Sengled E13N11 Lyric D6 Pro Ductless Controller User Manual user manual

Sengled Co.,Ltd. Lyric D6 Pro Ductless Controller user manual

Contents

user_manual

E13-N11
Features
• On/Off and dimming via mobile app, home hub display, as well as web portal.
• Report the current power consumption
• Compatible with most smart home hubs supporting Zigbee HA 1.2.1 to
control lighting schedules rules, and more.
• Sensors supported in local and smart mode.
• Light bulb will turn on 90s when any motion is detected in night mode with12
meters.
• Zigbee Alliance certified.
Package Includes
• One E13-N11 Bulb
• One quick start guide
• One welcome card and user manual on line
Product Specifications
• Input: 120 Vac, 60 Hz, 115mA
• Power: 14.0 Watts
• Brightness: 1050 lumens
• Light Socket: E26
• Color Temperature: 3000K soft white
• CRI: > 90
• Beam Angle: 40 degrees
• Sensor Range: Up to 12m, 100°
• Operating Temperature: -4℉ ~ +104 ℉
• Operating Humidity: 0% ~ 95% RH, non-condensing
• Sensor Smart control
.
FCC ID: 2AGN8-E13N11
IC: 20888-E13N11
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Radio Frequency (RF) Energy .
This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter and must be installed to provide a separation distance of at least 20cm
from all persons.
Canada Regulations:
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présentappareilestconforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitationestautorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d’encompromettre le fonctionnement.
Caution：
A label with the following statements must be attached to the host end product: This device
contains IC: 20888-E13N11.
Une étiquette avec les instructions suivantes doit être attachée au produit final hôte:
Cet appareil contient IC: 20888-E13N11.
