WRAP MULTIRADIO ACCESS SERVER

User’s and Developer’s Guide

Version 2.0.3

Monday, November 08, 2004

Bluegiga Technologies assumes no responsibility for any errors which may appear in this

manual. Furthermore, Bluegiga Technologies reserves the right to alter the hardware, software,

and/or specifications detailed herein at any time without notice, and does not make any

commitment to update the information contained herein. Bluegiga Technologies’ products are

not authorized for use as critical components in life support devices or systems.

The WRAP is a registered trademark of Bluegiga Technologies.

The Bluetooth trademark is owned by the Bluetooth SIG Inc., USA, and is licensed to Bluegiga

Technologies.

ARM and ARM9 are trademarks of ARM Ltd.

Linux is a trademark of Linus Torvalds.

All other trademarks listed herein belong to their respective owners.

2004-11-08

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

CONTENTS

1 Introduction ....................................................................................................... 6

1.1 Licenses and Warranty ......................................................................................6

1.2 Certification Information ....................................................................................6

1.3 Bluegiga Technologies Contact Information ..........................................................9

2 Controlling the Access Server ........................................................................... 10

2.1 Physical Interfaces.......................................................................................... 10

2.2 Shell Prompt Access........................................................................................ 11

2.2.1 Management Console ............................................................................... 11

2.2.2 Accessing Remotely.................................................................................. 12

2.3 Transferring Files to/from the Access Server....................................................... 12

3 Configuration.................................................................................................... 14

3.1 Using the Setup Application.............................................................................. 14

3.1.1 Network Configuration .............................................................................. 14

3.1.2 Bluetooth Settings.................................................................................... 15

3.1.2.1 General Bluetooth Settings ................................................................. 15

3.1.2.2 LAN Access Profile Settings ................................................................. 16

3.1.2.3 Serial Port Profile Settings .................................................................. 16

3.1.2.4 OBEX Settings .................................................................................. 18

3.1.2.5 Personal Area Network Profile Settings ................................................. 19

3.1.3 Ramdisk Settings ..................................................................................... 19

3.1.4 System Logger Settings ............................................................................ 20

3.1.5 Web Server Settings................................................................................. 20

3.1.6 Install Point Settings ................................................................................ 20

3.1.7 SMS Gateway Settings.............................................................................. 20

3.2 /etc/rc.d/rc.local............................................................................................. 20

3.3 Resetting Configuration ................................................................................... 21

3.4 Advanced Configuration................................................................................... 21

4 Using the System.............................................................................................. 22

4.1 Bluetooth ...................................................................................................... 22

4.1.1 Bluetooth Server Socket Interface Password Protection ................................. 22

4.1.2 LAN Access Profile.................................................................................... 22

4.1.3 Serial Port Profile ..................................................................................... 22

4.1.4 Object Push and File Transfer Profile ........................................................... 23

4.1.5 PAN Profile.............................................................................................. 24

4.1.6 Bluetooth Range Changing ........................................................................ 24

4.1.7 BTCLI - Bluetooth Server Command Line Interface Utility............................... 24

4.1.8 Serialbluetooth ........................................................................................ 24

4.2 Compact Flash GPRS Card................................................................................ 25

4.2.1 SIM Card’s PIN code................................................................................. 25

4.2.2 GPRS Troubleshooting .............................................................................. 25

4.2.3 Console Message "serial_cs: ParseTuple: Bad CIS tuple"................................ 25

4.3 Compact Flash WLAN ...................................................................................... 26

4.3.1 Hostap Driver .......................................................................................... 26

4.3.2 Hermes Driver ......................................................................................... 26

4.3.3 General Configuration............................................................................... 27

4.4 Servers ......................................................................................................... 27

4.4.1 Web Server............................................................................................. 28

4.4.2 Install Point............................................................................................. 28

4.4.2.1 Install Point configuration ................................................................... 29

4.4.2.2 Install Point example configuration ...................................................... 29

4.4.3 SMS Gateway Server ................................................................................ 30

4.4.4 User Level Watchdog ................................................................................ 30

4.4.5 Remote Management................................................................................ 30

4.4.5.1 Overview.......................................................................................... 30

4.4.5.2 Management Packet Format................................................................ 31

4.4.5.3 Management Packet Information File Format ......................................... 32

4.4.5.4 Management System Environment Variables ......................................... 32

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.4.5.5 Management Operation Example: IPQUERY ........................................... 32

4.4.5.6 Management Reply Packet Destination Definition ................................... 33

4.4.5.7 Management With USB Memory Dongle ................................................ 34

4.4.6 FTP ........................................................................................................ 34

4.4.7 SSH ....................................................................................................... 34

4.4.8 Telnet .................................................................................................... 34

4.5 Utilities ......................................................................................................... 34

4.6 Real Time Clock.............................................................................................. 37

4.7 Time Zone ..................................................................................................... 38

4.8 System Re-Install and Upgrade ........................................................................ 38

5 Bluetooth Technology Overview ....................................................................... 39

5.1 Frequency Bands and Channel Arrangement ....................................................... 39

5.2 Power Considerations ...................................................................................... 40

5.3 Radio Frequency Propagation ........................................................................... 40

6 Introduction to SDK.......................................................................................... 42

7 Installing the WRAP Software Development Environment ................................ 43

7.1 WRAP Software Development Environment System Requirements ......................... 43

7.2 Questions Asked by the Install Script................................................................. 43

8 Creating WRAP Applications ............................................................................. 45

8.1 Application Examples ...................................................................................... 45

8.1.1 Installing Examples .................................................................................. 45

8.1.2 Running Examples.................................................................................... 45

8.2 Creating a New Project .................................................................................... 47

8.3 Building From the Command Line...................................................................... 47

8.4 Transferring an Application to WRAP Hardware ................................................... 48

8.4.1 Transferring an Application to WRAP Using (S)FTP or SCP .............................. 48

8.4.2 Transferring an Application to WRAP Using Terminal Software ........................ 49

8.4.3 Using NFS mount ..................................................................................... 49

8.5 Running an Application Transferred to WRAP ...................................................... 49

8.6 Using Debugger (GDB/DDD) ............................................................................ 49

9 Bluetooth Server Socket Interface.................................................................... 51

9.1 Terms ........................................................................................................... 51

9.2 Starting the Bluetooth Servers.......................................................................... 51

9.3 Basic Commands ............................................................................................ 51

9.3.1 Info ....................................................................................................... 53

9.3.2 Inquiry ................................................................................................... 54

9.3.3 Name ..................................................................................................... 55

9.3.4 Quit ....................................................................................................... 56

9.3.5 Set ........................................................................................................ 57

9.3.6 Ping ....................................................................................................... 63

9.3.7 Pong ...................................................................................................... 64

9.3.8 Shutdown ............................................................................................... 65

9.3.9 Sleep ..................................................................................................... 66

9.4 Connection Commands and Replies ................................................................... 67

9.4.1 Call ........................................................................................................ 67

9.4.2 Connect.................................................................................................. 69

9.4.3 No Carrier............................................................................................... 70

9.4.4 Ring....................................................................................................... 71

9.4.5 Close...................................................................................................... 72

9.4.6 List ........................................................................................................ 73

9.4.7 Status .................................................................................................... 74

9.5 Service Discovery ........................................................................................... 75

9.5.1 SDP bdaddr UUID .................................................................................... 76

9.5.2 SdpSearch .............................................................................................. 77

9.5.3 SdpAttr .................................................................................................. 78

9.5.4 SdpQuery ............................................................................................... 79

9.5.5 Sdp........................................................................................................ 80

9.6 Example Sessions ........................................................................................... 80

9.7 Error Codes ................................................................................................... 81

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.8 WRAP Obex Libraries....................................................................................... 86

9.8.1 libobex ................................................................................................... 86

9.8.2 libobexclient............................................................................................ 87

9.8.3 Obexbrowser........................................................................................... 88

10 I/O API ............................................................................................................ 90

10.1 LED/BUZZER API .......................................................................................... 90

10.2 GPIO API ..................................................................................................... 90

11 About Bluegiga ................................................................................................. 91

Appendix A – WRAP Directory Structure................................................................... 93

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

1 INTRODUCTION

WRAP™

Bluegiga's WRAP product family offers for device manufacturers, teleoperators, integrators,

enterprises and platform developers a simple and fast way to set-up wireless communication

systems between standard or proprietary mobile devices, networks, machines and

instruments.

WRAP™ Multiradio Access Server

WRAP™ Multiradio Access Server is a cutting edge wireless Bluetooth basestation supporting

WLAN, Ethernet and GSM/GPRS offering TCP/IP connectivity. It can be deployed into existing

wired or wireless networks without uncompromising the speed, security and ease of

installation and management. WRAP Multiradio Access Server is an open platform for creating

and hosting also local applications and content in the Access Server. Bluegiga also provides

several additional software packages for different purposes; embedded device's Bluetooth

networking, mobile phone TCP/IP connectivity and generic application installation for different

mobile handsets.

It has support for multiple Bluetooth radios (model 2291 has one and model 2293 has three

installed) with configurable range up to 100 meters (class 1), USB host and Compact Flash.

The WRAP Multiradio Access Server enables you to connect a variety of equipment directly to

networks. As a software platform, WRAP Multiradio Access Server runs Linux 2.4 in powerful

ARM processor and has free memory for runtime and persistent storage use of the user

applications.

1.1 LICENSES AND WARRANTY

Warning: Bluegiga Technologies is hereby willing to license the enclosed WRAP product and its

documentation under the condition that the terms and conditions described in the License

Agreement are understood and accepted. The License Agreement is supplied within every

WRAP product both in hard copy and soft copy (file \doc\WRAP_eula.pdf on the WRAP CD-

ROM). The use of the WRAP product will indicate your assent to the terms. If you do not agree

to these terms, Bluegiga Technologies will not license the software and documentation to you,

in which event you should return this complete package with all original materials, equipment,

and media.

The following software components: GCC compiler tool chain, Linux kernel, and Linux-userland

applications are licensed under the terms and conditions of the GPL General Public License (file

\doc\GPL.txt on the WRAP CD-ROM). Upon request, Bluegiga will distribute a complete

machine-readable copy of the source of the aforementioned software components during a

period of three (3) years from the order date of the product. Delivery costs of the source code

will be charged from the party requesting the source code.

The Bluegiga WRAP Product Limited Warranty Statement is located in the file

\doc\WRAP_warranty.pdf on the WRAP CD-ROM.

1.2 CERTIFICATION INFORMATION

The product is CE approved and Bluetooth qualified v.1.1. It has been measured against the

following specification standards: Radio spectrum Matters (R&TTE, Article 3.2) ETSI EN 300

328-2 v1.3.1. / EN 301 489-1/17, and FCC part 15.247. Supported Bluetooth profiles are:

GAP, SDAP, LAN client and server, SPP A and B, FTP client and server, ObjP client and server,

PAN-PANU, PAN-GN and PAN-NAP.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Hereby, Bluegiga Technologies declares that this WRAP Multiradio Access Server is in

compliance with the essential requirements and other relevant provisions of Directive

1999/5/EC.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by 1 or

more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio or television technician for help

Warning: Changes or modifications made to this equipment not expressly approved by

Bluegiga Technologies Inc. may void the FCC authorization to operate this equipment.

The radiated output power of the WRAP Multiradio Access Server is far below the FCC radio

frequency exposure limits. Nevertheless, the WRAP Multiradio Access Server should be used in

such a manner that the potential for human contact during normal operation is minimized.

To meet the FCC’s exposure rules and regulations:

• The antenna(s) used for this transmitter must be installed to provide a separation

distance of at least 20 cm from all the persons.

• Any transmitter installed in the CF card slot must not exceed 4 W of e.i.r.p. To check if

a particular equipment complies with this restriction you need to know its FCC ID

number and visit the searching engine in FCC web site in the following Internet address,

where you can find the output power by the equipment in the grant of the equipment

https://gullfoss2.fcc.gov/prod/oet/cf/eas/reports/GenericSearch.cfm

If this link does not work properly please visit FCC website (http://www.fcc.gov) and

follow the following steeps to find the searching engine:

FCC website Æ Office of Engineering Technology Æ Equipment Authorization Electronic

Filing Æ Generic Search

Please notice that the output power listed in the grant uses different units depending on

the type of the equipment, e.g.:

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

1. The output power for 802.11a/b/g/h equipment or similar equipment approved

under §15.247 or §15.407 is listed as Conducted RF power. §15.247 or §15.407

limit the e.i.r.p. to 4 W, so this restriction is fulfilled.

2. The output power for Part 22 cellular equipment is listed as e.r.p. The

relationship between e.r.p. and e.i.r.p. is the following one:

e.i.r.p. = 1.64 x e.r.p.

3. The output power for Part 24 PCS equipment is listed as e.i.r.p.

4. For other type of equipment please consult the distributor in order to assure the

restriction is fulfilled.

Note: Definitions:

Effective Radiated Power (e.r.p.) (in a given direction): The product of the power supplied to

the antenna and its gain relative to half-wave dipole in a given direction.

Equivalent Isotropically Radiated Power (e.i.r.p.) (in a given direction): The product of the

power supplied to the antenna and its gain relative to an isotropic antenna.

The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum

Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure:

Frequency Range (MHz) Power Density (mW/cm2)

300 – 1500 f/1500

1500 – 100 000 1.0

The equipment WRAP Multiradio Access Server transmits in the 2400 - 2483.5 MHz frequency

range, so the applicable MPE limit is 1 mW/cm2. The equipment can be provided with up to 4

Bluetooth modules WRAP THOR 2022-1-B2B (FCC ID: QOQWRAP2022-1-B2B):

Under the conditions stated above MPE limits can be guaranteed as the calculation below

shows:

Example 1:

15.247 or 15.407 Compact Flash Card with maximum allowed e.i.r.p. of 4W

Using equation from page 18 of OET Bulletin 65, Edition 97-01:

S = P·G/4πR2 = Prad (e.i.r.p.)/4πR2

Where,

S = power density in mW/cm2 (1 mW/cm2 used for G)

P = power input to the antenna

G = power gain of the antenna in the direction of interest relative to an isotropic radiator

R = distance to the centre of radiation of the antenna in cm (20cm Prediction distance)

S Compact Flash card = Prad (e.i.r.p.) Compact Flash card /4πR2 = 4000mW/4π(20cm)2

we obtain the following results:

S Compact Flash card = 0.795774mW/cm2

S Total = 4 x S module + S Compact Flash card = 4 x 0.003579mW/cm2 + 0.795774mW/cm2

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

S Total = 0.014316mW/cm2 + 0.795774mW/cm2 = 0.795774mW/cm2 < 1mW/cm2

Example 2:

Part 22 Compact Flash Card with maximum e.r.p. of 1.5 W (Category excluded of MPE

evaluation according to §2.1091)

Using equation from page 18 of OET Bulletin 65, Edition 97-01 and considering that e.i.r.p. =

1.64 x e.r.p.:

S Compact Flash card = Prad (e.i.r.p.) Compact Flash card /4πR2 = 1500 x 1.64mW / 4π(20cm)2

S Compact Flash card = 0.489401mW/cm2

S Total = 4 x S module + S Compact Flash card = 4 x 0.003579mW/cm2 + 0.489401mW/cm2

S Total = 0.014316mW/cm2 + 0.489401mW/cm2 = 0.503717mW/cm2 < 1 mW/cm2

Example 3:

Part 24 Compact Flash Card with maximum e.r.p. of 3 W (Category excluded of MPE

evaluation according to §2.1091)

Using equation from page 18 of OET Bulletin 65, Edition 97-01 and considering that e.i.r.p. =

1.64 x e.r.p.:

S Compact Flash card = Prad (e.i.r.p.) Compact Flash card /4πR2 = 3000 x 1.64mW / 4π(20cm)2

S Compact Flash card = 0.978803 mW/cm2

S Total = 4 x S module + S Compact Flash card = 4 x 0.003579mW/cm2 + 0.978803 mW/cm2

S Total = 0.014316mW/cm2 + 0.978803mW/cm2 = 0.993119mW/cm2 < 1mW/cm2

1.3 BLUEGIGA TECHNOLOGIES CONTACT INFORMATION

Please see http://www.bluegiga.com/ for news and latest product offers. For more information,

contact sales@bluegiga.com.

Please check http://www.bluegiga.com/techforum/ for software and documentation updates.

Please contact support@bluegiga.com if you need more technical support. To speed up the

processing of your support request, please include as detailed information on your product and

your problem situation as possible. Please begin your email with the following details:

• WRAP product type

• WRAP product serial number

• WRAP software version

• End customer name

• Date of purchase

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

2 CONTROLLING THE ACCESS SERVER

There is no graphical user interface for the WRAP Multiradio Access Server. All controlling

operations to the Access Server must be done either by entering commands and using

applications at Access Server shell prompt or by sending and/or retrieving files to/from the

Access Server. There are several ways to access the shell prompt and to transfer files.

