User Manual

上海三思电子工程有限公司上海市闵行区疏影路 1280 号总机：021-54883434 转

E‐Mail:sales@sansitech.com http://www.sansitech.com 传真：021‐54883445

C21BB‐QE26

ColorTemperatureLEDBulb

Specifications

www.sansitech.com

SHANGHAI SANSI

ELECTRIC&ENGINEERING

CO,LMT

GeneralFeaturesMechanicalSpecification

C21BB‐QE26‐10W‐27/65‐80‐WLEDColor

temperaturebulbisanewtypeofenergysaving

lampwhichisasubstituteforthetraditional

incandescentlamp.Thatisapursuitofhighlight

flux,longlife,highenergyefficiencyofthe

high‐endlighting.Itusesauniquelight

distributiondesign,theuniformandsoftlight,

withhighefficiency,protecteyes,environmental

protectionandotheradvantages



∙Color：White

∙Base：E26

∙Protectionclass：IP20

∙Dimensions：D:62.5mm,H:100.1mm

∙Ratedlifetime：25000hrs

LightFeaturesLuminairePerformance

• Mobilecontrollightandshade,switches,color

temperature.

• Continuouslyadjustablecolortemperarure,

selectmore.

• All‐roundheat,fullyinsullatedonedesign.

• Ceramiclampbody,moretexture.

• Delicateporousdesign,extremesimplicity,

triggertheimagination.



ApplicativeLocation

Itcanbeusedattheoffice,administrative

officehall,shoppingmalls,stores,businesshall,

hotels,exhibitionhalls,window,libraries,

museums,disco,barandhomelightingetc.



∙Inputvoltage：AC90~132V

∙Frequency：60Hz

∙Power：10W

∙LuminousFlux：800~1099lm

∙CRI：Ra≥80

∙CCT：2700K~6500K

∙Dimming：Dimmable

StandardsComplianceE

t

UL1993/CSAC22.2No.1993‐12

UL8750

CAN/CSAC22.2No.250.13‐14

UL/FCC



∙OperatingTemp：‐20℃～+45℃

∙OperatingHumid：10～95%RH

Dimensionaldrawing



上海三思电子工程有限公司上海市闵行区疏影路 1280 号总机：021-54883434 转

E‐Mail:sales@sansitech.com http://www.sansitech.com 传真：021‐54883445

C21BB‐QE26

ColorTemperatureLEDBulb

Specifications

www.sansitech.com

SHANGHAI SANSI

ELECTRIC&ENGINEERING

CO,LMT



Precautions

Inordertoavoidpotentialrisks,besuretousethisproductinaccordancewithfollowingprovisions:：

●Handlebulbswithcareforfearofdamage.

●Donotinstallbulbsinsiteswhichhaveheatsources,hotsteamorcorrosivegas,otherwiseaffectingnormalservicelife.

●Makesurepowersupplyismatchedwithbulbs.

●Makesuretheswitchistunedoffbeforebeingconnectedtoapower.

●Donottouchbulbssurfaceafterbeinglit.

●Nonprofessionalsarestrictlyforbiddenfromdismountingormaintainingbulbs,etc.

●Werefusetoacceptresponsibilitiesforanybehaviornotinlightofinstructionresultinginbulbsdamage.



上海三思电子工程有限公司上海市闵行区疏影路 1280 号总机：021-54883434 转

E‐Mail:sales@sansitech.com http://www.sansitech.com 传真：021‐54883445

C21BB‐QE26RGBLED

BulbSpecifications

www.sansitech.com

SHANGHAI SANSI

ELECTRIC&ENGINEERING

CO,LMT



GeneralFeaturesMechanicalSpecification

C21BB‐QE26‐10W‐RCB/30‐80‐WLEDRGBbulb

isanewtypeofenergysavinglampwhichisa

substituteforthetraditionalincandescentlamp.

Thatisapursuitofhighlightflux,longlife,high

energyefficiencyofthehigh‐endlighting.Itusesa

uniquelightdistributiondesign,theuniformand

softlight,withhighefficiency,protecteyes,

environmentalprotectionandotheradvantages



∙Color：White

∙Base：E26

∙Protectionclass：IP20

∙Dimensions：D:62.5mm,H:100.1mm

∙Ratedlifetime：25000hrs

LightFeaturesLuminairePerformance

• Comewithwifimodule,phonedirectcontrol.

