ShenZhen KaiXingHui Technology F500 Wireless charger User Manual 1

ShenZhen KaiXingHui Technology Co.,Ltd. Wireless charger 1

Users Manual

Product Introduction
Use Instruction
IMPORTANCE
2. Connecting power with USB port, the indicator
will lights up for 3 seconds when power is on.
Package Contents
Wireless Charger(F500)
USB Cable
Attention:
1.Keep the charger away from water and other liquid is required.
2.Please make sure the power is cut off before you start to clean
the charger.
3.Use the charger under temperature only between 0-45°C
WIRELESS&LIMITLESS
User Manual
3.① Locate your phone on charging pad
and make sure it at sweet spot for
effective charging.
②When the phone is charged
successfully, the LED indicator
will lights up for 16 seconds then
off to keep the whole charging
process sleep-friendly.
WIRELESS&LIMITLESS
WIRELESS&LIMITLESS
WIR ELE SS CHA RGER
1. Please use good brand 2A adapter or
QC2.0/QC3.0 fast charging adapter(9V,1.67A).
(How to output 5w/7.5w/10w?)
Input: 5V/2A, 9V/1.67A Output: 5W/7.5W/10W
Charging Distance: ≤10mm Charging Efficiency: ≥73%
Size: 94.4mmX12.2mm
PowerInput
Anti-slipperyRubberband
LEDindicatorarea
Model:F 50 0
Input:DC 5V /2 A ,9V /1.67A
Output:5W/ 7.5W/ 10 W
Made In C hina
Wire le ss Charging Pad
UP
BA CK
Output Power
How can work with 10W
wireless charging power
(Max output power up to
10W fast wireless charging
standard )?
How can work with 7.5W
wireless charging power
(Max output power up to
7.5W fast wireless charging
standard )?
How can work with 5W
wireless charging power? Using 5V,2A adapter
Using QC2.0/QC3.0 fast
charging adapter(9V,1.67A)
Adapter Type Compatible Device
It is compatible with Any enabled devices like iPhone 8/
iPhone 8 plus/ iPhone X, Samsung Galaxy Note 8/ S8/
S8plus / S7/ S7edge/ S6 edge plus/ Note 5/ S6/ S6 edge/
S9 series devices and so on.
It is only compatible with iPhone 8/ iPhone 8 plus/
iPhone X and so on.
It is only compatible with Samsung Galaxy Note 8/ S8/
S8plus/S7/ S7edge/ S6 edge plus/ Note 5/ S9 series
devices so far.
5W
7.5W
10W
Wireless charger F500 is an intelligent simple design product, compatible with all Qi-enabled cell phones and devices.
You don't need any cords to plug in and out any more. Just placing your device in the center of F500, you are free to enjoy
your wireless and limitless charging experience now!
WIRELESS CHARGER
WIR ELE SS CH ARG ER
Such as:
①Samsung fast charging
adapter(9V,1.67A)
② Anker QC2.0/3.0 fast
charging adapter
Using QC2.0/QC3.0 fast
charging adapter(9V,1.67A)
Such as:
①Samsung fast charging
adapter(9V,1.67A)
② Anker QC2.0/3.0 fast
charging adapter
User Manual
Wireless Charger
F500
FCC ID: 2AOSUF500
FCC STATEMENT:
This equipment has been tested and found to comply with the
limits for a WPC device, pursuant to Part 18 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
CAUTION: Changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the product.
NOTE: This equipment has been tested and found to comply
with the limits for a wireless power charger, pursuant to Part
18 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
F C C I D : 2A O S U F 50 0
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator and
your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