2.1 PHYSICAL INTERFACES

The physical interfaces of the Access Server are described in Figure 1 and Figure 2.

Figure 1. WRAP Multiradio Access Server Connectors.

NOTE: The power adapter is the disconnection device, the socket-outlet shall be installed near

the equipment and shall be easy accessible. The power led (see Figure 2) is on when the

power adapter is connected.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Figure 2. WRAP Multiradio Access Server LEDs.

2.2 SHELL PROMPT ACCESS

You can get to the shell prompt using either the management console, SSH or telnet. Normally

the initial configuration, if needed, is done from the management console over the serial cable

and all further controlling activities are performed remotely using SSH or telnet sessions over

Ethernet or Bluetooth LAN / PAN connection.

If you can make SSH or telnet connections from a device that has Bluetooth LAN Access or

PAN profile support, you don’t need the management console. Just connect the Access using

LAN Access or PAN profile. The Access Server can be seen in Bluetooth inquiries as

"Wserialno_n", where "serialno" is the serial number of the device and "n" is the number of the

Bluetooth radio in guestion (model 2293 has three Bluetooth radios, any of which can be

connected). After you have connected (no PIN code / username / password needed), connect

using SSH or telnet to the device in the other end of the connection, typically 192.168.160.1.

When logging in for the first time, log in as the user "root", and enter anything for password.

2.2.1 MANAGEMENT CONSOLE

If you don't have Bluetooth LAN/PAN client and you don't have the Access Server connected to

your LAN or you don't know the IP address given to the Access Server, you can get the first

shell prompt access using the management console. To set up management console do the

following:

1. Have a PC with a free COM port.

2. Power off the Access Server.

3. Configure your terminal application, like HyperTerminal in Windows, to use the

following settings with the free COM port:

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Setting Value

Speed 115 200 bps

Data Bits 8

Parity None

Stop Bits 1

Flow Control None

Table 1. The Management Console Port Settings.

4. Connect the serial cable shipped with the Access Server to your PC's free COM port.

5. Connect the null-modem adapter shipped with the Access Server to the serial cable.

6. Connect the serial cable with the null-modem adapter to the management / user port in

the Access Server (see Figure 1).

7. Power on the Access Server.

8. Enter letter "b" in the terminal application during the first five seconds, while the blue

LEDs in the Access Server turn on one by one.

9. The management console is now activated and you should see the boot log in your

terminal window. Wait for the device to boot up and end with the prompt "[root@wrap

/]$ "

10. You are ready to control the Access Server from the management console.

2.2.2 ACCESSING REMOTELY

When the WRAP is connected to a LAN it tries to get the IP address using DHCP by default.

One way to see the IP address of the WRAP board, connect to the WRAP with a management

console, power on the board and, after the system is up and running, give the command

"ifconfig nap". The field "inet addr" for the interface "nap" contains the IP address of the WRAP

board. For example, in the following capture from the management console, the IP address is

"10.1.1.43":

[root@wrap /]$ ifconfig nap

nap Link encap:Ethernet HWaddr 00:07:80:00:04:6C

inet addr:10.1.1.43 Bcast:10.255.255.255 Mask:255.255.255.0

inet6 addr: fe80::207:80ff:fe00:46c/64 Scope:Link

UP BROADCAST MULTICAST MTU:1500 Metric:1

RX packets:12635 errors:0 dropped:0 overruns:0 frame:0

TX packets:8 errors:0 dropped:0 overruns:0 carrier:0

collisions:0 txqueuelen:100

RX bytes:1686246 (1.6 MiB) TX bytes:1640 (1.6 KiB)

Interrupt:24 Base address:0xc000

You can use this address to connect the Access Server remotely via SSH, telnet, FTP, SFTP.

2.3 TRANSFERRING FILES TO/FROM THE ACCESS SERVER

You can transfer file to and from the access server by default using for example:

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

- SCP (secure copy over SSH)

- SFTP (secure ftp connection over SSH)

- FTP (plain ftp connection), remember integrated client of the Internet Explorer

(type ftp://root:passwd@wrap-ip-address/ in address bar)

- Bluetooth OBEX (Object Push and File Transfer Profiles) to/from directory

"/tmp/obex" in WRAP Access Server

- NFS (mount a nfs-share from a remote device as a part of the file system of the

Access Server)

- USB memory dongle (mount it as a part of the file system of the Access Server)

- Xmodem/Ymodem/Zmodem (use "rz/rx/rb/sz/sx/sb" commands from the

management console)

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

3 CONFIGURATION

When the WRAP is installed and powered up for the first time, the default configuration

settings are being used. With these settings, the WRAP automatically configures its network

settings assuming that the board is connected to a LAN network with a DHCP server running.

After booting, you can use the WRAP as a Bluetooth LAN/PAN access point to the network

without any changes in configuration. Also, the Serial Port Profile is enabled by default in

listening mode. You can also use Object Push and File Transfer Profiles to send files to/from

the WRAP.

3.1 USING THE SETUP APPLICATION

The basic configuration settings can be changed using the "setup" application. It displays the

settings in a hierarchical menu. Navigating the menu is accomplished by entering the number

or letter corresponding to the setting to be viewed and/or changed and pressing <enter>.

Pressing only <enter> either accepts the previous value of the setting or returns to the

previous level in the menu hierarchy. The settings and their meanings, as well as their default

values are described in the following sections.

Note: Ensure that your terminal application transmits only Carriage Return (CR) when the

<enter> key is pressed. If your terminal transmits both CR and LF, you cannot navigate in the

"setup" application.

3.1.1 NETWORK CONFIGURATION

1. Enable Interface Eth0 [Y]

This option determines whether or not an Ethernet interface is brought up at all at boot.

If set to no, the other options in the Network Configuration menu are not visible.

2. Hostname of the Device [wrap]

The hostname of the WRAP device. Local applications will see this name.

3. Domain of the Device [locadomain]

The domain name of the WRAP device. Local applications will see this name.

4. Time Server []

Hostname (or IP address) of the time server connected at system boot to retrieve

correct time using the Time Protocol (RFC 868)

5. Use Dynamic Network Configuration [Y]

This option determines whether or not automatic configuration of the Ethernet interface

using DHCP should be attempted at boot. If set to yes, the following options in the

Network Configuration menu are not visible.

6. IP Address of the Host [10.0.0.101]

If the dynamic network configuration is disabled (step 5), the IP address of the WRAP

must be entered here.

7. Subnet Mask [255.255.255.0]

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

If the dynamic network configuration is disabled (step 5), the network mask of the

WRAP must be entered here.

8. IP Address of the Default Gateway [10.0.0.254]

If the dynamic network configuration is disabled (step 5), the IP address of the default

gateway in the LAN to which the WRAP is connected must be entered here.

9. IP Address of the Primary Name Server [10.0.0.1]

The IP address of the primary name server.

10. IP Address of the Secondary Name Server [10.0.0.2]

The IP address of the secondary name server.

3.1.2 BLUETOOTH SETTINGS

The Bluetooth settings are divided into general and profile specific settings, and are described

in the following sections.

3.1.2.1 GENERAL BLUETOOTH SETTINGS

1. Friendly Name [W$S_$p]

The name shown when this device is found when inquired about by other Bluetooth

devices. The name may end with asterisk (*), which will be replaced with the last 3

digits of the serial number of the WRAP board.

2. Bluetooth Server Socket Interface Password []

The password required to be entered before any commands when discussing with the

WRAP Bluetooth Server Socket Interface. Can be empty.

3. Connectable and Discoverable Mode [3]

The setting specifying whether this device is connectable and/or discoverable or not by

other Bluetooth devices.

When a device is connectable, other Bluetooth devices can make a Bluetooth connection

to it. Before making a connection, the calling device must know the Bluetooth address

of the device it is connecting to. The Bluetooth addresses can be found by making an

inquiry. When a device is discoverable, it shows up in inquiries. Possible values for all

combinations of these settings are:

0. Not connectable, not discoverable

1. Not connectable, discoverable

2. Connectable, not discoverable

3. Connectable and discoverable (default)

4. Master/Slave Role Switch Policy [1]

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

The setting specifying how the connecting Bluetooth devices should decide their roles.

When a device is calling another Bluetooth device, it originally is the master and the

answering device is the slave. When the connection is being built, a role switch can be

made. Normally, access point devices want to be the master for all their slaves, and

therefore they require a master-slave switch when a new device is connecting. This is

also how the WRAP is configured by default. Other possible combinations are:

0. Allow switch when calling, do not request when answering

1. Allow switch when calling, request when answering (default)

2. Do not allow switch when calling, request when answering

If you have problems with connecting to the WRAP, it might be due to the fact that your

client device does not support a master/slave switch. In this case, set this setting to

"0".

5. Default PIN Code []

The PIN code used when establishing connections. Up to 16 characters are significant.

If there is no default PIN code, the WRAP does not require a PIN code when

establishing connections. If in this case the other device requests a PIN code, the

default PIN code "1234" is sent, following the Bluetooth specification.

6. Power Save Mode and Parameters [4]

The power save mode used by default for all connections.

0. Active

1. Park: Round-robin

2. Park: Idle

3. Sniff: All

4. Sniff: Idle

3.1.2.2 LAN ACCESS PROFILE SETTINGS

1. Enable Lan Access Profile [Y]

Whether or not the LAN Access Profile is enabled.

2. Lan Access Login Name and Password []

The login name and password required from LAN Access Clients. Must be entered as a

single string, separated with a space. For example: "guest buffy". If empty (default), no

3. Service Name (shown in SDP) [Lan Access Using PPP]

The name of this service as shown in the Service Discovery.

3.1.2.3 SERIAL PORT PROFILE SETTINGS

Note: The visibility of some of these settings is controlled by the "Act as the Calling Device"

setting.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Note2: the Serial Port Profile is disabled if the SMS Gateway is enabled, as they share the

same physical serial port.

1. Enable Serial Port Profile [Y]

Whether the Serial Port Profile is enabled or not.

2. Act as the Calling Device [N]

Whether this device should act as the calling device (DevA) or the answering device

(DevB).

3. BPS Rate [9600]

The bits-per-second rate of the connection. Possible values are 300, 1200, 2400, 4800,

9600, 19200, 38400, 57600, 115200, 230400, and 460800.

4. Data Bits [8]

The number of data bits in the connection. Possible values are 5, 6, 7, and 8.

5. Parity [0]

The parity bit setting of the connection. Possible values are: 0: no parity, 1: odd parity,

and 2: even parity.

6. Stop Bits [1]

The number of stop bits in the connection. Possible values are 1 and 2.

7. Hardware Flow Control (RTS/CTS) [Y]

Whether or not the hardware flow control is used in the connection.

8. Software Flow Control (XON/XOFF) [N]

Whether or not the software flow control is used in the connection.

9. Service Name (shown in SDP) [Serial Port]

The name of this service as shown in the Service Discovery. (This setting is visible only

when setting 2., "Act as the Calling device", is disabled.)

10. Bluetooth Address of the Remote Device [00:07:80:80:01:1f]

The Bluetooth address of the device to be contacted. (This setting is visible only when

setting 2., "Act as the Calling device", is enabled.)

11. Server Channel of the Remote Device [2]

The Bluetooth server channel of the device to be contacted. (This setting is visible only

when setting 2., "Act as the Calling device", is enabled.)

12. Optional Command Line Parameters for SPP Application []

Optional extra parameters for the WRAP Serial Port Profile application. Currently the

only supported parameter is "--msc", which enables transmitting of DCD/DSR status in

MSC. By default, they are not transmitted.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

3.1.2.4 OBEX SETTINGS

1. Enable Object Push Profile [Y]

Whether or not the Object Push Profile is enabled.

2. Service Name (shown in SDP) [OBEX Object Push]

The name of this service as shown in the Service Discovery.

3. Enable File Transfer Profile [Y]

Whether or not the File Transfer Profile is enabled.

4. Service Name (shown in SDP) [OBEX File Transfer]

The name of this service as shown in the Service Discovery.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

3.1.2.5 PERSONAL AREA NETWORK PROFILE SETTINGS

1. Personal Area Network User (PANU) Profile

1. Enable PANU

Whether or not the PAN User Profile is enabled.

2. Service Name (shown in SDP) [PAN User]

The name of this service as shown in the Service Discovery.

2. Personal Area Network Generic Networking (PAN-GN) Profile

1. Enable PAN-GN [Y]

Whether or not the PAN Generic Networking Profile is enabled.

2. Use Dynamic Network Configuration for Local IP Address [N]

Whether or not DHCP is used for configuring Local IP Address. Enable only if you

are connecting this PAN-GN to another PAN-GN that will provide the IP

configuration.

3. Local GN Interface IP Address [192.168.161.1]

The IP address for the local GN interface (if the dynamic configuration is not

used; step 2 above).

4. Local GN Interface Netmask [255.255.255.0]

The netmask for the local GN interface (if the dynamic configuration is not used;

step 2 above).

5. Start DHCP Server for Remote Devices [Y]

Whether or not this device should launch DHCP for Remote Devices connecting

to this PAN-GN. Disabled if dynamic configuration is used; step 2 above.

6. Service Name (shown in SDP) [Generic Networking]

The name of this service as shown in the Service Discovery.

3. Personal Area Network Network Access Point (PAN-NAP) Profile

1. Enable PAN-NAP

Whether or not the PAN Network Access Point Profile is enabled.

2. Service Name (shown in SDP) [Network Access Point]

The name of this service as shown in the Service Discovery.

3.1.3 RAMDISK SETTINGS

1. Size of the ramdisk (in kilobytes) [512]

The size of the ramdisk (/mnt/ram/). Sizes below minimum (currently 50) and above

maximum (currently 20480) are not allowed.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

3.1.4 SYSTEM LOGGER SETTINGS

1. Log locally [Y]

This option determines whether or not the System Logger (syslogd) should log locally

(to /var/log/messages).

2. Address of the Remote Syslog Server []

The address of the device in the network to which the System Logger should log to.

Note: The remote device must be configured to accept syslogd connections from the

WRAP board. See the system logger documentation on the remote device for more

information on how to accomplish that.

3.1.5 WEB SERVER SETTINGS

1. Enable Web Server [Y]

Whether or not the Web (WWW) server is enabled.

2. Web Server Root Directory [/var/www/html]

The directory where the WWW pages to be served by the Web server are located.

3.1.6 INSTALL POINT SETTINGS

1. Install Point logging device [/dev/null]

The file to which the Install Point writes its logs. Use /dev/console for console output

and, for example, /tmp/installpoint.log if you want to save this information. Be careful,

however, not to fill the RAM file system (use a cron job to free disk space from time to

time).

Note: If the file is invalid, Install Point is not started at boot.

3.1.7 SMS GATEWAY SETTINGS

Note: The SMS Gateway is disabled by default, as the Serial Port Profile is enabled by default,

and they share the same physical serial port. Disable the Serial Port Profile first to be able to

enable the SMS Gateway.

1. Enable SMS Gateway at startup [N]

Whether or not the SMS Gateway (smsgw) should be started automatically when the

system boots up.

2. SMS Gateway logging device [/dev/null]

The file to which the SMS Gateway (smsgw) logs all traffic. Use /dev/console for

console output and, for example, /tmp/smsgw.log if you want to save this information.

Be careful, however, not to fill the RAM file system (use a cron job to free disk space

from time to time).

3.2 /ETC/RC.D/RC.LOCAL

While not configurable with the "setup" application, the file "/etc/rc.d/rc.local" is important for

system boot configuration. It is the last init script executed at system startup.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

By default, the script "/etc/rc.d/rc.local" just turns off all LEDs to indicate the startup has

finished. If you want to initialize something automatically at every boot, or start up your own

servers, for example, you should add the required commands here. You can use "vi" editor to

edit the file.

3.3 RESETTING CONFIGURATION

You can restore the default configuration by deleting the main configuration file and rebooting

the board. When the system starts up, the default configuration settings are restored. If you

have only changed the configuration by using the "setup" application, the following commands

at the WRAP command prompt will suffice:

[root@wrap /]$ rm /etc/sysconfig/config.xml

[root@wrap /]$ reboot

3.4 ADVANCED CONFIGURATION

More advanced configuration can be done by editing the appropriate files in the /etc directory.

Do not alter these files unless you are an expert user. The files that are the most "safe" to

edit, and their respective purposes, are listed in Table 2.

Note: Files are in Linux text file format, where the lines end with a single Line Feed (LF, "\n")

character. Some applications will not work if the configuration file format is changed to DOS

format, where the lines end with both Carriage Return and Line Feed (CR+LF, "\r\n")

characters.

