
: shows a list of attached
file(s).
•
Input language
: selects the language to
be used.
Z107Eng_Vodafone.book Page 71 Friday, October 22, 2004 5:04 PM
Messages
72
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu.
9. When you have finished writing the message,
press the
Options
soft key and select the
Send
option.
10.Enter a destination number in the
To
input
box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Phonebook
for a number. See page 92.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Settings
: allows you to change the settings
for message transmission.
11.To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to edit mode, press
the
C
key in an empty
To
input box.
12.When you have finished setting the
destination(s), press the
Options
soft key
and select the
Send
option to send the
message.
Writing and Sending E-mails
1. On the
Write
screen, press the
Select
soft
key when
Email
highlights.
2. Enter the subject of your message.
For more information about entering
characters, see page 32.
3. Press the Down scroll key and enter your
message contents.
4. Press the Down scroll key to attach a media
file, if desired, and press the
OK
key. The My
Items screen displays.
5. Select a media file by pressing the scroll keys
and press the
OK
key to select it. A check
mark appears next to the selected file.
6. Repeat step 5 to add more files.
Note
: The maximum size allowed for files can
differ depending upon the country.
Z107Eng_Vodafone.book Page 72 Friday, October 22, 2004 5:04 PM
Messages
73
7. When you have finished selecting the files,
press the
Options
soft key and press the
OK
key when
Attach
highlights. You can cancel
your selection by choosing
Deselect all
.
8. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
Use text template
: allows you to use one
of the preset message templates stored in
the
Text templates
menu; for further
details, see page 77.
•
Delete all attached file(s)
: removes all
attached files.
•
Attachment(s)
: shows a list of attached
file(s).
•
Input language
: selects the language to
be used.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu.
9. When you have finished composing your
message, press the
Options
soft key and
select the
Send
option to send the message.
10.Enter a destination e-mail address in the
To
input box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Phonebook
for an e-mail address. See page 92.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 76.
•
Send settings
: allows you to change the
settings for message transmission.
11.To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to edit mode, press
the
C
key in an empty
To
input box.
12.When you have finished setting the
destination(s), press the
Options
soft key
and select the
Send
option to send the
message.
Z107Eng_Vodafone.book Page 73 Friday, October 22, 2004 5:04 PM
Messages
74
Inbox
(Menu 5-2)
When you receive a new message, the new
message icon displays, corresponding to the type
of message.
• : Text message
• : Text SIM message
•: MMS message
• : MMS notification message
• : Voice message
• : Network configuration information
message. For information about
configuration messages, see
Configuration Message on page 75.
When you access the
Inbox
menu, the list of
messages received displays with each message’s
size, sender’s address, and message subject.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the message, or retrieves MMS
data if the message is an MMS notification
message.
Reply
: allows you to reply to the sender with a
text or multimedia message.
Reply all
: allows you to reply to the sender and
all other (if any) recipients with a text or
multimedia message.
Forward
: allows you to send the message to
other people.
Install
: allows you to install the network account
settings. This option is available only for
configuration messages.
Cancel retrieving
: allows you to cancel
retrieving a message.
Delete
: deletes the message.
Delete all
: deletes all messages in
Inbox
.
Details
: shows detailed information about the
message. This option is shown only for MMS
messages.
Z107Eng_Vodafone.book Page 74 Friday, October 22, 2004 5:04 PM
Messages
75
Configuration Messages
You may sometimes receive a configuration
message containing information about network
settings for MMS or the browser from your
server. When you open a configuration message,
you will see detailed information. When you
press the
OK
key or the
View
soft key, a popup
message appears asking if you want to apply the
settings to your phone. Press the
Yes
soft key to
update your phone’s network configuration. You
can check the new setting in the MMS or browser
setting menus.
Note
: The GSM setting is not supported.
Email Box
(Menu 5-3)
When you receive an e-mail message, the new
message icon displays.
•: E-mail
• : E-mail with attachment
When you access the
Email box
menu, the list of
messages received displays with each message’s
size, sender’s address, and message subject.
Scroll to the message you want to view and press
the
OK
key. The message displays.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the e-mail message.
Reply
: allows you to send a reply message to
the sender.
Reply all
: allows you to send a reply message to
the sender and all other (if any) recipients.
Forward
: allows you to send the e-mail
message to other people.
Download
: downloads new e-mail messages to
your phone.
Delete
: deletes the e-mail message.
Delete all
: deletes all of the e-mail messages in
Email box
.
Delete permanently
: deletes the e-mail
message from the server.
Details
: shows detailed information about the e-
mail message.
Z107Eng_Vodafone.book Page 75 Friday, October 22, 2004 5:04 PM
Messages
76
Outbox
(Menu 5-4)
Messages that you have sent can be accessed via
this menu.
When you access the
Outbox
menu, the list of
messages you have sent displays with each
message’s subject, recipient’s address, and
message size.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the message.
Send again
: allows you to send the message
again if delivery failed.
Forward
: allows you to send the message to
other people.
Cancel sending
: allows you to cancel sending
the message.
Delete
: deletes the message.
Delete all
: deletes all of the messages in
Outbox
.
Details
: shows detailed information about the
message. This option is shown only for
multimedia and e-mail messages.
Drafts
(Menu 5-5)
In this menu, you can read, edit, and send
messages that you have saved as drafts.
When you access the
Drafts
menu, the list of
messages you have saved displays with each
recipient’s address, message subject, if you
entered it, and message size.
Scroll to the message you want to view and press
the
OK
key. The message contents display.
Press the
Options
soft key to use options. The
options may be different depending on the
message type:
View
: views the message.
Edit
: allows you to edit the message.
Delete
: deletes the message.
Delete all
: deletes all of the messages in
Drafts
.
Z107Eng_Vodafone.book Page 76 Friday, October 22, 2004 5:04 PM
Messages
77
Templates
(Menu 5-6)
In this menu, you can read, edit, and send MMS
templates and text templates.
When you access the
Text templates
or
MMS
templates
menu in the
Templates
menu, the
list of MMS templates or Text templates displays.
Text Templates
After you have created new text template
messages, you can add them to your message.
Scroll to the message you want to use by
pressing the Up or Down scroll key and press the
OK
key. You can change the message. For more
information about entering characters, see
page 32.
Press the
Options
soft key to use the following
options:
Edit
: allows you to change the message.
Send
: allows you to send the message. For
further details about sending a message, see
page 68.
New
: allows you to add a new text template
message. When you have saved 30 messages,
this option is disabled.
Delete
: deletes the message.
Delete all
: deletes all of the text template
messages.
MMS Templates
1. On the
Messages
screen, scroll to the
Templates
menu and press the
Select
soft
key. Press the
Select
soft key when
MMS
templates
highlights.
2. Select an MMS message template.
3. Press the
Options
soft key to use the
following options:
•
View
: views the selected MMS template.
•
Send
: send the selected MMS template as a
multimedia message.
•
Edit
: allows you to edit the selected MMS
template the same way you edit an MMS
message. After you edit it, you can send it
the same way you send an MMS message.
Z107Eng_Vodafone.book Page 77 Friday, October 22, 2004 5:04 PM
Messages
78
•
Delete
: deletes the selected MMS template.
Delete appears only if you have edited the MMS
template.
Delete All
(Menu 5-7)
This menu option allows you to delete all of the
messages in each message box separately. You
can also delete all of your messages at one time.
1. Scroll to a message type and place a check
mark next to it by pressing the
OK
key.
Selecting
All
messages
places check marks
on all of the message boxes.
2. If necessary, repeat step 1 to select another
type.
3. When you have finished making selections,
press the
Delete
soft key.
4. When a confirming message appears, press
the
Yes
soft key to delete all of the messages
in the type(s).
Otherwise, press the
No
soft key.
Settings
(Menu 5-8)
In this menu, you can set up default information
for using the messaging features.
Press the Up or Down scroll key to scroll to a
message type and press the
Select
soft key.
Short Message Settings
You can have several separate settings. Each
setting contains the following options:
Centre address
: allows you to view the number
of your SMS centre. This number is required
when sending messages.
Expiration
: allows you to set the length of time
your text messages are stored at the message
server while attempts are made to deliver them.
Default type
: allows you to set the default
message type.
Name
: allows you to name the setting.
