![](/img.php?id=421073&img=bg1.png)
Declaration of Conformity
Hereby, Sharp Telecommunications of Europe Ltd, declares
that this GX15 is in compliance with the essential require-
ments and other relevant provisions of Directive 1999/5/
EC.
A copy of the original declaration of conformity can be
found at the following Internet address:
http://www.sharp-mobile.com
![](/img.php?id=421073&img=bg2.png)
Introduction 1
Introduction
Congratulations and thank you for choosing the GX15.
About This User Guide
This user guide is carefully designed to help you learn about
your phone’s features and operations quickly and effectively.
NOTICE
•
We strongly recommend that you keep separate
permanent written records of all important data. Data
may be lost or altered in virtually any electronic memory
product under certain circumstances. Therefore, we
assume no responsibility for data lost or otherwise
rendered unusable, whether as a result of improper use,
repairs, defects, battery replacement, use after the
specified battery life has expired or any other cause.
• We assume no responsibility, directly or indirectly,
for financial losses or claims from third parties
resulting from the use of this product and any of its
functions, such as stolen credit card numbers, the loss
or alteration of stored data, etc.
• All company and/or product names are trademarks
and/or registered trademarks of their respective
holders.
• Screen layout illustrated in this user guide may differ
from the actual one.
The information described in this user guide is
subject to change without notice.
• All the functions described in this user guide may not
be supported in all networks.
• We assume no responsibility for downloaded
contents, information, etc. from network.
• Occasionally, a few black or bright pixels may appear
on the screen. Please note that this will not have any
impact on any of the features or performance.
Copyright
According to copyright laws, the reproduction,
alteration and use of material which is protected by
copyright (music, pictures, etc.) is only permitted for
personal or private use. If the user is not in possession
of more extensive copyright or has not received the
explicit permission from the copyright owner to
reproduce, alter or use a copy which has been made or
modified in this way, this is considered to be a violation
of the copyright laws and gives the copyright owner the
right to claim for damages. For this reason, avoid the
illegal use of material which is protected by copyright.
Windows is a registered trademark of Microsoft
Corporation in the United States and/or other countries.
![](/img.php?id=421073&img=bg3.png)
2Introduction
This product is licensed under the MPEG-4 Visual Patent
Portfolio License for the personal and non-commercial use of
a consumer to (i) encode video in compliance with the
MPEG-4 Video Standard (“MPEG-4 Video”) and/or (ii) decode
MPEG-4 Video that was encoded by a consumer engaged in
a personal and non-commercial activity and/or was obtained
from a licensed video provider. No license is granted or
implied for any other use. Additional information may be
obtained from MPEG LA. See http://www.mpegla.com.
This product is licensed under the MPEG-4 Systems Patent
Portfolio License for encoding in compliance with the MPEG-
4 Systems Standard, except that an additional license and
payment of royalties are necessary for encoding in
connection with (i) data stored or replicated in physical media
which is paid for on a title by title basis and/or (ii) data which
is paid for on a title by title basis and is transmitted to an end
user for permanent storage and/or use. Such additional
license may be obtained from MPEG LA, LLC. See http://
www.mpegla.com for additional details.
Powered by JBlend™ Copyright 1997-
2004 Aplix Corporation. All rights reserved.
JBlend and all JBlend-based trademarks
and logos are trademarks or registered
trademarks of Aplix Corporation in Japan
and other countries.
Powered by Mascot Capsule®/Micro3D Edition™
Mascot Capsule® is a registered trademark of HI Corpora-
tion
©2002-2004 HI Corporation. All Rights Reserved.
Licensed by Inter Digital Technology Corporation under one
or more of the following United States Patents and/or their
domestic or foreign counterparts and other patents pend-
ing, including U.S. Patents: 4,675,863: 4,779,262:
4,785,450 & 4,811,420.
Licensed under U.S. Patent 4,558,302 and foreign counter-
parts.
T9 Text Input is licensed under one or more of the following:
U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928,
and 6,011,554; Australian Pat. No. 727539; Canadian Pat.
No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong
Kong Standard Pat. No. HK0940329; Republic of Singapore
Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/
DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat.
Nos. KR201211B1 and KR226206B1; and additional
patents are pending worldwide.
Bluetooth is a trademark of the Bluetooth SIG, Inc.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sharp is
under license. Other trademarks and trade names are
those of their respective owners.
CP8 PATENT
Introduction 3
Useful Functions and Services
Your phone offers you the following features:
• A built-in digital camera for taking pictures and
video clips.
• A message function for reading and creating SMS
messages.
• MMS (Multimedia Messaging Services) for
personalising your phone in various ways.
• A WAP browser for accessing information on the
mobile Internet.
• Java™ applications. You can also download various
applications from Vodafone via the mobile Internet.
• A melody editing function for creating original
ringtones using up to 32 voices.
• A voice recorder function for recording and playing
back voice clips.
•A Bluetooth® wireless technology interface for
establishing contact and transmitting data with
certain devices. You can transmit pictures, sounds,
and video clips to OBEX-enabled phones.
• An infrared interface for data communication. You
can transmit pictures, sounds, and video clips to
OBEX-enabled phones.
• A data synchronization function for synchronizing
the Contacts List and schedule entries with Microsoft
Outlook or Outlook Express on a PC.
• A schedule alarm for creating and sending schedule
entries with alarm settings.
![](/img.php?id=421073&img=bg5.png)
4 Table of Contents
Table of Contents
Introduction ................................................. 1
Useful Functions and Services .....................3
Your Phone .................................................. 7
Optional Accessories ...................................7
Getting Started ............................................ 8
Inserting the SIM Card and the Battery .....10
Charging the Battery ..................................12
Turning Your Phone On and Off ...............13
Keypad Lock ..............................................14
Display Indicators ......................................15
Navigating Functions ................................ 17
Call Functions ............................................ 18
Making a Call .............................................18
Speed Dialling ............................................18
Redialling ...................................................19
Answering a Call .......................................19
Incall Menu ................................................20
Entering Characters .................................. 24
Changing the Input Languages ..................25
Changing the Input Method .......................25
Using Text Templates ................................26
Using the Menu ..........................................27
List of Menu Functions ..............................28
Contacts List .............................................29
Selecting the Storage Memory ...................29
Changing the List Displayed ......................29
Add New Contact ......................................30
Copying Contacts List Entries between
SIM Card and Handset ...............................30
Finding a Name and Number .....................31
Dialling from the Contacts List ..................31
Editing Contacts List Entries .....................32
Deleting Contacts List Entries ...................32
Viewing Groups .........................................32
Memory Status ...........................................33
Speed Dial List ...........................................33
Sending a Contacts List Entry ....................34
Receiving a Contacts List Entry .................34
Camera .......................................................35
Take Picture ..............................................35
Record Video ............................................39
Table of Contents 5
Messages .................................................. 43
Multimedia (MMS) ...................................43
Text (SMS) ................................................48
Cell Broadcasts ..........................................51
Vodafone live! ........................................... 53
Starting the WAP Browser .........................53
Navigating a WAP Page .............................54
My Items .................................................... 57
Pictures ......................................................57
Games & More ..........................................59
Sounds .......................................................60
Videos .......................................................62
Text Templates ..........................................63
Memory Status ..........................................64
Games & More .......................................... 65
Applications ..............................................65
Screensavers ..............................................66
More Games ..............................................67
Settings ......................................................67
Java™ Information ....................................69
Applications .............................................. 70
SIM Application ........................................70
Alarms .......................................................70
Calculator ................................................. 71
Voice Recorder ......................................... 72
Melody Editor ........................................... 73
Phone Help ............................................... 77
Calendar ....................................................78
Contacts ....................................................81
Call Log .................................................... 81
Speed Dial List ......................................... 82
My Numbers ............................................. 82
Call Timers ............................................... 82
Data Counter ............................................. 82
Call Costs .................................................. 83
Settings .....................................................84
Profiles ...................................................... 84
Setting the Display ................................... 88
Call Settings .............................................. 91
Date & Time ............................................. 94
Changing the Language ............................ 95
Connectivity ............................................. 95
Network .................................................... 98
Security ................................................... 100
Master Reset ........................................... 101
6 Table of Contents
Connecting GX15 to Your PC ................. 102
System Requirements ..............................102
GSM/GPRS Modem ................................102
Handset Manager .....................................103
Software Installation ................................103
Note ..........................................................103
Troubleshooting ...................................... 105
Safety Precautions and Conditions of
Use ............................................................ 107
CONDITIONS OF USE ..........................107
ENVIRONMENT ....................................110
PRECAUTIONS CONCERNING
VEHICLE USE ........................................110
SAR ..........................................................111
PRECAUTIONS FOR USE IN USA ......111
Index ......................................................... 114
![](/img.php?id=421073&img=bg8.png)
Your Phone 7
Your Phone
Please check the following carefully. Your phone
should come complete with:
• GSM 900/1800/1900 GPRS phone
• Rechargeable Li-ion battery
• AC charger
•CD-ROM
• User guide
• Quickstart guide
Optional Accessories
• Li-ion Spare battery (XN-1BT30)
• Cigarette lighter charger (XN-1CL30)
• USB data cable (XN-1DC30)
• AC charger (XN-1QC30, XN-1QC31)
• Personal handsfree kit (XN-1ER20)
The above accessories may not be available in all
regions.
For details, please contact your dealer.
![](/img.php?id=421073&img=bg9.png)
8 Getting Started
Getting Started
1. Earpiece
2. Navigation Keys (Arrow Keys):
a b c dMoves cursor to select
menu items, etc.
Up/Down arrow keys: Displays Contacts List
entries in stand-by mode.
Left arrow key:
Displays list of Applications
in stand-by mode.
Right arrow key: Displays list of Saved
Pictures in stand-by mode.
3. Centre Key: Displays Main menu in
stand-by mode and
executes functions.
4. Left Soft Key: Executes the function at the
Abottom left of the screen.
5. Send Key: Makes or accepts calls,
Dviews the call in stand-by
mode.
1
2
3
4
5
6
7
8
9
11
10
12
13
14
15
16
17
22
19
20
21
18
Getting Started 9
6. Voice Mail Key: Press and hold this key to
Gconnect to the Voice mail
centre automatically.
(Depends on the SIM card.)
7. * /Shift Key: Switches character case
Pamong four modes: Abc,
ABC, 123 and abc.
8. Display
9. Right Soft Key: Executes the function at the
C bottom right of the screen.
Used to access “Vodafone
live!” by opening the
browser in stand-by mode.
10.End/Power Key: Ends a call, turns power on/
Foff.
11.Keypad
12.# Key: Switches symbol screens.
RPress and hold this key on
the text entry screen to shift
text input method between
multi-tap and T9 mode.
Press and hold this key
during stand-by to switch
Profiles settings between
Normal and Silent mode.
13.Side-Up/Side-Down Keys:
V WMoves cursor to select
menu items, adjusts
earpiece volume, etc.
14.External Connector:
Used to connect either the
charger or USB data cable.
15.Microphone
16.Infrared Port: Sends and receives data via
infrared.
17.Camera Key: Starts the digital camera in
stand-by mode.
Takes pictures or records
videos in viewfinder mode.
18.Handsfree Kit Connector
19.RF Connector
20.Camera
21.Self-Portrait Mirror: For taking a self-portrait.
22.Battery Cover
![](/img.php?id=421073&img=bgb.png)
10 Getting Started
Inserting the SIM Card and the
Battery
1. Slide off the battery cover ( ).
2. Slide the SIM card into the SIM holder.
3. Hold the battery so that the metal contacts of the
battery are facing down, slide the guides on the top
of the battery into the battery slots , and then
insert it .
4. Replace the battery cover and slide it as shown
below.
Note
• Make sure that only 3V SIM cards are used.
• Make sure that the standard accessory battery
(XN-1BT30) is used.
2
1
SIM card
2
1
![](/img.php?id=421073&img=bgc.png)
Getting Started 11
Removing the SIM Card and the Battery
1. Make sure to turn off your phone and disconnect the
charger and other accessories. Slide off the battery
cover ( ).
2. Pick up the battery using the protruding edge and
remove the battery from the phone.
3. Hold down gently whilst sliding the SIM card
out of the SIM holder .
Battery Disposal
The device is supported by a battery. In order to protect
the environment, please read the following points
concerning battery disposal:
• Take the used battery to your local waste depot,
dealer or customer service centre for recycling.
• Do not expose the used battery to an open flame, into
water or dispose with the household waste.
2
1
2
1
![](/img.php?id=421073&img=bgd.png)
12 Getting Started
Charging the Battery
You must charge the battery for at least 2 hours before
using your phone for the first time.
Using the Charger
1. Remove the cover of the external connector, and
connect the charger to the external socket located at
the bottom of the phone by pressing both sides
indicated with arrows. Connect the charger to an
AC outlet. Keep the cover in a safe place so as not
to lose it.
When the phone is charging, the animated battery
status icon ( ) in the upper right of the screen
displays the current status.
Standard charging time: Approx. 2 hours.
Note
• Charging time may vary depending on the state of the
battery and other conditions. (See “Battery” on
page 108.)
To Disconnect the Charger
Push and hold the side buttons of the charger, then
disconnect the charger from the external socket of the
phone.
2. When charging is complete, the battery indicator
icon displays the full charge status. Unplug the
charger from the AC outlet, then unplug the charger
connector from the phone. Put the cover back.
Note
• Do not use any non approved charger, this may
damage your phone and invalidate any warranty,
please see “Battery” on page 108 for details.
![](/img.php?id=421073&img=bge.png)
Getting Started 13
To Charge Using the Cigarette Lighter Charger
The optional cigarette lighter charger supplies power
for charging from the cigarette lighter socket of a car.
Battery Level Indicator
The current battery level is displayed in the upper right
hand side of the screen.
Low Battery During Use
When the battery is running low, an alarm will sound
and the “ ” is displayed on the screen.
If you are using your phone and you hear the “low
battery” alarm, attach your charger as soon as possible.
The phone may not be able to continue normal
operation if you continue to use it. The battery may only
last approximately five minutes before the phone itself
powers down during a call.
Turning Your Phone On and Off
To turn the power on, press and hold F for
approximately 2 seconds.
The stand-by screen is displayed.
To turn the power off, press and hold F for
approximately 2 seconds.
To Enter the PIN Code
If activated you are asked to enter a PIN (Personal
Identification Number) code after turning on your
phone.
1. Enter your PIN code.
2. Press .
Note
• If your PIN code is entered incorrectly three times in
a row, the SIM card is locked. See “Enabling/
Disabling the PIN Code” on page 100.
Battery Indicators Charge Level
Sufficiently charged
Partially charged
Charging recommended
Charging required
Empty
14 Getting Started
To Copy Contacts List from the SIM Card
When you insert the SIM card into your phone for the
first time and start the Contacts List application, you are
asked whether you wish to copy Contacts List entries
on the SIM card. Follow the on-screen instructions, or
you can do it later using the Contacts List menu as
follows:
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Copy All Entries”
1. Select “From SIM to Handset”.
Keypad Lock
You can lock the keypad to prevent it from being
pressed accidentally.
Locking the Keypad
1. Press P, then [LockKeys] during stand-by.
The soft and centre keys are not displayed.
To unlock, press P, then [Yes].
Tip
• Emergency numbers (112, etc.) can be input and
dialled regardless of the keypad lock.
• To lock the keypad automatically, see “Auto Keypad
Lock” on page 100.
![](/img.php?id=421073&img=bg10.png)
Getting Started 15
Display Indicators Status Indicators
1. / : Strength of received signal / Service out
of range
2. : GPRS enabled and within range —
flashes during GRPS transmission.
3. / / : Alerts [Text message / Multimedia
message / WAP]
4. / : Current application [executed (colour) /
suspended (grey)]
5.(No display)/////:
Current profile [Normal / Meeting /
Activity / Car / Headset / Silent]
6. : T9 text input method enabled
7. ///:
Current text input method [First letter
upper case / Upper case / Lower case /
Numeric]
8. : “Diverts” (p. 91) set to “All Calls”
Status
indicators
Right soft key
Left soft
key
Centre key/Navigation keys
![](/img.php?id=421073&img=bg11.png)
16 Getting Started
9. / : Secured WAP page displayed
10. : Call incoming
11. : Call in progress
12. / : Current WAP or MMS communication
mode [CSD / GPRS]
13. : Battery level
14. : Roaming outside network
15. : “Ringer Volume” (p. 84) set to “Silent”
16. : Vibration alert (p. 85) enabled
17. : USB data cable connected
18. / : “Infrared” connection [enabled /
communicating]
19. :
Bluetooth
wireless setting [enabled /
handsfree headset / handsfree car kit]
20. : Data communication mode enabled
21. : Fax communication mode enabled
22. : Outbox contains unsent multimedia
messages
23. : Voicemail message alert
24. : Daily alarm enabled
25. / : Schedule entry with reminder alarm
[enabled / disabled]
26. : Keypad Lock (p. 14) enabled
![](/img.php?id=421073&img=bg12.png)
Navigating Functions 17
Navigating Functions
All applications are accessed from the Main menu. To
open the Main menu, press the centre key ( ) during
stand-by.
To launch applications, you will need to highlight menu
items, and make selections. To select a menu item
(indicated in quotation marks), move the cursor using
a, b, c and d, and press to commit your
selection.
In certain procedures, you will need to press one of the
soft keys (indicated in square brackets), which are
displayed at the bottom left and right of the screen.
