Simcom 1005242010007 CELL PHONE User Manual Rev04 911 20110621

Shanghai Simcom Ltd. CELL PHONE Rev04 911 20110621

Contents

Users Manual

21
67
1 2
3
4
5
Life Alert 911 Emergency Phone
Quick Start Instructions
Environmental Use Conditions
Ambient Temperature: -20 C/-4 F to 60 C/140 F
Relative Humidity: 0％- 95％
Atmospheric Pressure: 86 - 106Kpa
Working Frequency: GSM 850/1900
Quick Battery Installation or Replacement
1.Open the battery compartment cover on the back of the phone by removing small Phillips screw
and gently pulling back retention tab and remove the battery cover.
2.Insert three (3) non-rechargeable AAA size batteries into the battery compartment. Be sure to
place them in the correct orientation (+ and -) to insure the polarity of the batteries matches the
battery drawings inside the battery compartment.
3.Carefully replace the battery compartment cover.
4.Gently screw the Phillips retention screw into the back cover.
5.Press the battery check button for three (3) seconds to test batteries.
Life Alert 911 Phone Buttons and Jacks
1.
2.
3.
4.
5.
911 Emergency Button: Press this key for three (3) seconds to turn on the 911 phone and
automatically dial “911”. In addition, this key can also be used to dial the “1” key during a call
when doing so is necessary to get through a menu in order to reach a live 911 operator.
End Button: Press this button for three (3) seconds to disconnect and turn off the phone at anytime
during or at the end of a call.
Battery Check Button: Press this button for three (3) seconds to turn the phone on and to display
the battery percentage. It will display the battery percentage for ten (10) seconds before turning
the 911 phone back off.
Volume Decrease (－) Button: Press this button during the 911 call to decrease the speaker
volume. This button only functions DURING a 911 call.
Volume Increase (＋) Button: Press this button during the 911 call to increase the speaker volume.
This button only functions DURING a 911 call.
6. The Firmware Upgrade Interface Jack: DO NOT use this mini-usb jack for charging or powering
the 911 phone. This jack is only for factory use.
7. Headphone Jack: This jack may be used for headsets as may be required by the hearing impaired.
IMPORTANT NOTE: 911 phone ONLY operates within GSM cellular service coverage areas.
34
2. Use 【911】button ( ) to simulate a press of the number【1】key to negotiate a menu.
3. Press 【End】button ( ) for three (3) seconds to end the present call and turn off the 911phone.
1
2
Checking the Battery Level
Press 【Check Battery】button ( ) to display the present remaining battery percentage. After 10
seconds, the 911 phone will automatically turn off. Display shows as the following example:
3
Note: If the remaining battery power is below 40%, please replace them immediately with three
(3) high quality non-rechargeable AAA batteries.
Ending the 911 Call
To end the 911call, press 【End】 button ( ) for three (3) seconds to end the 911 call and shutdown
the phone. Please note, that while checking the remaining battery power, the【End】button will be
not be active.
2
screen.After 10 failed attempts,the user must press the“911”button again for three (3) seconds
to restart the 911 dialing process.
Duringthe911Call:
1.The user can press【VOL＋】button( )and【VOL－】( )button to adjust the speaker volume.
The speaker volume can ONLY be adjusted during a 911 call. It does not affect the voice prompt
volume.
5 4
Safety Precautions
Sensitive Electronic Equipment
When near high precision electronic equipment, please turn off the phone. Otherwise, failure to do so
may cause nearby electronic equipment malfunctions. The following equipment may be affected by
the use of cellular telephones, including but not limited to: hearing aids, pacemakers, fire alarms,
automatic gates and other automatic control equipment. Users who use auxiliary medical equipment
should contact the equipment provider and confirm the effect of cellular telephones on the equipment.
Medical Facilities
Please note the following in medical facilities:
● Please do not use the 911 phone in the emergency room, operating room, intensive care unit
(ICU) or coronary care unit (CCU).
● Please do not use the phone when in the vicinity of medical equipment. Also, please do not use
the 911phone in medical places where the use of cellular phones is prohibited.
● Please note the ringer, volume level and vibration setting, so as not to disturb patients with heart
disease or other environmentally sensitive medical conditions.
Quick Start User Instructions
Dialing “911”
Press the 【911】button ( ) for three (3) seconds to turn on and dial the “911” operator. This will
be accompanied by a vibration indicating the phone is on and preparing to dial 911. Once connected
to the GSM cellular network, the voice prompt “calling 911” will enunciate and the 911 phone will
automatically attempt to connect to the “911”.
If the initial 911call fails,the 911 phone will automatically redial 911 up to a maximum of 10 times.
The redial attempts will be accompanied with the corresponding voice prompts and status on the LCD
1
56
FCC Statement and the body for body-worn operation.
RF Exposure Information:
The SAR limit of USA(FCC) is1.6W/kg averaged over one gram of tissue.This 911 phone device
(Containing module with FCC ID: ) has been tested against this SAR limit. TheUDV-1005242010007
highest SAR value reported under this standard during product certification for use at the ear is 0.838
W/kg.
Tests for SAR are conducted using standard operating positions specified by the FCC with the device
transmitting at its highest certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the device while operation can
be well below the maximum value. This is because the device is designed to operate at multiple
power levels so as to use only the power required to reach the network. In general, the closer you
are to a wireless base station antenna, the lower the power output. Before a device model is
available for sale to the public, it must be tested and certified to the FCC that it does not exceed the
limit established by the government-adopted requirement for safe exposure. The tests are performed
NOTE:
This device was tested to comply with FCC rules based on the pre-approved module (FCC ID:
UDV-1005242010007) that was installed in the unit. The original FCC ID is labeled on the GSM
Module.
This product's IMEI label was placed in the battery compartment. It can be accessed by removing
the battery cover and removing the batteries.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each
model. (Body-worn measurements may differ among device models, depending upon available
accessories and FCC requirements.) While there may be differences between the SAR levels of
various devices and at various positions, they all meet the government requirement for safe
exposure.
For body worn operation, this device has been tested and meets the FCC RF exposure guidelines
when used with an accessory that contains no metal. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.Please keep 1.5cm between the mobile phone
Combustion and Explosive Warnings
In flammable and explosive areas, please do not use the phone to avoid causing an explosion or fire.
Flammable and explosive area examples, but not limited to, the following:
● Gas stations
● Other fueling areas (such as propane gas filling stations)