The following options are in the
Common
settings
menu:
Z107Eng_Vodafone.book Page 78 Friday, October 22, 2004 5:04 PM
Messages
79
Reply path
: allows you to set your SMS centre
number as a reply path, so that the recipient can
send a reply through it. The charge is billed to
you.
Delivery report
: the network informs you
whether or not your message has been delivered.
Network selection
: allows you to select a
preferred data transmission method.
Keep a copy
: your phone leaves a copy of your
message in
Outbox
after sending it.
Character support
: allows you to select a
character set when editing and sending
messages.
GSM alphabet: you can compose a message
using GSM characters.
Unicode: you can compose a message using
Unicode characters. All GSM characters are
included in the Unicode character set. However,
when using Unicode, the maximum number of
characters which can be entered in a message is
reduced by half.
For details on the GSM and Unicode alphabets,
see the tables on page 35.
Automatic: if you select
Automatic
, the phone
selects the character set depending on whether
you enter Unicode characters or not.
Multimedia Message Settings
You can change the settings for sending or
receiving MMS messages.
Send settings
Priority
: allows you to change the priority level
of your messages.
Expiration
: allows you to specify how long your
MMS centre stores your messages after sending
them.
Delivery
: allows you to set when a message will
be sent.
Hide address
: allows you to prevent your
address from displaying on a recipient’s phone.
Delivery report
: allows you to request
notification from each recipient as to whether or
not your message has been delivered.
Read report
: allows you to request a report
from each recipient when your message has been
read by the recipient.
Z107Eng_Vodafone.book Page 79 Friday, October 22, 2004 5:04 PM
Messages
80
Keep a copy
: allows you to leave a copy of your
message in
Outbox
after sending it.
Add my name card
(selectable in the
File
sender
menu only): allows your contact
information to be attached to your message.
Add signature
(selectable in the
File sender
menu only): allows your signature text to be
attached to the end of your message. You can
enter text using up to 128 characters.
Receive settings
Home network/Roaming network
: allows you
to set how to receive a message in each network.
•
Auto
: you receive multimedia messages
automatically.
•
Manual
:
you receive a notification message
first. Then, if you choose, you can download
the multimedia message.
•
Restricted
(only for Roaming network): If you
select this method of notification, there may be
a possible additional charge, depending on
whether you download the message or not.
Delivery report
: allows the network to inform
the sender whether or not a message has been
delivered to you.
Read report
: allows your phone to send a
message to the sender to let them know when
the message has been read.
Anonymous reject
: allows your phone to reject
messages from callers without a caller ID.
Network settings
You can set up information about your MMS
network and select a network connection profile.
In most cases, you don’t need to change the
settings. In case of problems, please contact
your local customer service.
Note
: If you change these settings without the
network operator’s instructions, you may not
be able to send or receive multimedia
messages.
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key, but only one
setting can be active as your network setting.
For more information, see “Connections (Menu 9-
6)” on page 103.
Z107Eng_Vodafone.book Page 80 Friday, October 22, 2004 5:04 PM
Messages
81
Email Settings
You can change the settings for sending or
receiving e-mail messages.
Send settings
The following options are available:
From
: allows you to set the alias name.
Send Account
: allows you to select the default
account that is required when you send e-mail
messages.
Priority
: allows you to change the priority level
of your messages.
Keep a copy
: allows your phone to keep a copy
of your message in
Outbox
after sending it.
Add my name card
: allows your contact
information to be attached to your message.
Add signature
: allow your signature text to be
attached to the end of your message. You can
enter text of up to 128 characters.
Receive settings
The following options are available:
Receiving option
: allows you to set how to
receive a message.
•
Subject only
: you receive only the subjects of
e-mails. You can read the contents after
downloading.
•
Normal
: you receive the full e-mail.
Reject if over
: allows you to set the maximum
size of an incoming e-mail and rejects e-mails
when they are over the size limit.
Block address
: allows you to block e-mails from
particular addresses.
Block subject
: allows you to block e-mails
which contain the subjects you set.
Network settings
You can set up information about your network
and select a network connection profile. In most
cases, you don’t need to change the settings. In
case of problems, please contact your local
customer services.
Note
: If you change these settings without the
network operator’s instructions, you may not
be able to send or receive multimedia
messages.
Z107Eng_Vodafone.book Page 81 Friday, October 22, 2004 5:04 PM
Messages
82
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key, but only one
setting can be active as your network setting. For
more information, see “Connections (Menu 9-6)”
on page 103.
Account Settings
You can have up to 3 different e-mail accounts
on your phone. You can select and edit the
accounts.
Scroll to one of the accounts by pressing the Up
and Down scroll key and press the
Options
soft
key. Select the
Edit
option to change the
following options:
Account name
: edit the access name.
SMTP server
: set the SMTP (Simple Mail
Transfer Protocol) server address.
POP3 server
: set the POP3 server address.
My Address
: enter the e-mail address you want
replies to be sent to.
User name
: set the login name of the server.
Password
: set the login password of the server.
Use SMTP Authentication
: set SMTP
authentication. This option is used with for SMTP
servers that require this.
Voice Mail Settings
You can change the number of the voice mail
service centre. When you press the
1
key to
access your voice messages, your phone dials
this number.
Memory Status
(Menu 5-9)
You can check the memory status of each
message box in your phone memory or in your
SIM card.
Z107Eng_Vodafone.book Page 82 Friday, October 22, 2004 5:04 PM
83
My Items
You can access and enjoy various multimedia
files, such as sounds, videos, and pictures, using
My Items
.
Exploring Multimedia Files
There are 5 categories of multimedia files:
Images
,
Videos
,
Music
,
Sounds
, and
Others
.
When you press the
OK
key and the
Select
soft
key, the list of the files in the selected category
displays.
Using Multimedia Options
On the file list in any category, you can use the
following options by pressing the
Options
soft
key:
View/Play/Create new
: shows or plays the
selected file. Or, create a new file.
Delete
: allows you to select
File
,
Folder
, or
All
files
to delete files.
Delete all
: allows you to delete all files.
Rename
: allows you to change the file or folder
name. For further details about entering
characters, see page 32.
Move
: allows you to move the selected file to
another folder.
New folder
: allows you to create a new folder
for storing multimedia files.
Download
: allows you to download new files
from the web server.
Send
:
•
As multimedia msg.
: allows you to send a
multimedia message using the multimedia file.
For further details about sending multimedia
messages, see page 68.
•
As email
: allows you to send an e-mail using
the multimedia file.
•
Via file messenger
: allows you to send a
message with a multimedia file attached.
Set for cover LCD
(available in the
Images
category): allows you to use the image as the
background for the sub LCD.
Z107Eng_Vodafone.book Page 83 Friday, October 22, 2004 5:04 PM
My Items
84
Set as ringtone
(available in the
Sounds
category): allows you to use the sound as your
ringtone for voice or video calls.
Set as caller ID
: allows you to use the image or
sound as a caller ID indicator to be displayed or
played when a call comes in from a particular
contact.
Lock/Unlock
: allows you to protect the picture
from deletion, or not.
Details
:
shows detailed information about the
selected file.
Memory status
: shows you the amount of
memory used in the current category and the
remaining memory.
Using Image Files
You can use bmp, wbmp, gif, animated gif, png,
or jpg image files.
Viewing an Image
1. Press the Up or Down scroll key to select the
Images
category. The image list displays.
2. Press the Up or Down scroll key to select an
image and press the
OK
key.
3. The image viewer shows the selected file.
Press the Left or Right scroll key to load the
previous or next image file.
When viewing an image, you can use the
following options by pressing the
Options
soft
key:
Send
: allows you to send the selected file. For
more information, see
Send
on page 83.
Set as wallpaper
: allows you to use the image
as your wallpaper image, i.e., as the background
for your idle screen.
Set for cover LCD
: allows you to use the image
as the background for the sub LCD.
Set as caller ID
: allows you to use the image as
a caller ID indicator to be displayed when a call
comes in from a particular contact.
Real size
: shows you the selected image in its
real size. You can scroll through the image by
pressing the scroll keys.
Slide show
: allows you to view all of the images
in the selected folder using the Slide show
Z107Eng_Vodafone.book Page 84 Friday, October 22, 2004 5:04 PM
My Items
85
feature, which shows the images one by one on
full screen at 3-second intervals.
