AH68-01292B (Rev 3.0)
Samsung Electronics America Inc.
105 Challenger Road, Ridgefield Park, N.J. 07660
SERVICE DIVISION
400 Valley Road, Suite 201
Mount Arlington, NJ 07856
TEL: 1-800-SAMSUNG (1-800-726-7864)
http://www.samsungyepp.com
MP3 & WMA Playback
Removable Storage Device
Encoding Function
3D Sound
Upgradable
FM Reception
Cover-55-America 7/25/03 4:26 PM Page 2
3
Contents
2
Safety Instructions ................................................................................................................4
Features ................................................................................................................................6
Components ..........................................................................................................................9
Location of Controls (yepp) ..................................................................................................10
Preparations
Listening to Music with yepp ................................................................................................32
Setting up Volume/Hold Functions ......................................................................................33
Changing Modes ..................................................................................................................34
Recording Voice....................................................................................................................35
MP3 Encoding ....................................................................................................................36
Searching for Music/Voice Files ..........................................................................................38
Listening to FM Radio ..........................................................................................................40
FM Encoding ........................................................................................................................42
Basic Usage
Loop Repeating ....................................................................................................................43
Setting up SRS ....................................................................................................................44
Setting up MENU..................................................................................................................45
Repeating Tracks ................................................................................................................46
Setting up EQ ......................................................................................................................47
Managing Files ....................................................................................................................48
●Deleting ......................................................................................................................48
●Formatting ..................................................................................................................49
Setting up DIRECT PLAY ....................................................................................................50
Customizing Options (Display) ............................................................................................51
●DISPLAY ....................................................................................................................52
●BACKLIGHT................................................................................................................52
●BEEP ..........................................................................................................................53
●CONTRAST ................................................................................................................53
●SCROLL SPEED ........................................................................................................54
●POWER OFF TIME ....................................................................................................54
●DEFAULT VOLUME ....................................................................................................55
●WOW LEVEL ..............................................................................................................55
●ENCODE ....................................................................................................................56
Additional Usage
Description of Buttons (yepp player) ....................................................................................58
MENU Table ........................................................................................................................60
Appendix
Troubleshooting ....................................................................................................................62
Specifications........................................................................................................................64
Safety Information ................................................................................................................66
Warranty ..............................................................................................................................68
Customer Support
Connecting yepp to PC ........................................................................................................12
Manual Installation of USB Driver ........................................................................................16
Using the removable storage(PC) ........................................................................................20
●Downloading/Uploading files ......................................................................................20
●Disconnecting the USB cable ....................................................................................21
●Formatting ..................................................................................................................22
Installing yepp studio ............................................................................................................23
●To View Help on yepp studio ......................................................................................25
Connecting yepp to Macintosh ............................................................................................26
Using the removable storage(Macintosh) ............................................................................29
●Downloading/Uploading files ......................................................................................29
●Disconnecting the USB cable ....................................................................................30
●Formatting ..................................................................................................................31
Connection to Computer
55-eng-new 7/25/03 3:40 PM Page 2
5
Safety Instructions
4
Read and understand all the instructions to avoid injury to yourself and damage to the equipment.
Do not expose to extreme
temperatures (above 95°F or
below 23°F). Do not expose to
moisture.
Do not apply excessive pressure
to the device. Do not let any foreign matter spill
into the device.
Do not place heavy objects on top
of the device. Do not expose to chemicals such
as benzene and thinners. Remove batteries when the
device is left unused for a long
period of time.
Do not expose to direct sunlight
or heat sources. Do not store in dusty areas. Do not try to disassemble and
repair the device yourself.
Earphones
Follow Traffic Safety Instructions
●Do not use the earphones while driving an automobile or riding a bicycle.
It’s not only dangerous, but also against the law.
●It may cause an accident if you turn up the volume of the earphones while walking down the street,
especially crossing at intersections.
Protect your ears
●Do not turn up the volume too high.
Doctors warn against prolonged exposure to high volume.
●Stop using the device or turn the volume down if you have ringing in your ears.
Environmental Information
●Follow local guidelines for waste disposal when discarding packages, batteries, and old
electronic appliances.
●Yepp packages use cardboard, polyethylene etc., and do not use any unnecessary materials.
Ambient operating conditions
●Ambient temperature:
5°C ~ 35°C (41°F ~ 95°F)
Humidity : 10 ~ 75%
55-eng-new 7/25/03 3:40 PM Page 4
Removable Storage Device
You can easily copy and paste files to the yepp player using
Windows Explorer.
Featuring an Encoding Function
You can make a MP3 file out of an source using the ENC jack
on the main unit.
You can also convert an FM radio program into an MP3 file in real time.
Upgradable
You can upgrade the built-in programs when available.
Add functions, CODEC, etc.
Please check the yepp home page (
http://www.samsungyepp.com
)
for upgrades.
MP3 & WMA Playback
MP3 is an MPEG1 Layer3 audio format.
WMA is a Microsoft Windows Media audio format.
FM Reception
Listening to an FM program is made easy with Auto Search and
Frequency Memory functions.
Featuring 3D Sound
The 3D feature adds spaciousness to the sound.
55-eng-new 7/25/03 3:40 PM Page 6
Components
9
Voice Recording Function
You can do a Voice Recording with high quality and use it for a conference.
Sound
You can adjust equalizer manually.
15-Hour Continuous Play
This unit uses one AAA/LR03 alkaline battery. Operation can last up to 15 hours.
Actual playing time may vary according to the type and capacity of the battery.
Player
Earphone User manual
Carrying case
One Battery
(1.5V AAA/LR03 type)
USB Cable
Direct Connect
USB Adaptor Line Cable
Installation CD
MODE
REC / ENC
VOL
Neck Strap
●The capacity of the useable built-in memory is less than indicated as the internal
firmware uses a part of the memory as well.
●Design of accessories is subject to change for improvement without notice.