File Purpose

/etc/bluetooth.conf WRAP Bluetooth Server Socket Interface

commands that are run every time the

Bluetooth Server is started. See section 9 for

details.

/etc/crontab Cron daemon settings. Standard crontab

format. Note: cron is not enabled by default.

You must enable it with command "chkconfig

--add cron".

/etc/stupid-ftpd/stupid-ftpd.conf FTP daemon configuration file. Self

documented.

/etc/installpoint.conf Install Point configuration file. See section

4.4.2 for details.

/etc/smsgw.conf SMS Gateway configuration file. See section

4.4.3 for details.

/etc/profile Basic user profile.

Table 2. The Supported Advanced Configuration Files.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4 USING THE SYSTEM

This chapter describes the basic features of a Bluegiga WRAP Multiradio Access Server and

their usage. This includes information on using the WRAP board as a Bluetooth LAN/PAN

Access Point or a Bluetooth Serial Port Cable Replacer, using the Web Server, Install Point,

WRAP Package Management System and the various ways for uploading content for browsing

and/or downloading, as well as getting familiar with the utility applications.

Using the features described in this chapter does not require the WRAP Software Development

Environment to be installed.

4.1 BLUETOOTH

The Bluetooth servers are started automatically at power-up. By default, all servers act as a

LAN Access point following the LAN Access Profile specification. The Serial Port, PAN and Object

Push and File Transfer Profiles are also activated. The Bluetooth servers can be accessed and

controlled (by applications or even interactively with a telnet client) using the socket interface,

described in the Development section of the manual. Currently, there can be up to 14

simultaneous Bluetooth (RFCOMM) connections between the master WRAP and up to 7

simultaneous slaves.

4.1.1 BLUETOOTH SERVER SOCKET INTERFACE PASSWORD PROTECTION

The access to the Bluetooth Server Socket Interface can be password protected. By default,

the password is not in use, but it can be set with the "setup" application (see section 3.1.2.1).

The password is case sensitive. The password must be typed in as the first command after the

server has replied with "READY."

4.1.2 LAN ACCESS PROFILE

This profile is automatically started at boot. By default, no authentication is needed. The

default settings can be changed with the "setup" application (see section 3.1.2.2), or runtime

with the socket interface (see the Bluetooth developer documentation in chapter 9).

The WRAP board can also act as a LAN Access Client, but in this case it must be controlled

manually using the socket interface, described in the Bluetooth developer documentation.

4.1.3 SERIAL PORT PROFILE

The Serial Port Profile is used to replace an RS-232 serial cable between two devices with a

Bluetooth connection. The physical setup is shown in Figure 3.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Serial Cable

User

device A

User

device B

Serial

Cable

User

device A

User

device B

Serial

Cable

WRAP

DevA

WRAP

DevB

Bluetooth

Figure 3. Serial Cable Replacement Physical Setup.

State A) in the figure is the starting situation with a serial cable connecting the devices. This

cable is to be replaced with a Bluetooth connection.

In state B) the long serial connection is replaced with a Bluetooth Serial Port Profile connection

between the two WRAP devices. These WRAP devices are then connected locally to the user

devices with (short) serial cables. The cable between user device A and WRAP device A must

be a cross-over cable. The cable between user device B and WRAP device B must be similar

(direct or cross-over) to the one used in state A).

If RTS/CTS handshaking is used to ensure correct data transfer, the serial cables must have

these pins connected. Note: This handshaking is "local": it takes place between the user

device and the WRAP board. No handshaking between user device A and user device B on the

other end of the Bluetooth connection is provided.

If RTS/CTS handshaking is not used, CTS must be connected to DTR.

DCD, DTR, and DSR signals are not supported. This also means that user devices A and B will

not be able to tell whether or not the Bluetooth connection is up.

When the physical setup is ready, you can create the Bluetooth connection. By default, the

Serial Port Profile is started up at boot with the default settings. That is, listening in DevB

mode, at 9600 bps, 8 data bits, no parity, 1 stop bit, and RTS/CTS enabled. To change these

settings, use the "setup" application, as described in section 3.1.2.3.

You can also start the Serial Port Profile manually by calling its init script: "/etc/init.d/spp

start".

Note: When the Serial Port Profile is enabled, the WRAP SMS Gateway Server can not be used,

as they share the same physical user serial port

4.1.4 OBJECT PUSH AND FILE TRANSFER PROFILE

The WRAP also has two OBEX profiles: the Object Push Profile (ObjP) and the File Transfer

Profile (FTP). You can use these profiles to transfer files easily between different WRAP devices

and other devices supporting them.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

These profiles are handled by forwarding incoming calls to "obexserver" program, which

handles both profiles. The OBEX working directory is /tmp/obex, and users have full read and

write access there. By default, that directory also contains the default vCard.

Two simple command line utilities, "obexput" and "obexget", are also provided. They can be

used to send and retrieve a single file to and from another Bluetooth device supporting OBEX.

Enter either of the commands without parameters to get a short help for using the command.

If the return value is non-zero, one of the following situations has happened: -2: --help, 2:

Invalid parameter, -3: Error connecting to control socket, -4: Failed talking to Bluetooth

Server, -1: Error connecting to data socket. Note that return value is zero (0) even if the OBEX

communication has failed. You should therefore scan the standard output of the command. On

error, you will see the OBEX error in format "Failed to <what>, errorcode <hexcode>" where

<what> can be "connect", "setpath", "put", "get" or "disconnect" and <hexcode> is the

obexclientlib return code in hexadecimal format for the corresponding command, documented

in 9.8.2.

4.1.5 PAN PROFILE

The WRAP Multiradio Access Server has support for all PAN profile modes: Personal Area

Network User (PANU), Network Access Point (NAP) and Group Node (GN).

The device creating the PAN connection decides, which of these modes are to be used.

Incoming connections are handled automatically by the WRAP. The WRAP board can also act as

a PAN Client, but in this case it must be controlled manually using the socket interface,

described in the Bluetooth developer documentation.

4.1.6 BLUETOOTH RANGE CHANGING

The transmit power of the WRAP Multiradio Access is configurable. By default, class 1 (100

meter range) settings are used. The settings can be changed down to "class 2" settings (10

meter range) with "b2b_class2" command or even less with "b2b_class3" command. The class

1 settings can be restored with "b2b_class1" command.

After "b2b_classX" is given, it is recommended to reboot the WRAP once to restart Install Point

and other applications connected to the Bluetooth server(s).

Note: When the operation is successful, you should get one "Can't open baseband" message

with WRAP Multiradio Access Server model 2293 and three messages with 2291.

4.1.7 BTCLI - BLUETOOTH SERVER COMMAND LINE INTERFACE UTILITY

You can send commands to a Bluetooth server using the "btcli" application.

Usage: btcli [options] command

To see the options, enter the command "btcli --help".

The specified command is sent to a WRAP Bluetooth server (default: first server at port 10101)

and all replies are echoed to the standard output. The application waits and prints the replies

for a certain amount of time (default: 10 seconds) and exits.

4.1.8 SERIALBLUETOOTH

It is also possible to control the first WRAP Bluetooth server (at port 10101) via RS-232 with

the "serialbluetooth" application. Note: When you want to use this application, you must first

disable the Bluetooth Serial Port Profile and the WRAP SMS Gateway Server with the "setup"

application, as described in chapter 3.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Usage: serialbluetooth [options]

To see the options, enter the command "serialbluetooth --help".

Basically, serialbluetooth takes commands from a serial port and forwards them to the

Bluetooth server. All the commands available via socket interface are also available via serial

port.

There are two exceptions:

1) After making an outgoing RFCOMM data call, all input from the serial port is forwarded to

the data socket, not the control socket. To close the data socket, you have to write "+++" with

a 200ms pause before each character. There is no way to have two concurrent RFCOMM calls.

2) All incoming RFCOMM calls are answered automatically. Again, to close the data socket,

write "+++" as with the outgoing call.

4.2 COMPACT FLASH GPRS CARD

The Compact Flash GPRS card is identified automatically by the operating system when

inserted. At that time, the device file "/dev/ttyS0" is created.

A GPRS connection is made with command "pppd call gprs" and closed by killing the pppd –

process handling the GPRS connection.

The connections settings are in the directory "/etc/ppp/peers". The default GPRS call settings

work with major Finnish operators (TeliaSonera, Radiolinja, DNA).

If needed for special use, the Compact Flash GPRS card can also be accessed directly from

"/dev/ttyS0".

4.2.1 SIM CARD’S PIN CODE

If your SIM card has PIN code checking enabled, insert the following line just after the line '""

AT' in file "/etc/ppp/peers/gprs.connect":

OK 'AT+CPIN="pincode"'

4.2.2 GPRS TROUBLESHOOTING

If you don’t get connection, check "/var/log/messages". To get more verbose error messages

from the GPRS modem, enable more verbose error codes by adding line "OK 'AT+CMEE=2'"

just after the line '"" AT' in file "/etc/pp/peers/gprs.connect".

4.2.3 CONSOLE MESSAGE "SERIAL_CS: PARSETUPLE: BAD CIS TUPLE"

Sometimes, the Compact Flash GPRS card does not get identified. Instead, an error message

"serial_cs: ParseTuple: Bad CIS tuple" appears at console and the device file "/dev/ttyS0" is

not created. This happens most likely because of timing problems but there is no fix available

yet.

As a workaround, one can force the identification process to restart with the command line: "[

! -c /dev/ttyS0 ] && cardctl eject && cardctl insert".

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.3 COMPACT FLASH WLAN

The WLAN configuration with "setup" application is not yet available. The currently supported

WLAN cards are "EZ Connect" by SMC Networks and "Instant Wireless" by Linksys. For this

kind of Prism II/III based CF WLAN cards there are two different drivers.

4.3.1 HOSTAP DRIVER

If your WLAN card firmware is 1.7.4, you have to use Hostap driver. It supports both client and

master modes. You can check the firmware version by inserting the card and entering

command "dmesg". If you see the following line among the latest ones, you have firmware

1.7.4:

eth1: Looks like an Intersil firmware version 1.7.4

To select Hostap driver enter the following command (ignore errors):

[root@wrap /]$ mv /etc/pcmcia/hostap_cs.conf.hermes

/etc/pcmcia/hostap_cs.conf

To use the master mode create the file "/etc/sysconfig/wlan" with one line "DISABLE=no", for

example with the following command:

[root@wrap /]$ echo DISABLE=no > /etc/sysconfig/wlan

To configure the master mode to use encryption, add following lines (replace examples with

your ESSID and encryption key, which can be also shorter for 40/64bit encryption) to the file

"/etc/sysconfig/wlan":

WEPKEY="0123456789abcdef0123456789"

ESSID="myessid"

To use client mode create the file "/etc/sysconfig/wlan" with one line "DISABLE=yes", for

example with the following command:

[root@wrap /]$ echo DISABLE=yes > /etc/sysconfig/wlan

In client mode you also have to configure client settings in the file

"/etc/sysconfig/network.pcmcia", see below.

4.3.2 HERMES DRIVER

You have to use Hermes driver if your WLAN card firmware is below 1.7.4. Hermes supports

only client modes.

To select Hermes driver enter command (ignore errors):

[root@wrap /]$ mv /etc/pcmcia/hostap_cs.conf

/etc/pcmcia/hostap_cs.conf.hermes

To configure WLAN to use DHCP, create the file "/etc/sysconfig/network.pcmcia" with one line

"DHCP=y", for example with the following command:

[root@wrap /]$ echo "DHCP=y" > /etc/sysconfig/network.pcmcia

To configure WLAN with static network settings, create the file

"/etc/sysconfig/network.pcmcia" similar to this example configuration:

DHCP=n

IPADDR="10.0.0.41"

NETMASK="255.255.255.0"

NETWORK="10.0.0.0"

BROADCAST="10.0.0.255"

GATEWAY="10.1.1.254"

SEARCH="local.net"

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

DNS_1="10.1.1.1"

To configure WLAN to use encryption, add following lines (replace examples with your ESSID

and encryption key, which can be also shorter for 40/64bit encryption) to the file

"/etc/sysconfig/network.pcmcia"

0123456789abcdef0123456789"

ESSID="myessid"

After configuration, the WLAN interface comes up automatically when the WLAN card is

inserted. The WLAN interface is "eth1".

4.3.3 GENERAL CONFIGURATION

Standard set of wireless utilities are provided to fine-tune your WLAN configuration:

• iwconfig

• iwlist

• iwpriv

For more info see: http://www.hpl.hp.com/personal/Jean_Tourrilhes/Linux/Tools.html

4.4 SERVERS

The WRAP server applications are started automatically at system power-up or when needed

by the Bluetooth server or the Internet services daemon. The servers and their purposes are

described in Table 3.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Server Purpose

bluetooth WRAP Bluetooth Server, described in detail in section 9.

btcli WRAP Bluetooth Server Command Line Interface utility.

httpd Web server, described in detail in section 4.4.1.

installpoint WRAP Install Point server.

smsgw WRAP SMS gateway server, described in detail in section 4.4.2. Note: By default,

this server is not started at power-up.

watchdog WRAP user level watchdog.

wpkgd WRAP remote management system daemon.

cardmgr Daemon to monitor Compact Flash cards.

crond Daemon to execute scheduled commands. Configurable with /etc/crontab in the

same way as any Linux crond. Note: By default, this is disabled. Use "chkconfig --

add cron" to enable.

ftpd Internet File Transfer Protocol Server. Configurable with /etc/stupid-ftpd/stupid-

ftpd.conf.

dhcpcd DHCP client daemon for automatic network configuration.

inetd Internet services daemon. Note: By default, this is disabled. Use "chkconfig --add

inet" to enable.

pppd Point to Point Protocol daemon. Used by the Bluetooth server. Can be used

manually over the user serial port (/dev/ttySA1).

sshd SSH daemon.

syslogd System logging daemon. Configurable with the setup application.

telnetd Telnet protocol server.

Table 3. WRAP Servers.

4.4.1 WEB SERVER

The integrated web server in the Bluegiga WRAP supports HTTP/1.0 methods GET and POST,

and has light user authentication capabilities. The content can be either static or dynamic – the

WWW server is CGI/1.1 compatible.

The web server is always running and the content (http://wrap-ip-address/) is located in the

/var/www/html/ directory in the WRAP file system. The directory can be changes using "setup"

–application, see subsection 3.1.5. By default, there is only a simple demonstration file,

index.html, there, but it can be replaced, and more directories and pages can be added.

For further information, see the web examples in section 8.1.

4.4.2 INSTALL POINT

The Install Point software is started automatically in the WRAP Multiradio Access Server. It

server two purposes:

1. Receives business cards (vCards), analyses their content and sends files back selecting

them based on configured keywords found.

2. Receives management packets and forwards them to the WRAP Package daemon. The

default configuration is empty, so no files can be requested with business cards.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.4.2.1 INSTALL POINT CONFIGURATION

The Install Point is configured both by the "setup" application (the logging device / file, see 5)

Install Point Settings) and mainly with its configuration file, "/etc/installpoint.conf".

The configuration file can consists of the following lines:

'#' starts comment line

- # InstallPoint(tm) database file

'%' starts storage directory name definition (only one, last one used)

- %/var/lib/installpoint

All other lines are assumed to be "database" lines with four white space separated fields. When

a request vCard is received, it is parsed and these lines are scanned. If a match is found, a

filename specified is sent. There can be several matches, when several files can be sent. If the

request is not vCard or .wpk file, but for example a picture, it is handled as if it was empty

vCard.

filename

- filename to be sent, must locate in storage directory

"alias"

- string that must match in name field (first name or last name (N) or formatted

name (FN)) field in the vCard

- use "*" for accepting any

- NOTE: alias must be in quotes (as formatted name may contain spaces).

pincode

- pincode that must be in the preferred telephone (TEL;PREF) or voice telephone

(TEL;VOICE) number field in the vCard

- use '*' (with no quotes) for no pin code

bdaddr

- bdaddr that is allowed to ask for this file

- use '*' (with no quotes) for allowing anyone to request

4.4.2.2 INSTALL POINT EXAMPLE CONFIGURATION

# example installpoint config file

%/var/lib/installpoint

ipquery.wpk "ip" * *

<EOF>

With this configuration, anyone can send a vCard with "ip" in then name field, and the file

called "ipquery.wpk" is then sent back. The file "ipquery.wpk" must be located in the storage

directory "/var/lib/installpoint".

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.4.3 SMS GATEWAY SERVER

The WRAP SMS Gateway server supports Nokia 20, Nokia 30 or Wavecom WMOD2 compatible

GSM terminals for sending and receiving SMS messages. The device must be connected to the

user serial port when the server starts up. The terminals must be configured to operate in RS-

232/AT-command mode and the PIN code query of the SIM-card at power-up must be

disabled. The Nokia terminals are configured with the N20 or N30 Configurator application.

