CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
When you dispose of the battery, you must obey the law in the relative area or
country.
IMPORTANT
The name plate is located on the battery holder inside of the grip.
WARNING
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
If the transmitter develops an abnormally high temperature, a burning odor or
smoke during use, remove the battery holder and stop using the transmitter
immediately.
Take care not to burn your fingers when removing the battery holder as the
batteries may be very hot at this time.
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
For the customers in the U.S.A.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
All interface cables used to connect peripherals must be shielded in order to
comply with the limits for a digital device pursuant to Subpart B of part 15 of FCC
Rules.
If you have any questions about this product, you may call;
Sony Customer Information Service Center 1-800-222-7669 or http://www.sony.
com/
Declaration of Conformity
Trade Name: SONY
Model: DWM-02N
Responsible party: Sony Electronics Inc.
Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number: 858-924-2230
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Use of Sony wireless devices is regulated by the Federal Communications
Commission as described in Part 74 subpart H of the FCC regulations and users
authorized thereby are required to obtain an appropriate license.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment has very low levels of RF energy that are deemed to
comply without testing of specific absorption rate (SAR).
For the customers in Canada
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however,
that these low power wireless devices are absolutely safe. Low power Wireless
devices emit low levels of radio frequency energy (RF) in the microwave range
while being used. Whereas high levels of RF can produce health effects (by
heating tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF exposures
have not found any biological effects. Some studies have suggested that some
biological effects might occur, but such findings have not been confirmed by
additional research. DWM-02N has been tested and found to comply with IC
radiation exposure limits set forth for an uncontrolled environment and meets
RSS-102 of the IC radio frequency (RF) Exposure rules.
The term “IC:” before the radio certification number only signifies that Industry
Canada technical specifications were met.
This device operates on a no-protection no-interference basis. Should the user
seek to obtain protection from other radio services operating in the same TV
bands, a radio licence is required. Please consult Industry Canada’s document
CPC-2-1-28, Optional Licensing for Low-Power Radio Apparatus in the TV Bands,
for details.
For the customers in Europe
This product has been manufactured by or on behalf of Sony Corporation,
1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. Inquiries related to product
compliance based on European Union legislation shall be addressed to the
authorized representative, Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Germany. For any service or guarantee matters, please refer to
the addresses provided in the separate service or guarantee documents.
Before operating this unit, please read the separate R&TTE precautions
document.
Voor de klanten in Europa
Lees voordat u het apparaat gaat gebruiken eerst het aparte document met
waarschuwingen m.b.t. radio- en telecommunicatieontvangstapparatuur
(R&TTE).
För kunder i Europa
Innan du använder den här enheten ska du läsa det separata dokumentet om
försiktighetsåtgärder enligt R&TTE-direktivet.
Para clientes na Europa
Antes de utilizar esta unidade, leia o documento R&TTE fornecido em separado.
Til europæiske kunder
Læs det separate R&TTE-direktiv om forholdsregler, inden du betjener enheden.
Asiakkaille Euroopassa
Lue erillinen radio- ja telepäätelaitteita koskeva varoitusasiakirja (R&TTE) ennen
laitteen käyttöä.
For kunder i Europa
Les det separate R&TTE-dokumentet med forsiktighetsregler før du bruker denne
enheten.
Για τoυς πελάτες πoυ διαμένoυν σε χώρες της Eυρώπης
Πριν χρησιμοποιήσετε αυτήν τη μονάδα, διαβάστε το ξεχωριστό έγγραφο λήψης
προφυλάξεων της οδηγίας R&TTE.
Pro zákazníky v Evropě
Před použitím tohoto zařízení si prostudujte bezpečnostní upozornění v
samostatném dokumentu R&TTE.
Klientidele Euroopas
Palun tutvuge enne seadme kasutamist eraldi dokumendiga mis puudutab
R&TTE direktiivist tulenevaid ettevaatusabinõusid.
Európai ügyfeleinknek
A készülék használatba vétele előtt szíveskedjék elolvasni a rádió- és távközlési
berendezésekkel kapcsolatos óvintézkedéseket ismertető R&TTE dokumentumot.
Dla klientów w Europie
Przed przystąpieniem do korzystania z tego urządzenia należy przeczytać
oddzielny dokument dotyczący środków ostrożności wynikających z dyrektywy
w sprawie urządzeń radiowych i końcowych urządzeń telekomunikacyjnych oraz
wzajemnego uznawania ich zgodności (dyrektywa R&TTE).
Pentru clienţii din Europa
Înainte de a utiliza unitatea, vă rugăm să citiţi documentul separat R&TTE cu
măsuri de precauţie.
Pre zákazníkov v Európe
Pred spustením tohto prístroja si prečítajte osobitné opatrenia smernice R&TTE.
