08 user guide part 3
54 Connectivity
To disconnect the USB cable safely
1Right-click the removable disk icon i
n Windows Explorer.
2Select Eject.
3Disconnect the USB cable when the
following message is shown in the
phone: Mass storage session ended. It
is now safe to remove the USB cable.
Phone mode
Before synchronizing or using your
phone as a modem you must install
the Sony Ericsson PC Suite software
on your computer. See To install the
Sony Ericsson PC Suite on page 55.
To use phone mode
1Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
2Connect the USB cable to the phone
and the computer.
3Phone: Select Phone mode > Menu >
Settings > the Connectivity tab > USB >
USB mode > Phone mode.
4Computer: When you are notified that
the Sony Ericsson PC Suite has found
your phone, you can start using the
phone mode applications.
Synchronizing
You can use the USB cable or Bluetooth
wireless technology to synchronize
phone contacts, appointments,
bookmarks, tasks and notes with a
computer program such as Microsoft
Outlook. You can also synchronize
with an Internet service using SyncML
or a Microsoft® Exchange Server using
Exchange ActiveSync. For more
information go to the Getting started
section at
www.sonyericsson.com/support.
Synchronization using a computer
Before synchronizing you need to
install the Sony Ericsson PC Suite from
the CD included with your phone.
The software includes help information.
You can also go to
www.sonyericsson.com/support
to download the software.
You need one of these operating
systems to use the PC Suite on
your computer:
•Windows XP (Pro and Home)
For usage details, see the Sony Ericsson
PC Suite Help section once the software
has been installed on your computer.
Use only one of the synchronization
methods at a time with your phone.
Sofia_UG_P1C_EN.book Page 54 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
55Connectivity
•Windows Vista (32 bit and 64 bit
versions of: Ultimate, Enterprise,
Business, Home Premium, Home
Basic)
To install the Sony Ericsson PC Suite
1Turn on your computer and insert the
CD. The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson PC suite and
follow the instructions on the screen.
Synchronization using an Internet
service
You can synchronize online using
an Internet service with your phone.
If Internet settings are not in your phone,
see Settings on page 49.
Before you start to synchronize
You must enter settings for SyncML
synchronization and register a
synchronization account online with
a service provider. Settings that are
required are:
•Server address – server URL
•Database name – database to
synchronize with
To enter settings for SyncML
1From standby select Menu > Organizer
> Synchronization.
2Scroll to New account and select Add
> SyncML.
3Enter a name for the new account and
select Cont..
4Scroll to Server address. Enter the
required information and select OK.
5Enter Username and Password,
if required.
6Scroll to the Applications tab to mark
which applications you would like
to synchronize.
7Scroll to the App. settings tab and
select an application.
8Select Database name and enter
the required information.
9Scroll to the Advanced tab to enter
additional settings for synchronizing.
10 Select Save.
To delete an account
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select
Options > Delete.
To start synchronization
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Sofia_UG_P1C_EN.book Page 55 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
56 Connectivity
Synchronization using a Microsoft®
Exchange Server
You can access and synchronize
corporate exchange information such
as email, contacts and calendar entries
with a Microsoft® Exchange Server
using your phone.
Before you start to synchronize
You must enter settings for Exchange
ActiveSync to access a Microsoft
Exchange Server. Settings that are
required are:
•Server address – server URL
•Domain – server domain
•Username – account username
•Password – account password
To enter settings for Exchange
ActiveSync
1From standby select Menu > Organizer
> Synchronization > ActiveSync.
2Enter a name for the new account and
select Cont..
3Enter the required settings.
4Scroll between the tabs to enter
additional settings.
5Select Save.
To start synchronization
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Update service
You can update your phone with the
latest software. You do not lose
personal or phone information.
There are two ways to update your
phone:
•Over the air using your phone
•Using the provided USB cable and
an Internet-connected computer
Before you use the Update service
If settings are not in your phone see
Settings on page 49.
To view the current software in the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Software version.
For more information on synchronization
settings, contact your IT administrator.
Update service requires data access
such as GPRS, 3G or HSDPA.
Sofia_UG_P1C_EN.book Page 56 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
57More features
To use Update service using the phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Search for update and follow
the instructions that appear.
To use Update service using a USB
cable
1Go to www.sonyericsson.com/support
or click the Sony Ericsson Update
service in the PC Suite software if
installed on your computer. See
To install the Sony Ericsson PC Suite
on page 55.
2Select a region and country.
3Follow the instructions on the screen.
To set a reminder to use Update
service
1From standby select Menu > Settings
> the General tab > Update service >
Settings > Reminder.
2Select an option.
More features
Alarms
You can set a sound or the radio as an
alarm signal. The alarm sounds even if
the phone is turned off. When the alarm
sounds you can silence it for 9 minutes
or turn it off.
To set the alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Time: and select Edit.
4Enter a time and select OK > Save.
To set the recurrent alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Recurrent: and select Edit.
4Scroll to a day and select Mark.
5To select another day, scroll to the
day and select Mark.
6Select Done > Save.
To set the alarm signal
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Alarm signal: and select Edit.
4Find and select an alarm signal. Select
Save.
Sofia_UG_P1C_EN.book Page 57 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
58 More features
To silence the alarm
•When the alarm sounds, press any key.
•To repeat the alarm, select Snooze.
To turn off an alarm
•When the alarm sounds, select Turn off.
To cancel the alarm
1From standby select Menu > Alarms.
2Scroll to an alarm and select Turn off.
The alarm in silent mode
You can set the alarm not to sound
when the phone is in silent mode.
