user manual
4-30
4 Quick Tips
Before Using Handset
Charge handset before powering on for the fi rst time
(not adequately charged at time of purchase).
.Handset may not power on when charge is low.
.If handset does not power on even after charging, contact
WILLCOM Service Center or Sharp Customer Assistance
Center.
Accessories
.SD/USIM Card Insertion/Removal Tool (complimentary
sample)
.microSD Card (complimentary sample, preinstalled)
(Battery is built into handset; handset back cover is
not removable.)
Charging
AC Charger is not included in the package; purchase
WILLCOM AC Charger 01 (AC01-MU-K) separately.
.AC Charger is not water proof. Never charge handset while
it is wet; may cause electric shock, or fi re, malfunction,
burns, etc. due to short-circuiting.
.Handset/AC Charger may become warm while charging.
External
Device Port
Notification
Lamp
AC 100 V Outlet
AC
Charger
Blades
Micro USB Plug
1Insert Micro USB plug into External Device
Port
Micro USB Plug
External
Device Port
.Insert Micro USB plug in correct orientation; otherwise,
External Device Port may be damaged. Confi rm
contours and orientation of Micro USB plug before
inserting it.
4-31
4
2Rotate blades out as shown, then plug AC
Charger into AC outlet
.Notifi cation Lamp illuminates while charging.
.Notifi cation Lamp goes out when charge is full.
3
Unplug AC Charger and retract blades
4Remove Micro USB plug from External
Device Port
Handset Keys
Activate/cancel
Screen lock. Long
Press for power on
or phone options.
Decrease Volume.
Increase Volume.
Return to each
sheet. Long Press
to activate Camera.
Navigation Bar
Return to previous
screen.
Return to each
sheet.
Open Options
menu.
Open application
usage history.
4-32
4Quick Tips (Continued)
Basic Operations
Power On/Off
■Power On
(Long Press)
After Powering On for the First Time
利用する
Z Drag down Z Z Change interface to
English (See "English Interface" below)
Unlocking Touchscreen
Drag down.
Screen Lock
After a period of inactivity or Pressing , Display goes
completely dark and Screen lock activates. To cancel, Press
; lock screen appears.
■Power Off
(Long Press) Z
Power off
Z
OK
English Interface
In application sheet, (設定) Z
その他の設定
Z
言語と文字入力
Z
言語 (Language) を選択
Z
English
My Phone Number
In application sheet, (Settings) Z
Profi le
General Notes
Handset
Do not disassemble or modify handset.
Electromagnetic Safety in Europe
For body-worn operation, this mobile phone has been
tested and meets RF exposure guidelines when used with
an accessory containing no metal and positioning the
handset a minimum 15 mm from the body. Use of other
accessories may not ensure compliance with RF exposure
guidelines.
CE Declaration of Conformity
Hereby, Sharp Telecommunications of Europe Ltd, declares
that WX04SH is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity for each
model can be found at the following Internet address:
http://www.sharp.co.jp/k-tai/
4-33
4
■Battery Cautions
Use specifi ed AC Charger only.
Non-specifi ed equipment use may cause Internal Battery
to leak, overheat, burst or ignite, and may cause AC
Charger to overheat, ignite, malfunction, etc.
Battery is built into handset. Do not dispose of handset
with ordinary refuse; take it to a WILLCOM Plaza/
WILLCOM Counter for appropriate disposal.
Charge handset in ambient temperature 5oC - 35oC;
Internal Battery may leak/overheat and performance
may deteriorate outside this range.
■Mobile Light
Do not shine Mobile Light in eyes.
May temporarily aff ect eyesight or startle, leading to
accidents.
■European RF Exposure Information
Your mobile device is a radio transmitter and receiver.
It is designed not to exceed the limits for exposure to
radio waves recommended by international guidelines.
These guidelines were developed by the independent
scientifi c organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement known as
the Specifi c Absorption Rate, or SAR. The SAR limit for
mobile devices is 2.0 W/kg and the highest SAR value
for this device when tested at the ear was 0.528 W/kg*.