To enable the WRAP SMS Gateway Server, use the "setup" application, as described in section

3.1.6.

For further information on using "smsgw", see the "makesms" example in section 8.1.

Note: You must disable the Bluetooth Serial Port Profile before you can enable the WRAP SMS

Gateway Server, as they share the same physical user serial port.

Note2: You can use also the supported GSM/GPRS Compact Flash cards with the WRAP SMS

Gateway. Just edit "/etc/smsgw.conf" so that SMS GW will use the device "/dev/ttyS0" instead

of the default "/dev/ttySA1". Also remember that the PIN code query of the SIM-card must be

disabled.

4.4.4 USER LEVEL WATCHDOG

The WRAP User Level Watchdog daemon listens on UDP port 4266 for "id timeout" messages.

"id" is an ASCII string, without spaces. If "timeout" equals to 0 (zero), the "id" is removed

from the list of processes to wait. If "timeout" is greater than 0 (zero), the "id" is added or

updated.

When there is no message for "id" received within the "timeout" seconds, the user level

watchdog dies and the WRAP is rebooted by the kernel watchdog.

The "watchdog" command can be used to send messages to the watchdog daemon. This is

done via command "watchdog id timeout", for example "watchdog test 5".

4.4.5 REMOTE MANAGEMENT

The WRAP Multiradio Access Server contains simple tools that provide base for full and secure

remote management of the device.

4.4.5.1 OVERVIEW

The WRAP Remote Management System top level architecture is shown in Figure 4.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

WPKGD INBOX

/tmp/wpkgd/in

InstallPoint

USB memory USB hotplug

WPKGD OUTBOX

/tmp/wpkgd/out

Bluetooth

Rsync over SSH

FTP

Scp, Sftp

WPKG

processing

Customer System

InstallPoint

USB memory USB writer

Bluetooth

Rsync over SSH

FTP

Scp, Sftp

Figure 4. WRAP Remote Management Architecture.

A management action is performed using the following protocol:

1. A management packet (*.wpk) is prepared by the customer system.

2. The management packet is delivered to WRAP, into packaging daemon’s inbox

directory. One can currently use Bluetooth, Rsync over SSH, Scp, Sftp and plain FTP to

do this. Also some USB memory dongles are supported, see subsection 4.4.5.7.

3. The WRAP packaging daemon processes the management packet, possibly generating

reply packet into daemon's outbox.

4. (optional) Reply packet is delivered (or retrieved) to the customer system.

4.4.5.2 MANAGEMENT PACKET FORMAT

- Package name must be of format "name.wpk", where "name" can be user

defined.

- Package must be tar –archive that is compressed with gzip (like files named

*.tar.gz or *.tgz)

- Package must contain package information file called "wpkg.pif" in package root

(contents described later)

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

- Optional signature information file "wpkg.sig" may exist in package root (it is not

used yet though)

- All other files, if exist, should be data files, scripts or executables required for

the management operation

4.4.5.3 MANAGEMENT PACKET INFORMATION FILE FORMAT

The management packet information file (wpkg.pif) consists of tags and their data, described

here

%wpkg-version:0.0.1

- Must be the first line of the file. Contains information for version checking. 0.0.1

is currently the only version supported. Cannot be multi-line.

%wpkg-prepare:[command line[s]]

- One or more commands (all lines until next tag are interpreted as command

lines) to execute. Commands may contain parameters, but output redirection

and job control does not work.

%wpkg-output:[output line[s]]

- One or more lines of texts (all lines until next tag are interpreted as output lines)

to output. Useful mainly in interactive use (not in remote management).

4.4.5.4 MANAGEMENT SYSTEM ENVIRONMENT VARIABLES

The management system communicates to the management packets via environment

variables. As of version 0.0.1, two variables are supported and set by the system for user

scripts to use:

WPKG_OUTDIR:

- WPKGD OUTBOX directory, the place where the reply packet should be

generated.

WPKG_ORIGIN:

- file containing one line which identifies the sender of the management packet.

As of version 0.0.1, if Bluetooth was used to transmit the management packet

and this file is moved to "reply_packet_name.origin" in the WPKG_OUTDIR, the

reply packet is sent automatically.

4.4.5.5 MANAGEMENT OPERATION EXAMPLE: IPQUERY

In this example we build a simple packet that can be used with Bluetooth-enabled phone to

retrieve IP Address of the WRAP Multiradio Access Server. More (complex) examples will be

available soon.

The package consists of the following files (see ipquery.wpk, unpack it with "tar xzvf

ipquery.wpk"):

File "wpkg.pif":

- package information file, just tells to run "./ipquery" file.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

File "functions":

- some reusable shell functions

File "ipvcard":

- script which outputs the serial number, ip address and hostname of the device in

vcard format that can be viewed with a mobile phone.

File "ipquery":

- the main script which calls "ipvcard" to generate response vcard and moves it

and the originator info file to WPKG_OUTDIR.

To use the example, send the file "ipquery.wpk" to the inbox of you Bluetooth phone. Check

that you have Bluetooth enabled in the phone. Then from the phone’s inbox, send the file

"ipquery.wpk" via Bluetooth to the WRAP Multiradio Access Server.

4.4.5.6 MANAGEMENT REPLY PACKET DESTINATION DEFINITION

The WRAP Package daemon (WPKGD) operates in a simple loop.

First it scans its inbox directory for files ending ".wpk" AND ".wpk.origin". When both of these

are found with similar beginning, the package is processed with "wpkg" command.

Then it scans its outbox for "filename" AND "filename.origin" files. If they both are found and

"filename.origin" contains supported address information (OBEX or USB currently), the reply

packet is send.

The content of the "filename.wpk.origin" file is one line of following formats:

"obex://bd:ad:dr:es:00:00/"

"usb://path/to/reply/"

"rsync://user@host.remote.domain:path/to/reply/"

"scp://user@host.remote.domain:path/to/reply/"

"ftp://user:password@host.remote.domain:path/to/reply/"

Currently the WRAP Package daemon can only automatically handle Bluetooth (OBEX) and USB

replies. Other replies must be retrieved from the remote site manually (from the WRAP

Package daemon’s outbox, /tmp/wrap/outbox/).

When a management packet is received via Bluetooth or USB in the future, the

"filename.wpk.origin" file is generated automatically.

If one wants to remotely execute management operations, the "filename.wpk.origin" file must

be created by oneself. So, to activate remote management operation, one must send the

management packet file ("filename.wpk") AND the management packet origin file

(“filename.wpk.origin”) into the WPKGD inbox directory.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.4.5.7 MANAGEMENT WITH USB MEMORY DONGLE

When an USB memory dongle is inserted, the WRAP Multiradio Access Server automatically

tries to mount (using VFAT type) it. When the mount is successful, directory "/wpkgd/in" is

searched for a "*.wpk" packet and if the packet is found, it handled by the WRAP Package

daemon. Optional responses are sent to the directory "/wpkgd/out" in the USB dongle, or if

"out" does not exist, to the directory "/wpkgd".

NOTE: Not all dongels are currently supported and the testing of the dongles is still ongoing.

So far, Buffalo and Sandisk dongles have passed, but for example JetFlash dongles cannot get

mounted. Failure with a non-supported USB dongle may need system to be restarted for a

supported dongle to work.

4.4.6 FTP

By default, users can use FTP to log in anonymously to "/tmp/obex" -directory with download

access or as "root" with password "buffy" to the root directory with full access. The password

can be changed on the WRAP editing the file "/etc/stupid-ftpd/stupid-ftpd.conf".

4.4.7 SSH

By default, users can use SSH to log in (or SCP to transfer files) as "root" with any password.

The password can be changed on the WRAP using the command "passwd".

4.4.8 TELNET

By default, users can use telnet to log in as "root" without password. The password can be

changed on the WRAP using the command "passwd". The telnet port is the default, 23.

4.5 UTILITIES

The WRAP is basically a small Linux system. Whether logged in from the management console

or with telnet, your shell session starts as the root user in the root directory. After that, you

have the option to use most of the standard Linux utilities, briefly listed and described in Table

4. Most of the commands have a small built-in usage help that can be seen by executing the

command with the "-h" or "--help parameter.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Application Purpose

adduser Add user to the system.

arping Ping hosts by ARP requests/replies.

awk Pattern scanning and processing language.

b2b_class1 WRAP Board2Board module control script (set basebands to class 1).

b2b_class2 WRAP Board2Board module control script (set basebands to class 2).

b2b_class3

WRAP Board2Board module control script (set basebands to shortest possible

range).

basename Strip directory and suffix from filenames.

bash Bourne-Again SHell.

btproxy WRAP Bluetooth Proxy for Multiradio access servers (test revision).

bunzip2 Decompress bzip2-compressed files.

bzcat Decompress bzip2-compressed files to stdout.

cardctl Monitor and control the state of PCMCIA sockets.

cat Concatenate files and print on the standard output.

chat Automated conversational script with a modem.

chgrp Change group ownership.

chkconfig Updates and dqueries runlevel information for system services.

chmod Change file access permissions.

chown Change file owner and group.

chroot Run command or interactive shell with special root directory.

clear Clear the terminal screen.

cmp Compare two files.

cp Copy files and directories.

cpio Copy files to and from archives.

crontab Maintain crontab files for individual users.

cut Remove sections from each line of files.

date

Print or set the system date and time. Note: The date command does not store

the date into the battery powered real time clock. Use hwclock application

instead.

dd Convert and copy a file.

deluser Delete user from the system.

df Report file system disk space usage.

dirname Strip non-directory suffix from file name.

dmesg Prints of controls the kernel ring buffer.

du Estimate file space usage.

dump_cis

Retrieves and parses the Card Information Structures for inserted PCMCIA

devices, or optionally, parses CIS information from a file.

egrep Print lines matching a pattern.

env Run a command in a modified environment.

expr Evaluate expressions.

false Do nothing, unsuccessfully.

fgrep Print lines matching pattern.

find Search for files in a directory hierarchy.

free Display the amount of free and used memory in the system.

ftp Internet file transfer program.

gdbserver Remote server for GDB debugger.

getty Opens a tty, prompts for a login name, then invokes /bin/login.

grep Print lines matching a pattern.

gunzip Expand gzip compressed files.

gzip Compress files into gzip format.

head Output the first part of files.

hexdump

A filter which displays the specified files, or the standard input, if no files are

specified, in a user specified format.

hostid Print out a unique 32-bit identifier for the machine (not yet implemented).

hostname Show or set the system's host name.

hwclock Query and set the hardware clock.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

id Print information for username or current user.

ide_info IDE device information.

ifconfig Configure a network interface.

ifport Select the transceiver type for a network interface.

ifuser

Checks to see if any of the listed hosts or network addresses are routed through

the specified interface.

insmod Loads the specified kernel modules into the kernel.

ip TCP/IP interface configuration and routing utility.

iptables,

ip6tables IP packet filter administration.

kill Terminate a program.

killall Kill processes by name.

ln Make links between files.

logger Make entries into the system log.

logread Shows the messages from syslogd (using circular buffer).

ls List directory contents.

lsmod List loaded modules.

md5sum Compute and check MD5 message digest.

mkdir Make directories.

mknod Make block or character special files.

mktemp Make a temporary file name (unique).

modprobe High level handling of loadable modules.

more File perusal filter for crt viewing.

mount Mount a file system.

mv Move (rename) files.

nslookup Queries the nameserver for IP address of given host.

ntpclient Simple NTP client application.

obexbrowser The WRAP obexbrowser. A command line OBEX client interface.

obexget

The WRAP OBEX tool for retrieving a file from a remote device with ObjP/FTP

support.

obexput

The WRAP OBEX tool for sending a file to a remote device with ObjP/FTP

support.

pack_cis

Cconvert a text description of a PCMCIA Card Information Structure (CIS) to its

packed binary representation.

passwd Update a user’s authentication token(s).

picocom Minimal dumb-terminal emulation program.

pidof Find a process ID of a running program.

ping, ping6 Send ICMP ECHO_REQUEST packets to network hosts.

ps Report process status.

pwd Print the name of the current/working directory.

rb, rx, rz,

sb, sx, sz Xmodem, Ymodem, Zmodem file receive and send.

rdate Get and possibly set the system date and time from a remote HOST.

reboot Reboot the system.

renice Alter the priority of running processes.

reset Resets the screen.

rm Remove files or directories.

rmdir Remove empty directories.

rmmod Unload loadable modules.

route Show / manipulate the IP routing table.

rsync

A file transfer program capable of efficient remote update

via a fast differencing algorithm.

scp Secure copy (remote file copy program).

scsi_info SCSI device description tool.

sed A Stream EDitor.

setup The WRAP Setup Application. See chapter 3.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

sftp Secure file transfer program.

sleep Delay for a specified amount of time.

sort Sort lines of text files.

ssh, slogin OpenSSH SSH client (remote login program).

ssh-add Adds RSA or DSA identities to the authentication agent.

ssh-agent SSH authentication agent.

ssh-keygen SSH authentication key generation, management and conversion.

ssh-keyscan Gather SSH public keys.

strace Utility to trace system calls and signals.

strings Display printable strings in binary file.

stty Change and print terminal line settings.

su Run a shell with substitute user and group IDs.

sulogin Single-user login.

sync Flush filesystem buffers.

tail Output the last part of files.

tar Tar archiving utility.

tcpdump Utility for dumping traffic on a network.

telnet User interface to the TELNET protocol.

test Check file types and compare values.

time Run command and display it's resource usage information when finished.

top Provides view of processor activity in real time.

touch Change file timestamps.

tr Translate or delete characters.

traceroute Trace the route ip packets follow going to host.

true Do nothing, successfully.

tty Print the filename of the terminal connected to standard input.

uartmode WRAP Uartmode: Change the mode of the user serial port (DTE or DCE).

umount Unmount file systems.

uname Print system information.

uniq Remove duplicate lines from sorted lines.

unzip List, test, and extract compressed files in a ZIP archive.

uptime Tell how long the system has been running.

uudecode Decode a file create by uuencode.

uuencode Encode a binary file.

wc Print the number of bytes, words, and lines in files.

vi A text editor.

wget A utility to retrieve files from the World Wide Web.

wrapid

The WRAP identification program. Shows build and hardware configuration

information.

which Shows the full path of (shell) commands.

whoami Prints the user name associated with the current effective user id.

wpkg WRAP Package Management System.

zcat Expand gzip compressed files to the standard output.

xargs Build and execute command lines from the standard input.

Table 4. Utilities.

4.6 REAL TIME CLOCK

The system clock is read from the battery operated real time clock during boot. The time

between the system time and the real time clock can synchronized using the "hwclock"

application. Give command "hwclock --help" for more information.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4.7 TIME ZONE

The default time zone in the WRAP Multiradio Access Server is UTC. You can change the

timezone by replacing the file "/etc/localtime" with the correct file from your desktop Linux

system (using your /etc/localtime or a wanted zone from /usr/share/zoneinfo).

4.8 SYSTEM RE-INSTALL AND UPGRADE

The WRAP platform can be re-installed with the latest software version. The latest SW version

and instructions are available at http://www.bluegiga.com/techforum/

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

5 BLUETOOTH TECHNOLOGY OVERVIEW

Link Controller (LC)

RF RF

BaseBand

Logical Link Control and Adaption Protocol

(L2CAP)

SDP RFCOMM

BGT Bluetooth API

PPP / PAN

TCP/IP

BT Lower

Layers

BT Upper

Layers

Link Manager Protocoll (LMP)

HCI driver

Physical Bus Driver

HCI Firmware

BNEP

Profiles

Wireless Applications

Figure 5. Bluetooth Software and Hardware Components.

5.1 FREQUENCY BANDS AND CHANNEL ARRANGEMENT

The Bluetooth system operates in the license-free 2.4 GHz ISM (Industrial Science Medial)

band using frequency hopping spread spectrum (FHSS). In the vast majority of countries

around the world this frequency band is 2400 – 2483.5 MHz. Some countries have, however,

national limitations on the frequency range. In order to comply with these national limitations,

special frequency hopping algorithms have been specified for these countries. It should be

noted that products implementing the reduced frequency band will not work with products

implementing the full band. Products implementing the reduced frequency band must therefore

be considered local versions.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

The Bluetooth frequency band is divided into distinct channels with 1 MHz channel spacing. In

order to comply with out-of-band regulations in each country, a guard band is used at the

lower and upper band edge. The frequency range is 2.400 – 2483.5 MHz, and the

corresponding channels are f = 2402 + k MHz; k = 0 – 78. Transmission utilizes channel

hopping over the specified range at 1600 kHz hop frequency. When operating in countries that

permit the use of only a subset of the overall spectrum, transmission utilizes only the approved

portions of the spectrum. The Bluetooth system utilizes Gaussian frequency shift keying

(GFSK). The signaling rate is 1 Mbit/s.