Model
Built-in memory
YP-55 V
256MB
AH30-00056B AH39-00498A AH68-01292B AH80-00049B
AH39-00488A
AH39-00489A
AH61-01369A
AH61-01370A
4301-000115
55-eng-new 7/25/03 3:40 PM Page 8
00:01:30 001
Get Original, Black Eyed
NOR
NOR
MODE
REC / ENC
VOL
YP-55
128 MB
HOLD
11
Location of Controls (yepp)
10
Display
Earphone Jack
Microphone
Neck strap Hook
Display
Voice Recording Button
Hold Switch
ENC Jack
USB Cable
Connection Port
Battery Cover
Volume Button
Play/Stop/Pause Button Move to Track/
Speed Search Lever
Remaining Battery
Power indicator
Playtime indicator
Track Number indicator
Equalizer, SRS indicator
Title (track & artist) indicator
Repeat A-B indicator
Music/Voice/FM indicator
Play mode indicator
MENU/Loop Repeating Button
WOW Button
Inserting a Battery
How to Use the Carrying Case
Slide the cover in
the direction of the
arrow to open.
1
Insert a battery to the right
poles + , – and push-close
the cover in the direction
the arrow as indicated.
2
N
No
ot
te
e
:
:
●Do not place heavy objects on the cover.
➪
➡
Ϋ
Use as follows.
55-eng-new 7/25/03 3:40 PM Page 10
13
Connecting yepp to PC
12
Before connecting yepp to PC, make sure to install
USB driver. If “Add New Hardware Wizard” appears,
press the [Cancel] button and install USB driver.
System Requirements.
● Pentium 133MHz or greater
● Windows 98 SE/ME/2000/XP
● 20MB of available hard disk space
● CD-ROM drive
(double speed or greater)
● USB port (1.1) supported
● VGA graphic
Installing software
Insert the Installation CD into CD-ROM drive.
The picture shown below appears.
Select [USB Driver Install].
1
N
No
ot
te
e
:
:
●Install the operating system in Administrator
Account mode for Windows 2000 or XP.
Otherwise, installation will not be completed.
● Windows ME, 2000 and XP can recognize
the driver without installing the provided
program. However, you must install the
program in order to format yepp and
upgrade firmware.
●
If the YP-55 program has not been
installed in Windows 98, then it will not
communicate with your removable disk.
You must install the USB driver file first.
Click [Next] in the series of windows that appear.
2
When installation is completed,
connect yepp to PC and use it
as shown on the next page.
Continued...
55-eng-new 7/25/03 3:40 PM Page 12
1514
Connecting yepp to PC with USB cable
MODE
REC / ENC
VOL
When USB driver is not Installed automatically,
refer to next page.
7
Upon installation of the USB driver
"SAMSUNG YP-55”
will appear in the
[System Properties] ➝ [Device Manager].
6
N
No
ot
te
e
:
:
How to check USB driver
How to check USB driver
Windows 98:
Control Panel ➝ System ➝ Device Manager ➝
Universal Serial Bus controllers/Samsung YP-55 Class
Windows 2000:
Control Panel ➝ System ➝ Hardware ➝
Device Manager ➝
Universal Serial Bus controllers
➝
USB Mass Storage Device
Windows XP:
Control Panel ➝ System ➝ Hardware ➝
Device Manager ➝
Universal Serial Bus controllers
➝
USB Mass Storage Device
USB connect cable
Plug one end of the USB cable into the USB
port on the back of the PC.
3
Connect the opposite end of the USB cable to the
USB cable port on the bottom of the yepp.
●If you disconnect the USB cable from your PC while
implementing a command or initializing during USB driver
installation, your PC may not function correctly.
●
The yepp will automatically turn on.
4
USB driver is installed with a message saying that it
is searching for a new device. You may not see the
display screen during installation.
Go to the device manager to check that installation
has been successfully completed.
5
N
No
ot
te
e
:
:
For WinXP, the following window will appear whenever
you connect the USB cable to your yepp.
55-eng-new 7/25/03 3:40 PM Page 14
17
Manual Installation of USB Driver
16
Go to “Downloading/Uploading files” on page 20 if the USB driver is in place.
Follow these steps if the USB driver is not in place :
Check the device manager.
Windows 98,ME:
Control Panel ➝ System ➝ Device Manager
Windows 2000:
Control Panel ➝ System ➝ Hardware ➝
Device Manager
Windows XP:
Control Panel ➝ System ➝ Hardware ➝
Device Manager
1
Check if there is a device listed with
an exclamation point or a question
mark (displayed as unknown device
or USB device).
2
Double click on the device listed with an
exclamation point or a question mark.
3
After selecting the driver, click on [Update Driver].
4
Select a compatible driver, click on [Next] to finish.
5
For Windows 98, refer to page 18.
Continued...
N
No
ot
te
e
:
:
●If you are using Windows 2000 and your version of Windows does not recognize the USB driver
please download and install the latest service pack from windowsupdate.microsoft.com
●
The installation method may vary depending on the type of PC or operating system.
Contact your PC dealer or service center for installation information.
●
If errors occur continuously when you install the USB driver, reconnect the USB cable
after rebooting your system.
55-eng-new 7/25/03 3:40 PM Page 16
1918
● You must reboot your computer
to complete the installation.
Click [Next] button in the series of windows that appear.
In Windows 98
USB driver location
[CD ROM]\setup\Drivers
55-eng-new 7/25/03 3:40 PM Page 18
21
Using the removable storage
20
Downloading/Uploading files
Turn on the yepp and connect yepp to PC.
1
Open Windows Explorer on PC.
2
Select the file to save and drag-and-drop it into the removable disk icon.
(In numerical, alphabetical order)
3
N
No
ot
ti
ic
ce
e
:
:
●The “WRITING/READING” message will appear during file
download or upload. Disconnecting the USB cable while
“WRITING/READING” is displayed may cause malfunction
of the unit.
●Files within a user created folder can only be played in
Music Mode.
●The order of music files is not relative to the replay order
when you select a Removable Disk in Windows Explorer.
