User guide
Thank you for purchasing a Sony Ericsson C901 Cyber-
shot™.
For additional phone content, go to
www.sonyericsson.com/fun. Register now to get free online
storage and special offers at
www.sonyericsson.com/myphone.
For product support, go to www.sonyericsson.com/support
Please read the Important information before you use your
mobile phone.
Instruction symbols
These symbols may appear in the User guide.
Note
Tip
Warning
> Use a selection or navigation key to scroll and select.
See Navigation on page 12.
2
Getting started
Assembly
Before you start using your phone, you need to insert a SIM
card and the battery.
To insert the SIM card
1
23
1Unlock the battery cover lock.
2Remove the battery cover.
3Slide the SIM card into its holder with the gold-coloured
contacts facing down.
3
To insert the battery
2.1
1
3
2.2
1Insert the battery with the label side up and the connectors
facing each other.
2Attach the battery cover and lock it.
4
Turning on the phone
To turn on the phone
1Press and hold down .
2Enter your SIM card PIN, if requested, and select OK.
3Select a language.
4Follow the instructions to use the setup wizard for basic
settings and useful tips.
If you want to correct a mistake when you enter your
PIN, press .
Help
In addition to this User guide, an extended User guide,
Feature guides and more information are available at
www.sonyericsson.com/support.
Help and information are also available in your phone.
5
To access the User guide
•Select Menu > Settings > User help > User guide.
To view tips and tricks
•Select Menu > Settings > User help > Tips and tricks.
To view information about functions
•Scroll to a function and select Info, if available. In some
cases, Info appears under Options.
To view the phone status
•Press and then press the volume key. Phone,
memory and battery information is shown.
Charging the battery
The phone battery is partly charged when you buy it.
To charge the battery
1
2
6
1Connect the charger to the phone. It takes approximately
2.5 hours to fully charge the battery. Press a key to view
the screen.
2Remove the charger by tilting the plug upwards.
You can use your phone while it is charging. You can
charge the battery at any time and for more or less than
2.5 hours. You can interrupt the charging without
damaging the battery.
7
Phone overview
1 Ear speaker
1
2
3
4
5
6
7
13
9
10
12
11
14
8
2 Screen
3 Selection keys
4 Call key
5 Activity menu key
6 Navigation key
7 Keylock key
8 Volume, digital zoom
keys
9 Camera view key
10 Camera mode key
11 End, On/off key
12 Camera key
13 C key (Clear)
14 Silent key
8
15 Flash
15
16
17
19
21
20
18
16 Camera lens
17 Retractable lens cover
18 Memory card slot (under
the cover)
19 Connector for charger,
handsfree and USB
cable
20 Loudspeaker
21 Strap holder
9
Menu overview*
PlayNow™*
Cyber-shot™
Alarms
Calls**
All
Answered
Dialled
Missed
Internet
Messaging
Write new,
InboxConversations,
Messages, Email, IM, Call
voicemail
Contacts
Myself, New contact
Organiser
File manager,
Applications, Video call,
Calendar, Tasks, Notes,
Synchronisation, Timer,
Stopwatch, Calculator,
Code memo
Entertainment
Online services,
TrackID™, Location
services, Games,
VideoDJ™, PhotoDJ™,
MusicDJ™, Remote
control, Record sound,
Demo tour
Media
Photo, Music, Video,
Games, Web feeds,
Settings
Radio
Settings
General
Profiles, Time & date,
Language, Update
service, Voice control,
New events, Shortcuts,
10
Flight mode, Security,
Setup wizard,
Accessibility, Phone
status, Master reset
Sounds & alerts
Ring volume, Ringtone,
Silent mode, Increasing
ring, Vibrating alert,
Message alert, Key sound
Display
Wallpaper, Main menu
layout, Theme, Startup
screen, Screen saver,
Clock size, Brightness,
Edit line names
Calls
Speed dial, Smart search,
Divert calls, Switch to line
2, Manage calls, Time &
cost, Show/hide my no.,
Handsfree
Connectivity
Bluetooth, USB, Phone
name, Synchronisation,
Device management,
Mobile networks, Data
communication, Internet
settings, Streaming
settings, Message
settings, SIP settings,
Accessories
User help
User guide, Settings
download, Basic setup,
Tips and tricks
* Some menus are
operator-, network- and
subscription-dependent.
