08 user manual short
User guide
Aino™
Important information
Please read the Important information before you use
your mobile phone.
Experience more. Discover
how.
Fill it with pop and let it rock. Share your life in pictures. Or
why not go online for the latest updates? Your new phone is
the key to a wider world. And it's just around the corner.
Get started with this User guide. And join us online to get the
full picture. Music, games, apps, updates, downloads,
support and more. All in one place:
www.sonyericsson.com/Aino
Don't forget to update your phone software. See
Updating your phone on page 30.
User guide in the phone
An extended User guide is available in your phone.
To access the User guide in your phone
•Select Menu > Settings > User help > User guide.
Touch instructions
Instructions highlighted by a grey line refer to touch screen
functions only.
2
Phone overview
1 Ear speaker
1
2
3
4
5
6
7
8
9
10
2 Screen
3 Selection keys
4 Call key
5 Activity menu key
6 Navigation key
7 C key (Clear)
8 Volume key
9 End key, On/off key
10 Camera key/shutter key
3
11 Screen lock key
11
12
13
14
15
16
17
12 Flash light
13 Camera lens
14 Memory card slot
(under the cover)
15 Connector for
charger, handsfree
and USB cable
16 Phone antenna
17 Loudspeaker
4
Getting started
To insert the SIM card
1Remove the battery cover.
2Slide the SIM card into its holder with the gold-coloured
contacts facing down.
5
To insert the battery
1Insert the battery with the label side up and the
connectors facing each other.
2Attach the battery cover.
6
Turning on the phone
To turn on the phone
1Press and hold down .
2Enter your SIM card PIN (Personal Identification Number),
if requested, and select OK.
3Select a language.
4Follow the instructions that appear.
If you want to correct a mistake when you enter your
PIN, press .
Help
In addition to this User guide, Feature guides and more
information are available at
www.sonyericsson.com/support.
There are also help functions in your phone. See the
following instructions on how to access them.
7
To view tips and tricks
•Select Menu > Settings > User help > Tips and tricks.
To view information about functions
•Scroll to a function and select Info, if available. In some
cases, Info appears under Options.
To view the phone status
•Press the volume key. Phone, memory and battery
information is shown.
Supported services and features
Some of the services and features described in this
User guide are not supported by all networks and/or
service providers in all areas. Without limitation, this
applies to the GSM International Emergency Number
112. Please contact your network operator or service
provider to determine availability of any specific
service or feature and whether additional access or
usage fees apply.
Charging the battery
The phone battery is partly charged when you buy it.
Maximising battery performance
•Charge your phone often. The battery lasts longer if you
charge it frequently.
•If you are in an area with no coverage, your phone
repeatedly scans for available networks. This consumes
power. If you cannot move to an area with better
coverage, turn off your phone temporarily.
8
•Turn off 3G, Bluetooth™ wireless technology and Wi-
Fi™ when you do not need these functions.
•Do not cover the phone antenna when you are engaged
in a call.
Go to
www.sonyericsson.com/support
to learn more
about how to maximise your battery's performance.
Touch functionality
Your phone has touch functionality which is activated when
the phone is closed.
Navigating the touch screen
Tap
Touch to select or activate an item on
the screen.
Drag
Touch, hold and move an item from
one place on the screen to another.
Flick
Touch and move your finger quickly
left, right, up or down, respectively.
Touch and hold
Touch and let your finger remain on
the item to activate it or to have an
options menu appear.
9
Using touch functionality
To activate the screen
•Press on top of the phone.
To unlock the screen
•Drag to the top of the screen.
To lock the touch functionality
•Press on the top of the phone.
Media browser overview
1 2 3 4 5
1 Camera
2 Photo
3 Music
4 Video
5 Radio
To navigate your media browser
1Unlock the screen.
2Tap one of the items.
3To go back, tap on the top part of the screen, or .
10
Navigation
To access the main menu
•When Menu appears on the screen, press the centre
selection key to select Menu.
•If Menu does not appear on the screen, press , and
then press the centre selection key to select Menu.
To navigate the phone menus
•Press the navigation key upwards, downwards, left or
right to move through the menus.
To end a function
•Press .
To return to standby
•Press .
