08 user guide part 2
9Getting started
Phone overview
1Power on/off key
2Screen
3Navigation key, music player
control
4Selection key
5Internet key
6Back key
7Keypad lock
8Volume, camera digital zoom
buttons
9Selection key
10 Activity menu key
11 Clear key
12 Camera key
13 Silent key
13
12
8
9
10
11
2
4
5
7
1
3
6
10 Getting started
14 Light
15 Main camera
16 Active camera lens cover
17 Battery cover clasp
18 Connector for charger,
handsfree and USB cable
19 Speaker
14
15
16
19
18
17
11Getting started
Menu overview
PlayNow™* Internet* Entertainment
Online services*
Radio
Games
TrackID™
Video player
VideoDJ™
PhotoDJ™
MusicDJ™
Remote control
Record sound
Demo tour
Cyber-shot™ Messaging Music player
Write new
Inbox
Email
RSS reader
Drafts
Outbox
Sent messages
Saved messages
My friends*
Call voicemail
Templates
Settings
Now playing
Artists
Tracks
Playlists
File manager** Contacts Alarms
Camera album
Music
Pictures
Videos
Themes
Web pages
Games
Applications
Other
New contact
12 Getting started
Calls** Organizer
All Answered Dialled Missed
Applications
Video call
Calendar
Tasks
Notes
Synchronization
Timer
Stopwatch
Light
Calculator
Code memo
Settings**
General
Profiles
Time & date
Language
Update service
Voice control
New events
Shortcuts
Flight mode
Security
Setup wizard
Phone status
Master reset
Sounds & alerts
Ring volume
Ringtone
Silent mode
Increasing ring
Vibrating alert
Message alert
Key sound
Display
Wallpaper
Themes
Start-up screen
Screen saver
Clock size
Brightness
Edit line names*
Calls
Speed dial
Divert calls
Switch to line 2*
Manage calls
Time & cost*
Show/hide my no.
Handsfree
Connectivity
Bluetooth
USB
Synchronization
Device mgmt.
Mobile networks
Data comm.
Internet settings
Streaming settings
Accessories
* Some menus are operator-, network- and subscription-dependent.
** You can use the navigation key to scroll between tabs in submenus. For more information,
see Navigation on page 13.
13Getting started
Navigation
The main menus are shown as icons.
Some submenus include tabs.
To navigate the phone menus
1From standby select Menu.
2Use the navigation key to move
through the menus.
To scroll between the tabs
•Scroll to a tab by pressing the
navigation key left or right.
Key
Go to the main menus or to select items
Scroll between the menus and tabs.
Select options shown immediately above these keys on the screen
Go back one level in the menus.
Press and hold down to return to standby or to end a function
Delete items, such as pictures, sounds and contacts.
Press and hold down to mute the microphone during a call
Open the browser
Open the activity menu
Press and hold down to take a picture or record a video clip
Press and hold down to call your voicemail service (if set)
14 Getting started
Shortcuts
You can use keypad shortcuts to go
directly to a menu. Menu numbering
starts from the top left icon and moves
across and then down row by row.
To go directly to the seventh menu
•From standby select Menu and
press .
To use navigation key shortcuts
•From standby press , , or
to go directly to a function.
To edit a navigation key shortcut
1From standby select Menu > Settings
> the General tab > Shortcuts.
2Scroll to an option and select Edit.
3Scroll to a menu option and select
Shortcut.
- Press and hold down a number key to reach a contact beginning
with a specific letter.
- Press a number key and select Call... to speed dial.
Press to turn off the ringtone when you receive a call.
Press and hold down to set the phone to silent. The alarm signals
even if your phone is set to silent.
View status information in standby.
Increase the volume during a call, or when you use the music player.
Press and hold down to go back one track when you use the music
player.
Zoom out when you use the camera or view pictures.
Press twice to reject a call.
Voice control. See Voice control on page 24.
Decrease the volume during a call, or when you use the music player.
Press and hold down to go forward one track when you use the
Music player.
Zoom in when you use the camera or view pictures.
Voice control. See Voice control on page 24.
15Getting started
Activity menu
The activity menu gives you fast
access to certain functions.
To open the activity menu
•Press .
Activity menu tabs
•New events – view missed calls and
new messages. These can also be
set to appear as pop-up texts.
•Running apps – applications that are
running in the background.
•My shortcuts – add your favourite
functions to access them quickly.
•Internet – your Internet bookmarks.
To select pop-up texts
•From standby select Menu > Settings
> the General tab > New events
> Pop-up.
File manager
You can use the file manager to
handle items saved in the phone
memory or on a memory card.
Memory Stick Micro™ (M2™)
Your phone supports Memory Stick
Micro™ (M2™) memory card adding
more storage space to your phone. It
can also be used as a portable memory
card with other compatible devices.
To insert a memory card
1Remove the battery cover.
2Insert the memory card with the
golden contacts facing down.
To remove a memory card
1Press the edge to release and remove
the memory card.
2Replace the battery cover.
You may have to purchase a memory
card separately from your phone.
16 Getting started
To view memory card options
1From standby select Menu > File
manager > the On Memory Stick tab.
2Select More.
Handling files
You can move and copy files between
your phone, a computer and a memory
card. Files are saved on the memory
card first and then in the phone
memory. Unrecognized files are
saved in the Other folder.
You can create subfolders to move or
copy files to. When you handle files,
you can select more than one or all the
files in a folder at the same time for all
items except Games and Applications.
If the memory is full, delete some
content to create space.
File manager tabs
The file manager is divided into three
tabs, and icons indicate where the
files are saved.
•All files – all content in the phone
memory and on a memory card.
•On Memory Stick – all content on
a memory card.
•In phone – all content in the phone
memory.
To view information about files
1From standby select Menu > File
manager.
2Scroll to a folder and select Open.
3Scroll to a file and select More
>Information.
To move a file in the file manager
1From standby select Menu > File
manager.
2Scroll to a folder and select Open.
3Scroll to a file and select More
>Manage file > Move.
4Select an option.
To select more than one file
in a folder
1From standby select Menu > File
manager.
2Scroll to a folder and select Open.
3Select More > Mark > Mark several.
4Select Mark to mark the files.
To delete a file from the file manager
1From standby select Menu > File
manager.
2Find the file and press .
Phone language
You can select a language to use in
your phone.
17Getting started
To change the phone language
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
Entering text
There are two methods you can use
to enter text:
•Multitap text input
•T9™ Text Input
To change text input methods
•When you enter letters, press and hold
down .
To view options when you enter
letters
•Select More.
To enter text using multitap
•From standby select Menu > Messaging
> Write new > Text message.
•Press – until the desired
character appears.
•Press to delete.
•Press to shift between capitals
and lower-case letters.
•Press and hold down –
to enter numbers.
•Press to add a space.
•Press to enter full stops and
commas.
•Press to enter the + sign.
T9™ Text Input
The T9™ Text Input method uses
a built-in dictionary.
To enter text using T9™ Text Input
1From standby select Menu > Messaging
> Write new > Text message.
2Press each key only once, even if the
letter you want is not the first letter
on the key. For example, if you want
to write the word “Jane”, press ,
, , . Write the whole word
before looking at the suggestions.
3Press to delete.
4Use or to view suggestions.
5Press to accept a suggestion.
6Press to enter full stops and
commas.
To add words to the built-in
dictionary
1When you enter letters, select More
>Spell word.
2Write the word using multitap input
and select Insert.
18 Calling
Next word prediction
When you write a message, you can
use T9 Text Input to predict the next
word, if previously used in a sentence.
To turn next word prediction on
•When you enter letters, select More
>Writing options > Next word pred.
>On.
To use next word prediction
•When you enter letters, press to
accept or continue.
Calling
Making and receiving calls
You need to turn on your phone and
be within range of a network.
To make a call
1From standby enter a phone number
(with international country code and
area code, if applicable).
2Select Call.
See Video call on page 20.
To make international calls
1From standby press and hold down
until a “+” sign appears.
2Enter the country code, area code
(without the first zero) and phone
number.
3Select Call.
To re-dial a number
•When Retry? appears select Yes.
You can call numbers from the contacts
and call list, see Contacts on page 20, and
Call list on page 23. You can also use your
voice to make calls. See Voice control on
page 24.
Do not hold your phone to your ear when
waiting. When the call connects, your
phone gives a loud signal.
19Calling
To answer a call
•Select Answer.
To reject a call
•Select Busy.
To change the ear speaker volume
during a call
•Press or .
To mute the microphone during a call
1Press and hold down .
2Press and hold down again
to resume.
To turn the loudspeaker on during
acall
•Select More > Turn on speaker.
To view missed calls from standby
•Press and scroll to the New
events tab and select a number.
•If pop-up is set: select Calls and scroll
to the Missed tab and select a number.
Networks
Your phone switches automatically
between GSM and 3G (UMTS)
networks depending on availability.
Some network operators allow you
to switch networks manually.
To switch networks manually
1From standby select Menu > Settings
> the Connectivity tab > Mobile
networks > GSM/3G networks.
2Select an option.
Emergency calls
Your phone supports international
emergency numbers, for example, 112
and 911. These numbers can normally
be used to make emergency calls in
any country, with or without the SIM
card inserted, if a 3G (UMTS) or GSM
network is within range.
To make an emergency call
•From standby enter 112 (the
international emergency number)
and select Call.
To view your local emergency
numbers
1From standby select Menu > Contacts.
2Select More > Options > Special
numbers > Emergency nos.
Do not hold your phone to your ear when
using the loudspeaker. This could damage
your hearing.
In some countries, other emergency
numbers may also be promoted. Your
network operator may therefore have
saved additional local emergency numbers
on the SIM card.
20 Calling
Video call
You can see a person on the screen
during calls.
Before you use video call
Both parties need a subscription that
supports the 3G (UMTS) service, and
you need to be within range of a 3G
(UMTS) network. 3G (UMTS) service
is available when appears on the
screen.
To make a video call
1From standby enter a phone number
(international prefix and area code if
applicable).
2Select More > Make video call.
To use the zoom with an outgoing
video
•Press or .
To view video call options
1During the call, select More.
2Select an option.
Contacts
You can save names, phone numbers
and personal information in Contacts.
Information can be saved in the phone
memory or on the SIM card.
Default contact
You can choose which contact
information – Phone contacts or
SIM contacts – is shown as default.
If Phone contacts is selected as
default, your contacts show all the
information saved in Contacts. If you
select SIM contacts as default, your
contacts show names and numbers
saved on the SIM card.
To select default contacts
1From standby select Menu > Contacts.
2Select Options > Advanced > Default
contacts.
3Select an option.
Phone contacts
Phone contacts can contain names,
phone numbers and personal
information. They are saved in
the phone memory.
To add a phone contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option.
6Scroll between tabs and select the
fields to add information.
7Select Save.
21Calling
To add an item to a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and select More
>Edit contact.
3Scroll between the tabs and select
Add.
4Select an option and an item to add.
5Select Save.
To copy names and numbers to the
SIM card
1From standby select Menu > Contacts.
2Select More > Options > Advanced
>Copy to SIM.
3Select an option.
To call a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and select Call.
To call a SIM contact from phone
contacts
1From standby select Menu > Contacts
> More > Options > SIM contacts.
2Scroll to a contact and select Call.
To automatically save names and
phone numbers on the SIM card
1From standby select Menu > Contacts.
2Select More > Options > Advanced
>Auto save on SIM.
3Select an option.
SIM contacts
SIM contacts can contain names and
numbers only. They are saved on the
SIM card.
To add a SIM contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option and add more
information, if available.
6Select Save.
To copy names and numbers to
phone contacts
1From standby select Menu > Contacts
> More > Options.
2Select Advanced > Copy from SIM.
3Select an option.
If your subscription supports Calling Line
Identification (CLI) service, you can assign
personal ringtones to contacts.
When you copy all contacts from your
phone to the SIM card, all existing SIM
card information is replaced.
To go directly to a contact, from standby
press – . See Speed dial on
page 23.
22 Calling
To call a SIM contact
1From standby select Menu > Contacts.
