08 user guide part 1
X10 mini pro
User guide
Important information
Please read the Important information leaflet before you
use your mobile phone.
Some of the services and features described in this
User guide are not supported in all countries/regions or
by all networks and/or service providers in all areas.
Without limitation, this applies to the GSM International
Emergency Number 112. Please contact your network
operator or service provider to determine availability of
any specific service or feature and whether additional
access or usage fees apply.
Experience more. Discover
how.
Need help? Get more, do more. Miss nothing. Visit
www.sonyericsson.com/xperiax10minipro to learn more
about your phone.
User guide in the phone
An extended User guide is available in your phone. The
extended User guide and more information is also available
at www.sonyericsson.com/support.
To access the User guide in your phone
1From the Home screen, drag upwards.
2Find and tap User guide .
2
Getting started
To insert the SIM card and the memory card
2
1
1Remove the battery cover.
2Slide the SIM card with the gold-coloured contacts facing
down and memory card with the gold-coloured contacts
facing up.
To insert the battery
12
3
1Insert the battery with the label side up and the
connectors facing each other.
2Attach the battery cover.
To turn on the phone
1Press and hold down the key on the top of the
phone.
2Enter your SIM card PIN, if requested, and select OK.
3At first startup, follow the instructions in Setup guide.
Your PIN is supplied by your network operator. If you
want to correct a mistake made while entering your
SIM card PIN, press .
To turn off the phone
1Press and hold until the options menu opens.
2In the options menu, tap Power off.
3Tap OK.
To activate the screen
•Press .
To lock the screen
•Press .
Starting your phone for the first time
The first time you start your phone, a setup guide lets you
enter essential phone settings, import contacts, and set up
your email and online services accounts. You can also
access the setup guide later from the phone settings.
To set the language
1Scroll through the available languages list.
2Tap the language you want to use in your phone. The
language is marked.
4
3Tap Save.
Internet and messaging settings
In order to send messages and use the Internet you will
need a 2G/3G mobile data connection. For most mobile
phone networks and operators, settings for messaging and
the Internet will be preinstalled on the phone or downloaded
to your phone the first time you turn on the phone with a
SIM card inserted. If not, you can go to
www.sonyericsson.com/support
from your computer to
download the settings to your phone.
To import contacts from the SIM card
1From the setup guide, tap Import contacts.
2When you are asked to confirm if you want to import the
contacts from the SIM card to the phone, tap Yes.
By using Sony Ericsson Sync you can synchronise
contacts, bookmarks and calendar events between
your phone and your Sony Ericsson account. This way
you can transfer information from your old phone to
the Sony Ericsson account, and then transfer it to your
new phone. You can set up a Sony Ericsson account
from the Sony Ericsson Sync application in your
phone, or by going to www.sonyericsson.com/user
from your computer.
To set the time and date
1From the setup guide, tap Time & date.
2Unmark the Automatic checkbox, if it is marked.
3Tap Set date or Set time.
4Tap or to adjust the date or hour and minute.
5
5Tap Set.
While setting time, you can shift between 12-hour and
24-hour format. If you want to use AM and PM, you
have to unmark Use 24-hour format.
To create a new Google™ account in your phone
1From the setup guide, tap Google account.
2Tap Next.
3Tap Create.
4Enter your personal information and desired Google™
username. Tap Next.
5Enter and confirm your password. Tap Next.
6Select a security question and enter a personal answer
that only you know. You can also enter a secondary email
address to which your Google™ account information
could be sent in case you forget the information. Tap
Next.
7To agree to the Google™ Terms of service, tap I agree,
Next.
8Enter the security word displayed as an image. Tap
Next.
9Mark the checkboxes to allow the additional Google™
services, or leave them blank if you do not agree to use
these services. Tap Next.
10 Tap Finish setup. Your new Google™ account has now
been created and set up to be used with the Google™
services in your phone.
To set up an existing Google™ account in your phone
1From the setup guide, tap Google account.
2Tap Next.
3Tap Sign in.
6
4Enter your Google™ username and password. Tap Sign
in to continue.
5Mark the checkboxes to allow the additional Google™
services, or leave them blank if you do not agree to use
these services. Tap Next.