Disconnecting the USB cable
Double-click on the green arrow
in the taskbar on the bottom
right of the window. Disconnect
the USB cable.
After completing the file transmission, you must disconnect the cable in the following way:
1
Select the USB device, and then
press the [Stop] button.
2
Continued...
N
No
ot
te
e
:
:
The green arrow is not displayed on the Task Bar in
Windows 98 system. If “READY” message is shown in
Display window, please disconnect the USB cable.
55-eng-new 7/25/03 3:40 PM Page 20
Installing yepp studio
2322
Formatting
Select the removable disk icon
and click the right mouse button
to select [Format].
1
Press the [Start] button.
●All saved files will be formatted.
●You can change the name of
removable disk by selecting
[Volume label].
2
N
No
ot
ti
ic
ce
e
:
:
●If you format yepp in the PC without installing the provided program, it may not read the data.
●Care must be taken as formatted files can not be recovered.
●By formatting, all previously preset menus will be initialized.
N
No
ot
te
e
:
:
●You can format by executing "YP-55 Format" located under [Start] ➔[All Programs]
Continued...
Insert the Installation CD into CD-ROM drive.
Select [yepp studio].
1
Select language
2
55-eng-new 7/25/03 3:40 PM Page 22
2524
Click [Next] in the series of windows that appear.
●Please refer to Help for more information on how to use Yepp Studio.
3
To View Help on yepp Studio:
Run Yepp Studio and press F1.
●
Help will appear.
Move the arrow to the top of yepp Studio and right click on the
mouse. The following selection window will appear.
●
Click on Help and the Help window will appear.
➪
N
No
ot
te
e
:
:
●Music recognition technology and related data are provided by Gracenote and Gracenote CDDB®
Music Recognition ServiceSM.
●CDDB is a registered trademark of Gracenote. The Gracenote logo and logotype, the Gracenote
CDDB logo and logotype, and the "Powered by Gracenote CDDB" logo are trademarks of
Gracenote. Music Recognition Service and MRS are service marks of Gracenote.
55-eng-new 7/26/03 2:18 PM Page 24
27
Connecting yepp to Macintosh
26
System Requirements.
●20MB of available hard disk space
●System Memory 64MB or greater
●CD-ROM drive
(double speed or greater)
●USB(1.1) port supported
●Macintosh OS 9.X/10.2.6
Installing software
Insert the Installation CD into CD-ROM drive.
The picture shown below appears.
Select [Samsung YP-55 Installer].
1
After installation is complete, click on the OK button.
2
Continued...
N
No
ot
te
e
:
:
●The driver can be recognized by
Machintosh without installing an extra
program. The appropriate program
however must be installed to format and
upgrade the firmware.
●You cannot install softwares for YP-55 in
Macintosh OS 10.0 - 10.2.5.
❈When you install a program in Macintosh OS X, it
may check the user login information.
55-eng-new 7/25/03 3:40 PM Page 26
Using the removable storage
2928
Connecting yepp to Macintosh with USB cable
MODE
REC / ENC
VOL
USB connect cable
Plug one end of the USB cable into the
USB port on the back of the Macintosh.
3
Connect the opposite end of the USB cable to
the USB cable port on the bottom of the yepp.
●
The yepp will automatically turn on.
●
A untitled or unlabelled portable disc is created.
4
Downloading/Uploading files
Turn on the yepp and connect yepp to Macintosh.
1
A untitled or unlabelled portable disc will appear on the
Macintosh screen.
2
Select the file to save and drag-and-drop it into the removable disk icon.
3
N
No
ot
ti
ic
ce
e
:
:
●The “WRITING/READING” message will appear during file
download or upload. Disconnecting the USB cable while
“WRITING/READING” is displayed may cause malfunction
of the unit.
●Make sure to empty the trash after deleting a file from the
portable disc in order to free up space to download
additional files.
Continued...
55-eng-new 7/25/03 3:40 PM Page 28
3130
Disconnecting the USB cable
Drag and drop the portable disc to the trash.
After completing the file transmission, you must disconnect the cable in the following way:
1
Disconnect the USB cable.
●Disconnecting without deleting the portable disc may cause a malfunction.
2
Formatting
Click on Application Program and
select [Samsung YP-55 Formatter].
1
Press the [Start] button.
●All saved files will be formatted.
●You can change the name of
removable disk by selecting
[Volume label].
2
N
No
ot
ti
ic
ce
e
:
:
●If you format yepp in the Macintosh without installing the provided program, it may not read the data.
●Care must be taken as formatted files can not be recovered.
●By formatting, all previously preset menus will be initialized.
55-eng-new 7/25/03 3:40 PM Page 30
Setting up Volume/Hold Functions
33
Listening to Music with yepp
32
First, insert the battery and connect the earphones to the player.
Playing Music
(Power On) Stopping Music
(Power Off)
When you press the button, the
yepp logo appears and a music/voice
file is played.
When you press the button while playing,
the music stops. If no buttons are pressed within
10 seconds (changes depending on settings), the
yepp automatically powers off.
●
You can also turn off the power by pressing and
holding the button on the main body.
N
No
ot
te
e
:
:● WMA files can only be played at bit rates between 48Kbps and 192Kbps.
[supplied by Windows Media Player (Ver 8.0)] WMA files less than 48Kbps may not be played.
● Power off time can be set in the MENU mode.
00:01:30 001
Get Original, Black Eyed
NOR
NOR
FREE MEMORY
114.37 MB
00:01:30 001
Get Original, Black Eyed
NOR
NOR
GOOD BYE
00:01:30 001
20
NOR
NOR
00:01:30 001
20
NOR
NOR
Adjusting the Volume
HOLD Function
Move the button on the side of the yepp
player to adjust the volume while playing.
N
No
ot
te
e
:
:
●Volume ranges from 00 to 30.
●Press to adjust the volume by one level.
Press and hold to increase or decrease the volume
in greater increments.
Under Hold mode, buttons will not work.
Slide the switch on the player in the
direction of the arrow.