Press the corresponding soft key (A or C).
To return to the previous screen, press the right soft key
if it displays “Back”. To close the Main menu, press the
right soft key if it displays “Exit”.
Each section in this user guide starts with a list of items
you will need to select in order (indicated in italics)
before performing the procedures shown. Select each
item to reveal the next set of items that you have to
select. Open subsection items after opening those listed
in the main section.
Example:
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
![](/img.php?id=421073&img=bg13.png)
18 Call Functions
Call Functions
Making a Call
1. Enter the area code and the phone number you wish
to dial and press D to dial.
If you enter the wrong number, press [Clear] to
delete the number to the left of the cursor.
Emergency Calls
1. Enter 112 or 911 (international emergency number)
using the keypad and press D to dial.
Note
• Emergency calls may not be available on all mobile
phone networks when certain network services and/
or phone features are in use. Contact your network
operator for more information.
• This Emergency number can normally be used to
make an emergency call in any country, with or
without a SIM card inserted, if a GSM network is
within range.
International Calls
1. Press and hold P until a “+” (international
dialling prefix) sign is displayed.
2. Enter the country code, followed by the area code
(without the leading zero) and the phone number,
and press D to dial.
Speed Dialling
Up to 9 phone numbers from the Contacts List memory
(Handset and SIM) can be assigned to speed dials. You
can call the numbers using the digit keys (H to O
and Q).
For details on setting the Speed Dial List, see “Speed
Dial List” on page 33.
1. To dial a number using the speed dial, press and
hold any of the digit keys (H to O and Q).
The phone number stored in the Speed Dial List is
dialled.
![](/img.php?id=421073&img=bg14.png)
Call Functions 19
Redialling
You can redial numbers in the call log. Select from
specific categories or “All Calls”. Specific category
contains up to 10 numbers and the “All Calls” list
contains up to 30.
1. Press D during stand-by.
2. Select the category from “All Calls”, “Dialled
Numbers”, “Missed Calls” or “Received Calls”.
To switch logs, press c or d.
3. Select the phone number you wish to call.
4. Press D to redial the call.
Automatic Redialling
This setting allows you to automatically redial the
number if the first attempt was unsuccessful because
the called party was busy.
If you wish to stop redialling, press F or [End].
To Set the Auto Redial Function
“Settings”
→
“Call Settings”
→
“Auto Redial”
1. Select “On” or “Off”.
Note
• When you receive an incoming call, the Auto Redial
function is interrupted.
• Automatic redialling is not available for fax and data
calls.
Answering a Call
When an incoming call is detected, the phone rings.
1. Press D, or [Answer] to answer the call.
Or press any key except F and [Busy] when the
“Any Key Answer” function is enabled. Set the Any
Key Answer function in the profile of each mode.
(p. 88)
Tip
• When the Personal handsfree kit (option) is
connected to the phone, you can answer calls by
pressing the Answer button.
• If you have subscribed to the Calling Line
Identification (CLI) service and the caller’s network
sends the number, the caller’s number is displayed on
the screen. If the caller’s name and number are
stored in the Contacts List, the caller’s name and
phone number are displayed on the screen.
![](/img.php?id=421073&img=bg15.png)
20 Call Functions
• If the number is a restricted number, the display
shows “Withheld”.
• When receiving a call from the person whose picture
is registered in the Contacts List, receiving display
and the picture are displayed alternately.
Rejecting an Incoming Call
1. Press F or press and hold the side-up or side-
down key whilst the phone is ringing to reject a call
you do not wish to answer.
Letting the Caller Know You are Unavailable
1. Press [Busy] whilst the phone is ringing to send a
busy tone to the caller of an incoming call letting
them know that you cannot answer the call.
Incall Menu
Your phone has additional functions available whilst a
call is in progress.
Adjusting the Earpiece Volume
During a call, you can adjust the earpiece volume (and
handsfree volume, if connected).
1. During a call, press the side-up or side-down key to
display the Earpiece Volume screen.
2. Press the side-up key or a to increase the volume
of the call or press the side-down key or b to
decrease the volume.
Five levels (level 1 to 5) are selectable.
3. Press when the volume is set to the desired
level.
The phone returns to the in-call screen
automatically if left unoperated.
Call Functions 21
Putting a Call on Hold
This function allows you to manage two calls at the
same time. If you wish to make another call whilst you
are talking to someone, you can put the current call on
hold to call someone else.
To Make Another Call during a Call
1. During a call, press [Options].
2. Select “Hold”.
The current call is put on hold.
3. To retrieve a call, press [Options] and select
“Retrieve”.
4. Enter the phone number you wish to make another
call to, then press D.
Tip
• You can also make another call by entering the phone
number during a call instead of steps 1 and 2. The
current call is automatically put on hold.
Call Waiting
This service notifies you of another incoming call
whilst you have a call in progress.
1. During a call, press [Options] and select “Hold &
Answer” to answer the second call.
The first call is put on hold and you can now talk to
the second caller.
2. Press [Options] and select “Swap Calls” to switch
between the two calls.
3. Press [Options] and select “Release Call” to end the
current call and return to the held call.
Note
• You need to set “Call Waiting” to “On” if you use the
Call Waiting service (p. 92).
• Call Waiting service may not be available on all
networks. Contact your network operator for more
information.
• If you do not wish to answer the second call, press
[Busy], or press [Options], and select “Busy” or
“Reject”, in step 1. If “Reject” is selected, the call
log of the second call is saved as a missed call.
22 Call Functions
Accessing SMS Menu During a Call
1. During a call, press [Options] and select “Text”.
The following options are available: “Create
Message” to make an SMS, or “Inbox”, “Sent” or
“Drafts” to access these folders. For details on SMS,
see “Text (SMS)” on page 48.
Conference Call
Conference call is a call with more than 2 participants.
You may include up to 5 participants in a conference
call.
To Make a Conference Call
To make a conference call, you must have one active
call and one held call.
1. During a call, press [Options] and select
“Multiparty” to answer the second call.
2. Select “Conference All” to join the conference call.
3. Press F to end the conference call.
Note
• Conference call service may not be available on all
networks. Contact your network operator for more
information.
• You have more options for the Conference call in step
3:
• To put all participants on hold, select “Conference
Hold All”.
• To put all participants except the current call on
hold, select “Private”.
• To end the call with all participants, select
“Release All”.
• To disconnect from the conference call but still
allow the other participants to continue talking
together, select “Transfer”.
• To put the current call on hold and continue to
have a conference call with the remaining
participants, select “Exclude”.
• To reject adding more participants to the current
party, select “Reject”, or you can send the busy
tone by selecting “Busy”.
Call Functions 23
To Add New Participants to the Conference Call
1. Press [Options] and select “Dial”.
2. Enter the number you wish to include in the
conference call and press D to dial.
3. Press [Options] and select “Multiparty”.
4. Select “Conference All” to join the conference call.
If you wish to add other participants, repeat steps 1
to 4.
To End the Call with a Conference Call Participant
1. During a conference call, highlight the person that
you wish to disconnect from the conference call.
2. Press [Options] and select “Release Call”.
To Have a Private Conversation with One of the
Participants
If you wish to have a private conversation with one of
the participants, you may select the participant from the
conference list and put the other participants on hold.
1. During a conference call, select the person that you
wish to talk to.
2. Press [Options] and select “Multiparty”.
3. Select “Private”.
4. Once you have finished the private conversation,
press [Options] and select “Multiparty”.
5. Select “Conference All” to return to the conference
call.
Muting the Microphone
1. During a call, press [Mute] to mute the microphone.
To unmute the microphone, press [Unmute].
![](/img.php?id=421073&img=bg19.png)
24 Entering Characters
Entering Characters
When entering characters to create Contacts List
entries, text messages or multimedia messages, etc.,
press the corresponding keys.
In multi-tap input method, press each key until the
desired character is displayed. For example, press H
once for the letter “A” or twice for the letter “B”.
Table of Characters
Pressing each key scrolls characters in the following
order. The order varies depending on the language
selected.
English Mode
G-O: Press and hold to enter 0 - 9 numbers.
Q
P: Press and hold to enter *.
R: Press and hold to shift between multi-
tap and T9 mode.
Key Upper Case
Characters
Lower Case
Characters Numeric
G. (full-stop) , (comma) - (hyphen) ? !
’ (apostrophe) @ :1 1
HABC2 abc2 2
IDEF3 def3 3
JGHI4 ghi4 4
KJKL5 jkl5 5
LMNO6 mno6 6
MPQRS7 pqrs7 7
NTUV8 tuv8 8
OWXYZ9 wxyz9 9
Q(space)+ = < > € £ $ ¥ % &0 0
PSwitches character case among four modes:
Abc, ABC, 123 and abc.
R
.,?!:;-+#*
@' '' ( )_&€£$
%/ ˜<>§=\ | ¥
¿¡^[ ]{ }¤ÅÄ
Æå äæà ÇÉ è é ì
ÑñÖØöøòßÜü
ù∆ΦΓΛΩΠΨΣΘ
Ξ (space) ↵
Key Upper Case
Characters
Lower Case
Characters Numeric
![](/img.php?id=421073&img=bg1a.png)
Entering Characters 25
Changing the Input Languages
You can change the input language on the text entry
screen.
1. On the text entry screen, press [Options].
2. Select “Input Language”.
If “Input Language” is not displayed, select “Text
Options” and then select “Input Language”.
3. Select the desired language.
Changing the Input Method
T9 Text Input
T9 text input method is a shortcut to enter text easily
and quickly.
1. On the text entry screen, press and hold R to enter
T9 mode.
2. Press [Options].
3. Select “Input Method”.
If “Input Method” is not displayed, select “Text
Options” and then select “Input Method”.
4. Select the input mode (Abc, ABC, abc, 123).
5. Press each key once for any letter you require on
that key.
To enter the word “How”, press J L O.
6. If the word shown isn’t the one you want, press a
or b until you highlight the correct one.
7. Press to select the word.
Note
• If the correct word is not shown in step 6, enter the
correct word again after switching to the multi-tap
input method.
Tip
• If you press Q instead of step 7, a space is inserted
next to the selected word.
Symbols and Punctuations
1. On the text entry screen, press [Options].
2. Select “Add Symbol”.
If “Add Symbol” is not displayed, select “Text
Options” and then select “Add Symbol”.
3. Select the desired symbol.
26 Entering Characters
My Dictionary
You can create your own word list for T9 text input.
1. On the text entry screen in T9 mode, press
[Options].
2. Select “My Dictionary”.
If “My Dictionary” is not displayed, select “Text
Options” and then select “My Dictionary”.
3. Select “Add New Word” and enter a new word.
To edit a word in the list
1. On the text entry screen in T9 mode, press
[Options].
2. Select “My Dictionary”.
If “My Dictionary” is not displayed, select “Text
Options” and then select “My Dictionary”.
3. Select the desired word.
4. Press [Options] and select “Edit”.
5. Modify the word.
Using Text Templates
You can use the sentences registered in Text Templates
when entering characters.
For details on creating the text template, see “Adding
Phrases to Text Templates” on page 63.
1. On the text entry screen, move the cursor to the
point you wish to insert the template.
2. Press [Options].
3. Select “Text Template”.
If “Text Template” is not displayed, select “Text
Options” and then select “Text Template”.
4. Select the desired text template.
The selected text template is inserted.
![](/img.php?id=421073&img=bg1c.png)
Using the Menu 27
Using the Menu
Accessing Applications
1. Press during stand-by.
The Main menu is displayed.
2. Navigate to required location.
3. Press to access function.
Shortcut Keys
You can shortcut to the specified menus by pressing
and digit keys for the menu’s corresponding number on
the Main menu. See the following table for reference.
Shortcuts are listed in the headings of this manual. For
example: “M 9-6”.
Example: To Access “Language” Sub Menu
Using Shortcut Keys
Press O L.
Note
• The shortcut keys work for the first three menu levels
only.
![](/img.php?id=421073&img=bg1d.png)
28 Using the Menu
List of Menu Functions
* Depends on SIM card contents.
Menu No./
Main Menu
Menu No./
Sub Menu1
1Games & More 1Applications
2Screensavers
3More Games
4Settings
5Java™ Information
2Vodafone live! 1Vodafone live!
2Games
3Ringtones
4Pictures
5News
6Sport
7Find & Seek
8Chat
9Search
3Applications 1SIM Application*
2Alarms
3Calculator
4Voice Recorder
5Melody Editor
6Phone Help
4Messages 1Create Message
2Multimedia
3Te x t
4Media Album
5Vodafone Mail
6Messenger
7Cell Broadcasts
8Area Info
5Camera 1Take Picture
2Record Video
6My Items 1Pictures
2Games & More
3Sounds
4Videos
5Tex t Te m pl a te s
6Bookmarks
7Memory Status
7Calendar
8Contacts 1Contacts List
2Add New Contact
3Call Log
4Speed Dial List
5My Numbers
6Call Timers
7Data Counter
8Call Costs
9Settings 1Profiles
2Display
3Sound
4Call Settings
5Date & Time
6Language
7Connectivity
8Network
9Security
0Master Reset
Menu No./
Main Menu
Menu No./
Sub Menu1
![](/img.php?id=421073&img=bg1e.png)
Contacts List 29
Contacts List
You can store the phone numbers and e-mail addresses
of your friends, family and colleagues in the Contacts
List.
Your phone can store up to 640 phone numbers. In a
Contacts List, you can store the following items.
Items stored in the handset memory
First Name
Last Name
Tel Private
Tel Office
Tel Mobile Private
E-mail Private
E-mail Business
Address
Note
Tip
• There is no character limit for entering text into the
above fields when using the internal memory.
Items stored in the SIM memory
Name: The number of characters that can be
stored differs depending on the SIM
card you use.
Phone number: Up to 40 digits
Using the infrared or Bluetooth wireless function, you
can send the Contacts List entry to a PC to share the
same entries.
Selecting the Storage Memory
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Save New Contacts”
1. Select Contacts location from “Handset Memory”,
“SIM Memory” or “Choose before Saving”.
Tip
• “Choose before Saving” prompts you to choose the
memory every time you save a new entry.
Changing the List Displayed
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Contacts Location”
1. Select from “Handset Memory”, “SIM Memory” or
“Both”.
(M 8-1)
30 Contacts List
Add New Contact
You can choose either the phone or SIM card memory
locations to store the new entry. For switching
locations, see “Selecting the Storage Memory” on
page 29.
The amount of phone numbers that you can store to the
SIM card is dependent on its capacity. Contact your
network operator for details.
“Contacts”
→
“Add New Contact”
If you select the “Choose before Saving” option for the
memory to be used, the selection is between “To
Handset” and “To SIM”.
1. Select the field you wish to fill in, and enter the
relevant information.
2. Press [Save] when finished.
Tip
• To create an entry, at least one field must be filled. If
you create a new entry on the SIM card, you need to
enter a phone number.
Adding a Thumbnail to Entries
“Contacts”
→
“Contacts List”
1. Highlight the desired entry.
2. Press [Options] and select “Edit”.
3. Select “Picture”.
4. Select the desired picture.
5. Press [Save] when finished.
Note
• If you delete a picture in Saved Pictures, the
corresponding thumbnail is also deleted.
• If the picture size exceeds 120 dots (W) or 160 dots
(H), specify the area you wish to display.
Copying Contacts List Entries
between SIM Card and Handset
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Copy All Entries”
1. Select “From SIM to Handset” or “From Handset to
SIM”.
Note
• When you insert the SIM card into your phone for the
first time and start the Contacts List application, the
confirmation screen appears automatically, asking
you if you wish to copy or not. The number of
Contacts List entries to be copied varies depending
on the SIM capacity.
(M 8-2)
Contacts List 31
Copying a Single Entry from Handset to SIM
Card
“Contacts”
→
“Contacts List”
1. Select the desired entry.
2. Highlight the desired phone number.
3. Press [Options] and select “Copy to SIM”.
Finding a Name and Number
“Contacts”
→
“Contacts List”
1. Enter the first few letters of the name.
Search results are displayed in alphabetical order.
2. Select the desired entry.
Tip
• You can select the Contacts location from “Handset
Memory”, “SIM Memory” or “Both” before
searching.
• To view the details of the item such as address,
highlight the desired item, press [Options]and select
“View”.
Dialling from the Contacts List
“Contacts”
→
“Contacts List”
1. Highlight the desired entry and press D.
Tip
• You can also dial the desired phone number by
pressing the digit key corresponding to the position
the entry is on the list.
• If more than one phone number is registered for the
entry, select the desired phone number after step 1
and press D.
• You can also dial from the details screen of the
Contacts List. On the details screen, select the
desired phone number and press D.
• If you select “SIM Memory” for the “Contacts
Location” option in Contacts List menu (p. 29), only
one phone number entry is displayed.
![](/img.php?id=421073&img=bg21.png)
32 Contacts List
Editing Contacts List Entries
“Contacts”
→
“Contacts List”
→
[Options]
→
“Edit”
1. Select the field you wish to edit, and modify the
information.
2. Press [Save] when finished.
Deleting Contacts List Entries
Deleting All Contact Entries
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Delete All Entries”
1. Enter your handset code.
2. Select “Handset Entries” or “SIM Entries”.
The default handset code is “0000”. For details on
changing the handset code, see “To Change Handset
Code” on page 101.