Delete
: deletes the selected file.
Rename
: renames the file.
Details
: shows detailed information about the
file, such as file name, size, type, and many
other things.
Creating a New Image
From the file list of the folder, select
Create new
and press the
OK
key or use the
Camera
application.
For further details about using the camera, refer
to page 42.
Using Video Files
Your phone can play video files in mp4 or 3gp
format.
Playing a Video File
1. Press the Up or Down scroll key to select
Videos
. The video list displays.
2. Press the Up or Down scroll key to select a
video file and press the
OK
key.
3. Media Player plays the selected file.
For further details about using Media Player,
see page 47.
Creating a Video
From the file list in
Videos
, select
Create new
and press the
OK
key, or use the
Video
recorder
application.
For further details about recording a video, refer
to page 45.
Using Music Files
Your phone can play music files in mp4 and 3gp
format.
Playing a Music File
1. Press the Up or Down scroll key to select
Music
. The music list displays.
2. Press the Up or Down scroll key to select a
music file and press the
OK
key.
Z107Eng_Vodafone.book Page 85 Friday, October 22, 2004 5:04 PM
My Items
86
3. The music plays.
For further details about using Media Player,
see page 47.
Using Sounds and Tones
You can use 4-chord melodies or tones.
1. Press the Up or Down scroll key to select
Sounds
.
2. Press the Left or Right scroll key to scroll
through the sub folders:
Ringtones
,
Recordings
, and
Downloads
.
3. Press the Up or Down scroll key to select a file
and press the
OK
key.
4. The music plays.
Press the Up or Down scroll key or volume
key to control the volume.
Press the Left or Right scroll key to load the
previous or next file.
While playing a sound, you can use the following
options by pressing the
Options
soft key:
Send
: allows you to send the selected file. For
more information, see
Send
on page 83.
Set as ringtone
: allows you to use the sound or
melody as your ringtone for voice or video calls.
Set as caller ID
: allows you to use the sound as
a caller ID indicator to be played when a call
comes in from a particular contact.
Delete
: deletes the selected file.
Rename
: renames the file.
Details
: shows detailed information about the
file, such as file name, size, type, and many
other things.
Record settings
: allows you to set the default
name and recording time.
Creating a Sound
From the
Sounds
category, select the
Recordings
sub folder and select
Create new
.
Press the
OK
key or use the
Voice memo
application. The Voice memo screen displays.
For further details about using the Voice memo
screen, see page 49.
Z107Eng_Vodafone.book Page 86 Friday, October 22, 2004 5:04 PM
87
Organiser
The Organiser feature allows you to view the
current month as well as past or future months
in calendar format. You can schedule up to 100
events in total. You can also make up to 50
anniversary, 20 task, and 20 memo notices.
Calendar
(Menu 7-1)
The calendar displays the
current month and highlights
the current day.
Days with events scheduled
are marked with a coloured
symbol: green for scheduled
items, red for anniversaries,
blue for tasks, and orange
for memos.
To scroll through the calendar:
• Press the Up or Down scroll key to move to the
previous or next week.
• Press the Left or Right scroll key to move to
the previous or next day.
• Press the volume keys to move to the previous
or next month. You can also press the Left,
Right, or Up scroll key when the title bar
showing the month and year highlights.
• Press the
OK
key to access the selected day.
You can use the following options by pressing the
Options
soft key:
View
: shows you the schedule for the selected
day.
New
: allows you to make a new
Schedule
,
Anniversary
,
Task
,
or
Memo
.
Go to today
: shows today’s calendar.
Go to date
: enter the date to which you want to
go and press the
Go
soft key.
Delete
: deletes the events in the period you
specify.
Delete all
: deletes all of the events in your
calendar.
Z107Eng_Vodafone.book Page 87 Friday, October 22, 2004 5:04 PM
Organiser
88
Today’s Events
(Menu 7-2)
When you press the
Options
soft key, the
following options are available; these may be
different depending on the selected event type:
View
: shows you details of the event.
New
: allows you to make a new
Schedule
,
Anniversary
,
Task
, or
Memo
.
Done
: when you have completed a task, select
Done
to insert a check mark next to the item.
Note
: If you want to remove the check mark, select
the item and press the
Options
soft key.
Then select
To do
.
Month view
: returns to the calendar screen.
Change date
: allows you to change an
anniversary date.
Reschedule
: allows you to change the date of
an event easily. When the calendar displays,
move to a new start date using the scroll keys
and press the
OK
key.
Change due date
: allows you to change the
task’s due date.
Delete
: deletes the event.
Delete all
: deletes all of the events for that day.
Send schedule
: allows you to send the
scheduled event by text message, file sender, or
e-mail.
Send task
: allows you to send the task by text
message, file sender, or e-mail.
Send memo
: allows you to send the memo by
text message.
Schedule
(Menu 7-3)
Press the
Options
soft key and select the
Add
new
option to make a new event. See page 88
for other options.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Title
: enter a title for the event. See
page 32 for more information about
entering characters.
•
Details
: enter the event details.
Z107Eng_Vodafone.book Page 88 Friday, October 22, 2004 5:04 PM
Organiser
89
•
Start
: enter the start time of the event.
You can move the cursor using the Left and
Right scroll keys.
•
End
: enter the end time of the event the
same way as you would enter a start time.
•
Start date
: enter the start date. You can
move the cursor using the Left and Right
scroll keys.
•
End date
: enter the end date the same way
as you would enter a start date.
•
Location
: enter information about the
event location.
•
Alarm
: press the
OK
key to set an alarm to
remind you of the event. Then set when the
alarm is to alert you: enter the number and
select a unit,
min.
,
hour
, or
day
, using the
Left and Right scroll keys. You can move
from the number box to the time box by
using the Down scroll key.
•
Repeat
: if you are entering a recurring
event, press the
OK
key and select the
repeat option using the Left and Right scroll
keys. Then enter the date that you wish the
event to cease recurring.
•
Expiry
: select how long the event is to be
stored in your calendar.
2. When you have finished entering the event,
press the
Save
soft key.
Anniversary
(Menu 7-4)
Press the
Options
soft key and select the
Add
new
option to make a new anniversary. See
page 88 for the other options.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Occasion
: enter the information about the
occasion. See page 32 for more information
about entering characters.
•
Date
: enter the date. You can move the
cursor using the Left and Right scroll keys.
•
Alarm
: press the
OK
key to set an alarm to
remind you of the event. To set an alarm
ahead of the day required, enter the desired
number of days before the event, and the
time on that day that you want to be
Z107Eng_Vodafone.book Page 89 Friday, October 22, 2004 5:04 PM
Organiser
90
alerted. You can move the cursor using the
Left and Right scroll keys.
•
Repeat every year
: press the
OK
key to
mark or unmark this option.
2. When you have finished entering the
anniversary details, press the
Save
soft key.
Task List
(Menu 7-5)
Press the
Options
soft key and select
Add new
to make a new item for the Task list.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Task
: enter the information about the
occasion. See page 32 for more information
about entering characters.
•
Start date
: enter the start date. You can
move the cursor using the Left and Right
scroll keys.
•
Due date
: enter the due date.
•
Priority
: enter the priority, choosing 1, 2 or
3. 1 is the highest priority.
2. When you have finished entering the Task,
press the
Save
soft key.
When you have completed a task from the Task
list, select the item and press the
Options
soft
key. Then select
Done
to insert a check mark
next to the item.
Note
: If you want to remove the check mark, select
the item and press the
Options
soft key.
Then select
To do
.
Memo
(Menu 7-6)
Press the
Options
soft key and select the
New
option to create a new memo. See page 88 for
other options.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Memo
: enter the memo details.
•
Date
: enter the date.
2. When you have finished entering the memo,
press the
Save
soft key.
Z107Eng_Vodafone.book Page 90 Friday, October 22, 2004 5:04 PM
Organiser
91
Missed Event Alarm
(Menu 7-7)
When the alarm sounds, you must press the
OK
soft key in the reminder window within one
minute. Otherwise, the missed event alarm
window will be displayed.
You can view missed events in the
Missed Event
Alarm
menu.
Press the
Options
soft key to use the following
options:
View
: allows you to view the selected event
alarm details.
