User Manual
Discover your phone
Philips continuously strives to improve its
products. Therefore, Philips reserves the rights
to revise this user guide or withdraw it at any
time without prior notice. Philips provides this
user guide "as is" and does not accept, except
as required by the applicable law, liability for
any error, omission or discrepancy between this
user guide and the product described. The
device is meant to be connected to GSM/GPRS
networks.
How to...
262K TFT
LCD
Microphone
Hang up and
on/off ke
y
USB Port/
charger &
headset
Back of the
phone: speaker
& camera lens
Camera key
On-screen
keypad icon
Stylus
Lock key
+/- Volume
& zoom key
Pick up key
Switch the phone
On/Off
Long press .
Enter your PIN
code
Enter your PIN code via the
on-screen keypad and tap
on OK to confirm.
Make a call Enter the phone number via
the on-screen keypad and
press to dial.
Answer a call When the phone rings,
press .
Activate/
Deactivate
handsfree mode
When the phone rings,
press , then tap
Handsfree/Handheld.
X800_GB_EN.book Page 0 Thursday, May 29, 2008 6:10 PM
1
Hard keys
The Call Options list has
the following options:
•Hold
•End
• New call
•Phone Book
• Messages
• Sound recorder
•Mute
•DTMF
• Handsfree
End a call Press .
Reject a call Press when your
phone rings.
Access Call logs Press
in idle mode.
Call logs display your recent
Missed Calls, Dialed Calls and
Received Calls.
Quickly return
to idle when
browsing menus
Short press .
Active the
camera/video
function
In idle mode, short press
the camera key.
Hang up
Key
• In menu or edit mode, short
press to return to idle mode.
• During an incoming call or call in
progress, press to end the call or
reject the call.
• When the phone is switched off,
long press to switch on the
phone.
• When the phone is switched on,
long press to switch off the
phone anytime.
Answer
key
• Answer a call or dial a phone
number.
• In idle mode, press to view the
Call logs.
+/- Volume
side keys
• Adjust the speaker and ringtone
volume.
• Zoom in/out the image for phone
shooting.
X800_GB_EN.book Page 1 Thursday, May 29, 2008 6:10 PM
2
Softkeys
The soft keys located right below the main screen
allow you to select the corresponding options that
appear on the screen immediately above them,
including options during a call. These keys are
contextual: they vary according to the current
context.
Soft icons
There are 4 soft icons at the bottom of the touch
screen, namely (from left to right): Messages,
Contacts, On screen keypad and Home.
The 4 soft icons are displayed in idle mode. During
a call, both Message and On-screen keypad soft
icons are available.
Tap on the Messages icon to enter the message
editor.
Tap on the Contacts icon to enter the Contacts
menu.
Tap on the on-screen keypad icon to open the
on-screen keypad, whereby you can tap to enter
numbers.
Tap on the Home icon to enter the Main menu.
Touch screen
Warning! The stylus pen supplied with your
product is the only tool that you can use when
tapping the touch screen. Do NOT use any
other tool on the touch screen.
Your mobile phone features a touch screen which
provides a faster and more intuitive way for you to
navigate through lists and menus. The touch screen
is operated with a stylus pen located at the side of
the phone. It becomes available as soon as you
enter any of the available menus. Use the stylus pen
to tap once or twice on any available screen zone
to carry out the corresponding operations (such as
menu page header, menu items, lists, softkeys,
options menu, function keys, text input area,
selection area, pull-down menu box, selection box,
etc.).
Side
camera
key
• In idle mode, short press to
enter the camera mode.
X800_GB_EN.book Page 2 Thursday, May 29, 2008 6:10 PM
3
You will not be able to use the touch screen in
some cases, as they are not able to replace the
keys to carry out certain operations.
The screen will display lists and menus that can be
selected with the stylus pen. You can select an item,
move up and down or select a few items
simultaneously.
Main Menu
The main menu gives you access to all the different
features of your mobile phone presented in the
form of a grid. The table below summarizes the
arrangement of the Main Menu, the meanings of the
various icons found there, and the pages in this
manual where more detailed information
concerning the subjects can be found.
Tap to access the main menu when in idle
mode, then tap the main menu icons to browse the
sub-menus. Press OK to access the options related
to the selected item, or press Back to go back one
level.
Fun Browser Multimedia
page 16 page 18 page 20
Camera Messaging My files
page 23 page 25 page 34
Business Contacts Profiles
page 37 page 42 page 45
Bluetooth Calls Settings
page 46 page 47 page 51
X800_GB_EN.book Page 3 Thursday, May 29, 2008 6:10 PM
57
Table of contents
1. Getting Started ..................................6
Inserting the SIM card ......................................6
Switching on the phone ...................................7
Charging the battery ........................................8
Inserting the Micro-SD Card ..........................8
2. Calling ................................................10
Make a call ....................................................... 10
Answer and end a call ................................... 10
Options during a call ..................................... 10
Adjust the earpiece volume ......................... 11
Speed Dial ........................................................ 11
Make an emergency call ............................... 11
Handling multiple calls .................................. 11
3. Text Entry ........................................13
Handwriting recognition .............................. 13
On-screen keyboard input ........................... 14
4. Fun.......................................................16
Games ............................................................... 16
Java .................................................................... 16
5. Browser ............................................18
STK .................................................................... 18
WAP................................................................... 18
6. Multimedia ........................................20
Music player .................................................... 20
FM radio ........................................................... 21
7. Camera .............................................23
Camera ............................................................. 23
Video recorder ............................................... 24
8. Messaging ..........................................25
Compose message ......................................... 25
Inbox ................................................................. 27
Sent ................................................................... 27
Outbox ............................................................. 27
Drafts ................................................................ 28
SIM Archive ..................................................... 28
Templates ........................................................ 29
E-mail ................................................................ 29
Broadcast Messages ...................................... 31
Settings ............................................................. 31
9. My files ..............................................34
Picture .............................................................. 34
Video ................................................................ 35
Audio ................................................................ 35
Others .............................................................. 36
10. Business ..........................................37
X800_GB_EN.book Page 57 Thursday, May 29, 2008 6:10 PM
58
Calendar ........................................................... 37
Alarm ................................................................ 37
Quick Note ..................................................... 37
Calculator ........................................................ 38
Sound Recorder ............................................. 38
Stopwatch ........................................................ 38
Currency Converter ..................................... 38
Firewall ............................................................. 39
World Clock ................................................... 39
Eng-Chi Dictionary (if available)
............................................................................. 40
Reader................................................................ 40
Business Card Reader .................................... 41
11. Contacts ......................................... 42
View contacts .................................................. 42
View groups .................................................... 43
Special numbers .............................................. 43
Advanced ......................................................... 44
12. Profiles ............................................ 45
13. Bluetooth........................................ 46
Bluetooth ......................................................... 46
14. Calls ................................................ 47
View calls ......................................................... 47
Call options ..................................................... 47
Clear history .................................................... 49
15. Settings ........................................... 51
Pen calibration ................................................. 51
General ............................................................. 51
Display .............................................................. 52
Sounds .............................................................. 53
Connectivity .................................................... 53
Icons & Symbols .................................. 55
Precautions .......................................... 57
Troubleshooting ................................. 62
Philips Authentic Accessories .......... 65
Trademark Declaration ..................... 68
Specific Absorption Rate Information .. 69
Limited Warranty ............................... 70
Declaration of conformity ................ 73
X800_GB_EN.book Page 58 Thursday, May 29, 2008 6:10 PM
Getting Started 6
1. Getting Started
Please read the safety instructions in the
"Precautions" section before use.
To use your phone, you must insert a valid SIM card
supplied by your GSM operator or retailer. The
SIM card contains your subscription information,
your mobile telephone number, and a memory in
which you can store phone numbers and messages.
Inserting the SIM card
Follow the steps below to insert your new SIM
card. Remember to switch off your mobile phone
before removing the back cover.
Remove the back cover
To insert the SIM card, you must first remove the
back cover. Press on the button on the back cover
and then slide the cover downwards as shown in
the diagram.
Remove the battery
To remove the battery, pull up the battery from the
bottom right corner.
You may lose all your personal settings if you
remove the battery when the phone is switched
on.
Insert the SIM card
Insert your SIM card under the metal clip holder,
until it stops. Make sure that the clipped corner of
the SIM card is aligned with the clipped corner of
X800_GB_EN.book Page 6 Thursday, May 29, 2008 6:10 PM
7 Getting Started
the SIM card slot and that the gold contacts of SIM
card are facing downwards.
Replace the battery
Slide the battery into its slot, metallic connectors
facing downwards, until it stops. Then lock it by
pushing it down.
Replace the back cover
Align and hook the back cover to the left side of the
phone and press down the back cover until it locks
into place with the right side of the phone.
Remove the protective film covering the screen
and the camera lens before using the phone.
Switching on the phone
To switch on the phone, long-press key. Enter
the PIN code if required. A PIN code is a 4- to 8-
digit secret code of your SIM card. It is
preconfigured and communicated to you by your
network operator or retailer.
If you enter an incorrect PIN code three times
in succession, your SIM card will be blocked. To
unblock it, you must request the PUK code from
your operator.
X800_GB_EN.book Page 7 Thursday, May 29, 2008 6:10 PM
Getting Started 8
Charging the battery
Your phone is powered by a rechargeable battery.
A new battery is partially charged and a sound alert
will be emitted when the battery level reaches low
(if the battery alert is set to On).
Once the battery and battery cover are back in
place, you can charge the phone. Plug in the
connector as shown below. Then plug the other end
into a power socket.
The battery symbol indicates the state of charge.
During charging, the charge indicators will scroll; it
takes about 2.5 hours to fully recharge the battery.
When all the scroll bars are steady, the battery is
fully charged. You can then disconnect the charger.
Depending on the network and condition of use,
talk time goes up to 10 hours and stand-by time up
to 1 month.
Keeping the charger plugged to the mobile phone
when the battery is fully charged will not damage
the battery.
The only way to turn off the charger is to unplug it,
so use an easily accessible power socket.
Inserting the Micro-SD Card
The maximum capacity of Micro-SD that X800
can support is up to 8GB.
Remove the back cover
The micro-SD card slot is visible only when the
back cover of the phone is removed.
X800_GB_EN.book Page 8 Thursday, May 29, 2008 6:10 PM
9 Getting Started
Insert the Micro-SD card
After the cover is removed, you can open the
micro-SD card slot and insert the micro-SD card as
indicated below.
X800_GB_EN.book Page 9 Thursday, May 29, 2008 6:10 PM
Calling 10
2. Calling
Make a call
From the idle screen
1.
In idle mode, tap the icon at the bottom
of the touch screen to open the phone
number input screen. Tap the on-screen
numbers to enter the phone number. To
correct an error, tap on Clear.
2.
Press
to dial or tap on Dial.
3.
Press to hang up.
For international calls, long press the on-screen "0"
key to enter the "+" sign for the international
prefix.
Using the phonebook
1.
In idle mode, tap on the icon at the
bottom of the touch screen and select View
Contacts to open the contact list..
2.
Select a contact from the list and press
to dial the selected number.