Deleting a Contact Entry
“Contacts”
→
“Contacts List”
1. Highlight the desired entry.
2. Press [Options] and select “Delete”.
Viewing Groups
You can set group icons when storing Contacts entries
so that you can easily find and edit them.
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Group”
→
“View Groups”
1. Select the desired group.
“ ” appears next to the selected group. Select the
group again to cancel, and the checkbox becomes
unchecked.
Tip
• Press [Options] and select “Current Only” to view
only the selected group or “Select All” to view all
groups.
Group Call
Different ringtones can be set for each group. When
you purchase this phone, groups are set to off. If you do
not set a group ringtone, the ringtone assigned in the
Settings menu is used.
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Group”
→
“Group Call”
1. Select the desired group.
2. Select “Switch On/Off”.
3. Select “On” or “Off”.
4. Select “Assign Ringtone”.
Contacts List 33
5. Select “Preset Sounds” or “My Sounds”.
6. Select the desired ringtone.
For details on selecting a ringtone, see “Assigning
Ringtone” on page 85.
7. Select “Vibration” and select from “On”, “Off” or
“On & Link to Sound”.
For details on selecting a vibration, see “Vibration”
on page 85.
8. Press [OK].
Assigning a Ringtone to Each Contacts List
Entry
A specified ringtone or vibration setting can be
associated to a pre-registered entry.
“Contacts”
→
“Contacts List”
1. Select the desired entry.
2. Press [Options] and select “Edit”.
3. Press [Options] and select “Ringtone”.
4. Select “Switch On/Off”.
5. Select “On” or “Off”.
6. Select “Assign Ringtone”.
7. Select “Preset Sounds” or “My Sounds”.
8. Select the desired ringtone.
For details on selecting a ringtone, see “Assigning
Ringtone” on page 85.
9. Select “Vibration” and select from “On”, “Off” or
“On & Link to Sound”.
For details on selecting a vibration, “Vibration” on
page 85.
10.Press [OK].
11.Press [Save].
Memory Status
This function helps you to check the number of entries
stored in the Contacts List.
“Contacts”
→
“Contacts List”
→
[Options]
→
“Advanced”
→
“Memory Status”
Speed Dial List
You can set a maximum of 9 phone numbers in the
Speed Dial List (p. 82).
34 Contacts List
Setting Contacts List Entries in the Speed Dial
List
“Contacts”
→
“Contacts List”
1. Select the desired entry.
2. Highlight the desired phone number.
3. Press [Options] and select “Add to Speed Dial”.
4. Select the desired list number.
Tip
• The nine digit keys correspond to list numbers.
• To view the speed dial list, see page 82.
Sending a Contacts List Entry
“Contacts”
→
“Contacts List”
1. Highlight the desired entry.
2. Press [Options] and select “Send Contact”.
3. Select “Via Bluetooth” or “Via Infrared”.
The phone starts searching for Bluetooth wireless
technology enabled devices within 10 metres or an
infrared-enabled device within 20 centimetres.
The connection will be established and the entry
will be sent.
Receiving a Contacts List Entry
When the phone receives a Contacts List entry, a
confirmation message appears in the stand-by mode
screen.
1. Press [Yes].
The received entry is registered in the Contacts List.
Press [No] to reject.
Tip
• For details on making Infrared or Bluetooth wireless
settings, see “Connectivity” on page 95.
![](/img.php?id=421073&img=bg24.png)
Camera 35
Camera
Your phone has an integrated digital camera.
This allows you to take and send pictures or video clips
wherever you are.
Take Picture
Put the phone into the digital camera mode to take a
picture. Pictures are saved in Saved Pictures in JPEG
format in the following three picture sizes.
L: 480 × 640 dots
M: 240 × 320 dots
S: 120 × 160 dots
Taking Pictures
“Camera”
→
“Take Picture”
The preview is displayed through the screen.
1. Press or the Camera key to take the picture.
The shutter sounds and the still image of the taken
picture is displayed. Press [Cancel] to retake a picture.
2. Press [Save].
“Saving (file name) to My Items…” is displayed,
then the picture is registered.
3. Press F to return to stand-by.
Remaining shots indicator
123: Indicates the remaining number of
pictures that can be taken.
Tip
• Pressing the Camera key during stand-by also
activates digital camera mode.
• If you wish to send a picture by multimedia message
after taking the picture, press before step 2. Then
select “Multimedia” or “MMS Postcard”. (MMS
Postcard service may not be available on all
networks. Contact your network operator for more
information.) Large MMS messages may cause the
size of attached pictures to be reduced.
Using the Full Screen
The preview can be displayed on the full screen without
the soft key area.
“Camera”
→
“Take Picture”
→
[Options]
→
“Full
Viewfinder”
1. Select “On” or “Off”.
(M 5)
(M 5-1)
![](/img.php?id=421073&img=bg25.png)
36 Camera
Taking a Self-Portrait
To take a self-portrait, hold the phone with the mirror
facing you whilst holding the phone at least 40 cm
away. Press or the Camera key to take the picture.
Using the Zoom Function
Press c or d to change the zooming ratio.
Zooming ratio indicators
: Magnification.
Note
• When “Picture Size” is set to “S”, the zoom function
has 3 magnifications (
×
1,
×
2,
×
4).
• When “Picture Size” is set to “M”, the zoom function
has 2 magnifications (
×
1,
×
2).
Selecting the Picture Size
“Camera”
→
“Take Picture”
→
[Options]
→
“Picture Size”
1. Select the desired picture size.
Selecting the Picture Quality
“Camera”
→
“Take Picture”
→
[Options]
→
“Picture Quality”
1. Select “Normal” or “Fine”.
Picture quality indicators
:Fine
:Normal
Selecting the Anti-flicker Mode
“Camera”
→
“Take Picture”
→
[Options]
→
“Anti-
flicker”
1. Select “Mode1” or “Mode2”.
Note
• Vertical stripes may occur on the picture due to the
light source. Change the mode to rectify.
• The digital camera uses a C-MOS sensor. Although
this camera has been manufactured to the highest
specifications, some pictures may still appear too
bright or too dark.
• If the phone has been left in a hot place for a long
time before taking or registering a picture, the
picture quality may be poor.
![](/img.php?id=421073&img=bg26.png)
Camera 37
In the Case of No Available Memory
When the number of pictures that can be taken becomes
3 or less, the remaining shots indicator in the upper left
of the screen turns red. (The number of pictures that can
be taken is approximate.)
Even if the number of pictures that can be taken
becomes 0, you can continue to take and save pictures
until the message, “Memory full. Please delete some
data!” appears. After which, you can save the picture.
Adjusting the Brightness of the Picture
According to Lighting Conditions
Press a or b to adjust the brightness of the picture.
Picture brightness (exposure level) indicators
: (Bright → Normal
→
Dark)
Once the phone has returned to the stand-by screen, the
brightness settings return to default.
Viewing the Taken Pictures
“Camera”
→
“Take Picture”
→
[Options]
→
“My
Pictures”
The list of pictures is displayed.
1. Select the file you wish to view.
The selected picture is displayed.
Tip
• Your pictures are given file names which are
“pictureNNN.jpg” (NNN is a consecutive number).
The file name (without an extension), date and size of
your pictures are displayed in the list.
Using the Timer (Delay Timer)
“Camera”
→
“Take Picture”
→
[Options]
→
“Delay
Timer”
1. Select “On” or “Off”.
“ ” or “ ” is displayed on the screen and the
phone returns to digital camera mode.
![](/img.php?id=421073&img=bg27.png)
38 Camera
2. Press or the Camera key to start the delay timer.
10 seconds after the timer sounds, the shutter
sounds, and the camera takes a picture.
Note
• The countdown sounds whilst the delay timer is
operating.
• If or the Camera key is pressed whilst the delay
timer is operating, the picture is taken instantly.
• The zoom function with c or d, or brightness
adjustment of the picture with a or b, is
unavailable whilst the delay timer is operating.
• If you wish to stop taking pictures with the timer,
press [Cancel] whilst the delay timer is operating.
Continuous Shot
Four pictures are taken in succession. Auto Shot and
Manual Shot are available.
Continuous Shot indicators
“Camera”
→
“Take Picture”
→
[Options]
→
“Continuous Shot”
1. Select “Auto Shot” or “Manual Shot”.
Select “Off” to cancel.
2. Press or the Camera key to start Continuous
Shot.
Auto Shot: Four pictures are taken in a row.
Manual Shot: Pictures are taken one by one by
pressing or the Camera key.
The taken pictures are saved automatically.
To stop Continuous Shot, press [Cancel].
Note
• When “Picture Size” is set to “L” or “M”, you
cannot use the Continuous Shot.
• When you select a frame for taking pictures, you
cannot use the Continuous Shot function.
• Delay timer cannot be used with the Manual Shot.
:
When pictures are taken in Continuous Shot
mode, these indicators appear on the screen.
* When delay timer and Continuous Shot
functions are simultaneously set, “ ” is
displayed instead.
![](/img.php?id=421073&img=bg28.png)
Camera 39
Selecting a Frame
You can select the frame from preset patterns. You can
also select a frame in Saved Pictures.
“Camera”
→
“Take Picture”
→
[Options]
→
“Add
Frame”
1. Select “Preset Frame” or “My Pictures”.
2. Select the desired frame.
The selected frame is confirmed on the display.
3. Press .
Note
• When “Picture Size” is set to “L”or “M”, you
cannot use the Frame function.
• When you activate the Continuous Shot, you cannot
use the Frame function.
• Only the images of PNG format can be selected as the
frame if you select “My Pictures” in step 1.
Selecting the Shutter Sound
You can select the shutter sound from 3 preset patterns.
“Camera”
→
“Take Picture”
→
[Options]
→
“Shutter Sound”
1. Select the desired shutter sound.
To play back the shutter sound, press [Play].
Record Video
Put the phone into the video camera mode to record a
video.
Video clips are saved in “.3gp” format in the following
two modes:
Record time indicators
: Message sending mode enabled
: Extended video mode enabled
Recording Video Clips
Sound can be recorded with the video clip.
“Camera”
→
“Record Video”
The preview is displayed through the screen.
1. Press or the Camera key to start recording the
video clip.
The sound for recording the video clip occurs.
If you press or the Camera key again, or when
the recording is completed, the sound for ending the
video clip recording occurs and the display transits
to step 2.
(M 5-2)
![](/img.php?id=421073&img=bg29.png)
40 Camera
2. Select “Save”.
“Saving (file name) to My Items…” is displayed,
then the video clip is registered.
To preview a video clip before saving, select
“Preview”.
To send a video clip by multimedia message after
recording the video clip, select “Save and Send”.
To record a voice clip again, press [Cancel].
Remaining sets indicator
123 : Indicates the remaining sets of video
clips that can be recorded.
Using the Zoom Function
Press c or d to change the zooming ratio.
Zooming ratio indicators
: Magnification.
Selecting the Recording Size Mode
You can select the recording size mode.
“Camera”
→
“Record Video”
→
[Options]
→
“Record Size”
1. Select “Extended Video” or “For Message”.
Note
• If “For Message” is selected, the size of the video
clip that can be recorded depends on the message
size set in MMS settings (p. 47).
• “Save and Send” is not displayed after recording in
extended video mode.
• This option is not applicable to some service
providers. Please contact your service provider for
more information.
Selecting Video Quality
“Camera”
→
“Record Video”
→
[Options]
→
“Video
Quality”
1. Select “Normal” or “Fine”.
Video quality indicators
:Fine
:Normal
![](/img.php?id=421073&img=bg2a.png)
Camera 41
In the Case of No Available Memory
When the number of video clips that can be recorded
becomes 3 or less, the remaining sets indicator in the
upper left of the screen turns red. (The number of sets
that can be recorded is approximate.)
Even if the number of video clips that can be recorded
becomes 0, you can continue to record and save video
clips until the message, “Memory full. Please delete some
data!” appears. After which, you can save the video clip.
Adjusting the Brightness of the Video Clips
According to Light Conditions
Press a or b to adjust the brightness of the video clip.
Picture brightness (exposure level) indicators
: (Bright → Normal
→
Dark)
Once the phone has returned to the stand-by screen, the
brightness settings return to default.
Viewing Recorded Video Clips
“Camera”
→
“Record Video”
→
[Options]
→
“My
Videos”
The list of video clips is displayed.
1. Select the file you wish to view.
2. Press .
The selected video clip is played back.
To pause playback, press .
To resume playback, press again.
To stop playback, press [Back].
Tip
• Your video clips are given file names such as
“videoNNN.3gp” (NNN is a consecutive number).
The file name (without an extension), date and size of
your video clips are displayed in the list.
• If the video clip has been recorded with sound, the
volume can be adjusted by pressing a or b, or the
side-up or side-down key.
• The volume varies depending on the Multimedia
Volume settings (p. 87). The volume is 0 when
“Multimedia Volume” is set to “Silent”.
![](/img.php?id=421073&img=bg2b.png)
42 Camera
Using the Timer (Delay Timer)
To Record a Video Clip with the Timer
“Camera”
→
“Record Video”
→
[Options]
→
“Delay
Timer”
1. Select “On” or “Off”.
“ ” is displayed on the screen and the phone
returns to video camera mode.
2. Press or the Camera key to start the delay timer.
10 seconds after the timer sounds, the camera starts
recording the video clip.
Note
• The countdown sounds whilst the delay timer is
operating.
• If or the Camera key is pressed whilst the delay
timer is operating, the video clip is recorded
instantly.
• The zoom function with c or d, or brightness
adjustment of the video with a or b, is unavailable
whilst the delay timer is operating.
• If you wish to stop recording video clips with the
timer, press [Cancel] whilst the delay timer is
operating.
Recording Video Clips with Sound
“Camera”
→
“Record Video”
→
[Options]
→
“Voice
Record”
1. Select “On” or “Off”.
![](/img.php?id=421073&img=bg2c.png)
Messages 43
Messages
Your phone allows you to send and receive text or
multimedia and to receive WAP alerts.
Multimedia (MMS)
About Multimedia Messaging
Multimedia Messaging Service (MMS) allows you to
send and receive multimedia messages with graphical
images, photographs, sound, animations or video clips
attached.
Note
•Some MMS functions may not always be available
depending on your network. Contact your network
operator for more information.
Creating a New MMS
A
→
“Multimedia”
→
“Create Message”
1. Enter the message.
To use the text template, move the cursor to the
point you wish to insert the template. Press
[Options] and select “Text Options”. Select “Text
Template” and then select the desired template.
2. Enter the phone number or e-mail address of the
recipient.
3. Select “Send”.
After the message is sent, the message is moved to
the Sent box.
Note
• The current message size displayed whilst you are
creating the message is an approximation.
• If a message cannot be sent for some reason, the
message stays in the Outbox and “ ” is displayed
on the stand-by screen.
Tip
• You can use the phone number or e-mail address
from the Contacts List. (p. 31)
• To save the message without sending, select “Save to
Drafts” instead in step 3 .
• To enter the subject, select “Subject” in step 3 and
enter it. This is optional. Up to 40 characters as the
subject (and up to 20 characters (for To and Cc)) can
be entered. However, these may be limited depending
on your network. In this case, you may not be able to
send MMS. Contact your network operator for more
information.
(M 4)
(M 4-2)
(M 4-2-1)
44 Messages
• To add more recipients, select “Add Contact” in step
3. Select “To” or “Cc” and select the desired
number of the recipient. Then enter the phone
number or e-mail address.
To Send a Message Template MMS
Your phone provides message templates with an image
and voice attachment that help you create easily.
A
→
“Multimedia”
→
“Create Message”
→
[Options]
→
“Message Template”
A confirmation screen asking whether you wish to
discard the current text is displayed.
1. Confirm by selecting [Yes] or [No].
2. Select the desired template.
3. Enter the message.
4. Enter the phone number or e-mail address of the
recipient.
5. Select “Send”.
Note
• Selecting “Message Template” deletes messages or
images you have entered or attached. To prevent
deletion, select “Message Template” first, then enter
messages.
Turning the Slide Show Setting On or Off
A
→
“Multimedia”
→
“Settings”
→
“Slide Show”
1. Select “On” or “Off”.
If You Select “On”
• You can create messages which have up to 10 slides.
Each slide can contain one picture, one sound file
and up to 1000 characters of text (up to the message
total 30 Kbytes or 100 Kbytes limit).
• If you wish to add a slide to a single slide, press
[Options] and select “Add Slide”.
If you wish to perform slide operations for multiple
slides, press [Options] and select “Slide Control”.
The slide control options available are:
Add: To add a new slide.
Remove: To remove the active slide.
Previous: To navigate to the previous slide.
Next: To navigate to the next slide.
• Video clip data cannot be attached as slide data to
the message.
![](/img.php?id=421073&img=bg2e.png)
Messages 45
If You Select “Off”
• You can attach a maximum of 20 pictures, sounds or
video clips and up to 2000 characters of text (up to
the message total 30 Kbytes or 100 Kbytes limit).
Inserting Attached Data
You can send pictures, sounds and video clips saved in
the handset memory attached to multimedia messages.
When attaching video clips, “Slide Show” must be set
to “Off”.
A
→
“Multimedia”
→
“Create Message”
1. Press [Options] and select from “Picture”, “Sound”
or “Video”.
2. Select the desired file name.
The selected picture/sound/video clip is attached.
When attaching is complete, press [Back] to return
to the message creation screen.
• To add more files, press [Options] and select from
“Add Picture”, “Add Sound” or “Add Video”.
