08 user guide
R300a
User guide
2
Congratulations on your purchase of the Sony Ericsson
R300a. For additional phone content, go to
www.sonyericsson.com/fun. Register now to get free online
storage and special offers at www.sonyericsson.com/myphone.
For product support, go to www.sonyericsson.com/support.
Instruction symbols
The following instruction symbols appear in this User guide:
> Use a navigation or selection key to scroll and select.
Press the navigation key centre.
Press the navigation key to the left.
Press the navigation key to the right.
Press the navigation key up.
Press the navigation key down.
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
3
Preparing the phone
To insert the SIM card and battery
1Remove the battery cover. Slide the SIM card into its holder
with the contacts facing down.
2Insert the battery with the label side up and the connectors
facing each other. Replace the battery cover as shown in
the picture.
Do not force the battery cover into place. Place the
battery cover carefully onto the phone and close it.
4
To charge the battery
1The phone battery is partly charged when you buy it.
Connect the charger to the phone. It takes approximately
2.5 hours to fully charge the battery. Press a key to
illuminate the screen.
2To remove the charger, tilt the plug upwards.
You can use the phone during charging. You can charge
the battery for more or less than 2.5 hours. Interrupted
charging will not damage the battery.
5
To turn on the phone
1Press and hold down .
2Enter your PIN if requested. To correct mistakes, press .
3Select OK.
4Select a language.
5Enter the time and date and select
Save.
To turn off the phone
•Press and hold down .
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This is called
standby. You can now make and receive calls.
6
SIM and PIN
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone
and detach the charger before you insert or remove
the SIM card.
PIN code
You may need a PIN (Personal Identification Number) to
activate the services in your phone. Your PIN is supplied by
your network operator. Each PIN digit appears as *, unless it
starts with emergency number digits, for example, 112 or 911.
You can call an emergency number without entering a PIN.
You can save contacts on the SIM card before removing
it from your phone. Contacts may also be saved in the
phone memory. See Contacts on page 15.
If you enter the wrong PIN three times in a row, PIN
blocked. To unblock, enter your PUK code provided by
your network operator. appears. To unblock it, you need
to enter your PUK (Personal Unblocking Key).
7
Phone overview
Navigation
key with
shortcuts
C key
Connector for
charger, handsfree
and USB cable
Loud-
speaker
Radio
preset
keys
Camera
On/off key,
End key
Audio enhancer key
Volume keys
Shortcut key
Keylock
Call key
Selection key
Ear speaker
Silent key
Selection key
Screen
14
To make international calls
1From standby press and hold down until a + sign
appears on the screen.
2Enter the country code, area code (without the first zero)
and phone number.
3Press .
To view a missed call
•When Missed calls: is displayed, select Yes. To call back,
scroll to the number and press .
Call list
You can view information about recent calls.
To view the call list
•From standby press .
To call a number from the call list
1From standby press .
2Scroll to the name or number and press .
To clear the call list
1From standby press .
2Scroll to the All tab and select Options > Delete all.
13
Calling
You must turn on the phone and be within range of a network.
To make a call
1From standby enter the area code and phone number.
2Press .
To end a call
•Press .
To answer a call
•Press .
To reject a call
•Press .
To change the ear speaker volume during a call
•On the left side of the phone, press the volume keys up or
down.
To mute the microphone during a call
•Press and hold down .
•Press and hold down again to resume.
To turn off the ringtone when receiving a call
•Press without answering the call.
To turn the loudspeaker on during a call
•Select SpkrOn.
Do not hold the phone to your ear when using the
loudspeaker. This could damage your hearing.
12
To set the phone to silent
•Press and hold down .
To delete items
•Press to delete items such as numbers, letters and
pictures.
Shortcuts
You can use keypad shortcuts to go directly to a menu.
To use the navigation key shortcuts
•Press to create messages.
•Press to go to the camera.
•Press to play the radio.
•Press to go to your contacts.
To use the shortcut key
•Press to Add, Delete, Move or use shortcuts.
11
Navigation
The main menus are shown as icons. Some submenus include
tabs.
To navigate the menus
1From standby press to select Menu.
2Press , , , to move through
the menus.
To select actions on the screen
•Press any of the selection keys, or .
To scroll between the tabs
•Scroll to a tab by pressing or .
