User Manual
E12-N13- Wireless LED Bulb
E12-N13- Wireless LED Bulb
Z02-Hub –Sengled Hub
Element Bulb Specification
•Model: E12-N13
•Input: 100-130V AC, 60Hz, 85mA
•Power: 9.0W
•Brightness: 800 lumens
•CRI: >80
•Beam Angle: 110°
•Light Socket: E26
•Operating Temperature: -4 °F ~ + 104 °F (-20 °C ~ + 40 °C)
•Storage Temperature: -40 °F ~ + 158 °F (-40 °C ~ +70 °C)
•Operating Humidity: 10% ≤ RH ≤ 95%, non-condensing
•Dimensions: Dia: 5.1in (130mm); H: 3.7in (95mm)
Element Hub Specification
•Model: Z02-hub
•Input: 5V DC, 300mA
•Adapter Input: 100-240V AC, 30mA; Output: 5V DC, 1A
• Dimensions: L: 78mm; W: 78mm; H: 26mm
•Support Zigbee HA 1.2.1 and 2.4GHz Wi-Fi
Box Contents
•Two Element Classic BR30 Bulbs and One Hub
•One Ethernet Cable
•One welcome card
•Quick Start Guide
•Limited Written Express Warranty
NOT FOR EMERGENCY LIGHTING
This product is intended for indoor use only
Use in Dry Locations only
E12-N14- Wireless LED Bulb
E12-N14- Wireless LED Bulb
Z02-Hub –Sengled Hub
Element Bulb Specification
•Model: E12-N14
•Input: 100-130V AC, 60Hz, 85mA
•Power: 9.0W
•Brightness: 650 lumens
•CRI: >90
•Beam Angle: 110°
•Light Socket: E26
•Operating Temperature: -4 °F ~ + 104 °F (-20 °C ~ + 40 °C)
•Storage Temperature: -40 °F ~ + 158 °F (-40 °C ~ +70 °C)
•Operating Humidity: 10% ≤ RH ≤ 95%, non-condensing
•Dimensions: Dia: 5.1in (130mm); H: 3.7in (95mm)
Element Hub Specification
•Model: Z02-hub
•Input: 5V DC, 300mA
•Adapter Input: 100-240V AC, 30mA; Output: 5V DC, 1A
• Dimensions: L: 78mm; W: 78mm; H: 26mm
•Support Zigbee HA 1.2.1 and 2.4GHz Wi-Fi
Box Contents
•Two Element Classic BR30 Bulbs and One Hub
•One Ethernet Cable
•One welcome card
•Quick Start Guide
•Limited Written Express Warranty
NOT FOR EMERGENCY LIGHTING
This product is intended for indoor use only
Use in Dry Locations only
E12-N15- Wireless LED Bulb
E12-N15- Wireless LED Bulb
Z02-Hub –Sengled Hub
• Support for daylight white 5000K color temperature
Element Bulb Specification
•Model: E12-N15
•Input: 100-130V AC, 60Hz, 85mA
•Power: 9.0W
•Brightness: 800 lumens
•CRI: >80
•Beam Angle: 110°
•Light Socket: E26
•Operating Temperature: -4 °F ~ + 104 °F (-20 °C ~ + 40 °C)
•Storage Temperature: -40 °F ~ + 158 °F (-40 °C ~ +70 °C)
•Operating Humidity: 10% ≤ RH ≤ 95%, non-condensing
•Dimensions: Dia: 5.1in (130mm); H: 3.7in (95mm)
Element Hub Specification
•Model: Z02-hub
•Input: 5V DC, 300mA
•Adapter Input: 100-240V AC, 30mA; Output: 5V DC, 1A
• Dimensions: L: 78mm; W: 78mm; H: 26mm
•Support Zigbee HA 1.2.1 and 2.4GHz Wi-Fi
Box Contents
•Two Element Classic BR30 Bulbs and One Hub
•One Ethernet Cable
•One welcome card
•Quick Start Guide
•Limited Written Express Warranty
NOT FOR EMERGENCY LIGHTING
This product is intended for indoor use only
Use in Dry Locations only
Industry Canada (IC)
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Cet appareil est conforme à la norme RSS d'Industrie Canada. Son fonctionnementestsujet aux deux
conditions suivantes:
(1) ledispositif ne doit pas produire de brouillagepréjudiciable, et
(2) cedispositifdoit accepter tout brouillagereçu, y compris un brouillage susceptible de provoquer un
fonctionnementindésirable.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your
body.
Déclarationd'exposition aux radiations:
Cetéquipementestconforme aux limitesd'exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cetéquipementdoitêtreinstallé et utilisé avec un minimum de 20cm de distance entre la
source de rayonnement et votre corps.
