Sony Group ZSRS60BT Personal Audio System User Manual ZS RS60BT
Sony Corporation Personal Audio System ZS RS60BT
ZS-RS60BT_User manual
ZS-RS60BT_U2 [US] 4-559-901-11(1)
4-559-901-11(1)
Personal Audio System
Operating Instructions
©2014 Sony Corporation Printed in China
ZS-RS60BT
* and VOL + have a tactile dot.
The following FCC/IC statement applies
only to the version of this model
manufactured for sale in the USA and
Canada. Other versions may not comply
with FCC/IC technical regulations.
NOTE:
For United States customers. Not applicable in
Canada, including in the province of Quebec.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
This equipment must not be co-located or operated
in conjunction with any other antenna or transmitter.
This equipment complies with FCC/IC radiation
exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to OET65
and RSS-102 of the IC radio frequency (RF) Exposure
rules.
This equipment has very low levels of RF energy
that it deemed to comply without maximum
permissive exposure evaluation (MPE). But it is
desirable that it should be installed and operated
keeping the radiator at least 20 cm or more away
from person’s body (excluding extremities: hands,
wrists, feet and ankles).
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
This graphical symbol is located on the bottom of
the unit.
Notice for the customers in Canada
This device complies with Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.
Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Personal Audio System is designed to be used
for playing back music sources on CDs or USB
devices, transferring music to USB devices,
listening to radio stations, and listening to music
on BLUETOOTH devices.
Basic Operations
Before using the unit
To turn the power on or off
Press POWER . You can also turn on the power of
this unit using the direct power-on function (below).
In this manual, operations are mainly explained
using the direct power-on function.
To use the direct power-on function
Press CD , USB , BLUETOOTH , FM/AM ,
AUDIO IN or FAVORITE RADIO STATIONS (1-3)
while the unit is turned off. The power turns on with
the relevant function selected.
To adjust the volume
Press VOL + or .
To listen through headphones
Connect headphones to the (headphones) jack
.
To reinforce the bass
Press MEGA BASS .
“MEGA BASS” lights up on the display.
To return to normal sound, press the button again.
Playing a music disc
1 Press CD to turn on the CD function.
2 Press PUSH OPEN/CLOSE , place a disc in
the CD compartment and then close the
compartment cover.
Label side up
The disc is loaded and the disc information
appears on the display.
Audio CD
Total number of tracks
Total playing time
MP3/WMA disc
Total number of folders*
* If MP3/WMA files are present only in the root directory
(“ROOT” folder), “1FLDR” appears on the display.
3 Press to start playback.
Track number or MP3/WMA file
number
Playing time
When you play an MP3/WMA disc, the folder
name*1 and song title are displayed before the
playing time*2 appears.
*1 If MP3/WMA files are present only in the root directory,
“ROOT” appears on the display.
*2 If the playing time is longer than 100 minutes, “--:--”
appears on the display.
Other operations
To Do this
Pause playback Press . To return to
playback, press the button
again.
Stop playback Press . When you press
after playback is stopped,
playback starts from the point
where you stopped playback
(Resume Play).
Select a folder
on an MP3/WMA
disc
Press + or .
Select a track/
file
Press or . You can
skip tracks/files one by one.
Find a point in a
track/file
Hold down or
during playback, and release the
button at the desired point.
When locating a point while
paused, press to start
playback after the desired point
is found.
Tip
To cancel the Resume Play, press while the CD is
stopped.
Note
Resume Play is cancelled in the following cases:
When you open the CD compartment.
When you turn off the power.
Example of folder structure and playing order
The playing order of the folders and files is as
follows. However, the playing order may differ from
the original order on the disc, depending on the
recording method used.
Folder
MP3/WMA file
Notes on MP3/WMA discs
When a disc is loaded, the unit reads all the files on that
disc. During this time, “READING” is flashing. If there are
many folders or non-MP3/WMA files on the disc, it may
take a long time for play to begin or for the next MP3/
WMA file to start to play.
We recommend that non-MP3/WMA files or unnecessary
folders are excluded when creating MP3/WMA discs.
During playback, audio files other than MP3 and WMA
files are skipped even if those files are included in a folder.
The audio formats supported by this unit are as follows:
MP3: File extension “.mp3”
WMA: File extension “.wma”
Note that even if the file name has the correct file
extension but the actual file was created in a different
audio format, this unit may produce noise or may
malfunction.
MP3 PRO format is not supported.
This unit conforms to version 1.0, 1.1, 2.2, 2.3 and 2.4 of the
ID3 tag format for MP3 files, the WMA tag format defined
by the ASF specification (Advanced Systems Format) for
WMA files, and the AAC tag format for AAC files.
When a file has the ID3, WMA or AAC tag information, the
song title, artist name, and album name will be displayed.
If a file does not have the tag information, the unit
displays as follows:
File name instead of the song title.
“NO ARTIST” message instead of the artist name.
“NO ALBUM” message instead of the album name.
ID3, WMA and AAC tag information can be displayed up to
64 characters.
Transferring music from a disc to a
USB device
You can transfer a whole disc (CD SYNC transfer) or
the currently playing track or file (REC1 transfer) to a
USB device (digital music player or USB storage
media, etc.).
When transferring from a CD, the tracks are
transferred as MP3 files with a sampling frequency
of 44.1 kHz at 128 kbps (CBR). When transferring
from an MP3/WMA disc, MP3/WMA files are
transferred with the same bit rate as the original
MP3/WMA files.
1 Connect the USB device to the (USB) port .
2 Press CD to turn on the CD function.
3 Place the disc you want to transfer in the CD
compartment.
CD SYNC transfer
To transfer a whole disc
Proceed to step 4.
To transfer MP3/WMA files in a specific
folder
Press + or repeatedly to select the folder
you want.
To transfer only your favorite tracks/files
Perform step 1 to 5 of “Creating your own
program (Program Play)” on the back page.
REC1 transfer
To transfer a single track/file
Select and start playback of the track/file you
want to transfer.
4 Press REC .
“REC” flashes on the display and the unit starts
calculating the amount of free space on the USB
device.
If “LOW ***M” appears on the display, there is not
sufficient space on the device. To cancel the
transferring, press . To continue transferring
anyway, proceed to step 5.
5 Press ENTER .
Transferring starts.
