Contents

User Manual 2 of 2

19-28
Abridged English Manual
19
Save names with phone numbers, mail addresses, etc. to Phone Book.
1
Not supported on USIM Card.
2
Image may not appear while an S! Application is active, etc.
,
Save up to 750 entries in handset Phone Book; USIM Card Phone Book entry limit varies according to card specifications.
Depending on the USIM Card in use, some items may not be supported, and character entry limits or number of Categories may
be lower. Also, the number of phone numbers or mail addresses per entry may be lower.
Saving to Phone Book
Phone Book Entry Items
Item Description
Last Name:
Enter up to 32 characters. (Select
Name:
when
saving to USIM Card.)
First Name:
Reading:
Enter up to 64 characters
Add Phone
Number:
Enter up to three numbers on handset/two on
USIM Card (32 digits each)
Add Email
Address:
Enter up to three addresses on handset/one on
USIM Card (128 single-byte alphanumerics each)
Category:
Sort entries into 16 Categories (11 on some USIM
Cards). Category names can be changed. Set
ringtone/ringvideo, Mobile Light and Vibration
by Category (handset only).
Address:
1
Enter postal code (20 characters), country
name (32 characters), state/province
(64 characters), city name (64 characters)
and street name/number (64 characters)
Homepage:
1
Save URLs. Enter up to
1,024 bytes.
Item Description
Note:
1
Add personal details. Enter
up to 256 characters.
Birthday:
1
Enter birth date
Picture:
1, 2
Set an image to appear for
incoming calls/mail
Tone/Video for Voice Call:
1
Set ringtone/ringvideo,
Mobile Light or Vibration by
caller/sender
Tone/Video for Video Call:
1
Tone/Video for New Message:
1
Light for Voice Call:
1
Light for Video Call:
1
Light for New Message:
1
Vibration for Incoming Call:
1
Vibration for New Message:
1
Secret:
1
Restrict access to Phone
Book entries by saving them
as Secret Mode entries
Note
X
Back-up Important Information
When battery is exhausted/removed for long periods, Phone Book entries may be lost; handset damage may also affect
handset information recovery. SoftBank is not liable for damages from lost/altered data.
J410_insatsu.book 28 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-29
Abridged English Manual
19
Enter a name, reading, phone number and mail
address.
1
Press
%
, select
Phone
and press
%
2
Select
Add New Entry
and press
%
3
Select
Last Name:
and press
%
4
Enter last name and press
%
5
Select
First Name:
and press
%
6
Enter first name and press
%
Characters entered for names
appear under
Reading:
.
7
Select
Add Phone Number:
and press
%
8
Enter a phone number and press
%
9
Select an icon and press
%
11
1100
00 Select
Add Email Address:
and press %
11
1111
11 Enter a mail address and press %
11
1122
22 Press %
11
1133
33 Select an icon and press %
11
1144
44 Press A ß
1
Press
b
and select an entry
2
Press
B
ø
3
Select
Edit
and press
%
4
Select an item and press
%
5
Edit contents and press
%
After numbers/mail addresses, select an icon and
press
%
.
6
Press
A
ß
Creating Phone Book Entries
Tip
X
Correcting Reading
Select
Reading:
and press
%
.
Make corrections and press
%
.
Note
X
To save an entry, enter at least one of the following:
a) last name; b) first name; c) phone number; or
d) mail address.
Tip
X
Setting Default Storage Media
Press
%
S
Select
Phone
S
Press
%
S
Select
Ph.Book Settings
S
Press
%
S
Select
Save New
Entry
S
Press
%
S
Select
Phone
,
USIM Memory
or
Ask Each Time
S
Press
%
.
For
Ask Each Time
, select storage media for
each new entry.
Editing Phone Book Entries
J410_insatsu.book 29 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-30
Abridged English Manual
19
1
Select a record (see
P.19-23
"Calling from
Received Calls")
2
Press
B
ø
, select
Save Number
and
press
%
3
New Entry
1
Select
As New Entry
and press
%
2
Perform Steps 3 - 13 on
P.19-29
Add to Existing Entry
1
Select a Phone Book entry and press
%
2
Press
A
ß
1
Press
%
, select
Phone
and press
%
2
Select
Ph.Book Settings
and press
%
3
Select
Sort Entries
and press
%
4Select
By Reading
,
By Category
or
By a-ka-sa-
ta-na
and press %
1Set search method to
By Reading
2In Standby, press b
3Enter reading
4Select a name and press %
5Press !
