Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1212-5714.1
Printed in XXXXX
Stereo Streaming
Bluetooth™ Headset
HBH-IS800
1
2
Red/green indicator
light
Red/green indicator
light
Charger connector
Charger connector
Action key
Action key
White indicator light
White indicator light
Ear plugs
Ear plugs
Microphone
Microphone
S
M
L
Note: Due to electronic components one of the
earplugs can feel a bit warmer than the other.
Note: Due to electronic components one of the
earplugs can feel a bit warmer than the other.
2.5 hours
2.5 hours
First time use: Charge approximately 8 hours.
First time use: Charge approximately 8 hours.
3
4
CLA-60
CST-60/CST-70
CST-61
CLA-61
CDS-60
Microphone close to the
left ear
Microphone close to the
left ear
Red/green indicator light
Turning on and off
Green - Good battery level.
Red - Low battery level.
Normal use
Flashing green - The headset is on.
Flashing red - Low battery.
Pairing
Flashing red/green - Pairing is ongoing.
Charging
Steady red - Charging is ongoing.
Steady green - Charging is ready.
White indicator light
Steady light - A call is ongoing.
Flashing - Pairing is ongoing.
Red/green indicator light
Turning on and off
Green - Good battery level.
Red - Low battery level.
Normal use
Flashing green - The headset is on.
Flashing red - Low battery.
Pairing
Flashing red/green - Pairing is ongoing.
Charging
Steady red - Charging is ongoing.
Steady green - Charging is ready.
White indicator light
Steady light - A call is ongoing.
Flashing - Pairing is ongoing.
English
The Stereo Streaming Bluetooth™ Headset HBH-
IS800 lets you stay in control of your incoming and
outgoing phone calls. You can enjoy stereo audio from
a phone or other Bluetooth device, such as a
computer or a portable music player. During calls, the
music automatically pauses and starts playing again
when the call ends.
For full functionality, your phone or other device
should support the following Bluetooth profiles:
•Bluetooth Handsfree
•Bluetooth Headset
•Bluetooth Advanced Audio/Video Distribution
•Bluetooth Audio/Video Remote Control
Charging
Before using the headset for the first time, charge it
with the supplied charger for 8 hours, according to
picture 2. The headset turns off during charging and
switches on automatically when the charger is
removed.
For compatible chargers, see picture 3.
Pairing the headset
Before you can use the headset it has to be paired
once with your phone. After a successful pairing, the
headset will automatically connect to the phone as
soon as it is turned on and within range.
Note: The headset turns off if you do not pair it with the
phone within 10 minutes.
To pair the headset with the phone
1. Make sure the headset is turned off.
2. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
3. Turn on Bluetooth visibility in the phone. This makes
the phone visible to other Bluetooth devices.
4. Place the phone within 20 cm (8 inches) from the
headset.
5. Press and hold down the action key on the headset
for about 5 seconds until the white indicator light
starts flashing and the red/green indicator light
flashes red and green.
6. Press Yes when Add device? appears in the phone.
If required, the passcode is 0000. The white
indicator light stops flashing and the red/green
indicator light slowly flashes green when
successfully paired.
Note: If auto pairing is not supported by your phone, or
not successful, follow the first 5 steps above. Then pair
the headset with your phone as described in the phone
User guide. The passcode is 0000.
Turning on and off
To turn on the headset
•Press and hold down the action key for some
seconds until the white indicator light turns on.
To turn off the headset
•Press and hold down the action key until for some
seconds the white indicator light disappears.
Adjusting volume
See the phone User guide how to adjust ring volume,
speaker volume and music volume.
Calling
To make a call
•Dial the number using the phone keys. The call is
automatically activated in the headset.
To end a call
•Press the action key briefly.
To answer a call / a second call
•A beep indicates an incoming call. Briefly press the
action key.
To reject a call / a second call
•Press and hold down the action key until you hear a
beep.
To redial the last dialled number
•Double-click the action key.
To switch between two calls
•Press and hold down the action key until you hear a
beep.
Calling using voice commands
Voice commands can be useful when you are using
the headset. For more information on voice
commands, and if your phone supports it, see the
phone User guide.
To make a call using voice commands
•Press and hold the action key until you hear a beep.
Then say the command.
Transferring sound
To transfer the sound from the phone to the
headset
•During a call on the phone, press the action key.
To transfer the sound from the headset to the
phone
See the phone User guide.
Listening to music
To listen to music
•Start the media player in your phone and select to
use the headset.
Briefly press the action key to pause and restart the
music.
To move between tracks
•See the phone User guide.
Resetting the headset
Reset the headset if it behaves unexpectedly.