Delete
: allows you to delete the selected event
alarm in the list.
Delete all
: allows you to delete all event alarms
in the list.
Z107Eng_Vodafone.book Page 91 Friday, October 22, 2004 5:04 PM
92
Profiles
In
Profiles
, you can adjust and customise the
sounds the phone makes for different events or
situations. There are five preset profiles:
Normal
,
Meeting
,
Car
,
Silent
, and
Outdoor
,
which you can customise to meet your needs.
Changing the Profiles
On the Profiles screen, select a profile by
pressing the Up or Down scroll key and press the
Activate
soft key.
You can also press the
Activate
soft key from
the startup screen of the profiles menu, then
select a profile and press the
OK
key.
Note
: You can quickly change to silent mode by
holding
the key
down when
in idle mode.
To change back to the previous profile
mode, hold the key down again.
Customising the Profiles
1. To modify a profile, scroll to the profile on the
Profiles list by pressing the Up or Down scroll
key, and then press the
OK
key. A list of
profile settings opens. The available setting
options vary depending on the selected
profile.
2. Scroll to the setting you want to change by
pressing the Up or Down scroll key, and then
change the setting using the Left or Right
scroll keys, or the
OK
key.
The following options are available:
•
Call alert type
: allows you to select the
alert type for the call ringer. You can
choose from
Melody
,
Vibration
,
Mute
(Light only)
, and
Vib & melody
.
•
Voice call/V-Call ringtone
: enables you
to select a melody or tone to be used when
you have selected
Melody
or
Vib &
melody
in the
Call alert type
option.
Press the
OK
key and select a sound from
the alert tone list.
Z107Eng_Vodafone.book Page 92 Friday, October 22, 2004 5:04 PM
Profiles
93
•
Tone volume
: allows you to adjust the
volume level of the voice call, video call,
ringtone, and message alert tone.
•
Msg. alert type
: allows you to select the
alert type for the message ringer.
•
Msg. alert tone
: allows you to select the
melody or tone to be used if you have
selected
Melody
or
Vib & melody
in the
Msg. alert type
option.
The last item on the list of tone choices is
Special tone
. If you select
Special tone
,
you will see the list of tones that you have
downloaded, and you can select one of
those tones for your
Msg. alert tone
.
•
Msg. alert repetition
: allows you to
specify how often the phone informs you of
a new message. You can choose either
Once
or
Periodic
.
•
Effect tones
: allows you to turn the
following alert sounds on or off:
All on: enables all tones.
Popup box alerts: set s the phone to inform
you of the status.
Minute minder: lets you set the phone to
beep every minute during an outgoing call
to keep you informed of the length of your
call.
Call connect tone: sets the phone to beep
when the person you are calling answers
the phone.
Call end tone: sets the phone to beep when
your call ends.
Power on: sets the phone to beep when the
phone is switched on.
Effect sounds: sets the phone to beep when
you access the menu.
Folder open/close: sets the phone to beep
when you open or close the phone.
Alerts on call: sets the phone to sound all
alerts during a call.
All off: disables all tones.
To enable an effect tone(s), press the
OK
key to place a check mark next to the
tone(s) you want. To remove a check mark,
press the
OK
key again. Then press the
Done
soft key to save the settings.
•
Key tones
: allows you to select a tone
which sounds when you press a key.
•
Key tone volume
: allows you to adjust the
volume level of the key tones.
3. When you finish setting the options, press the
Save
soft key.
Z107Eng_Vodafone.book Page 93 Friday, October 22, 2004 5:04 PM
94
Settings
Many different features of your phone can be
customised to suit your preferences in the
Settings
menu.
Phone
(Menu 9-1)
In this menu, you can set options for the phone.
LCD Brightness
You can adjust the brightness of the screen.
Press the Left or Right scroll key to make the
screen darker or brighter, and then press the
Save
soft key.
Backlight
You can set the timer to go to dimming mode
when there is no input. This consumes less
battery power. You can select the length of time
the phone waits before it dims the screen after
the last key has been pressed. Once the phone
goes to dimming mode, the screen will turn off
after 30 seconds.
When your phone is in dimming mode or the
screen is off, you can activate it up by pressing
any key.
Ext. Light
This menu allows you to select whether or not
the service light is used and what colour it is.
The external light is a service availability
indicator. When you set the
Service light
to
On
,
the light flashes when you are in a service area.
If the phone is not in a service area, the light
doesn't flash.
If you do not wish to use the service light, select
Off
.
Language
You can select a different language for the
display text and the text input mode.
Z107Eng_Vodafone.book Page 94 Friday, October 22, 2004 5:04 PM
Settings
95
1. Press the
OK
key in the
Screen Text
field.
2. Press the Up or Down scroll key to select a
language for the display text, e.g., menu
names and warning or confirmation
messages, and press the
Select
soft key.
Note
: The SIM card determines the display
language when the
Screen Text
option is
set to
Automatic
.
3. Press the Down scroll key to move to the
Input T9
field and press the
OK
key.
4. Press the Up or Down scroll key to select a
language for the T9 input mode and press the
Select
soft key.
5. Press the
Save
soft key.
Shortcuts
You can set the Left, Right, and Down scroll keys
to be used as shortcut keys to the menu
functions you use most frequently. In idle mode,
this will allow you to access specific menu
options directly.
1. Press the Left or Right scroll key to check the
current function assigned, and select the
scroll key whose function you want to change.
2. Press the
Options
soft key to use the
following options:
•
Assign/Change
: assigns or changes the
function of the selected scroll key.
Select a function from the function list and
press the
Select
soft key to select it.
•
Remove
: removes the menu function of the
selected navigating key.
•
Remove all
: removes all functions assigned
to the scroll keys.
Active Folder
When this option is set to
On
, you can answer a
call by opening the phone.
When it is set to
Off
, you must flip the phone
open and then press a key, depending on the
setting of the
Anykey Answer
option.
Press the Up or Down scroll key to select
On
or
Off
, and press the
Save
soft key.
Z107Eng_Vodafone.book Page 95 Friday, October 22, 2004 5:04 PM
Settings
96
Anykey Answer
When this option is set to
On
, you can answer an
incoming call by pressing any key except the
key and the
Reject
soft key.
When this option is set to
Off
, you can only
answer by pressing the key or the
Accept
soft key.
Press the Up or Down scroll key to select
On
or
Off
, and press the
Save
soft key.
Infrared
In this menu, you can activate or deactivate the
infrared port.
The following options are available:
Off
: deactivates the infrared feature on the
phone.
On
: activates the infrared feature on the phone.
If there is no communication between your
phone and an Infrared-compliant device within 1
minute of activating the feature, it is
automatically deactivated.
Display
(Menu 9-2)
This menu allows you to customise the main
display screen by setting a greeting message,
setting a wallpaper image.
Greeting Message
You can set a greeting message to be displayed
briefly when you switch the phone on.
1. When
Greeting message
highlights in the
Display menu, press the
Select
soft key.
The current message displays.
2. Press the
C
key to clear the message.
3. Enter a new message.
For more information about entering
characters, see page 32.
4. When you have finished entering the
message, press the
Save
soft key.
Z107Eng_Vodafone.book Page 96 Friday, October 22, 2004 5:04 PM
Settings
97
Wallpaper
You can select a background image (wallpaper)
to be displayed on the idle screen.
1. Select
Wallpaper
in the Display menu using
the Up or Down scroll key, and press the
Select
soft key. You can also press the
Wallpaper
soft key from the Settings startup
screen.
The
Images
folder from
My Items
opens.
2. Press the Up or Down scroll key to scroll to
the image you want to use.
3. Press the
Select
soft key.
Cover LCD
You can choose one of the following options:
Clock
: a clock showing the current time and date
appears on the screen.
Cover title
: you can enter a greeting message.
For more information about entering characters,
see page 32.
Wallpaper
: you can select an image. You can
also adjust the size and position of the image.
Main Menu Style
You can change the appearance of the main
menu.
Call
(Menu 9-3)
Caller ID
You can prevent your phone number from being
displayed on the phone of the person being
called.
Note
: Some networks do not allow the user to
change this setting.
The following options are available:
By network
: the default setting provided by the
network is used.
Send
: your number is sent each time you make
a call.