3.
Press to hang up.
Answer and end a call
When receiving a call, the number of the caller may be
displayed, depending on whether or not the calling
party has chosen to display his or her ID. If the
number is stored in the phonebook, then the
corresponding name is displayed instead of the
number.
•Answer the call: press or tap on Options
and select Answer.
•Reject the call: press or tap on Options
and select Reject. If you have activated Call
forward, then the call will be diverted to another
number or your voice mail.
•Hang up: press .
The phone will not ring if it is in Silent mode (see
“Profiles” on page 45 ).
Options during a call
During a call, Select to access Contacts, display the
Keypad or Options to access the following options:
-Loud sp/Headset
-Put the call on Hold
-Sound Recorder
- Mute/Unmute the call
- Enabling DTMF (the touch tone dialing
system)
- Make a New call
X800_GB_EN.book Page 10 Thursday, May 29, 2008 6:10 PM
11 Calling
Sound Recorder
In most countries, recording of telephone
conversation is subject to legislation. We advise
you to notify the caller if you intend to record
the conversation and only do so if they agree.
You should also ensure confidentiality of the
recordings.
To record a conversation during a call, select
Options and select Sound Recorder. Recorded sound
is saved in *.amr format and stored in Audio of My
files menu. (see “Multimedia” on page 20).
Mute or unmute a call
During a call, select
Options
and select to set the
Mute
function
On
/
Off
. If you select
Mute
, the
microphone will be deactivated.
When you switch from one call to another, muting
will be cancelled.
Adjust the earpiece volume
During a call, press + or - side keys to increase or
decrease the volume.
Speed Dial
Speed dial via call logs
In idle mode, press to access
Call Logs
. Select a
number you wish to call and press to dial the
number.
Make an emergency call
Without a SIM card in phone, you can tap on SOS
to make the emergency call.
With a SIM card in phone, you can enter the
emergency number in idle mode, then press .
Note that an emergency call will not be stored
in the call record.
In Europe, the standard emergency number is
112, in the UK, it is 999.
Handle multiple calls (Network
Dependent)
You can handle two or more calls at the same time,
as well as make conference calls with your phone.
The availability of this feature is dependent on your
network operator and/or your subscription.
X800_GB_EN.book Page 11 Thursday, May 29, 2008 6:10 PM
Calling 12
Make a second call
You can make a second call when there is an active
call or with a call on hold. While on the phone, dial
the number (or select a contact from the
phonebook) and press . The first call is put on
hold and the second number is dialled. You can
then select Options to access the following options:
•Loud sp/Headset
•Swap to toggle between 2 calls.
•Conference to introduce the caller into a
conference call.
•Transfer to connect the two calls. You are
disconnected when the transfer is completed.
•End Single to disconnect one party from the call.
•End All to disconnect all party from the call.
•Phone book to access the contact list.
•Messages to send and receive messages.
•Sound Recorder to record the phone
conversation.
• Mute to deactivate the microphone.
• DTMF to activate the touch tone dialing system.
Answer a second call
When you receive a second call while already in
communication, the phone will emit a beep tone
and the screen displays information about the
incoming call. You can then:
To receive a second call, Call Divert for voice
calls (see page 48) must be deactivated and Call
waiting (see page 48) must be activated.
Press To answer the call (the first one
is put on hold).
Press To reject the call.
Options To access the options list. You
can select End Active to end the
current call and answer the
incoming call.
X800_GB_EN.book Page 12 Thursday, May 29, 2008 6:10 PM
Text Entry 13
3. Text Entry
Your mobile phone supports a number of text
editing modes, including Handwriting input, Pinyin
input, English input, Numeric input and Symbol
input.
During text editing, tap on and to toggle
between the handwriting recognition mode and on -
screen keyboard input mode.
You can use handwriting recognition mode and
on-screen keyboard input mode at the same
time .
Handwriting recognition
In handwriting recognition mode, you can enter
Chinese characters, English letters, numbers,
symbols (including punctuations) by means of
handwriting recognition.
1.
Tap the corresponding icon on the touch
screen to toggle between Chinese character
input mode , English letter input mode
and symbol input mode .
2.
Write the text with your stylus pen. The
system will recognize your handwriting
automatically and show the recognized result in
the input area, with the proposed candidate
characters displayed.
3.
Ta p Select to confirm the character. If the
recognized result is not the character you
desire, choose one from the candidate
characters and tap it to replace the one in the
input area. You can tap on Clear to delete the
character or symbol on the left of the cursor
in the text area. Long press Clear will clear all
contents on the left of the cursor in the text
area.
4.
After you have finished writing, tap on Done to
go to the next step and choose a recipient for
your message .
5.
Ta p o n Options to access the SMS/MMS
options menu. For detailed information, see
“Messaging” on page 25,
The following examples describe the handwriting
recognition process for Chinese characters, English
letters, symbols and numbers.
X800_GB_EN.book Page 13 Thursday, May 29, 2008 6:10 PM
14 Text Entry
Input Chinese characters
1.
Tap or to enter the Chinese character
input mode.
2.
Write the Chinese character with your stylus
pen on the touch screen.
3.
You will see the recognized result on the input
area, with the proposed candidate characters
displayed.
4.
Tap Select to confirm the character or choose
one of the candidates from the input line and tap
it to replace the one in the input area.
Input English letters
1.
Tap to enter the English letter input
mode.
2.
Write an English letter with your stylus pen
on the touch screen. The system can
differentiate between upper and lower case.
You do not need to shift case before you
write.
3.
You will see the recognized result on the input
area, with the proposed candidate characters
displayed. .
4.
Tap Select to confirm the character or choose
one of the candidates from the input line and tap
it to replace the one in the input area.
Input Symbols
1.
Tap to enter the symbol input mode.
2.
Tap a symbol on the touch screen with your
stylus pen.
Input numbers
1.
Tap to enter the number input mode.
2.
Write a number with your stylus pen on the
touch screen.
3.
You will see the recognized result on the input
area.
4.
with the proposed candidate characters
displayed. .
5.
Tap Select to confirm the character or choose
one of the candidates from the input line and tap
it to replace the one in the input area.
Space Input
Tap to insert a space after the cursor.
Line break operation
Tap on-screen line break symbol to start a new
line.
On-screen keyboard input
On-screen English keyboard
You can input 26 English letters, 10 numbers and
other symbols under this mode. Tap the letter or
X800_GB_EN.book Page 14 Thursday, May 29, 2008 6:10 PM
Text Entry 15
number on the screen and the editor will display
the letter or number you have tapped. Under the
English input mode, you can tap or on the
screen to switch between upper case and lower
case letter.
The on-screen keyboard input mode has 3 tabs,
allowing you to input Chinese characters,
English characters, and symbols. It does not
have a tab for entering numbers, because
numeric keys are part of the keyboard. The
method for entering English characters,
Chinese characters, symbols, space inputs, and
line breaks are exactly the same as those under
Handwriting recognition mode. Please refer to
the section “Handwriting recognition” on
page 13 for more information.
On-screen Pinyin keyboard (for Simplified
Chinese)
Tap the Chinese characters on the screen to
compose a pinyin combination, the corresponding
list of candidate characters will be displayed on the
screen. You can navigate the list of candidate
letters using and on-screen icons. They are
needed when the candidate characters cannot be
displayed on one line of space. If the character that
you wish to input is displayed in the candidate list,
you can tap the character directly with your stylus
pen to display it in the editor.
Predictive text input
The predictive text input is an intelligent editing
mode for entering text on a mobile phone. It allows
you to enter text more quickly by anticipating the
word you want to enter based on the key presses.
Press and on-screen icons to browse the list
and tap the character directly with your stylus pen
to display it in the editor.
On-screen symbol/number keyboard
See “Input Symbols” on page 14 and “Input
numbers” on page 14.
X800_GB_EN.book Page 15 Thursday, May 29, 2008 6:10 PM
Fun 16
4. Fun
Games
Select a game and tap OK. For details regarding a
certain game, please refer to Game Help.
Java
Your mobile phone features a Java run-time
environment, which allows you to run Java
applications, such as games downloaded from the
network.
The first time you launch Java, a message appears to
alert you that the installation and configuration of
Java will take several moments. This is a one-time
occurrence.
Java Settings
Once Java has been installed, you may then select
Options > Settings to set the following:
Network
Access
Allows you to set the automatic
connection preference. You can
select Prompt always, Prompt at
first, or Never.
Auto Invocation Allows you to set the preference
of starting a Midlet automatically.
You can select Prompt always,
Prompt at first, or Never.
Your mobile phone may display
messages about "MIDlets".
MIDlets are JAVA applications
or games.
Messaging Allows you to set the preference
of receiving messages. You can
select Prompt always or Never.
Multimedia Allows you to set the preference
of multimedia messages. You can
select Prompt always, Prompt at
first, or Never.
X800_GB_EN.book Page 16 Thursday, May 29, 2008 6:10 PM
17 Fun
Read user data Allows you to set the preference
of Read user data. You can select
Prompt always, Prompt at first, Allow,
or Never.
Write user data Allows you to set the preference
of Write user data. You can select
Prompt always, Prompt at first, Allow,
or Never.
Local
connectivity
Allows you to set the preference
of Local connectivity. You can
select Prompt always, Prompt at
first, Allow, or Never.
X800_GB_EN.book Page 17 Thursday, May 29, 2008 6:10 PM
18 Browser
5. Browser
This menu contains Wap and Data Accounts.
STK
The availability of the features in this menu depends
on whether or not your SIM card supports STK. If
your SIM card supports STK function, the STK
menu will be displayed on the screen.
WAP
This option allows you to access the internet. Your
phone has been pre-configured with a number of
internet access modes. You can start browsing the
internet once you have activated an access mode.
Home
You can store a homepage for each access mode.
When you access the internet with the WAP
browser, the homepage of the access mode which
you have selected will be displayed first.
Bookmarks
You can save the URL as a bookmark in your
phone. Select a bookmark and tap OK to access the
following options:
Enter address
Enter a web address and confirm connection to the
website.
History
This menu allows you to view the websites which
you have visited recently.
Settings
This menu allows you to configure web settings for
web browsing. Your phone may be preconfigured
with the settings parameter of a particular network
operator. If you are a subscriber of the network
Goto Access the web page of the
selected bookmark.
Edit Edit the selected bookmark.
Send Send the selected bookmark.
Delete Delete the selected bookmark.
Delete all Delete all bookmarks
Add Bookmark Enter the title and URL to create a
new bookmark.
X800_GB_EN.book Page 18 Thursday, May 29, 2008 6:10 PM
Browser 19
operator, you may start using your browser.
Otherwise, you need to reconfigure the settings.
Philips is not liable to give prior notification nor
shall it bear any consequences for any failures
arising from changes of configuration made by
you or by the network operator. Please check
with your network operator for the most
updated information.
The following options for Web settings are
available:
WAP Profile
Make changes on the configuration
of the currently selected profile.
Browser
Options
Allows you to configure the
browser parameters, such as set
Timeout
and enable or disable
Show
images
function.
Push Message
Settings
Allows you to configure the service
message settings.
