Inspiro audioHub legal information (029-3138)
Inspiro audioHub
Equipment and accessories
inspiro audioHub
Universal power supply US/EU
Audio cable 3.5 mm jack-jack (1m)
Cinch to 3.5 mm
Packaging insert
Declaration of Conformity
Declaration of Conformity
Hereby, Phonak Communications AG, Länggasse 17, CH-
3280 Murten, declares that the inspiro audioHub is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. To obtain a
copy of the Declaration of conformity, please contact the
manufacturer or the local Phonak representative whose
address can be taken from the list on www.phonak.com
(worldwide locations).
This device complies with Part 15 and part 95 of the FCC
Rules and with RSS210 of Industry Canada. Operation is
subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device
must accept any interference received, including
interference that may cause undesired operation. This
equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment. To
comply with FCC RF exposure limits for general
population/uncontrolled exposure, the antenna(s) used for
this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not
be collocated or operating in conjunction with any other
antenna or transmitter. This transmitter is authorized by
rule under the Low Power Radio Service (47 CFR part 95)
and must not cause harmful interference to TV reception
or United States Navy SPASUR installations. You do not
need an FCC license to operate this transmitter. This
transmitter may only be used to provide: auditory
assistance to persons with disabilities, persons who
require language translation, or persons in educational
settings; health care services to the ill; law enforcement
tracking services under agreement with a law enforcement
agency; or automated maritime telecommunications
system (AMTS) network control communications. Two
way voice communications and all other types of uses not
mentioned above are expressly prohibited. This device
may not interfere with TV reception or Federal
Government radar. For Canada: if TV channel 13 is used
in the area, the installer shall reduce or adjust the radio
frequency radiated power so that nearby TV channel 13
receivers do not receive radio interference from the
system installed. Suggestions: A test with a TV receiver
equipped with a “rabbit-ear antenna” and tuned to channel
13 should be conducted at the perimeter of the user’s
intended coverage area and should not overlap other
users’ areas without the latter’s consent. If this does not
solve the problem, a channel near the 217 MHz edge and
not near 216 MHz should be tried.
This Class B digital apparatus complies with Canadian
ICES-003. To comply with Industry Canada RF exposure
limits for general population / uncontrolled exposure, the
antenna(s) used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all
persons and must not be collocated or operating in
conjunction with any other antenna or transmitter.
Information and explanation of symbols
The CE symbol is confirmation
that this Phonak product meets
the requirements of the R&TTE
Directive 1999/5/EC on Radio
and Telecommunication
Terminal Equipment. The alert sign means that potential
restrictions on its use are applicable in one or more EU
Member States.
The symbol with the crossed out disposal
bin indicates that the product shall not be
treated as household waste. Please hand
over your old or unused product to the
applicable collection point for the recycling
of electrical and electronic equipment or
bring your old product to your hearing care professional
for appropriate disposal. By ensuring this product is
disposed of correctly, you will help prevent potential
negative effects on the environment and human health.
Connecting the device to mains power
Select an easily accessible socket
outlet and plug the power supply
unit into the socket outlet.
The device features input and
output mini-USB connectors which
both have the following electrical
characteristics:
5V 1A in, 0.77A out
Alternatively to plugging the power supply to the
mains, this device can be power-supplied through USB
(version 2.0 or higher) using a USB cable.
Procedure for charging an inspiro
Switch OFF inspiro device and place it on the USB
holder of inspiro audio Hub mechanical top housing.
