i
First Step Guide
See Online English Manual for "Safety Precautions."
Before Using Handset ii
Handset Functions vii
General Notes xii
Customer Service xv
Accessory
Battery (SHBBZ1)
Battery Installation
Remove cover

Press and slide as shown.
.
Insert battery

Close cover

Charging
Use specified AC Charger ZTDAA1 (sold
separately) only.
Small Light
External
Device Port
Port Cover
AC Charger
Blades
AC 100V Outlet
Release
Tabs
Charger
Connector
Arrows
1
2
3
Open Port Cover to connect

AC Charger
Plug AC Charger into AC

outlet
Small Light illuminates red while
.
charging.
Small Light goes out when battery is
.
full.
After charging, unplug AC

Charger, then disconnect　
handset
Before Using Handset
ii
USIM Card Installation
Notch
Slide in USIM Card with IC

chip facing down
Insert battery (P.ii)

First power off handset and remove
.
battery.
Do not force USIM Card into/out of
.
handset.
USIM Card must be inserted to use
.
handset.
USIM PINs
PIN
■
4-digit code; activate PIN Entry to restrict
usage.
PIN2
■
Required to clear Call Costs and to set
Max Cost.
PIN and PIN2,
9999
by default, are
changeable.
PIN Lock & Cancellation (PUK Code*)
■
Entering incorrect PIN or PIN2 three
consecutive times locks USIM Card,
disabling handset. Enter PUK Code to
unlock. For details, contact SoftBank
Customer Center, General Information.
USIM Personal Unblocking Key (PUK *
Code) unblocks a USIM Card blocked
after the wrong PIN has been entered
three consecutive times. Each USIM
Card has a unique PUK Code. Do not
disclose it to unauthorized persons.
iii
Display Indicators & Key Assignments
Signal strength Manner mode active
Packet transmission available (3G) Battery strength
Packet transmission available (GSM) New Voicemail
Unread mail Alarm set
Memory Card in use
BOpen Messaging menu or
execute Softkey functions
'Open Shortcuts menu. In
text entry windows, toggle
upper/lower case
$
Delete entries, escape/
return to previous window
!
Initiate/answer calls
1
|
#
Enter numbers/characters
Multi Selector
Select menu items, move cursor,
or scroll pages, etc. Multi
Selector operations are
indicated in this guide as shown
below:
%: Press the center
c: Press the left side
d: Press the right side
b: Press the bottom
AOpen Yahoo! Keitai Main
Menu or execute Softkey
functions
&Activate TV or switch entry
mode
"
Turn handset power on/off
Side Keys
Side Key operations are indicated
in this guide as shown below:
! (Long): Long Press !
L: Press E or F
iv
Manner Mode
Minding Mobile Manners
■
Please use handset responsibly. Inappropriate
handset use can be both dangerous and
bothersome. Please take care not to disturb
others when using handset. Adjust handset
use according to your surroundings.
Activating/Canceling Manner Mode
#
, (Long)
Security Codes
Handset Code
■
9999
by default; use or change some
functions.
Center Access Code
■
4-digit code selected at contract; access
Optional Services via landlines or change
contract details.
Network Password
■
4-digit code selected at contract; restrict
incoming/outgoing calls (Call Barring).
Message appears for incorrect code
.
entries; retry.
If Network Password is incorrectly
.
entered three times consecutively, Call
Barring settings are locked. To resolve,
Network Password and Center Access
Code must be changed. For details,
contact SoftBank Customer Center,
General Information.
Specifications
Weight* ● g
Continuous
Talk Time*
● minutes (3G)
● minutes (GSM)
Continuous
Standby Time*
(Slider closed)
● hours (3G)
● hours (GSM)
Charging Time*
(power off)
AC Charger: ● minutes
In-Car Charger: ● minutes
Dimensions*
(W x H x D)
● x ● x ● mm
(Slider closed, without
protruding parts)
Maximum