Clear Cache
You can enable, disable or clear
cache.
Clear Cookies
You can enable or disable Cookie,
and clear cookie. Cookie is an
information sent to your browser
when you visit a website.
X800_GB_EN.book Page 19 Thursday, May 29, 2008 6:10 PM
Multimedia 20
6. Multimedia
This feature allows you to play sound files and
video files. Your mobile phone supports MP3
format.
Music player
Tracks
This feature allows you to play downloaded music
from either the Phone or Memory Card. For
example, to play tracks from an inserted micro-SD
card, select the Tracks option. From the listed
tracks, select the music file you want to play and
then tap Play or access the following options:
When playing songs, a track will appear on the
screen to indicate the playback progress. The
screen will also display the total duration of the
song, the time lapse and the play volume.
The keypad operations during music playback are
as follows:
Settings
This feature allows you to access the following
settings:
Add to
Ringtone list Add the track to the Ringer list.
Details Display the detailed information of
the track .
Key
Operation
key Press to Start/Pause/resume
music playback.
or Short press to select the
previous song/next song.
Repeat When on, the icon will light up.
Shuffle When on, the icon will light up.
Equalizer When on, the icon will light up.
+/-
side keys
Adjust the volume.
Options
Open options menu.
Back
Return to previous menu.
Music
source
You can select Phone or Memory
Card.
Track
selection
You can select Show All or My
selection.
X800_GB_EN.book Page 20 Thursday, May 29, 2008 6:10 PM
21 Multimedia
Music playback options menu
Now playing
This feature displays the song that is currently
playing.
Only those music tracks saved in the root
directory folder of My files > Audio can be
displayed on Tracks.
FM Radio
This menu allows you to listen to the radio on your
phone. Connect the headset connector to your
phone. When listening the radio, the radio
frequency and volume will appear on the screen.
Music in
background
You can select Ask First, Always or
Never.
When you have an incoming
phone call while listening to the
music, the music will stop
playing until you have picked up
or rejected the call. When you
have an incoming message while
listening to the music, the music
will continue to play and you will
hear a beep sound for the event.
Equalizer You can select Normal, Bass, Dance,
Classical, Tremble, Party, Pop or Rock.
Repeat You can set the Repeat mode One,
Off or All.
Shuffle You can set the Shuffle mode On or
Off.
Options Description
Set as
Ringtone Set the track as ringtone.
Equalizer
You can select Normal, Bass,
Dance, Classical, Tremble, Party, Pop
or Rock.
Repeat You can set the Repeat mode One,
Off or All.
Shuffle You can set the Shuffle mode On
or Off.
Details Display the detailed information of
the track .
X800_GB_EN.book Page 21 Thursday, May 29, 2008 6:10 PM
22 Multimedia
The keypad operations during listening the radio
are as follows:
Music playback options menu
Key
Operation
or Manual tune to the previous/
next frequency.
Stop Tap to stop the radio.
Tap to enable the auto search
mode. Then press or
to start scanning the radio
frequency automatically.
+/-
side keys
Adjust the volume.
Options
Open options menu.
Back
Return to previous menu.
Channel List Displays the list of radio frequency
presets. You can save up to 4
preset stations.
Manual
Input
Allows you to enter the radio
frequency. Tap the number with
your stylus pen on the touch screen
to enter the radio frequency. Press
OK to confirm or Clear to remove
the number.
Auto Presets Scan the radio frequency
automatically and save it to the
preset channel list.
Settings Background Play: Listen to radio
station without quitting the radio
application.
When you have an incoming
phone call while listening to the
radio, the radio will stop playing
until you have picked up or
rejected the call. When you
have an incoming message while
listening to the radio, the radio
will continue to play and you will
hear a beep sound for the event.
Loud speaker: Allows you to listen
to the radio with loud speaker
(When set to On) or without loud
speaker (When set to Off).
X800_GB_EN.book Page 22 Thursday, May 29, 2008 6:10 PM
Camera 23
7. Camera
Camera
Your mobile phone features a digital camera that
allows you to take pictures (up to 2.0 Mega pixels)
and record short videos, store them in your phone
or transfer them to your PC via a data cable, use
them as wallpaper or send them to your friends via
MMS.
Consult the table below on how to perform
common operations with your camera.
Within any menu, press to cancel any current
operation and go back to the idle mode.
Once the pictures have been saved, they are
available in My files > Phone/Memory card > Picture.
Press To
or
Camera side
key
Enter the main menu, select Cam-
era
>
Camera.
Side keys +
and -
Adjust brightness (when the cam-
era is active)
Slightly press to focus, then press
to take a picture.
Side keys +
and -
Zoom in/out (when the camera is
active).
Zoom behaviour depends on
the resolution you have set for
the camera. The lower the
resolution, the higher the zoom
factor.
Tap on to change the reso-
lution of the camera. You can set
the resolution to 400x240,
640x480, 800x600, 1280x1024
or 1600x1200 .
Tap on to go back to the pre-
vious menu.
Access the setting menu and set the
Quality, Timer, Continuous, Picture
Mode, Scenes, Storage, Effects, EV
(Exposure Value), Shutter, Banding,
and Restore .
X800_GB_EN.book Page 23 Thursday, May 29, 2008 6:10 PM
24 Camera
Video Recorder
This option allows you to record short videos,
which you can play, save on the phone, or save on
an inserted memory (micro-SD) card. The
recording time depends on the memory status.
The phone memory can store up to 70MB. When
recording to a micro-SD card, the size of video you
may store is dependent on the size of the micro-SD
card.
How to record Video? Once you have activated the video, simply press
to take a video. Once the video is saved, you
can then go to view the video in My files > Phone/
Memory card > Video.
Press To
or
Camera
side key
Enter the main menu, select
Multimedia
>
Video Recorder.
Start recording a video.
Side keys +
and -
Zoom in/out (when the video mode
is active).
Zoom behaviour depends on the
resolution you have set for the
video function. The lower the
resolution, the higher the zoom
factor.
Tap on to go back to the pre-
vious menu.
Access the setting menu and set the
Quality, Picture Mode, Scenes, Record
audio, Storage, Effects, EV (Exposure
Value), Banding, File Size Limit, Rec
Time Limit, Encode Format, and
Restore .
X800_GB_EN.book Page 24 Thursday, May 29, 2008 6:10 PM
Messaging 25
8. Messaging
Compose Message
SMS
SMS enables you to send text messages to the
other party, using Short Messaging Service (SMS).
You can use the SMS menu to send messages to
another handphone or a device that is capable of
receiving SMS.To compose and send an SMS, follow
the steps below:
1.
Select Compose message > SMS, and write
your message via the on-screen keyboard and
the stylus pen.
2.
Tap o n Options to access the following options:
3.
Ta p o n Done to go to the next step, with the
following options:
4.
Ta p o n Options to access the following
options:.
5.
Ta p o n Send to send the message.
MMS
Your mobile phone can also send and receive MMS
(Multimedia Messaging Service) messages. With
MMS, you can send messages that contain pictures,
sound and text.
Save as Select Save as drafts or Save to
Templates. Then tap on OK.
Insert
Contact
Select a recipient from the contact
list. Then tap on OK.
Use
template
Select to insert a preset message.
Then tap on OK.
Contacts Select a recipient from the contact
list. You can select more than 1
recipient. Then tap on OK.
Phone
number
Enter the phone number of the
person to whom you wish to send
the new SMS. Then tap on Add.
Group Select a group of recipients. Then
tap on OK.
Add To add another recipient(s) from
the contacts list, or to enter a
phone number. Then tap on OK.
Delete To remove a contact. Then tap on
OK.
X800_GB_EN.book Page 25 Thursday, May 29, 2008 6:10 PM
26 Messaging
When sending MMS messages, your recipient must
also have an MMS-enabled phone in order to view
your messages. Follow the steps described below
to compose and send an MMS:
1. Select Compose Message> MMS, and enter the
following:
2. Tap on Options to access the following options
when you have finished editing:
3. Select Done to access the next option:
To Enter the number or E-mail of the
recipient.
Cc Enter the number or E-mail of
other recipients you wish to send
a copy of the message to.
Bcc Enter the number or E-mail of the
recipients you wish to send a copy
of the message to, by which the
recipients in the Bcc list will be
invisible to other recipients.
Subject Enter the subject of the MMS.
Edit content Edit the MMS content via the on-
screen keyboard and the stylus
pen..
Done Finish editing and go to the next
step.
Add Image Open the picture list to select and
insert a picture to your MMS.
Add Audio Open the audio list to select and
insert a sound file to your MMS.
Add Video Open the video list to select and
insert a video clip to your MMS.
Add
Attachment
Insert a file (txt, jar etc) to your
message.
Add Slide
Before
Only available when your MMS has
more than 1 slide. Insert a slide
before another slide.
Add Slide After Only available when your MMS has
more than 1 slide. Insert a slide
after another slide.
Add Bookmark
Text
Add a subject for your bookmark.
Preview Preview the current MMS.
Slide Timing Set play time of the MMS slides.
The default value is 3 seconds.
Send Only Send the MMS only.
Save and Send Save and Send the MMS.
Save to draft Save the MMS to Drafts.
X800_GB_EN.book Page 26 Thursday, May 29, 2008 6:10 PM
Messaging 27
Copyright protected pictures and sound cannot
be sent by SMS.
Inbox
This menu allows you to read the SMS/MMS
messages which you have received. The messages
are displayed in a list.
When a message is displayed, tap on View to read
it, then you can tap on Reply to reply to the sender
or Options to access the following options:
Sent
When you send a message, the messages will be
stored in Sent.
When you are in the Sent message list, tap on View
to read it, then you can tap on Forward to forward
the message or
Options to access the following
options:
Outbox
If you select Save and Send or Save before you send
a message, the messages will be stored in the
Outbox. When a message is displayed, tap on View
to read it, then tap on Options to access the
Send Options Set Validity period, Delivery
report, Read report, Priority.
Exit Exit
Forward Forward the selected message.
Edit Edit the selected message.
Delete Delete the selected message.
Move to
phone/SIM
Move the selected message stored in
SIM/phone to phone/SIM.
Edit before
Call
Edit the selected message before
calling the sender.
Delete all Delete all the messages in the Inbox.
Edit Edit the selected message.
Delete Delete the selected message.
Move to
phone/SIM
Move the selected message stored
in SIM/phone to phone/SIM.
Edit before
Call
Edit the selected message before
calling the sender.
Delete all Delete all the messages in the Sent
box.
X800_GB_EN.book Page 27 Thursday, May 29, 2008 6:10 PM
28 Messaging
following options:
Drafts
If you select Save as drafts after you have created
your SMS/MMS, the SMS/MMS will be stored in the
Drafts box. tap on Send to send the message or
View to read it, then tap on Options to access the
following options:
SIM Archive
This menu allows you to store SMS messages on
the SIM card. Tap on View to read it, then tap on
Options to access the following options:
Forward Forward the selected message.
Edit Edit the selected message.
Delete Delete the selected message.
Edit before
Call
Edit the selected message before
calling the sender.