2Scroll to a contact and select Call.
Deleting contacts
To delete a contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To delete all phone contacts
1From standby select Menu > Contacts.
2Select More > Options > Advanced
>Delete all contacts.
Sending contacts
To send a contact
1From standby select Menu > Contacts.
Scroll to a contact and select More
>Send contact.
2Select a transfer method.
Memory status
The number of contacts you can save
in your phone or on the SIM card
depends on available memory.
To view memory status
1From standby select Menu > Contacts.
2Select More > Options > Advanced
>Memory status.
Synchronizing contacts
Contacts can be synchronized
with your computer and some Web
applications. For more information,
see Synchronizing on page 53.
To save contacts on a memory card
1From standby select Menu > Contacts.
2Select More > Options > Advanced
>Back up to M.S.
Groups
You can create a group of phone
numbers and email addresses to
send messages to. See Messaging
on page 29. You can also use groups
(with phone numbers) when you
create accepted callers lists. See
Accept calls on page 27.
To create a group of numbers and
email addresses
1From standby select Menu > Contacts
> Options > Groups > New group.
2Enter a name for the group and select
Continue.
3Select New to find and select a contact
phone number or email address.
4Repeat step 3 to add more phone
numbers or email addresses.
5Select Done.
Make sure the receiving device supports
the transfer method you select.
23Calling
Call list
You can view information about most
recent calls.
To call a number from the call list
1From standby select Calls and scroll
to a tab.
2Scroll to a name or a number and
select Call.
To add a call list number to contacts
1From standby select Calls and scroll
to a tab.
2Scroll to the number and select More
>Save number.
3Select New contact to create a new
contact or select an existing contact
to add the number to.
To clear the call list
•From standby select Calls > the All tab
> More > Delete all.
Speed dial
Speed dialling lets you select nine
contacts that you can dial quickly.
The contacts can be saved in
positions 1-9.
To add contacts to speed dial
numbers
1From standby select Menu > Contacts.
2Select Options > Speed dial.
3Scroll to a position number and
select Add.
4Select a contact.
To speed dial
•From standby enter the position
number and select Call.
Voicemail
If your subscription includes an
answering service, callers can leave
a voicemail message when you cannot
answer a call.
To enter your voicemail number
1From standby select Menu > Messaging
> Settings > Voicemail number.
2Enter the number and select OK.
To call your voicemail service
•From standby press and hold
down .
To edit your voicemail number
1From standby select Menu > Messaging
> Settings > Voicemail number.
2Edit the number and select OK.
24 Calling
Voice control
By creating voice commands you can:
•Voice dial – call someone by saying
their name.
•Activate voice control by saying a
“magic word”.
•Answer and reject calls when you
use a handsfree.
To activate voice dialling and record
a voice command
1From standby select Menu > Settings
> the General tab > Voice control
>Voice dialling > Activate.
2Select Yes > New voice and select
a contact.
3If the contact has more than one
number, use and to select the
number to add the voice command to.
Record a voice command such as
“John mobile”.
4Follow the instructions on the screen.
Wait for the tone and say the command
to record. The voice command is
played back to you.
5If the recording sounds OK, select
Yes. If not, select No and repeat steps
3 and 4.
To re-record a voice command
1From standby select Menu > Settings
> the General tab > Voice control
>Voice dialling > Edit names.
2Scroll to a command and select
More > Replace voice > Yes.
3Wait for the tone and say the
command.
Voice dialling
You can hear your recorded contact
name when you receive a call from
that contact.
To voice dial
1From standby press and hold down
or .
2Wait for the tone and say a recorded
name, for example “John mobile”. The
name is played back to you and the
call is connected.
The magic word
You can record and use a voice
command as a magic word to activate
voice control without pressing any keys.
Voice commands are saved in the phone
memory only. They cannot be used in
another phone.
You should choose a long, unusual word
or phrase that can easily be distinguished
from ordinary background speech.
25Calling
To activate and record the magic
word
1From standby select Menu > Settings
> the General tab > Voice control
>Magic word > Activate.
2Follow the instructions on the screen
and select Continue. Wait for the tone
and say the magic word.
3Select Yes to accept or No for a new
recording.
4Follow the instructions on the screen
and select Continue.
5Select where your magic word is to be
activated.
To make a call using the magic word
1From standby say the magic word.
2Wait for the tone and say a voice
command.
Voice answering
When you use a handsfree, you can
answer or reject incoming calls with
your voice.
To activate voice answering and
record voice answer commands
1From standby select Menu > Settings
> the General tab > Voice control
>Voice answer > Activate.
2Follow the instructions on the screen
and select Continue. Wait for the tone
and say “Answer”, or another word.
3Select Yes to accept or No for a new
recording.
4Follow the instructions on the screen
and select Continue. Wait for the tone
and say “Busy”, or another word.
5Select Yes to accept or No for a new
recording.
6Follow the instructions on the screen
and select Continue.
7Select where your voice answering
is to be activated.
To answer a call using voice
commands
•Say “Answer”.
To reject a call using voice
commands
•Say “Busy”.
Diverting calls
You can divert calls, for example,
to an answering service.
Divert call options
Standard options are:
•Divert always – divert all your calls
•When busy – if a call is ongoing
When Restrict calls is used, some
divert call options are not available.
See Restricted dialling on page 28.
26 Calling
•Not reachable – if turned off or
unreachable
•No reply – if not answered in a
specified time
To divert calls
1From standby select Menu > Settings
> the Calls tab > Divert calls.
2Scroll to a call type and divert option
and select Activate.
3Enter the number to divert calls to and
select OK.
More than one call
You can handle more than one call at
the same time. For example, you can
put an ongoing call on hold, while you
make or answer a second call. You
can also switch between the two calls.
You cannot answer a third call without
ending one of the first two calls.
Call waiting
When call waiting is used, you hear
a beep if you receive a second call.
To activate call waiting
•From standby select Menu > Settings
> the Calls tab > Manage calls > Call
waiting > Activate.
To make a second call
1During the call, select More > Hold.
This puts the ongoing call on hold.
2Enter the number to call and select
More > Call.
To answer a second call
•During the call, select Answer. This
puts the ongoing call on hold.
To reject a second call
•During the call, select Busy and
continue with the ongoing call.
To end an ongoing call and answer
a second call
•During the call, select Replace active
call.
Handling two voice calls
You can have calls ongoing and on
hold at the same time.
To switch between two calls
•During the call, select More > Switch.
To join two calls
•During the call, select More > Join
calls.
To connect two calls
•During the call, select More > Transfer
call. You are disconnected from both
calls.
27Calling
To end an ongoing call and return
to the call on hold
•Select End call > Yes.
To end both calls
•Select End call > No.
Receiving a third voice call
You cannot answer a third call without
ending one of the first two calls or
joining them into a conference call.
Conference calls
With a conference call, you can have
a joint conversation with up to five
people.
To join the two calls
•During the call, select More > Join calls.
To add a new participant
1During the call, select More > Hold.
This puts the joined calls on hold.
2Select More > Add call.
3Enter the number to call and select Call.
4Select More > Join calls to add the new
participant.
5Repeat this task to add more
participants.
To release a participant
1Select More > Release part.
2Select the participant to release.
To have a private conversation
1During the call, select More > Talk to
and select the participant to talk to.
2To resume the conference call, select
More > Join calls.
My numbers
You can view, add and edit your own
phone numbers.
To check your phone numbers
1From standby select Menu > Contacts
> Options > Special numbers > My
numbers.
2Select an option.
Accept calls
You can choose to receive calls from
certain phone numbers only.
To add numbers to the accepted
callers list
1From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > Only from list > New.
2Scroll to a contact or select Groups.
See Groups on page 22.
If your subscription supports Alternate
Line Service (ALS), you can make separate
calls with different phone numbers.
28 Calling
To accept all calls
•From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > All callers.
Restricted dialling
You can restrict outgoing and incoming
calls. A password from your service
provider is required.
Restrict calls options
Standard options are:
•All outgoing – all outgoing calls
•Outgoing intl – all outgoing
international calls
•Outgoing intl roam. – all outgoing
international calls except to your
home country
•All incoming – all incoming calls
•Inc. when roaming – all incoming
calls when you are abroad
To restrict calls
1From standby select Menu > Settings
> the Calls tab > Manage calls
>Restrict calls.
2Select an option.
3Enter your password and select OK.
Fixed dialling
Fixed dialling allows calls to be
made only to certain numbers saved
on the SIM card. The fixed numbers
are protected by your PIN2.
Partial numbers can be saved. For
example, saving 0123456 allows calls
to be made to all numbers starting
with 0123456.
To use fixed dialling
1From standby select Menu > Contacts.
2Select More > Options > Special
numbers > Fixed dialling > Activate.
3Enter your PIN2 and select OK.
4Select OK again to confirm.
To save a fixed number
1From standby select Menu > Contacts.
2Select More > Options > Special
numbers > Fixed dialling > Fixed
numbers > New number.
3Enter the information and select Save.
If you divert incoming calls, you cannot
use some restrict calls options.
When fixed dialling is used, you can
still call the international emergency
number, 112.
When fixed dialling is used, you cannot
view or manage any phone numbers
saved on the SIM card.
29Messaging
Call time and cost
During a call, the duration of the call is
shown. You can check the duration of
your last call, outgoing calls and the
total time of your calls.
To check the call time
•From standby select Menu > Settings
> the Calls tab > Time & cost > Call
timers.
Business cards
To add your own business card
1From standby select Menu > Contacts.
2Select More > Options > My business
card.
3Scroll between tabs and select the
fields to add information. To enter
a symbol select More > Add symbol
>Insert.
4Enter the information and select Save.
To send your business card
1From standby select Menu > Contacts.
2Select More > Options > My business
card > Send my card.
3Select a transfer method.
Messaging
Text messages
Text messages can contain simple
pictures, sound effects, animations,
and melodies.
Before you use messaging
You must have a service centre
number. The number is supplied by
your service provider and is usually
saved on the SIM card. If the number
to your service centre is not saved
on your SIM card, you must enter the
number yourself.
To enter a service centre number
1From standby select Menu > Messaging
> Settings > Text message > Service
centre. The number is shown if it is
saved on the SIM card.
2If there is no number shown, select
Edit > New Service Centre and enter
the number, including the international
“+” sign and country code.
3Select Save.
Sending messages
For information about entering letters,
see Entering text on page 17.
Make sure the receiving device supports
the transfer method you select.
30 Messaging
To write and send a text message
1From standby select Menu > Messaging
> Write new > Text message.
2Write the message and select
Continue > Contacts look-up.
3Select a recipient and select Send.
To select more than one text
message
1From standby select Menu > Messaging
and select a folder.
2Scroll to a message and select More
>Mark several.
3Select Mark to mark the messages.
To add an item to a text message
1When you write the message, select
More > Add item.
2Select an option and then an item.
Receiving text messages
You are notified when you receive
a message. Received messages are
saved in the inbox.
To view a text message from standby
•If the activity menu is set: select View.
•If pop-up is set: follow the instructions
on the screen.
To view a text message from the
inbox
1From standby select Menu > Messaging
> Inbox.
2Scroll to the message and select View.
To close a text message
•Press .
To call a number in a text message
•When you view the message, scroll
to the phone number and select Call.
Saving and deleting text messages
Received text messages are saved
in the phone memory. When the
phone memory is full, you can delete
messages or move them to the SIM
card.
To save a text message on the
SIM card
1From standby select Menu > Messaging
and select a folder.
2Scroll to the message and select More
> Save message > Saved messages.
To save an item in a text message
1When you view the message, select
the item.
2Select More > Use.
3Select an option.
If you send a text message to a group,
you will be charged for each member.
See Groups on page 22.
31Messaging
To delete a text message
1From standby select Menu > Messaging
and select a folder.
2Scroll to the message and press .
Picture messages
Picture messages can contain text,
pictures, slides, sound recordings, video
clips, signatures and attachments. You
can send picture messages to a mobile
phone or an email address.
Before you use picture messaging
You must set an Internet profile and
the address of your message server.