Za stranke v Evropi
Pred uporabo te naprave preberite ločen dokument z varnostnimi ukrepi v zvezi
z R&TTE.
Za korisnike u Europi
Prije upotrebe ovog uređaja pročitajte dokument s R&TTE mjerama opreza.
For the customers in the U.S.A.
SONY LIMITED WARRANTY - Please visit http://www.sony.com/psa/warranty
for important information and complete terms and conditions of Sony’s
limited warranty applicable to this product.
For the customers in Canada
SONY LIMITED WARRANTY - Please visit http://www.sonybiz.ca/pro/lang/en/
ca/article/resources-warranty-product-registration for important information
and complete terms and conditions of Sony’s limited warranty applicable to
this product.
For the customers in Europe
Sony Professional Solutions Europe - Standard Warranty and Exceptions on
Standard Warranty.
Please visit http://www.pro.sony.eu/warranty for important information and
complete terms and conditions.
For the customers in Korea
SONY LIMITED WARRANTY - Please visit http://bpeng.sony.co.kr/handler/
BPAS-Start for important information and complete terms and conditions of
Sony’s limited warranty applicable to this product.
4-585-171-01
(1)
Digital Wireless
Microphone
Before Using this Unit
Before operating the unit, please read this manual thoroughly and retain it for
future reference.
DWM-02N
© 2015 Sony Corporation Printed in Japan
DWM-02N flyer (GB) 4-585-171-01 (1)
Mass approx. 235g (8oz) including batteries
Supplied accessories Identification ring (1 set)
Microphone holder (1)
USB adapter cable (1)
Carrying case (1)
Stand adaptor (1)
For the model available in the U.S.A.: PF1/2 to
W5/8 type
For the model available in Europe.: PF1/2 to W3/8
type
Before Using this Unit (3)
CD-ROM (1)
Design and specifications are subject to change without notice.
Notes
Always verify that the unit is operating properly before use. SONY WILL
NOT BE LIABLE FOR DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED
TO, COMPENSATION OR REIMBURSEMENT ON ACCOUNT OF THE LOSS
OF PRESENT OR PROSPECTIVE PROFITS DUE TO FAILURE OF THIS UNIT,
EITHER DURING THE WARRANTY PERIOD OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER REASON WHATSOEVER.
SONY WILL NOT BE LIABLE FOR CLAIMS OF ANY KIND MADE BY USERS OF
THIS UNIT OR MADE BY THIRD PARTIES.
SONY WILL NOT BE LIABLE FOR THE TERMINATION OR DISCONTINUATION
OF ANY SERVICES RELATED TO THIS UNIT THAT MAY RESULT DUE TO
CIRCUMSTANCES OF ANY KIND.
Precautions for Use
The life expectancy of the electrolytic capacitor is about 5 years under normal
operating temperatures and normal usage (8 hours per day; 25 days per month).
If usage exceeds the above normal usage frequency, the life expectancy may be
reduced correspondingly.
Features
The DWM-02N is a digital wireless microphone that features an interchangeable
microphone capsule unit design, and is intended for use in UHF synthesized
wireless microphone systems. The DWM-02N can be used in vocal performances,
interviews, speeches, and a variety of other applications.
Using the CD-ROM manual
The manual can be read on a computer with Adobe Reader installed.
You can download Adobe Reader free from the Adobe website.
Open the index.html file in the CD-ROM.
1
Select and click on the manual that you want to read.
2
Note
If you have lost or damaged the CD-ROM, you can purchase a new one from your
Sony dealer or Sony service counter.
Specifications
Transmitting section
Oscillator type Crystal-controlled PLL synthesizer
RF power output 1 mW/10 m W/50m W (e.r.p) selectable
Antenna type Helical antenna
Occupied RF bandwidth 192 kHz or less
Audio delay MODE1: 1.5 ms
MODE2: 1.0 ms
MODE3: 2.1 ms
Allowable deviation of transmission frequency
±6.5 ppm
Type of emission G1E or G1D
Modulation method π/4 Shift QPSK
Audio section
Maximum input level –16 dBu (with 0 dB attenuator)
Audio attenuator adjustment range (pad)
0 to 48 dB (3 dB steps)
Input impedance 4.7 kΩ or more
Frequency response 20 Hz to 22 kHz
General
Operating voltage 3V DC, with two LR6 (AA) alkaline batteries
Battery life Continuous operating time 5hours (at 25 °C (77 °F),
10-mW output using Sony LR6 (AA)-size alkaline
batteries with CODEC MODE set to MODE1 and
the wireless remote control function off and
DIMMER MODE set to AUTO OFF, and with the
CU-C31 Sony capsule unit mounted)
Operating temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Wireless remote control 2.4-GHz IEEE802.15.4 compliant
Dimensions (unit: mm (inches))
ø37.1
(11/2)
194
(7 3/4)

Navigation menu
