Environmental Product Declaration
Securitron
EcoPower Power Supply
ASSA ABLOY is committed to
providing products and services
that are environmentally sound
throughout the entire production
process and the product lifecycle.
Our unconditional aim is to make
sustainability a central part of our
business philosophy and culture,
but even more important is the job
of integrating sustainability into our
business strategy. The
employment of EPDs will help
architects, designers and LEED-
APs select environmentally
preferable door openings.
ASSA ABLOY will continue our
efforts to protect the environment
and health of our customers/end
users and will utilize the EPD as
one means to document those
efforts.
Environment
2 of 11
Product definition and information about building physics
Information about basic material and the material's origin
Description of the product's manufacturing
Indication of product processing
Information about the in-use conditions
Life cycle assessment results
Testing results and verifications
The PCR review was conducted by
INTERNAL EXTERNAL
1 Exclusions: EPDs do not indicate that any environmental or social performance benchmarks are met, and there may be impacts that they do not encompass. LCAs do not typically address the site-
specific environmental impacts of raw material extraction, nor are they meant to assess human health toxicity. EPDs can complement but cannot replace tools and certifications that are designed to
address these impacts and/or set performance thresholds , e.g., Type 1 certifications, health assessments and declarations, environmental impact assessments, etc. Accuracy of Results: EPDs
regularly rely on estimations of impacts, and the level of accuracy in estimation of effect differs for any particular product line and reported impact. Comparability
: EPDs are not comparative assertions
and are either not comparable or have limited comparability when they cover different life cycle stages, are based on different product category rules or are missing relevant environmental impacts.
EPDs from different programs may not be comparable.
CONTENTS OF THE
DECLARATION
The Independent Expert Committee, SVR
This declaration was independently verified in accordance with ISO 14025
by Underwriters Laboratories
UL Environment
This life cycle assessment was independently verified in accordance with
ISO 14044 and the reference PCR by
PROGRAM OPERATOR
Environmental Product Declaration
According
Securitron
to
This declaration is an environmental product declaration (EPD) in accordance with ISO 14025. EPDs rely on
Life Cycle Assessment (LCA) to provide information on a number of environmental impacts of products over
their life cycle. Exclusions: EPDs do not indicate that any environmental or social performance benchmarks
are met, and there may be impacts that they do not encompass. LCAs do not typically address the site-
specific environmental impacts of raw material extraction, nor are they meant to assess human health
toxicity. EPDs can complement but cannot replace tools and certifications that are designed to address
these impacts and/or set performance thresholds – e.g. Type 1 certifications, health assessments and
declarations, environmental impact assessments, etc. Accuracy of Results: EPDs regularly rely on
estimations of impacts, and the level of accuracy in estimation of effect differs for any particular product line
and reported impact. Comparability: EPDs are not comparative assertions and are either not comparable or
have limited comparability when they cover different life cycle stages, are based on different product
category rules or are missing relevant environmental impacts. EPDs from different programs may not be
comparable.
Door and door hardware
ISO 14025
REFERENCE PCR
DATE OF ISSUE
PERIOD OF VALIDITY
DECLARATION HOLDER
DECLARATION NUMBER
DECLARED PRODUCT
UL Environment and Institut Bauen und Umwelt e.V. (IBU). Product Category
Rules Part B: Requirements on the Environmental Product Declaration for
Electronic Access Control Systems
Environment
3 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
Technical Data
Battery Type
Operating Temperature
Installation
Mechanical Compatibility
Shipping Weight
Certification
Input Voltage
Output Voltage
110V - 240V
14V
EcoPower is ideal for a wide range of applications. The product can be surfaced mounted, recessed into drywall, or
mounted above a drop ceiling. This product is designed to provide power to an electrified lock, in either a fail-safe or fail-
secure configuration.
Product Definition and Information
Product Description
Lead Acid
-4 t+122F [-20 to +50C]
Surface mounted / Recessed in drywall / Mounted above
Designed to work with low-power, electrified lock
1.7 lbs [0.77 kg]
UL 294, UL 603, ULC S533
Standby Power
Output Current
<10mW @ 115V; <20mW @ 230V
0.5A peak; 0.1A continuous
Application
Product name: EcoPower
Product characteristic: power supply
EcoPower is an efficient, fully featured power supply:
- Extremely low power consumption
- 24 hours of battery backup power
- Universal voltage input capabilities
- Aesthetic design allows for convinient installation near the lock
- Product contains several small screws for installation, as well as paper instructions. Otherwise, no other accessory
materials are required for installation or use.