To set an alarm to sound or not
in silent mode
1From standby select Menu > Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Silent mode and select Edit.
5Select an option.
Calendar
The calendar can be synchronized with
a computer calendar, with a calendar
on the Web or with a Microsoft®
Exchange Server (Microsoft®
Outlook®). For more information
see Synchronizing on page 54.
Default view
You can choose whether month, week
or day view will appear first when you
open the calendar.
To set default view
1From standby select Menu > Organizer
> Calendar.
2Select Options > Advanced > Default
view.
3Select an option.
Appointments
You can add new appointments
or reuse existing appointments.
To add an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to New appointment and select
Add.
4Enter the information and confirm
each entry.
5Select Save.
To view an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
Sofia_UG_P1C_EN.book Page 58 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
59More features
To edit an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
4Select Options > Edit.
5Edit the appointment and confirm
each entry.
6Select Save.
To send an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
Options > Send.
4Select a transfer method.
To view a calendar week
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select Options > View week.
To set when reminders should sound
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select Options > Advanced > Reminders.
4Select an option.
Tasks
You can add new tasks or reuse
existing tasks.
To add a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to New task and select Add.
3Select an option.
4Enter details and confirm each entry.
To view a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
To reuse an existing task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
3Select Options > Edit.
4Edit the task and select Cont.
5Choose to set a reminder.
Make sure the receiving device supports
the transfer method you select.
A reminders option set in calendar
affects a reminders option set in tasks.
Sofia_UG_P1C_EN.book Page 59 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
60 More features
To send a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select Options >
Send.
3Select a transfer method.
To set when reminders should sound
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select Options >
Reminders.
3Select an option.
Notes
You can make notes and save them.
You can also show a note in standby.
To add a note
1From standby select Menu > Organizer
> Notes.
2Scroll to New note and select Add.
3Write a note and select Save.
To show a note in standby
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select Options >
Show in standby.
To send a note
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select Options >
Send.
3Select a transfer method.
To use an item in a note
1When you view the note, select a phone
number, email or Web address.
2Select Options > Use.
3Select an option.
Timer, stopwatch and
calculator
To use the timer
1From standby select Menu > Organizer
> Timer.
2Enter the hours, minutes and seconds.
3Select Start.
Make sure the receiving device supports
the transfer method you select.
A reminders option set in tasks affects
a reminders option set in calendar.
Make sure the receiving device supports
the transfer method you select.
Sofia_UG_P1C_EN.book Page 60 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
61More features
To use the stopwatch
1From standby select Menu > Organizer
> Stopwatch > Start.
2To view a new lap time, select Lap.
To use the calculator
1From standby select Menu > Organizer
> Calculator.
2Press or to select ÷ x - + . % =.
Code memo
You can save security codes, for
example, for credit cards. You must
set a passcode to open the code memo.
Checkword
The checkword confirms that you have
entered the correct passcode. If the
passcode is correct, the correct codes
are shown. If the passcode is incorrect,
the checkword and the codes shown
are also incorrect.
To open code memo for the first time
1From standby select Menu > Organizer
> Code memo.
2Follow the instructions that appear
and select Cont.
3Enter a passcode and select Cont.
4Confirm the passcode and select
Cont..
5Enter a checkword and select Done.
To add a code
1From standby select Menu > Organizer
> Code memo.
2Enter a passcode and select Cont.
3Scroll to New code and select Add.
4Enter a name associated with the
code and select Cont..
5Enter the code and select Done.
To change a passcode
1From standby select Menu > Organizer
> Code memo.
2Enter your passcode and select
Options > Change passcode.
3Enter your new passcode and select
Cont..
4Re-enter the new passcode and select
Cont.
5Enter a checkword and select Done.
Forget your passcode?
If you forget your passcode, you must
reset the code memo. This means that
all entries in the code memo are deleted.
The next time you enter the code memo,
you must proceed as if you are opening
it for the first time. See To open code
memo for the first time on page 61.
Sofia_UG_P1C_EN.book Page 61 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
62 More features
To reset code memo
1From standby select Menu > Organizer
> Code memo.
2Enter any passcode to access the
code memo. The checkword and
codes that are then shown are
incorrect.
3Select Options > Reset.
4Reset code memo? appears.
5Select Yes.
Profiles
Profiles automatically adapt some
phone settings to different situations,
for example, the ring volume may
be adapted to suit a meeting or an
accessory. You can reset all profiles
to how they were set when you
purchased your phone.
To select a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Select a profile.
To view and edit a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Scroll to a profile and select Options >
View and edit.
To reset all profiles
1From standby select Menu > Settings
> the General tab > Profiles.
2Select Options > Reset profiles.
Time and date
To set the time
1From standby select Menu > Settings >
the General tab > Time & date > Time.
2Enter the time and select Save.
To set the date
1From standby select Menu > Settings
> the General tab > Time & date > Date.
2Enter the date and select Save.
To set the time zone
1From standby select Menu > Settings
> the General tab > Time & date >
My time zone.
2Select the time zone you are in by city.
Locks
SIM card lock
This lock only protects your
subscription. Your phone will work with
a new SIM card. If the lock is on, you
have to enter a PIN (Personal Identity
Number).
You cannot rename the Normal profile.
If you select a city, My time zone also
updates the time when daylight saving
time changes.
Sofia_UG_P1C_EN.book Page 62 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
63More features
If you enter your PIN incorrectly three
times in a row, the SIM card is blocked
and you need to enter your PUK
(Personal Unblocking Key). Your PIN
and PUK are supplied by your network
operator.
To unblock the SIM card
1When PIN blocked appears, enter your
PUK and select OK.