To reset the handsfree
1. Make sure the headset is turned off.
2. Press and hold down the action key on the headset
for about 5 seconds until the white indicator light
starts flashing and the red/green indicator light
flashes red and green.
3. Press and hold the action key on the head set until
the headset is completely switched off
Note: After resetting the headset must be paired again
before it can be used.
Battery
A battery that has been infrequently used, or a new
one, could have reduced capacity. It may need to be
recharged a number of times.
When the battery level is too low you hear a low
beep. If you do not charge the headset, it
automatically turns off within 10 minutes.
Troubleshooting
No connection to the phone
Make sure the headset is charged and within 10
metres (33 feet) of the phone with no solid objects in
between. Check or redo the Bluetooth settings in the
phone. Try to pair the headset again.
Go to www.sonyericsson.com/learnabout for more
information on Bluetooth and pairing.
Redial does not work
•Make sure the call list in the phone is not empty.
Voice commands do not work
•Make sure your phone supports voice commands.
•Make sure the voice commands are enabled and
recorded in your phone before you start using them.
The music is not played in the headset
•Make sure your phone or other device is paired with
the headset. You may have to restart the media
player and select to use the headset.
•Make sure your phone supports the Bluetooth
Advanced Audio/Video Distribution profile.
The music volume cannot be changed
•Some mobiles do not support remote volume
control. Please check the support website for
downloading the additional software.
The headset is automatically turned off
•The battery level is too low. You hear a low beep
approximately 10 minutes before the headset turns
off. Charge the battery.
•The headset turns off if you do not pair it with the
phone within 10 minutes.
Unexpected behaviour
•Reset the headset.
Note: Removing the label from the head set might void
the warranty.
User guide
English
Language
Language
Language
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause
undesired operation.
Any change or modification not expressly approved by Sony Ericsson
may void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
Declaration of conformity for HBH-IS800
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony Ericsson type DDA-0002019
and in combination with our accessories, to which this declaration
relates is in conformity with the appropriate standards EN 300
328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489-17:V1.2.1 and EN
60950-1:2006 following the provisions of Radio Equipment and
Telecommunication Equipment directive 1999/5/EC.
Lund, July 2008
Jacob Sten, Head of Product Business Unit Accessories
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
Language 2
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1212-5714.1
Printed in XXXXX
Language 3 Language 4
1
2
Red/green indicator
light
Red/green indicator
light
Charger connector
Charger connector
Action key
Action key
White indicator light
White indicator light
Ear plugs
Ear plugs
Microphone
Microphone
S
M
L
Note: Due to electronic components one of the
earplugs can feel a bit warmer than the other.
Note: Due to electronic components one of the
earplugs can feel a bit warmer than the other.
2.5 hours
2.5 hours
First time use: Charge approximately 8 hours.
First time use: Charge approximately 8 hours.
3
4
CLA-60
CST-60/CST-70
CST-61
CLA-61
CDS-60
Microphone close to the
left ear
Microphone close to the
left ear
Red/green indicator light
Turning on and off
Green - Good battery level.
Red - Low battery level.
Normal use
Flashing green - The headset is on.
Flashing red - Low battery.
Pairing
Flashing red/green - Pairing is ongoing.
Charging
Steady red - Charging is ongoing.
Steady green - Charging is ready.
White indicator light
Steady light - A call is ongoing.
Flashing - Pairing is ongoing.
Red/green indicator light
Turning on and off
Green - Good battery level.
Red - Low battery level.
Normal use
Flashing green - The headset is on.
Flashing red - Low battery.
Pairing
Flashing red/green - Pairing is ongoing.
Charging
Steady red - Charging is ongoing.
Steady green - Charging is ready.
White indicator light
Steady light - A call is ongoing.
Flashing - Pairing is ongoing.
Stereo Streaming
Bluetooth™ Headset HBH-IS800
User guide
User guide
User guide
User guide
Sony Ericsson HBH-IS800
This User guide is published by Sony Ericsson Mobile
Communications AB, without any warranty. Improvements and
changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs
and/or equipment, may be made by Sony Ericsson Mobile
Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this User guide. All
rights reserved.
©Sony Ericsson Mobile Communications AB, 2007
Publication number: 1212-5714.1
Some of the services in this User guide are not supported by all
networks. This also applies to the GSM International Emergency
Number 112. Contact your network operator or service provider if you
are in doubt whether you can use a particular service.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by Sony Ericsson is under license.
Sony are trademarks or registered trademarks of Sony Corporation.
The Liquid Identity logo is a trademark or registered trademark of
Sony Ericsson Mobile Communications AB.
Ericsson is a trademark or registered trademark of
Telefonaktiebolaget LM Ericsson.
This product is leadfree and halogenfree.