❈When a button is pressed, “ HOLD!” message
will appear on the display.
HOLD
55-eng-new 7/25/03 3:40 PM Page 32
Recording Voice
35
Changing Modes
34
N
No
ot
te
e
:
:●You will exit from the Mode Switching function if no action is taken for 15 seconds or if
another button is pressed during mode switching.
●The Voice Mode settings will not be saved if the mode is switched to the Music or FM
modes or if the power is turned OFF.
To Record Voice
Slide the switch to the ENC position to begin Voice Recording.
1
Press the button briefly while the player is stopped.
1
To stop the recording, move the switch in the opposite
direction and a new voice file will be created.
2
001
00:00:02 001
V002. WAV
00:00:30
V002. WAV
00:00:00 001
NOR
NOR
V
V001. WAV
MUSIC VOICE FM
MUSIC VOICE FM
MUSIC VOICE FM
FM
MODESELECT
MODESELECT
MODESELECT
N
No
ot
te
e
:
:
●Recording is done in the order of V001,V002..…
●If the Memory is full, the Voice Recording is stopped automatically.
●The Voice Recording is also enabled in Music Mode.
●The backlight will not illuminate during a Voice Recording.
● The number of saved voice files and hours available for recording will be displayed
when Voice Mode is selected while the player is stopped.
● To Record Voice, be sure nothing is connected to the ENC jack.
● Voice Recording does not work in FM Mode or when the Line cable is connected.
Move to the mode you want by using the button, and then
press the button.
2
REC/ENC
REC/ENC
Music Mode
Voice Mode
FM Mode
55-eng-new 7/25/03 3:40 PM Page 34
37
MP3 Encoding
36
Connect the Audio Output port on the external audio source (or the Line
Out port) to the ENC port on the device with the Line cable.
1
Slide the switch to the ENC position begin MP3 encoding.
2
Slide the switch to the REC position while recording to stop
the encoding, and a new encoding file will be created.
●
Recording will take place in the order of L001, L002, L003…. When the recording
is finished, the files will be saved as MP3 files.
3
N
No
ot
te
e
:
:
●Bit Rates can be set within the range of 32Kbps~128Kbps.
●To pause during Encoding, press the button.
Press the button once again to recommence recording.
●Volume can be adjusted from level 0 to 10 while monitoring the Encoding.
N
No
ot
ti
ic
ce
e
:
:
●Do not disconnect the Line cable during Encoding.
●If the battery is not charged enough, encoding will not be done.
●Adjust the volume of the external audio source to a suitable level and encode it.
If the volume level is extremely high, the sound quality may not be good.
REC/ENC
REC/ENC
55-eng-new 7/25/03 3:40 PM Page 36
39
Searching for Music/Voice Files
38
Searching for Specific Parts in PLAY Mode
●To find a certain track, turn the lever to the
up or down during play.
●Release the lever and the lever will return to its original
position. Playing will recommence in the normal way.
Searching for Music Files in
PLAY Mode.
●The next track will play if you turn the
lever to the direction during play.
●
To move to and play the previous track, turn
the lever to the direction within 5 seconds of
the beginning of play. To move to and play
the current track from the beginning, turn the
lever to the direction 5 seconds after the
beginning of play.
N
No
ot
te
e
:
:
● VBR(Variable Bit Rate) file:
MP3 file whose compression rate
changes when played.
● With VBR files, Turning the
lever to the direction within 5
seconds from the start of the track
may not result in the previous track
playing.
● With VBR files, the actual running
time may differ from that of the
player display.
● This player may not play back
MPEG1 LAYER1 files.
00:01:30 001
Get Original, Black Eyed
NOR
NOR
00:04:30 001
Get Original, Black Eyed
NOR
NOR
00:00:15 001
Get Original, Black Eyed
NOR
NOR
00:01:30 002
End of the World, Cold
NOR
NOR
00:00:01 003
Girl Inside, Blues Traveler
NOR
NOR
00:00:01 001
Get Original, Black Eyed
NOR
NOR
00:01:30 002
End of the World, Cold
NOR
NOR
00:00:01 003
Girl Inside, Blues Traveler
NOR
NOR
00:00:01 001
Get Original, Black Eyed
NOR
NOR
Searching for Music Files
in STOP Mode.
Turn the lever to the up or down while the
player is stopped. It moves to the
track and plays it.
55-eng-new 7/25/03 3:40 PM Page 38
41
Listening to FM Radio
40
While the player is stopped, select FM Mode by using the button.
Turn the lever briefly to find the
frequency you want.
Manual Search for a Frequency
99.1 MHz
FM
MO
FREE CH
Upon finding a frequency you want,
press the button to store the
frequency.
Manual Storage of a Frequency
99.1 MHz
FM
MO
CH 02
● Press and hold the WOW button
while in FM Mode.
●Frequencies within the range of
88MHz to 108MHz are automatically
selected and stored.
●
Frequencies are automatically stored,
starting from 1.
Automatic Storage of a Frequency
● Press the WOW button briefly while in FM Mode.
●The stored frequencies are successively searched.
Searching Stored Frequencies
● Press and hold the button while
in FM Mode.
●As soon as ‘MUTE’appears on the
display no sound will be heard.
●To cancel the MUTE function, adjust
the volume with Switch.
MUTE Function
89.1 MHz
FM
SET
A
UTO
P
RESET
1
Turn and hold the lever to
automatically find and tune in to a
transmitted frequency.
Automatic Search for a Frequency
89.1 MHz
FM
MO
CH 01
99.1 MHz
FM
MO
CH 02
100.7 MHz
FM
MO
CH 03
99.1 MHz
FM
MO
99.1 MHz
FM
MO
FREE CH
FREE CH
MUTE
99.1 MHz
FM
AUTO
SEARCHING
Number of Channels to be Stored
N
No
ot
te
e
:
:
●To exit from FM Mode, press the button.
●Mono (MO) or Stereo (ST) is automatically selected.
N
No
ot
te
e
:
:
●You can store up to 20 frequencies.