When transferring is completed, playback stops
automatically (CD SYNC transfer) or proceeds to
the next track/file (REC1 transfer).
To stop transferring
Press .
An MP3/WMA file is created up to the point the
transferring was stopped.
Folder and file generation rules
When first transferring to a USB device, a “MUSIC”
folder and its sub folder “SONY” are created directly
below the “ROOT” folder.
Folders and files are generated within the “CD”
folder under the “SONY” folder based on the
following rules.
CD SYNC transfer
Transferring
source Folder name File name
MP3/WMA Same as the transferring source*1, 2
CD-DA “ALBUM001”*3“TRACK001”*4
REC1 transfer
Transferring
source Folder name File name
MP3/WMA “REC1”*5
Same as the
transferring
source*2
CD-DA “TRACK001”*4
*1 In Program Play mode, the folder name is “FLDRxxx,” and
the file name depends on the transferring source.
*2 A folder name of up to 64 characters can be assigned.
*3 Folder names are assigned in sequential order up to a
maximum of 999 (including the “ROOT” and “MUSIC”
folders).
*4 File names are assigned in sequential order.
*5 A new file is transferred to the “REC1” folder each time
single track transfer is performed.
To erase audio files or folders from the USB
device
1 Press or repeatedly to select an
audio file, or press + or – repeatedly to
select a folder.
2 Press ERASE .
“ERASE?” appears on the display.
3 Press ENTER .
“TRACK ERASE?” or “FOLDER ERASE?” appears on
the display.
4 Press ENTER .
The selected audio file or folder is erased, and
“COMPLETE” appears on the display.
Notes
If you start transferring in shuffle play or repeat play
mode, the selected play mode is automatically changed
to normal play.
Do not remove the USB device during transferring or erase
operations. Doing so may corrupt the data on the device
or damage the device itself.
While transferring, no sound is output and “HI-SPEED”
appears on the display.
CD-TEXT information is not transferred in the created MP3
files.
Transferring stops automatically if:
the USB device runs out of space during transferring.
the number of audio files and folders on the USB device
reaches the limit that the unit can recognize.
Non-MP3/WMA/AAC format files or sub folders in the
folder are not erased.
Radio sound and sound from an optional component
cannot be transferred to a USB device.
Note on copyright-protected content
The transferred music is limited to private use only. Use of
the music beyond this limit requires permission from the
copyright holders.
WMA files encoded in WMA DRM, WMA Lossless and
WMA PRO formats cannot be played back.
This unit cannot play audio files on a disc in the following
cases:
When the total number of audio files exceeds 999.
When the total number of folders on a single disc
exceeds 256 (including the “ROOT” folder).
When the directory level (folder depths) exceeds 8
(including the “ROOT” folder).
Folder names and file names can be displayed with up to
64 characters, including quotation marks.
Characters and symbols that cannot be displayed by the
unit will appear as “_”.
This unit conforms to version 1.0, 1.1, 2.2, 2.3 and 2.4 of the
ID3 tag format for MP3 files and the WMA tag format
defined by the ASF specification (Advanced Systems
Format) for WMA files. When a file has the ID3 or WMA tag
information, the song title, artist name, and album name
will be displayed. If a file does not have the tag
information, the unit displays as follows:
File name instead of the song title.
“NO ARTIST” message instead of the artist name.
“NO ALBUM” message instead of the album name.
ID3 and WMA tag information can be displayed up to 64
characters.
Listening to music on a USB device
You can listen to audio files stored on a USB device
(a digital music player or USB storage media).
Audio files in MP3, WMA and AAC formats* can be
played on this unit.
* Files with copyright protection (Digital Rights
Management) cannot be played on this unit.
1 Connect the USB device to the (USB) port .
2 Press USB to turn on the USB function.
The volume label scrolls once, then the total
number of folders appears on the display.
Total number of folders
3 Press to start playback.
The folder name and song title are displayed, and
then the file number and playing time appear.
File number
Playing time*
* If the playing time is longer than 100 minutes, “--:--”
appears on the display.
Other operations
To Do this
Pause playback Press . To return to
playback, press the button
again*.
Stop playback Press . When you press
after playback is stopped,
playback starts from the point
where you stopped playback
(Resume Play).
Select a folder Press + or .
Select a file Press or . You can
skip files one by one.
To skip files continuously, hold
down or and
release the button at the desired
file.
Find a point in a
file
Hold down or
during playback, and release the
button at the desired point.
When locating a point while
paused, press to start
playback after the desired point
is found.
* When playing a VBR MP3/WMA/AAC file, playback may
restart from a different point.
Note
When removing a USB device, always hold down until
“NO DEV” appears on the display. Removing the USB device
without performing this step may corrupt the data on the
USB device or damage the device itself.
Example of folder structure and playing order
The playing order of the folders and files is as
follows. However, the playing order may differ from
the original order on the USB device, depending on
the recording method used.
Folder
MP3/WMA/AAC file
USB device
Notes on the USB device
It may take a long time before playback starts when:
the folder structure is complex.
the USB device is close to capacity.
Do not save non-MP3/WMA/AAC files or unnecessary
folders to a USB device that contains MP3/WMA/AAC files.
During playback, audio files other than MP3, WMA and
AAC files are skipped even if those files are included in a
folder.
The audio formats supported by this unit are as follows:
MP3: file extension “.mp3”
WMA: file extension “.wma”
AAC: file extension “.m4a,” “.3gp” and “.mp4”
Note that even if the file name has the correct file
extension but the actual file was created in a different
audio format, this unit may produce noise or may
malfunction.
MP3 PRO format is not supported.
WMA files encoded in WMA DRM, WMA Lossless and
WMA PRO formats cannot be played back.
AAC files encoded in copyright-protected AAC format
cannot be played back.
This unit supports the AAC-LC (AAC Low Complexity)
profile.
This unit cannot play audio files on a USB device in the
following cases:
When the total number of audio files in a single folder
exceeds 999.
When the total number of audio files on a single USB
device exceeds 5,000.
When the total number of folders on a single USB
device exceeds 256 (including the “ROOT” folder).
When the directory level (folder depths) exceeds 8
(including the “ROOT” folder).
These numbers may vary depending on the file and folder
structure.
Compatibility with all encoding/writing software is not
guaranteed. If audio files on the USB device were
originally encoded with incompatible software, those files
may produce noise or interrupted sound, or may not be
played back at all.
