1 Purpose of the document
The purpose of this document is to describe the integration of the wireless module S5H-
WRCII into final Siemens Healthcare products.
This module is based on Mitsumi WML-C46NHN Bluetooth Module by a change ID
Identification procedure according to §2.933.
This document shows the implementation of the mentioned module with the tested antennas.
Wireless Remote Control II,
Integration Maual
0 SIEMENS Healthcare Sector
Page 6 of 8 Last Change: 2009-05-18 D. Sierk, H IM CV ME R&D 31
Copyright © Siemens AG 2009, 2009. All rights reserved. For internal use only.
Alle Rechte vorbehalten. Nur für internen Gebrauch.
2 General
The Bluetooth Module S5H-WRCII is based on the Mitsumi Module WML-C46NHN with the
following specifications:
Supply voltage: 2,8V -3,4V
Carrier Frequency: 2402MHz – 2480MHZ
Modulation Method: GFSK, note 1
Data Rate: max 1Mbit/s, note1
Hopping scheme: FHSS, F = 2402MHz + k | k=0 to 78
RF impedance: 50 Ohms
Output power: 0dBm (1mW)
Note 1: Any other modulation method shall not be used with the module S5H-WRCII.
Therefore the maximum data rate is limited to 1Mbit/s.
3 Antenna notes
Additional to the listed antennas by the origin grantee Mitsumi two types of antennas were
tested:
Manufacturer
Product description
Gain (dBi)
gigaAnt
Rufa 2.4 GHz SMD Antenna
4,1
Siemens AG, Healthcare
Sector
Patch antenna
3,6
Table 1 Tested antennas
All antenna connectors are internally in the final product. There is no external antenna
connector provided.
The manufacturer Siemens AG, Healthcare Sector integrates only the above listed antennas
for the final product.
4 Integration
This module will be only integrated into Siemens Healthcare medical devices. It is not
intended to resell the module with the S5H-xxxx grant.
Siemens AG, Healthcare Sector is responsible to provide all relevant approvals (FCC, EMC,
electrical and mechanical safety) for the final product.
Wireless Remote Control II,
Integration Maual
SIEMENS Healthcare Sector 0
D. Sierk, H IM CV ME R&D 31 Last Change: 2009-05-18 Page 7 of 8
Copyright © Siemens AG 2009, 2009. All rights reserved. For internal use only.
Alle Rechte vorbehalten. Nur für internen Gebrauch.
5 Identification / Label
A: Labeling of the module:
The module is tagged by label as follow:
Siemens AG
Wireless Remote Control II
FCC ID: S5H-WRCII
IC: 267 A0-WRCII
204WWxxxxxxxx
B: Labeling of the final product
The device is labeled in accordance to the FCC rules for modular approvals.
e.g. The device is labeled as follow:
Siemens AG
Wireless Remote Control, P/N: 100 96 785
contains
FCC ID: S5H-WRCII
IC: 267AO-WRCII
This device complies with part 15 of the FCC Rules. Operation
is subject to be following two conditions: (1) This device may
not cause harmful interference, and, (2) This device must
accept any interference received including interference that
may cause undesired operation.
This label will be placed on the final product clearly visible to all persons who handle this
product. The dimensions of the label are dependent on the size of the product, but in any case
clearly visible to all involved persons.