Then select the desired file.
• To remove the attached files, press [Options] and
select “Remove”.
Reading MMS
Messages you receive are stored in the Inbox.
Incoming Messages
The MMS indicator ( ) will appear when you are
receiving an incoming message.
A
→
“Multimedia”
→
“Inbox”
1. Select the message you wish to view.
The message is displayed.
2. Scroll the screen to read the message.
3. Press when finished.
Tip
• The volume varies depending on the Multimedia
Volume settings (p. 87). The volume is 0 when
“Multimedia Volume” is set to “Silent”.
![](/img.php?id=421073&img=bg2f.png)
46 Messages
Storing the Phone Number or E-mail Address
of a Sender in the Contacts List
A
→
“Multimedia”
→
“Inbox”
1. Highlight the message from which you want to store
the phone number or e-mail address.
2. Press [Options] and select “Save Sender”.
For details on entering a name, see “Add New
Contact” on page 30.
Retrieving MMS
When “ ” is in the Inbox, the following can be done.
A
→
“Multimedia”
→
“Inbox”
1. Highlight the alert you wish to download.
2. Press [Options] and select “Download”.
Tip
• You can press instead of steps 1 and 2 to start
downloading.
Confirming Arrival of Delivery Report
A
→
“Multimedia”
→
“Sent”
1. Highlight the message of which you wish to confirm
arrival of delivery report.
2. Press [Options] and select “Delivery Report”.
This menu is available only for sent messages that
have the “Delivery Report” set to “On”. For details
on selecting “Delivery Report”, see “Setting Up
MMS”.
Setting Up MMS
A
→
“Multimedia”
→
“Settings”
1. Select the item you wish to set up.
• Roam. Download (Immediate, Deferred):
Controls MMS download timing when roaming
outside of your network.
• Delivery Rep. Allow (On, Off):
Enables or disables Delivery Report when
receiving a message which applies to the Delivery
Report function.
• Anonymous Reject (On, Off):
Rejects a messages from an unknown or empty
address name or not.
• Auto Delete (Off, Inbox, Sent, Both):
Deletes the oldest message automatically, when the
Inbox, Sent or Both (Inbox and Sent) is full.
Messages 47
• Slide Show (On, Off):
Enables or disables Slide Show when sending a
message.
• Message Size (30KB, 100KB):
Sets the maximum message size that can be sent.
•Advanced
• Priority:
Prioritises composed messages.
• Delivery Report:
Enables Delivery Report.
• Expiry Time:
Sets Expiry Time for a message to be stored in
the Server.
• Sender Visibility:
Displays the information about the sender.
• Slide Interval:
Sets the slide display time when sending a
message.
2. Change each item.
Sending a Picture File with MMS Postcard
Your phone allows you to send multimedia messages to
a Vodafone specific postcard service centre that prints
the picture and mail it to the recipient’s home address
specified in the MMS message. (Your phone is initially
provided with the address of a Vodafone specific
Postcard service centre, and its address cannot be
changed.)
MMS Postcard service may not be available on all
networks. Contact your network operator for more
information.
To Create a New MMS Postcard (M 4-2-2)
A
→
“Multimedia”
→
“MMS Postcard”
1. Select a picture you wish to use for a postcard.
2. Enter your message.
3. Enter the following information for the recipient.
See the note below for details.
•Name •Postcode
• Additional Info • County / City
•House No. / Street •Country
4. Press [Options] and select “Send”.
48 Messages
Note
• The items Name, House No. / Street and Postcode are
necessary to complete sending MMS postcards.
• Information for a recipient
Name (mandatory):
Name of the recipient for a postcard up to 50
characters
Additional Info (optional):
Additional information of the recipient up to
50 characters
House No. / Street (mandatory):
Street and number up to 50 characters
Postcode (mandatory):
Postal code up to 60 characters
County / City (optional):
State, province, and region up to 50
characters
• Country (optional):
Country up to 20 characters
• The item “Country” may not be displayed, so you
cannot send MMS Postcards overseas from your
phone.
• Files in Animation GIF format cannot be used for the
MMS Postcard service.
• The picture quality of MMS Postcard varies
depending on the picture size.
Text (SMS)
About Text Messaging
The Short Message Service (SMS) allows you to send
text messages of up to 1024 characters to other GSM
users.
To Use SMS with Your Phone
Messages longer than 160 characters may be
composed. During sending, the messages are split. If
the receiver has a suitable phone the messages
recombines during reception, if not your message
appears as a number of separate 152 characters
messages.
You can send or receive SMS even if you are talking on
the phone.
You can also use Text Templates to help you compose
SMS.
(M 4-3)
![](/img.php?id=421073&img=bg32.png)
Messages 49
Creating and Sending a New SMS
A
→
“Text”
→
“Create Message”
1. Enter your message.
To use the text template, move the cursor to the
point you wish to insert the template. Press
[Options] and select “Text Template” and then
select the desired template.
2. Enter the phone number of the recipient.
3. Select “Send”.
The phone begins the sending process and the SMS
is sent. After the message has been sent, the
message is added to the Sent box.
To save the message in the Drafts box without
sending it, select “Save to Drafts”.
Note
• When you send a message of more than 160
characters, the confirmation message is displayed.
Tip
• You can use the phone number from the Contacts
List. (p. 31)
• To add more recipients, select “Add Contact” in step
3. Select an item number for adding the recipient’s
phone number. Then enter the phone number.
Reading SMS
Incoming Messages
The SMS indicator ( ) will appear when an incoming
message arrives.
1. When you receive a SMS, press during stand-
by.
2. Select the message you wish to view.
The sender’s phone number and a part of the
message are displayed. When the sender’s phone
number is stored in the Contacts List, the sender’s
name is displayed instead of the phone number.
Massages that are marked with “ ” denote unread
massages. If the Inbox, Sent box or Drafts box is
full, “ ” is displayed. Delete unnecessary
massages.
3. Scroll the screen to read the message.
4. Press F when finished.
(M 4-3-1)
50 Messages
Extracting Phone Numbers from the Received
Messages and Making a Call
You can make a call using the phone number embedded
in the received SMS message.
A
→
“Text”
→
“Inbox”
1. Select the message from which you wish to extract
phone numbers.
2. Press [Options] and select “Extract Numbers”.
Telephone numbers embedded in the message are
displayed.
3. Highlight the phone number.
4. Press [Options] and select “Make Call”.
To save this phone number in the Contacts List,
select “Save Number”.
Setting Up SMS
To Set Up the Service Centre Address
A
→
“Text”
→
“Settings”
→
“Message Centre”
1. Enter the centre phone number.
If you wish to enter a country code for a message to
an international number, press and hold P until a
“+” sign is displayed.
Message Lifetime
This indicates the number of days and hours for which
a message you send may remain undelivered to the
message recipient.
During this period, the message service centre will
continually try to deliver the message to the recipient.
A
→
“Text”
→
“Settings”
→
“Message Lifetime”
1. Select the validity period.
Message Format
A
→
“Text”
→
“Settings”
→
“Message Format”
1. Select the message format.
Connection Type
A
→
“Text”
→
“Settings”
→
“Connection Type”
1. Select the connection type.
(M 4-3-5)
![](/img.php?id=421073&img=bg34.png)
Messages 51
Optimisation
When set “On” (default), double-byte characters such
as European characters with an accent are converted
into single-byte characters and sent.
When “Off”, double-byte characters are sent as
displayed.
Please note that you may be charged double for double-
byte characters sent in an SMS when Optimisation is set
“Off”.
A
→
“Text”
→
“Settings”
→
“Optimisation”
1. Select “On” or “Off”.
Cell Broadcasts
You can receive Cell Broadcast messages or general
messages such as weather forecasts and traffic reports.
This information is broadcast to subscribers in certain
network areas.
This function may not be available on all mobile phone
networks. Contact your network operator for more
information.
Enabling/Disabling Cell Broadcasts
A
→
“Cell Broadcasts”
→
“Switch On/Off”
1. Select “On” or “Off”.
Reading Cell Broadcast Messages
1. When you receive a Cell Broadcast message, press
.
2. Press a or b to scroll the screen to read the
message.
3. Press F when finished.
Setting Languages
You can select your preferred language for the cell
broadcast message display.
F
→
“Cell Broadcasts”
→
“Settings”
→
“Language”
The language list is displayed.
1. Press a or b to highlight the language you wish to
set, then press .
2. Press F when finished.
(M 4-7)
(M 4-7-1)
(M 4-7-2)
(M 4-7-3)
52 Messages
Subscribing to Cell Broadcasts
Select the page of the cell broadcast message that you
want.
F
→
“Cell Broadcasts”
→
“Settings”
→
“Set Info
Subjects”
→
“Add/Remove”
1. Select the desired page.
2. Press F.
Tip
• If the desired page is not in the list that appears in
step 1, select “Create Subject” before step 1, then
enter the subject code to add a page. For details on
the subject code, contact your service provider.
![](/img.php?id=421073&img=bg36.png)
Vodafone live! 53
Vodafone live!
Your phone is already configured to access Vodafone
live! and the mobile internet*.
Vodafone live! is a new mobile internet portal which is
your gateway to a new world of information, games,
music and services.
Because your phone uses GPRS, a system that is much
faster than previous ways of getting mobile
information. Also, the connection is ‘always on’ which
means there is no need to wait for dialling up. You only
have to pay for the data you send or receive, not how
long you’re connected.
* If you have problems getting connected, please
phone Vodafone Customer Support.
Your phone contains a WAP browser used for surfing
on the Mobile Internet, where you can get a lot of useful
information. Normally, pages are designed for a mobile
phone.
Your phone is already setup to Vodafone site for WAP/
MMS Settings.
Starting the WAP Browser
1. Press C during stand-by.
To Exit the WAP Browser
1. Press F to exit the browser.
(M 2)
![](/img.php?id=421073&img=bg37.png)
54 Vodafone live!
Navigating a WAP Page
•a b c d:
Move the highlights around in the screen.
• : Executes the option displayed in the lower
centre of the screen.
•A: Launches browser option menu.
•C: Selects an action displayed in the lower
right corner of the screen.
Used to access “Vodafone live!” by
opening the browser.
•Q (press and hold):
Starts the “Go to URL”.
•G to O (press and hold):
Starts the Bookmark (WAP).
•F: Exits the browser (short press).
Turns off the phone. (press and hold)
Browser Menu
When you are browsing, you can reach browsing
options by pressing [Options].
• Select:
Selects the link you wish to see. (“Select” is
displayed only when the link is highlighted.)
•Home:
Goes to the homepage you set in the WAP Settings.
• Add bookmark:
Adds the site you are currently browsing to your
list of bookmarks.
• View bookmarks:
Displays a list of bookmarks.
• Save items:
Saves pictures, sounds or video clips in the
appropriate My Items folder.
•Go to URL:
Inputs the URL of the site you wish to go to.
•History:
Displays a history list.
• Forward:
Moves to the next URL in the history list.
Vodafone live! 55
• Reload page:
Refreshes the contents of the WAP page.
• Advanced...:
• Show URL:
Displays the URL of the site you are currently
browsing.
• Save page:
Saves the page you are currently browsing to
your list of Snap Shots.
• Snapshots:
Displays a list of Snap Shots.
• Alert inbox:
Displays a list of WAP push messages. You
can receive push messages via WAP Services.
This means that a service provider sends WAP
content to your phone, without any set up.
• Settings:
Includes “Downloads”, etc.
• Security:
Sets the security.
• Clear...:
Clears history, cache, etc.
• Restart Browser:
Restarts the browser.
Bookmarks
When you are browsing, press [Options] and select the
appropriate option.
To Add a Bookmark
1. Select “Add bookmark”.
To Access Bookmarked Pages
1. Select “View bookmarks”.
2. Select the desired bookmark.
To Edit Bookmarks
1. Select “View bookmarks”.
2. Select “More…”.
3. Highlight a bookmark page you wish to edit.
4. Press [Options] and select “Details”.
5. Edit the title, then press b.
6. Edit the URL, then press b.
7. Select “Save”.
56 Vodafone live!
To Delete Bookmarks
1. Select “View bookmarks”.
2. Select “More…”.
3. Highlight a bookmark page you wish to delete.
4. Press [Options] and select “Delete”.
5. Press [Options] and select “OK”.
Setting the Hotkeys to Web Page Bookmarks
You can access Web pages quickly by pressing the
shortcut keys (hotkeys). Follow the following to assign
shortcuts.
1. Select “View bookmarks”.
2. Select “More…”.
3. Highlight a bookmark page you wish to edit.
4. Press [Options] and select “Hotkeys”.
The list of hotkeys is displayed.
5. Select the number to which you wish to assign
hotkeys.
The list of registered bookmarks is displayed.
6. Select the desired bookmark.
![](/img.php?id=421073&img=bg3a.png)
My Items 57
My Items
My Items contains several types of picture, sound and
video clip data. Also included in My Items are
frequently used text message phrases and accessed
WAP pages (addresses) which you can use. You can
also transmit picture, sound and video clip data via
infrared or Bluetooth wireless technology to OBEX-
enabled phones.
Pictures
Pictures that are taken by a digital camera or images
that are downloaded from mobile Internet sites can be
managed.
: PNG format
: JPEG format
: GIF format
:BMP format
:WBMP format
: WPNG format
Note
• The phone can store approximately 1.8 Mbytes of
data across Pictures, Games & More, Sounds and
Videos.
Viewing Pictures
“My Items”
→
“Pictures”
→
“Saved Pictures”
1. Select the file you wish to view.
The selected picture is displayed.
Using Images as Wallpaper
“My Items”
→
“Pictures”
→
“Saved Pictures”
The list of pictures is displayed.
1. Highlight the file you wish to use as wallpaper.
2. Press [Options] and select “Set as Wallpaper”.
3. Specify the area you wish to display using the
navigation keys.
(M 6)
(M 6-1)
58 My Items
Saving to Contacts List
You can use this option only for pictures saved in the
handset memory.
“My Items”
→
“Pictures”
→
“Saved Pictures”
1. Highlight the file you wish to add to Contacts List.
2. Press [Options] and select “Add to Contact”.
To overwrite, select “Existing Contact” and select
the data you wish to save to.
If the picture size exceeds 120 dots in width or 160
dots in height, specify the area you wish to display.
To save as a new entry, select “New Contact”.
For details on entering a name, see “Add New
Contact” on page 30.
Editing Pictures
“My Items”
→
“Pictures”
→
“Saved Pictures”
1. Highlight the file you wish to edit.
2. Press [Options] and select “Edit”.
3. Select the desired option:
“Rotate”: The picture is rotated 90º
anticlockwise. Press [Rotate] again
for another 90º.
“Adjust Size”: Select the desired option.
“Retouch”: Select the retouching option.
“Add Frame”: Select the desired frame pattern.
“Add Stamps”: Press [Stamps] and select the
desired stamp pattern. Repeat this
step to add more patterns.
Note
• The size of pictures that you can rotate or add a
frame to is 120 dots [W] × 160 dots [H] or 160 dots
[W] × 120 dots [H] maximum.
• The size of pictures that you can retouch is 26 dots
[W] × 26 dots [H] minimum and 120 dots [W] × 160
dots [H] or 160 dots [W] × 120 dots [H] maximum.
• The size of pictures that you can add stamps to is 12
dots [W] × 12 dots [H] minimum and 120 dots [W] ×
160 dots [H] or 160 dots [W] × 120 dots [H]
maximum.
• “Adjust Size” may not be available depending on the
original picture and copyright issued.
Sending a Picture File
“My Items”
→
“Pictures”
→
“Saved Pictures”
1. Highlight the file you wish to send.
2. Press [Options] and select “Send”.
3. Select “As Multimedia” or “As Postcard”.
For details on creating a message, see “Creating a
New MMS” on page 43.
My Items 59
Note
• Pictures with a faint icon cannot be sent attached to
a message.
• MMS Postcard service may not be available on all
networks. Contact your network operator for more
information.
Tip
• For details on transmitting My Items data, see
“Sending My Items Data to OBEX-enabled Phones”
on page 63.
Uploading Picture Files
You can upload your pictures to the Media Album. This
option may not be available on all networks. Contact
your network operator for more information.
“My Items”
→
“Pictures”
→
“Saved Pictures”
1. Highlight the file you wish to upload.
2. Press [Options] and select “Send”.
3. Select “To Album”.
4. Press [Yes].
Downloading Picture Files
“My Items”
→
“Pictures”
→
“More Pictures”
The picture file download site is displayed.
Games & More
Along with the preloaded application, downloaded
applications are stored in Applications.
Note
• Applications can store up to 50 applications.
Using Applications
Various kinds of Vodafone specific applications can be
used in this phone.
To use applications, download the applications via the
mobile Internet.
Some applications offer the ability to connect to a
network either within a game or network based
application.
Note
• Applications may be both localised (no connectivity)
and network based (using the mobile Internet to
update information/play games). The network may
charge you more for using network-based
applications. Please contact your service provider
for more information.
(M 6-1-3)
(M 6-2)
![](/img.php?id=421073&img=bg3d.png)
60 My Items
Downloading Applications
Confirmation Screen
Before downloading the application you are asked to
confirm what you are about to receive.
After checking the information on the confirmation
screen, the application can be downloaded.
Note
• User authentication may be required before
downloading the application on some information
screens.
Executing Applications
“My Items”
→
“Games & More”
→
“Applications”
Downloaded applications are sequentially displayed
from the latest one.