Back up Phone Book via server; refresh SAB or
Phone Book to reflect changes; add to/update SAB
online via PC; restore lost/altered Phone Book entries
via SAB. SAB requires a separate contract. For
details, contact SoftBank Customer Centre, General
Information (see P.19-48) or access the SOFTBANK
MOBILE Corp. Website via PC:
http://www.softbank.jp
Saving from Received Calls
Dialling from Phone Book
Changing Search Method
By Reading Shows entries that start with specified
Reading
By Category Opens entries in the specified Category
By a-ka-sa-ta-na Shows entries with Readings that start
with katakana in the specified row
Tip XSwitching Between Handset & USIM Card
Press b S Press B ø S Select
Ph.Book
Settings
S Press % S Select
Select Phone Book
S Press % SSelect
Phone
,
USIM Memory
or
Both
S Press %
.For
Both
, entries in both storage media appear.
Search by Reading
Tip XMultiple Numbers
Use e to select other numbers.
S! Address Book (SAB)
J410_insatsu.book 30 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-31
Abridged English Manual
19
Select from two different shooting modes. Use Photo
Camera for still images and Video Camera for video.
■
Photo Camera
■
Video Camera
*MPEG-4 (.3gp) only for W 240
×
H 176 dots.
Camera Shake
Handset movement may blur images; hold handset firmly or
place it on a stable surface and use Self-timer.
1
Press
%
, select
Camera
and press
%
2
Frame image on Display
.
In Video Camera mode, press
A
(
#
) to switch to
Photo Camera.
3
Press
%
4
Press
%
to save
5
Press
"
to exit
Mobile Camera
Before Using Camera
Image Size
W 1200
×
H 1600 dots
W 960
×
H 1280 dots
W 480
×
H 640 dots
W 240
×
H 320 dots
W 120
×
H 160 dots
File Format
JPEG (.jpg)
Save Location
Handset or Memory Card
Image Size
W 176
×
H 144 dots
W 128
×
H 96 dots
W 480
×
H 640 dots
W 240
×
H 320 dots
W 240
×
H 176 dots*
File Format
MPEG-4 or
H.263 (.3gp)
MPEG-4
(.3gp)
MPEG-4
(.ASF)
Save Location
Handset or Memory Card
Memory
Card
Note
X
Lens Cover
Clean dust/smudges from lens cover (see
P.19-13
p
) with a soft cloth before use.
Mobile Camera
.
Mobile camera is a precision instrument, however,
some pixels may appear brighter/darker.
.
Shooting/saving images while handset is hot may
affect the image quality.
.
Subjecting the lens to direct sunlight will damage
the camera's colour filter.
Capturing Still Images
J410_insatsu.book 31 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-32
Abridged English Manual
19
Handset files are organised in folders by file format.
1
Press
%
, select
Data Folder
and press
%
2
Select a folder and press
%
.
To switch between handset and Memory Card, press
B
ø
, select
Change to
Phone
or
Change to
Memory Card
, then press
%
.
3
Select a file and press
%
4
Press
$
to return to file list
Example: Attaching an image from Pictures folder
to S! Mail
1
Press
%
, select
Data Folder
and press
%
2
Select
Pictures
and press
%
3
Select a file and press
B ø
4Select
Send
and press %
5Select
As Message
and press %
6Complete other fields and send S! Mail
(perform from Step 3 on P.19-36)
Data Folder
Contents
Data Folder
Ring Songs•Tones
S! Appli
My Pictograms
Videos
Lifestyle-appli
Music
Books
Custom Screens
Flash®
Flash
®
Ringtones
Other Documents
Pictures
DCIM
Still Images Large Still Images
on Memory Card
Downloaded
Pictograms
Shortcut to
S! Applications
Video Images
Downloaded
E-Books, etc.