For the declared product, the following technical data in the delivery status must be provided with reference to the test
standard:
Environment
4 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
62.61%
30.14%
3.47%
3.79%
Electronics
Plastics
Environmental and Health During Manufacturing
Percentage in mass (%)
Manufacture
Other
Total
Product Processing/ Installation
Steel
100.00%
ASSA ABLOY is committed to producing and distributing door opening solutions with minimal environmental impact,
where health & safety is the primary focus for all employees and associates.
• Environmental operations, GHG, energy, water, waste, VOC, surface treatment and H&S are being routinely
monitored. Inspections, audits, and reviews are conducted periodically to ensure that applicable standards are met and
environment management program effectiveness is evaluated.
• Code of Conduct covers human rights, labor practices and decent work. Management of ASSA ABLOY is aware of
their environmental roles and responsibilities, providing appropriate training, supporting accountability and recognizing
outstanding performance.
• Any waste metals during machining are separated and recycled. The waste from the water-based painting process is
delivered to waste treatment plant.
• The factory in Phoenix, AZ has certification of Environmental Management to ISO 14001:2004 and Occupational
Health and Safety to OHSAS 18001:2007.
EcoPower power supplies are distributed through and installed by trained installation technicians, such as locksmiths,
carpenters etc. adhering to local/national standards and requirements.
The primary manufacturing processes are made by Tier 1 suppliers and the final manufacturing processes occur in
Phoenix, AZ. The electronics are produced in China and the remainder of the components are produced in the United
States. The components come from processes like stamped steel, turning, zinc and steel casting. Final assembly takes
place in Phoenix, AZ.
Base Materials / Ancillary Materials
Material
Delivery Status
Power supplies are delivered in a box size - 6.5in x 6.5in x 3.875in.
The standards that can be applied for EcoPower power supply are:
- UL 294 - Standard for Access Control System Units
- UL 603 - Standard for Power Supplies for Use with Burglar-Alarm Systems
- ULC S533 - Standard for Egress Door Securing and Releasing Devices
Placing on the Market / Application Rules
Environment
5 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
Material
Quantity (% By Weight)
Cardboard
EcoPower power supplies are packed in a cardboard box with dimensions: 6.5in x 6.5in x 3.875in.
Other
-
Total
Extraordinary Effects
Condition of Use
Environmental and Health During Use
There is no harmful emissive potential. No damage to health or impairment is expected under normal use corresponding
to the intended use of the product.
No cleaning on annual maintenance is required.
Reference Service Life
The reference service life is 10 years, calculated based on a 40000 cycle endurance test.
Packaging
100%
100%
Water
Contains no substances that have any impact on water in case of flood. Electric operation of the device will be influenced
negative.
Mechanical destruction
No danger to the environment can be anticipated during mechanical destruction.
Re-use Phase
The product can be moved from one door to another during the reference service life, thus enabling re-use.
The majority of components are electronics and a battery. The product can be mechanically dissembled to separate the
different materials. 34% of the materials used are recyclable. The plastic components can be used for energy recovery
in an incineration plant.
Disposal
Further Information
Hanchett Entry Systems Inc, ASSA ABLOY
10027 S. 51st Street Ste. 102
Phoenix, AZ 85044
Fire
Suitable for use in fire and smoke doors (EN 14846).
Environment
6 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
End of Life
Conversion factor to 1 kg
Repair
Replacement
Disposal
Reuse-
Recovery-
Recycling
potential
Transport
Value
0.621
Declared unit
Mass
Refurbishment
Maintenance
Description of the System Boundary Stages Corresponding to the PCR
(X = Included; MND = Module Not Declared)
D
X
X
X
X
Waste
processing
B6
B7
A1
MND
MND
MND
Operational
energy use
X
C4
Use Stage
MND
Unit
unit of electronic cylinder
-
1.611
C1
C2
*This includes provision of all materials, products and energy, packaging processing and its transport, as well as waste
processing up to the end-of waste state or disposal of final residues.