Folder names and file names can be displayed using up to
64 characters, including quotation marks.
Characters and symbols that cannot be displayed by the
unit will appear as “_”.
WARNING
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To reduce the risk of fire, do not cover the ventilation
opening of the appliance with newspapers,
tablecloths, curtains, etc. Do not expose the
appliance to naked flame sources (for example,
lighted candles).
To reduce the risk of fire or electric shock, do not
expose this apparatus to dripping or splashing, and
do not place objects filled with liquids, such as
vases, on the apparatus.
As the main plug is used to disconnect the unit from
the mains, connect the unit to an easily accessible
AC outlet. Should you notice an abnormality in the
unit, disconnect the main plug from the AC outlet
immediately.
The unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned off.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
Do not expose the batteries (battery pack or
batteries installed) to excessive heat such as
sunshine, fire or the like for a long time.
The nameplate is located on the bottom exterior.
Owner’s Record
The model and serial numbers are located on the
bottom of the unit. Record these numbers in the
space provided below. Refer to them whenever you
call upon your Sony dealer regarding this product.
Model No. ZS-RS60BT
Serial No.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified by
the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Power Sources
Connect the AC power cord , or insert six LR14 (size C) batteries (not supplied) into the battery compartment
.
Listening to music wirelessly on a
BLUETOOTH device
Using the BLUETOOTH connection, you can listen to
music from wirelessly connected BLUETOOTH
devices such as mobile phones, smartphones, music
players, etc.
Pairing this unit with a
BLUETOOTH device
BLUETOOTH devices must be “paired” with each
other beforehand. Once BLUETOOTH devices are
paired, there is no need for pairing again, unless the
pairing information is cleared.
Choose the pairing method below depending on
your device.
Pairing with an NFC-incompatible BLUETOOTH
device:
see Pattern A
Pairing with an NFC-compatible smartphone:
see Pattern B
Pattern A
Pairing with an NFC-incompatible
BLUETOOTH device
Keep the BLUETOOTH device and the unit within 1
meter (39 3/8 in) of each other for this operation.
1 Press BLUETOOTH to turn on the
BLUETOOTH function.
If no devices have been paired, such as when you
press BLUETOOTH for the first time after you
purchase the unit, the unit automatically enters
pairing mode, and the BLUETOOTH indicator ( )
and “PAIRING” flash on the display.
When pairing with two or more
BLUETOOTH devices
Hold down BLUETOOTH (–PAIRING) until two
beeps are heard.
2 Turn on the BLUETOOTH function of the
BLUETOOTH device.
3 Perform the pairing procedure on the
BLUETOOTH device to detect the unit.
4 Select “ZS-RS60BT” shown on the display of
the BLUETOOTH device.
If “ZS-RS60BT” does not appear on the device’s
display, repeat from step 2.
5 If Passcode* input is required on the display of
the BLUETOOTH device, input “0000.”
The BLUETOOTH connection is established.
“BTAUDIO” appears on the display.
* “Passcode” may be referred to as “Passkey,” “PIN code,”
“PIN number,” or “Password.”
Tip
You can pair up to 8 BLUETOOTH devices. If the 9th
BLUETOOTH device is paired, the oldest paired device will be
deleted.
Notes
Pairing mode of the unit is cancelled after about
5minutes, and the BLUETOOTH indicator ( ) flashes. If
pairing mode is cancelled while performing this
procedure, start over from step 1.
The passcode of the unit is fixed as “0000.” The unit
cannot be paired with a BLUETOOTH device whose
Passcode is not “0000.”
Pattern B
Pairing with an NFC-compatible
smartphone
By just touching the unit with an NFC-compatible
smartphone, the unit is turned on and switched to
the BLUETOOTH function automatically and then
paired and connected to the smartphone.
Compatible smartphones
Smartphones with the NFC function built-in
(OS: Android™ 2.3.3 or later, excluding Android 3.x)
What is “NFC”?
NFC (Near Field Communication) is a
technology enabling short-range wireless
communication between various devices,
such as mobile phones and IC tags. Thanks to
the NFC function, data communication can be
achieved easily just by touching the relevant
symbol or designated location on NFC
compatible devices.
1 Turn on the NFC function of the smartphone.
For details, refer to the operating instructions
supplied with the smartphone.
If your smartphone OS is Android 2.3.3 or
later, but earlier than Android 4.1
Proceed to step 2.
If your smartphone OS is Android 4.1 or
later
Proceed to step 4.
2 Download and install the app “NFC Easy
Connect” on the smartphone.
“NFC Easy Connect” is an original app by Sony for
Android phones, and is available at the Google
Play™ Store.
Search for “NFC Easy Connect” or scan the
following two-dimensional code to download
and install the free app. Communication fees are
required to download the app.
The App may not be available in some countries
and/or regions.
Tip
For some smartphones, One-touch connection may be
available without downloading the app “NFC Easy
Connect.” In that case, the operation and specifications
may be different from the description here. For details,
refer to the operating instructions supplied with the
smartphone.
For the two-dimensional code:
Use a two-dimensional code reader app.
3 Start the app “NFC Easy Connect” on the
smartphone.
Make sure that the application screen is
displayed.
To a wall outlet
To AC IN
AC power cord (supplied)
Rear
Notes
Replace the batteries when the OPR/BATT indicator dims, or when the unit becomes inoperable. Replace all of the batteries
with new ones. Before you replace the batteries, be sure to remove any CD and disconnect any USB devices or optional
components from the unit.
To use the unit on batteries, disconnect the AC power cord from the unit and the wall outlet.
In standby mode with the AC power cord connected, “STANDBY” appears on the display.
4 Touch the unit with the smartphone.
Keep touching the smartphone to the N mark
on the unit until the smartphone responds.
Note
If your smartphone screen is locked, the smartphone will
not function. Release the lock, then touch the
smartphone to the N mark again.
Smartphone responds
(unit recognized)
Follow the on-screen instructions to establish the
connection.
When the BLUETOOTH connection is established,
“BTAUDIO” appears on the display.
Tips
If it is difficult to establish the connection, try the
following.
Activate the app “NFC Easy Connect” and move the
smartphone slightly across the N mark on the
unit.
If the smartphone is in a case, remove it.