If no Internet profile or message server
exists, you can receive all the settings
automatically from your network
operator or at
www.sonyericsson.com/support.
To select an Internet profile
1From standby select Menu > Messaging
> Settings > Picture message > MMS
profile.
2Select a profile.
To set the message server address
1From standby select Menu > Messaging
> Settings > Picture message > MMS
profile.
2Scroll to a profile and select More
>Edit > Message server.
3Select Edit and enter the address.
Sending messages
For information about entering letters,
see Entering text on page 17.
To create and send a picture
message
1From standby select Menu > Messaging
> Write new > Picture msg.
2Enter the text and press to add
items to the message.
3Select Continue > Contacts look-up.
4Select a recipient and select Send.
Receiving picture messages
You can select how to download
your picture messages. Standard
options when you download picture
messages are:
•Always – automatic download.
•Ask in roaming – ask to download
when not in home network.
•Not in roaming – do not download
when not in home network.
•Always ask – ask to download.
•Off – new messages appear in the
Inbox.
32 Messaging
To set automatic download
1From standby select Menu > Messaging
> Settings > Picture message > Auto
download.
2Select an option.
To view a picture message from
standby
•If the activity menu is set: select View.
•If pop-up is set: follow the instructions
on the screen.
To view a picture message from the
inbox
1From standby select Menu > Messaging
> Inbox.
2Scroll to the message and select View.
To close a picture message
•Press .
To save an item in a picture message
•When you view a picture message
select More > Save items and select
an item.
To delete a message
1From standby select Menu > Messaging
and select a folder.
2Scroll to the message and press .
Message options
You can set standard options for all
messages or choose specific settings
each time you send a message.
To set text message options
1From standby select Menu > Messaging
> Settings > Text message.
2Scroll to an option and select Edit.
To set picture message options
1From standby select Menu > Messaging
> Settings > Picture message.
2Scroll to an option and select Edit.
Send options
You can request a delivery report,
a read report, and set a priority for a
specific message. You can also add
more recipients to the message.
To set send options
1When the message is ready and
a recipient is selected, select More
>Advanced.
2Scroll to an option and select Edit.
Templates
If you often use the same phrases and
pictures in a message, you can save
the message as a template.
33Messaging
To use a text message template
1From standby select Menu > Messaging
> Templates.
2Scroll to a template and select Use
>Text message.
3Add text and select Continue and
select a recipient.
To use a picture message template
1From standby select Menu > Messaging
> Templates.
2Scroll to a template and select Use.
3When the message is ready, select
Continue and select a recipient.
To add a text message template
1From standby select Menu > Messaging
> Templates > New template > Text.
2Insert text or select More to add items.
Select OK.
3Enter a title and select OK.
To add a picture message template
1From standby select Menu > Messaging
> Templates > New template > Picture
msg.
2Enter the text and press to add
items to the message.
3Select Save, enter a title and select OK.
To edit a template
1From standby select Menu > Messaging
> Templates.
2Scroll to a template and select More
>Edit template > Save.
To save a message as a template
1From standby select Menu > Messaging
> Inbox.
2Scroll to the message and select More
> Save message > Templates.
Voice messages
You can send and receive a sound
recording as a voice message.
To record and send a voice message
1From standby select Menu > Messaging
> Write new > Voice message.
2Record the message and select Stop
> Send > Contacts look-up.
3Select a recipient and select Send.
Email
You can use standard email functions
and your computer email address in
your phone.
The sender and recipient must have a
subscription supporting picture messaging.
34 Messaging
Before you use email
Email settings must be entered in your
phone. You can have these settings
sent directly to your phone from the
Sony Ericsson support site, or you can
enter them manually.
Email settings using Internet
You can receive settings at
www.sonyericsson.com/support.
Entering email settings manually
You can also enter the email settings
manually. To do this, you need to ask
your email provider for the settings
information:
An email provider could be the company
that supplied your email address, for
example, your IT administrator at work
or an Internet provider.
You may find settings information in
your computer email program settings,
or in a document from your email
provider.
To enter email settings
1From standby select Menu > Messaging
> Email > Settings.
2Enter the settings.
Help appears as you enter settings.
To write and send an email message
1From standby select Menu > Messaging
> Email > Write new.
2Select Add > Enter email addr. Enter
the email address and select OK.
Settings
types
Examples
Connection
type
POP3 or IMAP4
Email
address
joe.smith@example.com
Incoming
server
mail.example.com
Username jsmith
Password zX123
Outgoing
server
mail.example.com
There are many different email providers.
Their terminology and required information
may differ. Not all service providers allow
email access.
For more information, contact
your email provider or go to
www.sonyericsson.com/support.
35Messaging
3To enter more recipients, select Edit.
Scroll to an option and select Add
>Enter email addr. Enter the email
address and select OK. When you
are ready, select Done.
4Press to scroll to Subject:. Select
Edit and enter a subject.
5Press to scroll to Text:. Select Edit
and enter the text.
6Press to scroll to Attachments:.
Select Add and select a file to attach.
7Select Continue > Send.
To receive and read an email
message
1From standby select Menu > Messaging
> Email > Inbox > Send&rec.
2Scroll to the message and select View.
To save an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select More
> Save message > Saved email.
To reply to an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select More
> Reply.
3Write the reply and select OK.
4Select Continue > Send.
To view an attachment in an email
message
•When you view the message, select
More > Attachments > View.
To save an attachment in an email
message
•When you view the message, select
More > Attachments > View > Save.
Active email account
If you have several email accounts,
you can change which one is active.
To change the active email account
1From standby select Menu > Messaging
> Email > Settings.
2Select an account.
To delete an email message (POP3)
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select More
> Mark for deletion > Yes.
To delete an email message (IMAP4)
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select More
> Mark for deletion > Yes.
3Select More > Clear inbox.
Marked messages will be deleted when
you next connect to your server.
36 Messaging
Push email
You can receive notification in your
phone from your email server that you
have new email.
To turn on push email notification
1From standby select Menu > Messaging
> Email > Settings.
2Scroll to an account to edit and select
More > Edit account > Advanced
settings > Push email.
3Select an option.
My friends
You can connect and log in to the My
friends server to communicate online
with chat messages.
Before you use My friends
If no settings exist in your phone, you
need to enter server settings. Standard
settings information supplied by your
service provider is:
•username
•password
•server address
•Internet profile
To enter My friends server settings
1From standby select Menu > Messaging
> My friends > Configure.
2Select Add and enter the settings.
To edit My friends settings
1From standby select Menu > Messaging
> My friends.
2Select More > Settings.
3Scroll to the setting and select Edit.
To log in to the My friends server
•From standby select Menu > Messaging
> My friends > Log in.
To log out of the My friends server
•Select More > Log out.
To add a chat contact
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Select More > Add contact.
To send a chat message
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Scroll to a contact and select Chat.
3Write the message and select Send.
Status
You can show your status, for example,
Happy or Busy, to your contacts only.
You can also show your status to all
users on the My friends server.
Marked messages will be deleted in the
phone and on the server.
37Messaging
To show my status
1From standby select Menu > Messaging
> My friends > More > Settings > Show
my status.
2Select an option.
To update your own status
1From standby select Menu > Messaging
> My friends > the My status tab.
2Scroll between tabs and select the
fields to add information.
Chat group
A chat group can be started by your
service provider, by an individual My
friends user or by yourself. You can
save chat groups by saving a chat
invitation or by searching for a specific
chat group.
To create a chat group
1From standby select Menu > Messaging
> My friends > the Chat groups tab.
2Select More > Add chat group > New
chat group.
3Select who to invite from your
contacts list and select Continue.
4Enter a short invitation text and select
Continue > Send.
To add a chat group
1From standby select Menu > Messaging
> My friends > the Chat groups tab
>More > Add chat group.
2Select an option.
To save a conversation
1From standby select Menu > Messaging
> My friends > the Conversations tab.
2Scroll to a conversation and select
More > Advanced > Save conv.
To view a saved conversation
1From standby select Menu > Messaging
> My friends > the Conversations tab.
2Select More > Saved conv.
Area and cell information
Area and cell information are text
messages, for example, local traffic
reports that are sent to subscribers
within a certain network area.
To turn area information on
1From standby select Menu > Messaging
> Settings > Area info.
2Scroll to Reception and select Edit
>On.
Conversation history is saved between log
out and when you log in again to let you
return to chat messages from previous
conversations.
Contact your service provider for more
information.
38 Imaging
Imaging
Camera and video recorder
You can take pictures and record
video clips to view, save or send.
To activate the camera
•When the phone is turned on, slide
open the lens cover.
To take a picture
1Activate the camera.
2Use the navigation key
to select camera.
3Press half way down to
use auto focus. When you hear
a beep, press fully down to
take a picture.
To record a video clip
1Activate the camera.
2Use the navigation key to
select video recorder.
3Press fully down to start
recording.
To stop recording
•Press .
Screen options
Zoom in
or out
Take pictures
Record video
Delete
Do not record with a strong light source
in the background.
39Imaging
To use zoom
•Press or .
To adjust brightness
•Press or .
Saving and deleting pictures and
video clips
Pictures and video clips are saved
automatically in File manager.
To view pictures and video clips
1From standby select Menu > File
manager > Camera album.
2Scroll to an item and select View.
To delete pictures and video clips
1From standby select Menu > File
manager > Camera album.
2Scroll to an item and press .
Photo fix
You can improve an under-exposed
picture with Photo fix.
To improve a picture with Photo fix
1Activate the camera.
2Take a picture.
3During review, select More > Photo fix.
Camera settings
You can select different settings
before you take a picture or record
a video clip.
To view settings
•When the camera is activated, select
Settings.
To view information about settings
•Scroll to a setting and select Info.
Camera shortcuts
Transferring pictures
Transfer to and from your computer
You can use Bluetooth technology and
picture messages to transfer pictures
to your computer. You can also use the
USB cable to drag and drop camera
pictures. See Transferring files using
the USB cable on page 56.
Key Shortcut
Shoot mode
Zoom out
Focus
Zoom in
Picture: Scenes
Picture: Turn on self-timer
Light
Night mode
Key guide
40 Imaging
You can enhance and organize
your pictures on your computer
by installing Adobe™ Photoshop™
Album Starter Edition. These are
included on the CD that comes
with your phone and are available
at www.sonyericsson.com/support.
Picture blog
A picture blog is a personal Web page.
If your subscription supports this
service, you can send pictures to a blog.
To send camera pictures to a blog
1From standby select Menu > File
manager > Camera album.
2Scroll to a picture and select More
>Send > To blog.
3Add title and text.
4Select OK > Publish.
To go to a blog address from
contacts
1From standby select Menu > Contacts.
2Scroll to contact.
3Scroll to a Web address and select
Go to.
Camera album printing
You can print camera pictures using the
USB cable connected to a compatible
printer.
To print camera pictures using the
USB cable
1From standby select Menu > File
manager > Camera album.
2Select More > Print.
3Select an option.
4Connect the USB cable to the phone.
5Connect the USB cable to the printer.
6Wait for feedback in the phone and
select OK.
7Set printer settings, if required and
select Print.
To print camera pictures using
a memory card
1Check printer documentation for
information regarding settings,
memory card and PictBridge support.
2When you view a camera picture, select
More > Print > DPOF (M.S.) > Save.
3Transfer the memory card to your
printer and follow the instructions on
the screen.
Web services may require a separate
license agreement between you and the
service provider. Additional regulations
and/or charges may apply. Contact your
service provider.
You can also print using a Bluetooth
compatible printer.
You should disconnect and re-connect
the USB cable if there isa printer error.
41Imaging
Pictures and video clips
You can view, add, edit or delete
pictures in the File manager. File types
supported are, for example, GIF, JPEG,
WBMP, BMP, PNG and SVG-Tiny.
Using pictures
You can add a picture to a contact,
use it during phone start-up, as a
wallpaper in standby or as a screen
saver.
To view pictures
1From standby select Menu > File
manager > Pictures.
2Scroll to a picture and select View.
To use pictures
1From standby select Menu > File
manager > Pictures.