Delete all Delete all the messages in the Sent
box.
Forward Forward the selected message.
Delete Delete the selected messages.
Edit Edit the selected message.
Use
number
Extract and save the number of the
sender or the number displayed in the
message to the SIM card or phone, or
dial the number.
Edit before
Call
Edit the selected message before
calling the sender.
Delete all Delete all the messages in the Sent
box.
Reply View details of the selected
message.
Foward Forward the selected message.
Edit Edit the selected message.
Use number Extract and save the number of the
sender or the number displayed in
the message to the SIM card or
phone, or dial the number.
Use URL Extract the URL displayed in the
message to connect the website.
X800_GB_EN.book Page 28 Thursday, May 29, 2008 6:10 PM
Messaging 29
Templates
Lists all SMS/MMS saved as templates for editing
and sending later. 10 SMS and 5 MMS have already
been preset. You can edit and modify them.
E-mail
If not included in your mobile phone contract,
you will need to subscribe to an e-mail service
in order to send and receive e-mails. In this
case, all parameters are communicated to you
by your operator.
This menu allows you to send e-mails to one or
several recipients at a time, including with an
attachment such as a JPEG picture. Once received,
your messages can be forwarded and the
attachments visualised with the appropriate
software.
Send and Receive
To send an e-email, select Options > Send. This
might bring up a message requesting airtime. Select
Yes to continue and send the e-email. To receive
new e-emails, select Options > Receive mail. This
might bring up a message requesting airtime. Select
Yes to continue and receive new e-emails.
Write e-mail
To write an e-email, select E-mail > Write E-mail.
Enter the address (To), a copy (Cc), Subject and
Attachment (up to 3 files), and the e-mail content.
When you have finished writing your e-mail, press
L
to access the option menu. You can then select to
Send, Send and Save, Save to Draft or Quit without
Saving.
If you exit the Messaging > Write E-mail menu
before sending your e-mail or if you cancel the
sending while it takes place, the e-mail content
is deleted without being stored.
You can only attach one file (JPEG, MID, JAR,
TXT, MP3) or one sound at a time. If you accept
an incoming call while writing an e-mail, the
menu is closed and the phone goes back to idle
mode when you hang up.
Inbox
This menu allows you to connect to your mailbox
and download the e-mail headers (sender and
Edit before
call
Edit the selected message before
calling the sender.
Delete all Delete all the messages.
X800_GB_EN.book Page 29 Thursday, May 29, 2008 6:10 PM
30 Messaging
subject lines) from the server. You may then select
an e-mail header and press
,
to access the following
options:
Unsent
This menu allows you to list the e-email that were
saved before sending or were not sent successfully.
Select an e-mail from the Unsent box and press
L
Options
to:
Edit
and
Delete
.
Sent
This menu allows you to list the e-mail that were
sent successfully and which you have chosen to save
before sending.
Select an e-mail from the Sent box and press
L
Options
to:
View
and
Delete
. If you select
View
, the
subsequent procedures would be similar to the
Inbox operations.
Drafts
This menu allows you to list the e-mail that were
created and saved but were not sent, and e-mail
which were automatically saved before you were
able to save or send them when you exit from the
e-mail editor.
Select an e-mail from the Draft box and press
L
Options
to:
View
,
Edit
,
Delete
,
Delete all
. If you select
View
, the subsequent procedures would be similar
to the Inbox operations.
E-Mail Profile
This menu allows you to Activate, or Edit one of the
available email profiles. Your mobile phone may
have been pre-configured. To change the settings,
choose an Email profile in the list and select Edit to
access the settings decribed below.
Reply without
content
Reply to the sender without the
email history.
Reply all Reply to all senders with the email
history.
Reply all
without
content
Reply to all senders without the
email history.
Forward Forward the downloaded e-mail to
someone else. Proceed as
described in “Inbox” on page 29.
Delete Mark the e-mail to be deleted
(select this option again to unmark
it). When you exit the E-mail menu,
you will be asked to confirm
deletion of the selected item(s)
from the e-mail server.
X800_GB_EN.book Page 30 Thursday, May 29, 2008 6:10 PM
Messaging 31
If one of the accounts has been pre-configured,
it may be locked, in which case it cannot be
renamed.
Broadcast Messages
Broadcast messages are public messages
broadcasted to a group of mobile users. The
messages are broadcasted on coded channels.
Generally, one broadcast channel can transmit one
type of message. Please contact your network
operator for a list of channel numbers and their
respective broadcast information.
Receive Mode
This menu allows you to set the reception of
broadcast messages. When On, you can receive
broadcast messages. When Off, you cannot receive
broadcast messages.
Read Message
This menu allows you to read broadcast messages
after you have activated receive mode.
Languages
This menu allows you to set the language of the
broadcast messages that can
be received.
Channel Settings
You can Select, Add, Edit or Delete channels.
Settings
SMS
Account
settings
Profile Name: Edit the name of the
current profile.
SC Address: Select your default SMS
centre. If not available on your SIM
card, you must enter your SMS
centre number.
Validity Period: Select the length of
time your messages will be stored
in the SMS centre. This is useful
when the recipient is not
connected to the network (and
thus cannot receive your message
immediately).
This feature is subscription
dependent.
Message Type: Select the format of
your sent messages. This option is
network dependent.
X800_GB_EN.book Page 31 Thursday, May 29, 2008 6:10 PM
32 Messaging
MMS
General
settings
Delivery report: When set to On, this
option will inform you via SMS
whether or not your own SMS was
received. This feature is
subscription dependent.
Reply path: When On, this option
allows you to transmit the number
of your SMS message center
together with the message. The
recipient can then reply using your
SMS center and not theirs. This
speeds up the rate of transmission.
This feature is subscription
dependent.
Memory
Status
This option can display the
memory status of the messages
saved in the SIM card and the
phone.
Preferred
Storage
Location
You can choose to save your
messages to Phone or SIM.
Preferred
Bearer
This option allows you to set the
preferred transmission mode. You
can select Preferred GPRS, Preferred
GSM or GSM Only. For further
details, please contact your
network operator.
Compose Set Creation Mode, Image Resizing
Auto Signature and Signature
Content.
Send Set Validity period, Delivery Report,
Read Report, Priority, Slide Timing
and Delivery time options for
sending an MMS.
Retrieve Set Home network, Roaming, Read
Report and Delivery Report options
for receiving an MMS.
Filter Set Anonymous, and Advertisement
from whom you want to filter
MMS or email messages.
X800_GB_EN.book Page 32 Thursday, May 29, 2008 6:10 PM
Messaging 33
Server Profile Set network configuration. Please
contact your network provider for
more information.
Memory Status View the memory status of your
MMS.
X800_GB_EN.book Page 33 Thursday, May 29, 2008 6:10 PM
My files 34
9. My files
This menu allows you to manage your files by
storing them into different folders in Phone or
Memory Card.
Then you can select a folder and tap on Create
Folder to create a sub-folder or to open the current
folder.
To create a subfolder, select a folder under
which you want to create a subfolder. Select
Create Folder. You can then store your files into
the subfolder.
You can download the pictures via MMS, WAP,
USB, and Bluetooth. Select a picture from the list.
Tap on View to view the picture or Options to carry
out the following operations:
Options Description
Forward Forward the selected picture to be
used by other applications:
To
Wallpaper
,
To Phone
,
To MMS
,
To E-mail
or
To Bluetoot h
.
Detail Display the detailed information of
the selected picture.
Browse
Style
Set the browse style as List Style or
Matrix Style.
Rename Rename the selected picture.
Copy Copy the selected picture to the
current folder or sub-folder.
Move Move the selected picture to
another folder. The picture in the
original location will be deleted.
Delete Delete the selected picture.
Delete All
Files
Delete all pictures.
Sort Sort all pictures according to name,
type, time or size.
Select
Multiple
Select multiple pictures at the same
time.
X800_GB_EN.book Page 34 Thursday, May 29, 2008 6:10 PM
35 My files
Video
Your phone manages video files the same way as it
manages pictures. Select a video from the list.
Tap on Play to play the video file or Options to carry
out the following operations::
Audio
Your phone manages audio files the same way as it
manages pictures. Select an audio file from the list.
Tap on Play to play the file or Options to carry out
the following operations:
Options Description
Forward Forward the selected picture to be
used by other applications:
To
PhoneBook
,
To MMS
,
To
E-mail
or
To
Bluetooth
.
Detail Display the detailed information of
the selected video.
Browse
Style
Set the browse style as List Style or
Matrix Style.
Rename Rename the selected video.
Copy Copy the selected video to the
current folder or sub-folder.
Move Move the selected video to another
folder. The source video in the
original location will be deleted.
Delete Delete the selected video.
Delete All
Files
Delete all videos.
Sort Sort all videos according to name,
type, time or size.
Select
Multiple
Select multiple videos at the same
time.
Options Description
Forward Forward the selected picture to be
used by other applications:
To IC
Ringer
,
To MMS
,
E-mail
or
To Bluetoot h
.
Detail Display the detailed information of
the selected audio file.
Browse
Style
Set the browse style as List Style or
Matrix Style.
Rename Rename the selected audio file.
X800_GB_EN.book Page 35 Thursday, May 29, 2008 6:10 PM
My files 36
Others
You can put all other files into this folder. Select a
file from the list.
Tap on Open to view the file or Options to carry out
the following operations:
Copy Copy the selected audio file to the
current folder or sub-folder.
Move Move the selected audio file to
another folder. The audio file in the
original location will be deleted.
Delete Delete the selected audio file.
Delete All
Files
Delete all audio files.
Sort Sort all audio files according to name,
type, time or size.
Select
Multiple
Select multiple audio files at the same
time.
Options Description
Create Create a sub-folder.
You can also organize your files
into subfolders. Select a folder
under which you want to create a
subfolder. Tap on Edit and select
Create Folder. You can then store
your files into the subfolder.
Browse
Style
Set the browse style as List Style or
Matrix Style.
Rename Rename the selected file.
Delete Delete the selected file.
Sort Sort all files according to name, type,
time or size.
X800_GB_EN.book Page 36 Thursday, May 29, 2008 6:10 PM
37 Business
10. Business
This menu contains features and options designed
to help you keep you organized and informed while
on the move.
Calendar
This menu allows you to view the calendar, and add
new tasks.
You can tap on View Tasks to view the task lists with
the set time or Options to access the following
options:
Alarm
Your mobile phone has a built-in alarm clock with
a snooze feature. You can set up to five separate
alarms and choose whether or not the alarm
should repeat. To set an alarm, follow the steps
below:
1.
Select an alarm.
2.
Enter the time and tap on Save.
3.
Select the frequency: repeat Once or Customize
and select the day you prefer.
4.
Select the type of alarm and tap on OK .
5.
Set the snooze mode: Off, 2, 5 or 10 minutes.
6.
Tap on when you finish setting the alarm.
Repeat above steps to set other alarms.
The alarm clock will ring even if your mobile
phone is switched off and/or the Profiles menu is
set to Silent. When the alarm rings, tap on Stop
or Snooze (if the snooze mode has not been set
to off).