** You can use the
navigation key to scroll
between tabs in
submenus. For more
information, see
Navigation on page 12.
11
Navigation
To access the main menu
•When Menu appears on the screen, press the centre
selection key to select Menu.
•If Menu does not appear on the screen, press , and
then press the centre selection key to select Menu.
To navigate the phone menus
•Press the navigation key , , or to move through
the menus.
To end a function
•Press .
To return to standby
•Press .
To delete items
•Press to delete items such as numbers, letters,
pictures and sounds.
Memory card
You may have to purchase a memory card separately.
12
Your phone supports Memory Stick Micro™ (M2™) memory
card adding more storage space to your phone. It can also
be used as a portable memory card with other compatible
devices.
You can move content between a memory card and the
phone memory. See Handling content in the phone on
page 19.
To insert a memory card
•Remove the battery cover and insert the memory card with
the gold-coloured contacts facing down.
Entering text
You can use multitap text input or T9™ Text Input to enter
text. The T9 Text Input method uses a built-in dictionary.
To change text input method
•When you enter text, press and hold down .
To shift between capitals and lower-case letters
•When you enter text, press .
To enter numbers
•When you enter text, press and hold down – .
13
To enter full stops and commas
•When you enter text, press .
To enter a symbol
1When you enter text, select Options > Add symbol.
2Scroll to a symbol and select Insert.
To enter text using T9™ Text Input
1Select, for example, Menu > Messaging > Write new >
Message.
2If is not displayed, press and hold down to change
to T9 Text Input.
3Press each key only once, even if the letter you want is not
the first letter on the key. For example, to write the word
“Jane”, press , , , . Write the whole word
before looking at the suggestions.
4Use or to view suggestions.
5Press to accept a suggestion.
To enter text using multitap
1From standby select, for example, Menu > Messaging >
Write new > Message.
2If is displayed, press and hold down to change to
multitap text input.
3Press – repeatedly until the desired letter
appears.
4When a word is written, press to add a space.
Cyber-shot™
You can take photos and record video clips to view, save or
send. You find saved photos and video clips in Media and
in File manager.
14
Using the camera
To activate the camera
•Open the retractable lens cover.
Viewfinder and camera keys
1
4
3
10
9
2
5
6
7
8
15
1 Zoom in or out
2 View photos and videos
3 Select still camera or video camera
4 Take photos/Record video
5 Photo: Flash Video: Light
6Self-timer
7 Photo: Scenes Video: Night mode
8 Photo: Shoot mode Video: Video length
9 Decrease brightness
10 Increase brightness
To take a photo
1Activate the camera and press to select .
2Press halfway down to use auto focus.
3When the dot and focus frame are green, press fully
down to take a photo. The photo is automatically saved.
To record a video clip
1Activate the camera and press to select .
2Press fully down to start recording.
3To stop recording, press fully down. The video clip
is automatically saved.
To use zoom
•Press the volume key.
16
To adjust brightness
•Press the navigation key. The amount of brightness is
shown beside the .
To view photos and video clips
1Activate the camera and press .
2Scroll to the item.
3To view a video clip, press the centre selection key.
More camera features
To change settings
•Activate the camera and select .
To view information about settings
•Scroll to a setting and select .
Photo fix
You can use Photo fix to improve photos. In a one-click
operation, brightness, light and contrast are adjusted to give
you the best possible photo. The improvements are saved
as a copy of the photo. The original photo is not affected.
To improve a photo with Photo fix
1Activate the camera and press to select .
2Make sure Review is set to On. Select > Settings and
scroll to Review > On. Select to return to the viewfinder.
3Take a photo.
4During review, select Options > Photo fix.
Face detection
You can use face detection to bring an off-centre face into
focus. The camera automatically detects up to three faces,
indicated by white frames. A green frame shows which face
17
has been selected when auto-focus is used. Focus is set to
the face closest to the camera.
To set face detection
1Activate the camera and press to select .
2Select > Focus > Face detection.