6Tap Finish setup. Your Google™ account has now been
set up in your phone.
In most cases, your Google™ username is the first
part of your Google™ email address.
To set up an email account
1From the setup guide, tap Email.
2Tap Email address, enter your email address and tap
Next.
3Enter your password and tap Done.
4Tap Continue.
5If the phone cannot download your email account
settings automatically, enter the account settings
manually.
If you need to enter the settings manually, contact
your email service provider for the correct email
account settings. For example, you need to know if
the account type is POP3 or IMAP.
Sony Ericsson Timescape™ settings
Sony Ericsson Timescape™ collects all the communication
events at one place and keeps you updated with messages,
missed calls from your contacts and friends in Facebook™
and Twitter™.
To set up a Facebook™ account
1From the setup guide, tap Facebook.
2Tap Username, enter your username and tap Next.
7
3Enter your password and tap Done.
To set up a Twitter™ account
1From the setup guide, tap Twitter.
2Tap Username, enter your username and tap Next.
3Enter your password and tap Done.
To exit the setup guide
•When you are finished with the setup guide, tap Done.
Getting to know your phone
Phone overview
1 Sensors
123
5
6
7
4
8
2 Ear speaker
3 Notification LED
4 Touch screen
5 Back key
6 Home key
7 Menu key
8 Keyboard
8
9 Power key/screen lock
10 9
11
12
13
14
15
17
16
10 3.5 mm headset
connector
11 Camera lens
12 Camera light
13 Volume key
14 Camera key
15 Speaker
16 Strap hole
17 Connector for charger/
USB cable
Charging the battery
The phone battery is partly charged when you buy the
phone. It may take a few minutes before the battery icon
appears on the screen when you connect the phone to a
power source. You can still use your phone while it is
charging.
The battery will start to discharge a little after it is fully
charged and then charges again after a certain time.
This is to extend battery life and may result in the
charge status showing a level below 100 percent.
9
1
2
To charge the phone using the power adapter
•Connect the phone to a power outlet using the USB cable
and the power adapter.
Using the hardware keys
10
Menu Open a list of options available in the
current screen or application
Home •Go to the Home screen or to the
applications panes from any
application or screen
•Open the recently used applications
window
Back •Go back to the previous screen
•Close the onscreen keypad, a dialog
box, an options menu, or the
Notifications panel
Status bar
A status bar at the top of the screen displays phone status
information and notifications. Notification icons appear on
the left side of the status bar. Phone status icons appear on
the right side. From the status bar you can access the
notification panel.
11:37
Using the touch screen
To open or highlight an item
•Tap the item.
11
To mark or unmark options
•Tap the relevant checkbox or in some cases the right side
of the list option, to mark or unmark an option.
Marked checkbox
Unmarked checkbox
Marked list option
Unmarked list option
To pan
•When this option is available, drag the screen to pan.
To zoom
•When available, tap or to zoom in or out.
•Touch, hold and drag upwards or downwards to zoom in
or out.
You may have to drag your finger on the screen (in any
direction) to make the zoom icons appear.
Scrolling
You can scroll up or down, and on some webpages you can
also scroll to the sides.
Dragging or flicking will not activate anything on the
screen.
Notification panel
In the Notification panel, notification icons are displayed in
a detailed view. You can open notifications, such as
messages, reminders, or event notifications directly from
the Notification panel. You can also open running
applications such as the music player or the radio.
12
To open the Notification panel
January 7, 2010
11: 3 7
No notication
20 January 2010
n
n
0
Januar
0
r
y
y
y
7
7
2
, 2
7
7
7
0
0
1
1
1
0
y
Ja
•Drag the status bar downwards.
Home screen
The Home screen is the starting point of your phone. You
can personalise the Home screen by adding widgets, or by
changing the wallpaper and the applications in the corners.
When you add more than one widget, the Home screen
extends beyond the screen width. The corners on the
Home screen are used to access applications or
13
bookmarks quickly. You can add any application or
bookmark to the corners.
When you go to the Home screen, some applications
may continue to run in the background. If you do not
want applications to run in the background, you should
exit each application you have opened before going to
the Home screen.