A3
A4
A5
B1
Use
X
B2
B3
B4
B5
A2
In the assessment, all available data from the production process are considered, i.e. all raw materials used, auxiliary
materials (e.g. lubricants), thermal energy consumption and electric power consumption - including material and energy
flows contributing less than 1% of mass or energy (if available). In case a specific flow contributing less than 1% in mass
or energy is not available, worst case assumption proxies are selected to represent the respective environmental
impacts. Impacts relating to the production of machines and facilities required during production are out of the scope of
this assessment.
Background data
For life cycle modeling of the considered products, the GaBi 6 Software System for Life Cycle Engineering, developed by
thinkstep, is used GaBi 6 2013. The GaBi-database contains consistent and documented datasets which are
documented in the online GaBi-documentation GaBi 6 2013D. To ensure comparability of results in the LCA, the basic
data of GaBi database were used for energy, transportation and auxiliary materials.
Estimates and Assumptions
In the End-of-Life phase, for all the materials which can be recycled, a recycling scenario with 100% collection rate was
assumed.
Cut-off Criteria
1
Name
MND
MND
System Boundary
MND
Product Stage Construction
Process Stage
Transport from
gate to the site
Construction/
installation
process
Operational
water use
Deconstruction
/demolition
X
X
X
X
The declaration refers to the functional unit of 1 unit (or piece) of EcoPower Power Supply, as specified in Part B
requirements on the EPD for Electronic Access Control Systems.
kg
C3
End of Life Stage*
Benefits and
Loads Beyond
the System
Boundaries
Raw material
supply
Transport
Manufacturing
Declared Unit
Life Cycle Assessment
This is a cradle to gate with options Environmental Product Declaration. The following life cycle phases were considered:
Environment
7 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
Data Quality
The data sources used are complete and representative of North America in terms of the geographic and technological
coverage and are a recent vintage (i.e. less than ten years old). The data used for primary data are based on direct
information sources of the manufacturer. Secondary data sets were used for raw materials extraction and processing,
end of life, transportation, and energy production flows. Wherever secondary data is used, the study adopts critically
reviewed data for consistency, precision, and reproducibility to limit uncertainty.
Period Under Review
Allocation was determined on a per unit basis.
A comparison or an evaluation of EPD data is only possible if all data sets to be compared were created according to EN
15804 and the building context, respectively the product-specific characteristics of performance, are taken into account.
Environmental delarations from different programs may not be comparable. Full conformance with the PCR for North
American Builders Hardware products allows EPD comparability only when all stages of a Builders Hardware product's
life cycle have been considered. However, variations and deviations are possible.
Comparability
The period under review is January through March of 2015, the first 3 months of production of this product.
Allocation
Environment
8 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
* This scenario is based on the worst case scenario: A fail-safe configuration with zero unlocks per cycle.
h
4.71
kWh
1.97
W
26.67
LCA: Modeling Scenarios and Additional Technical Information
Installation into the building (A5)
-
kg
kg
Value
0.4101
kg
Name
26.28
End of life (C1-C4)
10
years
Reference Service Life
Other resources
-kg
Reference Service Life
Other energy carriers
-
MJ
Electricity consumption
-
kWh
h
0.15 kg
Unit
kg
VOC in the air
Name
Value
-
Unit
0.007
W
Dust in the air
Landfilling
Energy recovery
0.1871
kg
Operational Energy Use (B6)*
Standby Power Consumption
Charging Power Consumption
Standby Cycle Time
Charge Cycle Time
Average Power Consumption
Annual Energy Consumption
Reference Service Life
Lifetime Energy Consumption
0.30
W
2.628
kWh
10
years
-
kg
Output substance following waste treatment
on-site
Water consumption
-
m3
Auxiliary
-
kg
Collected as mixed construction waste
Collected separately
Name
Recycling
Reuse kg
kg
0.2106
Unit
0.1871
0.3978
Material loss
-
kg
UnitNameValue Value
The following technical information is a basis for the declared modules or can be used for developing specific scenarios
in the context of a building assessment if modules are not declared.