To return to standby
•Press .
To lock the keypad
•Press and select Lock.
To unlock the keypad
•Press and select Unlock.
Calls to the international emergency number 112 can still
be made, even when the keypad is locked.
9
Menu overview
Organizer File manager, Alarms, Calendar, Tasks,
Notes, Timer, Stopwatch, Calculator
Internet
Entertainment TrackID™, My games, Sound recorder
Camera
Messaging Write new, Inbox, Call voicemail, Drafts,
Outbox, Sent messages, Saved msgs,
Templates, Settings
FM radio
Calls*
All Answered Dialled Missed
Contacts New contact
Settings*
General Sounds &
alerts
Display Calls Connectivity
Some menus and icons in this document may vary depending on
operator, network or subscription.
* You can use the navigation key to scroll between tabs in sub menus.
8
Network coverage
The network bars show the strength of the GSM network in
your area. Try moving to another location if you have trouble
calling and network coverage is poor. No network means you
are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
Battery
status
Network
coverage
10
Screen icons
These icons may appear on the screen.
Icon Description
Battery icon. A completely green icon means the
battery is fully charged
You have missed a call
Divert calls is activated
The phone is set to silent
The keypad is locked
You have received a new text message
You have received a new picture message
The handsfree is connected
An alarm is activated
Ongoing call
The loudspeaker is on
The radio is playing
The Bluetooth function is activated
15
Contacts
You can save contacts in the phone memory or on the SIM
card. You can copy contacts from the phone memory to the
SIM card or from the SIM card to the phone memory.
To add a contact
1From standby select .
2Scroll to New contact and select Add.
3Select Add to enter the name and select OK.
4Scroll to New number: and select Add.
5Enter the number and select OK.
6Select a number option.
7Scroll between tabs and select the fields to add information.
8Select Save.
To call a contact
1From standby press .
2Scroll to, or enter the first few letters of the contact.
3Press .
See Entering text on page 29.
You can enter the + sign and country code with all
phonebook numbers. They can then be used abroad or
at home. See To make international calls on page 14.
16
To edit a contact
1From standby press .
2Scroll to the contact and select Options > Edit contact.
3Scroll between the tabs, edit the information and select
Save.
To delete a contact
1From standby press .
2Scroll to the contact and press .
To copy all contacts to the SIM card
1From standby press .
2Scroll to New contact and select Options > Advanced
> Copy to SIM > Copy all.
To view and edit your phone numbers
1From standby press .
2Scroll to New contact and select Options > Special
numbers > My numbers.
3Select an option.
17
Radio
Your phone has a radio and the handsfree works as an
antenna.
To listen to the radio
1Connect the handsfree to the phone.
2From standby press .
To turn the loudspeaker on
•When the radio is playing, select Options > Turn on spkr.
To switch to AM
•When the radio is playing, select Options > Turn on AM.
To change the volume
•When the radio is playing, press the volume keys on the left
side of the phone up or down.
Do not use your phone as a radio in places where this is
prohibited.
When you listen to AM radio, you must use the handsfree
included in the phone kit.
18
Searching for channels
To automatically search for channels
•When the radio is playing, press .
To manually search for channels
•When the radio is playing, press or .
To switch between preset channels
•When the radio is playing, press or .
Saving channels
You can save up to 20 preset channels.
To save a radio channel to the list of channels
1When you have found a radio channel, select Options
> Channels > Save.
2Select Insert.
To select saved channels
1From standby press .
2Select Options > Channels > Channels.
3Select a radio channel.
To save a radio channel to a radio preset key
1When you have found a radio channel, select Options
> Set radio key.
2Select a radio key in the list > Add.
3Select Add to add the channel to the list of channels.
To select a radio channel saved to a radio preset key
•Press any of the radio preset keys , or .
1
2
3
19
To use concert sound
•When the radio is playing, press .
•To deactivate Concert sound and switch to Normal effect,
press again.
To use volume boost
•When the radio is playing, select Options > Turn on spkr
and press .
•To deactivate Volume boost and switch to Normal effect,
press again.
To record radio
•When the radio is playing, select Options > Record radio to
start recording and select Save to stop and save the
recording. The radio recording is saved in Options > My
radio recs.
Use Concert sound for a better listening experience.