5.2 POWER CONSIDERATIONS

The Bluetooth system transceivers are classified into three power classes to support different

link ranges.

• Power Class 1. Output power is 1 – 100 mW (0 – 20 dBm) with mandatory power

control ranging from 4 to 20 dBm.

• Power Class 2. Output power is 0.25 – 2.5 mW (-6 – +4 dBm) with optional power

control.

• Power Class 3. Output power is less than 1 mW (0 dBm) with optional power control.

Bluegiga’s WRAP products support a 100 meter link range with Option 1 (Power Class 1).

5.3 RADIO FREQUENCY PROPAGATION

The radio frequency signal propagates in free space as a spherical wave, from a point source

to all directions equally. In reality, the actual signal source always differs from a theoretic

isotropic signal source. The power distribution of wireless telecommunication equipment in

space is determined by the antenna radiation pattern. In free space the signal propagates with

the speed of light and attenuates with 1/r2 relation. In reality, the environment always differs

from free space. The propagation environment of wireless telecommunication equipment is

restricted by all obstacles.

The basic mechanism of radio propagation is attributed to reflection, diffraction, and scattering

depending on existing obstacles. Since the radio frequency signal propagates

omnidirectionally, the transmitted signal arrives at the receiver following multiple paths

deformed by the aforementioned propagation mechanisms. The received signal is the

superposition of attenuated and delayed replicas of the transmitted signal, leading to fading of

the transmitted signal and broadening of the duration of the transmitted pulse. The

transmitted pulse delay spread leads to inter-symbol interference (ISI) because the

subsequent symbols interfere with each other. The ISI leads to a bit error probability (BIT)

floor that is independent of the signal to noise ratio (SNR). Depending on the time delay

spread of the transmitted pulse or the amount of widening that the transmitted pulse

experiences across the radio channel, the multipath interference differs. When the time delay

spread of the transmitted signal is very small with respect to the signaling time, the multipath

interference essentially leads to the signal fading phenomena of the received signal. When the

time delay spread of the transmitted signal is high with respect to the signaling time, the

multipath interference leads to the symbol interference phenomena of the received signal as

well.

A major difference between indoor and outdoor environments is that the former is considerably

more sensitive to changes in the geometry of the environment than the latter. This is because

of the differences in distance between obstacles. For example, a door being shut rather than

open may have a major impact on an indoor environment whereas a comparable event in an

outdoor environment may have a minor impact.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

The Bluetooth standard has been designed to operate in noisy radio frequency environments.

Transmission utilizes fast frequency hopping and short packages to make the link efficient and

robust. Fast hopping and short packages limit the impact of interfering devices on the same

frequency band.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

6 INTRODUCTION TO SDK

This manual describes how to create and use applications using the WRAP Software

Development Environment. The relationship between the applications and the WRAP Software

and Hardware is shown in Figure 6.

BGT APIs

BGT Core Engine

Operating system

Customer Applications

Servers

Network Interfaces Local HW Interfaces

Figure 6. Relationship Between the Customer Applications and WRAP.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

7 INSTALLING THE WRAP SOFTWARE DEVELOPMENT ENVIRONMENT

Note: The Software Development Environment can be installed only on a PC running the Linux

operating system!

7.1 WRAP SOFTWARE DEVELOPMENT ENVIRONMENT SYSTEM REQUIREMENTS

The following hardware and software is required to run the WRAP Development Environment:

PC with

• CD-ROM drive

• Linux (tested with RedHat 6.2 and above, Fedora Core 1)

• 200MB of available hard disk space

An Ethernet connection to a Local Area Network (also connected to the WRAP board) is highly

recommended.

Mount the WRAP SDK CD-ROM or ISO image, change the current working directory to where it

is mounted, and run install as root.

Example (things you need to type are printed like this):

$ su -m (-m to keep original user's environment, will prompt for password)

$ mount /dev/cdrom /mnt/cdrom

$ (or mount –o loop /path/to/sdk2.iso /mnt/cdrom)

$ cd /mnt/cdrom

$ sh install

Install will ask you some questions (described below) regarding which components to install

and the paths to install them to. If you are not very familiar with Linux, just press <enter> to

these questions (the default values are suitable for most users and systems).

7.2 QUESTIONS ASKED BY THE INSTALL SCRIPT

1. WRAP tools directory (default: /usr/local/arm)

This is the path where you want the WRAP Software Development tools (arm-linux-gcc,

etc.) to be installed.

Note: If you change this value, the WRAP tools and libc must be recompiled. The

recompilation process is very complicated and lengthy, and it may fail, depending on your

system. Recompilation is done automatically by the install script, if necessary.

2. Development directory (default: [home_of_current_user]/asdk)

This is the path where you want the WRAP Software Development Environment to be

installed.

3. Development directory owner (default: [current_user])

This is the username of the owner of the development directory.

Note: If this is not the username of the developer for whom the Software Development

Environment is being installed, the user will not have rights to use the development files

and therefore can not develop any WRAP software.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

4. Install toolchain sources (default: no - unless the tools directory was

changed)

Whether or not the toolchain sources will be installed. These are required only if the WRAP

tools directory was changed from the default target location in step 1.

5. Install Linux headers (default: no - unless libc sources are selected)

Whether or not the Linux header files will be installed. These are required only if the libc

sources are being installed (chosen in step 5).

6. Install example applications (default: yes)

Whether or not the WRAP example applications and their sources will be installed.

7. Compile image after installation (default: yes)

If set to yes, install will compile the WRAP filesystem image to test that the installation

was successful and that the Development Environment is working correctly.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

8 CREATING WRAP APPLICATIONS

The fastest way to start developing WRAP applications is to study, change, and recompile the

example files in the asdk/src/examples directory.

8.1 APPLICATION EXAMPLES

To demonstrate the software development features of the WRAP, the WRAP Software

Development Environment comes with several example applications.

8.1.1 INSTALLING EXAMPLES

The compiled example files are located on the WRAP SDK tree in the file

asdk\src\examples\examples.tar.gz. The examples can be manually uploaded and installed on

the WRAP board.

Uploading can be done with SCP, FTP or X/Y/Zmodem. After uploading, the examples archive

needs to be unpacked with the "tar xzvf" command before the files can be used.

8.1.2 RUNNING EXAMPLES

After the example files have been transferred to the WRAP, they can be run from the directory

into which they were unpacked. The examples, with their usage and purpose, are described in

Table 5. Note: The example WWW pages must be transferred to the correct place, where the

Web server can find them. In this user manual it is assumed that this has been done by giving

the command "mv www/* /var/www/html" in the directory where the examples.tar.gz –file

was unpacked.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Example, source in

wrap/src/examples/

Usage, when installed to /tmp and

when it is the current directory Purpose

helloworld ./helloworld The "Hello, world!"

application.

serial ./serial /dev/ttySA1 "Hello, world!" to the serial

port.

btsend ./btsend – 12 on the first device,

./btsend <bdaddr of first> 12 on

second

Machine 2 Machine example.

"Hello, world!" over

Bluetooth. Note: Currently

uses "buffy" as Bluetooth

server password.

io/led

./led

I/O: LED/Buzzer example.

m2n echo testmessage | ./m2n Machine 2 Network example.

System Logger configuration

needed for actual remote

connection. Without it,

simulates it locally.

man2m ./ledserver &

browse with Java-enabled browser

to http://wrap-ip-adress/man2m/

Note: Assumes WWW pages moved

as guided.

Man 2 Machine example. Also

demonstrates Java applets.

www Browse to http://wrap-ip-address/

Note: Assumes WWW pages moved

as guided. More info on the page

itself.

Demonstration of the web

server capabilities.

makesms Browse to http://wrap-ip-

address/sms/

Note: Assumes WWW pages moved

as guided, "makesms" example

application is in /var/www/html/cgi-

bin, and WRAP SMS Gateway is up

and running (see section 4.4.2).

Demonstrates WRAP SMS

Gateway by sending SMS

messages with required

Nokia N30 or N20 GSM

Terminal.

obexbrowser Documented in chapter 9.8.3. Demonstrates the usage of

the WRAP OBEX libraries

implementing Object Push

Profile and File Transfer

Profile clients.

Table 5. Examples, Their Usage and Purpose.

If you do not want to re-install the example files after every system power-off, they can be

stored in the flash file system. Simply use the mv command to move the executables of the

examples you want to save into /usr/local/bin. After this, you can execute the examples from

anywhere (without the ./) and access the web examples directly under http://wrap-ip-

address/www/).

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

8.2 CREATING A NEW PROJECT

To start a new project, you need to create a new subdirectory in your Development

Environment’s source directory (src/) and add your application source files and Makefile to that

directory. This can be done automatically using WRAP Access Server Project AppWizard. Just

give the command "make appwiz APP=dir/to/newapp" in the Development Environments top

level source directory (src/). A "hello world" example project is then created.

You can add your directory to the compile queue by inserting it in the file src/DIRECTORIES if

you want to compile the whole source tree at once from the top level src-directory.

You may need to modify the variables in the Makefile for your project. You can see the defaults

and their description in the default Makefile created by the AppWizard

(src/dir/to/newapp/Makefile in our example above).

• TOPLEVEL

This should point to the Development Environment source directory, i.e. src/.

• APPNAME

This is the name of the executable file of the application. In our example, this line should

be APPNAME = testapp

• SRC

This variable defines the files to be compiled and linked into APPNAME. In our example, this

line could be SRC = testapp.c. Several files are separated with space, like "SRC = testapp.c

extraobj.c"

• APP_STRIP

Optional variable. The application symbols are removed by default to reduce application

size. For debugging, these are needed, which can be done by "APP_STRIP=false".

• CFLAGS

Optional extra flags for C compiler. Set "CFLAGS=-ggdb" if you want to debug application.

• CXXFLAGS

Optional extra flags for C++ compiler. Set "CXXFLAGS=-ggdb" if you want to debug

application.

• LIBS

Optional additional libraries needed by application. Multihreaded application needs

libpthread with "LIBS=pthread".

Now you have a new project just waiting for coding. To compile the project, you simply need

to run make in the testapp directory.

8.3 BUILDING FROM THE COMMAND LINE

The WRAP Development Environment uses the ARM port of the GNU bintools and compilers to

build applications. If you are not very familiar with Linux development, you should use the

method explained in section 8.2 instead of writing your own makefiles. If you still want to use

your very own development environment, there are two minor issues to remember:

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

1. Tools are prefixed with arm-linux-, so for calling gcc C-compiler you need to call arm-

linux-gcc, etc.

2. Tools are located in "/usr/local/arm/2.95.3/bin/" -directory, which is not in PATH by

default.

8.4 TRANSFERRING AN APPLICATION TO WRAP HARDWARE

To run an application on the WRAP, it must first be transferred into the WRAP system. There

are several ways of doing this:

1. Over TCP/IP by FTP, SFTP, SCP (using Ethernet or Bluetooth)

2. Over management console by X/Y/Zmodem (using terminal software connected to the

WRAP)

3. Using NFS mount

8.4.1 TRANSFERRING AN APPLICATION TO WRAP USING (S)FTP OR SCP

FTP is a fast and easy way to upload an application to the WRAP. If you wish to use FTP for

transferring data to and from the WRAP, there has to be an FTP daemon running on the WRAP

connected to your LAN (if an Ethernet interface is used). Normally, this is the case.

After connecting to the WRAP FTP daemon, you need to decide where you want to put your

application – either on the ramdisk for testing purposes, or on the flash file system for

preserving your application between power-offs. The ramdisk is accessed through the ram

directory and the flash file system through the flash directory after logging in with FTP.

In the following example we will transfer our application to the /tmp directory (on the ramdisk)

using a simple FTP client. SFTP works similary. User input is shown like this.

$ ftp <wrap-ip-address>

Connected to <wrap-ip-address>.

220 Welcome to Stupid-FTPd server.

User (<wrap-ip>:(none)): root

331 Guest login ok, send your e-mail address as password.

Password: buffy (not echoed)

230 User anonymous logged in.

ftp> bin

200 Type set to I.

ftp> cd /tmp

250 CWD command successful.

ftp> put testapp

200 PORT command successful.

150 FILE: testapp

226 Transfer complete.

ftp: 133120 bytes sent in 0.91Seconds 145.96Kbytes/sec.

ftp> bye

221 Bye.

SCP transfer is done with command "scp testapp root@<wrapip-address>:/tmp". If you want

to save the application to /usr/local/bin (on the flash filesystem), you will have to replace

'/tmp' with '/usr/local/bin'. To examine the directory structure of the WRAP, please see

Appendix A.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

8.4.2 TRANSFERRING AN APPLICATION TO WRAP USING TERMINAL SOFTWARE

If your WRAP is not connected to a LAN, you may use terminal software of your own choice to

transfer data to the WRAP. The WRAP contains an X/Y/Zmodem protocol application, which

allows you to transfer data over the console using almost any terminal software available.

1. Connect your computer to the WRAP management UART using a cross-over serial cable,

and start your terminal software (115 200bps, 8 data bits, no parity, 1 stop bit).

2. Change your working directory to where you want to upload your application, and run

the xmodem application with your application name as parameter.

3. Start Xmodem send from your terminal software.

Example: [root@wrap /] cd /tmp

[root@wrap /tmp] rx testapp

rx: ready to receive testapp.

now start xmodem (checksum, not CRC) send from your terminal

[root@wrap /tmp]

If you want to save the application to /usr/local/bin (on the flash file system), you will have to

replace 'cd /tmp' with 'cd /usr/local/bin'. To examine the directory structure of the WRAP,

please see Appendix A.

8.4.3 USING NFS MOUNT

To use NFS mount, have a NFS share prepared in your development PC and mount the

directory with command "mount -o nolock <dev-pc-ipaddress>:/nfsshare /mnt/nfs". After this,

you can access the share in directory "/mnt/nfs".

8.5 RUNNING AN APPLICATION TRANSFERRED TO WRAP

To run the application you just transferred to the WRAP, you need access to the WRAP Linux

console, either using terminal software connected to the WRAP management UART or using the

telnet connection (log in as "root" and remember the password, which is "buffy" by default).

After establishing a connection to the WRAP, change the directory to where your application is

located and change file permissions so that it can be executed, then run it.

Example: [root@wrap /] cd /tmp

[root@wrap /tmp] chmod 755 testapp

[root@wrap /tmp] ./testapp

8.6 USING DEBUGGER (GDB/DDD)

It is possible to use GNU debugger GDB and a graphical user interface, like DDD, for

debugging applications in the WRAP Access Server.

You have to compile with debug options and without symbol stripping to make debugging

work. As mentioned above, this can be done by adding lines "APP_STRIP=false" and "CFLAGS

= -ggdb" to the Makefile below SRC line.

After you have compiled your application with these options and transferred your application to

WRAP, you can start debugging the application as follows:

1) Start gdbserver on the WRAP Access Server

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

gdbserver :<port> <your application>

Example: gdbserver :6789 ./testapp

2) Start debugger on the host PC. (example is for DDD)

ddd --debugger /usr/local/arm/2.95.3/bin/arm-linux-gdb

3) Load symbolfile from ddd’s gdb console:

Example: symbol-file testapp

4) Create connection to the debugserver

target remote <node IP>:<port>

Example: target remote 10.1.1.63:6789

5) Press lookup and start debugging

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9 BLUETOOTH SERVER SOCKET INTERFACE

The Bluetooth in the WRAP is controlled via the TCP socket interface. The first Bluetooth server

is listening on port 10101. In case of WRAP 2293, the second Bluetooth server is listening on

port 10102 and the third one is listening on port 10103. All commands to a Bluetooth server

and replies from the server are plain ASCII strings ending in CR+LF ("\r\n"). Commands and

replies are not case sensitive.

When connecting to a server you must first wait for the "READY." prompt. Do not send any

commands prior to this. Some replies are broadcast to all clients of the server. If you see

something that you have not requested or that is not intended for your client (identified by the

link identifier), simply ignore the reply.

Normally, the Bluetooth Server Socket Interface is not protected with a password. The

password can be enabled and changed: see the SET command below. If the password is

enabled, it must be sent first, immediately following the "READY." prompt, to the Bluetooth

server. Otherwise, all commands will fail.

For an example of using the Bluetooth Server Socket Interface, please see

src/examples/btsend in the SDK directory.

9.1 TERMS

Bluetooth address (bdaddr) is six hex digits separated by a colon. For example,

"1a:2b:3c:4d:5e:6f". With commands requiring Bluetooth address, you can also use Bluetooth

friendly name instead.