Touch the unit with the smartphone again to
disconnect.
If you have multiple NFC-compatible devices, just
touch the smartphone to a different device to switch
the connection to that device. For example, when your
smartphone is connected with NFC-compatible
headphones, just touch the smartphone to the unit to
change the BLUETOOTH connection to the unit
(One-touch connection switching).
Listening to music
Check the following before operating the unit.
The BLUETOOTH function of the BLUETOOTH
device is turned on.
Pairing has been completed. (See “Pairing this unit
with a BLUETOOTH device”.)
1 Make the BLUETOOTH connection between
the unit and the device.
For an NFC-incompatible BLUETOOTH
device
Press BLUETOOTH to turn on the BLUETOOTH
function.
The last connected device will be connected
automatically.
For an NFC-compatible smartphone
Touch the smartphone to the N-Mark on the
unit.
2 Start playback of an audio source such as
music, videos, games, etc., on the device.
Refer to the instruction manual of your device for
details on playback operations.
Tip
To adjust the volume, set the volume of the BLUETOOTH
device or the smartphone to the moderate level, and then
press VOL or + on the unit.
To terminate a BLUETOOTH connection
Do any of following.
Turn off the BLUETOOTH function of the
BLUETOOTH device. For details, refer to the
operating instructions supplied with the device.
Turn off the BLUETOOTH device.
Change the function of the unit.
Turn off the unit.
Touch the unit with the smartphone again to
disconnect (NFC-compatible smartphones only).
To clear the paired device information
1 Hold down ERASE until “BT RESET” appears
on the display.
2 Press ENTER .
When the paired device information is cleared,
“COMPLETE” appears on the display. To cancel
the reset operation, press .
Listening to the radio
1 Press FM/AM repeatedly to turn on the
radio function and select the band “FM” or
“AM.”
2 Hold down TUNE + or until the frequency
digits begin to change on the display.
The unit automatically scans the radio
frequencies and stops when it finds a clear
station.
If you cannot tune to a station using automatic
tuning mode, press TUNE + or repeatedly to
change the frequency step by step.
When an FM stereo broadcast is received, “ST”
lights up on the display.
Tips
The unit of frequency of tuned stations is MHz for the FM
band and kHz for the AM band.
If the stereo FM reception is noisy, press FM MODE
repeatedly until “MONO” appears on the display. You will
lose the stereo effect, but the reception will be improved.
To improve radio reception
Reorient the antenna to
improve FM reception.
Reorient the unit
itself to improve AM
reception.
Presetting stations to FAVORITE
RADIO STATIONS
You can preset up to three favorite stations to
FAVORITE RADIO STATIONS (1-3) buttons. Assign one
FM or AM program for each button.
1 Press FM/AM repeatedly to turn on the
radio function and select the band “FM” or
“AM.”
2 Tune to the station you want to preset.
3 Press and hold the desired FAVORITE RADIO
STATIONS (–SET) (1-3) button until you hear
a beep.
The tuned station is preset to the selected button
of FAVORITE RADIO STATIONS (1-3) and the same
number as that of the button will light up on the
display.
(Example: Presetting FM 87.5 MHz to number )
To change the preset station
Repeat steps 1 to 3.
The preset station on the button will be replaced by
the new one.
Listening to preset stations with
FAVORITE RADIO STATIONS
Press the desired FAVORITE RADIO STATIONS (1-3)
button .
Note
To prevent the preset from being changed by mistake, do
not hold down the button. If doing so, the preset on the
button will be replaced by the currently tuned station.
ZS-RS60BT_U2 [US] 4-559-901-11(1)
Using the display
Checking the information of an audio CD
Press twice to cancel Resume Play.
The total number of tracks and total playing time
appear on the display.
Checking MP3/WMA/AAC file information
Press DISPLAY repeatedly while playing an
MP3/WMA file on the disc or an MP3/WMA/AAC
file on the USB device.
The display changes as follows:
Song title ( )*1, 2
Artist name ( )*1
Album name ( )*1
Current file number and playing time*3
*1 If the file does not have corresponding ID3, WMA or AAC
tag information, the file name, “NO ARTIST,” and “NO
ALBUM” scroll on the display instead of the song title,
artist name, and album name.
*2 The function name is displayed for 2 seconds before the
song title appears.
*3 The artist name or album name will change to this in a
few seconds.
Checking the connected BLUETOOTH
device name
Press DISPLAY while connecting the
BLUETOOTH device.
Checking the radio information
Press DISPLAY repeatedly while listening to
the radio.
The display changes as follows:
Preset number*1, 2 Frequency
*1 A preset number is displayed only when you are listening
to the preset radio station.
*2 The display automatically returns to the frequency display
after 2 seconds have elapsed.
Selecting play mode
You can set the unit to play tracks or files repeatedly
or in random order while a disc/USB device is
stopped.
Press PLAY MODE repeatedly.
Each time you press the button, the indication
changes as follows:
Normal play (None)
Single repeat ( 1)
All repeat ( )
Selected folder play ( )*
Selected folder repeat play ( , )*
Shuffle play ( )
Program play (PGM)
Program repeat play ( , PGM)
* These functions are available only when playing MP3/
WMA files on an MP3/WMA disc or MP3/WMA/AAC files
on a USB device.
Playing tracks/files repeatedly (Repeat
Play)
You can set the unit to repeatedly play CD-DA tracks
on an audio CD, MP3/WMA files on a CD-R/CD-RW
disc, or MP3/WMA/AAC files on a USB device in
normal and program play modes.
1 Press CD or USB to turn on the CD or
USB function.
2 Proceed as follows.
To repeat Do this
A single track/
file
1 Press PLAY MODE
repeatedly until “ 1” appears.
2 Press
or to select
a track/file that you want to
repeat.
3 Press
.
All tracks/files 1 Press PLAY MODE
repeatedly until “ ” appears.
2 Press
.
A selected folder
on an MP3/WMA
disc or USB
device
1 Press PLAY MODE
repeatedly until “ ” and “ ”
appear.
2 Select a folder by pressing +
or .
3 Press
.
Programmed
tracks/files
1 Program tracks/files (see
“Creating your own program
(Program Play)”).
2 Press PLAY MODE until
“PGM” and “ ” appear on the
display.
3 Press
.