Quick Note
Note down text to be saved to and displayed in idle
screen.
Options Description
Add Tasks
Allows you to set task type, date,
time, notes, alarm, frequency for the
task.
Go to date Allows you to view a specific day
quickly. Enter the date and tap on
OK.
Go to
weekly
view
Displays the calendar in week format.
X800_GB_EN.book Page 37 Thursday, May 29, 2008 6:10 PM
Business 38
Calculator
Your phone has a built-in calculator that you can
use to perform basic calculations with the on-
screen keypad. Calculation accuracy is 10 decimal
places and is rounded up to the higher decimal
figure.
The result of the calculator is indicative. The
calculation accuracy is 10 decimal places. The
result is then truncated after the 10th decimal
digit for the next operation.
Sound Recorder
This menu allows you to make recordings and listen
to the sound files you have recorded.
If there is no sound file in the list, tap on Record to
start recording. You can select to Pause/Resume or
Stop recording. The sound file will be displayed on
the screen. You can edit the file name before
saving it. If there are already sound files in the list,
select a file and select Play to listen. You can also
select Options to access the following options:
Stopwatch
When you enter Stopwatch menu, the screen will
display the Stopwatch with a start time as
00:00:00:00.
Tap on Start to start and Pause/Continue to pause/
continue the Stopwatch timer.
Currency Converter
This menu allows you to convert a sum from one
currency into another using the exchange rate of
your choice. You can convert from Local to Foreign.
Enter a rate in the Rate field and an amount in
either the Local field using the on-screen number
keys and your stylus pen. The foreign rate is
calculated automatically.
Options Description
Record Make a new recording.
Append Append sound to the recording.
Rename Rename the recording.
Delete Delete the recording.
Delete All Delete all recordings.
Settings Set the storage location, file format
and audio quality of the recording.
Forward Apply the recording to other options.
X800_GB_EN.book Page 38 Thursday, May 29, 2008 6:10 PM
39 Business
Firewall
This menu allows you to reject all calls received
from the people you have included in the blacklist.
You need to access Activation menu to enable this
function.
Blacklist Number
This menu displays the list of contacts whose calls
and SMS will be rejected. Select Add to add a name
and the corresponding number to the blacklist.
Select a name from the list and select Edit to change
the related information or Delete it. Select Details
to display details of the blacklist.
You can add a name to the blacklist directly
from Phone Book List. Select a contact and tap on
OK . The related number will be added to the
blacklist
World Clock
This menu allows you to check the time of the main
cities around the world.
Clock Status
If you want to display both the local time and the
time of another time zone on the idle screen. Select
On/Off to activate/inactivate this option.
Local settings
Tap on or to select the city. The local date
and time will be displayed on the screen. Then you
can select Options to access the following options:
Foreign settings
Alarms, reminders, programmed events are
time zone independent! If you set an alarm or
an event at 9:00 AM in time zone A, it will still
ring or be due at 9:00 AM if you change to time
zone B.
Set
DateTime
Allows you to set the date and
time.
Daylight
saving
Allows you to set the daylight
saving option On or Off for a
foreign time zone.
City list Displays the list of cities to be
selected.
Daylight
saving
Allows you to set the daylight
saving option On or Off for a
foreign time zone.
City list Displays the list of cities to be
selected.
X800_GB_EN.book Page 39 Thursday, May 29, 2008 6:10 PM
Business 40
Switch local/foreign
To display to foreign zone and vice-versa.
Eng-Chi Dictionary (if available)
This menu allows you to search for the meaning,
grammar or phonetic symbols, etc. of a particular
English or Chinese term. It features an intelligent
term recognition function. When a Chinese term is
entered, the corresponding English translation will
be provided, and when an English term is entered,
the corresponding Chinese translation will be
provided.
1.
Write the English/Chinese term on the text
editing screen with the virtus keypad and
stylus pen.
2.
Tap o n OK to display the meaning,
pronunciation and grammatical information of
the word.
Reader
This menu allows you to view the text files (txt, pdf,
doc, ppt, xls and html) saved in the phone or micro
SD card. You need to copy and save the files into
My files > Others so that you can read the text when
you enter the Reader menu. If there are existing
files, a text file list will display on the screen. Tap on
Options to access the following options:
Then you can select a file and tap on Open to view
it. To make the content become easier to read or
view, you can drag the document and reflow the
text to fit the display area of your mobile phone
screen. You can also select to access the following
options:
Doc Info Display the detailed info of the
selected file.
Delete Doc Delete the selected file.
Delete All Doc Delete all files under eBook.
Sort Select to sort the files By Name, By
Type, By Time, By Size or None (no
sorting or random sorting).
Select Memory Set the storage location.
Next Page Move to the next page
Previous Page Move to the previous page.
Goto Page Enter the page number.
Zoom In Move the file to a closer view.
Zoom Out Move the file to distant view.
X800_GB_EN.book Page 40 Thursday, May 29, 2008 6:10 PM
Business 41
Business Card Reader
This menu allows you to collect the business cards
information by directly scanning the business card
contents into Contacts. Consult the steps below on
how to perform operations:
1.
Enter the main menu, select Business
>
Business
Card Reader.
2.
Press to capture the business card image.
3.
The information will be scanned and the
recognition result will be displayed on screen.
4.
Tap on Done or Edit to edit the Name, mobile
number, Home number, Company name.
Find Look for a word in the document .
Find Next Look for the next word in the
document.
Find Previous Look for the previous word in the
document.
Wrap On/Off Select to enable/disable the word
wrap function.
This function only supports files
in txt or doc format.
X800_GB_EN.book Page 41 Thursday, May 29, 2008 6:10 PM
42 Contacts
11. Contacts
Contacts are stored in one of the two available
phonebooks: SIM phonebook (located on your SIM
card, by which the number of entries you can store
depends on the card capacity) or the Smart
Phonebook (located on your phone, which allows
you to store up to 1000 names). When adding new
contacts, the contacts will only be added to the
phonebook you have selected.
View contacts
To view or create a new SIM/phone contact:
1.
From the main menu, select Phone Book > View
Contacts.
2.
Select a contact from the contact list. You can
tap on and press the key that
corresponds to the letter you wish to search.
The first record starting with this letter in the
list will be selected.
3.
Tap o n View to view the contact or Options >
New contact.
4.
Enter the following fields of details for SIM
contacts.
• Name
• Mobile
5.
Select Save to store the entry.
Note that to create a contact, you must enter
at least a number.
Most of the fields are free-text, meaning you can
enter alphanumeric data using the text entry
functions of your mobile phone (for more
information on text entry, see “Text Entry” on
page 13).
Phonebook Options
In the phonebook, you can display the details of a
contact by selecting it and tap on Options to view/
edit more details:
Options Description
New
Contact
Create a new contact.
Send
message
Send a SMS or MMS to the contact.
Call Call the contact.
X800_GB_EN.book Page 42 Thursday, May 29, 2008 6:10 PM
Contacts 43
View groups
The View groups feature allows you to organize
your contacts so that you can send messages to all
the members of the group. From the Phone Book
menu, select View groups and the list of groups is
displayed.
View
Select a group and tap on OK to display the
members of the group.
Edit
Select a group and tap on OK to display the group
details. Then tap on OK to edit the information.
Special numbers
This menu allows you to keep a list of useful
numbers such as own numbers, service numbers,
voicemail and emergency numbers.
Call
Handsfree
Call the contact's number in
handsfree mode.
Delete Delete the contact.
Edit Change the contact’s information.
Add to
Blacklist
Add the contact to the blacklist.
Send
contact
Send the contact via Infrared or
Bluetooth.
Copy to
phone
Copy the entry from the SIM card to
the phone.
Move to
phone
Move the entry to the phone.
Select
multiple
Select one contact at a time or select
all contacts.
Options Description
My number Select to Edit or Erase your own
phone number.
Service
Number
This service is provided by your
network operator. For more
information regarding the
corresponding function, please
contact your network operator.
Voice Mail Dial the number of your voice mail
service provider.
Emergency Dial emergency phone numbers.
X800_GB_EN.book Page 43 Thursday, May 29, 2008 6:10 PM
44 Contacts
Advanced
This menu provides you with advanced features so
that you can view or edit your contacts.
Options Description
Choose
Contact list
Default contact list: Select SIM Only,
Phone Only or Both.
Default contact location: Select SIM
or Phone.
Fields You can set On or Off the contact’s
Home Number, Company Name, E-
mail Address, Office Number, Fax
Number and Birthday. You can also
Associate Picture, Associate video,
Ringtones as well as Associate
Caller Group to the contact. Press
L
to confirm. The phone will display a
notification to confirm that the
contact has been saved.
Copy to SIM Copy all the entries to the SIM card.
Copy to
phone
Copy all the entries to the Phone.
Move to
SIM
Move all the entries to the SIM card.
Move to
Phone
Move all the entries to the Phone.
Delete all
contacts Delete all contacts in the Phone.
X800_GB_EN.book Page 44 Thursday, May 29, 2008 6:10 PM
45 Profiles
12. Profiles
Profiles
This menu allows you to set the ring tone, alert
type, ring volume, answer mode and backlight, etc
when you receive an incoming call or a new
message so that you can adapt the use of your
phone to different types of call environments.
In idle mode, tap on
on the top of the screen
to
quickly access the menu or go to main menu and
select Profiles. Select General, Meeting, Outdoor,
Indoor, Headset or Flight Mode and Silent. Select
Activate or Modify to set the selected mode
including Volume (Ring Tone and Key Tone), Ringtones
(Calls and Message alert), Alert Type (Ring, Vibration
Only, Ring and Vibra or Vibra Then Ring), Key sound
(On or Off) and Backlight level (Level 1 to Level 4).
Flight Mode
This menu allows you to set your menu to Normal
Mode or Flight Mode. You can also select Ask When
Power On so that you will be asked which mode you
prefer when the phone is powered on. If Flight
Mode is activated, network function will be closed
and all related network operations will be
prohibited.
You can only exit this profile by deactivating
the Flight Mode in the menu.
X800_GB_EN.book Page 45 Thursday, May 29, 2008 6:10 PM
Bluetooth 46
13. Bluetooth
Bluetooth
Your phone supports Bluetooth wireless
technology, allowing connection to a compatible
Bluetooth device within 10 meters. The Bluetooth
connection can be subject to interference from
obstructions such as walls or other electronic
devices.
Before you can apply Bluetooth, make sure the
other device supports Bluetooth function by
contacting the device’s manufacturer or its
accompanied documentation.
Bluetooth menu
Making a Bluetooth connection
To make a Bluetooth connection, first of all, make
sure you switch on the Bluetooth feature in the
On/
Power
option. Then select and add
My Device
.
Connection with an audio device
Tap on
Add
. When the list of device appears, select
the one you want to make a connection with it. As
soon as you select a device and a connection is
made, you are prompted to enter a passkey in
order to pair with the device. This passkey is
supplied by the manufacturer of the other
Bluetooth device, refer to its documentation for
further information. The passkey feature ensures
that only legitimate connections are allowed to
connect either to your device or the selected
device.