Bluetooth channels are numbered from 1 to 30. In WRAP, the Serial Port Profile is assigned to

channel number two, the Object Push/File Transfer Profile to channel number three and the

LAN Access Profile is on channel number four. The other channels are free for user

applications.

Link Identifier (link_id) is a number from 0 to 99 used to identify established Bluetooth

connections.

9.2 STARTING THE BLUETOOTH SERVERS

Normally, the Bluetooth servers are started automatically upon power-up. You can restart the

servers manually (for example, to apply the changes made to the Bluetooth settings with

"setup" application without rebooting the system). To restart the servers manually, execute

the startup script with option "restart":

/> /etc/init.d/bluetooth restart

When the Bluetooth servers start up, it uses the settings configured with the "setup"

application described in the User manual. You can put your extra Bluetooth Server Socket

Interface commands in the /etc/bluetooth.conf file. The commands in that file are processed as

the last task every time each Bluetooth server is started.

9.3 BASIC COMMANDS

These commands are used for searching for and inquiring about nearby Bluetooth devices and

for controlling the Bluetooth server and/or the control connection itself.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

In the following examples, lines starting with C: are commands sent by the client to the

Bluetooth server and lines starting with S: are replies received from the Bluetooth server by

the client.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.1 INFO

INFO is used to retrieve version info of the Bluetooth server, in the same format as the READY-

prompt when the control connection is opened.

Command: INFO

Reply: READY. (wrap-2-0-3 $Revision: 1.289 $ bt1.1)

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.2 INQUIRY

INQUIRY is used to search for other Bluetooth devices. Timeout is in units of 1.25 seconds. If

an optional "NAME" parameter is provided, the NAME command will be sent automatically to all

found devices.

During the inquiry, all devices are listed as soon as they are found with "INQUIRY_PARTIAL"

replies. If the friendly name of the device found has been cached by the Bluetooth server, it is

also displayed. When the inquiry times out, a summary is displayed (how many devices were

found and their information repeated).

Command: INQUIRY timeout {NAME}

Reply: INQUIRY_PARTIAL bdaddr_of_dev_1 class_of_dev_1 "friendly name" rssi

INQUIRY_PARTIAL bdaddr_of_dev_2 class_of_dev_2 "friendly name" rssi

...

INQUIRY_PARTIAL bdaddr_of_dev_n class_of_dev_n "friendly name" rssi

INQUIRY number_of_devices_found

INQUIRY bdaddr_of_dev_1 class_of_dev_1 "friendly name"

INQUIRY bdaddr_of_dev_2 class_of_dev_2 "friendly name"

...

INQUIRY bdaddr_of_dev_n class_of_dev_n "friendly name"

Example: S: READY.

C: INQUIRY 10

S: INQUIRY 0

C: INQUIRY 10

S: INQUIRY_PARTIAL 00:11:22:33:44:55 120300 "willow" 255

S: INQUIRY_PARTIAL 11:22:33:44:55:66 520204 "" 255

S: INQUIRY 2

S: INQUIRY 00:11:22:33:44:55 120300 "willow"

S: INQUIRY 11:22:33:44:55:66 520204 ""

C: INQUIRY 10 NAME

S: INQUIRY_PARTIAL 00:11:22:33:44:55 120300 "" 255

S: INQUIRY_PARTIAL 11:22:33:44:55:66 520204 "buffy" 255

S: INQUIRY 2

S: INQUIRY 00:11:22:33:44:55 120300 ""

S: INQUIRY 11:22:33:44:55:66 520204 "buffy"

S: NAME 00:11:22:33:44:55 "willow"

S: NAME 11:22:33:44:55:66 "buffy"

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.3 NAME

You can ask for the friendly name of another Bluetooth device with the NAME command.

Command: NAME bdaddr

Reply: NAME bdaddr "friendly name"

NAME ERROR bdaddr reason_code more_info

Example: S: READY.

C: NAME 11:22:33:44:55:66

S: NAME 11:22:33:44:55:66 "buffy"

C: NAME 11:22:33:44:55:77

S: NAME ERROR 11:22:33:44:55:77 108 HCI_ERR_PAGE_TIMEOUT

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.4 QUIT

To close the connection to the Bluetooth server, use the QUIT command.

Command: QUIT

Reply: There is no reply.

Example: S: READY.

C: QUIT

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.5 SET

The SET command allows you to alter various Bluetooth and server parameters. The supported

parameters are listed in Table 6. Issuing a SET command without parameters will list the

current settings.

Topic Name Value Description

BLUETOOTH BDADDR bdaddr Our bdaddr. This is a read-only value.

BLUETOOTH NAME friendly_name Set your friendly name. Others can

request this name with the NAME

command. There are following meta

characters you can use:

*: Hardware serial number, last three

digits

$s: Hardware serial number, last three

digits

$S: Hardware serial number, all digits

$p: Server port, last digit

$P: Server port

$h: hostname

$H: FQDN

$$: $

$*: *

The default value is $S_$p.

BLUETOOTH READABLE mode If enabled, some SDP result codes will

have literal values instead of numeric

values.

0: No (always use numeric values)

1: Yes (literal values)

BLUETOOTH CLASS value Set class-of-device value.

BLUETOOTH ROLE role {policy

{timeout}}

Set master/slave role switch preference,

optionally also link policy

and link supervision timeout. Possible

values for "role" are:

0: allow calling, don’t request when

answering

1: allow calling, request when

answering

2: don’t allow calling, request when

answering

The default link policy is 000f and the

default link supervision timeout is 7d00.

See Bluetooth Core Specification 1.1 for

more information on these.

BLUETOOTH ENCRYPT value Whether or not to use Bluetooth

encryption. To actually have Bluetooth

encr

tion enabled

the connection has

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

to be authenticated.

0: No

1: Yes

BLUETOOTH PAGEMODE mode

{page_timeout

{page_scan_rep

etition_mode}}

Pagemode controls whether or not other

devices can find and call you. There are

four different modes:

0: No inquiry, no paging

1: Inquiry, no paging

2: No inquiry, paging

3: Inquiry and paging

Page timeout is in hex and the default

value is 2000. Default page scan

repetition mode is 2 (R2).

See Bluetooth Core Specification 1.1 for

more information on these.

BLUETOOTH AUTH * Remove default PIN code. If you are

making an outgoing connection and the

remote asks for PIN, "1234" will be

sent. If somebody is connecting to you,

no PIN will be requested.

BLUETOOTH AUTH * pin Set default PIN code. If you are making

an outgoing connection, this PIN code

will be sent. If somebody is connecting

to you, this PIN code is requested and,

if not supplied, the connection will be

refused.

BLUETOOTH AUTH bdaddr Remove PIN code for bdaddr.

BLUETOOTH AUTH bdaddr pin Set PIN code for bdaddr. See above for

functionality.

BLUETOOTH PAIR bdaddr linkkey Manually set linkkey for bdaddr.

BLUETOOTH PAIR bdaddr Manually delete linkkey for bdaddr.

BLUETOOTH PAIREXPIRE seconds Set expiration time, in seconds, for

pairing information.

BLUETOOTH LISTEN channel cmd

{mem {delay}}

Add fork-listener for the channel. When

there is an incoming RFCOMM

connection to the channel Bluetooth

server will handle the connection by

itself by forking "cmd". At least "mem"

kilobytes of free memory must be

available, or the connection will be

rejected. After forking Bluetooth server

will wait "delay" timerticks (50ms)

before transmitting any data.

The client application should modify

both the stdout and stdin pipes and set

NOECHO, 8BIT and all other necessary

modes in the very beginning. The

purpose of the "delay" parameter is to

ive the a

lication enou

h time to do

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

this.

BLUETOOTH LISTEN psm L2CAP Add L2CAP-listener for the psm.

BLUETOOTH LISTEN channel Remove fork/L2CAP-listener for the

channel/psm.

BLUETOOTH LINK mode params Modify slaves powermode according to

"mode". "params" are optional and

mode-dependent. Possible values for

"mode" are 0, 1, 2, 3, 4:

0: Active.

Params: None.

1: Park: Round-robin.

Params: max_beacon min_beacon

sleep_after_unpark sleep_after_round

Defaults: 254 160 5 30

Sleeps are specified by timerticks

(50ms).

2: Park: Idle.

Params: max_beacon min_beacon

max_active

Defaults: 512 384 6

max_active is the maximum number of

active slaves.

3: Sniff: All.

Params: max_interval min_interval

attempt timeout

Defaults: 640 426 1 8

4: Sniff: Idle.

Params: idle_timeout max_interval

min_interval attempt timeout

Defaults: 400 640 426 1 32

idle_timeout is in timerticks (50ms).

See Bluetooth Core Specification 1.1 for

more information on params.

BLUETOOTH QOS service_type

token_rate

peak_bandwidth

latency

delay_variation

Set default QoS values for new

connection. Parameters are in hex. See

Bluetooth Core Specification 1.1 for

more information on params.

Defaults: 01 00000000 00000000 ffffffff

ffffffff

L2CAP TIMEOUT flushto linkto Define FlushTimeout and LinkTimeout

for L2CAP connections. See Bluetooth

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Core Specification 1.1 for more

information on params.

Defaults: 65535 40000

PPP AUTH Don't require any PPP authentication on

incoming connections.

PPP AUTH username

password

Require specified username:password

on incoming PPP connections.

PPP CHANNEL channel Our PPP (LAN Access Profile) channel.

This channel will be handled internally

by the Bluetooth server. If you change

this, remember to modify the SDP

record as well. Use zero value to disable

the LAN Access Profile.

PPP DEFAULTROUTE value This setting controls whether or not the

Bluetooth server should modify the

defaultroute setting. There are four

different modes:

0: Don't alter defaultroute

1: Set defaultroute according to

outgoing PPP

2: Set defaultroute according to

incoming PPP

3: Set defaultroute according to all PPP

calls

PPP WINHANDSHAKE seconds Timeout to wait for the Windows RAS

handshake.

PPP IP ipaddr/mask Set network IP range for PPP clients.

PAN ENABLE bitmap Controls incoming PAN connections.

Bitmap:

1: Allow incoming PAN-PANU

connection.

2: Allow incoming PAN-GN connection.

4: Allow incoming PAN-NAP connection.

For most cases value "6" (the default) is

recommended.

CONTROL PASSWORD Don’t require password from control

clients (default)

CONTROL PASSWORD pass Enable password. Control connection

clients must send this password before

giving any other command. The

password is case sensitive.

CONTROL PING seconds If enabled (seconds > 0), the Bluetooth

server will send a "PING" reply to all

control connection clients. You have to

reply to it with "PONG" or the

connection will be closed.

link_id MSC value Set MSC for link_id to value. See ETSI

TS 101 369 (GSM 07.10) for more

information.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

link_id ACTIVE Set powermode for link_id to active.

link_id PARK params Set powermode for link_id park.

Required "params" are:

avg_beacon or

max_beacon min_beacon

See Bluetooth Core Specification 1.1 for

more information on params.

link_id HOLD params Set link's powermode to hold. Required

"params" are:

avg or

max min

See Bluetooth Core Specification 1.1 for

more information on params.

link_id SNIFF params Set powermode for link_id to sniff.

Required "params" are:

avg_interval or

max_interval min_interval or

max_interval min_interval attempt or

max_interval min_interval attempt

timeout

Default attempt is 1, default timeout is

See Bluetooth Core Specification 1.1 for

more information on params.

link_id QOS service_type

token_rate

peak_bandwidth

latency

delay_variation

Set link's QoS values. Parameters are in

hex.

See Bluetooth Core Specification 1.1 for

more information on params.

link_id MASTER Switch role to master.

link_id SLAVE Switch role to slave.

Table 6. Supported Parameters of Bluetooth SET Command.

Command: SET {topic name {value}}

Reply: When there are parameters, there is no reply.

Example: S: READY.

C: SET BLUETOOTH NAME Buffy

C: SET BLUETOOTH PAGEMODE 3

C: SET BLUETOOTH READABLE 1

C: SET BLUETOOTH CLASS 020300

C: SET BLUETOOTH ROLE 0

C: SET BLUETOOTH ENCRYPT 0

C: SET BLUETOOTH PAGEMODE 3

C: SET BLUETOOTH AUTH * 1234

C: SET BLUETOOTH AUTH 00:11:22:33:44:55 4242

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

C: SET BLUETOOTH AUTH *

C: SET BLUETOOTH PAIREXPIRE 600

C: SET BLUETOOTH LISTEN 1 /bin/login 200

C: SET BLUETOOTH LISTEN 2 "my/own/command with parameters" 100 5

C: SET BLUETOOTH LISTEN 3

C: SET PPP DEFAULTROUTE 0

C: SET PPP AUTH buffy willow

C: SET PPP AUTH

C: SET PPP CHANNEL 4

C: SET PPP WINHANDSHAKE 10

C: SET PPP IP 192.168.166.0/24

C: SET 0 MSC 8d

C: SET CONTROL PING 60

S: PING

C: PONG

C: SET CONTROL PASSWORD

C: SET CONTROL PASSWORD buffy

S: READY.

C: SET

S: ERROR PASSWORD NEEDED.

S: READY.

C: buffy

C: SET

S: SET BLUETOOTH BDADDR 00:11:22:33:44:55

S: SET BLUETOOTH NAME Buffy

S: SET PPP AUTH

S: SET CONTROL PASSWORD buffy

S: SET

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.6 PING

The PING command is used to check that the connection to the Bluetooth server is alive.

Command: PING

Reply: PONG

Example: S: READY.

C: PING

S: PONG

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.7 PONG

The PONG command has to be sent back if you see a PING reply from the server. If you do not

answer, the connection will be closed after a few seconds.

Command: PONG

Reply: There is no reply.

Example: S: READY.

S: PING

C: PONG

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.8 SHUTDOWN

To close the Bluetooth server you can use the SHUTDOWN command. This also immediately

closes all active connections.

Command:

SHUTDOWN

Reply: There is no reply.

Example: S: READY.

C: SHUTDOWN

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.3.9 SLEEP

SLEEP waits for a specified number of seconds before processing further commands.

It is only usable in rc scripts (/etc/bluetooth.conf).

Command: SLEEP seconds

Reply: There is no reply.

Example: S: READY.

C: SLEEP 4

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4 CONNECTION COMMANDS AND REPLIES

9.4.1 CALL

The CALL command is used to call other Bluetooth devices. It returns the link identifier (with

an immediate reply), which will be used in subsequent commands and replies.

Always make sure you check for a correct link_id before processing replies further.

You can use the special "FORK" call type to create an RFCOMM connection and automatically

launch an application which gets the RFCOMM connection bound to its standard input and

output. The client application should modify both the stdout and stdin pipes and set NOECHO,

8BIT and all other necessary modes in the very beginning.

Note 1: There can be only one pending CALL at any time, you have to wait for CONNECT/NO

CARRIER before issuing another CALL.

Note 2: PPP is "raw" PPP without any special handshaking. WINPPP is a Windows RAS

handshake followed by raw PPP. If you are unsure, use WINPPP.

Command: CALL bdaddr SDP

CALL bdaddr psm L2CAP

CALL bdaddr channel RFCOMM

CALL bdaddr uuid RFCOMM

CALL bdaddr channel PPP

CALL bdaddr uuid PPP

CALL bdaddr channel PPP username password

CALL bdaddr uuid PPP username password

CALL bdaddr channel WINPPP

CALL bdaddr uuid WINPPP

CALL bdaddr channel WINPPP username password

CALL bdaddr uuid WINPPP username password

CALL bdaddr channel FORK /full/path/to/command

CALL bdaddr uuid FORK /full/path/to/command

CALL bdaddr channel FORK "/full/path/to/command and parameters"

CALL bdaddr uuid FORK "/full/path/to/command and parameters"

CALL bdaddr PAN-destUUID

CALL bdaddr PAN-destUUID PAN-srcUUID

Reply: CALL link_id

Example: S: READY.

C: CALL 00:11:22:33:44:55 SDP

S: CALL 0

S: CONNECT 0 SDP

C: CALL 00:11:22:33:44:55 4 PPP

S: CALL 1

S: CONNECT 1 SDP

C: CALL NameOfOtherDevice LAN PPP

S: CALL 1

S: CONNECT 1 SDP

C: CALL 00:11:22:33:44:55 4 WINPPP buffy willow

S: CALL 2

S: CONNECT 2 PPP

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

C: CALL 00:11:22:33:44:55 1 RFCOMM

S: CALL 3

S: CONNECT 3 RFCOMM 1042

C: CALL 00:11:22:33:44:55 2 FORK /bin/login

S: CALL 4

S: CONNECT 4 FORK

C: CALL 00:11:22:33:44:66 PAN-NAP

S: CALL 5

S: CONNECT 5 PAN-NAP

C: CALL 00:11:22:33:44:77 PAN-NAP PAN-NAP

S: CALL 6

S: CONNECT 6 PAN-NAP

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.2 CONNECT

CONNECT is not a command, but rather a reply broadcast to you when CALL successfully

makes the connection. Remember to check that the link_id matches your CALL!