Smile Shutter™
Smile Shutter allows you to capture the smiles of family and
friends. The camera detects up to three faces and selects
one face for smile detection and auto focus. A yellow frame
shows which face is selected. When the selected face
smiles, the camera automatically takes a photo.
To set Smile Shutter™
1Activate the camera and press to select .
2Select > Shoot mode > Smile Shutter™.
3When appears, the camera is in Smile Shutter mode.
To use Smile Shutter™
1Activate the camera and press to select .
2When you see the yellow frame, press fully down.
When appears, smile detection is activated.
3The camera automatically takes the photo when the
subject smiles.
4To take a photo although no smile is detected, press
fully down again.
18
Transferring and handling
content
You can transfer and handle content such as pictures and
music.
You are not allowed to exchange some copyright-
protected material. identifies a protected item.
Handling content in the phone
You can use File manager to handle content saved in the
phone memory or on a memory card. Tabs and icons in File
manager show where the content is saved. If the memory is
full, delete some content to create space.
To select more than one item in a folder
1Select Menu > Organiser > File manager.
2Scroll to a folder and select Open.
3Select Options > Mark > Mark several.
4For each item you want to mark, scroll to the item and
select Mark.
To move items between the phone memory and the memory
card
1Select Menu > Organiser > File manager.
2Find an item and select Options > Manage file > Move.
3Select Memory card or Phone.
4Scroll to a folder and select Open.
5Select Paste.
Sending content to another phone
You can send content, for example, in messages or using
Bluetooth™ wireless technology.
19
To send content
1Scroll to an item and select Options > Send.
2Select a transfer method.
Make sure the receiving device supports the transfer
method you select.
Using a USB cable
You can connect your phone to a computer with a USB cable
to synchronise, transfer and back up phone content and use
your phone as a modem. For more information, go to
www.sonyericsson.com/support to read Feature guides.
You may have to purchase a USB cable separately.
Before using a USB cable
See Required operating systems on page 21.
Only use a USB cable supported by your phone. Do not
remove the USB cable from your phone or computer
during transfer as this may corrupt the memory card or
the phone memory.
To disconnect the USB cable safely
1Computer: Close any software that you are using with
your phone.
2Disconnect the USB cable.
Drag and drop content
You can drag and drop content between your phone, a
memory card and a computer in Microsoft Windows
Explorer.
To drag and drop content
1Connect your phone to a computer using a USB cable.
20
2Phone: Select Media transfer. The phone will remain
activated during file transfer.
3Computer: Wait until the phone memory and memory
card appear as external disks in Windows Explorer.
4Drag and drop selected files between the phone and the
computer.
Transferring content to and from a
computer
You can use Media Go™ to transfer media content between
your phone and a computer.
Media Go™ is available for download at
www.sonyericsson.com/support.
Required operating systems
You need one of these operating systems to use Sony
Ericsson PC software:
•Microsoft® Windows Vista™
•Microsoft® Windows XP, Service Pack 2 or higher
To download Media Go™
1Computer: In your Internet browser, go to
www.sonyericsson.com/support.
2Select a region and country.
3Select Software downloads.
4Select a phone from the list.
5Select Read more and download under Media Go™.
6Select Download now and save the file to your computer.
Remember where you save the file.
To install Media Go™ from the downloaded file
1Locate the downloaded Media Go™ file on the computer.
21
2Double-click the file and follow the instructions.
To transfer content using Media Go™
Do not remove the USB cable from your phone or
computer during transfer, as this may corrupt the
memory card or the phone memory.
1Connect the phone to a computer with a USB cable
supported by your phone.
2Computer: Select Start/Programs/Sony/Media Go™.
3Phone: Select Media transfer.
4Computer: Select Transfer to or from Device using Media
Go™ and click OK.
5Wait until the phone appears in Media Go™.
6Move files between your phone and the computer in
Media Go™.
Calling
Making and receiving calls
You need to turn on your phone and be within range of a
network.
To make a call
1Enter a phone number (with international country code and
area code, if applicable).
2Press .
You can call numbers from your contacts and call list.
See Contacts on page 24, and Call list on
page 24.
To end a call
•Press .
22
To make international calls
1Press and hold down until a “+” sign appears.
2Enter the country code, area code (without the first zero)
and phone number.
3Press .