Environment
9 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
Parameter Parameter
TRACI 2.1 Impact Assessment
CML 4.1 Impact Assessment
Resource Use
0.0E+00
0.0E+00
3.6E+02
0.0E+00
3.6E+02
0.0E+00
0.0E+00
0.0E+00
0.0E+00
B6
2.0E+01
2.1E-10
1.8E-01
2.5E-03
B6
2.0E+01
0.0E+00
Total use of nonrenewable
primary energy resources
EP
A1-A3
5.6E+00
2.2E-07
A4
4.6E-02
1.7E-12
A5
1.4E-01
C2
2.9E-03
C3
0.0E+00
0.0E+00
0.0E+001.9E-01
0.0E+00
2.3E-07
2.9E+02
POCP
Formation potential of
tropospheric ozone
photochemical oxidants
kg ethane-Eq. 1.4E-03
2.5E-06
Parameter Unit A1-A3 A4 A5 C2
AP Air Acidification potential for air
emissions kg SO2-Eq. 1.9E-02 2.3E-04 7.1E-04 1.4E-05
3.2E-05 6.8E-05 2.0E-06
6.8E-03
1.9E-02
EP Eutrophication potential kg(PO4)3-Eq. 1.2E-03 4.0E-05 2.0E-04
0.0E+00
0.0E+00 0.0E+00
2.7E-02 0.0E+00
0.0E+00
PENRE
Nonrenewable primary energy
as energy carrier
MJ, lower calorific
value 4.6E+01 5.9E-01 1.6E+00 3.7E-02 0.0E+00
PENRM
Nonrenewable primary energy
as material utilization
MJ, lower calorific
value 2.9E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
PENRT
2.7E-02
2.0E-03 0.0E+00
2.6E+00 4.6E-02 1.4E-01 2.9E-03 0.0E+00
1.7E-12 1.3E-11 1.1E-13
3.9E-05 0.0E+00
4.1E-05 0.0E+00
1.0E-05 0.0E+00
1.0E-09 0.0E+00
2.6E-02 0.0E+00
Results below contain the resource use throughout the life cycle of the product.
0.0E+00
Results shown below were calculated using TRACI 2.1 Methodology.
3.8E-02
3.6E-02
3.2E-01 7.6E-03 8.5E-03 4.8E-04 0.0E+00 3.9E-04 0.0E+00
0.0E+000.0E+00 1.0E-04
1.4E+00
C4
2.2E-02
D
GWP
ODP
LCA Results
0.0E+00
1.4E-11 1.1E-13 0.0E+00 8.8E-14 0.0E+00
1.5E-05 2.0E-04 9.6E-07 0.0E+00 3.7E-05 0.0E+00
2.8E-04 8.0E-04 1.7E-05
Unit
Global warming potential kg CO2-Eq.
Depletion potential of the
stratospheric ozone layer kg CFC-11 Eq.
Acidification potential for air
emissions kg SO2-Eq.
AP Air
6.8E+00 8.1E-02
8.2E-14 0.0E+00
Parameter Unit A1-A3 A4 A5 C2 C3 C4
2.5E-02 0.0E+00Global warming potential kg CO2-Eq.
1.5E-01 5.1E-03
Eutrophication potential kg N-Eq.
Smog formation potential kg O3-Eq.
Fossil Fuel Depletion
SP
FFD MJ-surplus
Results shown below were calculated using CML 2001 - April 2013 Methodology.
Parameter D
GWP
ODP Depletion potential of the
stratospheric ozone layer kg CFC-11 Eq. 3.7E-10 0.0E+001.7E-10
0.0E+001.2E+01 0.0E+00 3.3E-03
PERT Total use of renewable
primary energy resources
MJ, lower calorific
value 8.8E+00 0.0E+00 6.1E-01 0.0E+00 0.0E+00
ADPE
Abiotic depletion potential for non-
fossil resources kg Sb-Eq. 6.7E-04 1.9E-11 1.9E-07 1.2E-12 0.0E+00
ADPF Abiotic depletion potential for
fossil resources MJ 4.2E+01 5.8E-01 1.4E+00 3.6E-02 0.0E+00
D
2.0E-03 0.0E+00
PERM
Renewable primary energy
resources as material
utilization
MJ, lower calorific
value 2.9E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
PERE
Renewable primary energy as
energy carrier
MJ, lower calorific
value
C3
0.0E+00
C4B6Parameter
5.9E+00 0.0E+00 6.1E-01
MJ, lower calorific
value 4.9E+01 5.9E-01 1.6E+00 3.7E-02 0.0E+00
0.0E+00
RSF Use of renewable secondary
fuels
MJ, lower calorific
value 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
SM Use of secondary material
MJ, lower calorific
value
0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
0.0E+00 0.0E+00
FW Use of net fresh water m
3
2.6E+00 0.0E+00 3.5E-02 0.0E+00 0.0E+00 1.2E-03 0.0E+00
NRSF Use of nonrenewable
secondary fuels
MJ, lower calorific
value 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
Environment
10 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
0.0E+00
Output Flows and Waste Categories
0.0E+00
HWD Hazardous waste disposed kg
NHWD Non-hazardous waste
disposed kg 0.0E+00 0.0E+00
The operational energy use (B6) is the main driver of environmental impacts in the majority of categories, except for
ozone depletion and eutrophication potential, where, the production (A1-A3) life cycle stage drives the results.