Hide
: your number is not displayed on the other
person’s phone.
Z107Eng_Vodafone.book Page 97 Friday, October 22, 2004 5:04 PM
Settings
98
Diverting
This network service enables incoming calls to be
rerouted to the number that you specify, for
example, to your voicemail box.
To set your call diverting options:
1. From
Voice call
,
Data call
,
and
Video call
,
select the type of call to be diverted by
pressing the Up or Down scroll key, and then
press the
OK
key.
2. Select when the calls should be diverted by
pressing the Up or Down scroll key, and then
press the
OK
key.
•
Always
: all calls are diverted.
•
Busy
: calls are diverted if you are already
engaged on a call.
•
No reply
: calls are diverted if you do not
answer the phone.
•
Unreachable
: calls are diverted if you are
not in an area covered by your service
provider.
•
Cancel all
: all call diverting options are
cancelled.
The phone dials your network to ascertain
whether call diverting is possible or not.
After a few minutes, the current status
displays. If the option has already been set,
the numbers to which the calls are diverted
also displays.
3. Press the Left or Right scroll key to select one
of the following options:
•
Activate
: this option activates the number.
•
Deactivate
: this option deactivates the
setting choice.
4. Press the Down scroll key and enter or
change the number to which you want your
calls diverted. Or, press the
Phonebook
soft
key to select a stored number.
5. Press the Up scroll key and press the
Req.
soft key.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Barring
The call barring network service allows you to
restrict your calls.
Z107Eng_Vodafone.book Page 98 Friday, October 22, 2004 5:04 PM
Settings
99
To set your call barring options:
1. From
Voice call
,
Data call
,
and
Video call
,
select the type of call to be barred by pressing
the Up or Down scroll key, and then press the
OK
key.
2. Select which calls should be barred by
pressing the Up or Down scroll key, and then
press the
OK
key.
•
All outgoing calls
: calls cannot be made.
•
Outgoing int’l calls
: international calls
cannot be made.
•
Outgoing exc. home
: when abroad, calls
can be made only to numbers within the
current country and to your home country,
which is the country where your home
network operator is located.
•
All incoming
calls
: calls cannot be
received.
•
Incoming calls when roaming
: calls
cannot be received when you are using your
phone outside of your home service area.
•
Cancel all
: all call barring options are
cancelled.
The phone dials your network to ascertain
whether call barring is possible or not.
After a few minutes, the current status
displays.
3. Press the Left or Right scroll key to select one
of the following options.
•
Activate
: selecting this option activates
your setting choice.
•
Deactivate
: selecting this option
deactivates your setting choice.
4. Press the Down scroll key and enter the call
barring password supplied by your service
provider.
5. Press the
Req.
soft key.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Changing the Barring Password
You can change the call barring password
obtained from your service provider.
1. From the barring menu screen, press the
Options
soft key and select the
Change
password
option.
Z107Eng_Vodafone.book Page 99 Friday, October 22, 2004 5:04 PM
Settings
100
2. Enter the current password in the
Old
input
box.
3. Press the Down scroll key and enter a new
password.
4. Press the Down scroll key and enter the new
password again to confirm it.
5. Press the
Confirm
soft key.
Waiting
This network service informs you when someone
is trying to reach you when you are busy with
another call.
To set your call waiting options:
1. From
Voice call
and
Data call
, select the
type of call by pressing the Up or Down scroll
key, and then press the
OK
key.
The phone dials your network to ascertain
whether call waiting is possible or not.
After a few minutes, the current status
displays.
2. Press the Left or Right scroll key to select one
of the following options.
•
Activate
: selecting this option activates
your setting choice.
•
Deactivate
: selecting this option
deactivates your setting choice.
3. Press the
Req.
soft key.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Auto Redial
With this feature, the phone makes up to ten
attempts to redial a phone number when an
outgoing call fails.
Closed User Group (CUG)
This network service allows incoming and
outgoing calls to be restricted to a selected user
group. You may be a member of up to ten
groups.
Example
: A company lends SIM cards to its
employees and wants to restrict outgoing
calls to members of the same team.
Z107Eng_Vodafone.book Page 100 Friday, October 22, 2004 5:04 PM
Settings
101
Activating a Closed User Group
1. Press the
OK
key to put a check mark on the
Use user group
field.
2. Press the Down scroll key to move to the
Outside access
field. Use the
OK
key to
enable or disable calls to numbers other than
those in the Closed User Group.
This feature depends on the nature of your
CUG subscription. Please check with your
service provider.
3. Press the Down scroll key to move to the
Group index
field and select the CUG index
you want to activate.
4. Press the
Save
soft key.
Now, you can select the number from the
Index field.
Managing the Index List
You can add a new index and change or delete an
existing index.
1. On the Closed User Group screen, press the
Down scroll key to move to the
Group index
field.
2. Press the
OK
key to see the Group index list.
3. Press the Up or Down scroll key to select an
index and press the
Options
soft key.
The following options are available:
•
Select
: saves the current index list.
•
New index
: enter a new index name and
press the
Save
soft key.
•
Edit index
: allows you to change the
selected index.
•
Delete index
: deletes the selected index.
Video call
(Menu 9-4)
This menu allows you to select whether or not
the video camera is used when a video call is
received, or when you retry a failed or
interrupted video call (for example, when back
within 3G (UMTS) reception).
Show me
: allows you to set the video camera
use parameters when receiving an incoming
video call.
•
Always
: the video camera is always used.
Z107Eng_Vodafone.book Page 101 Friday, October 22, 2004 5:04 PM
Settings
102
•
Optionally
: allows you to select whether or
not the video camera is used.
Retry by
: allows you to set how to retry.
•
Voice call
: allows you to retry by voice call.
•
Multimedia msg.
: allows you to send a
multimedia message using video footage.
•
None
: no retry.
Network
(Menu 9-5)
Network Selection
The Network Selection feature enables you to
automatically or manually select the network
used when roaming outside of your home
network.
Note
: You can select a network other than your
home network only if it has a valid roaming
agreement with your home network.
Press the Up or Down scroll key until the
appropriate option highlights and then press the
Select
soft key.
If you select
Automatic
, you are connected to
the first available network when roaming.
If you select
Manual
, the phone scans for
available networks. Press the Up or Down scroll
key until the preferred network highlights and
then press the
Select
soft key. You are
connected to that network.
Network Mode
The Network mode feature enables you to select
the type of network you use.
Press the Up or Down scroll key until the
appropriate option highlights and then press the
Select
soft key.
Automatic
,
GSM
, and
UMTS
are available.
If you select
Automatic
, the phone scans for
available networks.
If you select
GSM
, you can use the GSM
network.
If you select
UMTS
(3G network), you can get
higher quality sound, including speech, than on
lower generation networks, and use advanced
data and information services, such as video
calls. If you do not select this option, you can not
use UMTS (3G network) services.
Z107Eng_Vodafone.book Page 102 Friday, October 22, 2004 5:04 PM
Settings
103
Connections
(Menu 9-6)
You can set up information about your network
connection. In most cases, you don’t need to
change the settings. In case of problems, please
contact customer service.
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key.
When the
Edit
option is highlighted, press the
OK
key to edit the following options:
Set name
: allows you to edit the name of the
network setting.
Access name
: allows you to edit the access
point name used for the address of the GPRS
network gateway.
Auth type
: allows you to choose the type of
authentication used.
User ID
: allows you to edit the server login ID.
Password
: allows you to edit the server
password.
Protocol
: allows you to select the protocol from
among WAP, HTTP, and Other.
Home URL
: allows you to edit the MMS server
address.
Gateway address
(available only with the WAP
protocol): allows you to set the gateway address.
Proxy address/Port
(available only with the
HTTP protocol): allows you to set the proxy
server address and port.
Secure connection
(available only with the WAP
protocol): allows you to select On or Off.
Linger time (sec.)
: allows you to set a time
period after which the network is disconnected if
there has been no new data traffic in that time.
Advanced settings
Static IP: you can specify if you want to manually
enter an IP address; see the Local phone IP
option. If you want the IP address to be
automatically assigned by the server, remove the
check mark.
Local phone IP: enter the IP address obtained
from the network operator, if you checked the
Static IP option.