If you do not use the Bluetooth feature for some
time, you should deactivate it in order to conserve
battery power.
Options Description
Power On/Off
Turn on/off the Bluetooth
feature.
Find
Device
Search the devices that are
available.
My devices
Select to connect to devices that
you predefined.
Settings
Allows you to set the following
options:
Visibility
,
My Name
.
X800_GB_EN.book Page 46 Thursday, May 29, 2008 6:10 PM
47 Calls
14. Calls
The menus described in this section allows you to
set how your phone handles calls and manage their
related costs.
View calls
This menu provides you with a list of calls you have
missed, answered and rejected. The calls include
Incoming calls missed, Incoming calls answered,
Outgoing calls, and Rejected calls, which are displayed
in chronological order with the most recent call
first. If the correspondent is stored in your
contacts list, the corresponding name is displayed.
Select a contact from the list, and tap OK to view
the detailed information of the call. Select Edit to
edit the information of the contact or select Options
to access the options: Delete, Save to PhoneBook,
Dial, IP call or Send SMS.
Call options
This menu allows you to set all the options related
to calls: call forwarding, call waiting, etc.
Headset Answer
This function is only available when you plug in the
headset.
Anykey Answer
When this function is On, you can answer incoming
calls by pressing any key, except .
Call Time Reminder
This menu allows you to set whether or not the
phone will emit a beep tone after a certain call
duration. You can select Off (does not emit a beep
tone), Single (select a value from 1 to 3000 seconds,
which is the duration after which the phone will
emit a beep tone) or Periodic (select a value from 30
to 60 seconds, which is the periodic time after
which the phone will emit a beep tone. The phone
will emit a beep tone after each periodic time
during a call).
Call Service
The available options include:
Call time
X800_GB_EN.book Page 47 Thursday, May 29, 2008 6:10 PM
Calls 48
Display the duration of your calls: Last call time,
Total Sent, Total received and Reset All Time.
Call cost
Display the cost of your calls: Last call cost, Total
cost, Reset cost, Max cost and Price per unit.
This feature is network/ subscription
dependent.
Call waiting
Select Activate or Deactivate, or check Status.
Caller ID
Select Set by network or Hide ID or Send ID to
determine your phone number or identity will be
displayed or not to the called party.
This feature is network/ subscription
dependent.
Call Divert
To divert incoming calls to your voice mailbox or
to another phone number (regardless of whether
or not the number is in your phonebook).
Select Activate and enter the number to forward
your calls to. Select Status to check the status of the
corresponding call divert options.
Before diverting your calls to your voice mailbox,
you must enter your voice mailbox number.
This feature is subscription dependent.
Call Barring
Allows you to limit the use of your phone to
specific calls. This can be applied to Outgoing Calls
All Voice Calls Divert all incoming calls. If you
select this option, you will not
receive any calls until you
deactivate it.
If Unreachable Divert when your phone is
switched off or out of the service
area.
If No Answer Divert when you did not answer
the call.
If Busy Divert when you are already on
the phone.
All Data Calls Divert all data calls.
Cancel All Cancel all call divert options.
X800_GB_EN.book Page 48 Thursday, May 29, 2008 6:10 PM
49 Calls
(All Calls, International Calls or International Except
Home) and/or to Incoming Calls (All Calls or When
Roaming). In both cases, Cancel All option applies to
all calls at once.
Change Barring PW allows you to change the call
barring password. Status allows you to check
whether or not a particular type of call has been
barred.
This feature is network dependent and requires
a specific call barring password supplied by
your service provider.
Auto Redial
When this function is On, your phone will
automatically redial this number at intervals if the
call you have dialed is not answered.
Fixed Dial
This menu allows you to restrict your outgoing
calls. You need to enter PIN2 code, which has to be
supplied / supported by your network operator.
Not all SIM cards support PIN2 code. If your
SIM card does not have a PIN2 code, this option
is not available.
IP Number
This menu allows you to store 3 groups of IP
number so that you need not enter the number
before you make an IP call. Tap on Activate to
activate or Edit to edit the IP Number.
The IP number has to be supported by your
network operator before you can make an IP
call. When you change a new SIM card, the IP
number you have stored will be cleared. The
phone does not validate the IP number you
have entered. Therefore, please ensure that the
numbers are correct.
Clear history
This menu allows you to clear the call history in:
Delete All/Missed Calls/Received Calls/Dialed Calls/
Mode There are two modes: On (you only dial
the numbers stored in the Fixed Dial List)
and Off (you can dial any number).
Fixed Dial
List
Displays the fixed dial list. Tap on Add
to enter the name and phone number,
then tap on OK, enter PIN2 code and
tap on OK again.
X800_GB_EN.book Page 49 Thursday, May 29, 2008 6:10 PM
50 Calls
Rejected Calls. Tap on OK > Yes to confirm deletion
and No to cancel deletion.
X800_GB_EN.book Page 50 Thursday, May 29, 2008 6:10 PM
Settings 51
15. Settings
This menu allows you to change the settings related
to each available option (sounds, time and date,
security, etc.) and to customize your phone.
There are 4 tabs in the Settings menu: General,
Display, Sound, Connectivity.
Use < and > keys to navigate the 4 tabs. You can
also use your stylus pen to tab directly on the tab.
Pen calibration
It is advisable to carry out screen calibration in
order to obtain better accuracy when using it with
the stylus pen. Tap the center of the symbol with
the stylus until “Done” appears on screen.
General
This menu allows you to configure some general
settings:
Options Description
Language This menu allows you to select a
language for all menu texts. Tap on
OK to confirm.
Time &
date
Display Time: Select Digital Clock,
Analog Clock or Off.
Set Time: Edit your current time .
Set Date: Edit your current date.
Set Format: Select the Time Format and
Date Format.
International clock: Go to the world
clock menu and change the time
zone.
Power-on time: Set a time for the
phone to be switched on. You can
select On or Off. When you select,
you need to enter the time you want
your phone to be switched on.
Power-off time: Same as above.
X800_GB_EN.book Page 51 Thursday, May 29, 2008 6:10 PM
52 Settings
Display
This menu allows you to configure how the menus
are displayed on screen.
Security SIM Lock: Allows you to set the PIN
protection On or Off. When On, you
will be asked to enter your PIN code
when switching on your phone.
The default PIN code is network
dependent on your service
provider. Please contact your
service operator for the PIN
information.
Phone Lock: Allows you to set a
password for your hone. The default
setting is . Once you have set phone
lock, you must enter the password
each time you switch on your phone.
Barred Dial: Allows you to change your
PIN and PIN 2 codes, as well as the call
Barring code. Depending on your SIM
card, some features or options may
require a PIN2 secret code given to
you by your operator.
Change password: Allows you to
change the PIN code, PIN 2 code and
Phone Lock Password.
Shortcuts Displays a list of shortcut features.
You can set a new shortcut key by
establishing a link between a certain
feature and a numeric or navigation
key. You can also change or delete an
existing shortcut key.
Default
storage
Set the default storage location:
Phone memory or Memory card.
Memory
status
You can check the memory status of
Contacts, Messaging and My files. You
can also check the memory status of
memory card if it is inserted.
Factory
settings
Restore your phone settings to the
default values.
Options Description
Wallpaper Allows you to set the wallpaper of
the main screen. You can select the
wallpaper from Default wallpapers
or User define.
X800_GB_EN.book Page 52 Thursday, May 29, 2008 6:10 PM
Settings 53
Sounds
This menu allows you to operate your phone with
different sound profiles.
Connectivity
Settings such as Call Options, Message settings,
Network, Browser, Data account, Connections, Java
settings and Java settings for connectivity have been
collected in this menu. For detailed description of
Call settings, Message settings, Browser, Data account,
Game settings and Java settings , please refer to the
previous chapters. For Network settings, , pls refer
to the description below.
Themes Select a theme for your phone.
Backlight
Level
Select one level from Level 1 to 4.
Backlight
duration
Select backlight duration from 1
minute, 30 seconds, 15 seconds or 5
seconds.
Show own
number
Select to determine to display or
not your number to the called
party.
Greeting Select to turn greetings On or Off
and edit the greetings message.
Light sensor Allows you to set the Light sensor
of the main screen On or Off.
Alert type Allows you to select different
alert types: Ring Only, Vibrate only,
Vibrate and ring or Vibrate then ring.
Ringtones Allows you to select a ringtone
for for Incoming call and Message
alert..
Ring volume Adjust the volume of your ringer.
Key sound Allows you to switch the key
sound On or Off.
Shutter sound Allows you to select from 3
shutter sounds. You can also
select Off.
Battery low Allows you to enable or disable
the emission of a warning tone
when the battery level is low.
X800_GB_EN.book Page 53 Thursday, May 29, 2008 6:10 PM
54 Settings
Network settings
This feature allows you to change your Network
settings:
Options Description
Select
Network
Select between New Search, Select
Network and Selection Mode.
GPRS
connection
Allows you to define how your
mobile phone connects to the GPRS
service.
•When needed: Your phone will
connect to the GPRS service only
when required. This option
reduces energy consumption, but
increases the connection delay.
•Always On: Your phone
automatically connects to the
GPRS service (if available). This
option allows quicker access to
GPRS features, but increases
energy consumption.
Preferred
Networks
Select your preferred network.
X800_GB_EN.book Page 54 Thursday, May 29, 2008 6:10 PM
55 Icons & Symbols
Icons & Symbols
In idle mode, several symbols can be displayed
simultaneously on the main screen. When pressing
some of the status icons, the corresponding menu
will be displayed on the screen.
If the network symbol isn’t displayed, the
network is currently not available. You may be
in a bad reception area, moving to a different
location may help.
Silent
- Your phone will not ring when
receiving a call.
Vibra
- Your phone will vibrate when
receiving a call.
SMS message
- You have received a new
message.
Voice mail
- You have received a new
voice mail.
Battery
- The bars indicate the battery
level
(4 bars = full, 1 bar = low).
Call divert
- Indicates that the call divert
function is activated.
Voice mail
- Feature is activated
Alarm clock
is activated.
Roaming
- Displayed when your phone is
registered to a network other than your
own (especially when you’re abroad).
SMS full
- Memory for messages is full.
Delete old messages to receive new ones.
Missed call
- You have a missed call.
Headset
- The headset is plugged into the
phone.
Home zone
- A zone designated by your
network operator. Subscription
dependent, contact your service provider
for details.
GSM Network
: your phone is connected
to a GSM network.
Reception quality
:
the more bars are
shown the better the reception is.
SIM Memory full
- The SIM memory is full.
Delete old items to store new ones.
Profiles
- You can access the Profiles
menu directly.
X800_GB_EN.book Page 55 Thursday, May 29, 2008 6:10 PM
Icons & Symbols 56
Shortcut
- You can access the Shortcut
menu directly.
MMS message
- You have received a new
multimedia message.
Wap message
- You have received a
message in the wap push inbox.
GPRS attach
- Your phone is connected
to the GPRS network.
EDGE attach
- Your phone is connected
to the EDGE network.
