This drawing and the contents herein are Copyright 2007 Vicon Industries Incorporated. They are furnished on a confidential basis for the specified
purpose as indicated on the drawing itself. Permission is granted to use and copy this drawing freely provided that (a) the intended usage is the
connection and operation of Vicon equipment, and (b) any copies contain this notice in its' entirety. Vicon makes no representations as to the
operability of any described systems or interconnections unless this drawing is specifically marked for Construction.
Connector Pinouts:
V1410X-DVC or V1411X-DVC
(Standalone Mode)
To
S2000, TB3
-001400-4000-07
UMBER:
N
ITLE:
T
Rev.
HECKED:
ROJECT:
P
RAWN:
C
D
CALE:
ATED:
D
S
JMH
C: A:
EVISIONS
NTS
4/06/06
R
Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, NY 11788
631-952-CCTV (2288)
Fax 631-951-CCTV
Toll Free 1-800-645-9116
Tech Support 1-800-34-VICON
www.vicon-cctv.com
Interconnects - Typical
2. Wire is Belden 8723 or its electrical equivalent.
3. Insure wires are paired as shown in drawing.
1. Connectors are shown from wiring side.
Notes:
1
12VDC Gnd
Supply
Power
RI+ RI-
CO+ CO-
V1410X-DVC or V1411X-DVC
with provided RJ-45 cable
Connects to
Surveyor 2000
J1
J2
S1
TB3
S2
1J3
S2000 Camera
Comm TB3
Connects to
TB1
1
2
3
45
6
7
8
5
12VDC (+/-)
N/C
GROUND
RESPONSE IN -
5
8
7
6
2
4
3
1
N/A
RESPONSE OUT -
RESPONSE OUT +
2
4
N/A
Surveyor S2000
COMMAND IN+
COMMAND IN -
GROUND
V1410X-DVC or V1411X-DVC to Surveyor S2000
3
5
N/A
1
V1410X-DVC or V1411X-DVC
12VDC (+/-)
RESPONSE IN +
COMMAND OUT+
COMMAND OUT -