On RFCOMM/L2CAP connections, there is an additional parameter called port. It is the TCP

socket port number, which is used to send and receive data to and from the remote device.

Connect to the port just like you connected to the Bluetooth server. The connection is "raw",

which means that no processing of incoming or outgoing data is made.

Note: In case of L2CAP connections, the data is handled as packets. Therefore both the

incoming and outgoing data must follow the format "HDR+L2CAPDATA", where HDR is two

bytes; first the low byte and then the high byte of the length of the L2CAPDATA packet and

L2CAPDATA contains the actual L2CAP-packet.

Command: This is not a command.

Reply: CONNECT link_id SDP

CONNECT link_id RFCOMM port

CONNECT link_id L2CAP port

CONNECT link_id PPP

CONNECT link_id FORK

CONNECT link_id PAN-PANU

CONNECT link_id PAN-GN

CONNECT link_id PAN-NAP

Example: S: READY.

C: CALL 00:11:22:33:44:55 SDP

S: CALL 0

S: CONNECT 0 SDP

C: CALL 00:11:22:33:44:55 4 PPP

S: CALL 1

S: CONNECT 1 PPP

C: CALL 00:11:22:33:44:55 1 RFCOMM

S: CALL 2

S: CONNECT 2 RFCOMM 1042

C: CALL 00:11:22:33:44:55 2 FORK /bin/login

S: CALL 3

S: CONNECT 3 FORK

C: CALL 00:11:22:33:44:66 PAN-NAP

S: CALL 5

S: CONNECT 5 PAN-NAP

C: CALL 00:11:22:33:44:77 PAN-NAP PAN-NAP

S: CALL 6

S: CONNECT 6 PAN-NAP

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.3 NO CARRIER

NO CARRIER-reply indicates that you or the remote device closed the active connection, or

that your CALL failed for some reason.

See 9.7 for the list of reason codes. Field "more_info" is optional. If present it gives you a

human readable error code or some statistics about the closed connection.

Command: This is not a command.

Reply: NO CARRIER link_id ERROR reason

NO CARRIER link_id

Example: S: READY.

C: CALL 00:11:22:33:44:55 4 PPP

S: CALL 0

S: NO CARRIER 0 ERROR 104 HCI_ERR_PAGE_TIMEOUT

C: CALL 00:11:22:33:44:55 1 RFCOMM

S: CALL 1

S: CONNECT 1 RFCOMM 1042

...

S: NO CARRIER 1 ERROR 000 IN=42,OUT=66,ELAPSED=69

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.4 RING

The RING reply indicates an incoming CALL from a remote device. As with CONNECT, on

RFCOMM/L2CAP calls there is an additional port parameter. Connect to it if you want to serve

this call. PPP and PAN calls are handled internally so you don't have to do anything about

them. The Bluetooth server closes the connection if nobody grabs the call within 30 seconds.

Command: This is not a command.

Reply: RING link_id bdaddr channel PPP

RING link_id bdaddr channel RFCOMM port

RING link_id bdaddr psm L2CAP port

RING link_id bdaddr PAN-PANU

RING link_id bdaddr PAN-GN

RING link_id bdaddr PAN-NAP

Example: S: READY.

S: RING 0 00:11:22:33:44:55 4 PPP

S: RING 1 00:11:22:33:44:55 1 RFCOMM 1042

S: RING 2 00:11:22:33:44:55 PAN-GN

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.5 CLOSE

The CLOSE command closes an active connection started with CONNECT or RING. Note that

closing the RFCOMM data socket connection also closes the Bluetooth connection.

Command: CLOSE link_id

Reply: There is no direct reply. NO CARRIER is replied when the connection actually closes.

Example: S: READY.

C: CALL 00:11:22:33:44:55 4 PPP

S: CALL 1

S: CONNECT 1 PPP

C: CLOSE 1

S: NO CARRIER 1 ERROR 000

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.6 LIST

The LIST command reports active connections as well as some statistics.

Command: LIST

Reply: LIST number_of_connections

LIST link_id status type blocksize bytes_in bytes_out elapsed_time

our_msc remote_msc bdaddr channel direction powermode role crypt

LIST link_id status type blocksize bytes_in bytes_out elapsed_time

our_msc remote_msc bdaddr channel direction powermode role crypt

...

LIST link_id status type blocksize bytes_in bytes_out elapsed_time

our_msc remote_msc bdaddr channel direction powermode role crypt

Example: S: READY.

C: LIST

S: LIST 1

S: LIST 0 CONNECTED RFCOMM 666 4242 100 30 8d 8d 00:11:22:33:44:55 4

OUTGOING ACTIVE MASTER PLAIN

Status values are: WAITING, CONNECTED, and CLOSING.

Type is SDP, RFCOMM, PPP, PAN-PANU, PAN-GN, PAN-NAP, FORK or L2CAP.

Blocksize is the maximum transfer unit of the Bluetooth link, only for statistics.

Bytes_in and bytes_out are numbers of bytes transferred.

Elapsed_time is the number of seconds the connection has been up.

Msc is the link's MSC value for both ends.

Bdaddr is the Bluetooth address of the connected device.

Channel is the service channel of the connection.

Direction is either OUTGOING or INCOMING.

Powermode is ACTIVE, SNIFF, PARK or HOLD.

Role is MASTER or SLAVE.

Crypt is PLAIN or ENCRYPTED.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.4.7 STATUS

The STATUS reply is used to inform you about changes in connection status. See also the SET

command.

Command: This is not a command.

Reply: STATUS link_id MSC value

Example: S: READY.

S: STATUS 0 MSC 8d

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5 SERVICE DISCOVERY

This section describes the commands used for Bluetooth service discovery and local SDP record

manipulation. The commands and their replies make use of SDP UUID and attribute values,

which are listed in the Bluetooth Assigned Numbers documentation. In the commands

documented below, the most useful UUID and attribute values can, however, be replaced with

keywords listed in Table 7. The same keywords are used in the command replies instead of

numeric values, if the parameter "BLUETOOTH READABLE" is set to 1 – see SET command

above for more information.

Keyword(s) Value Hex Value

SDP UUID_SDP 0001

RFCOMM UUID_RFCOMM 0003

OBEX UUID_OBEX 0008

BNEP UUID_BNEP 000F

L2CAP UUID_L2CAP 0100

PUBLICBROWSEGROUP,

BROWSE, ROOT

UUID_PUBLIC_BROWSE_GROUP 1002

SERIALPORT, SPP UUID_SERIALPORT 1101

LANACCESS, LAN UUID_LANACCESS 1102

DIALUPNETWORKING, DUN UUID_DIALUPNETWORKING 1103

OBEXOBJECTPUSH, OBJP UUID_OBEXOBJECTPUSH 1105

OBEXFILETRANSFER, FTP UUID_OBEXFILETRANSFER 1106

PAN-PANU, PANU UUID_PANU 1115

PAN-NAP, NAP UUID_NAP 1116

PAN-GN, GN UUID_GN 1117

PROTOCOLDESCRIPTORLIST,

DESCLIST, DESC

ATTR_PROTOCOLDESCRIPTORLIST 0004

SERVICENAME, NAME ATTR_SERVICENAME +

BASE_LANG_OFFSET

0000 + 0100

SECURITYDESCRIPTION ATTR_SECURITYDESCRIPTION 030A

NETACCESSTYPE ATTR_ NETACCESSTYPE 030B

MAXNETACCESSRATE ATTR_ MAXNETACCESSRATE 030C

Table 7. The Supported Keywords for Replacing SDP UUIDs or Attributes.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5.1 SDP

BDADDR UUID

The SDP bddaddr UUID command is the most useful command for retrieving SDP information

from the remote device. The command opens the SDP connection, does the SDP query, closes

the connection and replies to the client in encrypted form. The format is described below with

SDPATTR command.

Command: SDP bdaddr uuid

Reply: SDP bdaddr 0 ERROR reason

SDP bdaddr number_of_entries

SDP bdaddr info

...

SDP bdaddr info

SDPSEARCH link_id handle_1

SDPSEARCH link_id handle_2

...

SDPSEARCH link_id handle_n

Example: S: READY.

C: SDP 11:22:33:44:55:66 SERIALPORT

S: SDP 11:22:33:44:55:66 1

S: SDP 11:22:33:44:55:66 < I

PROTOCOLDESCRIPTORLIST < > >

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5.2 SDPSEARCH

The SDPSEARCH command is used to send a Service Search Request to a connected SDP

server, identified with link_id. The command only supports searching for one UUID at a time

(specified with the uuid parameter, 4 hex digits, or with a keyword), but several requests can

be sent during the same SDP connection. However, you must wait for the reply to the previous

reply before issuing new SDPSEARCH command.

Command: SDPSEARCH link_id uuid

Reply: SDPSEARCH link_id number_of_handles

SDPSEARCH link_id handle_1

SDPSEARCH link_id handle_2

...

SDPSEARCH link_id handle_n

Example: S: READY.

C: CALL 00:11:22:33:44:55 SDP

S: CALL 0

S: CONNECT 0 SDP

C: SDPSEARCH 0 LANACCESS

S: SDPSEARCH 0 1

S: SDPSEARCH 0 00010000

C: CLOSE 0

S: NO CARRIER 0 ERROR 000

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5.3 SDPATTR

The SDPATTR command is used to send a Service Attribute Request to a connected SDP

server, identified with link_id. The command supports requesting for one attribute value

(specified with the attribute parameter, 4 hex digits, or a keyword) in one (previously

retrieved) service entry (specified with the handle parameter, 8 hex digits), but several

requests can be sent during the same SDP connection. However, you must wait for the reply to

the previous reply before issuing new SDPSEARCH command.

The reply contains the response from the SDP server in encoded form. The code characters are

described in Table 8.

Char Description

I Unsigned integer (2, 4, or 8 hexadecimal digits) follows. Often handle, attribute,

or attribute value. Attribute values are shown as text if "BLUETOOTH READABLE"

is set to 1.

I Signed integer byte (2 hexadecimal digits) follows.

U UUID (4 or 8 hexadecimal digits) follows. Shown as text if "BLUETOOTH

READABLE" is set to 1.

S String follows.

B Boolean follows.

< Start of sequence.

> End of sequence.

A Alternative follows.

R Universal Resource Locator follows.

Table 8. SDP Response Formatting Characters.

Command: SDPATTR link_id handle attribute

Reply: SDPATTR link_id info

Example: S: READY.

C: CALL 00:11:22:33:44:55 SDP

S: CALL 0

S: CONNECT 0 SDP

C: SDPSEARCH 0 LAN

S: SDPSEARCH 0 1

S: SDPSEARCH 0 00010000

C: SDPATTR 0 00010000 DESCLIST

S: SDPATTR 0 > >

C: CLOSE 0

S: NO CARRIER 0 ERROR 000

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5.4 SDPQUERY

The SDPQUERY command is used to send a Service Search Attribute Request to a connected

SDP server, identified with link_id. The command supports requesting for one attribute value

(specified with the attribute parameter, 4 hex digits, or a keyword) in all service entries

containing one UUID (specified with the uuid parameter, 4 hex digits, or a keyword), but

several requests can be sent during the same SDP connection. However, you must wait for the

reply to the previous reply before issuing new SDPSEARCH command.

The reply contains the response from the SDP server in encoded form. The code characters are

described in Table 8.

Command: SDPQUERY link_id uuid attribute

Reply: SDPQUERY link_id info

Example: S: READY.

C: CALL 00:11:22:33:44:55 SDP

S: CALL 0

S: CONNECT 0 SDP

C: SDPQUERY 0 LAN DESCLIST

S: SDPQUERY 0 < > > >

C: SDPQUERY 0 1102 0100

S: SDPQUERY 0 < >

C: CLOSE 0

S: NO CARRIER 0 ERROR 000

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.5.5 SDP

The SDP command can be used to alter the WRAP’s SDP record. There are three

subcommands, described shortly in Table 9.

Subcommand Meaning

ADD uuid channel desc Add a new entry to the WRAP’s SDP record.

LIST List the WRAP’s SDP record entries.

DEL handle Delete one entry from the WRAP’s SDP record.

Table 9. The Subcommands of the SDP-command.

Command: SDP ADD uuid channel description

Reply: SDP handle

SDP handle ERROR reason

Command: SDP LIST

Reply: SDP handle uuid channel description

SDP handle uuid channel description

...

SDP handle uuid channel description

Command: SDP DEL handle

Reply: There is no reply.

Command: SDP bdaddr uuid

Reply: SDP bdaddr number_of_entries

SDP bdaddr info

...

SDP bdaddr info

Example: S: READY.

C: SDP ADD LANACCESS 4 "Lan access"

S: SDP 65536

C: SDP ADD SERIALPORT 10 "Serial port"

S: SDP 65537

C: SDP DEL 65537

C: SDP LIST

S: SDP 1

S: SDP 65536 LANACCESS 4 "Lan access"

C: SDP 11:22:33:44:55:66 SERIALPORT

S: SDP 11:22:33:44:55:66 1

S: SDP 11:22:33:44:55:66 < I

PROTOCOLDESCRIPTORLIST < > >

9.6 EXAMPLE SESSIONS

Outgoing RFCOMM Call:

S: READY.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

C: CALL 00:11:22:33:44:55 1 RFCOMM

S: CALL 2

S: CONNECT 2 RFCOMM 1042

S: STATUS 2 MSC 8d

C: CLOSE 2

S: NO CARRIER 2 ERROR 000

Incoming RFCOMM Call:

S: READY.

C: RING 2 00:11:22:33:44:55 1 RFCOMM 1042

S: STATUS 2 MSC 8d

S NO CARRIER 2 ERROR 000

9.7 ERROR CODES

Some commands may reply with an error code. The human-readable name of the error is

displayed as well, if the "SET BLUETOOTH READABLE" setting has a value of 1 (see the

description of the SET command). Error code 8 indicates that the Bluetooth server is busy

executing any number of commands; there can be several client applications using the stack.

Just wait a few seconds and try again. Other error codes indicate unexpected, but often only

temporary, communication problems.

You can analyze the error from the numeric code. Values bigger than or equal to 900 are

Bluetooth socket server interface errors, described in in Table 10.

Code Textual form Reason

900 SERVICE_NOT_FOUND Tried to CALL a device whose SDP records doesn't

include requested service.

901 ALREADY_CONNECTED Tried to CALL a device and a service channel that is

already connected.

902 OUT_OF_HANDLES Tried to CALL but there are too many open

connections.

903 INVALID_ADDRESS_<addr> Tried to CALL a device with a friendly name that

couldn't be found with inquiry.

904 BUSY Tried to CALL but there is another CALL still waiting for

CONNECT or NO CARRIER.

905 BUSY Tried to issue SDPATTR but another SDP request was

in progress.

906 BUSY Tried to issue SDPQUERY but another SDP request was

in progress.

907 NOT_CONNECTED Tried to CLOSE a connection handle that is not active.

908 BUSY Tried to issue SDPSEARCH but another SDP request

was in progress.

909 INVALID_ADDRESS Tried to NAME a device with a friendly name that can't

be found with inquiry.

90a BUSY Tried to issue NAME but another NAME was in

progress.

Table 10. Bluetooth Socket Server Interface Errors.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Other error codes can be analyzed as follows. For example "NO CARRIER ERROR 465": The

number "465" is hexadecimal, sum of 0x400 and 0x65, where 0x400 is a mask which means

this is an RFCOMM level error (see Table 11 for other error masks) and 0x65 (decimal 101)

that the RFCOMM error was connection timeout.

Mask Error level

0x100 HCI

0x200 L2CAP

0x300 SDP

0x400 RFCOMM

Table 11. Error masks.