Downloaded
Flash® Files
Other Files (vFiles,
Dictionary Files, etc.)
Downloaded
Melodies and other
Sound Files
Downloaded
Chaku-Uta Full®
Files
Downloaded
Lifestyle-Appli
Shortcut to
Custom Screens
Downloaded
Flash® Ringtones
Opening Data Folder
S! Mail Attachments
J410_insatsu.book 32 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-33
Abridged English Manual
19
To use Messaging, Internet and other Network-
related services, first retrieve Network information.
Handset initiates information retrieval when
B
,
A
or
%
is pressed for the first time. If handset is in
Japanese mode, select
いいえ
and press
%
, then
change to English mode (see
P.19-21
).
1
Press
B
,
A
or
%
2
Choose
Yes
and press
%
Handset connects to the Network and retrieves
required information.
Access Yahoo! Keitai Mobile Internet and PC sites.
Access compatible Mobile Internet sites via Yahoo!
Keitai Main Menu; download news/info as well as
files for use on handset.
Activate PC Site Browser to view websites designed
for PCs; only document files are downloadable and
browsing PC sites may incur higher charges.
1
Press
%
, select
Yahoo! Keitai
and press
%
2
Select
Yahoo! Keitai
and press
%
3
Select
English
and press
%
4
Highlight a menu item and press
%
5
Repeat Step 4 to open additional links
6
To exit, press
"
, choose
Yes
and press
%
Network Information
Retrieving Network Information
Yahoo! Keitai
Yahoo! Keitai
PC Sites
Opening Yahoo! Keitai Menu
Note
X
Yahoo! Keitai Main Menu is subject to change.
J410_insatsu.book 33 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-34
Abridged English Manual
19
Open a page and press
B
ø
to use the following
functions. Use SoftBank text communication services in Japan
and overseas. Exchange text/multimedia messages
with compatible handsets, PCs and other devices.
Use this basic messaging service to exchange short
text messages of up to 160 alphanumerics with
SoftBank handsets. This service is the ideal solution
for fast and short text messaging!
Exchange text messages of up to 30,000 characters
with e-mail compatible SoftBank handsets, other
mobiles and PCs, etc. Attach image/sound files.
Yahoo! Keitai Options Menu
Item Description
Bookmark
Save new site links, access saved links
(requires Network connection) or edit list
Saved Pages
Save page content; handset opens saved
pages without connecting to the Network
Copy Text
Copy text
Reload
Update page content
Enter URL
Enter URL directly to access sites
Save Items
Save images, sounds, etc. to Data Folder
Convenient
function
Send URL via SMS/S! Mail, open
properties, search within site, etc.
Change to
PC Browser
Activate PC Site Browser
History
Previously visited site links
Yahoo! Keitai
Return to Yahoo! Keitai Main Menu
Setting
Set font size, scroll unit, download
parameters; select cookie acceptance;
customise pointer settings, etc.
Open by
New Tab/
Tab Menu
Open link in new tab; switch/close tabs or
open another via Tab Menu
Help
View a summary of key assignments
Exit
Exit Yahoo! Keitai
Messaging
SMS
S! Mail
Note
X
Handset is incompatible with Greeting, Coordinator,
Relay Mail, Hotline and Polling service messages.
Tip
X
.
An additional contract is required to use S! Mail
and receive e-mail from PCs, etc.
.
The Centre resends undeliverable messages at
regular intervals until delivered. Messages not
received by specified expiry are deleted.
J410_insatsu.book 34 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-35
Abridged English Manual
19
1
Press
%
, select
Messaging
and press
%
2
Select
Received Msg.
,
Drafts
,
Templates
,
Sent
Messages
or
Unsent Messages
and press
%
3
Select a message and press
%
1
Select a draft, sent or unsent message and press
B
ø
2
Select
Edit & Send
or
Edit
and press
%
3
Edit the message
Change alphanumerics before @ of the default
handset mail address. Customising handset mail
address helps reduce spam.
1
Press
%
, select
Messaging
and press
%
2
Select
Settings
and press
%
3Select
Address Setting
and press %
Handset connects to the Network.
