manual Model Description

Model Description
FCC ID : APYHRO00078
Destination : Japan Market only
Model Name : 931SH
Brand Name : SoftBank
Emission Type : GSM(PCS) ----- GXW
Type of Equipment :
Cellular Phone / Bluetooth and FeliCa enable
RF-section
Items
Technical Specification 3GPP R99
WCDMA
2000MHz(band I) : Tx 1922.6 to 1977.4MHz, Rx 2112.6 to 2167.4MHz
NOTE: Band I does not operate in USA
Frequency Band GSM
900MHz : Tx 880.2 to 914.8MHz, Rx 925.2 to 959.8MHz
1800MHz : Tx 1710.2 to 1784.8MHz, Rx 1805.2 to 1879.8MHz
1900MHz : Tx 1850.2 to 1909.8MHz, Rx 1930.2 to 1989.8MHz
NOTE: GSM900/1800MHz Band do not operate in USA
WCDMA : 24dBm+1dB/-3dB
Tx Power GSM
900MHz : 33dBm±2dB(GSM/GPRS)
1800MHz: 30dBm±2dB(GSM/GPRS)
1900MHz: 30dBm±2dB(GSM/GPRS)
Transmission Technology WCDMA : DS/CDMA, FDD
GSM : FDMA/TDMA
Data Transmission GSM GPRS: GMSK
GSM GPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
Voice Codec WCDMA : AMR
GSM : EFR/ FR/HR/AMR
Cellular Phone
Antenna Integrated Antenna: Reversed L Type Antenna ------ See attached
construction drawing
Technical Specification Bluetooth Version 2.0 (without EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Bluetooth
Antenna Integrated Antenna ---- See attached construction drawing
Reversed L-Type / Gain= 0 dBi
Technical Specification NFCIP-1(ISO/IEC18092)
Frequency Band 13.56 -13.56MHz
Type of Modulation ASK(10%)
RF ID
(FeliCa)
Antenna Integrated Loop Antenna------ See attached construction drawing
Class B Personal computer PERIPHERAL DEVICE
Items
Clock Frequency 26MHz, 208MHz
USB Data Cable / Connector Shielded / Unshielded
USB
Rev1.0
Feature
SIM Plug-in 3V SIM card slot
Display
Main 3.77inch,16,777,216colorsTFT(ASV),480×1024(HarfXGA)with Backlight
Ｓub none
Camera
Main CMOS 5M pixel
Ｓub none
Battery/ Talk time
Battery Capacity 800mAh
Battery type Rechargeable Lithium-Ion Battery
standby time WCDMA 350h / GSM 320h
talk time WCDMA 250min. / GSM 240min.
Dimensions
Target size 52.45(W) x 115.4(D) x 16.35(H)mm (Close position)
Target weight 128g
Key Layout Soft key (2keys), Navigation key (4keys), Center key (include sensor
key), Custom key (2keys), 0-9 numeric keys, Send/End keys, “*”, ”#”,
“Clear” and 3 side keys
Cell Phone Feature
Interface
Headset connector For Stereo Headset (10 pins)
MCPC connector For USB Cable or PC Link cable or AC Charger
SIM card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit The terminals of charging are for using a cradle.
External I/F
Accessory
AC Charger Optional Accessories,
Input AC 100 to 240V Output DC 5.4V/700mA
Battery Inbox Accessories,
Lithium-Ion,DC3.7V 800mAh
Stereo Handsfree(Headset) Optional Accessories
USB Data Cable Optional Accessories
Accessory