Use Volume boost in noisy environment to maximize the
volume from the loudspeaker.
Adjust the volume cautiously when using Volume boost to
avoid volume levels that could damage your hearing.
Select Options > Settings > Record quality and select
between Normal quality or High quality.
This service is not available in all countries. Where
available, you may only use this service for playback
at a more convenient point in time.
20
To set the radio as alarm signal
1From standby select Menu > Organizer > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Alarm signal: > Edit.
5Select Radio. The latest used radio channel will be used as
alarm signal.
6Select Save.
To exit the radio
•When the radio is playing, press .
To minimize the radio on the screen
•Select Options > Minimize.
•To restore the radio on the screen, from standby press .
To turn off the radio when minimized
•From standby press and press .
Keep the handsfree inserted when you select radio as
alarm signal. The radio alarm signal will sound through
the loudspeaker.
21
Messaging
Text messages (SMS)
You must have a service centre number, which is supplied
by your service provider and saved on the SIM card. You
may have to enter the number yourself.
To set service centre number
1From standby select Menu > Messaging > Settings > Text
message > Service centre. The number is shown if it is
saved on the SIM card.
2If there is no number shown, enter the service centre
number, including the international “+” sign and country
code.
3Select Save.
To write and send a text message
1From standby press .
2Select Text message. Enter the message and select Cont.
3Select a recipient (Enter phone no. or Contacts look-up)
and select Send.
To view a received text message
1Text message received appears. Select Yes.
2Scroll to the unread message and select View.
See Entering text on page 29.
22
Picture messages (MMS)
Picture messages can contain text, pictures, sound
recordings and attachments.
To create and send a picture message
1From standby press .
2Select Picture msg.
3Enter text. To add items to the message, press , scroll
and select an item.
4When the message is ready select Continue.
5Select a recipient (Enter email addr., Enter phone no. or
Contacts look-up) and select Send.
You must set an MMS profile and the address of your
message server. If no MMS profile or message server
exists, you can receive all the settings automatically
from your network operator or at
www.sonyericsson.com/support.
Sending and receiving phones must have subscriptions
that support picture messaging.
23
Camera
Your phone has a digital camera to take pictures to save
or send. Pictures taken with the camera are saved in Menu
> Organizer > File manager > Camera album. The format is
JPEG.
To start the camera and take a picture
1From standby, press .
2Select TakePic to take the picture.
3The picture is automatically saved in Camera album.
To delete a saved picture
1From standby select Menu > Organizer > File manager
> Camera album.
2Scroll to a picture and press .
To send a saved camera picture as picture message
1From standby select Menu > Organizer > File manager
> Camera album.
2Scroll to a picture and select Options > Send > As picture
msg.
3Select Continue.
4Select a recipient (Enter email addr., Enter phone no. or
Contacts look-up) and select Send.
Pictures downloaded using picture messages, Internet or
Bluetooth™ wireless technology are saved in Pictures.
See To send a camera picture using Bluetooth on
page 28.
24
More functions
TrackID™
TrackID™ is a free music recognition service. Search for song
titles, artists and album names. You must have the required
settings in your phone. See Internet on page 24.
To search for song information
•When you hear a song through a loudspeaker, from standby
select Menu > Entertainment > TrackID™.
Internet
You need the correct settings in your phone. If settings are not
in your phone, you can:
•Get them in a text message (SMS) from the network
operator.
•On a computer, go to www.sonyericsson.com/support and
request a text message with the settings.
To select an Internet profile
•From standby select Menu > Settings > the Connectivity
tab > Internet settings > Internet profiles. Select a profile.
To start browsing
1From standby select Menu > Internet.
2Select Options > Go to.
3Select an option.
To exit browsing
•When you browse, select Options > Exit browser.
For cost information contact your service provider.
25
File manager
You can use the file manager to handle files saved in the phone
memory.
To view information about files
1From standby select Menu > Organizer > File manager.
2Find a file and select Options > Information.
To move a file in the file manager
1From standby select Menu > Organizer > File manager.
2Find a file and select Options > Manage file > Move.
3Select an option.
To delete a file from the file manager
1From standby select Menu > Organizer > File manager.
2Find the file and press .
26
Mass storage
You can connect your phone to a computer with a USB cable
to transfer files using Mass storage.
