GENERAL
Congratulations on your purchase of a Shure U1H. The U1H is a high– powered ver-
sion of the Shure U1 transmitter and is compatible with all Shure U4 receivers. Operation
of the U1H is virtually identical to that of the U1. Only the transmitter/receiver spacing
and battery life differ from the U1. Both are described below. Refer to the UHF System
User Guide for detailed U1H operating instructions.
Transmitter/Receiver Spacing
Because of its greater rf output power, an U1H can overload a nearby receiver. To pre-
vent overloading the receiver, Shure recommends you maintain a distance of a least 10
meters (30 ft.) between the U1H transmitter and the U4 receiver.
U1H Transmitter Battery Life
Because of its increased rf output power, the U1H requires more battery power than
the U1. Two 1.5V AA alkaline batteries typically provide 4–6 hours of U1H operation,
compared to 6–10 hours of operation they provide the U1 transmitter.
For more information on the U1H, contact the Shure Applications Group at
(847) 866–2525.
SPECIFICATIONS
Output Power:
U1H–MA (782–810 MHz): 50 mW
U1H–MB (800–830 MHz): 50 mW
U1H–UA (782–806 MHz): 100 mW
Working Range:
50 mW: 275 m (750 ft.) minimum, under typical conditions
100 mW: 300 m (1000 ft.) minimum, under typical conditions
NOTE: Actual working range depends on RF signal absorption, reflection, and inter-
ference.
Frequency Response:
50 to 15,000 Hz ±2 dB
Audio Gain Adjustment Range:
0–40 dB
Modulation:
FM ±45 kHz deviation
Antenna:
1/4 wave, whip antenna, 50 W
Power Requirements:
2 AA 1.5 V alkaline batteries
Battery Life:
4–6 hours
Certification:
Type Accepted under FCC Parts 74; Certified by IC in Canada under RSP 123.
RA Type Approved in the U.K. to MPT1350; EMC Approved to ETS 300 445.
Type Approved and EMC Approved systems are eligible to carry the CE mark.
NOTICE:
This product is part of a Shure Wireless Microphone System. Detailed operating in-
structions are provided in the UHF Wireless System User Guide. For a free copy of the
UHF Wireless System User Guide, contact:
Shure Brothers Incorporated
Customer Service Department
222 Hartrey Avenue
Evanston, IL 602023696 U.S.A.