7
2
7
0
1
0
Jan
J
7
2
7
0
1
0
anuar
y
7
, 2
77
0
1
0
0
y
7
2
7
0
1
0
To view the extended Home screen
•Drag your finger to the sides of the screen.
To add widgets to the Home screen
1Press .
2Tap Arrange widgets.
3Flick through the horizontal list of widgets and tap Add
widget.
4Select a widget from the list.
14
5Press to exit the edit mode.
You can add more widgets by flicking through the
horizontal list and tapping Add widgets.
To delete a widget from the Home screen
1Press .
2Tap Arrange widgets.
3Flick horizontally across the screen and tap the widget
you want to delete.
4Tap in the widget.
5Tap Yes.
6Press to exit the edit mode.
Orientation
When you open the keyboard, the screen orientation
changes automatically from portrait to landscape view. You
can also set the phone to stay in portrait orientation by
disabling the automatic orientation setting.
To prevent the screen orientation from changing
automatically
1From the Home screen, tap the applications bar.
2Tap Settings > Sound & display.
3Unmark the Orientation check box.
Preventing the screen orientation from changing
automatically means that the phone stays in portrait
orientation.
Applications panes
You can access your applications in the phone using the
applications panes. The applications panes extend beyond
the screen. You can create new panes and arrange the
applications after your preferences.
15
Shows which applications pane you are in
To open the applications panes
You can open the applications panes by different
ways.
•From the Home screen, drag upwards.
•From the Home screen, tap .
•Flick the Home screen upwards.
•From the Home screen, press .
To browse the applications panes
•From the applications panes, flick right or left.
16
To create a new applications pane
1From the Home screen, press .
2Tap Arrange icons.
3Touch and hold an item in the last pane until it vibrates
and then drag it to the right.
4Press to exit the edit mode.
To move an application
1From the Home screen, press .
2Tap Arrange icons.
3Touch and hold an item until it vibrates and drag it to one
of the corners or to another application pane. If you move
an item in the last applications pane, the pane switches
to the next pane.
4Press to exit the edit mode.
The items in the applications panes are not shortcuts
to the applications but the actual applications. When
you move an application from the applications panes
to corners or vice versa, the actual application gets
moved and not shortcut. There are no shortcuts to the
applications.
Recently used applications window
You can view and access recently used applications from
this window.
To open the recently used applications window
•From any application, press and hold down .
Phone settings overview
You can set up the phone to suit your requirements, for
example, Date & time, Wireless controls and Data
synchronization.
17
To change the phone language
1From the Home screen, drag upwards.
2Find and tap Settings > Locale & text > Select locale.
3Select an option.
If you choose the wrong language and cannot read the
menu texts, go to
www.sonyericsson.com/support
for
help.
To turn on Flight mode
1From the Home screen, drag upwards.
2Find and tap Settings > Wireless controls.
3Mark the Airplane mode checkbox.
You can also press and hold to turn on Flight
mode.
Entering text
To enter text and characters you can use either the slideout
keyboard or the on-screen keypad. When you are using the
slideout keyboard, you cannot enter text using the on-
screen keypad.
Using the slideout keyboard
•To type lower-case letters, press the relevant letter keys.
•To type a single upper-case letter, press and then
press the relevant letter key.
•To use all upper-case letters, press twice. To change
back to all lower-case letters, press again.
•To type special characters, press and hold
Sym
au
, and then
press the letter key until the required character appears.
•To enter a character printed in blue, press and then
press the relevant key.
18
•To use all the characters printed in blue, press twice
and enter the relevant characters.
To change writing language using the slideout keyboard
1When you enter text, tap the language icon in the lower
left corner of the screen.
2Select a language.
Using the on-screen keypad
When you start a program or select a field that requires text
or numbers, the default on-screen keypad appears.
You can use multitap text input method or quick text input
method to enter text. The quick text input method uses
a built-in dictionary.
You can close the keypad at any time by pressing
.
To display the on-screen keypad and enter text
•Tap the text field and the keypad appears.
To change writing language using the on-screen keypad
1When you enter text, tap the language icon in the upper
right corner.