4Select
English
and press %
Follow onscreen instructions.
Opening Messages
Editing Messages
Customising Handset Address
Note XThis procedure may change without prior notice.
For further information, contact SoftBank Customer
Centre, General Information (see P.19-48).
J410_insatsu.book 35 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-36
Abridged English Manual
19
Press
%
, select
Messaging
and press
%
to open
Messaging menu.
1
Press
%
, select
Messaging
and press
%
2
Select
Create Message
(for
S! Mail) or
Create New SMS
and
press
%
3
Select recipient field and press
%
4
Enter a recipient
Phone Book
1
Select
Phone Book
and
press
%
2
Select a recipient and press
%
.
When multiple items are saved,
select one and press
%
.
Contact Groups
1
Select
Select Group
and press
%
2
Select a Group and press
%
.
Press
$ to return. Omit this step when only one
member is saved.
Sent Mail Records
1Select a recipient and press %
Speed Mail List
1Select
Speed Mail List
and press %
2Select a recipient and press %
Messaging Menu
Item Description
Received Msg. List of received messages
Create Message Create and send new message
Retrieve New Msg. Receive newly arrived messages
Drafts List of incomplete/unsent messages
Templates Created or downloaded Arrange Mail
messages
Sent Messages List of sent messages
Unsent Messages Undelivered/cancelled/failed mail
Server Mail Box Request Centre message list and then
select messages to retrieve
Create New SMS Compose SMS messages
Settings
Customise SMS/S! Mail settings, sort
messages into folders or save
frequently used numbers/addresses to
Speed Mail List to send from Standby
Memory Status Memory usage of Messaging Folders
(except Templates)
Sending Text Messages
Mail Composition
Window
(S! Mail)
J410_insatsu.book 36 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-37
Abridged English Manual
19
Direct Entry
1
Select
Enter Number
or
Enter Address
and
press
%
.
Enter Address
is not available for SMS.
2
Enter recipient's SoftBank handset number or
mail address and press
%
5
Enter subject and press
%
(S! Mail only)
6
Select
X
and press
%
then enter a message
.
For SMS, press
%
or a key then enter a message.
7
Press
%
8
Attach files (S! Mail only)
Use
f
to select
x
and press
%
Image Files
1
Select
and press
%
2
Select a folder and press
%
3Select a file and press %
Melody Files
1Select
Sound
and press %
2Select a folder and press %
3Select a file and press %
Video Files
1Select
Video
and press %
2Select
Saved Videos
and press %
3Select a file and press %
9When finished, press A S to send
Delivery Notice appears and Information window
opens (z appears) for new mail. Press % to open
Received Msg. folder.
1Press %, select
Messaging
and press %
2Select
Received Msg.
and press %
3Select a message and press %
Centre sends initial portion of S! Mail message when:
.The message was sent to multiple recipients
.Files are attached to the message
1Perform Steps 1 - 2 above
2Select a message with L and press %
3Press A m
Incoming Text Messages
Receiving Messages
Opening Received Text Messages
Retrieving Complete S! Mail Messages
J410_insatsu.book 37 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-38
Abridged English Manual
19
1
Open a received message (see
P.19-37
)
2
Press
B
ø
3
Select
Reply
or
Reply All
and press
%
4
Replying to SoftBank Handset
1
To send as SMS, select
Reply (SMS)
or
Reply
with Hist. (SMS)
and press
%
2
To send as S! Mail, select
Reply (S! Mail)
or
Reply with Hist. (S!)
and press
%
Replying to E-mail
1
Select
Reply (S! Mail)
or
Reply with Hist. (S!)
and press
%
.
Select
Reply with Hist. (SMS)
or
Reply with Hist.
(S!)
to quote the original message text.
5
Complete and send message (perform from Step
5 or 6 on
P.19-37
)
1
Open a received message (see
P.19-37
)
2Press B ø
3Select
Forward
and press %
.To forward SMS, then select
S! Mail
or
SMS
and
press %.
4Enter a recipient (see P.19-36) and press %
5Press A S
Enjoy a variety of compatible S! Applications.
.Download S! Applications via Yahoo! Keitai.