X800_GB_EN.book Page 56 Thursday, May 29, 2008 6:10 PM
57
Precautions
Radio Waves
Your cellular mobile phone is a low
power radio transmitter and
receiver. When it is operating, it sends
and receives radio waves. The radio
waves carry your voice or data signal to
a base station that is connected to the telephone
network. The network controls the power at
which the phone transmits.
• Your phone transmits/receives radio waves in the
GSM frequency (900 / 1800 / 1900 MHz).
• The GSM network controls transmission power
(0.01 to 2 watts).
• Your phone complies with all relevant safety
standards.
• The CE mark on your phone shows compliancy
with European electromagnetic compatibility
(Ref. 89/336/EEC) and low voltage directives
(Ref. 73/23/EEC).
Your cellular mobile phone is your responsibility.
To avoid damage to yourself, to others or to the
phone itself, read and follow all the safety
instructions and make them known to anyone
borrowing your phone. Furthermore to prevent
unauthorised use of your phone:
Keep your phone in a safe place and keep
it out of small children's reach.
Avoid writing down your PIN code. Try
to remember it instead.
Switch off the phone and remove the battery if you
are going to leave it unused for a long time. Change
your PIN code after purchasing the phone and to
activate call restriction options.
The design of your phone complies with
all applicable laws and regulations.
However your phone may cause
interference with other electronic
devices. Consequently you should follow all local
recommendations and regulations when using
your cellular phone both at home and when away.
Regulations on the use of cellular phones in
vehicles and aircraft are particularly
stringent.
Public concern has been focused for some time on
the possible health risks for users of cellular phones.
The current research on radio wave technology,
including the GSM technology, has been reviewed
and safety standards have been drawn up to ensure
protection from exposure to radio wave energy.
X800_GB_EN.book Page 57 Thursday, May 29, 2008 6:10 PM
58
Your cellular telephone complies with all
applicable safety standards and the Radio
Equipment and Telecommunications Terminal
Equipment Directive 1999/5/EC.
Always switch off your phone...
Inadequately protected or sensitive electronic
equipment may be affected by radio energy. This
interference can lead to accidents.
Before boarding an aircraft and/or when
packing the phone in your luggage: the use
of mobile phones in an aircraft may be
dangerous for the operation of the aircraft, disrupt
the mobile phones network and may be illegal.
In hospitals, clinics, other health care
centres and anywhere else where you may
be in the close vicinity of medic
al
equ
ipment.
In areas with a potentially explosive
atmosphere (e.g. petrol stations and
also areas where the air contains dust
particles, such as metal powders).
In a vehicle transporting flammable products (even
if the vehicle is parked) or a vehicle powered by
liquefied petroleum gas (LPG), check first that the
vehicle complies with the applicable safety rules.
In areas where you are requested to turn off radio
transmitting devices, such as quarries or other
areas where blasting operations are in progress.
Check with the vehicle manufacturer that
electronic equipment used in your
vehicle will not be affected by radio
energy.
Pacemakers
If you have a pacemaker:
• Always keep the phone more than 15 cm from
your pacemaker when the phone is switched on,
in order to avoid potential interference.
• Do not carry the phone in a breastpocket.
• Use the ear opposite to the pacemaker to
minimise the potential interference.
• Switch off your phone if you suspect that
interference is taking place.
Hearing aids
If you are a user of a hearing aid, consult your
physician and hearing aid manufacturer to learn
whether your particular device is susceptible to
cellular phone interference.
X800_GB_EN.book Page 58 Thursday, May 29, 2008 6:10 PM
59
Improved performance
In order to improve the performance of your
phone, reduce radio energy emission, reduce
battery consumption and ensure safe
operation adhere to the following guidelines:
For the optimal and satisfactory operation
of the phone you are recommended to
use the phone in the normal operating
position (when not using in hands-free
mode or with a hands-free accessory).
• Do not expose your phone to extreme
temperatures.
• Treat the phone with care. Any misuse will void
the International Guarantee.
• Do not immerse the phone in any liquid; if your
phone is damp, switch it off, remove the battery
and let them dry for 24hrs before using them
again.
• To clean the phone, wipe it with a soft cloth.
• Placing and receiving calls consumes the same
amount of battery energy. However, the mobile
consumes less energy in idle screen when kept in
the same place. When in idle screen and while you
are moving, your phone consumes energy to
transmit updated location information to the
network. Setting the backlight for a shorter period
of time as well as avoiding unnecessary navigating
in the menus will also help to save the battery’s
energy for longer phoning and stand-by
performances.
Battery information
• Your phone is powered by a rechargeable
battery.
• Use specified charger only.
• Do not incinerate.
• Do not deform or open the battery.
• Do not allow metal objects (such as keys in your
pocket) to short circuit the battery contacts.
• Avoid exposure to excessive heat (>60° C or
140° F), moisture or caustic environments.
You should only use Philips Authentic
Accessories, as the use of any other
accessories may damage your phone and
may be dangerous, and will make all
guarantees for your Philips phone null and void.
The use of an incorrect type of battery may also
cause an explosion.
Make sure damaged parts are replaced immediately
by a qualified technician and that they are replaced
with genuine Philips replacement parts.
X800_GB_EN.book Page 59 Thursday, May 29, 2008 6:10 PM
60
Your mobile phone and your car
Studies have shown that speaking on the
telephone while driving lowers your
concentration, which can be dangerous.
Adhere to the following guidelines:
• Give your full attention to driving. Pull off the
road and park before using the phone.
• Respect the local regulations in countries where
you drive and use your GSM phone.
• If you want to use your phone in a vehicle, install
the hands-free car kit which is designed for that
purpose.
• Ensure that your phone and car kit do not block
any air bags or other security devices fitted in your
car.
• The use of an alarm system to operate a vehicle's
light or horn to indicate incoming phone calls is
prohibited on public roads in some countries.
Check local regulations.
EN 60950 Norm
In hot weather or after prolonged exposure to the
sun (e.g., behind a window or a windscreen), the
temperature of your phone's casing might increase,
especially when featuring a metallic finish. Be very
careful in this case when picking up your phone and
also avoid using it with an ambient temperature over
40° C.
For your phone, the socket-outlet shall be installed
near the phone and shall be accessible.
Environmental care
Remember to observe the local
regulations regarding the disposal of the
packaging materials, exhausted batteries
and old phone and please promote their
recycling.
Philips has marked the battery and packaging with
standard symbols designed to promote the
recycling and appropriate disposal of your eventual
waste.
The labelled packaging material is
recyclable.
A financial contribution has been
made to the associated national
packaging recovery and recycling
system.
The plastic material is recyclable
(also identifies the type of plastic).
X800_GB_EN.book Page 60 Thursday, May 29, 2008 6:10 PM
61
WEEE Marking in the DFU:
“Information to the Consumer”
Disposal of your old product
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by the
European Directive 2002/96/EC
Please inform yourself about the local
separate collection system for
electrical and electronic products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste. The correct disposal of your old
product will help prevent potential negative
consequences for the environment and human
health.
FCC Compliance Statement
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment
and receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
X800_GB_EN.book Page 61 Thursday, May 29, 2008 6:10 PM
62
Tro u b l e s h o o t i n g
The phone does not switch on
Remove/reinstall the battery. Then charge the
phone until the battery icon stops scrolling. Unplug
the charger and try to switch the mobile on.
The display shows BLOCKED when you
switch on the phone
Somebody tried to use your phone but didn’t know
the PIN code nor the unblocking code (PUK).
Contact your service provider.
The display shows IMSI failure
This problem is related to your subscription.
Contact your operator.
Your phone doesn’t return to idle screen
Long press the hang-up key or switch off the phone,
check that the SIM card and the battery are
installed correctly and switch it on again.
The network symbol is not displayed
The network connection is lost. Either you are in a
radio shadow (in a tunnel or between tall buildings) or
you are outside the network coverage area. Try from
another place, try to reconnect to the network
(especially when abroad), check that the antenna is in
place if your mobile has an external antenna, or
contact your network operator for assistance/
information.
The display doesn’t respond (or the
display responds slowly) to key presses
The display responds more slowly at very low
temperatures. This is normal and does not affect
the operation of the phone. Take the phone to a
warmer place and try again. In other cases please
contact your phone supplier.
Your battery seems to over heat
You might be using a charger that was not intended
for use with your phone. Make sure you always use
the Philips authentic accessory shipped with your
phone.
Your phone doesn’t display the phone
numbers of incoming calls
This feature is network and subscription
dependent. If the network doesn’t send the caller’s
number, the phone will display Call 1 or Withheld
instead. Contact your operator for detailed
information on this subject.
X800_GB_EN.book Page 62 Thursday, May 29, 2008 6:10 PM
63
You can’t send text messages
Some networks don’t allow message exchanges
with other networks. First check that you have
entered the number of your SMS centre, or contact
your operator for detailed information on this
subject.
You can’t receive and/or store JPEG pictures
A picture may not be accepted by your mobile
phone if it is too large, if its name is too long, or if
it doesn’t have the correct file format.
You feel that you have missed some calls
Check your call divert options.
When charging, the battery icon shows no
bar and the outline is flashing
Only charge the battery in an environment where
the temperature does not go below 0°C (32°F) or
above 50°C (113°F).
In other cases please contact your phone supplier.
The display shows SIM failure
Check that the SIM card has been inserted
correctly. If the problem persists, your SIM card
may be damaged. Contact your operator.
When attempting to use a feature in the
menu, the display shows NOT ALLOWED
Some features are network dependent. They are
only available, therefore, if the network or your
subscription supports them. Contact your
operator for detailed information on this subject.
The display shows INSERT YOUR SIM CARD
Check that the SIM card has been inserted
correctly. If the problem persists, your SIM card
may be damaged. Contact your operator.
The autonomy of your phone seems lower
than indicated on the user guide
The autonomy is linked to your settings (e.g., ringer
volume, backlight duration) and the features you
use. To increase the autonomy, and whenever
possible, you must deactivate features you do not
use.
Your phone doesn’t work well in your car
A car contains many metallic parts that absorb
electromagnetic waves which can affect the phone’s
performance. A car kit is available to provide you
with an external antenna and enables you to make
and receive phone calls without handling the
handset.
X800_GB_EN.book Page 63 Thursday, May 29, 2008 6:10 PM
64
Check with the local authorities whether or not
you are allowed to use the phone while driving.
Your phone is not charging
If the battery is completely flat, it might take several
minutes of pre-charge (up to 5 minutes in some
cases) before the charging icon is displayed on the
screen.
X800_GB_EN.book Page 64 Thursday, May 29, 2008 6:10 PM
65 Philips Authentic Accessories
Philips Authentic
Accessories
Some accessories, such as a standard battery,
headset, USB cable and a charger, are included as
standard accessories in your mobile phone
package. Additional accessories may also be
provided or sold separately. Package contents may
therefore vary.
To maximise the performance of your Philips
mobile phone and not to void the warranty,
always purchase Philips Authentic Accessories
that are specially designed for use with your
phone. Philips Consumer Electronics cannot be
held liable for any damages due to use with non
authorised accessories.
Charger
Charges your battery in any AC outlet. Small
enough to carry in a briefcase/handbag.