11
To delete items
•Press to delete items such as numbers, letters,
pictures and sounds.
Activity menu
The activity menu gives you quick access to:
•New events – missed calls and new messages.
•Running apps – applications that are running in the
background.
•My shortcuts – add your favourite functions to access
them quickly.
•Internet – connect conveniently to the Internet.
To open the activity menu
•Press .
Memory card
You may have to purchase a memory card separately.
Your phone supports a microSD™ memory card, adding
more storage space to your phone. This type of card can
also be used as a portable memory card with other
compatible devices.
You can move content between a memory card and the
phone memory.
12
To insert a memory card
•Remove the battery cover and insert the memory card
with the gold-coloured contacts facing down.
Entering text
You can use multitap text input or Quick text input to
enter text. The Quick text input method uses a dictionary
application in your phone.
To change the writing language
•When you enter text, press and hold down .
To change the text input method
•When you enter text, press and hold down .
13
To shift between upper- and lower-case letters or numbers
•When you enter text, press .
To enter numbers
1When you enter text, press until appears at the
top of the screen.
2To enter a number, press – .
To enter a number from text input mode, you can
press and hold down – .
To enter punctuation marks and symbols
1When you enter text, press briefly.
2Scroll to a symbol and select Insert.
To select from the most commonly used punctuation
marks, you can also press .
To enter text using Quick text input
1Select, for example, Menu > Messaging > Write new >
Message.
2If is not displayed, press and hold down to
change to Quick text input.
3Press each key only once, even if the letter you want is
not the first letter on the key. For example, to write the
word “Jane”, press , , , . Write the
whole word before looking at the suggestions.
4To view word suggestions, press or press the
navigation key downwards.
5Press to accept a suggestion and add a space.
To enter text using the multitap method
1Select, for example, Menu > Messaging > Write new >
Message.
14
2If is displayed, press and hold down to change
to multitap text input.
3Press – repeatedly until the desired letter
appears.
4Press to add a space.
To add words to the phone dictionary
1When you enter text using Quick text input, select
Options > Spell word.
2Write the word using multitap input and select Save.
Calling
You need to turn on your phone and be within range of a
network.
Answering calls
You can answer calls without opening the phone.
To answer a call when screen lock is on
•Drag from left to right.
To answer a call when screen lock is off
•Tap .
15
To reject a call when screen lock is on
•Drag to the right and then to the left.
To reject a call when screen lock is off
•Tap .
To mute the microphone during a call
•Tap .
To turn on a loudspeaker during a call
•Tap .
Do not hold your phone to your ear when using the
loudspeaker. This could damage your hearing.
16
To turn off the ringtone before answering a call when screen
lock is on
•Drag to the right.
To turn off the ringtone before answering a call when screen
lock is off
•Tap .
To end a call
•Tap .
Making and answering calls
To make a call
1Enter a phone number (with international country code
and area code, if applicable).
2Press .
You can call numbers from your contacts and call list.
17
To make international calls
1Press and hold down until a “+” sign appears.
2Enter the country code, area code (without the first zero)
and phone number.
3Press .
To answer a call
•Press .
To change the ear speaker volume during a call
•Press the volume key up or down.
Emergency calls
Your phone supports international emergency numbers, for
example, 112 or 911. You can normally use these numbers
to make emergency calls in any country, with or without the
SIM card inserted, if you are within range of a network.
In some countries, other emergency numbers may also
be promoted. Your network operator may therefore
have saved additional local emergency numbers on the
SIM card.
To make an emergency call
•Enter 112 (the international emergency number) and
press .
To view your local emergency numbers
1Select Menu > Contacts.
2Scroll to New contact and select Options > Special
numbers > Emergency numbers.
Call list
You can view information about answered , dialled
and missed or rejected calls.
18
To call a number from the call list
1Press and scroll to a tab.
2Scroll to a name or a number and press .
Contacts
You can save names, phone numbers and personal
information in Contacts. Information can be saved in the
phone memory or on the SIM card.
You can synchronise your contacts using the
Sony Ericsson PC Suite.
To add a phone contact
1Select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Scroll to New number: and select Add.
5Enter the number and select OK.