.Enjoy network gaming or access real-time news/info.
.Set an S! Application that activates in Standby.
Press %, select
S! Appli
and press % to open
S! Appli menu.
1Press %, select
S! Appli
and press %
2Select
S! Appli
and press %
3Select
Download
and press %
4Open a Mobile Internet site offering
S! Applications
5Select an S! Application and press %
6Press %
Downloaded S! Application is automatically saved and
a confirmation appears.
7Choose
Yes
and press %
Replying & Forwarding
Replying to Messages
Forwarding Messages
S! Appli
S! Appli Menu
Item Description
S! Appli Download, start or delete S! Applications
Settings Adjust S! Application settings
Information Open Java™ and JBlend™ licence information
Downloading S! Applications
J410_insatsu.book 38 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-39
Abridged English Manual
19
S! FeliCa
encompasses a range of IC Card-based
services available via FeliCa-compatible SoftBank
handsets. Handset supports S! FeliCa. To use
services such as e-money, e-ticketing and reward
point systems, simply hold handset over a compatible
reader/writer at a shop or restaurant, etc.
S! FeliCa (Japanese Only)
Basics
FeliCa
■
A contactless IC card technology enabling wireless data
transmissions with compatible reader/writer terminals
IC Card
■
The FeliCa chip embedded in FeliCa-compatible handsets
■
Holds information required to use S! FeliCa
Lifestyle-Appli
■
S! Applications required to use S! FeliCa
.
Edy e-money Lifestyle-Appli is preloaded on handset.
,
Edy is a prepaid e-money service run by bitWallet Inc.
Note
X
IC Card data content varies by service and usage
history. Procedures to delete IC Card data vary by
Lifestyle-Appli; contact service providers for details.
Service Usage Outline
Download Lifestyle-Appli
Download Lifestyle-Appli via Mobile Internet site.
.
Lifestyle-Appli is saved to Lifestyle-appli folder.
V
Complete Registration/Set Up
Activate Lifestyle-Appli, complete registration/customise
settings.
.
Charge accounts, check balance or payment records, etc.
V
Use Service
To use S! FeliCa at shops, restaurants, and locations, place
m
logo over reader/writer.
.
Use e-money/e-tickets to shop/travel; earn reward points.
Note
X
.
Lifestyle-Appli registration and usage vary;
contact the service provider for details.
.
SoftBank is not liable for damages resulting from
accidental loss/alteration of IC Card data/settings.
.
Keep service passwords/customer service
contact information, etc. in a separate place.
J410_insatsu.book 39 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-40
Abridged English Manual
19
To use S! FeliCa, activate a service Lifestyle-Appli
and complete service registration, setup, charge,
balance check, etc.
1
Select
Lifestyle-appli
and press
%
■ To download a Lifestyle-Appli, select
Download
S
Press
%
2
Select an application and press
%
Lifestyle-Appli starts.
■ To end the Lifestyle-Appli, press
"
.
Follow these steps to conduct a transaction.
Example: making an electronic payment:
.
Complete registration, setup and charge in advance.
.
Complete transactions without activating a Lifestyle-Appli.
1
Place
m
logo over reader/writer
.
Confirm scan results on reader/writer display.
.
If recognition is slow, move handset around slightly.
Starting Lifestyle-Appli
Main Menu
X
Lifestyle-appli
Note
X
Lifestyle-Appli cannot be started during calls or
when another S! Application is active.
Tip
X
Lifestyle-Appli settings and usage patterns resemble
those of other S! Applications (see
P.19-38
).
However, Lifestyle-Appli cannot be set as
Screensaver.
Using S! FeliCa
Note
X
.
Align handset parallel to reader/writer.
.
Foreign articles can block/hamper recognition.
Tip
X
.
When placed over sensor, handset may display a
message, vibrate or activate mail, Internet or an
S! Application for some services.
.
Reader/writer will scan FeliCa IC Card even
during calls or Internet transmissions. (It may take
some time.)
Place this part
over reader/writer
J410_insatsu.book 40 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-41
Abridged English Manual
19
Use this function to restrict access to/prevent
unauthorised use of S! FeliCa on handset.