Static DNS: you can specify if you want to
manually enter the DNS (Domain Name Server)
address; see the Server 1/2 option. If you want
Z107Eng_Vodafone.book Page 103 Friday, October 22, 2004 5:04 PM
Settings
104
the address to be automatically assigned by the
server, remove the check mark.
Server 1/2: enter the Domain Name Server
addresses.
Traffic class: select the traffic class, if you
selected the PS network.
Managing Connections
You can add a new connection and edit or delete
an existing connection.
On the list of connections, press the Up or Down
key to select a connection and press the
Options
soft key.
The following options are available.
Edit
: allows you to edit the selected connection.
New
: allows you to add a new connection.
Delete
: deletes the selected connection.
Rename
: allows you to change the name of the
selected connection.
Security
(Menu 9-7)
The Security feature enables you to restrict the
use of your phone:
• to the people of your choice
• to certain types of calls
Various codes and passwords are used to protect
the features of your phone. They are described in
the following sections; see also pages 111 to
112.
Phone Lock
When the Phone lock feature is enabled, the
phone is locked and you must enter a phone
password of between 4 and 8 digits each time
you switch the phone on.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to enter the phone password. Enter your
password and press the
Confirm
soft key.
To change the password, refer to the
Change
phone password
menu on page 106.
Z107Eng_Vodafone.book Page 104 Friday, October 22, 2004 5:04 PM
Settings
105
SIM Lock
When the SIM lock feature is enabled, your
phone only works with the current SIM card. To
use another SIM card in your phone, you must
enter the SIM lock password set when you lock
the card.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to set a new password. Enter a password using
four to eight digits and press the
Confirm
soft
key.
PIN Lock
When the PIN lock feature is enabled, you must
enter your PIN each time you switch the phone
on. Consequently, any person who does not have
your PIN cannot use your phone without your
approval.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to enter the PIN code. Enter your PIN code and
press the
Confirm
soft key.
The PIN code is supplied with your SIM card. To
change your PIN, refer to the
Change PIN
code
menu on page 106.
Fixed Dialling Mode
If the fixed dialling mode is supported by your
SIM card, you can restrict your outgoing calls to
the FDN (Fixed Dial Number) stored in the SIM
card memory.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to enter the PIN2 code. Enter your PIN2 code and
press the
Confirm
soft key.
The PIN2 code is supplied with your SIM card. To
change your PIN2, refer to the
Change PIN2
code
menu on page 107.
Note
: Not all SIM cards have a PIN2. If your SIM
card does not, this menu option does not
display.
Z107Eng_Vodafone.book Page 105 Friday, October 22, 2004 5:04 PM
Settings
106
Change Phone Password
Using this menu option, you can change your
phone password to a new one.
1. Enter the current password and press the
Confirm
soft key.
2. Enter a new password and press the
Confirm
soft key.
3. Enter the new password again to confirm it
and press the
Confirm
soft key.
Privacy Lock
This feature allows you to lock or unlock the
usage of the contents, such as messages,
pictures, and sounds.
1. Scroll to an item and place a check mark next
to it by pressing the
OK
key.
Selecting
All lock
places check marks on all
of the items except
All unlock
. Or, selecting
All unlock
removes all check marks except
All lock
.
2. If necessary, repeat step 1 to check another
item.
3. When you have finished making your
selections, press the
Save
soft key.
4. When a confirming message appears, enter
your phone password and press the
Confirm
soft key to lock the content(s) selected.
Otherwise, press the
Back
soft key.
Change PIN Code
This feature allows you to change your current
PIN to a new one, provided that the PIN lock
feature is enabled.
1. Enter the current PIN code and press the
Confirm
soft key.
2. Enter a new PIN code and press the
Confirm
soft key.
3. Enter the new code again to confirm it and
press the
Confirm
soft key.
Z107Eng_Vodafone.book Page 106 Friday, October 22, 2004 5:04 PM
Settings
107
Change PIN2 Code
The Change PIN2 code feature allows you to
change your current PIN2 to a new one.
1. Enter the current PIN2 code and press the
Confirm
soft key.
2. Enter a new PIN2 code and press the
Confirm
soft key.
3. Enter the new code again to confirm it and
press the
Confirm
soft key.
Note
: Not all SIM cards have a PIN2. If your SIM
card does not, this menu does not display.
Date & Time
(Menu 9-8)
This menu allows you to set the current time and
date to display on the idle screen.
You can scroll through the clock options by
pressing the Up or Down scroll key. Set the
following options:
Date
: enter today’s date. You can move the
cursor back and forth between the input boxes
using the Left and Right scroll keys.
You can change the date format in the
Date
format
option below.
Time
: enter the current time. You can move the
cursor using the Left and Right scroll keys.
Highlight AM or PM (in 12 hour mode) and
change by pressing any of the number keys.
You can change the time format in the
Time
format
option below.
Time format
: select the time format using the
Left and Right scroll keys. You can choose from
12H
and
24H
.
Date format
: select the date format using the
Left and Right scroll keys. You can choose from:
- DD/MM/YYYY (day/month/year)
- MM/DD/YYYY (month/day/year)
- YYYY/DD/MM (year/day/month)
- YYYY/MM/DD (year/month/day)
Summer time
: allows you to activate daylight
savings time.
Z107Eng_Vodafone.book Page 107 Friday, October 22, 2004 5:04 PM
Settings
108
Own Number
(Menu 9-9)
You can store your own phone number(s) with a
name in your SIM card.
1. Scroll to a number and press the
Select
soft
key.
2. Edit your name and number.
3. Press the
Save
soft key to save it.
If you want to cancel the setting, scroll to the
number field and press the
Back
soft key.
Memory Status
(Menu 9-0)
You can check the status of the memory in your
phone or your SIM card.
You can see the available memory space. You
can also check the memory used by several
applications.
Reset Settings
(Menu 9-*)
This menu option allows you to reset your phone
to its default configuration.
1. When the display asks you to enter the phone
password, enter it and press the
Confirm
soft
key.
2. When you are asked to confirm your choice,
press the
Yes
soft key.
To exit the function without resetting the
settings, press the
No
soft key.
Your phone automatically turns off and then
back on.
Z107Eng_Vodafone.book Page 108 Friday, October 22, 2004 5:04 PM
109
Solving Problems
Before contacting after-sales service, perform
the following simple checks. It may save you the
time and expense of an unnecessary service call.
When you switch your phone on, the
following messages may appear:
Insert SIM card
• Check that the SIM card is correctly installed.
Phone Lock
• The Phone lock feature is enabled. You must
enter the phone password each time you
switch the phone on. To disable this feature,
go to the
Phone lock
menu (Menu 9-7-1).
PIN Lock
• You are using your phone for the first time.
You must enter the Personal Identification
Number supplied with the SIM card.
• The PIN lock feature is enabled. You must
enter the PIN each time you switch the phone
on. To disable this feature, go to the
PIN lock
menu (Menu 9-7-3).
PUK Lock
• The PIN was entered incorrectly three times in
succession and the phone is now blocked.
Enter the PUK provided by your network
operator (you may need to ask them for this).
No Service
• The network connection has been lost. You
may be in a weak reception area (in a tunnel
or surrounded by buildings). Move and try
again.
• You are trying to access an option for which
you have not taken out a subscription with
your service provider. Contact the service
provider for further details.
You have entered a number but it was
not dialled
• Have you pressed the key?
• Are you accessing the right cellular network?
Z107Eng_Vodafone.book Page 109 Friday, October 22, 2004 5:04 PM
Solving Problems
110
• You may have set an outgoing call barring
option.
The person calling cannot reach you
• Is your phone switched on (the key pressed
for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring
option.
The person calling cannot hear you
speaking
• Have you switched off the microphone (the
Mute icon ( ) appears)?
• Are you holding the phone close enough to
your mouth? The microphone is located at the
bottom of the phone.
The phone starts beeping and “Battery
Low” flashes on the display
• The battery is insufficiently charged. Recharge
it. See page 14.
The audio quality of the call is poor
• Check the signal strength indicator on the
display ( ); the number of bars indicates
the signal strength, from strong ( ) to
weak ( ).
• Try moving the phone slightly or moving closer
to a window if you are in a building.
No number is dialled when you recall a
Phonebook entry
• Check that the number has been stored
correctly, by using the Search contact feature.