To cancel Repeat Play
Press to stop playback, and then press PLAY
MODE repeatedly until “ ” (or “ 1”) disappears
from the display.
Playing tracks/files in random order
(Shuffle Play)
You can set the unit to play CD-DA tracks on an
audio CD, MP3/WMA files on a CD-R/CD-RW disc or
MP3/WMA/AAC files on a USB device in random
order.
1 Press CD or USB to turn on the CD or
USB function.
2 Press PLAY MODE repeatedly until “ ”
appears on the display.
3 Press to start Shuffle Play.
To cancel Shuffle Play
Press to stop playback, and then press PLAY
MODE repeatedly until “ ” disappears from the
display.
Tip
During Shuffle Play, you cannot select the previous track/file
by pressing .
Creating your own program (Program
Play)
You can arrange the playing order of up to 25
tracks/files on a disc/USB device.
1 Press CD or USB to turn on the CD or
USB function.
2 Press PLAY MODE repeatedly until “PGM”
appears on the display.
3 Press or to select a track/file.
When you want to specify a folder that contains
MP3/WMA/AAC files, press + or first to
select a folder, and then press or to
select a file.
Other Operations 4 Press ENTER .
The track/file is programmed.
The program step number appears, followed by
the total playing time.
(Example: audio CD)
Step number
Last programmed track number
Total playing time*
* “--:--” appears when programming an MP3/WMA
disc/USB device or when the total playing time is
longer than 100 minutes.
5 Repeat steps 3 and 4 to program additional
tracks/files.
6 Press to start Program Play.
The created program remains available until you
open the CD compartment or turn off the power
of the unit. To play the same program again,
press .
Note
If you try to program 26 tracks/files or more, “FULL” flashes
on the display.
To display programmed track/file
information
After creating your own program, you can check
information about programmed tracks/files.
Press DISPLAY repeatedly and the display
changes as follows:
Total number of steps Last programmed track/
file number and the total playing time*
* “--:--” appears for MP3/WMA discs and USB devices.
To cancel Program Play
Press to stop playback, and then press PLAY
MODE repeatedly until “PGM” disappears from
the display.
To delete all tracks/files in the current
program
Stop playback, and then press . “NO STEP”
appears and you can create a new program,
following the procedure “Creating your own
program (Program Play).”
Presetting radio stations
You can store radio stations in the unit’s memory.
You can preset up to 30 radio stations, 20 for FM and
10 for AM.
1 Press FM/AM repeatedly to turn on the
radio function and select the band “FM” or
“AM.”
2 Hold down FM/AM until “AUTO” flashes on
the display.
3 Press ENTER to store the station.
The stations are stored in memory from lower
frequencies to higher ones.
If a station cannot be preset
automatically
You need to preset a station with a weak signal
manually.
1 Press FM/AM repeatedly to select a band.
2 Tune to the desired station.
3 Hold down ENTER until “FM-xx” or “AM-xx”
flashes on the display.
(Example: FM)
4 Press PRESET + or until the preset
number for the station you want flashes on
the display.
5 Press ENTER to store the station.
If another station is already assigned to the
selected preset number, that station is replaced
by the new one.
Tip
The preset radio stations remain in the unit’s memory even
in the following situations.
The AC power cord is unplugged.
The batteries are removed.
Listening to preset radio stations
1 Press FM/AM repeatedly to turn on the
radio function and select the band “FM” or
“AM.”
2 Press PRESET + or to select a stored
preset number for the desired radio station.
Using the Sleep Timer
You can set the unit to turn off automatically after a
set time has elapsed.
1 Press SLEEP .
The default setting (“90”) appears and the
“SLEEP” indicator lights up on the display.
2 Press SLEEP repeatedly to select the
desired setting.
Each time you press the button, the duration (in
minutes) changes on the display, and the
selected setting is confirmed automatically after
about 4 seconds.
Tip
You can check the time left until the unit turns off by
pressing SLEEP again after setting the sleep timer.
Connecting optional components
You can enjoy the sound from an optional
component, such as a portable digital music player,
through the speakers of this unit.
Be sure to turn off the power of each component
before making any connections.
For details, refer to the instruction manual of the
component to be connected.
1 Connect the AUDIO IN jack to the line
output jack of the portable digital music
player or other component using an audio
connection cable (not supplied).
2 Turn the connected component on.
3 Press AUDIO IN and start playing sound on
the connected component.
The sound from the connected component is
output from the speakers.
To connect the unit to a TV or video recorder/
player, use an extension cable (not supplied) with
a stereo-mini jack on one end and two phono
plugs on the other end.
Additional Information
Compatible devices
Compatible USB devices
Compatibility requirements for the USB devices are
as follows. Before using a device with this unit,
check that it meets the requirements.
Compliance with USB 2.0 (Full Speed)
Supports Mass Storage mode*
* Mass Storage mode is a mode that allows a USB device
to become accessible to a host device, enabling file
transfers. Most USB devices support Mass Storage
mode.
Notes on the USB device
When a USB device is connected, the unit reads all the
files on the device. If there are many folders or files on the
device, it may take a long time for the unit to finish
reading them.
Do not connect a USB device to the unit through a USB
hub.
With some connected USB devices, after an operation is
performed, there may be a delay before it is performed by
this unit.
This unit may not support all the functions provided with
a connected USB device.
The playback order on this unit may differ from the
playback order on a connected USB device.
Compatible BLUETOOTH devices
Compatibility requirements for the devices are as
follows. Before using a device with this unit, check
that it meets the requirements.
Devices must conform to BLUETOOTH Standard
version 2.1 + EDR.
Devices must support A2DP (Advanced Audio
Distribution Profile) and AVRCP (Audio/Video
Remote Control Profile).
NFC capability (required only when using the NFC
pairing function of the unit).
For the latest information on compatible
BLUETOOTH devices, including NFC-compatible
smartphones, check the websites below.
For customers in the USA:
http://esupport.sony.com
For customers in Canada:
(English)
http://sony.ca/support
(French)
http://fr.sony.ca/support
What is BLUETOOTH wireless
technology?
BLUETOOTH wireless technology is a short-range
wireless technology that enables wireless data
communication between digital devices, such as a
computer and digital camera. BLUETOOTH wireless
technology operates within a range of about 10 m
(33 feet).
Connecting two devices as necessary is common,
but some devices can be connected to multiple
devices at the same time.
