Sony DDA-2024 Bluetooth Headset User Manual VH310 Gorkim UG
Sony Mobile Communications Inc Bluetooth Headset VH310 Gorkim UG
Sony >
08 user manual
Draft for Sony Ericsson Internal Use Only
Draft for Sony Ericsson Internal Use Only
Draft for Sony Ericsson Internal Use Only
User guide
English
Language
Language
Language
1
2
Action key
Action key
Indicator light
Indicator light
Charge connector
Charge connector
Ear bud
Ear bud
Earspeaker
Earspeaker
Microphone
Microphone
Ear hook
Ear hook
3
4
5
6
Normal charging: about 2 hours
Normal charging: about 2 hours
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony Ericsson
may void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
Declaration of conformity for VH310
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony Ericsson type DDA-0002024
and in combination with our accessories, to which this declaration
relates is in conformity with the appropriate standards EN 300
328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489-17:V1.3.2 and EN
60950-1:2006 following the provisions of Radio Equipment and
Telecommunication Equipment directive 1999/5/EC.
Lund, May 2009
Jacob Sten, Head of Product Business Unit Accessories
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
We fulfil the R&TTE Directive.
For product support go to www.sonyericsson.com/
support
English
The Bluetooth™ Handsfree VH310 can be connected
to devices with Bluetooth wireless technology that
supports the handsfree or headset profile. This User
guide focuses on use with a Sony Ericsson mobile
phone.
Charging the headset
Before using the VH310 for the first time, you need to
charge it with the supplied charger or your phone
charger, see figure 6. For compatible chargers, see
figure 6.
Charging status
•Red light indicates charging (not ready),
•Green light indicates completed charging (ready).
Turning on and off the headset
To turn on the headset
•Press and hold down the action key (see figure 1)
until the indicator light shows a steady green light.
After 3 seconds, the light turns off and the headset is
on.
To turn off the headset
•Press and hold down the action key until the
indicator light shows a steady green or red light. If
the light is red, the headset needs charging). After 2
seconds, the light turns off and the headset is off.
Pairing the headset
Before you can use the headset it has to be paired
once with your phone.
To pair the headset with your phone
1. Make sure the headset is turned off.
2. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
3. Place the phone within 20 cm (8 inches) of the
headset.
4. Press and hold down the action key until the
indicator light flashes green and red alternately.
5. The first time you turn on the headset it
automatically enters pairing mode.
6. In your phone: Search for and add a new device.
7. The headset passcode is 0000.
To pair the headset with another phone
1. Make sure the headset is turned off.
2. Repeat the instructions for how to pair the headset
with your phone.
Putting on the headset
You can either use the headset with or without the ear
hook.
To put on the headset
•Slide the ear hook behind your right ear and point
the microphone towards your mouth. See figure 3-4.
Calling
When you have paired the headset with your phone,
you can make and receive calls as long as the headset
is turned on.
Solid objects, walls and a greater distance than 5
metres (16.5 feet) can affect the sound quality
negatively.
To make a call
•Use the phone keys to dial the number as normal.
The call is automatically activated in the headset.
To end a call
•Press the action key briefly.
To answer a call
•Press the action key briefly.
To reject a call (not possible with a second
incoming call)
•Press and hold down the action key until you hear a
short beep (after 2 seconds).
To redial the last number
•Double-click the action key.
To answer a second call
•Press the action key briefly. The ongoing call is put
on hold.
To switch between two calls
•Press and hold down the action key until you hear a
beep.
To adjust the speaker volume
•During a call, press a volume key on the phone.
Calling using voice commands
Voice commands can be useful when you are using
the headset and the phone is not close to you. For
more information on voice commands, see your
phone User guide.
To make a call using voice commands
•Press the action key briefly, wait for a beep and say
your command.
Note: Make sure voice commands are enabled and
recorded in your phone before you use them.
Transferring sound
To transfer sound from the phone to the
headset
•During a call, press the action key briefly. The sound
is transferred to the headset.
To transfer sound from the headset to the
phone
•See the phone User guide.
Battery
A new, or infrequently used, battery could have
reduced capacity. It may need to be recharged a
number of times.
When the battery needs charging, the indicator
light flashes red and you hear a low beep. If you do not
charge the headset, it automatically turns off.
To check the battery status
•Press the action key briefly:
•One red flash - the battery needs charging soon.
•One green flash - the battery is half full or fully
charged.
Resetting the headset
To reset the headset
1. Connect briefly to a charger
2. Press and hold down the action key until the
indicator light flashes red and green alternately.