6Select a number option.
7Scroll between the tabs and add information to the fields.
8Select Save.
To call with Smart search
1Press – to enter a sequence of (at least two)
digits. All entries which match the sequence of digits or
corresponding letters are shown in a list.
2Scroll to a contact or a phone number and press .
19
Stereo Streaming Bluetooth™
Headset MH100
1 Microphone
2
4
5
6
3
8
7
1
2 Call key
3 Earpiece connector
4 Volume touch area
5 On/off key
6 Charger connector
7 Next/Play-Pause/Previous
keys
8 Music/battery/status light
indicators
If you are using a headset other than the MH100, go to
www.sonyericsson.com/support
for more information.
20
To adjust speaker or music volume
•During a call, or when listening to music or the FM radio,
swipe your finger along the volume touch area.
Listening to music
To listen to music
1Press to start the media player in your phone.
2To start and pause the music, press on the
headset.
To move between tracks
•When you listen to music, press or .
To move within a track
•Press and hold or until you reach the desired
position.
Listening to the Radio
1Make sure your headset has a connection to the phone.
2Start the radio in your phone.
To search for channels manually
•Press and hold or until you reach the desired
position.
To select a preset radio station
•Press or .
Imaging
The phone must be closed before you can use the camera.
You can take photos and record videos to view, save or
send. When the phone is closed, you can find saved photos
and videos in or . When the phone is open, you can
21
find saved photos and videos in Media and in File
manager. Use Media Go™ to transfer content to and from
your phone. For more information, see Transferring content
to and from a computer on page 28.
To activate the camera
•Tap .
Using the still camera
To take a photo by tapping the screen
1Activate the camera.
2If the still camera is not selected, tap .
3Tap .
4Tap a spot in the viewfinder where you want the focus to
be. The photo is taken as soon as focus is set. The photo
is automatically saved.
5To return to the viewfinder and to take another photo,
press .
To use zoom
•Press the volume key.
Using the video camera
To record a video by tapping the screen
1Activate the camera.
2If the video camera is not selected, tap .
3Tap .
4To start recording, tap the screen.
5To pause the recording, tap . To continue recording,
tap .
6To stop recording, tap . The video is saved
automatically.
22
7To return to the viewfinder and to record another video,
tap .
Working with photos
You can view, enhance and organise photos and videos on
your computer by installing the Adobe™ Photoshop™
Album Starter Edition. It is available for download at
www.sonyericsson.com/support.
Use Media Go™ to transfer content to and from your phone.
Using photos
You can add a photo to a contact, use the photo during
phone startup, as a wallpaper in standby, or as a screen
saver.
To use photos
1Select Menu > Media > Photo > Camera album.
2Select a month.
3Scroll to a photo and select View.
4Select Options > Use as.
5Select an option.
Music
You can listen to music, audio books and podcasts. Use
Media Go™ to transfer content to and from your phone. For
more information, see Transferring content to and from a
computer on page 28.
Accessing music in your phone
When the phone is closed, you can browse and play music
using the music player in the media browser. More music
23
features are available in Media and File manager, which
you can access when the phone is open.
To browse music
1Tap .
2Tap a category.
3Flick left or right to browse through your music.
4Tap an album or a playlist to view its content.
5To go back, tap outside the list and then tap the top part
of the screen.
To play music
1Tap .
2Tap a category.
3Flick left or right to browse through your music.
4Tap an album or a playlist.
5To play a track, tap the title.
To pause the music
•Tap .
To fast forward and rewind music
•Touch and hold or .
You can also drag right or left to fast forward or
rewind.
To move between tracks
•Tap or .
To view the current play queue
•Tap the album art.
To minimise the music player
•Tap .
24
To return to the music player
•Tap in the lower part of the screen.
Using the music mini player
You can use the music mini player for quick access to music
controls when the screen lock is on.
To activate the music mini player
1To view the screen, press on top of the phone.
2Tap the status bar at the bottom of the screen.
Radio
Do not use your phone as a radio in places where this
is prohibited.
To turn on the radio
1Connect a handsfree to the phone.
2When the phone is closed, unlock the screen.
3Tap .
Transferring and handling
content
You can transfer and handle content such as pictures and
music.