IC Card Lock is
Off
by default.
1
Choose
On
and press
%
■ To cancel, choose
Off
S
Press
%
2
Enter Handset Code and press
%
3
To activate IC Card Lock, choose
Yes
and press
%
Subscribe to Japanese mobile periodicals that
download to handset automatically overnight.
.
A separate subscription and registration are required.
.
Only available within Japan on compatible 3G handsets.
.
Retrieve Network information (see
P.19-33
) beforehand.
1
Press
%
, select
Entertainment
and press
%
2
Select
CAST
and press
%
3
Select
Join/Cancel Service
and press
%
Handset
connects to the Network and service
registration page opens. Follow onscreen instructions.
1
Delivery Notice appears and Information window
opens (
E
appears) for new information
2
Select
CAST
and press
%
Follow onscreen instructions.
3
Press
"
to exit
When Handset Power is Off
■
Transactions possible; Lifestyle-Appli does not start
automatically.
.
After installing/reinstalling battery, always turn on
handset power to use S! FeliCa.
When Battery is Low
■
S! FeliCa is not available. Charge it beforehand.
IC Card Lock
Main Menu
X
Lifestyle-appli
S
IC Card Settings
S
IC Card Lock
Tip
X
For more information on S! FeliCa settings, please
see the full English manual.
S! Cast (Japanese Only)
Service Registration & Content Subscription
Note
X
Registration and subscription require Mobile
Internet use (connection fees apply). Confirm signal
strength beforehand.
Newly Arrived Information
J410_insatsu.book 41 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-42
Abridged English Manual
19
S! Town is an online communication application.
Select an avatar to enter this 3D virtual town, where
you can participate in events and meet other users.
.
Usage requires the pre-installed S! Town S! Application.
.
S! Town S! Application cannot be deleted.
.
Network connection is required; may incur high charges.
When using S! Town for the first time, agree to the
terms of service then complete free user registration.
1
Press
%
, select
Communication
and press
%
2
Select
S! Town
and press
%
S! Town starts.
.
For operations, read the instructions on the
application.
S! Loop is a communication service.
1
Press
%
, select
Communication
and press
%
2
Select
S! Loop
and press
%
Handset connects to the Network and S! Loop Main
Menu opens.
.
For operations, read the S! Loop instructions.
Exchange real-time text messages wirelessly with
compatible Bluetooth
®
devices within ten metres.
.
Because this application employs Bluetooth
®
wireless
technology transmission/connection fees do not apply.
.
Usage requires the pre-installed Near Chat S! Application.
S! Town (Japanese Only)
Using S! Town
S! Loop (Japanese Only)
Near Chat (Japanese Only)
Note
X
.
Near Chat range may vary by ambient conditions.
.Near Chat S! Application cannot be deleted.
J410_insatsu.book 42 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-43
Abridged English Manual
19
Check for firmware updates and download as required.
.
Choose to begin update or schedule update.
.
Handset is disabled until update is complete. Update
may take up to approximately 30 minutes.
.
Connection fees do not apply to updates (including
checking for updates, downloading and rewriting).
.
Keep handset in a place where signal is strong and stable.
.
Charge battery (
l
appears) beforehand; a low battery
may cause update to fail.
.
Do not remove battery during update; update may fail.
.
To reduce risk of failure, disconnect USB Cable from
handset beforehand.
Read previous Software Update Precautions (left)
beforehand.
1
Select
Software Update
and
press
%
Confirmation appears.
.
Follow onscreen instructions.
(
A
appears during update.)
.
Update may take up to
approximately 30 minutes.
.
Confirmation appears and
Information window opens
(
B
appears) for successful update.
■ While confirmation appears, press
%
to acknowledge update
completion and cancel Information
window.
Software Update
Precautions
Before updating software, turn power off to end all
active functions/applications, then restart handset.
Updating Software
Main Menu
X
Settings
S
Phone Settings (
f
)
S
Software Update
Confirmation
Update Complete
J410_insatsu.book 43 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-44
Abridged English Manual
19
Note
X
Update failure may disable
handset. Contact SoftBank
Customer Centre, Customer
Assistance (see
P.19-48
).
