Users Manual
dsa2ls
Quick Start Guide
快速安裝指南
快速安装指南
クリックスタートガイド
Kurzanleitung
Guide de Démarrage Rapide
Guía de inicio rápido
Краткое руководство пользователя
Copyright © 2014, Shuttle Corporation. All Rights Reserved
53R-DSA2L3-2001
Package Contents 包裝內容物 包装内容 パッケージ内容 Packungsinhalt
Contenu de l’emballage
Contenido de la caja
Комплект поставки
Supports 75x75mm and 100x100mm VESA standard.
Unterstützt die VESA-Standards 75x75 mm und 100x100 mm.
Compatible avec les formats VESA 75x75 mm et 100x100 mm.
Soporta los estándares VESA 75x75 mm y 100x100 mm.
x4
x4
Product Overview
產品外觀 产品概述 製品概要
Produktübersicht Aperçu du produit
Relación de productos Краткое описание
!
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measure.
FCC ID: TX2-XXXXXX:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
2-Pin DIP-Schalter
P:
Force Auto Power ON (Default : OFF)
P:
P:
P:
P:
Automatisches Einschalten erzwingen
(standardmäßig: Aus)
P:
Forcer allumage automatique
(standard: éteint)
P:
Forzar el encendido automático
(predeterminado: desactivado)
P:
Connecting to Power
電源連接 电源连接 電源への接続 Anschließen des Stromkabels
Branchement au secteur Conectar a la alimentación Соединяется
> 2 secs.
1 2 543
12
11
6
7 8
9
10
1. Mini-USB 2.0
3. SD Card Reader
SD-Cardreader
Lecteur de cartes SD
Lector de tarjetas SD
5. K-Lock Security Slot
K-Lock Sicherungsbefestigung
Encoche de sécurité Kensington
Fijación del seguro K-Lock
7. D-Sub / VGA Video Port
D-Sub / VGA-Videoanschluss
D-Sub / Port Video VGA
Puerto de vídeo D-Sub / VGA
9. HDMI Audio / Video Port
HDMI Audio/Video-Anschluss
HDMI Audio /Port Video
Conector de Audio/Vídeo HDMI
11. RJ45 Gigabit-LAN Port
RJ45 Gigabit-LAN-Anschluss
Port RJ45 Gigabit Lan
Conector LAN Gigabit RJ45
2. USB 2.0 (x3)
4. Power Button / Status LED
Einschaltknopf / Status-LED
Bouton de mise sous tension / Status LED
Botón de encendido/LED de estado
6. W-LAN Antenna
WLAN-Antenne
Antenne Wi-Fi
Antena WLAN
8. Audio Line-out
Audio Line-Out
Sortie Audio
Salida de línea de Audio
10. Com Port
COM-Port
Port Série
Puerto COM
12. AC IN
AC-Stromanschluss
AC IN
Conexión de corriente c.a.
AC IN
Installation of VESA Mount
VESA
掛架安裝
VESA
挂架安装
VESA
マウントの取り付け
Installation der VESA-Halterung
Installation de l’attache VESA Instalación del soporte VESA Установка крепления VESA
i
V:
Force VGA ON (Default: OFF)
V:
V:
V:
V:
VGA Einschalten erzwingen
(standardmäßig: Aus)
V:
Forcer mode VGA
(standard: éteint)
V:
Forzar la activación de VGA
(predeterminado: desactivado)
V:
x4
x4
1
2
3
1
2
4
3
VESA Mount