As mobile devices off er a range of functions, they can be
used in other positions, such as on the body as described
in this User Guide**. In this case, the highest tested SAR
value is 0.275 W/kg***. As SAR is measured utilizing
the device's highest transmitting power the actual SAR
of this device while operating is typically below that
indicated above. This is due to automatic changes to
the power level of the device to ensure it only uses the
minimum level required to reach the network.
The World Health Organization has stated that present
scientifi c information does not indicate the need for any
special precautions for the use of mobile devices. They
note that if you want to reduce your exposure then you
can do so by limiting the length of calls or using a hands-
free device to keep the mobile phone away from the
head and body.
*The tests are carried out in accordance with
international guidelines for testing.
**Please see "Electromagnetic Safety in Europe" on P.4-32
for important notes regarding body-worn operation.
***A method of measuring SAR when a mobile phone
is used at positions other than at the ear was established
in March 2010 through an international standard
(IEC62209-2). MIC technical regulation was reported in
4-34
4Quick Tips (Continued)
October 2011 by the Information and Communications
Council.
World Health Organization
http://www.who.int/emf
■Headphone Signal Level
The maximum output voltage for Music Player function,
measured in accordance with EN 50332-2, is 12.0 mV.
FCC Notice
.This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
.Changes or modifi cations not expressly approved by the
manufacturer responsible for compliance could void the
user's authority to operate the equipment.
■FCC Information to User
This equipment has been tested and found to comply
with the limits of a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation; if this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
diff erent from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician
for help.
■FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
of the U.S. Government.
The guidelines are based on standards that were
developed by independent scientifi c organization
through periodic and thorough evaluation of scientifi c
studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless handsets employs a
4-35
4
unit of measurement known as the Specifi c Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
The tests are performed in positions and locations (e.g.
worn on the body) as required by the FCC for each
model.
The highest SAR value for this model handset as
reported to the FCC when worn on the body in a holder
or carry case, is ＜0.10 W/kg.
Body-worn Operation; This device was tested for typical
body-worn operations with the back of the handset
kept 15 mm from the body. To maintain compliance
with FCC RF exposure requirements, use accessories
that maintain a 15 mm separation distance between
the user's body and the back of the handset. The use
of beltclips, holsters and similar accessories should not
contain metallic components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure
requirements, and should be avoided.
The FCC has granted an Equipment Authorization
for this model handset with all reported SAR levels
evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model handset is on
fi le with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/ea/ after
searching on FCC ID APYHRO00195.
Additional information on Specifi c Absorption Rates
(SAR) can be found on the FCC website at
http://transition.fcc.gov/oet/rfsafety/.
4-36
4Quick Tips (Continued)
◆Handset Operations◆
■Sharp Corporation
Customer Assistance Center
0120-606-512
*May not be accessible from some IP phones.
Business hours: 9:00 AM to 6:00 PM, Monday
through Friday
(Excluding national holidays, New Year holidays and
other company holidays)
◆Repairs of Handsets & Optional Accessories◆
■Sharp Corporation
Communication Systems Group
Mobile Telecommunication Services Business
Promotion Center
Repair Service Promotion Dept. Kinki Center 2 (PHS)
0570-081010
*Flat rate from anywhere in Japan.
*From an IP/PHS phone, dial 06-6794-9708.
Business hours: 9:00 AM to 5:40 PM, Monday
through Friday
(Excluding national holidays, New Year holidays
and other company holidays)
Address: 3-1-72 Kita Kamei-cho, Yao-shi, Osaka
◆WILLCOM Services◆
■WILLCOM Service Center
●General Information
From a WILLCOM handset, dial at 151
(charges apply)
*"Dare To Demo Teigaku" free call plan applies.
From another carrier's mobile phone, landline,
etc., dial at 0570-039-151 (charges apply)
Operators available 9:00 AM to 8:00 PM, 7
days a week
●Services
From a WILLCOM handset, dial toll free at 116
From another carrier's mobile phone, landline,
etc., dial toll free at 0120-921-156
Automated voice response system available
24 hours a day, 7 days a week
Charges may apply if operator assistance is required for
the service.