2Select an option.
Calling
To make an emergency call
1From the Home screen, tap .
19
2Enter the emergency number and tap . To delete a
number, tap .
You can make an emergency call without a SIM card
inserted.
To make an emergency call while the SIM card is locked
1Tap Emergency call.
2Enter the emergency number and tap . To delete a
number, tap .
To make a call
1From the Home screen, tap .
2If the call log is shown, tap to enter the dial pad view.
3Enter the number of the recipient and tap . To delete a
number, tap .
To end a call
•Tap .
To answer a call
•Drag the indicator to .
Contacts
In the Contacts application, you can enter information for
your personal contacts, for example, phone numbers and
20
email addresses. When you view a contact, you get quick
access to all communication with that contact. If you have
a synchronisation service account, you can synchronise
your phone contacts with the account contacts.
To view your contacts
•From the Home screen, tap to open the Contacts
application.
If you have not set up your phone for synchronisation
with a web service, or imported SIM contacts, you can
choose to do so the first time you open Contacts.
To call a contact
1From the Home screen, tap .
2Tap the contact.
3Tap the desired phone number of the contact.
SMS and MMS
To create and send a message
1From the Home screen, tap .
2Tap New message.
3Tap Write message, enter your message text and tap
Next.
4Tap to add a recipient.
5To add a recipient, select a contact in the list. You can
also tap the text field, enter a number manually, and then
tap Done.
6If you want to add a photo or a video, tap and select
an option.
7If you want to add, remove or edit recipients, press ,
then tap Edit recipients and edit the recipients.
21
8When you are finished, tap Send.
If you stop creating the message, it will be saved as a
draft. The message thread will be tagged with the
word Draft.
To read a received message
1From the Home screen, tap .
2Tap a message thread.
3If the message is not downloaded yet, tap the message
and then tap Download message.
4If the received message contains music or a video, tap
the item and then tap View video or Play audio.
When you receive a text or multimedia message,
appears in the status bar. To read the message, you
can also drag the status bar downwards and tap the
received message when the status bar is open.
Email
You can use your phone to send and receive emails through
your regular email account. First, you need the correct
Internet settings in your phone. See Internet and
messaging settings on page 5.
For more information on entering text, see Entering
text on page 18.
To set up an email account in your phone
1From the Home screen, drag upwards.
2Find and tap Email.
3Tap Email address, enter your email address and tap
Next.
4Enter your password and tap Done.
22
5Tap Continue.
6If the phone cannot download your email account
settings automatically, you can proceed by entering the
account settings manually.
If you need to enter the settings manually, contact
your email service provider for the correct email
account settings. For example, you need to know if
the account type is POP3 or IMAP.
To create and send an email message
1From the Home screen, drag upwards.
2Find and tap Email.
3Tap Write new.
4Tap To: and enter the recipient's address, then tap
Done. You can add more recipients the same way, or
delete a recipient by tapping .
5Tap Subject, enter the subject and tap Done.
6Tap Write email, enter the message text and tap
Done.
7To attach a file, tap and select the type of file to
attach.
8Tap Send.
To receive and open email messages
1From the Home screen, drag upwards.
2Find and tap Email.
3Tap Inbox.
4To update the inbox with new messages, tap .
5To open and read a message, tap the message.
23
Sony Ericsson Timescape™
Sony Ericsson Timescape™ revolutionises your social
experience by collecting all your communications into one
view. Every event – Facebook or Twitter updates, text and
multimedia messages, missed calls – appears as a tile in a
chronological flow on the screen. You can see a snack-size
preview of an event before choosing to view the full content.
You can filter by event type to view all communications for
a contact.
The services and features described in this chapter
may not be supported in all countries/ regions or by
all networks and/or service providers in all areas.
To start Timescape™
1From the Home screen, drag upwards.
2Find and tap Timescape.
3The first time you start Timescape, you can tap Log in
and log in to your Facebook or Twitter account to
receive Facebook and Twitter updates in Timescape. If
you do not want to log in, tap Continue.
If you are already logged in to Facebook, Twitter, or
another online service while setting up the phone for
the first time, when you start Timescape™, the
welcome screen will not be displayed and you are not
required to log in again.