To use Mass storage
1Connect a USB cable to the phone and the computer.
The phone will shut down in this mode and restart when
disconnected from the USB cable.
2Phone: Select Yes to confirm the mass storage session.
3Computer: Open the removable disk folder to view the
phone folders.
4Drag and drop files between the phone and the computer.
To disconnect the USB cable safely
1Computer: Right-click the removable disk icon and select
Eject.
2Phone: Disconnect the USB cable when the following
message is shown in the phone: Mass storage session
ended. It is now safe to remove the USB cable.
Only use a USB cable supported by your phone. Do not
remove the USB cable from your phone or computer
during file transfer as this may corrupt the phone memory.
27
Bluetooth™ wireless technology
Bluetooth™ wireless technology makes wireless connections
to other Bluetooth devices, for example, a Bluetooth headset,
possible. You can:
•Connect to several devices at the same time.
•Exchange items.
To turn the Bluetooth function on
•From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Turn on.
To show or hide your phone
•From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Visibility > Show phone or Hide phone.
The recommended maximum distance between two
Bluetooth devices is 10 metres (33 feet), with no solid
objects in between.
Please check if local laws or regulations restrict the use
of Bluetooth wireless technology. If it is not allowed, you
must ensure that the Bluetooth function is turned off.
If set to hide, other devices will not be able to identify your
phone using Bluetooth wireless technology.
28
To pair a device with your phone
1From standby select Menu > Settings > the Connectivity
tab > Bluetooth > My devices > New device to search for
available devices.
2Select a device from the list. Enter a passcode, if required.
To pair your phone with a Bluetooth handsfree
1From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Handsfree.
2Select Yes if you are adding a Bluetooth handsfree for the
first time or select Handsfree > My handsfree > New
handsfree if you are pairing with another Bluetooth
handsfree. Make sure that your handsfree is ready to be
paired.
To receive an item
1Menu > Settings > the Connectivity tab > Bluetooth
> Visibility > Show phone.
2When you receive an item follow the instructions that
appear.
To send a camera picture using Bluetooth
1From standby select, for example, Menu > Organizer
> File manager > Camera album.
2Scroll to a picture and select Options > Send > Via
Bluetooth.
35
Phone lock
The phone lock protects the phone against unauthorized use
if it is stolen and the SIM card is exchanged. You can change
the phone lock code (which is 0000 by default) to any four-digit
personal code. If the phone lock is set to Automatic, you do
not need to enter your phone lock code until a different SIM
card is inserted in the phone.
To turn the phone lock on
1From standby select Menu > Settings > the General tab
> Security > Phone lock > Protection > On.
2Enter the phone lock code and select OK.
To edit your phone lock code
1From standby select Menu > Settings > the General tab
> Security > Phone lock > Change code.
2Enter the current code and select OK.
3Enter a new code and select OK.
4Re-enter the new code to confirm and select OK.
To unlock the phone
1From standby select Menu > Settings > the General tab
> Security > Phone lock > Protection > Off.
2Enter your phone lock code and select OK.
If you forget your new code, you have to take your phone
to your local Sony Ericsson retailer.
34
To edit your PIN
1From standby select Menu > Settings > the General tab
> Security > SIM lock > Change PIN.
2Enter your PIN and select OK.
3Enter a new PIN and select OK.
4Re-enter the new PIN to confirm and select OK.
To edit your PIN2
1From standby select Menu > Settings > the General tab
> Security > SIM lock > Change PIN2.
2Enter your PIN2 and select OK.
3Enter a new PIN2 and select OK.
4Re-enter the new PIN2 to confirm and select OK.
33
Locks
SIM card lock
The SIM card lock protects your subscription, but not your
phone itself, from unauthorized use. If you change SIM cards,
the phone still works with the new SIM card. Most SIM cards
are locked at the time of purchase. If the SIM card lock is on,
you have to enter a PIN (Personal Identity Number) every time
you turn on your phone. If you enter your PIN incorrectly three
times in a row, the SIM card is blocked. This is indicated by the
message PIN blocked. To unblock, enter your PUK code
provided by your network operator. To unblock it, enter your
PUK (Personal Unblocking Key). Your PIN and PUK are supplied
by your network operator.