You are not allowed to exchange some copyright-
protected material. identifies a protected item.
Handling content in the phone
You can use File manager in your phone, to handle content
saved in the phone memory or on a memory card. Tabs and
25
icons in File manager show where the content is saved. If
the memory is full, delete some content to create space.
To select more than one item in a folder
1Select Menu > Organiser > File manager.
2Scroll to a folder and select Open.
3Select Options > Mark > Mark several.
4For each item you want to mark, scroll to the item and
select Mark.
To move items between the phone memory and the
memory card
1Select Menu > Organiser > File manager.
2Find an item and select Options > Manage file >
Move.
3Select Memory card or Phone.
4Scroll to a folder and select Open.
5Select Paste.
Sending content to another phone
You can send content, for example, in messages or using
Bluetooth wireless technology.
To send content
1Scroll to an item and select Options > Send.
2Select a transfer method.
Make sure the receiving device supports the transfer
method you select.
26
Using a USB cable
You can connect your phone to a computer with a USB
cable. If you are using a PC, you are asked to install PC
Companion the first time you connect.
You may have to purchase a USB cable separately.
Only use a USB cable supported by your phone.
To disconnect the USB cable safely
Do not disconnect the USB cable when transferring
content as this may corrupt the content.
1Computer: Right-click the Safely Remove Hardware icon
in Microsoft® Windows® Explorer.
2Select the drives you want to disconnect. Select Stop.
3Wait until you are notified that it is safe to remove the
drive. Disconnect the USB cable.
PC Companion
PC Companion lets you:
•Explore content in your phone.
•Use your phone as a modem.
•Install PC Software used to synchronise, transfer and
back up phone content.
For more information, go to
www.sonyericsson.com/support to read Feature guides.
To download Mac® compatible software, go to
www.sonyericsson.com/support.
To install PC Companion
1Connect your phone to a PC using a USB cable
supported by your phone.
2Computer: Follow the instructions.
27
Dragging and dropping content
You can drag and drop content between your phone, a
memory card and a computer in Microsoft Windows
Explorer.
To drag and drop content
1Connect your phone to a computer using a USB cable.
2Computer: Wait until the phone memory and memory
card appear as external disks in Microsoft® Windows®
Explorer.
3Drag and drop selected files between the phone and the
computer.
Required operating systems
You need one of these operating systems to use Sony
Ericsson PC software:
•Microsoft® Windows Vista™
•Microsoft® Windows® XP, Service Pack 2 or higher
Transferring content to and from a
computer
You can use Media Go™ to transfer media content between
your phone and a computer. Media Go™ is available for
download through PC Companion or from
www.sonyericsson.com/support.
To download Mac® compatible software, go to
www.sonyericsson.com/support.
To transfer content using Media Go™
1Connect the phone to a computer with a USB cable
supported by your phone.
2Computer: Select Start/Programs/Sony/Media Go™.
28
3Select Transfer to or from Device using Media Go™ and
click OK.
4Wait until the phone appears in Media Go™.
5Move files between your phone and the computer in
Media Go™.
Backing up and restoring
You can back up and restore contacts, the calendar, tasks,
notes and bookmarks using the Sony Ericsson PC Suite.
Before backing up and restoring, you need to install the
Sony Ericsson PC Suite, which is available through PC
Companion or from www.sonyericsson.com/support.
You can back up and restore contacts in your phone using
a memory card. You can move content between the
memory card and the phone memory. See Handling
content in the phone on page 25.
Back up your phone content regularly to make sure
you do not lose it.
To make a backup using the Sony Ericsson PC Suite
1Computer: Start the Sony Ericsson PC Suite from Start/
Programs/Sony Ericsson/Sony Ericsson PC Suite.
2Follow the instructions in the Sony Ericsson PC Suite on
how to connect.
3Go to the backup and restore section in the
Sony Ericsson PC Suite and make a backup of your
phone content.
29
Updating your phone
You can update your phone to the most recent software for
optimal performance and to get the latest enhancements.
You need a USB cable and an Internet-connected PC.
To learn how, go to
www.sonyericsson.com/update
.
Remember to back up your phone content before
updating. See Backing up and restoring on page 29.
