08_UserManual_English_204SH_APYHRO00188
わかる
3-52
Before Using Handset
Accessories
.Battery (SHBEY1)
.AC Charger (SHCEJ1)
.Desktop Holder (SHEEY1)
.microSD Card (complimentary sample)
Battery Installation
1
Remove Battery Cover
Notch
.Use notch to open Battery Cover as shown,
then push up Battery Cover along edges to
remove it.
67
Quick Tips Read the content thoroughly before using handset to learn about
basics and precautions.
Ｑｕｉｃｋ
Ｔｉｐｓ
わかる
3-53
Quick Tips
2
Insert Battery
Battery Tab
.With Battery tab (printed PULL) facing up, align
Battery terminals with charging terminals.
3
Close Battery Cover
Press shaded
areas firmly
.Align Battery Cover with handset, then fi rmly
press down along shaded areas.
.To maintain water/dust resistance, close Battery
Cover properly. Debris trapped between gasket
and base may expose handset to liquid/dust.
67
わかる
3-54
Quick Tips
Charging (Desktop Holder)
With Battery installed, use AC Charger (SHCEJ1)
and Desktop Holder (SHEEY1).
.AC Charger and Desktop Holder are not water or
dust proof. Never charge Battery while handset is
wet.
.Do not touch AC Charger or Desktop Holder with
wet hands. Electric shock may occur.
AC 100 V
Outlet
AC Charger
Micro USB Plug
Blades
Charging Terminal Lever
Charging
Terminals
3
2
4
1
Charging Indicator
1
Insert Micro USB plug of AC Charger
to connector port of Desktop Holder
Micro USB Plug
Tabs
Connector Port
2
Plug AC Charger into AC outlet after
rotating blades out
67
わかる
3-55
Quick Tips
3
Place handset into Desktop Holder
Charging Indicator
.Charging Indicator illuminates red while
charging.
.Charging Indicator goes out when Battery is
full.
4
After charging, remove handset
from Desktop Holder and unplug AC
Charger
AC 100 V
Outlet
.Hold Desktop Holder when removing handset.
.Pull Micro USB plug straight out from connector
port.
67
わかる
3-56
Quick Tips
Navigation Bar
Open Options menu
Zoom in or out
Go back/escape
Handset Keys
Activate/cancel Screen Lock;
Long Press for power on or
phone options
Increase Volume; Long
Press to turn on Mobile
Light (Press to turn it off)
Decrease Volume; Long
Press to activate/cancel
Manner mode
Activate Phone
Return to Home Screen
Activate Mail
67
わかる
3-57
Quick Tips
Basic Operations
Power On/Off
■Power On
p (Long Press)
After Powering On for the First Time
OK Z戻る ZOK
Unlocking Touchscreen
Drag down .
Screen Lock
After a period of inactivity or Pressing p，
Display goes completely dark and Screen
lock activates. To cancel, Press p; lock
screen appears.
■Power Off
p(Long Press)Z電源を切る ZOK
My Phone Number
Drag up Home ScreenZ開く on つながる
application barZプロフィール
67
わかる
3-58
Quick Tips
General Notes
Handset
Do not disassemble or modify handset.
Electromagnetic Safety
For body-worn operation, this mobile phone has
been tested and meets RF exposure guidelines
when used with an accessory containing no metal
and positioning the handset a minimum 15 mm
from the body. Use of other accessories may not
ensure compliance with RF exposure guidelines.
CE Declaration of Conformity
Hereby, Sharp Telecommunications of Europe
Ltd, declares that 204SH is in compliance with
the essential requirements and other relevant
provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity
for each model can be found at the following
Internet address:
http://www.sharp.co.jp/k-tai/
■Battery Cautions
Use specifi ed Battery or Charger only.
Non-specifi ed equipment use may cause
malfunctions, electric shock or fi re due to battery
leakage, overheating or bursting.
Do not dispose of an exhausted Battery with
ordinary refuse; always tape over Battery terminals
before disposal. Take Battery to a SoftBank Shop,
or follow the local disposal regulations.
67
わかる
3-59
Quick Tips
Charge Battery in ambient temperature 5oC - 35oC;
Battery may leak/overheat and performance may
deteriorate outside this range.
■Mobile Light
Do not shine Mobile Light in eyes.
May temporarily affect eyesight or startle, leading
to accidents.