1. Select the title of the application you wish to
execute.
The selected application is executed.
When using network connection type applications,
connection to the network can be selected.
2. To end the application, press F and select [End].
More Games
“My Items”
→
“Games & More”
→
“More Games”
1. Select the application you wish to download.
After a WAP browser is displayed variously, the
confirmation screen will appear after a whilst.
2. Press [Get] to start downloading.
3. Press [OK] when finished.
Sounds
The ringtones created using the Melody Editor and the
AMR data recorded by Voice Recorder are managed in
Saved Sounds. The default ringtones are not contained
within Saved Sounds.
:SMAF format
: Original ringtone (composed in Melody Editor)
: Standard MIDI format
: i Melody format
: WAVE format
: AMR format
Tip
• SMAF (Synthetic music Mobile Application Format)
is a format of music data for mobile phones.
(M 6-2-1)
(M 6-2-2)
(M 6-3)
![](/img.php?id=421073&img=bg3e.png)
My Items 61
Playing Back Sound Files
“My Items”
→
“Sounds”
→
“Saved Sounds”
1. Select the file you wish to play back.
To stop playback, press .
Note
• This option may not be available in all regions.
Using the Sound Files as Ringtone
“My Items”
→
“Sounds”
→
“Saved Sounds”
1. Highlight the file you wish to use as ringtone.
2. Press [Options] and select “Set as Ringtone”.
The selected sound is automatically used for the
ringtone of the current Profiles.
Note
• Files in AMR or WAVE format cannot be used for the
ringtone.
• The volume varies depending on the Multimedia
Volume settings (p. 87). The volume is 0 when
“Multimedia Volume” is set to “Silent”.
Sending a Sound File with MMS
“My Items”
→
“Sounds”
→
“Saved Sounds”
1. Highlight the file you wish to send.
2. Press [Options] and select “Send”.
3. Select “As Multimedia”.
If you select your original ringtone in step 1,
perform the following.
4. Select the file format “SMAF”, “MIDI” or
“i Melody”.
For details on creating a message, see “Creating a
New MMS” on page 43.
Note
• Sounds with a faint icon cannot be sent attached to a
message.
• Only the first part of the data is converted if you
select “i Melody” in step 4.
Uploading Sound Files
You can upload your sounds to the Media Album. This
option may not be available on all networks. Contact
your network operator for more information.
“My Items”
→
“Sounds”
→
“Saved Sounds”
1. Highlight the file you wish to upload.
2. Press [Options] and select “Send”.
3. Select “To Album”.
If you select your original ringtone in step 1,
perform the following.
![](/img.php?id=421073&img=bg3f.png)
62 My Items
4. Select the file format “SMAF”, “MIDI” or
“i Melody”.
Downloading Sound Files
“My Items”
→
“Sounds”
→
“More Sounds”
The sound file download site is displayed.
Videos
Video clips that are recorded by a video camera or
video clips that are downloaded from mobile Internet
sites can be managed.
Tip
• The volume varies depending on the Multimedia
Volume settings (p. 87). The volume is 0 when
“Multimedia Volume” is set to “Silent”.
Playing Back Video Clip Files
“My Items”
→
“Videos”
→
“Saved Videos”
1. Select the file you wish to play back.
2. Press .
To resume, press again.
To stop playback, press [Back].
Sending a Video Clip File with MMS
“My Items”
→
“Videos”
→
“Saved Videos”
1. Highlight the file you wish to send.
2. Press [Options] and select “Send”.
3. Select “As Multimedia”.
For details on creating a message, see “Creating a
New MMS” on page 43.
Note
• Video clips with a faint icon cannot be sent attached
to a message.
Uploading Video Clip Files
You can upload your video clips to the Media Album.
This option may not be available on all networks.
Contact your network operator for more information.
“My Items”
→
“Videos”
→
“Saved Videos”
1. Highlight the file you wish to upload.
2. Press [Options] and select “Send”.
3. Select “To Album”.
4. Press [Yes].
Downloading Video Clip Files
“My Items”
→
“Videos”
→
“More Videos”
The video clip file download site is displayed.
(M 6-3-4)
(M 6-4)
(M 6-4-3)
![](/img.php?id=421073&img=bg40.png)
My Items 63
Sending My Items Data to OBEX-enabled
Phones
Choose the appropriate menu.
“My Items”
→
“Pictures”
→
“Saved Pictures”
“My Items”
→
“Sounds”
→
“Saved Sounds”
“My Items”
→
“Videos”
→
“Saved Videos”
1. Highlight the desired file.
2. Press [Options] and select “Send”.
3. Select “Via Bluetooth” or “Via Infrared”.
The phone starts searching for Bluetooth wireless
technology enabled devices within 10 metres, or an
infrared-enabled device within 20 centimetres.
When an infrared-enabled device is detected, the
infrared connection is established and the entry is
sent.
When Bluetooth wireless technology enabled
devices are detected, a list of enabled devices is
displayed.
4. Select the desired Bluetooth wireless technology
enabled device.
The connection is established and the entry is sent.
Note
• You can send a maximum of 100 Kbyte data.
Receiving the My Items Data
When the phone receives the My Items data, a
confirmation message appears in the stand-by mode
screen.
1. Press [Yes].
The received entry is registered in the
corresponding My Items folder.
Tip
• For details on Infrared or Bluetooth wireless
settings, see “Connectivity” on page 95.
Text Templates
You can register up to 20 text templates for use in text
messages and multimedia messages.
120 characters may be registered in any text template.
Adding Phrases to Text Templates
“My Items”
→
“Text Templates”
1. Select the number you wish to register.
2. Enter the text and press .
(M 6-5)
![](/img.php?id=421073&img=bg41.png)
64 My Items
Editing Text Templates
“My Items”
→
“Text Templates”
1. Highlight the number you wish to edit.
2. Press [Options] and select “Edit”.
3. Enter new text and press .
Viewing Text Templates
“My Items”
→
“Text Templates”
The list of Text Templates is displayed.
1. Highlight the number you wish to view.
2. Press [Options] and select “View”.
Deleting Text Templates
“My Items”
→
“Text Templates”
1. Highlight the text template you wish to delete.
2. Press [Options] and select “Delete”.
Memory Status
This function helps you to check the memory status of
My Item. Memory status covers Applications, Pictures,
Sounds, and Videos.
“My Items”
→
“Memory Status”
(M 6-7)
![](/img.php?id=421073&img=bg42.png)
Games & More 65
Games & More
Applications
The list of Java™ applications is displayed.
Downloaded applications are displayed in order
starting from the latest one.
Executing Applications
For details on executing applications, see “Executing
Applications” on page 60.
Setting Permission
When using applications that access the network, you
may need online security against data theft or
tampering especially for monetary transactions. With
this option, you can set the confirmation method when
the Java™ application accesses the network.
To Select the Function and Confirmation Method
“Games & More”
→
“Applications”
1. Highlight the desired Java™ application.
2. Press [Options] and select “Permission”.
3. Select “Net Access” to access billing data on the
network.
4. Select the desired confirmation method.
Always Connect: Allows the Java™ application access
without confirmation.
First Time: Informs you when the Java™
application uses the function for the
first time. If allow is selected, no
more confirmations are made until
you delete the application.
Per Session: Informs you when the Java™
application uses the function for the
first time. If allow is selected, no
more confirmations are made until
the application finishes operation.
Per Access: Informs you every time the Java™
application uses the function
regardless of whether or not you
select allow or deny.
Never Connect: Prevents the Java™ application from
using the functions and no
confirmation is made.
(M 1)
(M 1-1)
66 Games & More
To Reset Permissions
You can reset all permissions you made
“Games & More”
→
“Applications”
1. Highlight the desired Java™ applications.
2. Press [Options] and select “Reset Permissions”.
Screensavers
You can download screensaver applications for the
stand-by screen.
“Games & More”
→
“Screensavers”
→
“Switch
On/Off”
1. Select “On” or “Off”.
Note
• If you select “On” and a screensaver application is
not set, a list displaying available screensavers
appears, asking you to make a selection.
Setting the Screensaver
“Games & More”
→
“Screensavers”
→
“Set
Application”
The downloaded screensaver applications are
displayed.
1. Select the desired screensaver application.
Set Network Access
You can set how and whether to connect to the network
or not using the screensaver application.
“Games & More”
→
“Screensavers”
→
“Set Network
Access”
1. Select from “Always Connect”, “Default Settings”
or “Never Connect”.
Note
• Changes made to the above setting whilst the
application is suspended are made effective by
restarting the application.
• You may not be able to make the above settings
depending on your network.
(M 1-2)
(M 1-2-2)
(M 1-2-3)
![](/img.php?id=421073&img=bg44.png)
Games & More 67
Resume Time
You can set the time period for the screensaver
application to activate.
“Games & More”
→
“Screensavers”
→
“Resume
Time”
1. Enter the resume time in two digits using the digit
key.
More Games
You can download applications.
“Games & More”
→
“More Games”
The application download site is displayed.
1. Select the application you wish to download.
After a WAP browser is displayed variously, the
confirmation screen will appear after a whilst.
2. Press [Get] to start downloading.
3. Press [OK] when finished.
Settings
Calls & Alarms
You can set the priority of incoming calls and alarms
whilst an application is operating.
“Games & More”
→
“Settings”
→
“Calls & Alarms”
1. Select “Incoming Call” or “Alarm”.
2. Select methods.
• “Call Priority” or “Alarm Priority”:
The application is suspended automatically, and you
can receive a call, or the alarm will sound. After
finishing the call or the alarm ends, the suspend icon
( ) is displayed letting know there is a suspended
application.
• “Call Notice” or “Alarm Notice”:
The marquee (character scrolls) is displayed on the
first line of the screen whilst the application
continues. If you press D, the application is
suspended, and you can receive a call. After finishing
the call, the suspend icon ( ) is displayed letting
know there is a suspended application.
(M 1-2-4)
(M 1-3)
(M 1-4)
(M 1-4-1)
68 Games & More
Sound Volume
You can set the volume of the application such as sound
effect to one of the five levels or silent. When
“Multimedia Volume” (p. 87) is set to “Silent”, this
setup has priority.
“Games & More”
→
“Settings”
→
“Sound Volume”
The current volume level is displayed.
1. Press a to increase the volume or press b to
decrease the volume.
Backlight
“Games & More”
→
“Settings”
→
“Backlight”
→
“Switch On/Off”
1. Select from “Always On”, “Always Off” or
“Normal Settings”.
• “Always On”: Lit whilst the application
is operated.
• “Always Off”: Unlit whilst the application is
operated even if a key is pressed.
• “Normal Settings”: Works with the main backlight
setting. (p. 89)
To Set the Blinking Operation
This setting enables the backlight to be controlled by
the application. If set to “Off”, the backlight cannot be
turned on from the application.
“Games & More”
→
“Settings”
→
“Backlight”
→
“Blink”
1. Select “On” or “Off”.
Vibration
When the vibrator is set in the application, you can
choose whether the operation is enabled or disabled.
When a SMAF file is specified in the application, you
can operate the vibrator set in the SMAF file.
Note
• SMAF (Synthetic music Mobile Application Format)
is a music data format for mobile phones.
“Games & More”
→
“Settings”
→
“Vibration”
1. Select from “On”, “Off” or “On & Link to Sound”.
When you set “On & Link to Sound”, the sound of
SMAF file in the application is synchronised with
the vibrator.
(M 1-4-2)
(M 1-4-3)
(M 1-4-4)
Games & More 69
Reset
To Reset All Items in Settings Menu
“Games & More”
→
“Settings”
→
“Set to Default”
1. Enter your handset code.
The default handset code is “0000”. For details on
changing the handset code, see “To Change Handset
Code” on page 101.
Java™ Information
The information about the license belonging to Java™
can be displayed.
(M 1-4-5)
(M 1-5)
![](/img.php?id=421073&img=bg47.png)
70 Applications
Applications
SIM Application
You can refer to the information on the SIM. Contact
your service provider for further details.
Alarms
Setting the Alarms
The alarm function allows you to be alerted at a
specified time.
Note that the alarm may not function correctly if the
clock has not been set.
“Applications”
→
“Alarms”
1. Select the blank setting.
2. Enter the desired time.
To Change the Type of Alarm Tone
3. Select “Set Alarm Tone”.
4. Select “Tone”.
5. Select “Preset Sounds” or “My Sounds”.
6. Select the desired tone.
For details on selecting a ringtone, see “Assigning
Ringtone” on page 85.
To Change the Vibration of Alarm Tone
7. Select “Vibration”.
8. Select “On”, “Off” or “On & Link to Sound”.
To Change the Duration of Alarm Tone
9. Select “Duration”.
10. Enter the desired time (02-59).
11. Press [Back].
To Set the Repeating Option
12. Select “Repeat Daily”.
13. Select “On”.
14. Press [Save].
(M 3)
(M 3-1)
(M 3-2)
![](/img.php?id=421073&img=bg48.png)
Applications 71
Editing the Alarm Setting
“Applications”
→
“Alarms”
1. Select the desired setting and edit it.
Resetting an Alarm Setting
“Applications”
→
“Alarms”
1. Select the alarm you wish to reset.
2. Select “Reset Alarm”.
Resetting All Alarm Settings
“Applications”
→
“Alarms”
1. Select “Clear All”.
Calculator
The calculator function performs the 4 arithmetic
calculations using up to 12 digits.
“Applications”
→
“Calculator”
→
“Calculator”
The calculator is displayed on the display.
Key operations for calculation are as follows.
To enter a decimal point, press R.
To clear the entered number or operand, press
[Clear].
To do the calculations, press .
To start a new calculation, press [Clear].
(M 3-3)
![](/img.php?id=421073&img=bg49.png)
72 Applications
Rate Conversion
You can also use the calculator as a currency calculator
to convert from/to a home currency using a conversion
rate that you enter.
To Set a Currency Conversion Rate
“Applications”
→
“Calculator”
→
“Exchange Rate”
1. Select “Foreign -> Domestic” or “Domestic ->
Foreign”.
2. Enter the currency conversion rate.
To delete all digits, press [Clear].
To Convert a Value
“Applications”
→
“Calculator”
→
“Calculator”
1. Enter the value to be converted.
2. Press [Options] and select “In Domestic” or “In
Foreign”.
The result is displayed.
If you select “Exchange Rate” in step 2, you can set
a currency conversion rate.
Note
• You cannot perform step 1 when an arithmetic
symbol (+, –, × or ÷ ) is displayed.
Voice Recorder
This allows you to record a voice clip of up to 60
seconds, which can be used to remind you of schedule
entries or be sent within a multimedia message. The
recorded voice clip is registered in Saved Sounds.
Voice clips are saved in “.amr” format.
Recording a Voice Clip
“Applications”
→
“Voice Recorder”
1. Press to start recording.
To stop recording before the recording time is over,
press .
2. Select “Save” to save the voice clip.
To play back the recorded voice clip, select
“Playback”.
To record a voice clip again, press [Cancel] .
Note
• To change recorded size before recording, press
[Options] and select “Record Size”. Then select
“Extended Voice” or “For Message”.
(M 3-3-2) (M 3-4)
![](/img.php?id=421073&img=bg4a.png)
Applications 73
Tip
• The volume varies depending on the Multimedia
Volume settings (p. 87). To adjust the volume, press
a or b, or the side-up or side-down key. The
volume is 0 when “Multimedia Volume” is set to
“Silent”.
• You can also activate Voice Recorder by pressing
, then R during stand-by.
Sending Voice Clips
“Applications”
→
“Voice Recorder”
1. Press to start recording.
2. Press to stop recording.
3. Select “Save and Send”.
For details on creating a message, see “Creating a New
MMS” on page 43.
Note
• “Save and Send” is not displayed after recording in
extended voice mode.
Melody Editor
You can create an original ringtone, or you can send a
melody attached to a multimedia message.
You can input up to 95 tones × 32 voices, 190 tones ×
16 voices, or 380 tones × 8 voices per melody.
The original ringtone is registered in Saved Sounds.
Creating Your Original Ringtone
“Applications”
→
“Melody Editor”
→
“Create New”
1. Enter the title.
Up to 24 characters can be entered.
2. Select a tempo.
The music tempo is described below.
• “Allegro (Fast)”: 150
• “Moderato (Normal)”: 125
• “Andante (Slow)”: 107
• “Adagio (Very Slow)”: 94
3. Select from “8 Chords”, “16 Chords” or “32
Chords”.
(M 3-5)
(M 3-5-1)
![](/img.php?id=421073&img=bg4b.png)
74 Applications
4. Press the digit keys to specify the musical scale and
rest.
For details on specifying the sound level and rest,
see “To Specify the Musical Scale and Rest” on
page 75.
5. Press P or R to specify the types of musical
notes or rest.
For details on specifying the musical notes and rest,
“To Specify the Types of Notes and Rests” on
page 75.
6. Press d after inputting one note.
Input the next note after the cursor moves to the
right.
7. Repeat steps 5 and 7 to input notes.
When entering notes, you can do the following:
• Press to play back all input notes.
• Press [Options] and select:
“Play before cursor” to play back notes up to the
cursor position.
“Select Part” to select another chord.
“Set Tone” to set or change the tone using different
instruments. (p. 76)
“Set Strength” sets the strength of the original
ringtone. (p. 76)
• To specify the types of notes or rests, see page 75.
8. When you finish inputting, press [Options] and
select “Save”.