Output
0.25 W (3G)
2.0 W (GSM)
Values calculated with battery installed.
.
*Approximate value
v
Before Using Handset
vi
Basic Operations
Handset Power On/Off
Power On
■
" (Long)
If Japanese appears first time 931SH powers
on, press % three times, choose
はい
and press
%. In Standby, press %, choose
いいえ
and
press %. In Main Menu, change interface to
English (below).
Power Off
■
" (Long)
English Interface
%S
設定
S%S
Language
S%S
English
S%
Network Settings
Retrieve Network Information to use
Network-related services; the first time
you press B, % or A, a prompt
appears.
B, % or A S
Yes
S%
Setting Clock
%S
Settings
S%S
Date & Time
S%S
Set Date/Time
S%S Enter date and
time (24-hour format) S%
My Phone Number
%S0
Calling
Voice Call
Enter number S!
"
• S Call ends
Redialing
cS A record S!
"
• S Call ends
Video Call
Enter number SBS
Video Call
S%
"
• S Call ends
Incoming Image
Outgoing Image
Other Party's
Number/Name
vi
Menu List
Messaging
Received Msg.
Create Message
Retrieve New Msg.
Drafts
Templates
Sent Messages
Unsent Messages
Chat Folder
Server Mail Box
Create New SMS
Settings
Memory Status
Yahoo! Keitai
Yahoo! Keitai
Bookmarks
Saved Pages
Enter URL
History
PC Site Browser
Browser Settings
S! Appli
S! Appli Library
Osaifu-Keitai
Demand History
Settings
Information
TV
Digital TV
TV Player
TV-Image Folder
TV Link
TV Listing
Familink Remote
Reservation List
Settings
Camera
Entertainment
Mobile Widget
S! Quick News
S! Information Channel/Weather
BookSurfing
e-Book Viewer
Tools
PIM/Lifestyle
Calendar
Alarms
Wakeup TV
Tasks
Calculator
Expenses Memo
Osaifu-Keitai
Pretense Call
Clocks/Gauges
Stopwatch
Countdown Timer
World Clock
Hour Minder
Pedometer
Compass
S! GPS Navi
Battery Meter
Doc./Rec.
Dictionary
Search
Document Viewer
Notepad
Scratch Pad
ASCII Art
Voice Recorder
Barcode/Scan
Phone Help
Data Folder
Pictures
DCIM
Ring Songs•Tones
S! Appli
Widget
Music
Videos
Lifestyle-Appli
Books
Customized Screen
Status Templates
Decoration Call
Flash®
Other Documents
Memory Status
Media Player
Music
Videos
Streaming
Settings
MTP Mode
Communication
S! Town
S! Loop
S! Friend's Status
S! Circle Talk
Near chat
Phone
Phone Book
Add New Entry
Information
Call Log
Play Messages
Call Voicemail
Category Control
My Details
Speed Dial/Mail
Mail Groups
S! Addressbook Backup
Ph.Book Settings
Call Log Settings
Manage Entries
Settings
Phone
Mode Settings
Display
Customized Screen
Sounds & Alerts
Date & Time
Set Key Light
言語選択 (Language)
User Dictionary
Set Key Shortcut
Motion Control
Touch Panel
Ringer Output
Earpiece Volume
Change Menu
Double Number Settings
Locks
Software Update
Master Reset
Connectivity
Bluetooth
Infrared
IC Transmission
USB Mode
USB Charge
Memory Card
Backup/Restore
Call
Call Time & Cost
Answer Phone
Voicemail/Divert
Video Call
Show My Number
)
Missed Calls
Int'l Calling
Disp. Time/Cost
Call Barring
Minute Minder
Decoration Call
Slider Settings
Auto Answer
Call Waiting
Network
Select Network
Select Service
Offline Mode
Retrieve NW Info
Network Info
External Device
vii
Before Using Handset Handset Functions
ix5ixviii
International Call
International Call Service may require
prior application; get information or
apply online: http://mb.softbank.jp/mb/
en/global_service/
931SH is Global Roaming eligible.
Enter number SBS
Int'l Call
S%S
A country S%S!
"
• S Call ends
Answering a Call
When a call arrives, !
"
• S Call ends
Answer Phone
Activating
■
$ (Long)
To cancel, • $ (Long)
Playing Messages
■
$ S A record S%
To stop, • $
Text Entry
Switching Entry Modes
In text entry windows, &S A mode
S%S Enter text
Kanji (hiragana)
Double-byte katakana
Single-byte katakana
/Double-byte alphanumerics