If you are not logged in and you tap Continue, then
you can always log in from the Home screen by
tapping Settings > Sony Ericsson > Timescape™
settings.
24
The Timescape™ start screen
2
3
1
5
6
4
1 Tile filter icon
2 Status update icon
3 Go to contact icon
4Refresh icon (only visible if you are logged in to a web
service account)
5 Timescape™ tiles, in chronological order
6 Tile content icon
25
Using Timescape™
To update your Facebook or Twitter status in Timescape™
1From the Home screen, drag upwards.
2Find and tap Timescape.
3Tap .
4Tap Select services.
5Use the toggles to select the services for which you want
to update your status. If you want to update your status
for a service you are not logged in to, tap the service and
log in to it. When you have selected the desired services,
tap Done.
6Tap Edit status, enter your new status, and tap Send.
To view an event in Timescape™
1From the Home screen, drag upwards.
2Find and tap Timescape.
3Scroll to the tile for the desired event, then tap the tile.
To schedule web service content updates in Timescape™
1From the Home screen, drag upwards.
2Find and tap Settings > Sony Ericsson > Timescape™
settings > Schedule updates.
3Tap the desired option. If you select Manual, no
automatic updates will be made.
To log in to Facebook or Twitter
1From the Home screen, drag upwards.
2Find and tap Settings > Sony Ericsson > Timescape™
settings > Services.
3Tap the service you want to log in to.
26
4Enter your login details.
When you have logged in to a web service, you can
update your status, or view updates from the web
service, in Timescape™.
Sony Ericsson Sync
Use the Sony Ericsson Sync application to synchronise
bookmarks, contacts and calendar events between your
phone and your Sony Ericsson account. At
www.sonyericsson.com/user you can then access, edit
and add information from any computer with an Internet
connection.
A Sony Ericsson account can be created and set up from
your phone, or you can create one at
www.sonyericsson.com/user.
Sony Ericsson Sync can be set up to connect to any
SyncML™ service.
To set up a Sony Ericsson account in your phone
1From the Home screen, drag upwards.
2Find and tap Sony Ericsson Sync.
3Tap Sony Ericsson Sync.
4Follow the registration wizard to create a Sony Ericsson
account.
5Mark the Sync interval checkbox and set the
synchronisation interval.
6If you want to synchronise Bookmarks, Contacts and
Calendar, mark the relevant checkboxes.
7Tap Save.
27
To synchronise using Sony Ericsson Sync
1From the Home screen, drag upwards.
2Find and tap Sony Ericsson Sync.
3Tap the sync icon for any listed synchronisation
service to start the synchronisation.
PC Companion
PC Companion enables you to access and use additional
features and services connected to your phone, for example
the Media Go™ application, to transfer music, video and
pictures. You can also update your phone to get the latest
software available.
You need one of these operating systems to use the
Media Go™ application:
•Microsoft® Windows 7
•Microsoft® Windows Vista™
•Microsoft® Windows® XP, Service Pack 3 or higher
Connect your phone and computer with a USB cable to
install and use PC Companion.
To install PC Companion
1Connect your phone to a computer using a USB cable.
2Tap Install PC Companion.
3Computer: PC Companion automatically starts on your
computer after a few seconds. Follow the on-screen
instructions to install PC Companion.
To use PC Companion
1Connect your phone to a computer using a USB cable.
2Tap Connect your phone.
28
3Computer: PC Companion automatically starts on your
computer after a few seconds.
To disconnect the USB cable safely
Do not disconnect the USB cable when transferring
content as this may corrupt the content.
1Computer: Make sure that the hardware is safely
removed.
2Disconnect the USB cable.
Computer instructions may vary depending on your
operating system. See the documentation of your
computer's operating system for more information.
Music
You can browse and listen to your music, audio books and
podcasts using the music player.
Use the Media Go™ application on your computer to
transfer content to and from the memory card in your
phone.
To play audio content
1From the Home screen screen, tap . If does not
appear on the Home screen, drag upwards, then find
and tap Music player .
2Tap .
3Tap to browse audio by artist. Tap to use playlists.