2Enter a new four- to eight-digit PIN
and select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1From standby select Menu > Settings
> the General tab > Security > Locks >
SIM protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four- to eight-digit PIN
and select OK.
4Re-enter the new PIN and select OK.
To use the SIM card lock
1From standby select Menu > Settings >
the General tab > Security > Locks >
SIM protection > Protection.
2Select an option.
3Enter your PIN and select OK.
Phone lock
You can stop unauthorized use of your
phone. Change the phone lock code
(0000) to any four- to eight-digit
personal code.
To use the phone lock
1From standby select Menu > Settings >
the General tab > Security > Locks >
Phone protection > Protection.
2Select an option.
3Enter the phone lock code and select
OK.
To change the phone lock code
1From standby select Menu > Settings >
the General tab > Security > Locks >
Phone protection > Change code.
2Enter the old code and select OK.
3Enter the new code and select OK.
4Repeat the code and select OK.
If Codes do not match appears, you
entered the new PIN incorrectly.
If Wrong PIN appears, followed by
Old PIN:, you entered your old PIN
incorrectly.
It is important that you remember your
new code. If you forget it, you have
to take your phone to your local
Sony Ericsson retailer.
Sofia_UG_P1C_EN.book Page 63 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
64 Troubleshooting
Keypad lock
You can set this lock to avoid accidental
dialling. Incoming calls can be answered
without unlocking the keypad.
To use the automatic keylock
1From standby select Menu > Settings >
the General tab > Security > Automatic
keylock.
2Select an option.
To lock the keypad manually
•From standby press and select
Lock.
To unlock the keypad manually
•From standby press and select
Unlock.
IMEI number
Keep a copy of your IMEI (International
Mobile Equipment Identity) number in
case your phone is stolen.
To view your IMEI number
•From standby press , , ,
, .
Troubleshooting
Some problems will require you to call
your network operator.
For more support go to
www.sonyericsson.com/support.
Common questions
I have problems with memory
capacity or the phone is working
slowly
Restart your phone every day to free
memory or do a Master reset.
Master reset
If you select Reset settings, the changes
that you have made to settings will be
deleted.
If you select Reset all, in addition to
your changes to settings, all contacts,
messages, personal data, and content
that you have downloaded, received
or edited will also be deleted.
To reset the phone
1From standby select Menu > Settings
> the General tab > Master reset.
2Select an option.
3Follow the instructions that appear.
Calls to the international emergency
number 112 can still be made.
Sofia_UG_P1C_EN.book Page 64 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
65Troubleshooting
I cannot charge the phone or battery
capacity is low
The charger is not properly connected
or the battery connection is poor.
Remove the battery and clean the
connectors.
The battery is worn out and needs to
be replaced. See Charging the battery
on page 7.
No battery icon appears when I start
charging the phone
It may take a few minutes before the
battery icon appears on the screen.
Some menu options appear in grey
A service is not activated. Contact
your network operator.
I cannot use SMS/text messages
on my phone
Settings are missing or incorrect.
Contact your network operator to find
out the correct SMS service centre
setting. See Text messages on page
28.
I cannot use picture messages
on my phone
Your subscription does not include
data capability. Settings are missing
or incorrect. Please contact your
network operator.
See Help in your phone on page 7
or go to www.sonyericsson.com/
support to order settings and follow
the instructions on the screen. See
Settings on page 49.
How do I turn on and off T9 Text
Input when writing?
When you enter text, press and hold
down . You will see at the top
of the screen when T9 Text Input is
activated.
How do I change phone language?
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
I cannot use the Internet
Your subscription does not include
data capability. Internet settings are
missing or incorrect. Please contact
your network operator.
See Help in your phone on page 7 or
go to www.sonyericsson.com/support
to order Internet settings, and follow
the instructions on the screen. See
Settings on page 49.
Sofia_UG_P1C_EN.book Page 65 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
66 Troubleshooting
The phone cannot be detected
by other devices using Bluetooth
wireless technology
You have not turned the Bluetooth
function on.
Make sure that the visibility is set to
show phone. See To receive an item
on page 52.
I cannot synchronize or transfer data
between my phone and my computer,
when using the USB cable.
The cable or software that came with
your phone has not been properly
installed. Go to
www.sonyericsson.com/support to
read Getting started guides which
contain detailed installation instructions
and troubleshooting guides.
Where can I find the regulatory
information such as my IMEI number
if I can’t turn on my phone?
Error messages
Insert SIM
There is no SIM card in your phone or
you may have inserted it incorrectly.
See Charging the battery on page 7.
The SIM card connectors need
cleaning. If the card is damaged,
contact your network operator.
Insert correct SIM card
Your phone is set to work only with
certain SIM cards. Check if you are
using the correct operator SIM card.
Wrong PIN/Wrong PIN2
You have entered your PIN or PIN2
incorrectly.
Sofia_UG_P1C_EN.book Page 66 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
67Troubleshooting
Enter the correct PIN or PIN2 and
select Yes. See To insert the SIM card
on page 5.
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2
code incorrectly three times in a row.
To unblock, see SIM card lock on
page 62.
Codes do not match
Codes that you have entered do not
match. When you want to change a
security code, for example your PIN,
you have to confirm the new code.
See SIM card lock on page 62.
No netw. coverage
Your phone is in flight mode. See
Flight mode on page 6.
Your phone is not receiving any
network signal, or the received signal
is too weak. Contact your network
operator and make sure that the
network has coverage where you are.
The SIM card is not working properly.
Insert your SIM card in another phone.
