Scosche IPRFES iJET Wireless RF Remote Control User Manual iprfes
Scosche Industries Inc iJET Wireless RF Remote Control iprfes
Scosche >
Users Manual
![](/img.php?id=577045&img=bg1.png)
IPRFES
SPORT STYLE WIRELESS RF REMOTE KIT
FOR iPod 3RD /
4TH GEN
/
iPod Mini/iPod PHOTO
If you have any further questions, call our toll free technical help line at: 1-800-621-3695x3
© 2005 SCOSCHE INDUSTRIES, INC. SI 8/05-IPRFES (300IPRFES 8/05)
RF RECEIVER SETUP
PARTS LIST
• 5 Button RF Remote
• Universal 3.5MM Headphone to RCA Audio Cable
iPod® RF Receiver Set-up: (FIG. 1)
Plug the RF receiver into the top of your iPod. See
Fig. 1. A self diagnostic will automatically be run and
your wireless remote will be ready for operation
within 30 seconds. Plug in the Male end of the
3.5MM-to-RCA cable for vehicle use, or your
personal Ear Buds for portable use. See Fig.1.
NOTE: The connection of a 3.5MM cable to the
receiver will provide optimum performance as it uses
this wire as an antenna for maximum range (Patent
pending). The receiver is powered by your iPod.
Advanced Low Power Mode:
Your Scosche iPod RF receiver uses an advanced
power down mode which minimizes current draw on
your iPod battery if you are not connected to a
constant power source. After 20 minutes of sensing
no music playing or no remote commands, the unit
will go into an advanced battery save mode. The
receiver will automatically re-power itself when it
detects music playing, (If there was none before) or
it sees a remote button being pressed for more than
0.6 seconds.
5 BUTTON RF REMOTE CONTROL
Track Back:
Press and release this button to
move track BACKWARDS. Press
and HOLD this button to rewind
through the track.
Pause/Play/Sleep:
Press and release to toggle
between Pause and Play.
Press and HOLD for 2 full
seconds to put the iPod into
sleep mode. If you press and
hold this button for longer than 1
second but less than 2 seconds
the receiver will ignore your
request. Track Forward:
Press and release this
button to move track
FORWARD. Press and
HOLD this button to
forward through the track.
Volume Up:
Press and HOLD this
button to increase the
volume.
Volume Down:
Press and HOLD this
button to reduce the
volume.
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: 1) This device may
not cause interference, and (2) this device must accept any interference that may be received, including interference
that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification could void the user's authority to operate the
equipment.
• RF Receiver (Designed for iPod 3rd/4th Gen)
• Adjustagle Arm Band Strap
iPod is a registered trademark of Apple Computer, Inc. All rights reserved.
Congratulations on your choice of a SCOSCHE sport style wireless RF iPod remote control kit! This
system provides you with maximum control of your iPod in or out of your car from over 100 feet away.
IPRFES
SPORT STYLE WIRELESS RF REMOTE KIT
FOR iPod 3RD /
4TH GEN
/
iPod Mini/iPod PHOTO
If you have any further questions, call our toll free technical help line at: 1-800-621-3695x3
© 2005 SCOSCHE INDUSTRIES, INC. SI 8/05-IPRFES (300IPRFES 8/05)
RF RECEIVER SETUP
PARTS LIST
• 5 Button RF Remote
• Universal 3.5MM Headphone to RCA Audio Cable
iPod® RF Receiver Set-up: (FIG. 1)
Plug the RF receiver into the top of your iPod. See
Fig. 1. A self diagnostic will automatically be run and
your wireless remote will be ready for operation
within 30 seconds. Plug in the Male end of the
3.5MM-to-RCA cable for vehicle use, or your
personal Ear Buds for portable use. See Fig.1.
NOTE: The connection of a 3.5MM cable to the
receiver will provide optimum performance as it uses
this wire as an antenna for maximum range (Patent
pending). The receiver is powered by your iPod.
Advanced Low Power Mode:
Your Scosche iPod RF receiver uses an advanced
power down mode which minimizes current draw on
your iPod battery if you are not connected to a
constant power source. After 20 minutes of sensing
no music playing or no remote commands, the unit
will go into an advanced battery save mode. The
receiver will automatically re-power itself when it
detects music playing, (If there was none before) or
it sees a remote button being pressed for more than
0.6 seconds.
5 BUTTON RF REMOTE CONTROL
Track Back:
Press and release this button to
move track BACKWARDS. Press
and HOLD this button to rewind
through the track.
Pause/Play/Sleep:
Press and release to toggle
between Pause and Play.
Press and HOLD for 2 full
seconds to put the iPod into
sleep mode. If you press and
hold this button for longer than 1
second but less than 2 seconds
the receiver will ignore your
request. Track Forward:
Press and release this
button to move track
FORWARD. Press and
HOLD this button to
forward through the track.
Volume Up:
Press and HOLD this
button to increase the
volume.
Volume Down:
Press and HOLD this
button to reduce the
volume.
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: 1) This device may
not cause interference, and (2) this device must accept any interference that may be received, including interference
that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification could void the user's authority to operate the
equipment.
• RF Receiver (Designed for iPod 3rd/4th Gen)
• Adjustagle Arm Band Strap
iPod is a registered trademark of Apple Computer, Inc. All rights reserved.
Congratulations on your choice of a SCOSCHE sport style wireless RF iPod remote control kit! This
system provides you with maximum control of your iPod in or out of your car from over 100 feet away.