To answer a call
•Press .
To reject a call
•Press .
To change the ear speaker volume during a call
•Press the volume key up or down.
To mute the microphone during a call
1Press and hold down .
2Press and hold down again to resume.
To turn on the loudspeaker during a call
•Press SpkrOn.
Do not hold your phone to your ear when using the
loudspeaker. This could damage your hearing.
Emergency calls
Your phone supports international emergency numbers, for
example, 112 or 911. You can normally use these numbers
to make emergency calls in any country, with or without the
SIM card inserted, if you are within range of a network.
In some countries, other emergency numbers may also
be promoted. Your network operator may therefore
have saved additional local emergency numbers on the
SIM card.
23
To make an emergency call
•Enter 112 (the international emergency number) and press
.
To view your local emergency numbers
1Select Menu > Contacts.
2Scroll to New contact and select Options > Special
numbers > Emergency nos..
Call list
You can view information about recent calls.
To call a number from the call list
1Press and scroll to a tab.
2Scroll to a name or a number and press .
Contacts
You can save names, phone numbers and personal
information in Contacts. Information can be saved in the
phone memory or on the SIM card.
You can synchronise your contacts using the
Sony Ericsson PC Suite.
To add a phone contact
1Select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Scroll to New number: and select Add.
5Enter the number and select OK.
6Select a number option.
7Scroll between the tabs and add information to the fields.
8Select Save.
24
Calling contacts
To call with Smart search
1Press – to enter a sequence of (at least two)
digits. All entries which match the sequence of digits or
corresponding letters are shown in a list.
2Scroll to a contact or a phone number and press .
To turn on or off Smart search
1Select Menu > Settings > Calls > Smart search.
2Select an option.
Messaging
Text and picture messages
Messages can contain text, pictures, sound effects,
animations, and melodies. You can also create and use
templates for your messages.
When sending messages, the phone automatically selects
the most suitable method (as a text or picture message) for
sending the message.
If you cannot use picture messages, see I cannot use
Internet-based services on page 32.
To create and send a message
1Select Menu > Messaging > Write new > Message.
2Enter text. To add items to the message, press , scroll
and select an item.
3Select Continue > Contacts look-up.
4Select a recipient and select Send.
If you send a message to a group, you will be charged
for each member.
25
To view a message from the inbox
1Select Menu > Messaging > Inbox.
2Scroll to the message and select View.
To call a number in a message
•When you view the message, scroll to the phone number
and press .
Music
You can listen to music, audio books and podcasts. Use
Media Go™ to transfer content to and from your phone. For
more information, see Transferring content to and from a
computer on page 21.
Stereo portable handsfree
Music player
To play music
1Select Menu > Media > Music.
26
2Browse by category using the navigation key.
3Scroll to a title and select Play.
To stop playing music
•Press the centre selection key.
To fast forward and rewind
•Press and hold down or .
To move between tracks
•Press or .
To change the volume
•Press the volume key up or down.
TrackID™
TrackID™ is a music recognition service. You can search for
title, artist and album name for a track you hear playing
through a loudspeaker or on the radio in your phone. If you
cannot use TrackID™, see I cannot use Internet-based
services on page 32.
To search for track information
•When you hear a track through a loudspeaker, select
Menu > Entertainment > TrackID™ > Start.
•When the radio in your phone is playing select Options >
TrackID™.
For best results, use TrackID™ in a quiet area.
Radio
Do not use your phone as a radio in places where this
is prohibited.
To turn on the radio
1Connect a handsfree to the phone.
27
2Select Menu > Radio.
To search for channels manually
•Press or .
Saving channels
You can save up to 20 preset channels.
To save channels automatically
•Select Options > Auto save.
To switch between saved channels
•Press or .
Internet
If you cannot use the Internet, see I cannot use Internet-
based services on page 32.
To start browsing
1Select Search.
2Enter a Web address, a search phrase or the name of a
bookmark.
3Scroll to an item in the list and select Go to or Search.
To exit the browser
•Select Options > Exit browser.
To create a bookmark
1When you browse the Internet, select Options > Tools >
Add bookmark.
2Enter a title and an address. Select Save.