If this works, it is probably your phone
that is causing the problem. Please
contact the nearest Sony Ericsson
service location.
Emerg. calls only
You are within range of a network, but
you are not allowed to use it. However,
in an emergency, some network
operators allow you to call the
international emergency number 112.
See Emergency calls on page 17.
PUK blocked. Contact operator.
You entered your personal unblocking
key code (PUK) incorrectly 10 times
in a row.
Charging, alien battery
The battery that you are using is not a
Sony Ericsson-approved battery. See
Battery on page 71.
Sofia_UG_P1C_EN.book Page 67 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
68 Important information
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support is a support
section where help and tips are only a few clicks
away. Here you will find the latest computer
software updates and tips on how to use your
product more efficiently.
Service and support
From now on you will have access to a portfolio
of exclusive service advantages such as:
• Global and local Web sites providing support.
• A global network of Call Centers.
• An extensive network of Sony Ericsson service
partners.
• A warranty period. Learn more about the warranty
conditions in this User guide.
On www.sonyericsson.com, under the support
section in the language of your choice, you will
find the latest support tools and information, such
as software updates, Knowledge base, phone
setup and additional help when you require it.
For operator-specific services and features, please
contact your network operator for more information.
You can also contact our Call Centers. See the phone
number for the nearest Call Center in the list below.
If your country/region is not represented in the list,
please contact your local dealer. (The phone numbers
below were correct at the time of going to print.
On www.sonyericsson.com you can always find the
latest updates.
In the unlikely event that your product needs service
please contact the dealer from whom it was
purchased or one of our service partners. Save
your original proof of purchase, you will need
it if you need to claim warranty.
For a call to one of our Call Centers you will be
charged according to national rates, including local
taxes, unless the phone number is a toll-free number.
Country Phone number Email address
Argentina 800-333-7427 questions.AR@support.sonyericsson.com
Australia 1-300 650 050 questions.AU@support.sonyericsson.com
Austria 0810 200245 questions.AT@support.sonyericsson.com
Belgium 02-7451611 questions.BE@support.sonyericsson.com
Brazil 4001-0444 questions.BR@support.sonyericsson.com
Canada 1-866-766-9374 questions.CA@support.sonyericsson.com
Central Africa +27 112589023 questions.CF@support.sonyericsson.com
Chile 123-0020-0656 questions.CL@support.sonyericsson.com
China 4008100000 questions.CN@support.sonyericsson.com
Colombia 18009122135 questions.CO@support.sonyericsson.com
Croatia 062 000 000 questions.HR@support.sonyericsson.com
Czech Republic 844 550 055 questions.CZ@support.sonyericsson.com
Denmark 33 31 28 28 questions.DK@support.sonyericsson.com
Finland 09-299 2000 questions.FI@support.sonyericsson.com
France 0 825 383 383 questions.FR@support.sonyericsson.com
Germany 0180 534 2020 questions.DE@support.sonyericsson.com
Sofia_UG_P1C_EN.book Page 68 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
69Important information
Greece 801-11-810-810
210-89 91 919 (from mobile) questions.GR@support.sonyericsson.com
Hong Kong 8203 8863 questions.HK@support.sonyericsson.com
Hungary +36 1 880 4747 questions.HU@support.sonyericsson.com
India 39011111
(Add STD code when dialling
from a GSM connection) questions.IN@support.sonyericsson.com
Indonesia 021-2701388 questions.ID@support.sonyericsson.com
Ireland 1850 545 888 questions.IE@support.sonyericsson.com
Italy 06 48895206 questions.IT@support.sonyericsson.com
Lithuania 8 700 55030 questions.LT@support.sonyericsson.com
Malaysia 1-800-889900 questions.MY@support.sonyericsson.com
Mexico 01 800 000 4722 questions.MX@support.sonyericsson.com
Netherlands 0900 899 8318 questions.NL@support.sonyericsson.com
New Zealand 0800-100150 questions.NZ@support.sonyericsson.com
Norway 815 00 840 questions.NO@support.sonyericsson.com
Pakistan 111 22 55 73
Outside Karachi:
(92-21) 111 22 55 73 questions.PK@support.sonyericsson.com
Philippines 02-6351860 questions.PH@support.sonyericsson.com
Poland 0 (prefix) 22 6916200 questions.PL@support.sonyericsson.com
Portugal 808 204 466 questions.PT@support.sonyericsson.com
Romania (+4021) 401 0401 questions.RO@support.sonyericsson.com
Russia 8(495) 787 0986 questions.RU@support.sonyericsson.com
Singapore 67440733 questions.SG@support.sonyericsson.com
Slovakia 02-5443 6443 questions.SK@support.sonyericsson.com
South Africa 0861 632222 questions.ZA@support.sonyericsson.com
Spain 902 180 576 questions.ES@support.sonyericsson.com
Sweden 013-24 45 00 questions.SE@support.sonyericsson.com
Switzerland 0848 824 040 questions.CH@support.sonyericsson.com
Taiwan 02-25625511 questions.TW@support.sonyericsson.com
Thailand 02-2483030 questions.TH@support.sonyericsson.com
Turkey 0212 47 37 777 questions.TR@support.sonyericsson.com
Ukraine (+380) 44 590 1515 questions.UA@support.sonyericsson.com
United Arab Emirates 43 919880 questions.AE@support.sonyericsson.com
United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com
United States 1-866-766-9374 questions.US@support.sonyericsson.com
Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com
Sofia_UG_P1C_EN.book Page 69 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
70 Important information
Guidelines for Safe and
Efficient Use
Please read this information before
using your mobile phone.