9. Select “Save to My Items”.
Note
• If the capacity or memory in Saved Sounds becomes
insufficient, the message, “Maximum capacity : 200
Not registered.” or “Not registered. Memory full.” is
displayed. The screen returns to step 9. Try again
after deleting unnecessary data.
• Melodies consisting of too many short notes
(semiquavers and triplets) cannot be played back in
step 8 and the following message is displayed: “Can
not play due to too many notes per sec.” The screen
returns to step 5.
The message “Can not save due to too many notes
per sec.” may also be displayed, and the screen
returns to step 5.
Reduce the number of melodies, replace short notes,
cancel triplets, etc. to remedy.
![](/img.php?id=421073&img=bg4c.png)
Applications 75
To Specify the Musical Scale and Rest
Using the keys shown below, specify the musical scale
and rest.
When you press the key shown above once, a crotchet
is specified in the middle scale (no mark).
When you press the same key repeatedly, the note will
shift cycle through the available octave ranges.
When you press a or b whilst a note is selected, the
note will move one semitone higher or lower.
When entering rest, crotchet rest is entered.
To Specify the Types of Notes and Rests
Press P or R repeatedly.
When you make a dotted note or a triplet, press O
after selecting the target note.
Note
• You cannot make a dotted semiquaver (semiquaver
rest) or a dotted semibreve (semibreve rest).
• Three continuous notes are required for a triplet.
To specify a tie, press N after selecting the target
notes.
An underscore (_) is displayed next to the note, and the
note is tied with the next one.
To enter the next note, press d to move the cursor to
the right. Then, repeat the operation on the previous
pages.
Do Re Mi Fa Sol La Ti Rest
GHIJKLMQ
LLL
L
( ) ( ) ( ) ( ) ( )
PP P
P
P
![](/img.php?id=421073&img=bg4d.png)
76 Applications
If the cursor is positioned next to a note, you can repeat
the note immediately left of the cursor when a or b is
pressed.
To Set the Tone
The phone can play notes using different instruments.
You can select from 128 basic tones (8 types of: Pianos,
Chimes, Organs, Guitars, Basses, Strings 1, Strings 2,
Brasses, Reeds, Flutes/Pipes, Synth Leads, Synth Pads,
Synth Effects, Ethnics, Percussions, and Effects) and
61 extended tones (40 types of Drums FM and 21 types
of Drums WT).
1. Press [Options] and select “Set Tone” in step 8 on
page 74.
2. Press c or d to highlight a category of the tone.
3. Press a or b to highlight a tone.
4. Press .
Now you can create a melody.
Tip
• You can play back the melody in the selected tone by
pressing [Options] and select “Play Current Part”,
or play back the syllable names in the selected tone
by selecting “Confirm Tones” instead.
To Set the Strength of the Original Ringtone
The strength of the original ringtone can be set in 3
levels for each melody.
When you purchase this phone, the strength of the
original ringtone is set to “Loud”.
1. Press [Options] and select “Set Strength” in step 8
on page 74.
2. Select a strength of the tone.
3. Press .
Now you can create an original ringtone.
Editing Original Ringtones
“Applications”
→
“Melody Editor”
→
“My Sounds”
1. Highlight an original ringtone you wish to edit.
2. Press [Options] and select “Edit Melody”.
3. Edit the title.
4. Select a tempo and number of voices.
(M 3-5-2)
Applications 77
5. Edit the data.
6. When you finish editing, press [Options] and select
“Save”.
7. Select “Save to My Items”.
8. Select “Overwrite” or “New”.
Note
• When the number of voices is modified in step 5, the
confirmation message may be displayed. When you
press [Yes], a section of the melody may be deleted.
Tip
• You can delete the melody after or before the cursor
by pressing [Options] and selecting “Del. after
cursor” or “Del. before cursor”.
Copying and Pasting Notes
You can copy and move a part of the melody to another
position.
Only original ringtones or editable melodies can be
copied or moved.
1. In the Score input screen, press [Options] and select
“Copy” or “Cut”.
2. Move the cursor to the first note to be copied or to
be cut.
3. Move the cursor to the last note to highlight the
area.
4. Press [Options] and select “Paste”.
5. Move the cursor to the point you wish to paste the
notes.
Phone Help
You can view the help list and use it to guide you in the
phone’s functions.
“Applications”
→
“Phone Help”
1. Highlight the desired function.
(M 3-6)
![](/img.php?id=421073&img=bg4f.png)
78 Calendar
Calendar
Calendar allows you to easily schedule appointments or
events, which are associated with the date and time.
These entries can also be sent via infrared or Bluetooth
wireless technology to a PC to share the same
schedules.
Creating a New Entry
“Calendar”
1. Highlight the desired day to which you want to add
an event.
2. Press [Options] and select “New Entry”.
3. Select from “Appointment”, “All Day Event” or
“Anniversary”.
To Set an Appointment
1. Enter the subject, start time and end time.
2. Select the reminder option.
3. Select and set “Tone”, “Vibration” or “Duration”.
4. Enter the location.
5. Press [Save].
To Set an All Day Event
1. Enter the subject, date and location.
2. Press [Save].
To Set an Anniversary
1. Select the anniversary option from “Ann by date” or
“Ann by day”.
2. (For “Ann by date”)
Enter the subject, date (month and day) and
location.
(For “Ann by day”)
Enter the subject, date (day of the week, week
number and month) and location.
(M 7)
Calendar 79
Sending a Schedule Entry
“Calendar”
1. Select the day including schedule entries you wish
to send.
2. Select “Via Bluetooth” or “Via Infrared”.
The phone starts searching for Bluetooth wireless
technology enabled devices within 10 metres, or an
infrared-enabled device within 20 centimetres.
When an infrared-enabled device is detected, the
infrared connection is established and the entry is
sent.
When Bluetooth wireless technology enabled
devices are detected, a list of enabled devices is
displayed.
3. Select the desired Bluetooth wireless technology
enabled device.
The connection is established and the entry is sent.
Tip
• You do not need to enter your passcode in step 3.
• For details on Infrared or Bluetooth wireless
settings, see “Connectivity” on page 95.
Viewing an Entry
“Calendar”
1. Select the day you wish to view.
The day view is displayed.
To Search By Date
1. In the monthly or daily view, press [Options].
2. Select “Go to”.
3. Select “Today” to display today or “Enter date” to
enter the desired date.
To Search By Subject
1. In the monthly or daily view, press [Options].
2. Select “Find”.
3. Enter the desired text.
To Change the Week Format
1. In the monthly view, press [Options].
2. Select “Week Format”.
3. Select “Monday-Sunday” or “Sunday-Saturday”.
80 Calendar
Deleting Entries
1. In the monthly or daily view, press [Options].
2. Select “Delete”.
3. Select the desired option.
• “This Appointment”:(daily view only)
Deletes the selected appointment.
• “All this Day”: Deletes all entries for the selected
day.
• “All this Month”: Deletes all entries for the selected
month.
• “Up to Last Month”:
Deletes all entries from the last
month to the selected month.
• “All Schedules”: Deletes all entries in this
application.
![](/img.php?id=421073&img=bg52.png)
Contacts 81
Contacts
Call Log
The phone will record the last 10 missed calls, received
calls and dialled numbers.
Viewing Call Log
“Contacts”
→
“Call Log”
1. Select from “All Calls”, “Dialled Numbers”,
“Missed Calls”, or “Received Calls”.
The selected call log list is displayed.
2. Select the phone number you wish to view.
If you wish to dial the number, press D.
Call log “1” is the most recent. When you press b,
call log “2” is displayed.
Tip
• You can also confirm call logs by pressing D
during stand-by mode.
Sending Messages
1. In call log list, highlight the call log you wish to
send a message to.
The selected call log is displayed in detail.
2. Press [Options] and select “Create Message”.
3. Select “Multimedia” or “Text”.
For details on creating a message, see “Creating a
New MMS” on page 43 or “Creating and Sending a
New SMS” on page 49.
Deleting a Call Log
1. In call log list, press [Options] and select “Delete”.
(M 8)
(M 8-3)
82 Contacts
Speed Dial List
You can view and perform other operations for phone
numbers registered in the Speed Dial List.
“Contacts”
→
“Speed Dial List”
The names and phone numbers stored in the Speed
Dial List are displayed in order.
My Numbers
You can check your own voice, data and fax phone
numbers.
“Contacts”
→
“My Numbers”
1. Select the phone number you wish to check from
“Voice”, “Data” or “Fax”.
Note
• “Data” or “Fax” may not be displayed depending on
the SIM card.
Call Timers
This function lets you check the duration of your calls.
Checking the Duration of the Last Call and All
Calls
“Contacts”
→
“Call Timers”
1. Select “Received Calls” or “Dialled Numbers”.
The duration of the last call or all calls is displayed.
Data Counter
You can confirm the amount of bytes that you used in
the GPRS transmission.
“Contacts”
→
“Data Counter”
1. Select from “Last Data” or “All Data”.
Resetting All Data Counter
“Contacts”
→
“Data Counter”
→
“Clear Counter”
(M 8-4)
(M 8-5)
(M 8-6)
(M 8-7)
![](/img.php?id=421073&img=bg54.png)
Contacts 83
Call Costs
This function lets you check the charges for your calls.
Some networks do not support Charging Advice.
Please check with your service provider for
availability.
Checking the Cost of the Last Call
“Contacts”
→
“Call Costs”
→
“Last Call”
The cost of the last call is displayed.
Checking the Total Call Cost
“Contacts”
→
“Call Costs”
→
“All Calls”
The cost of all calls is displayed.
Setting the Charge Rate
Set the charge rate to calculate the call cost and set the
maximum limit for call cost.
“Contacts”
→
“Call Costs”
→
“Costs Units”
→
“Set
Units”
1. Enter your PIN2 code.
2. Enter a cost per unit.
To enter a decimal point, press R.
3. Enter a currency unit (up to 3 characters).
Setting the Charge Limit
This function is useful if you wish to make sure you do
not exceed a certain charge limit.
“Contacts”
→
“Call Costs”
→
“Max Cost”
→
“Set
Limit”
1. Enter your PIN2 code.
2. Enter a value.
To enter a decimal point, press R.
Resetting All Call Costs
“Contacts”
→
“Call Costs”
→
“Clear Costs”
1. Enter your PIN2 code.
(M 8-8)
![](/img.php?id=421073&img=bg55.png)
84 Settings
Settings
Profiles
Tone sound and vibration set can be customised for
each profile according to your environment.
There are 6 profiles including one user definable
profile: Normal, Meeting, Activity, Car, Headset and
Silent.
Activating a Profile
“Settings”
→
“Profiles”
1. Select the desired profile.
Note
• When a profile is set, the corresponding icon
described on page 15 is displayed on the stand-by
screen.
Tip
• Press and hold R to switch Profiles settings
between Normal and Silent mode during stand-by.
Customising Profiles
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select the setting you wish to customise and change
as desired.
For details about settings, pages 84 to 88.
4. Press [Save] when finished.
Resetting Profile Settings
“Settings”
→
“Profiles”
1. Highlight the profile you wish to reset.
2. Press [Options] and select “Set to Default”.
3. Enter your handset code.
The default handset code is “0000”. For details on
changing the handset code, see “To Change Handset
Code” on page 101.
Ringer Volume
You can adjust the ringer volume to one of 6 levels or a
step tone.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
(M 9)
(M 9-1)
![](/img.php?id=421073&img=bg56.png)
Settings 85
3. Select “Ringer Volume”.
The current volume level is displayed.
4. Press a to increase the ringer volume or press b
to decrease the ringer volume and then press .
To select “Step Tone”, press a at level 5.
To select “Silent”, press b at level 1.
Assigning Ringtone
You can select the ringtone from 28 tones including 5
patterns, 13 sound effects and 10 melodies. You can
also select a sound in Saved Sounds as the default
ringtone excluding the AMR or WAVE format.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Assign Ringtone”.
4. Select “Preset Sounds” or “My Sounds”.
5. Select the ringtone you wish to use.
To hear the demo play, press . To stop playing,
press again.
6. Press [Options] and select “Assign”.
Note
• If you delete a ringtone that uses a sound in Saved
Sounds, the default ringtone is set.
Vibration
When the vibrator option is set on, the phone will
vibrate for incoming calls regardless of the ringer
volume and tone settings.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Vibration”.
4. Select from “On”, “Off” or “On & Link to Sound”.
Tip
• When the “On & Link to Sound” option is selected in
step 4, the vibrator synchronises with your selected
melody to pulse in time with the melody. Please note
that not all melodies support the “On & Link to
Sound” option. Should you select such a melody, only
the “On” option in step 4 will allow vibrator
function.
• When you select “On” or “On & Link to Sound” in
step 4, “ ” is displayed on the stand-by screen.
86 Settings
Alerts
You can personalise profiles for alerts including
warning tone, message alert and low battery alert.
Warning Tone
Your phone emits the warning tone when an error
occurs.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Alerts”.
4. Select “Warning tone”.
5. Select “Switch On/Off”.
6. Select “Volume” and select from “High”, “Middle”
or “Low”.
7. Select “Tone” and select “Preset Sounds” or “My
Sounds”.
8. Select “Duration” and select the desired time.
Message Alert
When receiving messages, special ringtones can be set.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Alerts”.
4. Select “Message Alert”.
5. Select from “Multimedia”, “Text” or “WAP”.
6. Select “Volume” and select the desired volume.
7. Select “Sound” and select “Preset Sounds” or “My
Sounds”.
8. Select “Vibration” and select from “On”, “Off” or
“On & Link to Sound”.
9. Select “Duration” and select the desired time.
![](/img.php?id=421073&img=bg58.png)
Settings 87
Keypad Tones
When the keypad tone is set on, you will hear a
confirmation tone each time you press any keys.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Keypad Tones”.
4. Select “Switch On/Off” and select “On”.
Select “Off” to cancel.
5. Select “Volume” and select from “High”, “Middle”
or “Low”.
6. Select “Tone” and select from “Preset Sounds”,
“My Sounds” or “Default Tone”.
When selecting “Default Tone”, go to step 8.
7. Select the desired tone.
For details on assigning the tone, see “Assigning
Ringtone” on page 85.
8. Select “Duration” and select the desired time.
Multimedia Volume
You can adjust volume for Video Camera, Voice
Recorder, Melody Editor, My Items, browser and
multimedia messages.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Multimedia Volume”.
The current volume level is displayed.
4. Press a to increase the volume or press b to
decrease the volume and then press .
To select “Silent”, press b at level 1.
Power On Sound / Power Off Sound
The phone can be set to emit a sound when it is
switched on or off. You can define the volume, duration
and the melody to be used for this task.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Power On Sound” or “Power Off Sound”.
4. Select “Volume” and select the desired volume.
5. Select “Sound” and select “Preset Sounds” or “My
Sounds”.
6. Select “Duration” and select the desired time.
![](/img.php?id=421073&img=bg59.png)
88 Settings
Echo Reduction
This function is for reducing irritating echoes,
especially when using the handsfree car kit.
“Settings”
→
“Profiles”
1. Highlight the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Echo Reduction”.
4. Select “On” or “Off”.
Any Key Answer
You can also answer a call by pressing any key except
F or [Busy]. For details, see page 19.
“Settings”
→
“Profiles”
1. Select the profile you wish to customise.
2. Press [Options] and select “Personalise”.
3. Select “Any Key Answer”.
4. Select “On” or “Off”.
Setting the Display
You can change the settings of the screen.
Wallpaper
For the stand-by screen, 3 pictures are provided.
Pictures taken with the digital camera or images
downloaded from a WAP site can be used for
wallpapers.
Setting My Pictures
“Settings”
→
“Display”
→
“Wallpaper”
→
“My
Pictures”
1. Select the desired picture.
2. After displaying the picture, press .
3. Specify the area you wish to display using the
navigation keys.
Note
• Some pictures cannot be used because of their
picture and data types.
(M 9-2)
Settings 89
Assigning the Pictures
Pictures can be displayed when turning the power on or
off, when receiving an incoming call, or when
operating the alarm.
Pictures taken by a digital camera or images
downloaded from a WAP site can be used.
To Set Built-in Pictures
“Settings”
→
“Display”
→
“Graphics”
1. Select the desired situation to set the picture.
2. Select “Preset Animation” when you select “Power
On” or “Power Off” in step 1.
Select “Pattern 1”, “Pattern 2” or “Pattern 3” when
you select “Incoming Call” or “Alarm” in step 1.
To Set My Pictures
“Settings”
→
“Display”
→
“Graphics”
1. Select the desired situation to set the picture
2. Select “My Pictures”.
3. Select the picture.
4. Specify the area you wish to display using the
navigation keys.
Note
• Some pictures cannot be used because of their
picture and data types.
Setting the Greeting Message
You can set the message which will appear when the
phone is turned on.
“Settings”
→
“Display”
→
“Greeting Message”
→
“Switch On/Off”
1. Select “On” to display the greeting message when
the phone is turned on.
Select “Off” for no message.
2. Select “Edit Message” and enter the message.
Up to 16 characters can be stored as a message.
For details on entering characters, see “Entering
Characters” on page 24.
Showing the Clock
You can display the current date and/or time on the
stand-by screen.
“Settings”
→
“Display”
→
“Show Clock”
1. Select from “Time Only”, “Date & Time” or “Off”.
Backlight
You can turn the backlight of the screen on or off when
you press the keypad or the optional cigarette lighter
charger is connected to the phone.