Tap to browse audio by track.
4Scroll up or down and browse to a track.
5Tap a track to play it.
29
Music player overview
2
9
3
4
5
6
1
8
7
1 Browse the music on the memory card
2 Infinite button: find related material online
3 Cover art (if available)
4 Go to the previous track in the current play queue,
or rewind
5 Play/Pause button
6 Progress indicator: fast forward or rewind by
dragging or tapping
7 Time remaining of current track
30
8Go to the next track in the current play queue, or fast
forward
9 View the current play queue
To explore related audio content
1In the music player, tap .
2Flick left or right to view results on available online services
(operator-dependent).
3To return to the music player, press .
Camera
You can take a photo or record a video by pressing the
camera key. Before taking a photo, you can improve it by
using the Scenes feature. You can use the flash or the light
when shooting or recording. You can share a photo or a
video with friends, or upload your photos and videos to a
web service. From the viewfinder, you can view an album
containing all photos and videos that you have taken using
the camera.
To activate the camera
•Press the camera key.
To take a photo
1Activate the camera.
2If the still camera is not selected, tap .
3Point the camera towards the subject and press the
camera key halfway down to use auto-focus.
4When the focus frame turns green, press the camera key
fully down. The photo is automatically saved on the
memory card. The photo appears in review mode.
31
5To take another photo, press the camera key.
Web browser
To open the web browser
1From the Home screen, drag upwards.
2Find and tap Browser .
To go to a web page
1Press and tap .
2Tap the text field to activate the keypad.
3Enter a web address.
4Tap Go.
If the screen orientation does not change
automatically when you turn the phone sideways,
mark the Orientation checkbox under Settings >
Sound & display.
Locking and protecting your
phone
IMEI number
Keep a copy of your IMEI (International Mobile Equipment
Identity) number in case your phone is stolen.
To view your IMEI number in the phone
1From the Home screen, drag upwards.
2Find and tap Settings > About phone > Status.
3Scroll to IMEI to view the IMEI number.
32
To change the SIM card PIN
1From the Home screen, drag upwards.
2Find and tap Settings > Security & location > Set up
SIM card lock > Change SIM PIN.
3Enter the old SIM card PIN and tap OK.
4Enter the new SIM card PIN and tap OK.
Updating your phone
You can update your phone to the most recent software for
optimal performance and to get the latest enhancements.
Updates can be downloaded wirelessly directly from your
phone via the Internet by using a 2G/3G mobile data
connection, or by using a Wi-Fi™ network connection. By
connecting your phone to a computer with a USB cable,
you can also download updates from the PC Companion
application.
When you are using a 2G/3G mobile data connection
to connect to Internet from your phone, data
transmission charges may apply. Contact your
network operator for more information.
Make sure you back up and save all data contained in
your phone before you start updating the phone.
To download software updates wirelessly
1From the Home screen, drag upwards.
2Find and tap Settings > About phone > Software
update. Follow the on screen instructions to update your
phone.
33
To download software updates using a USB cable
Do not disconnect the USB cable when updating your
phone as this may corrupt the content. Make sure that
the hardware is safely removed from your computer
when you are finished.
1Connect your phone to a computer using a USB cable. If
it is the first time you start PC Companion you have to
install it before moving on to the next step. Follow the on-
screen instructions in the menu displayed in your phone
to install PC Companion.
2Tap Connect your phone.
3Computer: Wait a few seconds for PC Companion to
start. Click Support Zone > Software Update and follow
the on-screen instructions to update your phone.
While using PC Companion, you will also get
notifications whenever there are available software
updates for your phone.
Troubleshooting
Common questions
My phone is not working as expected
If you experience problems with your phone, check these
tips before you try anything else:
•Restart your phone.
•Remove and re-insert the battery and SIM card. Then
restart your phone.
•Update your phone. Even if you have the latest software,
updating your phone can improve software stability and
34
solve other problems. Updating your phone also ensures
optimal performance and provides the latest
enhancements.
•Reset your phone.
Be patient while resetting your phone. Restarting the
phone while making a reset may damage the phone
permanently.