These instructions are intended
for your safety. Please follow these
guidelines. If the product has been
subject to any of the conditions listed
below or you have any doubt as to its proper function
make sure you have the product checked by a
certified service partner before charging or using it.
Failure to do so might entail a risk of product
malfunction or even a potential hazard to your
health.
Recommendations for safe use of
product (mobile phone, battery,
charger and other accessories)
• Always treat your product with care and keep
it in a clean and dust-free place.
•Warning! May explode if disposed of in fire.
• Do not expose your product to liquid or moisture
or humidity.
• Do not expose your product to
extreme high or low temperatures.
Do not expose the battery to
temperatures above +60°C (+140°F).
• Do not expose your product to open
flames or lit tobacco products.
• Do not drop, throw or try to bend your product.
• Do not paint your product.
• Do not attempt to disassemble
or modify your product. Only
Sony Ericsson authorised personnel
should perform service.
• Do not use your product near medical
equipment without requesting
permission from your treating physician
or authorized medical staff.
• Do not use your product when in, or around aircraft,
or areas showing the sign “turn off two-way radio”.
• Do not use your product in an area
where a potentially explosive
atmosphere exists.
• Do not place your product or install
wireless equipment in the area above
an air bag in your car.
•Caution: Cracked or broken displays may create
sharp edges or splinters that could be harmful upon
contact.
CHILDREN
KEEP OUT OF CHILDRENS REACH.
DO NOT ALLOW CHILDREN TO PLAY
WITH YOUR MOBILE PHONE OR ITS
ACCESSORIES. THEY COULD HURT
THEMSELVES OR OTHERS, OR COULD
ACCIDENTALLY DAMAGE THE MOBILE PHONE
OR ACCESSORY. YOUR MOBILE PHONE OR ITS
ACCESSORY MAY CONTAIN SMALL PARTS THAT
COULD BECOME DETACHED AND CREATE A
CHOKING HAZARD.
Power supply (Charger)
Connect the AC power adapter only to designated
power sources as marked on the product. Make
sure the cord is positioned so that it will not be
subjected to damage or stress. To reduce risk of
electric shock, unplug the unit from any power source
before attempting to clean it. The AC power adapter
must not be used outdoors or in damp areas.
Never alter the cord or plug. If the plug does not
fit into the outlet, have a proper outlet installed by
a qualified electrician.
Use only Sony Ericsson branded original chargers
intended for use with your mobile phone. Other
chargers may not be designed to the same safety
and performance standards.
Sofia_UG_P1C_EN.book Page 70 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
71Important information
Battery
We recommend that you fully charge the battery
before you use your mobile phone for the first time.
A new battery or one that has not been used for a
long time could have reduced capacity the first few
times it is used. The battery should only be charged
in temperatures between +5°C (+41°F) and +45°C
(+113°F).
Use only Sony Ericsson branded original batteries
intended for use with your mobile phone. Using
other batteries and chargers could be dangerous.
Talk and standby times depend on several different
conditions such as signal strength, operating
temperature, application usage patterns, features
selected and voice or data transmissions when the
mobile phone is being used.
Turn off your mobile phone before removing the
battery. Do not put the battery into your mouth.
Battery electrolytes may be toxic if swallowed.
Do not let the metal contacts on the battery touch
another metal object. Doing this could short-circuit
and damage the battery. Use the battery for the
intended purpose only.
Personal medical devices
Mobile phones may affect the operation of
pacemakers and other implanted equipment. Please
avoid placing the mobile phone over the pacemaker,
e.g. in your breast pocket. When using the mobile
phone, use it at the ear on the opposite side of the
body to the pacemaker. If a minimum distance of
15 cm (6 inches) is kept between the mobile phone
and the pacemaker, the risk of interference is limited.
If you have any reason to suspect that interference is
taking place, immediately turn off your mobile phone.
Contact your cardiologist for more information.
For other medical devices, please consult your
physician and the manufacturer of the device.
Driving
Please check if local laws and regulations restrict
the use of mobile phones while driving or require
drivers to use handsfree solutions. We recommend
that you use only Sony Ericsson handsfree solutions
intended for use with your product.
Please note that because of possible interference
to electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles
unless a handsfree kit with an external antenna has
been installed.
Always pay full attention to driving and pull off the
road and park before making or answering a call
if driving conditions so require.
Emergency calls
Mobile phones operate using radio signals, which
cannot guarantee connection in all conditions. You
should therefore never rely solely upon any mobile
phone for essential communications (e.g. medical
emergencies).
Emergency calls may not be possible in all areas,
on all cellular networks, or when certain network
services and/or mobile phone features are in use.
Check with your local service provider.
Antenna
This phone contains a built-in antenna. Use of
antenna devices not marketed by Sony Ericsson
specifically for this model could damage your
mobile phone, reduce performance, and produce
SAR levels above the established limits (see below).
Efficient use
Hold your mobile phone as you would any other
phone. Do not cover the top of the phone when it is
in use, as this affects call quality and may cause the
phone to operate at a higher power level than needed,
thus shortening talk and standby times.
Sofia_UG_P1C_EN.book Page 71 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
72 Important information
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
Your mobile phone is a low-power radio transmitter
and receiver. When it is turned on, it emits low levels
of radio frequency energy (also known as radio
waves or radio frequency fields).
Governments around the world have adopted
comprehensive international safety guidelines,
developed by scientific organizations, e.g. ICNIRP
(International Commission on Non-Ionizing Radiation
Protection) and IEEE (The Institute of Electrical and
Electronics Engineers Inc.), through periodic and
thorough evaluation of scientific studies. These
guidelines establish permitted levels of radio wave
exposure for the general population. The levels
include a safety margin designed to assure the
safety of all persons, regardless of age and health,
and to account for any variations in measurements.
Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency
energy absorbed by the body when using a mobile
phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but
the actual SAR level of the mobile phone while it
is operating can be well below this value. This is
because the mobile phone is designed to use the
minimum power required to reach the network.
Variations in SAR below the radio frequency exposure
guidelines do not mean that there are variations in
safety. While there may be differences in SAR
levels among mobile phones, all Sony Ericsson
mobile phone models are designed to meet radio
frequency exposure guidelines.
For phones sold in the US, before a phone model is
available for sale to the public, it must be tested
and certified by the Federal Communications
Commission (FCC) that it does not exceed the limit
established by the government-adopted requirement
for safe exposure. The tests are performed in
positions and locations (that is, at the ear and worn
on the body) as required by the FCC for each
model. For body-worn operation, this phone has
been tested and meets FCC RF exposure guidelines
when the handset is positioned a minimum of 15
mm from the body without any metal parts in the
vicinity of the phone or when used with the original
Sony Ericsson accessory intended for this phone
and worn on the body. Use of other accessories
may not ensure compliance with FCC RF exposure
guidelines.
A separate leaflet with SAR information about this
mobile phone model is included with the material
accompanying this mobile phone. This information
can also be found, together with more information
on radio frequency exposure and SAR, on:
www.sonyericsson.com/health.
Accessible Solutions/Special Needs
For phones sold in the US, you can use your TTY
terminal with your Sony Ericsson mobile phone
(with the necessary accessory). For information on
Accessible Solutions for individuals with special
needs call the Sony Ericsson Special Needs Center
on 877 878 1996 (TTY) or 877 207 2056 (voice), or
visit the Sony Ericsson Special Needs Center at
www.sonyericsson-snc.com.
Disposal of old electrical
and electronic equipment
This symbol indicates that all
electrical and electronic equipment
included shall not be treated as
household waste. Instead it shall be left at the
appropriate collection point for recycling of electrical
and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handling of this product.
The recycling of materials will help to conserve
natural resources. For more detailed information
about recycling this product, please contact your
Sofia_UG_P1C_EN.book Page 72 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
73Important information
local city office, your household waste disposal
service or the shop where you purchased the
product.
Disposing of the battery
Please check local regulations for
disposal of batteries or call your local
Sony Ericsson Call Center for
information.
The battery should never be placed in municipal
waste. Use a battery disposal facility if available.
Memory card
Your product comes complete with a removable
memory card. It is generally compatible with the
handset purchased but may not be compatible with
other devices or the capabilities of their memory
cards. Check other devices for compatibility before
purchase or use.
The memory card is formatted prior to shipping.
To reformat the memory card, use a compatible
device. Do not use the standard operating system
format when formatting the memory card on a PC.
For details, refer to the operating instructions of the
device or contact customer support.
WARNING:
If your device requires an adapter for insertion into
the handset or another device, do not insert the
card directly without the required adapter.
Precautions on Memory Card Use
• Do not expose the memory card to moisture.
• Do not touch terminal connections with your hand
or any metal object.
• Do not strike, bend, or drop the memory card.
• Do not attempt to disassemble or modify the
memory card.
• Do not use or store the memory card in humid
or corrosive locations or in excessive heat such
as a closed car in summer, in direct sunlight or near
a heater, etc.
• Do not press or bend the end of the memory card
adapter with excessive force.
• Do not let dirt, dust, or foreign objects get into the
insert port of any memory card adapter.
• Check you have inserted the memory card
correctly.
• Insert the memory card as far as it will go into any
memory card adapter needed. The memory card
may not operate properly unless fully inserted.
• We recommend that you make a backup copy of
important data. We are not responsible for any loss
or damage to content you store on the memory card.
• Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
turn off the power while formatting, reading or writing
data, or use the memory card in locations subject
to static electricity or high electrical field emissions.
Protection of personal information
To safeguard your privacy and prevent information
being accessible to a third party, you should erase
all personal data before selling or disposing of the
product. To delete personal data, perform a master
reset and remove the memory card. DELETION OF
MATERIAL FROM THE PHONE MEMORY DOES
NOT ENSURE THAT SAID INFORMATION CANNOT
BE RECOVERED BY A SUBSEQUENT USER.
SONY ERICSSON DOES NOT WARRANT AGAINST
A SUBSEQUENT USER OF THE DEVICE ACCESSING
YOUR INFORMATION AND DOES NOT ASSUME
ANY RESPONSIBILITY FOR SUBSEQUENT
DISCLOSURE OF SAID INFORMATION EVEN IF
A MASTER RESET HAS BEEN PERFORMED. If you
are concerned about such potential disclosure retain
your device or secure its permanent destruction.
Accessories
Sony Ericsson recommends use of Sony Ericsson
original accessories for safe and efficient use of its
products. Use of third-party accessories may decrease
performance or pose a risk to your health or safety.
Sofia_UG_P1C_EN.book Page 73 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
74 Important information
LOUDNESS WARNING:
Please adjust the audio volume cautiously when
using third-party audio accessories to avoid volume
levels that may be harmful to your hearing.
Sony Ericsson does not test use of third-party audio
accessories with this mobile phone. Sony Ericsson
recommends using only Sony Ericsson original
audio accessories.
End User Licence Agreement
This wireless device, including without limitation
any media delivered with the device, (“Device”)
contains software owned by Sony Ericsson Mobile
Communications AB and its affiliated companies
(“Sony Ericsson”) and its third party suppliers and
licensors (“Software”).