You can change time the backlight is on for, which will
help conserve battery life.
(M 9-2-4)
![](/img.php?id=421073&img=bg5b.png)
90 Settings
Tip
• When you purchase this phone, Backlight is set to 15
seconds.
To Select the Backlight Time Out
“Settings”
→
“Display”
→
“Backlight”
→
“Time
Out”
1. Select “On” or “Off”.
To Turn On/Off the Backlight whilst Charging with
the Cigarette Lighter Charger
With this setting On, the phone’s backlight is on when
the cigarette lighter charger is connected.
“Settings”
→
“Display”
→
“Backlight”
→
“In Car”
1. Select the desired time.
Adjusting the Brightness of the Backlight
You can adjust the brightness of the backlight of the
screen from 4 levels.
“Settings”
→
“Display”
→
“Brightness”
1. Adjust the brightness by pressing a (Light) and b
(Dark) for maximum clarity.
2. Press .
Setting the Display Saving
This phone’s screen will automatically turn off after a
given amount of time.
You can change the time before the Display Saving will
go into effect, which will help conserve battery life.
Tip
• When you purchase this phone, Display Saving is set
to 2 minutes.
“Settings”
→
“Display”
→
“Display Saving”
1. Select the desired time.
Note
• Display Saving does not work whilst you are calling,
using WAP, or using an application.
• To cancel the Display Saving: The display saving
continues until either a key is pressed or there is an
incoming alert. The first key press only cancels this
function. You must press another key in order to input
any numerical or text value.
Display Setting Reset
The phone settings can be reset to their default settings.
“Settings”
→
“Display”
→
“Set to Default”
1. Enter your handset code.
(M 9-2-8)
![](/img.php?id=421073&img=bg5c.png)
Settings 91
Call Settings
Set various types of functions and services.
Diverts
This service is used to divert incoming calls to your
voice mail system or to another number depending on
certain conditions in which you cannot answer a call.
To Divert Calls
“Settings”
→
“Call Settings”
→
“Diverts”
1. Select one of the following options.
• “All Calls”: Diverts all voice calls without
ringing.
• “When Busy”: Diverts incoming calls when you
are on a call.
• “No Answer”: Diverts incoming calls if you do
not answer a call within a certain
period of time.
• “Not Reachable”: Diverts incoming calls when your
phone is out of network service or
switched off.
2. Select “On”.
3. Enter a phone number to which you wish to divert
calls or search for it in the Contacts List. (p. 31)
4. Press .
If you select “No Answer” in step 1:
5. Select the period of time from 6 levels (05 to 30
seconds).
Note
• When a divert is set to “All Calls”, “ ” is displayed
on the stand-by screen.
Tip
• If you select “By Service” in step 2, you can select
further divert options.
To Check the Divert Status
“Settings”
→
“Call Settings”
→
“Diverts”
1. Select the divert option you wish to check.
2. Select “Status”.
You can check the status of the selected divert
option.
(M 9-4)
(M 9-4-1)
92 Settings
Call Waiting
If you wish to be able to receive another incoming call
whilst you have a call in progress, you must activate the
Call Waiting service.
“Settings”
→
“Call Settings”
→
“Call Waiting”
1. Select “On” or “Off”.
Note
• The Call Waiting service may not be available on all
mobile phone networks. Contact your network
operator for more information.
Showing Your Phone Number
This lets you control whether to show your phone
number when calling another party or not.
Some networks do not support this service. Please
check with your service provider for availability.
“Settings”
→
“Call Settings”
→
“Show Your
Number”
1. Select “On” or “Off”.
Note
• Some networks do not support this service. Please
check with your service provider for availability.
Restrict Calls
This function lets you place restrictions on incoming
and outgoing calls. To activate this option you will need
the specified password, which is available from your
service provider.
“Settings”
→
“Call Settings”
→
“Restrict Calls”
1. Select from “Outgoing Calls” or “Incoming Calls”.
• Outgoing Calls: Restricts outgoing calls.
• Incoming Calls: Restricts incoming calls.
2. (For “Outgoing Calls”)
Select “Bar Foreign Calls” or “Bar All Outgoing Calls”.
• Bar Foreign Calls: Restricts all outgoing
international calls.
• Bar All Outgoing Calls:
Restricts all outgoing calls
except emergency calls.
• Only Local & Home:
Restricts all outgoing
international calls except to
your home country.
(For “Incoming Calls”)
• Bar All Incoming Calls:
Restricts all incoming calls.
(M 9-4-2)
(M 9-4-3)
(M 9-4-4)
Settings 93
• Bar if Abroad: Restricts all incoming calls
when you are outside of the
coverage from your
registered network operator.
3. Select one of the following options.
• “All Services”: Restricts all services.
• “Voice Calls”: Restricts all voice calls.
• “Data”: Restricts all data calls.
• “Fax”: Restricts all fax calls.
• “Messages”: Restricts all messages.
• “All except msgs”: Restricts all services except
messages.
4. Select “On” or “Off”.
5. Enter the network password.
To Cancel Settings
“Settings”
→
“Call Settings”
→
“Restrict Calls”
1. Select “Outgoing Calls” or “Incoming Calls”.
2. Select “Cancel All”.
3. Enter the network password.
Fixed Dialling No.
When the Fixed Dialling No. is enabled, you can only
call predefined numbers.
To Enable Fixed Dialling No.
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Fixed Dialling No.”
1. Enter your PIN2 code.
2. Select “Switch On/Off”.
3. Select “On” or “Off”.
To Add a New Name
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Fixed Dialling No.”
1. Enter your PIN2 code.
2. Select “Edit Dial List”.
3. Press [Options] and select “Add New Contact”.
4. Add a name and a phone number.
For details on adding a name and a phone number,
see “Add New Contact” on page 30.
5. Press [Save].
![](/img.php?id=421073&img=bg5f.png)
94 Settings
Changing the Network Password
“Settings”
→
“Call Settings”
→
“Restrict Calls”
→
“Change Password”
1. Enter the old network password.
2. Enter a new network password.
3. Enter a new network password again.
If you enter the incorrect password, you are asked to
enter the password again.
4. Press .
Auto Redial (M 9-4-5)
See “Automatic Redialling” on page 19.
Minute Minder (M 9-4-6)
Minute Minder function informs you of your talk time
by sounding a tone after every minute.
“Settings”
→
“Call Settings”
→
“Minute Minder”
1. Select “On” or “Off”.
Call Setting Reset (M 9-4-7)
The call settings can be reset to their default settings.
“Settings”
→
“Call Settings”
→
“Set to Default”
1. Enter your handset code.
Date & Time
You need to set the correct time and date in order for
your phone’s various time-based functions to work
correctly.
“Settings”
→
“Date & Time”
→
“Set Date/Time”
1. Enter the day, month, year and time using the digit
keys.
Tip
• When you enter the time in the 12-hour format, press
P to switch between am and pm. The order in
which the date and time is displayed is based on the
format setting.
Selecting the Time Format
“Settings”
→
“Date & Time”
→
“Time Format”
1. Select “12 hour” or “24 hour”.
Selecting the Date Format
“Settings”
→
“Date & Time”
→
“Date Format”
1. Select from “D.M.Y”, “M-D-Y”, or “Y/M/D”.
Setting the Daylight Saving
“Settings”
→
“Date & Time”
→
“Daylight Saving”
1. Select “On” or “Off”.
(M 9-5)
![](/img.php?id=421073&img=bg60.png)
Settings 95
Setting the Time Zone
“Settings”
→
“Date & Time”
→
“Time Zone”
→
“Change Zone”
1. Press c or d to select the home city to set.
Customising the Time Zone
“Settings”
→
“Date & Time”
→
“Time Zone”
→
“Set
Custom Zone”
1. Enter the time-zone differences using the digit keys.
Pressing P switches between – and +.
Changing the Language
You can change the language that the phone uses to
display messages.
“Settings”
→
“Language”
1. Select the desired language.
Tip
• You can also change the input language on the text
entry screen (p. 25).
Note
• If you select “Automatic” in step 1, the language
preset on the SIM card is selected.
• If the language preset on the SIM card is not
supported, then the default language of the phone is
selected.
Connectivity
By using this menu, you can connect your phone to a
Bluetooth wireless technology enabled device via the
connection, or to a PC via the Infrared connection or a
USB cable.
Using the Bluetooth Wireless Function
To Turn On or Off
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Switch On/Off”
1. Select “On” or “Off”.
If the infrared setting has been activated, you will be
asked whether you wish to deactivate it or not. Press
[Yes].
The Bluetooth wireless setting is activated, and
“ ” is displayed on the stand-by mode screen.
(M 9-6)
(M 9-7)
(M 9-7-1)
96 Settings
To Search for Devices to be Paired
For using the Bluetooth wireless function, you need to
search for other Bluetooth wireless technology enabled
devices to establish contact with your phone. Keep your
phone within a distance of 10 metres before searching.
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Search for Devices”
The phone starts searching for devices within 10
metres.
1. Select the desired device for pairing.
2. Enter the device passcode.
Note
• If the Bluetooth wireless function is off before
searching, the phone turns the Bluetooth wireless
function on automatically and starts searching.
• If the infrared function is active, the confirmation
screen to deactivate the infrared function is
displayed. Press [Yes] to deactivate.
• You can only select one device for pairing. To change
the paired device, see “Paired Devices”.
Paired Devices
You can activate, rename, and delete the paired device
in the list.
To Activate a Device
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Paired Devices”
1. Select the device you wish to activate.
Tip
• You can save battery power by turning the Bluetooth
wireless function off whilst it is not in use. Turn the
Bluetooth wireless function off in “To Turn On or
Off” on page 95 or in “To Turn Off Automatically”.
• During a call, you can divert voice call to the paired
device. Press [Options] and select “Enable
Bluetooth”. If you wish to disconnect the paired
device, select “Disable Bluetooth”.
To Rename a Device
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Paired Devices”
1. Highlight the device you wish to rename.
2. Press [Options] and select “Change Name”.
3. Rename the device.
![](/img.php?id=421073&img=bg62.png)
Settings 97
To Clear a Device Name
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Paired Devices”
1. Highlight the device you wish to clear.
2. Press [Options] and select “Delete”.
Bluetooth Wireless Settings
You can prevent other GX15 phones from recognising
your phone, or turn the Bluetooth wireless function off
automatically to save battery power.
To Show or Hide Your Phone
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Bluetooth Settings”
→
“Visibility”
1. Select the desired visibility settings:
“Show My Phone”: Allows other devices to
recognize your phone.
“Hide My Phone”: Hides your phone from other
devices.
To Turn Off Automatically
“Settings”
→
“Connectivity”
→
“Bluetooth”
→
“Bluetooth Settings”
→
“Bluetooth Time Out”
1. Select the desired time.
Your phone turns the function off automatically for
the specified time.
Using the Infrared Function
To Turn the Infrared Function On or Off (M 9-7-2)
“Settings”
→
“Connectivity”
→
“Infrared”
1. Select “On” or “Off”.
If the Bluetooth wireless function has been
activated, you will be asked whether you wish to
deactivate it or not. Press [Yes].
“ ” will appear on the screen.
The infrared setting will return to off when no data
is transmitted/received via infrared communication.
PC Software
By connecting your phone to a PC, you can transmit
pictures, sounds, video clips, and Contacts List entries.
Follow the procedure to select the connection method
(Bluetooth wireless, USB or Infrared connection). For
details on getting the link software, see page 103.
“Settings”
→
“Connectivity”
→
“PC Software”
1. Select the desired connection type from “Data
Cable”, “Infrared” or “Bluetooth”.
(M 9-7-3)
![](/img.php?id=421073&img=bg63.png)
98 Settings
Network
Network Settings
To Select a Network Automatically
Each time the power is turned on, your phone always
tries to connect to the preferred network.
If your phone is not connected to the network, you can
perform the following immediately to establish the
preferred network connection.
“Settings”
→
“Network”
→
“Select Network”
→
“Automatic”
To Set the Network Manually
“Settings”
→
“Network”
→
“Select Network”
→
“Manual”
1. Select the desired network.
To Add a New Network
“Settings”
→
“Network”
→
“Select Network”
→
“Add New Network”
If there is no entry, press and go to step 2.
If there is an entry, press and perform the following
steps.
1. Select “Add”.
2. Enter the country code.
3. Enter the network code.
4. Enter a new network name.
To Change the Position of a Network in the
Preferred List
“Settings”
→
“Network”
→
“Select Network”
→
“Set
Preferred”
1. Select the name of the network to change the
position in the list.
2. Select “Insert” or “Add to end”.
To Delete a Network from the Preferred List
“Settings”
→
“Network”
→
“Select Network”
→
“Set
Preferred”
1. Select the name of the network you wish to delete.
2. Select “Delete”
WAP/MMS Settings
Note
• In normal operations, you do not need to change
settings.
(M 9-8)
Settings 99
WAP Settings (*: Item to be set as mandatory)
“Profile Name”*: WAP profile name (Unique name)
“IP Address”*: IP address
“Homepage”: Homepage
“Port Number”*: Security option (1024-65535)
“Circuit Prompt” (“Enable” or “Disable”):
Circuit prompt
“Connection Type” (“GPRS Then CSD”, “GPRS” or
“CSD”): Bearer connection type
GPRS Settings: Bearer connection type
“APN”*: Access point name
“Username”: Username
“Password”: Password
“Linger Time”: Linger time (0-99999 sec.)
CSD Settings: Bearer connection type
“Phone No.”*: Access point number
“Line Type”: ISDN or analogue
“Username”: Username
“Password”: Password
“Linger Time”: Linger time (0-99999 sec.)
MMS Settings (*: Item to be set as mandatory)
“Profile Name”*: MMS profile name (Unique name)
“IP Address”*: IP address
“Relay Server URL”*:MMS relay server
“Port Number”*: Security option (1024-65535)
“Connection Type” (“GPRS Then CSD”, “GPRS” or
“CSD”): Bearer connection type
GPRS Settings: Bearer connection type
“APN”*: Access point name
“Username”: Username
“Password”: Password
“Linger Time”: Linger time (0-99999 sec.)
CSD Settings: Bearer connection type
“Phone No.”*: Access point number
“Line Type”: ISDN or analogue
“Username”: Username
“Password”: Password
“Linger Time”: Linger time (0-99999 sec.)
100 Settings
To Activate the WAP/MMS Profile
“Settings”
→
“Network”
1. Select from “WAP Settings” or “MMS Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Activate”.
To Edit the WAP/MMS Profile
“Settings”
→
“Network”
1. Select from “WAP Settings” or “MMS Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Edit”.
4. Edit the desired item and select [Save].
To Copy the WAP/MMS Profile
“Settings”
→
“Network”
1. Select from “WAP Settings” or “MMS Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Copy”.
4. Edit the new profile name.
To Delete the WAP/MMS Profile
“Settings”
→
“Network”
1. Select from “WAP Settings” or “MMS Settings”.
2. Highlight the desired profile.
3. Press [Options] and select “Delete”.
Security
Auto Keypad Lock
By setting this option on, your phone will lock the
keypad in 20 seconds automatically if no operation is
performed.
“Settings”
→
“Security”
→
“Auto Keypad Lock”
1. Select “On” or “Off”.
Enabling/Disabling the PIN Code
If the PIN code is enabled you are asked to enter the
PIN code each time the phone is switched on. Your PIN
code is stored on the SIM card and you should have
been made aware of the code when you purchased the
SIM card. Contact your service provider for further
details.
“Settings”
→
“Security”
→
“PIN Entry”
1. Select “On” to enable the PIN code.
Select “Off” to disable it.
2. Enter your PIN code.
(M 9-9)
(M 9-9-1)
(M 9-9-2)
Settings 101
Note
• If you enter the wrong PIN code three times in step 2,
the SIM card will lock. To remove the lock, contact
your service provider/SIM card vendor.
To Change PIN Code
This allows you to change the PIN code stored on the
SIM card. Before you change the PIN code, select “On”
in step 1 in “Enabling/Disabling the PIN Code”.
“Settings”
→
“Security”
→
“Change PIN”
1. Enter the existing PIN code.
2. Enter new PIN code.
3. Enter the new PIN code again.
Changing PIN2 Code (M 9-9-3)
PIN2 code is used to protect certain functions in the
phone such as Fixed Dialling No. and call cost limits.
The following shows you how to change PIN2 code.
“Settings”
→
“Security”
→
“Change PIN2”
1. Enter the existing PIN2 code.
2. Enter a new PIN2 code.
3. Enter the new PIN2 code again.
Handset Lock
The Handset Lock is an additional security feature
which prevents unauthorised use of the phone or certain
features.
“Settings”
→
“Security”
→
“Handset Lock”
1. Select “On” or “Off”.
2. Enter your handset code.
To Change Handset Code
Before you change the handset code, select “On” in step
1 in “Handset Lock”. The default handset code is
“0000”.
“Settings”
→
“Security”
→
“Handset Lock”
→
“Change code”
1. Enter the old handset code.
2. Enter a new handset code.
3. Enter the new handset code again.
Master Reset
All settings can be reset to their default settings.