3. Pair the headset.
Language 2
VH310
Gorkim_VH310_UG.book Page 1 Tuesday, April 28, 2009 1:02 PM
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1223-5615.1
Printed in XXXXX
Draft for Sony Ericsson Internal Use Only
1
Action key
Action key
Indicator light
Indicator light
Charger connector
Charger connector
Ear bud
Ear bud
2
3
4
Earspeaker
Earspeaker
Microphone
Microphone
Ear hook
Ear hook
5
6
Normal charging: about 2 hours
Normal charging: about 2 hours
Language 3
The Bluetooth™ Handsfree VH310 can be connected
to devices with Bluetooth wireless technology that
supports the handsfree or headset profile. This User
guide focuses on use with a Sony Ericsson mobile
phone.
Charging the headset
Before using the VH310 for the first time, you need to
charge it with the supplied charger or your phone
charger, see figure 6. For compatible chargers, see
figure 6.
Charging status
•Red light indicates charging (not ready),
•Green light indicates completed charging (ready).
Turning on and off the headset
To turn on the headset
•Press and hold down the action key (see figure 1)
until the indicator light shows a steady green light.
After 3 seconds, the light turns off and the headset is
on.
To turn off the headset
•Press and hold down the action key until the
indicator light shows a steady green or red light. If
the light is red, the headset needs charging). After 2
seconds, the light turns off and the headset is off.
Pairing the headset
Before you can use the headset it has to be paired
once with your phone.
To pair the headset with your phone
1. Make sure the headset is turned off.
2. Turn on the Bluetooth function in the phone. For
instructions, see the phone User guide.
3. Place the phone within 20 cm (8 inches) of the
headset.
4. Press and hold down the action key until the
indicator light flashes green and red alternately.
5. The first time you turn on the headset it
automatically enters pairing mode.
6. In your phone: Search for and add a new device.
7. The headset passcode is 0000.
To pair the headset with another phone
1. Turn off the headset if it is turned on.
2. Repeat the instructions for how to pair the headset
with your phone.
Putting on the headset
You can either use the headset with or without the ear
hook.
To put on the headset
•Slide the ear hook behind your right ear and point
the microphone towards your mouth. See figure 3-4.
Calling
When you have paired the headset with your phone,
you can make and receive calls as long as the headset
is turned on.
Solid objects, walls and a greater distance than 5
metres (16.5 feet) can affect the sound quality
negatively.
To make a call
•Use the phone keys to dial the number as normal.
The call is automatically activated in the headset.
To end a call
•Press the action key briefly.
To answer a call
•Press the action key briefly.
To reject a call (not possible with a second
incoming call)
•Press and hold down the action key until you hear a
short beep (after 2 seconds).
To redial the last number
•Double-click the action key.
To answer a second call
•Press the action key briefly. The ongoing call is put
on hold.
To switch between two calls
•Press and hold down the action key until you hear a
beep.
To adjust the speaker volume
•During a call, press a volume key on the phone.
Calling using voice commands
Voice commands can be useful when you are using
the headset and the phone is not close to you. For
more information on voice commands, see your
phone User guide.
To make a call using voice commands
•Press the action key briefly, wait for a beep and say
your command.
Note: Make sure voice commands are enabled and
recorded in your phone before you use them.
Transferring sound
To transfer sound from the phone to the
headset
•During a call, press the action key briefly. The sound
is transferred to the headset.
To transfer sound from the headset to the
phone
•See the phone User guide.
Battery
A new, or infrequently used, battery could have
reduced capacity. It may need to be recharged a
number of times.
When the battery needs charging, the indicator
light flashes red and you hear a low beep. If you do not
charge the headset, it automatically turns off.
To check the battery status
•Press the action key briefly:
•One red flash - the battery needs charging soon.
•One green flash - the battery is half full or fully
charged.
Resetting the headset
To reset the headset
1. Connect briefly to a charger
2. Press and hold down the action key until the
indicator light flashes red and green alternately.
3. Pair the headset.
Language 4Bluetooth™ Headset VH310
User guide
User guide
User guide
User guide
Sony Ericsson VH310
This User guide is published by Sony Ericsson Mobile
Communications AB, without any warranty. Improvements and
changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs
and/or equipment, may be made by Sony Ericsson Mobile
Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this User guide. All
rights reserved.
©Sony Ericsson Mobile Communications AB, 2009
Publication number: 1223-5615.1
Some of the services in this User guide are not supported by all
networks. This also applies to the GSM International Emergency
Number 112. Contact your network operator or service provider if you
are in doubt whether you can use a particular service.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by Sony Ericsson is under license.
Ericsson is a trademark or registered trademark of
Telefonaktiebolaget LM Ericsson.
For product support go to www.sonyericsson.com/
support
Gorkim_VH310_UG.book Page 1 Tuesday, April 28, 2009 1:02 PM