To unblock your SIM card
1When PIN blocked. To unblock, enter your PUK code
provided by your network operator. is displayed, enter
your PUK and select OK.
2Enter a new PIN and select OK.
3Re-enter the new PIN to confirm and select OK.
To turn the SIM card lock on
1From standby select Menu > Settings > the General tab
> Security > SIM lock > Protection > On.
2Enter your PIN and select OK.
If the message Wrong PIN Attempts remaining: appears
when you edit your PIN, you entered the PIN or PIN2
incorrectly.
32
Emergency calls
Your phone supports international emergency numbers, for
example, 112 and 911. These numbers can normally be used
to make emergency calls in any country, with or without the
SIM card inserted, if a GSM network is within range.
To make an emergency call
•From standby enter 112 (the international emergency
number) and press .
To view or edit your local emergency numbers
1From standby press .
2Scroll to New contact and select Options > Special
numbers > Emergency nos.
30
•To change the writing language, press and hold down .
•To delete characters, press . To delete a whole word,
press and hold down .
•To enter numbers, press and hold down – .
Alarms
You can set a sound or the radio as an alarm signal. The alarm
sounds even if the phone is turned off.
To set the alarm
1From standby select Menu > Organizer > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Time: and select Edit.
4Enter a time and select OK > Save.
To set the alarm signal
1From standby select Menu > Organizer > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Alarm signal: and select Edit.
5Find and select an alarm signal. Select Save.
To silence the alarm
•When the alarm sounds, press any key.
•To repeat the alarm, select Snooze.
To turn off the alarm
•When the alarm sounds, select TurnOff.
29
Entering text
There are two methods you can use to enter text: multitap or
predictive text input.
To enter text using multitap
•Press – until the letter appears.
•Press to add a space.
•Press to enter punctuation marks.
To enter text using predictive text input
•For example, if you want to write the word “Land”, press
, , , .
•If the word or punctuation mark is the one you want, press
to accept and add a space. To accept a word without
adding a space, press .
•If the word or punctuation mark is not the one you want,
press or repeatedly to view alternative words.
To add a word to the dictionary
1When you write the message, select Options > Spell word.
2Enter the word using multitap and select Insert.
How to use the keys
•To change the input method, press and hold down .
•To shift between upper case and lower case letters, press
.
By using predictive text input you only have to press each
key once. Continue writing a word even if it appears to be
wrong. The phone uses the dictionary to recognize the
word when all letters are entered.
31
Ringtones and themes
Themes are used to change the appearance of the screen.
To select a ringtone
•From standby select Menu > Settings > the Sounds &
alerts tab > Ringtones and select a ringtone.
To set the ring volume
•From standby select Menu > Settings > the Sounds &
alerts tab > Ring volume and select an option.
To set the vibrating alert
•From standby select Menu > Settings > the Sounds &
alerts tab > Vibrating alert and select an option.
To select a key sound
•From standby select Menu > Settings > the Sounds &
alerts tab > Key sound and select an option.
To select a theme
•From standby select Menu > Settings > the Display tab
> Themes and select a theme.
To use a picture taken with camera as wallpaper
1From standby select Menu > Organizer > File manager
> Camera album.
2Scroll to a picture and select Options > Use as > Wallpaper.
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonyericsson.com
Printed in XXXX
36
Troubleshooting
Some problems require that you call your service provider, but
you can correct most problems yourself. Remove the SIM card
before handing your phone in for repair. Go to
www.sonyericsson.com/support for more information.
Memory capacity and speed
If you have not restarted the phone for a while, you may
experience problems with its memory capacity and speed.
You can restart the phone to improve its capacity.
1Turn the phone off and remove the battery cover.
2Remove the phone battery and then put it back in place.
3Replace the battery cover and turn the phone on.
Master reset
If you experience problems with your phone such as screen
flickering or freezing and navigation problems you should reset
the phone.
•From standby select Menu > Settings > the General tab
> Master reset > Reset settings and select an option.
The phone turns itself off
If your phone turns itself off when being transported, something
in your pocket or bag has activated the on/off key. Turn the
automatic key lock on. Select Menu > Settings > the General
tab > Security > Auto keylock > On.
Reset settings will reset all changes that you have made
in your phone to default.
Reset all will delete all user data as contacts, messages,
pictures and sounds in your phone.