2Scroll to a picture and select More
>Use as.
3Select an option.
To view pictures in a slide show
1From standby select Menu > File
manager > Pictures.
2Scroll to a picture and select View
>More > Slide show.
Sending and receiving
You can send and receive pictures as
a picture message, an email or using
Bluetooth.
To send a picture
1From standby select Menu > File
manager > Pictures.
2Scroll to a picture and select More
>Send.
3Select a transfer method.
To send a video clip
1From standby select Menu > File
manager > Videos.
2Scroll to a video clip and select More
>Send.
3Select a transfer method.
To receive a picture or video clip
•Follow the instructions that appear.
PhotoDJ™ and VideoDJ™
You can edit pictures and video clips
using PhotoDJ™ or VideoDJ™.
Make sure the receiving device supports
the transfer method you select.
Make sure the receiving device supports
the transfer method you select.
42 Entertainment
To edit and save a picture
1From standby select Menu > File
manager > Pictures.
2Scroll to a picture and select More
>Edit in PhotoDJ™.
3Select an option and edit the picture.
4Select More > Save picture.
To edit and save a video clip
1From standby select Menu > File
manager > Videos.
2Scroll to a video clip and select More
>VideoDJ™.
3Select an option and edit the video clip.
4Select More > Save.
Themes
You can change the appearance of the
screen through items such as colours
and wallpaper. You can also create
new themes and download them.
For more information, go to
www.sonyericsson.com/support.
To set a theme
1From standby select Menu > File
manager > Themes.
2Scroll to a theme and select Set.
Entertainment
Stereo portable handsfree
To use the handsfree
•Connect the portable handsfree.
Music stops when you receive a call
and resumes when the call has ended.
Music and video players
File types supported are: MP3, MP4,
M4A, 3GP, AAC, AAC+, Enhanced
AAC, AMR, MIDI, IMY, EMY, WAV
(16 kHz maximum sample rate) and
Real®8. Your phone also supports
streamed files that are 3GPP
compatible.
To play music
1From standby select Menu > Music
player.
2Scroll to an option and select Open.
3Scroll to a title and select Play.
43Entertainment
To play videos
1From standby select Menu
>Entertainment > Video player.
2Scroll to a title and select Play.
Music and video controls
To stop playing music
•Select Stop.
To resume playing music
•Select Play.
To change the volume
•When you listen to music in the
music player, press or .
To move between tracks
•When you listen to music in the
music player, press or .
To fast forward and rewind
•When you listen to music in the music
player, press and hold down or .
To return to the music player menu
•When you listen to music in the music
player, press .
To exit the music player menu
•Press and hold down .
Sending and receiving music
You can send and receive music in
a picture message, an email or using
Bluetooth.
To send music
1From standby select Menu > Music
player.
2Scroll to an option and select Open.
3Scroll to a title and select More
>Send.
4Select a transfer method.
To receive music
•Follow the instructions that appear.
Transferring music from a computer
Disc2Phone computer software and
USB drivers are included on the CD
that comes with your phone. You can
use Disc2Phone to transfer music
from CDs or your computer to the
phone memory or a memory card.
Before you use Disc2Phone
You need one of these operating
system requirements to use
Disc2Phone on your computer:
•Windows® 2000 SP4
•XP Home
•XP Professional SP1
Make sure the receiving device supports
the transfer method you select.
44 Entertainment
To install Disc2Phone
1Turn on your computer and insert
the CD that came with the phone.
The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Disc2Phone and follow
the instructions on the screen.
To use Disc2Phone
1Connect the phone to a computer with
the USB cable that came with the
phone.
2Select File transfer. The phone turns
off and prepares to transfer files.
3Computer: Start/Programs/
Disc2Phone.
4For details on transferring music,
please refer to Disc2Phone Help.
Click in the top-right corner of
the Disc2Phone window.
5For safe disconnection of the USB
cable in file transfer mode, right-click
the removable disk icon in Windows
Explorer and select Eject.
See Transferring files using the USB
cable on page 56.
More information about transferring
files to your phone is available at
www.sonyericsson.com/support.
Browsing files
Music and video files are saved and
categorized.
•Artists – list tracks you have
transferred using Disc2Phone.
•Tracks – list all music tracks in your
phone and on a memory card.
•Playlists – your own lists of tracks.
•Videos – list all video clips in your
phone or on a memory card.
Playlists
You can create playlists to organize
files in the File manager. You can sort
the files by artist or title. Files can be
added to more than one playlist.
Deleting a playlist, or a file from a
playlist, does not delete the file from the
memory, just the reference to the file.
Disc2Phone software is available at
www.sonyericsson.com/support.
Do not remove the USB cable from your
phone or computer during transfer, as this
may corrupt a memory card or the phone
memory. You cannot view the transferred
files in your phone until you have removed
the USB cable from your phone.
45Entertainment
To create a playlist
1From standby select Menu > Music
player.
2Scroll to Playlists and select Open.
3Scroll to New playlist and select Add.
4Enter a name and select OK.
5Scroll to a track and select Mark.
6Select Add to add the track to the
playlist.
To add files to a playlist
1From standby select Menu > Music
player.
2Scroll to Playlists and select Open.
3Scroll to the playlist and select Open.
4Select More > Add media.
5Scroll to a track and select Mark.
6Select Add to add the track to the
playlist.
To remove tracks from a playlist
1From standby select Menu > Music
player > Playlists.
2Scroll to a playlist and select Open.
3Scroll to the track and press .
To delete a playlist
1From standby select Menu > Music
player > Playlists.
2Scroll to a playlist and press .
To view information about a track
•Scroll to a track and select More
>Information.
Online music and video clips
You can view video clips and listen
to music by streaming them to your
phone from the Internet. If settings
are not already in your phone, see
Settings on page 51. For more
information, contact your network
operator or go to
www.sonyericsson.com/support.
To select a data account for
streaming
1From standby select Menu > Settings
> the Connectivity tab > Streaming
settings.
2Select the data account to use.
To stream music and video clips
1From standby select Menu > Internet
>More > Go to > Bookmarks.
2Select a link to stream from.
TrackID™
TrackID™ is a free music recognition
service. Search for song titles, artists
and album names.
46 Entertainment
To search for song information
•When you hear a song through a
loudspeaker, from standby select
Menu > Entertainment > TrackID™.
•When the radio is playing select More
> TrackID™.
Radio
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu
>Entertainment > Radio.
To change the volume
•When the radio is playing, press
or .
To automatically search for radio
channels
•When the radio is playing, select
Search.
To manually search for radio
channels
•When the radio is playing, press
or .
To search for preset channels
•When the radio is playing, press
or .
Saving radio channels
You can save up to 20 preset
channels.
To save radio channels
1From standby select Menu
>Entertainment > Radio.
2Select Search to find a radio channel.
3Select More > Save.
To select saved radio channels
1From standby select Menu
>Entertainment > Radio > More
>Channels.
2Select a radio channel.
To save radio channels in positions
1 to 10
•When you have found a radio channel,
press and hold down - .
To select radio channels saved in
positions 1 to 10
•When the radio is playing, press
- .
To view radio options
•When the radio is playing, select More.
Do not use your phone as a radio in
places where this is prohibited.
47Entertainment
PlayNow™
You can listen to music before you
purchase and download it to your phone.
Before you use PlayNow™
You must have the required settings in
your phone. See Settings on page 51.
To listen to PlayNow™ music
1From standby select Menu
>PlayNow™.
2Select music from a list.
Downloading from PlayNow™
The price appears when you select to
download and save a music file. Your
phone bill or prepay card is debited
when a purchase is accepted.
To download a music file
1When you have listened to a music file
preview, you can agree to accept the
conditions.
2Select Yes to download.
3A text message is sent to confirm
payment and the file is made available
to download.
Ringtones and melodies
To set a ringtone
1From standby select Menu > Settings
> the Sounds & alerts tab > Ringtone.
2Select an option.
To set the ringtone volume
1From standby select Menu > Settings
> the Sounds & alerts tab > Ring
volume.
2Press or to change the volume.
3Select Save.
To turn the ringtone off
•From standby press and hold
down .
All signals except the alarm signal
are affected.
To set the vibrating alert
1From standby select Menu > Settings
> the Sounds & alerts tab > Vibrating
alert.
2Select an option.
To send a ringtone
1From standby select Menu > File
manager > Music > Ringtones.
2Scroll to a ringtone and select More
>Send.
3Select a transfer method.
This service is not available in all countries.
Contact your network operator for more
information. In some countries you can
purchase music from some of the world’s
top musical artists.
48 Entertainment
To receive a ringtone
•Follow the instructions that appear.
MusicDJ™
You can compose and edit your
own melodies to use as ringtones.
A melody consists of four types of
tracks – Drums, Basses, Chords, and
Accents. A track contains a number
of music blocks. The blocks consist
of pre-arranged sounds with different
characteristics. The blocks are
grouped into Intro, Verse, Chorus,
and Break. You compose a melody
by adding music blocks to the tracks.
To compose a melody
1From standby select Menu
>Entertainment > MusicDJ™.
2Select to Insert, Copy or Paste blocks.
3Use , , or to scroll between
the blocks.
4Select More > Save melody.
To send a melody
1From standby select Menu > File
manager.
2Scroll to Music and select Open.
3Scroll to a melody and select More
>Send.
4Select a transfer method.
To receive a melody
•Follow the instructions that appear.
VideoDJ™
You can create and edit your own
video clips by using video clips,
pictures and text.
To create a video clip
1From standby select Menu
>Entertainment > VideoDJ™.
2Select Add and select an option.
3Press and select Add to add more
items.
4Select More > Save.
To edit a video clip
1From standby select Menu > File
manager.
2Scroll to Videos and select Open.
Make sure the receiving device supports
the transfer method you select.
You are not allowed to exchange some
copyright-protected material. A protected
file has a key symbol. Make sure the receiving device supports
the transfer method you select.
You cannot send a polyphonic melody or
MP3 file in a text message.
49Entertainment
3Scroll to a video clip and select More
>VideoDJ™ > Edit.
4Edit the video clip and select More
>Save.
To trim a video clip
1From standby select Menu > File
manager.
2Scroll to Videos and select Open.
3Scroll to a video clip and select More
>VideoDJ™ > Edit > Trim.
4Select Set to set the start point and
select Start.
5Select Set to set the end point and
select End.
6Select Trim > More > Save.
To send a video clip
1From standby select Menu > File
manager > Videos.
2Scroll to Videos and select Open.
3Scroll to a video clip and select More
>Send.
4Select a transfer method.
To receive a video clip
•Follow the instructions that appear.
Sound recorder
You can record a voice memo or a
call. Recorded sounds can also be set
as ringtones.
To record a sound
•From standby select Menu
>Entertainment > Record sound.
To listen to a recording
1From standby select Menu > File
manager > Music.
2Scroll to a recording and Play.
Games
Your phone contains several games.
You can also download games. Help
texts are available for most games.
To start a game
1From standby select Menu
>Entertainment > Games.
2Select game.
To end a game
•Press and hold down .
Make sure the receiving device supports
the transfer method you select.
In some countries or states it is required
by law that you inform the other person
before recording the call.
50 Entertainment
Applications
Before you use Java™ applications
If settings are not already entered in
your phone, see Settings on page 51.
You can download and run Java
applications. You can also view
information or set different
permissions.
To select a Java application
1From standby select Menu > File
manager > Applications.
2Select an application.
To view information about a Java
application
1From standby select Menu > File
manager > Applications.
2Scroll to an application and select
More > Information.
To set permissions for a Java
application
1From standby select Menu > File
manager > Applications.
2Scroll to an application and select
More > Permissions.
To set the screen size for a Java
application
1From standby select Menu > File
manager > Applications.
2Scroll to an application and select
More > Screen size.
3Select an option.
Internet profiles for Java applications
Some Java applications need to
connect to the Internet to receive
information.
To select an Internet profile for Java
applications
1From standby select Menu > Settings
> the Connectivity tab > Internet
settings > Settings for Java.
2Select an option.