Update Result
■
While Information window appears,
select
Update Result
S
Press
%
,
Press
%
again to exit.
■
In Standby, press
%
S
Select
Settings
S
Press
%
S
Use
f
to
select
Phone Settings
S
Select
Software Update
S
Press
%
S
Select
Update Result
S
Press
%
,
Press
%
again to exit.
Update Failure
Update Result
Scheduled Update
■
Confirmation appears at scheduled
update time. Press
%
or wait about
ten seconds for update to start.
.
Update will not start while handset is
in use. When the current operation
ends, confirmation appears. After
ten minutes, scheduled update is
automatically cancelled.
.
Update automatically cancels
Keypad Lock.
Note
X
.
Handset Phone Book entries, media files, and
other content are not affected by firmware
updates, but users should always back-up
important information (note that some files cannot
be copied). SoftBank is not liable for damages
from lost information, etc.
.
If handset does not return to Standby after update,
turn power off, reinsert battery, then restart
handset.
Confirmation
J410_insatsu.book 44 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-45
Abridged English Manual
19
Function List
Main Menu Sub Menu
Communication
S! Town
S! Loop
Near chat
Yahoo! Keitai
Yahoo! Keitai
Bookmarks
Saved Pages
Enter URL
History
Live Monitor
PC Site Browser
Common Settings
Media Player
Music
Videos
Streaming
Messaging
Received Msg.
Create Message
Retrieve New Msg.
Drafts
Templates
Sent Messages
Unsent Messages
Server Mail Box
Create New SMS
Settings
Memory Status
Camera −
Data Folder
Pictures
DCIM
My Pictograms
Ring Songs
•
Tones
S! Appli
Music
Videos
Lifestyle-appli
Books
Custom Screens
Flash
®
Flash
®
Ringtones
Other Documents
Memory Status
Tools
Tools 1
Calendar
Alarms
Calculator
Tasks
World Clock
Tools 2
Voice Recorder
Document Viewer
Stopwatch
Countdown Timer
Tools 3
Expenses Memo
Text Templates
Barcode
Phone Help
Entertainment
ComicSurfing
E-Book
CAST
S! Appli
S! Appli
Settings
Information
Lifestyle-appli
Lifestyle-appli
IC Card Settings
Phone
Phone Book List
Add New Entry
Information
Call Log
Play Messages
Call Voicemail
Category Control
My Details
Speed Dial List
Contact Groups
S! Address Book
Ph.Book Settings
Manage Entries
Service Dial No.
Main Menu Sub Menu
Settings
Phone
Settings
Mode Settings
Display
Custom Screens
Sounds & Alerts
Date & Time
言語選択
(Language)
User Dictionary
Ringer Output
Earpiece Volume
Simple Menu
Locks
Software Update
Master Reset
Connectivity
Bluetooth
Infrared/IrSS
Mass Storage
Memory Card
Call/Video Call
Call Time & Cost
Answer Phone
Voicemail/Divert
Video Call
Show My Number
~
Missed Calls
Int'l Calling
Disp. Time/Call
Call Barring
Minute Minder
Auto Answer
Call Waiting
Network
Settings
Select Network
Select Service
Offline Mode
Retrieve NW Info
Location Info
Network Info
Main Menu Sub Menu
J410_insatsu.book 45 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-46
Abridged English Manual
19
■ 810SH
.
Values above were calculated with battery installed.
.
Continuous Talk Time is an average measured with a
new, fully charged battery, with stable signals.
Continuous Talk Time may be less than half this value if
signal is weak.
■ 811SH
.
Values above were calculated with battery installed.
.
Continuous Standby Time is an average measured with a
new, fully charged battery, with handset closed without
calls or operations, in Standby with stable signals.
Standby Time may be less than half this value if handset
is out-of-range/signal is weak. Standby Time may vary
by environment (battery status, ambient temperature,
etc.).