You do not need to use a cable for connection, nor is
it necessary for the devices to face one another,
such is the case with infrared technology. For
example, you can use such a device in a bag or
pocket.
BLUETOOTH standard is an international standard
supported by thousands of companies all over the
world, and employed by various companies
worldwide.
Maximum communication range
Maximum communication range may shorten under
the following conditions.
There is an obstacle such as a person, metal, or
wall between the unit and BLUETOOTH device.
A wireless LAN device is in use near the unit.
A microwave oven is in use near the unit.
A device that generates electromagnetic radiation
is in use near the unit.
The unit is placed on a shelf made of steel.
Optimal performance
Limited performance
The unit
Steel cabinet
Interference from other devices
Because BLUETOOTH devices and wireless LAN
(IEEE802.11b/g/n) use the same frequency,
microwave interference may occur and resulting in
communication speed deterioration, noise, or invalid
connection if the unit is used near a wireless LAN
device. In such a case, perform the following.
Use the unit at least 10 m (33 feet) away from the
wireless LAN device.
If the unit is used within 10 m (33 feet) of a
wireless LAN device, turn off the wireless LAN
device.
Use the BLUETOOTH device as close to the unit as
possible.
Interference to other devices
Microwaves emitting from a BLUETOOTH device may
affect the operation of electronic medical devices.
Turn off the unit and other BLUETOOTH devices in
the following locations, as it may cause an accident.
where inflammable gas is present, in a hospital,
train, airplane, or a gas station
near automatic doors or a fire alarm
Notes
To be able to use the BLUETOOTH function, the
BLUETOOTH device to be connected requires the same
profile as the unit’s.
Note also that even if the same profile exists, devices may
vary in function depending on their specifications.
Due to the characteristic of BLUETOOTH wireless
technology, the sound played on the unit is slightly
delayed from the sound played on the BLUETOOTH device
during listening to the music.
This unit supports security capabilities that comply with
the BLUETOOTH standard to provide a secure connection
when the BLUETOOTH wireless technology is used, but
security may not be enough depending on the setting. Be
careful when communicating using BLUETOOTH wireless
technology.
We do not take any responsibility for the leakage of
information during BLUETOOTH communication.
A device featuring the BLUETOOTH function is required to
conform to the BLUETOOTH standard specified by
Bluetooth SIG, and be authenticated. Even if the
connected device conforms to the above mentioned
BLUETOOTH standard, some devices may not be
connected or work correctly, depending on the features or
specifications of the device.
Noise or sound skips may occur depending on the
BLUETOOTH device connected with the unit, the
communication environment or the usage environment.
MP3/WMA/AAC files cannot be played
back.
The audio files may have inappropriate file
extensions. The file extensions supported by this
unit are as follows:
MP3: file extension “.mp3”
WMA: file extension “.wma”
AAC: file extension “.m4a,” “.3gp” and “.mp4”
The audio files may have been created in formats
other than MP3/WMA/AAC formats.
The USB storage device uses a file system other
than FAT16 or FAT32.*
The files are encrypted or protected by passwords.
* This unit supports FAT16 and FAT32, but some USB storage
media may not support both file systems.
For details, refer to the operation manual of the USB
storage device in question or contact the manufacturer.
BLUETOOTH device
There is no sound.
Make sure that this unit is not too far from the
BLUETOOTH device (or smartphone), or that this
unit is not receiving interference from a wireless
LAN, another 2.4 GHz wireless device, or a
microwave oven.
Check that the BLUETOOTH connection was
completed properly between this unit and the
BLUETOOTH device (or smartphone).
Perform pairing again (See “Pairing this unit with a
BLUETOOTH device”).
Keep away from metal objects or surfaces.
Make sure that the BLUETOOTH function is
activated on the BLUETOOTH device (or
smartphone).
The sound skips or the correspondence
distance is short.
If a device that generates electromagnetic
radiation, such as a wireless LAN, other
BLUETOOTH device(s), or a microwave oven is
nearby, move away if possible. Or use the device
and the unit away from such sources.
Remove any obstacle between this unit and the
device or move the device and the unit away from
the obstacle.
Locate this unit and the device as close to each
other as possible.
Re-position this unit.
Try using the BLUETOOTH device or smartphone in
another position.
A connection cannot be established.
Depending on the device to be connected, it may
require some time to start communication.
Perform pairing again (See “Pairing this unit with a
BLUETOOTH device”).
Check that the BLUETOOTH device is compatible
with this unit. For the latest information on
compatible BLUETOOTH devices, check the
information on the website. The URL is listed
under “Compatible BLUETOOTH devices.”
Pairing fails.
Bring the BLUETOOTH device closer to the unit.
Delete the model name of this unit from the
BLUETOOTH device and perform pairing again
(See “Pairing this unit with a BLUETOOTH device”).
Check that the BLUETOOTH device is compatible
with this unit. For the latest information on
compatible BLUETOOTH devices, check the
information on the website. The URL is listed
under “Compatible BLUETOOTH devices.”
Pairing using the NFC function fails.
Try pairing manually (See “Pairing this unit with a
BLUETOOTH device”). Some NFC-compatible
smartphones may not be paired using the NFC
function of this unit, depending on the features or
specifications of the device.
Relaunch “NFC Easy Connect” and move the
smartphone slowly over the N mark .
Check that the smartphone meets the
compatibility requirements (See “Compatible
smartphones”).
Radio
The sound is weak or reception is poor.
Replace all the batteries with new ones.
Move the unit away from nearby TVs.
For FM reception, extend the antenna to its full
length, and reorient it for best FM reception. For
AM reception, reorient the unit itself to find the
best reception.
If you are in a building, listen near a window.
If a mobile phone is placed close to the unit, a
loud noise may be heard from the unit. Keep the
phone away from the unit.
The TV picture is unstable.
If you are listening to an FM program near a TV
with an indoor antenna, move the unit away from
the TV.
After trying the suggested remedies, if the problem
persists, unplug the AC power cord or remove all the
batteries. After all the indications on the display
disappear, plug in the AC power cord again, or
re-insert the batteries. If the problem persists,
consult your nearest Sony dealer.
Precautions
Discs that this unit CAN play
Audio CD (CD-DA*1 tracks)
CD-R/CD-RW that contains MP3/WMA files and
is finalized*2 correctly.