51Connectivity
Connectivity
Settings
Before you use Internet, PlayNow™, My
friends, Java, remote synchronization,
picture messaging, email and picture
blog you need to have settings in your
phone.
If settings are not already entered,
make sure your phone supports data
transfer. You can download settings
using the setup wizard or from
www.sonyericsson.com/support.
To download settings using the
Setup wizard
1From standby select Menu > Settings
> the General tab > Setup wizard
>Settings download.
2Follow the instructions on the screen.
To download settings using a
computer
1Go to
www.sonyericsson.com/support.
2Follow the instructions on the screen.
Using Internet
You can use the Internet to access
online services.
To start browsing
•From standby select Menu > Internet.
To exit the browser
•When you browse the Internet, select
More > Exit browser.
To view options
•When you browse the Internet, select
More.
When you browse the Internet
You can make a call or send a link
when you browse the Internet.
To make a call
•When you browse the Internet, select
More > Tools > Make a call.
To send a link
1When you browse the Internet, select
More > Tools > Send link.
2Select an option.
Using bookmarks
You can create and edit bookmarks
as quick links to your favourite Web
pages.
To create a bookmark
1From standby select Menu > Internet
>More > Go to > Bookmarks.
2Scroll to New bookmark and select
Add.
3Enter the information and select Save.
52 Connectivity
To select a bookmark
1From standby select Menu > Internet
>More > Go to > Bookmarks.
2Scroll to a bookmark and select Go to.
Internet keypad shortcuts
You can use the keypad to go directly
to an Internet browser function.
To select Internet keypad shortcuts
•From standby select Menu > Internet
>More > Options > Keypad mode
>Shortcuts.
Downloading
You can download files, for example,
pictures, themes, games and
ringtones from Web pages.
To download from a Web page
1When you browse the Internet, select
a file to download.
2Follow the instructions on the screen.
Internet profiles
You can select another Internet profile
if you have more than one.
To select an Internet profile for the
Internet browser
1From standby select Menu > Settings
> the Connectivity tab > Internet
settings > Internet profiles.
2Select an option.
Internet security and certificates
Your phone supports secure browsing.
Certain Internet services, such as
banking, require certificates in your
phone. Your phone may already contain
certificates when you buy it or you can
download new certificates.
To view certificates in the phone
•From standby select Menu
> Settings > the General tab
>Security >Certificates.
Key Shortcut
Bookmarks
Enter address
Search Internet
History
Refresh page
Forward
Page up
Page down
Fullscreen or Landscape or
Normal screen.
Zoom
Shortcuts
53Connectivity
RSS reader
You can receive frequently updated
content, such as news headlines, as
feeds, using Really Simple Syndication
(RSS).
To add new feeds for a Web page
•When you browse the Internet, select
More > RSS feeds.
To create a new feed
1From standby select Menu > Messaging
> RSS reader > More > New feed.
2Enter the address and select Go to.
To set and use RSS reader options
1From standby select Menu > Messaging
> RSS reader > More.
2Select an option.
Synchronizing
You can synchronize phone contacts,
appointments, tasks and notes. You
can use Bluetooth wireless technology,
Internet services or the USB cable.
Sony Ericsson PC Suite software
In order to synchronize, you need to
install the synchronization software for
your computer. This is found in the
Sony Ericsson PC Suite on the CD
included with your phone. The
software includes help information.
You can also go to
www.sonyericsson.com/support
to download the software.
Remote synchronization using Internet
You can synchronize online using an
Internet service. If Internet settings
are not in your phone, see Settings
on page 51.
Before you use Sony Ericsson
PC Suite
You must enter settings for remote
synchronization and register a
synchronization account online.
Settings that are required are:
•Server address – server URL.
•Username – account username.
•Password – account password.
•Connection – select an Internet
profile.
•Applications – mark applications to
synchronize.
•App. settings – select an application
and enter a database name, and if
required, username and password.
•Sync. interval – set how often to
synchronize.
•Remote initiation – select an option to
use when you start synchronization
from a service.
•Remote security – enter a server ID
and a server password.
54 Connectivity
To enter settings for remote
synchronization
1From standby select Menu > Organizer
> Synchronization > Yes.
2Enter a name for the new account and
select Continue.
3Enter the settings and select Save.
To start remote synchronization
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Bluetooth™ wireless
technology
The Bluetooth function makes wireless
connection to other Bluetooth devices
possible. You can, for example:
•Connect to handsfree devices.
•Connect to stereo headsets.
•Connect to more than one device
at the same time.
•Connect to computers and access
the Internet.
•Synchronize information with
computers.
•Use remote control computer
applications.
•Use media viewer accessories.
•Exchange items and play
multiplayer games.
Before you use Bluetooth wireless
technology
You must turn on the Bluetooth
function to communicate with other
devices. You must also pair your
phone with other Bluetooth devices.
To turn the Bluetooth function on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Turn on.
To pair the phone with a device
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth > My
devices > New device to search for
available devices.
2Select a device.
3Enter a passcode, if required.
To allow connection to the phone
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth > My
devices.
2Select a device from the list.
3Select More > Allow connection.
We recommend a range within 10 metres
(33 feet), with no solid objects in between,
for Bluetooth communication.
Make sure that the device you want to
pair your phone with has the Bluetooth
function activated and is made visible.
55Connectivity
To pair the phone with a Bluetooth
handsfree for the first time
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Handsfree.
2Select Yes.
3Enter a passcode, if required.
To pair the phone with more than one
Bluetooth handsfree
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Handsfree > My handsfree > New
handsfree.
2Scroll to a device and select Add.
Power save
You can save battery power with this
function. You can only connect with a
single Bluetooth device. You must turn
this function off if you want to connect
with more than one Bluetooth device
at the same time.
To turn powersave on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Powersave > On.
Phone name
You can enter a name for your phone
to be shown when other devices find it.
To enter a phone name
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Phone name.
2Enter the phone name and select OK.
Visibility
If you want other Bluetooth devices
to be able to discover your phone,
you can choose to make your phone
visible.
To send a contact using Bluetooth
1From standby select Menu > Contacts.
2Scroll to a contact and select More
>Send contact > Via Bluetooth.
3Select the device to send the item to.
To receive an item
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Turn on > Visibility > Show phone.
2When you receive an item, follow the
instructions on the screen.
Transferring sound to and from
a Bluetooth handsfree
You can transfer the sound to and
from a Bluetooth handsfree. To do
this, you can use a phone key or the
handsfree key.
56 Connectivity
To transfer sound
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
>Handsfree > Incoming call.
2Select an option. In phone transfers
sound to the phone. In handsfree
transfers sound to the handsfree.
File transfer
You can synchronize and transfer files
using Bluetooth wireless technology.
See Sony Ericsson PC Suite software
on page 53.
Transferring files using the USB
cable
You can connect your phone to a
computer, using the USB cable. You
can transfer files using File transfer and
you can synchronize your phone with
a computer using Phone mode.
Before you use the USB cable
You need one of the these operating
system requirements to transfer files
using a USB cable:
•Windows 2000 with SP3/SP4
•Windows XP (Pro and Home) with
SP1/SP2
USB drivers are installed automatically
with the Sony Ericsson PC Suite
software.
File transfer
You can drag and drop files between
your phone and a computer in
Microsoft Windows Explorer.
•Sony Disc2Phone – drag and drop
music files
•Adobe™ Photoshop™ Album
Starter Edition – drag and drop
pictures
These applications can only be used in
file transfer mode.
Only use the USB cable that comes with
your phone, and connect the USB cable
directly to the computer. Do not remove
the USB cable from your phone or
computer during file transfer as this may
corrupt the phone memory or the memory
card.
57Connectivity
To use file transfer mode
1Connect the USB cable to the phone
and the computer.
2Phone: From standby select Menu
>Settings > the Connectivity tab > USB
> USB connection > File transfer. The
phone shuts down.
3Wait until the phone memory and
memory card appear as external disks
in Windows Explorer.
To disconnect the USB cable safely
1Right-click the removable disk icon
in Windows Explorer.
2Select Eject.
3Remove the USB cable.
Phone mode
You can synchronize contacts and
calendar, transfer files and use your
phone as a modem from your
computer. Supported applications in
phone mode include:
•Synchronization
•File manager
•Mobile Networking Wizard.
For other applications, use the file
transfer mode.
To install the Sony Ericsson PC Suite
1Turn on your computer and insert
the CD that came with the phone.
The CD starts automatically and the
installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson PC suite
and follow the instructions on the
screen.
To use phone mode
1Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
2Connect the USB cable to the phone
and the computer.
3Phone: From standby select Menu
>Settings > the Connectivity tab > USB
> USB connection > Phone mode.
4Computer: Wait while Windows
installs the required drivers.
Sony Ericsson PC suite software
is available at
www.sonyericsson.com/support.
58 Connectivity
5Computer: When you are notified that
PC Suite has found your phone, use
one of the phone mode applications in
the Sony Ericsson PC Suite.
Update service
You can update your phone with
the latest software. You do not lose
personal or phone information.
There are two ways to update your
phone:
•Over the air using your phone
•Using the provided USB cable and
an Internet-connected computer
Before you use the Update service
If settings are not in your phone, see
Settings on page 51.
To view the current software in the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Software version.
To use Update service using the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Search for update and follow
the instructions on the screen.
To use Update service using a
USB cable
1Go to
www.sonyericsson.com/support.
2Select a region and country.
3Enter the product name.
4Select Sony Ericsson Update Service
and follow the instructions on the
screen.
To set a reminder to use Update
service
1From standby select Menu > Settings
> the General tab > Update service
>Reminder.
2Select an option.
The update service requires data access
(GPRS).
59More features
More features
Alarms
You can set a sound or the radio as
an alarm signal. The alarm sounds
even if the phone is set to silent or
turned off. When the alarm sounds
you can silence it for 9 minutes or
turn it off.
To set the alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Time: and select Edit.
4Enter a time and select OK > Save.
To set the recurrent alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Recurrent: and select Edit.
4Scroll to a day and select Mark.
5Select Done > Save.
To set the alarm signal
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Alarm signal: and select Edit.
4Scroll to an option and select Save.
To silence the alarm
•When the alarm sounds, press
any key.
To silence the radio alarm
•When the alarm sounds, select
Snooze.
To turn off an alarm
•When the alarm sounds, select
Turn off.
To cancel the alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Turn off.
Calendar
The calendar can be synchronized with
a computer calendar or with a calendar
on the Web. See Synchronizing on
page 53.
Appointments
You can add new appointments or
reuse existing appointments.
To add an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to New appointm. and select
Add.
4Enter the information and confirm
each entry.
5Select Save.
60 More features
To view an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
To reuse an existing appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
4Select More > Edit.
5Edit the appointment and confirm
each entry.
6Select Save.
To send an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
More > Send.
4Select a transfer method.
To view a calendar week
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select More > View week.
To set when reminders should sound
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select More > Advanced > Reminders.
4Select an option.
Navigating your calendar
You can use the navigation key to
move between days or weeks. In the
monthly view, you can use keypad
shortcuts.
Make sure the receiving device supports
the transfer method you select.
A reminders option set in calendar
affects a reminders option set in tasks.
Key Shortcut
Back a week
Back a month
Back a year
Today’s date
Next week
Next month
Next year
61More features
Calendar settings
To view calendar options
1From standby select Menu > Organizer
> Calendar.
2Select More.
Tasks
You can add new tasks or reuse
existing tasks.
To add a task
1From standby select Menu > Organizer
> Tasks.
2Select New task > Add.
3Select an option.
4Enter details and confirm each entry.
To view a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
To reuse an existing task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
3Select More > Edit.
4Edit the task and select Continue.
5Choose to set a reminder.
To send a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select More > Send.
3Select a transfer method.
To set when reminders should sound
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select More
>Reminders.
3Select an option.
Notes
You can make notes and save them.
You can also show a note in standby.
To add a note
1From standby select Menu > Organizer
> Notes.
2Select New note > Add.
3Write a note and select Save.
To show a note in standby
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select More
>Show in standby.
Make sure the receiving device supports
the transfer method you select.