As user of this Device, Sony Ericsson grants you
a non-exclusive, non-transferable, non-assignable
license to use the Software solely in conjunction
with the Device on which it is installed and/or
delivered with. Nothing herein shall be construed
as a sale of the Software to a user of this Device.
You shall not reproduce, modify, distribute, reverse
engineer, decompile, otherwise alter or use any other
means to discover the source code of the Software
or any component of the Software. For avoidance
of doubt, you are at all times entitled to transfer
all rights and obligations to the Software to a third
party, solely together with the Device with which
you received the Software, provided always that
such third party agrees in writing to be bound by
these rules.
You are granted this license for a term of the useful
life of this Device. You can terminate this license
by transferring all your rights to the Device on which
you have received the Software to a third party in
writing. If you fail to comply with any of the terms
and conditions set out in this license, it will
terminate with immediate effect.
Sony Ericsson and its third party suppliers and
licensors are the sole and exclusive owner of and
retain all rights, title and interest in and to the
Software. Sony Ericsson, and, to the extent that
the Software contains material or code of a third
party, such third party, shall be entitled third party
beneficiaries of these terms.
The validity, construction and performance of this
license shall be governed by the laws of Sweden.
The foregoing shall apply to the full extent permitted
by, when applicable, statutory consumer rights.
Limited Warranty
Sony Ericsson Mobile Communications AB, SE-221
88 Lund, Sweden, (Sony Ericsson) or its local affiliated
company, provides this Limited Warranty for your
mobile phone and original accessory delivered with
your mobile phone (hereinafter referred to as
“Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Center
(national rates may apply) or visit
www.sonyericsson.com to get further information.
Our warranty
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free
from defects in design, material and workmanship
at the time of its original purchase by a consumer.
This Limited Warranty will last for a period of one (1)
year as from the original date of purchase of the
Product.
What we will do
If, during the warranty period, this Product fails
to operate under normal use and service, due
to defects in design, materials or workmanship,
Sony Ericsson authorized distributors or service
partners, in the country* where you purchased the
Sofia_UG_P1C_EN.book Page 74 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
75Important information
Product, will, at their option, either repair or replace
the Product in accordance with the terms and
conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented by
applicable law, other regulation or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss.
You should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair
or replacement.
Conditions
1 This Limited Warranty is valid only if the original
proof of purchase for this Product issued by a
Sony Ericsson authorized dealer specifying the
date of purchase and serial number**, is presented
with the Product to be repaired or replaced.
Sony Ericsson reserves the right to refuse warranty
service if this information has been removed or
changed after the original purchase of the Product
from the dealer.
2 If Sony Ericsson repairs or replaces the Product,
the repair for the defect concerned, or the replaced
Product shall be warranted for the remaining time
of the original warranty period or for ninety (90) days
from the date of repair, whichever is longer. Repair
or replacement may involve the use of functionally
equivalent reconditioned units. Replaced parts or
components will become the property of
Sony Ericsson.
3 This warranty does not cover any failure of the
Product due to normal tear and wear, or due to
misuse, including but not limited to use in other
than the normal and customary manner, in accordanc
e
with the Sony Ericsson instructions for use and
maintenance of the Product. Nor does this warranty
cover any failure of the Product due to accident,
software or hardware modification or adjustment,
acts of God or damage resulting from liquid.
A rechargeable battery can be charged and
discharged
more than a hundred times. However,
it will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the
talk-time or standby time is noticeably shorter,
it is time to replace your battery. Sony Ericsson
recommends that you use only batteries and
chargers approved by Sony Ericsson.
Minor variations in display brightness and colour
may occur between the phones. There may be tiny
bright or dark dots on the display. These are called
defective pixels and occur when individual dots
have malfunctioned and can not be adjusted.
Two defective pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between phones. This is nothing uncommon
and is not regarded as a defective camera module.
4 Since the cellular system on which the Product is to
operate is provided by a carrier independent from
Sony Ericsson, Sony Ericsson will not be responsible
for the operation, availability, coverage, services
or range of that system.
5 This warranty does not cover Product failures caused
by installations, modifications, or repair or opening
of the Product performed by a non-Sony Ericsson
authorised person.
6 The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
7 Tampering with any of the seals on the Product will
void the warranty.
Sofia_UG_P1C_EN.book Page 75 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
76 Important information
8 THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY. ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO THE DURATION OF THIS LIMITED
WARRANTY. IN NO EVENT SHALL
SONY ERICSSON OR ITS LICENSORS BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT
NOT LIMITED TO LOST PROFITS OR COMMERCIAL
LOSS; TO THE FULL EXTENT THOSE DAMAGES
CAN BE DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion
or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties,
so the preceding limitations or exclusions may
not apply to you.
The warranty provided does not affect the
consumer's statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
*Geographical scope of the warranty
If you have purchased your Product in a country
member of the European Economic Area (EEA) or
in Switzerland or the Republic of Turkey, and such
Product was intended for sale in the EEA or in
Switzerland or in Turkey, you can have your Product
serviced in any EEA country or in Switzerland or in
Turkey, under the warranty conditions prevailing in
the country in which you require servicing, provided
that an identical Product is sold in such country by
an authorised Sony Ericsson distributor. To find out
if your Product is sold in the country you are in,
please call the local Sony Ericsson Call Center.