28
More features
Flight mode
In Flight mode the network and radio transceivers are turned
off to prevent disturbance to sensitive equipment.
When the flight mode menu is activated you are asked to
select a mode the next time you turn on your phone:
•Normal mode – full functionality
•Flight mode – limited functionality
To activate the flight mode menu
•Select Menu > Settings > General > Flight mode >
Continue > Show at startup.
To select flight mode
1When the flight mode menu is activated, turn off your
phone.
2Turn on your phone and select Flight mode.
Update Service
You can update your phone with the latest software using
your phone or a PC.
Updating using your phone is not possible in all
countries/regions.
To view the current software in the phone
1Select Menu > Settings > General > Update service.
2Select Software version.
29
Update Service using a PC
You can update your phone using a USB cable and an
Internet-connected PC.
Make sure all personal data in your phone memory is
backed up before you perform an update using a PC.
See cross reference error on page page reference
error.
To use Update Service using a PC
•Go to
www.sonyericsson.com/updateservice
.
Ringtones
To set a ringtone
1Select Menu > Settings > Sounds & alerts > Ringtone.
2Find and select a ringtone.
To turn off the ringtone
•Press and then press and hold down .
The alarm signal is not affected.
Locks
SIM card lock
This lock only protects your subscription. Your phone will
work with a new SIM card. If the lock is on, you have to enter
a PIN (Personal Identity Number).
If you enter your PIN incorrectly three times in a row, the SIM
card is blocked and you need to enter your PUK (Personal
Unblocking Key). Your PIN and PUK are supplied by your
network operator.
30
To unblock the SIM card
1When PIN blocked appears, enter your PUK and select
OK.
2Enter a new four-to-eight-digit PIN and select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1Select Menu > Settings > General > Security > Locks
> SIM protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four-to-eight-digit PIN and select OK.
4Re-enter the new PIN and select OK.
If Codes do not match appears, you entered the new
PIN incorrectly. If Wrong PIN appears, followed by Old
PIN:, you entered your old PIN incorrectly.
Troubleshooting
Some problems can be fixed using Update Service. Using
Update Service on regular basis will optimize the phone’s
performance. See Update Service on page 29.
Some problems will require you to call your network
operator.
For more support go to www.sonyericsson.com/support.
Common questions
I have problems with memory capacity or the phone
is working slowly
Restart your phone every day to free memory or do a Master
reset.
31
Master reset
If you select Reset settings, the changes that you have
made to settings will be deleted.
If you select Reset all, your settings and content, such as
contacts, messages, pictures, sounds and downloaded
games, will be deleted. You may also lose content that was
in the phone at purchase.
To reset the phone
1Select Menu > Settings > General > Master reset.
2Select an option.
3Follow the instructions that appear.
I cannot charge the phone or battery capacity is low
The charger is not properly connected or the battery
connection is poor. Remove the battery and clean the
connectors.
The battery is worn out and needs to be replaced. See
Charging the battery on page 6.
No battery icon appears when I start charging the
phone
It may take a few minutes before the battery icon appears on
the screen.
Some menu options appear in grey
A service is not activated. Contact your network operator.
I cannot use Internet-based services
Your subscription does not include data capability. Settings
are missing or incorrect.
You can download settings using the setup wizard or by
going to www.sonyericsson.com/support.
32
To download settings
1Select Menu > Settings > User help > Settings
download.
2Follow the instructions that appear.
Contact your network operator or service provider for
more information.
I cannot send messages from my phone
Most messages require a service centre number to send
them. The number is supplied by your service provider and
is usually saved on the SIM card. If the number to your service
centre is not saved on your SIM card, you must enter the
number yourself.
To send most picture messages, you must set an MMS
profile and the address of your message server. If no MMS
profile or message server exists, you can receive all the
settings automatically from your network operator, download
settings using the setup wizard or at
www.sonyericsson.com/support.
To enter a service centre number
1Select Menu > Settings > Connectivity > Message
settings > Text message and scroll to Service centre.
The number is shown if it is saved on the SIM card.
2If there is no number shown, select Edit.
3Scroll to New ServiceCentre and select Add.
4Enter the number, including the international “+” sign and
country code.
5Select Save.
To select an MMS profile
1Select Menu > Settings > Connectivity > Message
settings > Picture message.
