Sony Corporation Wireless HD Sink radio module Users Manual
Users Manual
Installation Manual
MODEL : SII-SK63101
FCC ID:AK8-HMZ-WM1
IC : 409B-HMZWM1
1. Example of mounting to the final product.
2. Contents of the plan described in the manual of the final product.
For FCC
"Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
Main
board
Cross-section
AV/Power
Cable
RF Board
BB Chip RF Chip
Battery
Module’s shield case
Exterior case (ABS)
Additional shield case / Heat sink
Additional shield case / Heat sink
EUT
RF
board
R
F
F
P
C
RF
board
R
F
EUT
EUT
Heat sink
Connect to
main board
with FPC
Assembly
AV/Power
Cable
Battry
Top cover
EUT
Middle cover
Battery
Bottom cover
Screw
SONY Corp.
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
--Consult the dealer or an experienced radio/TV technician for help."
FCC WARNING
You are cautioned that any changes or modifications not expressly approved in
this manual could void your authority to operate this equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
For IC
"This device complies with Industry Canada licence-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device."
For FCC/IC
"This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment and meets
the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC
radio frequency (RF) Exposure rules.
3. Contents of the plan described in the label of the final product.
For FCC
Label of the end product:
For SII-SK63101 module: The final end product must be labeled in a visible area with the following
"Contains FCC ID:AK8-HMZ-WM1 ".
For IC
Label of the end product:
For SII-SK63101 module: The final end product must be labeled in a visible area with the following
"Contains IC:409B-HMZWM1 ".
