User manual
279
付
録
／
索
引
is13sh_18.fm
[279/281]
Copyright (C) 2010-2011 Three Laws of Mobility. All Rights Reserved.
その他の社名および商品名は、それぞれ各社の登録商標または商標です。
OpenSSL License
【OpenSSL License】
Copyright © 1998-2009 The OpenSSL Project. All rights reserved.
This product includes software developed by the OpenSSL Project for use in
the OpenSSL Toolkit. (http://www.openssl.org/)
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ''AS IS''
AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT
LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE
OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
【Original SSLeay License】
Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved.
This product includes cryptographic software written by Eric Young
(eay@cryptsoft.com)
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ''AS IS'' AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE
OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
In some countries/regions, such as France, there are restrictions on the use of Wi-
Fi®. If you intend to use Wi-Fi® on the handset abroad, check the local laws and
regulations beforehand.
■Mobile Light
Do not point the illuminated light directly at someone’s eyes.
Do not use Mobile light near people’s faces. Eyesight may be temporarily
affected leading to accidents.
Safety Information
CE Declaration of Conformity
Hereby, Sharp Telecommunications of Europe Ltd, declares that this IS17SH is in
compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original declaration of conformity can be found at the following Internet
address:
http://www.sharp.co.jp/k-tai/
is13sh.book 279 ページ ２０１１年１０月６日 木曜日 午後８時５９分
280
付
録
／
索
引
is13sh_18.fm
[280/281]
CAUTION:
Use of controls, adjustments or performance of procedure other than those
specified herein may result in hazardous radiation exposure. As the
emission level from Mobile light LED used in this product is harmful to the
eyes, do not attempt to disassemble the cabinet. Servicing is limited to
qualified servicing station only.
Mobile light source LED characteristics
a) Continuous illumination
b) Wavelength
White: 400-700 nm
c) Maximum output
White: 910 μW (inside cell phone 1.57 mW)
■AC Adapter
Any AC adapter used with this handset must be suitably approved with a
5Vdc SELV output which meets limited power source requirements as
specified in EN/IEC 60950-1 clause 2.5.
■Battery - CAUTION
■Loudness warning
Excessive sound pressure from earphones and headphones can cause
hearing loss.
■Headphone Signal Level
The maximum output voltage for the music player function, measured in
accordance with EN 50332-2, is 56 mV.
■European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by international
guidelines. These guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest
SAR value for this device when tested at the ear was 0.141 W/kg※.
As SAR is measured utilizing the devices highest transmitting power the
actual SAR of this device while operating is typically below that indicated
above. This is due to automatic changes to the power level of the device to
ensure it only uses the minimum level required to reach the network.
The World Health Organization has stated that present scientific information
does not indicate the need for any special precautions for the use of mobile
devices. They note that if you want to reduce your exposure then you can do
so by limiting the length of calls or using a hands-free device to keep the
mobile phone away from the head.
Use specified battery or Charger only.
Non-specified equipment use may cause malfunctions, electric shock or fire
due to battery leakage, overheating or bursting.
EN60825-1:1994 A1:2002 & A2:2001
CLASS1
LED Product
Mobile light
Do not dispose of an exhausted battery with ordinary refuse; always tape
over battery terminals before disposal. Take battery to an au Shop, or follow
the local disposal regulations.
Charge battery in ambient temperatures between 5°C and 35°C; outside
this range, battery may leak/overheat and performance may deteriorate.
※The tests are carried out in accordance with international guidelines for testing.
is13sh.book 280 ページ ２０１１年１０月１７日 月曜日 午後７時３２分
281
付
録
／
索
引
is13sh_18.fm
[281/281]
- This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
- Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user's authority to operate the
equipment.
■Information to User
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation; if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
■FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of
the U.S. Government.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6W/kg.
Highest SAR value:
This device was tested for typical body-worn operations with the back of the
handset kept 1.5 cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.5 cm separation
distance between the user's body and the back of the handset. The use of
beltclips, holsters and similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization for this model handset
with all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model handset is on file with
the FCC and can be found at http://www.fcc.gov/oet/fccid/ under the Display
Grant section after searching on the corresponding FCC ID (see table
above).
Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications & Internet Association (CTIA)
Website at http://www.phonefacts.net.
FCC Notice
Model CDMA SHI17
FCC ID APYHRO00158
At the Ear 0.357 W/kg
On the Body 0.120 W/kg
is13sh.book 281 ページ ２０１１年１０月１７日 月曜日 午後７時３２分
291
簡
易
英
語
is13sh_20.fm
[291/292]
●Turning Power On
Hold down f for at least two seconds.
●Turning Power Off
Hold down f for at least two seconds.
z Tap [Power off]. z Tap [OK].
On the home screen: Tap [ ]. z Tap [設定].
z Tap [言語とキーボード]. z Tap [言語（Language）を選択].
z Tap [English].
On the home screen: Tap [ ]. z Tap [Settings]. z Tap [Profile].
English Simple Manual （簡易英語版）
IS13SH
External
connection
jack cover
External
connection
jack
Strap eyelet
Light
sensor
Power
key
Infrared port
Camera lens
au
IC-Card
Mobile light
Speaker
FeliCa mark
microSD
memory
card slot
Battery
pack
Internal antennas
Television
antenna
Battery pack
cover
Volume up/
down key
Display
(main area)
Display
(sub area)
Earpiece Internal antennas
Earphone jack
Microphone
Turning Power On and Off Switching the Screen to English
Checking Your Own Phone Number and
Mail Address
is13sh.book 291 ページ ２０１１年９月２０日 火曜日 午後６時４０分
IS17SH
292
簡
易
英
語
is13sh_20.fm
[292/292]
●Making a Call
On the home screen: Tap [ ]. z Tap [Phone].
z Enter the phone number you want to call. z Tap [Call].
To end a call: Slide [ ] in the left direction.
●Answering a Call
When the phone starts ringing, slide [ ] in the right direction.
When the phone starts ringing, tap [Answer] while the backlight
illuminates (except when the unlock screen is displayed).
To adjust the earpiece volume during a call: Press u/d.
●Storing an Entry
On the home screen: Tap [ ]. z Tap [Address Book].
z Tap [e]. z Tap [Add new entry].
z Select the item you want to edit. z Tap [Save]. z Tap [Yes].
●Recalling an Entry
On the home screen: Tap [ ]. z Tap [Address Book].
z Select the record you want to recall.
●Recording a Movie Clip
On the home screen: Tap [ ]. z Tap [Video Camera].
z Tap [ ] to start recording. z Tap [ ] to stop recording.
●Taking a Snapshot
On the home screen: Tap [ ]. z Tap [Camera].
z Tap [ ] to take a snapshot.
Ex: To call 212-123-XXXX in the USA
On the home screen: Tap [ ]. z Tap [Phone].
●Setting the Manner Mode
Hold down f for at least two seconds.
z Tap [Manner mode].
Repeat the above operation to disable the Manner Mode.
●Setting the Answer Memo (Voice Recording)
On the home screen: Tap [ ]. z Tap [Settings].
z Tap [Call settings]. z Tap [Call/Ans Memo].
z Tap [Answering memo setting]. z Tap [ON].
Making and Answering a Call
Storing and Recalling Address Book Entries
Using the Camera (Movie and Snapshot)
Making an International Call
［0］［0］［1］［0］［1］［0］ or ［0］［1］［0］z［1］z
［2］［1］［2］
International
access code
Area code
Country code (USA)
z
［1］［2］［3］
z△△△△ zTap [Call].
Number you want to call
Other Handy Features
For inquiries, call: Customer Service Center
For general information
●If you are calling from a landline phone: 0077-7-111 (toll free)
●If you are calling from an au mobile phone: 157 (toll free)
For repairs, loss or theft
●If you are calling from a landline phone: 0077-7-113 (toll free)
●If you are calling from an au mobile phone: 113 (toll free)
is13sh.book 292 ページ ２０１１年９月２０日 火曜日 午後６時４０分