Internet
If you cannot use the Internet, see I cannot use Internet-
based services on page 33.
To start browsing
1Select Search.
2Enter a web address, a search phrase or the name of a
bookmark.
3Scroll to an item in the list and select Go to or Search.
To exit the browser
1When you are browsing the web, select and then
select .
2Select Exit browser.
30
PIN codes
SIM protection
This lock only protects your subscription. Your phone will
work with a new SIM card. If the lock is on, you have to enter
a PIN (Personal Identity Number).
If you enter your PIN incorrectly three times in a row, the SIM
card is blocked and you need to enter your PUK (Personal
Unblocking Key). Your PIN and PUK are supplied by your
network operator.
To unblock the SIM card
1When PIN blocked appears, enter your PUK and select
OK.
2Enter a new four-to-eight-digit PIN and select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1Select Menu > Settings > General > PIN codes > SIM
protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four-to-eight-digit PIN and select OK.
4Re-enter the new PIN and select OK.
If Codes do not match appears, you entered the new
PIN incorrectly. If Incorrect PIN appears, you entered
the old PIN incorrectly.
Flight mode
In Flight mode the network and radio transceivers are
turned off to prevent disturbance to sensitive equipment.
31
When the flight mode menu is activated you are asked to
select a mode the next time you turn on your phone:
•Normal mode – full functionality
•Flight mode – limited functionality
To activate the flight mode menu
•Select Menu > Settings > General > Flight mode >
Continue > Show at startup.
To select flight mode
1When the flight mode menu is activated, turn off your
phone.
2Turn on your phone and select Flight mode.
appears.
Troubleshooting
Some problems can be fixed using Update Service. Using
Update Service on a regular basis will optimise the phone’s
performance. See Updating your phone on page 30.
Some problems will require you to call your network
operator.
For more support go to www.sonyericsson.com/support.
Common questions
I have problems with memory capacity or the phone
is working slowly
Restart your phone every day to free memory or do a
Master reset.
32
Master reset
If you select Reset settings, the changes that you have
made to settings will be deleted.
If you select Reset all, your settings and content, such as
contacts, messages, pictures, sounds and downloaded
games, will be deleted. You may also lose content that was
in the phone at purchase.
To reset the phone
1Select Menu > Settings > General > Master reset.
2Select an option.
3Follow the instructions that appear.
I cannot charge the phone or battery capacity is low
The charger is not properly connected or the battery
connection is poor. Remove the battery and clean the
connectors.
The battery is worn out and needs to be replaced. See
Charging the battery on page 8.
No battery icon appears when I start charging the
phone
It may take a few minutes before the battery icon appears
on the screen.
Some menu options appear in grey
A service is not activated. Contact your network operator.
I cannot use Internet-based services
Your subscription does not include data capability. Settings
are missing or incorrect.
You can download settings using the Settings download
or from www.sonyericsson.com/support.
33
To download settings
1Select Menu > Settings > User help > Settings
download.
2Follow the instructions that appear.
Contact your network operator or service provider for
more information.
I cannot send messages from my phone
To send messages, you need to set a service centre
number. The number is supplied by your service provider
and is usually saved on the SIM card. If the number of your
service centre is not saved on your SIM card, you must enter
the number yourself.
To send most picture messages, you must set an MMS
(Multimedia Messaging Service) profile and the address of
your message server. If no MMS profile or message server
exists, you can receive all the settings automatically from
your network operator, download settings using the
Settings download, or go
towww.sonyericsson.com/support.
To enter a service centre number
1Select Menu > Settings > Connectivity > Message
settings > Text message and scroll to Service centre.
The number is shown if it is saved on the SIM card.
2If there is no number shown, select Edit.
3Scroll to New service centre and select Add.
4Enter the number, including the international “+” sign and
country code.
5Select Save.
34
To select an MMS profile
1Select Menu > Settings > Connectivity > Message
settings > Multim. message.
2Select an existing profile or create a new one.
To set the message server address
1Select Menu > Settings > Connectivity > Message
settings > Multim. message.
2Scroll to a profile and select Options > Edit.
3Scroll to Message server and select Edit.