/Single-byte alphanumerics
Single-byte number
Character Code
Example: Entering no
In text entry windows, &S
Abc
S%S
66SdS666S%
Messaging
SMS/S! Mail
SMS
■
Exchange up to 160 alphanumerics with
SoftBank handsets.
S! Mail
■
Exchange up to 30,000 characters with
e-mail compatible SoftBank handsets or
other devices; attach media files, etc.
ix
Customizing Address
Change alphanumerics before @ of the
default handset mail address.
Customizing handset mail address helps
reduce spam.
BS
Settings
S%S
Address Settings
S%S
English
S%S Onscreen
instructions
Sending Messages
BS
Create Message
(S! Mail) or
Create
New SMS
S%S Enter recipient S Enter
subject (S! Mail) S Attach files (S! Mail)
S Enter text S%SA
Receiving Messages
Information window opens for new mail.
% to open message list.
Phone Book
Phone Book Entry Items
Phone Number
■
Enter up to five numbers on handset
(32 digits each).
Mail Address
■
Enter up to five addresses on handset
(128 single-byte alphanumerics each).
Saving to Phone Book
%S
Phone
S%S
Add New Entry
S%S
Last Name:
S%S Enter S%S
First Name:
S%S Enter S%S
Add Phone Number:
S%S Enter number S%S An icon S%S
Add Email Address:
S%S Enter address
S%S An icon S%SA
Editing Entries
bS An entry SBS
Edit
S%S An
item S%S Edit S%SA
Dialing via Phone Book
bS Enter reading S A name S%S
A phone number S!
Voicemail
Activating
%S
Settings
S%S
Call
S
Voicemail/
Divert
S%S
Voicemail
S%S
Activate
S%S
Always
or
No Answer
S%S Ring
time (for
No Answer
)S%
Playing Messages
%S
Phone
S%S
Call Voicemail
S%S
Follow the voice guidance
Handset Functions
x
Mobile Camera
Capturing Still Images
%S
Camera
S%S Frame image on
Display S%S%
Recording Video
%S
Camera
S%S Frame image on
Display S%S%S%
Digital TV
Area Setup
Follow these steps when activating TV
for the first time.
&S
Yes
S%S A region
S%S
A prefecture S%S A locality
S%S%
Watching TV
&S A channel
S L to adjust volume
To end, • "S
Yes
S%
Panel Description
■
Area name
Signal strength
Volume
Program name
Channel key
Station name
Recording/Playing Programs
Recording
■
&S A channel
S ! (Long) to start
S ! (Long) to end
Playing
■
&SBS
TV Player
S%S A file
S%
To stop, • A (Long)
Yahoo! Keitai
Accessing Yahoo! Keitai
AS
メニューリスト
S%S
English
S%S Highlight a menu item S%
Using PC Site Browser
%S
Yahoo! Keitai
S%S
PC Site Browser
S%S
Enter URL
S%S URL S%S
Highlight a menu item S%
xi
Media Player
Playing Music
%S
Media Player
S%S
Music
S%S
My
Music
S%S
Music
or
Ring Tones
S
All
Music
S%SA fileS%
Title
Artist name
Track number
Elapsed time
Volume
Sound Effects
Playback Mode
Adding Playlists
%S
Media Player
S%S
Music
S%S
My
Music
S%S
Music
or
Ring Tones
SB
S
Add New Playlist
S%S Enter name
S%
Using Playlists
%S
Media Player
S%S
Music
S%S
My
Music
S%S
Music
or
Ring Tones
S A
Playlist S%S A fileS%
Managing Files
Opening Files
%S
Data Folder
S%S A folder S%S
A file S%
Format Memory Card
%S
Settings
S%S
Connectivity
S
Memory Card
S%S
Format Card
S%S
Yes
S%S Handset Code S%S
Yes
S%
Software Update
Precaution
Before updating software, end all active
functions/applications.
Updating Software
%S
Settings
S%S
Software Update
S%S
Software Update
S%
Handset Functions
xiixii4xii
Touch Panel
Touch Display to select menu items,
move pointer, or scroll pages, etc;
supports most handset operations.
Calibrating Touch Panel
For best precision, calibrate Touch Panel
before use, in your usual posture and
grip angle.
%S
Settings
S%S
Touch Panel
S%S
Correct Touch Panel
S%S Onscreen
instructions
Important Touch Panel Usage Notes
Touch Panel may not respond
.
when:
Touched with gloves or fingernails
,
Touched with pens, ballpoint pens,
,
pencils or other sharp objects
Objects are placed on Display
,