Please observe that certain services may not be
possible elsewhere than in the country of original
purchase, for example due to the fact that your
Product may have an interior or exterior which
is different from equivalent models sold in other
countries. Please note in addition that it may
sometimes not be possible to repair SIM-locked
Products.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
FCC Statement
This device complies with Part 15
of the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause
harmful interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Sofia_UG_P1C_EN.book Page 76 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
77Important information
Declaration of Conformity
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our
product
Sony Ericsson type AAD-3252011-BV
and in combination with our accessories, to which
this declaration relates is in conformity with the
appropriate standards 3GPP TS 51.010-1,
EN 301908-1, EN 301489-7, EN 301489-24,
EN 300328, EN 301489-17 and EN 60950,
following the provisions of, Radio Equipment and
Telecommunication Terminal Equipment directive
99/5/EC with requirements covering EMC directive
89/336/EEC, and Low Voltage directive 73/23/EEC.
We fulfil the requirements of the R&TTE Directive
(99/5/EC).
Lund, April 2007
Shoji Nemoto,
Head of Product Business Group GSM/UMTS
Sofia_UG_P1C_EN.book Page 77 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
78 Index
Index
A
activity menu ........................................ 13
alarms .................................................. 57
answering service ................................ 22
applications .......................................... 48
appointments ....................................... 58
assembly ................................................ 5
automatic redialling .............................. 16
B
battery
charging ......................................... 7
inserting ......................................... 5
use and care ................................ 71
Bluetooth™ wireless technology ......... 51
business cards ..................................... 21
C
calculator ............................................. 60
calendar ..........................................58–59
call divert .............................................. 24
call list .................................................. 21
call numbers in message ..................... 29
call time ................................................ 27
caller-specific ringtones ....................... 19
calls
accepting ..................................... 26
answering and rejecting ............... 17
emergency ....................................17
handling two calls .........................25
international ..................................16
making and receiving ....................16
putting on hold ..............................24
recording .......................................47
video .............................................18
camera
overview ........................................35
settings .........................................37
code memo ...........................................61
conference calls ....................................25
contacts
adding phone contacts .................18
default contacts ............................18
groups of .......................................21
synchronizing ................................54
D
date .......................................................62
declaration of conformity ......................77
E
email ......................................................31
emergency numbers .............................17
entering text ..........................................15
Sofia_UG_P1C_EN.book Page 78 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
79Index
F
file manager .......................................... 13
fixed dialling ......................................... 27
G
games ................................................... 47
groups .................................................. 21
H
handsfree ....................................... 22, 41
Bluetooth technology ................... 52
help ........................................................ 7
I
IMEI number ......................................... 64
Internet
bookmarks ................................... 50
security and certificates ............... 50
settings ......................................... 49
J
Java™ .................................................. 48
K
keypad lock .......................................... 64
keys ........................................................ 8
L
language ............................................... 15
Limited Warranty .................................. 74
lock
keypad ......................................... 64
phone ........................................... 63
SIM card ....................................... 62
M
magic word .......................................... 23
master reset ......................................... 64
Media Manager .................................... 42
memory card ........................................ 13
memory status ..................................... 20
menu overview ..................................... 10
menus .................................................. 12
messages
area and cell information .............. 34
email ............................................. 31
picture .......................................... 29
text ............................................... 28
voice ............................................. 31
microphone .......................................... 17
MMS See picture messages
music player ......................................... 41
MusicDJ™ ............................................ 46
My friends ............................................ 33
my numbers ......................................... 26
N
navigating menus ................................. 12
notes .................................................... 60
Sofia_UG_P1C_EN.book Page 79 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
80 Index
P
phone name ......................................... 49
photo tags ............................................ 40
PhotoDJ™ ............................................ 40
picture messages ................................. 29
pictures ................................................ 39
edit ............................................... 40
PIN code
changing ...................................... 63
unblocking ..................................... 6
playlists ...........................................43–44
PlayNow™ ........................................... 45
profiles ................................................. 62
PUK ............................................ 6, 62, 63
push email ............................................ 33
R
ringtones .............................................. 46
S
safety guidelines .................................. 70
sending
appointments and tasks .............. 59
business cards ............................. 21
melodies and ringtones ............... 47
music ........................................... 42
notes ............................................ 60
pictures ........................................ 39
settings
Internet ..........................................49
Java™ ...........................................48
shortcuts ...............................................13
SIM card
copying to/from ......................19, 20
lock and unblock ..........................62
SMS See text messages
SOS See emergency numbers
sound recorder .....................................47
speed dialling ........................................22
standby ...................................................6
startup screen .........................................6
stopwatch .............................................60
submenus .............................................12
synchronizing ..................................54–56
T
T9™ Text Input .....................................15
tasks ................................................59–60
templates ..............................................30
text messages .......................................28
themes ............................................41–46
time .......................................................62
time zone ..............................................62
timer ......................................................60
touch options ........................................12
transfer method
Bluetooth technology ....................51
USB ...............................................52
Sofia_UG_P1C_EN.book Page 80 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
81Index
transferring
camera pictures ........................... 38
files ............................................... 52
music ............................................ 43
sound ........................................... 52
turning on/off
Bluetooth ...................................... 51
phone lock ................................... 63
SIM lock protection ...................... 63
U
unblock SIM card ................................. 63
Update service ..................................... 56
V
video player .......................................... 42
video recorder ...................................... 35
voice answering ................................... 24
voice control ......................................... 22
voice messages ................................... 31
voicemail .............................................. 22
volume
ear speaker .................................. 17
ringtone ........................................ 46
W
Web feeds ............................................ 50
Z
zoom .................................................... 36
Sofia_UG_P1C_EN.book Page 81 Wednesday, July 18, 2007 5:45 PM
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
0REFLIGHTEDBY