• Edit and re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung
after-sales service.
Z107Eng_Vodafone.book Page 110 Friday, October 22, 2004 5:04 PM
111
Access Codes
There are several access codes that are used by
your phone and its SIM card. These codes help
you protect the phone against unauthorised use.
The access codes (except for the PUK and PUK2
codes) can be changed using the
Security
menu
(Menu 9-7). See page 104 for further details.
Phone Password
The phone password can be used to avoid
unauthorised use of your phone. The default
password “00000000” (8 zeros) is usually
supplied with the phone. Change the password
before you start using your phone. Keep the new
password secret and in a safe place, separate
from the phone.
PIN
The PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
It is usually supplied with the SIM card. When
the PIN lock feature is enabled (see page 105),
you must enter the PIN each time you switch on
the phone.
If you enter an incorrect PIN three times in
succession, your phone will lock down. You will
need to enter the PUK obtained from your
network operator and press the
Confirm
soft
key to unlock the phone. Enter a new PIN and
press the
Confirm
soft key. Enter the new PIN
again and press the
Confirm
soft key.
Z107Eng_Vodafone.book Page 111 Friday, October 22, 2004 5:04 PM
Access Codes
112
PIN2
The PIN2, supplied with some SIM cards, is
required to access some functions, such as
charging unit counters. These functions are only
available if supported by your SIM card.
If you enter an incorrect PIN2 three times in
succession, the phone will lock down. You will
need to enter the PUK2 and press the
Confirm
soft key to unlock the phone. Enter a new PIN2
and press the
Confirm
soft key. Enter the new
PIN2 again and press the
Confirm
soft key.
PUK
The PUK (PIN Unblocking Key) is required to
change a blocked PIN. The PUK may be supplied
with the SIM card. If not, contact your local
service provider.
If you enter an incorrect PUK ten times in
succession, the SIM card cannot be used
anymore.
Contact your service provider for a new card.
You cannot change the PUK. If you lose the code,
contact your service provider.
PUK2
The PUK2, supplied with some SIM cards, is
required to change a blocked PIN2.
If you enter an incorrect PUK2 ten times in
succession, you cannot use the functions
requiring the PIN2. Contact your service provider
for a new card.
You cannot change the PUK2. If you lose the
code, contact your service provider.
Call Barring Password
The 4-digit call barring password is required
when you use the Call barring function. You
obtain the password from your service provider
when you subscribe to this function.
Z107Eng_Vodafone.book Page 112 Friday, October 22, 2004 5:04 PM
113
Health and Safety Information
SAR Certification Information
This phone meets European Union (EU)
requirements concerning exposure to radio
waves.
Your mobile phone is a radio transmitter and
receiver. It is designed and manufactured so as
not to exceed the limits for exposure to radio-
frequency (RF) energy, as recommended by the
EU Council. These limits are part of
comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines were developed by
independent scientific organisations through
periodic and thorough evaluation of scientific
studies. The limits include a substantial safety
margin designed to ensure the safety of all
persons, regardless of age and health.
The exposure standard for mobile phones
employs a unit of measurement known as SAR
(Specific Absorption Rate). The SAR limit
recommended by the EU Council is 2.0W/kg.
*
The Highest SAR Value for this model phone was
0.630 W/kg.
SAR tests are conducted using standard
operating positions with the phone transmitting
at its highest certified power level in all tested
frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a base station, the lower the
power output of the phone.
Before a new model phone is made available for
sale to the public, compliance with the European
R&TTE Directive must be shown. This directive
* The SAR limit for mobile phones used by the public is 2.0
watts/kilogram (W/kg) averaged over ten grams of body
tissue. The limit incorporates a substantial margin of safety to
give additional protection for the public and to account for
any variations in measurements. The SAR values may vary
depending on national reporting requirements and the
network band.
Z107Eng_Vodafone.book Page 113 Friday, October 22, 2004 5:04 PM
Health and Safety Information
114
includes as one of its essential requirements the
protection of the health and safety of the user
and any other person.
Precautions When Using Batteries
Your phone is powered by a rechargeable Li-ion
standard battery.
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby
times are greatly affected by the signal
strength on the cellular network and the
parameters set by the network operator.
• Battery charging times depend on the residual
battery charge, the type of battery, and the
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in
use, disconnect it from the power source. Do
not leave the battery connected to a charger
for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter
conditions, as you will reduce the capacity and
life-time of the battery. Always try to keep the
battery at room temperature. A phone with a
hot or cold battery may temporarily not work,
even when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental
short circuiting can occur when a metallic
object (coin, clip, or pen) causes a direct
connection between the + and – terminals of
the battery (metal strips on the back of the
battery), for example when you carry a spare
Z107Eng_Vodafone.book Page 114 Friday, October 22, 2004 5:04 PM
Health and Safety Information
115
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the
object causing the short-circuit.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not
dispose of batteries in a fire.
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you
are following the special regulations in a given
area or country.
Operating Environment
Remember to follow any special regulations in
force in any area and always switch off your
phone whenever it is forbidden to use it, or when
it may cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the normal
operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Consult the manufacturer to discuss alternatives.
Z107Eng_Vodafone.book Page 115 Friday, October 22, 2004 5:04 PM
Health and Safety Information
116
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with
the pacemaker. These recommendations are
consistent with the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• Should always keep the phone more than 15
cm (6 inches) from their pacemaker when the
phone is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimise potential interference
If you have any reason to suspect that
interference is taking place, switch off your
phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information. Switch
off your phone in health care facilities when any
regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be
using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or
its representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Z107Eng_Vodafone.book Page 116 Friday, October 22, 2004 5:04 PM
Health and Safety Information
117
Obey posted instructions
Switch off your phone in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in
bodily injury or even death.
Users are advised to switch off the phone while
at a refuelling point (service station). Users are
reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants
or where blasting operations are in progress.
Areas with a potentially explosive atmosphere
may not be clearly marked. They include below
decks on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain,
dust or metal powders, and any other area where
you would normally be advised to turn off your
vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline
networks, as well as user-programmed functions,
which cannot guarantee connection in all
conditions. Therefore, you should never rely
solely on any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls, the
phone must be switched on and in a service area
with adequate signal strength. Emergency calls
may not be possible on all wireless phone
networks or when certain network services and/
or phone features are in use. Check with local
service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Enter the emergency number for your present
location (for example, 112 or any other
Z107Eng_Vodafone.book Page 117 Friday, October 22, 2004 5:04 PM
Health and Safety Information
118
official emergency number). Emergency
numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to
give all the necessary information as accurately
as possible. Remember that your phone may be
the only means of communication at the scene of
an accident; do not cut off the call until given
permission to do so.
Other Important Safety
Information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases,
or explosive materials in the same
compartment as the phone, its parts, or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with great
force. Do not place objects, including both
installed or portable wireless equipment, in the
area over the air bag or in the air bag
deployment area. If wireless equipment is
improperly installed and the air bag inflates,
serious injury could result.
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and is illegal.
• Failure to observe these instructions may lead
to the suspension or denial of telephone
services to the offender, legal action, or both.
Z107Eng_Vodafone.book Page 118 Friday, October 22, 2004 5:04 PM
Health and Safety Information
119
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all of its parts and
accessories out of the reach of small children.
• Keep the phone dry. Precipitation, humidity,
and liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with wet hands while it
is charging. Doing so may give you an electric
shock or damage the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock, or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the phone. Wipe
it with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove, or a
radiator. The phone may explode when
overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas
or modified accessories may damage the phone
and violate regulations governing radio
devices.
• If the phone, battery, charger, or any
accessory is not working properly, take it to
your nearest qualified service facility. The
personnel there will assist you, and if
necessary, arrange for service.
Z107Eng_Vodafone.book Page 119 Friday, October 22, 2004 5:04 PM
120
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet and take
full advantage of the features of your mobile
phone, here are a few definitions.
3G (3rd Generation)
The collective name used to describe mobile
systems able to support a wide range of Mobile
Internet services, operating with greater
bandwidth than lower generation phones.
Bearer
Various mechanisms the network uses to
transmit voice and data.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Diverting
Ability to reroute calls to another number.
Call Holding
Ability to put one call on standby while answering
or making another call; you can then switch
between the two calls, as required.
