Secure Wireless IJETV2 iJET Wireless RF Remote Control User Manual IJETV2 V1 0
Secure Wireless, Inc iJET Wireless RF Remote Control IJETV2 V1 0
Users Manual
CONGRATULATIONS ON YOUR PURCHASE OF THE iJET
WIRELESS RF REMOTE CONTROL
The iJet was designed to provide maximum control of your iPod from anywhere you choose to place it
regardless of whether it is in your backpack or over a hundred feet away in a different room connected to
your home stereo.
Operation
iPod RF receiver setup: (FIG 1)
Plug the iJet into the dock connector located on bottom of
your iPod. Please WAIT 30 seconds for the automatic self-
diagnostic to run. Plug in your earbuds, speakers or connect
to your home stereo through a set of RCA jacks (supplied in
some iJet kits). To sync or charge the iPod, simply plug
your USB/Firewire or charging device into the bottom of the
iJet while it’s connected to the iPod.
Advanced Low Power Mode (ALPM):
The iJet uses an advanced power down mode which
minimizes current draw on your iPod battery if you are not
connected to a constant power source. After 20 minutes of
sensing no music playing or no remote commands being
sent, the iJet goes into a battery saving mode. The iJet receiver will automatically re-power itself when it
detects music playing or a remote button being pressed for more than 0.6 seconds.
Remote Control Functions
Features
• Pass-through 30-pin connector allows charge/sync.
• Thin profile (only 0.55”).
• Up to 150 ft range.
• Supports iPod with dock connector from 3rd Gen forward.
Optional iJet Accessories
iJet Remote:
Pair up to 10 iJet remotes with any iJet receiver. Place an iJet remote in each bedroom, out by pool or
anywhere you choose to control your music. Pairing instructions: 1) Unplug iJet receiver from your iPod.
2) Make sure your iPod is sufficiently charged. 3) Plug the iJet receiver into the iPod dock connector.
4) Within 30 seconds of step 3, press and hold all four buttons simultaneously on the new remote for three
seconds (Vol. +, Vol. -, FF, RW), release after three seconds. 5) The new remote has been paired.
Technical Specifications
Operating Range: Up to 150 ft.
Transmission Method: Radio frequency
Operating Frequency: 433.92 MHz
Remote Power: (2) CR2025 3V
Receiver Power: Powered from iPod with Advanced Low Power Mode (ALPM)
Remote Dimensions/Weight: 2.2” x 1.3” x 0.43” / 0.7 oz
Receiver Dimensions/Weight: 4.3” x 0.79” (w/o connector height) x 0.55” / 0.5 oz
Contact ABT
Advanced Bridging Technologies
Toll Free 888-869-4737
5817 Dryden Place Ste. 104
Carlsbad, CA 92008
iPod is a registered trademark of Apple Computer, Inc. All rights reserved.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired
operation.
Per FCC 15.21, you are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
Rewind: Press and release this button
to move track BACKWARDS. Press
and HOLD this button to rewind
through the track
Volume Down: Press and HOLD
this button to scroll volume down.
Forward:
Press and release this button to
move track FORWARD. Press
and HOLD this button to
forward through the track.
Volume Up: Press and
HOLD this button to scroll
volume up.
Play/Pause/Sleep: Press and release to toggle between Pause and Play.* Press and HOLD for 2
full seconds to put the iPod into sleep mode. If you press and hold this button for longer than 1
second but less than 2 seconds, the iJet will ignore your request.