A reminders option set in tasks affects
a reminders option set in calendar.
62 More features
To edit a note
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select More > Edit.
3Edit the note and select Save.
To send a note
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select More > Send.
3Select a transfer method.
Timer, stopwatch and
calculator
To use the timer
1From standby select Menu > Organizer
> Timer.
2Enter the hours, minutes and seconds.
3Select Start.
To use the stopwatch
1From standby select Menu > Organizer
> Stopwatch > Start.
2To view a new lap time, select New lap.
To use the calculator
1From standby select Menu > Organizer
> Calculator.
2Press or to select ÷ x - + % =.
Code memo
You can save security codes, for
example, for credit cards. You must
set a passcode to open the code
memo.
Checkword
The checkword confirms that you
have entered the correct passcode.
If the passcode is correct, the correct
codes are shown. If the passcode is
incorrect, the checkword and the
codes shown are also incorrect.
To open code memo for the first time
1From standby select Menu > Organizer
> Code memo.
2Follow the instructions on the screen
and select Continue.
3Enter a passcode and select Continue.
4Confirm the passcode and select
Continue.
5Enter a checkword and select Done.
To add a code
1From standby select Menu > Organizer
> Code memo.
2Enter a passcode and select New
code > Add.
3Enter a name associated with the
code and select Continue.
4Enter the code and select Done.
Make sure the receiving device supports
the transfer method you select.
63More features
To change a passcode
1From standby select Menu > Organizer
> Code memo.
2Enter your passcode and select More
> Change passcode.
3Enter your new passcode and select
Continue.
4Re-enter the new passcode and select
Continue.
5Enter a checkword and select Done.
Forget your passcode?
If you forget your passcode, you must
reset the code memo. This means that
all entries in the code memo are
deleted. The next time you enter the
code memo, you must proceed as if
you are opening it for the first time.
See To open code memo for the first
time on page 62.
To reset code memo
1From standby select Menu > Organizer
> Code memo.
2Enter any passcode to access the code
memo. The checkword and codes that
are then shown are incorrect.
3Select More > Reset.
4Reset code memo? appears.
5Select Yes.
Profiles
Profiles automatically adapt your
phone to different situations, for
example, while in a meeting or when
driving. Some profiles settings, for
example, ring volume may be adjusted
automatically to suit a certain area or
accessory. You can reset all profile
settings to how they were set when
you bought your phone.
To select a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Select a profile.
To view and edit a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Scroll to a profile and select More
>View and edit.
To reset all profiles
1From standby select Menu > Settings
> the General tab > Profiles.
2Scroll to a profile and select More
>Reset profiles.
You cannot rename the Normal profile.
64 More features
Time and date
To set the time
1From standby select Menu > Settings
> the General tab > Time & date > Time.
2Enter the time > Save.
To set the date
1From standby select Menu > Settings
> the General tab > Time & date > Date.
2Enter the date and select Save.
Locks
SIM card lock
This lock only protects your
subscription. Your phone will work
with a new SIM card. If the lock is
on, you have to enter a PIN (Personal
Identity Number).
If you enter your PIN incorrectly three
times in a row, the SIM card is blocked
and you need to enter your PUK
(Personal Unblocking Key). Your PIN
and PUK are supplied by your network
operator.
To unblock the SIM card
1When PIN blocked appears, enter your
PUK and select OK.
2Enter a new four-to-eight-digit PIN
and select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1From standby select Menu > Settings
> the General tab > Security > Locks
>SIM protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four-to-eight-digit PIN
and select OK.
4Re-enter the new PIN and select OK.
To use the SIM card lock
1From standby select Menu > Settings
> the General tab > Security > Locks
>SIM protection > Protection.
2Select an option.
3Enter your PIN and select OK.
Phone lock
You can stop unauthorized use of
your phone. Change the phone lock
code (0000) to any four-to-eight-digit
personal code.
If Codes do not match appears, you
entered the new PIN incorrectly.
If Wrong PIN appears, followed by Old PIN:,
you entered your old PIN incorrectly.
It is important that you remember your
new code. If you forget it, you have to take
your phone to your local Sony Ericsson
retailer.
65More features
To use the phone lock
1From standby select Menu > Settings
> the General tab > Security > Locks
>Phone protection > Protection.
2Select an option.
3Enter the phone lock code and
select OK.
To change the phone lock code
1From standby select Menu > Settings
> the General tab > Security > Locks
>Phone protection > Change code.
2Enter the old code and select OK.
3Enter the new code and select OK.
4Repeat the code and select OK.
Keypad lock
You can set this lock to avoid
accidental dialling. Incoming calls
can be answered without unlocking
the keypad.
To use the automatic keylock
1From standby select Menu
>Settings > the General tab
>Security >Automatic keylock.
2Select an option.
To lock the keypad manually
•From standby press and select
Lock keys.
To unlock the keypad manually
•From standby press and select
Unlock.
IMEI number
Keep a copy of your IMEI (International
Mobile Equipment Identity) number in
case your phone should be stolen.
To view your IMEI number
•From standby press , , ,
, .
Calls to the international emergency
number 112 can still be made.
66 Troubleshooting
Troubleshooting
Why doesn’t the phone work the way
I want it to?
Some problems will require that you
to call your network operator.
For more support go to
www.sonyericsson.com/support.
Common questions
I have problems with memory
capacity or the phone is working
slowly
Restart your phone every day to free
memory or do a Master reset.
Master reset
If you select Reset settings, the
changes that you have made to
settings will be deleted.
If you select Reset all, in addition to
your changes to settings, all contacts,
messages, personal data, and content
that you have downloaded, received
or edited will also be deleted.
To reset the phone
1From standby select Settings > the
General tab > Master reset > Reset
settings.
2Follow the instructions on the screen
and select Continue.
I cannot charge the phone or battery
capacity is low
The charger is not properly connected
or the battery connection is poor.
Remove the battery and clean the
connectors.
The battery is worn out and needs to
be replaced. See Charging the battery
on page 8.
No battery icon appears when I start
charging the phone
It may take a few minutes before the
battery icon appears on the screen.
Some menu options appear in grey
A service is not activated. Contact
your network operator.
I cannot use SMS/text messages
on my phone
Settings are missing or incorrect.
Contact your network operator to find
out the correct SMS service centre
setting. See Text messages on page 29.
I cannot use picture messages on
my phone
Your subscription does not include
data capability. Settings are missing
or incorrect. Please contact your
network operator.
67Troubleshooting
See Help in your phone on page 7
or go to
www.sonyericsson.com/support,
choose your phone model, then
choose “Phone setup – MMS” and
follow the instructions on the screen.
See Settings on page 51.
How do I turn on and off T9 text input
when writing a text message?
When you enter text, press and hold
down You will see “T9” at the
top of the text message when T9
is activated.
How do I change phone language?
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
I cannot use the Internet
Your subscription does not include
data capability. Internet settings are
missing or incorrect. Please contact
your network operator.
See Help in your phone on
page 7 or go to
www.sonyericsson.com/support,
choose your phone model, then
choose “Phone setup – WAP” and
follow the instructions on the screen.
See Settings on page 51.
The phone cannot be detected
by other devices using Bluetooth
wireless technology
You have not turned the Bluetooth
function on.
Make sure that the visibility is set to
show phone. See To receive an item
on page 55.
I cannot synchronize or transfer
data between my phone and my
computer, when using the USB cable.
The cable or software that came with
your phone has not been properly
installed. Go to
www.sonyericsson.com/support,
choose your phone model, then
choose Product information - Getting
started. The Synchronizing the phone
with a computer Getting started guide
contains installation instructions and a
troubleshooting guide.
Error messages
Insert SIM
There is no SIM card in your phone
or you may have inserted it incorrectly.
See Charging the battery on page 8.
The SIM card connectors need
cleaning. If the card is damaged,
contact your network operator.
68 Troubleshooting
Insert correct SIM card
Your phone is set to work only with
certain SIM cards. Check if you are
using the correct operator SIM card.
Wrong PIN/Wrong PIN2
You have entered your PIN or PIN2
incorrectly.
Enter the correct PIN or PIN2 and
select Yes. See To insert the SIM card
and battery on page 5.
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2
code incorrectly three times in a row.
To unblock, see SIM card lock on
page 64.
Codes do not match
Codes that you have entered do not
match. When you want to change a
security code, for example your PIN,
you have to confirm the new code.
See SIM card lock on page 64.
No netw. coverage
Your phone is in flight mode. See
Flight mode on page 6.
Your phone is not receiving any radio
signal, or the received signal is too
weak. Contact your network operator
and make sure that the network has
coverage where you are.
The SIM card is not working properly.
Insert your SIM card in another phone.
If this works, it is probably your phone
that is causing the problem. Please
contact the nearest Sony Ericsson
service location.
Emerg. calls only
You are within range of a network,
but you are not allowed to use it.
However, in an emergency, some
network operators allow you to call the
international emergency number 112.
See Emergency calls on page 19.
PUK blocked. Contact operator.
You entered your personal unblocking
key code (PUK) incorrectly 10 times in
a row.
Charging, alien battery
The battery that you are using is not a
Sony Ericsson-approved battery. See
Battery on page 72.
69Important information
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support is a support
section where help and tips are only a few clicks
away. Here you will find the latest computer
software updates and tips on how to use your
product more efficiently.
Service and support
From now on you will have access to a portfolio
of exclusive service advantages such as:
• Global and local Web sites providing support.
• A global network of Call Centers.
• An extensive network of Sony Ericsson service
partners.
• A warranty period. Learn more about the warranty
conditions in this User guide.
On www.sonyericsson.com, under the support
section in the language of your choice, you will find
the latest support tools and information, such as
software updates, Knowledge base, phone setup
and additional help when you require it.
For operator-specific services and features, please
contact your network operator for more
information.
You can also contact our Call Centers. See the
phone number for the nearest Call Center in the list
below. If your country/region is not represented in
the list, please contact your local dealer. (The
phone numbers below were correct at the time of
going to print. On www.sonyericsson.com you can
always find the latest updates.
In the unlikely event that your product needs
service please contact the dealer from whom it
was purchased or one of our service partners. Save
your original proof of purchase, you will need it if
you need to claim warranty.
For a call to one of our Call Centers you will be
charged according to national rates, including local
taxes, unless the phone number is a toll-free
number.
