Skidata SD705 Inductive Tag Reader Module User Manual sd705
Skidata AG Inductive Tag Reader Module sd705
Skidata >
Users Manual
V 1.0
Manual
sd705
Manual sd705
Page 2 © SKIDATA AG, June 2006
SKIDATA AG
Technical Documentation
Untersbergstrasse 40
A-5083 Grödig/Salzburg
Telephone +43 6246 888-0
Telefax +43 6246 888-7
Internet http://www.skidata.com
e-mail docu@skidata.com
Copyright
© 2006 by SKIDATA AG. All rights reserved. All information in the
following document is protected by copyright law. No part of this
document may be reproduced without the written consent of SKI-
DATA AG. SKIDATA AG reserves the right to make any changes
of specification and other information in this document without
further notice.
Please note
During the compilation of this Technical Documentation, great
care has been taken to ensure the accuracy of the information
contained in it. However, despite our constant effort to ensure the
highest degree of accuracy and comprehensiveness possible,
the information provided cannot be guaranteed to be absolutely
error-free.
Trademarks
This documentation may contain representations of registered
product or service trademarks owned by SKIDATA AG or third
parties, as well as references to proprietary know-how protected
by copyright laws or other legal provisions. In any case the intel-
lectual property rights remain exclusively with their respective
owners.
Declaration of Conformity
The sd705 has been developed, designed and manufactured in
accordance with the following EU directive:
R&TTE (1999/5/EC)
0408
Version June 2006
Sd705 Manual
© SKIDATA AG, June 2006 Page 3
FCC 15.21:
IMPORTANT: Any changes to or modifications of de sd705, in-
cluding antenna, unless expressly approved by SKIDATA™, may
void the user’s authority to operate this device.
The final product should contain labelling according to FCC re-
quirements.
For example:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause un-
desired operation. This device contains FCC ID QSS-SD705.
This label will be placed on the final product, clearly visible to all
persons exposed to the transmitter.
Canada:
Operation is subject to the following two conditions: (1) this de-
vice may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device.
Document Management – Version Table
Tab. 1: Document Version Table for Installation & Maintenance Instructions
Section Document Pages Version Date
1 sd705 4 1.0 2006-06-27
Manual sd705
Page 4 © SKIDATA AG, June 2006
sd705 1
1
sd705
Version 1.0
5 pages
Copyright 2006 by SKIDATA AG
sd705 1
General 1.2
© SKIDATA AG, Version 1.0 Page 3
1.2 General
The sd705 is a Radio Transceiver Module (RFID module) which
is designed for installation in SKIDATA devices by SKIDATA AG
only.
The module is not to be sold as an individual product.
The sd705 must be connected to the appropriate devices by
means of the plug-in connector provided for this purpose. The il-
lustrations show the plug-in boards for 5 V DC power supply and
the data transfer line, as well as the plug-in parts for the
antennas. It is prohibited to use antennas other as the antennas
certified to be used with the sd705.
1 sd705
1.3 sd705
Page 4 © SKIDATA AG, Version 1.0
1.3 sd705
1.3.1 front view
1.3.2 rear view
Fig. 1: front view sd705
13 Mhz Ant2
13 Mhz Ant1
125 kHz Ant1
Power / Rs232
125 kHz Ant2
Fig. 2: rear view sd705
Power
/
R
S
232
(
0 V
/
5 V
)
