Sintai Optical RC03 Remote Controller-B User Manual
Sintai Optical (Shenzhen) Co., Ltd. Remote Controller-B
User Manual
![](/img.php?id=3132650&img=bg1.png)
Remote Control-B
Optional Accessory for SP360 4K
© 2016 JK Imaging Ltd. All Rights Reserved.
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
http://kodakpixpro.com
Printed in China
VR369086099-0
Functionality Overview:
1. Signal Indicator Lamp
2. Signal Test Button
3. Recording / Shooting Switch *
4. Battery / Memory Card Indicator Light
5. Recording / Shooting Button
6. Shooting Status Indicator Light
7. External Antenna
8. Battery Cover
Indudes:
- Remote Control-B
- Part No. RR-BK02
- Accessories Tool
- Button Cell Battery CR2450
- External Antenna
- Wrist Strap
Specifications:
• Dimensions: 47×48×13.7mm (excluding external
antenna)
• Weight: 27g (battery included, excluding external
antenna)
• Temperature: -10 to 40°C
• Humidity: 0~90%
• Battery: Button Cell CR2450
EN
Battery Installation:
Open the battery cover plate with the included
accessories tool in a counter clockwise direction. Insert
the battery with the anode facing upward. Replace cover
plate over battery and turn clockwise to lock into place.
CR2450
1
6
7
5
2
3
4
8
Recording / Shooting Switch xed in Global Mode.
*
![](/img.php?id=3132650&img=bg2.png)
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
