ShenZhen KaiXingHui Technology X1 Wireless charger User Manual 1
ShenZhen KaiXingHui Technology Co.,Ltd. Wireless charger 1
Users Manual
X1
Wireless Charger Stand
Wireless charger X1 is an intelligent simple
design product, compatible with all Qi-enabled cell
phones and devices. You don't need any cords to
plug in and out any more. Just placing your device in
the center of X1, you are free to enjoyyourwireless
andlimitlesschargingexperiencenow!
Product Introduction
In order to bring you a better experience, read this
manual and also please refer to your mobile phone or
your electronic product manual.
Product Specification
尺⼨：108*72mm
Thanks For Choosing Us!
1.Please use good brand 2A adapter orQC2.0/QC3.0
fast charging adapter(9V,1.67A).
Use Instruction
2.Connecting power with USB port, the indicator will
flash for 3 seconds when power is on.
charging line
(Micro USB)
LEDindicator
flash 3s
3.① Locate your phone on charging pad and make sure
it at sweet spot for effective charging.
②When the phone is charged successfully, the
LED indicator will flash for 15 seconds then off
to keep the whole charging process
sleep-friendly.
Model: X1
Size: 90.3mm*110mm
Input:5V 2A,9V 1.67A
Output: 5W/7.5W/10W
Charging Distance: 4mm-6mm
Coils: 2 coils
Net Weight: 118g
PackageContents
Wireless Charger Stand charging line Instruction book
x1 x1 x1
Attention
1. Keep the charger away from water and other liquid is required.
2. Please make sure the power is cut off before you start to clean the charger.
3. Use the charger under temperature only between 0-45°C.
LEDindicator area
Anti-slippery
Rubber band
Power Input
Built-in 2 Coils
LEDindicator flash 15s
FCC ID: 2AOSUX1
FCC STATEMENT:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a WPC
device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the product.
NOTE: This equipment has been tested and found to comply with the limits for a
wireless power charger, pursuant to Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
User Manual
Old electrical appliances must not be disposed of together
with the residual waste, but have to be disposed of separately.
The disposal at the communal collecting point via private
persons is for free. The owner of old appliances is responsible
to bring the appliances to these collecting points or to similar
collection points. With this little personal effort, you contribute
to recycle valuable raw materials and the treatment of toxic
substances.
Environmentally friendly disposal
4. Do not drop the product or submit it to impact.
5. Dropping the product or submitting it to impact can cause the product
to malfunction.
6. Do not place the product in an area exposed to heal, direct sunlight,
dampness, moisture, rain, vibration, shock , dust or sand.
7. Do not place the product near any kind of magnet or expose it to
excessive vibration.
