Users Manual
9.957.033 002
584 PROFLAME G FIRE TRANSMITTER
USE AND INSTALLATION INSTRUCTIONS
Read the instructions before use. This control must be installed in accordance with the rules in force.
The SIT 584 PROFLAME G Fire Transmitter is a device that allows, when used with the 584
PROFLAME G Fire Receiver and in conjunction with the Combination Gas Control, to command
appliances like fireplaces and log sets.
With the 584 PROFLAME G Fire Transmitter it is possible to turn the appliance on and off.
The 584 PROFLAME G Fire Transmitter is the Remote Control that commands the Receiver. See
Fig. 1.
Moving the side slider in the direction of the transmission light it is also possible to disconnect the
electric supply of the internal batteries (child safety feature).
English -
4
2
2
ENGLISH
ON /OFF Key
Side slider
Fig. 1: 584 PROFLAME G Fire Transmitter
Transmission light
IMPORTANT
The 584 PROFLAME G Fire Transmitter is integrating part of the 584 PROFLAME G System,
which is composed of:
•
584 PROFLAME G Fire Transmitter
•
584 PROFLAME G Fire Receiver
The 584 PROFLAME G Fire Transmitter is designed and realized to be used exclusively with
the 584 PROFLAME G Fire Receiver.
Please use this Installation Manual in conjunction with the 584 PROFLAME G Fire System, for
complete installation instructions.
3
Supply voltage 4.5 V (Three AAA batteries)
Ambient temperature ratings 0 - 60 °C (32 - 140 °F)
Radio frequency 315 MHz
TECHNICAL DATA
CAUTION
Property Damage Hazard.
Excessive heat can cause property damage
The fireplace can stay ignited for many hours. Take care to turn off the fireplace if it is
unattended by adult people.
Do not leave the Remote Control where children can reach it.
Check the functionality of the
Remote Control
The Remote Control is powered by
three AAA 1.5 V batteries in the
proper compartment with the correct
polarity; see Fig. 2. The correct
power of the Remote Control can be
checked observing the presence of
the red light when ON/OFF button is
pressed; see Fig. 1.
ENGLISH
Fig. 2
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USERS'S AUTHORITY TO
OPERATE THE EQUIPMENT.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, this is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and Receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the Receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