●You can replace an existing frequency with a new one but you
cannot delete a stored frequency.
55-eng-new 7/25/03 3:40 PM Page 40
Loop Repeating
43
FM Encoding
42
FM Encoding to MP3
Slide the switch to the ENC
position during FM
●
Encoding of the currently transmitted
FM broadcast begins.
1
Slide the switch to REC.
●
A file is created and the encoding stops.
●
Files are saved in order of F001, F002,
F003… and stop automatically when the
memory is full.
2
00:01:00 001
F001. MP3
00:01:00
F001. MP3
Loop Function
Starting Point
While playing music files, press the
button briefly at the beginning
of the loop you want to set.
A appears in the display.
N
No
ot
te
e
:
:
●Press the button briefly to cancel the loop.
●Loop Repeat is automatically released if you Speed Search with button.
Ending Point
00:01:30 001
Get Original, Black Eyed
NOR
NOR
00:02:30 001
Get Original, Black Eyed
NOR
NOR
Press the button briefly
again to set the end of the loop.
appears in the display.
The loop is played repeatedly.
REC/ENC
REC/ENC
55-eng-new 7/25/03 3:40 PM Page 42
Setting up MENU
45
Setting up SRS (Sound Retrieval System)
44
● PLAY MODE : To select track repeating mode.
● EQUALIZER : To use equalizer function.
● FILE : To delete or format music files.
● DIRECT PLAY : It plays files encoded in Music, FM or Line.
● SETTING : To change the basic setup options of the display.
● EXIT : To exit MENU.
● SRS : You will hear 3D Stereo sound.
● TRUBASS: This is a bass boost feature that adds fullness to the sound.
● WOW : This feature allows you to enjoy the SRS and Trubass features simultaneously.
● EQ : Plays at the last EQ setting you made.
To switch to Menu Mode, press and hold the button while in
Music/Voice Mode.
Press the button briefly to select the menu you want.
To exit from Menu Mode, press and hold the button once again.
N
No
ot
te
e
:
:
● In MENU mode, no input for 15 seconds will cancel the MENU mode.
● Menu mode will be released if any button other than the MODE button is pressed.
N
No
ot
te
e
:
:
● is a trademark of SRS Labs, Inc.
WOW technology is incorporated under license from SRS labs, Inc..
● Please adjust the volume to a suitable level, as the volume may increase in the SRS setting.
● This unit supports sampling frequencies of 32KHz, 44.1KHz or 48KHz.
● You can set SRS functions only in Music Mode.
PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT
PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT
PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT
PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT PLAY MODE EQUALIZER FILE
DIRECT PLAY SETTING EXIT
MENU MENU MENU
MENU
MENU
MENU
SRS TRUBASS
WOW EQ
SRS TRUBASS
WOW EQ
SRS TRUBASS
WOW EQ
SRS TRUBASS
WOW EQ
EQ
SOUNDEFFECT SOUNDEFFECT
SOUNDEFFECT
SOUNDEFFECT
Press the WOW button while in Music Mode.
1
Press the WOW button to move, and then press and hold
the SRS button to select the mode you want.
2
SRS
WOW
55-eng-new 7/25/03 3:40 PM Page 44
Setting up EQ
47
Repeating Tracks
46
Track Repeating Function EQ Function
In MENU, select PLAY MODE. (refer to “Setting up MENU”)
1
In PLAY MODE, use the button to move to the mode you
want and press the button to select.
2
● INTRO: To play the first 10 seconds of each track.
● NORMAL: To play all the tracks in order one time.
● REPEAT ONE: To repeat one track.
● REPEAT ALL: To repeat all tracks.
● SHUFFLE: To play tracks at random.
● EXIT: To move to the upper menu.
INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT
INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT
ALL INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT
ONE
INTRO NORMAL REPEAT ONE
REPEAT ALL SHUFFLE EXIT
PLAY MODE PLAY MODE PLAY MODE
PLAY MODEPLAY MODEPLAY MODE
In MENU, select EQUALIZER. (refer to “Setting up MENU”)
1
In EQ, use the button to move to the setting you
want (out of the 4 settings) and press the button to select.
● Select the DBB Mode if you want to fine-tune the sound.
2
N
No
ot
te
e
:
:
●DBB is for Dynamic Bass Booster, which enhances bass response.
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
CLASS
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
BASS TREBLE EXIT
USER
NORMAL CLASS JAZZ ROCK
DBB USER EXIT
EQUALIZER
NOR
If you want to manually adjust the equalizer, select User and Bass/Treble.
● The adjustment range of Bass/Treble is 0 to 10.
3
55-eng-new 7/25/03 3:40 PM Page 46
49
Managing Files
48
Deleting
In MENU, select FILE. (refer to “Setting up MENU”)
1
In FILE, select DELETE and the mode (Music or Voice)
the target file is in.
2
Move to the file you want to delete and then press the button.
Select CONFIRM and then select CANCEL to exit from the setup.
3
DELETE FORMAT EXIT
FILE
MUSIC VOICE FM ENC
LINE ENC EXIT
DELETE DELETE
001-Get Original, Black Ey
Get Original, Black Eyed
CONFIRM CANCEL
COMPLETED
CONFIRM CANCEL
MUSIC
MUSIC
MUSIC
Formatting
In MENU, select FILE. (refer to “Setting up MENU”)
1
In File, select FORMAT.
2
N
No
ot
te
e
:
:
●All files will be deleted when formatting the built-in memory.
●It is recommended that formatting be carried out on a PC that has the provided
program installed as formatting in the Menu may take a long time.
DELETE FORMAT EXIT
FORMAT
CONFIRM CANCEL
FORMAT
55-eng-new 7/25/03 3:40 PM Page 48
Customizing Options (Display)
51
Setting up DIRECT PLAY
50
DIRECT PLAY Function
In MENU, select DIRECT PLAY. (refer to “Setting up MENU”)
●Set the player to this function for playing MP3 and FM encoded songs.