*1 CD-DA is the abbreviation for Compact Disc Digital Audio.
It is a recording standard used for audio CDs.
*2 Finalizing is the process to make the CD-R/CD-RW discs
playable on the consumer disc player products, and the
finalizing can be enabled or disabled as optional settings
during disc creation in most recording software.
Discs that this unit CANNOT play
CD-R/CD-RW other than those recorded in audio
CD format or formats conforming to ISO9660
Level 1/Level 2 or Joliet
CD-R/CD-RW of poor recording quality, CD-R/
CD-RW with scratches or that is dirty, or CD-R/
CD-RW recorded using an incompatible recording
device
CD-R/CD-RW that is unfinalized or finalized
incorrectly
Notes on discs
Clean the CD with a cleaning cloth if
the disc is dirty. Wipe the disc from
the center out. If there are scratches,
dirt or fingerprints on the disc, a
tracking error may occur.
Do not use solvents such as
benzine, thinner, commercially
available cleaners or anti-static
spray intended for vinyl LPs.
Do not expose the CD to direct sunlight or heat
sources such as hot air ducts, or leave it in a car
parked in direct sunlight as there can be a
considerable rise in temperature inside the car.
Do not stick paper or a sticker on the CD, or
scratch the surface of the CD.
After playing, store the CD in its case.
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side with
digital audio material on the other side. However,
since the audio material side does not conform to
the Compact Disc (CD) standard, playback on this
product is not guaranteed.
Music discs encoded with copyright
protection technologies
This product is designed to playback discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware that
among those discs, there are some that do not
conform to the CD standard and may not be
playable by this product.
On safety
As the laser beam used in the CD player section is
harmful to eyes, do not attempt to disassemble
the casing. Refer servicing to qualified personnel
only.
Should any solid object or liquid fall into the unit,
unplug the unit, and have it checked by qualified
personnel before operating it any further.
Discs with non-standard shapes (e.g., heart,
square, star) cannot be played on this unit.
Attempting to do so may damage the unit. Do not
use such discs.
On power sources
For AC operation, use the supplied AC power cord;
do not use any other cord.
Unplug the unit from the wall outlet if it is not to
be used for an extended period of time.
When not using the batteries, remove them to
avoid damage that can be caused by battery
leakage or corrosion.
On placement
Do not leave the unit in a location near heat
sources, in a place subject to direct sunlight,
excessive dust or mechanical shock, or in a car
subject to the direct rays of the sun.
Do not place the unit on an inclined or unstable
surface.
Do not place anything within 10 mm (13/32 in) of
the rear of the cabinet. The ventilation openings
must be unobstructed for the unit to operate
properly and prolong the life of its components.
Since a strong magnet is used for the speakers,
keep personal credit cards using magnetic coding
or spring-wound watches away from the unit to
prevent possible damage from the magnet.
On operation
If the unit is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens inside the CD
player section. Should this occur, the unit will not
operate properly. In this case, remove the CD and
wait about an hour for the moisture to evaporate.
On handling the unit
Do not leave the CD compartment open to avoid
dust and debris contamination.
On cleaning the cabinet
Clean the cabinet, panel and controls using a soft
cloth slightly moistened with a mild detergent
solution. Do not use any type of abrasive pad,
scouring powder, or solvent, such as alcohol or
benzine.
If you have any questions or problems concerning
your unit, consult your nearest Sony dealer.
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
(The United States model only)
With 6-ohm loads, both channels driven from 150Hz
10,000Hz; rated 1.5W per channel-minimum RMS power,
with no more than 10% total harmonic distortion in AC
operation.
CD player section
System
Compact disc digital audio system
Laser diode properties
Emission duration: Continuous
Laser output: Less than 44.6μW
(This output is the value measurement at a distance of
200 mm from the objective lens surface on the optical
pick-up block with 7mm aperture.)
Number of channels
2
Frequency response
20Hz 20,000Hz +1/–2dB
Wow and flutter
Below measurable limit
BLUETOOTH section
Communication System
BLUETOOTH Specification Version 2.1 + EDR
Output
BLUETOOTH Specification Power Class 2
Maximum communication range
Line of sight approx. 10 m (33 feet)*1
Frequency band
2.4GHz band (2.4000 GHz 2.4835 GHz)
Modulation method
FHSS
Supported BLUETOOTH Profiles*2
A2DP (Advanced Audio Distribution Profile)
AVRCP*3 (Audio/Video Remote Control Profile)
Supported codec*4
SBC (Subband Codec)
*1 The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, reception sensitivity,
aerial performance, operating system, application software,
etc.
*2 BLUETOOTH standard profiles provide the specifications for
BLUETOOTH communication between devices.
*3 Some operations may not be available depending on the
device.
*4 Codec: Audio signal compression and conversion format.
Radio section
Frequency range
FM: 87.5 MHz 108 MHz (100 kHz step)
AM: 530 kHz 1,710 kHz (10 kHz step)
Intermediate frequency
FM: 128kHz
AM: 45kHz
Antennas
FM: Telescopic antenna
AM: Built-in ferrite bar antenna
Input
AUDIO IN
Stereo mini jack
(USB) port
Type A, maximum current 500mA, USB 2.0 Full Speed
compatible
Output
(headphones) stereo mini jack
For 16 32 impedance headphones
Supported audio formats
Supported bit rates
MP3 (MPEG 1 Audio Layer-3):
32kbps 320kbps, VBR
WMA:
48kbps 192kbps, VBR
AAC*:
8kbps 320kbps, VBR
* USB function only
Sampling frequencies
MP3 (MPEG 1 Audio Layer-3):
32/44.1/48kHz
WMA:
32/44.1/48kHz
AAC*:
32/44.1/48kHz
* USB function only
General
Speaker
Full range, 8cm (3 1/4 in) dia., 6, cone type (2)
Power output
2.0W + 2.0W (at 6, 10% harmonic distortion)
Power requirements
120 V AC, 60 Hz (AC power supply)
9 V DC (6 LR14 (size C) batteries)
Power consumption
15W
0.9W (during standby mode)
Battery Life*1, *2
Playback of CD
Approx. 9 hours
Playback of USB device
Approx. 11 hours (at 100 mA load)
Approx. 3 hours (at 500 mA load)
FM reception
Approx. 26 hours
BLUETOOTH
Approx. 13 hours
*1 Measured by Sony standards. The actual battery life
may vary depending on the circumstances of the unit
or operating conditions.