Deluxe Headset
The integrated answer button offers you a simple
way to answer your calls. Simply answer an
incoming call by pressing the button or long press
to reject the incoming call.
Data Connect Kit
Provides easy data connection to your Philips
mobile phone. The USB cable enables high-speed
communication between your phone and your
computer. The provided software allows you to
download pictures and melodies and to
synchronise your contacts and appointments.
When your mobile phone is connected to the
PC via a USB data cable, the cable also acts as
charger to charge your phone (X800 USB
charging is compatible with most PCs).
X800_GB_EN.book Page 65 Thursday, May 29, 2008 6:10 PM
Philips Authentic Accessories 66
USB
This feature allows you to connect your phone to
a PC via USB cable. You can carry out the
following operations:
When the transfer is finished, please make sure
that you safely remove your device based on
the instruction of your computer.
Using Mobile Phone Tools
Mobile phone tools help you make the best use of
your mobile phone for data and document
transmission through the Mobile Phone Tools
software. With this software, you can upload and
download files, send and receive SMS and edit your
mobile phone contacts. To activate this feature, you
need to install and open the Mobile Phone Tools.
Then connect the phone via the USB cable. Enter
Connectivity
menu and select
Com port
. On the
computer screen, select
X800
and press
Connect
.
Mass Storage
Acts as a mass storage for your
mobile phone data on the computer
and recover the data saved in the
computer, upload and download
files, access the internal memory
and micro SD card (if present) and
the size of transfer is unlimited until
your memory is full.
Webcam
Acts as a webcam for your PC.
COM port
Acts as a modem for your phone
and PC connnection. You can use
the software provided to edit your
mobile phone contacts, pictures and
melodies.
X800_GB_EN.book Page 66 Thursday, May 29, 2008 6:10 PM
68
Trademark Declaration
JAVA is a trademark of Sun
Microsystems, Inc.
In-Fusio and the games engine
Exen are trademarks of In-
Fusio France.
X800_GB_EN.book Page 68 Thursday, May 29, 2008 6:10 PM
69 Specific Absorption Rate Information
Specific Absorption Rate Information
International standards
THIS MOBILE PHONE MEETS THE INTERNATIONAL RECOMMENDATIONS FOR EXPOSURE TO
RADIO WAVES
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits
for exposure to radio frequency (RF) energy defined by the international standards. These recommendations
have been established by the International Commission on Non-Ionizing Radiation Protection (ICNIRP) and, the
Institute of Electrical and Electronics Engineers (IEEE) that forecast a substantial safety margin for assuring the
protection of all persons, regardless of age and health.
The exposure recommendations for mobile phones use a measurement unit known as the Specific Absorption
Rate (SAR). The SAR limit recommended by the ICNIRP for the mobile phones used by the general public is
2.0W/kg averaged over ten grams of tissue and, is 1,6W/kg averaged over one gram of tissue by IEEE
Std 1528 for the head.
Tests for SAR have been conducted using recommended operating positions with the mobile phone transmitting
at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR levels of the mobile phone while operating are generally below the
maximum SAR value. This is because the phone is designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the closer you are to a base station antenna, the lower
the power output.
While there may be differences between the SAR levels of various phones and at various positions, they all meet
the international protection standards for exposure to radio waves.
The highest SAR value for this Philips Xenium X800 model phone when tested for compliance against the
standard was 0,854 W/kg for ICNIRP recommendation and 0,729 W/kg for IEEE Std 1528.
For limiting the radio waves exposure, it is recommended to reduce the mobile phone call duration or to use
a headset. The purpose of those precautions is to take the mobile phone away from the head and the body.
For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used whit
an accessory that contains no metal and that positions the handset a minimum of 1.5cm from the body. Use of
other accessories may not ensure compliance with FCC RF exposure guidelines.
X800_GB_EN.book Page 69 Thursday, May 29, 2008 6:10 PM
70
Limited Warranty
1. What Does This Limited Warranty Cover?
Philips warrants to the original retail purchaser
(“Consumer” or “You”) that this Philips
cellular product and all accessories originally
provided by Philips in the sales package
(“Product”) are free from defects in materials,
design and workmanship under normal use in
accordance with the operating instructions and
pursuant to the following terms and
conditions. This limited warranty extends only
to the Consumer for Products purchased and
used in the original country of purchase. The
limited warranty is valid only in Philips’
intended country of sales of the product.
2. How Long is The Limited Warranty Period?
The limited warranty period for the Product
extends for ONE (1) YEAR from the date of
purchase of the Product, documented by valid
proof of purchase. The limited warranty for
original Philips rechargeable battery extends
for six (6) months from the date of purchase.
3. What Will Philips Do if The Product is Not
Free From Material Defects in Materials and
Workmanship During The Limited Warranty
Period?
During the limited warranty period, Philips or
its authorized service representative will, at its
option either repair or replace, without charge
for parts or labour, a materially defective
Product with new or refurbished parts or
Product and return such repaired or replaced
Product to the Consumer in working
condition. Philips will retain defective parts,
modules or equipment.
Repaired or replaced Product will be covered
by this limited warranty for the balance of the
original limited warranty period or ninety (90)
days from the date of repair or replacement
whichever is longer. Repair or replacement of
Product, at Philips’ option is your exclusive
remedy.
4. What is Not Covered By This Limited
Warranty?
This limited warranty does not cover:
a) Product that has been subjected to
misuse, accident, shipping or other
physical damage, improper installation,
abnormal operation handling, neglect,
X800_GB_EN.book Page 70 Thursday, May 29, 2008 6:10 PM
71
inundation, fire, water or other liquid
intrusion; or
b) Product that has been damaged due to
repair, alteration, or modification by
anyone not authorized by Philips; or
c) Product that has reception or operation
problems caused by signal conditions,
network reliability or cable or antenna
systems; or
d) Product defects or problems caused by
uses with non-Philips products or
accessories; or
e) Product which warranty/quality stickers,
product serial number or electronic serial
number has been removed, altered or
rendered illegible; or
f) Product purchased, used, serviced, or
shipped for repair from outside the
original country of purchase, or used for
commercial or institutional purposes
(including but not limited to Products used
for rental purposes); or
g) Product returned without valid proof of
purchase or which proof of purchase has
been altered or is illegible.
h) Normal wear and tear or Force Majeure.
5. How Do You Get Warranty Service?
a) Return the Product to an authorized
service center of Philips. You may contact
the local Philips office for the location of
the nearest authorized service center.
b) The SIM card must be removed from the
Product before it is given to Philips. Philips
assumes no liability for damaged or loss of
the SIM card or the data contained
therein.
c) If the Product failure is not covered by this
limited warranty, or this limited warranty
is inapplicable, void or invalid due to any
terms and conditions stated herein, the
Consumer will be charged for the cost of
repair or replacement of the Product and
all other related cost incurred in repairing
or replacing the Product.
d) IMPORTANT - you are required to return
the Product together with a valid proof of
purchase which must identify the point of
purchase, date of purchase, Product
model and Product serial number clearly.
6. Other Limitation: This Warranty is The Entire
Agreement.
EXCEPT FOR THE EXPRESS WARRANTIES
SET FORTH ABOVE AND THOSE IMPLIED
BY LAW AND WHICH CANNOT BE
EXCLUDED OR MODIFIED BY
X800_GB_EN.book Page 71 Thursday, May 29, 2008 6:10 PM
72
AGREEMENT, PHILIPS PROVIDES NO
OTHER WARRANTY WHETHER EXPRESS
OR IMPLIED (WHETHER BY STATUTE,
UNDER THE OPERATION OF LAW OR
OTHERWISE) AND SPECIALLY DISCLAIMS
ANY WARRANTY OF SATISFACTORY
QUALITY MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
PHILIPS’ TOTAL LIABILITY FOR DAMAGES
RELATING TO OR ARISING OUT OF THE
PURCHASE OR USE OF THE PRODUCT,
REGARDLESS OF THE TYPE OR CAUSE OF
SUCH DAMAGE OR THE FORM OR
CHARACTERISATION OF THE CLAIM
ASSERTED (E.G. CONTRACT OR TOPIT),
SHALL NOT EXCEED THE ORIGINAL
PURCHASE PRICE PAID FOR THE
PRODUCT.
HOWEVER IN NO EVENT SHALL PHILIPS BE
LIABLE FOR ANY PUNITIVE, SPECIAL,
INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES (INCLUDING
BUT NOT LIMITED TO THE LOSS OF USE,
LOSS OF TIME, INCONVENIENCE,
COMMERIAL LOSS, LOST PROFITS, LOST
BUSINESS OPPORTUNITIES, COST OF
SUBSTITUTION OF GOODS OR SERVICES,
INVESTMENTS, DAMAGE TO GOODWILL
OR REPUTATION, OR LOSS OF DATA AND
CLAIMS BY THIRD PARTIES) RESULTING
FROM PURCHASE OR USE OF THE
PRODUCT, TO THE FULLEST EXTENT
ALLOWED BY LAW, WHETHER OR NOT
PHILIPS HAS BEEN ADVISED OF THE
POSSIBILTY OF SUCH DAMAGES. THESE
LIMITATIONS SHALL APPLY
NOTWITHSTANDING THE FAILURE OF
THE ESSENTIAL PURPOSE OF ANY LIMITED
REMEDY.
This limited warranty represents the complete
and exclusive agreement between the
Consumer and Philips with respect to this
cellular Product and it supercedes all prior
agreements between the parties, oral or
written, and all other communications
between the parties relating to the subject
matter of this limited warranty. No carrier,
retailer, agent, dealer, employee, thereof, or
employee of Philips is authorized to make
modifications to this limited warranty and you
should not rely on any such representation.
This limited warranty does not affect the
Consumer’s statutory rights under applicable
national laws in force.
X800_GB_EN.book Page 72 Thursday, May 29, 2008 6:10 PM
Declaration of
Conformity
We,
Shenzhen Sang Fei Consumer
Communications Co., Ltd.
11 Science and Technology Road,
Shenzhen Hi-tech Industrial Park,
Nanshan District, Shenzhen 518057
China
declare under our sole responsibility that the
product
Philip X800
Philips GSM/GPRS 900/1800/1900
TAC number: 35364802
to which this declaration relates, is in conformity
with the following Standards:
SAFETY : EN 60950-1: 2001+A11:2004
HEALTH: EN50360: 2001
EMC: ETSI EN301 489-7 v 1.2.1; ETSI EN 301
489-17 v1.2.1
SPECTRUM: ETSI EN 301 511 v9.0.2; ETSI EN
300 328 v1.6.1
We hereby declare that all essential radio test
suites have been carried out and that the above
named product is in conformity to all the essential
requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to
in Article 10 and detailed in Annex IV of Directive
1999/5/EC has been followed with the involvement
of the following Notified Body:
CETECOM ICT Services GmbH, Unterturkheimer
Strabe6-10, 66117, Saarbrucken,Germany.
Identification mark: 0682
May 5th, 2008
Quality Manager
X800_GB_EN.book Page 81 Thursday, May 29, 2008 6:10 PM