1
In DIRECT PLAY, move to the mode you want by pressing the button,
and then press the button to select.
2
● MUSIC: To play music files that are downloaded in the music folder
● FM ENC: To play encoded files in the FM ENC folder
● LINE ENC: To play encoded files in the LINE ENC folder
● EXIT: To move to the previous menu
DIRECT PLAY
MUSIC FM ENC LINE ENC
EXIT
DIRECT PLAY
MUSIC FM ENC LINE ENC
EXIT
DIRECT PLAY
MUSIC FM ENC LINE ENC
EXIT
DIRECT PLAY
MUSIC FM ENC LINE ENC
EXIT
Setting Function
In MENU, select SETTING. (refer to “Setting up MENU”)
1
In SETTING, use the button to move to the function you
want to change and select the function by using the button.
2
SETTING
DISPLAY BACK LIGHT BEEP
CONTRAST SCROLL SPEED
SETTING
DISPLAY BACK LIGHT BEEP
CONTRAST SCROLL SPEED
SETTING
DISPLAY BACK LIGHT BEEP
CONTRAST SCROLL SPEED
SETTING
DISPLAY BACK LIGHT BEEP
CONTRAST SCROLL SPEED
SETTING
DISPLAY BACK LIGHT BEEP
CONTRAST SCROLL SPEED
SCROLL
SPEED
SETTING
POWER OFF TIME DEFAULT VOL
WOW LEVEL ENCODE EXIT
SETTING
POWER OFF TIME DEFAULT VOL
WOW LEVEL ENCODE EXIT
DEFAULT
SETTING
POWER OFF TIME DEFAULT VOL
WOW LEVEL ENCODE EXIT
SETTING
POWER OFF TIME DEFAULT VOL
WOW LEVEL ENCODE EXIT
SETTING
POWER OFF TIME DEFAULT VOL
WOW LEVEL ENCODE EXIT
Continued...
55-eng-new 7/25/03 3:40 PM Page 50
5352
DISPLAY
● PLAY TIME: displays current play time
● REMAIN TIME: displays remaining play time
● USED SIZE: displays using memory
● FREE SIZE: displays remaining memory
BACK LIGHT
●Use the button to set the
Backlight “ON” time.
●
The setting range of Backlight-On Time is
0 to 10 seconds.
✽The backlight does not illuminate when the
residual battery level is insufficient.
Continued...
BEEP
●Use the button to set the
BEEP mode.
●BEEP ON: A beep sounds each time a
button is pressed.
●BEEP OFF: No beep sounds when a
button is pressed.
DISPLAY
PLAY TIME REMAIN TIME
USED SIZE
FREE SIZE
EXIT
BACK LIGHT
05
BEEP
ON OFF
CONTRAST
●Use the button to set the Contrast.
●The setting range of the contrast, which
adjusts the brightness of the screen, is
0 to 10.
CONTRAST
06
N
No
ot
te
e
:
:
●
No beep sounds while playing or recording of a
music/voice file even when set to ‘BEEP ON’.
55-eng-new 7/25/03 3:40 PM Page 52
5554
SCROLL SPEED
●Use the button to set the Scroll Speed.
●The setting range of the scroll speed, which
adjusts the speed of the track title flow,
is 0 to 10.
SCROLL SPEED
SCROLL
SPEED
06
POWER OFF TIME
●Use the button to set the Power Off Time.
●
The setting is
5 different levels ranging from
0 to 25 seconds.
The power will turn off after the
set time if no button is pressed when the
playback ends.
POW OFF TIME
5SEC
DEFAULT VOLUME
●Use the button to set the Default Volume.
●
The default volume setting range of the unit is
0 to 25. If the Volume is above 25(26-30) when
you turn the device off, it will default to 25 when the
device is turned back on.
●
If the Volume is set to 25 or lower when you turn the
device off, it will return to that setting when it is
turned back on.
DEFAULT VOL
DEFAULT
17
WOW LEVEL
●The levels of SRS and TRUBASS can be adjusted.
●
Select the mode you want by using the button.
●
The level for SRS and TRUBASS can each be set within the range of 0 to 10.
WOW LEVEL
SRS TRUBASS EXIT
SRS LEVEL
WOW LEVEL
SRS TRUBASS EXIT
Tru Bass LEVEL
01
01
N
No
ot
te
e
:
:
●
When ‘0 second’is set, the power will not turn off but
will remain in Standby Mode.
Continued...
55-eng-new 7/25/03 3:40 PM Page 54
5756
ENCODE
AUTO SYNC
●Use the button to set the
Encode AUTO SYNC.
●
ON: Automatically creates a file for each track.
●
OFF: All songs recorded in ENC mode are
saved in a single file.
AUTO SYNC
ON OFF
AUTO
SYNC
BIT RATE
●Use the button to set the
Encode BIT RATE.
●
When encoding music into an MP3 file, you can
select one of the following bit rates: 32Kbps,
48Kbps, 64Kbps, 96Kbps and 128Kbps.
BIT RATE
48Kbps
BIT RATE
32Kbps
BIT RATE
64Kbps
BIT RATE
96Kbps
BIT RATE
128Kbps
N
No
ot
te
e
:
:
●
What is Auto Sync?
Auto Sync senses the input sound during MP3 encoding.
If there is no sound, encoding stops automatically. Otherwise,
encoding keeps going. You can save MP3 files separately.
Example) If you encode a CD including 10 music files with MP3,
10 MP3 files are created automatically when set the Auto Sync to ON.
●
Auto Sync function can support from 64Kbps to 128Kbps.
55-eng-new 7/25/03 3:40 PM Page 56
59
Firmware Upgrade
58
Download the latest Firmware from www.samsungyepp.com
1
Install the latest Firmware program on your PC.
2
Connect to the USB port on your PC using the
USB cable or adapter while holding the play button
on the main body. If you press the Play button
more than 5 seconds, the “Player Recovery
Device” message is displayed on Device Manager
as shown in the picture on the right.
3
Run the upgrade program.
