See Me Here Electronic BV500 bluetooth speaker User Manual
Shenzhen See Me Here Electronic Co., Ltd. bluetooth speaker
User Manual
Getting to Know
● Please use and store this product at room temperature;
● Do not expose this product to rain or wet conditions;
● ;
Do not throw and drop this product, avoid damage
● Do not self-dismantle, repair and transform the product;
● Only charge with a rated voltage charger(DC5V 1A);
● Long time high volume may cause hearing impairment; please adjust the
volume appropriately when listening, especially for long time listening;
● Unauthorized dismantlement will void the warranty.
Warnings
Packing Content
USB cable: 1pcs
2
3.5mm audio
cable: 1pcs
4Manual: 1pcs
5
Master unit: 1 pcs
1
Features
◆ Bluetooth 4.0 , faster data transfer, lower power consumption;
◆ Support one-key to reconnect;
◆ Support Aux In play;
◆ Support iOS power display;
◆ Support TF card reader data access;
◆ Support Bluetooth hands-free bi-directional conversation;
◆ Output power is 3W*2;
◆ Built-in 1200mAh lithium battery, built-in intelligent power management module;
◆ Support TF card lossless MP3 /WMA / WAV / FLAC / APE format audio playback.。
Parameters
Appearance
Press and hold for
2 seconds to turn
on/off the speaker
Bluetooth connection
Turn on Bluetooth on the mobile phone, tablet PC
or other devices, search for Bluetooth device
“BV500”, and then tap Connect to confirm.
2
Bluet ooth
Bluet ooth OF F
Devic es
BV500
Successfully connect to Bluetooth and play
3
Devices
Press and hold for 2 seconds to turn
on/off the speaker
Press and hold for 2 seconds to turn on the
speaker, the speaker makes a ding dong sound,
and the blue LED starts flashing; press and hold
for 2 seconds again to turn off the speaker.
1
Insert a TF card and turn on the device
Insert a TF card with music files into the card
slot, press and hold the Power button to turn
on the speaker, accompanied by a ding-dong
sound.
1
Playing music on TF card
Tip: BT is the default mode of the Bluetooth speaker; if want to play music on
TF card, switch to TF mode first; if the speaker is turned on, the files on the
TF c a r d wil l b e pla y e d aut o m atic a lly w h en th e c ard i s inser t ed.
Press the Mode switch button
, and the speaker will make
a dong-dong sound and play
the music files on TF card.
Switch to TF music mode
2
Entering card reader/charging mode
Hands-free call
Connecting speaker and mobile phone
We the speaker connected to you smart phone,if there is an
coming call, the music will pause and the "dudu" sound is ring,
press to answer the call and press it again to end the call；
or press and hold to reject the call
1
External audio playing
Connect to
playback device
Connect to
the speaker
Audio cable
1
After pairing successfully, the device makes ding-dong-ding sound, the
blue LED stays, and then you can select and play music files on mobile
phone or tablet PC.
Turn off the speaker, insert the TF card, connect the speaker to PC with
the USB cable via Micro USB interface, press the Power button to enter
card reader mode, and then you can copy music files to the TF card.
①. Note: Improper battery replacement may cause explosion; only replace with
same or equivalent battery.
②. Do not expose the battery to sunlight, fire or excessive heat.
BV500
Press and hold the Power button to turn on the speaker, insert
the audio cable after the ding-dong sound, and press the Mode
switch button to switch to Aux In mode; you can also insert
the audio cable in power on state to realize plug and play.
Contents
Chapter 1：Getting to Know
① Warnings
② Packing Content
Features
③ Parameters
Chapter 2： Getting Started
④ Keys and Components
⑤ power on/off
Connect and Play
⑥ Play Music on TF Card
Hands-free Call
⑦ External Audio Playing
⑦ Enter Card Reader / Charging Mode
⑧ Chapter 3： Troubleshooting
产品参数
Power: same as the Mode
button; press and hold for 2
seconds to turn on/off.
Mode: press it to switch
among BT, TF and AUX
Play/Pause: press it in playing state to
play/pause
BT: press and hold it to disconnect the
Bluetooth, and press it to connect the
last connected Bluetooth device.