Call Waiting
Ability to inform users that they have an
incoming call when engaged on another call.
Circuit-switched
A type of network in which a physical path is
obtained for and dedicated to a single connection
between two end-points in the network for the
duration of the connection. Telephone networks
are examples of circuit-switched networks.
Ordinary voice phone service is circuit-switched.
The telephone company reserves a specific
physical path to the number you are calling for
the duration of your call. During that time, no
one else can use the physical lines involved.
Z107Eng_Vodafone.book Page 120 Friday, October 22, 2004 5:04 PM
Glossary
121
CLI (Caller Line Identification) Services
Services allowing subscribers to view or block the
telephone numbers of callers.
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a
mobile telephone network. GPRS guaranties
continuous connection to the Internet for mobile
phone and computer users. It is based on Global
System for Mobile Communication (GSM) circuit-
switched cellular phone connections and the
Short Message Service (SMS)
.
GSM
(Global System for Mobile Communication)
International standard for cellular
communication, guaranteeing compatibility
between various network operators. GSM covers
most European countries and many other parts
of the world.
Java
Programming language generating applications
that can run on all hardware platforms, whether
small, medium, or large, without modification. It
has been promoted for and geared heavily to the
Web, both for public web sites and Intranets.
When a Java programme runs from a web page,
it is called a “Java applet.” When it is run on a
mobile phone or pager, it is called a “Midlet.”
MMS (Multimedia Message Service)
A message service for the mobile environment,
standardised by the WAP Forum and the 3rd
Generation Partnership Program (3GPP). For
phone users, MMS is similar to Short Message
Service (SMS) - it provides automatic, immediate
delivery of user-created content from phone to
phone. The message addressing used is primarily
phone numbers; thus the traffic goes from phone
to phone. MMS also provides support for e-mail
addressing, so that messages can also be sent by
e-mail. In addition to the text content of SMS,
MMS messages can contain still images, voice or
audio clips, and in time, also video clips and
presentation information.
Multiparty Calling
Ability to establish a conference call involving up
to six parties, including the initial user.
Packet-Switched
Z107Eng_Vodafone.book Page 121 Friday, October 22, 2004 5:04 PM
Glossary
122
A type of network in which relatively small units
of data called packets are routed through a
network based on the destination address
contained within each packet. Today’s Internet is
fundamentally a packet-switched network.
Whereas voice requires a smooth flow of traffic to
avoid echo and breakup, data can be cut into
small packets, with each being sent across the
network and reassembled at the final destination.
Packet-switched networks inevitably allows a
greater amount of users because it does not
require a dedicated open circuit. PDC-P in Japan,
GPRS in Europe, and all the future 3G networks
will be packet-switch.
PIN (Personal Identification Number)
Security code that protects the phone/SIM
against unauthorised use. The PIN is supplied by
the service provider with the SIM card. It may be
a four to eight-digit number and can be changed,
as required.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your
home area; when travelling for example.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small slot
on the back of the phone and is protected by the
battery.
SMS (Short Message Service)
Network service sending and receiving messages
to and from another subscriber without having to
speak to the correspondent. The message
created or received can be displayed, received,
edited, or sent.
UMTS (Universal Mobile
Telecommunications System)
A 3rd generation (3G) mobile communications
technology that promises data transmission
speeds of up to 2 megabits per second (Mbps).
Z107Eng_Vodafone.book Page 122 Friday, October 22, 2004 5:04 PM
123
Index
A
ABC mode, text input 32, 34
Access codes 111
Active folder 95
Alarm 51
Alert tone
call 92
effect 93
feedback 93
message 93
Alert type
call 92
message 93
Anniversary 89
Answering a call 23
Anykey answer 96
Applications
downloading 53
explorer 42
memory status 108
switching 20
Auto redial 100
B
Background image 97
Backlight 94
Barring password 112
Barring, calls 98
Battery
charging 15
installing 14
low battery indicator 16
precautions 114
removing 15
Battery charger 16
Bookmark 64
Brightness
LCD 94
picture 44
video 46
Browser
ending 63
launching 63
menus 64
setting 66
C
Calculator 50
Calendar 87
Call costs 54
Call log 53
all 53
dialled 53
missed 53
received 53
Call times 55
Caller ID 97
Callsanswering 23
barring 98
diverting 98
ending 23
holding 24
making 21
rejecting 23
waiting 100
Camera 42
camera mode, set 44
recording videos 45
taking pictures 43
video mode, set 46
Characters, enter 32
Charging a battery 15
Clockdigital clock 97
world clock 50
Closed user group (CUG) 100
Conference call 26
Contacts
groups 60
memory status 108
Z107Eng_Vodafone.book Page 123 Friday, October 22, 2004 5:04 PM
Index
124
searching 56
viewing 59
Converter 51
CUG 100
D
Date, set 107
Deleting
calendar event 87
call log 54
contact 56
E-mail 75
image file 85
melody/tone 86
message 74
multimedia files 83
picture 43
today’s event 88
video 45
Dialled calls 53
Display
brightness 94
external 12
icons 11
layout 10
settings 96
Diverting, calls 98
Drafts 76
DTMF tones 29
E
Effect tones 93
Email box 75
Emergency call 6, 117
Ending a call 23
Ext. Light 94
External display 12
setting 97
External light 12
F
FDN mode 105
Flash mode 45
Forwarding
e-mail 75
messages 74
G
Greeting message 96
Groups, contacts 60
H
Health and safety 113
Holding, calls 24
I
Icons, description 11
Image files 84
Inbox 74
Infrared 96
International call 21
Internet 63
K
Key tone 24
Keysdescription 9
location 8
L
Language 94
Locking
Phone 104
PIN 105
privacy 106
SIM 105
Low battery indicator 16
M
Maintenance 119
Media player 47
Memo 90
Menu style 97
Menus
accessing 37
list 40
Messages 67
drafts 76
Z107Eng_Vodafone.book Page 124 Friday, October 22, 2004 5:04 PM
Index
125
inbox 74
memory status 82
multimedia 68
outbox 76
settings 78
templates 77
text 68
Microphone, mute 28
Missed calls 53
MMS (Multimedia Message
Service) 67
Multimedia files 83
Multimedia message 68
Music files 85
My items 83
My name card 62
N
Names
searching/dialling 56
Network selection 102
Number mode, text input 32, 36
Numbers, phone
searching/dialling 56
O
On/Off switch 17
Organiser 87
Own number 108
P
Password
barring 99, 112
phone 106, 111
Phone
care and mainenance 119
display 10
icons 11
keys 9
layout 8
locking 104
password 106, 111
resetting 108
safety information 113
switching on/off 17
unpacking 7
Pictures, take 43
PIN 106, 111
PIN lock 105
PIN2 107, 112
Problems, solve 108
Profiles 56
PUK 112
PUK2 112
R
Received calls 53
Rejecting a call 23
Reset settings 108
Resetting phone 108
Ringtone 92
Road safety 115
S
Safety
information 113
precautions 5
road 115
Schedule 88
Security 104
Settings 92
browser 66
call 97
capture mode 44
date & time 107
display 96
media player 48
message 78
network 102
phone 94
record mode 46
security 104
sounds 92
Short cuts 95
SIM card
inserting 13
locking 105
Z107Eng_Vodafone.book Page 125 Friday, October 22, 2004 5:04 PM
Index
126
removing 14
Skin colour 97
SMS (Short Message Service) 67
Solving problems 108
Sound mode 92
Speed dial 61
Swiching on/off
microphone 28
phone 17
Symbol mode, text input 32, 36
T
T9 mode, text input 32, 33
Task list 90
Template message 77
Text input modes 32
Text message 67
Text, enter 32
Time, set 107
Today’s event 88
Tone volume 93
Tones
call connect tone 93
call end tone 93
effect sounds 93
folder open/close 93
key tones 93
minute minder 93
popup box alerts 93
power on 93
ringtone 92
Travel charger 15
U
Unpacking 7
V
Video call 29
making 29
options 30
PIP 30
receiving 30
Video files 85
Videos, record 45
Viewing Contact Info. 59
Voice mail 82
Volume, adjust
alert tones 93
earpiece 24
key tone 24, 93
W
Waiting call 25
Wake up alarm 51
Wallpaper 97