Manufacturing impacts (A3) are primarily driven by electricity use. Raw materials, particularly the circuit board and
polycabonate drive the production stage (A1), as these materials are the primary materials within the product.
Transportation impacts (A2) have a negligble impact within the production stage. The figure below shows the graphical
representation of these impacts across the product's life cycle stages:
0.0E+00
0.0E+00
0.0E+00
4.7E-07
0.0E+00
0.0E+00
4.6E-05
0.0E+00
MER Materials for energy recovery kg
1.3E-03
0.0E+00
4.5E-02
0.0E+00
MFR 0.0E+000.0E+00
0.0E+00
0.0E+00
Radioactive waste disposed kg
Interpretation
Results below contain the output flows and wastes throughout the life cycle of the product.
Parameter Parameter Unit A1-A3 A4 A5 C2 C3 C4 DB6
0.0E+00 0.0E+00
0.0E+00
0.0E+00
Exported electrical energy MJ 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
0.0E+00
0.0E+00
0.0E+00
0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+000.0E+00
0.0E+00
0.0E+00kg
Materials for recycling kg
0.0E+00
0.0E+000.0E+00
0.0E+00
RWD
CRU Components for re-use
0.0E+00 1.2E-01
7.8E-03 0.0E+00EEE Exported thermal energy MJ 3.5E-04 0.0E+00 1.6E-02 0.0E+00 0.0E+00
0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00 0.0E+00
EEE 0.0E+00
0.0E+00
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
Global warming
potential
Depletion potential
of the stratospheric
ozone layer
Acidification
potential for air
emissions
Eutrophication
potential
Smog formation
potential
Fossil Fuel Depletion
TRACI Impacts by Life Cycle Stage
A1-A3 A4 A5 B6 C2 C3 C4 D
Environment
11 of 11
Environmental Product Declaration
According
Securitron
to
Door and door hardware
ISO 14025
l
PCR Part B
UL Environment and Institut Bauen und Umwelt e.V. (IBU). Product Category Rules Part B:
Requirements on the Environmental Product Declaration for Electronic Access Control Systems
l
GaBi 6
thinkstep.one: GaBi Software-System and Databases for Life Cycle Engineering. version 6.110.
Copyright, TM. Stuttgart, Echterdingen. 1992-2015
References
l
PCR Part A
UL Environment and Institut Bauen und Umwelt e.V., Königswinter (pub.): Product Category Rules
for Construction Products from the range of Environmental Product Declarations of Institut Bauen
und Umwelt (IBU), Part A: Calculation Rules for the Life Cycle Assessment and Requirements on
the Background Report. July 2014, version 1.3
l
ISO 14044
ISO 14044:2006-10, Environmental management — Life cycle assessment — Requirements and
guidelines.
l
EN 15804
EN 15804:2012-04: Sustainability of construction works — Environmental Product Declarations —
Core rules for the product category of construction product
l
ISO 14025
ISO 14025:2011-10, Environmental labels and declarations — Type III environmental declarations
— Principles and procedures.
l
ISO 14040
ISO 14040:2009-11, Environmental management — Life cycle assessment — Principles and
framework.
l
TRACI 2.1
US EPA. Tools for the Reduction and Assessment of Chemical Inventory. Version 2.1.
l
CML 2001
Center of Environmental Science of Leiden University impact categories and characterisation metho
l
ULE 2013
UL Environment, General Program Instructions, 2013.

Navigation menu