Next/VOL+: press it to switch to next track,
press and hold it to turn up the volume
Call: if there is incoming call in BT state,
press this button to answer the call, or
press and hold it to reject; during the call,
press it to end.
Previous/VOL-: press it to switch to previous
track, press and hold it to turn down the volume LED mode indicator
Mic
TF card slot: insert a TF card and play the audio file, or
connect to PC and read the data on the card
AUX port: 3.5MM Audio cable jack
USB port: data transfer/charging
Reset hole: Reset the device with thin stick when the speaker
halted
Getting Started
Connect to other
Bluetooth devices
Disconnect Bluetooth device
When the speaker and the device are connected, press and hold to
disconnect the Bluetooth connection, accompanied by a thud sound; the
speaker is available for connect now and the blue LED starts flashing.
4
Bluetooth reconnection
When the Bluetooth is disconnected, you can tap to connect to last
paired device, and tap to play last song.
5
1Connecting audio cable
Copy music
You can connect the speaker to PC with the provided USB cable and
charge the speaker no matter it's power on/off. It is recommended to buy
a separate DC5V 1A USB charger or other 5V1A charger for mobile
phone and charge the speaker through indoor outlet.
Tip: Please charge the speaker first if it hasn’t been used for a long time.
Charging the speaker
3
Fault Solution
产品参数
Troubleshooting
尺寸：80*104mm 材质：80g书写纸 折页
① ②
③
④
⑤ ⑥ ⑦ ⑧
Lanyard: 1pcs
3
Keys and Components
Around 6 hours at Mid-volume, around 3.5 hours at MAX-volume
External interfaces
Product specifications
Net Weight
Basic parameters
Product type
Speaker system
Volume control mode
Features
Storage type
Power supply
Technical parameters
Output power
Frequency response
USB specification
Charging time
Audio play time
Functions
File format
Voice call
TF card playback
Bluetooth play
TF card reader
External audio source
Bluetooth connection
Power level display
Ringtone
APP
Micro USB interface
TF card slot
AUX external audio interface
W142 × D70 × H46 (mm)
395g (including built-in lithium battery)
Portable Bluetooth speaker
3W*2 + Bass radiator
Touch the button to adjust
Bluetooth 4.0
TF card (MAX 32G)
Built-in 1200mAh lithium battery
3W*2 THD = 10%
110Hz--18KHz
USB2.0, compatible with USB1.1
DC5V 1A around 3 hours
MP3, WMA, WAV,APE,FLAC
Bi-directional conversation
TF card music playback
Yes
Support data access
Aux In
One key reconnect
Support iOS power display
Support ringtone playback
Yes
1. If necessary, type “0000”
and tap OK to connect
2. The Bluetooth speaker will connect
to the last paired device automatically
(when turned on)
1. Turn off the speaker and restart it
No reaction
Can’t turn on
the speaker
1. Restart the speaker,use the reset function
1. Restart the speaker, use the reset function
2. Check if the speaker is or paused
1. Check if the speaker volume is adjusted properly
2. Check if the file formats of the TF card are WAV,
WMA, MP3, APE or FLAC
1. Check if the TF format is proper (speaker supports
FAT32 format)
1. Check if the device is out of effective range, or if
there is barrier between speaker and the device
2. If your device requires code, type 0000
Pairing failed
repeatedly
TF card error
format error
No sound
during playing
Music play
interrupted
R
S E E M E H E R E
BV500
Outdoor water resistant
Bluetooth Speaker
www.see-me-here.com
Manufacturer: Shenzhen See Me Here Electronic Co.,Ltd.
Address: 3-4th Floor,Building D,TongFuYu Industrial Park,Xixiang Town,Bao'an
District,Shenzhen City,Guangdong Province,China
This device complies with part 15 of the FCC Rules. Operation is subject
to the condition that this device does not cause harmful interference (1)
this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposu
r e r e q u i r e m e n t . T h e d e v i c e c a n b e u s ed i n p o r t a b l e
exposure condition without restriction.
FCCID: 2ABNJ-BV500