• Avarietyofcolors,adjustable.

• Withtheupanddownsofmusic,youcan

experiencethechangeofcolors.

• Brightnessadjustable,powersaving,intimate.

• Setdailylightingandentertainmentinone.



ApplicativeLocation

Itcanbeusedattheoffice,administrativeoffice

hall,shoppingmalls,stores,businesshall,hotels,

exhibitionhalls,window,libraries,museums,

disco,barandhomelightingetc.

∙Inputvoltage：AC90~132V

∙Frequency：60Hz

∙Power：10W

∙LuminousFlux：800~1099lm

∙CRI：Ra≥80

∙CCT：3000K(RGB)

∙Dimming：Dimmable

StandardsComplianceE

t

UL1993/CSAC22.2No.1993‐12

UL8750

CAN/CSAC22.2No.250.13‐14

UL/FCC



∙OperatingTemp：‐20℃～+45℃

∙OperatingHumid：10～95%RH



Dimensionaldrawing



上海三思电子工程有限公司上海市闵行区疏影路 1280 号总机：021-54883434 转

E‐Mail:sales@sansitech.com http://www.sansitech.com 传真：021‐54883445

C21BB‐QE26RGBLED

BulbSpecifications

www.sansitech.com

SHANGHAI SANSI

ELECTRIC&ENGINEERING

CO,LMT



Precautions

Inordertoavoidpotentialrisks,besuretousethisproductinaccordancewithfollowingprovisions:：

●Handlebulbswithcareforfearofdamage.

●Donotinstallbulbsinsiteswhichhaveheatsources,hotsteamorcorrosivegas,otherwiseaffectingnormalservicelife.

●Makesurepowersupplyismatchedwithbulbs.

●Makesuretheswitchistunedoffbeforebeingconnectedtoapower.

●Donottouchbulbssurfaceafterbeinglit.

●Nonprofessionalsarestrictlyforbiddenfromdismountingormaintainingbulbs,etc.

●Werefusetoacceptresponsibilitiesforanybehaviornotinlightofinstructionresultinginbulbsdamage.



How to restore the factory settings

1. Turn off the lamp and wait for 10 seconds.

2. Repeat the following operation for 3 times.

(a) Turn on the lamp.

(b) When the lamp is on, turn it off

immediately.

3. Turn on the lamp and wait for 30 seconds.

The bulb will now restore factory settings. It

will change light according to: slow cold

white -> slow warm white -> no cold/warm

white and enter the Wi-Fi access point mode.

System Requirement

The Stellar Wi-fi application requires the

following system:

• iPhone 4s and later models, running iOS 7.0

or higher version.

• Android phone or tablet devices, running

android3.0 or higher version.

One or more than one Sansi Smart LED bulbs.

For the latest news about smart LED bulb,

please visit

http://www .sansistellar.com

For technical support, please contact

stellar@sansitech.com

Stellar LED Wi-Fi Bulb

Quick Guide

Shanghai Sansi Electronic Engineering Co., Ltd.

Last Updated on 05/06/2015

Introduction

Stellar Wi-Fi app supports wireless control over

Sansi Smart LED Bulbs on the

On/Off,dimming, or color.

Get the App

iPhone Users

Install the stellar Wi-fi application or scan the

QR code.

Android Users

Download the app from the link:

http://www.sansitech.com/app/stellarwi-fi.apk

Or scan the QR code below.

Local Control

Connect to the bulb

1. Fix the LED bulb and turn on its power. Open

the WLAN settings in the cell phone or tablet.

Find the bulb's Wifi network (name similar to

SLCCT*******), and connect.

2. Download App :

A) In the Appstore or Google Play, search for

Stellar Wi-Fi,

B) Scan the QR code.

3. Open the Stellar Wi-Fi application. It

searches the bulb automatically. The

connected bulbs will be shown in the list

(showing MAC addresses).

4. Touch to enter the control interface for the

bulb's color and brightness.