To force stop an application
•When a popup window tells you that an application is not
responding, tap Force stop.
If you do not want to force stop an application, you
can wait for it to respond by tapping Cancel.
Resetting the phone
Resetting the phone deletes all data, including downloaded
applications, and resets the phone back to its initial state,
the state before you turned on the phone for the first time.
Make sure to back up important data you have on the phone
before you reset the phone.
To reset the phone
1From the Home screen, drag upwards.
2Find and tap Settings > SD card, USB Mass Storage
& phone storage > Factory data reset > Reset
phone.
3Enter your screen unlock pattern.
4Tap Erase everything.
I cannot charge the phone or battery capacity is low
The charger is not properly connected or the battery
connection is poor. Remove the battery and clean the
connectors.
35
The battery is worn out and needs to be replaced. See
Charging the battery on page 9.
No battery charging icon appears when I start
charging the phone
It may take a few minutes before the battery icon appears
on the screen.
I cannot use Internet-based services
Make sure your subscription includes data download, and
that the Internet settings in your phone are correct.
See Internet and messaging settings on page 5 for more
information on how to download or change the Internet
settings. You can also download settings from
www.sonyericsson.com/support.
Error messages
No network coverage
•Your phone is in flight mode. Make sure flight mode is off.
•Your phone is not receiving any network signal, or the
received signal is too weak. Contact your network
operator and make sure that the network has coverage
where you are.
•The SIM card is not working properly. Insert your SIM
card in another phone. If this works, it is probably your
phone that is causing the problem. In this case, contact
the nearest Sony Ericsson service center.
Emergency calls only
You are within range of a network, but you are not allowed
to use it. However, in an emergency, some network
operators allow you to call the international emergency
number 112.
36
SIM card is locked.
You have entered your PIN incorrectly 3 times in a row. To
unlock the phone, you need the PUK provided by your
operator.
SIM card is PUK-locked.
You have entered your PUK (Personal Unblocking Key)
incorrectly 10 times in a row. Please contact your service
provider.
Legal information
Sony Ericsson U20i/U20a
This User guide is published by Sony Ericsson Mobile Communications
AB or its local affiliated company, without any warranty. Improvements
and changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/
or equipment, may be made by Sony Ericsson Mobile Communications
AB at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2010
Publication number: 1237-9737.1
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not limited
to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of any
additional content, please verify that your intended use is properly
licensed or is otherwise authorized. Sony Ericsson does not guarantee
the accuracy, integrity or quality of any additional content or any other
third party content. Under no circumstances will Sony Ericsson be liable
in any way for your improper use of additional content or other third party
content.
This User guide may reference services or applications provided by third
parties. Use of such programming or services may require separate
37
registration with the third party provider and may be subject to additional
terms of use. For applications accessed on or through a third-party
website, please review such websites’ terms of use and applicable
privacy policy in advance. Sony Ericsson does not warrant or guarantee
the availability or performance of any third-party websites or offered
services.
The Liquid Identity logo, Xperia, Timescape and xperiax10minipro are
trademarks or registered trademarks of Sony Ericsson Mobile
Communications AB.
Sony and "make.believe" are trademarks or registered trademarks of
Sony Corporation.
Media Go is a trademark or registered trademark of Sony Electronics Inc.
Google, Google Maps™, Picasa and Android are trademarks or
registered trademarks of Google, Inc.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget
LM Ericsson.
Facebook is a trademark or a registered trademark of Facebook, Inc.
Twitter is a trademark or a registered trademark of Twitter, Inc.
Wi-Fi is a trademark or a registered trademark of the Wi-Fi Alliance.
Microsoft, Windows, Outlook, Windows Vista, Windows Server, Explorer,
Windows Media and ActiveSync are registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
This product is protected by certain intellectual property rights of
Microsoft. Use or distribution of such technology outside of this product
is prohibited without a license from Microsoft.
Other product and company names mentioned herein may be the
trademarks of their respective owners. Any rights not expressly granted
herein are reserved. All other trademarks are property of their respective
owners.
All illustrations are for illustration only and may not accurately depict the
actual phone.
38
www.sonyericsson.com
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1237-9737.1