Support
Argentina 800-333-7427 questions.AR@support.sonyericsson.com
Australia 1-300650-600 questions.AU@support.sonyericsson.com
Belgique/België 02-7451611 questions.BE@support.sonyericsson.com
Brasil 4001-04444 questions.BR@support.sonyericsson.com
Canada 1-866-766-9374 questions.CA@support.sonyericsson.com
Central Africa +27 112589023 questions.CF@support.sonyericsson.com
Chile 123-0020-0656 questions.CL@support.sonyericsson.com
Colombia 18009122135 questions.CO@support.sonyericsson.com
Česká republika 844550 055 questions.CZ@support.sonyericsson.com
Danmark 33 31 28 28 questions.DK@support.sonyericsson.com
Deutschland 0180 534 2020 questions.DE@support.sonyericsson.com
ǼȜȜȐįĮ 801-11-810-810
210-89 91 919 questions.GR@support.sonyericsson.com
España 902 180 576 questions.ES@support.sonyericsson.com
France 0 825 383 383 questions.FR@support.sonyericsson.com
70 Important information
Hong Kong/ 8203 8863 questions.HK@support.sonyericsson.com
Hrvatska 062 000 000 questions.HR@support.sonyericsson.com
India/ 39011111 questions.IN@support.sonyericsson.com
Indonesia 021-2701388 questions.ID@support.sonyericsson.com
Ireland 1850 545 888 questions.IE@support.sonyericsson.com
Italia 06 48895206 questions.IT@support.sonyericsson.com
Lietuva 8 70055030 questions.LT@support.sonyericsson.com
Magyarország +36 1 880 4747 questions.HU@support.sonyericsson.com
Malaysia 1-800-889900 questions.MY@support.sonyericsson.com
México 01 800 000 4722 questions.MX@support.sonyericsson.com
Nederland 0900 899 8318 questions.NL@support.sonyericsson.com
New Zealand 0800-100150 questions.NZ@support.sonyericsson.com
Norge 815 00 840 questions.NO@support.sonyericsson.com
Österreich 0810 200245 questions.AT@support.sonyericsson.com
Pakistan 111 22 55 73
(92-21) 111 22 55 73 questions.PK@support.sonyericsson.com
Philippines/Pilipinas 02-6351860 questions.PH@support.sonyericsson.com
Polska 0 (prefiks) 22 6916200 questions.PL@support.sonyericsson.com
Portugal 808 204 466 questions.PT@support.sonyericsson.com
România (+4021) 401 0401 questions.RO@support.sonyericsson.com
Ɋɨɫɫɢɹ 8 (495) 787 0986 questions.RU@support.sonyericsson.com
Schweiz/Suisse/Svizzera 0848 824 040 questions.CH@support.sonyericsson.com
Singapore 67440733 questions.SG@support.sonyericsson.com
Slovensko 02-5443 6443 questions.SK@support.sonyericsson.com
South Africa 0861 6322222 questions.ZA@support.sonyericsson.com
Suomi 09-299 2000 questions.FI@support.sonyericsson.com
Sverige 013-24 45 00 questions.SE@support.sonyericsson.com
Türkiye 0212 47 37 777 questions.TR@support.sonyericsson.com
ɍɤɪɚʀɧɚ (+0380) 44 590 1515 questions.UA@support.sonyericsson.com
United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com
United States 1-866-7669347 questions.US@support.sonyericsson.com
Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com
43 919880 questions.AE@support.sonyericsson.com
4008100000 questions.CN@support.sonyericsson.com
02-25625511 questions.TW@support.sonyericsson.com
02-2483030 questions.TH@support.sonyericsson.com
71Important information
Guidelines for Safe and
Efficient Use
Please read this information before
using your mobile phone.
These instructions are intended for
your safety. Please follow these
guidelines. If the product has been
subject to any of the conditions listed
below or you have any doubt as to its proper
function make sure you have the product checked
by a certified service partner before charging
or using it. Failure to do so might entail a risk of
product malfunction or even a potential hazard
to your health.
Recommendations for safe use of
product (mobile phone, battery,
charger and other accessories)
• Always treat your product with care and keep
it in a clean and dust-free place.
•Warning! May explode if disposed of in fire.
• Do not expose your product to liquid or moisture
or humidity.
• Do not expose your product to
extremely high or low temperatures.
Do not expose the battery to
temperatures above +60°C (+140°F).
• Do not expose your product to open
flames or lit tobacco products.
• Do not drop, throw or try to bend your product.
• Do not paint your product.
• Do not attempt to disassemble or modify your
product. Only Sony Ericsson authorized personnel
should perform service.
• Do not use your product near medical
equipment without requesting
permission from your treating
physician or authorized medical staff.
• Do not use your product when in, or around
aircraft, or areas showing the sign “turn off two-way
radio”.
• Do not use your product in an area
where a potentially explosive
atmosphere exists.
• Do not place your product or install
wireless equipment in the area above
an air bag in your car.
•Caution: Cracked or broken displays may create
sharp edges or splinters that could be harmful upon
contact.
CHILDREN
KEEP OUT OF CHILDRENS REACH.
DO NOT ALLOW CHILDREN TO PLAY
WITH YOUR MOBILE PHONE OR ITS
ACCESSORIES. THEY COULD HURT
THEMSELVES OR OTHERS, OR COULD
ACCIDENTALLY DAMAGE THE MOBILE PHONE
OR ACCESSORY. YOUR MOBILE PHONE OR ITS
ACCESSORY MAY CONTAIN SMALL PARTS THAT
COULD BECOME DETACHED AND CREATE A
CHOKING HAZARD.
Power supply (Charger)
Connect the AC power adapter only to designated
power sources as marked on the product. Make
sure the cord is positioned so that it will not be
subjected to damage or stress. To reduce risk of
electric shock, unplug the unit from any power
source before attempting to clean it. The AC power
adapter must not be used outdoors or in damp
areas. Never alter the cord or plug. If the plug does
not fit into the outlet, have a proper outlet installed
by a qualified electrician.
Use only Sony Ericsson branded original chargers
intended for use with your mobile phone. Other
chargers may not be designed to the same safety
and performance standards.
72 Important information
Battery
We recommend that you fully charge the battery
before you use your mobile phone for the first time.
A new battery or one that has not been used for a
long time could have reduced capacity the first few
times it is used. The battery should only be charged
in temperatures between +5°C (+41°F) and +45°C
(+113°F).
Use only Sony Ericsson branded original batteries
intended for use with your mobile phone. Using
other batteries and chargers could be dangerous.
Talk and standby times depend on several different
conditions such as signal strength, operating
temperature, application usage patterns, features
selected and voice or data transmissions when the
mobile phone is being used.
Turn off your mobile phone before removing the
battery. Do not put the battery into your mouth.
Battery electrolytes may be toxic if swallowed.
Do not let the metal contacts on the battery touch
another metal object. Doing this could short-circuit
and damage the battery. Use the battery for the
intended purpose only.
Personal medical devices
Mobile phones may affect the operation of
pacemakers and other implanted equipment. Please
avoid placing the mobile phone over the pacemaker,
e.g. in your breast pocket. When using the mobile
phone, use it at the ear on the opposite side of the
body to the pacemaker. If a minimum distance of 15
cm (6 inches) is kept between the mobile phone and
the pacemaker, the risk of interference is limited. If
you have any reason to suspect that interference is
taking place, immediately turn off your mobile
phone. Contact your cardiologist for more
information.
For other medical devices, please consult your
physician and the manufacturer of the device.
Driving
Please check if local laws and regulations restrict the
use of mobile phones while driving or require drivers
to use handsfree solutions. We recommend that you
use only Sony Ericsson handsfree solutions
intended for use with your product.
Please note that because of possible interference to
electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles
unless a handsfree kit with an external antenna
has been installed.
Always pay full attention to driving and pull off the
road and park before making or answering a call if
driving conditions so require.
Emergency calls
Mobile phones operate using radio signals, which
cannot guarantee connection in all conditions. You
should therefore never rely solely upon any mobile
phone for essential communications (e.g. medical
emergencies).
Emergency calls may not be possible in all areas,
on all cellular networks, or when certain network
services and/or mobile phone features are in use.
Check with your local service provider.
Antenna
This phone contains a built-in antenna. Use of
antenna devices not marketed by Sony Ericsson
specifically for this model could damage your
mobile phone, reduce performance, and produce
SAR levels above the established limits (see below).
Efficient use
Hold your mobile phone as you would any other
phone. Do not cover the top of the phone when it
is in use, as this affects call quality and may cause
the phone to operate at a higher power level than
needed, thus shortening talk and standby times.
73Important information
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
Your mobile phone is a low-power radio transmitter
and receiver. When it is turned on, it emits low levels
of radio frequency energy (also known as radio
waves or radio frequency fields).
Governments around the world have adopted
comprehensive international safety guidelines,
developed by scientific organizations, e.g. ICNIRP
(International Commission on Non-Ionizing Radiation
Protection) and IEEE (The Institute of Electrical and
Electronics Engineers Inc.), through periodic and
thorough evaluation of scientific studies. These
guidelines establish permitted levels of radio wave
exposure for the general population. The levels
include a safety margin designed to assure the
safety of all persons, regardless of age and health,
and to account for any variations in measurements.
Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency
energy absorbed by the body when using a mobile
phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but
the actual SAR level of the mobile phone while it
is operating can be well below this value. This is
because the mobile phone is designed to use the
minimum power required to reach the network.
Variations in SAR below the radio frequency
exposure guidelines do not mean that there are
variations in safety. While there may be differences
in SAR levels among mobile phones, all
Sony Ericsson mobile phone models are designed
to meet radio frequency exposure guidelines.
For phones sold in the US, before a phone model
is available for sale to the public, it must be tested
and certified by the Federal Communications
Commission (FCC) that it does not exceed the
limit established by the government-adopted
requirement for safe exposure. The tests are
performed in positions and locations (that is, at the
ear and worn on the body) as required by the FCC
for each model. For body-worn operation,
this phone has been tested and meets FCC RF
exposure guidelines when the handset is positioned
a minimum of 15 mm from the body without any
metal parts in the vicinity of the phone or when used
with the original Sony Ericsson accessory intended
for this phone and worn on the body. Use of other
accessories may not ensure compliance with FCC
RF exposure guidelines.
A separate leaflet with SAR information about this
mobile phone model is included with the material
accompanying this mobile phone. This information
can also be found, together with more information
on radio frequency exposure and SAR, on:
www.sonyericsson.com/health.
Accessible Solutions/Special Needs
For phones sold in the US, you can use your TTY
terminal with your Sony Ericsson mobile phone
(with the necessary accessory). For information on
Accessible Solutions for individuals with special
needs call the Sony Ericsson Special Needs Center
on 877 878 1996 (TTY) or 877 207 2056 (voice), or
visit the Sony Ericsson Special Needs Center at
www.sonyericsson-snc.com.
Disposal of old electrical
and electronic equipment
This symbol indicates that all electrical
and electronic equipment included
shall not be treated as household
waste. Instead it shall be left at the appropriate
collection point for recycling of electrical and
electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and
human health, which could otherwise be caused
by inappropriate waste handling of this product. The
recycling of materials will help to conserve natural
resources. For more detailed information about
74 Important information
recycling this product, please contact your local
city office, your household waste disposal service
or the shop where you purchased the product.
Disposing of the battery
Please check local regulations for
disposal of batteries or call your local
Sony Ericsson Call Center for
information.
The battery should never be placed in municipal
waste. Use a battery disposal facility if available.
Memory card
Your product comes complete with a removable
memory card. It is generally compatible with the
handset purchased but may not be compatible with
other devices or the capabilities of their memory
cards. Check other devices for compatibility before
purchase or use.
The memory card is formatted prior to shipping.
To reformat the memory card, use a compatible
device. Do not use the standard operating system
format when formatting the memory card on a PC.
For details, refer to the operating instructions of the
device or contact customer support.
WARNING:
If your device requires an adapter for insertion into
the handset or another device, do not insert the
card directly without the required adapter.
Precautions on Memory Card Use
• Do not expose the memory card to moisture.
• Do not touch terminal connections with your hand
or any metal object.
• Do not strike, bend, or drop the memory card.
• Do not attempt to disassemble or modify the
memory card.
• Do not use or store the memory card in humid or
corrosive locations or in excessive heat such as
a closed car in summer, in direct sunlight or near
a heater, etc.
• Do not press or bend the end of the memory card
adapter with excessive force.
• Do not let dirt, dust, or foreign objects get into
the insert port of any memory card adapter.
• Check you have inserted the memory card
correctly.
• Insert the memory card as far as it will go into any
memory card adapter needed. The memory card
may not operate properly unless fully inserted.
• We recommend that you make a backup copy of
important data. We are not responsible for any loss
or damage to content you store on the memory
card.
• Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
turn off the power while formatting, reading or
writing data, or use the memory card in locations
subject to static electricity or high electrical field
emissions.
Protection of personal information
To safeguard your privacy and prevent information
being accessible to a third party, you should erase
all personal data before selling or disposing of the
product. To delete personal data, perform a master
reset and remove the memory card. DELETION OF
MATERIAL FROM THE PHONE MEMORY DOES
NOT ENSURE THAT SAID INFORMATION
CANNOT BE RECOVERED BY A SUBSEQUENT
USER. SONY ERICSSON DOES NOT WARRANT
AGAINST A SUBSEQUENT USER OF THE DEVICE
ACCESSING YOUR INFORMATION AND DOES
NOT ASSUME ANY RESPONSIBILITY FOR
SUBSEQUENT DISCLOSURE OF SAID
INFORMATION EVEN IF A MASTER RESET HAS
BEEN PERFORMED. If you are concerned about
such potential disclosure retain your device or
secure its permanent destruction.