■European RF Exposure Information
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits
for exposure to radio waves recommended
by international guidelines. These guidelines
were developed by the independent scientifi c
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement known
as the Specifi c Absorption Rate, or SAR. The SAR
limit for mobile devices is 2.0 W/kg and the highest
SAR value for this device when tested at the ear
was 0.505 W/kg*. As mobile devices offer a range
of functions, they can be used in other positions,
such as on the body as described in this User
Guide**. In this case, the highest tested SAR value
is 0.417 W/kg***. As SAR is measured utilizing the
device's highest transmitting power the actual SAR
of this device while operating is typically below
that indicated above. This is due to automatic
changes to the power level of the device to ensure
it only uses the minimum level required to reach
the network.
The World Health Organization has stated that
present scientifi c information does not indicate
the need for any special precautions for the use
of mobile devices. They note that if you want
to reduce your exposure then you can do so by
limiting the length of calls or using a hands-free
device to keep the mobile phone away from the
head and body.
67
わかる
3-60
Quick Tips
*The tests are carried out in accordance with
international guidelines for testing.
**Please see "Electromagnetic Safety" on P.3-58 for
important notes regarding body-worn operation.
***A method of measuring SAR when a mobile
phone is used at positions other than at the ear
was established in March 2010 through an
international standard (IEC62209-2). MIC technical
regulation was reported in October 2011 by the
Information and Communications Council.
World Health Organization
http://www.who.int/emf
List of Specifi c Absorption Rates (SAR) for radio
waves by smartphone model
http://mb.softbank.jp/mb/support/sar/
(Japanese)
■Headphone Signal Level
The maximum output voltage for the music player
function, measured in accordance with EN 50332-
2, is 12.0 mV.
FCC Notice
.This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
.Changes or modifi cations not expressly approved
by the manufacturer responsible for compliance
could void the user's authority to operate the
equipment.
■FCC Information to User
This equipment has been tested and found to
comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
67
わかる
3-61
Quick Tips
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation; if this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment
and receiver.
3. Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV
technician for help.
■FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It
is designed and manufactured not to exceed the
emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications
Commission of the U.S. Government.
The guidelines are based on standards that were
developed by independent scientifi c organization
through periodic and thorough evaluation of
scientifi c studies. The standards include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless handsets
employs a unit of measurement known as the
Specifi c Absorption Rate, or SAR. The SAR limit set
by the FCC is 1.6 W/kg. The tests are performed in
positions and locations (e.g. at the ear and worn
on the body) as required by the FCC for each
model.
67
わかる
3-62
Quick Tips
The highest SAR value for this model handset as
reported to the FCC when tested for use at the
ear is 0.59 W/kg, and when worn on the body in a
holder or carry case, is 0.98 W/kg.
Body-worn Operation; This device was tested for
typical body-worn operations with the back of the
handset kept 1.0 cm from the body. To maintain
compliance with FCC RF exposure requirements,
use accessories that maintain a 1.0 cm separation
distance between the user's body and the back
of the handset. The use of beltclips, holsters and
similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization
for this model handset with all reported SAR
levels evaluated as in compliance with the FCC
RF emission guidelines. SAR information on this
model handset is on fi le with the FCC and can be
found under the Display Grant section of
http://www.fcc.gov/oet/ea/ after searching on FCC
ID APYHRO00188.
Additional information on Specifi c Absorption
Rates (SAR) can be found on the FCC website at
http://transition.fcc.gov/oet/rfsafety/.
67
わかる
3-63
Quick Tips
Customer Service
For SoftBank handset or service information, call General Information. For repairs, call Customer Assistance.
■SoftBank Customer Support
General Information
Customer Assistance (Repairs/Lost Handsets)
From a SoftBank handset, dial toll free at
157
From a landline/IP phone, dial toll free at
0800-919-0157
From a SoftBank handset, dial toll free at
113
From a landline/IP phone, dial toll free at
0800-919-0113
If you cannot reach a toll free number, use the number (charges apply) below for your service area:
Hokkaido Area
Tohoku Area
Hokuriku Area
Kanto & Koshinetsu Area
022-380-4380 Tokai Area 052-388-2002
Kansai Area 06-7669-0180 Chugoku & Shikoku Area,
Kyushu & Okinawa Area 092-687-0010
■Smartphone Technical Support Center
From a SoftBank handset, dial toll free at 151
From a landline/IP phone, dial toll free at 0800-1700-151
■SoftBank Mobile Global Call Center
From outside Japan, dial +81-3-5351-3491 (toll free from SoftBank handsets)
If handset is lost/stolen, call this number immediately (international charges apply)
67