*2 When using Sony alkaline batteries.
Dimensions
Approx. 320mm × 133mm × 215mm (12 5/8in × 5 1/4in ×
8 1/2in) (W/H/D) (incl. projecting parts)
Mass
Approx. 2.3 kg (5 lb 1 1/8 oz) (incl. batteries)
Supplied accessories
AC power cord (1)
Design and specifications are subject to change without
notice.
Troubleshooting
General
The power does not turn on.
Make sure the AC power cord is connected to the
wall outlet securely.
Make sure the connector of AC power cord is
inserted into the AC IN jack securely.
Check if the batteries are inserted correctly,
matching the polarities.
Replace all the batteries with new ones when the
OPR/BATT indicator dims.
There is no sound.
Make sure the appropriate function is selected for
the music or sound source you want to listen to.
Unplug the headphones when listening through
speakers.
The sound is noisy.
Is someone using a mobile phone or other
equipment emitting radio waves near the unit? If
so, move the unit and the BLUETOOTH device
away from such devices. Devices such as mobile
phones, etc., can affect BLUETOOTH
communication.
CD/MP3/WMA player
The CD player does not play even when a
CD is in place.
Place the CD with the label side up.
Clean the CD.
Take out the CD and leave the CD compartment
open for about an hour to dry moisture
condensation.
The CD-R/CD-RW is blank or unfinalized.
There are no playable MP3/WMA files on the disc.
There is a problem with the quality of the CD-R/
CD-RW, recording device or application software.
Replace all the batteries with new ones when the
OPR/BATT indicator dims.
“NO CD” appears when the disc is loaded.
No disc is set in the CD compartment. Set a disc.
The CD may have a reading problem. Replace the
disc.
The CD may be placed upside down. Place the
disc with the label side up.
An unplayable disc (BD, etc.) is loaded. Replace
the disc.
“NO TRACK” flashes on the display when
the disc is loaded.
No audio files recorded in supported formats, or a
file to be played back has an unsupported file
extension.
“DISC ERR” appears when the disc is loaded.
The CD may be dirty. Clean the disc.
The CD may have scratches. Replace the disc.
An unplayable disc (DVD, etc.) is loaded. Replace
the disc.
The CD may have a reading problem. Replace the
disc.
A blank disc may be set in the CD compartment.
The sound drops out.
Reduce the volume.
Clean the CD, or replace it if the CD is badly
damaged.
Place the unit in a location free from vibrations.
Clean the lens with a commercially available
blower.
The sound may drop out or noise may be heard
when using a poor quality CD-R/CD-RW or if there
is a problem with the recording device or
application software.
Starting playback takes more time than
usual.
The following discs take a longer time to start
playback.
A disc recorded with a complicated tree
structure.
A disc that has many folders or non-MP3/WMA
files.
USB device
The USB device does not work properly.
If you connect an incompatible USB device, the
following problems may occur.
The USB device is not recognized.
File or folder names are not displayed on this
unit.
Playback is not possible.
The sound skips.
There is noise.
The sound output is distorted.
“OVER CURRENT” appears.
An abnormal level has been detected in the
electrical current from the (USB) port . Turn off
the unit and remove the USB device from the
(USB) port . Make sure there is no problem with
the USB device. If this message persists, contact
your nearest Sony dealer.
There is no sound.
The USB device may be connected incorrectly.
Turn off the unit and reconnect the USB device.
Then turn on the unit.
There is noise, skipping, or distorted sound.
Turn off the unit and reconnect the USB device.
Then turn on the unit again.
The music data itself contains noise, or the sound
is distorted. Noise may have entered during the
creation of audio files. Try re-creating audio files
and use them to play on this unit.
The USB device cannot be connected to the
(USB) port .
The connector on the USB device or the USB cable
is being inserted backwards. Insert it to the
(USB) port in the correct direction.
“READING” is displayed for an extended
time, or it takes a long time before playback
starts.
The reading process can take a long time in the
following cases:
There are many folders or files on the USB
device.
The file structure is complex.
The memory is almost full.
The internal memory is fragmented.
To avoid the above problems, we recommend that
you adhere to the following guidelines:
Keep the total number of folders on a USB
device to 100 or less.
Keep the total number of files per folder to 100
or less.
Erroneous display
The data stored on the USB device may be
corrupted. Send the music data to the USB device
again.
This unit can display only numbers and letters of
the alphabet. Other characters will not be
displayed correctly.
“REC ERROR” appears.
An error occurred during transferring. Turn off the
unit and remove the USB device from the unit.
Then check the following:
Check the remaining storage space on the USB
device. If there is insufficient space for the
transferring, delete any unnecessary files or
folders.
Check that the data to be transferred is not
corrupted.
Check that the file format to be transferred is
compatible with the unit.
If the message still persists, contact your nearest
Sony dealer.
The USB device is not recognized.
Turn off the unit and reconnect the USB device,
then turn on the unit.
The USB device is not functioning properly. Refer
to the USB device operation manual for details on
how to deal with this problem.
Play does not start.
Turn off the unit and reconnect the USB device.
Play does not start from the first track.
Set the play mode to Normal Play.
License and Trademark Notice
MPEG Layer-3 audio coding technology and
patents licensed from Fraunhofer IIS and
Thomson.
Windows Media is either a registered trademark
or trademark of Microsoft Corporation in the
United States and/or other countries.
This product is protected by certain intellectual
property rights of Microsoft Corporation. Use or
distribution of such technology outside of this
product is prohibited without a license from
Microsoft or an authorized Microsoft subsidiary.
The BLUETOOTH word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by Sony Corporation is under license.
The N Mark is a trademark or registered trademark
of NFC Forum, Inc. in the United States and in
other countries.
Android™ and Google Play™ are trademarks of
Google Inc.
Other trademarks and trade names are those of
their respective owners. In this manual, ™ and ®
marks are not specified.
For customers in the USA
Please register this product on line at the following
website.
http://www.sony.com/productregistration
Proper registration will enable us to send you
periodic mailings about new product, services and
other important announcements. Registering your
product will also allow us to contact you in the
unlikely event that the product needs adjustment or
modification. Thank you.