75Important information
Accessories
Sony Ericsson recommends use of Sony Ericsson
original accessories for safe and efficient use of
its products. Use of third-party accessories may
decrease performance or pose a risk to your health
or safety.
LOUDNESS WARNING:
Please adjust the audio volume cautiously
when using third-party audio accessories to avoid
volume levels that may be harmful to your hearing.
Sony Ericsson does not test use of third-party audio
accessories with this mobile phone. Sony Ericsson
recommends using only Sony Ericsson original
audio accessories.
End User Licence Agreement
This wireless device, including without limitation
any media delivered with the device, (“Device”)
contains software owned by Sony Ericsson Mobile
Communications AB and its affiliated companies
(“Sony Ericsson”) and its third party suppliers and
licensors (“Software”).
As user of this Device, Sony Ericsson grants you
a non-exclusive, non-transferable, non-assignable
license to use the Software solely in conjunction
with the Device on which it is installed and/or
delivered with. Nothing herein shall be construed
as a sale of the Software to a user of this Device.
You shall not reproduce, modify, distribute, reverse
engineer, decompile, otherwise alter or use any
other means to discover the source code of the
Software or any component of the Software. For
avoidance of doubt, you are at all times entitled
to transfer all rights and obligations to the Software
to a third party, solely together with the Device with
which you received the Software, provided always
that such third party agrees in writing to be bound
by these rules.
You are granted this license for a term of the useful
life of this Device. You can terminate this license by
transferring all your rights to the Device on which
you have received the Software to a third party in
writing. If you fail to comply with any of the terms
and conditions set out in this license, it will
terminate with immediate effect.
Sony Ericsson and its third party suppliers and
licensors are the sole and exclusive owner of
and retain all rights, title and interest in and to the
Software. Sony Ericsson, and, to the extent that the
Software contains material or code of a third party,
such third party, shall be entitled third party
beneficiaries of these terms.
The validity, construction and performance of this
license shall be governed by the laws of Sweden.
The foregoing shall apply to the full extent
permitted by, when applicable, statutory consumer
rights.
Limited Warranty
Sony Ericsson Mobile Communications AB, SE-221
88 Lund, Sweden, (Sony Ericsson) or its local
affiliated company, provides this Limited Warranty
for your mobile phone and original accessory
delivered with your mobile phone (hereinafter
referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Center
(national rates may apply) or visit
www.sonyericsson.com to get further information.
Our warranty
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free from
defects in design, material and workmanship at the
time of its original purchase by a consumer. This
Limited Warranty will last for a period of two (2)
years as from the original date of purchase of the
Product for your mobile phone, and for a period of
76 Important information
one (1) year following the original purchase date of
the Product for all original accessories (such as the
battery, charger or handsfree kit) which may be
delivered with your mobile phone.
What we will do
If, during the warranty period, this Product fails
to operate under normal use and service, due
to defects in design, materials or workmanship,
Sony Ericsson authorized distributors or service
partners, in the country/region* where you
purchased the Product, will, at their option, either
repair or replace the Product in accordance with
the terms and conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented by
applicable law, other regulations or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss.
You should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair or
replacement.
Conditions
1 This Limited Warranty is valid only if the original
proof of purchase for this Product issued by a
Sony Ericsson authorized dealer specifying the date
of purchase and serial number**, is presented with
the Product to be repaired or replaced. Sony Ericsson
reserves the right to refuse warranty service if this
information has been removed or changed after the
original purchase of the Product from the dealer.
2 If Sony Ericsson repairs or replaces the Product,
the repair for the defect concerned, or the replaced
Product shall be warranted for the remaining time
of the original warranty period or for ninety (90)
days from the date of repair, whichever is longer.
Repair or replacement may involve the use of
functionally equivalent reconditioned units.
Replaced parts or components will become
the property of Sony Ericsson.
3 This warranty does not cover any failure of the
Product due to normal tear and wear, or due to
misuse, including but not limited to use in other
than the normal and customary manner, in
accordance with the Sony Ericsson instructions for
use and maintenance of the Product. Nor does this
warranty cover any failure of the Product due to
accident, software or hardware modification or
adjustment, acts of God or damage resulting from
liquid.
A rechargeable battery can be charged and
discharged more than a hundred times. However,
it will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the
talk time or standby time is noticeably shorter, it
is time to replace your battery. Sony Ericsson
recommends that you use only batteries and
chargers approved by Sony Ericsson.
Minor variations in display brightness and color
may occur between the phones. There may be
small, bright or dark dots on the display. These are
called defective pixels and occur when individual
dots have malfunctioned and cannot be adjusted.
Two defective pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between phones. This is not uncommon and
is not regarded as a defective camera module.
77Important information
4 Since the cellular system on which the Product
is to operate is provided by a carrier independent
from Sony Ericsson, Sony Ericsson will not be
responsible for the operation, availability, coverage,
services or range of that system.
5 This warranty does not cover Product failures
caused by installations, modifications, or repair
or opening of the Product performed by a non-
Sony Ericsson authorised person.
6 The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
Sony Ericsson disclaims any and all warranties,
whether express or implied, for failures caused
to the Product or peripheral devices as a result of
viruses, trojans horses, spyware, or other malicious
software. Sony Ericsson strongly recommends that
you install appropriate virus protection software
on your Product and any peripheral devices
connected to it, as available, and update it
regularly, to better protect your device. It is
understood, however, that such software will never
fully protect your Product or its peripheral devices
and Sony Ericsson disclaims all warranties,
whether express or implied, in case of failure
by such antivirus software to fulfill its intended
purpose.
7 Tampering with any of the seals on the Product will
void the warranty.
8 THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY. ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. IN
NO EVENT SHALL SONY ERICSSON OR ITS
LICENSORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE
WHATSOEVER, INCLUDING BUT NOT LIMITED
TO LOST PROFITS OR COMMERCIAL LOSS; TO
THE FULL EXTENT THOSE DAMAGES CAN BE
DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion
or limitation of incidental or consequential
damages, or limitation of the duration of implied
warranties, so the preceding limitations or
exclusions may not apply to you.
The warranty provided does not affect the
consumer’s statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
* GEOGRAPHICAL SCOPE OF THE
WARRANTY
If you have purchased your Product in a country
member of the European Economic Area (EEA) or in
Switzerland or the Republic of Turkey, and such
Product was intended for sale in the EEA or in
Switzerland or in Turkey, you can have your Product
serviced in any EEA country or in Switzerland or in
Turkey, under the warranty conditions prevailing in
the country in which you require servicing of the
Product, provided that an identical Product is sold
in such country by an authorised Sony Ericsson
distributor. To find out if your Product is sold in
the country you are in, please call the local
Sony Ericsson Call Center. Please observe that
certain services may not be possible elsewhere than
in the country of original purchase due, for example,
to the fact that your Product may have an interior or
exterior which is different from equivalent models
sold in other countries. In addition, please note that
it may sometimes not be possible to repair SIM-
locked Products.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
78 Important information
FCC Statement
This device complies with Part 15
of the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause
harmful interference, and (2) This
device must accept any interference received,
including interference that may cause undesired
operation.
Declaration of Conformity for
K770i
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our
product
Sony Ericsson type AAD-3022082-BV
and in combination with our accessories, to which
this declaration relates is in conformity with the
appropriate standards 3GPP TS 51.010-1,
EN 301908-1, EN 301489-7, EN 301489-24,
EN 300328, EN 301489-17 and EN 60950,
following the provisions of, Radio Equipment and
Telecommunication Terminal Equipment directive
99/5/EC with requirements covering EMC directive
89/336/EEC, and Low Voltage directive 73/23/EEC.
We fulfil the requirements of the R&TTE Directive
(99/5/EC).
Lund, July 2007
Shoji Nemoto,
Head of Product Business Group GSM/UMTS
79Index
Index
A
activity menu ........................................ 15
alarms ................................................... 59
answering service ................................ 23
applications .......................................... 50
appointments ....................................... 59
assembly ................................................ 5
automatic redialling .............................. 18
B
battery
charging ......................................... 8
inserting ......................................... 5
use and care ................................ 72
Bluetooth™ wireless technology ......... 54
business cards ..................................... 29
buttons ............................................. 9, 13
C
calculator .............................................. 62
calendar ......................................... 59, 60
call divert .............................................. 25
call list .................................................. 23
call numbers in message ..................... 30
call time ................................................ 29
caller-specific ringtones ....................... 21
calls
accepting ..................................... 27
answering ................................. 7, 19
handling two calls ........................ 26
international ................................. 18
making ..................................... 7, 18
putting on hold ............................. 26
recording ...................................... 49
rejecting ................................... 7, 19
video ............................................ 20
camera
overview ....................................... 38
settings ......................................... 39
code memo .......................................... 62
conference calls ................................... 27
contacts
adding phone contacts ................ 20
default contacts ........................... 20
groups of ...................................... 22
synchronizing ............................... 53
D
date ...................................................... 64
declaration of conformity ..................... 78
Disc2Phone .......................................... 43
downloading files ................................. 52
80 Index
E
email ..................................................... 33
entering text
multitap ........................................ 17
T9™ Text Input ............................ 17
F
file manager ......................................... 15
fixed dialling ......................................... 28
G
games .................................................. 49
groups .................................................. 22
H
handsfree ....................................... 24, 42
Bluetooth technology ................... 55
help ........................................................ 7
I
IMEI number ......................................... 65
Internet
bookmarks ................................... 51
profiles ......................................... 52
security and certificates ............... 52
settings ........................................ 51
J
Java™ .................................................. 50
K
keypad lock ...........................................65
keys ...................................................9, 13
L
Limited Warranty ...................................75
lock
keypad ..........................................65
phone ............................................64
SIM card .......................................64
M
magic word ...........................................24
master reset ..........................................66
memory card .........................................15
memory status ......................................22
menu overview ........................................9
menus ...................................................13
messages
area and cell information ..............37
email .............................................33
voice .............................................33
microphone ...........................................19
music
transferring ....................................43
video files ......................................42
music player ..........................................42
MusicDJ™ ............................................48
My friends .............................................36
my numbers ..........................................27
81Index
N
navigating menus ................................. 13
notes .............................................. 61, 62
P
phone
language ...................................... 17
lock ............................................... 64
PhotoDJ™ ............................................ 41
pictures ................................................ 41
edit ............................................... 41
PIN code
changing ...................................... 64
unblocking ...................................... 6
playlists .......................................... 44, 45
PlayNow™ ............................................ 47
profiles .................................................. 63
PUK .................................................. 6, 64
push email ............................................ 36
R
ringtones .............................................. 47
RSS reader ........................................... 53
S
safety guidelines .................................. 71
sending
appointments and tasks .............. 60
business cards ............................. 29
melodies and ringtones ................ 48
music ............................................ 43
notes ............................................ 62
pictures ........................................ 41
settings
Internet ......................................... 51
Java™ .......................................... 50
shortcuts .............................................. 14
SIM card
copying from ................................ 21
copying to .................................... 21
lock and unblock .......................... 64
sound recorder ..................................... 49
sound, transferring and directing ......... 55
speed dialling ....................................... 23
standby .................................................. 7
start-up screen ....................................... 7
stopwatch ............................................ 62
submenus ............................................. 13
synchronizing ................................. 53, 54
T
T9™ Text Input .................................... 17
tasks ..................................................... 61
templates ............................................. 32
text ....................................................... 17
themes ................................................. 42
time ...................................................... 64
timer ..................................................... 62
TrackID™ ............................................. 45
82 Index
transfer method
Bluetooth technology ................... 54
USB .............................................. 56
transferring
camera pictures ........................... 39
files ............................................... 56
music ........................................... 43
turning on/off
Bluetooth ..................................... 54
phone lock ................................... 65
SIM lock protection ...................... 64
U
unblock SIM card ................................. 64
V
video player ...........................................42
video recorder .......................................38
VideoDJ™ .............................................48
voice answering ....................................25
voice control .........................................24
voice messages ....................................33
voicemail ...............................................23
volume
ear speaker ...................................19
ringtone .........................................47
Z
zoom .....................................................39