Specifications
Weight
Approximately 117
g
(with battery)
Continuous
Talk Time
Approximately ●●
minutes (3G)
Approximately ●●
minutes (GSM)
Continuous
Standby Time
(handset closed)
Approximately ●●
hours (3G)
Approximately ●●
hours (GSM)
Video Call
Continuous
Talk Time
Approximately ●●
minutes
(with Internal Camera in use)
Approximately ●●
minutes
(with External Camera in use)
Charging Time
(power off)
AC Charger: Approximately ●●
minutes
In-Car Charger: Approximately
●●
minutes
Dimensions
(W
×
H
×
D)
Approximately 49.8
×
100
×
21.3 mm
(handset closed, 21.3 mm at thickest point)
Maximum Output
0.25 W (3G)
2.0 W (GSM)
Weight
Approximately 117
g
(with battery)
Continuous
Talk Time
Approximately ●●
minutes (3G)
Approximately ●●
minutes (GSM)
Continuous
Standby Time
(handset closed)
Approximately ●●
hours (3G)
Approximately ●●
hours (GSM)
Video Call
Continuous
Talk Time
Approximately ●●
minutes
(with Internal Camera in use)
Approximately ●●
minutes
(with External Camera in use)
Charging Time
(power off)
AC Charger: Approximately ●●
minutes
In-Car Charger: Approximately
●●
minutes
Dimensions
(W
×
H
×
D)
Approximately 49.8
×
100
×
21.3 mm
(handset closed, 21.3 mm at thickest point)
Maximum Output
0.25 W (3G)
2.0 W (GSM)
J410_insatsu.book 46 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-47
Abridged English Manual
19
.
Talk Time/Standby Time decrease with frequent use of
Display/Keypad backlights.
.
Talk Time/Standby Time may decrease when an
S! Application is active.
.
Talk Time/Standby Time decrease with handset use in
poor signal conditions.
.
Display employs precision technology, however, some
pixels may appear brighter/darker.
■ AC Charger
■ Battery
■ Video Cable
Power Source AC 100V-240V, 50/60 Hz
Power
Consumption 12VA
Output
Voltage/Current DC 5.2V/650 mA
Charging
Temperature 5℃
to 35℃
Dimensions
(W
×
H
×
D)
Approximately 55
×
45
×
22 mm
(without protruding parts, cord)
Cord Length Approximately 1.5 m
Voltage 3.7V
Battery Type Lithium-ion
Capacity 810 mAh
Dimensions
(W
×
H
×
D)
Approximately 37.8
×
5.8
×
36.9 mm
(without protruding parts)
Weight Approximately ●●
g
Cord Length Approximately ●●
cm
J410_insatsu.book 47 ページ ２００６年８月２９日　火曜日　午後５時２８分
19-48
Abridged English Manual
19
If you have questions about SoftBank handsets or services, please call General Information. For repairs, please
call Customer Assistance.
Call these numbers toll free from landlines.
Customer Service
SoftBank Customer Centres
From a SoftBank handset, dial toll free at 157
for General Information or 113 for Customer Assistance
SoftBank International Call Centre
From outside Japan, dial +81-3-5351-3491
(International charges will apply to this call.)
Subscription Area Service Centre Phone Number
General Information ƒ 0088-240-157
Hokkaido, Aomori, Akita, Iwate, Yamagata, Miyagi, Fukushima, Niigata,
Tokyo, Kanagawa, Chiba, Saitama, Ibaraki, Tochigi, Gunma, Yamanashi,
Nagano, Toyama, Ishikawa, Fukui Customer Assistance ƒ 0088-240-113
General Information ƒ 0088-241-157
Aichi, Gifu, Mie, Shizuoka Customer Assistance ƒ 0088-241-113
General Information ƒ 0088-242-157
Osaka, Hyogo, Kyoto, Nara, Shiga, Wakayama Customer Assistance ƒ 0088-242-113
General Information ƒ 0088-250-157
Hiroshima, Okayama, Yamaguchi, Tottori, Shimane, Tokushima, Kagawa,
Ehime, Kochi, Fukuoka, Saga, Nagasaki, Oita, Kumamoto, Miyazaki,
Kagoshima, Okinawa Customer Assistance ƒ 0088-250-113
J410_insatsu.book 48 ページ ２００６年８月２９日　火曜日　午後５時２８分

Navigation menu