The error codes for each mask are listed in the following tables.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

HCI Error Code

(decimal)

HCI_SUCCESS 0

HCI_ERR_UNKNOWN_COMMAND 1

HCI_ERR_NOCONNECTION 2

HCI_ERR_HARDWARE_FAIL 3

HCI_ERR_PAGE_TIMEOUT 4

HCI_ERR_AUTHENTICATION_FAILED 5

HCI_ERR_KEY_MISSING 6

HCI_ERR_MEMORY_FULL 7

HCI_ERR_CONNECTION_TIMEOUT 8

HCI_ERR_MAX_NUM_CONNECTIONS 9

HCI_ERR_MAX_NUM_SCO_CONNECTIONS 10

HCI_ERR_ACL_CONN_ALREADY_EXISTS 11

HCI_ERR_COMMAND_DISALLOWED 12

HCI_ERR_HOST_REJECTED_0D 13

HCI_ERR_HOST_REJECTED_0E 14

HCI_ERR_HOST_REJECTED_0F 15

HCI_ERR_HOST_TIMEOUT 16

HCI_ERR_UNSUPPORTED_PARAM_VALUE 17

HCI_ERR_INVALID_HCI_PARAMETER_VALUE 18

HCI_ERR_OTHER_END_TERMINATE_13 19

HCI_ERR_OTHER_END_TERMINATE_14 20

HCI_ERR_OTHER_END_TERMINATE_15 21

HCI_ERR_CONNECTION_TERMINATE_LOCALLY 22

HCI_ERR_REPEATED_ATTEMPTS 23

HCI_ERR_PARING_NOT_ALLOWED 24

HCI_ERR_UNKNOWN_LMP_PDU 25

HCI_ERR_UNSUPPORTED_REMOTE_FEATURE 26

HCI_ERR_SCO_OFFSET_REJECTED 27

HCI_ERR_SCO_INTERVAL_REJECTED 28

HCI_ERR_SCO_AIR_MODE_REJECTED 29

HCI_ERR_INVALID_LMP_PARAMETERS 30

HCI_ERR_UNSPECIFIED_ERROR 31

HCI_ERR_UNSUPPORTED_LMP_PARAMETER_VAL 32

HCI_ERR_ROLE_CHANGE_NOT_ALLOWED 33

HCI_ERR_LMP_RESPONSE_TIMEOUT 34

HCI_ERR_LMP_ERROR_TRANSACTION_COLLISION 35

HCI_ERR_LMP_PDU_NOT_ALLOWED 36

HCI_ERR_ENCRYPTION_MODE_NOT_ACCEPTABLE 37

HCI_ERR_UNIT_KEY_USED 38

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

HCI_ERR_QOS_NOT_SUPPORTED 39

HCI_ERR_INSTANT_PASSED 40

HCI_ERR_PAIRING_WITH_UNIT_KEY_NOT_SUPP 41

HCI_ERR_ILLEGAL_HANDLE 100

HCI_ERR_TIMEOUT 101

HCI_ERR_OUTOFSYNC 102

HCI_ERR_NO_DESCRIPTOR 103

Table 12. HCI Error Codes.

L2CAP Error Code

L2CAP_NO_CAUSE 0

L2CAP_ERR_PENDING 1

L2CAP_ERR_REFUS_INV_PSM 2

L2CAP_ERR_REFUS_SEC_BLOCK 3

L2CAP_ERR_REFUS_NO_RESOURCE 4

L2CAP_ERR_TIMEOUT_EXTERNAL 0xee

Table 13. L2CAP Error Codes.

SDP Error Code

(decimal)

SDP_ERR_RESERVED 0

SDP_ERR_UNSUPPORTED_SDP_VERSION 1

SDP_INVALID_SERVICE_RECORD_HANDLE 2

SDP_INVALID_REQUEST_SYNTAX 3

SDP_INVALID_PDU_SIZE 4

SDP_INVALID_CONTINUATION_STATE 5

SDP_INSUFFICIENT_RESOURCES 6

SDP_ERR_UNHANDLED_CODE 100

SDP_ERR_TIMEOUT 101

SDP_ERR_NOTFOUND 102

SDP_INVALID_RESPONSE_SYNTAX 103

SDP_NOT_FOUND (not really an error) 200

Table 14. SDP Error Codes.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

RFCOMM Error Code

(decimal)

RFCOMM_SUCCESS 0

RFCOMM_ERR_NORESOURCES 1

RFCOMM_ERR_ILL_PARAMETER 2

RFCOMM_ERR_REJECTED (Connection setup was rejected by remote side) 100

RFCOMM_ERR_TIMEOUT (Connection timed out) 101

RFCOMM_ERR_NSC (Non supported command received) 102

RFCOMM_ERR_ILLPARAMETER 103

Table 15. RFCOMM Error Codes.

If the problems persist after restarting the communication parties, please contact Bluegiga

Technologies as instructed in section 1.3.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.8 WRAP OBEX LIBRARIES

There are two libraries for making your own OBEX clients. See include/obex.h. libobex contains

mostly low level functions and libobexclient high level functions. Their usage in practice can be

studied using the source code of the "obexbrowser" application found in

src/examples/obexbrowser/.

9.8.1 LIBOBEX

int obex_init(int s_in, int s_out)

Initialize the OBEX library. Must be the first function called. s_in and s_out are data

handles for reading and writing.

int obex_deinit(void)

Deinitialize the OBEX library. Must be the last function called.

struct obex_t *obex_recv_packet(int timeout)

Receive one OBEX packet. You have to free() the received packet! If NULL is

returned, you have to disconnect next (timeout, dead socket, ...). If timeout is

zero, wait forever. If timeout is nonzero, wait up to timeout seconds.

int obex_send_packet(struct obex_t *o)

Send one packet. Does not call free().

void obex_packet(struct obex_t *o, int command)

Initialize an OBEX packet to empty command type packet.

void obex_packet_byte(struct obex_t *o, int header, char c)

void obex_packet_long(struct obex_t *o, int header, long l)

void obex_packet_string(struct obex_t *o, int header, char *s)

void obex_packet_binary(struct obex_t *o, int header, char *data, int len)

void obex_packet_ascii(struct obex_t *o, int header, char *s)

Add byte/long/unicode-string/binary/ascii data to an OBEX packet.

int obex_find_string(struct obex_t *o, int startoffset, int header, char *dest)

int obex_find_binary(struct obex_t *o, int startoffset, int header, char *dest)

int obex_find_ascii(struct obex_t *o, int startoffset, int header, char *dest)

int obex_find_long(struct obex_t *o, int startoffset, int header, long *dest)

Find header data from an OBEX packet. Returns -1 if not found, otherwise the

length of the data.

void obex_mime(char *filename, char *mime)

Return mime type for filename.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.8.2 LIBOBEXCLIENT

int obex_connect(char *target);

Connect to target UUID. Target can be NULL (Object Push connect). Returns 0 if no

errors, -1 if timeout, -2 if broken socket, >0 if OBEX error (see OBEX specification for

OBEX Response Codes).

int obex_disconnect(void);

Disconnect. Returns 0 if no errors, -1 if timeout, -2 if broken socket, >0 if OBEX error

(see OBEX specification for OBEX Response Codes).

int obex_put(char *name, char *type, char *data, long length, FILE *fdata);

Put local file / data block to remote.

name Remote file name. Can be NULL.

type Remote MIME type. Can be NULL.

data/length Pointer to data block and length. Can be NULL/0.

fdata File handle for local file, if data was NULL.

Returns 0 if no errors, -1 if timeout, -2 if broken socket, >0 the OBEX error code (see

OBEX specification).

signed long obex_get(char *name, char *type, char *data, long max_length, FILE *fdata);

Get remote file to local.

name Remote file name. Can be NULL.

type Remote MIME type. Can be NULL.

data/max_length Pointer to data block and length. Can be NULL/0.

fdata File handle for local file, if data was NULL.

Returns >=0 (number of bytes received) if no errors, -1 if timeout, -2 if broken

socket, <0 if OBEX error (see OBEX specification for OBEX Response Codes).

int obex_setpath(char *name, int flags);

Setpath to name with flags. Returns 0 if no errors, -1 if timeout, -2 if broken socket, >0

if OBEX error (see OBEX specification for OBEX Response Codes).

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

9.8.3 OBEXBROWSER

The application "obexbrowser" is an Object Push Profile (ObjP) and File Transfer Profile (FTP)

client, and is shipped with WRAP in both binary form (as it is part of the WRAP platform) and in

source form (at it is a good example of using the WRAP OBEX libraries).

For an outgoing ObjP/FTP call you need to:

1. Make the outgoing RFCOMM call from the Bluetooth server's command socket.

For example: "CALL 00:11:22:33:44:55 3 RFCOMM"

2. Run "obexbrowser" from the command line. It takes two parameters: hostname and

port number. Hostname is usually "localhost" and port number can be read from the

Bluetooth server's "CONNECT"-reply.

For example: "obexbrowser localhost 1024".

"obexbrowser" itself supports all the OBEX commands. See the source code and the Infrared

Data Association's "IrDA Object Exchange Protocol" documentation. The commands

obexbrowser accepts are described in Table 16.

Command Purpose

connect Makes default INBOX connect (Object Push).

connect-ftp Makes connect to FTP UUID.

disconnect Disconnect.

cd/ Setpath to root.

cd path Setpath to path.

cd.. Setpath with backup.

md path Create subdirectory path.

put local remote Put local to remote. Use "-" for local name to

delete remote file.

get local remote Get remote to local.

cat remote Cat remote.

ls Get mime "x-obex/folder-listing" without

filename.

Table 16. Obexbrowser commands.

Example:

Bluetooth server:

S: READY.

C: CALL 00:11:22:33:44:55 3 RFCOMM

S: CALL 0

S: CONNECT 0 RFCOMM 1024

Command line:

C: obexbrowser localhost 1024

C: connect

S: connect=00

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

C: get remote.vcf -

S: get=143

C: put default.vcf

S: put=00

C: disconnect

S: disconnect=00

C: <ctrl-d>

Bluetooth server:

S: NO CARRIER 0 ERROR 000

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

10 I/O API

The Bluegiga I/O API (Application Programming Interface) defines how to access the WRAP

general purpose I/O (P1), A/D converter (JP2 & JP3), DIP switches (SW2), and LEDs (D1-D8)

and contains functions to accomplish this.

The I/O API is accessed by using functions, macros, and constants defined in the header file

bgio.h. You can use the macros by including the file.

Example:

#include <bgio.h>

10.1 LED/BUZZER API

WRAP LEDs are controlled by using the following macros and functions. You need to add an

extra linker flag "LDFLAGS = -lbgio" to your Makefile when using the LED API.

#include <bgio.h>

BGIO_LED(int lednum)

BGIO_LED returns ledmask for lednum. lednum is the number of LED in the range 0

(D1) to BGIO_LED_MAX (D8).

int bgio_led_status(void)

bgio_led_status reads LEDs and returns current ledmask.

void bgio_led_set(int ledmask)

bgio_led_set sets LEDs in ledmask ON.

void bgio_led_clr(int ledmask)

bgio_led_clr sets LEDs in ledmask OFF.

ledmask is a bit mask where bit 0 is LED 0 (D1), bit 1 is LED 1 (D2), etc..

See src/examples/io/led/ for a LED API example.

LEDs and the buzzer can also be accessed via "/dev/led". You can check the status of the LEDs

and buzzer with "cat /dev/led" command and set LEDs or buzzer with "echo abcde > /dev/led"

command. A letter in upper case means that the LED or buzzer is ON, lower case means that

the LED or buzzer is OFF. Letter "a" is the buzzer, letters "b".."e" are LEDs 1..4.

10.2 GPIO API

Not yet available.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

11 ABOUT BLUEGIGA

Bluegiga Technologies Ltd. provides wireless local area networks and communication systems

based on Bluetooth technology.

Bluegiga connects Bluetooth enabled devices with corporate networks and the Internet. In

addition, Bluegiga products create easy-to-use and secure wireless links between Bluetooth

devices and applications.

Bluetooth connectivity extended to business and industrial applications

Bluetooth technology has become a new standard functionality in cell phones, PDAs, laptops

and an increasing number of other devices. With GSM-level security and low power drain,

Bluetooth links are utilized to enable cost efficient wireless connectivity.

For many, Bluetooth technology is first encountered as a flexible replacement to infrared links

and cables, and as convenient hands-free accessories to mobile phones. With the introduction

of intelligent access servers and Bluetooth modules that provide a connection between

Bluetooth devices and other network technologies, the way is paved for more demanding

business and industrial applications.

Using a Bluetooth access server, content and applications in both the Internet and corporate

intranets can be wirelessly accessed and synchronized using smart phones and other Bluetooth

enabled devices. With significantly lower power drain and superior flexibility compared to

WLAN technologies, Bluetooth is an ideal link between small battery-operated wireless devices

and data networks.

Versatile and cost-efficient network access from any device with a Bluetooth link provides a

platform for a wide variety of new wireless services - in marketing, promotion, retail, sports,

wellness, and more. First business applications include distribution and synchronization of

content; near future opportunities include - among many others - the use of Bluetooth enabled

smartphones as VoIP terminals.

Comprehensive product portfolio to design and build Bluetooth networks

Bluegiga products are software configurable for versatile integration. Bluegiga access products

link wireless devices as integral and secure parts of corporate networks and provide an ideal

solution for remote monitoring applications. In addition, Bluegiga range includes products to

replace cables in various industrial, M2M and telemetry applications, enhancing flexibility and

decreasing costs.

Bluegiga WRAP Multiradio Access Server enables the deployment of Bluetooth connectivity as a

new virtue of existing networks without network reconfiguration. Bluegiga’s first-generation

access products have been on the market since 2002, and the new Multiradio Access Server,

the first device to integrate multiple Bluetooth modules with WLAN, GSM, GPRS and Ethernet

LAN connectivities, was commercially launched in February 2004.

Bluegiga WRAP THOR Bluetooth modules with 100 meter range are robust, lightweight and

flexibly embeddable. The modules enable device manufacturers to easily add secure and

robust wireless communications links in both new and existing applications. Bluegiga also

offers a range of development tools, software versions and flexible production models from low

to high-volume applications with customized or standard Bluegiga software options.

Enabling new wireless services

A pioneering innovator in Bluetooth technology, Bluegiga has developed an easy-to-use,

secure and cost-efficient solution to connect Bluetooth devices to the Internet, corporate

intranets and other devices, enabling a wide range of new wireless services.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

Founded in 2000, Bluegiga is headquartered in Espoo, Finland and privately held. Bluegiga is

an associate member of the Bluetooth Special Interest Group. Bluegiga products are globally

available via a network of qualified distributors, original equipment and design manufacturers,

and system integrators.

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

APPENDIX A – WRAP DIRECTORY STRUCTURE

Directory Tree Type Note

============== ==== ====

/ f whole filesystem is root writable

|-- bin f

|-- boot f contains skeleton ramdisk structure

|-- dev d

| |-- [other devices] d

| `-- shm d resizable ramdisk

| |-- etc w resolv.conf

| |-- tmp w /tmp

| | |-- in w smsgw dir

| | |-- logo w smsgw dir

| | |-- obex w obexserver dir

| | |-- out w smsgw dir

| | |-- tone w smsgw dir

| | `-- wpkgd w wpkgd dirs

| | |-- in w

| | |-- out w

| | `-- spool w

| `-- var w ramdisk part of /var

| |-- lock w

| | `-- subsys w

| |-- log w

| |-- run w

| `-- tmp w

|-- etc f system config and init scripts

| |-- init.d -> rc.d/init.d l

| |-- pcmcia f

| | `-- cis f

| |-- ppp f

| | `-- peers f

| |-- rc.d f

| | |-- init.d f

| | `-- rc3.d f

| |-- rc3.d -> rc.d/rc3.d l

| |-- stupid-ftpd f

| `-- sysconfig f

|-- lib f system libraries

| |-- iptables f

| `-- modules f

| `-- [module directories] f

|-- mnt f mount points

| |-- mtd f2 second flash, 8MB for user use

| `-- nfs f empty mount point

|-- opt f

|-- proc p proc filesystem

|-- sbin f system binaries

|-- tmp -> dev/shm/tmp l temporary data (ramdisk)

|-- usr f

| |-- bin f

| |-- include f

| |-- lib f

| |-- local f

| | |-- bin f user binaries here

| | |-- etc f

| | |-- games f

| | |-- include f

| | |-- lib f

| | |-- libexec f

| | |-- man f

USER'S AND DEVELOPER'S GUIDE WRAP MULTIRADIO ACCESS SERVER

| | |-- sbin f

| | |-- share f

| | `-- src f

| |-- sbin f

| `-- share f

| |-- man f

| |-- misc f

| `-- terminfo f

| |-- a f

| |-- l f

| |-- v f

| `-- x f

`-- var f

|-- cache f

|-- empty f

|-- lib f

| |-- b2b f

| |-- installpoint f

| |-- misc f

| `-- setup f

|-- local f

|-- lock -> ../dev/shm/var/lock l

|-- log -> ../dev/shm/var/log l log files

|-- opt f

|-- run -> ../dev/shm/var/run l

|-- spool f

| `-- cron f

| `-- crontabs f

|-- tmp -> ../dev/shm/var/tmp l

`-- www f

`-- html f WWW pages

Types

=====

d = device file system, can be used to configure Linux

f = FLASH file system, read/write, files will be saved on power-down

l = link, symbolic link

p = PROC file system, can be used to configure Linux

w = RAM file system, read/write, files will be lost on power-down