Do not:
.
Touch Display with wet fingers
,
Press Display strongly
,
Place labels or stickers over Display
,
Keypad Lock
After a period of inactivity or when H
is pressed, Display goes dark and Keypad
Lock activates. To unlock handset, Long
Press H (Display turns on) and follow
these operations.
Place finger on
the upper part
of graphic
Move
down finger
(Keypad Lock
deactivates)
Selection & Execution (Tapping)
Touch Display then release finger
immediately to open windows or execute
Softkey functions/operations.
xiiixiii5xiii
Execution (Long Touch)
You need to place finger and hold it
to execute some Softkey functions/
operations. Release finger afterward.
Execution (Double Tapping)
Some operations require double tapping;
tap the same spot again.
Move/Draw (Dragging)
Slide finger over Display to move icons,
etc. Release finger to stop.
Scroll (Flicking)
To see portions outside Display, place
finger on Display then flick it in the
opposite direction.
Enlarge/Reduce (Pinching)
Place two fingers on Display then slide
them close/open to reduce/enlarge
images, etc.
Onscreen Keyboard
Use onscreen keyboard to enter
characters, phone numbers, etc.
Handset Functions
Information to User
This equipment has been tested and found to
comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation; if this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the
equipment and receiver.
3. Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/
TV technician for help.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed
the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission of the U.S.
Government.
The guidelines are based on standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of
scientific studies. The standards include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless handsets
employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg.
Highest SAR value:
Model FCC ID At the Ear On the Body
931SH APYHRO00078 0.518 W/kg0.728 W/kg
This device was tested for typical body-worn
operations with the back of the handset kept
1.5 cm from the body. To maintain compliance
with FCC RF exposure requirements, use
accessories that maintain a 1.5 cm separation
distance between the user's body and the back
of the handset. The use of beltclips, holsters and
similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be avoided.
The FCC has granted an Equipment
Authorization for this model handset with all
reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR
information on this model handset is on file
with the FCC and can be found at https://
fjallfoss.fcc.gov/oetcf/eas/reports/
GenericSearch.cfm under the Display Grant
section after searching on the corresponding FCC
ID (see table above).
Additional information on Specific Absorption
Rates (SAR) can be found on the Cellular
Telecommunications & Internet Association
(CTIA) Website at http://www.phonefacts.net.
General Notes
xiv
Hardware
Mobile Light
■
Do not use Mobile Light near people's
faces.
Eyesight may be temporarily affected leading to
accidents.
CAUTION:
CLASS 1
LED Product
EN60825-1:1994 A1:2002 & A2:2001
Use of controls, adjustments
or procedures not specified
here may result in harmful
LED radiation. Mobile Light
LED emission level is harmful to eyes; do not
attempt to disassemble the cabinet. Service is
limited to qualified service outlets only.
Mobile Light
■ Mobile Light LED Properties
a) Emission Duration: Continuous
b) Wavelength
White: 400 - 700 nm
c) Maximum Emission Output
White: 840 µW (1.2 mW inside handset)
Battery
■
Use specified battery or Charger only.
Non-specified equipment use may cause
malfunctions, electric shock or fire due to