“Settings”
→
“Master Reset”
1. Enter your handset code.
(M 9-9-4)
(M 9-0)
![](/img.php?id=421073&img=bg67.png)
102 Connecting GX15 to Your PC
Connecting GX15 to Your PC
You can use the following functions by connecting the
GX15 to your PC using an infrared port, USB port* or
Bluetooth wireless technology:
• GSM/GPRS modem
• Handset Manager for GX15
•Bluetooth wireless connection
* Requires an optional USB data cable XN-1DC30 for
USB port connection.
System Requirements
Operating System: Windows® 98*, Windows® Me,
Windows® 2000**, Windows® XP***
* Windows® 98 Second Edition, Windows® 98
Service Pack 1
** Service Pack 4
***Service Pack 1a
Microsoft® Outlook/Outlook Express
Interface: Infrared port or USB port
CD-ROM drive
GSM/GPRS Modem
You can use GX15 as a GSM/GPRS modem to access
the Internet from your PC. Connect your phone to your
PC via the Infrared connection or a USB cable and
install the necessary software. For details, see
“Software Installation” on page 103.
Modem via the Infrared Connection
To use the modem function via the Infrared connection,
see “Using the Infrared Function” on page 97 and turn
the modem function on.
Modem via the USB Cable
To use the modem function using a USB cable, use the
cable mentioned above and see the instructions
accompanying the cable.
For details on software support, refer to the following
site:
http://www.sharp-mobile.com
Note
• Modem communication is not possible whilst
communicating with the Handset Manager via the
Infrared connection or USB cable.
![](/img.php?id=421073&img=bg68.png)
Connecting GX15 to Your PC 103
Handset Manager
You can transmit the following items between your
phone and your PC, and can use Contacts List entries on
your PC.
• My Items entries
• Contacts List entries
• Short messages
To use the Handset Manager function, see “PC
Software” on page 97 and set your phone to Data
Transfer mode.
For details on software support, refer to the following
site:
http://www.sharp-mobile.com
Software Installation
1. Insert the supplied CD-ROM into your CD-ROM
drive.
The GX15 CD-ROM screen is displayed.
If the GX15 CD-ROM screen is not displayed,
double-click [Launcher.exe] in your CD-ROM.
2. Press the desired button.
The installation starts.
3. Follow the on-screen instructions to complete
installation.
Note
Infrared communication
• Infrared ports need to be aligned with each other.
Infrared port
104 Connecting GX15 to Your PC
• Infrared ports need to be placed within 20 cm of each
other and within a 30° angle.
• It is not recommended that you make or answer a call
during data communication. The operation may be
interrupted.
GSM/GPRS modem
• It is not recommended that you make or answer calls
when you are using GX15 as a GSM/GPRS modem.
The operation may be interrupted.
• When transmitting data via infrared communication,
you need to set the infrared setting to “On”. (p. 97)
Handset Manager
• Some large files may not be able to be transmitted
from the PC to the phone.
• When connecting your phone to a PC, you need to
select the connection method for PC Software. (p. 97)
• The phone may not recognize the USB data cable if it
is connected whilst an application (Camera, My
Items, etc.) is running. Connect the USB data cable
during stand-by.
• Applications (Camera, My Items, etc.) do not run
when the phone is connected to the PC by IrDA or
USB data cable.
![](/img.php?id=421073&img=bg6a.png)
Troubleshooting 105
Troubleshooting
Problem Solution
The phone does not
turn on.
• Make sure the battery is
properly inserted and
charged.
PIN code or PIN2
code is rejected.
• Make sure you have entered
the correct code (4 to 8 digits).
• Your SIM card/protected
functions will become locked
after 3 unsuccessful attempts.
• Contact your SIM provider if
you do not have the correct
PIN code.
The SIM card
becomes locked.
• Enter PUK code (8 digits)
provided by your service
provider (if supported).
• If the attempt is successful,
enter the new PIN code and
confirm your phone is
operational again. Otherwise
contact your dealer.
The display is
difficult to read.
• Adjust the backlight
brightness for the main
display.
Phone functions do
not work after the
phone is turned on.
• Check the radio signal
strength indicator as you may
be outside the service area.
• Check to see if any error
message is displayed when
you turn your phone on. If so,
contact your dealer.
• Make sure the SIM card is
correctly inserted.
Calls cannot be
made or received.
• If the message “SIM card
error” is displayed at start-up,
you cannot use your SIM card
or the SIM card is damaged.
Contact your dealer or
network service provider.
• Check your call barring, fixed
dialling setting, remaining
battery and call forwarding
settings.
• Check if your phone is
currently performing data
communication using Infrared
(IrDA) or a data cable.
• Check the remaining balance
if you are using a pre-paid
SIM card.
Problem Solution
![](/img.php?id=421073&img=bg6b.png)
106 Troubleshooting
Call quality is poor.
• Your current location may not
provide good call quality (i.e.,
in a car or train). Move to a
location where radio signal
strength is greater.
Cannot access
network service.
• Check where your account
has been registered and
where the service is
available.
Cannot send or
receive Text
Message.
• Make sure you are correctly
subscribed for the Short
Message Service, that the
network supports this service,
and that the centre number is
set up correctly. If not, contact
your network service
provider.
Cannot connect to
Multimedia
Message service
provider.
• MMS settings and
configuration may be missing
or incorrect or the network
does not support it. Check
your service provider’s
access point number.
Contact your service provider
to confirm the correct
settings.
Problem Solution
Limited memory
available.
• Delete any unnecessary data.
Call is terminated
unexpectedly.
• Magnetised objects such as
health necklaces placed near
the phone may terminate the
call. Keep your phone away
from such objects.
No entries are
displayed in the
Contacts List
• Confirm that the Contacts
Location setting (Handset or
SIM) and View Groups setting
are made correctly.
Fax transmission
failure
• Before transmitting fax data,
configure your fax software to
use the software flow control.
• Use of the optional data cable
is recommended for
transmitting fax data.
Problem Solution
![](/img.php?id=421073&img=bg6c.png)
Safety Precautions and Conditions of Use 107
Safety Precautions and
Conditions of Use
Your phone conforms to international regulations
insofar as it is used under normal conditions and in
accordance with the following instructions.
CONDITIONS OF USE
Electromagnetic waves
• Do not switch on your phone aboard an aircraft (as
your phone may interfere with the aircraft’s
electronic systems). Current legislation forbids this
use and legal action can be taken against the user.
• Do not switch on your phone in a hospital, except in
designated areas.
• Use of your phone’s function may affect the
performance of medical electronic units
(pacemakers, hearing aids, insulin pumps, etc.).
When the phone function is on, do not bring it near
medical equipment or into areas in which medical
equipment is being used. If you have a hearing aid or
a pacemaker, only use the phone on the opposite side
of your body from where it is located. The phone
should be kept at least 6 inches (15.24 cm) from a
pacemaker ANYTIME the phone is switched on.
• Do not switch on your phone near gas or flammable
substances.
• Observe the rules concerning the use of mobile
phones at gasoline stations, chemical plants and at all
sites where a risk of explosion exists.
Caring for your phone
• Do not allow children to use your phone without
supervision.
• Do not open or attempt to repair your phone yourself.
The product can only be repaired by authorised
service personnel.
• Do not drop your phone or subject it to severe
impacts. Bending the body and pushing the display or
keys with extreme force could damage the phone.
• Do not use solvents to clean your phone. Use only a
soft, dry cloth.
• Do not carry your phone in your back pocket as it
could break when you sit down. The display is made
of glass and is particularly fragile.
• Avoid touching the external connector on the
underside of the phone, since the delicate
components within can be damaged by static
electricity.
![](/img.php?id=421073&img=bg6d.png)
108 Safety Precautions and Conditions of Use
Battery
• Use your phone only with batteries, chargers and
accessories recommended by the manufacturer. The
manufacturer disclaims any liability for damage
caused by the use of other chargers, batteries or
accessories.
•Network configuration and phone usage will
affect talk-time and stand-by time.
Using the games or camera will hasten battery
consumption.
•When the battery charging alert is displayed on
the screen, charge the battery as soon as
possible. If you continue using your phone ignoring
the alert, the phone may cease to function, and all
data and settings you have stored may be lost at any
moment.
• Before removing the battery from the phone, make
sure the phone is switched off.
• Replace and charge the new battery as soon as
possible after removing the old one.
• Do not touch the battery terminals. Batteries can
cause damage, injury or burns if a conductive
material touches exposed terminals. When the battery
is detached from the phone, use a cover made of non-
conductive material for keeping and carrying the
battery safely.
• Recommended temperature for using and storing
batteries is approximately 20°C.
• The batteries’ performance is limited in low
temperatures, particularly below 0°C and the phone
may not work temporarily regardless of the amount
of remaining battery power.
• Exposing the phone to extreme temperatures will
shorten battery life.
• The battery can be charged and discharged hundreds
of times but it will eventually wear out. When the
operating time (talk-time and stand-by time) is
noticeably shorter than normal, it is time to buy a new
battery.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE,
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
See “Battery Disposal” on page 11.
![](/img.php?id=421073&img=bg6e.png)
Safety Precautions and Conditions of Use 109
Aerial Care
• Do not touch the aerial unnecessarily, whilst using
the mobile phone. If it is held, call quality may be
hindered leading to shortened talk-time and stand-by
time because the mobile phone may have to operate
on a higher power level than is necessary.
• Use only the aerial supplied or one approved by
Sharp for your mobile phone. Using unauthorised or
modified aerials may damage the mobile phone.
Moreover, since the mobile phone may violate the
appropriate regulations, it may lose performance or
exceed the limitation of SAR levels.
• To avoid impaired performance, do not damage the
aerial of the mobile phone.
• Whilst talking directly to the microphone, please
hold the mobile phone so that the aerial is upwards
over your shoulder.
• To avoid interfering with blasting operations, please
turn off the mobile phone in a blasting area or in a
place where a “turn off two-way radio” sign is
posted.
Camera Operation
• Learn picture quality, file formats, etc. beforehand.
The taken pictures can be saved in JPEG format.
• Be careful not to move your hand whilst taking
pictures.
If the phone moves whilst taking a picture, the picture
can be blurred. When taking a picture, hold the phone
firmly to prevent it from moving, or use the delay
timer.
• Clean the lens cover before taking a picture.
Fingerprints, oils, etc. on the lens cover hinder clear
focusing. Wipe them off with a soft cloth before
taking a picture.
Others
• As with any electronic storage unit, data may be lost
or corrupted under various circumstances.
• Before connecting the phone with a PC or a
peripheral unit, read the operation manual for the
other unit carefully.
• If the phone’s battery has been removed for some
time, or the phone has been reset, the unit’s clock and
calendar may be reinitialised. The date and time
should be updated in this case.
• Use only the specified handsfree kit (option). Some
phone’s functions may not work when unauthorised
handsfree kit is used.
110 Safety Precautions and Conditions of Use
ENVIRONMENT
• Keep your phone away from extreme heat. Do not
leave it on the dashboard of a car or near a heater. Do
not leave it in any place that is extremely damp or
dusty.
• Since this product is not waterproof, do not use it or
store it where fluids such as water can splash onto it.
Raindrops, water spray, juice, coffee, steam,
perspiration, etc. will also cause a malfunction.
PRECAUTIONS CONCERNING
VEHICLE USE
• It is the user’s responsibility to check the local laws
governing the use of a mobile phone in vehicles. Pay
full attention to driving. Pull off to the side of the
road, park the car, and switch off the engine before
making or answering a call.
• Use of your phone’s function may interfere with the
vehicle’s electronic systems, such as the ABS anti-
lock brakes or the air-bag. To ensure no such problem
occurs, please check with your dealer or car
manufacturer before connecting your phone.
• Only allow qualified service maintenance personnel
to install the vehicle accessories.
The manufacturer disclaims any liability for damage
which may result as a consequence of improper use or
use contrary to the instructions contained herein.
![](/img.php?id=421073&img=bg70.png)
Safety Precautions and Conditions of Use 111
SAR
Your Sharp mobile phone has been designed,
manufactured and tested so as not to exceed the limits
for exposure to electromagnetic fields recommended by
the Council of the European Union. These limits are
part of comprehensive guidelines developed by
independent scientific organisations. The guidelines
include a substantial safety margin designed to assure
the safety of the phone user and others and to take into
account variations in age and health, individual
sensitivities and environmental conditions. European
standards provide for the amount of radio frequency
electromagnetic energy absorbed by the body when
using a mobile phone to be measured by reference to
the Specific Absorption Rate (SAR). The SAR limit for
the general public is currently 2 watts per kilogram
averaged over 10 grams of body tissue. Your Sharp
mobile phone SAR value is x.xxx watts per kilogram.
This has been tested to ensure that this limit is not
exceeded even when the phone is operating at its
highest certified power. In use however your Sharp
mobile phone may operate at less than full power
because it is designed to use only sufficient power to
communicate with the network.
PRECAUTIONS FOR USE IN USA
FCC Declaration of Conformity
This mobile phone GX15 with PC/Data interface cable
XN-1DC30 complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Responsible Party:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430
TEL: 1-800-BE-SHARP
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
![](/img.php?id=421073&img=bg71.png)
112 Safety Precautions and Conditions of Use
Information To User
This equipment has been tested and found to comply
with the limits of a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation; if this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Changes or modifications not expressly
approved by the manufacturer responsible for
compliance could void the user’s authority to operate
the equipment.
Exposure to Radio Waves
THIS MODEL PHONE MEETS THE
GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications
Commission of the U.S. Government. These limits are
part of comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on standards that
were developed by independent scientific organizations
through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the
FCC is 1.6W/kg.* Tests for SAR are conducted using
standard operating positions specified by the FCC with
Safety Precautions and Conditions of Use 113
the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR
is determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels so
as to use only the power required to reach the network.
In general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a phone model is available for sale to the public,
it must be tested and certified to the FCC that it does not
exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed
in positions and locations (e.g., at the ear and worn on
the body) as required by the FCC for each model. The
highest SAR value for this model phone when tested for
use at the ear is 0.352 W/kg and when worn on the
body, as described in this user guide, is 0.544 W/kg.
Body-worn Operation; This device was tested for
typical body-worn operations with the back of the
phone kept 1.5 cm from the body. To maintain
compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5 cm separation distance
between the user's body and the back of the phone. The
use of belt-clips, holsters and similar accessories should
not contain metallic components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure
requirements, and should be avoided. While there may
be differences between the SAR levels of various
phones and at various positions, they all meet the
government requirement for safe exposure.
The FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after
searching on FCC ID APYHRO00035.
Additional information on Specific Absorption Rates
(SAR) can be found on the Cellular
Telecommunications & Internet Association (CTIA)
web-site at http://www.phonefacts.net.
* In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6 watts/kg (W/
kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account for
any variations in measurements.
![](/img.php?id=421073&img=bg73.png)
114 Index
Index
A
Accessories 7
Alarms 70
Any Key Answer 88
Auto Keypad Lock 100
B
Battery 10
Bluetooth wireless function 95
C
Calculator 71
Calendar 78
Call Costs 83
Call functions 18
Answering 19
Earpiece volume 20
Holding 21
Letting the caller know you are
unavailable 20
Making 18
Making another call during a
call 21
Muting 23
Putting on hold 21
Redialling 19
Rejecting 20
Speed dialling 18
Call Log 81
Call settings 91
Auto Redial 94
Call Waiting 92
Fixed Dialling No. 93
Minute Minder 94
Network password 94
Resetting 94
Restrict Calls 92
Show Your Number 92
Call Timers 82
Call Waiting 21, 92
Cell Broadcasts 51
Centre key 8
Centre key/Navigation keys 15
Conference Call 22
Contacts List 29
Changing the list 29
Creating 30
Dialling 31
Editing 32
Finding 31
Memory status 33
Receiving 34
Sending 34
D
Date & Time 94
Digital camera 35
Display indicators 15
Display language 95
Display settings 88
Diverts 91
E
Earpiece volume 20
Emergency calls 18
H
Handset code 101
Handset Lock 101
I
Infrared function 97
Infrared port 9
Input languages 25
Input method 25
International calls 18
J
Java™ applications 65
Index 115
K
Keypad Lock 14
L
Left soft key 8
M
Master Reset 101
Melody Editor 73
Memory status 64
Menu and shortcut 27
Multimedia message 43
Confirming arrival of delivery
report 46
Creating 43
Inserting attached data 45
Reading 45
Retrieving 46
Setting up 46
Storing the phone number or
e-mail address of a sender
in the Contacts List 46
Turning the slide show setting
on or off 44
My Numbers (Voice/Data/Fax) 82
N
Navigation keys 8
Network settings 98
Adding a new network 98
Changing the position of a
network in the Preferred
List 98
Deleting a network from the
Preferred List 98
Selecting a network
automatically 98
P
PC connection 102
PC Software 97
Phone Help 77
Phone settings
Assigning pictures 89
Brightness of backlight 90
Changing language 95
Display saving 90
Greeting message 89
Resetting 90
Picture file 57
PIN code 100
PIN2 code 101
Power on and off 13
Profiles
Activating 84
Any Key Answer 88
Customising 84
Echo reduction 88
Keypad tones 87
Resetting 84
Ringer volume 84
Vibration 85
R
Right soft key 9
S
Screensavers 66
Security 100
Auto Keypad Lock 100
Changing handset code 101
Changing PIN code 101
Changing PIN2 code 101
Enabling/Disabling PIN code
100
Fixed Dialling No. 93
Handset Lock 101
Self-portrait mirror 36
SIM Application 70
SIM card 10
Sound file 60
Sound settings
Message Alert 86
Power Off Sound 87