4
When the program is running, the screen
will show the progress.
5
The upgrade window will appear when the
Recovery process is complete. Ensure
that ‘Quick Download’is deselected. Click
Start to begin the upgrade.
6
The upgrade is complete.
7
Reconnect the USB for the driver to be newly recognized.
8
N
No
ot
te
e
:
:
●
If you do not release Quick Download, you cannot proceed to upgrade.
●
When the Quick Download is deselected, formatting will commence at the same time, and
the saved file will be deleted.
●
If your operating system is Windows 98, you will have to restart the YP-55 Upgrade program.
55-eng-new 7/25/03 3:40 PM Page 58
61
Description of Buttons (yepp player)
60
BUTTON STATUS
Power Off
Play
Cancel
Play the next track
Fast forward search in PLAY mode
Cancel MENU
Power On, and play
Pause(When no button is
pressed for 10 seconds, yepp
powers off automatically)
Press and hold the 2 seconds
Power Off.
MENU Mode
Play
Play
Less than 1 second
Longer than 1 Second
Stop/Pause Play the next track
Frequency Search
FM Mode
MENU Mode
RESPONSE
PRESSING LENGTH
Cancels Intro, returns to Play mode
Intro Play
Longer than 1 Second
Move MENU
Volume increase/decrease
Set the starting point for loop function
Loop mode
Cancel loop mode
Changing modes (music ↔ voice↔ FM)
Enter MENU
Selection/Exiting MENU
Voice recording
Voice Recording/Encoding Stop
MP3 Encoding
Fast reverse search in
PLAY mode
Longer than 2 Seconds
Play Short
Within 5 seconds from the start:
Play the previous track
After 5 seconds from the start:
Play the beginning of the current track.
Short
Short
Short
Short
Play
Stop/Pause Play the previous track
MENU Mode
Play or Stop Mode
Play
During Loop Setting
Loop Mode
Stop
Play or Stop Mode
MENU Mode
VoiceRecording/Encoding
Line in Connect
FM Encoding
FM Mode
Frequency Search
FM Mode
Volume
Mode
REC/ENC
Play or Stop Mode
55-eng-new 7/25/03 3:40 PM Page 60
63
MENU Table
62
SRS
TRU BASS
EXIT
BIT RATE
AUTO SYNC
EXIT
MENU
PLAY MODE
SETTING
EXIT
EQUALIZER
INTRO
NORMAL
REPEAT ONE
REPEAT ALL
SHUFFLE
EXIT
NORMAL
CANCEL
CONFIRM
VOICE
FM ENC
LINE ENC
EXIT
MUSIC
TREBLE
EXIT
BASS
CLASS
JAZZ
ROCK
USER
DBB
EXIT
FILE
DELETE
FORMAT
EXIT
DISPLAY
BACK LIGHT
BEEP
CONTRAST
SCROLL SPEED
POWER OFF TIME
DEFAULT VOL
WOW LEVEL
ENCODE
EXIT
DIRECT PLAY
MUSIC
FM ENC
LINE ENC
EXIT
PLAY TIME
REMAIN TIME
USED SIZE
FREE SIZE
EXIT
●Select with the button and move.
55-eng-new 7/25/03 3:40 PM Page 62
65
Troubleshooting
64
Backlight does not work.
●Check the backlight setup.
●When the battery power is low, the backlight will go out.
yepp does not work and the LCD displays nothing.
●Check the battery capacity
●Check to see if the battery is inserted to the right poles ( , )
The buttons do not work.
● Check setting of Hold switch.
●When the message "Please Reformat" is displayed, please format your
YP-55 by installing the software using Windows Explorer.
Files cannot be downloaded.
● Check to see if the driver is installed correctly in the computer.
● Check the connection between yepp and computer.
● Check and/or replace the battery, turn on the yepp's power.
● The Windows98 operating system limits the number of files you can save.
Please save your music files by creating a subfolder.
yepp keeps being turned off.
●In Stop mode, the power is automatically turned off after ten seconds
(changes depending on settings).
●Check to see if there are files saved in it.
Something’s wrong with play time displayed during Play mode.
●“VBR SONG” message is displayed while VBR (Variable Bit Rate) file is playing.
LCD window is dark
●Check Contrast
In PLAY mode, music is not played after pressing the button
●Check to see if MP3 or WMA files are saved in the built-in memory.
●Check to see if the HOLD switch is locked.
●Check if the REC button is on.
●Check if the memory is full.
55-eng-new 7/25/03 3:40 PM Page 64
Memo
67
Specifications
66
Model
Built-in Memory capacity
Voltage
Playing time
Dimensions/Weight
Case
Noise Ratio
Earphones Jack Output Power
Output Frequency Range
Operating Temperature Range
FM Frequency
FM Signal to Noise Ratio
FM T.H.D
FM Useable Sensitiivity
File Support
YP-55
256MB(YP-55 V)
1.5V✕1 (AAA/LR03 size alkaline battery)
lasts up to 15hours (Alkaline battery, MP3 128Kbps, Vol level 20)
1.02 ✕ 3.19 ✕ 1.02 inches/1.6oz (without battery)
Plastic/Aluminum
80dB with 20kHz LPF (1KHz 0dB)
5mW(Max 10mW)/CH (16 Ω)
20Hz~20kHz
-5 ~ +35˚C (23 ~ 95F)
88.0 ~ 108.0 MHz
45 dB
1%
10 dB
MPEG1/2/2.5 Layer3 (8Kbps ~ 320Kbps, 8KHz ~ 48 KHz)
WMA (48Kbps ~ 192Kbps, 8KHz ~ 48KHz)
55-eng-new 7/25/03 3:40 PM Page 66
69
Safety Information
68
FCC Part 15: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, this notice is not a guarantee that
interference will not occur in a particular installaion. If this
equipment does cause harmful
interference to radio or television reception, which can be
detemined by turning the equipment off and on, the user is
encouraged to try one or more of the following measures:
Any changes or modifications not expressly
approved by the grantee of this device could
void the user’s authority to operate the device.