battery leakage, overheating or bursting.
Do not dispose of an exhausted battery with
ordinary refuse; always tape over battery
terminals before disposal. Take battery to a
SoftBank Shop, or follow the local disposal
regulations.
Charge battery in ambient temperatures
between 5℃ and 35℃; outside this range,
battery may leak/overheat and performance
may deteriorate.
Electromagnetic Waves
For body-worn operation, this phone has been
tested and meets RF exposure guidelines when
used with accessories containing no metal, that
position handset a minimum of 15 mm from
the body. Use of other accessories may not
ensure compliance with RF exposure guidelines.
FCC Notice
This device complies with part 15 of the FCC
.
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly
.
approved by the manufacturer responsible for
compliance could void the user's authority to
operate the equipment.
xv
xvi
European RF Exposure Information
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits
for exposure to radio waves recommended by
international guidelines. These guidelines were
developed by the independent scientific
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement
known as the Specific Absorption Rate, or SAR.
The SAR limit for mobile devices is 2 W/kg.
As mobile devices offer a range of functions,
they can be used in other positions, such as on
the body as described in this user guide*.
Highest SAR value:
Model At the Ear** On the Body
931SH 1.157 W/kg0.488 W/kg
As SAR is measured utilizing the device's highest
transmitting power the actual SAR of this device
while operating is typically below that indicated
above. This is due to automatic changes to the
power level of the device to ensure it only uses
the minimum level required to reach the Network.
The World Health Organization has stated that
present scientific information does not indicate
the need for any special precautions for the use
of mobile devices. They note that if you want to
reduce your exposure then you can do so by
limiting the length of calls or using a handsfree
device to keep the mobile phone away from the
head and body.
*Please see Electromagnetic Waves on P.xiv
for important notes regarding body-worn
operation.
**Measured in accordance with international
guidelines for testing.
Hereby, Sharp Telecommunications of Europe Ltd, declares
that 931SH is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity for each
model can be found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Declaration of Conformity
xvii
General Notes
SoftBank Customer Center
From a SoftBank handset, dial toll free at
157 (General Information) 113 (Customer Assistance)
SoftBank Global Call Center
From outside Japan, dial
+81-3-5351-3491 (International charges apply)
Call this number immediately if handset/USIM Card is lost or stolen while outside Japan.
Call these numbers toll free from landlines.
■
Subscription Area Service Center Phone Number
Hokkaido, Aomori, Akita, Iwate, Yamagata,
Miyagi, Fukushima, Niigata, Tokyo, Kanagawa,
Chiba, Saitama, Ibaraki, Tochigi, Gunma,
Yamanashi, Nagano, Toyama, Ishikawa, Fukui
General Information m 0088-240-157
Customer
Assistance m 0088-240-113
Aichi, Gifu, Mie, Shizuoka
General Information m 0088-241-157
Customer
Assistance m 0088-241-113
Osaka, Hyogo, Kyoto, Nara, Shiga, Wakayama
General Information m 0088-242-157
Customer
Assistance m 0088-242-113
Hiroshima, Okayama, Yamaguchi, Tottori,
Shimane, Tokushima, Kagawa, Ehime, Kochi,
Fukuoka, Saga, Nagasaki, Oita, Kumamoto,
Miyazaki, Kagoshima, Okinawa
General Information m 0088-250-157
Customer
Assistance m 0088-250-113
Customer Service

Navigation menu