33
2Select an existing profile or create a new one.
To set the message server address
1Select Menu > Settings > Connectivity > Message
settings > Picture message.
2Scroll to a profile and select Options > Edit.
3Scroll to Message server and select Edit.
4Enter the address and select OK > Save.
I cannot synchronise or transfer content between my
phone and my computer, when using a USB cable.
The cable or software has not been properly installed. Go to
www.sonyericsson.com/support to read Feature guides
which contain detailed installation instructions and
troubleshooting sections.
Error messages
Insert SIM
There is no SIM card in your phone or you may have inserted
it incorrectly.
See To insert the SIM card on page 3.
The SIM card connectors need cleaning. If the card is
damaged, contact your network operator.
Insert correct SIM card
Your phone is set to work only with certain SIM cards. Check
if you are using the correct operator SIM card.
Wrong PIN/Wrong PIN2
You have entered your PIN or PIN2 incorrectly.
Enter the correct PIN or PIN2 and select Yes.
34
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2 code incorrectly three
times in a row.
To unblock, see SIM card lock on page 30.
Codes do not match
Codes that you have entered do not match. When you want
to change a security code, for example your PIN, you have
to confirm the new code. See SIM card lock on page 30.
No netw. coverage
Your phone is in flight mode. See Flight mode on page 29.
Your phone is not receiving any network signal, or the
received signal is too weak. Contact your network operator
and make sure that the network has coverage where you are.
The SIM card is not working properly. Insert your SIM card
in another phone. If this works, it is probably your phone that
is causing the problem. Please contact the nearest
Sony Ericsson service location.
Emerg. calls only
You are within range of a network, but you are not allowed
to use it. However, in an emergency, some network
operators allow you to call the international emergency
number 112. See Emergency calls on page 23.
PUK blocked. Contact operator.
You entered your personal unblocking key code (PUK)
incorrectly 10 times in a row.
35
Legal information
Sony Ericsson C901 Cyber-shot™
This User guide is published by Sony Ericsson Mobile Communications
AB or its local affiliated company, without any warranty. Improvements
and changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/or
equipment, may be made by Sony Ericsson Mobile Communications AB
at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2009
Publication number: 1220-7402.1
Attention: Some of the services and features described in this User
guide are not supported by all networks and/or service providers in all
areas. Without limitation, this applies to the GSM International
Emergency Number 112. Please contact your network operator or
service provider to determine availability of any specific service or
feature and whether additional access or usage fees apply.
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not limited
to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of any
additional content, please verify that your intended use is properly licensed
or is otherwise authorized. Sony Ericsson does not guarantee the
accuracy, integrity or quality of any additional content or any other third
party content. Under no circumstances will Sony Ericsson be liable in any
way for your improper use of additional content or other third party
content.
Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc.
and any use of such mark by Sony Ericsson is under license.
The Liquid Identity logo, BestPic, PlayNow, MusicDJ, PhotoDJ, TrackID,
Style-Up and VideoDJ are trademarks or registered trademarks of
Sony Ericsson Mobile Communications AB.
TrackID™ is powered by Gracenote Mobile MusicID™. Gracenote and
Gracenote Mobile MusicID are trademarks or registered trademarks of
Gracenote, Inc.
36
Cyber-shot, Smile Shutter, Sony, Memory Stick Micro™, M2™ and Media
Go are trademarks or registered trademarks of Sony Corporation.
Google™, Google Maps™, YouTube and the YouTube logo are
trademarks or registered trademarks of Google, Inc.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget LM
Ericsson.
Microsoft, Windows and Vista are registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
T9™ Text Input is a trademark or a registered trademark of Tegic
Communications. T9™ Text Input is licensed under one or more of the
following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and
6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No.
2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of
Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK,
FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending
worldwide.
This product is protected by certain intellectual property rights of
Microsoft. Use or distribution of such technology outside of this product
is prohibited without a license from Microsoft.
Other product and company names mentioned herein may be the
trademarks of their respective owners.
Any rights not expressly granted herein are reserved.
All illustrations are for illustration only and may not accurately depict the
actual phone.
37
www.sonyericsson.com
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden

Navigation menu