4Enter the address and select OK > Save.
I cannot synchronise or transfer content between
my phone and the computer, when using a USB
cable.
The software or the USB drivers have not been properly
installed. Go to www.sonyericsson.com/support to read
Feature guides which contain detailed installation
instructions and troubleshooting sections.
Error messages
Insert SIM
There is no SIM card in your phone or you may have inserted
it incorrectly.
See To insert the SIM card on page 5.
The SIM card connectors need cleaning. If the card is
damaged, contact your network operator.
Insert correct SIM card
Your phone is set to work only with certain SIM cards.
Check if you are using the correct operator SIM card.
35
Incorrect PIN/Incorrect PIN2
You have entered your PIN or PIN2 incorrectly.
Enter the correct PIN or PIN2 and select OK.
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2 code incorrectly three
times in a row.
To unblock, see SIM protection on page 31.
No netw. coverage
•Your phone is in flight mode. See Flight mode on
page 31.
•Your phone is not receiving any network signal, or the
received signal is too weak. Contact your network
operator and make sure that the network has coverage
where you are.
•The SIM card is not working properly. Insert your SIM
card in another phone. If this works, it is probably your
phone that is causing the problem. Please contact the
nearest Sony Ericsson service location.
Emergency calls only
You are within range of a network, but you are not allowed
to use it. However, in an emergency, some network
operators allow you to call the international emergency
number 112. See Emergency calls on page 18.
Legal information
Sony Ericsson U10i/U10a/U10 - MH100
This User guide is published by Sony Ericsson Mobile Communications
AB or its local affiliated company, without any warranty. Improvements
and changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/
36
or equipment, may be made by Sony Ericsson Mobile Communications
AB at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2009
Publication number: 1226-9533.1
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not limited
to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of any
additional content, please verify that your intended use is properly
licensed or is otherwise authorized. Sony Ericsson does not guarantee
the accuracy, integrity or quality of any additional content or any other
third party content. Under no circumstances will Sony Ericsson be liable
in any way for your improper use of additional content or other third party
content.
Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc.
and any use of such mark by Sony Ericsson is under license.
The Liquid Identity logo and Aino are trademarks or registered
trademarks of Sony Ericsson Mobile Communications AB.
Sony is a trademark or registered trademark of Sony Corporation.
Media Go is a trademark or registered trademark of Sony Media Software
and Services.
microSD is a trademark or a registered trademark of SanDisk
Corporation.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget
LM Ericsson.
Adobe Photoshop Album Starter Edition is a trademark or registered
trademark of Adobe Systems Incorporated in the United States and/or
other countries.
Mac is a trademark of Apple Inc., registered in the U.S. and other
countries.
Microsoft, Windows, Outlook, Windows Vista, Windows Server and
ActiveSync are registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
37
This product is protected by certain intellectual property rights of
Microsoft. Use or distribution of such technology outside of this product
is prohibited without a license from Microsoft.
Other product and company names mentioned herein may be the
trademarks of their respective owners.
Any rights not expressly granted herein are reserved.
All illustrations are for illustration only and may not accurately depict the
actual phone.
38
www.sonyericsson.com
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
1226-9533.1
FCC Statement
Declaration of Conformity
Sony Ericsson MH100
3
FCC Statement
This device complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
Any change or modification not expressly approved by
Sony Ericsson may void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
4
Declaration of Conformity for MH100
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
S-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony Ericsson type DDA-0002025
and in combination with our accessories, to which this declaration
relates is in conformity with the appropriate standards
EN 300 328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489-17:V1.3.2
and EN 60950-1:2006 following the provisions of Radio Equipment
and Telecommunication Equipment directive 1999/5/EC.
Lund, June 2009
Place & date of issue
Jacob Sten,
Head of Product Business Unit Accessories
We fulfil the requirements of the R&TTE Directive (1999/5/EC).
pçåó=bêáÅëëçå=jçÄáäÉ=`çããìåáÅ~íáçåë=^_
pbJOON=UU=iìåÇI=pïÉÇÉå
ïïïKëçåóÉêáÅëëçåKÅçã
NOOTJMUSMKN
mêáåíÉÇ=áå=`çìåíêó