37
I cannot turn the phone on, what should I do?
Try charging the phone until it has finished charging. Attach
the charger (make sure the power icon on the charger is facing
upwards) and charge the phone for 2.5 hours. The battery icon
on the screen may not appear until the phone has charged for
30 minutes.
What is my phone lock code?
A phone lock protects your phone against unauthorized use.
If a different SIM card is inserted in the phone, the phone lock
code has to be entered. The default phone lock code is 0000.
What do these error messages mean?
PIN blocked
You have entered the wrong PIN code three times. Your SIM
is now locked. Unlock your SIM with your PUK code, which is
provided together with your PIN code by your network operator.
1Enter your PUK code and select OK.
2Enter a new PIN and select OK.
3Re-enter the new PIN to confirm and select OK.
Insert SIM
Your SIM card is not inserted correctly or may be damaged or
dirty. Try one or more of the following:
•Remove the SIM card and insert it correctly.
•Clean the connectors on the SIM card and phone with a soft
brush, a cloth or a cotton bud.
•Check if the SIM card is damaged.
•Contact your network operator to get a new SIM card.
38
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony Ericsson
may void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
39
Industry Canada Statement
This device complies with RSS-210 of Industry Canada. Operation is
subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
Sony Ericsson R300a
GSM 850/1800/1900
This User guide is published by Sony Ericsson Mobile Communications
AB or its local affiliated company, without any warranty. Improvements
and changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/or
equipment, may be made by Sony Ericsson Mobile Communications AB
at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
© Sony Ericsson Mobile Communications AB, 2008
Publication number: 1210-2648.1
Please note: Some of the services in this User guide are not supported by
all networks. This also applies to the GSM International Emergency
Number 112. Please contact your network operator or service provider if
you are in doubt whether you can use a particular service or not. Please
read the Important information before you use your mobile phone.
40
All illustrations are for illustration only and may not accurately depict the
actual phone.
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not limited
to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of any
additional content, please verify that your intended use is properly
licensed or is otherwise authorized. Sony Ericsson does not guarantee
the accuracy, integrity or quality of any additional content or any other
third party content. Under no circumstances will Sony Ericsson be liable
in any way for your improper use of additional content or other third party
content.
Sony is a trademark or registered trademark of Sony Corporation.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget
LM Ericsson. The Predictive Text Technology is used under license from
Zi Corporation. The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is under
license. The Liquid Identity logo and TrackID are trademarks or registered
trademarks of Sony Ericsson Mobile Communications AB. TrackID™ is
powered by Gracenote Mobile. This product is protected by certain
intellectual property rights of Microsoft. Use or distribution of such
technology outside of this product is prohibited without a license from
Microsoft. Content owners use Windows Media digital rights
management technology (WMDRM) to protect their intellectual property,
including copyrights. This device uses WMDRM software to access
WMDRM-protected content. If the WMDRM software fails to protect the
content, content owners may ask Microsoft to revoke the software's
ability to use WMDRM to play or copy protected content. Revocation
does not affect unprotected content. When you download licenses for
protected content, you agree that Microsoft may include a revocation list
with the licenses. Content owners may require you to upgrade WMDRM
to access their content. If you decline an upgrade, you will not be able to
access content that requires the upgrade. MPEG Layer-3 audio decoding
technology licensed from Fraunhofer IIS and Thomson.
41
Export Regulations: Software, including technical data, is subject to U.S.
export control laws, including the U.S. Export Administration Act and its
associated regulations, and may be subject to export or import regulations
in other countries. Customer agrees to comply strictly with all such
regulations and acknowledges that it has the responsibility to obtain
licenses to export, reexport, or import Software. Software may not be
downloaded, or otherwise exported or re-exported (i) into, or to a national
or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such
listing may be revised from time to time) or any country to which the U.S.
has embargoed goods; or (ii) to anyone on the U.S. Treasury Department's
list of Specially Designated Nations or the U.S. Commerce Department's
Table of Denial Orders. Restricted Rights: Use, duplication or disclosure
by the United States government is subject to the restrictions as set forth
in the Rights in Technical Data and Computer Software Clauses in DFARS
252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable.
All other trademarks and copyrights are the property of their respective
owners.
Any rights not expressly granted herein are reserved.
1210-2648.1