Name: Samsung Electronics Co., Ltd
Address: 416, Maetan-3Dong, Paldal-Gu, Suwon
City, Kyungki-Do, Korea 442-742
declares under its sole responsibility that the product
Trade Name: Samsung Electronics Co., Ltd
Model Number: YP-55
has been tested according to the FCC/CISPR22/95
requirements for Class B devices and found
compliant with the following standards
This product conforms to the following
Council Directive:
● Directive 89/336/EEC, 92/31/EEC(EMC)
●Reorient or relocate the receiving antenna.
●Increase the distance between the equipment and receiver.
●Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
●
Consult the dealer or an experienced radio/TV technician.
Modifications
Compliance
Declaration of Conformity
EMI/EMC: AnSI C63.4 1992, FCC Part 15 Subpart B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesirable operation.
Party Responsible for Product Compliance
Samsung Electronics America
QA Lab.
3351 Michelson Dr. Suite #290
Irvine, CA92612
55-eng-new 7/25/03 3:40 PM Page 68
71
Warranty
70
Samsung warrants this product as free of
defects in material, design and workmanship
for the period of twelve(12) months from the
original date of purchase.
If during the period of warranty this product
proves defective under normal use and service,
you should return the product to the retailer from
whom it was originally purchased. The liability of
Samsung and its appointed maintenance
company is limited to the cost of repair and/or
replacement of the unit under warranty.
Return of the product for defective reasons
should be to the original purchaser, however
Samsung Authorized Dealers and Authorized
Service Centers will comply with the warranty on
the terms issued to purchasers in the country
concerned, for further information relating to the
Authorized Service Centers contact.
1-800-SAMSUNG (1-800-726-7864)
www.samsungyepp.com
WARRANTY CONDITIONS:
1. The warranty is only valid when the warranty card is
properly completed, and upon presentation of the proof of
purchase consisting of original invoice or sales slip
confirmation, indicating the date of purchase, dealers
name, model, serial No. and product number.
Samsung reserves the right to refuse warranty service if
this information has been removed or changed after the
original purchase of the product from the dealer.
2. Samsung's obligations are to the repair of the defective
part, and at its discretion, replacement of the product
(service exchange unit).
3.Warranty repairs must be carried out by an Authorized
Samsung Dealer/Service Center. No reimbursement will
be made for repairs carried out by non Samsung Centers,
and warranty coverage will not be valid for any repairs or
damage caused by such repairs.
4. Repair or replacement under the terms of this warranty
does not give right to extension to or a new starting of the
period of warranty. Repair or direct replacement under the
terms of this warranty may be fulfilled with functionally
equivalent service exchange units.
5. The warranty is not applicable in cases other than
defects in material, design and workmanship. The
warranty does not cover the following:
◆Periodic checks, maintenance, repair and replacement
of parts due to normal wear and tear.
◆Abuse or misuse, including but not solely limited to the
failure to use this product for its normal purposed or in
accordance with Samsung's instructions usage and
maintenance.
◆The product has been used in conjunction with
accessories not approved by Samsung for use with this
product.
◆Failure of the product arising from incorrect installation
or use not consistent with technical or safety standards
in current force, or failure to comply with product
manual instructions.
◆Accidents, Acts of God or any cause beyond the control
of Samsung caused by lightning, water, fire, public
disturbances and improper
ventilation.
◆Unauthorized modifications carried out for the product
to comply with local or national technical standards in
countries for which the Samsung product was not
originally designed.
◆Repairs performed by non-authorized service centers
such as opening of the product by a non-authorized
person.
◆The model, serial No. and product number on the
product has been altered, deleted, removed or made
illegible.
6. This warranty does not affect the consumers statutory
rights nor the consumers rights against the dealer from
their purchase/sales agreement.
55-eng-new 7/25/03 3:40 PM Page 70
7372
THERE ARE NO EXPRESS WARRANTIES OTHER
THAN THOSE LISTED AND DESCRIBED ABOVE, AND
NO WARRANTIES WHETHER EXPRESS OR
IMPLIED,INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, SHALL
APPLY AFTER THE EXPRESS WARRANTY PERIODS
STATED ABOVE, AND NO OTHER EXPRESS
WARRANTY OR GUARANTY GIVEN BY ANY PERSON,
FIRM OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG,
SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF
REVENUE OR PROFITS,FAILURE TO REALIZE
SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR
INABILITY TO USE THIS PRODUCT, REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS
BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. NOR
SHALL RECOVERY OF ANY KIND AGAINST
SAMSUNG BE GREATER IN AMOUNT THAN THE
PURCHASE PRICE OF THE PRODUCT SOLD BY
SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER
ASSUMES ALL RISK AND LIABILITY FOR LOSS,
DAMAGE OR INJURY TO PURCHASER AND
PURCHASER’S PROPERTY AND TO OTHERS AND
THEIR PROPERTY ARISING OUT OF THE USE,
MISUSE OR INABILITY TO USE THIS PRODUCT SOLD
BY SAMSUNG NOT CAUSED DIRECTLY BY THE
NEGLIGENCE OF SAMSUNG. THIS LIMITED
WARRANTY SHALL NOT EXTEND TO ANYONE
OTHER THAN THE ORIGINAL PURCHASER OF THIS
PRODUCT, IS NONTRANSFERABLE AND STATES
YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an
implied warranty lasts, or the exclusion or limitation
of incidental or consequential damages, so the
above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights,
and you may also have other rights which vary from
state to state.
This product is for personal use only, and is only for
use in compliance with the limitations of copyright
and other laws.
To obtain warranty service, please contact
SAMSUNG at:
Samsung Electronics America, Inc.
400 Valley Road, Suite 201 Mount Arlington, NJ
07856
Tel: (973) 601-6000, Fax: (973) 601-6001
1-800-SAMSUNG (1-800-726-7864)
www.samsungyepp.com
081299
55-eng-new 7/25/03 3:40 PM Page 72

Navigation menu