Connect Multiple Bulbs

To connect multiple bulbs, you need to include

them into the same Wi-Fi network, such as

the network you use at home.

1. Do the following operations to the bulbs you

wish to connect.

(a) Connect the bulb. In control page, touch

the Config button at the lower-right corner.

(b) This opens the LED bulb configuration page.

wireless network, Touch Join.

(d) The bulb will restart and connect to the

new network. You can now continue to add

other bulbs.

2. Join your phone into the new Wi-Fi network.

3. Open the Stellar Wi-Fi application and let it

search all the bulbs in the network.

Remote Control

1. Make sure the bulb and the cell phone are

connected to the network.

2. Touch left side menu to switch the control

interface.

3.Select Remote Control and a Login Interface

will display.

4. Enter your email address and password to

an account. Simply input an email address

and password, then re-enter the password.

Touch Register to create a new account.

5. After successfully logging in, a list of remote

lamps will be displayed.

6. Switch to the local list and the editor page to

set the bulb for remote control.

How to restore the factory settings

1. Turn off the lamp and wait for 10 seconds.

2. Repeat the following operation for 3 times.

(a) Turn on the lamp.

(b) When the lamp is on, turn it off

immediately.

3. Turn on the lamp and wait for 30 seconds.

The bulb will now restore factory settings. It

will change light according to: slow red ->

slow green -> slow blue -> warm white and

enters Wi-Fi access point mode.

System Requirement

The Stellar Wi-fi application requires the

following system:

• iPhone 4s and later models, running iOS 7.0

or higher version.

• Android phone or tablet devices, running

android3.0 or higher version.

One or more than one Sansi Smart LED bulbs.

For the latest news about smart LED bulb,

please visit

http://www .sansistellar.com

For technical support, please contact

stellar@sansitech.com

Stellar LED Wi-Fi Bulb

Quick Guide

Shanghai Sansi Electronic Engineering Co., Ltd.

Last Updated on 05/06/2015

Introduction

Stellar Wi-Fi app supports wireless control

over Sansi Smart LED Bulbs on the

On/Off,dimming, color. The lamp has 20

built-in preset scenes. You can also use

the microphone on the iphone (only) or the

songs in your library to interact with the bulb.

Get the App

iPhone Users

Install the stellar Wi-fi application or scan the

QR code.

Android Users

Download the app from the link:

http://www.sansitech.com/app/stellarwi-fi.apk

Or scan the QR code below.

Local Control

Connect to the bulb

1. Fix the LED bulb and turn on its power.

Open the WLAN settings in the cell phone or

tablet. Find the bulb's Wifi network (name

similar to SLRGBW*******), and connect.

2. Download App :

A) In the Appstore or Google Play, search for

Stellar Wi-Fi,

B) Scan the QR code.

3. Open the Stellar Wi-Fi application. It

searches the bulb automatically. The

connected bulbs will be shown in the list

(showing MAC addresses).

4. Touch to enter the control interface for the

bulb's color and brightness.

Connect Multiple Bulbs

To connect multiple bulbs, you need to include

them into the same Wi-Fi network, such as

the network you use at home.

1. Do the following operations to the bulbs you

wish to connect.

(a) Connect the bulb. In control page, touch

the Config button at the lower-right corner.

(b) This opens the LED bulb configuration page.

wireless network, Touch Join.

(d) The bulb will restart and connect to the

new network. You can now continue to add

other bulbs.

2. Join your phone into the new Wi-Fi network.

3. Open the Stellar Wi-Fi application and let it

search all the bulbs in the network.

Remote Control

1. Make sure the bulb and the cell phone are

connected to the network.

2. Touch left side menu to switch the control

interface.

3.Select Remote Control and a Login Interface

will display.

4. Enter your email address and password to

an account. Simply input an email address

and password, then re-enter the password.

Touch Register to create a new account.

5. After successfully logging in, a list of remote

lamps will be displayed.

6. Switch to the local list and the editor page to

set the bulb for remote control.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

Sansi Technology A19001 LED Lamps User Manual

Shanghai Sansi Technology Co., Ltd LED Lamps

User Manual

Navigation menu

Namespaces

Views

Navigation
